Supero C9Z390-CG-IW operation manual

C9Z390-CG-IW

USER’S MANUAL

Revision 1.0

!

The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The
vendor assumes no responsibility for any inaccuracies that may be contained in this document, makes
no commitment to update or to keep current the information in this manual, or to notify any person
or organization of the updates. Please Note: For the most up-to-date version of this manual,

please see our web site at www.supermicro.com.

Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product de­scribed in this manual at any time and without notice. This product, including software and documenta­tion, is the property of Supermicro and/or its licensors, and is supplied only under a license. Any use or
reproduction of this product is not allowed, except as expressly permitted by the terms of said license.

IN NO EVENT WILL SUPERMICRO BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDEN­TAL, SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY
TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. IN PARTICULAR, SUPERMICRO SHALL NOT HAVE LIABILITY FOR ANY
HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE PRODUCT, INCLUDING THE
COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH
HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between manufacturer and customer shall be governed by the laws of Santa
Clara County in the State of California, USA. The State of California, County of Santa Clara shall be
the exclusive venue for the resolution of any such disputes. Super Micro's total liability for all claims
will not exceed the price paid for the hardware product.

FCC Statement: This equipment has been tested and found to comply with the limits for a class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance with the instruc­tions, may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful interfer­ence to radio or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment to an outlet on a circuit different from that to which the

receiver is connected.

• Consult the authorized dealer or an experienced radio/TV technician for help.

California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate warning
applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate Material­special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”

WARNING: This product can expose you to chemicals including
lead, known to the State of California to cause cancer and birth
defects or other reproductive harm. For more information, go
to www.P65Warnings.ca.gov.

Manual Revision: 1.0
Release Date: Oct 11, 2018

Unless you request and receive written permission from Super Micro Computer, Inc., you may not
copy any part of this document.

Information in this document is subject to change without notice. Other products and companies
referred to herein are trademarks or registered trademarks of their respective companies or mark
holders.

Copyright © 2018 by Super Micro Computer, Inc. All rights reserved.

Printed in the United States of America

Preface

Preface

This manual is written for system integrators, PC technicians and
knowledgeable PC users. It provides information for the installation and
use of the C9Z390-CG-IW motherboard.

Manual Organization

Chapter 1 describes the features, specications and performance of

the motherboard, and provides detailed information on the Intel Z390
chipset.

Chapter 2 provides hardware installation instructions. Read this chap­ter when installing the processor, memory modules and other hardware
components into the system.

If you encounter any problems, see Chapter 3, which describes trouble­shooting procedures for video, memory and system setup stored in the
CMOS.

Chapter 4 includes an introduction to the BIOS, and provides detailed
information on running the CMOS Setup utility.

Appendix A provides BIOS Error Beep Codes.

Appendix B lists software program installation instructions.

Appendix C contains UEFI BIOS Recovery instructions.

Appendix D contains an introduction and instructions regarding the Dual

Boot Block feature of this motherboard.

iii

Supermicro C9Z390-CG-IW Motherboard User’s Manual

Checklist

Congratulations on purchasing your computer motherboard from an ac­knowledged leader in the industry. Supermicro boards are designed with
the utmost attention to detail to provide you with the highest standards
in quality and performance.

Please check that the following items have all been included with your
motherboard. If anything listed here is damaged or missing, contact
your retailer.

The following items are included in the retail box:

• One (1) Supermicro Motherboard

• Two (2) SATA cables

• One (1) I/O shield

• One (1) Quick Reference Guide

• One (1) Driver CD

• Two (2) Wi Antennas

Conventions Used in the Manual

Special attention should be given to the following symbols for proper
installation and to prevent damage done to the components or injury
to yourself:

Attention! Critical information to prevent damage to the com­ponents or injury to yourself.

Important: Important information given to ensure proper sys­tem installation or to relay safety precautions.

Note: Additional Information given to differentiate various mod­els or provides information for correct system setup.

iv

Standardized Warning Statements

Standardized Warning Statements

The following statements are industry-standard warnings, provided to
warn the user of situations which have the potential for bodily injury.

Should you have questions or experience difculty, contact Supermicro's
Technical Support department for assistance. Only certied technicians
should attempt to install or congure components.

Read this section in its entirety before installing or conguring compo-

nents in the Supermicro chassis.

Battery Handling

Warning!

There is a danger of explosion if the battery is replaced incorrectly. Re­place the battery only with the same or equivalent type recommended
by the manufacturer. Dispose of used batteries according to the manu­facturer's instructions

電池の取り扱い

電池交換が正しく行われなかった場合、破裂の危険性があります。 交換する電池はメー
カーが推奨する型、または同等のものを使用下さい。 使用済電池は製造元の指示に従
って処分して下さい。

警告

电池更换不当会有爆炸危险。请只使用同类电池或制造商推荐的功能相当的电池更

换原有电池。请按制造商的说明处理废旧电池。

警告

電池更換不當會有爆炸危險。請使用製造商建議之相同或功能相當的電池更換原有

電池。請按照製造商的說明指示處理廢棄舊電池。

Warnung

Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen

Sie die Batterie nur durch den gleichen oder vom Hersteller empfohlenen

Batterietyp. Entsorgen Sie die benutzten Batterien nach den Anweisungen

des Herstellers.

Attention

Danger d'explosion si la pile n'est pas remplacée correctement. Ne la

remplacer que par une pile de type semblable ou équivalent, recom-

mandée par le fabricant. Jeter les piles usagées conformément aux

instructions du fabricant.

v

Supermicro C9Z390-CG-IW Motherboard User’s Manual

¡Advertencia!

Existe peligro de explosión si la batería se reemplaza de manera incor­recta. Reemplazar la batería exclusivamente con el mismo tipo o el
equivalente recomendado por el fabricante. Desechar las baterías gasta­das según las instrucciones del fabricante.

!הרהזא

שי .הניקת אל ךרדב הפלחוהו הדימב הללוסה לש ץוציפ תנכס תמייק

ףילחהל

.תצלמומ ןרצי תרבחמ םאותה גוסב הללוסה תא

.ןרציה תוארוה יפל עצבל שי תושמושמה תוללוסה קוליס

           

 

          

       

경고!

배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일
하거나 제조사에서 권장하는 동등한 종류의 배터리로만 교체해야 합니다. 제조사
의 안내에 따라 사용된 배터리를 처리하여 주십시오.

Waarschuwing

Er is ontplofngsgevaar indien de batterij verkeerd vervangen wordt. Ver­vang de batterij slechts met hetzelfde of een equivalent type die door de
fabrikant aanbevolen wordt. Gebruikte batterijen dienen overeenkomstig
fabrieksvoorschriften afgevoerd te worden.

Product Disposal

Warning!

Ultimate disposal of this product should be handled according to all na­tional laws and regulations.

vi

Standardized Warning Statements

製品の廃棄

この製品を廃棄処分する場合、国の関係する全ての法律・条例に従い処理する必要が
ありま す。

警告

本产品的废弃处理应根据所有国家的法律和规章进行。

警告

本產品的廢棄處理應根據所有國家的法律和規章進行。

Warnung

Die Entsorgung dieses Produkts sollte gemäß allen Bestimmungen und
Gesetzen des Landes erfolgen.

¡Advertencia!

Al deshacerse por completo de este producto debe seguir todas las leyes
y reglamentos nacionales.

Attention

La mise au rebut ou le recyclage de ce produit sont généralement soumis
à des lois et/ou directives de respect de l'environnement. Renseignez­vous auprès de l'organisme compétent.

רצומה קוליס

!הרהזא

.הנידמה יקוחו תויחנהל םאתהב תויהל בייח הז רצומ לש יפוס קוליס

             

경고!

이 제품은 해당 국가의 관련 법규 및 규정에 따라 폐기되어야 합니다.

Waarschuwing

De uiteindelijke verwijdering van dit product dient te geschieden in over-

eenstemming met alle nationale wetten en reglementen.

vii

Supermicro C9Z390-CG-IW Motherboard User’s Manual

Contacting Supermicro

Headquarters

Address: Super Micro Computer, Inc.

980 Rock Ave.

San Jose, CA 95131 U.S.A.

Tel: [phone]

Fax: [phone]

Email: [e-mail] (General Information)

[e-mail] (Technical Support)

Website: www.supermicro.com

Europe

Address: Super Micro Computer B.V.

Het Sterrenbeeld 28, 5215 ML

's-Hertogenbosch, The Netherlands

Tel: [phone]

Fax: [phone]

Email: [e-mail] (General Information)

[e-mail] (Technical Support)

[e-mail] (Customer Support)

Website: www.supermicro.nl

Asia-Pacic

Address: Super Micro Computer, Inc.

3F, No. 150, Jian 1st Rd.

Zhonghe Dist., New Taipei City 235

Taiwan (R.O.C)

Tel: [phone]

Fax: [phone]

Email: [e-mail]

Web Site: www.supermicro.com.tw

viii

Contacting Supermicro

Where to Find More Information

For your system to work properly, please follow the links below to

download all necessary drivers/utilities and the user's manual for your

motherboard.

Supermicro product manuals: http://www.supermicro.com/support/

manuals/

Product Drivers and utilities: https://www.supermicro.com/wftp/driver/

If you have any questions, please contact our support team at support@

supermicro.com.

ix

Supermicro C9Z390-CG-IW Motherboard User’s Manual

Table of Contents

Preface

Manual Organization ..........................................................................iii

Checklist ..........................................................................................iv

Conventions Used in the Manual .........................................................iv

Standardized Warning Statements ....................................................... v

Battery Handling ....................................................................... v

Product Disposal .......................................................................vi

Contacting Supermicro ..................................................................... viii

Where to Find More Information..........................................................ix

Chapter 1 Introduction

1-1 Overview .............................................................................. 1-1

About this Motherboard .......................................................... 1-1

1-2 Chipset Overview .................................................................. 1-1

Intel Z390 Express Chipset Features ........................................ 1-1

1-3 Motherboard Features ............................................................... 1-2

1-4 Special Features .................................................................... 1-4

Recovery from AC Power Loss ................................................. 1-4

1-5 PC Health Monitoring .............................................................. 1-4

Fan Status Monitor with Firmware Control ............................... 1-4

Environmental Temperature Control ......................................... 1-4

System Resource Alert ........................................................... 1-5

1-6 ACPI Features ....................................................................... 1-5

Slow Blinking LED for Suspend-State Indicator .......................... 1-5

1-7 Power Supply ........................................................................ 1-6

1-8 Super I/O ............................................................................. 1-6

Chapter 2 Installation

2-1 Installation Components and Tools Needed ............................... 2-1

2-2 Static-Sensitive Devices .......................................................... 2-2

Precautions ........................................................................... 2-2

Unpacking ............................................................................. 2-2

2-3 Processor and Heatsink Installation .......................................... 2-3

Installing the Processor ......................................................... 2-3

Installing a CPU Heatsink ........................................................ 2-6

Removing a Heatsink ............................................................. 2-7

2-4 Installing DDR4 Memory ......................................................... 2-8

DIMM Installation .................................................................. 2-8

x

Table of Contents

Removing Memory Modules ..................................................... 2-8

Memory Support .................................................................... 2-9

Memory Population Guidelines ................................................. 2-9

2-5 Motherboard Installation ....................................................... 2-10

Tools Needed ....................................................................... 2-10

Location of Mounting Holes ................................................... 2-10

Installing the Motherboard .................................................... 2-11

2-6 Connectors/IO Ports ............................................................. 2-12

I/O Back Panel .................................................................... 2-12

C9Z390-CG-IW .................................................................... 2-12

Universal Serial Bus (USB) ................................................ 2-13

C9Z390-CG-IW .................................................................... 2-13

Universal Serial Bus (USB) Continued ................................. 2-14

HD AUDIO Ports ............................................................... 2-15

C9Z390-CG-IW .................................................................... 2-15

ATX PS/2 Keyboard/Mouse Port .......................................... 2-16

Ethernet Port ................................................................... 2-16

C9Z390-CG-IW .................................................................... 2-16

Front Control Panel .............................................................. 2-17

Front Control Panel Pin Denitions ......................................... 2-18

Power LED ..................................................................... 2-18

HDD LED ........................................................................ 2-18

NIC1 Activty LED ............................................................. 2-18

Overheat (OH)/Fan Fail ..................................................... 2-19

Power Fail LED ................................................................. 2-19

Power Button .................................................................. 2-20

Reset Button .................................................................. 2-20

2-7 Connecting Cables ............................................................... 2-21

ATX Main PWR and CPU PWR Connectors ............................ 2-21

Fan Headers .................................................................... 2-22

Chassis Intrusion ............................................................. 2-22

Speaker .......................................................................... 2-23

DOM PWR Connector ........................................................ 2-24

M.2 Connectors ................................................................ 2-25

Front Panel Audio Header .................................................. 2-26

2-8 Jumper Settings .................................................................. 2-27

Explanation of Jumpers ........................................................ 2-27

Watch Dog Timer Enable/Disable ....................................... 2-28

Manufacturing Mode ......................................................... 2-29

xi

Supermicro C9Z390-CG-IW Motherboard User’s Manual

OC1 Header .................................................................... 2-29

2-9 Onboard Indicators ................................................................ 2-30

LAN LEDs ........................................................................ 2-30

Onboard Power LED .......................................................... 2-30

2-10 Hard Drive Connections ........................................................ 2-31

SATA Connections (I-SATA0~I-SATA3) ................................ 2-31

Chapter 3 Troubleshooting

3-1 Troubleshooting Procedures ..................................................... 3-1

Before Power On.................................................................... 3-1

No Power .............................................................................. 3-1

No Video .............................................................................. 3-2

Memory Errors ..................................................................... 3-2

When the System is Losing the Setup Conguration .................. 3-2

3-2 Technical Support Procedures .................................................. 3-3

3-3 Frequently Asked Questions .................................................... 3-4

3-4 Battery Removal and Installation ............................................. 3-5

Battery Removal .................................................................... 3-5

Proper Battery Disposal .......................................................... 3-5

Battery Installation ................................................................ 3-5

3-5 Returning Motherboard for Service ........................................... 3-6

Chapter 4 BIOS

4-1 Introduction .......................................................................... 4-1

4-2 EZ Mode ............................................................................... 4-3

4-3 Overclocking ......................................................................... 4-4

4-4 CPU ................................................................................... 4-18

4-5 Memory .............................................................................. 4-24

4-6 Advanced ............................................................................ 4-26

4-7 H/W Monitor ....................................................................... 4-42

4-8 Save & Exit ......................................................................... 4-44

4-9 BIOS Update ....................................................................... 4-46

Appendix A BIOS Error Beep Codes

A-1 BIOS Error Beep Codes .......................................................... A-1

Appendix B Software Installation Instructions

B-1 Installing Drivers ................................................................... B-1

B-2 Conguring SuperDoctor® 5 ................................................... B-2

xii

Table of Contents

Appendix C UEFI BIOS Recovery Instructions

C-1 An Overview to the UEFI BIOS ................................................ C-1

C-2 How to Recover the UEFI BIOS Image (the Main BIOS Block) ..... C-1

C-3 To Recover the Main BIOS Block Using a USB-Attached Device .... C-2

xiii

Supermicro C9Z390-CG-IW Motherboard User’s Manual

Notes

xiv

Chapter 1: Introduction

Chapter 1

Introduction

1-1 Overview

About this Motherboard

The C9Z390-CG-IW motherboard supports a single 8th Generation Intel®

Core™ i3/i5/i7/i9, Pentium, or Celeron processor in an LGA1151 socket.

With the Intel Z390 chipset built in, the C9Z390-CG-IW motherboard of-

fers substantial system performance and storage capability for overclock-

ing platforms in a sleek package. Please refer to our website (http://www.

supermicro.com/products/) for processor and memory support updates.

1-2 Chipset Overview

Intel Z390 Express Chipset Features

• Direct Media Interface (up 10 Gb/s transfer, Full Duplex)

• Intel® Matrix Storage Technology and Intel Rapid Storage Technology

• Dual NAND Interface

• Intel I/O Virtualization (VT-d) Support

• Intel Trusted Execution Technology Support

• PCI Express 3.0 Interface (up to 8 GT/s)

• SATA Controller (up to 6Gb/sec)

• Advanced Host Controller Interface (AHCI)

1-1

Supermicro C9Z390-CG-IW Motherboard User’s Manual

1-3 Motherboard Features

CPU

One 8th generation Intel® Core™ i3/i5/i7/i9, Pentium,
or Celeron processor in an LGA1151 H4 type socket.
Up to 120W TDP.

Memory

Supports up to 32GB of unbuffered, non-ECC,
DDR4 memory with speeds of 2400/2666MHz up to
4000+MHz(OC).

Dual-channel memory

DIMM sizes

UDIMM Up to 32GB

Chipset

Expansion Slots

Intel Z390 chipset

One (1) PCI-E 3.0 x16 slot

One (1) PCI-E x4 2280 M.2 (M-key)

One (1) PCI-E x4/SATA 2280 M.2 (M-key)

One (1) E-Key M.2 2230 (pre-installed WiFi module)

Network
Connections

Intel I219V Network Controller

One (1) RJ-45 port with Link and Activity LEDs on the
I/O back panel

I/O Devices Hard Drive Connections

SATA 3.0 (6Gb/s) Four (4) SATA0~3 via Intel Z390

RAID 0, 1, 5, 10

USB Devices

One (1) USB 3.1 Gen 2 Type-C port on the I/O back panel
Three (3) USB 3.1 Gen 2 Type-A ports on the I/O back

panel
One (1) front accessible USB 3.1 Gen 2 Type-C header
Two (2) USB 3.1 Gen 1 ports on the I/O back panel
Two (2) front accessible USB 3.1 Gen 1 headers

Keyboard/Mouse

One PS/2 Keyboard/Mouse port on the I/O back panel

Other I/O Ports

One (1) DisplayPort 1.2

One (1) HDMI 2.0a Port

Audio

One (1) High Denition Audio 7.1 channel connector

supported by Realtek ALC1220 on the back panel

One (1) Front Panel Audio Header

1-2

BIOS

Power
Configuration

Health
Monitoring

System
Management

CD Utilities

LED Indicators

Dimensions

Chapter 1: Introduction

Super I/O

Nuvoton NCT6792D-B

128/256Mb AMI BIOS® SPI Flash BIOS

DMI 2.8, PCI 3.0, ACPI 3.0, BIOS rescue hot-key, SPI
dual/quad speed support, Overclock support

ACPI Power Management (S3/S4/S5)

Power Button Override Mechanism

Power-on mode for AC power recovery

CPU Monitoring

Onboard monitors: +1.8V, +3.3V, +5V, +/- 12V,
+3.3V Stby, +5V Stby, VBAT, HT, Memory, PCH
Temperature, System Temperature, Memory
Temperature

CPU/System overheat LED

CPU Thermal Trip support

Fan Control

Two (2) 4-pin fan headers

Multi-speed fan control via onboard Super I/O

PECI (Platform Environment Conguration Interface)

2.0 support

System resource alert via SuperDoctor® 5

SuperDoctor 5

Chassis Intrusion header and detection

BIOS ash upgrade utility

Drivers and software for Intel Z390 chipset utilities

Power/suspend state

Mini-ITX form factor (6.7" x 6.7") (170.18 mm x

170.18 mm)

1-3

Supermicro C9Z390-CG-IW Motherboard User’s Manual

1-4 Special Features

Recovery from AC Power Loss

Basic I/O System (BIOS) provides a setting for you to determine how
the system will respond when AC power is lost and then restored to
the system. You can choose for the system to remain powered off, (in
which case you must press the power switch to turn it back on), or for
it to automatically return to a power-on state. See the Advanced BIOS
Setup section to change this setting. The default setting is Last State.

1-5 PC Health Monitoring

This section describes the PC health monitoring features of the board.
All have an onboard System Hardware Monitoring chip that supports PC
health monitoring. An onboard voltage monitor will scan these onboard
voltages continuously: +1.8V, +3.3V, +5V, +/- 12V, +3.3V Stby, +5V
Stby, VBAT, HT, Memory, PCH Temperature, and System Temperature.
Once a voltage becomes unstable, a warning is given, or an error mes­sage is sent to the screen. The user can adjust the voltage thresholds

to dene the sensitivity of the voltage monitor.

Fan Status Monitor with Firmware Control

PC health monitoring in the BIOS can check the RPM status of the cool­ing fans. The onboard CPU and chassis fans are controlled by Thermal
Management via SIO.

Environmental Temperature Control

The thermal control sensor monitors the CPU temperature in real time
and will turn on the thermal control fan whenever the CPU temperature
exceeds a user-dened threshold. The overheat circuitry runs indepen­dently from the CPU. Once the thermal sensor detects that the CPU
temperature is too high, it will automatically turn on the thermal fans to
prevent the CPU from overheating. The onboard chassis thermal circuitry
can monitor the overall system temperature and alert the user when the
chassis temperature is too high.

Note: To avoid possible system overheating, please be sure to

provide adequate airow to your system.

1-4

Chapter 1: Introduction

System Resource Alert

This feature is available when the system is used with SuperDoctor 5

in the Windows and Linux operating systems. SuperDoctor is used to

notify the user of certain system events. For example, you can also

congure SuperDoctor to provide you with warnings when the system

temperature, CPU temperatures, voltages, and fan speeds go beyond

predened thresholds.

1-6 ACPI Features

ACPI stands for Advanced Conguration and Power Interface. The ACPI

specication denes a exible and abstract hardware interface that

provides a standard way to integrate power management features

throughout a PC system, including its hardware, operating system and

application software. This enables the system to automatically turn on

and off peripherals such as CD-ROMs, network cards, hard disk drives

and printers.

In addition to enabling operating system-directed power management,

ACPI also provides a generic system event mechanism for Plug and Play,

and an operating system-independent interface for conguration control.

ACPI leverages the Plug and Play BIOS data structures, while providing

a processor architecture-independent implementation that is compatible

with Windows 7, Windows 8, and Windows 2008 Operating Systems.

Slow Blinking LED for Suspend-State Indicator

When the CPU goes into a suspend state, the chassis power LED will

start to blink to indicate that the CPU is in suspend mode. When the user

presses any key, the CPU will wake up, and the LED will automatically

stop blinking and remain on.

1-5

Supermicro C9Z390-CG-IW Motherboard User’s Manual

1-7 Power Supply

As with all computer products, a stable power source is necessary for
proper and reliable operation. It is even more important for processors
that have high CPU clock rates or overclocked processors.

This motherboard accommodates 24-pin ATX power supplies. Although

most power supplies generally meet the specications required by the

CPU, some are inadequate. In addition, the 12V 8-pin power connector
located at JPW2 is also required to ensure adequate power supply to the
system. Also your power supply must supply 1.5A for the Ethernet ports.

Attention! To prevent damage to the power supply or mother­board, please use a power supply that contains a 24-pin and a
8-pin power connectors. Be sure to connect these connectors to
the 24-pin (JPW1) and the 8-pin (JPW2) power connectors on the
motherboard.

It is strongly recommended that you use a high quality power supply

that meets ATX power supply Specication 2.02 or above. It must also

be SSI compliant. (For more information, please refer to the web site
at http://www.ssiforum.org/). Additionally, in areas where noisy power

transmission is present, you may choose to install a line lter to shield

the computer from noise. It is recommended that you also install a power
surge protector to help avoid problems caused by power surges.

1-8 Super I/O

The Super I/O supports two high-speed, 16550 compatible serial commu­nication ports (UARTs). Each UART includes a 16-byte send/receive FIFO,
a programmable baud rate generator, complete modem control capability
and a processor interrupt system. Both UARTs provide legacy speed with
baud rate of up to 115.2 Kbps as well as an advanced speed with baud
rates of 250 K, 500 K, or 1 Mb/s, which support higher speed modems.

The Super I/O provides functions that comply with ACPI (Advanced Con-

guration and Power Interface), which includes support of legacy and

ACPI power management through an SMI or SCI function pin. It also
features auto power management to reduce power consumption.

1-6

C9Z390-CG-IW Motherboard Image

Chapter 1: Introduction

Note: All graphics shown in this manual were based upon the latest
PCB Revision available at the time of publishing of the manual. The
motherboard you've received may or may not look exactly the same
as the graphics shown in this manual.

1-7

Supermicro C9Z390-CG-IW Motherboard User’s Manual

C9Z390-CG-IW Motherboard Layout

AUDIO FP

HD AUDIO

CPU SLOT7 PCI-E 3.0 X16

JPME2

2-3:ME MANUFACTURING MODE

1-2:NORMAL

JL1

OC1

PCI-E M.2-M1

JD1JWD1

USB 2/3(3.0)

SPEAKER:Pin1-4

JD1:

JSD1

SATA DOM PWR

MH12

2280

USB 6/7(3.1)

INTRUSION

CHASSIS

USB 8(3.1)

LED5

A

A

C C

JL1:

LED2

I-SATA3

I-SATA1

JCMOS

MAC CODE

PWR

ON

RST

X

OH/FF

1-2 RST

JWD1:WATCH DOG

2-3 NMI

X
NIC

1

LED

HDD

LED

PWR

PCI-E M.2-E1

USB 4/5(3.1)

WIFI+BT

JCMOS:
OPEN:NORMAL
SHORT:CLEAR CMOS

BAR CODE

JF1

C9Z390-CG-IW

I-SATA2

I-SATA0

LAN1

REV:1.01

JRF1

JRF1:
OPEN:NORMAL
SHORT:FORCEx8+x8
(RISER CARD)

DESIGNED IN USA

JPW1

HDMI/DP

B1

KB/MOUSE
USB 0/1(3.0)

JVR1

JPW2

JRLED1

SYS_FAN1

JF1

CPU LED

DIMM LED

VGA LED

BOOT LED

C

CC

A

A

A

CPU_FAN1

A

C

C

A

LED1

DIMMA1

DIMMB1

JP1

^

^

^

^

`

`

`

`

Important Notes to the User

• See Chapter 2 for detailed information on jumpers, I/O ports and

JF1 front panel connections.

• " " indicates the location of "Pin 1".

• Jumpers not indicated are for testing only.

• When LED1 (Onboard Power LED Indicator) is on, system power

is on. Unplug the power cable before installing or removing any
components.

1-8

PCIe x16 SLOT

HDMI 2.0

Display Port

3 X Rear Type-A,1 X Rear Type-C

1X Type-C Header

1 X Header

2 X Rear

Audio Jack/ Aduio Pin Header

Head Phone Header

PCIe3.0_x16

8.0GT/s

PS175

C9Z390-CG-IW Block Diagram

INTEL LGA1151

DDI1

DDI2

USB3.1 GEN2 x4

10Gbps

USB3.1 GEN2 x2

10Gbps

USB3.1 GEN1

5Gbps

USB3.1 GEN1

5Gbps

Realtek ALC1220

AZALIA

(Socket-H4)

x4 DMI
8GT/s

Intel

PCH-H Z390

PCH

FLASH

SPI 256Mb

SPI

SVID

IMVP8

DDR4 (CHA)

2400/2133/1866MHz

DDR4 (CHB)

2400/2133/1866MHz

PCIe3.0_x1

GLAN1

8GT/s

PCIe3.0_x4

8GT/s

PCIe3.0_x4

8GT/s

SATA-III 6Gb/s

LPC

NCT6792D-B

Chapter 1: Introduction

DIMMA0

DIMMB0

RJ45

I219

M.2 SOCKET SSD

M.2 SOCKET SSD

4 X SATA-III

CNVi interface

LPC I/O

PS2 KB/MS

M.2 key E
for WLAN & BT

1-9

Supermicro C9Z390-CG-IW Motherboard User’s Manual

C9Z390-CG-IW Quick Reference

AUDIO FP

CPU SLOT7 PCI-E 3.0 X16

JPME2

2-3:ME MANUFACTURING MODE

1-2:NORMAL

JL1

OC1

PCI-E M.2-M1

JD1JWD1

USB 2/3(3.0)

SPEAKER:Pin1-4

JD1:

JSD1

SATA DOM PWR

HD AUDIO

MH12

2280

USB 6/7(3.1)

INTRUSION

CHASSIS

USB 8(3.1)

LED2

LED5

A

A

C C

MAC CODE

JL1:

I-SATA3

I-SATA1

JCMOS

1-2 RST

JWD1:WATCH DOG

2-3 NMI

WIFI+BT

BAR CODE

JF1

PWR

ON

RST

X

OH/FF

X
NIC

1

LED

HDD

LED

PWR

I-SATA2

I-SATA0

PCI-E M.2-E1

JCMOS:
OPEN:NORMAL
SHORT:CLEAR CMOS

JRF1

JRF1:
OPEN:NORMAL
SHORT:FORCEx8+x8
(RISER CARD)

LAN1

USB 4/5(3.1)

C9Z390-CG-IW

REV:1.01

DESIGNED IN USA

JPW1

HDMI/DP

B1

KB/MOUSE
USB 0/1(3.0)

JVR1

JPW2

JRLED1

SYS_FAN1

JF1

CPU LED

DIMM LED

VGA LED

BOOT LED

C

CC

A

A

A

CPU_FAN1

A

C

C

A

LED1

DIMMA1

DIMMB1

JP1

^

^

^

^

`

`

`

`

Jumper Description Default

JCMOS Clear CMOS Open: Normal

JPME2 Intel® Manufacturing Mode Pins 1-2 (Normal)

JRF1 Force x8+x8 link (Riser Card) Open: Normal

JWD1 Watch Dog Function Enable Pins 1-2 (RST)

1-10

Short: Clear CMOS

Short: Enable

Chapter 1: Introduction

Connector Description

AUDIO FP Front Panel Audio Header

B1 RTC Battery

CPU_FAN1 CPU Fan Header

CPU SLOT7 PCI-E 3.0 x16 PCI Express x16 Slot

DP DisplayPort 1.2

HDMI HDMI Port 2.0a

HD AUDIO High Denition Audio Ports (back panel)

I-SATA0~3 Intel Z390 SATA 3.0 Ports (6Gb/sec)

JD1 Speaker/buzzer

(Pins 1-4: External Speaker)

JF1 Front Control Panel Header

JL1 Chassis Intrusion Header

JPW1 24-pin ATX Main Power Connector (Re-

quired)

JPW2 +12V 8-pin CPU power Connector (Re-

quired)

JRLED1 4-pin header for 12V RGB Strip

JSD1 SATA DOM (Disk On Module) Power Con-

nector

JVR1 Header for Manufacturing purpose

KB/MOUSE PS/2 Keyboard/Mouse Port

LAN1 RJ45 GbE LAN Port

OC1 2-pin Header for Overclocking Setting

PCI-E M.2 CONNECTOR E1 M.2 E-key connector (Pre-installed Intel

Wireless-AC 9560 WiFi module)

PCI-E M.2 CONNECTOR M1, M2M.2 PCI-E Connectors (Small form factor

devices and other portable devices for
high speed NVMe SSDs
*PCI-E M.2-M2 is on the bottom side of
the motherboard (Only PCI-E M.2-M2
supports both PCI-E and SATA)

1-11

Supermicro C9Z390-CG-IW Motherboard User’s Manual

SYS_ FA N1 System Fan Header

USB 0/1 Back Panel USB 3.1 Gen 1 Ports

USB2/3 Front Accessible USB 3.1 Gen 1 Header

USB 4/5/6/7 Back Panel USB 3.1 Gen 2 Ports

USB8 Front Accessible USB 3.1 Gen 2 Type-C

Header

LED Description Color/State

BOOT
LED

CPU
LED
DIMM
LED
VGA
LED

LED1

Bootable Device POST
(Power-On Self-Test) Status

CPU POST (Power-On Self­Test) Status
DIMM POST (Power-On
Self-Test) Status
Onboard VGA POST (Power­On Self-Test) Status
Power On: Green On
S3 (Suspend to RAM) LED

LED2 PCI-E M.2 Device LED

Bootable Device POST: Red ON
Bootable Device POST Completion:
OFF
CPU POST: Yellow ON
CPU POST Completion: OFF
DIMM POST: Blue ON
DIMM POST Completion: OFF
Onboard VGA POST: Green ON
Onboard VGA POST Completion: OFF
Power On: Green ON
S3: Green Blinking
PCI-E Device Detected: Green ON
Activity: Green Blinking
PCI-E/SATA Device Detected: Green

LED5 PCI-E/SATA M.2 LED

ON
Activity: Green Blinking

*Download the AMI status codes at https://ami.com/ami_downloads/

Aptio_V_Status_Codes.pdf

1-12

Chapter 2: Installation

Chapter 2

Installation

2-1 Installation Components and Tools Needed

Screws

Intel LGA 1151 Processor

PC Chassis

Power Supply

Phillips-Head Screwdriver

DDR4 DIMMs

Heatsink with Fan

Video Card (Optional)

SATA/USB Optical Drive (Optional)

SATA Hard Disk Drive

2-1

Supermicro C9Z390-CG-IW Motherboard User’s Manual

2-2 Static-Sensitive Devices

Electrostatic-Discharge (ESD) can damage electronic com ponents. To
avoid damaging your system board, it is important to handle it very

carefully. The following measures are generally sufcient to protect your

equipment from ESD.

Precautions

• Use a grounded wrist strap designed to prevent static discharge.

• Touch a grounded metal object before removing the board from the
antistatic bag.

• Handle the board by its edges only; do not touch its components,
peripheral chips, memory modules or gold contacts.

• When handling chips or modules, avoid touching their pins.

• Put the motherboard and peripherals back into their antistatic bags
when not in use.

• For grounding purposes, make sure your computer chassis provides
excellent conductivity between the power supply, the case, the mount­ing fasteners and the motherboard.

• Use only the correct type of onboard CMOS battery. Do not install the
onboard battery upside down to avoid possible explosion.

Unpacking

The motherboard is shipped in antistatic packaging to avoid static dam­age. When unpacking the board, make sure that the person handling it
is static protected.

2-2

Chapter 2: Installation

2-3 Processor and Heatsink Installation

Attention! When handling the processor package, avoid placing
direct pressure on the label area of the fan.

Important:

• Always connect the power cord last, and always remove it before

adding, removing or changing any hardware components. Make sure
that you install the processor into the CPU socket before you install
the CPU heatsink.

• If you buy a CPU separately, make sure that you use an Intel-certied

multi-directional heatsink only.

• Make sure to install the system board into the chassis before you

install the CPU heatsink.

• When receiving a server board without a processor pre-installed, make

sure that the plastic CPU socket cap is in place and none of the socket
pins are bent; otherwise, contact your retailer immediately.

• Refer to the Supermicro website for updates on CPU support.

Installing the Processor

1. Remove the WARNING plastic cap from the socket.

2. Press and move the locking lever to the unlocked position.

2-3

Supermicro C9Z390-CG-IW Motherboard User’s Manual

3. With the locking lever unlocked, push it back to expose the socket

plate.

4. Use your thumb and index nger to hold the CPU on its edges.

Align the CPU keys, which are semi-circle cutouts, against the
socket keys.

5. Once they are aligned, carefully lower the CPU straight down into
the socket. To avoid damaging the CPU or socket, do not drop the
CPU onto the socket, move it horizontally or vertically, or rub it
against the socket pins.

6. With the CPU inside the socket, inspect the four corners of the CPU
to make sure that the CPU is properly installed.

2-4

Chapter 2: Installation

7. Close the load plate with the CPU inside the socket. Gently push
the locking lever down to secure the CPU.

2-5

Supermicro C9Z390-CG-IW Motherboard User’s Manual

Installing a CPU Heatsink

1. Apply the proper amount of thermal grease to the heatsink.

2. Place the heatsink on top of the CPU so that the two mount-

ing holes on the heatsink are aligned with those on the retention
mechanism.

3. Tighten the screws in the following order:

Screw #4

Screw #3

Screw #2

Note: Screw #1 is not shown in the illustration.

Note: Graphic drawings included in this manual are for reference

only. They might look different from the components installed in
your system.

2-6

Chapter 2: Installation

Removing a Heatsink

Warning: We do not recommend that the CPU or the heatsink be removed.
However, if you do need to remove the heatsink, please follow the instruc­tions below to uninstall the heatsink to avoid damaging the CPU or other
components.

1. Unplug the power cord from the power supply.

2. Loosen the screws in the order below.

3. Gently wiggle the heatsink to loosen it. Do not use excessive force

when wiggling the heatsink.

Screw #4

Screw #3

Screw #2

4. Once the heatsink is loosened, remove it from the motherboard.

Note: Screw #1 is not shown in the illustration.

Note: Graphic drawings included in this manual are for reference

only. They might look different from the components installed in
your system.

2-7

Supermicro C9Z390-CG-IW Motherboard User’s Manual

2-4 Installing DDR4 Memory

Note: Check the Supermicro website for recommended memory
modules.

Attention! Exercise extreme care when installing or removing
DIMM modules to prevent any possible damage.

DIMM Installation

1. Insert the desired number of
DIMMs into the memory slots,
starting with DIMMA1, DIMMB1.
For the system to work properly,
please use the memory modules
of the same type and speed.

2. Push the release tab outwards
on the end of the DIMM slot to
unlock it.

3. Align the key of the DIMM mod­ule with the receptive point on the
memory slot.

4. Align the notches on both ends of
the module against the receptive
points on the ends of the slot.

5. Use two thumbs together to press
the notches on both ends of the
module straight down into the slot
until the module snaps into place.

6. Press the release tab to the lock
position to secure the DIMM module
into the slot.

AUDIO FP

CPU SLOT7 PCI-E 3.0 X16

JPME2

2-3:ME MANUFACTURING MODE

1-2:NORMAL

JL1

OC1

JD1JWD1

SPEAKER:Pin1-4

JD1:

JSD1

SATA DOM PWR

HD AUDIO

MH12

2280

PCI-E M.2-M1

USB 2/3(3.0)

JRF1

PCI-E M.2-E1

JRF1:
OPEN:NORMAL
SHORT:FORCEx8+x8

JF1

X

X

I-SATA2

I-SATA0

WIFI+BT

JCMOS:
OPEN:NORMAL
SHORT:CLEAR CMOS

BAR CODE

LAN1

USB 4/5(3.1)

C9Z390-CG-IW

DESIGNED IN USA

REV:1.01

(RISER CARD)

JPW1

A

A

C C

USB 6/7(3.1)

INTRUSION

CHASSIS
JL1:

USB 8(3.1)

LED2

LED5

MAC CODE

I-SATA3

I-SATA1

JCMOS

PWR
ON

RST

OH/FF

1-2 RST

JWD1:WATCH DOG

2-3 NMI

NIC
1

LED

HDD

LED

PWR

Notches

Release Tabs

Press both notches

straight down into

the memory slot.

HDMI/DP

B1

KB/MOUSE
USB 0/1(3.0)

JVR1

JPW2

JRLED1

SYS_FAN1

JF1

CPU LED

DIMM LED

VGA LED

BOOT LED

C

CC

A

A

A

CPU_FAN1

A

C

C

A

LED1

DIMMA1

JP1

DIMMB1

^

^

^

^

`

`

`

`

Removing Memory Modules

Reverse the steps above to remove the
DIMM modules from the motherboard.

2-8

Chapter 2: Installation

Memory Support

The C9Z390-CG-IW supports up to 32GB of Unbuffered (UDIMM) non­ECC DDR4 memory with speeds of up to 4000+MHz (OC) in four 288-pin
memory slots. Populating these DIMM modules with a pair of memory
modules of the same type and same size will result in interleaved mem­ory, which will improve memory performance.

Memory Population Guidelines

When installing memory modules, the DIMM slots should be populated
in the following order: DIMMA1, DIMMB1.

• Always use DDR4 DIMM modules of the same size and type.

• Mixed DIMM speeds can be installed. However, all DIMMs will run at

the speed of the slowest DIMM.

DIMMB1

DIMMA1

Recommended

Population

Towards the CPU

One DIMM

Two DIMM

2-9

Supermicro C9Z390-CG-IW Motherboard User’s Manual

2-5 Motherboard Installation

All motherboards have standard mounting holes to t different types of

chassis. Make sure that the locations of all the mounting holes for both
motherboard and chassis match. Although a chassis may have both plas­tic and metal mounting fasteners, metal ones are highly recommended
because they ground the motherboard to the chassis. Make sure that the
metal standoffs click in or are screwed in tightly. Then use a screwdriver
to secure the motherboard onto the motherboard tray.

Phillips Screwdriver (1)

Phillips Screws (4)

Standoffs (4)

Only if Needed

Tools Needed

JRF1

JRF1:
OPEN:NORMAL
SHORT:FORCEx8+x8
(RISER CARD)

LAN1

USB 4/5(3.1)

C9Z390-CG-IW

DESIGNED IN USA

REV:1.01

JPW1

HDMI/DP

B1

KB/MOUSE
USB 0/1(3.0)

JVR1

JPW2

JRLED1

SYS_FAN1

JF1

CPU LED

DIMM LED

VGA LED

BOOT LED

C

CC

A

A

A

CPU_FAN1

A

C

C

A

LED1

DIMMA1

DIMMB1

JP1

^

^

^

^

`

`

`

`

AUDIO FP

CPU SLOT7 PCI-E 3.0 X16

JPME2

2-3:ME MANUFACTURING MODE

1-2:NORMAL

JL1

OC1

PCI-E M.2-M1

JD1JWD1

USB 2/3(3.0)

SPEAKER:Pin1-4

JD1:

JSD1

SATA DOM PWR

HD AUDIO

MH12

2280

USB 6/7(3.1)

INTRUSION

USB 8(3.1)

LED5

A

A

C C

CHASSIS

JL1:

LED2

JCMOS

MAC CODE

1-2 RST

JWD1:WATCH DOG

2-3 NMI

I-SATA3

I-SATA1

WIFI+BT

BAR CODE

JF1

PWR

ON

RST

X

OH/FF

X
NIC

1

LED

HDD

LED

PWR

I-SATA2

I-SATA0

PCI-E M.2-E1

JCMOS:
OPEN:NORMAL
SHORT:CLEAR CMOS

Location of Mounting Holes

Attention! 1) To avoid damaging the motherboard and its compo­nents, please do not use a force greater than 8 lb/inch on each mount­ing screw during motherboard installation. 2) Some components are
very close to the mounting holes. Please take precautionary measures
to avoid damaging these components when installing the motherboard
to the chassis.

2-10

Chapter 2: Installation

Installing the Motherboard

1. Install the I/O shield into the back of the chassis.

2. Locate the mounting holes on the motherboard. (See the previous

page.)

3. Locate the matching mounting holes on the chassis. Align the
mounting holes on the motherboard against the mounting holes on
the chassis.

4. Install standoffs in the chassis as needed.

5. Install the motherboard into the chassis carefully to avoid damaging

other motherboard components.

6. Using the Phillips screwdriver, insert a Phillips head #6 screw into a
mounting hole on the motherboard and its matching mounting hole
on the chassis.

7. Repeat Step 6 to insert screws into all mounting holes.

8. Make sure that the motherboard is securely placed in the chassis.

Note: Images displayed are for illustration only. Your chassis
or components might look different from those shown in this
manual.

2-11

Supermicro C9Z390-CG-IW Motherboard User’s Manual

F

2-6 Connectors/IO Ports

The I/O ports are color coded in conformance with the industry standards.

See the gure below for the colors and locations of the various I/O ports.

I/O Back Panel

AUDIO FP

HD AUDIO

CPU SLOT7 PCI-E 3.0 X16

JPME2

2-3:ME MANUFACTURING MODE

1-2:NORMAL

PCI-E M.2-E1

USB 6/7(3.1)

INTRUSION

CHASSIS

JL1:

JCMOS

MAC CODE

WIFI+BT

JCMOS:
OPEN:NORMAL

SHORT:CLEAR CMOS

MH12

2280

BAR CODE

LAN1

USB 4/5(3.1)

JRF1

JRF1:
OPEN:NORMAL
SHORT:FORCEx8+x8
(RISER CARD)

HDMI/DP

B1

KB/MOUSE
USB 0/1(3.0)

JVR1

JPW2

USB 8(3.1)

JRLED1

SPEAKER:Pin1-4

JD1:

JSD1

JL1

OC1

PCI-E M.2-M1

JD1JWD1

USB 2/3(3.0)

SATA DOM PWR

LED2

LED5

JF1

PWR

A

ON

A

2-3 NMI

1-2 RST

RST

X

OH/FF

JWD1:WATCH DOG

X
NIC

1

LED

HDD

LED

PWR

C9Z390-CG-IW

REV:1.01

DESIGNED IN USA

DIMMA1

C C

DIMMB1

I-SATA3

I-SATA1

I-SATA2

I-SATA0

JPW1

CPU LED

DIMM LED

VGA LED

BOOT LED

C

SYS_FAN1

JF1

C

CC

A

A

A

CPU_FAN1

A

C
A

LED1

^

^

`

`

JP1

^

^

`

`

A PS/2 Keyboard/Mouse F LAN1 K USB 3.1 Gen 2 Port 7 P Line Out

B USB 3.1 Gen 1 Port 0 G USB 3.1 Gen 2 Port 4 L Center/LFE Out Q Mic In

C USB 3.1 Gen 1 Port 1 H USB 3.1 Gen 2 Port 5 M Surround Out

D HDMI I PCI-E M.2 E-Key N S/PDIF Out

E DisplayPort J USB 3.1 Gen 2 Port 6 O Line In

C9Z390-CG-IW

L

A

D

E

B

C

G

H

J

I

K

2-12

O

M

P

N

Q

Chapter 2: Installation

F

Universal Serial Bus (USB)

Two USB 3.1 Gen 1 ports (USB0/1), four USB 3.1 Gen 2 ports (USB4/5,
USB6: Type A, USB7: Type C) are on the I/O back panel. In addition,
one USB 3.1 Gen 1 header (USB2/3) and one USB 3.1 Gen 2 Type-C
header (USB8) are located on the motherboard to provide front chassis
access using USB cables (not included). Refer to the tables below for

pin denitions.

Front Panel USB (3.1 Gen 1) Header #2/3

Pin Definitions

Pin# Pin# Signal Name Description

1 19 VBUS Power

2 18 StdA_SSRX- SuperSpeed Receiver

3 17 StdA_SSRX+ Differential Pari

4 16 Ground Ground of PWR Return

5 15 StdA_SSTX- SuperSpeed Transmitter

6 14 StdA_SSTX+ Differential Pair

7 13 GND_DRAIN Ground for Signal

Return

8 12 D- USB 2.0 Differential Pair

9 11 D+

C9Z390-CG-IW

A

B

C

D

E

2-3:ME MANUFACTURING MODE

Back Panel USB (3.1 Gen 1) #0/1, USB

(3.1 Gen 2) #4/5/6/7 Pin Definitions

Pin# Denition Pin# Denition

1 +5V 5 +5V

2 USB_PN1 6 USB_PN0

3 USB_PP1 7 USB_PP0

4 Ground 8 Ground

A. Back panel USB0

B. Back panel USB1

C. Back panel USB4

D. Back panel USB5

E. Back panel USB6

F. Back panel USB7

G. USB2/3

PCI-E M.2-E1

USB 6/7(3.1)

AUDIO FP

CPU SLOT7 PCI-E 3.0 X16

JPME2

1-2:NORMAL

JL1

HD AUDIO

MH12

2280

INTRUSION

CHASSIS
JL1:

USB 8(3.1)

MAC CODE

JCMOS

WIFI+BT

JCMOS:
OPEN:NORMAL
SHORT:CLEAR CMOS

BAR CODE

LAN1

USB 4/5(3.1)

JRF1

JRF1:
OPEN:NORMAL
SHORT:FORCEx8+x8
(RISER CARD)

HDMI/DP

B1

KB/MOUSE
USB 0/1(3.0)

JVR1

JPW2

JRLED1

SYS_FAN1

OC1

LED2

LED5

PCI-E M.2-M1

JD1JWD1

USB 2/3(3.0)

SPEAKER:Pin1-4

JD1:

G

JSD1

SATA DOM PWR

JF1

PWR

ON

A

A

RST

C C

X

OH/FF

1-2 RST

JWD1:WATCH DOG

2-3 NMI

X
NIC

1

LED

HDD

C9Z390-CG-IW

LED

I-SATA3

I-SATA1

PWR

I-SATA2

I-SATA0

REV:1.01

DESIGNED IN USA

JPW1

DIMMA1

DIMMB1

CPU LED

DIMM LED

VGA LED

BOOT LED

C

JF1

C

CC

A

A

A

CPU_FAN1

A

C
A

LED1

^

`

JP1

^

^

^

`

`

`

2-13

Supermicro C9Z390-CG-IW Motherboard User’s Manual

Universal Serial Bus (USB) Continued

One USB 3.1 Gen 2 Type-C header (USB8) is located on the motherboard
to provide front chassis access using USB cables (not included). Refer to

the tables below for pin denitions.

Front Panel USB (3.1 Gen 2) Type-C

Header #8 Pin Definitions

Pin# Denition Pin# Denition

1 VBUS 11 VBUS

2 TX1+ 12 TX2+

3 TX1- 13 TX2-

4 GND 14 GND

5 RX1+ 15 RX2+

6 RX1- 16 RX2-

7 VBUS 17 GND

8 CC1 18 D-

9 SBU1 19 D+

10 SBU2 20 CC2

A. USB8

JRF1

PCI-E M.2-E1

HD AUDIO

MH12

2280

USB 6/7(3.1)

MAC CODE

INTRUSION

CHASSIS
JL1:

JCMOS

WIFI+BT

JCMOS:
OPEN:NORMAL
SHORT:CLEAR CMOS

BAR CODE

AUDIO FP

CPU SLOT7 PCI-E 3.0 X16

JPME2

2-3:ME MANUFACTURING MODE

1-2:NORMAL

USB 8(3.1)

JL1

JSD1

SPEAKER:Pin1-4

OC1

JD1JWD1

JD1:

SATA DOM PWR

PCI-E M.2-M1

USB 2/3(3.0)

LED2

LED5

JF1

PWR

ON

A

A

RST

C C

X
OH/FF

1-2 RST

JWD1:WATCH DOG

2-3 NMI

X
NIC

1

LED

HDD

LED

PWR

I-SATA2

I-SATA3

I-SATA1

I-SATA0

A

2-14

JRF1:
OPEN:NORMAL
SHORT:FORCEx8+x8
(RISER CARD)

LAN1

USB 4/5(3.1)

C9Z390-CG-IW

DESIGNED IN USA

REV:1.01

JPW1

HDMI/DP

B1

KB/MOUSE
USB 0/1(3.0)

JVR1

JPW2

JRLED1

SYS_FAN1

JF1

CPU LED

DIMM LED

VGA LED

BOOT LED

C

CC

A

A

A

CPU_FAN1

A

C

C

A

LED1

DIMMA1

DIMMB1

JP1

^

^

^

^

`

`

`

`

Chapter 2: Installation

HD AUDIO Ports

This motherboard features a 7.1 Channel

High Denition Audio (HDA) codec that

provides 10 DAC channels. The HD Audio
connections on the I/O back panel simul­taneously supports multiple-streaming

7.1 sound playback with two channels
of independent stereo output through
the front panel stereo out for front, rear,
center and subwoofer speakers. Use the
Advanced software included in the CD­ROM with your motherboard to enable
this function.

Audio Configuration

Color/Line 2 Ch 4.1 Ch 5.1 Ch 7.1 Ch

Light Blue

(Line In/Side Speaker Out)

Lime Green

(Line Out/Front Speaker Out)

Orange

(Center/Subwoofer)

Black

(Surround)

Pink

(Mic In)

Line In Line In Line In

Line

Front Speaker Out Front Speaker Out

Out

Center/Subwoofer

Rear Speaker Out Rear Speaker Out

Mic In Mic In Mic In Mic In

Side Speaker

Out

Front

Speaker Out

Center/

Subwoofer

Rear Speak-

er Out

A. Line In
B. Line Out
C. Center/LFE Out
D. Surround Out
E. Mic In

C9Z390-CG-IW

2-15

A

C

D

B

E

Supermicro C9Z390-CG-IW Motherboard User’s Manual

ATX PS/2 Keyboard/Mouse Port

The ATX PS/2 keyboard and mouse port is located on the back panel
above USB Ports 0/1.

Ethernet Port

There is one Gigabit Ethernet port (LAN1)
on the I/O back panel to provide network
connections. These ports accept RJ45
type cables.

Note: Please refer to the LED Indica­tor Section for LAN LED information.

LAN1 Port

Pin Definition

Pin# Denition Pin# Denition

1 P2V5SB 10 SGND

2 TD0+ 11 Act LED

3 TD0- 12 P3V3SB

4 TD1+ 13 Link 100

5 TD1- 14 Link 1000

6 TD2+ 15 Ground

7 TD2- 16 Ground

8 TD3+ 17 Ground

9 TD3- 18 Ground

(NC: No Connection)

LED (Green,
+3V3SB)

LED (Yellow,
+3V3SB)

A. PS/2 Keyboard/Mouse Port
B. LAN1

C9Z390-CG-IW

A

B

2-16

Chapter 2: Installation

2

Front Control Panel

JF1 contains header pins for various buttons and indicators that are
normally located on a control panel at the front of the chassis. These

connectors are designed specically for use with Supermicro chassis. See
the gure below for the descriptions of the front control panel buttons

and LED indicators. Refer to the following section for descriptions and

pin denitions.

AUDIO FP

HD AUDIO

MH12

CPU SLOT7 PCI-E 3.0 X16

JD1:

JL1

OC1

PCI-E M.2-M1

JD1JWD1

USB 2/3(3.0)

SATA DOM PWR

2280

JPME2

2-3:ME MANUFACTURING MODE

1-2:NORMAL

SPEAKER:Pin1-4

JSD1

Power Button

Reset Button

Overheat/Fan Fail LED (+)

USB 6/7(3.1)

JCMOS

MAC CODE

INTRUSION

CHASSIS

JL1:

USB 8(3.1)

LED2

LED5

A

A

C C

1-2 RST

JWD1:WATCH DOG

2-3 NMI

I-SATA3

I-SATA1

JF1 Header Pins

NIC1 LED (+)

HDD LED (+)

Power LED (+)

WIFI+BT

BAR CODE

JF1

PWR

ON

RST

X

OH/FF

X
NIC

1

LED

HDD

LED

PWR

I-SATA2

I-SATA0

PWR

Reset

X

X

JCMOS:
OPEN:NORMAL
SHORT:CLEAR CMOS

LAN1

USB 4/5(3.1)

REV:1.01

JRF1

DESIGNED IN USA

PCI-E M.2-E1

C9Z390-CG-IW

1

Ground

Ground

15

16

JRF1:
OPEN:NORMAL
SHORT:FORCEx8+x8
(RISER CARD)

HDMI/DP

B1

JVR1

DIMMA1

DIMMB1

JPW1

X

OH/Fan Fail LED (-)

X

NIC1 LED (-)

HDD LED (-)

Power LED (-)

CPU LED

DIMM LED

VGA LED

KB/MOUSE
USB 0/1(3.0)

JPW2

JRLED1

SYS_FAN1

JF1

BOOT LED

C

CC

A

A

A

CPU_FAN1

A

C

C

A

LED1

^

^

`

JP1

^

^

`

`

`

2-17

Supermicro C9Z390-CG-IW Motherboard User’s Manual

1

2

Front Control Panel Pin Definitions

Power LED

The Power LED connection is located on
pins 15 and 16 of JF1. Refer to the table

on the right for pin denitions.

HDD LED

The HDD LED connection is located on
pins 13 and 14 of JF1. Attach a cable
here to indicate the status of HDD­related activities, including IDE and SATA
activities. Refer to the table on the right

for pin denitions.

NIC1 Activty LED

The NIC (Network Interface Controller)
LED connection for LAN port 1 is located
on pins 11 and 12 of JF1. Attach NIC
LED cables to the NIC1 LED indicator to
display network activities. Refer to the

table on the right for pin denitions.

Power LED

Pin Definitions (JF1)

Pin# Denition

15 Vcc

16 PWR LED

HDD LED

Pin Definitions (JF1)

Pin# Denition

13 Vcc

14 HD Active

LAN LED

Pin Definitions (JF1)

Pin# Denition

11 Vcc

12 NIC1 LED

Power Button

Reset Button

Overheat/Fan Fail LED (+)

NIC1 LED (+)

HDD LED (+)

Power LED (+)

PWR

Reset

X

X

A. PWR LED

Ground

Ground

X

OH/Fan Fail LED (-)

X

NIC1 LED (-)

HDD LED (-)

Power LED (-)

15

16

2-18

C

B

A

B. HDD LED
C. NIC1 LED

Chapter 2: Installation

2

Overheat (OH)/Fan Fail

Connect an LED cable to OH/Fan Fail
connections on pins 7 and 8 of JF1 to
provide warnings for chassis overheat/
fan failure. Refer to the tables on the

right for pin denitions.

OH/Fan Fail LED

Pin Definitions (JF1)

Pin# Denition

7 Vcc

8 OH/Fan Fail LED

OH/Fan Fail Indicator

Status

State Denition

Off Normal

On Overheat

Flashing Fan Fail

Power Button

Reset Button

Overheat/Fan Fail LED (+)

NIC1 LED (+)

HDD LED (+)

Power LED (+)

PWR

Reset

X

X

1

Ground

Ground

X

OH/Fan Fail LED (-)

X

NIC1 LED (-)

HDD LED (-)

Power LED (-)

15

16

2-19

A. Overheat/Fan Fail

A

Supermicro C9Z390-CG-IW Motherboard User’s Manual

2

Power Button

The Power Button connection is located
on pins 1 and 2 of JF1. Momentarily
contacting both pins will power on/off
the system. This button can also be con-

gured to function as a suspend button

(with a setting in the BIOS - see Chapter

4). To turn off the power in the suspend
mode, press the button for at least four
seconds. Refer to the table on the right

for pin denitions.

Reset Button

The Reset Button connection is located
on pins 3 and 4 of JF1. Attach it to a
hardware reset switch on the computer
case to reset the system. Refer to the

table on the right for pin denitions.

Power Button

Pin Definitions (JF1)

Pin# Denition

1 Signal

2 Ground

Reset Button

Pin Definitions (JF1)

Pin# Denition

3 Reset

4 Ground

A

Power Button

Reset Button

B

Overheat/Fan Fail LED (+)

NIC1 LED (+)

HDD LED (+)

Power LED (+)

PWR

Reset

X

X

1

Ground

Ground

X

OH/Fan Fail LED (-)

X

NIC1 LED (-)

HDD LED (-)

Power LED (-)

15

16

2-20

A. Power Button
B. Reset Button

Chapter 2: Installation

2-7 Connecting Cables

This section provides brief descriptions and pin-out denitions for on­board headers and connectors. Be sure to use the correct cable for each
header or connector.

ATX Main PWR and CPU PWR Connectors

The 24-pin main power connector
(JPW1) provides power to the mother­board. The 8-pin CPU PWR connector
(JPW2) is also required for the proces­sor. These power connectors meet the

SSI EPS 12V specication. Refer to the
table on the right for pin denitions.

12V 8-pin Power

Connector Pin

Denitions

Pins Denition

1-4 Ground

5-8 +12V

(Required)

JRF1

PCI-E M.2-E1

USB 6/7(3.1)

HD AUDIO

MH12

CPU SLOT7 PCI-E 3.0 X16

INTRUSION

CHASSIS

JL1:

2280

USB 8(3.1)

JCMOS

MAC CODE

WIFI+BT

JCMOS:
OPEN:NORMAL
SHORT:CLEAR CMOS

BAR CODE

LAN1

USB 4/5(3.1)

JPME2

2-3:ME MANUFACTURING MODE

1-2:NORMAL

AUDIO FP

JL1

ATX Power 24-pin Connector

Pin Definitions (JPW1)

Pin# Denition Pin # Denition

13 +3.3V 1 +3.3V

14 -12V 2 +3.3V

15 Ground 3 Ground

16 PS_ON 4 +5V

17 Ground 5 Ground

18 Ground 6 +5V

19 Ground 7 Ground

20 Res (NC) 8 PWR_OK

21 +5V 9 5VSB

22 +5V 10 +12V

23 +5V 11 +12V

24 Ground 12 +3.3V

A. 24-Pin ATX Main PWR

B. 8-Pin PWR

JRF1:
OPEN:NORMAL
SHORT:FORCEx8+x8
(RISER CARD)

HDMI/DP

B1

KB/MOUSE
USB 0/1(3.0)

JVR1

B

JPW2

JRLED1

SYS_FAN1

JSD1

SPEAKER:Pin1-4

OC1

JD1JWD1

JD1:

SATA DOM PWR

PCI-E M.2-M1

USB 2/3(3.0)

LED2

LED5

JF1

PWR

ON

A

A

RST

C C

X

OH/FF

1-2 RST

JWD1:WATCH DOG

2-3 NMI

X

NIC

1

LED

HDD

C9Z390-CG-IW

LED

I-SATA3

I-SATA1

PWR

I-SATA2

I-SATA0

REV:1.01

DESIGNED IN USA

JPW1

A

DIMMA1

DIMMB1

CPU LED

DIMM LED

VGA LED

BOOT LED

C

JF1

C

CC

A

A

A

CPU_FAN1

A

C
A

LED1

^

JP1

^

^

^

`

`

`

`

2-21

Supermicro C9Z390-CG-IW Motherboard User’s Manual

Fan Headers

The motherboard has two 4-pin fan head­ers (CPU_FAN1, SYS_FAN1). Although
pins 1-3 of the system fan headers are
backward compatible with the traditional
3-pin fans, we recommend the use of
4-pin fans to take advantage of the fan
speed control. This allows the fan speeds
to be automatically adjusted based on
the motherboard temperature. Refer to

the table on the right for pin denitions.

Chassis Intrusion

A Chassis Intrusion header is located at
JL1 on the motherboard. Attach the ap­propriate cable from the chassis to inform
you of a chassis intrusion when the chassis
is opened.

Fan Header

Pin Definitions

Pin# Denition

1 Ground (Black)

2 2A/+12V (Red)

3 Tachometer

4 PWM_Control

Chassis Intrusion

Pin Definitions

Pin# Denition

1 Intrusion Input

2 Ground

A. CPU_FAN1

B. SYS_FAN1

C. Chassis Intrusion

C

AUDIO FP

CPU SLOT7 PCI-E 3.0 X16

JPME2

2-3:ME MANUFACTURING MODE

1-2:NORMAL

JL1

OC1

PCI-E M.2-M1

JD1JWD1

USB 2/3(3.0)

SPEAKER:Pin1-4

JD1:

JSD1

SATA DOM PWR

HD AUDIO

MH12

2280

USB 8(3.1)

LED5

A

A

C C

INTRUSION

USB 6/7(3.1)

MAC CODE

CHASSIS

JL1:

LED2

I-SATA3

I-SATA1

2-3 NMI

JCMOS

1-2 RST

JWD1:WATCH DOG

PWR

ON

RST

X

OH/FF

X
NIC

1

LED

HDD

LED

PWR

I-SATA0

WIFI+BT

JCMOS:
OPEN:NORMAL
SHORT:CLEAR CMOS

BAR CODE

JF1

I-SATA2

PCI-E M.2-E1

JRF1

JRF1:
OPEN:NORMAL
SHORT:FORCEx8+x8
(RISER CARD)

LAN1

USB 4/5(3.1)

C9Z390-CG-IW

DESIGNED IN USA

REV:1.01

JPW1

B1

2-22

HDMI/DP

JVR1

DIMMA1

DIMMB1

CPU LED

DIMM LED

KB/MOUSE
USB 0/1(3.0)

JRLED1

VGA LED

BOOT LED

C

A

A

C

JPW2

SYS_FAN1

JF1

CC

A

A

CPU_FAN1

C
A

LED1

^

^

^

^

`

`

`

`

B

A

JP1

Chapter 2: Installation

Speaker

On the JD1 header, if you wish to use an
external speaker, close pins 1-4 with a
cable. Refer to the table on the right for

pin denitions.

PCI-E M.2-E1

AUDIO FP

HD AUDIO

CPU SLOT7 PCI-E 3.0 X16

JPME2

2-3:ME MANUFACTURING MODE

1-2:NORMAL

JL1

USB 6/7(3.1)

INTRUSION

CHASSIS

JL1:

JCMOS

MAC CODE

MH12

2280

WIFI+BT

JCMOS:
OPEN:NORMAL
SHORT:CLEAR CMOS

LAN1

USB 4/5(3.1)

BAR CODE

USB 8(3.1)

Speaker Connector

Pin Definitions

Pin Setting Denition

Pins1-4 External Speaker

A. Speaker Header

JRF1

JRF1:

OPEN:NORMAL
SHORT:FORCEx8+x8
(RISER CARD)

HDMI/DP

B1

JVR1

KB/MOUSE
USB 0/1(3.0)

JPW2

JRLED1

SYS_FAN1

OC1

PCI-E M.2-M1

SPEAKER:Pin1-4

JD1:

JD1JWD1

USB 2/3(3.0)

A

LED2

LED5

A

A

C C

1-2 RST

2-3 NMI

PWR

ON

RST

X

OH/FF

JWD1:WATCH DOG

X
NIC

1

LED

HDD

LED

PWR

JF1

C9Z390-CG-IW

REV:1.01

DESIGNED IN USA

DIMMA1

DIMMB1

JSD1

SATA DOM PWR

I-SATA3

I-SATA1

I-SATA2

I-SATA0

JPW1

CPU LED

DIMM LED

VGA LED

BOOT LED

C

JF1

C

CC

A

A

A

CPU_FAN1

A

C
A

LED1

^

^

^

`

`

`

JP1

^

`

2-23

Supermicro C9Z390-CG-IW Motherboard User’s Manual

DOM PWR Connector

The Disk-On-Module (DOM) power con­nector, located at JSD1, provides 5V
power to a solid state DOM storage
device connected to one of the SATA
ports. Refer to the table on the right for

pin denitions.

AUDIO FP

HD AUDIO

CPU SLOT7 PCI-E 3.0 X16

JPME2

2-3:ME MANUFACTURING MODE

1-2:NORMAL

JL1

PCI-E M.2-E1

USB 6/7(3.1)

INTRUSION

CHASSIS

JL1:

JCMOS

MAC CODE

WIFI+BT

JCMOS:
OPEN:NORMAL
SHORT:CLEAR CMOS

MH12

2280

BAR CODE

USB 8(3.1)

LAN1

USB 4/5(3.1)

JRF1

JRF1:
OPEN:NORMAL
SHORT:FORCEx8+x8
(RISER CARD)

DOM PWR

Pin Definitions

Pin# Denition

1 5V

2 Ground

3 Ground

A. DOM PWR

HDMI/DP

B1

JVR1

KB/MOUSE
USB 0/1(3.0)

JPW2

JRLED1

SYS_FAN1

SPEAKER:Pin1-4

JD1:

OC1

PCI-E M.2-M1

JD1JWD1

USB 2/3(3.0)

LED2

LED5

JF1

PWR

A

C C

ON

A

RST

X

OH/FF

1-2 RST

JWD1:WATCH DOG

2-3 NMI

X

NIC

1

LED

HDD

C9Z390-CG-IW

LED

PWR

REV:1.01

DESIGNED IN USA

DIMMA1

DIMMB1

JSD1

A

SATA DOM PWR

I-SATA3

I-SATA1

I-SATA2

I-SATA0

JPW1

CPU LED

DIMM LED

VGA LED

BOOT LED

C

JF1

C

CC

A

A

A

CPU_FAN1

A

C
A

LED1

^

^

`

`

JP1

^

^

`

`

2-24

Chapter 2: Installation

M.2 Connectors

M.2 is formerly known as Next Generation Form Factor (NGFF). The M.2
M-key (2280) connector is designed for internal mounting devices and
provides support dedicated for SSD devices with the ultimate perfor­mance capability in a PCI Express 3.0 interface for native PCI-E SSD
support. M.2 SATA capability is also supported by PCI-E M.2-M2 (at the
bottom side of motherboard). The M.2 E-key connector supports a pre­installed WiFi module.

A. PCI-E M.2 Connector M1
(Top Side)

B. PCI-E M.2 (E-Key)

AUDIO FP

CPU SLOT7 PCI-E 3.0 X16

JPME2

2-3:ME MANUFACTURING MODE

1-2:NORMAL

JL1

OC1

PCI-E M.2-M1

JD1JWD1

USB 2/3(3.0)

SPEAKER:Pin1-4

JD1:

JSD1

SATA DOM PWR

HD AUDIO

MH12

2280

USB 6/7(3.1)

INTRUSION

USB 8(3.1)

LED5

A

A

C C

A

CHASSIS

JL1:

LED2

B

JCMOS

MAC CODE

ON

1-2 RST

JWD1:WATCH DOG

2-3 NMI

1

HDD

I-SATA3

I-SATA1

WIFI+BT

BAR CODE

JF1

PWR

RST

X

OH/FF

X

NIC

LED

LED

PWR

I-SATA2

I-SATA0

PCI-E M.2-E1

JCMOS:
OPEN:NORMAL
SHORT:CLEAR CMOS

JRF1

JRF1:
OPEN:NORMAL
SHORT:FORCEx8+x8
(RISER CARD)

LAN1

USB 4/5(3.1)

C9Z390-CG-IW

REV:1.01

DESIGNED IN USA

JPW1

2-25

HDMI/DP

B1

KB/MOUSE
USB 0/1(3.0)

JVR1

JPW2

JRLED1

SYS_FAN1

JF1

CPU LED

DIMM LED

VGA LED

BOOT LED

C

CC

A

A

A

CPU_FAN1

A

C

C

A

LED1

DIMMA1

DIMMB1

JP1

^

^

^

^

`

`

`

`

Supermicro C9Z390-CG-IW Motherboard User’s Manual

Front Panel Audio Header

A 10-pin Audio header at AUDIO FP is
supported on the motherboard. This
header allows you to connect the moth­erboard to a front panel audio control
panet, if needed. Connect an audio cable
to the audio header to use this feature
(not supplied). Refer to the table at right

for pin denitions for the header.

10-in Audio

Pin Definitions

Pin# Signal

1 Microphone_Left

2 Audio_Ground

3 Microphone_Right

4 Audio_Detect

5 Line_2_Right

6 Ground

7 Jack_Detect

8 Key

9 Line_2_Left

10 Ground

A. AUDIO FP

AUDIO FP

A

CPU SLOT7 PCI-E 3.0 X16

JPME2

2-3:ME MANUFACTURING MODE

1-2:NORMAL

JL1

OC1

JD1JWD1

SPEAKER:Pin1-4

JD1:

JSD1

SATA DOM PWR

HD AUDIO

MH12

2280

PCI-E M.2-M1

USB 2/3(3.0)

A

A

C C

USB 8(3.1)

LED5

USB 6/7(3.1)

MAC CODE

INTRUSION

CHASSIS

JL1:

LED2

I-SATA3

I-SATA1

1-2 RST

2-3 NMI

JCMOS

PWR

ON

RST

OH/FF

JWD1:WATCH DOG

NIC

1

LED

HDD

LED

PWR

JF1

X

X

I-SATA2

I-SATA0

PCI-E M.2-E1

USB 4/5(3.1)

WIFI+BT

JCMOS:
OPEN:NORMAL
SHORT:CLEAR CMOS

BAR CODE

C9Z390-CG-IW

REV:1.01

2-26

LAN1

JRF1

JRF1:
OPEN:NORMAL
SHORT:FORCEx8+x8
(RISER CARD)

DESIGNED IN USA

JPW1

HDMI/DP

B1

KB/MOUSE
USB 0/1(3.0)

JVR1

JPW2

JRLED1

SYS_FAN1

JF1

CPU LED

DIMM LED

VGA LED

BOOT LED

C

CC

A

A

A

CPU_FAN1

A

C

C

A

LED1

DIMMA1

DIMMB1

JP1

^

^

^

^

`

`

`

`

Chapter 2: Installation

2-8 Jumper Settings

Explanation of Jumpers

To modify the operation of the motherboard, jumpers can be used to
choose between optional settings. Jumpers create shorts between two

pins to change the function of the connector. Pin 1 is identied with a

square solder pad on the printed circuit board.

Note: On two-pin jumpers, Closed means the jumper is on, and Open
means the jumper is off the pins.

2-27

Supermicro C9Z390-CG-IW Motherboard User’s Manual

Watch Dog Timer Enable/Disable

Watch Dog (JWD1) is a system monitor
that can reboot the system when a soft­ware application hangs. Close pins 1 and
2 to reset the system if an application
hangs. Close pins 2 and 3 to generate a
non-maskable interrupt signal for the ap­plication that hangs. Refer to the table on
the right for jumper settings.

AUDIO FP

CPU SLOT7 PCI-E 3.0 X16

JPME2

2-3:ME MANUFACTURING MODE

1-2:NORMAL

JL1

HD AUDIO

MH12

2280

USB 6/7(3.1)

MAC CODE

INTRUSION

CHASSIS

JL1:

USB 8(3.1)

JCMOS

PCI-E M.2-E1

WIFI+BT

JCMOS:
OPEN:NORMAL
SHORT:CLEAR CMOS

BAR CODE

LAN1

USB 4/5(3.1)

JRF1

JRF1:
OPEN:NORMAL
SHORT:FORCEx8+x8
(RISER CARD)

Watch Dog

Jumper Settings

Pin# Denition

1-2 Reset (default)

2-3 NMI

Open Disabled

A. Watch Dog Timer

HDMI/DP

B1

JVR1

KB/MOUSE
USB 0/1(3.0)

JPW2

JRLED1

SYS_FAN1

A

SPEAKER:Pin1-4

JD1:

JSD1

OC1

PCI-E M.2-M1

JD1JWD1

USB 2/3(3.0)

SATA DOM PWR

LED2

LED5

JF1

PWR

A

C C

ON

A

RST

X

OH/FF

1-2 RST

JWD1:WATCH DOG

2-3 NMI

X
NIC

1

LED

HDD

C9Z390-CG-IW

LED

PWR

REV:1.01

DESIGNED IN USA

DIMMA1

DIMMB1

I-SATA3

I-SATA1

I-SATA2

I-SATA0

JPW1

2-28

CPU LED

DIMM LED

VGA LED

BOOT LED

C

JF1

C

CC

A

A

A

CPU_FAN1

A

C
A

LED1

^

^

^

`

`

`

JP1

^

`

Chapter 2: Installation

Manufacturing Mode

Close pins 2 and 3 of jumper JPME2

to bypass SPI flash security and force

the system to operate in Manufacturing
Mode, allowing the user to flash the sys-

Manufacturing Mode

Jumper Settings

Pin# Denition

1-2 Normal (Default)

2-3 Manufacturing Mode

tem rmware from a host server for sys­tem setting modications. Refer to the

table on the right for jumper settings.

OC1 Header

Attach an external switch to the OC1 header to enable overclocking set-

tings as pre-dened in the BIOS.

A. Manufacturing Mode
B. Overclocking Setting
Header

LAN1

USB 4/5(3.1)

JRF1

JRF1:
OPEN:NORMAL
SHORT:FORCEx8+x8
(RISER CARD)

HDMI/DP

B1

KB/MOUSE
USB 0/1(3.0)

JVR1

JPW2

JRLED1

SYS_FAN1

A

AUDIO FP

HD AUDIO

CPU SLOT7 PCI-E 3.0 X16

JPME2

2-3:ME MANUFACTURING MODE

1-2:NORMAL

JL1

MH12

2280

USB 6/7(3.1)

MAC CODE

INTRUSION

CHASSIS

JL1:

USB 8(3.1)

JCMOS

PCI-E M.2-E1

WIFI+BT

JCMOS:
OPEN:NORMAL
SHORT:CLEAR CMOS

BAR CODE

OC1

B

SPEAKER:Pin1-4

JD1:

PCI-E M.2-M1

JD1JWD1

USB 2/3(3.0)

LED2

LED5

A

A

C C

1-2 RST

2-3 NMI

PWR

ON

RST

X

OH/FF

JWD1:WATCH DOG

X

NIC

1

LED

HDD

LED

PWR

JF1

C9Z390-CG-IW

REV:1.01

DESIGNED IN USA

DIMMA1

DIMMB1

JSD1

SATA DOM PWR

I-SATA3

I-SATA1

I-SATA2

I-SATA0

JPW1

CPU LED

DIMM LED

VGA LED

BOOT LED

C

JF1

C

CC

A

A

A

CPU_FAN1

A

C
A

LED1

^

^

^

`

`

`

JP1

^

`

2-29

Supermicro C9Z390-CG-IW Motherboard User’s Manual

2-9 Onboard Indicators

LAN LEDs

Two LAN ports are on the I/O back
panel. These Ethernet LAN ports have
two LEDs (Light Emitting Diode). The
yellow LED indicates activity, while the
Link LED may be green, amber, or off to
indicate the speed of the connections.
Refer to the tables on the right for more
information.

LAN

Link LED

Activity LED

Onboard Power LED

An Onboard Power LED is located at
LED1. When this LED is on, the AC power
cable is connected. Make sure to discon­nect the power cable before removing or
installing a component.

A

GLAN Activity Indicator

LED Settings

Color Status Denition

Yellow Flashing Active

GLAN Link Indicator

LED Settings

LED Color Denition

Off No Connection/10 Mbps/100

Mbps

Amber 1 Gbps

Green 10 Gbps

Onboard PWR LED Indicator

LED Status

Status Denition

Off System Off

Solid

Green

System on, or
System off and PWR
Cable Connected

A. LAN LEDs

B. Onboard Power LED

AUDIO FP

CPU SLOT7 PCI-E 3.0 X16

JPME2

2-3:ME MANUFACTURING MODE

1-2:NORMAL

JL1

OC1

PCI-E M.2-M1

JD1JWD1

USB 2/3(3.0)

SPEAKER:Pin1-4

JD1:

JSD1

SATA DOM PWR

HD AUDIO

MH12

2280

A

A

C C

USB 6/7(3.1)

MAC CODE

INTRUSION

CHASSIS
JL1:

USB 8(3.1)

LED2

LED5

I-SATA3

I-SATA1

2-3 NMI

1-2 RST

JWD1:WATCH DOG

JCMOS

JF1

PWR

ON

RST

X
OH/FF

X
NIC

1

LED

HDD

LED

PWR

I-SATA2

I-SATA0

PCI-E M.2-E1

USB 4/5(3.1)

WIFI+BT

JCMOS:
OPEN:NORMAL
SHORT:CLEAR CMOS

BAR CODE

C9Z390-CG-IW

LAN1

REV:1.01

JRF1

JRF1:
OPEN:NORMAL
SHORT:FORCEx8+x8
(RISER CARD)

DESIGNED IN USA

JPW1

HDMI/DP

B1

KB/MOUSE
USB 0/1(3.0)

JVR1

JPW2

JRLED1

SYS_FAN1

JF1

CPU LED

DIMM LED

VGA LED

BOOT LED

C

CC

A

A

A

CPU_FAN1

A

C

C

A

LED1

B

DIMMA1

DIMMB1

JP1

^

^

^

^

`

`

`

`

2-30

2-10 Hard Drive Connections

Chapter 2: Installation

SATA Connections (I-SATA0~I­SATA3)

Four Serial ATA (SATA) 3.0 connectors
(I-SATA 0~3) are supported by the
Intel Z390 chip (supports RAID 0, 1, 5,

10). Refer to the table on the right for

pin denitions.

AUDIO FP

HD AUDIO

CPU SLOT7 PCI-E 3.0 X16

JPME2

2-3:ME MANUFACTURING MODE

1-2:NORMAL

JL1

PCI-E M.2-E1

USB 6/7(3.1)

INTRUSION

CHASSIS

JL1:

JCMOS

MAC CODE

WIFI+BT

JCMOS:
OPEN:NORMAL
SHORT:CLEAR CMOS

MH12

2280

BAR CODE

USB 8(3.1)

LAN1

USB 4/5(3.1)

JRF1

JRF1:
OPEN:NORMAL
SHORT:FORCEx8+x8
(RISER CARD)

HDMI/DP

B1

JVR1

SATA 2.0/3.0 Connectors

Pin Definitions

Pin# Signal

1 Ground

2 SATA_TXP

3 SATA_TXN

4 Ground

5 SATA_RXN

6 SATA_RXP

7 Ground

KB/MOUSE
USB 0/1(3.0)

JPW2

JRLED1

SYS_FAN1

A. I-SATA3

B. I-SATA1

C. I-SATA2

D. I-SATA0

SPEAKER:Pin1-4

JD1:

JSD1

OC1

PCI-E M.2-M1

JD1JWD1

USB 2/3(3.0)

SATA DOM PWR

A

A C
B

JF1

CPU LED

DIMM LED

VGA LED

DIMMA1

DIMMB1

BOOT LED

A

C

C

CC

A

A

A

CPU_FAN1

C
A

LED1

^

^

^

`

`

`

JP1

^

`

LED2

LED5

JF1

PWR

ON

A

RST

C C

X
OH/FF

1-2 RST

JWD1:WATCH DOG

2-3 NMI

X
NIC

1

LED

HDD

C9Z390-CG-IW

LED

I-SATA3

I-SATA1

PWR

I-SATA2

I-SATA0

REV:1.01

DESIGNED IN USA

JPW1

D

2-31

Supermicro C9Z390-CG-IW Motherboard User’s Manual

Notes

2-32

Chapter 3: Troubleshooting

Chapter 3

Troubleshooting

3-1 Troubleshooting Procedures

Use the following procedures to troubleshoot your system. If you have
followed all of the procedures below and still need assistance, refer to the
‘Technical Support Procedures’ and/or ‘Returning Merchandise for Service’
section(s) in this chapter. Always disconnect the AC power cord before
adding, changing or installing any hardware components.

Before Power On

1. Make sure that the Standby PWR LED is not on. (Note: If it is on,
the onboard power is on. Be sure to unplug the power cable before
installing or removing the components.)

2. Make sure that there are no short circuits between the motherboard
and chassis.

3. Disconnect all ribbon/wire cables from the motherboard, including
those for the keyboard and mouse. Also, be sure to remove all add­on cards.

4. Install a CPU and heatsink (be sure that it is fully seated) and then
connect the chassis speaker and the power LED to the mother­board. Check all jumper settings as well.

No Power

1. Make sure that there are no short circuits between the motherboard
and chassis.

2. Make sure that all jumpers are set to their default positions.

3. Check if the 115V/230V switch on the power supply is properly set.

4. Turn the power switch on and off to test the system.

3-1

Supermicro C9Z390-CG-IW Motherboard User’s Manual

5. The battery on your motherboard may be old. Check to make sure
that it still supplies ~3VDC. If it does not, replace it with a new
one.

No Video

1. If the power is on, but you have no video--in this case, you will

need to remove all the add-on cards and cables rst.

2. Use the speaker to determine if any beep codes exist. (Refer to Ap­pendix A for details on beep codes.)

3. Remove all memory modules and turn on the system. (If the

alarm is on, check the specications of memory modules, reset the

memory or try a different one.)

Memory Errors

1. Make sure that the DIMM modules are properly installed and fully
seated in the slots.

2. You should be using unbuffered Non-ECC DDR4 (up to 3866 if
overclocked) MHz memory recommended by the manufacturer. Also,
it is recommended that you use the memory modules of the same
type and speed for all DIMMs in the system. Do not use memory
modules of different sizes, speeds, and types.

3. Check for bad DIMM modules or slots by swapping modules be­tween slots to see if you can locate the faulty ones.

4. Check the switch of 115V/230V power supply.

When the System is Losing the Setup Configuration

1. Please be sure to use a high quality power supply. A poor quality
power supply may cause the system to lose CMOS setup informa­tion. Refer to Section 1-7 for details on recommended power sup­plies.

2. The battery on your motherboard may be old. Check to verify that
it still supplies ~3VDC. If it does not, replace it with a new one.

3-2

Chapter 3: Troubleshooting

3. If the above steps do not x the Setup Conguration problem,

contact your vendor for repairs.

3-2 Technical Support Procedures

Before contacting Technical Support, please make sure that you have
followed all the steps listed below. Also, note that as a motherboard
manufacturer, Supermicro does not sell directly to end users, so it is

best to rst check with your distributor or reseller for troubleshooting
services. They should know of any possible problem(s) with the specic
system conguration that was sold to you.

1. Please go through the ‘Troubleshooting Procedures’ and 'Frequently
Asked Question' (FAQ) sections in this chapter or see the FAQs on
our website (http://www.supermicro.com/support/faqs/) before
contacting Technical Support.

2. BIOS upgrades can be downloaded from our website at (http://

www.supermicro.com/support/bios/).

Note: Not all BIOS can be ashed. Some cannot be ashed; it

depends on the boot block code of the BIOS.

3. If you've followed the instructions above to troubleshoot your
system, and still cannot resolve the problem, then contact Supermi­cro's technical support and provide them with the following infor­mation:

• Motherboard model and PCB revision number

• BIOS release date/version (this can be seen on the initial display when

your system rst boots up)

• System conguration

• An example of a Technical Support form is on our website at (http://

www.supermicro.com/support/contact.cfm).

4. Distributors: For immediate assistance, please have your account

number ready when placing a call to our technical support depart-

ment. We can be reached by e-mail at [e-mail],

by phone at: [phone], option 2, or by fax at (408)503-

8019.

3-3

Supermicro C9Z390-CG-IW Motherboard User’s Manual

3-3 Frequently Asked Questions

Question: What type of memory does my motherboard support?

Answer: The C9Z390-CG-IW supports up to 32GB of unbuffered Non-

ECC U-DIMM DDR4. See Section 2-4 for details on installing memory.

Question: How do I update my BIOS?

Answer: We do NOT recommend that you upgrade your BIOS if you are

not experiencing any problems with your system. Updated BIOS les are

located on our website at http://www.supermicro.com/support/bios/.
Please check our BIOS warning message and the information on how
to update your BIOS on our web site. Select your motherboard model
and download the BIOS ROM le to your computer. Also, check the cur­rent BIOS revision to make sure that it is newer than your BIOS before

downloading. You may choose the zip le or the .exe le. If you choose
the zipped BIOS le, please unzip the BIOS le onto a bootable device
or a USB pen/thumb drive. To ash the BIOS, run the batch le named
"ami.bat" with the new BIOS ROM le from your bootable device or USB

pen/thumb drive. Use the following format:

F:\> ami.bat BIOS-ROM-lename.xxx <Enter>

Note: Always use the le named “ami.bat” to update the BIOS,
and inse r t a spa ce be twe en "ami.bat" and the l ename. The BI­OS - ROM-  lenam e will bea r th e motherbo a r d name (i .e., CZ39 0)

and build version as the extension. For example, "C9Z390.115".
When completed, your system will automatically reboot.

If you choose the .exe le, please run the .exe le under Win­dows to create the BIOS ash oppy disk. Insert the oppy disk
into the system you wish to ash the BIOS. Then, boot the sys­tem to the oppy disk. The BIOS utility will automatically ash

the BIOS without any prompts. Please note that this process
may take a few minutes to complete. Do not be concerned if
the screen is paused for a few minutes.

When the BIOS ashing screen is completed, the system will
reboot and will show “Press F1 or F2”. At this point, you will
need to load the BIOS defaults. Press <F1> to go to the BIOS
setup screen, and press <F9> to load the default settings. Next,
press <F10> to save and exit. The system will then reboot.

Attention! Do not shut down or reset the system while updating
the BIOS to prevent possible system boot failure!

3-4

Chapter 3: Troubleshooting

Question: I think my BIOS is corrupted. How can I recover my BIOS?

Answer: Please see Appendix C - BIOS Recovery for detailed instructions.

3-4 Battery Removal and Installation

Battery Removal

To remove the onboard battery, follow the steps below:

1. Power off your system and unplug your power cable.

2. Locate the onboard battery connector (B1) on the motherboard.

3. Carefully remove the jumper from the connector.

4. Remove the battery.

Proper Battery Disposal

Attention! Please handle used batteries carefully. Do not damage

the battery in any way; a damaged battery may release hazardous

materials into the environment. Do not discard a used battery in the

garbage or a public landll. Please comply with the regulations set

up by your local hazardous waste management agency to dispose
of your used battery properly.

Battery Installation

1. To install an onboard battery, follow steps 1 and 2 above and con-

tinue below:

2. Connect the new battery's jumper to the B1 connector.

Attention! When replacing a battery, be sure to only replace it
with the same type.

3-5

Supermicro C9Z390-CG-IW Motherboard User’s Manual

3-5 Returning Motherboard for Service

A receipt or copy of your invoice marked with the date of purchase is
required before any warranty service will be rendered. You can obtain
service by calling your vendor for a Returned Merchandise Authorization
(RMA) number. For faster service, you may also obtain RMA authoriza­tions online (http://www.supermicro.com/RmaForm/). When you return
the motherboard to the manufacturer, the RMA number should be
prominently displayed on the outside of the shipping carton, and mailed
prepaid or hand-carried. Shipping and handling charges will be applied
for all orders that must be mailed when service is complete.

This warranty only covers normal consumer use and does not cover
damages incurred in shipping or from failure due to the alteration,
misuse, abuse or improper maintenance of products.

During the warranty period, contact your distributor rst for any prod­uct problems.

3-6

Chapter 4: AMI BIOS

Chapter 4

BIOS

4-1 Introduction

This chapter describes the AMI BIOS Setup Utility for the C9Z390-CG-IW.
The ROM BIOS is stored in a Flash EEPROM and can be easily updated.
This chapter describes the basic navigation of the AMI BIOS Setup Util­ity setup screens.

Note: For AMI BIOS Recovery, please refer to the UEFI BIOS Re­covery Instructions in Appendix C.

How To Change the Configuration Data

The conguration data that determines the system parameters may be

changed by entering the AMI BIOS GUI Setup utility. This Setup util-

ity can be accessed by pressing <Del> at the appropriate time during
system boot.

Note: For the purposes of this manual, options that are printed in
Bold are default settings.

Each BIOS menu option is described in this manual. The Advanced Mode
BIOS Setup screen has two main areas. The top area is the main Naviga­tion, and the bottom area is for the Information Section. Icons that do not
respond when the mouse pointer is hovering on top are not congurable.

4-1

Supermicro C7Z390-CG-IW Motherboard User’s Manual

The AMI BIOS GUI Setup Utility uses a mouse pointer navigation system
similar to standard graphical user interfaces. Hover and click an icon to
select a section, click a down arrow to select from an options list.

You may press the <F1> on any screen under the Setup Section to see
a list of Hot Keys that are available. Press <F12> to print the screen.

The keyboard's Escape key <ESC> cancels the current screen and will
return you back to the previous screen.

Changing Between EZ Mode and Advanced Mode

To change between EZ Mode and Advanced Mode, hit F7 on the keyboard.

When in EZ Mode, select feature options and an overview of hardware

status are displayed (see CHART. 4-2). When in Advanced Mode, all fol­lowing conguration menus and their contents become available.

4-2

Chapter 4: AMI BIOS

4-2 EZ Mode

While in EZ Mode, the following information will be displayed:

System Temp - Displays CPU and PCH temperatures

CPU Prole - Allows changing of the CPU prole by clicking the left

or right arrows

DRAM Status - Status of all DIMM slots

SATA Info - Displays which SATA ports are connected to storage

devices

Boot Priority - Allows changing of the boot order, or click a device to

boot selected device

Note: Using this will reboot the computer.

X.M.P. - Allows changing the X.M.P. prole

Intel Rapid Storage Technology - Allows for enabling Intel Rapid

Storage Technology

Fan Prole - Displays current fan speeds

4-3

Supermicro C7Z390-CG-IW Motherboard User’s Manual

4-3 Overclocking

CPU Overclocking

CPU Prole

This feature allows for preset CPU overclocking proles to be selected.

The options are Stable, Default, and Performance.

Advanced CPU OC Setting

This feature controls the CPU overclocking settings. The options are
Manual, 4.3GHz, 4.4GHz, 4.5GHz, 4.6GHz, 4.7GHz, 4.8GHz, 4.9GHz,

5.0GHz, 5.1GHz, 5.2GHz, 5.3GHz, 5.4GHz, and 5.5GHz.

1-Core ~ 4-Core Ratio Limit Override

Enter a value for the each invidual CPU core.

Active Processor Cores

Use this feature to select the number of active processor cores. The

default option is All. These options depend on how many cores are sup­ported by the CPU.

BCLK Clock Frequency(1/100 MHz)

Enter a value for the BCLK frequency. The default is 10000.

4-4

Chapter 4: AMI BIOS

Spread %

Enter a value (each whole number is equivalent to 0.01%) for the spread
spectrum clocking to be applied to the base clock frequency. The default

is 45.

FCLK Frequency for Early Power On

Select the FCLK frequency for early power on. The options are Normal
(800MHz), 1GHz, 400MHz, and Auto.

BCLK Aware Adaptive Voltage

This feature enables BCLK Aware Adaptive Voltage, which helps avoid high
voltage overrides by forcing pcode to be aware of the BCLK frequency
when making calculations. The options are Disabled or Enabled.

Core Max OC Ratio

This feature controls the general maximum overclocking ratio for the CPU

cores and Ring. The default is 43.

AVX Ratio Offset

Enter a value for AVX Ratio Offset. The default is 0.

TjMax Offset

Enter a value to change the Tj-Max value. The default is 0.

Power Limit 1 Override

This feature enables Power Limit 1 override. If set to Disabled, the BIOS
will program a default power limit and power limit time window. If set to
Enabled, the following two features become available. The options are

Disabled or Enabled.

Power Limit 1

Enter a value for Power Limit 1. The default is 160000.

Power Limit 1 Time Window

This feature controls the time window for Power Limit 1. The default is 8.

Power Limit 2 Override

This feature enables Power Limit 2 override. If set to Disabled, the BIOS
will program a default power limit and power limit time window. The op-

tions are Disabled or Enabled.

4-5

Supermicro C7Z390-CG-IW Motherboard User’s Manual

Power Limit 2

Enter a value for Power Limit 2. The default is 113750.

TVB Ratio Clipping

This feature enables CPU core frequency reduction for processors that
implement Intel Thermal Velocity Boost (TVB). For overclocking, this

feature must be Disabled.

TVB Voltage Optimizations

This feature enables thermal base voltage optimizations for processors
that implement Intel Thermal Velocity Boost (TVB). The options are

Disabled or Enabled.

CPU feature

Hyper-Threading

This feature enables hyper-threading, which is a software method to

control logical processor threads. The options are Disabled or Enabled.

Boot Performance Mode

This feature controls the performance state that the BIOS will set intially.

The options are Max Non-Turbo Performance or Turbo Performance.

Intel(R) SpeedStep(tm)

Intel SpeedStep Technology allows the system to automatically adjust
processor voltage and core frequency in an effort to reduce power
consumption and heat dissipation. Please refer to Intel’s website

for detailed information. The options are Disabled or Enabled.

Race To Halt (RTH)

This feature enables Race To Halt, which dynamically increases CPU
frequency in order to enter package C-State faster. This will reduce
overall power consumption. The options are Disabled or Enabled.

Intel(R) Speed Shift Technology

This feature enables Intel® Speed Shift, which allows the operating

system to hand control of CPU frequency and voltage to the processor.
This increases P-state change speed and improves power efciency.

The options are Disabled or Enabled.

4-6

Chapter 4: AMI BIOS

C states

C-state architecture, a processor power management platform devel­oped by Intel, can further reduce power consumption from the basic
C1 (Halt State) state that blocks clock cycles to the CPU. Select En-

abled for CPU C-State support. The options are Disabled or Enabled.

Thermal Monitor

This feature enables the CPU thermal monitor. The options are Dis­abled or Enabled.

Ring

Ring Max OC Ratio

Enter a value for the maximum overclock ratio for CPU Ring. The

default is 0.

Ring Down Bin

This feature enables Ring Down Bin. If set to Enabled, the maximum

ring ratio will not be observed. The options are Disabled or Enabled.

Min Ring Ratio Limit

Enter a value for the minimum ratio limit for CPU Ring. The default

is 0.

Max Ring Ratio Limit

Enter a value for the maximum ratio limit for CPU Ring. The default

is 0.

CPU VR Settings

VR Power Delivery Design

This feature is intended for motherboard validation purposes. The
species the CFL-S board design for VR settings override values.

The default is Auto.

PSYS Slope

Enter a value for the PSYS Slope. The range is 0-200. The default

is 0.

4-7

Supermicro C7Z390-CG-IW Motherboard User’s Manual

PSYS Offset

Enter a value for the PSYS Offset. The range is 0-255. The default

is 0.

PSYS PMax Power

Enter a value for the PSYS PMax Power. The range is 0-8192. The

default is 0.

Acoustic Noise Settings

Acoustic Noise Mitigation

This feature enables Acoustic Noise Mitigation, which mitigates

acoustic noise on certain CPUs when they are in deep C-states.

If set to Enabled, the following features may be congured:

Pre-Wake Time
Ramp Up Time
Ramp Down Time

Enter a value for the desired feature. The range is 0-255. The

default is 0.

Disable Fast PKG C State Ramp for IA Domain
Disable Fast PKG C State Ramp for GT Domain
Disable Fast PKG C State Ramp for SA Domain
Disable Fast PKG C State Ramp for VccIn Domain

This feature disables fast package C-state ramping in a specic
domain. If set to FALSE, the selected domain will continue to
fast ramp. If set to TRUE, the selected domain will disable fast
ramping. The options are TRUE or FALSE.

Slow Slew Rate for IA Domain
Slow Slew Rate for GT Domain
Slow Slew Rate for SA Domain
Slow Slew Rate for VccIn Domain

This feature controls the slow slew rate for a specic domain.

The options are Fast/2, Fast/4, Fast/8, and Fast/16.

4-8

Chapter 4: AMI BIOS

Core/IA VR Settings

VR Cong Enable

This feature enables VR Cong. The options are Disabled or

Enabled.

AC Loadline

Enter a value for AC Loadline. The default is 0.

DC Loadline

Enter a value for DC Loadline. The default is 0.

PS Current Threshold1

Enter a value for PS Current Threshold1. The range is 0-512.

The default is 80.

PS Current Threshold2

Enter a value for PS Current Threshold2. The range is 0-512.

The default is 20.

PS Current Threshold3

Enter a value for PS Current Threshold3. The range is 0-512.

The default is 4.

PS3 Enable

This feature enables PS3. The options are Disabled or Enabled.

PS4 Enable

This feature enables PS4. The options are Disabled or Enabled.

IMON Slope

Enter a value for IMON Slope. The range is 0-200. The default

is 0.

IMON Offset

Enter a value for IMON Offset. The range is 0-63999. The de­fault is 0.

4-9

Supermicro C7Z390-CG-IW Motherboard User’s Manual

IMON Prex

Use this feature to set the prex value as a positive (+) or a
negative (-). The options are “+” or “-”.

VR Current Limit

Enter a value for the voltage regulator current limit, with each
whole number equating to 1/4A (i.e. 400 = 100A). Enter 0 for

Auto. The default is 1023.

VR Voltage Limit

Enter a value (in mV) for the voltage regulator voltage limit. The

range is 0-7999. Enter 0 for Auto. The default is 7999.

TDC Enable

This feature enables TDC. The options are Disabled or Enabled.

TDC Current Limit

Enter a value for the TDC Current Limit, with each whole number
equating to 1/8A (i.e. 1000 = 125A). The range is 0-32767. The

default is 800.

TDC Time Window

This feature controls the TDC Time Window. The options are 1
ms, 2 ms, 3 ms, 4 ms, 5 ms, 6 ms, 7 ms, 8 ms, and 10 ms.

TDC Lock

This feature enables TDC Lock. The options are Disabled or
Enabled.

GT VR Settings

VR Cong Enable

This feature enables VR Cong. The options are Disabled or

Enabled.

AC Loadline

Enter a value for AC Loadline. The default is 0.

DC Loadline

Enter a value for DC Loadline. The default is 0.

4-10

Chapter 4: AMI BIOS

PS Current Threshold1

Enter a value for PS Current Threshold1. The range is 0-512.

The default is 80.

PS Current Threshold2

Enter a value for PS Current Threshold2. The range is 0-512.

The default is 20.

PS Current Threshold3

Enter a value for PS Current Threshold3. The range is 0-512.

The default is 4.

PS3 Enable

This feature enables PS3. The options are Disabled or Enabled.

PS4 Enable

This feature enables PS4. The options are Disabled or Enabled.

IMON Slope

Enter a value for IMON Slope. The range is 0-200. The default

is 0.

IMON Offset

Enter a value for IMON Offset. The range is 0-63999. The de­fault is 0.

IMON Prex

Use this feature to set the prex value as a positive (+) or a
negative (-). The options are “+” or “-”.

VR Current Limit

Enter a value for the voltage regulator current limit, with each
whole number equating to 1/4A (i.e. 400 = 100A). Enter 0 for

Auto. The default is 1023.

VR Voltage Limit

Enter a value (in mV) for the voltage regulator voltage limit. The

range is 0-7999. Enter 0 for Auto. The default is 7999.

4-11

Supermicro C7Z390-CG-IW Motherboard User’s Manual

TDC Enable

This feature enables TDC. The options are Disabled or Enabled.

TDC Current Limit

Enter a value for the TDC Current Limit, with each whole number
equating to 1/8A (i.e. 1000 = 125A). The range is 0-32767. The

default is 800.

TDC Time Window

This feature controls the TDC Time Window. The options are 1
ms, 2 ms, 3 ms, 4 ms, 5 ms, 6 ms, 7 ms, 8 ms, and 10 ms.

TDC Lock

This feature enables TDC Lock. The options are Disabled or
Enabled.

Intersil VR Command

This feature enables Intersil VR Command to x VR C-state issues.

The options are Disabled, Send for IA/GT rails, and Send for IA/
GT/SA rails.

Memory OverClocking

This section displays the following memory prole information for Default,
Custom, XMP1, and XMP2 proles:

tCK [MHz]
tCL
tRCD/tRP
tRAS
tCWL
tFAW
tREFI
tRFC
tRRD
tRTP
tWR
tWTR
NMode
VDD [mV]

Realtime Memory Timing

This feature enables realtime memory timing changes to be made after
MRC_DONE. The options are Disabled or Enabled.

4-12

Chapter 4: AMI BIOS

Memory prole

This feature controls the memory prole. The options are Default pro-
le, Custom prole, and XMP prole 1.

*When set to "Custom prole", the following memory timing congura­tions become available.

Memory Reference Clock

This feature controls the memory reference clock, in MHz. The options

are 133 or 100.

Memory Ratio

This feature controls the memory ratio. The memory frequency is equal
to the memory ratio times the reference clock. The default is DDR4-

2133MHz.

Memory Voltage

Enter a value for the memory voltage override. The default is 1200.

QCLK Odd Ratio

If set to Enabled, this feature adds the Memory Reference Clock amount
to the QCLK frequency. The options are Disabled or Enabled.

Note: When the Memory prole feature (above) is set to "Custom
prole" the following memory timings may be manually changed.

The defaults are listed below.

tCL - 14
tRCD/tRP - 14
tRAS - 35
tCWL - 14
tFAW - 23
tREFI - 8316
tRFC - 278
tRRD - 4
tRTP - 8
tWR - 16
tWTR - 0
NMode - 2
tRRD_sg - 6
tRRD_dg - 4
tRDRD_sg - 6
tRDRD_dg - 4
tRDRD_dr - 6
tRDRD_dd - 7
tRDWR_sg - 9

4-13

Supermicro C7Z390-CG-IW Motherboard User’s Manual

tRDWR_dg - 9
tRDWR_dr - 9
tRDWR_dd - 10
tWRRD_sg - 28
tWRRD_dg - 23
tWRRD_dr - 7
tWRRD_dd - 7
tWRWR_sg - 6
tWRWR_dg - 4
tWRWR_dr - 7
tWRWR_dd - 7
tCKE - 6

ODT RTT WR(CHA)

This feature controls ODT RTT WR(CHA). The options are Auto, 0, 80,
120, 240, and 255.

ODT RTT PARK(CHA)

This feature controls ODT RTT PARK(CHA). The options are Auto, 0, 34,
40, 48, 60, 80, 120, and 240.

ODT RTT NOM(CHA)

This feature controls ODT RTT NOM(CHA). The options are Auto, 0, 34,
40, 48, 60, 80, 120, and 240.

ODT RTT WR(CHB)

This feature controls ODT RTT WR(CHB). The options are Auto, 0, 80,
120, 240, and 255.

ODT RTT PARK(CHB)

This feature controls ODT RTT PARK(CHB). The options are Auto, 0, 34,
40, 48, 60, 80, 120, and 240.

ODT RTT NOM(CHB)

This feature controls ODT RTT NOM(CHB). The options are Auto, 0, 34,
40, 48, 60, 80, 120, and 240.

RcompTarget[RdOdt] - 60
RcompTarget[WrDS] - 26
RcompTarget[WrDSCmd] - 20
RcompTarget[WrDSCtl] - 20
RcompTarget[WrDSClk] - 26
SCompDq StageDelayPS - 59
SCompCmd StageDelayPS - 89
SCompCtl StageDelayPS - 53
SCompClk StageDelayPS - 53

4-14

Chapter 4: AMI BIOS

RTLatency_CH0_DIMM0 - 63
RTLatency_CH1_DIMM0 - 63
IOLatency_CH0_DIMM0 - 4
IOLatency_CH1_DIMM0 - 4
DllBwEn[0] - 0
DllBwEn[1] - 1
DllBwEn[2] - 2
DllBwEn[3] - 3

Graphics OverClocking

RC6(Render Standby)

Use this feature to enable Render Standby support. The options are
Disabled or Enabled.

GT OverClocking Frequency

Enter a value for the overclocked RP0 frequency (in multiples of 50 MHz)
in the GT domain. The default is 0.

GT Voltage Mode

This feature controls the voltage mode in the GT domain. The options

are Adaptive or Override.

GT Extra Turbo Voltage

Enter a value for the extra turbo voltage (in mV) that will be applied
while GT is operating in turbo mode. The default is 0.

GT Voltage Offset

Enter a value for the offset voltage (in mV) that will be applied to the
GT domain. The default is 0.

Offset Prex

Use this feature to set the prex value as a positive (+) or a negative
(-). The options are “+” or “-”.

GT OverClocking Frequency

Enter a value for the overclocked RP0 frequency (in multiples of 50 MHz)
in the GT Unslice domain. The default is 0.

GT Voltage Mode

This feature controls the voltage mode in the GT Unslice domain. The

options are Adaptive or Override.

4-15

Supermicro C7Z390-CG-IW Motherboard User’s Manual

GT Extra Turbo Voltage

Enter a value for the extra turbo voltage (in mV) that will be applied
while GT is operating in turbo mode. The default is 0.

GTU Voltage Offset

Enter a value for the offset voltage (in mV) that will be applied to the
GT domain. The default is 0.

Offset Prex

Use this feature to set the prex value as a positive (+) or a negative
(-). The options are “+” or “-”.

Voltage Configuration

System Agent Voltage (mV)

Enter a value for the System Agent voltage (in mV). The default is 1056.

Core Voltage Mode

This feature controls the core voltage mode. The options are Adaptive
or Override.

SVID

This feature enables Serial Voltage Identication (SVID). The options are

Disabled or Enabled.

Core Voltage Override

Enter a value for the Core Voltage Override (in mV). The default is 1350.

Core Voltage Offset

Enter a value for the offset voltage (in mV) that will be applied to the
IA Core domain. The default is 0.

Offset Prex

Use this feature to set the prex value as a positive (+) or a negative
(-). The options are “+” or “-”.

PCH Voltage

Enter a value for the PCH voltage override. The default is 1010.

CPU_IO Voltage

Enter a value for the CPU IO voltage override. The default is 936.

4-16

Chapter 4: AMI BIOS

Load Line Calibration

This feature controls the load line calibration. The options are Disabled,
Level 1, Level 2, Level 3, Level 4, Level 5, Level 6, Level 7, and Auto.

Uncore

Uncore Voltage Offset

Enter a value for the offset voltage (in mV) that will be applied to the
Uncore domain. The default is 0.

Offset Prex

Use this feature to set the prex value as a positive (+) or a negative
(-). The options are “+” or “-”.

Voltage PLL Trim Controls

Core PLL Voltage Offset

Enter a value for the Core PLL voltage offset, with each whole number
equating to 17.5 mV. The range is 0-63. The default is 0.

GT PLL Voltage Offset

Enter a value for the GT PLL voltage offset, with each whole number
equating to 17.5 mV. The range is 0-63. The default is 0.

Ring PLL Voltage Offset

Enter a value for the Ring PLL voltage offset, with each whole number
equating to 17.5 mV. The range is 0-63. The default is 0.

System Agent PLL Voltage Offset

Enter a value for the System Agent PLL voltage offset, with each whole
number equating to 17.5 mV. The range is 0-63. The default is 0.

Memory Controller PLL Voltage Offset

Enter a value for the Memory Controller PLL voltage offset, with each
whole number equating to 17.5 mV. The range is 0-63. The default is 0.

4-17

Supermicro C7Z390-CG-IW Motherboard User’s Manual

4-4 CPU

The following information will be displayed:

• Type - the brand, model name, model number of the CPU and its

rated clock speed

• Speed - the detected CPU speed

• ID - the unique CPU ID

• Stepping - the processor stepping

• Number of Processors - the number of cores detected

• Microcode Revision - the CPU's microcode patch version

• GT Information - the processor's GT Information

• IGFX VBIOS Version - the Integrated Graphics VBIOS version

• IGFX GOP Version - the Integrated Graphics VOP version

• Memory RC Version - the memory RC version

4-18

Chapter 4: AMI BIOS

CPU Conguration

The following information will be displayed:

• Type - the brand, model name, model number of the CPU and its

rated clock speed

• ID - the unique CPU ID

• Speed - the detected CPU speed

• L1 Data Cache - displays if Level 1 cache is supported

• L1 Instruction Cache - displays if Level 1 instruction cache is

supported

• L2 Cache - displays if Level 2 cache is supported

• L3 Cache - displays if Level 3 cache is supported

• VMX - displays if VMX is supported

• SMX/TXT - displays if SMX/TXT is supported

C6DRAM

This feature enables moving DRAM contents to PRM memory when the
CPU is in a C6 state. The options are Disabled or Enabled.

SW Guard Extension (SGX)

Select Enabled to activate the Software Guard Extensions (SGX). The

options are Enabled, Disabled, and Software Controlled.

Select Owner EPOCH input type

There are three Owner EPOCH modes (Each EPOCH is 64 bit). The
options are No Change in Owner EPOCHs, Change to New Random
Owner EPOCH, and Manual User Dened Owner EPOCHs.

Hardware Prefetcher

(Available when supported by the CPU)

If set to Enabled, the hardware prefetcher will prefetch streams of data
and instructions from the main memory to the L2 cache to improve
CPU performance. The options are Disabled or Enabled.

4-19

Supermicro C7Z390-CG-IW Motherboard User’s Manual

Adjacent Cache Line Prefetch

(Available when supported by the CPU)

Select Enabled for the CPU to prefetch both cache lines for 128 bytes
as comprised. Select Disabled for the CPU to prefetch both cache lines
for 64 bytes. The options are Disabled or Enabled.

Intel (VMX) Virtualization Technology

(Available when supported by the CPU)

Select Enabled to use the Intel Virtualization Technology to allow
one platform to run multiple operating systems and applications in
independent partitions, creating multiple "virtual" systems in one
physical computer. The options are Disabled or Enabled.

Note: If there is any change to this setting, you will need to

power off and reboot the system for the change to take effect.
Please refer to Intel’s web site for detailed information.

Active Processor Cores

Use this feature to select the number of active processor cores. The
options depend on how many cores are supported by the CPU. The

default is All.

BIST

Select Enabled to activate the Built-In Self Test (BIST) on reset. The

options are Disabled or Enabled.

AES

Select Enable for Intel CPU Advanced Encryption Standard (AES) In­structions support to enhance data integrity. The options are Disabled
or Enabled.

Machine Check

Select Enable to activate Machine Check. The options are Disabled

or Enabled.

MonitorMWait

Select Enable to activate MonitorMWait. The options are Disabled or

Enabled.

FCLK Frequency for Early Power On

Select the FCLK frequency for early power on. The options are Normal
(800MHz), 1GHz, and 400MHz.

4-20

Chapter 4: AMI BIOS

Power & Performance

CPU - Power Management Control

Boot Performance Mode

This feature enables the selection of the default CPU performance
during system boot. The options are Max Non-Turbo Perfor-

mance, Max Battery, and Turbo Performance.

Intel(R) SpeedStep(tm)

Intel SpeedStep Technology allows the system to automatically
adjust processor voltage and core frequency in an effort to reduce
power consumption and heat dissipation. Please refer to Intel’s

website for detailed information. The options are Disabled or
Enabled.

C States

C-States architecture, a processor power management platform
developed by Intel, can further reduce power consumption from
the basic C1 (Halt State) state that blocks clock cycles to the CPU.

Select Enabled for CPU C State support. The options are Disabled
or Enabled. If this feature is set to Enabled, the following features
will display:

Enhanced C-states

(Available when "C States" is set to Enabled)

Select Enabled to enable Enhanced C1 Power State to boost system
performance. The options are Disabled or Enabled.

C-State Auto Demotion

When this feature is enabled, the CPU will conditionally demote C
State based on un-cored auto-demote information. The options are
Disabled, C1, C3, and C1 and C3.

C-State Un-demotion

When this feature is enabled, the CPU will conditionally undemote
from demoted C3 or C1. The options are Disabled, C1, C3, and C1

and C3.

4-21

Supermicro C7Z390-CG-IW Motherboard User’s Manual

Package C-State Demotion

This feature enables the Package C-State demotion. The options

are Disabled or Enabled.

Package C-State Un-Demotion

When this feature is enabled, the CPU will conditionally undemote
from demoted Packaged Package C-State Un-Demotion. The options

are Disabled or Enabled.

CState Pre-Wake

This feature to enables C-State pre-wake. The options are Disabled

or Enabled.

IO MWAIT Redirection

When enabled, this feature will map and send the IO read instruc­tions to the IO registers. The options are Disabled or Enabled.

Package C State Limit

Select Auto for the AMI BIOS to automatically set the limit on the
C-State package register. The options are C0, C2, C3, C6, C7, C7s,

and Auto.

Package C State Workaround

This feature enables a workaround for Package C State 6/7. The

options are Disabled or Enabled.

GT-Power Management

RC6(Render Standby)

Use this feature to enable Render Standby support. The options are
Disabled or Enabled.

Maximum GT Frequency

This feature is the Maximum GT Frequency as dened by the user.
Choose between 300MHz (RPN) and 1200MHz (RP0). Any value
beyond this range will be clipped to its min/max supported by the
CPU. The options are Default Max Frequency, 100MHz~1200MHz
(in increments of 50MHz).

4-22

Chapter 4: AMI BIOS

Disable Turbo GT frequency

This feature disables Turbo GT frequency. If set to Enabled, Turbo
GT frequency becomes disabled. If set to Disabled, GT frequency
limiters will be removed.

4-23

Supermicro C7Z390-CG-IW Motherboard User’s Manual

4-5 Memory

The following information will be displayed:

• Memory RC Version

• Memory Frequency

• Memory Timings (tCL-tRCD-tRP-tRAS)

• DIMM#A1, DIMM#B1

Maximum Memory Frequency

This feature controls the speed of the memory installed. The options are
1333, 1600, 1867, 2133, 2400, 2667, 2933, and 3200. All values are in
MHz. Default speed is auto detected.

Memory Scrambler

This feature enables memory scrambler support for memory error cor­rection. The settings are Disabled or Enabled.

Force ColdReset

Use this feature when ColdBoot is required during MRC execution. The

settings are Disabled or Enabled.

4-24

Chapter 4: AMI BIOS

Force Single Rank

When enabled, only Rank0 will be use in each DIMM. The settings are

Disabled or Enabled.

Memory Remap

PCI memory resources will overlap with the total physical memory if 4GB
of memory or above is installed on the motherboard. When this occurs,
Enable this function to reallocate the overlapped physical memory to a
location above the total physical memory to resolve the memory overlap-

ping situation. The options are Disabled or Enabled.

MRC Fast Boot

This feature enables fast path through MRC. The settings are Disabled
or Enabled.

4-25

Supermicro C7Z390-CG-IW Motherboard User’s Manual

4-6 Advanced

Setup Mode

This feature sets the default screen that displays after entering Setup
Mode. The options are EZ Mode or Advanced Mode.

Boot Feature

Fast Boot

This feature enables the system to boot with a minimal set of required

devices to launch. This has no effect on BBS boot options. The options
are Disabled or Enabled.

Quiet Boot

Use this feature to enable quiet boot. The default is Enabled.

Bootup Num-Lock

Use this feature to set the Power-on state for the <Numlock> key. The

options are Off and On.

Wait for "F1" If Error

Use this feature to force the system to wait until the "F1" key is pressed

if an error occurs. The options are Disabled or Enabled.

4-26

Chapter 4: AMI BIOS

Re-try Boot

If this feature is enabled, the BIOS will automatically reboot the system
from a specied boot device after its initial boot failure. The options are

Disabled, Legacy Boot, and EFI Boot.

Watch Dog Function

If enabled, the Watch Dog Timer will allow the system to reset or gen­erate NMI based on jumper settings when it is expired for more than
ve minutes. The options are Disabled or Enabled.

AC Loss Policy Depend On

Use this feature to set the power state after a power outage. Select

Stay Off for the system power to remain off after a power loss. Se­lect Power On for the system power to be turned on after a power
loss. Select Last State to allow the system to resume its last power

state before a power loss. The options are Stay Off, Power On,
and Last State.

Power Button Function

This feature controls how the system shuts down when the power but­ton is pressed. Select 4 Seconds Override for the user to power off the
system after pressing and holding the power button for four seconds or
longer. Select Instant Off to instantly power off the system as soon as

the user presses the power button. The options are Instant Off or 4
Seconds Override.

DeepSx Power Policies

Use this feature to congure the Advanced Conguration and Power
Interface (ACPI) settings for the system. Enable S5 to power off the
whole system except the power supply unit (PSU) and keep the power
button “alive” so that the user can “wake up” the system by using a USB
keyboard or mouse. The options are Disabled or Enabled.

Install Windows 7 USB Support

Enable this feature to use the USB keyboard and mouse during the Win­dows 7 installation since the native XHCI driver support is unavailable.
Use a SATA optical drive as a USB drive. USB CD/DVD drives are not
supported. Disable this feature after the XHCI driver has been installed

in Windows. The options are Disabled and Enabled.

RGB Led Control

This feature enables RGB LED controls. The options are Disabled or

Enabled.

4-27

Supermicro C7Z390-CG-IW Motherboard User’s Manual

NCT6792D Super IO Configuration

Serial Port 1 Conguration

Serial Port

This feature enalbes Serial Port 1 (COM1). Click the toggle box to en­able or disable Serial Port 1. The default is Enabled.

Device Settings

This feature displays the current IRQ setting for Serial Port 1 (COM1).

The default is Auto.

Change Settings

This feature congures the IRQ setting for Serial Port 1 (COM1).

The options for Serial Port 1 are Auto, "IO=3F8h; IRQ=4", "IO=3F8h;
IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12", "IO=2F8h; IRQ=3, 4, 5, 6, 7, 9, 10,
11, 12", "IO=3E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12", and "IO=2E8h;
IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12".

Serial Port Console Redirection

COM 1

Console Redirection

This feature enables COM Port 1 Console Redirection, which will allow
a client machine to be connected to a host machine at a remote site
for networking. Click the toggle box to enable or disable. The default is

Disabled.

*If the feature above is set to Enabled, the following features will become
available for conguration:

Console Redirection Settings

Terminal Type

This feature allows the user to select the target terminal emulation
type for Console Redirection. Select VT100 to use the ASCII Character
set. Select VT100+ to add color and function key support. Select ANSI
to use the Extended ASCII Character Set. Select VT-UTF8 to use UTF8
encoding to map Unicode characters into one or more bytes. The op-

tions are ANSI, VT100, VT100+, and VT-UTF8.

4-28

Chapter 4: AMI BIOS

Bits per second

Use this feature to set the transmission speed for a serial port used
in Console Redirection. Make sure that the same speed is used in the
host computer and the client computer. A lower transmission speed
may be required for long and busy lines. The options are 9600, 19200,
38400, 57600, and 115200 (bits per second).

Data Bits

Use this feature to set the data transmission size for Console Redirec­tion. The options are 7 (Bits) or 8 (Bits).

Parity

A parity bit can be sent along with regular data bits to detect data

transmission errors. Select Even if the parity bit is set to 0, and the
number of 1's in data bits is even. Select Odd if the parity bit is set
to 0, and the number of 1's in data bits is odd. Select None if you
do not want to send a parity bit with your data bits in transmission.
Select Mark to add a mark as a parity bit to be sent along with the

data bits. Select Space to add a Space as a parity bit to be sent with
your data bits. The options are None, Even, Odd, Mark, and Space.

Stop Bits

A stop bit indicates the end of a serial data packet. Select 1 Stop Bit
for standard serial data communication. Select 2 Stop Bits if slower

devices are used. The options are 1 or 2.

Flow Control

Use this feature to set the ow control for Console Redirection to pre­vent data loss caused by buffer overow. Send a "Stop" signal to stop
sending data when the receiving buffer is full. Send a "Start" signal
to start sending data when the receiving buffer is empty. The options

are None or Hardware RTS/CTS.

VT-UTF8 Combo Key Support

Select Enabled to enable VT-UTF8 Combination Key support for ANSI/
VT100 terminals. Click the toggle box to enable or disable. The default

is Enabled.

Recorder Mode

Select Enabled to capture the data displayed on a terminal and send
it as text messages to a remote server. Click the toggle box to enable

or disable. The default is Disabled.

4-29

Supermicro C7Z390-CG-IW Motherboard User’s Manual

Resolution 100x31

Select Enabled for extended-terminal resolution support. Click the

toggle box to enable or disable. The default is Enabled.

Legacy OS Redirection Resolution

Use this feature to select the number of rows and columns used in

Console Redirection for legacy OS support. The options are 80x24

or 80x25.

Putty KeyPad

This feature selects Function Keys and KeyPad settings for Putty, which
is a terminal emulator designed for the Windows OS. The options are

VT100, LINUX, XTERMR6, SCO, ESCN, and VT400.

Redirection After BIOS POST

Use this feature to enable or disable legacy Console Redirection after
BIOS POST. When the option Bootloader is selected, legacy Console
Redirection is disabled before booting the OS. When the option Always

Enable is selected, legacy Console Redirection remains enabled upon

OS bootup. The options are Always Enable or Bootloader.

EMS Console Redirection

Select Enabled to use a COM port selected by the user for EMS Console

Redirection. Click the toggle box to enable or disable. The default is

Disabled.

*If the feature above set to Enabled, the following features will become
available for user conguration:

Console Redirection Settings

Out-of-Band Mgmt Port

The feature selects a serial port in a client server to be used by the

Windows Emergency Management Services (EMS) to communicate
with a remote host server. The options are dependent on the avail-

able COM ports.

4-30

Chapter 4: AMI BIOS

Terminal Type

Use this feature to select the target terminal emulation type for Con­sole Redirection. Select VT100 to use the ASCII character set. Select
VT100+ to add color and function key support. Select ANSI to use the
extended ASCII character set. Select VT-UTF8 to use UTF8 encoding
to map Unicode characters into one or more bytes. The options are
ANSI, VT100, VT100+, and VT-UTF8.

Bits per second

This feature sets the transmission speed for a serial port used in Con­sole Redirection. Make sure that the same speed is used in both host
computer and the client computer. A lower transmission speed may
be required for long and busy lines. The options are 9600, 19200,
57600, and 115200 (bits per second).

Flow Control

Use this feature to set the ow control for Console Redirection to pre­vent data loss caused by buffer overow. Send a "Stop" signal to stop
data sending when the receiving buffer is full. Send a "Start" signal
to start data sending when the receiving buffer is empty. The options

are None, Hardware RTS/CTS, and Software Xon/Xoff.

The setting for each these features is displayed:

Data Bits
Parity
Stop Bits

System Agent (SA) Configuration

The following information will be displayed:

• SA PCIe Code Version

• VT-d Capability

PEG Port Conguration

CPU SLOT7 PCI-E 3.0 X16

Enable Root Port

Select Enable to activate the Root Port. The options are Disabled,
Enabled, and Auto.

4-31

Supermicro C7Z390-CG-IW Motherboard User’s Manual

Max Link Speed

Select Auto, Gen1, Gen2, or Gen3 to set the PEG Max Link Speed.

VT-d

This feature enables VT-d. The options are Disabled or Enabled.

GNA Device (B0:D8:F0)

This feature enables the SA GNA device. The options are Disabled or

Enabled.

X2APIC Opt Out

This feature enables X2APIC Opt Out. The options are Disabled or
Enabled.

Graphics Configuration

Graphics Turbo IMON Current

Use this feature to set the limit on the current voltage regulator. Valid
range is 14-31. Default is 31.

Skip Scanning of External Gfx Card

Use this feature to scan for External Gfx Card on PEG and PCH PCIE Ports.
If this feature is enabled, the system will not scan for a new card. The

options are Disabled or Enabled.

Primary Display

Use this feature to select the graphics device to be used as the primary
display. Select from IGFX/PEG/PCI or select SG for switchable GFX. The

options are Auto, IGFX, PEG, PCIE, and SG.

External Gfx Card Primary Display Conguration

Primary PEG

This feature allows the user to select the primary PCI Express Graphics
(PEG) slot. The options are Auto, PEG11, and PEG12.

Primary PCIE

This feature allows the user to specify which graphics card to be

used as the primary graphics card. The options are Auto and PCIE1
~ PCIE19.

4-32

Chapter 4: AMI BIOS

Internal Graphics

This feature keeps the Internal Graphics Device (IGD) enabled, based

on setup options. The options are Auto, Enabled, and Disabled.

GTT Size

Use this feature to set the memory size to be used by the graphics
translation table (GTT). The options are 2MB, 4MB, and 8MB.

Aperture Size

Use this feature to set the Aperture size, which is the size of system
memory reserved by the BIOS for graphics device use. The options are
128MB, 256MB, 512MB, 1024MB, and 2048MB.

DVMT Pre-Allocated

Dynamic Video Memory Technology (DVMT) allows dynamic allocation
of system memory to be used for video devices to ensure best use of
available system memory based on the DVMT 5.0 platform. The options
are 0M, 32M, 64M, 4M, 8M, 12M, 16M, 20M, 24M, 28M, 32M/F7, 36M,
40M, 44M, 48M, 52M, 56M, and 60M.

DVMT Total Gfx Mem

Use this feature to set the total memory size to be used by internal graph­ics devices based on the DVMT 5.0 platform. The options are 128MB,

256MB, and MAX.

VDD Enable

Activating this feature will force VDD in the BIOS. The options are Dis­abled or Enabled.

PM Support

This feature enables PM support. The options are Disabled or Enabled.

PAVP Enable

This feature enables PAVP support. The options are Disabled or Enabled.

Cdynmax Clamping Enable

This feature enables Cdynmax Clamping. The options are Disabled or

Enabled.

4-33

Supermicro C7Z390-CG-IW Motherboard User’s Manual

Graphics Clock Frequency

This feature controls the graphics clock frequency. Select the highest
clock frequency supported by the platform. The options are 337.5 Mhz,
450 Mhz, 540 Mhz, and 675 Mhz.

Skip CD Clock Init in S3 resume

This feature enables skipping the full CD clock initialization. If set to
Disabled, the full CD clock will initialize. The options are Disabled or

Enabled.

PCH-IO Configuration

HD Audio

Use this feature to detect an HD Audio device. The options are Disabled,

Enabled, and Auto.

Wake on LAN Enable

Select Enabled to enable the capabiltiy to "wake up" the system through

the Ethernet port. The settings are Disabled or Enabled.

PCIE PLL SSC

Use this feature to set the PCIE PII SSC percentage. Select Auto to

keep the hardware default with no BIOS override. The range is from

0.0% to 2.0%.

DMI Link ASPM Control

Use this feature to set the ASPM (Active State Power Management)
state on the SA (System Agent) side of the DMI Link. The options are

Disabled or Enabled.

ASPM 5/7/8/9/10/11/16/18/19/20

Use this feature to set the Active State Power Management (ASPM) to
power manage the PCIe link during the various L states. The options are

Auto, L0sL1, L1, L0s, and Disabled.

L1 Substates

Use this feature to dene which L1 substate to use. The options are
Disabled, L1.1, L1.2, and L1.1&L1.2.

4-34

Chapter 4: AMI BIOS

SATA and RST Configuration

SATA Controllers

Select Disabled to disable the onboard SATA Controllers. The settings
are Disabled or Enabled.

SATA Mode Selection

This feature selects the mode for the installed SATA drives. The options

are AHCI or Intel RST Premium.

Aggressive LPM Support

This feature enables the PCH to aggressively enter link power state. The

options are Disabled or Enabled.

Storage Option ROM/UEFI Driver

This feature controls the execution of UEFI and Legacy Storage OpROM.
The options are Do not launch, UEFI, and Legacy.

Serial ATA Port0~5

This feature dispays the detected SATA drive, if any.

Hot Plug

This feature designates the port specied for hot plugging. Set this fea­ture to Enabled for hot-plugging support, which will allow the user to

replace a SATA disk drive without shutting down the system. The options

are Disabled or Enabled.

Spin Up Device

When this feature is disabled, all drives will spin up at boot. When this

feature is enabled, it will perform Staggered Spin Up on any drive this

feature is activated. The settings are Disabled or Enabled.

SATA Device Type

Use this feature to identify the type of HDD that is connected to the SATA

port. The options are Hard Disk Drive or Solid State Drive.

PCH FW Configuration

The following information will be displayed:

• ME Firmware Version

• ME Firmware Mode

4-35

Supermicro C7Z390-CG-IW Motherboard User’s Manual

• ME Firmware SKU

ME FW Image Re-Flash

This feature will update the PCH Firmware from an image in a USB ash

drive attached to a USB port. The options are Disabled or Enabled.

USB Configuration

The following information will be displayed:

• USB Module Version

• USB Controllers

• USB Devices

Legacy USB Support

Select Enabled to support legacy USB devices. Select Auto to disable
legacy support when legacy USB devices are not present. If Disable
is selected, legacy USB devices will not be supported. The options are
Disabled, Enabled, and Auto.

XHCI Hand-Off

This feature is a work-around solution for operating systems that do not
support XHCI (Extensible Host Controller Interface) hand-off. The XHCI
ownership change should be claimed by the XHCI driver. The settings

are Disabled or Enabled.

USB Mass Storage Driver Support

Set Enabled to enable USB mass storage driver support. The options are

Disabled or Enabled.

Port 60/64 Emulation

This feature enables I/O port 60h/64h emulation for legacy USB keyboard
support on non-USB aware operating systems. The options are Disabled

or Enabled.

Connectivity Configuration

CNVi WiFi&BT

This feature controls the connectivity mode. Selecting Enable enables WiFi

& Bluetooth support. The options are Disabled or Enabled.

4-36
