SureCall Fusion2Go 3.0, Fusion2Go 3.0 CA User Manual

Fusion2Go™ 3.0

Vehicle Voice and 4G Data Signal Booster

User Guide

SureCall | www.surecall.com | 1-888-365-6283 | [e-mail]

Table of Contents

2

Thank you for purchasing SureCall’s Fusion2Go 3.0 cell phone signal booster kit. Fusion2Go 3.0

provides enhanced voice, text and 4G data signal for any vehicle.

If you have any questions during setup, please reach out to our US-based experienced support

technicians:

• Call: 1-888-365-6283

• Email: [e-mail]

How It Works ................................................................................................................................. 3

Package Contents ......................................................................................................................... 4

Step 1: Mount Outside Antenna..................................................................................................... 5

Step 2. Install the Inside Patch Antenna ........................................................................................ 5

Step 3. Place Booster and Connect Cables ................................................................................. 6

Step 4. Connect Power.................................................................................................................. 7

LED Indicators .............................................................................................................................. 8

Troubleshooting ............................................................................................................................. 8

Specications ................................................................................................................................ 9

Antenna Kitting Information ......................................................................................................... 10

Safety Information ....................................................................................................................... 12

Three-Year Product Warranty ...................................................................................................... 13

SureCall | www.surecall.com | 1-888-365-6283 | [e-mail]

3

How It Works

The SureCall Fusion2Go 3.0 is a high-quality bidirectional booster that enhances cellular signals for

vehicles.

The Fusion2Go 3.0 works with two antennas:

• An inside antenna that communicates with your cell phone.

• An outside antenna that communicates with the cell tower.

Signals sent from a cell tower are received by the outside antenna, amplied by the booster and

then sent to your cell phone via the inside antenna. When your phone transmits, the signal is sent to

the inside antenna, and then sent to the cell tower via the outside antenna.

How It Works

Outside Magnetic

Antenna

Power Adapter

Inside Antenna

Fusion2Go

SureCall | www.surecall.com | 1-888-365-6283 | [e-mail]

4

Package Contents

Package Contents

1. Unpack all package contents. For missing or damaged items, contact your reseller.

2. Turn over the signal booster and record the model and serial number for reference:

Serial #:

Purchase Date:

3. Keep the carton and packing material to store the product in case you need to return it.

Your Fusion2Go 3.0 signal booster package includes the following items:

• One SureCall Fusion2Go 3.0 signal booster

• DC power adapter

• One inside patch antenna

• One outside magnetic mount antenna

Fusion2Go 3.0

Amplier

Inside Patch

Antenna

Power Adapter Outside Magnetic-

Mount Antenna

One free

magnetic

vent clip

SureCall | www.surecall.com | 1-888-365-6283 | [e-mail]

5

Step 1: Mount Outside Antenna

Place the magnetic-mount antenna on the top of your vehicle, preferably toward the back, maximiz-

ing the distance from planned location of the inside patch antenna. Ensure that the antenna has at

least a 12-inch radius clear of obstructions and other radiating elements, such as a radio antenna.

Next, run the cable from the outside antenna across the car’s roof and into the car. To hide and pro-

tect the antenna cable, carefully pull down the door seal, run cable underneath it and push the seal

back into place. Run the cable to the inside of the vehicle near the planned location of the booster

(under the seat of the vehicle, or in the front or middle console).

Note: The outside antenna must not be collocated or operating with any other antenna or booster.

Step 2. Install the Inside Patch Antenna

Identify a location for the inside antenna on or near your front dashboard that is

1. Within 2-3 feet of the typical cell phone location

2. At least 8 inches (20cm) from cellular devices and

3. At least 4 inches (10cm) from metal

Next, peel Velcro backing and apply to a clean dry surface

in your chosen location.

Or try this - Use the free vent clip provided with your
product as a mounting surface then simply clip to an
air vent.

Installation
