USER GUIDE

Adult assembly required

Read User Guide before assembling

Please keep this guide for further reference

Your Warranty

Tel: [phone] | www.supertramp.co.uk | [e-mail]

IMPORTANT

Please keep your proof of purchase ­it will be needed if you wish to make a claim.

For more information, please call our office on the number provided below.

PLEASE NOTE THE FOLLOWING:

 Domestic trampolines purchased for use commercially will not be covered by guarantee. All trampolines

used in-ground will be covered by the warranty levels outlined above, except for the frame pads which will
be covered for 12 months only.

 Using your trampoline on concrete ground without rubber feet or mats will invalidate any guarantee on the

frame.

 Jet Sports reserve the right to revoke any form of guarantee in circumstances where they believe there to

be evidence of misuse.

RECOMMENDATION:

We recommend that all 2-string performance beds
are refurbished every 2-5 years.

Silver Level Warranty

Frame – 10 years – structural failure due to rust

Springs – 10 years structural failure due to rust

Bed – 5 years – structural failure due to rot

Frame Pad – 12 months – stitching failure only

Net – 12 months – manufacturing defects only

Ladder – 12 months – manufacturing defects only

Ranges covered by this
warranty level:

XR Series 300 & 360

12’x’8 Rectangular

King 110

Tel: [phone] | www.supertramp.co.uk | [e-mail]

Siting Your Trampoline

 Your trampoline works best and is safest if it is

completely level. It is vital that you keep two
metres of unobstructed lawn space surrounding
the trampoline at all times.

 The XR360 trampoline is designed to stand on a lawn

or other soft surfaces such as artificial grass and bark.
If you are positioning your trampoline on an
abrasive surface such as concrete or gravel, the
underside of the leg bases will deteriorate quickly. In
these circumstances, we recommend you use floor
guards or rubber matting to protect your frame.

 Children must be supervised by a responsible adult at all times.

 Only one user at a time is recommended.

 Storing your trampoline away in bad weather is recommended (see care and maintenance)

 Always aim to bounce as close to the middle of the bed as possible.

 Do not in any circumstances let a person under the trampoline.

 Do not use this trampoline indoors.

 Be aware of the weather at all times – rain, ice and snow can make it slippery underfoot.

 Do not attempt somersaults unless you are fully competent or trained to do so.

 Do not bounce under the influence of drugs or alcohol.

 Remove all footwear before bouncing.

 Make sure you empty your pockets before bouncing as sharp objects can damage the mat and cause injury.

Please note:

The Safe Bouncing Guide on the next page only includes basic moves that are relatively simple and safe to learn.
There are, of course, many additional moves that can be performed. However, it is important that you are taught
these by a qualified instructor. This will ensure that you learn in a safe environment and under supervision. This
will also ensure that you do not get in to bad habits, as these could cause you problems and put you at risk as
you continue to develop your skills.

For details regarding trampolining sessions in your area, contact your local leisure centre or visit:

www.british-gymnastics.org/discover/trampoline

Before You Start

WARNINGS

Use the basic “feet to feet” standing bounce to warm up
and get the feel of the trampoline.

Try to keep the body straight. Your legs should be slightly
apart when landing on the bed and together in the air
with toes pointed.

Keep your eyes fixed on the frame pads in front of you.
As you jump up from the trampoline bed, push down
hard on the balls of your feet and toes. Stretch your body
upwards and swing your arms forwards and upwards.

As you come down on to the bed, bring your arms down
to your sides, part your legs slightly and land with your
feet flat whilst flexing your knees.

Safe Bouncing Guide

Standing Bounce

Without bouncing, adopt the hands and knees position as
shown below, keeping your eyes on the edge of the
trampoline.

Return to standing position and with a small bounce, shift
your hips back and upwards and drop to the hands and
knees position.

Your hands and knees must hit the bed at exactly the same time. Push up slightly with your arms to return
to the standing position.

Hands and Knees

IMPORTANT:

To stop your bounce, bend your knees as your
feet touch the bed and resist the momentum
which will try to force you up again. Practice
this move so that you are confident that you
can stop if you find you are getting out of
control or going away from the centre of the
bed.

First, without bouncing, sit in the middle of the bed in
the correct landing position.

This should be with your legs together and straight out
in front of you. Lean slightly backwards whilst keeping
your back straight. Keep your arms beside and slightly
behind you with fingers together and pointing forward.

Next, stand up and drop to the seat drop position,
without bouncing. Then try the move from a little
bounce. To bounce back onto your feet, shift your hips
forward and push up with your hands.

Seat Drop

Make sure that you drop to the seat drop
position in the middle of the bed and land back
on your feet in the middle of the bed.

Safe Bouncing Guide

Start as if doing a standing bounce.

At the top of your bounce, bend your body at the hips by
raising your legs whilst keeping them straight and together.
Arrive at the horizontal position and briefly touch your
shins.

Release this position and return to the standing bounce
stance before landing on the bed with arms at your sides.

Pike Jump

Start as if doing a standing bounce.

At the top of your bounce, bring your knees to your chest and
briefly clasp your shins. Keep your head high and looking
forward; focus on a point ahead to help keep you balanced.

Let go of your shins and return to standing bounce with your
body straight and arms at your sides before landing on the
bed.

Tuck Jump

Half Twist

From a standing bounce, as you leave the bed raise both
arms out to the side and bring them together above your
head whilst looking in the direction you wish to twist.
This action will help you twist your body round so that you
land facing the opposite direction, having rotated through
180°. The higher and quicker you lift your arms, the further
you will twist. Always twist in the same direction.

Full Twist

Performed as the half twist but with more effort so that you rotate through a full 360° and land in the same
position that you took off from. Do not attempt a full twist until you have perfected the half twist.

Half and Full Twist

Tel: [phone] | www.supertramp.co.uk | [e-mail]

XR360 Parts List

2 x End Rails 4x Leg Bases

2 x Side Rails

4 x Frame

Connectors

Frame Pads x1 section

8 x Leg

Extensions

1 x polymesh bed

88 x 216§mm

Springs

10 x 165mm

Toggle Loops

Tel: [phone] | www.supertramp.co.uk | [e-mail]

4 x Corner Pieces

x2

x2

Exploded Diagram

Tel: [phone] | www.supertramp.co.uk | [e-mail]

Polymesh
Bed

Corner
Peice

Leg Bases

End Rail

Side Rail

Frame
Connectors

Leg
Extension

Frame Pads

Assembling the Frame

A minimum of two people will be

required for Step 1 – Frame Assembly

1

Start by laying the frame parts out on a flat
surface.

a. Please note that the side rails of the

XR360 bow outwards (part A). Please take
this into consideration when positioning
the parts on the floor.

b. Please also note the positioning

of parts C & D (the corner rails).
It is very important these
are positioned correctly.

STEP

2

Whilst keeping the frame parts laid on the
floor, assemble parts A, B, C, D & G so that
you have formed the outline of the top
frame.

STEP

3

Next, build the leg assemblies by
connecting parts E & F together.
This should leave you with four
assembled leg bases.

STEP

D

C

D

B

A

E

G

G

F

G

G

A

C

B

F

F

F

C

A

B

C

D

F

F

F

F

E

E

E

G

G

F

G

G

A

D

B

F

F

F

F

E

F

F

F

E

E

E

Tel: [phone] | www.supertramp.co.uk | [e-mail]

Fitting the Bed and Springs

1

Begin by unfolding the polymesh bed
and laying it on the ground inside the
frame. Ensure the painted markings on
the bed are facing upwards.

STEP

Before you begin: Before you start, please note that each

spring will have an elongated hook and a standard hook. Please
ensure that it is the elongated hook that you fit into the frame
and the standard hook onto the bed.

Left diagram shows how the spring attaches to the bed and
frame

Side or
end Rail

Spring

Elongated
Hook

Hole in frame

Bed

4

Now fit each leg assembly to the top rail section by
slotting it onto a stub on the end rail (part B) and
a stub on the side rail (part A).

Note that each leg assembly will fit diagonally
across each corner of the frame with one leg
extension fitting to an end rail stub
and the other to a side rail
stub (please see diagram for
reference).

Please ensure that each
ball-catch is aligned and
secured to stop the leg
assemblies separating from the
top frame.

STEP

Frame

Bed

2

Using the diagram provided for guidance, use the springs to
fit the bed to the side rails and end rails. Fit the corner springs
first, and then side rails.

Fit the first 20 springs in
the order shown below.

STEP

3

With the bed now fitting loosely to the frame, proceed to fill in the gaps around the frame ensuring that you
work symmetrically so that the tension is distributed evenly around the bed. As the tension in the bed
increases, it may become more challenging to fit the springs so please use a spring tool.

STEP

11112

3

9 10

526

4

16

15

17

18

7 8

14

13

20

19

Fitting the Frame Pads

Eyelets on underside
of Frame Pad

Rail

Frame Pad

Toggle
Loop

1

Unfold the pads in half so that the underside is face-up
with the brass eyelets showing

STEP

2

Start threading the black elasticated end of the toggle loops through the
eyelets in the frame pads.

STEP

Spring

Tip: it might be useful to have a screwdriver (or similar) available to help feed
the loop through the eyelet.

3

Flip the pads over and complete on the other side. Once all toggle loops have been looped though, turn the
frame pads over and fit around the frame. Both the springs and framework should now be covered.

STEP

1x Clamp

1x Fastener

1x Spacer

4

Proceed to fix the frame pads in to place by looping the
toggle loops around the frame and then secure by pulling the
black toggle through the elastic. Do this for all 20 toggle
loops.

Once you have completed wrapping the toggles, make sure
you pull the skirt of the frame pad down around the edge of
the frame.

STEP

The Safety Enclosure

16 x Clamp Kits

1 x Enclosure Net 8 x Bottom Poles

with foam

24 x Bungee

Loops with

Q-Hook

8 x Top Poles

with foam

Tel: [phone] | www.supertramp.co.uk | [e-mail]

Tel: [phone] | www.supertramp.co.uk | [e-mail]

1

Before you start, position the following parts
next to each of the 8 vertical trampoline legs at
each corner:

 1 x bottom pole with foam

 1 x top pole with foam

 2 x clamp kits

STEP

2

Start by removing the foam from the bottom
enclosure poles.

Next, proceed to fit each bottom enclosure
pole to the vertical trampoline leg by using
the clamps provided.

STEP

3

Insert a black rubber spacer between the
enclosure pole and the vertical leg in
between the clamp. Now proceed to
tighten the quick-release clamp.

STEP

4

When you have attached all 8 bottom
poles in this manner, replace the
neoprene foam covers to the top half of
the bottom poles. The poles should now
be firmly clamped to the trampoline legs.

STEP

5

You can now fit the top part of the
enclosure pole to each bottom section
by sliding it into the bottom part.

STEP

Bottom Pole

Rubber
Spacer

Quick release
clamp

Clamps

Top

Poles

Replace neoprene

pole covers

to bottom poles

PLEASE NOTE that each pole requires two

clamps. The first should be positioned just
below the join between the leg extension
and the leg base. The second should be
fitted just below the edge of the frame.

CONGRATULATIONS, YOUR

is assembled and ready for use.

1

Lay the enclosure net on top of
the trampoline ensuring that
you align the zip so that it is
positioned between two
enclosure poles on the short
end of the frame.

STEP

2

Using the elasticated bungy
loops with Q-hooks, attach the
net to the top and middle of
the poles via the eye-bolts in
the poles.

STEP

3

Finally, to complete the assembly, attach
the straps at the bottom corners of the
netting to each corresponding corner
spring.

STEP

Fitting the Safety Net

Elasticated bungee

with Q hooks

Top Pole

Eyelebolt

Enclosure

Net

Trampoline Care and Maintenance

General

Your Super Tramp trampoline has been designed to
live outdoors all year round and will generally
require very little maintenance. However, a little care
and attention can add years to the life of your
trampoline. Please remember that the bed (mat) and
frame pads are made of synthetic materials which
can become easily damaged by cigarette ends,
fireworks and bonfire debris. Please make sure that
the following checks are made monthly:

 Check that all joints are still intact and have not

become dislodged during use

 Check that all springs are attached and that any

stretched springs are replaced

The Frame

Do not sit or stand on the frame/frame pads whilst
the trampoline is in use; this will cause excessive
wear to the springs and frame pads. In some
climates/environments, surface rust can appear. If
this happens, it should be removed using either a
wire brush or coarse sandpaper, and the area treated
with a non-toxic paint.

The Springs

Do not stand on the springs whilst the trampoline is
in use. Ensure you do not bounce on the springs as
they are not designed to withstand these sorts of
stresses. Doing so can result in them becoming
stretched, misshaped and weakened. If you find you
have any damaged springs, it is crucial you replace
them as soon as possible so as to avoid inflicting
damage to the remaining springs.

The Bed

The bed (mat) may eventually become weakened by
the effects of Ultra-Violet radiation. A little mould or
mildew should not harm the mat. Please make sure
that all footwear is removed before bouncing and
ensure that any other sharp objects and jewellery are
removed.

Useful Information

 A stretched or dead spring can be identified

where there is visible light through the coils of
the spring. Any springs identified with these
effects should be replaced in order to maintain
the performance of your trampoline. Please note:
this assessment should only be made when the
spring has been removed from the trampoline. It
is normal to see visible light when the springs
are under tension on the trampoline.

 When fitting the springs, it is often more

effective to use your bodyweight to pull the
spring back, rather than relying solely on your
upper-body and arm strength.

Accessories

Do not bounce in footwear. Instead, use grip
socks. You can buy these from us in a variety of
sizes!

Don’t forget to pick up a Ground
Anchor Kit for those windy days.

Tel: [phone] | www.supertramp.co.uk | [e-mail]

Thank you for purchasing a Super Tramp Trampoline

We hope you found this guide helpful.

www.supertramp.co.uk

Follow Us On Social Media!

Visit our website for our full range of

trampolines, spare parts and accessories

@supertramptrampolines

@supertrampuk
