Supero SC417E16-RJBOD1 User Manual

SC417J CHASSIS SERIES

USER’S MANUAL

1.0a

SUPER

®

SC417E16-RJBOD1

SC417J Chassis Manual

ii

Manual Revision 1.0a
Release Date: November 28, 2011

The information in this User’s Manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
makes no commitment to update or to keep current the information in this manual, or to notify any
person or organization of the updates. Please Note: For the most up-to-date version of this

manual, please see our web site at www.supermicro.com.

Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product
described in this manual at any time and without notice. This product, including software and
documentation, is the property of Supermicro and/or its licensors, and is supplied only under a
license. Any use or reproduction of this product is not allowed, except as expressly permitted by
the terms of said license.

IN NO EVENT WILL SUPERMICRO BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO
USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. IN PARTICULAR, SUPERMICRO SHALL NOT HAVE LIABILITY FOR ANY
HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE PRODUCT, INCLUDING THE
COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH
HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between manufacturer and customer shall be governed by the laws of Santa
Clara County in the State of California, USA. The State of California, County of Santa Clara shall
be the exclusive venue for the resolution of any such disputes. Super Micro's total liability for all
claims will not exceed the price paid for the hardware product.

California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate
warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate
Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”

WARNING: Handling of lead solder materials used in this
product may expose you to lead, a chemical known to
the State of California to cause birth defects and other
reproductive harm.

Unless you request and receive written permission from Super Micro Computer, Inc., you may not
copy any part of this document.

Information in this document is subject to change without notice. Other products and companies
referred to herein are trademarks or registered trademarks of their respective companies or mark
holders.

Copyright © 2011 by Super Micro Computer, Inc.
All rights reserved.

Printed in the United States of America

iii

Preface

Contacting Supermicro

Headquarters

Address: Super Micro Computer, Inc.

980 Rock Ave.

San Jose, CA 95131 U.S.A.

Tel: [phone]

Fax: [phone]

Email: [e-mail] (General Information)

[e-mail] (Technical Support)

Web Site: www.supermicro.com

Europe

Address: Super Micro Computer B.V.

Het Sterrenbeeld 28, 5215 ML

's-Hertogenbosch, The Netherlands

Tel: [phone]

Fax: [phone]

Email: [e-mail] (General Information)

[e-mail] (Technical Support)

[e-mail] (Customer Support)

Asia-Pacic

Address: Super Micro Computer, Inc.

4F, No. 232-1, Liancheng Rd.

Chung-Ho 235, Taipei County

Taiwan, R.O.C.

Tel: [phone]

Fax: [phone]

Web Site: www.supermicro.com.tw

Technical Support:

Email: [e-mail]

Tel: [phone]

SC417J Chassis Manual

iv

Preface

About This Manual

This manual is written for professional system integrators and PC technicians. It

provides information for the installation and use of the SC417J chassis. Installation

and maintenance should be performed by experienced technicians only.

This manual lists compatible parts available when this document was published.

Always refer to the Supermicro Web site for updates on supported parts and con-

gurations.

v

Preface

Manual Organization

Chapter 1 Introduction

The rst chapter provides a description of the main components included with this

chassis and describes the main features of the SC417J chassis. This chapter also

includes contact information.

Chapter 2 System Safety

This chapter lists warnings, precautions, and system safety. It is recommended that

you thoroughly familiarize yourself with installing and servicing the chassis and all

safety precautions.

Chapter 3 System Interface

Refer to this chapter for details on the system interface, which includes the func-

tions and information provided by the chassis control panel, as well as other LEDs

located throughout the system.

Chapter 4 Chassis Setup and Maintenance

Follow the procedures given in this chapter when installing, removing, or

reconguring components in your chassis.

Chapter 5 Rack Installation

Refer to this chapter for detailed information on chassis rack installation. You should

follow the procedures given in this chapter when installing, removing or reconguring

your chassis into a rack environment.

This section lists compatible cables, power supply specications, and compatible

backplanes. Not all compatible backplanes are listed. Refer to our Web site for the

latest compatible backplane information.

SC417J Chassis Manual

vi

Appendix A Cables and Hardware

This section provides information on cabling, and other hardware which is compat-

ible with your chassis. For complete information on supported cables and hardware,

refer to the Supermico Web site at www.supermicro.com.

AppendixBPowerSupplySpecications

This chapter lists the specications for the power supply provided with your chas-

sis. For additional information, refer to the Supermicro website at www.supermicro.

com.

AppendixCSAS2-216ELBackplaneSpecications

This section contains detailed specications on the SAS2-216EL1 and SAS2-

216EL2 backplanes. Additional information can be found on the Supermicro Web

site at www.supermicro.com.

AppendixDSAS2-213ELBackplaneSpecications

This section lists detailed specications on the SAS2-213EL1 backplane. Additional

information can be found on the Supermicro Web site at www.supermicro.com.

Appendix E SC417J Chassis Internals and Externals

This section contains detailed specications unique to the SC427J chassis. Ad-

ditional information can be found on the Supermicro Web site at www.supermicro.

com.

vii

Preface

Table of Contents

Contacting Supermicro .......................................................................................iii

Chapter 1 Introduction

1-1 Overview ......................................................................................................... 1-1

1-2 Shipping List .................................................................................................... 1-1

1-3 Where to get Replacement Components ........................................................ 1-2

1-4 Returning Merchandise for Service................................................................. 1-3

Chapter 2 System Safety

2-1 Overview ......................................................................................................... 2-1

2-2 Warnings and Precautions .............................................................................. 2-1

2-3 Preparing for Setup ......................................................................................... 2-1

2-4 Electrical Safety Precautions .......................................................................... 2-2

2-5 General Safety Precautions ............................................................................ 2-3

2-6 System Safety ................................................................................................. 2-3

Chapter 3 System Interface

3-1 Overview ......................................................................................................... 3-1

3-2 Control Panel Buttons ..................................................................................... 3-2

3-3 Control Panel LEDs ........................................................................................ 3-2

3-4 Drive Carrier LEDs .......................................................................................... 3-4

SAS/SATA Drives ............................................................................................ 3-4

SCSI Drives ..................................................................................................... 3-4

Chapter 4 Chassis Setup and Maintenance

4-1 Overview ......................................................................................................... 4-1

4-2 Removing the Chassis Cover ......................................................................... 4-2

4-3 Installing Removable Hard Drives................................................................... 4-3

4-4 System Fans ................................................................................................... 4-6

4-5 Power Supply ................................................................................................. 4-8

Chapter 5 Rack Installation

5-1 Overview ......................................................................................................... 5-1

5-2 Unpacking the System .................................................................................... 5-1

5-3 Preparing for Setup ......................................................................................... 5-1

Choosing a Setup Location ............................................................................. 5-1

5-4 Warnings and Precautions .............................................................................. 5-2

Rack Precautions ............................................................................................ 5-2

General Server Precautions ............................................................................ 5-2

5-5 Rack Mounting Considerations ....................................................................... 5-3

SC417J Chassis Manual

viii

Ambient Operating Temperature ..................................................................... 5-3

Reduced Airow .............................................................................................. 5-3

Mechanical Loading ........................................................................................ 5-3

Circuit Overloading .......................................................................................... 5-3

Reliable Ground .............................................................................................. 5-3

5-6 Rack Mounting Instructions ............................................................................. 5-4

Identifying the Sections of the Rack Rails ...................................................... 5-4

Locking Tabs ................................................................................................... 5-5

Releasing the Inner Rail ................................................................................. 5-5

Installing The Inner Rails on the Chassis ....................................................... 5-6

Installing the Outer Rails on the Rack ............................................................ 5-7

Standard Chassis Installation ......................................................................... 5-8

Optional Quick Installation Method ................................................................. 5-9

Adapters for Round and Threaded Hole Racks ........................................... 5-10

Appendix A SC417J Cables and Hardware

Appendix B SC417J Power Supply Specications

Appendix C SAS2-216EL1/EL2 Backplane Specications

Appendix D SAS2-213EL Backplane Specications

Appendix E SC417J Chassis Internals and Externals

Appendix F SC417J Backplane and Fan Congurations

Chapter 1

Introduction

1-1 Overview

Optimized for enterprise-level heavy-capacity storage applications, Supermicro's

SC417J JBOD chassis features eighty-eight (forty-eight in the front plus forty in the

rear) 2.5" hot-swap hard drive bays for up to eighty-eight hard drives. The SC417

server chassis offers the option to reduce the number of hard drives to seventy-

two (forty-eight in the front plus twenty-four in the rear) allowing for an optional

motherboard to be installed.

The SC417J design provides high-density storage in a 4U form factor, with high

power efciency, optimized hard drive signal trace routing and improved hard drive

carrier design to dampen vibration and maximize performance. Equipped with a

1400W (Gold Level) high-efciency redundant power supply and ve hot-plug redun-

dant cooling fans, the SC417J is a reliable, high-quality storage workhorse system.

1-2 Shipping List

Please visit the following link for the latest shiping lists and part numbers for your

particular chassis model http://www.supermicro.com/

Chapter 1: Introduction

1-1

SC417J Chassis

Model CPU HDD

Power

Supply

SC417E16-RJBOD1

DP/UP 88x (JBOD) SAS/SATA

1400W redundant

(Gold Level)

SC417J Chassis Manual

1-2

1-3 Where to get Replacement Components

Alhough not frequently, you may need replacement parts for your system. To en-

sure the highest level of professional service and technical support, we strongly

recommend purchasing exclusively from our Supermicro Authorized Distributors/

System Integrators/Resellers. A list of Supermicro Authorized Distributors/System

Integrators/Resellers can be found at: http://www.supermicro.com. Click the Where

to Buy link.

1-3

Chapter 1: Introduction

1-4 Returning Merchandise for Service

A receipt or copy of your invoice marked with the date of purchase is required be-

fore any warranty service will be rendered. You can obtain service by calling your

vendor for a Returned Merchandise Authorization (RMA) number. When returning to

the manufacturer, the RMA number should be prominently displayed on the outside

of the shipping carton, and mailed prepaid or hand-carried. Shipping and handling

charges will be applied for all orders that must be mailed when service is complete.

For faster service, RMA authorizations may be requested online (http://www.

supermicro.com/support/rma/).

Whenever possible, repack the chassis in the original Supermicro carton, using the

original packaging material. If these are no longer available, be sure to pack the

chassis securely, using packaging material to surround the chassis so that it does

not shift within the carton and become damaged during shipping.

This warranty only covers normal consumer use and does not cover damages in-

curred in shipping or from failure due to the alteration, misuse, abuse or improper

maintenance of products.

During the warranty period, contact your distributor rst for any product problems.

SC417J Chassis Manual

1-4

Notes

2-1

Chapter 2: System Safety

Chapter 2

System Safety

2-1 Overview

This chapter provides a quick setup checklist to get your chassis up and running.

Following the steps in order given should enable you to have your chassis set up

and operational within a minimal amount of time. This quick setup assumes that you

are an experienced technician, familiar with common concepts and terminology.

2-2 Warnings and Precautions

You should inspect the box the chassis was shipped in and note if it was damaged

in any way. If the chassis itself shows damage, le a damage claim with carrier

who delivered your system.

Decide on a suitable location for the rack unit that will hold that chassis. It should

be situated in a clean, dust-free area that is well venilated. Avoid areas where heat,

electrical noise and eletromagnetic elds are generated.

The system must be placed near at two grounded power outlets. When congured,

the SC417J chassis includes one primary and one redundant power supply.

2-3 Preparing for Setup

The SC417J chassis includes a set of rail assemblies which includes mounting

brackets and mounting screws you will need to install the systems into the rack.

Please read this manual in its entirety before you begin the installation proce-

dure.

SC417J Chassis Manual

2-2

2-4 Electrical Safety Precautions

Basic electrical safety precautions should be followed to protect yourself from harm

and the SC417J from damage:

•Be aware of the locations of the power on/off switch on the chassis as well

as the room’s emergency power-off switch, disconnection switch or electrical

outlet. If an electrical accident occurs, you can then quickly remove power from

the system.

•Do not work alone when working with high-voltage components.

•Power should always be disconnected from the system when removing or install-

ing main system components, such as the serverboard, memory modules (not

necessary for hot swappable drives). When disconnecting power, you should rst

power down the system with the operating system and then unplug the power

cords from all the power supply modules in the system.

•When working around exposed electrical circuits, another person who is fa-

miliar with the power-off controls should be nearby to switch off the power, if

necessary.

•Use only one hand when working with powered-on electrical equipment. This

is to avoid making a complete circuit, which will cause electrical shock. Use

extreme caution when using metal tools, which can easily damage any electrical

components or circuit boards they come into contact with.

•Do not use mats designed to decrease electrostatic discharge as protection from

electrical shock. Instead, use rubber mats that have been specically designed

as electrical insulators.

•The power supply power cord must include a grounding plug and must be

plugged into grounded electrical outlets.

•Serverboard battery: CAUTION - There is a danger of explosion if the onboard

battery is installed upside down, which will reverse its polarities This battery

must be replaced only with the same or an equivalent type recommended by

the manufacturer. Dispose of used batteries according to the manufacturer’s

instructions.

2-3

Chapter 2: System Safety

•Handle used batteries carefully. Do not damage the battery in any way; a dam-

aged battery may release hazardous materials into the environment. Do not

discard a used battery in the garbage or a public landll. Please comply with

the regulations set up by your local hazardous waste management agency to

dispose of your used battery properly.

2-5 General Safety Precautions

•Keep the area around the chassis clean and free of clutter.

•Place the chassis top cover and any system components that have been re-

moved away from the system or on a table so that they won’t accidentally be

stepped on.

•While working on the system, do not wear loose clothing such as neckties and

unbuttoned shirt sleeves, which can come into contact with electrical circuits or

be pulled into a cooling fan.

•Remove any jewelry or metal objects from your body, which are excellent metal

conductors that can create short circuits and harm you if they come into contact

with printed circuit boards or areas where power is present.

•After accessing the inside of the system, close the system back up and secure

it to the rack unit with the retention screws after ensuring that all connections

have been made.

2-6 System Safety

Electrostatic discharge (ESD) is generated by two objects with different electrical

charges coming into contact with each other. An electrical discharge is created to

neutralize this difference, which can damage electronic components and printed

circuit boards. The following measures are generally sufcient to neutralize this

difference before contact is made to protect your equipment from ESD:

•Do not use mats designed to decrease electrostatic discharge as protection from

electrical shock. Instead, use rubber mats that have been specically designed

as electrical insulators.

•Use a grounded wrist strap designed to prevent static discharge.

•Keep all components and printed circuit boards (PCBs) in their antistatic bags

until ready for use.

SC417J Chassis Manual

2-4

•Touch a grounded metal object before removing any board from its antistatic

bag.

•Do not let components or PCBs come into contact with your clothing, which may

retain a charge even if you are wearing a wrist strap.

•Handle a board by its edges only; do not touch its components, peripheral chips,

memory modules or contacts.

•When handling chips or modules, avoid touching their pins.

•Put the serverboard and peripherals back into their antistatic bags when not

in use.

•For grounding purposes, make sure your computer chassis provides excellent

conductivity between the power supply, the case, the mounting fasteners and

the serverboard.

3-1

Chapter 3: System Interface

Chapter 3

System Interface

3-1 Overview

There are several LEDs on the control panel as well as others on the drive carriers

to keep you constantly informed of the overall status of the system as well as the

activity and health of specic components. SC417J models have two buttons on

the chassis control panel: A reset button and a power on/off switch. This chapter

explains the meanings of all LED indicators and the appropriate responses you

may need to take.

Figure 3-1: Control Panel

SC417J Chassis Manual

3-2

3-3 Control Panel LEDs

The control panel located on the left handle of the SC417J chassis has six LEDs.

These LEDs provide you with critical information related to different parts of the

system. This section explains what each LED indicates when illuminated and any

corrective action you may need to take.

Power: The main power button is used to apply or remove power from the power

supply to the server system. Turning off system power with this button removes

the main power but keeps standby power supplied to the system. Therefore, you

must unplug system before servicing.

3-2 Control Panel Buttons

There are two push-buttons located on the left handle of the chassis. These are

(in order from top to bottom) a power on/off button and a reset button.

Power: Indicates power is being supplied to the system's power supply units. This

LED should normally be illuminated when the system is operating.

HDD: Indicates IDE channel activity. SAS/SATA drive, and/or DVD-ROM drive

activity when ashing.

Reset: The reset button is used to reboot the system.

3-3

Chapter 3: System Interface

NIC1: Indicates network activity on GLAN1 when ashing.

NIC2: Indicates network activity on GLAN2 when ashing.

1

2

!

Power Failure: When this LED ashes, it indicates a failure in the redundant power

supply.

Overheat/Fan Fail: When this LED ashes, it indicates a fan failure. When con-

tinuously on (not ashing) it indicates an overheat condition, which may be caused

by cables obstructing the airow in the system or the ambient room temperature

being too warm. Check the routing of the cables and make sure all fans are pres-

ent and operating normally. You should also check to make sure that the chassis

covers are installed. Finally, verify that the heatsinks are installed properly. This

LED will remain ashing or on as long as the overheat condition exists.

SC417J Chassis Manual

3-4

3-4 Drive Carrier LEDs

Your chassis uses SAS/SATA.

SAS/SATA Drives

Each SAS/SATA drive carrier has two LEDs.

•Blue:

Solid on = Drive is present and available.

Blinking = Drive is actively being accessed.

Each Serial ATA drive carrier has a blue LED. When illuminated in a solid

on state, this blue LED (on the front of the SAS/SATA drive carrier) indicates

drive activity. A connection to the SAS/SATA backplane enables this LED to

blink on and off when that particular drive is being accessed.

•Red:

Solid on = Drive failure

Blinking = RAID activity

When the red LED is blinking, it indicates that the system is either building,

initializing or rebuilding RAID.

SCSI Drives

This chassis does not support SCSI drives at this time.

4-1

Chapter 4: Chassis Setup and Maintenance

Chapter 4

Chassis Setup and Maintenance

4-1 Overview

This chapter covers the steps required to install components and perform mainte-

nance on the chassis. The only tool you will need to install components and perform

maintenance is a Phillips screwdriver. Print this chapter to use as a reference while

setting up your chassis.

Review the warnings and precautions listed in the manual before

setting up or servicing this chassis. These include information in

Chapter 2: System Safety and the warnings/precautions listed in the

setup instructions.

Safety Warning: Before performing any chassis setup or mainte-

nance, it is recommended that the chassis be removed from the rack

and placed on a stable bench or table. For instructions on how to

uninstall the chassis from the rack, refer to Chapter 5 Rack Instal-

lation in this manual.

!

!

SC417J Chassis Manual

4-2

4-2 Removing the Chassis Cover

Figure 4-1: Removing the Chassis Cover

2

1

2

1

2

2

Removing the Chassis Cover

1. Unplug the chassis from any power source

2. Remove the screws securing the cover to the chassis.

3. Lift the cover up and off the chassis.

Warning: Except for short periods of time, do NOT operate the

server without the cover in place. The chassis cover must be in

place to allow proper airow and prevent overheating.

!

4-3

Chapter 4: Chassis Setup and Maintenance

4-3 Installing Removable Hard Drives

Removing Hard Drive Carriers from the Chassis

1. Press the release button on the drive carrier. This extends the drive carrier

handle.

2. Use the handle to pull the drive carrier out of the chassis.

Figure 4-2: Removing a Hard Drive Carrier

2

1

SC417J Chassis Manual

4-4

The drives are mounted in drive carriers to simplify their installation and removal

from the chassis. These carriers also help to promote proper airow for the drive

bays.

Figure 4-3: Chassis Drive Carrier

Installing a Hard Drive to the Hard Drive Carrier

1. Remove the four screws securing the dummy drive to the drive carrier and

remove the dummy drive.

Warning: Except for short periods of time (while swapping

hard drives), do not operate the server with the drives re-

moved from the chassis drive bays.

Figure 4-4: Removing the Dummy Drive from the Carrier

Drive Carrier

Dummy Drive

!

1

Warning! Enterprise level hard disk drives are recommended
for use in Supermicro chassis and servers. For information on
recommended HDDs, visit the Supermicro Web site at http://
www.supermicro.com/products/nfo/storage.cfm

!

4-5

Chapter 4: Chassis Setup and Maintenance

2. Place the hard drive carrier on a at surface such as a desk, table or work

bench.

3. Slide the hard drive into the carrier with the printed circuit board side facing

down.

4. Carefully align the mounting holes in both the drive carrier and the hard drive.

5. Secure the hard drive to the carrier using four screws.

6. Replace the drive tray into the chassis. Close the drive carrier handle to lock

the drive carrier into place.

SAS/SATA

Hard Drive

Figure 4-5: Installing the Hard Drive into the Carrier

Figure 4-6: Installing the Hard Drive

3

5

SC417J Chassis Manual

4-6

Seven hot-swappable, heavy-duty fans provide cooling for the chassis. These fans

circulate air through the chassis thereby lowering the chassis internal tempera-

ture.

4-4 System Fans

Replacing a System Fan

1. Open the chassis while the power is running to determine which fan has

failed. (Never run the server for an extended period of time with the chassis

cover open.)

2. Remove the failed fan's power cord from the serverboard.

3. Press the fan release tab to lift the failed fan from the chassis and pull it

completely out of the chassis.

4. Place the new fan into the vacant space in the housing while making sure the

arrows on the top of the fan (indicating air direction) point in the same direc-

tion as the arrows on the other fans.

5. Check that the fan is working properly before replacing the chassis cover.

Figure 4-7: System Fan

Release Tab

Air Direction

Indicator

4-7

Chapter 4: Chassis Setup and Maintenance

Figure 4-8: Placing the System Fan

SC417J Chassis Manual

4-8

4-5 Power Supply

The SC417J chassis comes equipped with a 1400 Watt high-efciency redundant

power supply. This power supply is auto-switching capable. This enables it to au-

tomatically sense and operate at a 100v to 240v input voltage. An amber light will

be illuminated on the power supply when the power is off. An illuminated green light

indicates that the power supply is operating.

Redundant power supplies are hot-swappable, meaning that they can be changed

without powering-down the system. New units can be ordered directly from

Supermicro (see contact information in the Preface).

Changing the Power Supply:

1. The SC417J chassis includes a redundant power supply (at least two power

modules), you can leave the server running and remove one power supply.

2. Push the release tab (on the back of the power supply) as illustrated.

3. Pull the power supply out using the handle provided.

4. Replace the failed power module with another of the same model.

Figure 4-9: Power Supply Release Tab

Release Tab

4-9

Chapter 4: Chassis Setup and Maintenance

Figure 4-10: Power Supply Release Tab

1

4

5. Push the new power supply module into the power bay until it clicks into the

secure, locked position.

6. If using only one power supply, plug the AC power cord back into the module

and power up the server.

SC417J Chassis Manual

4-10

Notes

5-1

Chapter 5: Rack Installation

Chapter 5

Rack Installation

5-1 Overview

This chapter provides a quick setup checklist to get your chassis up and running.

Following these steps in the order given should enable you to have the system

operational within a minimal amount of time.

5-2 Unpacking the System

Inspect the box which the chassis was shipped in and note if it was damaged in

any way. If the chassis itself shows damage, you should le a damage claim with

the carrier who delivered it.

Decide on a suitable location for the rack unit that will hold the chassis. It should

be situated in a clean, dust-free area that is well ventilated. Avoid areas where

heat, electrical noise and electromagnetic elds are generated. The system needs

to be placed near a grounded power outlet. Be sure to read the Rack and Server

Precautions in the next section.

5-3 Preparing for Setup

The box the chassis was shipped in should include two sets of rail assemblies and

the mounting screws needed for installing the system into the rack. Also included

is an optional square hole to round hole converter bracket, for use in racks with

round mounting holes. Please read this section in its entirety before you begin the

installation procedure outlined in the sections that follow.

Choosing a Setup Location

•Leave enough clearance in front of the rack to enable you to open the front

door completely (~25 inches).

•Leave approximately 30 inches of clearance in the back of the rack to allow for

sufcient airow and ease in servicing.

•This product is for installation only in a Restricted Access Location (dedicated

equipment rooms, service closets and similar environments).

SC417J Chassis Manual

5-2

5-4 Warnings and Precautions

Rack Precautions

•Ensure that the leveling jacks on the bottom of the rack are fully extended to

the oor with the full weight of the rack resting on them.

•In single rack installations, stabilizers should be attached to the rack.

•In multiple rack installations, the racks should be coupled together.

•Always make sure that the rack is stable before extending a component from

the rack.

•You should extend only one component at a time - extending two or more si-

multaneously may cause the rack to become unstable.

General Server Precautions

•Review the electrical and general safety precautions that came with the com-

ponents you are adding to your chassis.

•Determine the placement of each component in the rack before you install the

rails.

•Install the heaviest server components on the bottom of the rack rst, and then

work upwards.

•Use a regulating uninterruptible power supply (UPS) to protect the server from

power surges, voltage spikes and to keep your system operating in case of a

power failure.

•Allow the hot plug hard drives and power supply modules to cool before touch-

ing them.

Warning!

! !

5-3

Chapter 5: Rack Installation

•Always keep the rack's front door and all panels and components on the servers

closed when not servicing to maintain proper cooling.

5-5 Rack Mounting Considerations

Ambient Operating Temperature

If installed in a closed or multi-unit rack assembly, the ambient operating tempera-

ture of the rack environment may be greater than the ambient temperature of the

room. Therefore, consideration should be given to installing the equipment in an

environment compatible with the manufacturer’s maximum rated ambient tempera-

ture (TMRA).

ReducedAirow

Equipment should be mounted into a rack so that the amount of airow required

for safe operation is not compromised.

Mechanical Loading

Equipment should be mounted into a rack so that a hazardous condition does not

arise due to uneven mechanical loading.

Circuit Overloading

Consideration should be given to the connection of the equipment to the power

supply circuitry and the effect that any possible overloading of circuits might have

on overcurrent protection and power supply wiring. Appropriate consideration of

equipment nameplate ratings should be used when addressing this concern.

Reliable Ground

A reliable ground must be maintained at all times. To ensure this, the rack itself

should be grounded. Particular attention should be given to power supply connec-

tions other than the direct connections to the branch circuit (i.e. the use of power

strips, etc.).

SC417J Chassis Manual

5-4

5-6 Rack Mounting Instructions

This section provides information on installing the chassis into a rack unit with the

rails provided. There are a variety of rack units on the market, which may mean

that the assembly procedure will differ slightly from the instructions provided. You

should also refer to the installation instructions that came with the rack unit you are

using. NOTE: This rail will t a rack between 26.5" and 36.4" deep.

Identifying the Sections of the Rack Rails

The chassis package includes two rail assemblies in the rack mounting kit. Each

assembly consists of three sections: An inner chassis rail which secures directly to

the chassis, an outer rail that secures to the rack, and a middle rail which extends

from the outer rail. These assemblies are specically designed for the left and right

side of the chassis.

Figure 5-1: Identifying the Outer Rail, Middle Rail and Inner Rails

(Left Rail Assembly Shown)

Inner Rail

Rail Assembly

(Shown with Rails

Retracted)

This Side Faces

Outward

Locking Tab

Middle Rail

Outer Rail

5-5

Chapter 5: Rack Installation

Figure 5-2: Extending and Releasing the Inner Rail

1

2

1

1

1

3

1

4

Locking Tabs

Each inner rail has a locking tab. This tab locks the chassis into place when installed

and pushed fully into the rack. These tabs also lock the chassis in place when fully

extended from the rack. This prevents the server from coming completely out of

the rack when when the chassis is pulled out for servicing.

Releasing the Inner Rail

Releasing Inner Rail from the Outer Rails

1. Identify the left and right outer rail assemblies as described on page 5-4.

2. Pull the inner rail out of the outer rail until it is fully extended as illustrated

below.

3. Press the locking tab down to release the inner rail.

4. Pull the inner rail all the way out.

5. Repeat steps 1-3 for the second outer rail.

SC417J Chassis Manual

5-6

Figure 5-4: Inner Rails Installed on the Chassis

Figure 5-3: Installing the Inner Rails

Installing The Inner Rails on the Chassis

Installing the Inner Rails

1. Conrm that the left and right inner rails have been correctly identied.

2. Place the inner rail rmly against the side of the chassis, aligning the hooks

on the side of the chassis with the holes in the inner rail.

3. Slide the inner rail forward toward the front of the chassis until the rail clicks

into the locked position, which secures the inner rail to the chassis.

4. Secure the inner rail to the chassis with the screws provided.

5. Repeat steps 1 through 4 above for the other inner rail.

3

1

4

1

4

2

Inner Rails

5-7

Chapter 5: Rack Installation

Installing the Outer Rails on the Rack

Installing the Outer Rails

1. Press upward on the locking tab at the rear end of the middle rail.

2. Push the middle rail back into the outer rail.

3. Hang the hooks of the front of the outer rail onto the slots on the front of

the rack. If necessary, use screws to secure the outer rails to the rack, as

illustrated above.

4. Pull out the rear of the outer rail, adjusting the length until it ts within the

posts of the rack.

5. Hang the hooks of the rear portion of the outer rail onto the slots on the rear

of the rack. If necessary, use screws to secure the rear of the outer rail to the

rear of the rack.

6. Repeat steps 1-5 for the remaining outer rail.

Figure 5-5: Extending and Releasing the Outer Rails

1

1

1

2

1

3

1

4

SC417J Chassis Manual

5-8

Figure 5-6: Installing into a Rack

Standard Chassis Installation

Installing the Chassis into a Rack

1. Conrm that the inner rails are properly installed on the chassis.

2. Conrm that the outer rails are correctly installed on the rack.

3. Pull the middle rail out from the front of the outer rail and make sure that the

ball-bearing shuttle is at the front locking position of the middle rail.

4. Align the chassis inner rails with the front of the middle rails.

5. Slide the inner rails on the chassis into the middle rails, keeping the pressure

even on both sides, until the locking tab of the inner rail clicks into the front of

the middle rail, locking the chassis into the fully extended position.

6. Depress the locking tabs of both sides at the same time and push the chassis

all the way into the rear of the rack.

7. If necessary for security purposes, use screws to secure the chassis handles

to the front of the rack.

Ball-Bearing

Shuttle

5-9

Chapter 5: Rack Installation

Optional Quick Installation Method

The following quick installation method may be used to install the chassis onto a

rack.

Installing the Chassis into a Rack

1. Install the whole rail assembly onto the rack as described on page 5-7.

2. Release the inner rail without retracting the middle rail.

3. Install the inner rails on the chassis as previously described on page 5-6.

4. Install the chassis onto the middle rail as described in the previous section.

SC417J Chassis Manual

5-10

Adapters for Round and Threaded Hole Racks

The SC417J chassis includes adapter brackets for those customers using round

hole racks or racks with threaded holes size M5 or larger.

Installing the Adapter Bracket

1. Place the hooks of the front of the outer rail into the square holes of one of

the adapter brackets.

2. Place the hooks of the rear of the outer rail into the square holes of a second

adapter bracket.

3. Adjust the length of the outer rail to t within the rack uprights.

4. Secure the front adapter bracket to the front of the rack using the screws

recommended by the rack manufacturer.

5. Secure the rear adapter bracket to the rear of the rack in the same manner.

A-1

Appendix A: Chassis Cables

Appendix A

SC417J Cables and Hardware

A-1 Overview

This appendix lists supported cables for your chassis system. It only includes the

most commonly used components and congurations. For more compatible cables,

refer to the manufacturer of the motherboard you are using and our Web site at:

www.supermicro.com.

A-2 Cables Included with SC417J Chassis (SAS/SATA)

SC417J

Part # Type Length Description

CBL-0386L Cable ---

Four parts (two in and two out) EXT

- to-INT iPass connector

CBL-0281L Cable 75 cm iPass to iPass connector

CBL-0102L Cable 51 cm I2C cable for SATA LED

SC417J Chassis Manual

A-2

A-3 Compatible Cables

These cables are compatible with the SC417J chassis.

Description: This cable has one SFF-8484 (32-pin) connector on one end and four

SAS connectors (seven pins each) at the other. This cable connects from the host

(motherboard or other controller) to the backplane SAS hard drive port.

Cable Name: SAS Cable Quantity: 1

Part #: CBL-0175L
Alt. Name: "Big Four"

Alternate SAS/SATA Cables

Some compatible motherboards have different connectors. If your motherboard

has only one SAS connector that the SAS/SATA cables must share, use one of the

following cables. These cables must be purchased separately.

Description: This cable has one iPass (SFF-8087/Mini-SAS) connector (36-pin) at

one end and four SAS connectors on one end. This cable connects from the host

(motherboard or other controller) to the backplane SAS hard drive port.

Cable Name: SAS Cable Quantity: 1

Part #: CBL-0116
Alt. Name: iPass or "Small Four"

A-3

Appendix A: Chassis Cables

Extending Power Cables

Although Supermicro chassis are designed with to be efcient and cost-effective,

some compatible motherboards have power connectors located in different areas.

To use these motherboards you may have to extend the power cables to the mother

boards. To do this, use the following chart as a guide.

Power Cable Extenders

Number of Pins Cable Part # Length

24-pin CBL-0042 7.9”(20 cm)

20-pin CBL-0059 7.9”(20 cm)

8-pin CBL-0062 7.9”(20 cm)

4-pin CBL-0060 7.9”(20 cm)

Front Panel to the Motherboard

The SC417J chassis includes a cable to connect the chassis front panel to the

motherboard. If your motherboard uses a different connector, use the following list

to nd a compatible cable.

Front Panel to Motherboard Cable (Ribbon Cable)

Number of Pins

(Front Panel)

Number of Pins

(Motherboard)

Cable Part #

16-pin 16-pin CBL-0049

16-pin 20-pin CBL-0048

20-pin 20-pin CBL-0047

16-pin various* CBL-0068

20-pin various* CBL-0067

* Split cables: Use these cable if your motherboard requires several different con-

nections from the front panel.

SC417J Chassis Manual

A-4

A-4 Chassis Screws

The accessory box includes all the screws needed to set up your chassis. This

section lists and describes the most common screws used. Your chassis may not

require all the parts listed.

Flat head

M4 x 4 mm

[0.157]

RAIL

Round head

M4 x 4 mm

[0.157]

Flat head

M5 x 12 mm[0.472]

Washer for M5

DVD-ROM, CD-ROM, and FLOPPY DRIVE

Flat head

6-32 x 5 mm

[0.197]

Pan head

6-32 x 5 mm

[0.197]

Round head

M3 x 5 mm

[0.197]

Pan head

6-32 x 5 mm

[0.197]

M/B

Flat head

6-32 x 5 mm

[0.197]

HARD DRIVE

Thumb screw

6-32 x 5 mm

[0.197]

M/B standoff

6-32 to 6-32

M/B STANDOFFS

M/B (CPU)

standoff

M5 to 6-32

Round head
M2.6 x 5 mm

[0.197]

1/U M/B standoff

6-32 x 5 mm

[0.197]

B-1

Appendix B: Power Supply Specications

Appendix B

SC417JPowerSupplySpecications

This appendix lists power supply specications for your chassis system.

SC417J

1400W

MFR Part # PWS-1K41P-1R

AC Input

1100W: 100 - 140V, 50 - 60Hz, 9.5 - 13.5 Amp
1400W: 180 - 240V, 50 - 60Hz, 7.0 - 9.5 Amp

DC Output

+5V Standby

4 Amp

DC Output

+12V

92 Amp @ 100-140V
116 Amp @ 180-240V

With Distributor:

+5V 30 Amp

+3.3V 24 Amp

-12V 0.6 Amp

SC417J Chassis Manual

B-2

Notes

C-1

Appendix C: SAS2-216EL1/EL2 Backplane Specications

Appendix C

SAS2-216EL1/EL2BackplaneSpecications

C-1 Overview of the SAS2-216EL1/EL2 Backplanes

The SAS2-216EL1/EL2 model backplanes consists of a SAS2-216EB backplane

(A) with one or two SAS2-216EL daughter cards (B and C) mounted on the rear

of the backplane.

The SAS2-216EL1 model consists of the SAS2-216EB backplane (A) and one

SAS2-216EL daughter card (B), mounted on the right-hand side of the backplane.

The SAS2-216EL2 model consists of the SAS2-216EB backplane (A), and two

SAS-216EL daughter cards (B and C), mounted on the rear of the backplane.

Components on the front side of the SAS2-216EB backplane include twenty-four

SAS connectors and their respecitve activity and failure LEDs. Components on the

rear side of the backplane include jumpers and power and fan connectors. The

daughter card's components include SAS ports, ash and expander chips, and

mode select jumpers.

SAS2-216EL Daughter Card (C)

SAS2-216EB Backplane (A)

SAS2-216EL Daughter Card (B)

Rear Side of the Backplane

Front Side of the Backplane

Figure C-1: Overview of the SAS2-216EL1/EL2 Backplane

C-2

SC417 Chassis Manual

Safety Guidelines

To avoid personal injury and property damage, carefully follow all the safety steps

listed below when accessing your system or handling the components.

C-2 ESD Safety Guidelines

Electrostatic Discharge (ESD) can damage electronic com ponents. To prevent damage

to your system, it is important to handle the backplane very carefully. The following

measures are generally sufcient to protect your equipment from ESD.

•Use a grounded wrist strap designed to prevent static discharge.

•Touch a grounded metal object before removing a component from the antistatic

bag.

•Handle the backplane and daughter cards by their edges only; do not touch the

components, peripheral chips, memory modules or gold contacts.

•When handling chips or modules, avoid touching their pins.

•Put the backplane and peripherals back into their antistatic bags when not in

use.

C-3 General Safety Guidelines

•Always disconnect power cables before installing or removing any components

from the computer, including the backplane.

•Disconnect the power cable before installing or removing any cables from the

backplane.

•Make sure that the backplane is securely and properly installed on the mother-

board to prevent damage to the system due to power shortage.

C-3

Appendix C: SAS2-216EL1/EL2 Backplane Specications

C-4 An Important Note to Users

All images and layouts shown in this user's guide are based upon the latest PCB

Revision available at the time of publishing. The card you have received may or

may not look exactly the same as the graphics shown in this manual.

C-5 Introduction to the SAS2-216EL1/EL2 Backplane

The SAS2-216EL1/EL2 model backplane has been designed to utilize the most

up-to-date technology available, providing your system with reliable, high-quality

performance.

This manual reects the SAS2-216EL Revision 1.02 backplane, the most current

release available at the time of publication.

This manual also describes the SAS2-216EL daughter card, Revision 1.02, the most

current release available at the time of publication. Always refer to the Supermicro

Web site at www.supermicro.com for the latest updates, compatible parts and sup-

ported congurations.

C-4

SC417 Chassis Manual

Connectors, Jumpers and LEDs

C-6 Connectors

Connectors

1. Flash Chip

2. Expander Chip

3. SAS Port: PRI_J1

4. SAS Port: PRI_J2

5. SAS Port: PRI_J3

Figure C-2: Connectors on the Backplane and Daughter Cards

MH4

MH3

MH2

MH1

R159

R157

R158

R161

BCA534

BCA236

BCA234

1

MDIOINTERFACE

U320

ACT0

A

C

L37

18

U16

U326

16

17

32

33

48

49

64

L396

1 4

SMART_UART

14

EXPDBG1

Y9

Q3

PRI_MODE2

1

3

PRI_MODE1

1

3

Q1

PRI_J3

PRI_J2

PRI_J1

P_ICE_RTCK

P_ICE_TCK

P_ICE_TDO

2

1

J2

+

EC6

+

C2926

+

+

EC5

+

EC2

+

EC1

+

EC3

+

C862

+

C861

+

C860

+

+

C858

+

5

Y

E

20

R

K

10 15AE25 28

AH

WWN

BAR CODE

A

A

DESIGNED IN USA

Rev:1.02

BPN-SAS2-216EL

J25

2

64

63

J24

2

64

63

U2

Q5

1

BUZZER_ENB1

1

REMOTE_FAN_FAIL2

1

REMOTE_FAN_FAIL1

OVERHEATFAIL1

A

C

FANFAIL1

A

C

5V_LED1

A

C

12V_LED1

A

C

F2

F1

+

EC25

+

EC23

+

EC22

+

EC19

+

EC17

+

EC9

+

EC8

+

EC7

+

EC6

+

EC5

+

EC4

+

EC3

+

EC24

+

EC21

+

EC20

+

EC2

+

EC18

+

EC16

+

EC15

+

EC14

+

EC13

+

EC12

+

EC11

+

EC10

+

EC1

P1

B1

A1

A15

B15

A29

B29

A43

A56

B56B43

P2

B1

A1

A15

B15

A29

B29

A43 A56

B56B43

U3

F7 F4

F11 F10

4

1

FAN1

41

FAN2

4

1

FAN3

PRI_I2C

BUZZER1

+

R14

R16

R17

R19

BPN-SAS2-216EB
REV: 1.02

DESIGNED IN USA

BAR CODE

+5V +12V

GND GND

PWR1

+5V

+12VGND GND

PWR2

+5V +12VGND GND

PWR3

+5V

+12V

GND GND

PWR4

7

1

1

Rear of SAS2-261EB Backplane

Front of SAS2-2l6EL

Daughter Card(s)

2

3

4

5

6

1

9

7

7

8

8

8

1

10

8

6. EPP Connectors: J2

7. Fan Connectors: Fan1, Fan2, and

Fan3

8. Power Connectors: PWR1 - PWR4

9. Debug Connector: EXPDBG1

10. UART Connector: SMART_UART

C-5

Appendix C: SAS2-216EL1/EL2 Backplane Specications

C-7 FrontConnectorandPinDenitions

Backplane

Main Power

4-Pin Connector

Pin# Denition

1

+12V

2 and 3 Ground

4 +5V

8. Backplane Main Power Connectors

The 4-pin connectors are designated

PWR1, PWR2, PWR3 and PWR4. They

provide power to the backplane. See the

table on the right for pin denitions.

7. Fan Connectors

The 3-pin connectors, designated FAN1,

FAN2, and FAN3, provide power to the

fans. See the table on the right for pin

denitions.

Fan Connectors

Pin# Denition

1 Ground

2 +12V

3 Tachometer

2. Expander Chips

This expander chip allows the backplane

to support dual ports, cascading, and

failover.

1. Flash Chips

The ash chip enhances the backplane

memory.

3. - 5. SAS Ports

The primary and secondary sets of SAS

ports provide expander features including

cascading and failover. From right to left

the ports are Primary 1,2,3 and Second-

ary 1,2,3.

6. EPP Ports

The EPP ports are used for manufacturer

diagnostic purposes only.

9. Debug Connector

The debug connector is designated EX-

PDBG1 and is used for manufacturer's

diagnostic purposes only.

10. UART Connector

The UART connector is designated SMART_

UART and is used for manufacturer's diag-

nostic purposes only.

C-6
