Supero MicroCloud 5038ML-H8TRF User Manual

SUPER

SUPERSERVER

MicroCloud

5038ML-H8TRF

®

USER’S MANUAL

Revision 1.0

The information in this User’s Manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
makes no commitment to update or to keep current the information in this manual, or to notify any
person or organization of the updates. Please Note: For the most up-to-date version of this

manual, please see our web site at www.supermicro.com.

Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product
described in this manual at any time and without notice. This product, including software and docu­mentation, is the property of Supermicro and/or its licensors, and is supplied only under a license.
Any use or reproduction of this product is not allowed, except as expressly permitted by the terms
of said license.

IN NO EVENT WILL SUPERMICRO BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO
USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. IN PARTICULAR, SUPERMICRO SHALL NOT HAVE LIABILITY FOR ANY
HARDWARE, SOFTW ARE, OR DA TA STORED OR USED WITH THE PRODUCT, INCLUDING THE
COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH
HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between manufacturer and customer shall be governed by the laws of Santa
Clara County in the State of California, USA. The State of California, County of Santa Clara shall
be the exclusive venue for the resolution of any such disputes. Super Micro's total liability for all
claims will not exceed the price paid for the hardware product.

FCC Statement: This equipment has been tested and found to comply with the limits for a Class A
digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial environ­ment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the manufacturer’s instruction manual, may cause harmful interference
with radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference, in which case you will be required to correct the interference at your own expense.

California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate warn­ing applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate
Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”

WARNING: Handling of lead solder materials used in this
product may expose you to lead, a chemical known to the
State of California to cause birth defects and other repro­ductive harm.

Manual Revision 1.0
Release Date: August 7, 2013

Unless you request and receive written permission from Super Micro Computer, Inc., you may not
copy any part of this document.

Information in this document is subject to change without notice. Other products and companies
referred to herein are trademarks or registered trademarks of their respective companies or mark
holders.

Copyright © 2013 by Super Micro Computer, Inc.
All rights reserved.

Printed in the United States of America

Preface

About This Manual

This manual is written for professional system integrators and PC technicians. It
provides information for the installation and use of the SuperServer 5038ML-H8TRF .
Installation and maintenance should be performed by experienced technicians only .

Preface

The SuperServer 5038ML-H8TRF is an 8-node, MicroCloud
on the SC938BH-R1620B 3U chassis and eight X10SLD-F motherboards.

TM

server system based

Manual Organization

Chapter 1: Introduction

The fi rst chapter provides a checklist of the main components included with the
system and describes the main features of the Super X10SLD-F motherboard and
the SC938BH-R1620B chassis.

Chapter 2: Server Installation

This chapter describes the steps necessary to install the server into a rack and
check out the server confi guration prior to powering up the system. If your server
was ordered without the processor and memory components, this chapter will refer
you to the appropriate sections of the manual for their installation.

Chapter 3: System Interface

Refer to this chapter for details on the system interface, which includes the functions
and information provided by the control panel on the chassis as well as other LEDs
located throughout the system.

Chapter 4: Standardized Warning Statements

You should thoroughly familiarize yourself with this chapter for a general overview
of safety precautions that should be followed when installing and servicing the
SuperServer 5038ML-H8TRF.

iii

SUPERSERVER 5038ML-H8TRF User's Manual

Chapter 5: Advanced Motherboard Setup

Chapter 5 provides detailed information on the X10SLD-F motherboard, including
the locations and functions of connectors, headers and jumpers. Refer to this chap­ter when adding or removing processors or main memory and when reconfi guring
the motherboard.

Chapter 6: Advanced Chassis Setup

Refer to Chapter 6 for detailed information on the SC938BH-R1620B 3U server
chassis. You should follow the procedures given in this chapter when installing,
removing or reconfi guring drives and when replacing system power supply units
and cooling fans.

Chapter 7: BIOS

The BIOS chapter includes an introduction to BIOS and provides detailed informa­tion on running the CMOS Setup Utility.

Appendix A: BIOS Error Beep Codes

Appendix B: System Specifi cations

iv

Notes

Preface

v

SUPERSERVER 5038ML-H8TRF User's Manual

Table of Contents

Chapter 1 Introduction

1-1 Overview .........................................................................................................1-1

1-2 Motherboard Features .....................................................................................1-2

Processors ......................................................................................................1-2

Memory ...........................................................................................................1-2

SATA ..............................................................................................................1-2

Rear I/O Ports ................................................................................................. 1-2

IPMI .................................................................................................................1-2

Other Features ................................................................................................ 1-2

1-3 Server Chassis Features ................................................................................1-4

System Power ................................................................................................. 1-4

Front Control Panel .........................................................................................1-4

Cooling System ............................................................................................... 1-4

1-4 Contacting Supermicro ....................................................................................1-5

Chapter 2 Server Installation

2-1 Overview .........................................................................................................2-1

2-2 Unpacking the System .................................................................................... 2-1

2-3 Preparing for Setup .........................................................................................2-1

Choosing a Setup Location .............................................................................2-1

2-4 Warnings and Precautions .............................................................................. 2-2

Rack Precautions ............................................................................................ 2-2

Server Precautions ..........................................................................................2-2

Rack Mounting Considerations .......................................................................2-2

Ambient Operating Temperature ................................................................ 2-2

Reduced Airfl ow .........................................................................................2-3

Mechanical Loading ................................................................................... 2-3

Circuit Overloading .....................................................................................2-3

Reliable Ground ......................................................................................... 2-3

2-5 Installing the System into a Rack ................................................................... 2-4

Identifying the Sections of the Rack Rails ...................................................... 2-4

Locking Tabs ...................................................................................................2-5

Releasing the Inner Rail .................................................................................2-5

Installing The Inner Rails on the Chassis ....................................................... 2-6

Installing the Outer Rails on the Rack ............................................................ 2-7

Standard Chassis Installation .........................................................................2-8

Optional Quick Installation Method .................................................................2-9

vi

Table of Contents

Chapter 3 System Interface

3-1 Overview .........................................................................................................3-1

3-2 Control Panel Buttons ..................................................................................... 3-1

3-3 LEDs ................................................................................................................3-2

3-4 Hard Drive Carrier LEDs ................................................................................. 3-3

3-5 Node LEDs ...................................................................................................... 3-3

Chapter 4 Standardized Warning Statements for AC Systems

4-1 About Standardized Warning Statements .......................................................4-1

Warning Defi nition ...........................................................................................4-1

Installation Instructions ....................................................................................4-4

Circuit Breaker ................................................................................................ 4-5

Power Disconnection Warning ........................................................................ 4-6

Equipment Installation ..................................................................................... 4-8

Restricted Area ................................................................................................ 4-9

Battery Handling ............................................................................................4-10

Redundant Power Supplies ..........................................................................4-12

Backplane Voltage ........................................................................................ 4-13

Comply with Local and National Electrical Codes ........................................ 4-14

Product Disposal ........................................................................................... 4-15

Hot Swap Fan Warning ................................................................................. 4-16

Power Cable and AC Adapter ...................................................................... 4-18

Chapter 5 Advanced Motherboard Setup

5-1 Handling the Motherboard ..............................................................................5-1

Precautions .....................................................................................................5-1

Unpacking .......................................................................................................5-2

5-2 Connecting Cables .......................................................................................... 5-2

5-3 I/O Ports ..........................................................................................................5-2

5-4 Installing the Processor and Heatsink ............................................................ 5-3

Installing an LGA1150 Processor ....................................................................5-3

Installing a CPU Heatsink ............................................................................... 5-6

5-5 Installing Memory ............................................................................................ 5-7

Memory Support .............................................................................................. 5-7

Memory Population Guidelines .......................................................................5-8

5-6 Adding PCI Add-On Cards .............................................................................. 5-9

5-7 Motherboard Details .......................................................................................5-11

X10SLD-F Quick Reference..........................................................................5-12

5-8 Connector Defi nitions ................................................................................... 5-13

5-9 Jumper Settings ............................................................................................5-15

vii

SUPERSERVER 5038ML-H8TRF User's Manual

5-10 Onboard Indicators ........................................................................................5-17

5-11 SATA Drive Connections ............................................................................... 5-17

5-12 Installing Software ......................................................................................... 5-18

SuperDoctor III .............................................................................................. 5-19

5-13 Onboard Battery ............................................................................................ 5-20

Chapter 6 Advanced Chassis Setup

6-1 Static-Sensitive Devices ..................................................................................6-1

Precautions .....................................................................................................6-1

6-2 Removing the Chassis Cover ......................................................................... 6-2

6-3 Corresponding Nodes, Fans and Hard Drives ................................................6-3

6-4 Removing and Installing Hard Drives ............................................................. 6-4

6-5 Removing and Installing the Backplane ..........................................................6-7

Removing the Backplane and Fan Bracket Assembly ....................................6-7

Removing the Backplane from the Fan Bracket ............................................. 6-8

Installing the Backplane onto the Fan Bracket ............................................... 6-9

Installing the Backplane and Fan Bracket Assembly ....................................6-10

6-6 Removing and Installing Motherboard Nodes ................................................6-11

6-7 Installing an Air Shroud ................................................................................. 6-12

6-8 System Fans .................................................................................................6-13

6-9 Power Supply ................................................................................................ 6-14

Power Supply Replacement .......................................................................... 6-14

Chapter 7 BIOS

7-1 Introduction ......................................................................................................7-1

Starting BIOS Setup Utility .............................................................................. 7-1

How To Change the Confi guration Data ......................................................... 7-1

How to Start the Setup Utility .........................................................................7-2

7-2 Main Setup ...................................................................................................... 7-2

7-3 Advanced Setup Confi gurations......................................................................7-4

7-4 Event Logs .................................................................................................... 7-23

7-5 IPMI ............................................................................................................... 7-25

7-6 Boot Settings ................................................................................................. 7-27

7-7 Security Settings ...........................................................................................7-29

7-8 Save & Exit ................................................................................................... 7-30

Appendix A BIOS Error Beep Codes
Appendix B System Specifi cations

viii

Chapter 1: Introduction

Chapter 1

Introduction

1-1 Overview

The SuperServer 5038ML-H8TRF is an eight node, MicroCloud server system
comprised of two main subsystems: the SC938BH-R1620B 3U chassis and eight
X10SLD-F motherboards. Please refer to our web site for information on operating
systems that have been certifi ed for use with the 5038ML-H8TRF (www.supermicro.
com).

In addition to the motherboards and chassis, various hardware components have
been included with the 5038ML-H8TRF, as listed below:

• Four chassis fans (FAN-0133L4)

• One passive heatsink, each node (SNK-P0047PS+)

• One air shroud, each node (MCP-310-93804-0B)

• One riser card, each node (RSC-RR1U-E8)

• One add-on card, each node (AOC-CGP-i2)

• SATA Accessories

One SATA backplane (BPN-SAS-938H)
Sixteen hot-swap hard drive carriers (MCP-220-00094-0B)

• One rail kit (MCP-290-00057-0N)

1-1

SUPERSERVER 5038ML-H8TRF User's Manual

1-2 Motherboard Features

The 5038ML-H8TRF includes a total of eight X10SLD-F single processor mother­boards, which are based on the Intel C224 PCH chipset. Below are the main features
of the X10SLD-F. (See Figure 1-1 for a block diagram of the chipset).

Processors

Each X10SLD-F supports a single Intel® Xeon® E3-1200 v3 family or Intel 4th
Gen Core™ i3, Pentium or Celeron processor in an LGA 1150 socket (Socket H3).
Please refer to the motherboard description pages on our web site for a complete
listing of supported processors (www.supermicro.com).

Memory

The X10SLD-F has four DIMM slots that can support up to 32 GB of ECC UDIMM
DDR3-1600/1333/1066 memory. This equates to a maximum of 256 GB for the
system. Memory modules of the same size and speed should be used. See Chapter
5 for details.

SATA

Each X10SLD-F has a SA TA controller integrated into the chipset to provide four on­board SA T A 3.0 ports. T wo of these can be connected to the system's hot-swappable
SATA drives (two from each node for 16 total in the system).

Rear I/O Ports

The rear I/O panel includes one KVM connector, an IPMI port, a power LED and
buttons for UID (Unit Identifi cation) and power.

IPMI

IPMI (Intelligent Platform Management Interface) is a hardware-level interface speci­fi cation that provides remote access, monitoring and administration for Supermicro
server platforms. IPMI allows server administrators to view a server’s hardware
status remotely, receive an alarm automatically if a failure occurs, and power cycle
a system that is non-responsive.

Other Features

Other onboard features that promote system health include onboard voltage moni­tors, a chassis intrusion header, auto-switching voltage regulators, chassis and CPU
overheat sensors, virus protection and BIOS rescue.

1-2

Chapter 1: Introduction

Figure 1-1. Intel C224 Chipset:

System Block Diagram

Note: This is a general block diagram. See Chapter 5 for details.

PCIe x8 SLOT
PCIe x8 Micro-LP SLOT

SVID

VRM 12.5
MISC VRs

4 SATA PORTS

1 SATA PORT

1 USB PORT (Type A)

2 USB PORTS

2 USB PORTS (KVM)

TPM1.2 Header

FLASH SPI 128Mb

PCIe3.0_x8
PCIe3.0_x8

8.0Gb/s

USB2.0 X 1

480Mb/s

SATA-III

6.0Gb/s

SATA-II

(3.0Gb/s for-F, 6.0Gb/s for-HF)

USB3.0 X 1

5.0Gb/s

USB3.0 X 1

5.0Gb/s

USB2.0 X 3

480Mb/s

LPC
SPI

Haswell

(H3)

5.0Gb

x4 DMI II

Lynx Point

C224/C226

PCH

LPC

DDR3 (CHA)

1600/1333MHz

DDR3 (CHB)

1600/1333MHz

PCIe2.0 x1

LPC

ASPEED
ASP2400

RGMII

RTL8211E
PHY

RJ45
(1Gb)

DIMM1
DIMM2 (Far)

DIMM1
DIMM2 (Far)

VGA PORT

(KVM)

COM1 (KVM)

HEALTH
INFO

NCT6776D
LPC I/O

1-3

SUPERSERVER 5038ML-H8TRF User's Manual

1-3 Server Chassis Features

The following is a general outline of the main features of the SC938BH-R1620B
server chassis.

System Power

The SC938BH-R1620B features a redundant (two separate power modules) 1620W
Platinum Level, high-effi ciency power supply . This power redundancy feature allows
you to replace a failed power supply without shutting down the system.

Front Control Panel

The control panel on the 5038ML-H8TRF features a power button/LED, a power fail
LED and eight LEDs to indicate the status of each node in the system.

Cooling System

The SC938BH-R1620B chassis includes four 8-cm fans located behind the back­plane. Each fan is associated with and controlled by two nodes. Each node also
has an air shroud to channel the airfl ow from the system fans to effi ciently cool the
components that generate the most heat. See Chapter 6 for details.

1-4

1-4 Contacting Supermicro

Headquarters

Address: Super Micro Computer, Inc.

980 Rock Ave.

San Jose, CA 95131 U.S.A.
Tel: [phone]
Fax: [phone]
Email: [e-mail] (General Information)

[e-mail] (Technical Support)

Chapter 1: Introduction

Web Site:

Europe

Address: Super Micro Computer B.V.

Tel: [phone]
Fax: [phone]
Email: [e-mail] (General Information)

Asia-Pacifi c

Address: Super Micro Computer, Inc.

www.supermicro.com

Het Sterrenbeeld 28, 5215 ML

's-Hertogenbosch, The Netherlands

[e-mail] (Technical Support)

[e-mail] (Customer Support)

3F, No. 150, Jian 1st Rd.

Zhonghe Dist., New Taipei City 23511

Taiwan (R.O.C)
Tel: [phone]
Fax: [phone]
Web Site:
Technical Support:
Email: [e-mail]
Tel: [phone]

www.supermicro.com.tw

1-5

SUPERSERVER 5038ML-H8TRF User's Manual

Notes

1-6

Chapter 2: Server Installation

Chapter 2

Server Installation

2-1 Overview

This chapter provides a quick setup checklist to get your 5038ML-H8TRF up and
running. Following these steps in the order given should enable you to have the
system operational within a minimum amount of time. This quick setup assumes
that your system has come to you with the processors and memory preinstalled.

2-2 Unpacking the System

You should inspect the box the 5038ML-H8TRF was shipped in and note if it was
damaged in any way. If the server itself shows damage you should fi le a damage
claim with the carrier who delivered it.

Decide on a suitable location for the rack unit that will hold the 5038ML-H8TRF.
It should be situated in a clean, dust-free area that is well ventilated. Avoid areas
where heat, electrical noise and electromagnetic fi elds are generated. You will also
need it placed near a grounded power outlet. Be sure to read the Rack and Server
Precautions in the next section.

2-3 Preparing for Setup

The 5038ML-H8TRF may have come with hardware to mount it into a server rack. If
mounting to a rack with the rail kit, follow the steps in the order given to complete the
installation process in a minimum amount of time. Please read this section in its en­tirety before you begin the installation procedure outlined in the sections that follow.

Choosing a Setup Location

• Leave enough clearance in front of the rack to enable you to open the front door

completely (~25 inches) and approximately 30 inches of clearance in the back
of the rack to allow for suffi cient airfl ow and ease in servicing.

• This product is for installation only in a Restricted Access Location (dedicated

equipment rooms, service closets and the like).

2-1

SUPERSERVER 5038ML-H8TRF User's Manual

• This product is not suitable for use with visual display work place devices

acccording to §2 of the the German Ordinance for Work with Visual Display Units.

2-4 Warnings and Precautions

Rack Precautions

• Ensure that the leveling jacks on the bottom of the rack are fully extended to

the fl oor with the full weight of the rack resting on them.

• In single rack installation, stabilizers should be attached to the rack. In multiple

rack installations, the racks should be coupled together.

• Always make sure the rack is stable before extending a component from it.

• You should extend only one component at a time - extending two or more si-

multaneously may cause the rack to become unstable.

Server Precautions

• Review the electrical and general safety precautions in Chapter 4.

• Determine the placement of each component in the rack before you install the

rails.

• Install the heaviest server components on the bottom of the rack fi rst, and then

work up.

• Use a regulating uninterruptible power supply (UPS) to protect the server from

power surges, voltage spikes and to keep your system operating in case of a
power failure.

• Allow the SATA drives and power supply modules to cool before touching them.

• Always keep the rack's front door and all panels and components on the servers

closed when not servicing to maintain proper cooling.

Rack Mounting Considerations

Ambient Operating Temperature

If installed in a closed or multi-unit rack assembly, the ambient operating tempera­ture of the rack environment may be greater than the ambient temperature of the

2-2

Chapter 2: Server Installation

room. Therefore, consideration should be given to installing the equipment in an
environment compatible with the manufacturer’s maximum rated ambient tempera­ture (Tmra).

Reduced Airfl ow

Equipment should be mounted into a rack so that the amount of airfl ow required
for safe operation is not compromised.

Mechanical Loading

Equipment should be mounted into a rack so that a hazardous condition does not
arise due to uneven mechanical loading.

Circuit Overloading

Consideration should be given to the connection of the equipment to the power
supply circuitry and the effect that any possible overloading of circuits might have
on overcurrent protection and power supply wiring. Appropriate consideration of
equipment nameplate ratings should be used when addressing this concern.

Reliable Ground

A reliable ground must be maintained at all times. To ensure this, the rack itself
should be grounded. Particular attention should be given to power supply connec­tions other than the direct connections to the branch circuit (i.e. the use of power
strips, etc.).

Warning! To prevent bodily injury when mounting or servicing this unit in a
rack, you must take special precautions to ensure that the system remains
stable. The following guidelines are provided to ensure your safety:

• This unit should be mounted at the bottom of the rack if it is the only unit in

the rack.

• When mounting this unit in a partially fi lled rack, load the rack from the bottom

to the top with the heaviest component at the bottom of the rack.

• If the rack is provided with stabilizing devices, install the stabilizers before

mounting or servicing the unit in the rack.

2-3

SUPERSERVER 5038ML-H8TRF User's Manual

2-5 Installing the System into a Rack

This section provides information on installing the chassis into a rack unit with the
rails provided. There are a variety of rack units on the market, which may mean
that the assembly procedure will differ slightly from the instructions provided. You
should also refer to the installation instructions that came with the rack unit you are

using. Note: This rail will fi t a rack between 26.5" and 36.4" deep.

Identifying the Sections of the Rack Rails

The chassis package includes two rail assemblies in the rack mounting kit. Each
assembly consists of three sections: An inner chassis rail that secures directly to
the chassis, an outer rail that secures to the rack, and a middle rail, which extends
from the outer rail. These assemblies are specifi cally designed for the left and right
side of the chassis.

Rail Assembly

(Shown with Rails

Retracted)

This Side Faces

Outward

Figure 2-1. Identifying the Outer, Middle and Inner Rails

Outer Rail

Middle Rail

Locking Tab

Inner Rail

(Left Rail Assembly Shown)

Warning: do not pick up the server with the front handles. They are de-

signed to pull the system from a rack only.

2-4

Chapter 2: Server Installation

Locking Tabs

Each inner rail has a locking tab. This tab locks the chassis into place when installed
and pushed fully into the rack. These tabs also lock the chassis in place when fully
extended from the rack. This prevents the server from coming completely out of
the rack when when the chassis is pulled out for servicing.

Releasing the Inner Rail

Releasing Inner Rail from the Outer Rails

1. Identify the left and right outer rail assemblies as described on the previous
page.

2. Pull the inner rail out of the outer rail until it is fully extended as illustrated
below.

3. Press the locking tab down to release the inner rail.

4. Repeat steps 1-3 for the remaining outer rail.

1

1

2

1

3

1

Figure 2-2. Extending and Releasing the Inner Rail

2-5

4

1

SUPERSERVER 5038ML-H8TRF User's Manual

4

1

Figure 2-3. Installing the Inner Rails

Inner Rails

2

1

3

1

1

4

Figure 2-4. Inner Rails Installed on the Chassis

Installing The Inner Rails on the Chassis

Installing the Inner Rails

1. Confi rm that the left and right inner rails have been correctly identifi ed.

2. Place the inner rail fi rmly against the side of the chassis, aligning the hooks
on the side of the chassis with the holes in the inner rail.

3. Slide the inner rail forward toward the front of the chassis until the rail clicks
into the locked position, which secures the inner rail to the chassis.

4. Secure the inner rail to the chassis with the screws provided.

5. Repeat steps 1 through 4 above for the other inner rail.

2-6

Chapter 2: Server Installation

1

1

4

1

2

1

3

1

Figure 2-5. Extending and Releasing the Outer Rails

Installing the Outer Rails on the Rack

Installing the Outer Rails

1. Press upward on the locking tab at the rear end of the middle rail.

2. Push the middle rail back into the outer rail.

3. Hang the hooks of the front of the outer rail onto the slots on the front of
the rack. If necessary, use screws to secure the outer rails to the rack, as
illustrated above.

4. Pull out the rear of the outer rail, adjusting the length until it fi ts within the
posts of the rack.

5. Hang the hooks of the rear portion of the outer rail onto the slots on the rear
of the rack. If necessary, use screws to secure the rear of the outer rail to the
rear of the rack.

6. Repeat steps 1-5 for the remaining outer rail.

Stability hazard. The rack stabilizing mechanism must be in place, or the
rack must be bolted to the fl oor before you slide the unit out for servicing.
Failure to stabilize the rack can cause the rack to tip over.

2-7

SUPERSERVER 5038ML-H8TRF User's Manual

Ball-Bearing

Shuttle

Figure 2-6. Installing the Chassis into a Rack

Standard Chassis Installation

1. Confi rm that the inner rails are properly installed on the chassis.

2. Confi rm that the outer rails are correctly installed on the rack.

3. Pull the middle rail out from the front of the outer rail and make sure that the
ball-bearing shuttle is at the front locking position of the middle rail.

4. Align the chassis inner rails with the front of the middle rails.

5. Slide the inner rails on the chassis into the middle rails, keeping the pressure
even on both sides, until the locking tab of the inner rail clicks into the front of
the middle rail, locking the chassis into the fully extended position.

6. Depress the locking tabs of both sides at the same time and push the chassis
all the way into the rear of the rack.

7. If necessary for security purposes, use screws to secure the chassis handles
to the front of the rack.

2-8

Chapter 2: Server Installation

Optional Quick Installation Method

The following quick installation method may be used to install the chassis onto a
rack.

1. Install the inner rails on the chassis as previously described on page 2-6.

2. Install the whole rail assembly onto the rack as described on page 2-7.

3. Release the inner rail without retracting the middle rail.

4. Install the chassis onto the middle rail as described in the previous section.

Note that these fi gures are for illustrative purposes only. Servers should always be
installed to racks from the bottom up.

Figure 2-7. Installing the Chassis into a Rack

2-9

SUPERSERVER 5038ML-H8TRF User's Manual

Notes

2-10

Chapter 3: System Interface

Chapter 3

System Interface

3-1 Overview

LEDs are included on the control panel, the motherboard nodes and on the drive
carriers to keep you constantly informed of the overall status of the system. The
SC938BH-R1620B features four separate control panels on the handles of the
chassis to control the nodes.

This chapter explains the meanings of all LED indicators and the appropriate re­sponse you may need to take.

3-2 Control Panel Buttons

Power Button/LED

The main power button on the control panel functions as both an on/off switch and
as an LED. The LED illuminates green when powered-on and is not illuminated
when powered-off.

• A quick press of less than fi ve seconds will sequentially power-on all of the

nodes in order from one to eight.

• Pressing the button for longer than fi ve seconds will sequentially power-

down the nodes in order from one to eight.

Turning off system power with this button removes the main power, but keeps
standby power supplied to the system. Therefore, you must completely unplug
system from any power source before servicing the chassis. This does not apply
to hot-swappable hard drives, motherboard nodes and system fans.

3-1

SUPERSERVER 5038ML-H8TRF User's Manual

3-3 LEDs

Power Failure LED

This red LED is illuminated only when a power failure occurs. The LED will illuminate
when any node is powered-on and one of the power supplies fails. This LED is off
during normal operation.

Node Status LEDs

The SC938BH-R1620B control panel features eight numbered node status LEDs,
which indicate the status of each motherboard node.

Figure 3-1. Node Status LEDs

LED Appearance Description

Solid Green The node is powered on and operating normally

Blinking Green The node is in the process of shutting down

Solid Red The node is detecting an overheated condition

1Hz Blinking Red The node is detecting a fan failure

.25Hz Blinking Red The node is detecting a power failure

Solid Blue The node local UID is on

1Hz Blinking Blue The node remote UID is on

No Illumination The node is powered-down

3-2

Chapter 3: System Interface

3-4 Hard Drive Carrier LEDs

The hard drives ued in the SC938BH-R1620B chassis are installed in drive carriers.
Each drive carrier has two LEDs located on the front of the carrier.

• Green: Each drive carrier has a green LED. When illuminated, this LED indicates

drive activity. A connection to the SATA backplane enables this LED to blink on
and off when that particular drive is being accessed.

• Red: Indicates a drive failure. If one of the drives fail, you should also be notifi ed

by your system management software.

Figure 3-2. Hard Drive Carrier LEDs

Hard Drive Carrier LEDs

3-5 Node LEDs

Individual LEDS are located on the back of each motherboard node on the rear
of the chassis.

3-3

SUPERSERVER 5038ML-H8TRF User's Manual

Figure 3-3. Rear Node LED Indicators

Power Button

and LED

(Green)

UIO Button

and LED

(Blue)

Failure LED

(Red)

Power Button and LED

This button will power on the node individually . It is illuminated green when the node
is powered on, it is off (unilluminated ) when the node is powered off.

UIO Button and LED

This button is used to identify the node within the system. It is illuminated blue when
activated, it is off when inactive.

Failure LED

This LED is illuminated red when a failure has occurred and off during normal opera­tion. If illuminated, check that the two corresponding hard drives are fully inserted
into their bays with their handles completely pushed in. Check also that the fan is
operating properly and that the node is fully inserted into its bay.

3-4

Chapter 4: Warning Statements for AC Systems

Chapter 4

Standardized Warning Statements for AC Systems

4-1 About Standardized Warning Statements

The following statements are industry standard warnings, provided to warn the user
of situations which have the potential for bodily injury. Should you have questions
or experience difficulty, contact Supermicro's Technical Support department
for assistance. Only certifi ed technicians should attempt to install or confi gure
components.

Read this appendix in its entirety before installing or confi guring components in the
Supermicro chassis.

These warnings may also be found on our web site at http://www.supermicro.com/
about/policies/safety_information.cfm.

Warning Defi nition

Warning!

This warning symbol means danger. You are in a situation that could cause bodily
injury. Before you work on any equipment, be aware of the hazards involved with
electrical circuitry and be familiar with standard practices for preventing accidents.

警告の定義

この警告サインは危険を意味します。

人身事故につながる可能性がありますので、いずれの機器でも動作させる前に、

電気回路に含まれる危険性に注意して、標準的な事故防止策に精通して下さい。

此警告符号代表危险。

您正处于可能受到严重伤害的工作环境中。在您使用设备开始工作之前，必须充分
意识到触电的危险，并熟练掌握防止事故发生的标准工作程序。请根据每项警告结
尾的声明号码找到此设备的安全性警告说明的翻译文本。

此警告符號代表危險。

您正處於可能身體可能會受損傷的工作環境中。在您使用任何設備之前，請注意觸
電的危險，並且要熟悉預防事故發生的標準工作程序。請依照每一注意事項後的號
碼找到相關的翻譯說明內容。

4-1

SUPERSERVER 5038ML-H8TRF User's Manual

ןונקת תורהצהאהרהז

Warnung
WICHTIGE SICHERHEITSHINWEISE
Dieses Warnsymbol bedeutet Gefahr. Sie befi nden sich in einer Situation, die zu

Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den
Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung
vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen
Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten
Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.

BEWAHREN SIE DIESE HINWEISE GUT AUF.

INSTRUCCIONES IMPORTANTES DE SEGURIDAD
Este símbolo de aviso indica peligro. Existe riesgo para su integridad física. Antes

de manipular cualquier equipo, considere los riesgos de la corriente eléctrica y
familiarícese con los procedimientos estándar de prevención de accidentes. Al
fi nal de cada advertencia encontrará el número que le ayudará a encontrar el texto
traducido en el apartado de traducciones que acompaña a este dispositivo.

GUARDE ESTAS INSTRUCCIONES.

IMPORTANTES INFORMATIONS DE SÉCURITÉ
Ce symbole d'avertissement indique un danger. Vous vous trouvez dans une

situation pouvant entraîner des blessures ou des dommages corporels. Avant
de travailler sur un équipement, soyez conscient des dangers liés aux circuits
électriques et familiarisez-vous avec les procédures couramment utilisées pour
éviter les accidents. Pour prendre connaissance des traductions des avertissements
fi gurant dans les consignes de sécurité traduites qui accompagnent cet appareil,
référez-vous au numéro de l'instruction situé à la fi n de chaque avertissement.

CONSERVEZ CES INFORMATIONS.

ןה תואבה תורהצהא ינפמ שמתשמה תא ריהזהל תנמ לע ,היישעתה ינקת יפ לע תורהז הלבח

ה וא תולאש שיו הדימב .תירשפא תיזיפי ,יהשלכ היעבב תולקתרוציל שי הכימת תקלחמ םע רשק

רידגהל וא ןיקתהל םיאשר דבלב םיכמסומ םיאנכט .ורקימרפוס לש תינכט תאה .םיביכר

תרדגה וא תנקתה ינפל ואולמב חפסנה תא

אורקל שי .ורקימרפוס יזראמב םיביכרה

4-2

Warning Statements for AC Systems

. ﻲﻓ ﻚﻧﺍ ﻥﺃ ﻦﻜﻤﻳ ﺔﻟﺎﺣ ﻲﻓ ﺐﺒﺴﺘﺗ ﺔﺑﺎﺻﺍ ﺔﻳﺪﺴﺟ ﺰﻣﺮﻟﺍ ﺍﺬﻫ ﻲﻨﻌﻳ ﺮﻄﺧ !ﺮﻳﺬﺤﺗ

ﻥﺃ ﻞﺒﻗ ﻱﺃ ﻰﻠﻋ ﻞﻤﻌﺗ ﺕﺍﺪﻌﻣ،ﻛﻢﻠﻋ ﻰﻠﻋ ﻦ ﻦﻋ ﺔﻤﺟﺎﻨﻟﺍ ﺮﻁﺎﺨﻤﻟﺎﺑ ﺮﺋﺍﻭﺪﻟﺍ

ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ

ﻛﻭﺔﻳﺍﺭﺩ ﻰﻠﻋ ﻦ ﺭﺎﻤﻤﻟﺎﺑﺕﺎﺳ ﺔﻴﺋﺎﻗﻮﻟﺍ ﻟ ﻊﻨﻤﻉﻮﻗﻭ ﻱﺃﺙﺩﺍﻮﺣ

ﻢﻗﺭ ﻡﺪﺨﺘﺳﺍ ﻥﺎﻴﺒﻟﺍ ﺹﻮﺼﻨﻤﻟﺍ ﺔﻳﺎﻬﻧ ﻲﻓ ﺮﻳﺬﺤﺗ ﻞﻛ ﺭﻮﺜﻌﻠﻟ ﺎﻬﺘﻤﺟﺮﺗ

안전을 위한 주의사항

경고!

이 경고 기호는 위험이 있음을 알려 줍니다. 작업자의 신체에 부상을 야기 할 수
있는 상태에 있게 됩니다. 모든 장비에 대한 작업을 수행하기 전에 전기회로와
관련된 위험요소들을 확인하시고 사전에 사고를 방지할 수 있도록 표준
작업절차를 준수해 주시기 바랍니다.

해당 번역문을 찾기 위해 각 경고의 마지막 부분에 제공된 경고문 번호를
참조하십시오

BELANGRIJKE VEILIGHEIDSINSTRUCTIES
Dit waarschuwings symbool betekent gevaar. U verkeert in een situatie die

lichamelijk letsel kan veroorzaken. Voordat u aan enige apparatuur gaat werken,
dient u zich bewust te zijn van de bij een elektrische installatie betrokken risico's
en dient u op de hoogte te zijn van de standaard procedures om ongelukken te
voorkomen. Gebruik de nummers aan het eind van elke waarschuwing om deze te
herleiden naar de desbetreffende locatie.

BEWAAR DEZE INSTRUCTIES

4-3

SUPERSERVER 5038ML-H8TRF User's Manual

Installation Instructions

Warning!

Read the installation instructions before connecting the system to the power source.

設置手順書

システムを電源に接続する前に、設置手順書をお読み下さい。

警告
将此系统连接电源前,请先阅读安装说明。

警告
將系統與電源連接前，請先閱讀安裝說明。

Warnung
Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen

lesen.

¡Advertencia!
Lea las instrucciones de instalación antes de conectar el sistema a la red de

alimentación.

Attention
Avant de brancher le système sur la source d'alimentation, consulter les directives

d'installation.

אורקל שי רוקמל תכרעמה רוביח ינפל הנקתה תוארוה תאחתמ.

ﻟﺍ ﺕﺍﺩﺎﺷﺭﺇ ﺮﻗﺍﺐﻴﻛﺮﺘ ﻞﻴﺻﻮﺗ ﻞﺒﻗ ﻰﻟﺇ ﻡﺎﻈﻨﻟﺍ ﺔﻗﺎﻄﻠﻟ ﺭﺪﺼﻣ

시스템을 전원에 연결하기 전에 설치 안내를 읽어주십시오.

Waarschuwing
Raadpleeg de installatie-instructies voordat u het systeem op de voedingsbron

aansluit.

4-4

Chapter 4: Warning Statements for AC Systems

Circuit Breaker

Warning!

This product relies on the building's installation for short-circuit (overcurrent)
protection. Ensure that the protective device is rated not greater than: 250 V, 20 A.

サーキット・ブレーカー

この製 品は、短絡（過電流）保護装置がある建物での設置を前提としています。

保護装置の定格が250V、20Aを超えないことを確認下さい。

警告
此产品的短路(过载电流)保护由建筑物的供电系统提供,确保短路保护设备的额定电
流不大于250V,20A。

警告
此產品的短路(過載電流)保護由建築物的供電系統提供,確保短路保護設備的額定電
流不大於250V,20A。

Warnung
Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss-

bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der
Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt.

¡Advertencia!
Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes)

del edifi cio. Asegúrese de que el dispositivo de protección no sea superior a: 250
V, 20 A.

Attention
Pour ce qui est de la protection contre les courts-circuits (surtension), ce produit

dépend de l'installation électrique du local. Vérifi ez que le courant nominal du
dispositif de protection n'est pas supérieur à :250 V, 20 A.

4-5

SUPERSERVER 5038ML-H8TRF User's Manual

경고!

이 제품은 전원의 단락(과전류)방지에 대해서 전적으로 건물의 관련 설비에
의존합니다. 보호장치의 정격이 반드시 250V(볼트), 20A(암페어)를 초과하지
않도록 해야 합니다.

Waarschuwing
Dit product is afhankelijk van de kortsluitbeveiliging (overspanning) van

uw electrische installatie. Controleer of het beveiligde aparaat niet groter
gedimensioneerd is dan 220V, 20A.

Power Disconnection Warning

Warning!

The system must be disconnected from all sources of power and the power cord
removed from the power supply module(s) before accessing the chassis interior to
install or remove system components.

電源切断の警告
システムコンポーネントの取り付けまたは取り外しのために、シャーシー内部にアクセス

するには、
システムの電源はすべてのソースから切断され、電源コードは電源モジュールから取り

外す必要があります。

警告

在你打开机箱并安装或移除内部器件前,必须将系统完全断电,并移除电源线。

警告

在您打開機殼安裝或移除內部元件前，必須將系統完全斷電，並移除電源線。

Warnung
Das System muss von allen Quellen der Energie und vom Netzanschlusskabel

getrennt sein, das von den Spg.Versorgungsteilmodulen entfernt wird, bevor es
auf den Chassisinnenraum zurückgreift, um Systemsbestandteile anzubringen oder
zu entfernen.

4-6

Chapter 4: Warning Statements for AC Systems

ילמשח קותינ ינפמ הרהזא

!הרהזא

¡Advertencia!
El sistema debe ser disconnected de todas las fuentes de energía y del cable

eléctrico quitado de los módulos de fuente de alimentación antes de tener acceso
el interior del chasis para instalar o para quitar componentes de sistema.

Attention
Le système doit être débranché de toutes les sources de puissance ainsi que de

son cordon d'alimentation secteur avant d'accéder à l'intérieur du chassis pour
installer ou enlever des composants de systéme.

למשחה תורוקמ לכמ תכרעמה תא קתנל שי ריסהל שיו קפסהמ ילמשחה לבכ תא

נקתה ךרוצל זראמה לש ימינפה קלחל השיג ינפלת רסה ואת .םיביכר

ﻞﺼﻓ ﺐﺠﻳ ﻡﺎﻈﻨﻟﺍ ﻊﻴﻤﺟ ﻦﻣﺭﺩﺎﺼﻣ ﺔﻗﺎﻄﻟﺍ ﺔﻟﺍﺯﺇﻭ ءﺎﺑﺮﻬﻜﻟﺍ ﻚﻠﺳ ﻦﻣ ﺓﺪﺣﻭ ﺩﺍﺪﻣﺍ

ﺔﻗﺎﻄﻟﺍ ﻞﺒﻗ

ﺯﺎﻬﺠﻟﺍ

경고!

시스템에 부품들을 장착하거나 제거하기 위해서는 섀시 내부에 접근하기 전에
반드시 전원 공급장치로부터 연결되어있는 모든 전원과 전기코드를 분리해주어야
합니다.

Waarschuwing
Voordat u toegang neemt tot het binnenwerk van de behuizing voor het installeren

of verwijderen van systeem onderdelen, dient u alle spanningsbronnen en alle
stroomkabels aangesloten op de voeding(en) van de behuizing te verwijderen

ﻰﻟﺇ ﻝﻮﺻﻮﻟﺍ ﺔﻴﻠﺧﺍﺪﻟﺍ ﻖﻁﺎﻨﻤﻟﺍ ﻟﻞﻜﻴﻬﻠ ﺔﻟﺍﺯﺇ ﻭﺃ ﺖﻴﺒﺜﺘﻟ ﺕﺎﻧﻮﻜﻣ

4-7

SUPERSERVER 5038ML-H8TRF User's Manual

Equipment Installation

Warning!

Only trained and qualifi ed personnel should be allowed to install, replace, or service
this equipment.

機器の設置

トレーニングを受け認定された人だけがこの装置の設置、交換、またはサービスを許可
されています。

警告
只有经过培训且具有资格的人员才能进行此设备的安装、更换和维修。

警告
只有經過受訓且具資格人員才可安裝、更換與維修此設備。

Warnung
Das Installieren, Ersetzen oder Bedienen dieser Ausrüstung sollte nur geschultem,

qualifi ziertem Personal gestattet werden.

¡Advertencia!
Solamente el personal califi cado debe instalar, reemplazar o utilizar este equipo.

Attention
Il est vivement recommandé de confier l'installation, le remplacement et la

maintenance de ces équipements à des personnels qualifi és et expérimentés.

!הרהזא

שר דבלב ךמסומ תווצתא ףילחהל ,ןיקתהל יא .דויצה רובע תוריש תתל וא דויצה

ﻦﻴﺑﺭﺪﻤﻟﺍﻭ ﻭ ﺐﻴﻛﺮﺘﻟﻝﺍﺪﺒﺘﺳﺍ ﻭﺃ ﺔﻣﺪﺧ ﺯﺎﻬﺠﻟﺍ ﺍﺬﻫ ﺢﻤﺴﻳ ﻥﺃ ﺐﺠﻳ ﻂﻘﻓ ﻦﻴﻠﻫﺆﻤﻟﺍ ﻦﻴﻔﻅﻮﻤﻠﻟ

경고!

훈련을 받고 공인된 기술자만이 이 장비의 설치, 교체 또는 서비스를 수행할 수
있습니다.

4-8

Chapter 4: Warning Statements for AC Systems

Waarschuwing
Deze apparatuur mag alleen worden geïnstalleerd, vervangen of hersteld door

geschoold en gekwalifi ceerd personeel.

Restricted Area

Warning!

This unit is intended for installation in restricted access areas. A restricted access
area can be accessed only through the use of a special tool, lock and key, or other
means of security. (This warning does not apply to workstations).

アクセス制限区域
このユ ニットは、アクセス制限区域に設置されることを想定しています。
アクセス制限区域は、特別なツール、鍵と錠 前、その他のセキュリティの手段を用いての

み出入りが可能です。

警告
此部件应安装在限制进出的场所，限制进出的场所指只能通过使用特殊工具、锁和
钥匙或其它安全手段进出的场所。

警告
此裝置僅限安裝於進出管制區域，進出管制區域係指僅能以特殊工具、鎖頭及鑰匙
或其他安全方式才能進入的區域。

Warnung
Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen.

Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und
Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich.

¡Advertencia!
Esta unidad ha sido diseñada para instalación en áreas de acceso restringido.

Sólo puede obtenerse acceso a una de estas áreas mediante la utilización de una
herramienta especial, cerradura con llave u otro medio de seguridad.

Attention
Cet appareil doit être installée dans des zones d'accès réservés. L'accès à une

zone d'accès réservé n'est possible qu'en utilisant un outil spécial, un mécanisme
de verrouillage et une clé, ou tout autre moyen de sécurité.

4-9

SUPERSERVER 5038ML-H8TRF User's Manual

תלבגומ השיג םע רוזא

!הרהזא

תרזעב תנתינ השיגה .השיג תלבגה םהב שיש םירוזאב הדיחיה תא ןיקתהל שי

.('דכו לוענמ ,חתפמ) דבלב החטבא ילכ

. ﺺﻴﺼﺨﺗ ﺓﺪﺣﻮﻟﺍ ﻩﺬﻫ ﻲﻓ ﺎﻬﺒﻴﻛﺮﺘﻟ ﻖﻁﺎﻨﻣ ﺓﺭﻮﻈﺤﻣ ﻢﺗ

ﺻﻮﻟﺍ ﻦﻜﻤﻳﻰﻟﺇ ﻝﻮ ﺔﻘﻄﻨﻣ ﺓﺭﻮﻈﺤﻣ ﻂﻘﻓ ﻡﺍﺪﺨﺘﺳﺍ ﻝﻼﺧ ﻦﻣ ،ﺔﺻﺎﺧ ﺓﺍﺩﺃ

ﻭﺃ ﻱﺃ ﻼﻟ ﻯﺮﺧﺃ ﺔﻠﻴﺳﻭﻥﺎﻣﻷ ﺡﺎﺘﻔﻣﻭ ﻞﻔﻗ

경고!

이 장치는 접근이 제한된 구역에 설치하도록 되어있습니다. 특수도구, 잠금 장치 및
키, 또는 기타 보안 수단을 통해서만 접근 제한 구역에 들어갈 수 있습니다.

Waarschuwing
Dit apparaat is bedoeld voor installatie in gebieden met een beperkte toegang.

Toegang tot dergelijke gebieden kunnen alleen verkregen worden door gebruik te
maken van speciaal gereedschap, slot en sleutel of andere veiligheidsmaatregelen.

Battery Handling

Warning!

There is the danger of explosion if the battery is replaced incorrectly. Replace the
battery only with the same or equivalent type recommended by the manufacturer.
Dispose of used batteries according to the manufacturer's instructions

電池の取り扱い

電池交換が正しく行われなかった場合、破裂の危険性があります。交換する電池はメー
カーが推奨する型、または同 等のものを使用 下さい。使用済電池は製造元の指示に従

って処 分して下さい。

警告
电池更换不当会有爆炸危险。请只使用同类电池或制造商推荐的功能相当的电池更
换原有电池。请按制造商的说明处理废旧电池。

警告
電池更換不當會有爆炸危險。請使用製造商建議之相同或功能相當的電池更換原有
電池。請按照製造商的說明指示處理廢棄舊電池。

4-10

Chapter 4: Warning Statements for AC Systems

!הרהזא

Warnung
Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die

Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp.
Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers.

Attention
Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer

que par une pile de type semblable ou équivalent, recommandée par le fabricant.
Jeter les piles usagées conformément aux instructions du fabricant.

¡Advertencia!
Existe peligro de explosión si la batería se reemplaza de manera incorrecta.

Reemplazar la batería exclusivamente con el mismo tipo o el equivalente
recomendado por el fabricante. Desechar las baterías gastadas según las
instrucciones del fabricante.

תנכס תמייקץוציפ .הניקת אל ךרדב הפלחוהו הדימב הללוסה לש ףילחהל שי

גוסב הללוסה תא מ םאותה תרבחלמומ ןרציתצ.

תוללוסה קוליס תושמושמה עצבל שי .ןרציה תוארוה יפל

ﺮﻄﺧ ﻙﺎﻨﻫ ﻦﻣ ﻝﺍﺪﺒﺘﺳﺍ ﺔﻟﺎﺣ ﻲﻓ ﺭﺎﺠﻔﻧﺍ ﺔﻳﺭﺎﻄﺒﻟﺍ ﺔﺤﻴﺤﺻ ﺮﻴﻏ ﺔﻘﻳﺮﻄﺑ ﻚﻴﻠﻌﻓ

ﺔﻳﺭﺎﻄﺒﻟﺍ ﻝﺍﺪﺒﺘﺳﺍ

ﻂﻘﻓ ﻉﻮﻨﻟﺍ ﺲﻔﻨﺑ ﺎﻬﻟﺩﺎﻌﻳ ﺎﻣ ﻭﺃ ﺎﻤﻛﺖﺻﻭﺃ ﺔﻌﻨﺼﻤﻟﺍ ﺔﻛﺮﺸﻟﺍ ﻪﺑ

ﺕﺎﻳﺭﺎﻄﺒﻟﺍ ﻦﻣ ﺺﻠﺨﺗ ﻟ ﺎﻘﻓﻭ ﺔﻠﻤﻌﺘﺴﻤﻟﺍﺔﻌﻧﺎﺼﻟﺍ ﺔﻛﺮﺸﻟﺍ ﺕﺎﻤﻴﻠﻌﺘ

경고!

배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와
동일하거나 제조사에서 권장하는 동등한 종류의 배터리로만 교체해야 합니다.
제조사의 안내에 따라 사용된 배터리를 처리하여 주십시오.

Waarschuwing
Er is ontploffi ngsgevaar indien de batterij verkeerd vervangen wordt. Vervang de

batterij slechts met hetzelfde of een equivalent type die door de fabrikant aanbevolen
wordt. Gebruikte batterijen dienen overeenkomstig fabrieksvoorschriften afgevoerd
te worden.

4-11

SUPERSERVER 5038ML-H8TRF User's Manual

דחא קפסמ רתוי םייק םא

!הרהזא

Redundant Power Supplies

Warning!

This unit might have more than one power supply connection. All connections must
be removed to de-energize the unit.

冗長電源装置

このユニットは複数の電源装置が接続されている場合があります。

ユニットの電源を切るためには、すべての接続を取り外さなければなりません。

警告
此部件连接的电源可能不止一个，必须将所有电源断开才能停止给该部件供电。

警告
此裝置連接的電源可能不只一個，必須切斷所有電源才能停止對該裝置的供電。

Warnung
Dieses Gerät kann mehr als eine Stromzufuhr haben. Um sicherzustellen, dass

der Einheit kein trom zugeführt wird, müssen alle Verbindungen entfernt werden.

¡Advertencia!
Puede que esta unidad tenga más de una conexión para fuentes de alimentación.

Para cortar por completo el suministro de energía, deben desconectarse todas las
conexiones.

Attention
Cette unité peut avoir plus d'une connexion d'alimentation. Pour supprimer toute

tension et tout courant électrique de l'unité, toutes les connexions d'alimentation
doivent être débranchées.

.קפס לש דחא רוביחמ רתוי שי הדחיל תא ריסהל שיןקורל תנמ לע םירוביחה לכ

חיה תאי.הד

4-12

Chapter 4: Warning Statements for AC Systems

. ﺪﻗ ﺍﺬﻬﻟ ﻥﻮﻜﻳ ﻟﺍﺯﺎﻬﺠ ﺕﻻﺎﺼﺗﺍ ﺓﺪﻋ ﺕﺍﺪﺣﻮﺑ ﺔﻗﺎﻄﻟﺍ ﺩﺍﺪﻣﺍ

ﺔﻟﺍﺯﺇ ﺐﺠﻳ ﺕﻻﺎﺼﺗﻻﺍ ﺔﻓﺎﻛ ﻝﺰﻌﻟ ﻟﺍﺓﺪﺣﻮ ﻦﻋ ءﺎﺑﺮﻬﻜﻟﺍ

경고!

이 장치에는 한 개 이상의 전원 공급 단자가 연결되어 있을 수 있습니다. 이 장치에
전원을 차단하기 위해서는 모든 연결 단자를 제거해야만 합니다.

Waarschuwing
Deze eenheid kan meer dan één stroomtoevoeraansluiting bevatten. Alle

aansluitingen dienen verwijderd te worden om het apparaat stroomloos te maken.

Backplane Voltage

Warning!

Hazardous voltage or energy is present on the backplane when the system is
operating. Use caution when servicing.

バックプレーンの電圧
システムの稼働中は危険な電圧または電力が、バックプレーン上にかかっています。

修理する際には注意ください。

警告
当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。

警告
當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。

Warnung
Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche

Spannungen oder Energien auf. Vorsicht bei der Wartung.

¡Advertencia!
Cuando el sistema está en funcionamiento, el voltaje del plano trasero es peligroso.

Tenga cuidado cuando lo revise.

Attention
Lorsque le système est en fonctionnement, des tensions électriques circulent sur

le fond de panier. Prendre des précautions lors de la maintenance.

4-13

SUPERSERVER 5038ML-H8TRF User's Manual

ירוחאה לנפב חתמ

ךלהמב רהזיהל שי .תכרעמה לועפת ןמזב ירוחאה לנפב חתמ תנכס תמייק

זא!הרה

.הדובעה

ﻙﺎﻨﻫ ﺮﻄﺧ ﻦﻣ ﻲﺋﺎﺑﺮﻬﻜﻟﺍ ﺭﺎﻴﺘﻟﺍ ﻰﻠﻋ ﺓﺩﻮﺟﻮﻤﻟﺍ ﺔﻗﺎﻄﻟﺍﻭﺃ ﺔﺣﻮﻠﻟﺍ

ﻥﻮﻜﻳ ﺎﻣﺪﻨﻋﻡﺎﻈﻨﻟﺍ ﻞﻤﻌﻳ ﺪﻨﻋ ﺍﺭﺬﺣ ﻦﻛ ﺔﻣﺪﺧ ﺯﺎﻬﺠﻟﺍ ﺍﺬﻫ

경고!

시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생
합니다. 서비스 작업 시 주의하십시오.

Waarschuwing
Een gevaarlijke spanning of energie is aanwezig op de backplane wanneer het

systeem in gebruik is. Voorzichtigheid is geboden tijdens het onderhoud.

Comply with Local and National Electrical Codes

Warning!

Installation of the equipment must comply with local and national electrical codes.

地方および国の電気規格に準拠
機器の取り付けはその地方および国の電気規格に準拠する必要があります。

警告

设备安装必须符合本地与本国电气法规。

警告

設備安裝必須符合本地與本國電氣法規。

Warnung
Die Installation der Geräte muss den Sicherheitsstandards entsprechen.

¡Advertencia!
La instalacion del equipo debe cumplir con las normas de electricidad locales y

nacionales.

4-14

Chapter 4: Warning Statements for AC Systems

יצראה למשחה יקוח םואית

Attention
L'équipement doit être installé conformément aux normes électriques nationales

et locales.

!הרהזא

תנקתה םייצראהו םיימוקמה למשחה יקוחל תמאות תויהל תבייח דויצה.

ﺕﺍﺪﻌﻤﻟﺍ ﺐﻴﻛﺮﺗ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﻠﻟ ﻞﺜﺘﻤﻳ ﻥﺃ ﺐﺠﻳ ﻦﻴﻧﺍﻮﻘﺔﻴﻨﻁﻮﻟﺍﻭ ﺔﻴﻠﺤﻤﻟﺍ ﺔﻘﻠﻌﺘﻤﻟﺍ

ءﺎﺑﺮﻬﻜﻟﺎﺑ

경고!

현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다.

Waarschuwing
Bij installatie van de apparatuur moet worden voldaan aan de lokale en nationale

elektriciteitsvoorschriften.

Product Disposal

Warning!

Ultimate disposal of this product should be handled according to all national laws
and regulations.

製品の廃棄

この製品を廃棄処分する場合、国の関係する全ての法律・条例に従い処理する必要が
あります。

警告
本产品的废弃处理应根据所有国家的法律和规章进行。

警告
本產品的廢棄處理應根據所有國家的法律和規章進行。

Warnung
Die Entsorgung dieses Produkts sollte gemäß allen Bestimmungen und Gesetzen

des Landes erfolgen.

4-15

SUPERSERVER 5038ML-H8TRF User's Manual

רצומה קוליס

¡Advertencia!
Al deshacerse por completo de este producto debe seguir todas las leyes y

reglamentos nacionales.

Attention
La mise au rebut ou le recyclage de ce produit sont généralement soumis à des

lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de
l'organisme compétent.

!הרהזא

ו תויחנהל םאתהב תויהל בייח הז רצומ לש יפוס קוליס.הנידמה יקוח

ﻲﺋﺎﻬﻨﻟﺍ ﺺﻠﺨﺘﻟﺍ ﻦﻣ ﺞﺘﻨﻤﻟﺍ ﺍﺬﻫ ﻪﻌﻣ ﻞﻣﺎﻌﺘﻟﺍ ﻲﻐﺒﻨﻳ ﻟ ﺎﻘﻓﻭ ﻊﻴﻤﺠﺔﻴﻨﻁﻮﻟﺍ ﺢﺋﺍﻮﻠﻟﺍﻭ ﻦﻴﻧﺍﻮﻘﻟﺍ ﺪﻨﻋ

경고!

이 제품은 해당 국가의 관련 법규 및 규정에 따라 폐기되어야 합니다.

Waarschuwing
De uiteindelijke verwijdering van dit product dient te geschieden in overeenstemming

met alle nationale wetten en reglementen.

Hot Swap Fan Warning

Warning!

The fans might still be turning when you remove the fan assembly from the chassis.
Keep fi ngers, screwdrivers, and other objects away from the openings in the fan
assembly's housing.

ファン・ホットスワップの警告

シャーシから冷却ファン装置を取り外した際、ファンがまだ回転している可能性がありま

す。ファンの開口部に、指、ドライバー、およびその他のものを近づけないで下さい。

警告
当您从机架移除风扇装置，风扇可能仍在转动。小心不要将手指、螺丝起子和其他
物品太靠近风扇

4-16

Chapter 4: Warning Statements for AC Systems

警告
當您從機架移除風扇裝置，風扇可能仍在轉動。小心不要將手指、螺絲起子和其他
物品太靠近風扇。

Warnung
Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis

genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände
von den Öffnungen des Lüftergehäuses entfernt.

¡Advertencia!
Los ventiladores podran dar vuelta cuando usted quite ell montaje del ventilador

del chasis. Mandtenga los dedos, los destornilladores y todos los objetos lejos de
las aberturas del ventilador

Attention
Il est possible que les ventilateurs soient toujours en rotation lorsque vous retirerez

le bloc ventilateur du châssis. Prenez garde à ce que doigts, tournevis et autres
objets soient éloignés du logement du bloc ventilateur.

!הרהזא

יקלח תא םיריסמ רשאכ שי .םידבוע ןיידע םיררוואמהו ןכתי ,זראמהמ ררוואמה

קיחרהללררוואמה ךותב םיחתפהמ םינוש הדובע ילכו תועבצאה תא חוטב קחרמ

ﻦﻜﻤﻤﻟﺍ ﻦﻣ ﺡﻭﺍﺮﻤﻟﺍ ﻥﺃ ﻝﺍﺰﺗ ﻻ ﺔﻟﺍﺯﺇ ﺪﻨﻋﺭﻭﺪﺗ ﺔﻠﺘﻛ ﺔﺣﻭﺮﻤﻟﺍ ﻞﻜﻴﻬﻟﺍ ﻦﻣ ﺐﺠﻳ ءﺎﻘﺑﺇ

ﻊﺑﺎﺻﻷﺍ ﻭﻲﻏﺍﺮﺒﻟﺍ ﺕﺎﻜﻔﻣ

. ءﺎﻴﺷﻷﺍ ﻦﻣ ﺎﻫﺮﻴﻏﻭ ﺍﺪﻴﻌﺑ ﻦﻋ ﺕﺎﺤﺘﻔﻟﺍ ﻲﻓ ﺔﻠﺘﻛ ﺔﺣﻭﺮﻤﻟﺍ

경고!

섀시로부터 팬 조립품을 제거할 때 팬은 여전히 회전하고 있을 수 있습니다. 팬
조림품 외관의 열려있는 부분들로부터 손가락 및 스크류드라이버, 다른 물체들이
가까이 하지 않도록 배치해 주십시오.

Waarschuwing
Het is mogelijk dat de ventilator nog draait tijdens het verwijderen van het

ventilatorsamenstel uit het chassis. Houd uw vingers, schroevendraaiers
en eventuele andere voorwerpen uit de buurt van de openingen in de
ventilatorbehuizing.

4-17

SUPERSERVER 5038ML-H8TRF User's Manual

Power Cable and AC Adapter

Warning!

When installing the product, use the provided or designated connection cables,
power cables and AC adaptors. Using any other cables and adaptors could cause
a malfunction or a fi re. Electrical Appliance and Material Safety Law prohibits the
use of UL or CSA -certifi ed cables (that have UL/CSA shown on the code) for any
other electrical devices than products designated by Supermicro only.

電源コードとACアダプター

製品を設置する場合、提供または指定された接続ケーブル、電源コードとACアダプター
を使用下さい。他のケーブルやアダプタを使用すると故障や火災の原因になることがあ

ります。電気用品安全法は、ULまたはCSA認定のケーブル(UL/CSEマークがコードに表

記)をSupermicroが指定する製品以外に使用することを禁止しています。

警告
安装此产品时,请使用本身提供的或指定的连接线,电源线和电源适配器.使用其它线
材或适配器可能会引起故障或火灾。除了Supermicro所指定的产品,电气用品和材
料安全法律规定禁止使用未经UL或CSA认证的线材。(线材上会显示UL/CSA符号)。

警告
安裝此產品時,請使用本身提供的或指定的連接線,電源線和電源適配器.使用其它線
材或適配器可能會引起故障或火災。除了Supermicro所指定的產品,電氣用品和材
料安全法律規定禁止使用未經UL或CSA認證的線材。(線材上會顯示UL/CSA符號)。

Warnung
Bei der Installation des Produkts, die zur Verfügung gestellten oder benannt

Anschlusskabel, Stromkabel und Netzteile. Verwendung anderer Kabel und Adapter
kann zu einer Fehlfunktion oder ein Brand entstehen. Elektrische Geräte und
Material Safety Law verbietet die Verwendung von UL-oder CSA-zertifi zierte Kabel,
UL oder CSA auf der Code für alle anderen elektrischen Geräte als Produkte von
Supermicro nur bezeichnet gezeigt haben.

¡Advertencia!
Al instalar el producto, utilice los cables de conexión previstos o designados, los

cables y adaptadores de CA. La utilización de otros cables y adaptadores podría
ocasionar un mal funcionamiento o un incendio. Aparatos Eléctricos y la Ley de
Seguridad del Material prohíbe el uso de UL o CSA cables certifi cados que tienen
UL o CSA se muestra en el código de otros dispositivos eléctricos que los productos
designados por Supermicro solamente.

4-18

Chapter 4: Warning Statements for AC Systems

אתמו םיילמשחמ י

Attention
Lors de l'installation du produit, utilisez les bables de connection fournis ou désigné.

L'utilisation d'autres cables et adaptateurs peut provoquer un dysfonctionnement
ou un incendie. Appareils électroménagers et de loi sur la sécurité Matériel interdit
l'utilisation de UL ou CSA câbles certifi és qui ont UL ou CSA indiqué sur le code
pour tous les autres appareils électriques que les produits désignés par Supermicro
seulement.

AC

!הרהזא

AC רשא

םימאתמו םיקפס ,םילבכב שמתשהל שי ,רצומה תא םיניקתמ רשאכ

וא הלקתל םורגל לוכי רחא םאתמ וא לבכ לכב שומיש .ךכ םשל וקפוסו ודעונ

טב יקוחו למשח ירישכמב שומיש יקוח יפ לע .ילמשח רצק רוסיא םייק ,תוחי

UL ב וא- CSA לש דוק םהילע עיפומ ראשכ)

ב םיכמסומה םילבכב שמתשהל-

UL/CSA( רחא ילמשח רצומ לכ רובע.דבלב ורקימקרפוס ידי לע ןיוצ אלש

ﺐﻴﻛﺮﺗ ﺪﻨﻋ ﻡﺍﺪﺨﺘﺳﺍ ﺐﺠﻳ ﺯﺎﻬﺠﻟﺍ ﻭ،ﻞﻴﺻﻮﺘﻟﺍ ﺕﻼﺑﺎﻛ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺕﻼﺑﺎﻜﻟﺍ

ﺕﻻﻮﺤﻣﻭ ﺩﺩﺮﺘﻤﻟﺍ ﺭﺎﻴﺘﻟﺍ

. ﻥﺃ ﻱﺃ ﻡﺍﺪﺨﺘﺳﺍ ﺕﻼﺑﺎﻛ ﺕﻻﻮﺤﻣﻭ ﻯﺮﺧﺃ ﺐﺒﺴﺘﻳ ﻲﻓ ﻞﻄﻋ ﺙﻭﺪﺣ ﻖﻳﺮﺣ ﻭﺃ . ﻲﺘﻟﺍ

ﻚﻟ ﺎﻫﺮﻴﻓﻮﺗ ﻢﺗ ﺞﺘﻨﻤﻟﺍ ﻊﻣ

UL ﻭﺃ CSA ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺰﻬﺟﻷﺍ ﺩﺍﻮﻣﻭ ﻥﻮﻧﺎﻗ ﺔﻣﻼﺴﻟﺍ ﻡﺍﺪﺨﺘﺳﺍ ﺮﻈﺤﻳ ﺕﻼﺑﺎﻜﻟﺍ

ﻞﺒﻗ ﻦﻣ ﺓﺪﻤﺘﻌﻣ

Supermicro ﺓﺰﻬﺟﺃ ﻯﺮﺧﺃ ﺔﻴﺋﺎﺑﺮﻬﻛ ﺮﻴﻏ ﺕﺎﺠﺘﻨﻤﻟﺍ ﺔﻨﻴﻌﻤﻟﺍ ﻞﺒﻗ ﻦﻣ ﻱﻷ

(UL/CSA ﻞﻤﺤﺗ ﻲﺘﻟﺍﺔﻣﻼﻋ )

경고!

제품을 설치할 때에는 제공되거나 지정된 연결케이블과 전원케이블, AC어댑터를
사용해야 합니다. 그 밖의 다른 케이블들이나 어댑터들은 고장 또는 화재의 원인이
될 수 있습니다. 전기용품안전법 (Electrical Appliance and Material Safety
Law)은 슈퍼마이크로에서 지정한 제품들 외에는 그 밖의 다른 전기 장치들을
위한 UL또는 CSA에서 인증한 케이블(전선 위에 UL/CSA가 표시)들의 사용을
금지합니다.

Waarschuwing
Bij het installeren van het product, gebruik de meegeleverde of aangewezen kabels,

stroomkabels en adapters. Het gebruik van andere kabels en adapters kan leiden
tot een storing of een brand. Elektrisch apparaat en veiligheidsinformatiebladen wet
verbiedt het gebruik van UL of CSA gecertifi ceerde kabels die UL of CSA die op
de code voor andere elektrische apparaten dan de producten die door Supermicro
alleen.

4-19

SUPERSERVER 5038ML-H8TRF User's Manual

Notes

4-20

Chapter 5: Advanced Motherboard Setup

Chapter 5

Advanced Motherboard Setup

This chapter covers the steps required to connect the data and power cables and
install add-on cards. All motherboard jumpers and connections are also described.
A layout and quick reference chart are included in this chapter for your reference.
Remember to completely close the chassis when you have fi nished working with
the server to better cool and protect the system.

5-1 Handling the Motherboard

Electrostatic Discharge (ESD) can damage electronic com ponents. To prevent dam­age to any printed circuit boards (PCBs), it is important to handle them very carefully
(see previous chapter). To prevent the motherboard from bending, keep one hand
under the center of the board to support it when handling. The following measures
are generally suffi cient to protect your equipment from electric static discharge.

Precautions

• Use a grounded wrist strap designed to prevent Electrostatic Discharge

(ESD).

• Touch a grounded metal object before removing any board from its antistatic

bag.

• Handle a board by its edges only; do not touch its components, peripheral chips,

memory modules or gold contacts.

• When handling chips or modules, avoid touching their pins.

• Put the motherboard, add-on cards and peripherals back into their antistatic

bags when not in use.

• For grounding purposes, make sure your computer chassis provides excellent

conductivity between the power supply, the case, the mounting fasteners and
the motherboard.

5-1

SUPERSERVER 5038ML-H8TRF User's Manual

Unpacking

The motherboard is shipped in antistatic packaging to avoid electrical static dis­charge. When unpacking the board, make sure the person handling it is static
protected.

5-2 Connecting Cables

The 5038ML-H8TRF server was designed as a cableless system. As a result, all
power and data connections to the motherboard nodes are made whenever a node
is installed into its bay in the chassis. This covers the main power connection, the
control panel connections and the data and power connections for the SATA drives.

5-3 I/O Ports

The I/O ports are located at the back of the motherboard node. See Figure 5-1
below for the locations of the various I/O ports.

Figure 5-1. I/O Ports

1 3

I/O Ports

1. USB2.0 (x2)/VGA/COM (JKVM1)

2. IPMI_LAN

3. Power Switch (SW1)

2

5-2

Chapter 5: Advanced Motherboard Setup

5-4 Installing the Processor and Heatsink

Caution: Avoid placing direct pressure to the top of the processor package. Always

remove the power cord fi rst before adding, removing or changing any hardware
components.

Notes:

• Always connect the power cord last and always remove it before adding, re-

moving or changing any hardware components. Make sure that you install the
processor into the CPU socket before you install the CPU heatsink.

• If you buy a CPU separately, make sure that you use an Intel-certifi ed multi-

directional heatsink only.

• Make sure to install the motherboard into the chassis before you install the

CPU heatsinks.

• When receiving a motherboard without a processor pre-installed, make sure that

the plastic CPU socket cap is in place and none of the socket pins are bent;
otherwise, contact your retailer immediately.

• Refer to the Sup ermi cro web s ite for upd ates on CPU su ppor t.

Installing an LGA1150 Processor

1. Gently press down the load plate
handle and push it outward (to the
right side) to unlock it.

2. Once th e load plate h andle is
unloc ked, gently li ft t he handl e to
open the load plate.

Load Plate

Handle Lock

5-3

Load Plate Handle

SUPERSERVER 5038ML-H8TRF User's Manual

3. Once t he load p late is ope n, use your thumb and your index fi nger to hold
the CPU at the north center edge and the south center edge of the CPU.

North Center Edge

South Center Edge

4. Align the CPU keys, which are the semicircular cutouts on the sides of the
CPU (shown below), against the socket keys, the semicircular notches on the
sides of the CPU socket. Align CPU pin 1, the triangle at the bottom left of
the CPU, against pin 1 of the socket, the triangle marker at the bottom left of
the CPU socket.

Socket Pin1

Socket Keys

CPU Pin1

CPU Keys

5. Once they are aligned, carefully lower the CPU straight down into the socket.
(To avoid damaging the CPU or the socket, do not drop the CPU on the
socket. Do not rub the CPU against the surface or against any pins of the
socket.)

6. With the CPU seated inside the socket, inspect the four corners of the CPU
to ensure that it is properly installed.

5-4

Chapter 5: Advanced Motherboard Setup

7. Once the CPU is properly installed, use your thumb to gently push the load
plat handle down to the handle lock and lock it.

CPU properly installed

Load Plate Handle is

locked into place

8. When the CPU is securely locked into the CPU socket, the plastic cap will be
automatically loosened from the load plate. Use your thumb and index fi nger
to remove the plastic cap from the socket.

The plastic cap will pop
open when the CPU is
properly installed in
the socket. Remove the
cap from the socket.

Warning: You can install the CPU inside the socket only in one direction. Make sure

that it is properly inserted into the CPU socket before closing the load plate. If it
doesn't close properly, do not force it, as that may damage your CPU. Instead, open
the load plate again and check whether the CPU is properly aligned and securely
seated inside the socket.

5-5

SUPERSERVER 5038ML-H8TRF User's Manual

Installing a CPU Heatsink

1. Remove power from the system
and unplug the AC power cord
from the power supply.

2. Do not apply any thermal grease
to the heatsink or the CPU die;
the required amount has already
been applied.

3. Place the heatsink on top of the
CPU so that the four mounting
holes are aligned with those on
the (preinstalled) heatsink reten­tion mechanism.

4. Screw in two diagonal screws
(i.e. the #1 and the #2 screws)
until just snug. Do not fully
tighten the screws or you may
damage the CPU.)

5. Add the two remaining screws
then fi nish the installation by fully
tightening all four screws.

Removing the Heatsink

1. Unscrew and remove the heatsink screws from the motherboard in the sequence
as show in the picture above.

2. Hold the heatsink and gently wriggle the heatsink to loosen it from the CPU. (Do
not use excessive force when wriggling the heatsink!!)

3. Once the heatsink is loose, remove it from the CPU socket.

4. Clean the surface of the CPU and the heatsink to get rid of the old thermal
grease. Reapply the proper amount of thermal grease on the surface before you
re-install a heatsink.

Note: see Chapter 6 for details on installing the air shroud.

5-6

Chapter 5: Advanced Motherboard Setup

5-5 Installing Memory

Warning: Exercise extreme care when installing or removing DIMM modules to prevent

any possible damage.

Installing DIMMs

1. Insert the desired number of DIMMs into the DIMM slots, starting with DIM­MA2. Pay attention to the notch along the bottom of the module to prevent
incorrect installation. Use memory modules of the same type and speed.

2. Retract the slot's release tabs then insert the DIMM module vertically. Push
down until it and snaps into place. Repeat to install more memory if needed.

Memory Support

Each X10SLD-F supports up to 32GB of ECC Unbuffered (UDIMM) DDR3­1600/1333/1066 memory in four slots. Populating these DIMM modules with a
pair of memory modules of the same type and same size will result in interleaved
memory, which will improve memory performance. Please refer to the table below:

To In st al l : Inser t
module vertically
and pre ss dow n
until it s naps i nto
place. Pay attention
to the alignment
notch at t he bo tto m.

To Remove:

Use your thumbs to
gently push the re­lease tabs near both
ends of the module.
This should release
it from the slot.

Figure 5-2. DIMM Installation

Notch

Release Tab

Notch should align
with the receptive
key point on the slot.

Top View of DDR3 Slot

JWD1

DIMMB2
DIMMB1
DIMMA2
DIMMA1

S-SATA/SAS2

S-SATA/SAS3

S-SGPIO1

CPU1

S-SATA/SAS0
S-SATA/SAS1

JTPM1

VBAT

JBT1

JPME1

USB0

(3.0)

JPME2

X10SLD-F/HF

Rev. 1.00

Intel

PCH

J2

BIOS

JSD1

I-SATA4

Micro-LP PCI-E 3.0 x8

BMC

JPG1

CPU Slot1 PCI-E 3.0 x8

PWR

IPMI_LAN

LE5

SW1

Front View

LED6

UID

JUIDB1

JKVM1

LED5

Notch

Release Tab

Warning: Exercise extreme care when installing or removing DIMM modules to prevent

any possible damage.

5-7

SUPERSERVER 5038ML-H8TRF User's Manual

Towards the CPU

Channel A, Slot 1

Channel A, Slot 2

(Blue Slot)

Channel B, Slot 1

Channel B, Slot 2

(Blue Slot)

Towards the edge of the motherboard

Memory Population Guidelines

1. When installing memory modules, the DIMM slots should be populated in the
following order: DIMMA2, DIMMB2, DIMMA1 and DIMMB1

2. Always use DDR3 DIMM modules of the same size, type and speed.

3. The motherboard will support one or three DIMM modules installed. However,
for best memory performance, install DIMM modules in pairs.

DDR3 Unbuffered ECC (UDIMM) Memory

DIMM Slots per

Channel

2 1 Unbuffered

2 2 Unbuffered

DIMMs Populat-

ed per Channel

DIMM Type POR Speeds Ranks per DIMM (any

combination)

1066, 1333, 1600 Single Rank, Dual Rank

DDR3

1066, 1333, 1600 Single Rank, Dual Rank

DDR3

Recommended Population (Balanced)

DIMMA2 Slot DIMMB2 Slot DIMMA1 Slot DIMMB1 Slot Total System Memory

2GB DIMM 2GB DIMM 4GB
2GB DIMM 2GB DIMM 2GB DIMM 2GB DIMM 8GB
4GB DIMM 4GB DIMM 8GB
4GB DIMM 4GB DIMM 4GB DIMM 4GB DIMM 16GB
8GB DIMM 8GB DIMM 16GB
8GB DIMM 8GB DIMM 8GB DIMM 8GB DIMM 32GB

5-8

Chapter 5: Advanced Motherboard Setup

5-6 Adding PCI Add-On Cards

The 5038ML-H8TRF supports one low-profi le PCI card in each of the eight nodes
with the included riser card (RSC-RR1U-E8-O-P). To install an add-on card, follow
the instructions below.

Installing an Add-on Card

1. Power-down the node using that node's individual power button and remove it
as described in Chapter 6.

2. Open the PCI slot clip and remove the PCI slot shield.

3. Open the PCI slot clip in the rear of the motherboard node.

4. Remove the PCI slot shield.

5. Insert the expansion card into the riser card, which is pre-installed on the
motherboard (if desired the riser card may be removed from the motherboard
by removing the riser card screw).

6. Slide the add-on cards bracket into the PCI card slot and fi t it with the open-
ing in the rear of the node.

7. Close the PCI card slot clip to secure the add-on card.

Note: The PCI slot shields protect the motherboard and its components from EMI
and aid in proper ventilation, so make sure there is always a shield covering each
unused slot.

5-9

SUPERSERVER 5038ML-H8TRF User's Manual

Add-on Card

PCI Slot

Bracket

Riser Card

Figure 5-3: Installing an Add-on Card

Note: The node and motherboard shown above are examples. Your actual node

and motherboard may vary from those illustrated.

5-10

5-7 Motherboard Details

Figure 5-4. X10SLD-F Layout

Chapter 5: Advanced Motherboard Setup

Micro-LP PCI-E 3.0 x8

JTPM1

UID

LED6

VBAT

JUIDB1

SW1
PWR

IPMI_LAN

BMC

X10SLD-F/HF

Rev. 1.00

J2

JPME2

Intel
PCH

JBT1

JPME1

LE5

JPG1

BIOS

LED5

JKVM1

CPU Slot1 PCI-E 3.0 x8

JSD1

I-SATA4

USB0
(3.0)

JWD1

DIMMB1

DIMMB2

DIMMA2

DIMMA1

5-11

CPU1

S-SATA/SAS2

S-SATA/SAS0

S-SATA/SAS1

S-SGPIO1

S-SATA/SAS3

SUPERSERVER 5038ML-H8TRF User's Manual

X10SLD-F Quick Reference

Jumper Description Default

JBT1 CMOS Clear See Section 5-9
JPG1 VGA Enable/Disable Pins 1-2 (Enabled)
JPME1 ME Recovery Pins 1-2 (Normal)
JPME2 Manufacture Mode Select Pins 1-2 (Normal)
JWD1 Watch Dog Pins 1-2 (NMI)

Connector Description

Battery Onboard Battery
IPMI LAN Dedicated IPMI LAN

JKVM1
JSD1 SATA DOM (Device On Module) Power Connector

JTPM1 Trusted Platform Module/Port 80 Connector

Micro-LP PCI-E Slot

PCI-E Slot 1 PCI-Express 3.0 x8 slot
I-SATA4 SATA Port4 (Internal SATA2 Port for SATA DOM)

(S-)SATA/SAS0-3

S-SGPIO1 Serial Link General Purpose Input/Output Header
SW1 Power Switch/LED Indicator
UID Unit Ide ntifi er (UID) Button
USB0 (3.0) I nterna l Type A USB 3 .0 Por t

LED Description State/Status

LE5 BMC Heartbeat LED Blinking Green: BMC Functions Normally

USB 2.0 (x2)/VGA (Monitor)/COM Connector for Remote
Console Redirection or Remote Network Interface

SMC-Proprietary Micro Low-Profi le (LP) PCI-Express 3.0
x8 Slot

SATA/SAS Ports 0-3 (SATA3/SAS2 is only for add-on
cards)

LED5 Power/Fan Fail/Overheat LED Red: Power Fail, Fan Fail or Overheating
LED6 UID LED Blue: Unit Identifi ed

5-12

5-8 Connector Defi nitions

DOM PWR Connector (JSD1)

The Disk-On-Module (DOM) power con­nector, located at JSD1, provides 5V
(Gen1/Gen) power to a solid state DOM
storage device connected to one of the
SA TA ports. See the table on the right for
pin defi nitions.

Chapter 5: Advanced Motherboard Setup

DOM PWR

Pin Defi nitions

Pin# Defi nition
15V
2 Ground

3 Ground

S-SGPIO 1 Header

An SGPIO (Serial-Link General Purpose
Input/Output) header is located on the
motherboard. S-SGPIO1 supports a
Serial Link (SATA/SAS) interface. See
the table on the right for pin defi nitions.

Universal Serial Bus (USB)

A T ype A USB0 (3.0) port is located next
to the CPU. See the table on the right
for pin defi nitions.

S-SGPIO1

Pin Defi nitions

Pin# Defi nition Pin Defi nition
1NC 2 NC
3 Ground 4 Data

5 Load 6 Ground
7 Clock 8 NC

USB (3.0) Type A

Pin Defi nitions

Pin# Signals Pin# Signals
1 VBUS 8 StdA_SSTX­2 D- 9 StdA_SSTX+
3 D+ 10 Ground

4 Ground 11 Ground
5 StdA_SSRX- 12 Ground
6 StdA_SSRX+ 13 Ground
7 GND_DRAIN

USB 2.0 (x2)/VGA/COM Connector

JKVM1 supports USB 2.0 (x2)/VGA/
COM connections on the I/O backplane.

Power Switch/LED

A power switch/LED indicator is located
next to the UID button/LED on the back­plane. Use this switch to power on or
power off the system.

5-13

SUPERSERVER 5038ML-H8TRF User's Manual

TPM Header/Port 80 Header

A Trusted Platform Module/Port 80 head­er is located at JTPM1 to provide TPM
support and Port 80 connection. Use this
header to enhance system performance
and data security. See the table on the
right for pin defi nitions.

TPM/Port 80 Header

Pin Defi nitions

Pin # Defi nition Pin # Defi nition
1 LCLK 2 GND
3 LFRAME# 4 <(KEY)>
5 LRESET# 6 +5V (X)
7 LAD 3 8 LAD 2
9 +3.3V 10 LAD1
11 LAD0 12 GND
13 RSV0 14 RSV1
15 +3V_DUAL 16 SERIRQ
17 GND 18 CLKRUN# (X)
19 RSV2 20 RSV3

IPMI_LAN Port

A dedicated IPMI Ethernet port is located
on the I/O backpanel to provide network
connection via the IPMI interface. This
port accepts a RJ45 type cable. Pease
refer to the LED Indicator Section for
LAN LED information.

Unit Identifi er Switch/UID LED
Indicators

A Unit Identifier (UID) button and a
LED Indicator are located on the moth­erboard. The UID button is located at
JUIDB1, and LED is located at LED6 on
the backplane. When you press the UID
button, the UID LED Indicator will be
turned on. Press the UID button again
to turn off the LED Indicator. The UID
Indicator provides easy identifi cation of
a system unit that may be in need of
service.

UID Button

Pin# Defi nition
1 Ground
2 Ground
3 Button In
4 Button In

UID LED

Status

Color/State Status
Blue: On Unit Identifi ed

Note: UID can also be triggered via IPMI
on the motherboard. For more informa­tion on IPMI, please refer to the IPMI
User's Guide posted on our website @
http://www.supermicro.com.

5-14

5-9 Jumper Settings

Explanation of Jumpers

To modify the operation of the mother­board, jumpers can be used to choose
between optional settings. Jumpers
create shorts between two pins to
change the function of the connector.
Pin 1 is identifi ed with a square solder
pad on the printed circuit board. See
the motherboard layout pages for
jumper locations.

Note: On a two-pin jumper, "Closed"
means the jumper is on both pins and
"Open" means the jumper is either on
only one pin or completely removed.

Chapter 5: Advanced Motherboard Setup

3 2 1

Connector

Pins

Jumper

3 2 1

Setting

CMOS Clear

JBT1 is used to clear CMOS (which will also clear any passwords). Instead of pins,
this jumper consists of contact pads to prevent accidentally clearing the contents
of CMOS.

To clear CMOS,

1. First power down the system and unplug the power cord(s). It is also recom­mended that you remove the onboard battery from the motherboard.

2. With the power disconnected, short the CMOS pads with a metal object such
as a small screwdriver.

3. Remove the screwdriver (or shorting device).

4. Reconnect the power cord(s) and onboard battery and power on the system.

Note: Do not use the PW_ON connector to clear CMOS.

5-15

SUPERSERVER 5038ML-H8TRF User's Manual

VGA Enable (JPG1)

JPG1 allows the user to enable the on­board VGA connector (through the KVM).
Close pins 1~2 to enable the VGA. The
default setting is Enabled.

Watch Dog RST/NMI Selection
(JWD1)

Watch Dog (JWD1) is a system moni­tor that can reboot the system when a
software application hangs. Close pins
2~3 to reset the system if an applica­tion hangs. Close pins 1~2 to generate
a non-maskable interrupt signal for the
application that hangs. See the table on
the right for jumper settings. Watch Dog
must also be enabled in the BIOS.

VGA Enable/Disable

Jumper Settings

Jumper Setting Defi nition
Pins 1-2 Enabled
Pins 2-3 Disabled

Watch Dog

Jumper Settings

Jumper Setting Defi nition
Pins 1-2 NMI
Pins 2-3 Reset
Open Disabled

ME Recovery

Use jumper JPME1 to select ME Firm­ware Recovery mode, which will limit
system resources for essential functions
only without putting restrictions on power
use. In single operation mode, online
upgrade will be available via Recovery
mode.

Manufacturer Mode Select

Close this jumper (JPME2) to bypass
SPI fl ash security and force the system
to use the Manufacturer mode, which
allows the user to flash the system
fi rmware from a host server to modify
system settings.

ME Recovery

Jumper Settings

Jumper Setting Defi nition
Pins 1-2 Normal (Default)
Pins 2-3 ME Recovery

ME Mode Select

Jumper Settings

Jumper Setting Defi nition
Pins 1-2 Normal (Default)
Pins 2-3 Manufacture Mode

5-16

5-10 Onboard Indicators

Chapter 5: Advanced Motherboard Setup

IPMI_LAN LEDs

A dedicated IPMI LAN is also located on
the I/O backplane. The yellow LED on the
right indicates activity while the green
LED on the left indicates the speed of
the connecti on. See the t able at right for
more information.

BMC Heartbeat LED

A BMC He ar tbeat L ED is loc ated at LE5
on the motherboard. When LE5 is blink­ing, BMC functions normally. See the
table at r ight for m ore info rmati on.

IPMI LAN

Link LED Activity

IPMI LAN Link LED (Left) &

Activity LED (Right)

Color/State Defi nition

Link (Left) Green: Solid 100 Mbps

Activity
(Right)

BMC Heartbeat LED

Color/State Defi nition
Green:

Blinking

Amber: Solid 1000

Yellow Blink­ing

Status

BMC: Normal

Mbps
Active

PWR Fail/Fan Fail/OH LED

A Power Fail/Fan Fail/Overheat LED is
located at LED5 on the motherboard. See
the tab le at right f or more i nform ation.

PWR Fail/Fan Fail/OH LED

Color/State Defi nition
Red:

On

Power Fail, Fan Fail or
Overheating

5-11 SATA Drive Connections

The SA TA drive connections are made automatically when a drive is inserted into its
bay in the chassis. No cables are needed to make the power and data connections.

5-17

SUPERSERVER 5038ML-H8TRF User's Manual

5-12 Installing Software

The Supermicro ftp site contains drivers and utilities for your system at ftp://ftp.

supermicro.com. Some of these must be installed, such as the chipset driver.

After accessing the ftp site, go into the CDR_Images directory and locate the ISO
fi le for your motherboard. Download this fi le to create a CD/DVD of the drivers and
utilities it contains. (You may also use a utility to extract the ISO fi le if preferred.)

Another option is to go to the Supermicro Website at

products/. Find the product page for your motherboard here, where you may down-

load individual drivers and utilities.
After creating a CD/DVD with the ISO fi les, insert the disk into the CD/DVD drive

on your system and the display shown in Figure 5-5 should appear.

http://www.supermicro.com/

Figure 5-5. Driver/Tool Installation Display Screen

Note: Click the icons showing a hand writing on paper to view the readme fi les

for each item. Click the computer icons to the right of these items to install each
item (from top to the bottom) one at a time. After installing each item, you must
re-boot the system before moving on to the next item on the list. The bottom
icon with a CD on it allows you to view the entire contents.

5-18

Chapter 5: Advanced Motherboard Setup

SuperDoctor III

The SuperDoctor® III program is a web-based management tool that supports
remote management capability. It includes Remote and Local Management tools.
The local management is called SD III Client. The SuperDoctor III program allows
you to monitor the environment and operations of your system. SuperDoctor III
displays crucial system information such as CPU temperature, system voltages
and fan status. See the fi gures below for examples of the SuperDoctor III interface.

Note: The default User Name and Password for SuperDoctor III is ADMIN / ADMIN.
Note: When SuperDoctor III is fi rst installed, it adopts the temperature threshold

settings that have been set in BIOS. Any subsequent changes to these thresholds
must be made within SuperDoctor III, as the SuperDoctor III settings override the
BIOS settings. To set the BIOS temperature threshold settings again, you would
fi rst need to uninstall SuperDoctor III.

Figure 5-6. SuperDoctor III Interface Display Screen (Health Information)

5-19

SUPERSERVER 5038ML-H8TRF User's Manual

Figure 5-7. SuperDoctor III Interface Display Screen (Remote Control)

Note: The SuperDoctor III program and User ’s Manual can be downloaded from

the Supermicro web site at

ware/SuperDoctorIII.cfm. For Linux, we recommend that you use the SuperDoctor

II application instead.

http://www.supermicro.com/products/accessories/soft-

5-13 Onboard Battery

Please handle used batteries carefully. Do not damage the battery in any way; a
damaged battery may release hazardous materials into the environment. Do not
discard a used battery in the garbage or a public landfi ll. Please comply with the
regulations set up by your local hazardous waste management agency to dispose
of your used battery properly.

Figure 5-8. Installing the Onboard Battery

5-20

Chapter 6: Advanced Chassis Setup

Chapter 6

Advanced Chassis Setup

This chapter covers the steps required to install components and perform main­tenance on the SC938BH-R1620B chassis. For component installation, follow the
steps in the order given to eliminate the most common problems encountered. If
some steps are unnecessary, skip ahead to the step that follows.

Tools Required: The only tool you will need to install components and perform
maintenance is a Philips screwdriver.

6-1 Static-Sensitive Devices

Electrostatic Discharge (ESD) can damage electronic com ponents. To prevent
damage to any printed circuit boards (PCBs), it is important to handle them very
carefully. The following measures are generally suffi cient to protect your equipment
from ESD damage.

Precautions

• Use a grounded wrist strap designed to prevent static discharge.

• Touch a grounded metal object before removing any board from its antistatic

bag.

• Handle a board by its edges only; do not touch its components, peripheral chips,

memory modules or gold contacts.

• When handling chips or modules, avoid touching their pins.

• Put the motherboard, add-on cards and peripherals back into their antistatic

bags when not in use.

• For grounding purposes, make sure your computer chassis provides excellent

conductivity between the power supply, the case, the mounting fasteners and
the motherboard.

• The person unpacking the system should be static protected.

6-1

SUPERSERVER 5038ML-H8TRF User's Manual

6-2 Removing the Chassis Cover

Remove Film

From Vents

4

1

Remove Three

2

1

Screws

3

1

Figure 6-1. Removing the Chassis Cover

IMPORTANT: Before operating the SC938BH-R1620B for the fi rst time, it is im-

portant to remove the protective fi lm covering the ventilation openings on the top
of the chassis. These vents provide proper ventilation and cooling for the system.

Removing the Chassis Cover and Protective Film

1. Disconnect the chassis from any power source.

2. Remove the three screws which secure the top cover to the chassis as il­lustrated above.

3. Lift the top cover up and off the chassis.

4. Peel off the protective fi lm covering the top cover and the top of the chassis

5. Check that all ventilation openings on the top cover and the top of the chassis
are clear and unobstructed.

Warning: Except for short periods of time, do NOT operate the server without the
cover in place. The chassis cover must be in place to allow proper airfl ow and prevent
overheating.

6-2

Chapter 6: Advanced Chassis Setup

6-3 Corresponding Nodes, Fans and Hard Drives

The SC938BH-R1620B chassis contains eight individual motherboards contained
in separate nodes. Each node controls two hard drives and shares a fan with the
node beside it. Note that if a node is pulled out of the chassis, the hard drives as­sociated with that node will power-down.

Corresponding Nodes, Fans and HDDs

Node Fan HDDs
Node 1 Fan 1 HDDs A1 and A2
Node 2 Fan 1 HDDs B1 and B2
Node 3 Fan 2 HDDs C1 and C2
Node 4 Fan 2 HDDs D1 and D2
Node 5 Fan 3 HDDs E1 and E2
Node 6 Fan 3 HDDs F1 and F2
Node 7 Fan 4 HDDs G1 and G2
Node 8 Fan 4 HDDs H1 and H2

Figure 6-2. Corresponding Nodes, Fans and HDDs

Node 1

Node 2

Node 3

Node 4

Node 5

A

1

C

1

B

1

Fan 4

Fan 3

Fan 2

Fan 1

1

D

F

1

H

1

Node 6

Node 7

Node 8

E

1

G

1

6-3

SUPERSERVER 5038ML-H8TRF User's Manual

6-4 Removing and Installing Hard Drives

The SC938BH-R1620B features sixteen hot-swappable hard drives. These hard
drives are contained in drive carriers and may be removed without powering-down
the system.

Removing Hard Drive Carriers from the Chassis

1. Press the release button on the drive carrier, which will extend the drive car­rier handle.

2. Use the drive carrier handle to pull the drive out of the chassis.

Figure 6-3. Removing a Hard Drive

3

1

6-4

1

1

2

1

Chapter 6: Advanced Chassis Setup

Dummy Drive

2

1

Drive Carrier

2

1

Figure 6-4. Removing a Dummy Drive from the Drive Carrier

The hard drives are mounted in drive carriers to simplify their installation and re­moval from the chassis. These carriers also help promote proper airfl ow through
the drive bays.

Removing the Dummy Drive from the Drive Carrier

1. Remove the hard drive carrier from the chassis as described in the previous
section and lay the drive carrier on a fl at surface.

2. Remove the two screws securing the dummy drive to the drive carrier.

3. Lift the dummy drive from the drive carrier.

Warning: Except for short periods of time while swapping hard drives, do not operate
the server with the hard drive bays empty. All carriers (even without hard drives pres­ent) must remain in their bays to maintain proper airfl ow.

6-5

SUPERSERVER 5038ML-H8TRF User's Manual

Hard Drive

4

1

Drive Carrier

4

1

Figure 6-5. Installing a Hard Drive

Installing a Hard Drive into the Drive Carrier

1. Place the hard drive carrier on a fl at surface.

2. Insert the hard drive into the carrier with the printed circuit board side facing
downward and so that the mounting holes in the drive align with those in the
drive carrier.

3. Secure the hard drive to the carrier with the four screws included with the
hard drive.

4. Use the open handle of the drive carrier to insert the drive carrier into the
open drive bay.

5. Secure the drive carrier into the drive bay by closing the drive carrier handle.

Warning: Regardless of how many hard drives are installed, all drive carriers must
remain in the drive bays to promote proper airfl ow.

Warning: Enterprise level hard disk drives are recommended for use in Supermicro
chassis and servers. For information on recommended HDDs, visit the Supermicro
Web site at http://www.supermicro.com/products/nfo/storage.cfm

6-6

Chapter 6: Advanced Chassis Setup

6-5 Removing and Installing the Backplane

The backplane is attached to the fan bracket, which is located in the midsection
of the chassis. In the unlikely event of a backplane failure, follow the instructions
below to replace it.

Removing the Backplane and Fan Bracket Assembly

Removing the Backplane and Fan Bracket from the Chassis

1. Power down the system and disconnect it from any power source.

2. Remove the chassis cover as described in section 6-2 of this manual.

3. Disconnect all cabling to the backplane.

4. Remove the screws securing the fan bracket to the chassis and set them
aside for later use.

5. Lift the fan bracket and backplane out of the chassis.

5

1

4

1

Fan Bracket

4

1

Backplane

Figure 6-6. Removing the Fan Bracket and Backplane

6-7

SUPERSERVER 5038ML-H8TRF User's Manual

1

1

2

1

3

1

Figure 6-7. Removing the Backplane from the Fan Bracket

1

1

Removing the Backplane from the Fan Bracket

Removing the Backplane

1. Remove the eight screws securing the two side mounting brackets to the
sides of the fan bracket and set them aside for later use. Remove the side
mounting brackets.

2. Remove the eleven screws securing the backplane to the fan bracket and set
these screws aside for later use.

3. Hold the backplane by its edges and carefully remove it from the fan bracket.

6-8

Chapter 6: Advanced Chassis Setup

3

1

4

1

2

1

Figure 6-8. Installing the Backplane onto the Fan Bracket

3

1

Installing the Backplane onto the Fan Bracket

Installing the Backplane

1. Ensure that all power has been disconnected from the chassis.

2. Hold the backplane by its edges and carefully place it against the fan mount­ing bracket, aligning the mounting holes in the backplane with those in the fan
bracket.

3. Secure the two side mounting brackets to the backplane with the eight screws
previously set aside.

4. Secure the backplane to the front of the fan bracket using the eleven screws
previously set aside.

5. Reconnect all wiring to the backplane.

6-9

SUPERSERVER 5038ML-H8TRF User's Manual

Figure 6-9. Installing the Backplane and Fan Bracket

Installing the Backplane and Fan Bracket Assembly

Installing the Backplane and Fan Bracket

1. Ensure that the chassis has been disconnected from any power source.

2. Remove the chassis cover as described in Section 6-2.

3. Reconnect the wiring to the backplane.

4. Insert the fan bracket and backplane assembly into the chassis as illustrated
above.

5. Secure the fan bracket to the chassis with the six screws that were previously
set aside.

6-10

Chapter 6: Advanced Chassis Setup

6-6 Removing and Installing Motherboard Nodes

Release Tab

Node Power LED

Node Power Button

Node Handle

Figure 6-10. Removing Nodes from the System

The SC938BH-R1620B chassis comes equipped with eight removable nodes, each
one containing an individual motherboard. Removing these nodes will also power­down the corresponding hard drives. See the table in Section 6-3 to determine which
hard drives are controlled by each node.

Removing Nodes from the System

1. Power-down the individual node by pressing that node's power button.

2. Press and hold down the release tab on the back of the node.

3. Using the node's handle, pull the node from the chassis.

Warning: Except for short periods of time while swapping nodes, do not operate the
server with the node bays empty. In the unlikely event of a node failure, remove the
failed node and replace it with the dummy node that was included with the system..

6-11

SUPERSERVER 5038ML-H8TRF User's Manual

6-7 Installing an Air Shroud

Air shrouds concentrate airfl ow to maximize fan effi ciency. The SC938BH-R1620B
chassis requires that air shrouds be used in each node.

Installing the Air Shroud

1. Make sure that the motherboard expansion card (if present) and all compo­nents are properly installed in each motherboard node.

2. Place the air shroud over the motherboard, as shown below. The air shroud
sits behind the system fans and goes over the top of the motherboard and its
components. Secure by inserting screws through the tabs and tightening.

3. Repeat the procedure for the remaining nodes.

4. Reverse this procedure to remove an air shroud.

6-12

Chapter 6: Advanced Chassis Setup

6-8 System Fans

Four 8-cm fans circulate air through the chassis to lower the internal temperature.
The SC938BH-R1620B system fans are designed to be easily changed, with no
tools required and no need to remove any other parts inside the chassis. See Sec­tion 6-3 to determine which nodes and hard drives are cooled by each system fan.

Replacing a System Fan

1. If necessary, open the chassis top cover while the system is operating to
determine which fan has failed. Never run the server for an extended period
of time with the top cover open.

2. Remove the failed fan's power cord from the backplane.

3. Simultaneously squeeze both release tabs on the top of the fan module.

4. Lift the fan module up and out of the chassis.

5. Place the replacement fan into the vacant space in the fan bracket while mak­ing sure the arrows on the top of the fan (indicating air direction) point in the
same direction as the arrows on the other fans.

6. Put the fan back into the chassis and reconnect the cable.

7. Confi rm that the fan is working properly before replacing the chassis cover.

6-13

SUPERSERVER 5038ML-H8TRF User's Manual

Figure 6-11. System Fan Placement

Release Tabs

6-9 Power Supply

The SC938BH-R1620B chassis includes a redundant 1620 watt power supply,
which is auto-switching capable. This enables it to automatically sense and operate
at a 100V to 240V input voltage. An amber light will be illuminated on the power
supply when the power is off. An illuminated green light indicates that the power
supply is operating.

Power Supply Replacement

In the unlikely event that one of the power supplies needs to be replaced, one power
supply can be removed without powering-down the system. Replacement power
supply units may be ordered directly from Supermicro See the contact information
in the Preface of this manual or visit www.supermicro.com.

6-14

Chapter 6: Advanced Chassis Setup

Changing the Power Supply

1. Unplug the AC power cord from the failed power supply.

2. With the system running, press the release tab at the top of the power supply

3. Push and hold the release tab on the back of the power supply.

4. Pull the power supply out using the handle provided.

5. Push the replacement power supply module into the chassis' power bay until
it clicks into the locked position.

6. Plug the AC power cord back into the power supply module and power- up
the nodes if needed (with a single power supply failure, the nodes should
continue to run).

Figure 6-12. Changing the Power Supply

Release Tab

6-15

SUPERSERVER 5038ML-H8TRF User's Manual

Notes

6-16

Chapter 7: BIOS

Chapter 7

BIOS

7-1 Introduction

This chapter describes the AMI BIOS Setup Utility for the X10SLD-F/X10SLD-HF.
The ROM BIOS is stored in a Flash EEPROM and can be easily updated. This
chapter describes the basic navigation of the AMI BIOS Setup Utility setup screens.

Note: For AMI BIOS Recovery, please refer to the UEFI BIOS Recovery
Instructions in Appendix C.

Starting BIOS Setup Utility

To enter the AMI BIOS Setup Utility screens, press the <Delete> key while the
system is booting up.

Note: In most cases, the <Delete> key is used to invoke the AMI BIOS
setup screen. There are a few cases when other keys are used, such as
<F1>, <F2>, etc.

Each main BIOS menu option is described in this manual. The Main BIOS setup
menu screen has two main frames. The left frame displays all the options that can
be confi gured. Grayed-out options cannot be confi gured. Options in blue can be
confi gured by the user. The right frame displays the key legend. Above the key
legend is an area reserved for a text message. When an option is selected in the
left frame, it is highlighted in white. Often a text message will accompany it. (Note:
the AMI BIOS has default text messages built in. Supermicro retains the option to
include, omit, or change any of these text messages.)

The AMI BIOS Setup Utility uses a key-based navigation system called "hot keys".
Most of the AMI BIOS setup utility "hot keys" can be used at any time during the
setup navigation process. These keys include <F1>, <F4>, <Enter>, <ESC>, arrow
keys, etc.

Note: Options printed in Bold are default settings.

How To Change the Confi guration Data

The confi guration data that determines the system parameters may be changed by
entering the AMI BIOS Setup utility. This Setup utility can be accessed by pressing
<Del> at the appropriate time during system boot.

7-1

SUPERSERVER 5038ML-H8TRF User's Manual

How to Start the Setup Utility

Normally, the only visible Power-On Self-Test (POST) routine is the memory test.
As the memory is being tested, press the <Delete> key to enter the main menu of
the AMI BIOS Setup Utility. From the main menu, you can access the other setup
screens. An AMI BIOS identifi cation string is displayed at the left bottom corner of
the screen, below the copyright message.

Warning: Do not upgrade the BIOS unless your system has a BIOS-related issue.
Flashing the wrong BIOS can cause irreparable damage to the system. In no event
shall Supermicro be liable for direct, indirect, special, incidental, or consequential dam­ages arising from a BIOS update. If you have to update the BIOS, do not shut down
or reset the system while the BIOS is updating. This is to avoid possible boot failure.

7-2 Main Setup

When you fi rst enter the AMI BIOS Setup utility , you will enter the Main setup screen.
You can always return to the Main setup screen by selecting the Main tab on the
top of the screen. The Main BIOS Setup screen is shown below.

7-2

Chapter 7: BIOS

The following Main menu items will display:

System Date/System Time

Use this option to change the system date and time. Highlight System Date or
System Time using the arrow keys. Enter new values through the keyboard. Press

the <Tab> key or the arrow keys to move between fi elds. The date must be entered
in Day MM/DD/YY format. The time is entered in HH:MM:SS format.

Note: The time is in the 24-hour format. For example, 5:30 P.M. appears
as 17:30:00.

The following BIOS items will also be displayed:

Supermicro X10SLD-F/HF

Version

Build Date

Memory Information

Total Memory

This displays the total size of memory available in the system.

7-3

SUPERSERVER 5038ML-H8TRF User's Manual

7-3 Advanced Setup Confi gurations

Use the arrow keys to select Boot Setup and press <Enter> to access the submenu
items:

Warning: Take Caution when changing the Advanced settings. An incorrect value, a
very high DRAM frequency , or an incorrect DRAM timing setting may make the system
unstable. When this occurs, revert to the setting to its manufacture default setting.



Boot Feature

Quiet Boot

This feature selects the screen display between POST messages or the OEM
logo at bootup. Select Disabled to display the POST messages. Select Enabled
to display the OEM logo instead of the normal POST messages. The options are

Enabled and Disabled.

AddOn ROM Display Mode

This feature sets the display mode for the Option ROM. Select Keep Current to
use the current AddOn ROM display setting. Select Force BIOS to use the Option
ROM display mode set by the system BIOS. The options are Force BIOS and
Keep Current.

Bootup Num-Lock

This featu re sel ect s the Powe r-on st ate for t he Num loc k key. The options ar e Of f
and On.

7-4

Chapter 7: BIOS

Wait For 'F1' If Error

This feature force s the system to wa it until th e 'F1' key is pressed if an e rror o c­curs. T he opti ons are D isab led and Enabl ed.

Interrupt 19 Capture

Interrupt 19 is the software interrupt that handles the boot disk function. When this
item is set to Enabled, the ROM BIOS of the host adaptors will "capture" Interrupt 19
at bootup and allow the drives that are attached to these host adaptors to function
as bootable disks. If this item is set to Disabled, the ROM BIOS of the host adap­tors will not capture Interrupt 19, and the drives attached to these adaptors will not
function as bootable devices. The options are Enabled and Disabled.

Re-try Boot

If this item is enabled, the BIOS will automatically reboot the system from a spe ci­fi ed boot device after its initial boot failure. The options are Disabled, Legacy
Boot, and EFI B oot.



Power Confi guration

Watch Dog Function

If enable d, the Watch Dog Ti mer will allow the system to rebo ot when it is inac tive
for more t han 5 minu tes. The o ption s are Enabl ed and Disabled.

Power Button Function

This feature controls how the system shuts down when the power button is pressed.
Select 4_Seconds_Override for the user to power off the system after pressing and
holding the power button for 4 seconds or longer. Select Instant Off to instantly
power off the system as soon as the user presses the power button. The options
are 4 Seconds Override and Instant Off.

Restore on AC Power Loss

Use this feature to set the power state after a power outage. Select Power-Off for
the system power to remain off after a power loss. Select Power-On for the system
power to be turned on after a power loss. Select Last State to allow the system
to resume its last power state before a power loss. The options are Power-On,
Stay-Off and Last State.

7-5

SUPERSERVER 5038ML-H8TRF User's Manual



CPU Confi guration

The following CPU information will be displayed:

• Type of CPU

• CPU Signature

• Microcode Patch

• Max (Maximum) CPU Speed

• Min (Minimum) CPU Speed

• CPU Speed

• Processor Cores

• Intel HT(Hyper-Threading) Technology

• Intel VT-x (Virtualization) Technology

• Intel SMX (Trusted Execution) Technology

• 64-bit

• EIST Technology

• CPU C3 State

• CPU C6 State

• CPU C7 State

• L1 Data Cache

• L1 Code Cache

• L2 Cache

• L3 Cache

Hyper-Threading

Select Enabled to enable Hyper-Threating support to enhance CPU performance.
The options are Enabled and Disabed.

7-6

Chapter 7: BIOS

Active Processor Cores

This feature determines how many CPU cores will be activated for each CPU. When
all is selected, all cores in the CPU will be activated. (Please refer to Intel's web
site for more information.) The options are All, 1, 2, and 3.

Limit CPUID Maximum

Select Enabled to set the maximum CPU ID value and to boot the legacy operat­ing systems that cannot support processors with extended CPUID functions. The
options are Enabled and Disabled (for the Windows OS).

Execute Disable Bit Capability (Available if supported by the OS & the CPU)

Set to Enabled to enable the Execute Disable Bit which will allow the processor
to designate areas in the system memory where an application code can execute
and where it cannot, thus preventing a worm or a virus from fl ooding illegal codes
to overwhelm the processor or damage the system during an attack. The default is

Enabled. (Refer to Intel and Microsoft Web Sites for more information.)

Intel® Virtualization Technology (Available when supported by the CPU)

Selec t Enabl ed to us e the I ntel Vi r tua liz atio n Technolog y to allo w one p lat for m to
run mult iple ope rating syst ems and app licati ons in inde pendent p art itions , creat­ing mult iple " vi r tu al" sy stems i n one p hysic al c o mput er. The opti ons ar e Enabled
and Disabled.

Hardware Prefetcher (Available when supported by the CPU)

If set to Enabled, the hardware prefetcher will prefetch streams of data and instruc­tions from the main memory to the L2 cache to improve CPU performance. The
options are Disabled and Enabled.

Adjacent Cache Line Prefetch (Available when supported by the CPU)

Select Enabled for the CPU to prefetch both cache lines for 128 bytes as comprised.
Select Disabled for the CPU to prefetch both cache lines for 64 bytes. The options
are Disabled and Enabled.

Note: If there is any c hange to this s etting, you wi ll need to rebo ot the
system for t he change to t ake effec t. Please r efer to Intel’s web site fo r
detailed information.

CPU AES

Select Enable to enable Intel CPU Advanced Encryption Standard (AES) Instruc­tions for CPU to enhance data integrity. The options are Enabled and Disabled.

7-7

SUPERSERVER 5038ML-H8TRF User's Manual

EIST

EIST (Enhanced Intel SpeedStep Technology) allows the system to automatically
adjust processor voltage and core frequency in an effort to reduce power consump­tion and heat dissipation. Please refer to Intel’s web site for detailed information.
The options are Disabled and Enabled.

Turbo Mode

This feature allows processor cores to run faster than the frequency recommended
by the manufacturer. The options are Disabled and Enabled. If this feature is set
to Enabled, the following items will display:

CPU Power Limit1 (Available when "Turbo Mode" is set to Enabled)

Use this feature to set the power limit for CPU1. Use the number keys on your
keyboard to enter the value. Enter 0 to use the manufacture default setting.

CPU Power Limit1 Time (Available when "Turbo Mode" is set to Enabled)

This item allows the user to determine how long CPU1 should operate at the
power limit set by the user for the item above. Use the number keys on your
keyboard to enter the value. Enter 0 to use the manufacture default setting.

CPU Power Limit2 (Available when "Turbo Mode" is set to Enabled)

Use this feature to set the power limit for CPU2. Use the number keys on your
keyboard to enter the value. Enter 0 to use the manufacture default setting.

DDR Power Limit1 (Available when "Turbo Mode" is set to Enabled)

Use this feature to set the power limit for DDR1. Use the number keys on your
keyboard to enter the value. Enter 0 to use the manufacture default setting.

DDR Power Limit1 Time (Available when "Turbo Mode" is set to Enabled)

This item allows the user to determine how long DDR1 should operate at the
power limit set by the item above. Use the number keys on your keyboard to
enter the value. Enter 0 to use the manufacture default setting.

DDR Power Limit2 (Available when "Turbo Mode" is set to Enabled)

Use this feature to set the power limit for DDR2. Use the number keys on your
keyboard to enter the value. Enter 0 to use the manufacture default setting.

1-Core Ratio Limit (Available when "Turbo Mode" is set to Enabled)

This increases (multiplies) 1 clock speed in the CPU core in relation to the bus
speed when one CPU core is active. Press "+" or "-" on your keyboard to change
the value. Enter 0 to use the manufacture default setting.

7-8

Chapter 7: BIOS

2-Core Ratio Limit (Available when "Turbo Mode" is set to Enabled)

This increases (multiplies) 2 clock speeds in the CPU core in relation to the bus
speed when two CPU cores are active. Press "+" or "-" on your keyboard to
change the value. Enter 0 to use the manufacture default setting.

3-Core Ratio Limit (Available when "Turbo Mode" is set to Enabled)

This increases (multiplies) 3 clock speeds in the CPU core in relation to the bus
speed when three CPU cores are active. Press "+" or "-" on your keyboard to
change the value. Enter 0 to use the manufacture default setting.

4-Core Ratio Limit (Available when "Turbo Mode" is set to Enabled)

This increases (multiplies) 4 clock speeds in the CPU core in relation to the bus
speed when four CPU cores are active. Press "+" or "-" on your keyboard to
change the value. Enter 0 to use the manufacture default setting.

Energy Performance

Use this feature to select an appropriate fan setting to achieve the maximum system
performance (with maximum cooling) or maximum energy effi ciency (with maximum
power saving). The fan speeds are controlled by the fi rmware management via IPMI

2.0. The options are Performance, Balanced Performance, Balanced Energy, and
Energy Effi cient.

VR Current Value

Use this feature to set the limit on the current voltage regulator (VR). Press "+" or
"-" on your keyboard to change this value. Enter 0 to use the manufacture default
setting.

CPU C-States

C-States architecture, a processor power management platform developed by
Intel, can further reduce power consumption from the basic C1 (Halt State) state
that blocks clock cycles to the CPU. Select Enabled for CPU C-Sates support. The
options are Enabled and Disabled. If this feature is set to Enabled, the following
items will display:

Enhanced C1E State (Available when "CPU C-States" is set to Enabled)

Select Enabled to enable Enhanced C1 Power State to boost system perfor­mance. The options are Enabled and Disabled.

CPU C3 Report (Available when "CPU C-States" is set to Enabled)

Select Enabled to allow the BIOS to report the CPU C3 State (ACPI C2) to the
operating system. During the CPU C3 State, the CPU clock generator is turned
off. The options are Enabled and Disabled.

7-9

SUPERSERVER 5038ML-H8TRF User's Manual

CPU C6 Report (Available when "CPU C-States" is set to Enabled)

Select Enabled to allow the BIOS to report the CPU C6 State (ACPI C3) to the
operating system. During the CPU C6 State, the power to all caches is turned
off. The options are Enabled and Disabled.

C6 Latency (Available when "CPU C-States" is set to Enabled)

Select Short to set a short delay time(period) during which the BIOS reports
CPU C6 State (ACPI C3) to the operating system. Select Long to set a long
delay time(period) during which the BIOS reports CPU C6 State (ACPI C3)
to the operating system. The options are Short and Long.

CPU C7 Report (Available when "CPU C-States" is set to Enabled

Select Enabled to allow the BIOS to report the CPU C7 State (ACPI C3) to the
operating system. CPU C7 State is a processor-specifi c low C-State. The options
are Disabled, CPU C7, and CPU C7s

C7 Latency (Available when "CPU C-States" is set to Enabled)

Select Short to set a short delay time(period) during which the BIOS reports
CPU C7 State (ACPI C3) to the operating system. Select Long to set a long
delay time(period) during which the BIOS reports CPU C7 State (ACPI C3)
to the operating system. The options are Short and Long.

C1 State Auto Demotion

When this item is enabled, the CPU will conditionally demote C3, C6 or C7
requests to C1 State based on un-cored auto-demote information. The options
are Disabled and Enabled.

C3 State Auto Demotion

When this item is enabled, the CPU will conditionally demote C6 or C7 requests
to C3 State based on un-cored auto-demote information. The options are Dis­abled and Enabled.

C-State Pre-Wake

Select Enabled to support C State Pre-Wake State features. The options are

Enabled and Disabled

Package C-State limit

Select Auto for the AMI BIOS to automatically set the limit on the C-State package
register. The options are C0/C1, C2, C3, C6, C7 and Auto.

7-10

Chapter 7: BIOS

LakeTiny Feature

Select Enabled for LakeTiny feature support for C-State confi guration. The options
are Enabled and Disabled.

ACPI T State

Select Enabled for ACPI T state (processor throttling) feature support. The options
are Disabled and Enabled.



Chipset Confi guration

Warning: Setting the wrong values in the following sections may cause the system

to malfunction.



System Agent (SA) Confi guration

The following System Agent (SA) information will be displayed:

• System Agent Bridge Name

• VT-d Capability

VT-d

Select Enabled to enable Intel Virtualization Technology support for Direct I/O VT-d
by reporting the I/O device assignments to VMM through the DMAR ACPI Tables.
This feature offers fully-protected I/O resource-sharing across the Intel platforms,
providing the user with greater reliability, security and availability in networking and
data-sharing. The settings are Enabled and Disabled.



PCI-E Confi guration

This item displays the information of the (graphics) device installed on a PCI-E
slot.

Micro-LP Slot

Micro-LP Slot-Gen X

Slot1

Slot1 - Gen X

This feature allows the user to select PCI-E support for the device installed on
CPU Slot 6. The options are Auto, Gen1 (Generation 1), Gen 2 and Gen 3.

7-11

SUPERSERVER 5038ML-H8TRF User's Manual

Detect Non-Compliance Device

Select Enabled for the AMI BIOS to automatically detect a PCI-E device that is
not compliant with the PCI-E standards. The options are Enabled and Disabled.

Program PCI-E ASPM After OpROM

PCI-E ASPM, the Active State Power Management for PCI-Express slots, is a
power management protocol used to manage power consumption of serial-link
devices installed on PCI-Exp slots during a prolonged off-peak time. If this item
is set to Enabled, PCI-E ASMP will be programmed after OpROM. If this item
is set to Disabled, the PCI-E ASPM will be programmed before OpROM. The
options are Enabled and Disabled.

Micro-LP Slot-ASPM/Slot1-ASPM

Use this feature to set the ASPM (Active State Power Management) level for the
device installed on the PCI-E slot specifi ed above. The options are Disabled,

Auto, ASPM L0s, ASPM L1, and, ASPM L0sL1.

DMI Link ASPM Control

This feature confi gures the ASPM (Active State Power Management) settings for
the devices/components connected to the DMI Link on the System Agent side.
The options are Disabled, L0s, L1, and L0sL1.

PCH Link ASPM Control

Select Enabled to support ASPM (Active State Power Management) for both
North Bridge and South Bridge. The options are Disabled and Enabled.



Memory Confi guration

This submenu displays the information on the memory modules installed on the
motherboard.

• Memory RC Version

• Memory Frequency

• Total Memory

• Memory Voltage

• DIMMA1

• DIMMA2

• DIMMB1

7-12

Chapter 7: BIOS

• DIMMB2

• CAS Latency (tCL)

• Minimum Delay Time

• CAS to RAS (tRODmin)

• Row Precharge (tRPmin)

• Active to Precharege (tRASmin)

Memory Frequency Limiter

This feature sets the limit of memory frequency for DIMM modules installed
on the the motherboard. The options are Auto, 1067 (MHz), 1333 (MHz), and
1600 (MHz).

Max TOLUD (Top of Low Usable DRAM)

This feature sets the maximum TOLUD value, which specifi es the "Top of Low
Usable DRAM" memory space to be used by internal graphics devices, GTT
Stolen Memory, and TSEG, respectively, if these devices are enabled. The op­tions are Enabled and Dynamic, 1 GB, 1.25 GB, 1.5 GB, 1.75 GB,. 2 GB, 2.25
GB, 2.5 GB, 2.75 GB, 3 GB and 3.25 GB.

Note: TSEG is a block of memory that is only accessible by the processor
while operating in SMM mode.

Memory Scrambler

This feature enables or disables memory scrambler support for memory error
correction. The settings are Enabled and Disabled.



PCH-IO Confi guration

This item displays the information for PCH-IO Chip.

• Intel PCH Rev ID

• USB Confi guration

• USB Devices

7-13

SUPERSERVER 5038ML-H8TRF User's Manual

EHCI1

Select Enabled to enable EHCI (Enhanced Host Controller Interface) Controller 1
for USB 2.0 support. One EHCI controller must always be enabled. The settings
are Enabled and Disabled.

EHCI2

Select Enabled to enable EHCI (Enhanced Host Controller Interface) Controller 2
for USB 2.0 support. One EHCI controller must always be enabled. The settings
are Enabled and Disabled.

Legacy USB Support

This feature enables support for legacy USB devices. Select Auto to disable
legacy support if USB devices are not present. Select Disable to have USB
devices available only for EFI applications. The options are Enabled, Disabled
and Auto.

Port 60/64 Emulation

This feature enables or disables I/O port 60h/64h emulation support. This should
be enabled for complete USB keyboard legacy support for non-USB-aware op­erating systems. The options are Disabled and Enabled.

XHCI Hand-Off

This item is a work-around solution for operating systems that do not support
XHCI (Extensible Host Controller Interface) hand-off. The XHCI ownership
change should be claimed by the XHCI driver. The settings are Enabled and
Disabled.

EHCI Hand-Off

This item is for Operating Systems that do not support Enhanced Host Controller
Interface (EHCI) hand-off. When this item is enabled, EHCI ownership change
will be claimed by the EHCI driver. The settings are Enabled and Disabled.

XHCI Mode

This feature handles the operation mode for the XHCI (Extensible Host Control­ler Interface) controller. The settings are Smart Auto, Auto, Enabled, Disabled
and Manual.



SATA Confi guration

When this submenu is selected, the AMI BIOS automatically detects the presence
of the SATA Devices and displays the following items:

7-14

Chapter 7: BIOS

SATA Controllers

This item Enables or Disables the built-in SA TA controllers on the motherboard. The
options are Enabled and Disabled.

SATA Mode Selection

This item selects the mode for the installed SATA drives. The options are IDE,

AHCI and RAID.

SATA RAID Option ROM/UEFI Driver (Available if the item above - SATA
Mode Select is set to AHCI or RAID)

Select Enabled to use the SATA RAID Option ROM/UEFI driver for system boot.
The options are Enabled and Disabled.

If the item above -SATA Mode Select is set to AHCI, the following items are
displayed:

Serial ATA Port 0~ Port 4

This item displays the information detected on the installed SATA drives on the
particular SATA port.

• Model number of drive and capacity

• Software Preserve Support

Port 0 ~ Port 4 Hot Plug

This feature designates the port specifi ed for hot plugging. Set this item to En-
abled for hot-plugging support, which will allow the user to replace a SATA disk
drive without shutting down the system. The options are Enabled and Disabled.

Port 0 ~ Port 1 SATA Device Type

This feature confi gures the selected SATA port to support either a solid state
drive or hard disk drive. The options are Hard Disk Drive and Solid Sate Drive.

Port 0 ~ Port 4 Spin Up Device

On an edge detect from 0 to 1, set this item to allow the PCH to start a COMRE­SET initialization sequence to the device. The options are Enabled and Disabled.

If the item above - SATA Mode Select is set to IDE, the following items are
displayed:

Serial ATA Port 0~ Port 4

This item displays the information detected on the installed SATA drives on the
particular SATA port.

• Model number of drive and capacity

7-15

SUPERSERVER 5038ML-H8TRF User's Manual

• Software Preserve Support

If the item above - SATA Mode Select is set to RAID, the following items are
displayed:

Serial ATA Port 0~ Port 4

This item displays the information detected on the installed SATA drives on the
particular SATA port.

• Model number of drive and capacity

• Software Preserve Support

Port 0 ~ Port 4 Hot Plug

This feature designates this port for hot plugging. Set this item to Enabled for
hot-plugging support, which will allow the user to replace a SATA drive without
shutting down the system. The options are Enabled and Disabled.

Port 0 ~ Port 1 SATA Device Type

This feature confi gures the selected SATA port to support either a solid state
drive or hard disk drive. Set this item to Enabled to enable hot-plugging. The
options are Hard Disk Drive and Solid Sate Drive.

Port 0 ~ Port 4 Spin Up Device

On an edge detect from 0 to 1, set this item to allow the PCH to start a COMRE­SET initialization sequence to the device. The options are Enabled and Disabled.



PCIe/PCI/PnP Confi guration

This feature allows the user to set the PCI/PnP confi gurations for the following items:

Above 4G Decoding

Selec t Enabled fo r 64- bit devic es to be dec oded above t he 4GB addr ess space
If 64b it PCI de codi ng is sup por ted by the sy stem. Th e optio ns are Disabled and
Enabled.

VGA Palette Snoop

Select Enabled to support VGA palette register snooping which will allow the
PCI car ds that do not c ontain the ir own VGA colo r palette to exa mine the vid eo
cards p alet t e and m imi c it fo r pr ope r c ol or di spl ay. The optio ns a re Disabled and
Enabled.

7-16
