SuperTooth Disco 3 User Manual
Pantone 286 CFoldingCutting
Charging
1. Connect the USB Cable to the DC 5V USB Input (7) found at
the back of the DISCO 3 then connect the other end of the
USB Cable to your Computer or USB power supply.
2. The Charge Indicator (8) is steady red while charging.
Charging is complete when the Charge indicator (8) goes
green.
Turning the SUPERTOOTH DISCO 3 On and O
Power On : Press and hold the On / O Button (6) for 2 seconds.
A power on beep is heard in the speaker, Play / Pause Indicator
(3) will blink for 2 seconds.
Note 1 : At rst time use, when you turn it on, the DISCO 3 goes
to pairing mode automatically (ready to be paired with your
phone / device).
Note 2 : If you are not playing music, the DISCO 3 goes to
standby mode automatically after a few seconds. To check it is
turned on, press any button. Play / Pause Indicator (3) will ash.
Power O : Press and hold the On / O Button (6) for 3 seconds.
A power o beep is heard in the speaker.
Pairing the SUPERTOOTH DISCO 3 with your
Bluetooth A2DP phone / device.
Pair the DISCO 3 to your phone / device to create the link or
audio connection between the two. Pairing should be done at
rst connection to a phone / device.
Important : Make sure that your phone / device supports A2DP*
(Advanced Audio Distribution Prole) before proceeding.
1. If the Disco 3 is o, press the On / O button (6) for 2 seconds,
to switch it on.
2. If this is the rst time you are turning on the Disco 3, the Play /
Pause (3) button blinks red fast. This indicates that the DISCO
3 is ready to be pair.
If the Play / Pause button (3) is not fast blinking red, press and
hold the Play / Pause button (3) for 3 seconds (until the unit
beeps twice). The Play / Pause button (3) should blink red
now and the Disco 3 is ready to pair.
3. While the DISCO 3 is in pairing mode, access the Bluetooth
menu of your device. Turn on its Bluetooth function then
execute a Bluetooth search to nd the DISCO 3. (See your
device manual).
4. When your device displays the list of Bluetooth devices, select
ST DISCO3.
5. If your device asks for the password / pin code, enter 0000 and
press OK.
6. The Disco 3 beeps twice. It is ready to use with your device.
*A2DP (Advanced Audio Distribution Prole) is a technology enabling to
stream stereo sound from an audio source (phone, pc, laptop, tablet, MP3
player) to a stereo speaker or headset via Bluetooth. To do so both devices
must support this prole.
Using the SUPERTOOTH DISCO 3 with your
Bluetooth A2DP phone / device
Important : The DISCO 3 needs to be “paired” with your
Bluetooth A2DP phone / device rst. Please refer to “Pairing
the SUPERTOOTH DISCO 3 with your Bluetooth A2DP phone /
device” section.
Reconnecting the SUPERTOOTH DISCO 3 with a Bluetooth
A2DP phone / device already paired
When you turn it on, the DISCO 3 reconnects automatically
with the latest paired device. When you leave the Bluetooth
operating range, with the DISCO 3 turned ON, it disconnects.
When you come back into the Bluetooth operating range,
press the Play / Pause Button (3) for 1 second to reconnect the
latest paired device. The DISCO 3 beeps twice.
Streaming music from a Bluetooth A2DP phone / device
1. Go to your device music player and play a track by pressing
“Play” or the Play / Pause Button (3) for 1 second. If the
DISCO 3 is connected, the music will be heard directly in the
speaker. See your device manual if needed.
2. Audio is now on the DISCO 3. The Play / Pause Indicator (3)
turns steady white, indicating that the device is connected
and streaming music via the DISCO 3.
3. When it is connected, you can control the music using the
buttons of the DISCO 3. Please refer to “SUPERTOOTH
DISCO 3 Button Functions” section.
Using the SUPERTOOTH DISCO 3 with a non
Bluetooth A2DP Mp3 Player
You can connect directly an Mp3 player via the Stereo Line
Input (9) situated at the back of the DISCO 3.
Connecting directly a non Bluetooth A2DP Mp3 player with
the SUPERTOOTH DISCO 3
1. Plug one end of the supplied audio cable into the Stereo
Line Input (9) and the other end into the output of your
music player.
2. Press “Play” on your Mp3 player to stream music directly via
the DISCO 3.
3. Non Bluetooth devices won’t support Play / Pause / Previous
/ Next commands from the DISCO 3. Please use the buttons
of your Mp3 player directly.
0 0 0 0
To download the user guide in
Pairing code
full version please go to
www.supertooth.net
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries with separate collection
systems). This marking shown on the product or its literature, indicates that it should not
be disposed with other household wastes at the
possible harm to the environment or human health from uncontrolled waste disposal,
please separate this from other types of wastes and recycle it responsibly to promote the
sustainable reuse of material resources. Household users should contact either the retailer where
they purchased this product, or their local government oce, for details of where and how they
can take this item for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase
contract. This product should not be mixed with other commercial wastes for disposal.
This product has an embedded, non-replaceable battery, do not attempt to open the product or
remove the battery as this may cause injury and damage the product. Please contact the local
recycling facility for removal of the battery. The embedded, non-replaceable battery is designed
to last the life time of the product.
Hereby, EURO COMMUNICATION EQUIPEMENTS, represented by Xavier MARCHANT, CEO, declares
that the SUPERTOOTH DISCO 3, MODEL BTD3, is in compliance with the essential requirements
and other relevant provisions of Directive 1999/5/EC of the European Parliament and of the
Council of 9 March 1999 on radio equipment and telecommunications terminal equipment and
the mutual recognition of their conformity.
For the whole declaration please visit : http://www.supertooth.net/download
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such
marks by Euro-CB is under license. Other trademarks and trade names are those of their respective owners.
The aptX® software is copyright CSR plc or its group companies. All rights reserved. The aptX® mark and the aptX
logo are trademarks of CSR plc or one of its group companies and may be registered in one or more jurisdictions.
Federal Communications Commission (FCC) Statement
Industry Canada (IC) Statement
15.21
You are cautioned that changes or modications not expressly approved by the part responsible
for compliance could void the user’s authority to operate the equipment.
15.105(b)
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC/IC rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which
equipment o and on, the user is encouraged to try to correct the interference by one or more of
the following measures :
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit dierent from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC rules and Industry Canada licence-exempt RSS standard(s)
Operation is subject to the following two conditions :
1) This device may not cause interference and
2) This device must accept any interference, including interference that may cause undesired
operation of the device.
FCC/IC RF Radiation Exposure Statement :
This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled
environment. End users must follow the specic operating instructions for satisfying RF exposure
compliance. This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
Euro Communication Equipements SAS
Route de Foix D117
11500 NEBIAS (FRANCE)
end of its working life. To prevent
can be determined by turning the
0 0 0 0
Pairing code
DISCO 3
USER GUIDE
The SUPERTOOTH DISCO 3 is a portable, wireless stereo
speaker featuring an avant-garde design and compact
footprint.
Users can stream music wirelessly from any cell phone,
tablet, computer, laptop or Mp3 player supporting
Bluetooth A2DP.
The SUPERTOOTH DISCO 3 kicks out 12 watts RMS audio
power, with two high eciency speakers on the front
and a bass reex system situated at the back of the unit.
The integrated rechargeable battery ensures 3 to 4
hours of non-stop, maximum-volume music, and up to
15 hours of moderately played melodies.
The SUPERTOOTH DISCO 3 comes with a 3.5 mm stereo
jack cable for devices that do not support Bluetooth
A2DP.
FoldingCutting
Specications :
Bluetooth Compliance :
Bluetooth version 4.0 specications
Supported Bluetooth Proles :
- A2DP (Advanced Audio Distribution Prole)
- Stereo music streaming
- AVRCP (Audio / Video Remote Control Prole)
- aptX® (High quality Bluetooth audio codec)
Operating Range :
10 meters Bluetooth standard
Frequency :
2.4 GHZ
Battery and Battery Life :
- Battery type : Lithium-Ion Power pack battery
- Music playing time (maximum volume level) : 3 to 4 hours
- Music playing time (medium volume) : 15 hours
- Stand-by time : 2000 hours
- Charging time : 3 hours (charger >0.7A)
Audio Features :
- Dual high eciency speakers + bass reex
- 12 Watt RMS power
- Compatible with any Bluetooth A2DP phone, PC, laptop, tablet
or Mp3 player
- Jack 3.5 auxiliary input for non Bluetooth A2DP Mp3 players,
iPods or computers
- Wireless Play / Previous / Next / Pause / Volume control (AVRCP
standard)
Multipairing :
- Maximum 8 phones paired
- 1 phone connected at a time
Special Features :
- Low battery / Charging indicator
- Can charge from the computer USB socket
Size and Weight :
- Height : 180 mm
- Width : 108 mm
- Depth : 70 mm
- Weight : 546 g
Accessories :
- Travel charger
- 3.5 mm stereo jack cable
- USB cable
SUPERTOOTH DISCO 3 Button Functions
The following buttons can be used to control functions on the SUPERTOOTH DISCO 3.
(1) Volume Down
• Press for 1 second for lower volume
• Long press to reach desired volume level
(6) On / O Button
• Press for 2 seconds to switch ON
• Press for 3 seconds to switch OFF
(2) Backward Button *
(For Bluetooth connection only)
• Press for 1 second to skip to previous track
• Long press to rewind a track to a specific point **
(3) Play / Pause Button *
(For Bluetooth connection only)
• Press for 1 second to play a track
• Press for 1 second to pause a track
• Blinking red : the SUPERTOOTH DISCO 3 is in pairing mode
(5) Volume Up
• Press for 1 second for higher volume
• Long press to reach desired volume level
(4) Forward Button *
(For Bluetooth connection only)
• Press for 1 second to skip to next track
• Long press to fast-forward a track to a
specic point **
• Triple blinking red : low battery, the SUPERTOOTH DISCO 3 needs to be charged
• Blinking red / white : low battery during playing
• From ON, press for 3 seconds to activate pairing mode
(7) Charge Port
USB 5V Input
(9) Stereo Line Input
• 3.5 mm Jack connection
(8) Charge Indicator
• Red : charging
• Green : battery full
(*) To access those commands, your phone / device must support Bluetooth AVRCP* (Audio/Video Remote Control Prole), a technology enabling to control functions directly from the DISCO 3.
(**) If supported by phone
Loading...
