Supero X9DRW-7TPF, X9DRW-iTPF User Manual

USER’S MANUAL

Revision 1.0b

X9DRW-7TPF

X9DRW-iTPF

Manual Revision 1.0b

Release Date: December 2, 2013

Unless you request and receive written permission from Super Micro Computer, Inc., you may not
copy any part of this document.

Information in this document is subject to change without notice. Other products and companies
referred to herein are trademarks or registered trademarks of their respective companies or mark
holders.

Copyright © 2013 by Super Micro Computer, Inc.
All rights reserved.

Printed in the United States of America

The information in this User’s Manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
and makes no commitment to update or to keep current the information in this manual, or to notify
any person or organization of the updates. Please Note: For the most up-to-date version of this

manual, please see our Website at www.supermicro.com.

Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product
described in this manual at any time and without notice. This product, including software and docu­mentation, is the property of Supermicro and/or its licensors, and is supplied only under a license.
Any use or reproduction of this product is not allowed, except as expressly permitted by the terms
of said license.

IN NO EVENT WILL SUPER MICRO COMPUTER, INC. BE LIABLE FOR DIRECT, INDIRECT,
SPECIAL, INCIDENTAL, SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE
USE OR INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF
THE POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER MICRO COMPUTER, INC.
SHALL NOT HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED OR USED
WITH THE PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING,
INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between the manufacturer and the customer shall be governed by the laws of
Santa Clara County in the State of California, USA. The State of California, County of Santa Clara
shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for
all claims will not exceed the price paid for the hardware product.

FCC Statement: This equipment has been tested and found to comply with the limits for a Class
A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the manufacturer’s instruction manual, may cause harmful
interference with radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference, in which case you will be required to correct the interference at your
own expense.

California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate
warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate
Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”.

WARNING: Handling of lead solder materials used in this
product may expose you to lead, a chemical known to
the State of California to cause birth defects and other
reproductive harm.

Preface

This manual is written for system integrators, PC technicians and

knowledgeable PC users. It provides information for the installation and use of the

X9DRW-7TPF/iTPF motherboard.

About This Motherboard

The Super X9DRW-7TPF/iTPF motherboard supports dual Intel E5-2600(v2) Series

Processors (Socket R LGA 2011) and Intel QPI (QuickPath Interface) Technology

(V.1.1), providing point-to-point connections with transfer speeds of up to 8.0 TG/s.

With the C602 chipset built in, the X9DRW-7TPF/iTPF supports Intel® Intelligent

Power Node Manager (NM), Management Engine (ME), Rapid Storage Technology,

Digital Media Interface (DMI), PCI-E Gen. 3.0, and up to 1866 MHz DDR3 memory.

These features greatly enhance system performance for 1U/2U servers. This moth-

erboard is ideal for high-end server platforms. Please refer to our website (http://

www.supermicro.com) for processor and memory support updates.

Manual Organization

Chapter 1 provides quick installation instructions.

Chapter 2 describes the features, specications and performance of the mother-

board. It also provides detailed information about the Intel C602 chipset.

Chapter 3 provides hardware installation instructions. Read this chapter when in-

stalling the processor, memory modules, and other hardware components into the

system. If you encounter any problems, see Chapter 4, which describes trouble-

shooting procedures for video, memory, and system setup stored in the CMOS.

Chapter 5 includes an introduction to the BIOS, and provides detailed information

on running the CMOS Setup utility.

Appendix A provides BIOS Error Beep Codes.

Appendix B lists software installation instructions.

Preface

iii

iv

Conventions Used in the Manual

Please pay special attention to the following symbols to ensure proper system

installation and to prevent damaging the system or injuring yourself:

Warning: Important information given to ensure proper system installation or to prevent

damage to the components

Note: Additional information given to differentiate among various models

or to provides information for correct system setup.

X9DRW-7TPF/iTPF Motherboard User’s Manual

Preface

v

Contacting Supermicro

Headquarters

Address: Super Micro Computer, Inc.

980 Rock Ave.

San Jose, CA 95131 U.S.A.

Tel: [phone]

Fax: [phone]

Email: [email protected] (General Information)

[email protected] (Technical Support)

Web Site: www.supermicro.com

Europe

Address: Super Micro Computer B.V.

Het Sterrenbeeld 28, 5215 ML

's-Hertogenbosch, The Netherlands

Tel: [phone]

Fax: [phone]

Email: [email protected] (General Information)

[email protected] (Technical Support)

[email protected] (Customer Support)

Asia-Pacic

Address: Super Micro Computer, Inc.

3F, No. 150, Jian 1st Rd.

Zhonghe Dist., New Taipei City 23511

Taiwan (R.O.C)

Tel: [phone]

Fax: [phone]

Web Site: www.supermicro.com.tw

Technical Support:

Email: [email protected]

Tel: [phone]

vi

Table of Contents

Preface

Chapter 1 Overview

1-1 Overview ......................................................................................................... 1-1

1-2 Processor and Chipset Overview...................................................................1-11

1-3 Special Features ........................................................................................... 1-12

1-4 PC Health Monitoring .................................................................................... 1-12

1-5 ACPI Features ............................................................................................... 1-13

1-6 Power Supply ................................................................................................ 1-13

1-7 Super I/O ....................................................................................................... 1-14

1-8 Advanced Power Management ..................................................................... 1-14

Intel® Intelligent Power Node Manager (NM) ................................................ 1-14

Management Engine (ME) ............................................................................ 1-15

1-9 Overview of the Nuvoton WPCM450 Controller ........................................... 1-15

Other Features Supported by the WPCM450 BMC Controller ..................... 1-15

Chapter 2 Installation

2-1 Standardized Warning Statements ................................................................. 2-1

Battery Handling .............................................................................................. 2-1

Product Disposal ............................................................................................. 2-3

2-2 Static-Sensitive Devices .................................................................................. 2-4

Precautions ..................................................................................................... 2-4

Unpacking ....................................................................................................... 2-4

2-3 Processor and Heatsink Installation................................................................ 2-5

Installing the LGA2011 Processor ................................................................. 2-5

Installing a Passive CPU Heatsink ................................................................. 2-9

Removing the Heatsink ................................................................................. 2-10

2-4 Installing and Removing the Memory Modules ..............................................2-11

Installing & Removing DIMMs ........................................................................2-11

Removing Memory Modules ..........................................................................2-11

2-5 Motherboard Installation ................................................................................ 2-16

Tools Needed ................................................................................................ 2-16

Location of Mounting Holes .......................................................................... 2-16

Installing the Motherboard ............................................................................ 2-17

2-6 Control Panel Connectors and I/O Ports ...................................................... 2-18

Back Panel Connectors and I/O Ports .......................................................... 2-18

Back Panel I/O Port Locations and Denitions ........................................... 2-18

ATX PS/2 Keyboard and Mouse Ports ..................................................... 2-19

Universal Serial Bus (USB) ...................................................................... 2-19

X9DRW-7TPF/iTPF Motherboard User’s Manual

vii

Table of Contents

Serial Ports ............................................................................................... 2-20

Video Connection ..................................................................................... 2-20

Ethernet Ports .......................................................................................... 2-21

Unit Identier Switch ................................................................................ 2-22

Front Control Panel ....................................................................................... 2-23

Front Control Panel Pin Denitions............................................................... 2-24

NMI Button ............................................................................................... 2-24

Power LED .............................................................................................. 2-24

HDD LED .................................................................................................. 2-25

NIC1/NIC2 LED Indicators ....................................................................... 2-25

Overheat (OH)/Fan Fail/PWR Fail/UID LED ............................................ 2-26

Power Fail LED ........................................................................................ 2-26

Reset Button ........................................................................................... 2-27

Power Button ........................................................................................... 2-27

2-7 Connecting Cables ........................................................................................ 2-28

Power Connectors ................................................................................... 2-28

Fan Headers ............................................................................................. 2-29

Chassis Intrusion ..................................................................................... 2-29

Internal Speaker ....................................................................................... 2-30

Overheat/Fan Fail LED ............................................................................ 2-30

TPM Header/Port 80 ................................................................................ 2-31

Standby Power Header ............................................................................ 2-31

Power SMB (I2C) Connector .................................................................... 2-32

IPMB ......................................................................................................... 2-32

T-SGPIO/S-SGPIO Headers .................................................................... 2-33

DOM Power Connector ............................................................................ 2-33

Front Panel LEDs for TLAN1/TLAN2 ....................................................... 2-34

Activity/Link LEDs for TLAN1/TLAN2 ....................................................... 2-34

2-8 Jumper Settings ............................................................................................ 2-35

Explanation of Jumpers ................................................................................ 2-35

GLAN/10G_LAN Enable/Disable .............................................................. 2-35

CMOS Clear ............................................................................................. 2-36

Watch Dog Enable/Disable ...................................................................... 2-36

VGA Enable .............................................................................................. 2-37

BMC Enable ............................................................................................ 2-37

Management Engine (ME) Recovery ...................................................... 2-39

Manufacture Mode Select ........................................................................ 2-39

2-9 Onboard LED Indicators ............................................................................... 2-40

GLAN 1/2 LEDs ........................................................................................ 2-40

viii

IPMI Dedicated LAN LEDs ....................................................................... 2-40

Onboard Power LED ............................................................................... 2-41

Rear UID LED ......................................................................................... 2-41

SAS Activity LED (X9DRW-7TPF Only) ................................................... 2-42

SAS Fault LED (X9DRW-7TPF Only) ...................................................... 2-42

BMC Heartbeat LED ................................................................................ 2-43

2-10 SATA/SAS Connections ................................................................................ 2-44

Serial ATA Ports........................................................................................ 2-44

SAS Ports (X9DRW-7TPF Only) .............................................................. 2-45

Chapter 3 Troubleshooting

3-1 Troubleshooting Procedures ........................................................................... 3-1

3-2 Technical Support Procedures ........................................................................ 3-5

3-3 Battery Removal and Installation .................................................................... 3-6

3-4 Frequently Asked Questions ........................................................................... 3-7

3-5 Returning Merchandise for Service................................................................. 3-8

Chapter 4 BIOS

4-1 Introduction ...................................................................................................... 4-1

4-2 Main Setup ...................................................................................................... 4-2

4-3 Advanced Setup Congurations...................................................................... 4-4

4-4 Event Logs .................................................................................................... 4-27

4-5 IPMI ............................................................................................................... 4-29

4-6 Boot ............................................................................................................... 4 -31

4-7 Security ......................................................................................................... 4-32

4-8 Save & Exit ................................................................................................... 4-33

Appendix A BIOS Error Beep Codes

A-1 BIOS Error Beep Codes .................................................................................A-1

Appendix B Software Installation Instructions

B-1 Installing Software Programs ..........................................................................B-1

B-2 Conguring SuperDoctor® III (Windows OS Only) .........................................B-2

X9DRW-7TPF/iTPF Motherboard User’s Manual

Chapter 2: Overview

1-1

Note: For your system to work properly, please follow the links below to

download all necessary drivers/utilities and the user's manual for your

motherboard.

•SMCI product manuals: http://www.supermicro.com/support/manuals/

•Product Drivers and utilities: ftp://ftp.supermicro.com/

Warning: For safety considerations, please refer to the complete list of safety warn-

ings posted on the Supermicro website at http://www.supermicro.com/about/policies/

safety_information.cfm.

If you have any questions, please contact our support team at support@supermicro.

com.

Chapter 1

Overview

1-1 Overview

Checklist

Congratulations on purchasing your computer motherboard from an acknowledged

leader in the industry. Supermicro boards are designed with the utmost attention to

detail to provide you with the highest standards in quality and performance.

This motherboard was designed to be used in an SMC-proprietary server as a part

of an integrated system platform.

1-2

X9DRW-7TPF/iTPF Motherboard User’s Manual

Motherboard Image

Note: All graphics shown in this manual were based upon the latest PCB

Revision available at the time of publishing of the manual. The motherboard

you've received may or may not look exactly the same as the graphics

shown in this manual.

Chapter 2: Overview

1-3

Motherboard Layout

Note 1: TLAN1/TLAN2 ports support 10G LAN connections for Small Form

-Factor Pluggable Transceivers (SFP+).

Note 2: For the latest CPU/Memory updates, please refer to our website

at http://www.supermicro.com/products/motherboard/ for details.

JP7

JP6

JPL1

JPB1

JPL2

JPG1

JWD1

JPS1

LEDB7

JF2

J21

LE1

JPI2C1

JL1

JOH1

JI2C2

JI2C1

JSD1

JSTBY1

SFP2

FAN1

FAN6

FAN4

FAN5

FAN3

JTPM1

JBT1

LEDS1
LEDS2

LE2

JF1

I-SATA4 I-SATA2

S-SATA3S-SATA2

I-SATA5

I-SATA3

S-SATA0

S-SATA1

I-SATA0

SXB2

SXB1_2

SXB1_1

SXB1_3

SFP1

SXB1D

SXB1C

SCU-SGPIO1

T-SGPIO2

T-SGPIO1

COM1

USB0/1

SAS4~7

P2-DIMMF1

P2-DIMMF2

SXB1B

SXB1A

USB4/5

USB2/3

COM2

P1-DIMMD1

BATTERY

P1-DIMMD2

P1-DIMMC1

P1-DIMMC2

P2-DIMME1

UID

P2-DIMME2

TLAN1

LAN2

LAN1

P1-DIMMB2

P1-DIMMB1

P2-DIMMH2

P2-DIMMH1

P1-DIMMA2

IPMI_LAN

P2-DIMMG2

P2-DIMMG1

VGA1

KB/MOUSE

JIPMB1

I-SATA1

SAS0~3

FAN2

BIOS

JPW1JPW2

DS1

USB6

SP1

SAS CTRL

LAN
CTRL

BMC

LAN
CTRL

Intel
PCH

X9DRW-7TPF/iTPF

Rev. 1.01

JPW3

TLAN2

LEM2

JPME1

JPME2

CPU1

CPU2

JS3

P1-DIMMA1

1-4

X9DRW-7TPF/iTPF Motherboard User’s Manual

Notes:

•See Chapter 2 for detailed information on jumpers, I/O ports and JF1 front

panel connections. Jumpers/LED Indicators not indicated are for testing only.

The components that are not documented are reserved for internal testing only.

•" " indicates the location of "Pin 1".

•Use only the correct type of onboard CMOS battery as specied by the manu-

facturer. Do not install the onboard battery upside down to avoid damaging the

motherboard.

X9DRW-7TPF/iTPF Quick Reference

JP7

JP6

JPL1

JPB1

JPL2

JPG1

JWD1

JPS1

LEDB7

JF2

J21

LE1

JPI2C1

JL1

JOH1

JI2C2

JI2C1

JSD1

JSTBY1

SFP2

FAN1

FAN6

FAN4

FAN5

FAN3

JTPM1

JBT1

LEDS1
LEDS2

LE2

JF1

I-SATA4 I-SATA2

S-SATA3S-SATA2

I-SATA5

I-SATA3

S-SATA0

S-SATA1

I-SATA0

SXB2

SXB1_2

SXB1_1

SXB1_3

SFP1

SXB1D

SXB1C

SCU-SGPIO1

T-SGPIO2

T-SGPIO1

COM1

USB0/1

SAS4~7

P2-DIMMF1

P2-DIMMF2

SXB1B

SXB1A

USB4/5

USB2/3

COM2

P1-DIMMD1

BATTERY

P1-DIMMD2

P1-DIMMC1

P1-DIMMC2

P2-DIMME1

UID

P2-DIMME2

TLAN1

LAN2

LAN1

P1-DIMMB2

P1-DIMMB1

P2-DIMMH2

P2-DIMMH1

P1-DIMMA2

IPMI_LAN

P2-DIMMG2

P2-DIMMG1

VGA1

KB/MOUSE

JIPMB1

I-SATA1

SAS0~3

FAN2

BIOS

JPW1JPW2

DS1

USB6

SP1

SAS CTRL

LAN
CTRL

BMC

LAN
CTRL

Intel
PCH

X9DRW-7TPF/iTPF

Rev. 1.01

JPW3

TLAN2

LEM2

JPME1

JPME2

CPU1

CPU2

JS3

P1-DIMMA1

Chapter 2: Overview

1-5

X9DRW-7TPF/iTPF Jumpers

Jumper

Description Default Setting

JBT1

Clear CMOS See Chapter 2

JI2C1/JI2C2 SMB to PCI-E Slots Pins 2-3 (Normal)

JPB1 BMC Enable Pins 1-2 (Enabled)

JPG1 VGA Enable Pins 1-2 (Enabled)

JPL1 LAN1/LAN2 Enable Pins 1-2 (Enabled)

JPL2 TLAN1/TLAN2 Enable Pins 1-2 (Enabled)

JPME1 Management Engine (ME)

Recovery Mode

Pine 1-2 (Normal)

JPME2 Management Engine (ME)

Manufacture Mode

Pins 1-2 (Normal)

JPS1 SAS Enable Pins 1-2 (Enabled)

JWD1 Watch Dog Pins 1-2 (Reset)

X9DRW-7TPF/iTPF Connectors

Connectors Description

Battery Onboard CMOS Battery (See Chapter 3 for Battery Disposal)

COM1/COM2 Backplane COM Port1/Front Accessible COM2 Header

FAN1~6 CPU/System Fan Headers

JF1 Front Panel Control Header

JF2 TLAN 1/2 Link/Activity LED Indicators

JIPMB1 4-pin External BMC I2C Header (for an IPMI Card)

JL1 Chassis Intrusion

JOH1 Overheat/Fan Fail LED

JPI2C1 Power Supply SMBbus I2C Header

JPW1 ATX 24-Pin Power Connector (See Warning on Pg. 1-6.)

JPW2/JPW3 12V 8-Pin Power Connectors (See Warning on Pg. 1-6.)

JSD1 SATA DOM (Device_On_Module) Power Connector

JSTBY1 Standby Power Header

JTPM1 TPM (Trusted Platform Module)/Port 80

KB/Mouse Keyboard/Mouse

LAN1/2 G-bit Ethernet Ports 1/2 (from Intel i350)

TLAN1/2 (SFP1/2) 10G (T) Ethernet Ports 1/2 for 10G Small Form-Factor Plug-

gable Transceivers (SFP+) (from Broadcom 57810S)

(IPMI) LAN IPMI_Dedicated LAN

SAS 0-3, 4-7 Serial_Attached_SCSI Connectors 0-3, 4-7

1-6

X9DRW-7TPF/iTPF Motherboard User’s Manual

Warning: To prevent damage to the power supply or motherboard, please use a power

supply that contains a 24-pin and two 8-pin power connectors. Be sure to connect

these power supply connectors to the 24-pin power connector (JPW1), and the 8-pin

power connectors (JPW2/JPW3) on the motherboard. Failure in doing so will void the

manufacturer warranty on your power supply and motherboard.

I-SATA 0/1 Intel SATA 3.0 Connections 0/1 (from Intel AHCI)

I-SATA 2-5 Intel SATA 2.0 Connectors 2-5 (from Intel AHCI)

S-SATA 0-3 Intel SATA 2.0 Connectors 0-3 (from Intel SCU)

SP1 Onboard Buzzer (Internal Speaker)

SXB1A/1B/1C/1D SMC-Proprietary WIO_L (Left) Add-On Card (x48) Slot

SXB2 SMC-Proprietary WIO_R (Right) Add-On Card (x16) Slot

S-SGPIO 1 Serial-Link General_Purpose IO Header for S-SATA 0-3

T-SGPIO 1/2 Serial-Link General_Purpose IO Headers for I-SATA 0~5

USB 0/1 Back Panel USB 0/1

USB 2/3, 4/5 Front Panel Accessible USB 2/3, 4/5 Connections (USB 4/5:

Optional)

USB 6 Front Panel Type A USB 6 Port

UID Switch UID (Unit Identier) Switch

VGA1 Backpanel VGA Port

X9DRW-7TPF/iTPF LED Indicators

LED Description Color/State Status

LE1 Standby PWR LED Green: On SB Power On

LE2 UID LED Blue Unit Identied

LEDB7

Activity/Link LED for
TLAN1/TLAN2

Green: 10G LAN
Amber: 1G LAN

(JF2

Front Panel LED for
TLAN1/TLAN2

Green Normal)

LEDS1 SAS Activity LED Green: SAS Active SAS Active

LEDS2 SAS Fault LED On SAS Error(s)

LEM2 BMC Heartbeat LED Green: Blinking BMC Normal

Chapter 2: Overview

1-7

Motherboard Features

CPU

• Dual Intel

®

E5-2600(v2) Series Processors (Socket

R LGA 2011); each processor supports two full-width

Intel QuickPath Interconnect (QPI) links (with support

of up to 8.0 GT/s per QPI link.

• CPU Thermal Design Power (TDP): support up to

135W (See Note 1 on Page 1-9).

Note: For Intel E5-2600(v2) processor support,

BIOS version 3.0 is required.

Memory

• Integrated memory controller supports up to 1 TB

of Load Reduced (LRDIMM), 512 GB of Registered

(RDIMM) or 128 GB of Unbuffered (UDIMM) ECC/

Non-ECC DDR3 800/1066/1333/1600/1866 MHz

240-pin 4-channel memory modules in 16 DIMM

slots.

Note 1: 1866 MHz memory speed is dependent

on Intel E5-2600v2 CPUs.

Note 2: For the latest memory updates, please

refer to the Tested Memory List posted on our

website (http://www.supermicro.com/products/

motherboard).

Chipset

• Intel® C602 PCH

Expansion

• One (1) SMC-Proprietary WIO-R slot (SXB2),

• One (1) SMC-Proprietary WIO-L slot

(SXB1A/1B/1C/1D)

Slots

Graphics

• Nuvoton BMC G200 Video Controller (via WPCM450)

Network

• One Intel i350 Dual 1Gb Ethernet Controller for

LAN1/LAN2 ports.

• One Broadcom 57810S Dual 10-Gigabit Ethernet

Controller for TLAN1/TLAN2 ports (X9DRW-7TPF

only)

• Nuvoton WPCM450 Base-board Controller (BMC)

supports IPMI_LAN 2.0

I/O Devices

SATA Connections

• SATA Ports •Six (6) SATA Ports from AHCI:

Two (2) I-SATA 3.0 (SATA 0/1)

Four (4) I-SATA 2.0 (SATA 2-5)

•Four (4) SATA 2.0 Ports from

SCU (S-SATA 0-3)

1-8

X9DRW-7TPF/iTPF Motherboard User’s Manual

SAS Connections (X9DRW-7TPF Only)

• SAS Ports SAS 0-3, SAS 4-7

LSI 2208 SAS Controller w/1 GB

cache, up to 16 HDD support

*OEM SKU can support up to 240

HDD. Contact our Sales Dept. for

more information.

• RAID Hardware RAID 0, 1, 5, 6, 10,

50, 60

IPMI 2.0

• IPMI 2.0 supported by the Nuvoton WPCM450 BMC

Serial (COM) Port

• Two (2) Fast UART 16550 Connection: 9-pin RS-

232 port

Keyboard/Mouse

• Backplane PS2 Keyboard/Mouse

VGA

• Backplane VGA Port

Peripheral
Devices

USB Devices

• Two (2) USB ports on the rear I/O panel (USB 0/1)

• Two (2) USB connections for front access (USB 2/3)

• One (1) Type A USB connections for front access

(USB 6)

BIOS

• 16MB AMI BIOS® Flash EEPROM

• APM 1.2, DMI 2.3, PCI 2.3, ACPI 1.0/2.0/3.0, USB

Keyboard, Plug & Play (PnP) and SMBIOS 2.3

Power

• ACPI/ACPM Power Management

Cong.

• Main switch override mechanism

• RAID RAID 0, 1, 5, 10

• Intel® Management Engine (ME)

• Intel® Intelligent Power Node Manager (NM)

• Advanced Power Management with NM and ME

support (Available when the supporting software

and power supply cables are installed. Refer to

Section 1-8)

• Power-on mode for AC power recovery

Chapter 2: Overview

1-9

PC Health
Monitoring

CPU Monitoring

• Onboard voltage monitors for +3.3V, 3.3VSB, +5V,

+5V Standby, 12V, VDDQ AB/CD/EF/GH and Bat-

tery Voltage.

• CPU 5-Phase switching voltage regulator

• CPU/System overheat LED and control

• CPU Thermal Trip support

• Thermal Monitor 2 (TM2) support

Fan Control

• Fan status monitoring with rmware thermal man-

agement via IPMI 2.0

• Low noise fan speed control

LED Indicators

• System/CPU Overheat LED

• Suspend-state LED

• UID/Remote UID LED

System
Management

• PECI (Platform Environment Conguration Interface)

2.0 support

• System resource alert via SuperDoctor® III

• Thermal Monitor 2 (TM2) support

• SuperDoctor® III, Watch Dog, NMI

• Chassis Intrusion Header and Detection

Dimensions

• 16.50" (L) x 12.80" (W) (419.10 mm x 325.12 mm)

Note 1: CPU Maximum Thermal Design Power (TDP) is subject to chassis

and heatsink cooling restrictions. For proper thermal management, please

check the chassis and heatsink specications for proper CPU TDP sizing.

Note 2: For IPMI Conguration Instructions, please refer to the Embedded

IPMI Conguration User's Guide available @ http://www.supermicro.com/

support/manuals/.

Note 3: Changing BMC log-in information is recommended during initial

system power-on. The default username is ADMIN and password is

ADMIN. For BMC best practices, please refer to: http://www.supermicro.

com/products/nfo/les/IPMI/Best_Practices_BMC_Security.pdf

1-10

X9DRW-7TPF/iTPF Motherboard User’s Manual

System Block Diagram

Notes: 1. This is a general block diagram and may not exactly represent

the features on your motherboard. See the Motherboard Features pages

for the actual specications of each motherboard. 2. This block diagram

is intended for your reference only.

P0 P1

PE3 PE2 DMI

DDR3 DIMM

CPU2

F

E

Socket 01

#2

#1

DDR3 DIMM

#2

#1

x16

x16

x8

x16

x16

#1~#8

#1~#6

#7~#10

x8 [7..0]

x8 [15..8]

x4

PE1

x8 Gen3

RJ45

CPU0

PE3

RJ45

VGA CONN

SFP+ Conn + Cage

SFP+ Conn + Cage

LAN

PHY1
RTL8201F

x16

CPU1

PE3

x16

CPU1

PE2

DDR3 DIMM

H

G

#2

#1

DDR3 DIMM

#2

#1

P1 P0

PE3 PE2 DMI

DMI

PCH C602/C602J

SPI

SATA

SCU

USB

USB

LPC

PEG0

PEG1 [4:1]

PEG1_8

PCI

AT25321

BMC57810S
10G SFP+
Chipset

SAS2208

DDR3 DIMM

CPU1

D

C

Socket 00

#2

#1

#2

#1

PE1

DDR3 DIMM

B

A

#2

#1

DDR3 DIMM

QPI

QPI

#2

#1

USB

SATA

SAS

SATA

Powerville-2

L1/L2

REAR

HDR 2X5

0,1

TYPE-A

2,3 4,5 6

HDR 2X5

TPM

Header

WPCM450
VGA BMC

DDR2

BBU Conn

DDR3

DDR3

DDR3

DDR3

DDR3

DDR3 DIMM

E5-2600(v2) Series Processor

E5-2600(v2) Series Processor

to WIO

Left WIO

to WIO

x8

CPU0
PE2 [7..0]

x8

CPU1

PE1

Right WIO

Chapter 2: Overview

1-11

1-2 Processor and Chipset Overview

Built upon the functionality and the capabilities of the Intel E5-2600(v2) Series

(Socket R LGA 2011) and the C602 chipset, the X9DRW-7TPF/iTPF motherboard

provides the performance and feature sets required for dual_processor-based

HPC/Cluster/Database servers.

With support of Intel QuickPath interconnect (QPI) Technology, the X9DRW series

motherboard offers point-to-point serial interconnect interface with a transfer speed

of up to 8.0 GT/s, providing superb system performance.

The C602 chipset provides extensive IO support, including the following functions

and capabilities:

•PCI-Express Gen. 2.0 support

•ACPI Power Management Logic Support Rev. 3.0b or Rev. 4.0

•USB host interface backplane and front access support

•Intel Rapid Storage Technology supported

•Intel Virtualization Technology for Directed I/O (Intel VT-d) supported

•Intel Trusted Execution Technology supported

•Serial Peripheral Interface (SPI) Supported

•Digital Media Interface (DMI) supported

•Advanced Host Controller Interface (AHCI) supported

Note: For Intel E5-2600(v2) processor support, BIOS version 3.0 is

required.

1-12

X9DRW-7TPF/iTPF Motherboard User’s Manual

1-3 Special Features

Recovery from AC Power Loss

The Basic I/O System (BIOS) provides a setting that determines how the system will

respond when AC power is lost and then restored to the system. You can choose for

the system to remain powered off (in which case you must press the power switch

to turn it back on), or for it to automatically return to the power-on state. See the

Advanced BIOS Setup section for this setting. The default setting is Last State.

1-4 PC Health Monitoring

This section describes the features of PC health monitoring of the motherboard.

This motherboard has an onboard System_Hardware_Monitor chip that supports PC

health monitoring. An onboard voltage monitor will scan the following onboard volt-

ages continuously: VCORE0, VCORE1, MEM_AB, MEM_CD, MEM_EF, MEM_GH,

3.3V, 3.3VSB, 5V, 5VSB, +12V, and Battery Voltage. Once a voltage becomes un-

stable, a warning is given, or an error message is sent to the screen. The user can

adjust the voltage thresholds to dene the sensitivity of the voltage monitor.

Environmental Temperature Control

A thermal control sensor monitors the CPU temperature in real time and will turn

on the thermal control fan whenever the CPU temperature exceeds a user-dened

threshold. The overheat circuitry runs independently from the CPU. Once it detects

that the CPU temperature is too high, it will automatically turn on the thermal fan

control to prevent the CPU from overheating. The onboard chassis thermal circuitry

can monitor the overall system temperature and alert the user when the chassis

temperature is too high.

Note: To avoid possible system overheating, please be sure to provide

adequate airow to your system.

System Resource Alert

This feature is available when used with SuperDoctor® III in the Windows OS

environment or used with SuperDoctor II in Linux. SuperDoctor is used to notify

the user of certain system events. For example, you can congure SuperDoctor

to provide you with warnings when the system temperature, CPU temperatures,

voltages and fan speeds go beyond a predened range.

Chapter 2: Overview

1-13

1-5 ACPI Features

ACPI stands for Advanced Conguration and Power Interface. The ACPI specica-

tion denes a exible and abstract hardware interface that provides a standard

way to integrate power management features throughout a PC system, including

its hardware, operating system and application software. This enables the system

to automatically turn on and off peripherals such as CD-ROMs, network cards, hard

disk drives and printers.

In addition to enabling operating_system-directed power management, ACPI also

provides a generic system event mechanism for Plug and Play, and an operating

system-independent interface for conguration control. ACPI leverages the Plug and

Play BIOS data structures, while providing a processor architecture-independent

implementation that is compatible with Windows 7, Windows 8, and Windows

2008/2012 Operating Systems.

Slow Blinking LED for Suspend-State Indicator

When the CPU goes into a suspend state, the chassis power LED will start blinking

to indicate that the CPU is in suspend mode. When the user presses any key, the

CPU will "wake up" and the LED will automatically stop blinking and remain on.

1-6 Power Supply

As with all computer products, a stable power source is necessary for proper and

reliable operation. It is even more important for processors that have high CPU

clock rates.

The X9DRW series motherboard accommodates 24-pin ATX power supplies. Al-

though most power supplies generally meet the specications required by the CPU,

some are inadequate. In addition to the 24-pin ATX power, two 12V 8-pin power

connectors (JPW2/JPW3) are also required to ensure adequate power supply to the

system. Your power supply must also supply 1.5A for the Ethernet ports.

Warning: To prevent damage to the power supply or motherboard, please use a power

supply that contains a 24-pin and two 8-pin power connectors. Be sure to connect

these power supply connectors to the 24-pin power connector (JPW1), and the 8-pin

power connectors (JPW2/JPW3) on the motherboard. Failure in doing so will void the

manufacturer warranty on your power supply and motherboard.

It is strongly recommended that you use a high quality power supply that meets ATX

power supply Specication 2.02 or above. It must also be SSI compliant. (For more

information, please refer to the website at http://www.ssiforum.org/). Additionally, in

areas where noisy power transmission is present, you may choose to install a line

1-14

X9DRW-7TPF/iTPF Motherboard User’s Manual

lter to shield the computer from noise. It is recommended that you also install a

power surge protector to help avoid problems caused by power surges.

1-7 Super I/O

The Super I/O supports two high-speed, 16550 compatible serial communication

ports (UARTs). Each UART includes a 16-byte send/receive FIFO, a programmable

baud rate generator, complete modem control capability and a processor interrupt

system. Both UARTs provide legacy speed with baud rate of up to 115.2 Kbps.

The Super I/O provides functions that comply with ACPI (Advanced Conguration

and Power Interface), which includes support of legacy and ACPI power manage-

ment through an SMI or SCI function pin. It also features auto power management

to reduce power consumption.

1-8 Advanced Power Management

The new Advanced Power Management features are included below:

The new advanced power management features supported by this motherboard

include IPNM and ME. Please note that you will need to do the following to use

these two new features:

•Use a power supply that supports PMBus 1.1 or 1.2.

•Install the NMView software in your system. NMView is optional and can be

purchased from Supermicro.

Intel® Intelligent Power Node Manager (NM)

The Intel® Intelligent Power Node Manager (IPNM) provides your system with

real-time thermal control and power management for maximum energy efciency.

Although IPNM is supported by the BMC (Baseboard Management Controller),

your system must also have IPNM-compatible Management Engine (ME) rmware

installed in your system for IPNM support.

Note: Support for IPNM Specication Version 1.5 or Version 2.0 depends

on the power supply used in the system.

Chapter 2: Overview

1-15

Management Engine (ME)

The Management Engine, which is an ARC controller embedded in the PCH, pro-

vides Server Platform Services (SPS) to your system. The services provided by

SPS are different from those provided by the ME on client platforms.

1-9 Overview of the Nuvoton WPCM450 Controller

The Nuvoton WPCM450R Controller, a Baseboard Management Controller (BMC),

supports 2D/VGA-compatible graphic engine with PCI interface, creating multi-me-

dia virtualization via Keyboard/Video/Mouse Redirection (KVMR). The WPCM450R

Controller is ideal for remote system management.

The WPCM450R Controller interfaces with the host system via PCI connections

to communicate with the graphic engine. It supports USB 2.0 and 1.1 for remote

keyboard/mouse/virtual media emulation. It also provides LPC interface support to

control Super IO functions. The WPCM450R Controller is connected to the network

via an external Ethernet PHY module or shared NCSI connections.

The WPCM450R communicates with onboard components via six SMBus inter-

faces, PECI (Platform Environment Control Interface) buses, and General Purpose

I/O (GPIO) ports.

Other Features Supported by the WPCM450 BMC
Controller

The WPCM450R supports the following features:

•IPMI 2.0

•Serial over LAN

•KVM over LAN

•LAN Alerting-SNMP Trap

•Event Log

•X-Bus parallel interface for I/O expansion

•Multiple ADC inputs, Analog and Digital Video outputs

•SPI Flash Host BIOS and rmware bootstrap program supported

•Reduced Media Independent Interface (RMII)

1-16

X9DRW-7TPF/iTPF Motherboard User’s Manual

•OS (Operating System) Independency

•Provides remote Hardware Health Monitoring via IPMI. Key features

•Provides Network Management Security via remote access/console redirection.

•Supports the following Management tools: IPMIView, CLI (Command Line

Interface)

•RMCP+ protocol supported

Note 1: For more information on IPMI conguration, please refer to the

IPMI User's Guide posted on our website at http://www.supermicro.com/

support/manuals/.

Note 2: The term "IPMI controller" and the term "BMC controller" can be

used interchangeably in this section.

Note 3: Changing BMC log-in information is recommended during initial

system power-on. The default username is ADMIN and password is

ADMIN. For BMC best practices, please refer to: http://www.supermicro.

com/products/nfo/les/IPMI/Best_Practices_BMC_Security.pdf

Chapter 2: Installation

2-1

Chapter 2

Installation

2-1 Standardized Warning Statements

The following statements are industry-standard warnings provided to warn the user

of situations when potential bodily injury may occur. Should you have questions or

experience difculty, contact Supermicro's Technical Support department for assis-

tance. Only certied technicians should attempt to install or congure components.

Read this section in its entirety before installing or conguring components in the

system.

Battery Handling

Warning! There is a danger of explosion if the battery is replaced incor-

rectly. Replace the battery only with the same or equivalent type recom-

mended by the manufacturer. Dispose of used batteries according to the

manufacturer's instructions. (Refer to Chapter 3 for more information on

used battery disposal.

Warnung

Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die Bat-

terie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp. Entsorgen

Sie die benutzten Batterien nach den Anweisungen des Herstellers.

¡Advertencia!

Existe peligro de explosión si la batería se reemplaza de manera incorrecta. Reem-

plazar la batería exclusivamente con el mismo tipo o el equivalente recomendado por

el fabricante. Desechar las baterías gastadas según las instrucciones del fabricante.

電池交換が正しく行われなかった場合、破裂の危険性があります。 交換する電池はメ
ーカーが推奨する型、または同等のものを使用下さい。 使用済電池は製造元の指示に
従って処 分して 下さい 。

2-2

X9DRW-7TPF/iTPF Motherboard User’s Manual

Attention

Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer que

par une pile de type semblable ou équivalent, recommandée par le fabricant. Jeter les

piles usagées conformément aux instructions du fabricant.

Waarschuwing

Er is ontplofngsgevaar indien de batterij verkeerd vervangen wordt. Vervang de batterij

slechts met hetzelfde of een equivalent type die door de fabrikant aanbevolen wordt.

Gebruikte batterijen dienen overeenkomstig fabrieksvoorschriften afgevoerd te worden.

هناكخطرمنانفجارفيحالةاستبدالالبطاريةبطريقةغيرصحيحةفعليك

استبدالالبطارية

فقطبنفسالنوعأومايعادلهاكماأوصتبهالشركةالمصنعة

تخلصمنالبطارياتالمستعملةوفقالتعليماتالشركةالصانعة

Chapter 2: Installation

2-3

Product Disposal

Warning! Ultimate disposal of this product should be handled according

to all national laws and regulations.

Waarschuwing

De uiteindelijke verwijdering van dit product dient te geschieden in overeenstemming

met alle nationale wetten en reglementen.

Attention

La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois

et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme

compétent.

¡Advertencia!

Al deshacerse por completo de este producto debe seguir todas las leyes y regla-

mentos nacionales.

Warnung

Die Entsorgung dieses Produkts sollte gemäß allen Bestimmungen und Gesetzen des

Landes erfolgen.

التخلصالنهائيمنهذاالمنتجينبغيالتعاملمعهوفقالجميعالقوانين

واللوائحالوطنيةعند

!הרהזא

תנכס תמייקץוציפ .הניקת אל ךרדב הפלחוהו הדימב הללוסה לש ףילחהל שי

גוסב הללוסה תא מ םאותה תרבחלמומ ןרציתצ.

תוללוסה קוליס תושמושמה עצבל שי .ןרציה תוארוה יפל

2-4

X9DRW-7TPF/iTPF Motherboard User’s Manual

2-2 Static-Sensitive Devices

Electrostatic Discharge (ESD) can damage electronic com ponents. To avoid dam-

aging your system board, it is important to handle it very carefully. The following

measures are generally sufcient to protect your equipment from ESD.

Precautions

•Use a grounded wrist strap designed to prevent static discharge.

•Touch a grounded metal object before removing the board from the antistatic

bag.

•Handle the board by its edges only; do not touch its components, peripheral

chips, memory modules or gold contacts.

•When handling chips or modules, avoid touching their pins.

•Put the motherboard and peripherals back into their antistatic bags when not

in use.

•For grounding purposes, make sure that your system chassis provides excellent

conductivity between the power supply, the case, the mounting fasteners and

the motherboard.

Unpacking

The motherboard is shipped in antistatic packaging to avoid static damage. When

unpacking the board, make sure that the person handling it is static-protected.

Chapter 2: Installation

2-5

OPEN 1st

WARNING!

2-3 Processor and Heatsink Installation

Warning: When handling the processor package, avoid placing direct pressure on

the label area.

Notes:

•Always connect the power cord last, and always remove it before adding,

removing or changing any hardware components. Make sure that you install

the processor into the CPU socket before you install the CPU heatsink.

•If you buy a CPU separately, make sure that you use an Intel-certied multi-

directional heatsink only.

•Make sure to install the system board into the chassis before you install

the CPU heatsink.

•When receiving a system board without a processor pre-installed, make sure

that the plastic CPU socket cap is in place, and none of the socket pins are

bent; otherwise, contact your retailer immediately.

•When you have one CPU, be sure to install the CPU in Socket 1 rst.

•Refer to the Supermicro website for CPU support and updates.

Press down

on

Load Lever

labeled 'Open 1st'.

Installing the LGA2011 Processor

1. There are two load levers on the LGA2011 socket. To open the socket cover,

rst press and release the load lever labeled 'Open 1st'.

OPEN 1st

WARNING!

1

2

2-6

X9DRW-7TPF/iTPF Motherboard User’s Manual

OPEN 1st

WARNING!

OPEN 1st

WARNING!

OPEN 1st

WARNING!

Gently push
down to pop the
load plate open.

2. Press the second load lever labeled 'Close 1st' to release the load plate that

covers the CPU socket from its locking position.

3. With the lever labeled 'Close 1st' fully retracted, gently push down on the

'Open 1st' lever to open the load plate. Lift the load plate to open it com-

pletely.

1

2

Press down on

Load the

Lever labeled 'Close 1st'

1

Pull lever away from
the socket

2

Chapter 2: Installation

2-7

1. Use your thumb and index nger to loosen the lever and open the load plate.

2. Using your thumb and index nger, hold the CPU on its edges and align the

CPU keys, the semi-circle cutouts, against the socket keys.

3. Once they are aligned, carefully lower the CPU straight down into the socket.

(Do not drop the CPU on the socket. Do not move the CPU horizontally or

vertically. Do not rub the CPU against the surface or against any pins of the

socket to avoid damaging the CPU or the socket.)

Socket Keys

CPU Keys

Warning: You can only install the CPU

inside the socket in one direction.

Make sure that it is properly inserted

into the CPU socket before closing the

load plate. If it doesn't close properly,

do not force it as it may damage your

CPU. Instead, open the load plate

again and double-check that the CPU

is aligned properly.

2-8

X9DRW-7TPF/iTPF Motherboard User’s Manual

OPEN 1st

OPEN 1st

4. With the CPU inside the socket, inspect the four corners of the CPU to make

sure that the CPU is properly installed.

5. Close the load plate with the CPU inside the socket. Lock the lever labeled

'Close 1st' rst, then lock the lever labeled 'Open 1st' second. Use your

thumb to gently push the load levers down to the lever locks.

OPEN 1st

Lever Lock

Lever Lock

Push down and

lock the lever

labeled 'Open 1st'

Push down and lock the

level labeled 'Close 1st'.

Gently close

the load plate.

1 2

3

4

Chapter 2: Installation

2-9

OPEN 1st

Motherboard

Screw#1

Screw#2

Installing a Passive CPU Heatsink

1. Do not apply any thermal grease to the heatsink or the CPU die -- the re-

quired amount has already been applied.

2. Place the heatsink on top of the CPU so that the four mounting holes are

aligned with those on the Motherboard's and the Heatsink Bracket under-

neath.

3. Screw in two diagonal screws (i.e., the #1 and the #2 screws) until just snug

(-do not over-tighten the screws to avoid possible damage to the CPU.)

4. Finish the installation by fully tightening all four screws.

Mounting Holes

Screw#3

Screw#4

Notes: 1. For optimized air ow, please follow your chassis air ow di-

rection to install the correct CPU heatsink direction. 2. Graphic drawings

included in this manual are for reference only. They might look different

from the components installed in your system.

2-10

X9DRW-7TPF/iTPF Motherboard User’s Manual

OPEN 1st

Removing the Heatsink

Warning: We do not recommend that the CPU or the heatsink be removed. However,

if you do need to uninstall the heatsink, please follow the instructions below to uninstall

the heatsink to prevent damage done to the CPU or the CPU socket.

1. Unscrew the heatsink screws from the motherboard in the sequence as

shown in the illustration below.

2. Gently wriggle the heatsink to loosen it from the CPU. (Do not use excessive

force when wriggling the heatsink!)

3. Once the CPU is loosened, remove the CPU from the CPU socket.

4. Remove the used thermal grease and clean the surface of the CPU and the

heatsink, Reapply the proper amount of thermal grease on the surface before

reinstalling the CPU and the heatsink.

Loosen screws
in sequence as
shown.

Screw#2

Motherboard

Screw#1

Screw#3

Chapter 2: Installation

2-11

JP7

JP6

JPL1

JPB1

JPL2

JPG1

JWD1

JPS1

LEDB7

JF2

J21

LE1

JPI2C1

JL1

JOH1

JI2C2

JI2C1

JSD1

JSTBY1

SFP2

FAN1

FAN6

FAN4

FAN5

FAN3

JTPM1

JBT1

LEDS1
LEDS2

LE2

JF1

I-SATA4 I-SATA2

S-SATA3S-SATA2

I-SATA5

I-SATA3

S-SATA0

S-SATA1

I-SATA0

SXB2

SXB1_2

SXB1_1

SXB1_3

SFP1

SXB1D

SXB1C

SCU-SGPIO1

T-SGPIO2

T-SGPIO1

COM1

USB0/1

SAS4~7

P2-DIMMF1

P2-DIMMF2

SXB1B

SXB1A

USB4/5

USB2/3

COM2

P1-DIMMD1

BATTERY

P1-DIMMD2

P1-DIMMC1

P1-DIMMC2

P2-DIMME1

UID

P2-DIMME2

TLAN1

LAN2

LAN1

P1-DIMMB2

P1-DIMMB1

P2-DIMMH2

P2-DIMMH1

P1-DIMMA2

IPMI_LAN

P2-DIMMG2

P2-DIMMG1

VGA1

KB/MOUSE

JIPMB1

I-SATA1

SAS0~3

FAN2

BIOS

JPW1JPW2

DS1

USB6

SP1

SAS CTRL

LAN
CTRL

BMC

LAN
CTRL

Intel
PCH

X9DRW-7TPF/iTPF

Rev. 1.01

JPW3

TLAN2

LEM2

JPME1

JPME2

CPU1

CPU2

JS3

P1-DIMMA1

Release Tabs

Notches

2-4 Installing and Removing the Memory Modules

Note: Check Supermicro's Website for recommended memory modules.

CAUTION

Exercise extreme care when installing or removing DIMM

modules to prevent any possible damage.

Installing & Removing DIMMs

1. Insert the desired number of DIMMs into the memory slots, starting with

P1-DIMMA1. (For best memory performance, please use the modules of the

same type and speed in the same bank.)

2. Push the release tabs outwards on both ends of the DIMM slot to unlock it.

Removing Memory Modules

3. Align the DIMM module key with the receptive point on the memory slot.

4. Align the notches on the both ends of the module with the receptive points on

ends of the slot.

5. Use two thumbs together to press the notches of the module straight down

into the slot until the module snaps into place.

6. Press the release tabs to the locked positions to secure the DIMM module

into the slot.

Press both notches straight

down into the memory slot at

the same time.

Press both notches on the ends of the DIMM module to unlock it. Once the DIMM

module is loosened, remove it from the memory slot.

2-12

X9DRW-7TPF/iTPF Motherboard User’s Manual

Notes: 1866 MHz memory speed is dependent on Intel E5-2600v2 CPUs.

For Intel E5-2600(v2) processor support, BIOS version 3.0 is required.

Memory Support for the X9DRW-7TPF/iTPF Motherboard

The X9DRW-7TPF/iTPF motherboard supports up to 1 TB of Load Reduced

(LRDIMM), 512 GB of Registered (RDIMM) or 128 GB of Unbuffered (UDIMM)

ECC/Non-ECC DDR3 800/1066/1333/1600/1866 MHz 240-pin 4-channel memory

modules in 16 DIMM slots.

Note: For the latest memory updates, please refer to the Tested Memory

List posted on our website (http://www.supermicro.com/products/mother-

board).

Processor & Memory Module Population Conguration

For memory to work properly, follow the tables below for memory population.

Processors and their Corresponding Memory Modules

CPU# Corresponding DIMM Modules

CPU 1 P1-

DIMMA1

P1­DIMMB1

P1­DIMMC1

P1­DIMMD1

P1­DIMMA2

P1­DIMMB2

P1­DIMMC2

P1­DIMMD2

CPU2 P2-

DIMME1

P2­DIMMF1

P2­DIMMG1

P2­DIMMH1

P2­DIMME2

P2­DIMM F2

P2­DIMMG2

P2­DIMMH2

Processor and Memory Module Population for Optimal Performance

Number of

CPUs+DIMMs

CPUandMemoryPopulationCongurationTable

(For memory to work properly, follow the instructions below.)

1 CPU &

2 DIMMs

CPU1
P1-DIMMA1/P1-DIMMB1

1 CPU &

4 DIMMs

CPU1
P1-DIMMA1/P1-DIMMB1, P1-DIMMC1/P1-DIMMD1

1 CPU &

5~8 DIMMs

CPU1
P1-DIMMA1/P1-DIMMB1, P1-DIMMC1/P1-DIMMD1 + Any memory pairs in P1­DIMMA2/P1-DIMMB2/P1-DIMMC2/P1-DIMMD2 slots

2 CPUs &

4 DIMMs

CPU1 + CPU2
P1-DIMMA1/P1-DIMMB1, P2-DIMME1/P2-DIMMF1

2 CPUs &

6 DIMMs

CPU1 + CPU2
P1-DIMMA1/P1-DIMMB1/P1-DIMMC1/P1-DIMMD1, P2-DIMME1/P2-DIMMF1

2 CPUs &

8 DIMMs

CPU1 + CPU2
P1-DIMMA1/P1-DIMMB1/P1-DIMMC1/P1-DIMMD1, P2-DIMME1/P2-DIMMF1/P2­DIMMG1/P2-DIMMH1

2 CPUs &

10~16 DIMMs

CPU1/CPU2
P1-DIMMA1/P1-DIMMB1/P1-DIMMC1/P1-DIMMD1, P2-DIMME1/P2-DIMMF1/P2­DIMMG1/P2-DIMMH1 + Any memory pairs in P1, P2 DIMM slots

2 CPUs &

16 DIMMs

CPU1/CPU2
P1-DIMMA1/P1-DIMMB1/P1-DIMMC1/P1-DIMMD1, P2-DIMME1/P2-DIMMF1/P2-DIM­MG1/P2-DIMMH1,P1-DIMMA2/P1-DIMMB2/P1-DIMMC2/P1-DIMMD2, P2-DIMME2/
P2-DIMMF2/P2-DIMMG2/P2-DIMMH2

Chapter 2: Installation

2-13

Populating UDIMM (ECC/Non-ECC) Memory Modules

Intel E5-2600(v2) Series Processor UDIMM Memory Support

Ranks

Per

DIMM

& Data

Width

Memory Capacity

Per DIMM

(See the Note below)

Speed (MT/s) and Voltage Validated by Slot per Channel (SPC) and

DIMM Per Channel (DPC)

2 Slots Per Channel 3 Slots Per Channel

1DPC 2DPC 1DPC 2DPC

1.35V 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V 1.5v

SRx8

Non­ECC

1GB 2GB 4GB NA 1066,

1333,
1600,

1866

NA 1066,

1333,

1600

N/A 1066,

1333,
1600,

1866

N/A 1066,

1333,

1600

DRx8

Non­ECC

2GB 4GB 8GB NA 1066,

1333,
1600,

1866

NA 1066,

1333,

1600

N/A 1066,

1333,
1600,

1866

N/A 1066,

1333,

1600

SRx16

Non­ECC

512MB 1GB 2GB NA 1066,

1333,
1600,

1866

NA 1066,

1333,

1600

N/A 1066,

1333,
1600,

1866

N/A 1066,

1333,

1600

SRx8

ECC

1GB 2GB 4GB 1066,

1333

1066,
1333,
1600,

1866

1066,
1333

1066,
1333,

1600

1066,
1333

1066,
1333,
1600,

1866

1066,
1333

1066,
1333,

1600

DRx8

ECC

2GB 4GB 8GB 1066,

1333

1066,
1333,
1600,

1866

1066,
1333

1066,
1333,

1600

1066,
1333

1066,
1333,
1600,

1866

1066,
1333

1066,
1333,

1600

Note: For detailed information on memory support and updates, please refer to the SMC Recommended
Memory List posted on our website at http://www.supermicro.com/support/resources/mem.cfm.

Populating RDIMM (ECC) Memory Modules

Intel E5-2600(v2) Series Processor RDIMM Memory Support

Ranks

Per

DIMM

&

Data

Width

Memory Capacity

Per DIMM

(See the Note Below)

Speed (MT/s) and Voltage Validated by Slot per Channel (SPC) and DIMM Per Channel

(DPC)

2 Slots Per Channel 3 Slots Per Channel

1DPC 2DPC 1 DPC 2DPC 3DPC

1.35V 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V 1.5v

SRx8 1GB 2GB 4GB 1066,

1333

1066,
1333,
1600,

1866

1066,

1333

1066,
1333,

1600

1066,
1333

1066,
1333,
1600,
1866

1066,
1333

1066,
1333,

1600

800 800,

1066

DRx8 2GB 4GB 8GB 1066,

1333

1066,
1333,
1600,

1866

1066,

1333

1066,
1333,

1600

1066,
1333

1066,
1333,
1600,
1866

1066,
1333

1066,
1333,

1600

800 800,

1066

SRx4 2GB 4GB 8GB 1066,

1333

1066,
1333,
1600,

1866

1066,

1333

1066,
1333,

1600

1066,
1333

1066,
1333,
1600,
1866

1066,
1333

1066,
1333,

1600

800 800,

1066

DRx4 4GB 8GB 16GB 1066,

1333

1066,
1333,
1600,

1866

1066,

1333

1066,
1333,

1600

1066,
1333

1066,
1333,
1600,
1866

1066,
1333

1066,
1333,

1600

800 800,

1066

QRx4 8GB 16GB 32GB 800 800

1066

800 800 800 800,

1066

800 800 N/A N/A

QRx8 4GB 8GB 16GB 800 800

1066

800 800 800 800,

1066

800 800 N/A N/A

Note: For detailed information on memory support and updates, please refer to the SMC Recommended Memory List posted on
our website at http://www.supermicro.com/support/resources/mem.cfm.

2-14

X9DRW-7TPF/iTPF Motherboard User’s Manual

Populating UDIMM (ECC/Non-ECC) Memory Modules

Intel E5-2600 Series Processor UDIMM Memory Support

Ranks

Per

DIMM

& Data

Width

Memory Capacity

Per DIMM

(See the Note below)

Speed (MT/s) and Voltage Validated by Slot per Channel (SPC) and

DIMM Per Channel (DPC)

2 Slots Per Channel 3 Slots Per Channel

1DPC 2DPC 1DPC 2DPC

1.35V 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V 1.5v

SRx8

Non-

ECC

1GB 2GB 4GB NA 1066,

1333

NA 1066,

1333

N/A 1066,

1333,

N/A 1066,

1333

DRx8

Non-

ECC

2GB 4GB 8GB NA 1066,

1333

NA 1066,

1333

N/A 1066,

1333,

N/A 1066,

1333

SRx16

Non-

ECC

512MB 1GB 2GB NA 1066,

1333

NA 1066,

1333

N/A 1066,

1333

N/A 1066,

1333

SRx8

ECC

1GB 2GB 4GB 1066,

1333

1066,

1333

1066 1066,

1333

1066 1066,

1333,

1066,
1333

1066,
1333

DRx8

ECC

2GB 4GB 8GB 1066,

1333

1066,

1333

1066 1066,

1333

1066 1066,

1333,

1066,
1333

1066,
1333

Note: For detailed information on memory support and updates, please refer to the SMC Recommended
Memory List posted on our website at http://www.supermicro.com/support/resources/mem.cfm.

Populating RDIMM (ECC) Memory Modules

Intel E5-2600 Series Processor RDIMM Memory Support

Ranks

Per

DIMM

&

Data

Width

Memory Capacity

Per DIMM

(See the Note Below)

Speed (MT/s) and Voltage Validated by Slot per Channel (SPC) and DIMM Per Channel

(DPC)

2 Slots Per Channel 3 Slots Per Channel

1DPC 2DPC 1 DPC 2DPC 3DPC

1.35V 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V 1.5v

SRx8 1GB 2GB 4GB 1066,

1333

1066,
1333,

1600

1066,

1333

1066,
1333,

1600

1066,
1333

1066,
1333,
1600

1066,
1333

1066,
1333,

1600

N/A 800,

1066

DRx8 2GB 4GB 8GB 1066,

1333

1066,
1333,

1600

1066,

1333

1066,
1333,

1600

1066,
1333

1066,
1333,
1600

1066,
1333

1066,
1333,

1600

N/A 800,

1066

SRx4 2GB 4GB 8GB 1066,

1333

1066,
1333,

1600

1066,

1333

1066,
1333,

1600

1066,
1333

1066,
1333,
1600

1066,
1333

1066,
1333,

1600

N/A 800,

1066

DRx4 4GB 8GB 16GB 1066,

1333

1066,
1333,

1600

1066,

1333

1066,
1333,

1600

1066,
1333

1066,
1333,
1600

1066,
1333

1066,
1333,

1600

N/A 800,

1066

QRx4 8GB 16GB 32GB 800 1066 800 800 800 1066 800 800 N/A N/A

QRx8 4GB 8GB 16GB 800 1066 800 800 800 1066 800 800 N/A N/A

Note: For detailed information on memory support and updates, please refer to the SMC Recommended Memory List posted on

our website at http://www.supermicro.com/support/resources/mem.cfm.

Chapter 2: Installation

2-15

Populating LRDIMM (ECC) Memory Modules

Intel E5-2600(v2) Series Processor LRDIMM Memory Support

Ranks

Per

DIMM

&

Data

Width

Memory

Capacity

Per DIMM

(See the Note

Below)

Speed (MT/s) and Voltage Validated by Slot per Channel (SPC) and DIMM Per

Channel (DPC)

2 Slots Per Channel 3 Slots Per Channel

1DPC 2DPC 1DPC 2DPC 3DPC

1.35V 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V 1.5V

QRx4

(DDP)

16GB 32GB 1066,

1333,
1600

1066,
1333,
1600,

1866

1066,
1333,

1600

1066,
1333,

1600

1066,
1333,

1600

1066,
1333,
1600,

1866

1066,
1333,

1600

1066,
1333,

1600

1066 1066

8Rx4

(QDP)

32GB 64GB 1066 1066 1066 1066 1066 1066 1066 1066 1066 1066

Note: For detailed information on memory support and updates, please refer to the SMC Recommended Memory
List posted on our website at http://www.supermicro.com/support/resources/mem.cfm.

Intel E5-2600 Series Processor LRDIMM Memory Support

Ranks

Per

DIMM

&

Data

Width

Memory

Capacity

Per DIMM

(See the Note

Below)

Speed (MT/s) and Voltage Validated by Slot per Channel (SPC) and DIMM Per

Channel (DPC)

2 Slots Per Channel 3 Slots Per Channel

1DPC 2DPC 1DPC 2DPC 3DPC

1.35V 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V 1.5V

QRx4

(DDP)

16GB 32GB 1066 1066,

1333

1066 1066,

1333

1066 1066,

1333

1066 1066,

1333

1066 1066

QRx8

(QDP)

8GB 16GB 1066 1066,

1333

1066 1066,

1333

1066 1066 1066 1066 1066 1066

Note: For detailed information on memory support and updates, please refer to the SMC Recommended Memory
List posted on our website at http://www.supermicro.com/support/resources/mem.cfm.

Other Important Notes and Restrictions

•For the memory modules to work properly, please install DIMM modules of the same

type, same speed and same operating frequency on the motherboard. Mixing of

RDIMMs, UDIMMs or LRDIMMs is not allowed. Do not install both ECC and Non-ECC

memory modules on the same motherboard.

•Using DDR3 DIMMs with different operating frequencies is not allowed. All channels

in a system will run at the lowest common frequency.

2-16

X9DRW-7TPF/iTPF Motherboard User’s Manual

JP7

JP6

JPL1

JPB1

JPL2

JPG1

JWD1

JPS1

LEDB7

JF2

J21

LE1

JPI2C1

JL1

JOH1

JI2C2

JI2C1

JSD1

JSTBY1

SFP2

FAN1

FAN6

FAN4

FAN5

FAN3

JTPM1

JBT1

LEDS1
LEDS2

LE2

JF1

I-SATA4 I-SATA2

S-SATA3S-SATA2

I-SATA5

I-SATA3

S-SATA0

S-SATA1

I-SATA0

SXB2

SXB1_2

SXB1_1

SXB1_3

SFP1

SXB1D

SXB1C

SCU-SGPIO1

T-SGPIO2

T-SGPIO1

COM1

USB0/1

SAS4~7

P2-DIMMF1

P2-DIMMF2

SXB1B

SXB1A

USB4/5

USB2/3

COM2

P1-DIMMD1

BATTERY

P1-DIMMD2

P1-DIMMC1

P1-DIMMC2

P2-DIMME1

UID

P2-DIMME2

TLAN1

LAN2

LAN1

P1-DIMMB2

P1-DIMMB1

P2-DIMMH2

P2-DIMMH1

P1-DIMMA2

IPMI_LAN

P2-DIMMG2

P2-DIMMG1

VGA1

KB/MOUSE

JIPMB1

I-SATA1

SAS0~3

FAN2

BIOS

JPW1JPW2

DS1

USB6

SP1

SAS CTRL

LAN
CTRL

BMC

LAN
CTRL

Intel
PCH

X9DRW-7TPF/iTPF

Rev. 1.01

JPW3

TLAN2

LEM2

JPME1

JPME2

CPU1

CPU2

JS3

P1-DIMMA1

2-5 Motherboard Installation

All motherboards have standard mounting holes to t different types of chassis.

Make sure that the locations of all the mounting holes for both motherboard and

chassis match. Although a chassis may have both plastic and metal mounting fas-

teners, metal ones are highly recommended because they ground the motherboard

to the chassis. Make sure that the metal standoffs click in or are screwed in tightly.

Then use a screwdriver to secure the motherboard onto the motherboard tray.

Tools Needed

•Phillips Screwdriver

•Pan head screws (11 pieces)

•Standoffs (11 pieces, if needed)

Location of Mounting Holes

There are eleven (11) mounting holes on this motherboard indicated by the arrows.

Warning: 1) To avoid damaging the motherboard and its components, please do

not use a force greater than 8 lb/inch on each mounting screw during motherboard

installation. 2) Some components are very close to the mounting holes. Please take

precautionary measures to avoid damaging components when installing the mother-

board to the chassis.

Chapter 2: Installation

2-17

Installing the Motherboard

1. Install the I/O shield into the chassis.

2. Locate the mounting holes on the motherboard.

3. Locate the matching mounting holes on the chassis. Align the mounting holes

on the motherboard with the mounting holes on the chassis.

4. Install standoffs in the chassis as needed.

5. Install the motherboard into the chassis carefully to avoid damaging mother-

board components.

6. Using the Phillips screwdriver, insert a Pan head #6 screw into a mounting

hole on the motherboard and its matching mounting hole on the chassis.

7. Repeat Step 5 to insert #6 screws into all mounting holes.

8. Make sure that the motherboard is securely placed in the chassis.

Note: Images displayed are for illustration only. Your chassis or compo-

nents might look different from those shown in this manual.

2-18

X9DRW-7TPF/iTPF Motherboard User’s Manual

JP7

JP6

JPL1

JPB1

JPL2

JPG1

JWD1

JPS1

LEDB7

JF2

J21

LE1

JPI2C1

JL1

JOH1

JI2C2

JI2C1

JSD1

JSTBY1

SFP2

FAN1

FAN6

FAN4

FAN5

FAN3

JTPM1

JBT1

LEDS1

LEDS2

LE2

JF1

I-SATA4 I-SATA2

S-SATA3S-SATA2

I-SATA5

I-SATA3

S-SATA0

S-SATA1

I-SATA0

SXB2

SXB1_2

SXB1_1

SXB1_3

SFP1

SXB1D

SXB1C

SCU-SGPIO1

T-SGPIO2

T-SGPIO1

COM1

USB0/1

SAS4~7

P2-DIMMF1

P2-DIMMF2

SXB1B

SXB1A

USB4/5

USB2/3

COM2

P1-DIMMD1

BATTERY

P1-DIMMD2

P1-DIMMC1

P1-DIMMC2

P2-DIMME1

UID

P2-DIMME2

TLAN1

LAN2

LAN1

P1-DIMMB2

P1-DIMMB1

P2-DIMMH2

P2-DIMMH1

P1-DIMMA2

IPMI_LAN

P2-DIMMG2

P2-DIMMG1

VGA1

KB/MOUSE

JIPMB1

I-SATA1

SAS0~3

FAN2

BIOS

JPW1JPW2

DS1

USB6

SP1

SAS CTRL

LAN
CTRL

BMC

LAN
CTRL

Intel
PCH

X9DRW-7TPF/iTPF

Rev. 1.01

JPW3

TLAN2

LEM2

JPME1

JPME2

CPU1

CPU2

JS3

P1-DIMMA1

2-6 Control Panel Connectors and I/O Ports

The I/O ports are color coded in conformance with the PC 99 specication. See

the picture below for the colors and locations of the various I/O ports.

Back Panel Connectors and I/O Ports

BackPanelI/OPortLocationsandDenitions

1. Keyboard

2. Mouse

3. Back Panel USB Port 0

4. Back Panel USB Port 1

5. IPMI LAN

6. COM Port 1 (Turquoise)

7. Back Panel VGA (Blue)

8. Gigabit LAN 1

9. Gigabit LAN 2

10. TLAN 1+ 10_Gigabit SFP+ (SFP1)

11. LEDB7: TLAN 1/2 LED

12. TLAN 2+ 10_Gigabit SFP+ (SFP2)

1

2

3

4

5

678

9

10

11

12

Chapter 2: Installation

2-19

JP7

JP6

JPL1

JPB1

JPL2

JPG1

JWD1

JPS1

LEDB7

JF2

J21

LE1

JPI2C1

JL1

JOH1

JI2C2

JI2C1

JSD1

JSTBY1

SFP2

FAN1

FAN6

FAN4

FAN5

FAN3

JTPM1

JBT1

LEDS1
LEDS2

LE2

JF1

I-SATA4 I-SATA2

S-SATA3S-SATA2

I-SATA5

I-SATA3

S-SATA0

S-SATA1

I-SATA0

SXB2

SXB1_2

SXB1_1

SXB1_3

SFP1

SXB1D

SXB1C

SCU-SGPIO1

T-SGPIO2

T-SGPIO1

COM1

USB0/1

SAS4~7

P2-DIMMF1

P2-DIMMF2

SXB1B

SXB1A

USB4/5

USB2/3

COM2

P1-DIMMD1

BATTERY

P1-DIMMD2

P1-DIMMC1

P1-DIMMC2

P2-DIMME1

UID

P2-DIMME2

TLAN1

LAN2

LAN1

P1-DIMMB2

P1-DIMMB1

P2-DIMMH2

P2-DIMMH1

P1-DIMMA2

IPMI_LAN

P2-DIMMG2

P2-DIMMG1

VGA1

KB/MOUSE

JIPMB1

I-SATA1

SAS0~3

FAN2

BIOS

JPW1JPW2

DS1

USB6

SP1

SAS CTRL

LAN
CTRL

BMC

LAN
CTRL

Intel
PCH

X9DRW-7TPF/iTPF

Rev. 1.01

JPW3

TLAN2

LEM2

JPME1

JPME2

CPU1

CPU2

JS3

P1-DIMMA1

1. Keyboard

2. Mouse

3. Backpanel USB 0

4. Backpanel USB 1

5. Front Accessible USB 2/3

6. FP USB 6

Universal Serial Bus (USB)

Two Universal Serial Bus ports (USB

0/1) are located on the I/O back panel.

In addition, a USB header, located

close to the I-SATA ports, is used to

provide front-accessible USB connec-

tions (USB 2/3). A Type A connector

(USB 6) also provides front panel USB

support. (Cables are not included).

See the tables on the right for pin

denitions.

FP USB (2/3, 6)

PinDenitions

USB 2, 6

Pin # Denition

USB 3

Pin # Denition

1 +5V 1 +5V

2 PO- 2 PO-

3 PO+ 3 PO+

4 Ground 4 Ground

5 NC 5 Key

(NC= No connection)

Backplane USB

(USB 0/1)

PinDenitions

Pin# Denition

1 +5V

2 PO-

3 PO+

4 Ground

5 NA

2

3

5

6

ATX PS/2 Keyboard and Mouse

Ports

The ATX PS/2 keyboard and PS/2

mouse are located next to the Back

Panel USB Ports 0/1 and the IPMI

LAN port on the motherboard. See the

table on the right for pin denitions.

PS/2 Keyboard/Mouse Pin

Denitions

PS2 Keyboard PS2 Mouse

Pin# Denition Pin# Denition

1 KB Data 1 Mouse Data

2 No Connection 2 No Connection

3 Ground 3 Ground

4 Mouse/KB VCC

(+5V)

4 Mouse/KB VCC

(+5V)

5 KB Clock 5 Mouse Clock

6 No Connection 6 No Connection

VCC: with 1.5A PTC (current limit)

1

4

2-20

X9DRW-7TPF/iTPF Motherboard User’s Manual

JP7

JP6

JPL1

JPB1

JPL2

JPG1

JWD1

JPS1

LEDB7

JF2

J21

LE1

JPI2C1

JL1

JOH1

JI2C2

JI2C1

JSD1

JSTBY1

SFP2

FAN1

FAN6

FAN4

FAN5

FAN3

JTPM1

JBT1

LEDS1
LEDS2

LE2

JF1

I-SATA4 I-SATA2

S-SATA3S-SATA2

I-SATA5

I-SATA3

S-SATA0

S-SATA1

I-SATA0

SXB2

SXB1_2

SXB1_1

SXB1_3

SFP1

SXB1D

SXB1C

SCU-SGPIO1

T-SGPIO2

T-SGPIO1

COM1

USB0/1

SAS4~7

P2-DIMMF1

P2-DIMMF2

SXB1B

SXB1A

USB4/5

USB2/3

COM2

P1-DIMMD1

BATTERY

P1-DIMMD2

P1-DIMMC1

P1-DIMMC2

P2-DIMME1

UID

P2-DIMME2

TLAN1

LAN2

LAN1

P1-DIMMB2

P1-DIMMB1

P2-DIMMH2

P2-DIMMH1

P1-DIMMA2

IPMI_LAN

P2-DIMMG2

P2-DIMMG1

VGA1

KB/MOUSE

JIPMB1

I-SATA1

SAS0~3

FAN2

BIOS

JPW1JPW2

DS1

USB6

SP1

SAS CTRL

LAN
CTRL

BMC

LAN
CTRL

Intel
PCH

X9DRW-7TPF/iTPF

Rev. 1.01

JPW3

TLAN2

LEM2

JPME1

JPME2

CPU1

CPU2

JS3

P1-DIMMA1

Video Connection

One video (VGA) port (VGA1) is lo-

cated next to COM Port1 on the I/O

backplane. Refer to the board layout

below for the location.

1. COM1

2. COM2

3. VGA1

Serial Ports

Two COM connections (COM1 &

COM2) are located on the mother-

board. COM1 is located on the Back-

plane I/O panel. COM2, located next

to the JTPM1/Port 80 header, is used

to provide front access support. See

the table on the right for pin denitions.

Serial COM) Ports

PinDenitions

Pin # Denition Pin # Denition

1 DCD 6 DSR

2 RXD 7 RTS

3 TXD 8 CTS

4 DTR 9 RI

5 Ground 10 N/A

COM1

COM2

COM1

COM2

2

1

2

3

1

Chapter 2: Installation

2-21

1. GLAN1

2. GLAN2

3. TLAN1 (10 GLAN Port+SFP1)

4.TLAN2 (10 GLAN Port+SFP2)

5. IPMI_LAN

Ethernet Ports

Two Gigabit Ethernet ports (LAN1/2)

and two 10G LAN ports (TLAN1,

TLAN2) are located on the I/O back-

plane to provide internet connec-

tions. TLAN1 & TLAN2 also support

10-Gigabit small form-factor pluggable

(SFP) transceivers optimized for on-

board telecommunication and data

communications. In addition to LAN/

TLAN ports, an IPMI_Dedicated LAN,

located above USB 0/1 ports on the

backplane, provides KVM support for

IPMI 2.0. (Note: Please refer to the

LED Indicator Section for LAN LED

information.)

GLAN Ports (LAN 1/2)

PinDenition

Pin# Denition

1 P2V5SB 10 SGND

2 TD0+ 11 Act LED

3 TD0- 12 P3V3SB

4 TD1+ 13 Link 100 LED (Yel-

low, +3V3SB)

5 TD1- 14 Link 1000 LED

(Yellow, +3V3SB)

6 TD2+ 15 Ground

7 TD2- 16 Ground

8 TD3+ 17 Ground

9 TD3- 18 Ground

(NC: No Connection)

JP7

JP6

JPL1

JPB1

JPL2

JPG1

JWD1

JPS1

LEDB7

JF2

J21

LE1

JPI2C1

JL1

JOH1

JI2C2

JI2C1

JSD1

JSTBY1

SFP2

FAN1

FAN6

FAN4

FAN5

FAN3

JTPM1

JBT1

LEDS1
LEDS2

LE2

JF1

I-SATA4 I-SATA2

S-SATA3S-SATA2

I-SATA5

I-SATA3

S-SATA0

S-SATA1

I-SATA0

SXB2

SXB1_2

SXB1_1

SXB1_3

SFP1

SXB1D

SXB1C

SCU-SGPIO1

T-SGPIO2

T-SGPIO1

COM1

USB0/1

SAS4~7

P2-DIMMF1

P2-DIMMF2

SXB1B

SXB1A

USB4/5

USB2/3

COM2

P1-DIMMD1

BATTERY

P1-DIMMD2

P1-DIMMC1

P1-DIMMC2

P2-DIMME1

UID

P2-DIMME2

TLAN1

LAN2

LAN1

P1-DIMMB2

P1-DIMMB1

P2-DIMMH2

P2-DIMMH1

P1-DIMMA2

IPMI_LAN

P2-DIMMG2

P2-DIMMG1

VGA1

KB/MOUSE

JIPMB1

I-SATA1

SAS0~3

FAN2

BIOS

JPW1JPW2

DS1

USB6

SP1

SAS CTRL

LAN
CTRL

BMC

LAN
CTRL

Intel
PCH

X9DRW-7TPF/iTPF

Rev. 1.01

JPW3

TLAN2

LEM2

JPME1

JPME2

CPU1

CPU2

JS3

P1-DIMMA1

23145

2-22

X9DRW-7TPF/iTPF Motherboard User’s Manual

Power Button

Blue+ (OH/Fan Fail/
PWR FaiL/UID LED)

1

NIC1 Link LED

Reset Button

2

Power Fail LED

HDD LED

FP PWRLED

Reset

PWR

3.3 V

ID_UID_SW/3/3V Stby

Red+ (Blue LED Cathode)

Ground

Ground

1920

3.3V

X

Ground

NMI

X

NIC2 Link LED

NIC2 Activity LED

NIC1 Activity LED

UnitIdentierSwitch

A Unit Identifier (UID) Switch and

two LED Indicators are located on

the motherboard. The UID Switch is

located next to the TLAN Port 2 on the

backplane. The Rear UID LED (LE2)

is located next to the UID Switch.

The Front Panel UID LED is located

at pins 7/8 of the Front Control Panel

at JF1. Connect a cable to pin 8 on

JF1 for Front Panel UID LED indica-

tion. When you press the UID switch,

both Rear UID LED and Front Panel

UID LED Indicators will be turned on.

Press the UID switch again to turn

off both LED Indicators. These UID

Indicators provide easy identication

of a system unit that may be in need

of service.

Note: UID can also be trig-

gered via IPMI on the moth-

erboard. For more informa-

tion on IPMI, please refer

to the IPMI User's Guide

posted on our website @

http://www.supermicro.com.

UID Switch

Pin# Denition

1 Ground

2 Ground

3 Button In

4 Ground

1. UID Switch

2. Rear UID LED (LE2)

3. Front UID LED

UID LED (LE2)

Status

Color/State OS Status

Blue: On Windows OS Unit Identied

Blue:
Blinking

Linux OS Unit Identied

JP7

JP6

JPL1

JPB1

JPL2

JPG1

JWD1

JPS1

LEDB7

JF2

J21

LE1

JPI2C1

JL1

JOH1

JI2C2

JI2C1

JSD1

JSTBY1

SFP2

FAN1

FAN6

FAN4

FAN5

FAN3

JTPM1

JBT1

LEDS1
LEDS2

LE2

JF1

I-SATA4 I-SATA2

S-SATA3S-SATA2

I-SATA5

I-SATA3

S-SATA0

S-SATA1

I-SATA0

SXB2

SXB1_2

SXB1_1

SXB1_3

SFP1

SXB1D

SXB1C

SCU-SGPIO1

T-SGPIO2

T-SGPIO1

COM1

USB0/1

SAS4~7

P2-DIMMF1

P2-DIMMF2

SXB1B

SXB1A

USB4/5

USB2/3

COM2

P1-DIMMD1

BATTERY

P1-DIMMD2

P1-DIMMC1

P1-DIMMC2

P2-DIMME1

UID

P2-DIMME2

TLAN1

LAN2

LAN1

P1-DIMMB2

P1-DIMMB1

P2-DIMMH2

P2-DIMMH1

P1-DIMMA2

IPMI_LAN

P2-DIMMG2

P2-DIMMG1

VGA1

KB/MOUSE

JIPMB1

I-SATA1

SAS0~3

FAN2

BIOS

JPW1JPW2

DS1

USB6

SP1

SAS CTRL

LAN
CTRL

BMC

LAN
CTRL

Intel
PCH

X9DRW-7TPF/iTPF

Rev. 1.01

JPW3

TLAN2

LEM2

JPME1

JPME2

CPU1

CPU2

JS3

P1-DIMMA1

2

3

1

Chapter 2: Installation

2-23

JP7

JP6

JPL1

JPB1

JPL2

JPG1

JWD1

JPS1

LEDB7

JF2

J21

LE1

JPI2C1

JL1

JOH1

JI2C2

JI2C1

JSD1

JSTBY1

SFP2

FAN1

FAN6

FAN4

FAN5

FAN3

JTPM1

JBT1

LEDS1

LEDS2

LE2

JF1

I-SATA4 I-SATA2

S-SATA3S-SATA2

I-SATA5

I-SATA3

S-SATA0

S-SATA1

I-SATA0

SXB2

SXB1_2

SXB1_1

SXB1_3

SFP1

SXB1D

SXB1C

SCU-SGPIO1

T-SGPIO2

T-SGPIO1

COM1

USB0/1

SAS4~7

P2-DIMMF1

P2-DIMMF2

SXB1B

SXB1A

USB4/5

USB2/3

COM2

P1-DIMMD1

BATTERY

P1-DIMMD2

P1-DIMMC1

P1-DIMMC2

P2-DIMME1

UID

P2-DIMME2

TLAN1

LAN2

LAN1

P1-DIMMB2

P1-DIMMB1

P2-DIMMH2

P2-DIMMH1

P1-DIMMA2

IPMI_LAN

P2-DIMMG2

P2-DIMMG1

VGA1

KB/MOUSE

JIPMB1

I-SATA1

SAS0~3

FAN2

BIOS

JPW1JPW2

DS1

USB6

SP1

SAS CTRL

LAN
CTRL

BMC

LAN
CTRL

Intel
PCH

X9DRW-7TPF/iTPF

Rev. 1.01

JPW3

TLAN2

LEM2

JPME1

JPME2

CPU1

CPU2

JS3

P1-DIMMA1

Front Control Panel

JF1 contains header pins for various buttons and indicators that are normally lo-

cated on a control panel at the front of the chassis. These connectors are designed

specically for use with Supermicro's server chassis. See the gure below for the

descriptions of the various control panel buttons and LED indicators. Refer to the

following section for descriptions and pin denitions.

JF1 Header Pins

Power Button

Blue+ (OH/Fan Fail/
PWR FaiL/UID LED)

1

NIC1 Link LED

Reset Button

2

Power Fail LED

HDD LED

FP PWRLED

Reset

PWR

3.3 V

ID_UID_SW/3/3V Stby

Red+ (Blue LED Cathode)

Ground

Ground

1920

3.3V

X

Ground

NMI

X

NIC2 Link LED

NIC2 Activity LED

NIC1 Activity LED

2-24

X9DRW-7TPF/iTPF Motherboard User’s Manual

JP7

JP6

JPL1

JPB1

JPL2

JPG1

JWD1

JPS1

LEDB7

JF2

J21

LE1

JPI2C1

JL1

JOH1

JI2C2

JI2C1

JSD1

JSTBY1

SFP2

FAN1

FAN6

FAN4

FAN5

FAN3

JTPM1

JBT1

LEDS1
LEDS2

LE2

JF1

I-SATA4 I-SATA2

S-SATA3S-SATA2

I-SATA5

I-SATA3

S-SATA0

S-SATA1

I-SATA0

SXB2

SXB1_2

SXB1_1

SXB1_3

SFP1

SXB1D

SXB1C

SCU-SGPIO1

T-SGPIO2

T-SGPIO1

COM1

USB0/1

SAS4~7

P2-DIMMF1

P2-DIMMF2

SXB1B

SXB1A

USB4/5

USB2/3

COM2

P1-DIMMD1

BATTERY

P1-DIMMD2

P1-DIMMC1

P1-DIMMC2

P2-DIMME1

UID

P2-DIMME2

TLAN1

LAN2

LAN1

P1-DIMMB2

P1-DIMMB1

P2-DIMMH2

P2-DIMMH1

P1-DIMMA2

IPMI_LAN

P2-DIMMG2

P2-DIMMG1

VGA1

KB/MOUSE

JIPMB1

I-SATA1

SAS0~3

FAN2

BIOS

JPW1JPW2

DS1

USB6

SP1

SAS CTRL

LAN
CTRL

BMC

LAN
CTRL

Intel
PCH

X9DRW-7TPF/iTPF

Rev. 1.01

JPW3

TLAN2

LEM2

JPME1

JPME2

CPU1

CPU2

JS3

P1-DIMMA1

Power Button

Blue+ (OH/Fan Fail/
PWR FaiL/UID LED)

1

NIC1 Link LED

Reset Button

2

Power Fail LED

HDD LED

FP PWRLED

Reset

PWR

3.3 V

ID_UID_SW/3/3V Stby

Red+ (Blue LED Cathode)

Ground

Ground

1920

3.3V

X

Ground

NMI

X

NIC2 Link LED

NIC2 Activity LED

NIC1 Activity LED

Power LED

The Power LED connection is located

on pins 15 and 16 of JF1. Refer to the

table on the right for pin denitions.

NMI Button

The non-maskable interrupt button

header is located on pins 19 and 20

of JF1. Refer to the table on the right

for pin denitions.

NMI Button

PinDenitions(JF1)

Pin# Denition

19 Control

20 Ground

Power LED

PinDenitions(JF1)

Pin# Denition

15 3.3V

16 PWR LED

FrontControlPanelPinDenitions

A. NMI

B. PWR LED

A

B

Chapter 2: Installation

2-25

Power Button

Blue+ (OH/Fan Fail/
PWR FaiL/UID LED)

1

NIC1 Link LED

Reset Button

2

Power Fail LED

HDD LED

FP PWRLED

Reset

PWR

3.3 V

ID_UID_SW/3/3V Stby

Red+ (Blue LED Cathode)

Ground

Ground

1920

3.3V

X

Ground

NMI

X

NIC2 Link LED

NIC2 Activity LED

NIC1 Activity LED

B

C

A

D

E

NIC1/NIC2 LED Indicators

The NIC (Network Interface Control-

ler) LED connections for GLAN port 1

are located on pins 11 and 12 of JF1,

and the LED connection for GLAN

Port 2 are on pins 9 and 10. Attach

the NIC LED cables here to display

network activity. Refer to the table on

the right for pin denitions.

Note: The NIC LED connec-

tions for TLAN Ports 1/2 are

located on JF2 and LEDB7.

HDD LED

The HDD LED connection is located

on pins 13 and 14 of JF1. Attach a

cable here to indicate HDD activ-

ity. See the table on the right for pin

denitions.

HDD LED

PinDenitions(JF1)

Pin# Denition

13 ID_UID_

SW_3.3V/3.3V SB

14 HDD Active

A. HDD LED

B. NIC1 (GLAN1) Link LED

C. NIC1 (GLAN1) Activity LED

D. NIC2 (GLAN2) Link LED

E. NIC2 (GLAN2) Activity LED

GLAN1/2 LED

PinDenitions(JF1)

Pin# Denition

9 NIC 2 Activity LED

10 NIC 2 Link LED

11 NIC 1 Activity LED

12 NIC 1 Link LED

JP7

JP6

JPL1

JPB1

JPL2

JPG1

JWD1

JPS1

LEDB7

JF2

J21

LE1

JPI2C1

JL1

JOH1

JI2C2

JI2C1

JSD1

JSTBY1

SFP2

FAN1

FAN6

FAN4

FAN5

FAN3

JTPM1

JBT1

LEDS1
LEDS2

LE2

JF1

I-SATA4 I-SATA2

S-SATA3S-SATA2

I-SATA5

I-SATA3

S-SATA0

S-SATA1

I-SATA0

SXB2

SXB1_2

SXB1_1

SXB1_3

SFP1

SXB1D

SXB1C

SCU-SGPIO1

T-SGPIO2

T-SGPIO1

COM1

USB0/1

SAS4~7

P2-DIMMF1

P2-DIMMF2

SXB1B

SXB1A

USB4/5

USB2/3

COM2

P1-DIMMD1

BATTERY

P1-DIMMD2

P1-DIMMC1

P1-DIMMC2

P2-DIMME1

UID

P2-DIMME2

TLAN1

LAN2

LAN1

P1-DIMMB2

P1-DIMMB1

P2-DIMMH2

P2-DIMMH1

P1-DIMMA2

IPMI_LAN

P2-DIMMG2

P2-DIMMG1

VGA1

KB/MOUSE

JIPMB1

I-SATA1

SAS0~3

FAN2

BIOS

JPW1JPW2

DS1

USB6

SP1

SAS CTRL

LAN
CTRL

BMC

LAN
CTRL

Intel
PCH

X9DRW-7TPF/iTPF

Rev. 1.01

JPW3

TLAN2

LEM2

JPME1

JPME2

CPU1

CPU2

JS3

P1-DIMMA1

2-26

X9DRW-7TPF/iTPF Motherboard User’s Manual

Power Button

Blue+ (OH/Fan Fail/
PWR FaiL/UID LED)

1

NIC1 Link LED

Reset Button

2

Power Fail LED

HDD LED

FP PWRLED

Reset

PWR

3.3 V

ID_UID_SW/3/3V Stby

Red+ (Blue LED Cathode)

Ground

Ground

1920

3.3V

X

Ground

NMI

X

NIC2 Link LED

NIC2 Activity LED

NIC1 Activity LED

Power Fail LED

The Power Fail LED connection is

located on pins 5 and 6 of JF1. Re-

fer to the table on the right for pin

denitions.

PWR Fail LED

PinDenitions(JF1)

Pin# Denition

5 3.3V

6 PWR Supply Fail

B

A

A. OH/Fail/PWR Fail LED (Red)/UID

(Blue)

B. Blue LED Cathode

C. PWR Supply Fail

Overheat (OH)/Fan Fail/PWR Fail/
UID LED

Connect an LED cable to pins 7 and

8 of Front Control Panel to use the

Overheat/Fan Fail/Power Fail and

UID LED connections. The Red LED

on pin 7 provides warnings of over-

heat, fan failure or power failure. The

Blue LED on pin 8 works as the front

panel UID LED indicator. The Red

LED takes precedence over the Blue

LED by default. Refer to the table on

the right for pin denitions.

OH/Fan Fail/ PWR Fail/Blue_UID

LEDPinDenitions(JF1)

Pin# Denition

7 Red_LED-Cathode/OH/Fan Fail/

Power Fail5.5V.SB

8 Blue_UID LED

OH/Fan Fail/PWR Fail

LED Status (Red LED)

State Denition

Off Normal

On Overheat

Flashing Fan Fail

C

JP7

JP6

JPL1

JPB1

JPL2

JPG1

JWD1

JPS1

LEDB7

JF2

J21

LE1

JPI2C1

JL1

JOH1

JI2C2

JI2C1

JSD1

JSTBY1

SFP2

FAN1

FAN6

FAN4

FAN5

FAN3

JTPM1

JBT1

LEDS1
LEDS2

LE2

JF1

I-SATA4 I-SATA2

S-SATA3S-SATA2

I-SATA5

I-SATA3

S-SATA0

S-SATA1

I-SATA0

SXB2

SXB1_2

SXB1_1

SXB1_3

SFP1

SXB1D

SXB1C

SCU-SGPIO1

T-SGPIO2

T-SGPIO1

COM1

USB0/1

SAS4~7

P2-DIMMF1

P2-DIMMF2

SXB1B

SXB1A

USB4/5

USB2/3

COM2

P1-DIMMD1

BATTERY

P1-DIMMD2

P1-DIMMC1

P1-DIMMC2

P2-DIMME1

UID

P2-DIMME2

TLAN1

LAN2

LAN1

P1-DIMMB2

P1-DIMMB1

P2-DIMMH2

P2-DIMMH1

P1-DIMMA2

IPMI_LAN

P2-DIMMG2

P2-DIMMG1

VGA1

KB/MOUSE

JIPMB1

I-SATA1

SAS0~3

FAN2

BIOS

JPW1JPW2

DS1

USB6

SP1

SAS CTRL

LAN
CTRL

BMC

LAN
CTRL

Intel
PCH

X9DRW-7TPF/iTPF

Rev. 1.01

JPW3

TLAN2

LEM2

JPME1

JPME2

CPU1

CPU2

JS3

P1-DIMMA1

Chapter 2: Installation

2-27

Power Button

Blue+ (OH/Fan Fail/
PWR FaiL/UID LED)

1

NIC1 Link LED

Reset Button

2

Power Fail LED

HDD LED

FP PWRLED

Reset

PWR

3.3 V

ID_UID_SW/3/3V Stby

Red+ (Blue LED Cathode)

Ground

Ground

1920

3.3V

X

Ground

NMI

X

NIC2 Link LED

NIC2 Activity LED

NIC1 Activity LED

Power Button

The Power Button connection is located

on pins 1 and 2 of JF1. Momentarily

contacting both pins will power on/off

the system. This button can also be con-

gured to function as a suspend button

(with a setting in the BIOS - See Chapter

4). To turn off the power when the system

is in suspend mode, press the button for

4 seconds or longer. Refer to the table on

the right for pin denitions.

Power Button

PinDenitions(JF1)

Pin# Denition

1 Signal

2 Ground

Reset Button

The Reset Button connection is located

on pins 3 and 4 of JF1. Attach it to a

hardware reset switch on the computer

case. Refer to the table on the right for

pin denitions.

Reset Button

PinDenitions(JF1)

Pin# Denition

3 Reset

4 Ground

A. Reset Button

B. PWR Button

A

B

JP7

JP6

JPL1

JPB1

JPL2

JPG1

JWD1

JPS1

LEDB7

JF2

J21

LE1

JPI2C1

JL1

JOH1

JI2C2

JI2C1

JSD1

JSTBY1

SFP2

FAN1

FAN6

FAN4

FAN5

FAN3

JTPM1

JBT1

LEDS1
LEDS2

LE2

JF1

I-SATA4 I-SATA2

S-SATA3S-SATA2

I-SATA5

I-SATA3

S-SATA0

S-SATA1

I-SATA0

SXB2

SXB1_2

SXB1_1

SXB1_3

SFP1

SXB1D

SXB1C

SCU-SGPIO1

T-SGPIO2

T-SGPIO1

COM1

USB0/1

SAS4~7

P2-DIMMF1

P2-DIMMF2

SXB1B

SXB1A

USB4/5

USB2/3

COM2

P1-DIMMD1

BATTERY

P1-DIMMD2

P1-DIMMC1

P1-DIMMC2

P2-DIMME1

UID

P2-DIMME2

TLAN1

LAN2

LAN1

P1-DIMMB2

P1-DIMMB1

P2-DIMMH2

P2-DIMMH1

P1-DIMMA2

IPMI_LAN

P2-DIMMG2

P2-DIMMG1

VGA1

KB/MOUSE

JIPMB1

I-SATA1

SAS0~3

FAN2

BIOS

JPW1JPW2

DS1

USB6

SP1

SAS CTRL

LAN
CTRL

BMC

LAN
CTRL

Intel
PCH

X9DRW-7TPF/iTPF

Rev. 1.01

JPW3

TLAN2

LEM2

JPME1

JPME2

CPU1

CPU2

JS3

P1-DIMMA1

2-28

X9DRW-7TPF/iTPF Motherboard User’s Manual

JP7

JP6

JPL1

JPB1

JPL2

JPG1

JWD1

JPS1

LEDB7

JF2

J21

LE1

JPI2C1

JL1

JOH1

JI2C2

JI2C1

JSD1

JSTBY1

SFP2

FAN1

FAN6

FAN4

FAN5

FAN3

JTPM1

JBT1

LEDS1
LEDS2

LE2

JF1

I-SATA4 I-SATA2

S-SATA3S-SATA2

I-SATA5

I-SATA3

S-SATA0

S-SATA1

I-SATA0

SXB2

SXB1_2

SXB1_1

SXB1_3

SFP1

SXB1D

SXB1C

SCU-SGPIO1

T-SGPIO2

T-SGPIO1

COM1

USB0/1

SAS4~7

P2-DIMMF1

P2-DIMMF2

SXB1B

SXB1A

USB4/5

USB2/3

COM2

P1-DIMMD1

BATTERY

P1-DIMMD2

P1-DIMMC1

P1-DIMMC2

P2-DIMME1

UID

P2-DIMME2

TLAN1

LAN2

LAN1

P1-DIMMB2

P1-DIMMB1

P2-DIMMH2

P2-DIMMH1

P1-DIMMA2

IPMI_LAN

P2-DIMMG2

P2-DIMMG1

VGA1

KB/MOUSE

JIPMB1

I-SATA1

SAS0~3

FAN2

BIOS

JPW1JPW2

DS1

USB6

SP1

SAS CTRL

LAN
CTRL

BMC

LAN
CTRL

Intel
PCH

X9DRW-7TPF/iTPF

Rev. 1.01

JPW3

TLAN2

LEM2

JPME1

JPME2

CPU1

CPU2

JS3

P1-DIMMA1

Warning: To prevent damage to the power supply

or motherboard, please use a power supply that

contains a 24-pin and two 8-pin and one 4-pin

power connectors. Be sure to connect these power

supply connectors to the 24-pin power connector

(JPW1), and the 8-pin power connectors (JPW2/

JPW3) on the motherboard.

2-7 Connecting Cables

Power Connectors

A 24-pin main power supply connector(JPW1),

and two 8-pin power connectors (JPW2/JPW3)

are located on the motherboard. These power

connectors meet the SSI EPS 12V specica-

tion. These power connectors must also be

connected to your power supply. See the table

on the right for pin denitions.

ATX Power 24-pin Connector

PinDenitions

Pin# Denition Pin # Denition

13 +3.3V 1 +3.3V

14 -12V 2 +3.3V

15 COM 3 COM

16 PS_ON 4 +5V

17 COM 5 COM

18 COM 6 +5V

19 COM 7 COM

20 Res (NC) 8 PWR_OK

21 +5V 9 5VSB

22 +5V 10 +12V

23 +5V 11 +12V

24 COM 12 +3.3V

12V 8-pin PWR

Connector

PinDenitions

Pins Denition

1~ 4 Ground

5 ~8 +12V

A. JPW1: 24-pin ATX PWR

(Req'd)

B. JPW2: 8-pin PWR (Req'd)

C. JPW3: 8-pin PWR (Req'd)

A

B

C

(Required)

Chapter 2: Installation

2-29

JP7

JP6

JPL1

JPB1

JPL2

JPG1

JWD1

JPS1

LEDB7

JF2

J21

LE1

JPI2C1

JL1

JOH1

JI2C2

JI2C1

JSD1

JSTBY1

SFP2

FAN1

FAN6

FAN4

FAN5

FAN3

JTPM1

JBT1

LEDS1

LEDS2

LE2

JF1

I-SATA4 I-SATA2

S-SATA3S-SATA2

I-SATA5

I-SATA3

S-SATA0

S-SATA1

I-SATA0

SXB2

SXB1_2

SXB1_1

SXB1_3

SFP1

SXB1D

SXB1C

SCU-SGPIO1

T-SGPIO2

T-SGPIO1

COM1

USB0/1

SAS4~7

P2-DIMMF1

P2-DIMMF2

SXB1B

SXB1A

USB4/5

USB2/3

COM2

P1-DIMMD1

BATTERY

P1-DIMMD2

P1-DIMMC1

P1-DIMMC2

P2-DIMME1

UID

P2-DIMME2

TLAN1

LAN2

LAN1

P1-DIMMB2

P1-DIMMB1

P2-DIMMH2

P2-DIMMH1

P1-DIMMA2

IPMI_LAN

P2-DIMMG2

P2-DIMMG1

VGA1

KB/MOUSE

JIPMB1

I-SATA1

SAS0~3

FAN2

BIOS

JPW1JPW2

DS1

USB6

SP1

SAS CTRL

LAN
CTRL

BMC

LAN
CTRL

Intel
PCH

X9DRW-7TPF/iTPF

Rev. 1.01

JPW3

TLAN2

LEM2

JPME1

JPME2

CPU1

CPU2

JS3

P1-DIMMA1

A. Fan 1

B. Fan 2

C. Fan 3

D. Fan 4

E. Fan 5

F. Fan 6

G. Chassis Intrusion

Chassis Intrusion

A Chassis Intrusion header is located

at JL1 on the motherboard. Attach an

appropriate cable from the chassis to

inform you of a chassis intrusion when

the chassis is opened.

Chassis Intrusion

PinDenitions

Pin# Denition

1 Intrusion Input

2 Ground

C

D

E

F

Fan Headers

This motherboard has six system/CPU

fan headers (Fan 1~Fan 6) on the moth-

erboard. All these 4-pin fans headers are

backward compatible with the traditional

3-pin fans. However, fan speed control

is available for 4-pin fans only. The fan

speeds are controlled by rmware ther-

mal management via IPMI interface. See

the table on the right for pin denitions.

Fan Header

PinDenitions

Pin# Denition

1 Ground

2 +12V

3 Tachometer

4 Pulse Width Modu-

lation (PWM)

G

A

B

2-30

X9DRW-7TPF/iTPF Motherboard User’s Manual

JP7

JP6

JPL1

JPB1

JPL2

JPG1

JWD1

JPS1

LEDB7

JF2

J21

LE1

JPI2C1

JL1

JOH1

JI2C2

JI2C1

JSD1

JSTBY1

SFP2

FAN1

FAN6

FAN4

FAN5

FAN3

JTPM1

JBT1

LEDS1
LEDS2

LE2

JF1

I-SATA4 I-SATA2

S-SATA3S-SATA2

I-SATA5

I-SATA3

S-SATA0

S-SATA1

I-SATA0

SXB2

SXB1_2

SXB1_1

SXB1_3

SFP1

SXB1D

SXB1C

SCU-SGPIO1

T-SGPIO2

T-SGPIO1

COM1

USB0/1

SAS4~7

P2-DIMMF1

P2-DIMMF2

SXB1B

SXB1A

USB4/5

USB2/3

COM2

P1-DIMMD1

BATTERY

P1-DIMMD2

P1-DIMMC1

P1-DIMMC2

P2-DIMME1

UID

P2-DIMME2

TLAN1

LAN2

LAN1

P1-DIMMB2

P1-DIMMB1

P2-DIMMH2

P2-DIMMH1

P1-DIMMA2

IPMI_LAN

P2-DIMMG2

P2-DIMMG1

VGA1

KB/MOUSE

JIPMB1

I-SATA1

SAS0~3

FAN2

BIOS

JPW1JPW2

DS1

USB6

SP1

SAS CTRL

LAN
CTRL

BMC

LAN
CTRL

Intel
PCH

X9DRW-7TPF/iTPF

Rev. 1.01

JPW3

TLAN2

LEM2

JPME1

JPME2

CPU1

CPU2

JS3

P1-DIMMA1

A. Internal Speaker (Buzz-

er)

B. OH LED

Internal Speaker

The Internal Speaker, located at SP1,

can be used to provide audible indica-

tions for various beep codes. See the

table on the right for pin denitions.

Refer to the layout below for the loca-

tions of the Internal Buzzer (SP1).

Internal Buzzer (SP1)

PinDenition

Pin# Denitions

Pin 1 Pos. (+) Beep In

Pin 2 Neg. (-) Alarm

Speaker

A

B

Overheat/Fan Fail LED

The JOH1 header is used to connect

an LED indicator to provide warnings

of chassis overheating and fan failure.

This LED will blink when a fan failure

occurs. Refer to the tables on right for

pin denitions.

OH/Fan Fail LED

Status

State Message

Solid Overheat

Blinking Fan Fail

OH/Fan LED

PinDenitions

Pin# Denition

1 5vDC

2 OH Active

Chapter 2: Installation

2-31

JP7

JP6

JPL1

JPB1

JPL2

JPG1

JWD1

JPS1

LEDB7

JF2

J21

LE1

JPI2C1

JL1

JOH1

JI2C2

JI2C1

JSD1

JSTBY1

SFP2

FAN1

FAN6

FAN4

FAN5

FAN3

JTPM1

JBT1

LEDS1
LEDS2

LE2

JF1

I-SATA4 I-SATA2

S-SATA3S-SATA2

I-SATA5

I-SATA3

S-SATA0

S-SATA1

I-SATA0

SXB2

SXB1_2

SXB1_1

SXB1_3

SFP1

SXB1D

SXB1C

SCU-SGPIO1

T-SGPIO2

T-SGPIO1

COM1

USB0/1

SAS4~7

P2-DIMMF1

P2-DIMMF2

SXB1B

SXB1A

USB4/5

USB2/3

COM2

P1-DIMMD1

BATTERY

P1-DIMMD2

P1-DIMMC1

P1-DIMMC2

P2-DIMME1

UID

P2-DIMME2

TLAN1

LAN2

LAN1

P1-DIMMB2

P1-DIMMB1

P2-DIMMH2

P2-DIMMH1

P1-DIMMA2

IPMI_LAN

P2-DIMMG2

P2-DIMMG1

VGA1

KB/MOUSE

JIPMB1

I-SATA1

SAS0~3

FAN2

BIOS

JPW1JPW2

DS1

USB6

SP1

SAS CTRL

LAN
CTRL

BMC

LAN
CTRL

Intel
PCH

X9DRW-7TPF/iTPF

Rev. 1.01

JPW3

TLAN2

LEM2

JPME1

JPME2

CPU1

CPU2

JS3

P1-DIMMA1

A. TPM/Port 80 Header

B. Standby PWR

TPM Header/Port 80

A Trusted Platform Module/Port 80

header is located at JTPM1 to provide

TPM support and Port 80 connection.

Use this header to enhance system

performance and data security. See

the table on the right for pin deni-

tions.

TPM/Port 80 Header

PinDenitions

Pin # Denition Pin # Denition

1 LCLK 2 GND

3 LFRAME# 4 <(KEY)>

5 LRESET# 6 +5V (X)

7 LAD 3 8 LAD 2

9 +3.3V 10 LAD1

11 LAD0 12 GND

13 SMB_CLK4 14 SMB_DAT4

15 +3V_DUAL 16 SERIRQ

17 GND 18 CLKRUN# (X)

19 LPCPD# 20 LDRQ# (X)

A

B

Standby Power Header

The Standby Power header is located

at JSTBY1 on the motherboard. See

the table on the right for pin deni-

tions. (You must also have a cable to

use this feature.)

Standby PWR

PinDenitions

Pin# Denition

1 +5V Standby

2 Ground

3 Wake-up

2-32

X9DRW-7TPF/iTPF Motherboard User’s Manual

JP7

JP6

JPL1

JPB1

JPL2

JPG1

JWD1

JPS1

LEDB7

JF2

J21

LE1

JPI2C1

JL1

JOH1

JI2C2

JI2C1

JSD1

JSTBY1

SFP2

FAN1

FAN6

FAN4

FAN5

FAN3

JTPM1

JBT1

LEDS1
LEDS2

LE2

JF1

I-SATA4 I-SATA2

S-SATA3S-SATA2

I-SATA5

I-SATA3

S-SATA0

S-SATA1

I-SATA0

SXB2

SXB1_2

SXB1_1

SXB1_3

SFP1

SXB1D

SXB1C

SCU-SGPIO1

T-SGPIO2

T-SGPIO1

COM1

USB0/1

SAS4~7

P2-DIMMF1

P2-DIMMF2

SXB1B

SXB1A

USB4/5

USB2/3

COM2

P1-DIMMD1

BATTERY

P1-DIMMD2

P1-DIMMC1

P1-DIMMC2

P2-DIMME1

UID

P2-DIMME2

TLAN1

LAN2

LAN1

P1-DIMMB2

P1-DIMMB1

P2-DIMMH2

P2-DIMMH1

P1-DIMMA2

IPMI_LAN

P2-DIMMG2

P2-DIMMG1

VGA1

KB/MOUSE

JIPMB1

I-SATA1

SAS0~3

FAN2

BIOS

JPW1JPW2

DS1

USB6

SP1

SAS CTRL

LAN
CTRL

BMC

LAN
CTRL

Intel
PCH

X9DRW-7TPF/iTPF

Rev. 1.01

JPW3

TLAN2

LEM2

JPME1

JPME2

CPU1

CPU2

JS3

P1-DIMMA1

B

A. JPI

2

C1

B. IPMB

A

Power SMB (I2C) Connector

Power System Management Bus (I2C)

Connector (JPI2C1) monitors power

supply, fan and system temperatures.

See the table on the right for pin

denitions.

PWR SMB

PinDenitions

Pin# Denition

1 Clock

2 Data

3 PWR Fail

4 Ground

5 +3.3V

IPMB

A System Management Bus header

for IPMI 2.0 is located at JIPMB1.

Connect the appropriate cable here

to use the IPMB I2C connection on

your system.

IPMB Header

PinDenitions

Pin# Denition

1 Data

2 Ground

3 Clock

4 No Connection

Chapter 2: Installation

2-33

JP7

JP6

JPL1

JPB1

JPL2

JPG1

JWD1

JPS1

LEDB7

JF2

J21

LE1

JPI2C1

JL1

JOH1

JI2C2

JI2C1

JSD1

JSTBY1

SFP2

FAN1

FAN6

FAN4

FAN5

FAN3

JTPM1

JBT1

LEDS1

LEDS2

LE2

JF1

I-SATA4 I-SATA2

S-SATA3S-SATA2

I-SATA5

I-SATA3

S-SATA0

S-SATA1

I-SATA0

SXB2

SXB1_2

SXB1_1

SXB1_3

SFP1

SXB1D

SXB1C

SCU-SGPIO1

T-SGPIO2

T-SGPIO1

COM1

USB0/1

SAS4~7

P2-DIMMF1

P2-DIMMF2

SXB1B

SXB1A

USB4/5

USB2/3

COM2

P1-DIMMD1

BATTERY

P1-DIMMD2

P1-DIMMC1

P1-DIMMC2

P2-DIMME1

UID

P2-DIMME2

TLAN1

LAN2

LAN1

P1-DIMMB2

P1-DIMMB1

P2-DIMMH2

P2-DIMMH1

P1-DIMMA2

IPMI_LAN

P2-DIMMG2

P2-DIMMG1

VGA1

KB/MOUSE

JIPMB1

I-SATA1

SAS0~3

FAN2

BIOS

JPW1JPW2

DS1

USB6

SP1

SAS CTRL

LAN
CTRL

BMC

LAN
CTRL

Intel
PCH

X9DRW-7TPF/iTPF

Rev. 1.01

JPW3

TLAN2

LEM2

JPME1

JPME2

CPU1

CPU2

JS3

P1-DIMMA1

A

B

C

A. T-SGPIO 1

B. T-SGPIO 2

C. S-SGPIO 1

D. DOM PWR

T-SGPIO/S-SGPIO Headers

Three Serial-Link General Purpose

Input/Output headers are located at

T-SGPIO 1/2 and S-SGPIO 1 on the

motherboard. T-SPGIO 1/2 support

I-SATA 0~5, and S-SGPIO 1 supports

S-SATA 0-3 connections. See the

table on the right for pin denitions.

Note: NC= No Connection

T-SGPIO/S-SGPIO

PinDenitions

Pin# Denition Pin Denition

1 NC 2 NC

3 Ground 4 Data

5 Load 6 Ground

7 Clock 8 NC

DOM Power Connector

A power connector for SATA DOM

(Disk_On_Module) devices is located

at JSD1. Connect an appropriate

cable here to provide power support

for your SATA DOM devices.

DOM PWR

PinDenitions

Pin# Denition

1 +5V

2 Ground

3 Ground

D

2-34

X9DRW-7TPF/iTPF Motherboard User’s Manual

Note: The NIC LED connections for LAN Ports 1/2 are located on JF1.

See Page 2-23 for details.

Front Panel LEDs for TLAN1/TLAN2

The Front Panel LED indicator for TLAN

port 1 is located on pins 3 and 4 of JF2,

and for TLAN port 2 is on pins 1 and 2

of JF2. Attach a NIC LED cable here to

display network activities and connection

speeds. Refer to the table on the right for

pin denitions.

JP7

JP6

JPL1

JPB1

JPL2

JPG1

JWD1

JPS1

LEDB7

JF2

J21

LE1

JPI2C1

JL1

JOH1

JI2C2

JI2C1

JSD1

JSTBY1

SFP2

FAN1

FAN6

FAN4

FAN5

FAN3

JTPM1

JBT1

LEDS1
LEDS2

LE2

JF1

I-SATA4 I-SATA2

S-SATA3S-SATA2

I-SATA5

I-SATA3

S-SATA0

S-SATA1

I-SATA0

SXB2

SXB1_2

SXB1_1

SXB1_3

SFP1

SXB1D

SXB1C

SCU-SGPIO1

T-SGPIO2

T-SGPIO1

COM1

USB0/1

SAS4~7

P2-DIMMF1

P2-DIMMF2

SXB1B

SXB1A

USB4/5

USB2/3

COM2

P1-DIMMD1

BATTERY

P1-DIMMD2

P1-DIMMC1

P1-DIMMC2

P2-DIMME1

UID

P2-DIMME2

TLAN1

LAN2

LAN1

P1-DIMMB2

P1-DIMMB1

P2-DIMMH2

P2-DIMMH1

P1-DIMMA2

IPMI_LAN

P2-DIMMG2

P2-DIMMG1

VGA1

KB/MOUSE

JIPMB1

I-SATA1

SAS0~3

FAN2

BIOS

JPW1JPW2

DS1

USB6

SP1

SAS CTRL

LAN
CTRL

BMC

LAN
CTRL

Intel
PCH

X9DRW-7TPF/iTPF

Rev. 1.01

JPW3

TLAN2

LEM2

JPME1

JPME2

CPU1

CPU2

JS3

P1-DIMMA1

A. TLAN 1/2 Front

Panel LED Indications

B. TLAN 1/2 Act/Link

LED

A

Front Panel LEDs for TLAN 1/TLAN 2

PinDenitions(JF2)

Pin# Denition Pin Denition

1 TLAN2

Activity

2 TLAN2 Link

3 TLAN1

Activity

4 TLAN1 Link

Activity/Link LEDs for TLAN1/TLAN2

LEDB7 indicates activity and connection

speeds for TLAN Ports 1/2. Refer to the

table on the right for pin denitions.

Act/Link LED for TLAN 1/TLAN 2

PinDenitions(LEDB7)

Pin# LAN#3 Speed Pin# LAN#4 Speed

1/2 Amber: 1G 3/4 Amber: 1G

1/2 Green: 10G 3/4 Green: 10G

B

Chapter 2: Installation

2-35

JP7

JP6

JPL1

JPB1

JPL2

JPG1

JWD1

JPS1

LEDB7

JF2

J21

LE1

JPI2C1

JL1

JOH1

JI2C2

JI2C1

JSD1

JSTBY1

SFP2

FAN1

FAN6

FAN4

FAN5

FAN3

JTPM1

JBT1

LEDS1

LEDS2

LE2

JF1

I-SATA4 I-SATA2

S-SATA3S-SATA2

I-SATA5

I-SATA3

S-SATA0

S-SATA1

I-SATA0

SXB2

SXB1_2

SXB1_1

SXB1_3

SFP1

SXB1D

SXB1C

SCU-SGPIO1

T-SGPIO2

T-SGPIO1

COM1

USB0/1

SAS4~7

P2-DIMMF1

P2-DIMMF2

SXB1B

SXB1A

USB4/5

USB2/3

COM2

P1-DIMMD1

BATTERY

P1-DIMMD2

P1-DIMMC1

P1-DIMMC2

P2-DIMME1

UID

P2-DIMME2

TLAN1

LAN2

LAN1

P1-DIMMB2

P1-DIMMB1

P2-DIMMH2

P2-DIMMH1

P1-DIMMA2

IPMI_LAN

P2-DIMMG2

P2-DIMMG1

VGA1

KB/MOUSE

JIPMB1

I-SATA1

SAS0~3

FAN2

BIOS

JPW1JPW2

DS1

USB6

SP1

SAS CTRL

LAN
CTRL

BMC

LAN
CTRL

Intel
PCH

X9DRW-7TPF/iTPF

Rev. 1.01

JPW3

TLAN2

LEM2

JPME1

JPME2

CPU1

CPU2

JS3

P1-DIMMA1

2-8 Jumper Settings

Explanation of Jumpers

To modify the operation of the motherboard,

jumpers can be used to choose between

optional settings. Jumpers create shorts be-

tween two pins to change the function of the

connector. Pin 1 is identied with a square

solder pad on the printed circuit board. See

the motherboard layout pages for jumper

locations.

Note: On two-pin jumpers,

"Closed" means the jumper is on

and "Open" means the jumper is

off the pins.

Connector

Pins

Jumper

Cap

Setting

Pin 1-2 short

3 2 1

3 2 1

GLAN/10G_LAN Enable/Disable

Use JPL1 to enable/disable LAN Ports 1/2,

and use JPL2 for TLAN Ports 1/2. See the

table on the right for jumper settings. The

default setting is Enabled.

LAN1/2, TLAN1/2 Enable

Jumper Settings

Jumper Setting Denition

1-2 Enabled (default)

2-3 Disabled

A. LAN Ports 1/2 Enable

B. TLAN Ports 1/2 Enable

A

B

2-36

X9DRW-7TPF/iTPF Motherboard User’s Manual

JP7

JP6

JPL1

JPB1

JPL2

JPG1

JWD1

JPS1

LEDB7

JF2

J21

LE1

JPI2C1

JL1

JOH1

JI2C2

JI2C1

JSD1

JSTBY1

SFP2

FAN1

FAN6

FAN4

FAN5

FAN3

JTPM1

JBT1

LEDS1
LEDS2

LE2

JF1

I-SATA4 I-SATA2

S-SATA3S-SATA2

I-SATA5

I-SATA3

S-SATA0

S-SATA1

I-SATA0

SXB2

SXB1_2

SXB1_1

SXB1_3

SFP1

SXB1D

SXB1C

SCU-SGPIO1

T-SGPIO2

T-SGPIO1

COM1

USB0/1

SAS4~7

P2-DIMMF1

P2-DIMMF2

SXB1B

SXB1A

USB4/5

USB2/3

COM2

P1-DIMMD1

BATTERY

P1-DIMMD2

P1-DIMMC1

P1-DIMMC2

P2-DIMME1

UID

P2-DIMME2

TLAN1

LAN2

LAN1

P1-DIMMB2

P1-DIMMB1

P2-DIMMH2

P2-DIMMH1

P1-DIMMA2

IPMI_LAN

P2-DIMMG2

P2-DIMMG1

VGA1

KB/MOUSE

JIPMB1

I-SATA1

SAS0~3

FAN2

BIOS

JPW1JPW2

DS1

USB6

SP1

SAS CTRL

LAN
CTRL

BMC

LAN
CTRL

Intel
PCH

X9DRW-7TPF/iTPF

Rev. 1.01

JPW3

TLAN2

LEM2

JPME1

JPME2

CPU1

CPU2

JS3

P1-DIMMA1

CMOS Clear

JBT1 is used to clear CMOS. Instead of pins, this "jumper" consists of contact pads

to prevent accidental clearing of CMOS. To clear CMOS, use a metal object such

as a small screwdriver to touch both pads at the same time to short the connection.

Always remove the AC power cord from the system before clearing CMOS.

Note 1: For an ATX power supply, you must completely shut down the

system, remove the AC power cord, and then short JBT1 to clear CMOS.

Note 2: Be sure to remove the onboard CMOS Battery before you short

JBT1 to clear CMOS.

Note 3: Clearing CMOS will also clear all passwords.

A. Clear CMOS

B. Watch Dog Enable

Watch Dog Enable/Disable

Watch Dog (JWD1) is a system monitor that

can reboot the system when a software appli-

cation hangs. Close pins 1-2 to reset the sys-

tem if an application hangs. Close pins 2-3 to

generate a non-maskable interrupt signal for

the application that hangs. See the table on

the right for jumper settings. Watch Dog must

also be enabled in the BIOS.

Watch Dog

Jumper Settings

Jumper Setting Denition

Pins 1-2 Reset (default)

Pins 2-3 NMI

Open Disabled

A

B

Chapter 2: Installation

2-37

JP7

JP6

JPL1

JPB1

JPL2

JPG1

JWD1

JPS1

LEDB7

JF2

J21

LE1

JPI2C1

JL1

JOH1

JI2C2

JI2C1

JSD1

JSTBY1

SFP2

FAN1

FAN6

FAN4

FAN5

FAN3

JTPM1

JBT1

LEDS1
LEDS2

LE2

JF1

I-SATA4 I-SATA2

S-SATA3S-SATA2

I-SATA5

I-SATA3

S-SATA0

S-SATA1

I-SATA0

SXB2

SXB1_2

SXB1_1

SXB1_3

SFP1

SXB1D

SXB1C

SCU-SGPIO1

T-SGPIO2

T-SGPIO1

COM1

USB0/1

SAS4~7

P2-DIMMF1

P2-DIMMF2

SXB1B

SXB1A

USB4/5

USB2/3

COM2

P1-DIMMD1

BATTERY

P1-DIMMD2

P1-DIMMC1

P1-DIMMC2

P2-DIMME1

UID

P2-DIMME2

TLAN1

LAN2

LAN1

P1-DIMMB2

P1-DIMMB1

P2-DIMMH2

P2-DIMMH1

P1-DIMMA2

IPMI_LAN

P2-DIMMG2

P2-DIMMG1

VGA1

KB/MOUSE

JIPMB1

I-SATA1

SAS0~3

FAN2

BIOS

JPW1JPW2

DS1

USB6

SP1

SAS CTRL

LAN
CTRL

BMC

LAN
CTRL

Intel
PCH

X9DRW-7TPF/iTPF

Rev. 1.01

JPW3

TLAN2

LEM2

JPME1

JPME2

CPU1

CPU2

JS3

P1-DIMMA1

A. VGA Enabled

B. BMC Enabled

VGA Enable

Jumper JPG1 allows the user to enable

the onboard VGA connector. The default

setting is 1-2 to enable the connection.

See the table on the right for jumper

settings.

VGA Enable

Jumper Settings

Jumper Setting Denition

1-2 Enabled (Default)

2-3 Disabled

BMC Enable

Jumper JPB1 allows you to enable the

embedded the Nuvoton BMC (Base-

board Management) Controller to pro-

vide IPMI 2.0/KVM support on the

motherboard. See the table on the right

for jumper settings.

BMC Enable

Jumper Settings

Jumper Setting Denition

Pins 1-2 BMC Enable (Default)

Pins 2-3 Normal

A

B

2-38

X9DRW-7TPF/iTPF Motherboard User’s Manual

JP7

JP6

JPL1

JPB1

JPL2

JPG1

JWD1

JPS1

LEDB7

JF2

J21

LE1

JPI2C1

JL1

JOH1

JI2C2

JI2C1

JSD1

JSTBY1

SFP2

FAN1

FAN6

FAN4

FAN5

FAN3

JTPM1

JBT1

LEDS1
LEDS2

LE2

JF1

I-SATA4 I-SATA2

S-SATA3S-SATA2

I-SATA5

I-SATA3

S-SATA0

S-SATA1

I-SATA0

SXB2

SXB1_2

SXB1_1

SXB1_3

SFP1

SXB1D

SXB1C

SCU-SGPIO1

T-SGPIO2

T-SGPIO1

COM1

USB0/1

SAS4~7

P2-DIMMF1

P2-DIMMF2

SXB1B

SXB1A

USB4/5

USB2/3

COM2

P1-DIMMD1

BATTERY

P1-DIMMD2

P1-DIMMC1

P1-DIMMC2

P2-DIMME1

UID

P2-DIMME2

TLAN1

LAN2

LAN1

P1-DIMMB2

P1-DIMMB1

P2-DIMMH2

P2-DIMMH1

P1-DIMMA2

IPMI_LAN

P2-DIMMG2

P2-DIMMG1

VGA1

KB/MOUSE

JIPMB1

I-SATA1

SAS0~3

FAN2

BIOS

JPW1JPW2

DS1

USB6

SP1

SAS CTRL

LAN
CTRL

BMC

LAN
CTRL

Intel
PCH

X9DRW-7TPF/iTPF

Rev. 1.01

JPW3

TLAN2

LEM2

JPME1

JPME2

CPU1

CPU2

JS3

P1-DIMMA1

A. JI

2

C1

B. JI

2

C2

C. SAS Enable

(X9DRW-7TPF)

A

I2C Bus to PCI-Exp. Slots

Jumpers JI2C1 and JI2C2 allow you

to connect the System Management

Bus (I2C) to PCI-Express slots. The

default setting is Open to disable the

connection. See the table on the right

for jumper settings.

I2C to PCI-Exp

Jumper Settings

Jumper Setting Denition

Closed Enabled

Open Disabled (Default)

B

C

SAS Enable (X9DRW-7TPF
Only)

Use Jumper JPS1 to enable or dis-

able onboard SAS connections. The

default setting is on pins 1/2 to enable

onboard SAS support. See the table

on the right for jumper settings.

SAS Enable

Jumper Settings

Jumper Setting Denition

Pins 1/2 Enabled (Default)

Pins 2/3 Disabled

Chapter 2: Installation

2-39

Management Engine (ME) Recovery

Use Jumper JPME1 to select ME Firm-

ware Recovery mode, which will limit

resource allocation for essential system

operation only in order to maintain nor-

mal power operation and management.

In the single operation mode, online

upgrade will be available via Recovery

mode. See the table on the right for

jumper settings.

ME Recovery

Jumper Settings

Jumper Setting Denition

1-2 Normal (Default)

2-3 ME Recovery

Manufacture Mode Select

Close pin 2 and pin 3 of Jumper JPME2

to bypass SPI ash security and force

the system to operate in the Manufac-

ture mode, allowing the user to ash the

system rmware from a host server for

system setting modications. See the

table on the right for jumper settings.

ME Mode Select

Jumper Settings

Jumper Setting Denition

1-2 Normal (Default)

2-3 Manufacture Mode

A. JPME1

B. JPME2

JP7

JP6

JPL1

JPB1

JPL2

JPG1

JWD1

JPS1

LEDB7

JF2

J21

LE1

JPI2C1

JL1

JOH1

JI2C2

JI2C1

JSD1

JSTBY1

SFP2

FAN1

FAN6

FAN4

FAN5

FAN3

JTPM1

JBT1

LEDS1

LEDS2

LE2

JF1

I-SATA4 I-SATA2

S-SATA3S-SATA2

I-SATA5

I-SATA3

S-SATA0

S-SATA1

I-SATA0

SXB2

SXB1_2

SXB1_1

SXB1_3

SFP1

SXB1D

SXB1C

SCU-SGPIO1

T-SGPIO2

T-SGPIO1

COM1

USB0/1

SAS4~7

P2-DIMMF1

P2-DIMMF2

SXB1B

SXB1A

USB4/5

USB2/3

COM2

P1-DIMMD1

BATTERY

P1-DIMMD2

P1-DIMMC1

P1-DIMMC2

P2-DIMME1

UID

P2-DIMME2

TLAN1

LAN2

LAN1

P1-DIMMB2

P1-DIMMB1

P2-DIMMH2

P2-DIMMH1

P1-DIMMA2

IPMI_LAN

P2-DIMMG2

P2-DIMMG1

VGA1

KB/MOUSE

JIPMB1

I-SATA1

SAS0~3

FAN2

BIOS

JPW1JPW2

DS1

USB6

SP1

SAS CTRL

LAN
CTRL

BMC

LAN
CTRL

Intel
PCH

X9DRW-7TPF/iTPF

Rev. 1.01

JPW3

TLAN2

LEM2

JPME1

JPME2

CPU1

CPU2

JS3

P1-DIMMA1

A

B

2-40

X9DRW-7TPF/iTPF Motherboard User’s Manual

Note: For TLAN 1/2 LED indica-

tors, please refer to JF2 and LEB7

on Page 2-34.

JP7

JP6

JPL1

JPB1

JPL2

JPG1

JWD1

JPS1

LEDB7

JF2

J21

LE1

JPI2C1

JL1

JOH1

JI2C2

JI2C1

JSD1

JSTBY1

SFP2

FAN1

FAN6

FAN4

FAN5

FAN3

JTPM1

JBT1

LEDS1
LEDS2

LE2

JF1

I-SATA4 I-SATA2

S-SATA3S-SATA2

I-SATA5

I-SATA3

S-SATA0

S-SATA1

I-SATA0

SXB2

SXB1_2

SXB1_1

SXB1_3

SFP1

SXB1D

SXB1C

SCU-SGPIO1

T-SGPIO2

T-SGPIO1

COM1

USB0/1

SAS4~7

P2-DIMMF1

P2-DIMMF2

SXB1B

SXB1A

USB4/5

USB2/3

COM2

P1-DIMMD1

BATTERY

P1-DIMMD2

P1-DIMMC1

P1-DIMMC2

P2-DIMME1

UID

P2-DIMME2

TLAN1

LAN2

LAN1

P1-DIMMB2

P1-DIMMB1

P2-DIMMH2

P2-DIMMH1

P1-DIMMA2

IPMI_LAN

P2-DIMMG2

P2-DIMMG1

VGA1

KB/MOUSE

JIPMB1

I-SATA1

SAS0~3

FAN2

BIOS

JPW1JPW2

DS1

USB6

SP1

SAS CTRL

LAN
CTRL

BMC

LAN
CTRL

Intel
PCH

X9DRW-7TPF/iTPF

Rev. 1.01

JPW3

TLAN2

LEM2

JPME1

JPME2

CPU1

CPU2

JS3

P1-DIMMA1

2-9 Onboard LED Indicators

A. GLAN 1/2 LEDs

B. IPMI LAN LEDs

C. TLAN 1/2 LED

IPMI Dedicated LAN LEDs

In addition to the Gigabit Ethernet ports,

an IPMI Dedicated LAN is also located

above the Backplane USB ports 0/1 on the

motherboard. The amber LED on the right

indicates activity, while the green LED on

the left indicates the speed of the connec-

tion. See the table on the right for more

information.

LAN 1/LAN 2

Link LED

Activity LED

IPMI LAN

IPMI LAN Link LED (Left) &

Activity LED (Right)

Color/State Denition

Link (Left) Green: Solid 100 Mbps

Activity (Right) Amber: Blinking Active

GLAN 1/2 LEDs

The LAN 1/2 ports are located on the IO

Backplane. Each Ethernet LAN port has

two LEDs. The yellow LED on the right

indicates activity. The Link LED on the left

may be green, amber or off to indicate the

speed. See the tables on the right for more

information.

Activity LED

GLAN/TLAN Link Indicator

LED Settings

LED Color Denition

Off No Connection/10 Mbps/100

Mbps

Amber 1 Gbps

Green 10 Gbps.

Link LED

GLAN/TLAN Activity Indicator

LED Settings

Color Status Denition

Yellow Flashing Active

Rear View (LAN Ports 1/2)

A

B

C

Chapter 2: Installation

2-41

JP7

JP6

JPL1

JPB1

JPL2

JPG1

JWD1

JPS1

LEDB7

JF2

J21

LE1

JPI2C1

JL1

JOH1

JI2C2

JI2C1

JSD1

JSTBY1

SFP2

FAN1

FAN6

FAN4

FAN5

FAN3

JTPM1

JBT1

LEDS1
LEDS2

LE2

JF1

I-SATA4 I-SATA2

S-SATA3S-SATA2

I-SATA5

I-SATA3

S-SATA0

S-SATA1

I-SATA0

SXB2

SXB1_2

SXB1_1

SXB1_3

SFP1

SXB1D

SXB1C

SCU-SGPIO1

T-SGPIO2

T-SGPIO1

COM1

USB0/1

SAS4~7

P2-DIMMF1

P2-DIMMF2

SXB1B

SXB1A

USB4/5

USB2/3

COM2

P1-DIMMD1

BATTERY

P1-DIMMD2

P1-DIMMC1

P1-DIMMC2

P2-DIMME1

UID

P2-DIMME2

TLAN1

LAN2

LAN1

P1-DIMMB2

P1-DIMMB1

P2-DIMMH2

P2-DIMMH1

P1-DIMMA2

IPMI_LAN

P2-DIMMG2

P2-DIMMG1

VGA1

KB/MOUSE

JIPMB1

I-SATA1

SAS0~3

FAN2

BIOS

JPW1JPW2

DS1

USB6

SP1

SAS CTRL

LAN
CTRL

BMC

LAN
CTRL

Intel
PCH

X9DRW-7TPF/iTPF

Rev. 1.01

JPW3

TLAN2

LEM2

JPME1

JPME2

CPU1

CPU2

JS3

P1-DIMMA1

Onboard Power LED

An Onboard Power LED is located at LE1

on the motherboard. When this LED is on,

the system is on. Be sure to turn off the

system and unplug the power cord before

removing or installing components. See

the tables on the right for more informa-

tion.

Onboard PWR LED Indicator (LE1)

LED Settings

LED Color Status

Off System Off (PWR cable

not connected)

Green System On

Green:
Flashing
Quickly

ACPI S1 State

Green:
Flashing
Slowly

ACPI S3 (STR) State

A. PWR LED

B. Rear UID LED

A

B

Rear UID LED

The rear UID LED is located at LE2 on

the rear of the motherboard. This LED

is used in conjunction with the rear UID

switch to provide easy identication of a

system that might be in need of service.

Refer to UID Switch on Page 2-22 for

more information.

UID LED

Status

Color/State OS Status

Blue: On Windows OS Unit Identied

Blue:
Blinking

Linux OS Unit Identied

2-42

X9DRW-7TPF/iTPF Motherboard User’s Manual

JP7

JP6

JPL1

JPB1

JPL2

JPG1

JWD1

JPS1

LEDB7

JF2

J21

LE1

JPI2C1

JL1

JOH1

JI2C2

JI2C1

JSD1

JSTBY1

SFP2

FAN1

FAN6

FAN4

FAN5

FAN3

JTPM1

JBT1

LEDS1

LEDS2

LE2

JF1

I-SATA4 I-SATA2

S-SATA3S-SATA2

I-SATA5

I-SATA3

S-SATA0

S-SATA1

I-SATA0

SXB2

SXB1_2

SXB1_1

SXB1_3

SFP1

SXB1D

SXB1C

SCU-SGPIO1

T-SGPIO2

T-SGPIO1

COM1

USB0/1

SAS4~7

P2-DIMMF1

P2-DIMMF2

SXB1B

SXB1A

USB4/5

USB2/3

COM2

P1-DIMMD1

BATTERY

P1-DIMMD2

P1-DIMMC1

P1-DIMMC2

P2-DIMME1

UID

P2-DIMME2

TLAN1

LAN2

LAN1

P1-DIMMB2

P1-DIMMB1

P2-DIMMH2

P2-DIMMH1

P1-DIMMA2

IPMI_LAN

P2-DIMMG2

P2-DIMMG1

VGA1

KB/MOUSE

JIPMB1

I-SATA1

SAS0~3

FAN2

BIOS

JPW1JPW2

DS1

USB6

SP1

SAS CTRL

LAN
CTRL

BMC

LAN
CTRL

Intel
PCH

X9DRW-7TPF/iTPF

Rev. 1.01

JPW3

TLAN2

LEM2

JPME1

JPME2

CPU1

CPU2

JS3

P1-DIMMA1

SAS Activity LED Indicators

Status

Color/State SAS Status

LEDS1
Green: Blinking

SAS: Active
(Normal)

A

SAS Activity LED (X9DRW-7TPF Only)

SAS Activity LED indicator is located at LEDS1

on the motherboard. When the LEDS1 is blink-

ing, SAS operates properly. See the table on the

right for more information.

A. LEDS1: SAS Activity LED

(X9DRW-7TPF)

B. LEDS2: SAS Fault LED

(X9DRW-7TPF)

B

SAS Fault LED Indicators

Status

Color/State SAS Status

LEDS2: On Error(s) in SAS

SAS Fault LED (X9DRW-7TPF Only)

SAS Fault LED indicator is located at LEDS2

on the X9DRW-7TPF. When LEDS2 is on, SAS

does not function properly. See the table on the

right for more information.

Chapter 2: Installation

2-43

BMC Heartbeat LED

Status

Color/State Denition

Green:
Blinking

BMC: Normal

BMC Heartbeat LED

A BMC Heartbeat LED is located at LEM2

on the motherboard. When LEM2 is blink-

ing, BMC functions normally. See the

table on the right for more information.

JP7

JP6

JPL1

JPB1

JPL2

JPG1

JWD1

JPS1

LEDB7

JF2

J21

LE1

JPI2C1

JL1

JOH1

JI2C2

JI2C1

JSD1

JSTBY1

SFP2

FAN1

FAN6

FAN4

FAN5

FAN3

JTPM1

JBT1

LEDS1

LEDS2

LE2

JF1

I-SATA4 I-SATA2

S-SATA3S-SATA2

I-SATA5

I-SATA3

S-SATA0

S-SATA1

I-SATA0

SXB2

SXB1_2

SXB1_1

SXB1_3

SFP1

SXB1D

SXB1C

SCU-SGPIO1

T-SGPIO2

T-SGPIO1

COM1

USB0/1

SAS4~7

P2-DIMMF1

P2-DIMMF2

SXB1B

SXB1A

USB4/5

USB2/3

COM2

P1-DIMMD1

BATTERY

P1-DIMMD2

P1-DIMMC1

P1-DIMMC2

P2-DIMME1

UID

P2-DIMME2

TLAN1

LAN2

LAN1

P1-DIMMB2

P1-DIMMB1

P2-DIMMH2

P2-DIMMH1

P1-DIMMA2

IPMI_LAN

P2-DIMMG2

P2-DIMMG1

VGA1

KB/MOUSE

JIPMB1

I-SATA1

SAS0~3

FAN2

BIOS

JPW1JPW2

DS1

USB6

SP1

SAS CTRL

LAN
CTRL

BMC

LAN
CTRL

Intel
PCH

X9DRW-7TPF/iTPF

Rev. 1.01

JPW3

TLAN2

LEM2

JPME1

JPME2

CPU1

CPU2

JS3

P1-DIMMA1

A. BMC Heartbeat LED

A

2-44

X9DRW-7TPF/iTPF Motherboard User’s Manual

JP7

JP6

JPL1

JPB1

JPL2

JPG1

JWD1

JPS1

LEDB7

JF2

J21

LE1

JPI2C1

JL1

JOH1

JI2C2

JI2C1

JSD1

JSTBY1

SFP2

FAN1

FAN6

FAN4

FAN5

FAN3

JTPM1

JBT1

LEDS1
LEDS2

LE2

JF1

I-SATA4 I-SATA2

S-SATA3S-SATA2

I-SATA5

I-SATA3

S-SATA0

S-SATA1

I-SATA0

SXB2

SXB1_2

SXB1_1

SXB1_3

SFP1

SXB1D

SXB1C

SCU-SGPIO1

T-SGPIO2

T-SGPIO1

COM1

USB0/1

SAS4~7

P2-DIMMF1

P2-DIMMF2

SXB1B

SXB1A

USB4/5

USB2/3

COM2

P1-DIMMD1

BATTERY

P1-DIMMD2

P1-DIMMC1

P1-DIMMC2

P2-DIMME1

UID

P2-DIMME2

TLAN1

LAN2

LAN1

P1-DIMMB2

P1-DIMMB1

P2-DIMMH2

P2-DIMMH1

P1-DIMMA2

IPMI_LAN

P2-DIMMG2

P2-DIMMG1

VGA1

KB/MOUSE

JIPMB1

I-SATA1

SAS0~3

FAN2

BIOS

JPW1JPW2

DS1

USB6

SP1

SAS CTRL

LAN
CTRL

BMC

LAN
CTRL

Intel
PCH

X9DRW-7TPF/iTPF

Rev. 1.01

JPW3

TLAN2

LEM2

JPME1

JPME2

CPU1

CPU2

JS3

P1-DIMMA1

Note: For more information on SATA HostRAID conguration, please refer

to the Intel SATA HostRAID User's Guide posted on our website @ http://

www.supermicro.com..

SATA2.0/SATA3.0

PinDenitions

Pin# Denition

1 Ground

2 TX_P

3 TX_N

4 Ground

5 RX_N

6 RX_P

7 Ground

A. I-SATA0

B. I-SATA1

C. I-SATA2

D. I-SATA3

E. I-SATA4

F. I-SATA5 (also used

as Wireless SATA

DOM)

G.S-SATA0

H. S-SATA1

I. S-SATA2

J. S-SATA3

Serial ATA Ports

There are two SATA 3.0 Ports (I-SATA0/1)

and eight SATA 2.0 Ports (I-SATA 2-5,

S-SATA 0-3) on the motherboard. These

ports provide serial-link signal connec-

tions, which are faster than the connec-

tions of Parallel ATA. In addition, I-SATA5

also functions as a wireless SATA DOM

that can be used to provide power supply

to onboard SATA DOM devices. See the

table on the right for pin denitions.

C

D

E

2-10 SATA/SAS Connections

F

A

G

H

B

I

J

Chapter 2: Installation

2-45

JP7

JP6

JPL1

JPB1

JPL2

JPG1

JWD1

JPS1

LEDB7

JF2

J21

LE1

JPI2C1

JL1

JOH1

JI2C2

JI2C1

JSD1

JSTBY1

SFP2

FAN1

FAN6

FAN4

FAN5

FAN3

JTPM1

JBT1

LEDS1
LEDS2

LE2

JF1

I-SATA4 I-SATA2

S-SATA3S-SATA2

I-SATA5

I-SATA3

S-SATA0

S-SATA1

I-SATA0

SXB2

SXB1_2

SXB1_1

SXB1_3

SFP1

SXB1D

SXB1C

SCU-SGPIO1

T-SGPIO2

T-SGPIO1

COM1

USB0/1

SAS4~7

P2-DIMMF1

P2-DIMMF2

SXB1B

SXB1A

USB4/5

USB2/3

COM2

P1-DIMMD1

BATTERY

P1-DIMMD2

P1-DIMMC1

P1-DIMMC2

P2-DIMME1

UID

P2-DIMME2

TLAN1

LAN2

LAN1

P1-DIMMB2

P1-DIMMB1

P2-DIMMH2

P2-DIMMH1

P1-DIMMA2

IPMI_LAN

P2-DIMMG2

P2-DIMMG1

VGA1

KB/MOUSE

JIPMB1

I-SATA1

SAS0~3

FAN2

BIOS

JPW1JPW2

DS1

USB6

SP1

SAS CTRL

LAN
CTRL

BMC

LAN
CTRL

Intel
PCH

X9DRW-7TPF/iTPF

Rev. 1.01

JPW3

TLAN2

LEM2

JPME1

JPME2

CPU1

CPU2

JS3

P1-DIMMA1

Note: For more information on LSI SAS RAID conguration, please refer

to the LSI MegaRAID User's Guide posted on our website @ http://www.

supermicro.com..

SAS Connections

PinDenitions

Pin# Denition

1 Ground

2 TX_P

3 TX_N

4 Ground

5 RX_N

6 RX_P

7 Ground

A. SAS 0-3 (X9DRW-7TPF)

B. SAS 4-7 (X9DRW-7TPF)

A

SAS Ports (X9DRW-7TPF Only)

Eight Serial_Attached_SCSI Ports (SAS

0-3, 4-7) located on the X9DRW-7TPF

series motherboard to provide serial link

connections. These ports are supported

by the Intel LSI 2208 Controller. See the

table on the right for pin denitions.

B

2-46

X9DRW-7TPF/iTPF Motherboard User’s Manual

Notes

3-1

Chapter 3: Troubleshooting

Chapter 3

Troubleshooting

3-1 Troubleshooting Procedures

Use the following procedures to troubleshoot your system. If you have followed all

of the procedures below and still need assistance, refer to the ‘Technical Support

Procedures’ and/or ‘Returning Merchandise for Service’ section(s) in this chapter.

Note: Always disconnect the power cord before adding, changing or installing any

hardware components.

Before Power On

1. Make sure that there are no short circuits between the motherboard and

chassis.

2. Disconnect all ribbon/wire cables from the motherboard, including those for

the keyboard and mouse.

3. Remove all add-on cards.

4. Install CPU 1 rst (making sure it is fully seated) and connect the front panel

connectors to the motherboard.

No Power

1. Make sure that there are no short circuits between the motherboard and the

chassis.

2. Make sure that the ATX power connectors are properly connected

3. Check that the 115V/230V switch on the power supply is properly set, if avail-

able.

4. Turn the power switch on and off to test the system, if applicable.

5. The battery on your motherboard may be old. Check to verify that it still sup-

plies ~3VDC. If it does not, replace it with a new one.

3-2

X9DRW-7TPF/iTPF Motherboard User’s Manual

No Video

1. If the power is on, but you have no video, remove all the add-on cards and

cables.

2. Use the speaker to determine if any beep codes exist. Refer to Appendix A

for details on beep codes.

System Boot Failure

If the system does not display POST or does not respond after the power is turned

on, check the following:

1. Check for any error beep from the motherboard speaker.

•If there is no error beep, try to turn on the system without DIMM modules in-

stalled. If there is still no error beep, try to turn on the system again with only

one processor installed in CPU Socket#1. If there is still no error beep, replace

the motherboard.

•If there are error beeps, clear the CMOS settings by unplugging the power cord

and contacting both pads on the CMOS Clear Pad (JBT1). (Refer to Section

2-8 in Chapter 2.)

2. Remove all components from the motherboard, especially the DIMM modules.

Make sure that system power is on, and memory error beeps are activated.

3. Turn on the system with only one DIMM module installed. If the system

boots, check for bad DIMM modules or slots by following the Memory Errors

Troubleshooting procedure in this Chapter.

LosingtheSystem’sSetupConguration

1. Make sure that you are using a high quality power supply. A poor quality

power supply may cause the system to lose the CMOS setup information.

Refer to Section 2-7 for details on recommended power supplies.

2. The battery on your motherboard may be old. Check to verify that it still sup-

plies ~3VDC. If it does not, replace it with a new one.

3. If the above steps do not x the Setup Conguration problem, contact your

vendor for repairs.

3-3

Chapter 3: Troubleshooting

Memory Errors

When a No-Memory Beep Code is issued by the system, check the following:

1. Make sure that the memory modules are compatible with the system and that

the DIMM modules are properly and fully installed. (For memory compatibility,

refer to the Memory Compatibility Chart posted on our website @ http://www.

supermicro.com.)

2. Check if different speeds of DIMMs have been installed. It is strongly recom-

mended that you use the same RAM speed for all DIMMs in the system.

3. Make sure that you are using the correct type of Registered (RDIMM)/Load

Reduced (LRDIMM) ECC or Unbuffered (UDIMM) ECC-Non ECC DDR3 mod-

ules recommended by the manufacturer.

4. Check for bad DIMM modules or slots by swapping a single module among

all memory slots and check the results.

5. Make sure that all memory modules are fully seated in their slots. Follow the

instructions given in Section 2-4 in Chapter 2.

6. Please follow the instructions given in the DIMM Population Tables listed in

Section 2-4 to install your memory modules.

When the System Becomes Unstable

A. When the system becomes unstable during or after OS installation, check

the following:

1. CPU/BIOS support: Make sure that your CPU is supported, and you have the

latest BIOS installed in your system.

2. Memory support: Make sure that the memory modules are supported by test-

ing the modules using memtest86 or a similar utility.

Note: Refer to the product page on our website http://www.supermicro.

com for memory and CPU support and updates.

3. HDD support: Make sure that all hard disk drives (HDDs) work properly. Re-

place the bad HDDs with good ones.

4. System cooling: Check system cooling to make sure that all heatsink fans,

and CPU/system fans, etc., work properly. Check Hardware Monitoring set-

tings in the BIOS to make sure that the CPU and System temperatures are

3-4

X9DRW-7TPF/iTPF Motherboard User’s Manual

within the normal range. Also check the front panel Overheat LED, and make

sure that the Overheat LED is not on.

5. Adequate power supply: Make sure that the power supply provides adequate

power to the system. Make sure that all power connectors are connected.

Please refer to our website for more information on minimum power require-

ment.

6. Proper software support: Make sure that the correct drivers are used.

B. When the system becomes unstable before or during OS installation, check

the following:

1. Source of installation: Make sure that the devices used for installation are

working properly, including boot devices such as CD/DVD disc, CD/DVD-

ROM.

2. Cable connection: Check to make sure that all cables are connected and

working properly.

3. Using minimum conguration for troubleshooting: Remove all unnecessary

components (starting with add-on cards rst), and use minimum conguration

(with a CPU and a memory module installed) to identify the trouble areas.

Refer to the steps listed in Section A above for proper troubleshooting proce-

dures.

4. Identifying bad components by isolating them: If necessary, remove a compo-

nent in question from the chassis, and test it in isolation to make sure that it

works properly. Replace a bad component with a good one.

5. Check and change one component at a time instead of changing several

items at the same time. This will help isolate and identify the problem.

6. To nd out if a component is good, swap this component with a new one to

see if the system will work properly. If so, then the old component is bad.

You can also install the component in question in another system. If the new

system works, the component is good and the old system has problems.

3-5

Chapter 3: Troubleshooting

3-2 Technical Support Procedures

Before contacting Technical Support, please take the following steps. Also, please

note that as a motherboard manufacturer, Supermicro also sells motherboards

through its channels, so it is best to rst check with your distributor or reseller for

troubleshooting services. They should know of any possible problem(s) with the

specic system conguration that was sold to you.

1. Please go through the ‘Troubleshooting Procedures’ and 'Frequently Asked

Question' (FAQ) sections in this chapter or see the FAQs on our website

(http://www.supermicro.com/) before contacting Technical Support.

2. BIOS upgrades can be downloaded from our website (http://www.supermicro.

com).

3. If you still cannot resolve the problem, include the following information when

contacting Supermicro for technical support:

•Motherboard model and PCB revision number

•BIOS release date/version (This can be seen on the initial display when your

system rst boots up.)

•System conguration

4. An example of a Technical Support form is on our website at (http://www.

supermicro.com).

•Distributors: For immediate assistance, please have your account number ready

when placing a call to our technical support department. We can be reached by

e-mail at [email protected].

3-6

X9DRW-7TPF/iTPF Motherboard User’s Manual

3-3 Battery Removal and Installation

Battery Removal

To remove the onboard battery, follow the steps below:

1. Power off your system and unplug your power cable.

2. Locate the onboard battery as shown below.

3. Using a tool such as a pen or a small screwdriver, push the battery lock out-

wards to unlock it. Once unlocked, the battery will pop out from the holder.

4. Remove the battery.

Proper Battery Disposal

Warning: Please handle used batteries carefully. Do not damage the battery in any

way; a damaged battery may release hazardous materials into the environment. Do

not discard a used battery in the garbage or a public landll. Please comply with the

regulations set up by your local hazardous waste management agency to dispose of

your used battery properly.

Battery Installation

1. To install an onboard battery, follow the steps 1 & 2 above and continue

below:

2. Identify the battery's polarity. The positive (+) side should be facing up.

3. Insert the battery into the battery holder and push it down until you hear a

click to ensure that the battery is securely locked.

Warning: When replacing a battery, be sure to only replace it with the same type.

OR

3-7

Chapter 3: Troubleshooting

3-4 Frequently Asked Questions

Question: What are the various types of memory that my motherboard can

support?

Answer: The motherboard supports Registered (RDIMM)/Load Reduced (LRDIMM)

ECC or Unbuffered (UDIMM) ECC-Non ECC DDR3 modules. To enhance memory

performance, do not mix memory modules of different speeds and sizes. Please

follow all memory installation instructions given on Section 2-4 in Chapter 2.

Question: How do I update my BIOS?

It is recommended that you do not upgrade your BIOS if you are not experiencing

any problems with your system. Updated BIOS les are located on our website

at http://www.supermicro.com. Please check our BIOS warning message and the

information on how to update your BIOS on our website. Select your motherboard

model and download the BIOS le to your computer. Also, check the current BIOS

revision to make sure that it is newer than your BIOS before downloading. You can

choose from the zip le and the .exe le. If you choose the zip BIOS le, please

unzip the BIOS le onto a bootable USB device. Run the batch le using the format

AMI.bat lename.rom from your bootable USB device to ash the BIOS. Then, your

system will automatically reboot.

Warning: Do not shut down or reset the system while updating the BIOS to prevent

possible system boot failure!)

Note: The SPI BIOS chip used on this motherboard cannot be removed.

Send your motherboard back to our RMA Department at Supermicro for

repair. For BIOS Recovery instructions, please refer to the AMI BIOS

Recovery Instructions posted at http://www.supermicro.com.

Question: How do I handle the used battery?

Answer: Please handle used batteries carefully. Do not damage the battery in any

way; a damaged battery may release hazardous materials into the environment.

Do not discard a used battery in the garbage or a public landll. Please comply

with the regulations set up by your local hazardous waste management agency to

dispose of your used battery properly.

3-8

X9DRW-7TPF/iTPF Motherboard User’s Manual

3-5 Returning Merchandise for Service

A receipt or copy of your invoice marked with the date of purchase is required before

any warranty service will be rendered. You can obtain service by calling your ven-

dor for a Returned Merchandise Authorization (RMA) number. When returning the

motherboard to the manufacturer, the RMA number should be prominently displayed

on the outside of the shipping carton, and the shipping package is mailed prepaid

or hand-carried. Shipping and handling charges will be applied for all orders that

must be mailed when service is complete. For faster service, you can also request

a RMA authorization online (http://www.supermicro.com/RmaForm/).

This warranty only covers normal consumer use and does not cover damages in-

curred in shipping or from failure due to the alternation, misuse, abuse or improper

maintenance of products.

During the warranty period, contact your distributor rst for any product problems.

Chapter 4: AMI BIOS

4-1

Chapter 4

BIOS

4-1 Introduction

This chapter describes the AMI BIOS Setup utility for the X9DRW-7TPF/iTPF. It also

provides the instructions on how to navigate the AMI BIOS Setup utility screens.

The AMI ROM BIOS is stored in a Flash EEPROM and can be easily updated.

Starting BIOS Setup Utility

To enter the AMI BIOS Setup utility screens, press the <Del> key while the system

is booting up.

Note: In most cases, the <Del> key is used to invoke the AMI BIOS setup

screen. There are a few cases when other keys are used, such as <F3>,

<F4>, etc.

Each main BIOS menu option is described in this manual. The Main BIOS setup

menu screen has two main frames. The left frame displays all the options that can

be congured. Grayed-out options cannot be congured. Options in blue can be

congured by the user. The right frame displays the key legend. Above the key

legend is an area reserved for informational text. When an option is selected in

the left frame, it is highlighted in white. Often informational text will accompany it.

Note: The AMI BIOS has default informational messages built in. The

manufacturer retains the option to include, omit, or change any of these

informational messages.

The AMI BIOS Setup utility uses a key-based navigation system called "hot keys."

Most of the AMI BIOS setup utility "hot keys" can be used at any time during setup

navigation. These keys include <F3>, <F4>, <Enter>, <ESC>, arrow keys, etc.

Note 1: Options printed in Bold are default settings.

Note 2: <F3> is used to load optimal default settings. <F4> is used to save

the settings and exit the setup utility.

4-2

X9DRW-7TPF/iTPF Motherboard User’s Manual

HowToChangetheCongurationData

The conguration data that determines the system parameters may be changed by

entering the AMI BIOS Setup utility. This Setup utility can be accessed by pressing

<Delete> at the appropriate time during system boot.

Note: For AMI UEFI BIOS Recovery, please refer to the UEFI BIOS Re-

covery User Guide posted @http://www.supermicro.com/support/manuals/.

Starting the Setup Utility

Normally, the only visible Power-On Self-Test (POST) routine is the memory test.

As the memory is being tested, press the <Delete> key to enter the main menu of

the AMI BIOS Setup utility. From the main menu, you can access the other setup

screens. An AMI BIOS identication string is displayed at the left bottom corner of

the screen below the copyright message.

Warning: Do not upgrade the BIOS unless your system has a BIOS-related issue.

Flashing the wrong BIOS can cause irreparable damage to the system. In no event

shall the manufacturer be liable for direct, indirect, special, incidental, or consequential

damage arising from a BIOS update. If you have to update the BIOS, do not shut down

or reset the system while the BIOS is being updated to avoid possible boot failure.

4-2 Main Setup

When you rst enter the AMI BIOS Setup utility, you will enter the Main setup screen.

You can always return to the Main setup screen by selecting the Main tab on the

top of the screen. The Main BIOS Setup screen is shown below.

The AMI BIOS Main menu displays the following information:

Chapter 4: AMI BIOS

4-3

System Date/System Time

Use this option to change the system time and date. Highlight System Time or

System Date using the arrow keys. Enter new values through the keyboard and

press <Enter>. Press the <Tab> key to move between elds. The date must be

entered in Day MM/DD/YY format. The time is entered in HH:MM:SS format. (Note:

The time is in the 24-hour format. For example, 5:30 P.M. appears as 17:30:00.).

Supermicro X9DRW-7/iTPF

Version

This item displays the SMC version of the BIOS ROM used in this system.

Build Date

This item displays the date that the BIOS Setup utility was built.

Memory Information

Total Memory

This displays the amount of memory that is available in the system.

4-4

X9DRW-7TPF/iTPF Motherboard User’s Manual

4-3 AdvancedSetupCongurations

Select the Advanced tab to access the following submenu items.

Boot Feature

Quiet Boot

This feature allows the user to select bootup screen display between POST mes-

sages and the OEM logo. Select Disabled to display the POST messages. Select

Enabled to display the OEM logo instead of the normal POST messages. The op-

tions are Enabled and Disabled.

AddOn ROM Display Mode

Use this item to set the display mode for the Option ROM. Select Keep Current to

use the current AddOn ROM Display setting. Select Force BIOS to use the Option

ROM display mode set by the system BIOS. The options are Keep Current and

Force BIOS.

Bootup Num-Lock

Use this feature to set the Power-on state for the Numlock key. The options are

Off and On.

Wait For 'F1' If Error

Select Enabled to force the system to wait until the 'F1' key is pressed if an error

occurs. The options are Disabled and Enabled.

Chapter 4: AMI BIOS

4-5

Interrupt 19 Capture

Interrupt 19 is the software interrupt that handles the boot disk function. When this

item is set to Enabled, the ROM BIOS of the host adaptors will "capture" Interrupt 19

at bootup and allow the drives that are attached to these host adaptors to function

as bootable disks. If this item is set to Disabled, the ROM BIOS of the host adap-

tors will not capture Interrupt 19, and the drives attached to these adaptors will not

function as bootable devices. The options are Enabled and Disabled.

Re-try Boot

When set to Enabled, the BIOS will continuously retry to boot from the selected

boot type. The options are Disabled, Legacy Boot, and EFI Boot.

PowerConguration

Watch Dog Function

If enabled, the Watch Dog timer will allow the system to automatically reboot when

a non-recoverable error occurs that lasts for more than ve minutes. The options

are Enabled and Disabled.

Power Button Function

If this feature is set to Instant Off, the system will power off immediately as soon

as the user presses the power button. If this feature is set to 4 Seconds Override,

the system will power off when the user presses the power button for 4 seconds or

longer. The options are Instant Off and 4 Seconds Override.

Restore on AC Power Loss

Use this feature to set the power state after a power outage. Select Stay Off for the

system power to remain off after a power loss. Select Power On for the system

power to be turned on after a power loss. Select Last State to allow the system

to resume its last state before a power loss. The options are Stay Off, Power On,

and Last State.

CPUConguration

This submenu displays the information of the CPU as detected by the BIOS. It also

allows the user to congure CPU settings.

Socket 1 CPU Information, Socket 2 CPU Information

This submenu displays the following information regarding the CPUs installed

in Socket 1 and Socket 2.

•Type of CPU

4-6

X9DRW-7TPF/iTPF Motherboard User’s Manual

•CPU Signature

•Microcode Patch

•CPU Stepping

•Maximum / Minimum CPU Speed

•Processor Cores

•Intel HT (Hyper-Threading) Technology

•Intel VT-x Technology

•Intel SMX Technology

•L1 Data Cache / L1 Code Cache

•L2 Cache

•L3 Cache

CPU Speed

This item displays the speed of the CPU installed in Socket 1/Socket 2.

64-bit

This item indicates if the CPU installed in Socket 1 or Socket 2 supports 64-bit
technology.

Clock Spread Spectrum

Select Enable to enable Clock Spectrum support, which will allow the BIOS to moni-

tor and attempt to reduce the level of Electromagnetic Interference caused by the

components whenever needed. The options are Disabled and Enabled.

RTID (Record Types IDs)

This feature displays the total number of Record Type IDs for local and remote

pools. The options are Optimal and Alternate.

Hyper-threading

Select Enabled to support Intel Hyper-threading Technology to enhance CPU per-

formance. The options are Enabled and Disabled.

Chapter 4: AMI BIOS

4-7

Active Processor Cores

Set to Enabled to use a processor's second core and above. (Please refer to Intel's

website for more information.) The options are All, 1, 2, 4, and 6.

Limit CPUID Maximum

This feature allows the user to set the maximum CPU ID value. Enable this function

to boot the legacy operating systems that cannot support processors with extended

CPUID functions. The options are Enabled and Disabled (for the Windows OS).

Execute-Disable Bit (Available if supported by the OS & the CPU)

Select Enabled to enable the Execute Disable Bit which will allow the processor

to designate areas in the system memory where an application code can execute

and where it cannot, thus preventing a worm or a virus from ooding illegal codes

to overwhelm the processor or damage the system during an attack. The default is

Enabled. (Refer to Intel and Microsoft Web sites for more information.)

Intel® AES-NI

Select Enable to use the Intel Advanced Encryption Standard (AES) New Instruc-

tions (NI) to ensure data security. The options are Enabled and Disabled.

MLC Streamer Prefetcher (Available when supported by the CPU)

If set to Enabled, the MLC (mid-level cache) streamer prefetcher will prefetch

streams of data and instructions from the main memory to the L2 cache to improve

CPU performance. The options are Disabled and Enabled.

MLC Spatial Prefetch (Available when supported by the CPU)

If this feature is set to Disabled, The CPU prefetches the cache line for 64 bytes.

If this feature is set to Enabled the CPU fetches both cache lines for 128 bytes as

comprised. The options are Disabled and Enabled.

DCU Streamer Prefetcher (Available when supported by the CPU)

Select Enabled to support Data Cache Unit (DCU) prefetch of L1 data to speed

up data accessing and processing in the DCU to enhance CPU performance. The

options are Disabled and Enabled.

DCU IP Prefetcher

Select Enabled for DCU (Data Cache Unit) IP Prefetcher support, which will prefetch

IP addresses to improve network connectivity and system performance. The options

are Enabled and Disabled.

4-8

X9DRW-7TPF/iTPF Motherboard User’s Manual

Intel® Virtualization Technology (Available when supported by the CPU)

Select Enabled to support Intel Virtualization Technology, which will allow one

platform to run multiple operating systems and applications in independent parti-

tions, creating multiple "virtual" systems in one physical computer. The options

are Enabled and Disabled.

Note: If there is any change to this setting, you will need to power off and

restart the system for the change to take effect. Please refer to Intel’s

website for detailed information.)

CPUPowerManagementConguration

This submenu allows the user to congure the following CPU Power Manage-

ment settings.

Power Technology

Select Energy Efciency to support power-saving mode. Select Custom to cus-

tomize system power settings. Select Disabled to disable power-saving settings.
The options are Disabled, EnergyEfcient, and Custom. If the option is set to

Custom, the following items will display:

EIST (Available when Power Technology is set to Custom)

EIST (Enhanced Intel SpeedStep Technology) allows the system to au-

tomatically adjust processor voltage and core frequency to reduce power

consumption and heat dissipation. The options are Disabled, and Enabled.

Turbo Mode (Available when Power Technology is set to Custom and

EIST is enabled)

Select Enabled to use the Turbo Mode to boost system performance. The

options are Enabled and Disabled.

C1E Support (Available when Power Technology is set to Custom)

Select Enabled to enable Enhanced C1 Power State to boost system per-

formance. The options are Enabled and Disabled.

CPU C3 Report (Available when Power Technology is set to Custom)

Select Enabled to allow the BIOS to report the CPU C3 State (ACPI C2) to

the operating system. During the CPU C3 State, the CPU clock generator

is turned off. The options are Enabled and Disabled.

Chapter 4: AMI BIOS

4-9

CPU C6 Report (Available when Power Technology is set to Custom)

Select Enabled to allow the BIOS to report the CPU C6 State (ACPI C3) to

the operating system. During the CPU C6 State, the power to all cache is

turned off. The options are Enabled and Disabled.

CPU C7 Report (Available when Power Technology is set to Custom)

Select Enabled to allow the BIOS to report the CPU C7 State (ACPI C3) to

the operating system. CPU C7 State is a processor-specic low C-State.

The options are Enabled and Disabled.

Package C-State limit (Available when Power Technology is set to

Custom)

This feature allows the user to set the limit on the C-State package register.

The options are C0, C2, C6, and No Limit.

Energy/Performance Bias

Use this feature to select an appropriate fan setting to achieve maximum system

performance (with maximum cooling) or maximum energy efciency with maxi-

mum power saving). The fan speeds are controlled by the rmware management

via IPMI 2.0. The options are Performance, Balanced Performance, Balanced

Energy, and Energy Efcient.

Factory Long Duration Power Limit

This item displays the power limit (in watts) set by the manufacturer during which

long duration power is maintained.

Long Duration Power Limit

This item displays the power limit (in watts) set by the user during which long

duration power is maintained. The default setting is 0.

Factory Long Duration Maintained

This item displays the period of time (in seconds) set by the manufacturer during

which long duration power is maintained.

Long Duration Maintained

This item displays the period of time (in seconds) during which long duration

power is maintained. The default setting is 0.

Recommended Short Duration Power Limit

This item displays the short duration power settings (in watts) recommended by

the manufacturer.

4-10

X9DRW-7TPF/iTPF Motherboard User’s Manual

Short Duration Power Limit

During Turbo Mode, the system may exceed the processors default power setting

and exceed the Short Duration Power limit. By increasing this value, the proces-

sor can provide better performance for short duration. This item displays the time

period during which short duration power is maintained. The default setting is 0.

ChipsetConguration

North Bridge

This feature allows the user to congure the settings for the Intel North Bridge.

IntegratedIOConguration

Intel® VT-d

Select Enabled to enable Intel Virtualization Technology support for Direct I/O
VT-d by reporting the I/O device assignments to the VMM (Virtual Machine

Monitor) through the DMAR ACPI Tables. This feature offers fully-protected I/O

resource sharing across Intel platforms, providing greater reliability, security

and availability in networking and data-sharing. The options are Enabled and

Disabled.

Intel® I/OAT

Select Enabled to enable Intel I/OAT (I/O Acceleration Technology), which sig-

nicantly reduces CPU overhead by leveraging CPU architectural improvements

and freeing the system resource for other tasks. The default setting is Enabled.

DCA Support

When set to Enabled, this feature uses Intel's DCA (Direct Cache Access)

Technology to improve data transfer efciency. The options are Enabled and

Disabled.

Riser Card on SXB1, SXB2

When detected by the BIOS, these items display riser card information

IIO 1 PCIe Port Bifurcation Control

This submenu congures the following IO PCIe Port Bifurcation Control settings

for IIO 1 PCIe ports to determine how the available PCI-Express lanes to be

distributed between the PCI-Exp. Root Ports.

Chapter 4: AMI BIOS

4-11

IOU1-PCIe Port

This feature allows the user to set the bus speed between the IOU1 and the

PCI-Exp port. The options are x4x4 and x8.

IOU2-PCIe Port

This feature allows the user to set the bus speed between the IOU2 and the

PCI-Exp port. The options are x4x4x4x4, x4x4x8, x8x4x4, x8x8, and x16.

Port 2A Link Speed

Enable the desired type of PCI-Exp Generation support for this slot. The options

are GEN1, GEN2, and GEN3.

Port 2C Link Speed

Enable the desired type of PCI-Exp Generation support for this slot. The options

are GEN1, GEN2, and GEN3.

IOU3-PCIe Port

This feature allows the user to set the bus speed between the IOU2 and the

PCI-Exp port. The options are x4x4x4x4, x4x4x8, x8x4x4, x8x8, x16 and Auto.

IIO 2 PCIe Port Bifurcation Control

This submenu congures the following IO PCIe Port Bifurcation Control settings

for IIO 2 PCIe ports to determine how the available PCI-Express lanes to be

distributed between the PCI-Exp. Root Ports.

IOU1-PCIe Port

This feature allows the user to set the bus speed between the IOU1 and the

PCI-Exp port. The options are x4x4 and x8.

Port 1A Link Speed

Enable the desired type of PCI-Exp Generation support for this slot. The options

are GEN1, GEN2, and GEN3.

IOU2-PCIe Port

This feature allows the user to set the bus speed between the IOU2 and the

PCI-Exp port. The options are x4x4x4x4, x4x4x8, x8x4x4, x8x8, x16 and Auto.

IOU3-PCIe Port

This feature allows the user to set the bus speed between the IOU2 and the

PCI-Exp port. The options are x4x4x4x4, x4x4x8, x8x4x4, x8x8, x16 and Auto.

4-12

X9DRW-7TPF/iTPF Motherboard User’s Manual

QPIConguration

Current QPI Link

This item displays the current status of the QPI Link.

Current QPI Frequency

This item displays the frequency of the QPI Link.

Isoc

Select Enabled to enable Isochronous support to meet QoS (Quality of Service)

requirements. This feature is especially important for virtualization technology.

The options are Enabled and Disabled.

QPI (Quick Path Interconnect) Link Speed Mode

Use this feature to select data transfer speed for QPI Link connections. The

options are Slow and Fast.

QPI Link Frequency Select

Use this feature to select the desired QPI frequency. The options are Auto, 6.4

GT/s, 7.2 GT/s, and 8.0 GT/s.

DIMMConguration

This section displays the following DIMM information.

Current Memory Mode

This item displays the current memory mode.

Current Memory Speed

This item displays the current memory speed.

Mirroring

This item displays if memory mirroring is supported by the motherboard. Memory

mirroring creates a duplicate copy of the data stored in the memory to enhance

data security.

Sparing

This item displays if memory sparing is supported by the motherboard. Memory

sparing enhances system reliability, availability, and serviceability.

Chapter 4: AMI BIOS

4-13

DIMM Information

CPU Socket 1 DIMM Information, CPU Socket 2 DIMM Information

The status of the memory modules is displayed as detected by the BIOS.

Memory Mode

When Independent is selected, all DIMMs are available to the operating system.

When Mirroring is selected, the motherboard maintains two identical copies of all

data in memory for data backup. When Lock Step is selected, the motherboard

uses two areas of memory to run the same set of operations in parallel. The

default setting is Independent.

DRAM RAPL Mode

RAPL (Running Average Power Limit) provides mechanisms to enforce power

consumption limits on supported processors The options are Disabled, DRAM

RAPL MODE0, and DRAM RAPL MODE1.

Memory Energy/Performance

Use this feature to select a memory setting that maximizes either memory per-

formance or memory energy saving. The options are Performance and Energy

Saving.

DDR Speed

Use this feature to force a DDR3 memory module to run at a frequency other than

what is specied in the specication. The options are Force DDR3-800, Force

DDR3-1066, Force DDR3-1333, Force DDR3-1600 and Force SPD, and Auto.

Channel Interleaving

This feature selects from the different channel interleaving methods. The options

are Auto, 1 Way, 2 Way, 3, Way, and 4 Way.

Rank Interleaving

This feature allows the user to select a rank memory interleaving method. The

options are Auto, 1 Way, 2 Way, 4, Way, and 8 Way.

Patrol Scrub

Patrol Scrubbing is a process that allows the CPU to correct correctable memory

errors detected on a memory module and send the correction to the requestor

(the original source). When this item is set to Enabled, the IO hub will read and

write back one cache line every 16K cycles, if there is no delay caused by internal

processing. By using this method, roughly 64 GB of memory behind the IO hub

will be scrubbed every day. The options are Enabled and Disabled.

4-14

X9DRW-7TPF/iTPF Motherboard User’s Manual

Demand Scrub

Demand Scrubbing is a process that allows the CPU to correct correctable

memory errors found on a memory module. When the CPU or I/O issues a

demand-read command, and the read data from memory turns out to be a

correctable error, the error is corrected and sent to the requestor (the original

source). Memory is updated as well. Select Enabled to use Demand Scrubbing

for ECC memory correction. The options are Enabled and Disabled.

Data Scrambling

Select Enabled to enable data scrambling to ensure data security and integrity.

The options are Disabled and Enabled.

Device Tagging

Select Enabled to support device tagging. The options are Disabled and En-

abled.

Thermal Throttling

Throttling improves reliability and reduces power consumption in the proces-

sor via automatic voltage control during processor idle states. The options are

Disabled and CLTT (Closed Loop Thermal Throttling).

SouthBridgeConguration

This feature allows the user to congure the settings for the Intel PCH chip.

PCH Information

This feature displays the following PCH information.

Name: This item displays the name of the PCH chip.

Stepping: This item displays the status of the PCH stepping.

USB Devices: This item displays the USB devices detected by the BIOS.

All USB Devices

This feature enables all USB ports/devices. The options are Disabled and Enabled.

(If set to Enabled, EHCI Controller 1 and Controller 2 will appear.)

EHCI Controller 1/EHCI Controller 2 (Available when All USB Devices is set
to Enabled)

Select Enabled to enable EHCI (Enhanced Host Controller Interface) Controller 1

or Controller 2. The options are Disabled and Enabled.

Chapter 4: AMI BIOS

4-15

Legacy USB Support (Available when USB Functions is not Disabled)

Select Enabled to support legacy USB devices. Select Auto to disable legacy sup-

port if USB devices are not present. Select Disabled to have USB devices available

for EFI (Extensive Firmware Interface) applications only. The settings are Enabled

Disabled, and Auto.

Port 60/64 Emulation

Select Enabled to enable I/O port 60h/64h emulation support for the legacy USB

keyboard so that it can be fully supported by the operating systems that does not

recognize a USB device. The options are Disabled and Enabled.

EHCI Hand-Off

This item is for operating systems that do not support Enhanced Host Controller

Interface (EHCI) hand-off. When enabled, EHCI ownership change will be claimed

by the EHCI driver. The options are Disabled and Enabled.

SATAConguration

When this submenu is selected, the AMI BIOS automatically detects the presence

of IDE or SATA devices and displays the following items.

SATA Port0~SATA Port5: The AMI BIOS displays the status of each SATA port

as detected by the BIOS.

SATA Mode

Use this feature to congure SATA mode for a selected SATA port. The options are

Disabled, IDE Mode, AHCI Mode and RAID Mode. The following are displayed

depending on your selection:

IDE Mode

The following items are displayed when IDE Mode is selected:

Serial-ATA (SATA) Controller 0~1

Use this feature to activate or deactivate the SATA controller, and set the

compatibility mode. The options for SATA Controller 0 are Disabled, En-

hanced, and Compatible. The options for SATA Controller 1 are Disabled

and Enhanced.

4-16

X9DRW-7TPF/iTPF Motherboard User’s Manual

AHCI Mode

The following items are displayed when the AHCI Mode is selected.

Aggressive Link Power Management

When Enabled, the SATA AHCI controller manages the power usage of

the SATA link. The controller will put the link in a low power mode during

extended periods of I/O inactivity, and will return the link to an active state

when I/O activity resumes. The options are Enabled and Disabled.

Port 0~5 Hot Plug

Select Enabled to enable hot-plug support for a particular port, which will

allow the user to change a hardware component or device without shutting

down the system. The options are Enabled and Disabled.

Port 0~5 Staggered Spin Up

Select Enabled to enable Staggered Spin-up support to prevent excessive

power consumption caused by multiple HDDs spinning-up simultaneously.

The options are Enabled and Disabled.

RAID Mode

The following items are displayed when RAID Mode is selected:

Onboard SATA RAID Oprom/Driver

Use this feature to enable the onboard SATA Option ROM or EFI Driver.

The options are Enabled and Disabled.

Port 0~5 Hot Plug

Select Enabled to enable hot-plug support for the particular port. The options

are Enabled and Disabled.

SCU(StorageControlUnit)Conguration

Storage Controller Unit

Select Enabled to enable PCH SCU storage devices. The options are Disabled

and Enabled.

SCU RAID Option ROM

Select Enabled to support the onboard SCU Option ROM to boot up the system via

a storage device. The options are Disabled and Enabled.

SCU Port 0~SCU Port 3: The AMI BIOS will automatically detect the onboard SCU

devices and display the status of each SCU device as detected.

Chapter 4: AMI BIOS

4-17

PCIe/PCI/PnPConguration

Launch Storage OpROM Policy

Use this feature to select the Option ROM to boot the system when there are multiple

Option ROMs available in the system. The options are UEFI only and Legacy only.

PCI Latency Timer

Use this feature to set the latency Timer of each PCI device installed on a PCI bus.

Select 64 to set the PCI latency to 64 PCI clock cycles. The options are 32, 64, 96,

128, 160, 192, 224 and 248.

PERR# Generation

Select Enabled to allow a PCI device to generate a PERR number for a PCI Bus

Signal Error Event. The options are Enabled and Disabled.

SERR# Generation

Select Enabled to allow a PCI device to generate an SERR number for a PCI Bus

Signal Error Event. The options are Enabled and Disabled.

Maximum Payload

Select Auto to allow the system BIOS to automatically set the maximum payload

value for a PCI-E device to enhance system performance. The options are Auto,

128 Bytes and 256 Bytes.

Maximum Read Request

Select Auto to allow the system BIOS to automatically set the maximum Read

Request size for a PCI-E device to enhance system performance. The options are

Auto, 128 Bytes, 256 Bytes, 512 Bytes, 1024 Bytes, 2048 Bytes, and 4096 Bytes.

ASPM Support

This feature allows the user to set the Active State Power Management (ASPM)

level for a PCI-E device. Select Force L0s to force all PCI-E links to operate at L0s

state. Select Auto to allow the system BIOS to automatically set the ASPM level for

the system. Select Disabled to disable ASPM support. The options are Disabled,

Force L0s, and Auto.

Warning: Enabling ASPM support may cause some PCI-E devices to fail!

Above 4G Decoding (Available if the system supports 64-bit PCI decoding)

Select Enabled to decode a PCI device that supports 64-bit in the space above 4G

Address. The options are Enabled and Disabled.

4-18

X9DRW-7TPF/iTPF Motherboard User’s Manual

BCM57810S 10G OPROM

Select Enabled to boot the computer using the BCM57810S Ethernet device. The

options are Enabled and Disabled.

Onboard LAN Option ROM Select

Select iSCSI to use the iSCSI Option ROM to boot the computer using a network

device. Select PXE (Preboot Execution Environment) to use an PXE Option ROM

to boot the computer using a network device. The options are PXE and iSCSI.

Load Onboard LAN1 Option ROM, Load Onboard LAN2 Option ROM

Select Enabled to enable the onboard LAN1/LAN2 Option ROM. This is to boot

the computer using a network device. The default setting for LAN1 Option ROM is

Enabled, and the default setting for LAN2 Option ROM is Disabled.

Load Onboard SAS Option ROM

Select Enabled to use the onboard SAS Option ROM to boot the computer using

a SAS device. The options are Enabled and Disabled.

VGA Priority

This feature allows the user to select the graphics adapter to be used as the primary

boot device. The options are Onboard, and Offboard.

Network Stack

Select Enabled enable PXE (Preboot Execution Environment) or UEFI (Unied

Extensible Firmware Interface) for network stack support. The options are Enabled

and Disabled.

IPv4 PXE Support (Available when Network Stack is set to Enabled)

Set this item to Enabled to activate IPv4 PXE Support. The options are Enabled

and Disabled.

IPv6 PXE Support (Available when Network Stack is set to Enabled)

Set this item to Enabled to activate IPv6 PXE Support. The options are Enabled

and Disabled.

SuperIOConguration

Super IO Chip: This item displays the Super IO chip used in the motherboard.

Chapter 4: AMI BIOS

4-19

SerialPort1Conguration

Serial Port

Select Enabled to enable serial port 1. The options are Enabled and Disabled.

Device Settings

This item displays the settings of Serial Port 1.

Change Settings

This option species the base I/O port address and the Interrupt Request address

of Serial Port 1. Select Disabled to prevent the serial port from accessing any

system resources. When this option is set to Disabled, the serial port becomes

unavailable. The options are Auto, IO=3F8h; IRQ=4, IO=3F8h; IRQ=3, IO=2F8h;

IRQ=3, IO=3E8h; IRQ=5, IO=2E8h; IRQ=7, IO=3F8h; IRQ=3, 4, 5, 6, 7, 10, 11,

12; IO=2F8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12; IO=3E8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12;

IO=2E8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12;

Device Mode

Use this feature to select the desired mode for a serial port specied. The options

are Normal and High Speed.

SerialPort2Conguration

SOL Serial Port

Select Enabled to enable serial port 2. The options are Enabled and Disabled.

Device Settings

This item displays the settings of Serial Port 2.

SOL Change Settings

This option species the base I/O port address and the Interrupt Request address

of Serial Port 2. Select Disabled to prevent the serial port from accessing any

system resources. When this option is set to Disabled, the serial port becomes

unavailable. The options are Auto, IO=3F8h; IRQ=4, IO=3F8h; IRQ=3, IO=2F8h;

IRQ=3, IO=3E8h; IRQ=5, IO=2E8h; IRQ=7, IO=3F8h; IRQ=3, 4, 5, 6, 7, 10, 11,

12; IO=2F8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12; IO=3E8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12;

IO=2E8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12;

SOL Device Mode

Use this feature to select the desired mode for a serial port specied. The options

are Normal and High Speed.

4-20

X9DRW-7TPF/iTPF Motherboard User’s Manual

Serial Port 2 Attribute

Use this feature to select the attribute for this serial port. The options are SOL

(Serial Over LAN), and COM.

Serial Port Console Redirection

COM1, COM2

These two submenus allow the user to congure the following Console Redirection

settings for a COM Port specied by the user.

Console Redirection

Select Enabled to use a COM Port selected by the user for Console Redirection.

The options are Enabled and Disabled. The default setting for COM1 is Disabled,

and for COM2 is Enabled.

Console Redirection Settings

This feature allows the user to specify how the host computer will exchange

data with the client computer, which is the remote computer used by the user.

Terminal Type

This feature allows the user to select the target terminal emulation type for Con-

sole Redirection. Select VT100 to use the ASCII Character set. Select VT100+ to

add color and function key support. Select ANSI to use the Extended ASCII Char-

acter Set. Select VT-UTF8 to use UTF8 encoding to map Unicode characters

into one or more bytes. The options are VT100, VT100+, VT-UTF8, and ANSI.

Bits Per second

Use this feature to set the transmission speed for a serial port used in Console

Redirection. Make sure that the same speed is used in the host computer and the

client computer. A lower transmission speed may be required for long and busy

lines. The options are 9600, 19200, 38400, 57600 and 115200 (bits per second).

Data Bits

Use this feature to set the data transmission size for Console Redirection. The

options are 7 Bits and 8 Bits.

Parity

A parity bit can be sent along with regular data bits to detect data transmission

errors. Select Even if the parity bit is set to 0, and the number of 1's in data bits

is even. Select Odd if the parity bit is set to 0, and the number of 1's in data bits

is odd. Select None if you do not want to send a parity bit with your data bits

Chapter 4: AMI BIOS

4-21

in transmission. Select Mark to add a mark as a parity bit to be sent along with

the data bits. Select Space to add a Space as a parity bit to be sent with your

data bits. The options are None, Even, Odd, Mark and Space.

Stop Bits

A stop bit indicates the end of a serial data packet. Select 1 Stop Bit for standard

serial data communication. Select 2 Stop Bits if slower devices are used. The

options are 1 and 2.

Flow Control

This feature allows the user to set the ow control for Console Redirection to

prevent data loss caused by buffer overow. Send a "Stop" signal to stop send-

ing data when the receiving buffer is full. Send a "Start" signal to start sending

data when the receiving buffer is empty. The options are None and Hardware

RTS/CTS.

VT-UTF8 Combo Key Support

Select Enabled to enable VT-UTF8 Combination Key support for ANSI/VT100

terminals. The options are Enabled and Disabled.

Recorder Mode

Select Enabled to capture the data displayed on a terminal and send it as text

messages to a remote server. The options are Disabled and Enabled.

Resolution 100x31

Select Enabled for extended-terminal resolution support. The options are Dis-

abled and Enabled.

Legacy OS Redirection Resolution

Use this feature to select the number of rows and columns used in Console

Redirection for legacy OS support. The options are 80x24 and 80x25.

Putty KeyPad

This feature selects Function Keys and KeyPad settings for Putty, which is a

terminal emulator designed for the Windows OS. The options are VT100, LINUX,

XTERMR6, SCO, ESCN, and VT400.

Redirection After BIOS Post

Use this feature to enable or disable legacy console redirection after BIOS POST.

When set to Bootloader, legacy console redirection is disabled before booting

the OS. When set to Always Enable, legacy console redirection remains enabled

when booting the OS. The options are Always Enable and Bootloader.

4-22

X9DRW-7TPF/iTPF Motherboard User’s Manual

Serial Port for Out-of-Band Management/Windows Emergency Management
Services (EMS)

The submenu allows the user to congure Console Redirection settings to support

Out-of-Band Serial Port management.

Console Redirection (for EMS)

Select Enabled to use a COM Port selected by the user for Console Redirection.

The options are Enabled and Disabled.



Console Redirection Settings (for EMS)

This feature allows the user to specify how the host computer will exchange

data with the client computer, which is the remote computer used by the user.

Out-of-Band Management Port

The feature selects a serial port used by the Microsoft Windows Emergency

Management Services (EMS) to communicate with a remote server. The options

are COM1 and COM2.

Terminal Type

This feature allows the user to select the target terminal emulation type for Con-

sole Redirection. Select VT100 to use the ASCII character set. Select VT100+

to add color and function key support. Select ANSI to use the extended ASCII

character set. Select VT-UTF8 to use UTF8 encoding to map Unicode characters

into one or more bytes. The options are ANSI, VT100, VT100+, and VT-UTF8.

Bits Per Second

This item sets the transmission speed for a serial port used in Console Redirec-

tion. Make sure that the same speed is used in the host computer and the client

computer. A lower transmission speed may be required for long and busy lines.

The options are 9600, 19200, 57600, and 115200 (bits per second).

Flow Control

This feature allows the user to set the ow control for Console Redirection to

prevent data loss caused by buffer overow. Send a "Stop" signal to stop send-

ing data when the receiving buffer is full. Send a "Start" signal to start sending

data when the receiving buffer is empty. The options are None, Hardware RTS/

CTS, and Software Xon/Xoff.

Data Bits, Parity, Stop Bits

The status of these features is displayed.
