Page 1
BTCRY6
Bluetooth Handsfree Kit
Manual
Page 2
A. Product Overview
1. On/Off Button
2. Reject Button
3. MFB Button
4. Volume Down
5. Volume Up
6. Microphone
7. Charger Port
8. Bluetooth Indicator / Charge Indicator
9. Speaker
B. Charging
1. Connect the charger’s plug to the Charger Port (7) of the
SUPERTOOTH CRYSTAL. Connect the charger to an external power
source.
Charge Indicator (8) Status:
Steady Red: Battery Low
Steady Orange: Charging
Steady Green: Battery Full
2. When fully charged, disconnect the charger.
C. Power On/Off
Power On: Press the On/Off (1) button for 1 second, the Bluetooth
Indicator (8) turns blinking blue. A beep will be heard.
Power Off: Press and hold the On/Off (1) button for 3 seconds, until the
Bluetooth Indicator (8) turns red. A beep will be heard.
D. Pairing to your Bluetooth Mobile Phone
Pair the SUPERTOOTH CRYSTAL to your Bluetooth mobile phone to create
the link or audio connection between the two. The pairing process is required
only once for each phone.
Pairing Procedure :
1. From OFF, press and hold the On/Off (1) button until the Bluetooth
Indicator (8) turns blinking red/blue. The handsfree kit is now in pairing
mode.
Page 3
2. While the handsfree kit is in pairing mode, access the Bluetooth menu of
your phone. Turn on the Bluetooth function then execute a Bluetooth
search. (See your phone’s manual.)
3. When the phone displays the list of Bluetooth devices, select BTCRY6.
4. When the phone asks for the password/pin code, enter 0000 and press Ok.
5. The handsfree kit is now ready to use.
E. Basic Operations
IMPORTANT :
The handsfree kit needs to be ‘paired’ to your Bluetooth mobile phone, before
you can use the following functions. See “Pairing to your Bluetooth Mobile
Phone in Section D”.
Make a Call ( Normal Dial ):
Dial the number on your phone. Audio will automatically be heard through the
handsfree kit. During an ongoing call, the Bluetooth Indicator (8) will turn
steady blue.
Note: With some phones, audio is always on the phone during an outgoing
call. You will need to press the MFB (3) button for 1 second to transfer the
audio to your handsfree kit.
Answer a Call :
To answer a call, simply press the MFB (3) button for 1 second, the Bluetooth
Indicator (8) will turn steady blue.
End a Call :
Press the MFB (3) button for 1 second to end the call.
Voice Dial :
Important : Before using this feature, make sure that the voice dialing function
of your phone is activated and at least one voice tag is recorded on your
phone. (Kindly refer to the procedure in your phone’s manual.)
Note: Voice dialing entries must be stored in the phone’s memory, not on the
SIM card!
1. Press the MFB (3) button for 1 second.
2. A voice dial beep will be heard on the handsfree kit prompting you to say
the voice tag of the contact to call and the Bluetooth Indicator (8) will turn
steady blue.
Page 4
3. Say the voice tag exactly as how you recorded it.
4. The voice tag will be played back to you and then the phone will dial the
number automatically.
Redial ( For Handsfree Profile Phones only ) :
Press the MFB (3) button for 3 seconds. The last dialed number will be
redialed.
Reject a Call ( For Handsfree Profile Phones only ) :
During the ring tone, short press Reject (2) button.
Volume Setting :
Increase or decrease the volume by pressing the Volume Up (5) or Volume
Down (4) button. Press repeatedly until the desired level is reached. A beep
will be heard as lowest and highest levels are reached.
Audio Transfer ( Phone to HF / HF to Phone ):
During an ongoing call, you can transfer the audio.
Press the MFB (3) for 3 seconds and the audio will be transferred.
Note: For some phones, you may need to accept a connection prompt on the
phone before automatic transfer takes place.
To Reconnect Phone to Kit :
In case of intentional disconnection (using the phone menu), short press MFB
(3) button to reconnect. Beep will be heard then phone reconnect to kit.
F Special Features
3- Way Calling :
You can talk with two parties at the same time with a three-way conversation on
your SUPERTOOTH CRYSTAL.
Note: This 3-way calling is Network Service dependent.
To end the current call and accept the second incoming call
Short press MFB (3) button will end the current call and accept the second
call. The audio for the second call will be heard through the handsfree kit.
Short press MFB (3) button will end the call.
Page 5
FCC/IC statements :
Federal Communications Commission (FCC) Statement
Industry Canada (IC) Statement
15.21
You are cautioned that changes or modications not expressly approved by the part responsible
for compliance could void the user’s authority to operate the equipment.
15.105(b)
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC/IC rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures :
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit di-erent from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
Operation is subject to the following two conditions :
1)This device may not cause interference and
2)This device must accept any interference, including interference that may cause undesired
operation of the device.
FCC/IC RF Radiation Exposure Statement :
This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled
environment. End users must follow the specific operating instructions for satisfying RF
exposure compliance. This transmitter must not be co-located or operating in conjunction with
any other antenna or transmitter.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.
and any use of such marks by Euro-CB is under license. Other trademarks and trade names
are those of their respective owners.
English
English
Hereby
Hereby, ,
EURO
EURO
COMMUNICATION
COMMUNICATION
EQUIPEMENTS
EQUIPEMENTS, ,
represented
represented byby
Xavier
Xavier
MARCHANT
MARCHANT, ,
CEO
CEO, ,
declares
declares
that
that
the
the
SUPERTOOTH
SUPERTOOTH
CRYSTAL,
CRYSTAL,
MODEL
MODEL
BTCRY6,
BTCRY6, isis inin
compliance
compliance
with
with
the
the
essential
essential
requirements
requirements
and
and
other
other
relevant
relevant
provisions
provisions ofof
Directive
Directive
1999/5/
1999/5/ECEC ofof
the
the
European
European
Parliament
Parliament
and
and ofof
the
the
Council
Council ofof 9 9
March
March
1999
1999 onon
radio
radio
equipment
equipment
and
and
telecommunications
telecommunications
terminal
terminal
equipment
equipment
and
and
the
the
mutual
mutual
recognition
recognition
ofof their
their
conformity
conformity..
For
For
the
the
whole
whole
declaration
declaration
please
please
visit
visit ::
http
http
://
://
www
www
..
SuperTooth
SuperTooth
.. frfr //
download
download
Euro
Euro
Communication
Communication
Equipements
Equipements
Sas
Sas
Route
Route dede
Foix
Foix DD
117
117
11 500
11 500
NEBIAS
NEBIAS
FRANCE
FRANCE
