Supero H8QGL-6F, H8QGL-iF User Manual

USER'S MANUAL

Revision 1.1

®

SUPER

H8QGL-6F

H8QGL-iF

The information in this User’s Manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
and makes no commitment to update or to keep current the information in this manual, or to notify
any person or organization of the updates. Please Note: For the most up-to-date version of this

manual, please see our web site at

www.supermicro.com.

Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product
described in this manual at any time and without notice. This product, including software and
documentation, is the property of Supermicro and/or its licensors, and is supplied only under a
license. Any use or reproduction of this product is not allowed, except as expressly permitted by
the terms of said license.

IN NO EVENT WILL Super Micro Computer, Inc. BE LIABLE FOR DIRECT, INDIRECT, SPECIAL,
INCIDENTAL, SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE
OR INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER MICRO COMPUTER, INC. SHALL
NOT HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED OR USED
WITH THE PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING,
INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between manufacturer and customer shall be governed by the laws of Santa
Clara County in the State of California, USA. The State of California, County of Santa Clara shall be
the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims
will not exceed the price paid for the hardware product.

FCC Statement: Refer to Supermicro's web site for FCC Compliance Information.
California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate

warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate
Material-special handling may apply. See

www.dtsc.ca.gov/hazardouswaste/perchlorate”.

WARNING: Handling of lead solder materials used in this
product may expose you to lead, a chemical known to
the State of California to cause birth defects and other
reproductive harm.

Manual Revision 1.1
Release Date: January 10, 2014
Unless you request and receive written permission from Super Micro Computer, Inc., you may not

copy any part of this document.
Information in this document is subject to change without notice. Other products and companies

referred to herein are trademarks or registered trademarks of their respective companies or mark
holders.

Copyright © 2014 by Super Micro Computer, Inc.
All rights reserved.

Printed in the United States of America

Preface

iii

Preface

About This Manual

This manual is written for system integrators, PC technicians and
knowledgeable PC users. It provides information for the installation and use of
the H8QGL-6/iF serverboards. The H8QGL-6F serverboard includes onbard SAS2
support while the H8QGL-iF does not.

The H8QGL-6/iF serverboard is based on the AMD® Dual SR5690/SP5100
chipset and supports four AMD Socket G34 type processors with up to 512 GB of
DDR3-1866/1600/1333/1066 Mhz speed SDRAM.

Please refer to the motherboard specifi cations pages on our web site for updates on
supported processors (http://www.supermicro.com/aplus/). This product is intended
to be professionally installed.

Manual Organization

Chapter 1 includes a checklist of what should be included in your motherboard

box, describes the features, specifi cations and performance of the motherboard
and provides detailed information about the chipset.

Chapter 2 begins with instructions on handling static-sensitive devices. Read this
chapter when installing the processor(s) and memory modules and when installing
the motherboard in a chassis. Also refer to this chapter to connect the hard disk
drives, the various ports, and the power and reset buttons and the system LEDs.

If you encounter any problems, see Chapter 3, which describes troubleshooting
procedures for the video, the memory and the setup confi guration stored in CMOS.
For quick reference, a general FAQ (Frequently Asked Questions) section is
provided. Instructions are also included for contacting technical support. In addition,
you can visit our web site for more detailed information.

Chapter 4 includes an introduction to BIOS and provides detailed information on
running the CMOS Setup utility.

Appendix A provides BIOS Error Beep Code Messages.
Appendix B lists BIOS POST Checkpoint Codes.

iv

H8QGL-6/iF SERVERBOARD USER'S MANUAL

Notes

v

Standardized Warning Statements

Standardized Warning Statements

About Standardized Warning Statements

The following statements are industry standard warnings, provided to warn the user
of situations which have the potential for bodily injury. Should you have questions
or experience difficulty, contact Supermicro's Technical Support department
for assistance. Only certifi ed technicians should attempt to install or confi gure
components.

Read this section in its entirety before installing or confi guring components in the
Supermicro chassis.

These warnings may also be found on our web site at http://www.supermicro.

com/about/policies/safety_information.cfm.

Battery Handling

Warning!

There is a danger of explosion if the battery is replaced incorrectly. Replace the
battery only with the same or equivalent type recommended by the manufacturer.
Dispose of used batteries according to the manufacturer's instructions

電池の取り扱い
電池交換が正しく行われなかった場合、破裂の危険性があります。交換する電池はメー

カーが推奨する型、または 同等のものを 使用下さい。 使用済電池は製造元の指示に従

って処 分して下さい。

警告

电池更换不当会有爆炸危险。请只使用同类电池或制造商推荐的功能相当的电池更
换原有电池。请按制造商的说明处理废旧电池。

警告

電池更換不當會有爆炸危險。請使用製造商建議之相同或功能相當的電池更換原有
電池。請按照製造商的說明指示處理廢棄舊電池。

Warnung
Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die

Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp.
Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers.

vi

H8QGL-6/iF SERVERBOARD USER'S MANUAL

Attention
Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer

que par une pile de type semblable ou équivalent, recommandée par le fabricant.
Jeter les piles usagées conformément aux instructions du fabricant.

!הרהזא

תנכס תמייקץוציפ .הניקת אל ךרדב הפלחוהו הדימב הללוסה לש ףילחהל שי

גוסב הללוסה תא מ םאותה תרבחלמומ ןרציתצ.

תוללוסה קוליס תושמושמה עצבל שי .ןרציה תוארוה יפל

ﺮﻄﺧ ﻙﺎﻨﻫ ﻦﻣ ﻝﺍﺪﺒﺘﺳﺍ ﺔﻟﺎﺣ ﻲﻓ ﺭﺎﺠﻔﻧﺍ ﺔﻳﺭﺎﻄﺒﻟﺍ ﺔﺤﻴﺤﺻ ﺮﻴﻏ ﺔﻘﻳﺮﻄﺑ ﻚﻴﻠﻌﻓ

ﺔﻳﺭﺎﻄﺒﻟﺍ ﻝﺍﺪﺒﺘﺳﺍ

ﻂﻘﻓ ﻉﻮﻨﻟﺍ ﺲﻔﻨﺑ ﺎﻬﻟﺩﺎﻌﻳ ﺎﻣ ﻭﺃ ﺎﻤﻛﺖﺻﻭﺃ ﺔﻌﻨﺼﻤﻟﺍ ﺔﻛﺮﺸﻟﺍ ﻪﺑ

ﺕﺎﻳﺭﺎﻄﺒﻟﺍ ﻦﻣ ﺺﻠﺨﺗ ﻟ ﺎﻘﻓﻭ ﺔﻠﻤﻌﺘﺴﻤﻟﺍﺔﻌﻧﺎﺼﻟﺍ ﺔﻛﺮﺸﻟﺍ ﺕﺎﻤﻴﻠﻌﺘ

Waarschuwing
Er is ontploffi ngsgevaar indien de batterij verkeerd vervangen wordt. Vervang de

batterij slechts met hetzelfde of een equivalent type die door de fabrikant aanbevolen
wordt. Gebruikte batterijen dienen overeenkomstig fabrieksvoorschriften afgevoerd
te worden.

경고!

배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와
동일하거나 제조사에서 권장하는 동등한 종류의 배터리로만 교체해야 합니다.
제조사의 안내에 따라 사용된 배터리를 처리하여 주십시오.

¡Advertencia!
Existe peligro de explosión si la batería se reemplaza de manera incorrecta.

Reemplazar la batería exclusivamente con el mismo tipo o el equivalente
recomendado por el fabricante. Desechar las baterías gastadas según las
instrucciones del fabricante.

Standardized Warning Statements

vii

Product Disposal

Warning!

Ultimate disposal of this product should be handled according to all national laws
and regulations.

製品の廃棄

この製品を廃棄処分する場合、国の関係する全ての法律・条例に従い処理する必要が
あります。

警告

本产品的废弃处理应根据所有国家的法律和规章进行。

警告

本產品的廢棄處理應根據所有國家的法律和規章進行。

Warnung
Die Entsorgung dieses Produkts sollte gemäß allen Bestimmungen und Gesetzen

des Landes erfolgen.
¡Advertencia!
Al deshacerse por completo de este producto debe seguir todas las leyes y

reglamentos nacionales.
Attention
La mise au rebut ou le recyclage de ce produit sont généralement soumis à des

lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de
l'organisme compétent.

רצומה קוליס

!הרהזא

ו תויחנהל םאתהב תויהל בייח הז רצומ לש יפוס קוליס.הנידמה יקוח

Waarschuwing
De uiteindelijke verwijdering van dit product dient te geschieden in overeenstemming

met alle nationale wetten en reglementen.

ﻲﺋﺎﻬﻨﻟﺍ ﺺﻠﺨﺘﻟﺍ ﻦﻣ ﺞﺘﻨﻤﻟﺍ ﺍﺬﻫ ﻪﻌﻣ ﻞﻣﺎﻌﺘﻟﺍ ﻲﻐﺒﻨﻳ ﻟ ﺎﻘﻓﻭ ﻊﻴﻤﺠﺔﻴﻨﻁﻮﻟﺍ ﺢﺋﺍﻮﻠﻟﺍﻭ ﻦﻴﻧﺍﻮﻘﻟﺍ ﺪﻨﻋ

경고!

이 제품은 해당 국가의 관련 법규 및 규정에 따라 폐기되어야 합니다.

viii

H8QGL-6/iF SERVERBOARD USER'S MANUAL

Notes

ix

Table of Contents

Chapter 1 Introduction

1-1 Overview ......................................................................................................... 1-1

Checklist ..........................................................................................................1-1

1-2 Contacting Supermicro .................................................................................... 1-2

1-3 Chipset Overview ...........................................................................................1-11

AMD SR5690/SP5100 Chipsets ....................................................................1-11

HyperTransport Technology ...........................................................................1-11

1-4 PC Health Monitoring .....................................................................................1-11

1-5 Power Confi guration Settings........................................................................1-12

1-6 Power Supply ................................................................................................1-13

1-7 Super I/O ....................................................................................................... 1-13

Chapter 2 Installation

2-1 Static-Sensitive Devices .................................................................................. 2-1

Precautions .....................................................................................................2-1

Unpacking .......................................................................................................2-1

2-2 Processor and Heatsink Installation................................................................2-2

2-3 Mounting the Motherboard into a Chassis ...................................................... 2-4

2-4 Installing Memory ............................................................................................2-4

DIMM Module Population Confi guration .................................................... 2-6

2-5 PCI Expansion Cards ...................................................................................... 2-7

2-6 I/O Port and Control Panel Connections ........................................................ 2-8

Front Control Panel ......................................................................................... 2-8

2-7 Connector Defi nitions ...................................................................................... 2-9

Power Connectors ..................................................................................... 2-9

Power Connector ........................................................................................ 2-9

Reset Connector ...................................................................................... 2-10

Power Fail LED ........................................................................................ 2-10

Overheat (OH)/Fan Fail/PWR Fail/UID LED ............................................2-10

NIC2 (Link/Activity) LED ........................................................................... 2-10

NIC1 (Link/Activity) LED ........................................................................... 2-10

HDD LED ...................................................................................................2-11

Power LED Connector ..............................................................................2-11

NMI Button ................................................................................................2-11

Universal Serial Bus Ports ........................................................................2-11

USB Headers ............................................................................................2-11

LAN1/2 (Ethernet Ports) ........................................................................... 2-12

Table of Contents

x

SMBus Header .........................................................................................2-12

SGPIO ......................................................................................................2-12

Serial Ports ............................................................................................... 2-13

Wake-On-LAN ..........................................................................................2-13

Power SMB (I

2

C) ......................................................................................2-13

Video Connector ....................................................................................... 2-13

Power LED/Speaker ................................................................................. 2-14

Overheat LED ........................................................................................... 2-14

ATX PS/2 Keyboard and PS/2 Mouse Ports ............................................ 2-14

JIBTN1 Header ......................................................................................... 2-14

Chassis Intrusion ..................................................................................... 2-15

Unit Identifi er Button ................................................................................. 2-15

Trusted Platform Module Header ............................................................. 2-15

Compact Flash Card PWR Connector .....................................................2-15

Fan Headers ............................................................................................. 2-16

2-8 Jumper Settings ............................................................................................ 2-17

Explanation of Jumpers ................................................................................ 2-17

CMOS Clear .............................................................................................2-17

I2C to PCI-Express Slot ...........................................................................2-18

Watch Dog Enable/Disable ...................................................................... 2-18

VGA Enable/Disable ................................................................................. 2-18

LAN1/2 Enable/Disable ...........................................................................2-18

BMC Jumper ............................................................................................ 2-19

SAS Enable/Disable .................................................................................2-19

2-9 Onboard Indicators ........................................................................................ 2-19

GLAN LEDs .............................................................................................. 2-19

IPMI Dedicated LAN LEDs .......................................................................2-20

Power LED ............................................................................................... 2-20

IPMI LED ..................................................................................................2-20

UID LED (LE1) ........................................................................................2-20

2-10 SAS and SATA Drive Connections ...............................................................2-21

SATA Ports ...............................................................................................2-21

SAS Ports ................................................................................................. 2-21

2-11 Enabling SATA RAID .....................................................................................2-22

Serial ATA (SATA).......................................................................................... 2-22

Installing the OS/SATA Driver ....................................................................... 2-22

Building a Driver Diskette ......................................................................... 2-22

H8QGL-6/iF SERVERBOARD USER'S MANUAL

Table of Contents

xi

Enabling SATA RAID in the BIOS .................................................................2-23

Using the Adaptec RAID Utility ..................................................................... 2-24

Installing the RAID Driver During OS Installation .........................................2-24

2-12 Installing Drivers ............................................................................................2-25

SuperDoctor III ..............................................................................................2-26

2-13 Serverboard Battery ...................................................................................... 2-28

Chapter 3 Troubleshooting

3-1 Troubleshooting Procedures ........................................................................... 3-1

Before Power On ............................................................................................ 3-1

No Power ........................................................................................................3-1

No Video .........................................................................................................3-2

Memory Errors ............................................................................................... 3-2

Losing the System’s Setup Confi guration ....................................................... 3-2

3-2 Technical Support Procedures ........................................................................ 3-2

3-3 Frequently Asked Questions ...........................................................................3-3

3-4 Returning Merchandise for Service.................................................................3-5

Chapter 4 BIOS

4-1 Introduction ......................................................................................................4-1

4-2 Main Menu ...................................................................................................... 4-2

4-3 Advanced Settings Menu ................................................................................4-2

4-6 Security Settings Menu .................................................................................4-15

4-5 Boot Settings Menu ....................................................................................... 4-16

4-8 Exit Menu ...................................................................................................... 4-17

Appendix A BIOS Error Beep Codes
Appendix B BIOS POST Checkpoint Codes

B-1 Uncompressed Initialization Codes ................................................................. B-1

B-2 Bootblock Recovery Codes ............................................................................. B-2

B-3 Uncompressed Initialization Codes ................................................................. B-3

Notes

xii

H8QGL-6/iF SERVERBOARD USER'S MANUAL

Chapter 1: Introduction

1-1

Chapter 1

Introduction

1-1 Overview

Checklist

Congratulations on purchasing your computer motherboard from an acknowledged
leader in the industry. Supermicro boards are designed with the utmost attention to
detail to provide you with the highest standards in quality and performance.

Please check that the following items have all been included with your motherboard.
If anything listed here is damaged or missing, contact your retailer.

• One (1) H8QGL-6/iF serverboard

• One (1) I/O shield (MCP-260-00027-0N)

• One (1) 9-pin serial port cable (CBL-0010L)

• Eight (8) (H8QGL-6F) or six (6) (H8QGL-iF) 2ft. Amphenol, SATA cables

(CBL-0044L)

Note: For your system to work properly, please follow the links below to download
all necessary drivers/utilities and the user’s manual for your motherboard.

• Supermicro product manuals: http://www.supermicro.com/support/manuals/

• Product drivers and utilities: ftp://ftp.supermicro.com

• Product safety information:

http://super-dev/about/policies/safety_information.cfm

• If you have any questions, please contact our support team at:

[e-mail]

1-2

H8QGL-6/iF SERVERBOARD USER'S MANUAL

1-2 Contacting Supermicro

Headquarters

Address: Super Micro Computer, Inc.

980 Rock Ave.

San Jose, CA 95131 U.S.A.
Tel: [phone]
Fax: [phone]
Email: [e-mail] (General Information)

[e-mail] (Technical Support)
Web Site:

www.supermicro.com

Europe

Address: Super Micro Computer B.V.

Het Sterrenbeeld 28, 5215 ML

's-Hertogenbosch, The Netherlands
Tel: [phone]
Fax: [phone]
Email: [e-mail] (General Information)

[e-mail] (Technical Support)

[e-mail] (Customer Support)
Web Site:

www.supermicro.com

Asia-Pacifi c

Address: Super Micro Computer, Inc.

3F, No. 150, Jian 1st Rd.

Zhonghe Dist., New Taipei City 235

Taiwan (R.O.C)
Tel: [phone]
Fax: [phone]
Email: [e-mail]
Tel: [phone]
Web Site:

www.supermicro.com.tw

Chapter 1: Introduction

1-3

Note: Some components shown in the above image may be changed or unavailable
in later revisions of this serverboard.

Figure 1-1. H8QGL-6F Image

1-4

H8QGL-6/iF SERVERBOARD USER'S MANUAL

Note: Some components shown in the above image may be changed or unavailable
in later revisions of this serverboard.

Figure 1-2. H8QGL-iF Image

Chapter 1: Introduction

1-5

Note: Jumpers not indicated are for test purposes only. Not all ports, jumpers or LED
Indicators are available on all serverboards.

Figure 1-3. H8QGL-6/iF Motherboard Layout

(not drawn to scale)

JIBTN1

1

FAN6

FAN5

FAN8

FAN3

FAN2

JD1

JF1

JI2C1

JI2C2

JOH1

JL1

LE1

JWF1

DP1

DP3

JPW4

JPW3 JPW2

BATTERY

JPG1

JPB1

JPL1

JWD1

JPS1

JWOL1

T-SGPIO2

3-SGPIO1

3-SGPIO2

T-SGPIO1

JSMB1

COM2

JBT1

USB7

JPI2C1

COM1

JPW1

SPEAKER

JTPM1

UID

LAN2

LAN1

SLOT6 PCI-E 2.0 X16

SLOT5 PCI-E 2.0 X8 IN X16

FAN7/
CPU4

FAN9/
CPU3

FAN4/
CPU1

FAN1
/CPU2

P3-DIMM1A

P2-DIMM3A

P2-DIMM4A

P3-DIMM2A

P2-DIMM2A

P2-DIMM1A

P4-DIMM4A

P1-DIMM4A

P1-DIMM1A

P1-DIMM2A

P1-DIMM3A

P3-DIMM4A

P3-DIMM3A

P4-DIMM1A

P4-DIMM2A

P4-DIMM3A

CPU3

KB/

MOUSE

CPU2

VGA

CPU1

SLOT4 PCI-E 2.0 X16

SLOT3 PCI-E 2.0 X8 IN X16

SLOT1 PCI-E 2.0 X4 IN X16

USB6

USB2/3

USB4/5

SATA5

SATA3

SATA4

SATA1

SATA2

SATA0

SAS7
SAS6

SAS4

SAS5

SAS3
SAS2
SAS1
SAS0

SLOT2 PCI-E 2.0 X16

USB0/1

IPMI LAN

CPU4

BMC

Intel

82576

AMD

SP5100

AMD

SR5690

LSI

2008

SAS2

AMD

SR5690

1-6

H8QGL-6/iF SERVERBOARD USER'S MANUAL

H8QGL-6/iF Quick Reference

Jumper Description Default Setting

JBT1 CMOS Clear (See Section 2-7)
JI2C1/JI2C2 I2C to PCI-E Slot Enable/Disable Both Open (Disabled)
JPB1 BMC Enable/Disable Pins 1-2 (Enabled)
JPG1 VGA Enable/Disable Pins 1-2 (Enabled)
JPL1 LAN 1/2 Enable/Disable Pins 1-2 (Enabled)
JPS1 SAS Controller Enable/Disable (only on H8QGL-6F) Pins 1-2 (Enabled)
JWD1 Watch Dog Pins 1-2 (Reset)

LED Description

LAN Ports LEDs for the LAN Ethernet ports
Dedicated IPMI LAN LEDs for the dedicated IPMI LAN Ethernet port
LE1 LED for UID Button
DP1 LED for IPMI Heartbeat
DP3 LED for Serverboard Power-On

Chapter 1: Introduction

1-7

Connector Description

COM1/COM2 COM1 Serial Port/Header
FAN 1-9 Chassis/CPU Fan Headers
IPMI LAN Dedicated IPMI LAN Port
JD1 Speaker Header
JF1 Front Panel Connector
JIBTN1 RAIDKey for RAID 5 SAS support (only on H8QGL-6F)
JL1 Chassis Intrusion Header
JOH1 Overheat Warning Header
JPI2C1 Power I2C Header
JPW1 24-pin Main ATX Power Connector
JPW2/3/4 +12V 8-pin CPU/Memory Power Connectors
JSMB1 System Management Bus Header (SMBus)
JTPM1 Trusted Platform Module Header
JWF1 Compact Flash Card Power Connector
JWOL1 Wake-On-LAN Header
LAN1/2 Gigabit Ethernet (RJ45) Ports
KB/Keyboard PS2 Mouse/Keyboard connectors
SAS0~3, SAS4~7 SAS Ports (only on H8QGL-6F)
SATA0 ~ SATA5 SATA Ports
3-SGPIO1/3-SGPIO2 Serial General Purpose I/O Header for SAS (only on H8QGL-6F)
T-SGPIO1/T-SGPIO2 Serial General Purpose Input/Output Header for SATA
UID Unit Identifi er Button
USB0/1, USB6, USB2/3, USB4/5 Universal Serial Bus (USB) Ports, Type-A Port and Headers
VGA VGA Connector

1-8

H8QGL-6/iF SERVERBOARD USER'S MANUAL

Motherboard Features

CPU

• Quad AMD Opteron 6000 series (AMD Socket G34 type) processors

Note: You must install at least two processors for full functions to be supported.

Memory

• Sixteen (16) single/dual/tri/quad channel DIMM slots supporting up to

512 GB of registered ECC RDIMM/LRDIMM or 128 GB of Unbuffered
ECC/non-ECC UDIMM DDR3-1866/1600/1333/1066 Mhz speed,
1 GB, 2 GB, 4 GB, 8 GB, 16 GB or 32 GB size SDRAM at 1.35V or 1.5
voltages

Note: Refer to Section 2-4 before installing memory and our web site for recommended DIMMs.
Note: Refer the tested memory list on the motherboard website.

Chipset

• Dual AMD SR5690 plus one SP5100 Southbridge chipset

Expansion Slots

• Three (3) PCI-Express x16 Gen. 2

• Two (2) PCI-Express x8 (in x16) Gen. 2

• One (1) PCI-Express x4 (in x16) Gen. 2

BIOS

• 16 Mb AMI BIOS® SPI Flash ROM

• APM 1.2, DMI 2.3, PCI 2.2, ACPI 1.0 (ACPI 2.0 is BIOS supported), SMBIOS

2.3, Real Time Clock Wakeup, Plug and Play (PnP), BIOS resume hot keys,

PC Health Monitoring

• Onboard voltage monitors

• Fan status monitor with fi rmware/software on/off and speed control

• Watch Dog

• Environmental temperature monitoring via BIOS

• Power-up mode control for recovery from AC power loss

• System resource alert (via included utility program)

• Auto-switching voltage regulator for the CPU core

• CPU thermal trip support

• I

2

C temperature sensing logic

Chapter 1: Introduction

1-9

ACPI Features

• Microsoft OnNow

• Slow blinking LED for suspend state indicator

• BIOS support for USB keyboard

• Wake-On-LAN (WOL)

• Internal/external modem ring-on

• Hardware BIOS Virus protection

Onboard I/O

• Six (6) SATA ports supported by an on-chip SATA controller (RAID 0, 1, 10

supported)

• Eight (8) SAS ports supported by an LSI 2008 SAS2 controller (RAID 0, 1, 10

supported; RAID 5 supported is optional with the AOC-SAS2-RAID5-KEY add-on
card installed (H8QGL-6F only).

• Two (2) Fast UART 16550 compatible serial port (one header and one port)

• Seven (7) USB (Universal Serial Bus 2.0) ports (2x rear, 4x header,

1x type A)

• Two (2) LAN ports supported by an onboard Intel® 82576 dual port Ethernet

controller for 10/100/1000Base-T

• One (1) dedicated IPMI LAN port

• One (1) VGA port supported by an onboard Matrox

®

G200eW graphics controller

(with 16 MB DDR2 memory)

Other

• Onboard power LED

• Chassis intrusion detection

CD Utilities

• BIOS fl ash upgrade utility

• Super Doctor III

• IPMI 1.5 / 2.0 (Optional)

Dimensions

• Propriatory format: (LxW) 16.48" x 13" (418 x 330 mm)

1-10

H8QGL-6/iF SERVERBOARD USER'S MANUAL

LPC BUS

FWH

KB.
MS.

LPC SIO

W83627DHG-P

VRM

PCIE (X16)

H/W_MONITOR

W83795

PCIE (X8)

9_FAN_CONN

.

SATA PORT X6

SATA

SLOT 1

PCIE_(X4)

HT Link

HT Link

VRM VRM

HT Link

16/16-1GHz

SLOT#2

PCIE_(X16)

SLOT#5

PCIE_(X8)

4x DIMM

G34-SOCKET #3

4x DIMM

G34-SOCKET #4

HT Link

HT Link

AMD

SR5690#1

USB

SLOT#6

PCIE_(X16)

LSI

SAS2 2008

PCIE (X4)

LAN

Intel 82576

PCIE (x4)

Winbond

WPCM450

USB PORT X7

AMD

SP5100

VGA

HT Link

16/16-1GHz

AMD

SR5690#2

PCIE (X8)

SLOT#3

PCIE_(X8)

CH 1A, 1B, 2A, 2BCH 1A, 1B, 2A, 2B

4x DIMM 4x DIMM

G34-SOCKET #2

G34-SOCKET #1

SLOT#4

PCIE_(X16)

VRM

DDR3

1600/1333/1066

DDR3

1600/1333/1066

DDR3

1600/1333/1066

DDR3

1600/1333/1066

Note: This is a general block diagram and may not exactly represent

the features on your motherboard. See the previous pages for the

actual specifi cations of your motherboard.

Figure 1-4. AMD Dual SR5690/SP5100 Chipset:

System Block Diagram

Chapter 1: Introduction

1-11

1-3 Chipset Overview

The H8QGL-6/iF serverboard is based on the AMD Dual SR5690/SP5100 chipset.
This chipset functions as a Media and Communications Processor (MCP). Controllers
for the system memory are integrated directly into AMD Opteron processors.

AMD SR5690/SP5100 Chipsets

The AMD Dual SR5690/SP5100 are each a single-chip, high-performance
HyperTransport peripheral controller. It includes a 42-lane PCI Express interface,
an AMD Opteron 16-bit Hyper T ransport interface link, a six-port Serial ATA interface
and a seven-port USB 2.0 interface. This hub connects directly to the CPU.

HyperTransport Technology

HyperTransport technology is a high-speed, low latency point to point link that was
designed to increase the communication speed by a factor of up to 48x between
integrated circuits. This is done partly by reducing the number of buses in the
chipset to reduce bottlenecks and by enabling a more effi cient use of memory
in multi-processor systems. The end result is a signifi cant increase in bandwidth
within the chipset.

1-4 PC Health Monitoring

This section describes the PC health monitoring features of the H8QGL-6/iF
serverboard. The serverboard has an onboard System Hardware Monitor chip that
supports PC health monitoring.

Onboard Voltage Monitors

The onboard voltage monitor will continuously scan crucial voltage levels. Once
a voltage becomes unstable, it will give a warning or send an error message to
the screen. Users can adjust the voltage thresholds to defi ne the sensitivity of the
voltage monitor. Real time readings of these voltage levels are all displayed in BIOS.

Fan Status Monitor with Firmware/Software Speed Control

The PC health monitor can check the RPM status of the cooling fans. The onboard
fans are controlled by thermal management via BIOS.

1-12

H8QGL-6/iF SERVERBOARD USER'S MANUAL

CPU Overheat/Fan Fail LED and Control

This feature is available when the user enables the CPU overheat/Fan Fail warning
function in the BIOS. This allows the user to defi ne an overheat temperature. When
this temperature is exceeded or when a fan failure occurs, the Overheat/Fan Fail
warning LED is triggered.

Auto-Switching Voltage Regulator for the CPU Core

The 6-phase-switching voltage regulator for the CPU core can support up to
AMD Opteron 6000SE series processors. This will allow the regulator to run cooler
and thus make the system more stable.

1-5 Power Confi guration Settings

This section describes the features of your motherboard that deal with power and
power settings.

Microsoft OnNow

The OnNow design initiative is a comprehensive, system-wide approach to system
and device power control. OnNow is a term for a PC that is always on but appears
to be off and responds immediately to user or other requests.

Slow Blinking LED for Suspend-State Indicator

When the CPU goes into a suspend state, the chassis power LED will start blinking
to indicate that the CPU is in suspend mode. When the user presses any key, the
CPU will wake-up and the LED will automatically stop blinking and remain on.

BIOS Support for USB Keyboard

If a USB keyboard is the only keyboard in the system, it will function like a normal
keyboard during system boot-up.

Main Switch Override Mechanism

The power button can function as a system suspend button. When the user
depresses the power button, the system will enter a SoftOff state. The monitor
will be suspended and the hard drive will spin down. Depressing the power button
again will cause the whole system to wake-up. During the SoftOff state, the power
supply provides power to keep the required circuitry in the system alive. In case the
system malfunctions and you want to turn off the power, just depress and hold the
power button for 4 seconds. The power will turn off and no power will be provided
to the motherboard.

Chapter 1: Introduction

1-13

Wake-On-LAN (WOL)

Wake-On-LAN is defi ned as the ability of a management application to remotely
power up a computer that is powered off. Remote PC setup, up-dates and access
tracking can occur after hours and on weekends so that daily LAN traffi c is kept
to a minimum and users are not interrupted. The motherboard has a 3-pin header
(WOL) to connect to the 3-pin header on a Network Interface Card (NIC) that has
WOL capability. Wake-On-LAN must be enabled in BIOS.

1-6 Power Supply

As with all computer products, a stable power source is necessary for proper and
reliable operation. It is even more important for processors that have high CPU
clock rates.

The H8QGL-6/iF serverboard requires the use of proprietary power supplies. Please
refer to the pinout information for the power connectors in Section 6 of Chapter 2
for detailed information on power requirements.

In areas where noisy power transmission is present, you may choose to install a
line fi lter to shield the computer from noise. It is recommended that you also install
a power surge protector to help avoid problems caused by power surges.

Warning: To prevent the possibility of explosion, do not use the wrong type of
onboard CMOS battery or install it upside down.

1-7 Super I/O

The Super I/O includes a data separator, write pre-compensation circuitry, decode
logic, data rate selection, a clock generator, drive interface control logic and interrupt
and DMA logic. The wide range of functions integrated onto the Super I/O greatly
reduces the number of components required for interfacing with fl oppy disk drives.

The Super I/O provides two high-speed, 16550 compatible serial communication
ports (UARTs), one of which supports serial infrared communication. Each UART
includes a 16-byte send/receive FIFO, a programmable baud rate generator,
complete modem control capability and a processor interrupt system. Both UARTs
provide legacy speed with baud rate of up to 115.2 Kbps as well as an advanced
speed with baud rates of 250 K, 500 K, or 1 Mb/s, which support higher speed
modems.

The Super I/O provides functions that comply with ACPI (Advanced Confi guration
and Power Interface), which includes support of legacy and ACPI power management
through a SMI or SCI function pin. It also features auto power management to reduce
power consumption.

1-14

H8QGL-6/iF SERVERBOARD USER'S MANUAL

The IRQs, DMAs and I/O space resources of the Super I/O can be fl exibly adjusted
to meet ISA PnP requirements, which support ACPI and APM (Advanced Power
Management).
