TeraDrive FT2 SATA Solid State Drive
(
)
(
)
SATA-II 3Gbps SSD
Overview
TeraDrive™ SSDs are the new pinnacle of performance in enterprise
storage. The TeraDrive FT2 is based on the advanced new SandForce™
SF-1500 SSD processor. TRIM and Garbage Collection features are
included to ensure exceptional performance, both sequentially and
randomly, over the life of the drive with no performance degradation over
time.
This drive is native SAS tested and verified for RAID cards, making it
ideal for use in servers and workstations. Supporting up to 50,000
random read IOPS, the TeraDrive FT2 is ideal for use in database
servers. The TeraDrive FT2 makes no compromises in reliability or
endurance with state-of-the-art wear leveling, bad bit management, and
excellent ECC with up to 24 bytes correctable per 512 byte sector. Set to
revolutionize enterprise storage, the TeraDrive FT2 is available with either
MLC or SLC NAND flash, and is offered in capacities from 50GB to
200GB.
Physical Specifications
Form Factor 2.5"
Capacity* 50GB - 200GB
Dimension 69.85 x 100.20 x 9.50 mm
SATA Interface Serial ATA-II 3Gbps
NAND Flash MLC / SLC
Power Supply 5.0Vcc +/- 5%
Package Metal housing
tures
Environmental Specifications
Operating Shock 1500G
Operating Vibration 16G
Operating Temperature 0C to +70C
Operating Humidity 5 to 90%
Reliability Specifications
MTBF 1,000,000 hours
Data Reliability Built-in EDC/ECC function
Data Retention 10 years
Wear Leveling Algor. Patent Pending
Performance Specifications
Seq. Read
Capacity
50GB 285 200
100GB
200GB
400GB
MB/sec max
285
285
285
Seq. Write
MB/sec max
275
275
275
Ordering Information
MLC SLC
50GB FTM05F225H FTD05F225H
100GB
200GB
400GB
FTM10F225H FTD10F225H
FTM20F225H
FTM40F225H
FTD20F225H
© 2010 Super Talent Technology. Specifications subject to change without notice. US patent # 6,547,130 and others apply. 1GB=1,000,000,000 Bytes. Usable capacity may be less than
specified after formatting. Actual performance varies depending upon the system configuration and the application used. Performance is highly dependent upon test environment and use
case.
ssd.supertalent.com
www.supertalent.com
p.1
TeraDrive FT2
SATA Flash Drive Pin Assignment
Power Segment
PIN Signal Name Description
P1 Not Used (3.3V) N/A
P2 Not Used (3.3V) N/A
P3 Not Used (3.3V Precharge)
P4 GND 1stmate
P5 GND 2ndmate
P6 GND
P7 5V Precharge 5V Power
P8 5V Precharge 5V Power
P9 5V Precharge
P10 GND
P11 Reserved
P12 GND 1stmate
P13 Not Used (12V Precharge) N/A
P14 Not Used (12V)
P15 Not Used (12V)
ea
evirDetatSdiloSATAS
Signal Segment
PIN Signal Name Description
S1 GND
S2 RxP
S3 RxN
S4 GND
S5 TxN
dule F
S6 TxP
S7 GND
Differential Signal
pair for Receive
Differential Signal
pair for Transmit
tur
Revision History
January 20, 2010 Rev-A Released first data sheet
Revision History
© 2010 Super Talent Technology. Specifications subject to change without notice. US patent # 6,547,130 and others apply.
p.2
www.supertalent.com
TeraDrive FT2
Mechanical Specifications
