Preface

This manual is written for system integrators, PC technicians and

knowledgeable PC users. It provides information for the installation and use of the

X9DRFF/X9DRFF-7 motherboard.

About This Motherboard

The Super X9DRFF/X9DRFF-7 motherboard supports dual Intel E5-2600 Series

(Socket R) processors that offer QPI (Intel QuickPath Interface) Technology (V.1.1),

providing point-to-point connection with a transfer speed of up to 8.0 TG/s. With

the C602-J chipset built in, the X9DRFF/X9DRFF-7 motherboard supports Intel®
Intelligent Power Node Manager (NM), Manageability Engine (ME) Technology,

Digital Media Interface (DMI), PCI-E Gen. 3.0 and 1600 MHz DDR3 memory. This

motherboard is ideal for 4U Fat Twin server platforms. Please refer to our Website

(http://www.supermicro.com) for CPU and memory support updates.

Manual Organization

Chapter 1 describes the features, specications and performance of the mother-

board, and provides detailed information about the Intel C602-J chipset.

Chapter 2 provides hardware installation instructions. Read this chapter when in-

stalling the processor, memory modules and other hardware components into the

system. If you encounter any problems, see Chapter 3, which describes trouble-

shooting procedures for video, memory, and system setup stored in the CMOS.

Chapter 4 includes an introduction to the BIOS, and provides detailed information

on running the CMOS Setup utility.

Appendix A provides BIOS Error Beep Codes.

Appendix B lists Software Installation Instructions.
