Supero X10SRi-F User Manual

X10SRi-F

USER’S MANUAL

Revision 1.0b

The information in this User’s Manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
makes no commitment to update or to keep current the information in this manual, or to notify any
person or organization of the updates. Please Note: For the most up-to-date version of this

manual, please see our web site at www.supermicro.com.

Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product
described in this manual at any time and without notice. This product, including software and docu­mentation, is the property of Supermicro and/or its licensors, and is supplied only under a license.
Any use or reproduction of this product is not allowed, except as expressly permitted by the terms
of said license.

IN NO EVENT WILL SUPERMICRO BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO
USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. IN PARTICULAR, SUPERMICRO SHALL NOT HAVE LIABILITY FOR ANY
HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE PRODUCT, INCLUDING THE
COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH
HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between manufacturer and customer shall be governed by the laws of Santa
Clara County in the State of California, USA. The State of California, County of Santa Clara shall
be the exclusive venue for the resolution of any such disputes. Super Micro's total liability for all
claims will not exceed the price paid for the hardware product.

FCC Statement: This equipment has been tested and found to comply with the limits for a class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance with the instruc­tions, may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful interfer­ence to radio or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment to an outlet on a circuit different from that to which the receiver

is connected.

•Consult the authorized dealer or an experienced radio/TV technician for help.

California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate warn­ing applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate
Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”

WARNING: Handling of lead solder materials used in this
product may expose you to lead, a chemical known to the
State of California to cause birth defects and other repro­ductive harm.

Manual Revision: 1.0b
Release Date: December 31, 2014

Unless you request and receive written permission from Super Micro Computer, Inc., you may not
copy any part of this document.
Information in this document is subject to change without notice. Other products and companies
referred to herein are trademarks or registered trademarks of their respective companies or mark
holders.
Copyright © 2014 by Super Micro Computer, Inc.
All rights reserved.

Printed in the United States of America

iii

Preface

Preface

This manual is written for system integrators, IT professionals, and

knowledgeable end users. It provides information for the installation and use of the

X10SRi-F motherboard.

About This Motherboard

The X10SRi-F supports a single Intel® E5-2600/1600 Series processor in

an LGA2011 R3 socket. With the Intel® C612 Express chipset built in, the X10SRi-

F motherboard supports Intel® Active Management Technology (iAMT), offering

great system enhancement to high performance storage platforms. Please refer

to our website (http://www.supermicro.com/products/) for processor and memory

support updates. This product is intended to be installed and serviced by profes-

sional technicians.

Manual Organization

Chapter 1 describes the features, specications and performance of the mother-

board, and provides detailed information on the Intel® C612 Express chipset.

Chapter 2 provides hardware installation instructions. Read this chapter when in-

stalling the processor, memory modules and other hardware components into the

system. If you encounter any problems, see Chapter 3, which describes trouble-

shooting procedures for video, memory and system setup stored in the CMOS.

Chapter 4 includes an introduction to the BIOS, and provides detailed information

on running the CMOS Setup utility.

Appendix A provides BIOS Error Beep Codes.

Appendix B lists software program installation instructions.

Appendix C contains UEFI BIOS Recovery instructions.

Appendix D contains Dual Boot Block instructions.

iv

Conventions Used in the Manual:

Special attention should be given to the following symbols for proper system instal-

lation:

Warning: Critical information given to prevent damage to the components or injury

to yourself.

Note: Additional Information provided for correct system setup.

X10SRi-F User’s Manual

v

Contacting Supermicro

Contacting Supermicro

Headquarters

Address: Super Micro Computer, Inc.

980 Rock Ave.

San Jose, CA 95131 U.S.A.

Tel: [phone]

Fax: [phone]

Email: [e-mail] (General Information)

[e-mail] (Technical Support)

Web Site: www.supermicro.com

Europe

Address: Super Micro Computer B.V.

Het Sterrenbeeld 28, 5215 ML

's-Hertogenbosch, The Netherlands

Tel: [phone]

Fax: [phone]

Email: [e-mail] (General Information)

[e-mail] (Technical Support)

[e-mail] (Customer Support)

Web Site: www.supermicro.nl

Asia-Pacic

Address: Super Micro Computer, Inc.

3F, No. 150, Jian 1st Rd.

Zhonghe Dist., New Taipei City 235

Taiwan (R.O.C)

Tel: [phone]

Fax: [phone]

Email: [e-mail]

Web Site: www.supermicro.com.tw

vi

Table of Contents

Preface

About This Motherboard ................................................................................................ iii

Manual Organization .....................................................................................................iii

Conventions Used in the Manual: .................................................................................iv

Contacting Supermicro ...................................................................................................v

Chapter 1 Introduction

1-1 Overview ......................................................................................................... 1-1

Checklist .......................................................................................................... 1-1

Motherboard Features ..................................................................................... 1-6

1-2 Chipset Overview ........................................................................................... 1-9

Intel C612 Express Chipset Features ............................................................. 1-9

1-3 Special Features ........................................................................................... 1-10

Recovery from AC Power Loss ..................................................................... 1-10

1-4 PC Health Monitoring .................................................................................... 1-10

Environmental Temperature Control ............................................................. 1-10

System Resource Alert ................................................................................. 1-10

1-5 ACPI Features ................................................................................................1-11

Slow Blinking LED for Suspend-State Indicator ............................................1-11

1-6 Power Supply .................................................................................................1-11

1-7 Super I/O ....................................................................................................... 1-12

Chapter 2 Installation

2-1 Standardized Warning Statements ................................................................. 2-1

Battery Handling .............................................................................................. 2-1

Product Disposal ............................................................................................. 2-3

2-2 Static-Sensitive Devices .................................................................................. 2-4

Precautions ..................................................................................................... 2-4

Unpacking ....................................................................................................... 2-4

2-3 Motherboard Installation .................................................................................. 2-5

Tools Needed .................................................................................................. 2-5

Location of Mounting Holes ............................................................................ 2-5

Installing the Motherboard .............................................................................. 2-6

2-4 Processor and Heatsink Installation................................................................ 2-7

Installing the LGA2011 Processor ................................................................. 2-7

Installing a Passive CPU Heatsink ................................................................2-11

Removing the Heatsink ................................................................................. 2-12

2-5 Installing DDR4 Memory ............................................................................... 2-13

DIMM Installation .......................................................................................... 2-13

X10SRi-F User’s Manual

vii

Table of Contents

Removing Memory Modules ......................................................................... 2-14

Memory Support ............................................................................................ 2-14

2-6 Connectors/IO Ports ...................................................................................... 2-16

Backplane I/O Panel ..................................................................................... 2-16

Universal Serial Bus (USB) ...................................................................... 2-17

Ethernet Ports .......................................................................................... 2-18

Serial Ports (COM1/COM2)...................................................................... 2-18

Unit Identier Switch/UID LED Indicator .................................................. 2-19

VGA Port ..................................................................................................2-19

Front Control Panel ....................................................................................... 2-20

Front Control Panel Pin Denitions............................................................... 2-21

NMI Button ............................................................................................... 2-21

Power LED .............................................................................................. 2-21

HDD LED .................................................................................................. 2-22

NIC1/NIC2 LEDs ...................................................................................... 2-22

Overheat (OH)/Fan Fail/PWR Fail/UID LED ............................................ 2-23

Power Fail LED ........................................................................................ 2-23

Reset Button ........................................................................................... 2-24

Power Button ........................................................................................... 2-24

2-7 Connecting Cables ........................................................................................ 2-25

ATX Main PWR & CPU PWR Connectors (J24 & JPWR1) ..................... 2-25

Fan Headers (Fan 1-Fan 5 & Fan A ) ...................................................... 2-26

Chassis Intrusion (JL1) ........................................................................... 2-26

Internal Buzzer (SP1) ............................................................................... 2-27

Speaker (JD1) .......................................................................................... 2-27

DOM PWR Connector (JSD1) .................................................................. 2-28

Standby Power ......................................................................................... 2-28

T-SGPIO 1/2/3 Headers ........................................................................... 2-29

Power SMB (I2C) Connector .................................................................... 2-29

TPM Header/Port 80 Header ................................................................... 2-30

Overheat/Fan Fail ..................................................................................... 2-30

2-8 Jumper Settings ............................................................................................ 2-31

Explanation of Jumpers ................................................................................ 2-31

LAN1/LAN2 Enable/Disable ..................................................................... 2-31

CMOS Clear (JBT1) ................................................................................. 2-32

PCI-E Slot SMB Enable (JI2C1/JI2C2) ...................................................... 2-32

Manufacturer Mode Select ....................................................................... 2-33

VRM SMB Clock/Data .............................................................................. 2-33

VGA Enable .............................................................................................. 2-34

viii

BIOS Recovery Enable ............................................................................ 2-34

Watch Dog Enable/Disable ...................................................................... 2-35

BMC Enable ............................................................................................ 2-35

2-9 Onboard Indicators ........................................................................................ 2-36

LAN 1/LAN 2 LEDs .................................................................................. 2-36

IPMI Dedicated LAN LEDs ....................................................................... 2-36

Onboard Power LED (LE2) ..................................................................... 2-37

BMC Heartbeat LED ................................................................................ 2-37

2-10 SATA Connections ......................................................................................... 2-38

SATA Connections .................................................................................... 2-38

Chapter 3 Troubleshooting

3-1 Troubleshooting Procedures ........................................................................... 3-1

Before Power On ............................................................................................ 3-1

No Power ........................................................................................................ 3-1

No Video ......................................................................................................... 3-2

Memory Errors ............................................................................................... 3-2

Losing the System’s Setup Conguration ....................................................... 3-2

3-2 Technical Support Procedures ........................................................................ 3-3

3-3 Frequently Asked Questions ........................................................................... 3-4

3-4 Battery Removal and Installation .................................................................... 3-5

Battery Removal .............................................................................................. 3-5

Proper Battery Disposal .................................................................................. 3-5

Battery Installation ........................................................................................... 3-5

3-5 Returning Merchandise for Service................................................................. 3-6

Chapter 4 BIOS

4-1 Introduction ...................................................................................................... 4-1

Starting BIOS Setup Utility .............................................................................. 4-1

How To Change the Conguration Data ......................................................... 4-1

How to Start the Setup Utility ......................................................................... 4-2

4-2 Main Setup ...................................................................................................... 4-2

The following Main menu items will be displayed: ..................................... 4-2

System Date/System Time ........................................................................ 4-3

Supermicro X10SRI-F ................................................................................ 4-3

BIOS Version: This item displays the version of the BIOS ROM used in the

system. ....................................................................................................... 4-3

Build Date: This item displays the date when the version of the BIOS ROM

used in the system was built. ................................................................... 4-3

X10SRi-F User’s Manual

ix

Table of Contents

Memory Information ................................................................................... 4-3

Total Memory: This item displays the total size of memory available in the

system. ....................................................................................................... 4-3

Memory Speed: This item displays the default speed of the memory

modules installed in the system.. ............................................................... 4-3

4-3 Advanced Setup Congurations...................................................................... 4-4



Boot Feature ................................................................................................. 4-4

Quiet Boot .................................................................................................. 4-4

AddOn ROM Display Mode ........................................................................ 4-4

Bootup Num-Lock ....................................................................................... 4-4

Wait For 'F1' If Error ................................................................................... 4-5

INT19 (Interrupt 19) Trap Response .......................................................... 4-5

Re-try Boot ................................................................................................. 4-5

Power Conguration ........................................................................................ 4-5

DeepSx Power Policies .............................................................................. 4-5

Watch Dog Function ................................................................................... 4-5

Power Button Function ............................................................................... 4-5

Restore on AC Power Loss ........................................................................ 4-6



CPU Conguration ....................................................................................... 4-6

CPU Conguration ..................................................................................... 4-6

Clock Spread Spectrum ............................................................................. 4-6

Hyper-Threading (ALL) ............................................................................... 4-7

Execute Disable Bit (Available if supported by the OS & the CPU) .......... 4-7

PPIN Control .............................................................................................. 4-7

Hardware Prefetcher (Available when supported by the CPU) ................. 4-7

Adjacent Cache Line Prefetch (Available when supported by the CPU) ... 4-7

DCU Streamer Prefetcher (Available when supported by the CPU) ......... 4-7

DCU IP Prefetcher...................................................................................... 4-7

DCU (Data Cache Unit) Mode ................................................................... 4-8

Direct Cache Access (DCA) ....................................................................... 4-8

DCA Prefetch Delay ................................................................................... 4-8

X2APIC (Extended Advanced Programmable Interrupt Controller) ........... 4-8

AES-NI ........................................................................................................ 4-8

Intel Virtualization Technology .................................................................... 4-8

Advanced Power Management Conguration ............................................. 4-8

Energy Performance Tuning .................................................................... 4-10

Energy Performance BIAS Setting ........................................................... 4-10

Power/Performance Switch ...................................................................... 4-10

x

X10SRi-F User’s Manual

Workload Conguration ............................................................................ 4-10

Averaging Time Window........................................................................... 4-10

P0 TotalTimeThreshold Low ..................................................................... 4-10

P0 TotalTimeThreshold High .....................................................................4-11

Chipset Conguration ................................................................................ 4-12

North Bridge ............................................................................................... 4-12

IIO Conguration ........................................................................................ 4-12

 Intel VT for Directed I/O (VT-d) ................................................................ 4-13

QPI (Quick Path Interconnect) Conguration ............................................ 4-13



South Bridge ............................................................................................... 4-17

Legacy USB Support ................................................................................ 4-17

XHCI Hand-Off ......................................................................................... 4-17

EHCI Hand-Off ......................................................................................... 4-17

USB Mass Storage Driver Support .......................................................... 4-18

Port 60/64 Emulation ................................................................................ 4-18

USB 3.0 Support ...................................................................................... 4-18

EHCI1 ....................................................................................................... 4-18

EHCI2 ....................................................................................................... 4-18

XHCI Pre-Boot Drive ................................................................................ 4-18

XHCI Idle L1 ............................................................................................. 4-18

PCH DMI ASPM ....................................................................................... 4-18



SATA Conguration .................................................................................... 4-18

SATA Controller ........................................................................................ 4-19

Congure SATA as ................................................................................... 4-19

Support Aggressive Link Power Management ......................................... 4-19

*If the item above "Congure SATA as" is set to IDE, the following items

will display: ............................................................................................... 4-20

*If the item above "Congure SATA as" is set to RAID, the following items

will display: ............................................................................................... 4-20



sSATA Conguration ................................................................................... 4-21

sSATA Controller ...................................................................................... 4-21

Congure sSATA as ................................................................................. 4-21

*If the item above "Congure sSATA as" is set to IDE, the following items

will display: ............................................................................................... 4-22

*If the item above "Congure sSATA as" is set to RAID, the following items

will display: ............................................................................................... 4-22

Server ME (Management Engine) Conguration ....................................... 4-23

PCIe/PCI/PnP Conguration ...................................................................... 4-24

The following PCI information will be displayed: ..................................... 4-24

VGA Palette Snoop .................................................................................. 4-24

xi

Table of Contents

PCI AER (Advanced Error-Reporting) Support ........................................ 4-24

Above 4G Decoding (Available if the system supports 64-bit PCI decoding)
4-24

SR-IOV Support (Available if the system supports Single-Root

Virtualization) ............................................................................................ 4-24

Maximum Payload .................................................................................... 4-24

Maximum Read Request .......................................................................... 4-24

ASPM Support .......................................................................................... 4-25

MMIOHBase ............................................................................................. 4-25

MMIO High Size ....................................................................................... 4-25

PCH SLOT1 PCI-E 2.0 x2 (in x8) OPROM, CPU SLOT2 PCI-E 3.0 x4 (in
x8) OPROM, CPU SLOT3 PCI-E 3.0 x8 OPROM, CPU SLOT4 PCI-E 3.0
x8 OPROM, CPU SLOT5 PCI-E 3.0 x4 (in x8) OPROM, CPU SLOT6 PCI-E

3.0 x16 OPROM ...................................................................................... 4-25

Onboard LAN Option ROM Type ............................................................. 4-25

Onboard LAN1 Option ROM/Onboard LAN2 Option ROM ...................... 4-25

Onboard Video Option ROM .................................................................... 4-25

VGA Priority .............................................................................................. 4-25

Network Stack .......................................................................................... 4-26



Super IO Conguration ............................................................................. 4-26



Serial Port 1 Conguration/Serial Port 2 Conguration ........................ 4-26

Serial Port 1/Serial Port 2 ........................................................................ 4-26

Device Settings ........................................................................................ 4-26

Change Port 1 Settings/Change Port 2 Settings ..................................... 4-26

Serial Port 2 Attribute ............................................................................... 4-26



Serial Port Console Redirection ................................................................. 4-26

COM 1 Console Redirection .................................................................... 4-26

COM1 Console Redirection ....................................................................... 4-27

SOL/COM2 ............................................................................................... 4-28

SOL/COM2 Console Redirection ............................................................. 4-28

SOL/COM2 Console Redirection Settings ................................................. 4-28

Serial Port for Out-of-Band Management/Windows Emergency Management

Services (EMS) ........................................................................................ 4-30

EMS (Emergency Management Services) Console Redirection ............. 4-30



EMS Console Redirection Settings ............................................................ 4-30

Trusted Computing (Available when a TPM device is installed and detected

by the BIOS) ................................................................................................. 4-31

Conguration ............................................................................................ 4-31

Security Device Support ........................................................................... 4-31

TPM State ................................................................................................ 4-31

Pending Operation ................................................................................... 4-31

xii

X10SRi-F User’s Manual

Current Status Information ....................................................................... 4-31

WHEA Support ......................................................................................... 4-32

High Precision Timer ................................................................................ 4-32

NUMA ....................................................................................................... 4-32

4-4 Event Logs .................................................................................................... 4-33

Change SMBIOS Event Log Settings ....................................................... 4-33

Enabling/Disabling Options ...................................................................... 4-33

SMBIOS Event Log .................................................................................. 4-33

Runtime Error Logging Support ............................................................... 4-33

Memory Corrected Error Enabling (Available when the item above-Runtime

Error Logging Support is set to Enable) .................................................. 4-33

PCI-Ex (PCI-Express) Error Enable ......................................................... 4-33

Memory Correctable Error Threshold ....................................................... 4-33

Erasing Settings ....................................................................................... 4-34

Erase Event Log ....................................................................................... 4-34

When Log is Full ...................................................................................... 4-34

SMBIOS Event Log Standard Settings .................................................... 4-34

Log System Boot Event ........................................................................... 4-34

MECI (Multiple Event Count Increment) .................................................. 4-34

METW (Multiple Event Count Time Window) ........................................... 4-34

View System Event Log ........................................................................... 4-34

4-5 IPMI ............................................................................................................... 4-35

IPMI Firmware Revision ........................................................................... 4-35

IPMI Status ............................................................................................... 4-35

System Event Log ..................................................................................... 4-35

Enabling/Disabling Options ...................................................................... 4-35

SEL Components ..................................................................................... 4-35

Erasing Settings ....................................................................................... 4-35

Erase SEL ................................................................................................ 4-35

When SEL is Full ...................................................................................... 4-36

BMC Network Conguration ...................................................................... 4-36

IPMI LAN Selection .................................................................................. 4-36

IPMI Network Link Status ......................................................................... 4-36

Update IPMI LAN Conguration ............................................................... 4-36

Conguration Address Source ................................................................. 4-36

4-6 Security Settings ........................................................................................... 4-38

Password Check ...................................................................................... 4-38

Administrator Password ........................................................................... 4-38

4-7 Boot Settings ................................................................................................. 4-39

xiii

Table of Contents

Setup Prompt Timeout ............................................................................. 4-39

Boot Mode Select ..................................................................................... 4-39

Fixed Boot Order Priorities ....................................................................... 4-39

Add New Boot Option .............................................................................. 4-40

Boot Option File Path ............................................................................... 4-40



Delete Boot Option ................................................................................ 4-40



Hard Disk Drive BBS Priorities ............................................................. 4-40



Network Drive BBS Priorities ................................................................ 4-41



UEFI Application Boot Priorities ............................................................ 4-41

4-8 Save & Exit ................................................................................................... 4-41

Discard Changes and Exit ...................................................................... 4-41

Save Changes and Reset ........................................................................ 4-41

Save Options ............................................................................................ 4-42

Save Changes .......................................................................................... 4-42

Discard Changes ...................................................................................... 4-42

Restore Defaults ....................................................................................... 4-42

Save As User Defaults ............................................................................. 4-42

Restore User Defaults .............................................................................. 4-42

Boot Override ........................................................................................... 4-42

Appendix A BIOS Error Beep Codes

A-1 BIOS Error Beep Codes .................................................................................A-1

Appendix B Software Installation Instructions

B-1 Installing Software Programs ..........................................................................B-1

B-2 Installing SuperDoctor5 ...................................................................................B-2

Appendix C UEFI BIOS Recovery Instructions

C-1 An Overview to the UEFI BIOS ......................................................................C-1

C-2 How to Recover the UEFI BIOS Image .........................................................C-1

C-3 To Recover the Main BIOS Block Using a USB-Attached Device..................C-1

Appendix D Dual Boot Block on Grantley Platforms

Overview .....................................................................................................................D-1

Before Startup ............................................................................................................D-1

When to Use Dual Boot Block ...................................................................................D-1

How to Use Dual Boot Block......................................................................................D-1

D-1 IPMI GUI Browser ...........................................................................................D-2

D-2 IPMI Command Sets .......................................................................................D-7

User Approach ............................................................................................................D-9

xiv

X10SRi-F User’s Manual

Notes

Chapter 1: Introduction

1-1

Chapter 1

Introduction

1-1 Overview

Checklist

Congratulations on purchasing your computer motherboard from an acknowledged

leader in the industry. Supermicro boards are designed with the utmost attention to

detail to provide you with the highest standards in quality and performance.

Please check that the following items have all been included with your motherboard.

If anything listed here is damaged or missing, contact your retailer.

The following items are included in the retail box:

•One (1) Supermicro Motherboard

•Six (6) SATA cables

•One (1) I/O shield

•One (1) Quick Reference Guide

Note: For your system to work properly, please follow the links below to

download all necessary drivers/utilities and the user's manual for your

motherboard.

Supermicro product manuals: http://www.supermicro.com/support/manuals/

Product Drivers and utilities: ftp://ftp.supermicro.com/

If you have any questions, please contact our support team at support@supermicro.

com.

1-2

X10SRi-F User’s Manual

X10SRi-F Motherboard Image

Note: All graphics shown in this manual were based upon the latest PCB Revision

available at the time of publishing of the manual. Your motherboard or components

may or may not look exactly the same as the graphics shown in this manual.

Chapter 1: Introduction

1-3

X10SRi-F Motherboard Layout

Notes:

•See Chapter 2 for detailed information on jumpers, I/O ports and JF1 front

panel connections.

•" " indicates the location of "Pin 1".

•Jumpers not indicated are for testing only.

•When the onboard Power LED Indicator (LE2) is on, system power is on.

Unplug the power cable before installing or removing any components.

DESIGNED IN USA

1.01REV:

X10SRi-F

JP3

JTPM1

JF1

JD1

J23

T-SGPIO1

T-SGPIO2

T-SGPIO3

JOH1

JL1

JPME2

JWD1

JPG1

JPB1

1

JI2C2

JI2C1

JBR1

JVRM2

JVRM1

JPL1

JSD1

JSD2

JIPMB1

JPWR1

JUIDB1

LE1

LE2

LEDM1

JBT1

BT1

FAN4

FAN1

FAN2

FAN3

FANA

FAN5

J24

JPI2C1

JSTBY1

S-SATA3

I-SATA4

I-SATA0

I-SATA1

I-SATA2

I-SATA3

S-SATA0

S-SATA1

S-SATA2

I-SATA5

SP1

1-2:ENABLE

2-3:DISABLE

JPB1:BMC

CPU

CPU SLOT5 PCI-E 3.0 X4(IN X8)

CPU SLOT4 PCI-E 3.0 X8

CPU SLOT3 PCI-E 3.0 X8

JPME2

2-3:ME MANUFACTURUNG MODE

1-2:Normal

USB0/1

DIMMC2

PWR LED1-3:

JD1:

SPEAKER4-7:

JBR1

1-2:Normal

2-3:BIOS recovery

:TPM/PRO80

USB8/9

USB6/7

LED

NMI

PWR

X

USB2/3
(3.0)

HDD

NIC

1

JWD1:Watch Dog

1-2:RST

2-3:NMI

LAN1

DIMMA2

DIMMA1

USB10(3.0)

FF

2

NIC

OH

LAN2

RST

PWR

PWR
FAIL

USB4/5

ON

1-2:ENABLE

2-3:DISABLE

JPG1:VGA

JI2C1/JI2C2

I2C bus for PCI-E slot

OFF:DISABLE

ON: ENABLE

PCH SLOT2 PCI-E 2.0 X4(IN X8)

PCH SLOT1 PCI-E 2.0 X2(IN X8)

COM2

COM1

DIMMB2

DIMMB1

PWR I2C

DIMMD2

DIMMD1

DIMMC1

IPMI_LAN

UID

USB11(3.0)

0N: POWER FORCE ON

JPL1:LAN1/2
1-2:ENABLE

VGA

2-3:DISABLE

LGA2011-3

1

1

CPU SLOT6 PCI-E 3.0 X16

BAR CODE

IPMI CODE

MAC CODE

BIOS
LICENSE

BIOS

1-4

X10SRi-F User’s Manual

X10SRi-F Jumpers

Jumper Description Default

JBR1 BIOS Recovery Pins 1-2 (Normal), Pins 2-3 (BIOS Recovery)

JBT1 CMOS Clear Short: Clear CMOS, Open: Normal

JI2C1/JI2C2 SMB to PCI-E Slots Pins 2-3 (Disabled)

JPB1 BMC Enable/Disable Pins 1-2 (Enabled)

JPG1 VGA Enable Pins 1-2 (Enabled)

JPL1 LAN1/LAN2 Enable Pins 1-2 (Enabled)

JPME2 Manufacture Mode Select Pins 1-2 (Normal)

JWD1 Watch Dog Enable Pins 1-2 (Reset)

JVRM1 VRM SMB Clock (to BMC or PCH) Pins 1-2 (BMC, Normal)

JVRM2 VRM SMB Data (to BMC or PCH) Pins 1-2 (BMC, Normal)

X10SRi-F Quick Reference

DESIGNED IN USA

1.01REV:

X10SRi-F

JP3

JTPM1

JF1

JD1

J23

T-SGPIO1

T-SGPIO2

T-SGPIO3

JOH1

JL1

JPME2

JWD1

JPG1

JPB1

1

JI2C2

JI2C1

JBR1

JVRM2

JVRM1

JPL1

JSD1

JSD2

JIPMB1

JPWR1

JUIDB1

LE1

LE2

LEDM1

JBT1

BT1

FAN4

FAN1

FAN2

FAN3

FANA

FAN5

J24

JPI2C1

JSTBY1

S-SATA3

I-SATA4

I-SATA0

I-SATA1

I-SATA2

I-SATA3

S-SATA0

S-SATA1

S-SATA2

I-SATA5

SP1

1-2:ENABLE

2-3:DISABLE

JPB1:BMC

CPU

CPU SLOT5 PCI-E 3.0 X4(IN X8)

CPU SLOT4 PCI-E 3.0 X8

CPU SLOT3 PCI-E 3.0 X8

JPME2

2-3:ME MANUFACTURUNG MODE

1-2:Normal

USB0/1

DIMMC2

PWR LED1-3:

JD1:

SPEAKER4-7:

JBR1

1-2:Normal

2-3:BIOS recovery

:TPM/PRO80

USB8/9

USB6/7

LED

NMI

PWR

X

USB2/3
(3.0)

HDD

NIC
1

JWD1:Watch Dog

1-2:RST

2-3:NMI

LAN1

DIMMA2

DIMMA1

USB10(3.0)

FF

2

NIC

OH

LAN2

RST

PWR

PWR

FAIL

USB4/5

ON

1-2:ENABLE

2-3:DISABLE

JPG1:VGA

JI2C1/JI2C2

I2C bus for PCI-E slot

OFF:DISABLE

ON: ENABLE

PCH SLOT2 PCI-E 2.0 X4(IN X8)

PCH SLOT1 PCI-E 2.0 X2(IN X8)

COM2

COM1

DIMMB2

DIMMB1

PWR I2C

DIMMD2

DIMMD1

DIMMC1

IPMI_LAN

UID

USB11(3.0)

0N: POWER FORCE ON

JPL1:LAN1/2
1-2:ENABLE

VGA

2-3:DISABLE

LGA2011-3

1

1

CPU SLOT6 PCI-E 3.0 X16

BAR CODE

IPMI CODE

MAC CODE

BIOS
LICENSE

BIOS

Chapter 1: Introduction

1-5

X10SRi-F Headers/Connectors

Connector Description

Battery (BT1) Onboard Battery

COM1/COM2 COM1 (Port)/COM2 (Header)

Fan1 - Fan5, FanA System/CPU Fan Headers

JD1 Speaker/Buzzer (Pins 1-3: Power LED, Pins 4-7: Speaker)

JF1 Front Panel Control Header

JIPMB1 4-pin External BMC I2C Header (for an IPMI Card)

JL1 Chassis Intrusion Header

JPI2C1 Power SMB (System Management Bus)

J24 24-pin ATX Main Power Connector (Required)

JOH1 Overheat/Fan Fail LED Indicator

JPWR1 +12V 8-pin CPU power Connector (Required)

JSD1/JSD2 SATA DOM (Device_On_Module) Power Connectors

JSTBY1 Standby Power Header

JTPM1 Trusted Platform Module/Port 80 Connector

JUIDB1 UID (Unit Identier) Switch

LAN1/LAN2 Gigabit (RJ45) Ports (LAN1/2)

IPMI_LAN IPMI_Dedicated LAN

I-SATA0~5, S-SATA0~3 (Intel PCH) Serial ATA (SATA 3.0) Ports 0/1 (6Gb/sec)

(PCH) Slots 1/2 PCI-Express 2.0 Slots: Slot1 x2 (in x8), Slot2 x4 (in x8)

(CPU) Slots 3/4/5/6 PCI-Express 3.0 Slots: Slot3 x8, Slot4 x8, Slot5 x4 (in x8), Slot6 x16

SP1 Internal Speaker/Buzzer

T-SGPIO 1/2/3 Serial_Link General Purpose I/O Headers 1/2/3 for SATA Connections

USB 0/1 Backpanel USB 2.0 Ports 0, 1

USB 2/3 (3.0) Backpanel USB 3.0 Ports 2, 3

USB 4/5, 6/7, 8/9 Front Panel Accessible USB 2.0 Headers 4/5, 6/7, 8/9

USB 10, USB 11 Front Panel Accessible USB 3.0 Header 10, Type A Header 11

VGA Backpanel VGA Port

X10SRi-F LED Indicators

LED Description State/Color Status

LE1 UID LED Blue: On Unit Identied

LE2 Onbaord Power LED Green: On System Power On

LEDM1 BMC Heartbeat LED Green: Blinking BMC Normal

1-6

X10SRi-F User’s Manual

Motherboard Features

CPU Single Intel® E5-2600/1600 Series processor in an

LGA2011 R3 socket.

Memory Eight (8) slots support up to 256GB of RDIMM and 512GB

of LRDIMM DDR4 ECC 1333/1600/1866/2133 MHz

memory

Dual-channel memory

DIMM sizes

RDIMM 1GB, 2GB, 4GB, 8GB, 16GB, 32GB

Chipset Intel® C612 Express

Expansion Slots Two (2) PCI Express 2.0: 1 (x4 in x8), 1 (x2 in x8)

Four (4) PCI Express 3.0: 1 (x16), 1 (x4 in x8), 2 (x8)

Two (2) RJ-45 rear I/O panel connectors with Link and
Activity LEDs

I/O Devices SATA Connections

SATA 3.0 (6Gb/s)

Ten (10) SATA3 ports

•AHCI controller supports six (6)

SATA3 drives compatible with

RAID 0, 1, 5, 10.

•sSATA controller supports four

(4) SATA3 drives compatible

with RAID 0, 1, 5, 10.

•RAID array and volume(s) can-

not span across the two (AHCI

and sSATA) controllers.

SATA DOM Two (2) SATA DOM Ports (SATA 4/5)

USB Devices

• Four (4) USB 3.0 ports (2 rear, 1 Type-A, 1

header)

• Eight (8) USB 2.0 (2 rear, 6 headers)

Two (2) Front Accessible USB 2.0 ports on one header
(USB 8/9)

Serial (COM) Ports

Two (2) COM Ports (1 rear, 1 header)

Graphics Controller

AST 2400 Graphics Controller

BIOS 128 Mb AMI BIOS® SPI Flash BIOS

Plug and Play (PnP), DMI 2.3, PCI 2.3, ACPI 1.0/2.0/3.0,
USB Keyboard and SMBIOS 2.5

Chapter 1: Introduction

1-7

Power Conguration ACPI/APM Power Management

Main Switch Override Mechanism

Keyboard Wake-up from Soft-Off

Power-on mode for AC power recovery

PC Health Monitoring CPU Monitoring

Onboard voltage monitors for CPU core, +3.3V, +5V, 12V,
+3.3V Stdby, VBAT, Memory

CPU 3-phase switching voltage regulator

CPU/System overheat LED and control

CPU Thermal Trip support

Thermal Monitor 2 (TM2) support

vPro 9.0/AMT 9.0 support

Fan Control

Fan status monitoring with rmware 4-pin fan speed con­trol via IPMI interface

Low noise fan speed control

System Management PECI (Platform Environment Conguration Interface) 2.0

support

UID (Unit Identier)/Remote UID

System resource alert via SuperDoctor® 5

SuperDoctor® 5, Watch Dog, NMI

Chassis Intrusion header and detection

BIOS ash upgrade utility

Dimensions ATX form factor: 9.6" x 12" (243.84mm x 304.8mm)

1-8

X10SRi-F User’s Manual

System Block Diagram

Note: This is a general block diagram and may not exactly represent

the features on your motherboard. See the Motherboard Features

pages for the actual specications of each motherboard.

X10SRi-F Block Diagram

SPI

LAN3

RGRMII

Debug Card

FRONT PANEL

SYSTEM POWER

CTRL

FAN SPEED

PCI-E X1 Gen2

USB 2.0

13 USB2.0

1/2/3/4

PCH

6.0 Gb/S

USB 2.0

LPC

USB

1

0

SATA

5

4

RTL8211E-VB-CG

3

2

RJ45

BIOS

SPI

SPI

Temp Sensor

EMC1402-1 *2 at diff SMBUS

TPM HEADER

USB 3.0

USB

BIOS
HEADER

SPI

AST2400

BMC

5/6

7

RMII/NCSI

COM1
Connector

COM2
Header

VGA CONN

BMC Boot Flash

DDR3

5 PHASE
145W

VR12.5

PCI-E X8 Gen3

DMI2

PCI-E X8 Gen3

PCI-E X4 Gen3

DMI2

Skt-R3
LGA2011-3

3A/B

i350

LAN

PCI-E X4 Gen2

6

7

8

9

1333/1600/2133

0-4

0-3

0-2

0-1

DDRIV

1333/1600/2133

DDRIV

0-8

0-7

0-6

0-5

3D

SLOT5

PCIe3.0 x8
(x4 in x8)

PCIe3.0 x8

SLOT4

SLOT3

PCIe3.0 x8

PCI-E X16 Gen3

SLOT2

PCIe2.0 x8
(x4 in x8)

PCI-E X4 Gen2

PCI-E X2 Gen2

SLOT1

PCIe2.0 x8
(x2 in x8)

1

2

5

6

0

1

2

3

4

5

6

7

RJ45

RJ45

1 3C 2

SLOT6

PCIe3.0 x16

Chapter 1: Introduction

1-9

1-2 Chipset Overview

The X10SRi-F supports a single Intel® E5-2600/1600 Series Processor in an

LGA2011 R3 socket. Built upon the functionality and the capability of the Intel®

C612 Express chipset, the motherboard provides substantial enhancement to

system performance and storage capability for high performance platforms in a

sleek package.

The high-speed Direct Media Interface (DMI) featured in the Intel® C612 Express

chipset supports high-speed Direct Media Interface (DMI) for chip-to-chip true

isochronous communication, providing up to 5 Gb/s of software-transparent data

transfer rate on each read/write direction. In addition, the X10SRi-F also features

a TCO timer which allows the system to recover from a software/hardware lock

and perform tasks, including Function Disable and Intruder Detect.

Intel C612 Express Chipset Features

•Direct Media Interface (up 5 Gb/s transfer, Full Duplex)

•Dual NAND Interface

•Intel

®

I/O Virtualization (VT-d) Support

•Intel

®

Trusted Execution Technology Support

•PCI Express 2.0 Interface (up to 5.0 GT/s)

•SATA Controller (up to 6Gb/sec)

•Advanced Host Controller Interface (AHCI)

•Intel

®

Active Management Technology (iAMT) 9.0 and vPRO 9.0 support

1-10

X10SRi-F User’s Manual

1-3 Special Features

Recovery from AC Power Loss

Basic I/O System (BIOS) provides a setting for you to determine how the system will

respond when AC power is lost and then restored to the system. You can choose

for the system to remain powered off, (in which case you must press the power

switch to turn it back on), or for it to automatically return to a power-on state. See

the Advanced BIOS Setup section to change this setting. The default setting is

Last State.

1-4 PC Health Monitoring

This section describes the PC health monitoring features of the board. All have an

onboard System Hardware Monitoring chip that supports PC health monitoring. An

onboard voltage monitor will scan these onboard voltages continuously: CPU Vcore,

12V, 5V, 3.3V, 3.3VSB, Memory, and Battery voltages. Once a voltage becomes

unstable, a warning is given, or an error message is sent to the screen. The user

can adjust the voltage thresholds to dene the sensitivity of the voltage monitor.

Environmental Temperature Control

The thermal control sensor monitors the CPU temperature in real time and will turn

on the thermal control fan whenever the CPU temperature exceeds a user-dened

threshold. The overheat circuitry runs independently from the CPU. Once the ther-

mal sensor detects that the CPU temperature is too high, it will automatically turn

on the thermal fans to prevent the CPU from overheating. The onboard chassis

thermal circuitry can monitor the overall system temperature and alert the user when

the chassis temperature is too high.

Note: To avoid possible system overheating, please be sure to provide

adequate airow to your system.

System Resource Alert

This feature is available when the system is used with SuperDoctor® 5 in the

Windows and Linux operating systems. SuperDoctor is used to notify the user

of certain system events. For example, you can also congure SuperDoctor to

provide you with warnings when the system temperature, CPU temperatures,

voltages and fan speeds go beyond predened thresholds.

Chapter 1: Introduction

1-11

1-5 ACPI Features

ACPI stands for Advanced Conguration and Power Interface. The ACPI specica-

tion denes a exible and abstract hardware interface that provides a standard

way to integrate power management features throughout a PC system, including

its hardware, operating system and application software. This enables the system

to automatically turn on and off peripherals such as CD-ROMs, network cards, hard

disk drives and printers.

In addition to enabling operating system-directed power management, ACPI also

provides a generic system event mechanism for Plug and Play, and an operating

system-independent interface for conguration control. ACPI leverages the Plug and

Play BIOS data structures, while providing a processor architecture-independent

implementation that is compatible with Windows 7, Windows 8, and Windows 2008

Operating Systems.

Slow Blinking LED for Suspend-State Indicator

When the CPU goes into a suspend state, the chassis power LED will start to blink

to indicate that the CPU is in suspend mode. When the user presses any key, the

CPU will "wake up", and the LED will automatically stop blinking and remain on.

1-6 Power Supply

As with all computer products, a stable power source is necessary for proper and

reliable operation. It is even more important for processors that have high CPU

clock rates.

This motherboard accommodates 24-pin ATX power supplies. Although most

power supplies generally meet the specications required by the CPU, some are

inadequate. In addition, the 12V 8-pin power connector located at JPWR1 is also

required to ensure adequate power supply to the system.

Warning: To avoid damaging the power supply or motherboard, please use a power

supply that contains a 24-pin and an 8-pin power connectors. Be sure to connect the

24-pin (J24) and the 8-pin (JPWR1) power connectors on the motherboard to the

power supply. Failure in doing so will void the manufacturer warranty on your power

supply and motherboard.

It is strongly recommended that you use a high quality power supply that meets ATX

power supply Specication 2.02 or above. It must also be SSI compliant. (For more

information, please refer to the web site at http://www.ssiforum.org/). Additionally, in

areas where noisy power transmission is present, you may choose to install a line lter

1-12

X10SRi-F User’s Manual

to shield the computer from noise. It is recommended that you also install a power

surge protector to help avoid problems caused by power surges.

1-7 Super I/O

The Super I/O supports two high-speed, 16550 compatible serial communication

ports (UARTs). Each UART includes a 16-byte send/receive FIFO, a programmable

baud rate generator, complete modem control capability and a processor interrupt

system. Both UARTs provide legacy speed with baud rate of up to 115.2 Kbps

as well as an advanced speed with baud rates of 250 K, 500 K, or 1 Mb/s, which

support higher speed modems.

The Super I/O provides functions that comply with ACPI (Advanced Conguration

and Power Interface), which includes support of legacy and ACPI power manage-

ment through an SMI or SCI function pin. It also features auto power management

to reduce power consumption.

Chapter 2: Installation

2-1

Chapter 2

Installation

2-1 Standardized Warning Statements

The following statements are industry-standard warnings, provided to warn the user

of situations which have the potential for bodily injury. Should you have questions or

experience difculty, contact Supermicro's Technical Support department for assis-

tance. Only certied technicians should attempt to install or congure components.

Read this section in its entirety before installing or conguring components in the

Supermicro chassis.

Battery Handling

Warnung

Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die

Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp.

Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers.

Warning!

There is a danger of explosion if the battery is replaced incorrectly. Replace the

battery only with the same or equivalent type recommended by the manufacturer.

Dispose of used batteries according to the manufacturer's instructions

電池の取り扱い

電池交換が正しく行われなかった場合、破裂の危険性があります。 交換する電池はメー
カーが推奨する型、または同等のものを使用下さい。 使用済電池は製造元の指示に従
って処分して下さい。

警告
电池更换不当会有爆炸危险。请只使用同类电池或制造商推荐的功能相当的电池更
换原有电池。请按制造商的说明处理废旧电池。

警告
電池更換不當會有爆炸危險。請使用製造商建議之相同或功能相當的電池更換原有
電池。請按照製造商的說明指示處理廢棄舊電池。

2-2

X10SRi-F User’s Manual

Attention

Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer

que par une pile de type semblable ou équivalent, recommandée par le fabricant.

Jeter les piles usagées conformément aux instructions du fabricant.

¡Advertencia!

Existe peligro de explosión si la batería se reemplaza de manera incorrecta. Re-

emplazar la batería exclusivamente con el mismo tipo o el equivalente recomen-

dado por el fabricante. Desechar las baterías gastadas según las instrucciones

del fabricante.

!הרהזא

תנכס תמייקץוציפ .הניקת אל ךרדב הפלחוהו הדימב הללוסה לש ףילחהל שי

גוסב הללוסה תא מ םאותה תרבחלמומ ןרציתצ.

תוללוסה קוליס תושמושמה עצבל שי .ןרציה תוארוה יפל









경고!

배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일
하거나 제조사에서 권장하는 동등한 종류의 배터리로만 교체해야 합니다. 제조사
의 안내에 따라 사용된 배터리를 처리하여 주십시오.

Waarschuwing

Er is ontplofngsgevaar indien de batterij verkeerd vervangen wordt. Vervang de

batterij slechts met hetzelfde of een equivalent type die door de fabrikant aan-

bevolen wordt. Gebruikte batterijen dienen overeenkomstig fabrieksvoorschriften

afgevoerd te worden.

Chapter 2: Installation

2-3

Product Disposal

Warning!

Ultimate disposal of this product should be handled according to all national laws

and regulations.

製品の廃棄

この製品を廃棄処分する場合、国の関係する全ての法律・条例に従い処理する必要が

ありま す。

警告
本产品的废弃处理应根据所有国家的法律和规章进行。

警告
本產品的廢棄處理應根據所有國家的法律和規章進行。

Warnung

Die Entsorgung dieses Produkts sollte gemäß allen Bestimmungen und Gesetzen

des Landes erfolgen.

¡Advertencia!

Al deshacerse por completo de este producto debe seguir todas las leyes y regla-

mentos nacionales.

Attention

La mise au rebut ou le recyclage de ce produit sont généralement soumis à des

lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de

l'organisme compétent.

רצומה קוליס

!הרהזא

ו תויחנהל םאתהב תויהל בייח הז רצומ לש יפוס קוליס.הנידמה יקוח

2-4

X10SRi-F User’s Manual

2-2 Static-Sensitive Devices

Electrostatic-Discharge (ESD) can damage electronic com ponents. To avoid dam-

aging your system board, it is important to handle it very carefully. The following

measures are generally sufcient to protect your equipment from ESD.

Precautions

• Use a grounded wrist strap designed to prevent static discharge.

• Touch a grounded metal object before removing the board from the antistatic

bag.

• Handle the board by its edges only; do not touch its components, peripheral

chips, memory modules or gold contacts.

• When handling chips or modules, avoid touching their pins.

• Put the motherboard and peripherals back into their antistatic bags when not in

use.

• For grounding purposes, make sure your computer chassis provides excellent

conductivity between the power supply, the case, the mounting fasteners and

the motherboard.

• Use only the correct type of onboard CMOS battery. Do not install the onboard

battery upside down to avoid possible explosion.

Unpacking

The motherboard is shipped in antistatic packaging to avoid static damage. When

unpacking the board, make sure that the person handling it is static protected.

Waarschuwing

De uiteindelijke verwijdering van dit product dient te geschieden in overeenstemming

met alle nationale wetten en reglementen.

 

경고!

이 제품은 해당 국가의 관련 법규 및 규정에 따라 폐기되어야 합니다.
