VENTILATOR USER GUIDE MODEL 724WT

2
VentilatorUserGuide-724WT.doc REV. 09/23/02

This manual covers the description, cautions, operation and maintenance of the Super Vac Hydraulic Positive Pressure Ventilator

Model 724WT

Please take the time to read this manual before operating the ventilator.

Save this guide for future reference.

CONTENTS

1. BREAKAGE OR DAMAGE DURING SHIPMENT.........................................................................................................................................................3

2. GENERAL DESCRIPTION AND SPECIFICATIONS .....................................................................................................................................................4

3. PRODUCT SAFETY PRECAUTIONS...........................................................................................................................................................................5

4. BEFORE OPERATING VENTILATOR ........................................................................................................................................................................5

5. OPERATION ...........................................................................................................................................................................................................6

6. PARTS LIST.............................................................................................................................................................................................................8

7. EXPLODED VIEW DRAWING...................................................................................................................................................................................9

8. WARRANTY ..........................................................................................................................................................................................................10

9. CONTACT INFORMATION ....................................................................................................................................................................................11

3

VentilatorUserGuide-724WT.doc Last printed 9/23/2002 12:48 PM

1. Breakage or Damage During Shipment

The transportation company is fully responsible for all shipping damage and will resolve problems
promptly if you handle it correctly. Please read these instructions carefully.

Examine the contents of all shipping cases. If you find any damage, call your transportation agent at once
and have them make a description on the freight or express bill describing the damage and the number of
pieces. Then write us and we will send you the original bill of lading. Get a claim blank from the express
or truck company. Fill the claim form out. Attach the claim blank to the original bill of lading together
with a copy of our invoice. Attach a memo on which you show the value of the damaged goods. Mail or
hand these papers to your local transportation agent. They will process your claim with reasonable
promptness.

Please note, we cannot and will not enter claims for damages. If we filed claim here, it would be sent to
your local freight agent for verification and investigation. This time can be saved by your filing the claim
directly. Every consignee is on the ground floor and in contact with the local agent who inspects the
damaged goods, and thus, each claim can be given individual attention.

Since our goods are packed to comply with the regulations of all railroad, truck, and express companies,
we cannot allow deduction from any invoice because of any damage, however, be sure to file your claim
promptly. Our goods are sold F.O.B. factory. We take receipt from the transportation company certifying
that the goods were delivered to them in good order, and our responsibility ceases.

It is seldom that any breakage or damage occurs in any of our shipments, and in no case will the customer
be out any expense if they follow the above instructions.

Be sure to keep all damaged goods subject to examination of the truck or express company inspector, who
may call on you some time later. These damaged goods, of course, will belong to them, and they will
inform you what to do with them. If you dispose of these damaged goods, your claim may not be paid.

4
VentilatorUserGuide-724WT.doc REV. 09/23/02

2. General Description and Specifications

Super Vac ventilators are specifically designed to provide a convenient and portable source of air. Super
Vac positive pressure ventilators are tested to AMCA PPV Standard 240-95, for use in extreme conditions.

Specifications1

Model# Engine HP Height x Width x Depth Weight (lbs.)

724WT POK 12 21” X 28” X 27.5” 110

1

Specifications are subject to change without notification. Refer to model decal affixed to

ventilator to determine actual specifications.

This ventilator is designed for high powered air movement. Super Vac’s propeller produces a greater

intake of air and eliminates turbulence at the tips. Each blade is statically balanced for high efficiency and
long life.

This document is designed to function as a quick start guide and not an in-depth comprehensive
instructional manual. Please read all accompanying documents shipped with your ventilator. Due to the
many features of powered equipment thorough familiarity with the operating controls is essential to assure
safe and trouble free operation.
