Instructions:
1. Slide the Switch button to power on or power off the device;
2. After power on, the device default mode is Bluetooth mode, you may pair
this device to your mobile phone and play the music;and you can adjust
volume by the button
3. Short press to play or pause the music
4. Press “Next” button to skip to the next song, or press “Prev” button
to go back to previous song; If there is a telephone coming in during
the Bluetooth mode, short press pause button to answer the phone by
speaker; Otherwise press answer button on your mobile phone to answer
the phone without Bluetooth speaker.
5. Press and hold the multifunction knob to switch the modes between blue
tooth mode/TF card reading/USB reading/line-in/FM.
6. During FM mode, insert the charging cable to micro USB slot as FM
Page 3
antenna; Short press multifunction button to start radio auto search and
storing, Press “Previous” or “Next” to select the saved FM station;
7.If the battery is low, you can hear voice”battery is low，please charge”from this
device,please use your mobile’s 5V wall charger to charge the device. The
charging status LED will turn on in red once the device is in charging. And the
LED will turn off after fully charged.
Specification：
Support BT/Aux/TF/USB/FM/Clock/Phone Cradle
Bluetooth Solution: V4.2
Output Power: 1x5Watts
Driver Size: 1 x Φ66 mm
Frequency Response: 150HZ-20KHz
Battery Capacity: 1200mAh
Play Time: 5-6 hrs (70% Volume)
Charging Time: 4 hrs
Casing: Plastic + Fabric covering
Overall Dimension: 248*100*109mm
Page 4
FCC Warnning:
This equipment has been tested and found to comply with the limits for a Class B digital device,
Pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.• Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly approved by manufacturer
could void your authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1)This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
