Supero C2SBA+II, C2SBA+, C2SBE User Manual

C2SBA+II
C2SBA+
C2SBA
C2SBE

USER’S MANUAL

Revision 1.0a

The information in this User’s Manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
makes no commitment to update or to keep current the information in this manual, or to notify any
person or organization of the updates. Please Note: For the most up-to-date version of this

manual, please see our web site at www.supermicro.com.

SUPER MICRO COMPUTER reserves the right to make changes to the product described in this
manual at any time and without notice. This product, including software, if any, and documenta­tion may not, in whole or in part, be copied, photocopied, reproduced, translated or reduced to any
medium or machine without prior written consent.

IN NO EVENT WILL SUPER MICRO COMPUTER BE LIABLE FOR DIRECT, INDIRECT, SPECIAL,
INCIDENTAL, SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE
OR INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER MICRO COMPUTER SHALL NOT
HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE
PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING
OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between manufacturer and customer shall be governed by the laws of Santa
Clara County in the State of California, USA. The State of California, County of Santa Clara shall
be the exclusive venue for the resolution of any such disputes. Super Micro's total liability for all
claims will not exceed the price paid for the hardware product.

FCC Statement: This equipment has been tested and found to comply with the limits for a Class B
digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
manufacturer’s instruction manual, may cause interference with radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, you are encouraged to try to correct the interference by one or more of
the following measures:
*Reorient or relocate the receiving antenna.
*Increase the separation between the equipment and the receiver.
*Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
*Consult the dealer or an experienced radio/television technician for help.

California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate
warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate
Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”.

WARNING: Handling of lead solder materials used in this
product may expose you to lead, a chemical known to
the State of California to cause birth defects and other
reproductive harm.

Manual Revision: Rev. 1.0a
Release Date: Aug. 14, 2007

Unless you request and receive written permission from SUPER MICRO COMPUTER, you may not
copy any part of this document.

Information in this document is subject to change without notice. Other products and companies
referred to herein are trademarks or registered trademarks of their respective companies or mark
holders.

Copyright © 2007 by SUPER MICRO COMPUTER INC.
All rights reserved.

Printed in the United States of America

Preface

Preface

About This Manual

This manual is written for system integrators, PC technicians and

knowledgeable PC users. It provides information for the installation and use of the

C2SBA+II/C2SBA+/C2SBA/C2SBE motherboard. The C2SBA+II/C2SBA+/

C2SBA/C2SBE supports single Intel Xeon 3000 Series/Core 2 Quad/Core 2 Duo

Processor with a system bus speed of 1.33 GHz or 1.066 GHz. The Intel Core 2

Quad/Core 2 Duo Processor supports the 775-Land Grid Array Package, which

interfaces with the motherboard via an LGA775 socket. With the support of the

Quad-Core/Dual-Core Technology, the Hyper-Threading (HT) Technology, Wide

Dynamic Execution, FSB Dynamic Bus Inversion (DBI), Advanced Digital Media

Boost, Smart Memory Access, and Thermal Management 2 (TM2), the C2SBA+II/

C2SBA+/C2SBA/C2SBE delivers unparalleled system performance and great power

effi ciency in a slim package. Please refer to the motherboard specifi cations pages

on our web site (http://www.supermicro.com/Products/) for updates on supported

processors. This product is intended to be professionally installed.

Manual Organization

Chapter 1 describes the features, specifi cations and performance of the mainboard

and provides detailed information about the chipset.

Chapter 2 provides hardware installation instructions. Read this chapter when

installing the processor, memory modules and other hardware components into

the system.

If you encounter any problems, see Chapter 3, which describes troubleshooting

procedures for the video, the memory and the system setup stored in CMOS.

Chapter 4 includes an introduction to BIOS and provides detailed information on

running the CMOS Setup utility.

Appendix A provides BIOS POST Messages.

Appendix B lists BIOS POST Codes.

Appendix C provides Software Installation Instructions.

Conventions Used in the Manual:

Special attention should be given to the following symbols for proper installation and
to prevent damage done to the components or injury to yourself:

Danger/Caution: Instructions to be strictly followed to prevent catastrophic

system failure or to avoid bodily injury.

Warning: Important information given to ensure proper system installation or

to prevent damage to the components.

Note: Additional Information given to differentiate various models or to ensure cor-

rect system setup.

iii

C2SBA+II/C2SBA+/C2SBA/C2SBE User’s Manual

Table of Contents

About This Manual ...................................................................................................... iii

Manual Organization ....................................................................................................iii

Conventions Used in the Manual .................................................................................. iii

Chapter 1: Introduction

1-1 Overview ......................................................................................................... 1-1

Checklist ..................................................................................................... 1-1

Contacting Super Micro .............................................................................. 1-2

C2SBA+II/C2SBA+/C2SBA/C2SBE Image ............................... 1-3

C2SBA+II/C2SBA+/C2SBA/C2SBE Layout ................................ 1-4

C2SBA+II/C2SBA+/C2SBA/C2SBE Quick Reference ................ 1-5

Motherboard Features .............................................................................. 1-7

Intel G33/P35 Chipset: System Block Diagram ......................................... 1-9

1-2 Chipset Overview ......................................................................................... 1-10

1-3 Recovery from AC Power Loss .................................................................... 1-11

1-4 PC Health Monitoring ................................................................................... 1-11

1-5 ACPI Features .................................................................................................1-11

1-6 Power Supply ............................................................................................... 1-12

1-7 Versatile Media Capabilities ........................................................................... 1-13

1-8 Super I/O ...................................................................................................... 1-13

Chapter 2: Installation

2-1 Static-Sensitive Devices ................................................................................. 2-1

2-2 Motherboard Installation .................................................................................. 2-1

2-3 Processor and Heatsink Installation ............................................................... 2-2

2-4 Installing DDR2 Memory ................................................................................ 2-6

2-5 Control Panel Connectors/IO Ports ................................................................. 2-8

A. Back Panel Connectors/IO Ports ................................................................. 2-8

B. Front Control Panel ...................................................................................... 2-9

C. Front Control Panel Pin Defi nitions ........................................................... 2-10

PWR LED ............................................................................................... 2-10

HDD LED ................................................................................................. 2-10

NIC1 LED Indicators .............................................................................. 2-11

OH/Fan Fail LED ......................................................................................2-11

Reset Button ............................................................................................ 2-12

PWR Button ............................................................................................. 2-12

2-6 Connecting Cables ....................................................................................... 2-13

ATX/Auxiliary Power Connectors ........................................................... 2-13

Universal Serial Bus (USB) ..................................................................... 2-14

iv

Table of Contents

Chassis Intrusion .................................................................................... 2-14

Fan Headers ............................................................................................. 2-15

VGA Connector ........................................................................................ 2-15

ATX PS/2 Keyboard and PS/2 Mouse Ports ............................................ 2-16

Serial Ports ............................................................................................... 2-16

Wake-On-Ring ......................................................................................... 2-17

Wake-On-LAN .......................................................................................... 2-17

GLAN1 Port .............................................................................................. 2-18

Speaker Connector .................................................................................. 2-18

High Defi nition Audio (HDA) ..................................................................... 2-19

CD Header/Auxiliary Audio Header .......................................................... 2-19

Front Panel Audio Control ........................................................................ 2-20

Power LED ............................................................................................... 2-20

2-7 Jumper Settings ............................................................................................ 2-21

Explanation of Jumpers ......................................................................... 2-21

GLAN Enable/Disable .............................................................................. 2-21

CMOS Clear ........................................................................................... 2-22

Watch Dog Enable ................................................................................... 2-22

CPU Front Side Speed ............................................................................ 2-23

PCI/PCI-Exp. Slots to SMB Speeds ......................................................... 2-23

IDE Enable/Disable .................................................................................. 2-24

TPM Enable .............................................................................................. 2-24

Audio Enable ............................................................................................ 2-25

Keyboard Wake-Up .................................................................................. 2-25

USB Wake-Up .......................................................................................... 2-26

2-8 Onboard Indicators ....................................................................................... 2-27

GLAN LED Indicators ............................................................................... 2-27

Onboard Power LED ................................................................................ 2-28

2-9 Parallel Port, Floppy Drive and IDE Hard Drive Connections ..................... 2-29

Parallel Port Connector ............................................................................ 2-29

Floppy Connector .................................................................................... 2-30

IDE Connectors ........................................................................................ 2-31

Chapter 3: Troubleshooting

3-1 Troubleshooting Procedures ........................................................................... 3-1

Before Power On ....................................................................................... 3-1

No Power ................................................................................................... 3-1

No Video .................................................................................................. 3-1

Memory Errors ........................................................................................... 3-2

Losing the System’s Setup Confi guration ................................................ 3-2

v

C2SBA+II/C2SBA+/C2SBA/C2SBE User’s Manual

3-2 Technical Support Procedures ....................................................................... 3-2

3-3 Frequently Asked Questions .......................................................................... 3-3

3-4 Returning Merchandise for Service ................................................................. 3-4

Chapter 4: BIOS

4-1 Introduction ....................................................................................................... 4-1

4-2 Running Setup ................................................................................................. 4-2

4-3 Main BIOS Setup ............................................................................................. 4-2

4-4 Advanced Setup ............................................................................................... 4-7

4-5 Security Setup ............................................................................................... 4-21

4-6 TPM State ....................................................................................................... 4-23

4-7 Boot Setup ...................................................................................................... 4-24

4-8 Exit .................................................................................................................. 4-25

Appendices:

Appendix A: BIOS POST Messages ......................................................................... A-1

Appendix B: BIOS POST Codes ................................................................................B-1

Appendix C: Intel HostRAID Setup Guidelines ..........................................................C-1

Appendix D: Software Installation Instructions ...........................................................D-1

vi

Chapter 1: Introduction

Chapter 1

Introduction

1-1 Overview

Checklist

Congratulations on purchasing your computer motherboard from an acknowledged

leader in the industry. Super Micro boards are designed with the utmost attention

to detail to provide you with the highest standards in quality and performance.

Please check that the following items have all been included with your motherboard.

If anything listed here is damaged or missing, contact your retailer.

All Included in the Retail Box Only

One (1) Super Micro Mainboard

One (1) fl oppy drive ribbon cable (CBL-022L)

Four (4) SATA cables (CBL-0044L) (*For C2SBA+/C2SBA/C2SBE)

Six (6) SATA cables (CBL-0044L) (*For the C2SBA+II only)

Two (2) IDE hard drive cables (CBL-0036L-3) (*C2SBA+II/C2SBA+ Only)

One (1) USB cable (CBL-041)

One (1) Super Micro CD containing drivers and utilities

One (1) User's/BIOS Manual

1-1

C2SBA+II/C2SBA+/C2SBA/C2SBE User’s Manual

Contacting Super Micro

Headquarters

Address: Super Micro Computer, Inc.

980 Rock Ave.

San Jose, CA 95131 U.S.A.

Tel: [phone]

Fax: [phone]

Email: [e-mail] (General Information)

[e-mail] (Technical Support)

Web Site: www.supermicro.com

Europe

Address: Super Micro Computer B.V.

Het Sterrenbeeld 28, 5215 ML

's-Hertogenbosch, The Netherlands

Tel: [phone]

Fax: [phone]

Email: [e-mail] (General Information)

[e-mail] (Technical Support)

[e-mail] (Customer Support)

Asia-Pacifi c

Address: Super Micro, Taiwan

4F, No. 232-1 Liancheng Road

Chung-Ho 235, Taipei Hsien, Taiwan, R.O.C.

Tel: [phone]

Fax: [phone]

Web Site: www.supermicro.com.tw

Technical Support:

Email: [e-mail]

Tel: [phone], ext.132 or 139

1-2

Chapter 1: Introduction

C2SBA+II/C2SBA+/C2SBA/C2SBE Image

Note: All pictures and drawings shown in this manual were based upon the latest

PCB revision available at the time of publishing of the manual. The motherboard

you've received may or may not look exactly the same as those in this manual.

1-3

C2SBA+II/C2SBA+/C2SBA/C2SBE User’s Manual

Motherboard Layout

KB/MOUSE

J28

COM1

J31

VGA

J30

JG1

USB

3/4/5/6

J43

USB 1/2

J11

Audio

J46

JKB

Parallel Port

LAN

Fan5

GLAN CTRL

J41

4-Pin PWR

JFSB2

JFSB1

JPUSB1

Slot7 PCI-E x1

J1

J7

Processor

JFSB3

Slot6 PCI-E x16

Intel G33

North Bridge

CPU Fan

FAN1

DIMM1A

DIMM1

FAN2

DIMM1B

DIMM2A

DIMM2

DIMM3

S I/O

W83627DHG

24-pin ATX PWR

DIMM2B

J40

Floppy

J27

DIMM4

Audio CTRL

JP5

CD-IN

CD1

J8

PCI4

Audio Enabled

PCI3

Slot5 PCI-E x4

JI2C1
JI2C2

Slot4 PCI-33MHz

Slot3 PCI-33MHz

JWOR

BIOS

JPL1

JP2

JRTC1
JRTC2

Intel ICH9

South Bridge

C2SBA

PCI2

J12
Front Audio

PCI1

COM2

J13

(*Please see important notes on Page 1-6.)

Slot2 PCI-33MHz

Slot1 PCI-33MHz

J9
Speaker

Buzzer

SPKR1

IDE CTRL

ITE 8212

WO

WOL

JPUSB2

JS3

JS4

JS1

JS2

J44

FP USB 7/8

J48

J10

J3

I-SATA2

I-SATA3

I-SATA0

I-SATA1

J45

FP USB 9/10

Front-Access USB 11Front-Access USB 12

IDE#2

IDE#1

I-SATA4

I-SATA5

J47

Battery

JP3
JWD
JLED

JS5

JS6

LE1

JF1

JL1

FAN3

FAN4

Front Panel CTRL

1-4

Chapter 1: Introduction

C2SBA+II/C2SBA+/C2SBA/C2SBE Quick Reference

Jumpers Description Default Setting

JRTC1/JRTC2 CMOS Clear Pins 1-2/Pins 1-2 (Normal)

JFSB1/JFSB2/JFSB3 CPU Frequency Pins 1-2/Pins 1-2/Pins 1-2 (Auto)

JKB Keyboard Enabled Pins 1-2 (Enabled)

JI2C1/JI2C2 SMB to PCI Slots Open/Open (Disabled)

JP2 ITE IDE Enabled Pins 1-2 (Enabled) (*See Note 4)

JP3 TPM Enabled Pins 1-2 (Enabled) (*See Note 6)

JP5 Audio Enabled Pins 1-2 (Enabled)

JPL1 Giga-bit LAN Enab. Pins 1-2 (Enabled)

JPUSB1 B/P USB Wake Up Pins 2-3 (Disabled)

JPUSB2 F/P USB Wake Up Pins 2-3 (Disabled)

JWD Watch Dog Enable Pins 1-2 (Reset)

Connectors Description

CD1 Audio CD Input (CD-In) Header

DIMM#1A,#2A,#1B,#2B Memory (DIMM) Slots (1 through 4)

Fans 1-5 Fan1: CPU Fan, Fan2-5: System/Chassis Fan Headers

IDE#1/IDE#2 IDE Hard Drive #1 & Hard Drive #2 (*See Note 4)

J9 Speaker Header

J11 (Back Panel) Universal Serial Ports 1-2/G-LAN Port

J12 Front Panel Audio Connector

J27 Floppy Disk Connector

J28 PS/2 Keyboard/Mouse

J30 Parallel Printer Port

J31, J13 COM Port/Serial Port 1 & Port 2 Connectors

J40 ATX 24-Pin Power Connector

J41 12V 4-pin Power Connector (*required connection)

J43 (Back Panel) Universal Serial Ports 3-6

J44, J45 (Front Panel) USB ports 7/8 (J44), USB 9/10 (J45)

J46 Audio Port

47, J48 Front-Accessible USB ports #11 (J47), USB #12 (J48)

JF1 Front Control Panel Header

JG1 Video/Graphics Connector (*See Note 7)

JL1 Chassis Intrusion Header

JLED Onboard Power LED Indicator

JS1/JS2/JS5/JS6 Intel SATA (#0/1/4/5) Headers (*See Note 8)

JWOR Wake-On-Ring Header

LE1 Standby Power LED Indicator

Slot 1-Slot 4 PCI 33 MHz (PCI #1-#4) (*See Note 5)

Slots 5-7 PCI-E x4 (Slot5), PCI-E x16 (Slot6), PCI-Ex1 (Slot7)

WOL Wake-On-LAN Header

(*All notes indicated above are listed on Page 1-6.)

1-5

C2SBA+II/C2SBA+/C2SBA/C2SBE User’s Manual

Important Notes to the User

• 1. Jumpers not indicated are for testing only.

• 2. See Chapter 2 for detailed information on CPU/Heatsink installation, memory

population, jumpers, connectors, I/O ports and JF1 front panel connections.

• 3. " " indicates the location of "Pin 1.'

• 4. IDE is available on the C2SBA/C2SBA+/C2SBA+II only.

• 5. PCI Slot 4 is not available on the C2SBA+/C2SBA+II.

• 6. Trusted Platform Module (TPM) support is available on the C2SBA and

C2SBA+II/C2SBA+ only.

• 7. VGA is not available on the C2SBE.

• 8. The ICH9R and SATA Ports 2 & 3 (JS3/4) are available on the C2BA+II.

• 9. G33 is available on the C2SBA/C2SBA+II/C2SBA+. P35: is available on the

C2SBE only.

Overclocking Considerations

Warning: Please be aware of the following conditions when "overclock-

ing" is used:

Setting a high CPU FSB Speed (overclocking), DRAM Frequency or selecting a

high CPU V-Core voltage, memory voltage, chipset voltage, ICH chipset voltage,

or the FSB termination voltage may result in system instability. If this occurs, revert

the setting to the default setting. In addition, extra fans may be needed for proper

system cooling. The C2SBA+II/C2SBA+/C2SBA/C2SBE offers the option of "over-

clocking"; however, Super Micro is not responsible for any damage caused by the

use of overclocking.

1-6

Chapter 1: Introduction

Motherboard Features

CPU  Latest CPU technology!

• Single Intel Xeon 3000 Series/Core 2 Quad/Core 2 Duo Processor with a system

bus speed of 1.33 GHz/1.066 GHz

• Supports Intel Dual Core Technology, Hyper-Threading, Wide Dynamic Execu-

, FSB Dynamic Bus Inversion (DBI), Advanced Digital Media Boost, Smart

tion

Memory Access, and Thermal Management 2 (TM2)

Memory  Latest memory technology!

• Supports unbuffered single or dual channel Non ECC Unbuffered DDR2 up

to 8GB/s (DDR2 800/667) for single channel mode or dual-channel Interleaved

mode.

Chipset  Latest Intel chipset technology!

• Intel G33/P35 GMCH (North Bridge), ICH9/ICH9R (South Bridge)

Expansion Slots

• One (1) PCI-Express x16 (Slot 6)

• One (1) PCI-Express x4 (Slot 5)

• One (1) PCI-Express x1 (Slot 7)

• Four (4) 32-bit PCI 33MHz (Slot 1 to Slot 4) (*Slot 4: Not available on the

C2SBA+II/C2SBA+)

BIOS

• 8 Mb Firmware Hub Phoenix BIOS

®

Flash BIOS

• DMI 2.3, PCI 2.2, ACPI 1.0/2.0, SMBIOS 2.3, and Plug and Play (PnP)

PC Health Monitoring

• Onboard voltage monitors for CPU Core Voltage, Memory Voltage,+1.8V, +3.3V,

+3.3V standby, +5V, Vbat (battery voltage) and ±12V

• Fan status monitor with fi rmware 4 pin fan speed control

• CPU 3-Phase-switching voltage regulator

• SuperDoctor III, Watch Dog, NMI

• Power-up mode control for recovery from AC power loss

• CPU/System overheat LED and control

• System resource alert via Supero Doctor III

• Auto-switching voltage regulator for the CPU core

• CPU Thermal Trip support

• Thermal Monitor 2 (TM2) support

• Trusted Platform Module (TPM) support

ACPI Features

• Slow blinking LED for suspend state indicator

• BIOS support for USB keyboard

• Main switch override mechanism

• External modem ring-on

1-7

C2SBA+II/C2SBA+/C2SBA/C2SBE User’s Manual

Onboard I/O

• Built in ICH9 SATA Controller, 4 connectors for 4 devices (*For the C2SBA+/
C2SBA/C2SBE)

• Built in ICH9R SATA Controller, 6 connectors for 6 devices (*For the

C2SBA+II)

• 1 fl oppy port interface (up to 2.88 MB)

• 1 Fast UART 16550 compatible serial port/header

• Intel 82566 Gigabit Ethernet Controller

• PS/2 mouse and PS/2 keyboard ports

• ITE-8212 IDE controller supports two IDE hard drives (*for the C2SBA+II/

C2SBA+ only)

• Up to 10 USB (Universal Serial Bus) 2.0 ports for a speed of up to 480Mbps

 Latest USB 2.0 technology!

• Realtek ALC 883 7.1 Channel High Defi nition Audio (HDA) codecs supports 10

DAC Channels

• Built-in GMCH and onboard VGA connector (*Not available on C2SBE)

Other

• Trusted Platform Module (TPM) support (* For the C2SBA/C2SBA+II/C2SBA+

only)

• Wake-on-LAN

• Wake-on-Ring (WOR)

• System Bus Clock Frequency Selection (Overclocking) Support (Note)

• Suspend-to-RAM

• Onboard +3V Standby Power Warning LED ("LE1")

• Pb Free

CD Utilities

• BIOS fl ash upgrade utility

• Drivers and software for Intel G33/P35 chipset utilities

Dimensions

• ATX form factor, 12.0" x 9.6" (304.8 x 243.8 mm)

1-8

Chapter 1: Introduction

VRM 11.0

FSB: 1333/1066MHz

INTEGRATED

GRAPHICS

1 PCIE_x16

GRAPHIC

4 or 6 SATAII

PORTS

12x USB2.0

PORTS

VRM 11.0

PCIE_x16

S-ATA/300

USB2.0/1.1

FWH

TPM

LGA775_PROCESSOR

ADDR

CTRL CTRL

ADDR

G33/P35

GMCH/MCH

DMI

ICH-9(R)

LPC

LPC

W83627DHG 7.1-CH

LPC I/O

LPC

HD-A

HD_AUDIO

DATADATA

DDR2 800/667

PCIE_x1

PCIE_x4

PCI_32

PCI_32

PCIE_x1

CK505 CLK

DIMM_CHA

DIMM_CHB

1_PCIE_x1

1_PCIE_x8

3_PCI_x32

82566 G_LAN

RJ45 PORT

1_PCI_x32

(Option)

ITE-8212

(Option)

IDE1

IDE2

MS.KB.

FDD. SER.1/2 PRN.

HD_AUDIO

PORTS

Figure 1-3. The Intel G33/P35 Chipset:

System Block Diagram

Note: This is a general block diagram and may not exactly represent

the features on your motherboard. See the following pages for the

actual specifi cations of each motherboard.

Note 1: Integrated Graphics support is not available for the P35 Chipset.

Note 2: ICH9R is available on the C2SBA+II only.

1-9

C2SBA+II/C2SBA+/C2SBA/C2SBE User’s Manual

1-2 Chipset Overview

The Intel G33/P35 chipset is specially designed for use with the Intel dual core

processors. It consists of two primary components: the Graphic Memory Controller

Hub (GMCH) and the I/O Controller Hub (ICH9/ICH9R). The GMCH (North Bridge)

manages the data fl ow between the CPU interface (FSB), the System Memory

interface, the External Graphics interface, and the I/O Controller through the DMI

(Direct Media) Interface. The ICH9/ICH9R (South Bridge) provides a multitude of

I/O related functions.

Graphic Memory Controller Hub (GMCH)

Utilizing a single LGA 775 socket processor, the G33/P35 GMCH supports an FSB

frequency of 1333/1066 MHz. Host-initiated I/O cycles are decoded to the PCI-

Express, the DMI, or the GMCH confi guration space. Host-initiated memory cycles

are decoded to PCI-Express, DMI or system memory. The GMCH supports 36-bit

host bus addressing and a Cache Line Size of 64 bytes.

The GMCH supports one or two channels of DDR2 memory with up to two DIMMs

per channel with a maximum bandwidth of 6.4 GB/s in asymmetric mode or 12.8

GB/s in symmetric mode using DDR2 800 MHz memory. It also supports an op-

portunistic refresh scheme, a memory thermal management scheme and Partial

Writes to Memory using Data Mask (DM) signals.

The GMCH contains one PCI-Express x16 (16-lane) port intended for an external

PCI-Express graphics card that is compatible with the PCI Express Base Specifi ca-

tion revision 1.1. This PCI-E x16 port runs at a frequency of 2.5 GB/s on each lane

and supports a maximum theoretical bandwidth of 40 GB/s in each direction for

an aggregate of 8 GB/s @ x16. It supports traditional PCI-/AGP- style traffi c and a

PCI-Exp. Enhanced Addressing Mechanism with advanced capabilities in automatic

discovery, negotiation and training of link out of reset.

Providing the high-speed, chip-to-chip connection between the GMCH and ICH9/

ICH9R is the Direct Media Interface (DMI). The DMI integrates advanced priority-

based servicing, allowing for concurrent traffi c, true isochronous transfer capabilities

and permitting current as well as legacy software to function seamlessly.

Intel ICH9/ICH9R System Features

The Intel 9th Generation I/O Controller Hub (ICH9/ICH9R) supports a variety of I/O

related functions and PCI devices, including the following:

DMI-to PCI Bridge

•

LPC Controller

•

Thermal Subsystem

•

SMBus Controller

•

USB FS/LS UHCI Controllers #1, #2 and #3

•

1-10

Chapter 1: Introduction

1-3 Recovery from AC Power Loss

BIOS provides a setting for you to determine how the system will respond when

AC power is lost and then restored to the system. You can choose for the system

to remain powered off (in which case you must hit the power switch to turn it back

on) or for it to automatically return to a power on state. See the Power Lost Con-

trol setting in the BIOS chapter of this manual to change this setting. The default

setting is Last State.

1-4 PC Health Monitoring

This section describes the PC health monitoring features of the C2SBA+II/C2SBA+/

C2SBA/C2SBE. The motherboard has an onboard System Hardware Monitor chip

that supports PC health monitoring.

Onboard Voltage Monitors for the CPU Core, +1.8V, +3.3V, +3.3V
standby, +5V, Vbat and ±12V

The onboard voltage monitor will scan these voltages continuously. Once a voltage

becomes unstable, it will give a warning or send an error message to the screen.

Users can adjust the voltage thresholds to defi ne the sensitivity of the voltage moni-

tor by using SuperO Doctor III.

1-5 ACPI Features

ACPI stands for Advanced Confi guration and Power Interface. The ACPI specifi ca-

tion defi nes a fl exible and abstract hardware interface that provides a standard

to integrate power management features throughout a PC system, including its

hardware, operating system and application software. This enables the system to

automatically turn on and off peripherals such as CD-ROMs, network cards, hard

disk drives and printers. This also includes consumer devices connected to the PC

such as VCRs, TVs, telephones and stereos.

In addition to enabling operating system-directed power management, ACPI pro-

vides a generic system event mechanism for Plug and Play and an operating- sys-

tem-independent interface for confi guration control. ACPI leverages the Plug and

Play BIOS data structures while providing a processor architecture-independent

implementation that is compatible with Windows 2000, Windows XP, Windows 2003,

Windows 2003 Servers.

Enhanced Power Management

The onboard ICH9/ICH9R chip provides advanced power management functions

that will greatly improve the performance of various low-power (suspend) states and

1-11

C2SBA+II/C2SBA+/C2SBA/C2SBE User’s Manual

enhance clock control. A hardware-based component provides software-indepen-

dent thermal management that is compatible with the ACPI Revision 3.0a.

Slow Blinking LED for Suspend-State Indicator

When the CPU goes into a suspend state, the chassis power LED will start blinking

to indicate that the CPU is in suspend mode. When the user presses any key, the

CPU will wake-up and the LED will automatically stop blinking and remain on.

BIOS Support for USB Keyboard

If the USB keyboard is the only keyboard in the system, it will function like a normal

keyboard during system boot-up.

Wake-On-LAN (WOL)

Wake-On-LAN is defi ned as the ability of a management application to remotely

power up a computer that is powered off. Remote PC setup, up-dates and asset

tracking can occur after hours and on weekends so that daily LAN traffi c is kept

to a minimum and users are not interrupted. The motherboard has a 3-pin header

(WOL) to connect to the 3-pin header on a Network Interface Card (NIC) that has

WOL capability. In addition, an onboard LAN controller can also support WOL

without any connection to the WOL header. The 3-pin WOL header is to be used

with a LAN add-on card only.

Note: Wake-On-LAN requires an ATX 2.01 (or above) compliant power supply.

1-6 Power Supply

As with all computer products, a stable power source is necessary for proper and

reliable operation. It is even more important for processors that have high CPU

clock rates of 1 GHz and faster.

The

supplies. Although most power supplies generally meet the specifi cations required

by the CPU, some are inadequate. A 2-Amp of current supply on a 5V Standby

rail is strongly recommended.

It is strongly recommended that you use a high quality power supply that meets

12V ATX power supply Specifi cation 1.1 or above. It is also required that the 12V

4-pin power connection (J41) be used for high-load confi gurations. In areas where

noisy power transmission is present, you may choose to install a line fi lter to shield

the computer from noise. It is recommended that you also install a power surge

protector to help avoid problems caused by power surges.

C2SBA+II/C2SBA+/C2SBA/C2SBE accommodates 12V ATX power

1-12

Chapter 1: Introduction

1-7 Versatile Media Capabilities

High Defi nition Audio

The High Defi nition Audio Controller embedded in the ICH9/ICH9R delivers up to

4 codecs that can be used for different types of codecs, such as audio and mo-

dem codecs. Operating at 3.3V or 1.5V, the embedded Audio Controller supports

a multi-channel audio stream, 32-bit sample depth, up to 192 kHz of same rate,

and can be used with a variety of microphones for input. With these versatile audio

capabilities built in, the C2SBA+II/C2SBA+/C2SBA/C2SBE provides the user with

a surreal audio experience that is larger than life.

I/O Virtualization Technology (VT-d)

With the Intel ICH9 built in, the C2SBA+II/C2SBA+/C2SBA/C2SBE supports I/O

Virtualization Technology (VT-d) that enables multiple operating systems and ap-

plications to run in independent partitions. Each partition uses its own subset of host

physical memory, and behaves like a virtual machine (VM), providing isolation and

protection across multiple partitions. This feature is available when a processor that

supports the virtualization of platforms is installed on the motherboard.

1-8 Super I/O

The disk drive adapter functions of the Super I/O chip include a fl oppy disk drive

controller that is compatible with industry standard 82077/765, a data separator,

write pre-compensation circuitry, decode logic, data rate selection, a clock genera-

tor, drive interface control logic and interrupt and DMA logic. The wide range of

functions integrated onto the Super I/O greatly reduces the number of components

required for interfacing with fl oppy disk drives. The Super I/O supports two 360 K,

720 K, 1.2 M, 1.44 M or 2.88 M disk drives and data transfer rates of 250 Kb/s,

500 Kb/s or 1 Mb/s.

It also provides two high-speed, 16550 compatible serial communication ports

(UARTs). Each UART includes a 16-byte send/receive FIFO, a programmable baud

rate generator, complete modem control capability and a processor interrupt sys-

tem. Both UARTs provide legacy speed with baud rate of up to 115.2 Kbps as well

as an advanced speed with baud rates of 250 K, 500 K, or 1 Mb/s, which support

higher speed modems.

The Super I/O provides functions that comply with the ACPI (Advanced Confi gura-

tion and Power Interface), which includes support of legacy and ACPI power man-

agement through a SMI or SCI function pin. It also features auto power management

to reduce power consumption.

1-13

C2SBA+II/C2SBA+/C2SBA/C2SBE User’s Manual

Notes

1-14

Chapter 2: Installation

Chapter 2

Installation

2-1 Static-Sensitive Devices

Electric-Static-Discharge (ESD) can damage electronic com ponents. To prevent

damage to your system board, it is important to handle it very carefully. The following

measures are generally suffi cient to protect your equipment from ESD.

Precautions

• Use a grounded wrist strap designed to prevent static discharge.

• Touch a grounded metal object before removing the board from the antistatic

bag.

• Handle the board by its edges only; do not touch its components, peripheral

chips, memory modules or gold contacts.

• When handling chips or modules, avoid touching their pins.

• Put the motherboard and peripherals back into their antistatic bags when not in

use.

• For grounding purposes, make sure your computer chassis provides excellent

conductivity between the power supply, the case, the mounting fasteners and

the motherboard.

• Use only the correct type of onboard CMOS battery as specifi ed by the manu-

facturer. Do not install the onboard battery upside down to avoid possible explo-

sion.

Unpacking

The motherboard is shipped in antistatic packaging to avoid static damage. When

unpacking the board, make sure the person handling it is static protected.

2-2 Motherboard Installation

(Note: Be sure to mount the motherboard into the chassis before you install
the CPU onto the motherboard.)

All motherboards have standard mounting holes to fi t different types of chassis.

Make sure that the locations of all the mounting holes for both motherboard and

chassis match. Make sure that the metal standoffs click in or are screwed in

tightly. Then use a screwdriver to secure the motherboard onto the motherboard

tray. (Note: some components are very close to the mounting holes. Please

take precautionary measures to prevent damage to these components when

installing the motherboard to the chassis.)

2-1

C2SBA+II/C2SBA+/C2SBA/C2SBE User's Manual

2-3 Processor and Heatsink Fan Installation

When handling the processor package, avoid placing

direct pressure on the label area of the fan.

Notes: 1. Always connect the power cord last and always remove it before adding,

removing or changing any hardware components. Make sure that you install the

processor into the CPU LGA 775 socket before you install the CPU heatsink.

2. The Intel LGA 775 Processor package contains the CPU fan and heatsink as-

sembly. If you buy a CPU separately, make sure that you use only Intel-certifi ed

multi-directional heatsink and fan.

3. Make sure to install the motherboard into the chassis before you install the CPU

heatsink and fan.

4. When purchasing an LGA 775 Processor or when receiving a motherboard with

an LGA 775 Processor pre-installed, make sure that the CPU plastic cap is in place

and none of the CPU pins are bent; otherwise, contact the retailer immediately.

5. Refer to the MB Features Section for more details on CPU support.

!

Installation of the LGA 775 Processor

Load Lever

1. Press the load lever to release

the load plate, which covers the CPU

socket, from its locking position.

2. Gently lift the load lever to open the

load plate.

PnP Cap on

top of the

Load Plate

Load Plate

(with PnP Cap

attached)

2-2

Chapter 2: Installation

3. Use your thumb and your index

fi nger to hold the CPU at the North

Center Edge and the South Center

Edge of the CPU.

4. Align CPU Pin1 (the CPU corner

marked with a triangle) against the

socket corner that is marked with a

triangle cutout.

5. Align the CPU key that is the

semi-circle cutout below a golden dot

against the socket key, the Notch on

the same side of the triangle cutout

on the socket.

6. Once aligned, carefully lower the

CPU straight down to the socket.

(Note: Do not drop the CPU on the

socket. Do not move the CPU horizon-

tally or vertically. Do not rub the CPU

against the surface or against any pins

of the socket to avoid damage to the

CPU or the socket.)

Socket Key

(Socket Notch)

CPU Key (semi-

circle cutout)

below the circle.

Corner with a

triangle cutout

North Center Edge

South Center Edge

golden dot

CPU Pin1

7. With the CPU inside the socket,

inspect the four corners of the CPU

to make sure that the CPU is properly

installed.

8. Use your thumb to gently push the

load lever down to the lever lock.

9. If the CPU is properly installed into

the socket, the plastic PnP cap will be

automatically released from the load

plate when the load lever is pushed

in the lever lock. Remove the PnP cap

from the motherboard.

(Warning: Please save the plas-

!

tic PnP cap. The motherboard must

be shipped with the PnP cap properly

installed to protect the CPU socket

pins. Shipment without the PnP cap

properly installed will cause damage

to the socket pins.)

Load Lever

CPU in the CPU socket

Plastic cap

is released

from the

load plate

if CPU

properly

installed.

2-3

C2SBA+II/C2SBA+/C2SBA/C2SBE User's Manual

Installation of the Heatsink

1. Locate the CPU Fan on the mother-

board. (Refer to the layout on the right

for the CPU Fan location.)

2. Position the heatsink in such a way

that the heatsink fan wires are closest

to the CPU fan and are not interfered

with other components.

3. Inspect the CPU Fan wires to make

sure that the wires are routed through

the bottom of the heatsink.

4. Remove the thin layer of the protec-

tive fi lm from the copper core of the

heatsink.

Thermal Grease

(*Warning: CPU overheat may occur if

the protective fi lm is not removed from

the heatsink.)

5. Apply the proper amount of thermal

grease on the CPU. (Note: if your

heatsink came with a thermal pad,

please ignore this step.)

6. If necessary, rearrange the wires

to make sure that the wires are not

pinched between the heatsink and the

CPU. Also make sure to keep clear-

ance between the fan wires and the

fi ns of the heatsink.

7. Align the four heatsink fasteners

with the mounting holes on the mother-

board. Gently push the pairs of diago-

nal fasteners (#1 & #2, and #3 & #4)

into the mounting holes until you hear

a click. (Note: Make sure to orient each

fastener in a way that the narrow end of

the groove is pointing outward.)

CPU

Fan Wires

Heatsink Fins

Heatsink

Fastener

#1

#4

#3

#2

Narrow end of the groove

points outward

2-4

8. Repeat Step 6 to insert all four heatsink

fasteners into the mounting holes.

9. Once all four fasteners are securely insert-

ed into the mounting holes and the heatsink

is properly installed on the motherboard,

connect the heatsink fan wires to the CPU

Fan connector.

Heatsink Removal

1. Unplug the power cord from the power

supply.

2. Disconnect the heatsink fan wires from the

CPU fan header.

3. Use your fi nger tips to gently press on the

fastener cap and turn it counterclockwise

to make a 1/4 (90

fastener upward to loosen it.

0

) turn, and then pull the

Chapter 2: Installation

4. Repeat Step 3 to loosen all fasteners from

the mounting holes.

5. With all fasteners loosened, remove the

heatsink from the CPU.

2-5

C2SBA+II/C2SBA+/C2SBA/C2SBE User's Manual

2-4 Installing DIMMs

Note: Check the Super Micro web site for recommended memory modules.

CAUTION

Exercise extreme care when installing or removing DIMM

modules to prevent any possible damage. Also note that the

memory is interleaved to improve performance (see step 1).

DIMM Installation (See Figure 2-2)

1. Insert the desired number of DIMMs into the memory slots, starting with DIMM1A.

The memory scheme is interleaved so you must install two modules at a time,

beginning with DIMM1A, DIMM1B, then, DIMM2A and DIMM2B

2. Insert each DIMM module vertically into its slot. Pay attention to the notch along

the bottom of the module to prevent inserting the DIMM module incorrectly.

3. Gently press down on the DIMM module until it snaps into place in the slot.

Repeat for all modules (see step 1 above).

Memory Support

The C2SBA+II/C2SBA+/C2SBA/C2SBE supports up to 8 GB Unbuffered Non-

ECC DDR2 800/677 MHz in 4 DIMMs. Populating DIMM#1A,DIMM#1B, and/or

DIMM#2A, DIMM#2B with memory modules of the same size and of the same

type will result in dual channel, two-way interleaved memory which is faster than

the single channel, non-interleaved memory.

Notes:

1. Due to the OS limitations, some operating systems may not show more than 4

GB of memory.

2. Both Unbuffered ECC and Non-ECC memory modules can be installed in the

memory slots. However, the functionality of ECC is not supported by the

chipset.

3. Due to memory allocation to system devices, memory remaining available for

operational use will be reduced when 4 GB of RAM is used. The reduction in

memory availability is disproportional. (Refer to the following Memory Avail-

ability Table for details.)

2-6

Possible System Memory Allocation & Availability

Chapter 2: Installation

System Device Size Physical Memory

Firmware Hub fl ash memory (System
BIOS)

Local APIC 4 KB 3.99

Area Reserved for the chipset 2 MB 3.99

I/O APIC (4 Kbytes) 4 KB 3.99

PCI Enumeration Area 1 256 MB 3.76

PCI Express (256 MB) 256 MB 3.51

PCI Enumeration Area 2 (if needed)

-Aligned on 256-MB boundary-

VGA Memory 16 MB 2.85

TSEG 1 MB 2.84

Memory available to OS and other ap­plications

1 MB 3.99

512 MB 3.01

Remaining (-Available)
(4 GB Total System Memory)

2.84

Figure 2-2. Installing and Removing DIMMs

C2SBA

To Remove:

Use your thumbs
to gently push
the release tabs
near both ends of
the module. This
should release it
from the slot.

DDR2 FBD DIMM

DDR2

To Install: Insert module vertically and press down until it

snaps into place. Pay attention to the alignment notch at
the bottom.

Top View of DDR2 FBD Slot

Top View of DDR2

2-7

C2SBA+II/C2SBA+/C2SBA/C2SBE User's Manual

2-5 Control Panel Connectors/IO Ports

The I/O ports are color coded in conformance with the PC 99 specifi cation. See

Figure 2-3 below for the colors and locations of the various I/O ports.

A. Back Panel Connectors/IO Ports

8

2

4

7

14

11

17

C2SBA

1

3

8

1

Figure 2-3. Back Panel I/O Port Locations and Defi nitions

Back Panel Connectors

1. Keyboard (Purple)

2. PS/2 Mouse (Green)

3. COM Port 1 (Turquoise)

4. Parallel Port (Printer)

5. Back Panel USB Port 3

6. Back Panel USB Port4

7. Back Panel USB Port 5

8. Back Panel USB Port 6

9. Back Panel USB Port 1

10. Back Panel USB Port 2

11. Gigabit LAN 1

12. Side_Surround (Grey)

13. Back_Surround (Black)

14. CEN/LFE (Orange)

15. Microphone-In (Pink)

16. Front (Green)

17. Line-In (Blue)

18. VGA (*Not included on the
C2SBE)

13

12

16

15

10

6

9

5

2-8

Chapter 2: Installation

B. Front Control Panel

JF1 contains header pins for various buttons and indicators that are normally

located on a control panel at the front of the chassis. These connectors are de-

signed specifi cally for use with Super Micro server chassis. See Figure 2-4 for the

descriptions of the various control panel buttons and LED indicators. Refer to the

following section for descriptions and pin defi nitions.

Figure 2-4. JF1 Header Pins

C2SBA

Power LED

HDD LED

NIC1 LED

OH/Fan Fail LED

Ground

Ground

LED_Anode+

LED_Anode+

LED_Anode+

Reset

PWR

1

X

LED_Anode+

X

Reset Button

Power Button

X

X

2

2-9

C2SBA+II/C2SBA+/C2SBA/C2SBE User's Manual

C. Front Control Panel Pin Defi nitions

Power LED

The Power LED connection is located

on pins 15 and 16 of JF1. Refer to the

table on the right for pin defi nitions.

HDD LED

The HDD LED connection is located

on pins 13 and 14 of JF1. Attach a

hard drive LED cable here to display

disk activity (for any hard drives on

the system, including SAS and Serial

ATA). See the table on the right for

pin defi nitions.

Power LED

Pin Defi nitions

Pin# Defi nition

15 LED_Anode+

16 PWR LED Signal

HDD LED

Pin Defi nitions

Pin# Defi nition

13 LED_Anode+

14 HD Active

JKB

4-Pin PWR

KB/MOUSE

Slot5 PCI-E x4

JFSB3

Slot6 PCI-E x16

JI2C1

JI2C2

Slot4 PCI-33MHz

Slot3 PCI-33MHz

Slot2 PCI-33MHz

Slot1 PCI-33MHz

Processor

JWOR

Intel G33

North Bridge

BIOS

JPL1

JRTC1
JRTC2

JP2

Speaker

Buzzer

SPKR1

COM1

VGA

USB

USB 1/2

Audio

Parallel Port

3/4/5/6

GLAN CTRL

Audio CTRL

CD-IN

C2SBA

Front Audio

JFSB2

JFSB1

LAN

JPUSB1

Fan5

Slot7 PCI-E x1

JP5

Audio Enabled

COM2

IDE CTRL

ITE 8212

CPU Fan

Intel ICH9(R)

South Bridge

JPUSB2

WOL

WO

FAN1

DIMM1A

FP USB 7/8

FAN2

DIMM2A

I-SATA2

I-SATA3

I-SATA0

I-SATA1

FP USB 9/10

DIMM1B

IDE#2

IDE#1

Front-Access USB 11Front-Access USB 12

I-SATA4

I-SATA5

DIMM2B

S I/O

Battery

JP3
JWD
JLED

24-pin ATX PWR

Floppy

LE1

W83627DHG

FAN3

FAN4

Front Panel CTRL

JL1

2-10

A. PWR LED

B. HDD LED

Power LED

A

B

HDD LED

NIC1 LED

OH/Fan Fail LED

Ground

Ground

LED_Anode+

LED_Anode+

LED_Anode+

X

X

LED_Anode+

X

2

X

Reset

Reset Button

Power Button

PWR

1

NIC1 Indicator

The NIC (Network Interface Control-

ler) LED connection for the GLAN port

is located on pins 11 and 12 of JF1.

Attach the NIC LED cables to display

network activity. Refer to the table on

the right for pin defi nitions.

Overheat/Fan Fail LED (OH)

Connect an LED to the OH/Fan Fail

connection on pins 7 and 8 of JF1 to

provide advanced warnings of chassis

overheating or fan failure. Refer to the

table on the right for pin defi nitions.

Chapter 2: Installation

GLAN1/2 LED

Pin Defi nitions

Pin# Defi nition

11 LED_Anode+

12 NIC1 LED

Signal

OH/Fan Fail LED

Pin Defi nitions

Pin# Defi nition

7 LED_Anode+

8 OH/Fan Fail

LED Signal

OH/Fan Fail Indicator

Status

State Defi nition

Off Normal

On Overheat

Flash-

Fan Fail

ing

JKB

4-Pin PWR

KB/MOUSE

Slot5 PCI-E x4

JFSB3

Slot6 PCI-E x16

JI2C1

JI2C2

Slot4 PCI-33MHz

Slot3 PCI-33MHz

Slot2 PCI-33MHz

Slot1 PCI-33MHz

Processor

JWOR

BIOS

JPL1

JP2

COM1

VGA

USB

USB 1/2

Audio

Parallel Port

3/4/5/6

GLAN CTRL

Audio CTRL

CD-IN

C2SBA

Front Audio

JFSB2

JFSB1

LAN

JPUSB1

Fan5

Slot7 PCI-E x1

JP5

Audio Enabled

COM2

Intel G33

North Bridge

JRTC1
JRTC2

Speaker

Buzzer

SPKR1

IDE CTRL

ITE 8212

CPU Fan

Intel ICH9(R)

South Bridge

JPUSB2

WOL

WO

FAN1

DIMM1A

FP USB 7/8

FAN2

DIMM2A

I-SATA2

I-SATA3

I-SATA0

I-SATA1

FP USB 9/10

DIMM1B

IDE#2

IDE#1

Front-Access USB 11Front-Access USB 12

I-SATA4

I-SATA5

DIMM2B

Battery

JP3
JWD
JLED

S I/O

W83627DHG

24-pin ATX PWR

Floppy

LE1

JL1

FAN3

FAN4

Front Panel CTRL

2-11

Power LED

HDD LED

NIC1 LED

A

OH/Fan Fail LED

B

Ground

Ground

A. NIC1 LED

B.OH/Fan Fail LED

X

X

Reset

PWR

2

1

LED_Anode+

LED_Anode+

LED_Anode+

X

LED_Anode+

X

Reset Button

Power Button

C2SBA+II/C2SBA+/C2SBA/C2SBE User's Manual

Reset Button

The Reset Button connection is located

on pins 3 and 4 of JF1. Attach it to a

hardware reset switch on the computer

case. Refer to the table on the right for

Pin# Defi nition

3 Reset

4 Ground

pin defi nitions.

Power Button

The Power Button connection is located

on pins 1 and 2 of JF1. Momentarily

contacting both pins will power on/off

the system. This button can also be con-

fi gured to function as a suspend button

(with a setting in the BIOS - see Chapter

4). To turn off the power when set to sus-

pend mode, press the button for at least

4 seconds. Refer to the table on the right

for pin defi nitions. (Note: Do not close or

short Pins 1 & 2 since this will cause the

system to continuously reboot.)

Pin Defi nitions

Pin# Defi nition

1 Signal

2 +3V Standby

Reset Button

Pin Defi nitions

Power Button

JKB

4-Pin PWR

KB/MOUSE

Slot5 PCI-E x4

JFSB3

Slot6 PCI-E x16

JI2C1

JI2C2

Slot4 PCI-33MHz

Slot3 PCI-33MHz

Slot2 PCI-33MHz

Slot1 PCI-33MHz

Processor

JWOR

Intel G33

North Bridge

BIOS

JPL1

JRTC1
JRTC2

JP2

Speaker

Buzzer

SPKR1

COM1

VGA

USB

USB 1/2

Audio

Parallel Port

3/4/5/6

GLAN CTRL

Audio CTRL

CD-IN

C2SBA

Front Audio

JFSB2

JFSB1

LAN

JPUSB1

Fan5

Slot7 PCI-E x1

JP5

Audio Enabled

COM2

IDE CTRL

ITE 8212

CPU Fan

Intel ICH9(R)

South Bridge

JPUSB2

WOL

WO

FAN1

DIMM1A

FP USB 7/8

FAN2

DIMM2A

I-SATA2

I-SATA3

I-SATA0

I-SATA1

FP USB 9/10

DIMM1B

IDE#2

IDE#1

Front-Access USB 11Front-Access USB 12

I-SATA4

I-SATA5

DIMM2B

S I/O

Battery

JP3
JWD
JLED

24-pin ATX PWR

Floppy

LE1

W83627DHG

JL1

Power LED

HDD LED

NIC1 LED

OH/Fan Fail LED

FAN3

FAN4

Front Panel CTRL

2-12

A. Reset

B. PWR Button

X

X

Ground

Ground

LED_Anode+

LED_Anode+

LED_Anode+

X

LED_Anode+

X

Reset

PWR

2

1

A

Reset Button

Power Button

B

Chapter 2: Installation

2-6 Connecting Cables

ATX Main Power Connector

A 24-pin main power connector is

located at J40. This power connector

meets the SSI EPS 12V specifi ca-

tion. See the table on the right for pin

defi nitions.

4-pin CPU Power Connector

A 4-pin 12V power connector is located

at J41 on the motherboard. This power

connector also meets the SSI EPS

12V specifi cation, and is required to

ensure adequate power to the proces-

sor. See the table on the right for pin

defi nitions.

ATX Power 24-pin Connector

Pin Defi nitions

Pin# Defi nition Pin # Defi nition

13 +3.3V 1 +3.3V

14 -12V 2 +3.3V

15 COM 3 COM

16 PS_ON 4 +5V

17 COM 5 COM

18 COM 6 +5V

19 COM 7 COM

20 Res (NC) 8 PWR_OK

21 +5V 9 5VSB

22 +5V 10 +12V

23 +5V 11 +12V

24 COM 12 +3.3V

12V 4-pin Power

Connector

Pin Defi nitions

Pins Defi nition

1 and 2 Ground

3 and 4 +12V

KB/MOUSE

COM1

VGA

USB

3/4/5/6

USB 1/2

Audio

JKB

Parallel Port

LAN

GLAN CTRL

Audio CTRL

CD-IN

C2SBA

Front Audio

Fan5

JP5

B

4-Pin PWR

JPUSB1

Slot7 PCI-E x1

Audio Enabled

COM2

JFSB2

JFSB1

Slot5 PCI-E x4

Slot4 PCI-33MHz

Processor

JFSB3

Slot6 PCI-E x16

JI2C1
JI2C2

JWOR

Slot3 PCI-33MHz

Slot2 PCI-33MHz

Slot1 PCI-33MHz

JPL1

BIOS

JP2

Intel G33

North Bridge

JRTC1
JRTC2

Speaker

Buzzer

SPKR1

IDE CTRL

ITE 8212

WO

WOL

CPU Fan

Intel ICH9(R)

South Bridge

JPUSB2

FAN1

DIMM1A

FP USB 7/8

FAN2

DIMM1B

DIMM2A

I-SATA2

I-SATA3

I-SATA0

I-SATA1

FP USB 9/10

IDE#2

IDE#1

I-SATA4

I-SATA5

Front-Access USB 11Front-Access USB 12

DIMM2B

Battery

JP3
JWD
JLED

S I/O

W83627DHG

24-pin ATX PWR

Floppy

LE1

JL1

FAN3

FAN4

Front Panel CTRL

A

A. 24-pin ATX PWR

B. 4-pin PWR

2-13

C2SBA+II/C2SBA+/C2SBA/C2SBE User's Manual

Universal Serial Bus (USB)

There are 12 USB 2.0 (Universal

Serial Bus) ports/headers on the

motherboard. Six of them are Back

Panel USB ports: USB#1/2 (J11) and

USB#3/4/5/6 (J43). USB #7/8 (J44)

and USB#9/10 (J45) are headers

that can be used for front panel con-

nections. Additionally, USB#11(J47)

and USB#12 (J48) are onboard USB

connectors that can be accessed from

the front side of the chassis. See the

tables on the right for pin defi nitions.

Chassis Intrusion

A Chassis Intrusion header is located

at JL1 on the motherboard. Attach an

appropriate cable from the chassis to

inform you of a chassis intrusion when

it is opened.

Back Panel USB

Pin# Defi nitions

1 +5V

2 PO-

3 PO+

4 Ground

5N/A

Front Panel USB (#7/8/9/10) and Front-

Accessible Onboard USB (#11/12)

Connections

Pin # Defi nition

Pin # Defi nition

1 +5V 1 +5V

2 PO- 2 PO-

3 PO+ 3 PO+

4 Ground 4 Ground

5 Key 5 No connection

Chassis Intrusion

Pin Defi nitions

Pin# Defi nition

1 Intrusion Input

2 Ground

KB/MOUSE

COM1

VGA

USB

3/4/5/6

USB 1/2

Audio

C2SBA

JKB

Parallel Port

GLAN CTRL

Audio CTRL

CD-IN

Front Audio

CPU Fan

4-Pin PWR

Processor

B

JFSB2

JFSB1

LAN

A

JPUSB1

Fan5

Slot7 PCI-E x1

JFSB3

Intel G33

North Bridge

FAN1

DIMM1A

FAN2

DIMM1B

DIMM2A

DIMM2B

S I/O

W83627DHG

24-pin ATX PWR

Floppy

A. Back panel USB Ports 1/2

B. Back panel USB Ports 3/4/5/6

C. Front Panel USB 7/8

D. Front Panel USB 9/10

E. USB 11

F. USB 12

Slot6 PCI-E x16

Slot5 PCI-E x4

Audio Enabled

COM2

Slot4 PCI-33MHz

Slot3 PCI-33MHz

Slot2 PCI-33MHz

JP5

JI2C1
JI2C2

JWOR

Slot1 PCI-33MHz

JPL1

BIOS

JP2

JRTC1

JRTC2

Speaker

Buzzer

SPKR1

IDE CTRL

ITE 8212

WO

WOL

Intel ICH9(R)

South Bridge

JPUSB2

C

FP USB 7/8

E

I-SATA2

I-SATA3

I-SATA0

D

I-SATA1

FP USB 9/10

IDE#2

IDE#1

I-SATA4

I-SATA5

Front-Access USB 11Front-Access USB 12

Battery

JP3
JWD
JLED

FAN3

FAN4

LE1

Front Panel CTRL

JL1

G

F

G. Chassis Intrusion

2-14

Fan Headers

The C2SBA+II/C2SBA+/C2SBA/C2SBE

has fi ve chassis fan headers (Fan 1 to Fan

5). Fan 1 is the CPU Fan. Fan 2 to Fan

5 are system/chassis fans. (Note: Pins

1-3 of a 4-pin fan headers are backward

compatible with the traditional 3-pin fans.)

See the table on the right for pin defi nitions.

*The onboard fan speeds are controlled by

Thermal Management via BIOS Hardware

Monitoring in the Advanced Setting

Default: Disabled. When using Thermal

Management settings, please use all 3-pin

fans or all 4-pin fans on the motherboard.)

. (Note:

Chapter 2: Installation

Fan Header

Pin Defi nitions

Pin# Defi nition

1 Ground

2 +12V

3 Tachometer

4 PWR Modulation

VGA Connector

(*Not available on the C2SBE)

A VGA connector (JG1) is located next to the

USB ports on the IO backplane. Refer to the

board layout below for the location.

Intel G33

North Bridge

JRTC1
JRTC2

Speaker

Buzzer

SPKR1

IDE CTRL

ITE 8212

WO

WOL

CPU Fan

Intel ICH9(R)

South Bridge

JPUSB2

FAN1

A

DIMM1A

FP USB 7/8

FAN2

DIMM2A

I-SATA2

I-SATA3

I-SATA0

I-SATA1

FP USB 9/10

KB/MOUSE

COM1

VGA

USB

3/4/5/6

USB 1/2

Audio

JKB

Parallel Port

F

LAN

GLAN CTRL

Audio CTRL

CD-IN

C2SBA

Front Audio

Fan5

JP5

4-Pin PWR

JPUSB1

E

Slot7 PCI-E x1

Audio Enabled

COM2

JFSB2

JFSB1

Slot5 PCI-E x4

Slot4 PCI-33MHz

Processor

JFSB3

Slot6 PCI-E x16

JI2C1
JI2C2

JWOR

Slot3 PCI-33MHz

Slot2 PCI-33MHz

Slot1 PCI-33MHz

BIOS

JPL1

JP2

B

DIMM1B

IDE#2

IDE#1

I-SATA4

I-SATA5

Front-Access USB 11Front-Access USB 12

DIMM2B

Battery

JP3
JWD
JLED

S I/O

W83627DHG

24-pin ATX PWR

Floppy

LE1

JL1

FAN3

FAN4

A. Fan 1 (CPU Fan)

B. Fan 2

C. Fan 3

D. Fan 4

E. Fan 5

F. V G A

C

D

Front Panel CTRL

2-15

C2SBA+II/C2SBA+/C2SBA/C2SBE User's Manual

ATX PS/2 Keyboard and
PS/2 Mouse Ports

The ATX PS/2 keyboard and the PS/2

mouse are located at J28. See the

table on the right for pin defi nitions.

(The mouse port is above the key-

board port. See the table on the right

for pin defi nitions.)

Serial Ports

COM1 (J31) is a connector located

on the IO Backpanel and COM2 is a

header located at J13. See the table

on the right for pin defi nitions.

PS/2 Keyboard and

Mouse Port Pin

Defi nitions

Pin# Defi nition

1 Data

2NC

3 Ground

4 VCC

5 Clock

6NC

Serial Port Pin Defi nitions

Pin # Defi nition Pin # Defi nition

1 DCD 6 DSR

2RXD 7RTS

3TXD 8 CTS

4 DTR 9 RI

5 Ground 10 NC

KB/MOUSE

COM1

VGA

USB

3/4/5/6

USB 1/2

Audio

C2SBA

JKB

B

Parallel Port

GLAN CTRL

Audio CTRL

CD-IN

Front Audio

(Pin 10 is available on COM2
only. NC: No Connection.)

CPU Fan

4-Pin PWR

A

Processor

JFSB2

JFSB1

LAN

JPUSB1

Fan5

Slot7 PCI-E x1

JP5

Audio Enabled

COM2

Slot6 PCI-E x16

Slot5 PCI-E x4

Slot4 PCI-33MHz

Slot2 PCI-33MHz

C

JFSB3

JI2C1
JI2C2

Slot3 PCI-33MHz

Slot1 PCI-33MHz

JWOR

JPL1

BIOS

JP2

Intel G33

North Bridge

JRTC1

JRTC2

Speaker

Buzzer

SPKR1

IDE CTRL

ITE 8212

WO

WOL

Intel ICH9(R)

South Bridge

JPUSB2

FAN1

DIMM1A

FP USB 7/8

FAN2

DIMM2A

DIMM1B

I-SATA2

I-SATA3

I-SATA0

I-SATA1

FP USB 9/10

IDE#2

IDE#1

I-SATA4

I-SATA5

Front-Access USB 11Front-Access USB 12

DIMM2B

Battery

JP3
JWD
JLED

S I/O

W83627DHG

24-pin ATX PWR

Floppy

LE1

JL1

FAN3

FAN4

Front Panel CTRL

A. Keyboard/Mouse

B. COM1

C. COM2

2-16

Wake-On-Ring

Chapter 2: Installation

The Wake-On-Ring header is des-

ignated JWOR. This function allows

your computer to receive and be

"awakened" by an incoming call when

in the suspend state. See the table on

the right for pin defi nitions. You must

have a Wake-On-Ring card and cable

to use this feature.

Wake-On-LAN

The Wake-On-LAN header is located

at JWOL on the motherboard. See the

table on the right for pin defi nitions.

(You must also have a LAN card with

a Wake-On-LAN connector and cable

to use this feature.)

Wake-On-Ring

Pin Defi nitions

Pin# Defi nition

1 Ground

2 Wake-up

Wake-On-LAN

Pin Defi nitions

Pin# Defi nition

1 +5V Standby

2 Ground

3 Wake-up

KB/MOUSE

COM1

VGA

USB

3/4/5/6

USB 1/2

Audio

JKB

Parallel Port

LAN

GLAN CTRL

Audio CTRL

CD-IN

C2SBA

Front Audio

Fan5

JP5

4-Pin PWR

JPUSB1

Slot7 PCI-E x1

Audio Enabled

COM2

JFSB2

JFSB1

Slot5 PCI-E x4

Slot4 PCI-33MHz

Processor

JFSB3

Slot6 PCI-E x16

JI2C1
JI2C2

JWOR

A

Slot3 PCI-33MHz

Slot2 PCI-33MHz

Slot1 PCI-33MHz

JPL1

BIOS

JP2

Intel G33

North Bridge

JRTC1
JRTC2

Speaker

Buzzer

SPKR1

IDE CTRL

ITE 8212

WO

WOL

CPU Fan

Intel ICH9(R)

South Bridge

JPUSB2

B

FAN1

DIMM1A

FP USB 7/8

FAN2

DIMM2A

DIMM1B

I-SATA2

I-SATA3

I-SATA0

I-SATA1

FP USB 9/10

IDE#2

IDE#1

I-SATA4

I-SATA5

Front-Access USB 11Front-Access USB 12

DIMM2B

Battery

JP3
JWD
JLED

S I/O

W83627DHG

24-pin ATX PWR

Floppy

LE1

JL1

FAN3

FAN4

A. WOR

B. WOL

Front Panel CTRL

2-17

C2SBA+II/C2SBA+/C2SBA/C2SBE User's Manual

GLAN 1 (Giga-bit Ethernet
Port)

A G-bit Ethernet port is located at J11

on the IO backplane. This port accepts

RJ45 type cables.

Speaker

GLAN1

A Speaker/Buzzer header (J9) is

located on the motherboard. See the

table on the right for speaker pin defi -

nitions. Note: The speaker connector

pins are for use with an external

speaker. If you wish to use the on-

board speaker, you should close pins

3-4 with a jumper.

CPU Fan

FAN1

Intel G33

North Bridge

KB/MOUSE

COM1

VGA

USB

3/4/5/6

USB 1/2

Audio

JKB

4-Pin PWR

Processor

Parallel Port

JFSB2

JFSB1

LAN

A

JPUSB1

Fan5

Slot7 PCI-E x1

JFSB3

DIMM1A

FAN2

DIMM2A

DIMM1B

DIMM2B

Speaker Connector

Pin Setting Defi nition

Pins 3-4 Internal Speaker

Pins 1-4 External Speaker

S I/O

W83627DHG

24-pin ATX PWR

Floppy

A. GLAN1

B. Speaker/Buzzer

Audio Enabled

Slot6 PCI-E x16

Slot5 PCI-E x4

Slot4 PCI-33MHz

JI2C1
JI2C2

JWOR

Slot3 PCI-33MHz

BIOS

JPL1

JP2

GLAN CTRL

Audio CTRL

JP5

CD-IN

C2SBA

COM2

Slot2 PCI-33MHz

Slot1 PCI-33MHz

Front Audio

JRTC1

JRTC2

B

Speaker

Buzzer

SPKR1

IDE CTRL

ITE 8212

WO

WOL

Intel ICH9(R)

South Bridge

JPUSB2

FP USB 7/8

I-SATA2

I-SATA3

I-SATA0

I-SATA1

FP USB 9/10

IDE#2

IDE#1

2-18

I-SATA4

I-SATA5

Front-Access USB 11Front-Access USB 12

Battery

JP3
JWD
JLED

LE1

FAN3

FAN4

Front Panel CTRL

JL1

High Defi nition Audio (HDA)

The C2SBA+II/C2SBA+/C2SBA/C2SBE

features a 7.1+2 Channel High Definition

Audio (HDA) (J46) codec that provides 10DAC

channels, simultaneously supporting 7.1 sound

playback and two channels of independent

stereo sound output (multiple streaming)

through the front panel stereo out for front

L&R, rear L&R, center and subwoofer speakers.

This feature is activated with the Advanced

software in the CD-ROM that came with your

motherboard. Sound is then output through

the Line In, Line Out and MIC jacks (See at

the picture at right).

CD Header

Orange:
CEN/LFE

Black: Back
Surround

Grey: Side
Surround

Chapter 2: Installation

Blue: Line-In

Green:Front

Pink: Mic-In

A 4-pin CD header is located at CD1, and an

Auxiliary header is located at J12 on the moth-

erboard. These headers allow you to use the

onboard sound for audio CD playback. Con-

nect an audio cable from your CD drive to the

header that fi ts your cable's connector. Only

one CD header can be used at any one time.

See the tables at right for pin defi nitions.

Intel G33

North Bridge

CPU Fan

FAN1

DIMM1A

FAN2

DIMM2A

DIMM1B

KB/MOUSE

COM1

VGA

USB

3/4/5/6

USB 1/2

Audio

JKB

4-Pin PWR

Processor

Parallel Port

JFSB2

JFSB1

LAN

JPUSB1

Fan5

A

Slot7 PCI-E x1

JFSB3

S I/O

DIMM2B

W83627DHG

24-pin ATX PWR

Floppy

CD1 Pin Defi nition

Pin# Defi nition

1 Left Stereo Signal

2 Ground

3 Ground

4 Right Stereo

Signal

A. HD Audio

B. CD-In

C. Front Panel Audio

Audio Enabled

COM2

Slot6 PCI-E x16

Slot5 PCI-E x4

Slot4 PCI-33MHz

Slot2 PCI-33MHz

JI2C1
JI2C2

Slot3 PCI-33MHz

Slot1 PCI-33MHz

GLAN CTRL

Audio CTRL

CD-IN

C2SBA

Front Audio

JP5

B

C

JWOR

JPL1

BIOS

JP2

JRTC1
JRTC2

Speaker

Buzzer

SPKR1

IDE CTRL

ITE 8212

Intel ICH9(R)

South Bridge

JPUSB2

WO

WOL

FP USB 7/8

I-SATA2

I-SATA3

I-SATA0

I-SATA1

FP USB 9/10

Front-Access USB 11Front-Access USB 12

IDE#2

IDE#1

2-19

I-SATA4

I-SATA5

Battery

JP3
JWD

JLED

FAN3

FAN4

LE1

Front Panel CTRL

JL1

C2SBA+II/C2SBA+/C2SBA/C2SBE User's Manual

Front Panel Audio Control

When front panel headphones are plugged

in, the back panel audio output is disabled.

This is done through the FP Audio header

(J12). If the front panel interface card is not

connected to the front panel audio header,

jumpers should be installed on the header

(J12) pin pairs: 1-2, 5-6, and 9-10. If these

jumpers are not installed, the back panel

line out connector will be disabled and

microphone input Pin 1 will be left fl oating,

which can lead to excessive back panel

microphone noise and cross talk. See the

table below for pin defi nitions.

High Definition Front Panel Audio
Pins# Signal

1
2
3
4
5
6
7
8
9
10

MIC_L
AUD_GND
MIC_R
FP_Audio-Detect
Line_2_R
Ground
FP_Jack-Detect
Ke y
Line_2_L
Ground

Power LED

The Power LED connector is designated

JLED. This connection is used to provide

LED Indication of power supplied to the

system. See the table on the right for pin

defi nitions.

Intel G33

North Bridge

CPU Fan

FAN1

DIMM1A

KB/MOUSE

COM1

VGA

USB

3/4/5/6

USB 1/2

Audio

JKB

4-Pin PWR

Processor

Parallel Port

JFSB2

JFSB1

LAN

JPUSB1

Fan5

Slot7 PCI-E x1

JFSB3

FAN2

DIMM2A

DIMM1B

DIMM2B

S I/O

W83627DHG

24-pin ATX PWR

Floppy

PWR LED

Pin Defi nitions

Pin# Defi nition

1 +5V

2 Key

3 Ground

A. Front Panel Audio

B. PWR LED

Audio Enabled

COM2

Slot6 PCI-E x16

Slot5 PCI-E x4

Slot4 PCI-33MHz

Slot2 PCI-33MHz

JI2C1

JI2C2

JWOR

Slot3 PCI-33MHz

Slot1 PCI-33MHz

GLAN CTRL

Audio CTRL

CD-IN

C2SBA

A

Front Audio

JP5

JPL1

BIOS

JP2

JRTC1
JRTC2

Speaker

Buzzer

SPKR1

Intel ICH9(R)

IDE CTRL

ITE 8212

WO

WOL

South Bridge

JPUSB2

FP USB 7/8

I-SATA2

I-SATA3

I-SATA0

I-SATA1

FP USB 9/10

Front-Access USB 11Front-Access USB 12

IDE#2

IDE#1

2-20

I-SATA4

I-SATA5

Battery

JP3
JWD
JLED

B

FAN3

FAN4

LE1

Front Panel CTRL

JL1

2-7 Jumper Settings

Explanation of
Jumpers

To modify the operation of the

motherboard, jumpers can be used

to choose between optional settings.

Jumpers create shorts between two

pins to change the function of the

connector. Pin 1 is identifi ed with a

square solder pad on the printed circuit

board. See the motherboard layout

pages for jumper locations.

Note: On two pin jumpers, "Closed"

means the jumper is on and "Open"

means the jumper is off the pins.

Connector

Pins

Jumper

Cap

Setting

Chapter 2: Installation

3 2 1

3 2 1

Pin 1-2 short

GLAN Enable/Disable

JPL1 enables or disables the GLAN

Port on the motherboard. See the

table on the right for jumper settings.

The default setting is enabled.

Intel G33

North Bridge

JRTC1
JRTC2

Speaker

Buzzer

SPKR1

IDE CTRL

ITE 8212

WO

WOL

CPU Fan

FAN1

Intel ICH9(R)

South Bridge

JPUSB2

KB/MOUSE

COM1

VGA

USB

3/4/5/6

USB 1/2

Audio

JKB

Parallel Port

LAN

GLAN CTRL

Audio CTRL

CD-IN

C2SBA

Front Audio

Fan5

JP5

4-Pin PWR

JPUSB1

Slot7 PCI-E x1

Audio Enabled

COM2

JFSB2

JFSB1

Slot5 PCI-E x4

Slot4 PCI-33MHz

Processor

JFSB3

Slot6 PCI-E x16

JI2C1
JI2C2

JWOR

A

Slot3 PCI-33MHz

Slot2 PCI-33MHz

Slot1 PCI-33MHz

BIOS

JPL1

JP2

DIMM1A

FP USB 7/8

FAN2

DIMM2A

DIMM1B

I-SATA2

I-SATA3

I-SATA0

I-SATA1

FP USB 9/10

IDE#2

IDE#1

GLAN Enable

Pin# Defi nition

1-2 Enabled (*default)

2-3 Disabled

S I/O

W83627DHG

24-pin ATX PWR

DIMM2B

Floppy

Battery

JP3
JWD
JLED

FAN3

I-SATA4

FAN4

I-SATA5

LE1

Front Panel CTRL

JL1

Front-Access USB 11Front-Access USB 12

A. GLAN Port1 Enable

2-21

C2SBA+II/C2SBA+/C2SBA/C2SBE User's Manual

Clear CMOS

JRTC1/JRTC2 are used to clear CMOS. Close

pins 1 and 2 on both JRTC1/JRTC2 for normal

system operation (*Default). Close pins 2 and

3 on JRCT1/JRTC2 to clear CMOS. Note: For

an ATX power supply, you must completely shut

down the system, remove the AC power cord and

then close pins 2 and 3 to clear CMOS.

Watch Dog Enable/Disable

Watch Dog is a system monitor that can reboot

the system when a software application hangs.

Close pins 1-2 to reset the system if an applica-

tion hangs. Close pins 2-3 to generate a non-

maskable interrupt signal for the application that

hangs. See the table on the right for jumper set-

tings. Watch Dog must also be enabled in the

BIOS. (Note: When enabled, the user needs to

write his/her own application software to disable

the Watch Dog Timer.)

Clear CMOS

Jumper Settings

Setting Defi nition

Pins 1-2 Normal (*Default)

Pins 2-3 Clear CMOS

Watch Dog

Jumper Settings

Jumper Setting Defi nition

Pins 1-2 Reset

(*default)

Pins 2-3 NMI

Open Disabled

KB/MOUSE

COM1

VGA

USB

3/4/5/6

USB 1/2

Audio

C2SBA

JKB

Parallel Port

GLAN CTRL

Audio CTRL

CD-IN

Front Audio

CPU Fan

4-Pin PWR

Processor

JFSB2

JFSB1

LAN

JPUSB1

Fan5

Slot7 PCI-E x1

JP5

Audio Enabled

COM2

Slot6 PCI-E x16

Slot5 PCI-E x4

Slot4 PCI-33MHz

Slot2 PCI-33MHz

JFSB3

JI2C1
JI2C2

Slot3 PCI-33MHz

Slot1 PCI-33MHz

JWOR

JPL1

BIOS

JP2

North Bridge

A

Speaker

Buzzer

Intel G33

JRTC1

JRTC2

SPKR1

IDE CTRL

ITE 8212

WO

WOL

Intel ICH9(R)

South Bridge

JPUSB2

FAN1

DIMM1A

FP USB 7/8

FAN2

DIMM2A

DIMM1B

I-SATA2

I-SATA3

I-SATA0

I-SATA1

FP USB 9/10

IDE#2

IDE#1

B

I-SATA4

I-SATA5

Front-Access USB 11Front-Access USB 12

DIMM2B

Battery

JP3
JWD
JLED

S I/O

W83627DHG

24-pin ATX PWR

Floppy

LE1

JL1

FAN3

FAN4

Front Panel CTRL

A. Clear CMOS

B. Watch Dog Enable

2-22

Chapter 2: Installation

CPU Front Side Bus Speed

JFSB1, JFSB2 and JFSB3 allow you to

set the Front Side Bus Frequency. See

the table on the right for pin defi nitions.

(*Default: Auto.)

PCI/PCI-E Slots to SMB
Speeds

Jumpers JI2C1/JI2C2 allow you to con-

nect PCI/PCI-Exp. Slots to the System

Management Bus

open to disable the connection. See the

table on the right for jumper settings.

. The default setting is

CPU FSB Jumper Settings

JFSB3 JFSB2 JFSB1 Frequency

1-2 1-2 1-2 *Auto

Open 2-3 2-3 333MHz

2-3 2-3 2-3 266MHz

2-3 Open 2-3 200MHz

2-3 2-3 Open 133MHz

SMBus to PCI-X/PCI-Exp Slots

Jumper Settings

Jumper Setting Defi nition

Closed Enabled

Open Disabled (*Default)

KB/MOUSE

COM1

VGA

USB

3/4/5/6

USB 1/2

Audio

JKB

Parallel Port

LAN

GLAN CTRL

Audio CTRL

CD-IN

C2SBA

Front Audio

Fan5

JP5

4-Pin PWR

A

B

JPUSB1

JFSB2

JFSB1

Slot7 PCI-E x1

Audio Enabled

COM2

Slot5 PCI-E x4

D

E

Slot4 PCI-33MHz

Processor

JFSB3

C

Slot6 PCI-E x16

JI2C1
JI2C2

JWOR

Slot3 PCI-33MHz

Slot2 PCI-33MHz

Slot1 PCI-33MHz

JPL1

BIOS

JP2

Intel G33

North Bridge

JRTC1
JRTC2

Speaker

Buzzer

SPKR1

IDE CTRL

ITE 8212

WO

WOL

CPU Fan

Intel ICH9(R)

South Bridge

JPUSB2

FAN1

DIMM1A

FP USB 7/8

FAN2

DIMM2A

DIMM1B

I-SATA2

I-SATA3

I-SATA0

I-SATA1

FP USB 9/10

IDE#2

IDE#1

I-SATA4

I-SATA5

Front-Access USB 11Front-Access USB 12

DIMM2B

Battery

JP3
JWD
JLED

S I/O

W83627DHG

24-pin ATX PWR

Floppy

LE1

JL1

FAN3

FAN4

A. JFSB1

B. JFSB2

C. JFSB3

2

C1

D. JI

2

C2

E. JI

Front Panel CTRL

2-23

C2SBA+II/C2SBA+/C2SBA/C2SBE User's Manual

IDE Enable/Disable

JP2 enables or disables IDE#1 and

IDE#2 on the C2SBA+II/C2SBA+.

See the table on the right for jumper

settings.The default setting is en-

Pin# Defi nition

1-2 Enabled (*default)

2-3 Disabled

abled.

TPM Enable (For the
C2SBA/C2SBA+II/C2SBA+)

IDE Enable

TPM Enable

Use JP3 to enable or disable Trust

Platform Module Management (TPM)

on the motherboard. See the table

on the right for jumper settings. The

default setting is Enabled.

CPU Fan

Intel G33

North Bridge

KB/MOUSE

COM1

VGA

USB

3/4/5/6

USB 1/2

Audio

JKB

4-Pin PWR

Processor

Parallel Port

JFSB2

JFSB1

LAN

JPUSB1

Fan5

Slot7 PCI-E x1

JFSB3

FAN1

DIMM1A

FAN2

DIMM2A

DIMM1B

DIMM2B

S I/O

W83627DHG

24-pin ATX PWR

Floppy

Pin# Defi nition

1-2 Enabled (*default)

2-3 Disabled

A. IDE Enable

B. TPM Enable

Audio Enabled

Slot6 PCI-E x16

Slot5 PCI-E x4

Slot4 PCI-33MHz

JI2C1
JI2C2

JWOR

Slot3 PCI-33MHz

BIOS

JPL1

JP2

GLAN CTRL

Audio CTRL

JP5

CD-IN

C2SBA

COM2

Slot2 PCI-33MHz

Slot1 PCI-33MHz

Front Audio

JRTC1

JRTC2

A

Speaker

Buzzer

SPKR1

IDE CTRL

ITE 8212

WO

WOL

Intel ICH9(R)

South Bridge

JPUSB2

FP USB 7/8

I-SATA2

I-SATA3

I-SATA0

I-SATA1

FP USB 9/10

IDE#2

IDE#1

2-24

I-SATA4

I-SATA5

Front-Access USB 11Front-Access USB 12

Battery

JP3
JWD
JLED

LE1

B

FAN3

FAN4

Front Panel CTRL

JL1

Chapter 2: Installation

Audio Enable

JP5 enables or disables the onboard

audio connections. See the table on the

right for jumper settings. The default

setting is Enabled.

Keyboard Wake-Up

The JKB jumper is used together

with the Keyboard Wake-Up function

in BIOS. Enable the jumper and the

BIOS setting to allow the user to "wake

the system up" by hitting a key on the

keyboard. See the table on the right

for jumper settings. Your power supply

must meet ATX specifi cation 2.01 or

higher and supply 720 mA of standby

power to use this feature.

Audio Enable

Pin# Defi nition

1-2 Enabled (*default)

2-3 Disabled

KB Wake-up Enable

Pin# Defi nition

1-2 Enabled (*default)

2-3 Disabled

KB/MOUSE

COM1

VGA

USB

3/4/5/6

USB 1/2

Audio

JKB

B

Parallel Port

LAN

GLAN CTRL

Audio CTRL

CD-IN

C2SBA

Front Audio

Fan5

JP5

4-Pin PWR

JPUSB1

Slot7 PCI-E x1

Audio Enabled

COM2

JFSB2

JFSB1

A

Slot5 PCI-E x4

Slot4 PCI-33MHz

Processor

JFSB3

Slot6 PCI-E x16

JI2C1
JI2C2

JWOR

Slot3 PCI-33MHz

Slot2 PCI-33MHz

Slot1 PCI-33MHz

JPL1

BIOS

JP2

Intel G33

North Bridge

JRTC1
JRTC2

Speaker

Buzzer

SPKR1

IDE CTRL

ITE 8212

WO

WOL

CPU Fan

Intel ICH9(R)

South Bridge

JPUSB2

FAN1

DIMM1A

FP USB 7/8

FAN2

DIMM1B

DIMM2A

I-SATA2

I-SATA3

I-SATA0

I-SATA1

FP USB 9/10

IDE#2

IDE#1

I-SATA4

I-SATA5

Front-Access USB 11Front-Access USB 12

DIMM2B

Battery

JP3
JWD
JLED

S I/O

W83627DHG

24-pin ATX PWR

Floppy

LE1

JL1

FAN3

FAN4

A. Audio Enable

B. KB Wake-up Enable

Front Panel CTRL

2-25

C2SBA+II/C2SBA+/C2SBA/C2SBE User's Manual

USB Wake-Up

Use JPUSB jumpers (JPUSB1/JPUSB2) to en-

able the function of "System Wake-Up via USB

devices", which allows you to "wake-up" the

system by pressing a key on the USB keyboard

or by clicking the USB mouse of your system.

The JPUSB jumpers are used together with the

USB Wake-Up function in the BIOS. Enable

both jumpers and the BIOS setting to allow the

system to "wake-up via USB Devices". See the

table on the right for jumper settings and jumper

connections. (Note: JPUSB1 is for Back Panel

USB ports:1/2/3/4/5/6, and JPUSB2 is for Front

Panel USB ports:7/8/9/10 and Front Accessible

USB ports: 11/12.)

(Note: The default jumper setting for the USB

ports is "Disabled". However, when the "USB

Wake-Up" function is enabled in the BIOS and

the desired USB ports are enabled via the

JPUSB jumper, please be sure to remove all

USB devices from the USB ports whose USB

jumpers are set to "Disabled" before the system

goes into the standby mode.)

USB Wake-up Enable

Pin# Defi nition

1-2 Enabled

2-3 Disabled

KB/MOUSE

COM1

VGA

USB

3/4/5/6

USB 1/2

Audio

C2SBA

JKB

Parallel Port

GLAN CTRL

Audio CTRL

CD-IN

Front Audio

CPU Fan

4-Pin PWR

Processor

FAN1

FAN2

S I/O

W83627DHG

A. JPUSB1

B. JPUSB2

24-pin ATX PWR

DIMM2B

DIMM2A

DIMM1B

Intel ICH9(R)

South Bridge

JPUSB2

WO

WOL

DIMM1A

FP USB 7/8

B

I-SATA2

I-SATA3

I-SATA0

I-SATA1

FP USB 9/10

IDE#2

IDE#1

I-SATA4

I-SATA5

Front-Access USB 11Front-Access USB 12

Battery

JP3
JWD
JLED

LE1

Floppy

JL1

FAN3

FAN4

Front Panel CTRL

JFSB2

JFSB1

A

LAN

JPUSB1

Fan5

Slot7 PCI-E x1

JP5

Audio Enabled

COM2

Slot6 PCI-E x16

Slot5 PCI-E x4

Slot4 PCI-33MHz

Slot2 PCI-33MHz

JFSB3

JI2C1
JI2C2

Slot3 PCI-33MHz

Slot1 PCI-33MHz

JWOR

JPL1

BIOS

JP2

Intel G33

North Bridge

JRTC1
JRTC2

Speaker

Buzzer

SPKR1

IDE CTRL

ITE 8212

2-26

Chapter 2: Installation

2-8 Onboard Indicators

GLAN LEDs

A Gigabit-LAN port (J11) is located above

USB Port 1 on the I/O Backpanel. This

Gigabit Ethernet LAN port has two LEDs.

The yellow LED indicates activity, while

the Link LED may be green, amber or

off to indicate the speed of the connec-

tion. See the tables at right for more

information.

Link

LED

Activity

LED

Rear View
(When viewing from the rear
side of the chassis.)

GLAN Activity Indicator

Color Status Defi nition

Yellow Flashing Active

GLAN Link Indicator

LED Color Defi nition

Off No Connection or 10 Mbps

Green (On) 100 Mbps

Amber (On) 1 Gbps

KB/MOUSE

COM1

VGA

USB

3/4/5/6

USB 1/2

Audio

JKB

Parallel Port

LAN

GLAN CTRL

Audio CTRL

CD-IN

C2SBA

Front Audio

Fan5

JP5

4-Pin PWR

A

JPUSB1

JFSB2

JFSB1

Slot7 PCI-E x1

Audio Enabled

COM2

Slot5 PCI-E x4

Slot4 PCI-33MHz

Processor

JFSB3

Slot6 PCI-E x16

JI2C1
JI2C2

JWOR

Slot3 PCI-33MHz

Slot2 PCI-33MHz

Slot1 PCI-33MHz

JPL1

BIOS

JP2

Intel G33

North Bridge

JRTC1
JRTC2

Speaker

Buzzer

SPKR1

IDE CTRL

ITE 8212

WO

WOL

CPU Fan

Intel ICH9(R)

South Bridge

JPUSB2

FAN1

DIMM1A

FP USB 7/8

FAN2

DIMM2A

DIMM1B

I-SATA2

I-SATA3

I-SATA0

I-SATA1

FP USB 9/10

IDE#2

IDE#1

I-SATA4

I-SATA5

Front-Access USB 11Front-Access USB 12

DIMM2B

Battery

JP3
JWD
JLED

S I/O

W83627DHG

24-pin ATX PWR

Floppy

LE1

JL1

FAN3

FAN4

A. GLAN Port1 LEDs

Front Panel CTRL

2-27

C2SBA+II/C2SBA+/C2SBA/C2SBE User's Manual

Onboard Power LED (LE1)

The Onboard 3.3V Standby Power LED is

located at LE1 on the motherboard. When

LE1 is off, the system is off. When the

green light is on, the system is on. When

the LED is on, the power is on. Unplug the

power cable before removing or installing

components. See the layout below for the

LED location.

Onboard PWR LED Indicator

LED Color Defi nition

Off System Off

On Standby Power On

Green System On

KB/MOUSE

COM1

VGA

USB

3/4/5/6

USB 1/2

Audio

C2SBA

JKB

Parallel Port

GLAN CTRL

Audio CTRL

CD-IN

Front Audio

CPU Fan

4-Pin PWR

Processor

JFSB2

JFSB1

LAN

JPUSB1

Fan5

Slot7 PCI-E x1

JP5

Audio Enabled

COM2

Slot6 PCI-E x16

Slot5 PCI-E x4

Slot4 PCI-33MHz

Slot2 PCI-33MHz

JFSB3

JI2C1
JI2C2

Slot3 PCI-33MHz

Slot1 PCI-33MHz

JWOR

JPL1

BIOS

JP2

Intel G33

North Bridge

JRTC1

JRTC2

Speaker

Buzzer

SPKR1

IDE CTRL

ITE 8212

WO

WOL

Intel ICH9(R)

South Bridge

JPUSB2

FAN1

DIMM1A

FP USB 7/8

FAN2

DIMM2A

DIMM1B

I-SATA2

I-SATA3

I-SATA0

I-SATA1

FP USB 9/10

IDE#2

IDE#1

I-SATA4

I-SATA5

Front-Access USB 11Front-Access USB 12

DIMM2B

A

S I/O

W83627DHG

24-pin ATX PWR

Floppy

Battery

JP3
JWD
JLED

LE1

A. Power LED

FAN3

FAN4

Front Panel CTRL

JL1

2-28

Chapter 2: Installation

2-9 Parallel Port, Floppy Drive and IDE Hard Drive
Connections

Note the following when connecting the fl oppy and hard disk drive cables:

• The fl oppy disk drive cable has seven twisted wires.

• A red mark on a wire typically designates the location of pin 1.

• A single fl oppy disk drive ribbon cable has two connectors to provide for two

fl oppy disk drives. The connector with twisted wires always connects to drive

A, and the connector that does not have twisted wires always connects to drive

B.

Parallel (Printer) Port
Connector

The parallel (printer) port is located

at J30. See the table on the right for

pin defi nitions.

Pin# Defi nition Pin # Defi nition

1 Strobe- 2 Auto Feed-

3 Data Bit 0 4 Error-

5 Data Bit 1 6 Init-

7 Data Bit 2 8 SLCT IN-

9 Data Bit 3 10 GND

11 Data Bit 4 12 GND

13 Data Bit 5 14 GND

15 Data Bit 6 16 GND

17 Data Bit 7 18 GND

19 ACK 20 GND

21 BUSY 22 Write Data

23 PE 24 Write Gate

25 SLCT 26 NC

Parallel (Printer) Port Connector

Pin Defi nitions

KB/MOUSE

COM1

VGA

USB

3/4/5/6

USB 1/2

Audio

C2SBA

JKB

Parallel Port

GLAN CTRL

Audio CTRL

CD-IN

Front Audio

CPU Fan

4-Pin PWR

Processor

FAN1

FAN2

SI/O

W83627DHG

A

24-pin ATX PWR

DIMM2B

DIMM2A

DIMM1B

Intel ICH9(R)

South Bridge

JPUSB2

WOL

WO

DIMM1A

FP USB 7/8

I-SATA2

I-SATA3

I-SATA0

I-SATA1

FP USB 9 /10

IDE#2

IDE#1

Front-Access USB 11Front-Access USB 12

I-SATA4

I-SATA5

Battery

JP3

JWD

JLED

Floppy

LE1

A. Parallel Port

FAN3

FAN4

Front Panel CTRL

JL1

JFSB2

JFSB1

LAN

JPUSB1

Fan5

Slot7 PCI-E x1

JP5

Audio Enabled

COM2

Slot5 PCI-E x4

Slot4 PCI-33MHz

JFSB3

Slot6 PCI-E x16

JI2C1
JI2C2

Slot3 PCI-33MHz

Slot2 PCI-33MHz

Slot1 PCI-33MHz

JWOR

JPL1

BIOS

JP2

Intel G33

North Bridge

JRTC1
JRTC2

Speaker

Buzzer

SPKR1

IDE CTRL

ITE 8212

2-29

C2SBA+II/C2SBA+/C2SBA/C2SBE User's Manual

Floppy Connector

The fl oppy connector is located at

J27. See the table on the right for pin

defi nitions.

Floppy Drive Connector

Pin Defi nitions

Pin# Defi nition Pin # Defi nition

1 Ground 2 FDHDIN

3 Ground 4 Reserved

5 Key 6 FDEDIN

7 Ground 8 Index

9 Ground 10 Motor Enable

11 Ground 12 Drive Select B

13 Ground 14 Drive Select B

15 Ground 16 Motor Enable

17 Ground 18 DIR

19 Ground 20 STEP

21 Ground 22 Write Data

23 Ground 24 Write Gate

25 Ground 26 Track 00

27 Ground 28 Write Protect

29 Ground 30 Read Data

31 Ground 32 Side 1 Select

33 Ground 34 Diskette

KB/MOUSE

COM1

VGA

USB

3/4/5/6

USB 1/2

Audio

C2SBA

JKB

Parallel Port

GLAN CTRL

Audio CTRL

CD-IN

Front Audio

CPU Fan

4-Pin PWR

Processor

JFSB2

JFSB1

LAN

JPUSB1

Fan5

Slot7 PCI-E x1

JP5

Audio Enabled

COM2

Slot6 PCI-E x16

Slot5 PCI-E x4

Slot4 PCI-33MHz

Slot2 PCI-33MHz

JFSB3

JI2C1
JI2C2

Slot3 PCI-33MHz

Slot1 PCI-33MHz

JWOR

JPL1

BIOS

JP2

Intel G33

North Bridge

JRTC1

JRTC2

Speaker

Buzzer

SPKR1

IDE CTRL

ITE 8212

WO

WOL

Intel ICH9(R)

South Bridge

JPUSB2

FAN1

DIMM1A

FP USB 7/8

FAN2

DIMM2A

DIMM1B

I-SATA2

I-SATA3

I-SATA0

I-SATA1

FP USB 9/10

IDE#2

IDE#1

I-SATA4

I-SATA5

Front-Access USB 11Front-Access USB 12

DIMM2B

Battery

JP3
JWD
JLED

S I/O

W83627DHG

24-pin ATX PWR

Floppy

LE1

JL1

FAN3

FAN4

Front Panel CTRL

A. Floppy

A

2-30

Chapter 2: Installation

IDE Connectors (For the
C2SBA+II/C2SBA+ only)

There are two ITE IDE connectors on

the C2SBA+II/C2SBA+. Be sure to

close Pin 1 and Pin 2 of JP2 to enable

the IDE connectors before using them.

(Please refer to the jumper section for

more details.) See the table on the right

for pin defi nitions.

IDE Drive Connectors

Pin Defi nitions

Pin# Defi nition Pin # Defi nition

1 Reset IDE 2 Ground

3 Host Data 7 4 Host Data 8

5 Host Data 6 6 Host Data 9

7 Host Data 5 8 Host Data 10

9 Host Data 4 10 Host Data 11

11 Host Data 3 12 Host Data 12

13 Host Data 2 14 Host Data 13

15 Host Data 1 16 Host Data 14

17 Host Data 0 18 Host Data 15

19 Ground 20 Key

21 DRQ3 22 Ground

23 I/O Write 24 Ground

25 I/O Read 26 Ground

27 IOCHRDY 28 BALE

29 DACK3 30 Ground

31 IRQ14 32 IOCS16

33 Addr1 34 Ground

35 Addr0 36 Addr2

37 Chip Select 0 38 Chip Select 1

39 Activity 40 Ground

KB/MOUSE

COM1

VGA

USB

3/4/5/6

USB 1/2

Audio

C2SBA

JKB

Parallel Port

GLAN CTRL

Audio CTRL

CD-IN

Front Audio

CPU Fan

4-Pin PWR

Processor

JFSB2

JFSB1

LAN

JPUSB1

Fan5

Slot7 PCI-E x1

JP5

Audio Enabled

COM2

Slot6 PCI-E x16

Slot5 PCI-E x4

Slot4 PCI-33MHz

Slot2 PCI-33MHz

JFSB3

JI2C1
JI2C2

Slot3 PCI-33MHz

Slot1 PCI-33MHz

JWOR

JPL1

BIOS

JP2

Intel G33

North Bridge

JRTC1
JRTC2

Speaker

Buzzer

SPKR1

Intel ICH9(R)

IDE CTRL

ITE 8212

WO

WOL

South Bridge

JPUSB2

FAN1

DIMM1A

FP USB 7/8

FAN2

DIMM2A

DIMM1B

I-SATA2

I-SATA3

I-SATA0

I-SATA1

FP USB 9/10

IDE#2

IDE#1

Front-Access USB 11Front-Access USB 12

DIMM2B

I-SATA4

I-SATA5

S I/O

W83627DHG

24-pin ATX PWR

Floppy

Battery

JP3
JWD
JLED

LE1

JL1

A. IDE#1

B. IDE#2

FAN3

FAN4

Front Panel CTRL

B

A

2-31

C2SBA+II/C2SBA+/C2SBA/C2SBE User's Manual

Notes

2-32

Chapter 3: Troubleshooting

Chapter 3

Troubleshooting

3-1 Troubleshooting Procedures

Use the following procedures to troubleshoot your system. If you have followed all

of the procedures below and still need assistance, refer to the ‘Technical Support

Procedures’ and/or ‘Returning Merchandise for Service’ section(s) in this chapter.

Always disconnect the AC power cord before adding, changing or installing any

hardware components.

Before Power On

1. Make sure that there are no short circuits between the motherboard and chas-

sis.

2. Disconnect all ribbon/wire cables from the motherboard, including those for the

keyboard and mouse.

3. Remove all add-on cards.

4. Install a CPU and heatsink (making sure it is fully seated) and connect the

chassis speaker and the power LED to the motherboard. Check all jumper

settings as well.

5. Use the correct type of onboard CMOS battery as specifi ed by the Manufacturer.

Do not install the CMOS battery upside down to avoid possible explosion.

6. Make sure that the 4-pin 12v power connector at J41 is connected to your

power supply.

No Power

1. Make sure that there are no short circuits between the motherboard and chas-

sis.

2. Verify that all jumpers are set to their default positions.

3. Check that the 115V/230V switch on the power supply is properly set.

4. Turn the power switch on and off to test the system.

5. The battery on your motherboard may be old. Check to verify that it still sup-

plies ~3VDC. If it does not, replace it with a new one.

No Video

1. If the power is on but you have no video, remove all the add-on cards and

cables.

2. Use the speaker to determine if any beep codes exist. Refer to Appendix A for

details on beep codes.

3-1

C2SBA+II/C2SBA+/C2SBA/C2SBE User's Manual

NOTE

If you are a system integrator, VAR or OEM, a POST diagnostics

card is recommended. For I/O port 80h codes, refer to App. B.

Memory Errors

1. Make sure that the DIMM modules are properly and fully installed.

2. You should be using unbuffered DDR2 memory (see the next page). Also, it

is recommended that you use the same memory speed for all DIMMs in the

system. See Section 2-4 for memory limitations.

3. Check for bad DIMM modules or slots by swapping modules between slots and

noting the results.

4. Check the power supply voltage 115V/230V switch.

Losing the System’s Setup Confi guration

1. Make sure that you are using a high quality power supply. A poor quality power

supply may cause the system to lose the CMOS setup information. Refer to

Section 1-6 for details on recommended power supplies.

2. The battery on your motherboard may be old. Check to verify that it still sup-

plies ~3VDC. If it does not, replace it with a new one.

3. If the above steps do not fi x the Setup Confi guration problem, contact your

vendor for repairs.

3-2 Technical Support Procedures

Before contacting Technical Support, please take the following steps. Also, note

that as a motherboard manufacturer, Super Micro does not sell directly to end-us-

ers, so it is best to fi rst check with your distributor or reseller for troubleshooting

services. They should know of any possible problem(s) with the specifi c system

confi guration that was sold to you.

1. Please go through the ‘Troubleshooting Procedures’ and 'Frequently Asked

Question' (FAQ) sections in this chapter or see the FAQs on our web site

(

http://www.supermicro.com/support/faqs/) before contacting Technical

Support.

2. BIOS upgrades can be downloaded from our web site at

com/support/bios/

).

(http://www.supermicro

Note: Not all BIOS can be fl ashed; it depends on the modifi cations to the

boot block code.

3. If you still cannot resolve the problem, include the following information when

3-2

Chapter 3: Troubleshooting

contacting Super Micro for technical support:

• Motherboard model and PCB revision number

• BIOS release date/version (this can be seen on the initial display when your

system fi rst boots up)

• System confi guration

An example of a Technical Support form is on our web site at

supermicro.com/support/contact.cfm).

4. Distributors: For immediate assistance, please have your account number ready

when placing a call to our technical support department. We can be reached

by e-mail at [e-mail], by phone at:[phone], option

2, or by fax at [phone].

(http://www.

3-3 Frequently Asked Questions

Question: What type of memory does my motherboard support?

Answer: The C2SBA+II/C2SBA+/C2SBA/C2SBE supports unbuffered, DDR2

667/800 MHz memory modules. See Section 2-4 for details on installing mem-

ory.

Question: How do I update my BIOS?

Answer: It is recommended that you not upgrade your BIOS if you are not ex-

periencing problems with your system. Updated BIOS fi les are located on our

web site at

warning message and the information on how to update your BIOS on our web

site. Also, check the current BIOS revision and make sure it is newer than your

current BIOS before downloading. Select your mainboard model and download

the BIOS fi le to your computer. Unzip the BIOS update fi le and follow the readme.

txt to fl ash the BIOS. You can also run an .exe fi le from our web site to create a

bootable fl oppy disk and fl ash the BIOS automatically. (Note: It may take about 1

minute to load the fl ash BIOS fi le. Please allow enough time for the fl ash process

to complete.)

Question: What's on the CD that came with my motherboard?

Answer: The supplied compact disc has quite a few drivers and programs that

will greatly enhance your system. We recommend that you review the CD and

install the applications you need. Applications on the CD include chipset drivers,

security and audio drivers.

(http://www.supermicro com/support/bios/). Please check our BIOS

Question: How do I utilize the onboard HD sound?

Answer: The onboard HD sound available on the C2SBA+II/C2SBA+/C2SBA/

C2SBE can be enabled with the audio driver software that was included in your

motherboard package. When activated, sound will be routed through the jacks

next to the LAN Port according to the audio connection descriptions listed on Page

3-3

C2SBA+II/C2SBA+/C2SBA/C2SBE User's Manual

2-8. You must also set the HD Audio setting to "Auto" in the Advanced Chipset

section of the BIOS setup.

Question: I installed my microphone correctly but I can't record any sound.

What should I do?

Answer: Go to <Start>, <Programs>, <Accessories>, <Entertainment> and then

<Volume Control>. Under the Properties tab, scroll down the list of devices in the

menu and check the box beside "Microphone".

Question: After I have installed 4 pieces of 1GB Memory, why does the BIOS

only detect about 3.145 GB of memory during POST?

Answer: Because the chipset does not support memory remapping, and PCI-E

memory requires a great deal of memory, so there is a memory hole located

around the 4GB memory address.

Question: How do I connect the ATA100/66 cable to my IDE device(s)?

Answer: The 80-wire/40-pin high-density ATA100/66 IDE cable that came with

your system has two connectors to support two drives. This special cable must be

used to take advantage of the speed the ATA100/66 technology offers. Connect

the blue connector to the onboard IDE header and the other connector(s)

to your hard drive(s). Consult the documentation that came with your disk drive

for details on actual jumper locations and settings.

3-4 Returning Merchandise for Service

A receipt or copy of your invoice marked with the date of purchase is required

before any warranty service will be rendered. You can obtain service by calling

your vendor for a Returned Merchandise Authorization (RMA) number. When

returning to the manufacturer, the RMA number should be prominently displayed

on the outside of the shipping carton, and mailed prepaid or hand-carried. Ship-

ping and handling charges will be applied for all orders that must be mailed when

service is complete.

This warranty only covers normal consumer use and does not cover damages

incurred in shipping or from failure due to the alteration, misuse, abuse or improper

maintenance of products.

During the warranty period, contact your distributor fi rst for any product prob-

lems.

3-4

Chapter 4: BIOS

Chapter 4
BIOS

4-1 Introduction

This chapter describes the Phoenix BIOS™ Setup utility for the C2SBA+II/

C2SBA+/C2SBA/C2SBE. The Phoenix ROM BIOS is stored in a fl ash chip and

can be easily upgraded using a fl oppy disk-based program.

Note: Due to periodic changes to the BIOS, some settings may have been added

or deleted and might not yet be recorded in this manual. Please refer to the Manual

Download area of the Super Micro web site <http://www.supermicro.com> for any

changes to the BIOS not refl ected in this manual.

System BIOS

The BIOS is the Basic Input Output System used in all IBM® PC, XT™, AT®, and

PS/2® compatible computers. The Phoenix BIOS stores the system parameters,

types of disk drives, video displays, etc. in the CMOS. The CMOS memory re-

qu ires very little ele c t r ical power. When the c ompu ter is tur ned of f, a backup batter y

provides power to the CMOS logic, enabling it to retain system parameters. Each

time the computer is powered on, the computer is confi gured with the values stored

in the CMOS logic by the system BIOS, which gains control at boot-up.

How To Change the Confi guration Data

The CMOS information that determines the system parameters may be changed

by entering the BIOS Setup utility. This Setup utility can be accessed by pressing

the <Delete> key at the appropriate time during system boot. (See below.)

Starting the Setup Utility

Normally, the only visible POST (Power On Self Test) routine is the memory test.

As the memory is being tested, press the <Delete> key to enter the main menu

of the BIOS Setup utility. From the main menu, you can access the other setup

screens, such as the Security and Power menus. Beginning with Section 4-3,

detailed descriptions are given for each parameter setting in the Setup utility.

Warning: Do not shut down or reset the system while updating the BIOS

to prevent possible boot failure.

4-1

C2SBA+II/C2SBA+/C2SBA/C2SBE User's Manual

4-2 Running Setup

*Default settings are in bold text unless otherwise noted.

The BIOS setup options described in this section are selected by choosing the ap-

propriate text from the main BIOS Setup screen. All displayed text is described in

this section, although the screen display is often all you need to understand how

to set the options (see the next page).

When you fi rst power on the computer, the Phoenix BIOS™ is immediately acti-

vated.

While the BIOS is in control, the Setup program can be activated in one of two

ways:

1. By pressing <Delete> immediately after turning the system on, or

2. When the message shown below appears briefl y at the bottom of the screen

during the POST (Power On Self-Test), press the <Delete> key to activate

the main Setup menu. Press the <Delete> key to enter Setup

4-3 Main BIOS Setup

All main Setup options are described in this section. The main BIOS Setup screen

is displayed below.

Use the Up/Down arrow keys to move among the different settings in each menu.

Use the Left/Right arrow keys to change the options for each setting.

Press the <Esc> key to exit the CMOS Setup Menu. The next section describes in

detail how to navigate through the menus.

Items that use submenus are indicated with the

press the <Enter> key to access the submenu.

icon. With the item highlighted,

4-2

Main BIOS Setup Menu

Chapter 4: BIOS

Main Setup Features

System Time

To set the system date and time, key in the correct information in the appropriate

fi elds. Then press the <Enter> key to save the data.

System Date

Using the arrow keys, highlight the month, day and year fi elds, and enter the correct

data. Press the <Enter> key to save the data.

Legacy Diskette A

This setting allows the user to set the type of fl oppy disk drive installed as diskette A.

The options are Disabled, 360Kb 5.25 in, 1.2MB 5.25 in, 720Kb 3.5 in, 1.44/1.25MB,

3.5 in and 2.88MB 3.5 in.

BIOS Date

The item displays the date that the BIOS was built.

Hard Disk Pre-Delay

Select Enable to allow for the time needed for a hard drive to perform initialization

before it is accessed by the BIOS after power-up to prevent possible system boot

failure. A boot failure may occur if the BIOS accesses a hard drive that has not

been properly initialized. The default setting is Disabled.

4-3

C2SBA+II/C2SBA+/C2SBA/C2SBE User's Manual

Serial ATA

This setting allows the user to enable or disable the function of the Serial ATA. The

options are Disabled and Enabled.

Native Mode Operation

Select Serial ATA for SATA or select Auto (Native Mode) for ATA. The
options are: Serial ATA and Auto.

Serial ATA (SATA) RAID Enable

Select Enable to enable Serial ATA RAID Functions. (*For the Windows OS

environment, use the RAID driver if this feature is set to Enabled. When this item

is set to Enabled, the item: "ICH RAID Code Base" will be available for you to select

either Intel or Adaptec Host RAID fi rmware. If this item is set to Disabled, the item-

SATA AHCI Enable will be available.) The options are Enabled and Disabled.

SATA AHCI Enable

Select Enabled to use the Serial ATA Advanced Host Interfacing. This feature is

available when the Windows XP OS, the SPI BIOS Chip, and the IAA Driver are

installed in the system. (*Take caution when using this function. This feature is for

advanced programmers only. The options are Enabled and Disabled.)

SATA AHCI Legacy Enable

Select Enabled use the SATA Advanced Host Interface Legacy Mode. When in AHCI

Legacy Mode, SATA Port 5 and SATA Port 6 are disabled. (*Take caution when

using this function. This feature is for advanced programmers only. The options

are Enabled and Disabled.)

IDE Channel 0 Master/Slave, IDE Channel 1 Master/Slave, SATA
Port2/SATA Port3

These settings allow the user to set the parameters of slots indicated above. Hit

<Enter> to access the following sub-menu screen. Set the correct confi gurations

accordingly.

4-4

Chapter 4: BIOS

Type

This option allows you to select the type of IDE hard drive. Select Auto to allow

BIOS to automatically detect the hard drive's capacity, number of heads, etc.).

The option User allows the user to enter the parameters for the HDD installed

at this connection. Enter a number between 1 to 39 to select a predetermined

HDD type. Select CDROM if a CDROM drive is installed. Select ATAPI if a

removable disk drive is installed.

CHS Format

The following items will be displayed by the BIOS:

TYPE: This item displays the type of IDE or SATA Device.

Cylinders: This item indicates the status of Cylinders.

Headers: This item indicates the number of headers.

Sectors: This item displays the number of sectors.

Maximum Capacity: This item displays the maximum storage capacity of

the system.

4-5

C2SBA+II/C2SBA+/C2SBA/C2SBE User's Manual

LBA Format

The following items will be displayed by the BIOS:

Total Sectors: This item displays the number of total sectors available in the

LBA Format.

Maximum Capacity: This item displays the maximum capacity in the LBA

Format.

Multi-Sector Transfers

This item allows the user to specify the number of sectors per block to be used

in the multi-sector transfer. The options are Disabled, 4 Sectors, 8 Sectors, and

16 Sectors.

LBA Mode Control

This item determines whether the Phoenix BIOS will access the IDE Channel 0

Master Device via the LBA mode. The options are Enabled and Disabled.

32 Bit I/O

This option allows the user to enable or disable the function of a 32-bit data

transfer. The options are Enabled and Disabled.

Transfer Mode

This option allows the user to set the transfer mode. The options are Standard,

Fast PIO1, Fast PIO2, Fast PIO3, Fast PIO4, FPIO3/DMA1 and FPIO4/DMA2.

Ultra DMA Mode

This option allows the user to select Ultra DMA Mode. The options are Disabled,

Mode 0, Mode 1, Mode 2, Mode 3, Mode 4, and Mode 5.

System Memory

This display informs you how much system memory is recognized as being present

in the system.

Extended Memory

This display informs you how much extended memory is recognized as being

present in the system.

4-6

Chapter 4: BIOS

4-4 Advanced Setup

Choose Advanced from the Phoenix BIOS Setup Utility main menu with the arrow

keys. You should see the following display. The items with a triangle beside them have

sub- menus that can be accessed by highlighting the item and pressing <Enter>.

Boot Features

Floppy Check

Select Enabled to allow the BIOS to verify the type of fl oppy drive at bootup.

Select Disabled to speed up the boot process. The settings are Enabled and

Disabled.

Quiet Mode

This setting allows you to Enable or Disable the graphic logo screen display

during bootup.

QuickBoot Mode

If enabled, this feature will speed up the POST (Power On Self Test) routine by

skipping certain tests after the computer is turned on. The settings are Enabled

and Disabled. If Disabled, the POST routine will run at normal speed.

ACPI Mode

Use this setting to determine whether you want to use the ACPI (Advanced

Confi guration and Power Interface) power management on your system. The

options are Yes and No.

4-7

C2SBA+II/C2SBA+/C2SBA/C2SBE User's Manual

ACPI Sleep Mode

This setting allows you to confi gure the ACPI (Advanced Confi guration and Power

Interface) Sleep Mode for your system. The options are S1, S3 and S1S3.

High Precision Event Time

Select Yes to activate the High Precision Event Timer (HPET) that produce

periodic interrupts at a much higher frequency than a Real-time Clock (RTC) can

in synchronizing multimedia streams, providing smooth playback and reducing

the dependency on other timestamp calculation devices, such as an x86 RDTSC

Instruction embedded in a CPU. The High Precision Event Timer is used to

replace the 8254 Programmable Interval Timer. The default setting is No.

Power Button Behavior

If set to Instant-Off, the system will power on or power off the system immediately
as soon as the user hits the power button. The options are Instant-Off and
4-second Override.

Resume On Modem Ring

Select On to “wake your system up” when an incoming call is received by your
modem. The options are On and Off.

Resume On PME#

Select On to “wake your system up” from the PME#. The options are On and

Off.

PS2 Keyboard (KB)/Mouse Wake Up

Select Enable to “wake your system up” from S3, S4 or S5 state. The options
are Enabled and Disabled. (This feature is available when the jumper-JPWAKE
is enabled by closing pin 1 and pin 2. Please refer to Chapter 2.)

Power Loss Control

This setting allows you to decide how the system will react when power returns

after an unexpected loss of power. The options are Stay Off, Power On, and

Last State.

Legacy USB Support

Select Enabled to enable Legacy USB Support. The options are Enabled and

Disabled.

Watch Dog

Select Enabled to automatically reset the system if the system is not active for

more than 4 minutes. The options are Enabled and Disabled.

Summary Screen

This setting allows you to Enable or Disable the summary screen which displays

the system confi guration during bootup.

4-8

Chapter 4: BIOS

Advanced Processor Options

Access the submenu to make changes to the following settings.

CPU Speed

This is a display that indicates the speed of the installed processor.

Frequency Ratio (*Available when supported by the CPU.)

The feature allows the user to set the internal frequency multiplier ratio for the CPU.

The options are: Default, x6, x7, x8, x9, x10 and x11.

Frequency High Ratio (*Available when supported by the CPU.)

The feature allows the user to set the high ratio internal frequency multiplier for the

Intel SpeedStep CPUs. The settings are: Disabled, +5%, +10%, +15% and +20%.

(Note: If a wrong ratio that is not supported by the CPU is selected, the system

may hang. If this happens, clear the CMOS to recover the system.)

Hyperthreading (*Available when supported by the CPU.)

Set to Enabled to use the Hyperthreading Technology, which will result in increased

CPU performance. The options are Disabled and Enabled.

Core-Multi-Processing (*Available when supported by the CPU.)

Set to Enabled to use a processor's Second Core and beyond. (Please refer to

Intel's web site for more information.) The options are Disabled and Enabled.

Single-Logical Processing

When set to Enabled, only one CPU thread/core will be enabled when a multi-core

processor is installed in the system. The options are Enabled and Disabled.

Machine Checking (*Available when supported by the CPU.)

Set to Enabled to activate the function of Machine Checking and allow the CPU to

detect and report hardware (machine) errors via a set of model-specifi c registers

(MSRs). The options are Disabled and Enabled.

Fast String Operations (*Available when supported by the CPU.)

Set to Enabled to enable the fast string operations for special CPU instructions.

The options are Disabled and Enabled.

Compatible FPU Code (*Available when supported by the CPU.)

Set to Enabled to keep the content of the last instruction Operating Code (OPCode)

in the fl oating point (FP) state. The options are Disabled and Enabled.

4-9

C2SBA+II/C2SBA+/C2SBA/C2SBE User's Manual

Thermal Management 2 (*Available when supported by the CPU.)

Set to Enabled to use the Thermal Management 2 (TM2) Technology, which will lower

the CPU voltage and frequency when the CPU temperature reaches a predefi ned

overheat threshold. Set to Disabled to use Thermal Manager 1 (TM1), and allow

CPU clocking to be regulated via the CPU Internal Clock modulation when the CPU

temperature reaches the overheat threshold.

Adjacent Cache Line Prefetch (*Available when supported by the CPU.)

The CPU fetches the cache line for 64 bytes if this option is set to Disabled. The

CPU fetches both cache lines for 128 bytes as comprised if Enabled. The options

are Disabled and Enabled.

Set Maximum Ext. CPUID=3

When set to Enabled, the Maximum Extended CPUID will be set to 3. The options

are Disabled and Enabled.

Echo TPR

Set to Enabled to prevent xTPR messages from being sent to the system. The

options are Disabled and Enabled.

C1 Enhanced Mode (*Available when supported by the CPU.)

Set to Enabled to enable the Enhanced Halt State to lower CPU voltage/frequen-

cy to prevent overheat. The options are Enabled and Disabled. (Note: Please

refer to Intel’s web site for detailed information.)

Intel <R> Virtualization Technology (*Available when supported by
the CPU.)

Select Enabled to use the feature of Virtualization Technology to allow one platform

to run multiple operating systems and applications in independent partitions,

creating multiple virtual systems in one computer. The options are Enabled and

Disabled. (Note: If there is any change to this setting, you will need to power off

and restart the system for the change to take effect.) Please refer to Intel’s web

site for detailed information.

No Execute Mode Memory Protection (*Available when supported by the

CPU and the OS.)

Set to Enabled to enable Execute Disable Bit and allow the processor to classify

areas in memory where an application code can execute and where it cannot, and

thus preventing a worm or a virus from inserting and creating a fl ood of codes to

overwhelm the processor or damage the system during an attack.

Note: This feature is available when your OS and your CPU support the function

of Execute Disable Bit. For more information, please visit Intel and Microsoft web

sites. The options are Disabled and Enabled.

4-10

Chapter 4: BIOS

Intel Speed Step Support (*Available when supported by the CPU.)

Select Enabled to use the Enhanced Intel SpeedStep Technology and allow the

system to automatically adjust the processor voltage and core frequency in an effort

to reduce power consumption and heat dissipation. The options are Enabled (-C

States, GV1/GV3 are enabled), GV1/GV3 Only (C States: Disabled), C-States Only

(-G1/G3: Disabled), and Disabled (-C States, GV1/GV3 are disabled). Please refer

to Intel’s web site for detailed information.

Advanced Chipset Control

Access the submenu to make changes to the following settings.

*Warning: Take caution when changing the Advanced settings. An incorrect

setting, a very high DRAM frequency or an incorrect DRAM timing may result in

system instability. When this occurs, reset the setting to the default setting.

Clock Spectrum Feature

When set to Enabled, the BIOS will monitor the level of Electromagnetic Interference

caused by the components and will attempt to decrease the interference whenever

needed. The options are Enabled and Disabled.

Integrated Device Control Sub-menu

USB Host Controller 1

This feature allows the user to confi gure the control setting for USB Host Controller

1. The default setting is Functions 0, 1, 2, 3, 7. (Fun0: USB 1/2 Control, Fun1:

USB 3/4 Control, Fun2: USB 5/6 Control, Fun3: USB 11/12 Control, Fun7:

USB 1-6 USB 2.0 Control)

USB Host Controller 2

This feature allows the user to confi gure the control setting for USB Host

Controller 2. The default setting is Functions 0, 1, 2, 7. (Fun0: USB 7/8 Control,

Fun1: USB 9/10 Control, Fun2: USB 11/12 Control, Fun7: USB 7-12 USB

2.0 Control)

Memory Reclaiming

Select Enable to enable the functionality of Memory Remapping above 4GB. The

settings are Enabled and Disabled.

Default Primary Video Adapter

This feature allows the user to select the video device used by the BIOS during

POST. If set to Auto, PEG, PCI, IGD (Internal Graphics Device) devices will be

selected. If set to IGD (Internal Graphics Device), IGD and PCI devices will be

selected. If set to PEG, PEG and PCI devices will be selected. If set to PCI, PCI,

PEG and IGD devices will be selected.

4-11

C2SBA+II/C2SBA+/C2SBA/C2SBE User's Manual

IGD-Device 2

This feature allows the user to enable or disable Internal Graphics Device#2 by

entering a specifi ed value.

IGD-Device 2, Function 1

This feature allows the user to enable or disable Function#1 of Internal Graphics

Device#2 by entering a specifi ed value.

DVMT 4.0 Mode

This feature allows the user to confi gure the DVMT 4.0 Graphics Memory to be used

by the Internal Graphics Device. The options are Fixed, DVMT and Auto.

Pre-allocated Memory Size

This feature allows the user to set the total amount of Pre-allocated graphics memory

to be used by the Internal Graphics Device. The options are 1 MB and 8 MB.

IGD Memory Size

This feature allows the user to set the total amount of graphics memory to be used by

the Internal Graphics Device. The settings are 128 MB, 256 MB and MAXDVMT.

Fixed Graphics Memory

This feature allows the user to display the Fixed Graphics Memory settings.

DVMT Graphics Memory

This feature allows the user to display the DVMT Graphics Memory settings.

Azalia Audio Controller

This option allows the user to enable or disable the onboard Azalia Audio Controller.

Select Auto to allow the HD Audio Controller to be automatically enabled when

detected by the BIOS. The options are Enable, Disabled and Auto.

Route Port 80h Cycles to

This feature allows the user to decide which bus to send debug information to. The

options are Disabled, PCI and LPC.

4-12

Chapter 4: BIOS

Memory Cache

Cache System BIOS Area

This setting allows you to designate a reserve area in the system memory to be used

as a System BIOS buffer and allow BIOS to write (cache) data into this reserved

memory area. Select Write Protect to enable this function, and this area will be

reserved for BIOS ROM access only. Select Uncached to disable this function and

make this area available for other devices.

Cache Video BIOS Area

This setting allows you to designate a reserve area in the system memory to be

used as a Video BIOS buffer and allow BIOS to write (cache) data into this reserved

memory area. Select Write Protect to enable the function and this area will be

reserved for Video BIOS ROM access only. Select Uncached to disable this function

and make this area available for other devices.

Cache Base 0-512K

If enabled, this feature will allow the data stored in the base memory area: block

0-512K to be cached (written) into a buffer, a storage area in the Static DROM

(SDROM) or to be written into L1, L2 cache inside the CPU to speed up CPU

operations. Select Uncached to disable this function. Select Write Through to allow

data to be cached into the buffer and written into the system memory at the

same time. Select Write Protect to prevent data from being written into the base

memory area of Block 0-512K. Select Write Back to allow the CPU to write data

back directly from the buffer without writing data to the System Memory for fast

CPU data processing and operation. The options are Uncached, Write Through,

Write Protect, and Write Back.

Cache Base 512K-640K

If enabled, this feature will allow the data stored in the memory area: 512K-640K

to be cached (written) into a buffer, a storage area in the Static DROM (SDROM)

or written into L1, L2, L3 cache inside the CPU to speed up CPU operations.

Select Uncached to disable this function. Select Write Through to allow data to

be cached into the buffer and written into the system memory at the same time.

Select Write Protect to prevent data from being written into the base memory

area of Block 512K-640K. Select Write Back to allow the CPU to write data back

directly from the buffer without writing data to the System Memory for fast CPU

data processing and operation. The options are Uncached, Write Through, Write

Protect, and Write Back.

Cache Extended Memory

If enabled, this feature will allow the data stored in the extended memory area to

be cached (written) into a buffer, a storage area in the Static DROM (SDROM) or

written into L1, L2, L3 cache inside the CPU to speed up CPU operations. Select

4-13

C2SBA+II/C2SBA+/C2SBA/C2SBE User's Manual

Uncached to disable this function. Select Write Through to allow data to be cached

into the buffer and written into the system memory at the same time. Select Write

Protect to prevent data from being written into the extended memory area above 1

MB. Select Write Back to allow the CPU to write data back directly from the buffer

without writing data to the System Memory for fast CPU data processing and operation.

The options are Uncached, Write Through, Write Protect, and Write Back.

Cache A000-AFFF
Cache B000-BFFF
Cache C800-CBFF
Cache CC00-CFFF
Cache D000-D3FF
Cache D400-D7FF
Cache D800-DBFF
Cache DC00-DFFF

Select Disabled to prevent the data stored in the memory block specifi ed from being

cached into a cache area in the CPU or a buffer in the Static DROM. Select USWC

Caching to use the Uncached, Speculative and Write Combined Mode for the data

in the memory block specifi ed. Select Write Through to allow the data stored in the

memory block specifi ed to be cached into a CPU cache area and written into the

system memory at the same time. Select Write Protect to prevent data from being

written into the memory block specifi ed. Select Write Back to allow the CPU to write

data back directly from the buffer to the memory block specifi ed without writing data

to the System Memory for fast CPU data processing and operation. The options are

Disabled, USWC Caching, Write Through, Write Protect, and Write Back.

Cache E000-E3FF
Cache E400-E7FF
Cache E800-EBFF
Cache EC00-EFFF

Select Disabled to prevent the data stored in the memory block specifi ed from being

cached into a cache area in the CPU or a buffer in the Static DROM. Select USWC

Caching to use the Uncached, Speculative and Write Combined Mode for the data

in the memory block specifi ed. Select Write Through to allow the data stored in the

memory block specifi ed to be cached into a CPU cache area and written into the

system memory at the same time. Select Write Protect to prevent data from being

written into the memory block specifi ed. Select Write Back to allow the CPU to write

data back directly from the buffer to the memory block specifi ed without writing data

to the System Memory for fast CPU data processing and operation. The options are

Disabled, USWC Caching, Write Through, Write Protect, and Write Back.

4-14

Chapter 4: BIOS

PNP Confi guration

Access the submenu to make changes to the following settings for PNP (Play &

Plug) devices.

PCI Device Slot#1 - PCI Device Slot#4

Access the submenu for each of the settings above to make changes to the

following settings:

Option ROM Scan

When enabled, this setting will initialize the device expansion ROM. The options

are Enabled and Disabled.

Enable Master

This setting allows you to enable the selected device as the PCI bus master.

The options are Enabled and Disabled.

Latency Timer

This setting allows you to set the clock rate for the bus master. A high-priority,

high-throughout device may benefi t from a greater clock rate. The options are

Default, 0020h, 0040h, 0060h, 0080h, 00A0h, 00C0h, and 00E0h. For Unix,

Novelle and other Operating Systems, please select the option: other. If a drive

fails after the installation of a new software, you might want to change this setting

and try again. A different OS requires a different Bus master clock rate.

Onboard PCI IDE/Onboard LAN (*PCI IDE: for C2SBA+II/C2SBA+
only)

Option ROM Scan

When enabled, this setting will initialize the device expansion ROM. The options

are Enabled and Disabled.

Enable Master

This setting allows you to enable the selected device as the PCI bus master.

The options are Enabled and Disabled.

Latency Timer

This setting allows you to set the clock rate for the bus master. A high-priority,

high-throughout device may benefi t from a greater clock rate. The options are

Default, 0020h, 0040h, 0060h, 0080h, 00A0h, 00C0h, and 00E0h. For Unix,

Novelle and other Operating Systems, please select the option: other. If a drive

fails after the installation of a new software, you might want to change this setting

and try again. A different OS requires a different bus master clock rate.

4-15

C2SBA+II/C2SBA+/C2SBA/C2SBE User's Manual

IDE RAID Mode (Available on the Onboard PCI IDE Submenu.)

This feature allows you to set the IDE RAID Mode. The default setting is ATA/

ATAPI.

PCI-E x1 Slot

Access the submenu for each of the settings above to make changes to the

following:

PCI Express Port#1

Select Enabled to always enable PCI-Ex1 Port#1. Select Disabled to disable

PCI-Ex1 Port#1 and all other PCI-E ports. When set to Auto, PCI-Ex1 Port#1

will be enabled if a PCI add-on card is detected. The options are Auto, Enabled

and Disabled.

Option ROM Scan

When enabled, this setting will initialize the device expansion ROM. The options

are Enabled and Disabled.

Enable Master

This setting allows you to enable the selected device as the PCI bus master.

The options are Enabled and Disabled.

Latency Timer

This setting allows you to set the clock rate for the bus master. A high-priority,

high-throughout device may benefi t from a greater clock rate. The options are

Default, 0020h, 0040h, 0060h, 0080h, 00A0h, 00C0h, and 00E0h. For Unix,

Novelle and other Operating Systems, please select the option: other. If a drive

fails after the installation of a new software, you might want to change this setting

and try again. A different OS requires a different bus master clock rate.

PEG (PCI-Express Graphics) Port Submenu

Access the submenu for each of the settings above to make changes to the

following:

PCI-Express Graphics (PEG) Port (This submenu is for debugging
only.)

Select Auto to automatically enable the PCI-Express Graphics Port if a PCI

add-on card is detected. Select Disabled to always disable the PEG Port. Select

Enabled to always enable the PEG Port. (Debugging is enabled if a debug card

is detected.) The default setting is Auto.

When the PCI-Exp. Graphics Port is enabled, the following items will be

displayed:

4-16

Chapter 4: BIOS

PEG Port Enabled=
PEG Port Number=
PEG Port Width=
PEG Port Slot Number=
PEG Port Power Limit=
PEG Port Slot Detect=

PCI-Express x4 Slot

Access the submenu for each of the settings above to make changes to the

following:

PCI Express Port#5

Select Enabled to always enable PCI-Ex4 Port#5. Select Disabled to always

disable PCI-Ex4 Port#5. (If PCI-E x1 Port#1 is disabled, PCI-E x4 Port#5 will

be disabled as well). When set to Auto, PCI-Ex4 Port#5 will be enabled if a PCI

add-on card is detected. The options are Auto, Enabled and Disabled.

Option ROM Scan

When enabled, this setting will initialize the device expansion ROM. The options

are Enabled and Disabled.

Enable Master

This setting allows you to enable the selected device as the PCI bus master.

The options are Enabled and Disabled.

Latency Timer

This setting allows you to set the clock rate for the bus master. A high-priority,

high-throughout device may benefi t from a greater clock rate. The options are

Default, 0020h, 0040h, 0060h, 0080h, 00A0h, 00C0h, and 00E0h. For Unix,

Novelle and other Operating Systems, please select the option: other. If a drive

fails after the installation of a new software, you might want to change this setting

and try again. A different OS requires a different bus master clock rate.

4-17

C2SBA+II/C2SBA+/C2SBA/C2SBE User's Manual

I/O Device Confi guration

Access the submenu to make changes to the following settings.

KBC Clock Input

This setting allows you to select the clock frequency for the Keyboard Controller.

The options are 6MHz, 8MHz, 12MHz, and 16MHz.

Serial Port A

This setting allows you to decide how the system controls Serial Port A. The options

are Enabled (user defi ned), Disabled, and Auto (BIOS- or OS- controlled).

Base I/O Address

This setting allows you to select the base I/O address for Serial Port A. The

options are 3F8, 2F8, 3E8, and 2E8.

Interrupt

This setting allows you to select the IRQ (interrupt request) for Serial Port A.

The options are IRQ3 and IRQ4.

Serial Port B

This setting allows you to decide how the system controls Serial Port B. The options

are Enabled (user defi ned), Disabled, Auto (BIOS controlled) and OS Controlled.

Mode

This setting allows you to set the type of device that will be connected to Serial

Port B. The options are Normal and IR (for an infrared device).

Base I/O Address

This setting allows you to select the base I/O address for Serial Port B. The

options are 3F8, 2F8, 3E8 and 2E8.

Interrupt

This setting allows you to select the IRQ (interrupt request) for Serial Port B.

The options are IRQ3 and IRQ4.

Parallel Port

This setting allows you to decide how the system controls the parallel port. The

options are Enabled (user defi ned), Disabled and Auto (BIOS-or OS- controlled).

Base I/O Address

Select the base I/O address for the parallel port. The options are 378, 278

and 3BC.

4-18

Chapter 4: BIOS

Interrupt

This setting allows you to select the IRQ (interrupt request) for the parallel port.

The options are IRQ5 and IRQ7.

Mode

This feature allows you to specify the parallel port mode. The options are Output

only, Bi-Directional, EPP and ECP.

DMA Channel

This item allows you to specify the DMA channel for the parallel port. The

options are DMA1 and DMA3.

Floppy Disk Controller

This setting allows you to assign control of the fl oppy disk controller. The options

are Enabled (user defi ned), Disabled, and Auto (BIOS and OS controlled).

Hardware Monitoring

CPU Overheat Temperature

This option allows the user to set a CPU temperature overheat threshold that will

activate the alarm system when the CPU temperature reaches this pre-set temperature

threshold. The Default setting is 80

Highlight this and hit <Enter> to see monitor data for the following items:

CPU1 Temperature/System Temperature

Fan1 - Fan 5

If the feature of Auto Fan Control is enabled, the BIOS will automatically display

the status of the fan as specifi ed.

Fan Speed Control Modes

This feature allows the user to decide how the system controls the speeds of the

onboard fans. The CPU temperature and the fan speed are correlative. When

the CPU on-die temperature increases, the fan speed will also increase, and vice

versa. If the option is set to “4-pin”, the fan speed will be controlled by Pulse Width

Modulation (PWM). Select “Workstation” if your system is used as a Workstation.

Select “Disable” to disable the fan speed control function to allow the onboard fans

to constantly run at full speed (12V). The Options are: 1. Disable and 2. Optimized

for Workstations with 4-pin.

o

C. (*See the note below.)

Note: In the Windows OS environment, the Supero Doctor III settings take prece-

dence over the BIOS settings. When fi rst installed, Supero Doctor III adopts the

temperature threshold settings previously set in the BIOS. Any subsequent changes

to these thresholds must be made within Supero Doctor, since the SD III settings

override the BIOS settings. For the Windows OS to adopt the BIOS temperature

threshold settings, please change the SDIII settings to be the same as those set

in the BIOS.

4-19

C2SBA+II/C2SBA+/C2SBA/C2SBE User's Manual

Voltage Monitoring

The following items will be monitored and displayed:

Vcore A

12V

V_DIMM

5V

3.3V

-12V

3V Standby

Vbatt.

4-20

Chapter 4: BIOS

4-5 Security Settings

Choose Security from the Phoenix BIOS Setup Utility main menu with the arrow

keys. You should see the following display. Security setting options are displayed

by highlighting the setting using the arrow keys and pressing <Enter>. All Security

BIOS settings are described in this section.

Supervisor Password Is:

This item indicates if a supervisor password has been entered for the system. Clear

means such a password has not been used and Set means a supervisor password

has been entered for the system.

User Password Is:

This item indicates if a user password has been entered for the system. Clear

means such a password has not been used and Set means a user password has

been entered for the system.

Set Supervisor Password

When the item Set Supervisor Password is highlighted, hit the <Enter> key. When

prompted, type the Supervisor's password in the dialogue box to set or to change

supervisor's password, which allows access to the BIOS.

Set User Password

When the item Set User Password is highlighted, hit the <Enter> key. When

prompted, type the user's password in the dialogue box to set or to change the

user's password, which allows access to the system at boot-up.

4-21

C2SBA+II/C2SBA+/C2SBA/C2SBE User's Manual

Fixed Disk Boot Sector

Select Normal to enable the function of Write-Protect to protect the boot sector on

the hard drives against viruses.

Password on Boot

When this feature is set to Enabled, a password is required for a user to enter

the system at bootup. The options are Enabled (password required) and Disabled

(password not required).

TPM (Trusted Platform Modules) Support

Select Enabled to enable support for trusted platforms and allow the BIOS to

automatically download the drivers needed to provide support for the platforms

specifi ed. The options are Enabled and Disabled.

If set to Enabled, the TPM State screen displays. (See the next section.)

4-22

Chapter 4: BIOS

4-6 TPM (Trusted Platform Modules) State (*Available when

TPM Support is enabled in Security Settings.)

Choose the TPM State menu from the Phoenix BIOS Setup Utility with the arrow

keys. You should see the following display.

Current TPM State

This item shows the current TPM State only.

Change TPM State

Select "Enabled & Activate" to enable TPM support for the system. Select De-activate

& Disabled to disable the function of TPM support. If "No Change" is selected, no

changes will be done to the current TPM State. Select Clear to clear or erase all

information related to TPM support.

If set to "Clear", the sub-menu: Physical Presence Operations will appear. Select

Reject to cancel the selection. Select Execute to proceed with selection. All

information related to TPM Support will be erased.

4-23

C2SBA+II/C2SBA+/C2SBA/C2SBE User's Manual

4-7 Boot Settings

Choose Boot from the Phoenix BIOS Setup Utility main menu with the arrow keys.

You should see the following display. See details on how to change the order and

specs of boot devices in the Item Specifi c Help window. All Boot BIOS settings are

described in this section.

Boot List

Candidate
List

Boot Priority Order/Excluded from Boot Orders

The devices included in the boot list section (above) are bootable devices listed in

the sequence of boot order as specifi ed. The boot functions for the devices included

in the candidate list (above) are currently disabled. Use a <+> key or a <-> key to

move the device up or down. Use the <f> key or the <r> key to specify the type of

an USB device, either fi xed or removable. You can select one item from the boot

list and hit the <x> key to remove it from the list of bootable devices (to make its

resource available for other bootable devices). Subsequently, you can select an

item from the candidate list and hit the <x> key to remove it from the candidate

list and put it in the boot list. This item will then become a bootable device. See

details on how to change the priority of boot order of devices in the Item Specifi c

Help window.

4-24

Chapter 4: BIOS

4-8 Exit

Choose Exit from the Phoenix BIOS Setup Utility main menu with the arrow keys.

You should see the following display. All Exit BIOS settings are described in this

section.

Exit Saving Changes

Highlight this item and hit <Enter> to save any changes you made and to exit the

BIOS Setup utility.

Exit Discarding Changes

Highlight this item and hit <Enter> to exit the BIOS Setup utility without saving any

changes you may have made.

Load Setup Defaults

Highlight this item and hit <Enter> to load the default settings for all items in the

BIOS Setup. These are the safest settings to use.

Discard Changes

Highlight this item and hit <Enter> to discard (cancel) any changes you made.

You will remain in the Setup utility.

Save Changes

Highlight this item and hit <Enter> to save any changes you made. You will remain

in the Setup utility.

4-25

C2SBA+II/C2SBA+/C2SBA/C2SBE User's Manual

Notes

4-26

Appendix A: BIOS POST Messages

Appendix A

BIOS POST Messages

During the Power-On Self-Test (POST), the BIOS will check for problems. If a prob-

lem is found, the BIOS will activate an alarm or display a message. The following is

a list of such BIOS messages.

Failure Fixed Disk

Fixed disk is not working or not confi gured properly. Check to see if fi xed disk is at-

tached properly. Run Setup. Find out if the fi xed-disk type is correctly identifi ed.

Stuck key

Stuck key on keyboard.

Keyboard error

Keyboard not working.

Keyboard Controller Failed

Keyboard controller failed test. May require replacing keyboard controller.

Keyboard locked - Unlock key switch

Unlock the system to proceed.

Monitor type does not match CMOS - Run SETUP

Monitor type not correctly identifi ed in Setup

Shadow Ram Failed at offset: nnnn

Shadow RAM failed at offset nnnn of the 64k block at which the error was de-

tected.

System RAM Failed at offset: nnnn

System RAM failed at offset nnnn of in the 64k block at which the error was de-

tected.

Extended RAM Failed at offset: nnnn Extended memory not working or not con-

fi gured properly at offset nnnn.

System battery is dead - Replace and run SETUP

The CMOS clock battery indicator shows the battery is dead. Replace the battery and

run Setup to reconfi gure the system.

A-1

C2SBA+II/C2SBA+/C2SBA/C2SBE User's Manual

System CMOS checksum bad - Default confi guration used

System CMOS has been corrupted or modifi ed incorrectly, perhaps by an application

program that changes data stored in CMOS. The BIOS installed Default Setup Values.

If you do not want these values, enter Setup and enter your own values. If the error

persists, check the system battery or contact your dealer.

System timer error

The timer test failed. Requires repair of system board.

Real time clock error

Real-Time Clock fails BIOS hardware test. May require board repair.

Check date and time settings

BIOS found date or time out of range and reset the Real-Time Clock. May require

setting legal date (1991-2099).

Previous boot incomplete - Default confi guration used

Previous POST did not complete successfully. POST loads default values and offers

to run Setup. If the failure was caused by incorrect values and they are not corrected,

the next boot will likely fail. On systems with control of wait states, improper Setup

settings can also terminate POST and cause this error on the next boot. Run Setup

and verify that the waitstate confi guration is correct. This error is cleared the next

time the system is booted.

Memory Size found by POST differed from CMOS

Memory size found by POST differed from CMOS.

Diskette drive A error

Diskette drive B error

Drive A: or B: is present but fails the BIOS POST diskette tests. Check to see that

the drive is defi ned with the proper diskette type in Setup and that the diskette drive

is attached correctly.

Incorrect Drive A type - run SETUP

Type of fl oppy drive A: not correctly identifi ed in Setup.

Incorrect Drive B type - run SETUP

Type of fl oppy drive B: not correctly identifi ed in Setup.

A-2

Appendix A: BIOS POST Messages

System cache error - Cache disabled

RAM cache failed and BIOS disabled the cache. On older boards, check the cache

jumpers. You may have to replace the cache. See your dealer. A disabled cache slows

system performance considerably.

CPU ID:

CPU socket number for Multi-Processor error.

EISA CMOS not writeable

ServerBIOS2 test error: Cannot write to EISA CMOS.

DMA Test Failed

ServerBIOS2 test error: Cannot write to extended DMA (Direct Memory

Access) registers.

Software NMI Failed

ServerBIOS2 test error: Cannot generate software NMI (Non-Maskable Interrupt).

Fail-Safe Timer NMI Failed

ServerBIOS2 test error: Fail-Safe Timer takes too long.

Device Address Confl ict

Address confl ict for specifi ed device.

Allocation Error for: device

Run ISA or EISA Confi guration Utility to resolve resource confl ict for the specifi ed

device.

CD ROM Drive

CD ROM Drive identifi ed.

Entering SETUP ...

Starting Setup program

Failing Bits: nnnn

The hex number nnnn is a map of the bits at the RAM address which failed the memory

test. Each 1 (one) in the map indicates a failed bit. See errors 230, 231, or 232 above

for offset address of the failure in System, Extended, or Shadow memory.

Fixed Disk n

Fixed disk n (0-3) identifi ed.

A-3

C2SBA+II/C2SBA+/C2SBA/C2SBE User's Manual

Invalid System Confi guration Data

Problem with NVRAM (CMOS) data.

I/O device IRQ confl ict

I/O device IRQ confl ict error.

PS/2 Mouse Boot Summary Screen:

PS/2 Mouse installed.

nnnn kB Extended RAM Passed

Where nnnn is the amount of RAM in kilobytes successfully tested.

nnnn Cache SRAM Passed

Where nnnn is the amount of system cache in kilobytes successfully tested.

nnnn kB Shadow RAM Passed

Where nnnn is the amount of shadow RAM in kilobytes successfully tested.

nnnn kB System RAM Passed

Where nnnn is the amount of system RAM in kilobytes successfully tested.

One or more I2O Block Storage Devices were excluded from the Setup Boot

Menu

There was not enough room in the IPL table to display all installed I2O block-storage

devices.

Operating system not found

Operating system cannot be located on either drive A: or drive C:. Enter Setup and

see if fi xed disk and drive A: are properly identifi ed.

Parity Check 1 nnnn

Parity error found in the system bus. BIOS attempts to locate the address and display

it on the screen. If it cannot locate the address, it displays ????. Parity is a method

for checking errors in binary data. A parity error indicates that some data has been

corrupted.

Parity Check 2 nnnn

Parity error found in the I/O bus. BIOS attempts to locate the address and display it

on the screen. If it cannot locate the address, it displays ????.

A-4

Appendix A: BIOS POST Messages

Press <F1> to resume, <F2> to Setup, <F3> for previous

Displayed after any recoverable error message. Press <F1> to start the boot process

or <F2> to enter Setup and change the settings. Press <F3> to display the previous

screen (usually an initialization error of an Option ROM, i.e., an add-on card). Write

down and follow the information shown on the screen.

Press <F2> to enter Setup

Optional message displayed during POST. Can be turned off in Setup.

PS/2 Mouse:

PS/2 mouse identifi ed.

Run the I2O Confi guration Utility

One or more unclaimed block storage devices have the Confi guration Request bit set

in the LCT. Run an I2O Confi guration Utility (e.g. the SAC utility).

System BIOS shadowed

System BIOS copied to shadow RAM.

UMB upper limit segment address: nnnn

Displays the address nnnn of the upper limit of Upper Memory Blocks, indicating

released segments of the BIOS which can be reclaimed by a virtual memory man-

ager.

Video BIOS shadowed

Video BIOS successfully copied to shadow RAM.

A-5

C2SBA+II/C2SBA+/C2SBA/C2SBE User's Manual

Notes

A-6

Appendix B: BIOS POST Codes

Appendix B

BIOS POST Codes

This section lists the POST (Power On Self Test) codes for the Phoenix BIOS. POST

codes are divided into two categories: recoverable and terminal.

Recoverable POST Errors

When a recoverable type of error occurs during POST, the BIOS will display an

POST code that describes the problem. BIOS may also issue one of the follow-

ing beep codes:

1 long and two short beeps - video confi guration error

1 repetitive long beep - no memory detected

Terminal POST Errors

If a terminal type of error occurs, BIOS will shut down the system. Before doing

so, BIOS will write the error to port 80h, attempt to initialize video and write the

error in the top left corner of the screen. The following is a list of codes that may

be written to port 80h.

POST Code Description

02h Verify Real Mode

03h Disable Non-Maskable Interrupt (NMI)

04h Get CPU type

06h Initialize system hardware

07h Disable shadow and execute code from the ROM.

08h Initialize chipset with initial POST values

09h Set IN POST fl ag

0Ah Initialize CPU registers

0Bh Enable CPU cache

0Ch Initialize caches to initial POST values

0Eh Initialize I/O component

0Fh Initialize the local bus IDE

10h Initialize Power Management

11h Load alternate registers with initial POST values

12h Restore CPU control word during warm boot

13h Reset PCI Bus Mastering devices

14h Initialize keyboard controller

16h 1-2-2-3 BIOS ROM checksum

17h Initialize cache before memory Auto size

B-1

C2SBA+II/C2SBA+/C2SBA/C2SBE User's Manual

POST Code Description

18h 8254 timer initialization

1Ah 8237 DMA controller initialization

1Ch Reset Programmable Interrupt Controller

20h 1-3-1-1 Test DRAM refresh

22h 1-3-1-3 Test 8742 Keyboard Controller

24h Set ES segment register to 4 GB

28h Auto size DRAM

29h Initialize POST Memory Manager

2Ah Clear 512 kB base RAM

2Ch 1-3-4-1 RAM failure on address line xxxx*

2Eh 1-3-4-3 RAM failure on data bits xxxx* of low byte of

memory bus

2Fh Enable cache before system BIOS shadow

32h Test CPU bus-clock frequency

33h Initialize Phoenix Dispatch Manager

36h Warm start shut down

38h Shadow system BIOS ROM

3Ah Auto size cache

3Ch Advanced confi guration of chipset registers

3Dh Load alternate registers with CMOS values

41h Initialize extended memory for RomPilot (optional)

42h Initialize interrupt vectors

45h POST device initialization

46h 2-1-2-3 Check ROM copyright notice

48h Check video confi guration against CMOS

49h Initialize PCI bus and devices

4Ah Initialize all video adapters in system

4Bh QuietBoot start (optional)

4Ch Shadow video BIOS ROM

4Eh Display BIOS copyright notice

4Fh Initialize MultiBoot

50h Display CPU type and speed

51h Initialize EISA board (optional)

52h Test keyboard

54h Set key click if enabled

55h Enable USB devices

58h 2-2-3-1 Test for unexpected interrupts

59h Initialize POST display service

5Ah Display prompt “Press <ESC> to enter SETUP”

5Bh Disable CPU cache

B-2

Appendix B: BIOS POST Codes

POST Code Description

5Ch Test RAM between 512 and 640 kB

60h Test extended memory

62h Test extended memory address lines

64h Jump to UserPatch1

66h Confi gure advanced cache registers

67h Initialize Multi Processor APIC

68h Enable external and CPU caches

69h Setup System Management Mode (SMM) area

6Ah Display external L2 cache size

6Bh Load custom defaults (optional)

6Ch Display shadow-area message

70h Display error messages

72h Check for confi guration errors

76h Check for keyboard errors

7Ch Set up hardware interrupt vectors

7Dh Initialize Intelligent System Monitoring (optional)

7Eh Initialize coprocessor if present

80h Disable onboard Super I/O ports and IRQs (optional)

81h Late POST device initialization

82h Detect and install external RS232 ports

83h Confi gure non-MCD IDE controllers

84h Detect and install external parallel ports

85h Initialize PC-compatible PnP ISA devices

86h Re-initialize onboard I/O ports.

87h Confi gure Motherboard Confi gurable Devices

(optional)

88h Initialize BIOS Data Area

89h Enable Non-Maskable Interrupts (NMIs)

8Ah Initialize Extended BIOS Data Area

8Bh Test and initialize PS/2 mouse

8Ch Initialize fl oppy controller

8Fh Determine number of ATA drives (optional)

90h Initialize hard-disk controllers

91h Initialize local-bus hard-disk controllers

92h Jump to UserPatch2

93h Build MPTABLE for multi-processor boards

95h Install CD ROM for boot

96h Clear huge ES segment register

97h Fix up Multi Processor table

98h 1-2 Search for option ROMs and shadow if successful. One

long, two short beeps on checksum failure

B-3

C2SBA+II/C2SBA+/C2SBA/C2SBE User's Manual

POST Code Description

99h Check for SMART Drive (optional)

9Ch Set up Power Management

9Dh Initialize security engine (optional)

9Eh Enable hardware interrupts

9Fh Determine number of ATA and SCSI drives

A0h Set time of day

A2h Check key lock

A4h Initialize typematic rate

A8h Erase <ESC> prompt

AAh Scan for <ESC> key stroke

ACh Enter SETUP

AEh Clear Boot fl ag

B0h Check for errors

B1h Inform RomPilot about the end of POST (optional)

B2h POST done - prepare to boot operating system

B4h 1 One short beep before boot

B5h Terminate QuietBoot (optional)

B6h Check password (optional)

B7h Initialize ACPI BIOS and PPM Structures

B9h Prepare Boot

BAh Initialize SMBIOS

BCh Clear parity checkers

BDh Display MultiBoot menu

BEh Clear screen (optional)

BFh Check virus and backup reminders

C0h Try to boot with INT 19

C1h Initialize POST Error Manager (PEM)

C2h Initialize error logging

C3h Initialize error display function

C4h Initialize system error fl ags

C6h Console redirection init.

C7h Unhook INT 10h if console redirection enabled

C8h Force check (optional)

C9h Extended ROM checksum (optional)

CDh Reclaim console redirection vector

B-4

Appendix B: BIOS POST Codes

POST Code Description

D2h Unknown interrupt

D4h Check Intel Branding string

D8h Alert Standard Format initialization

DEh Log error if micro-code not updated properly

The following are for boot block in Flash ROM

POST Code Description

E0h Initialize the chipset

E1h Initialize the bridge

E2h Initialize the CPU

E3h Initialize system timer

E4h Initialize system I/O

E5h Check force recovery boot

E6h Checksum BIOS ROM

E7h Go to BIOS

E8h Set Huge Segment

E9h Initialize Multi Processor

EAh Initialize OEM special code

EBh Initialize PIC and DMA

ECh Initialize Memory type

EDh Initialize Memory size

EEh Shadow Boot Block

EFh System memory test

F0h Initialize interrupt vectors

F1h Initialize Run Time Clock

F2h Initialize video

F3h Initialize System Management Manager

F4h Output one beep

F5h Clear Huge Segment

F6h Boot to Mini DOS

F7h Boot to Full DOS

* If the BIOS detects errors on 2C, 2E, or 30 (base 512K RAM error), it displays an

additional word-bitmap (xxxx) indicating the address line or bits that have failed. For

example, “2C 0002” means address line 1 (bit one set) has failed. “2E 1020" means

data bits 12 and 5 (bits 12 and 5 set) have failed in the lower 16 bits. The BIOS also

sends the bitmap to the port-80 LED display. It fi rst displays the checkpoint code,

followed by a delay, the high-order byte, another delay, and then the low-order byte

of the error. It repeats this sequence continuously.

B-5

C2SBA+II/C2SBA+/C2SBA/C2SBE User's Manual

Notes

B-6

Appendix C: Intel HostRAID Setup Guidelines

Appendix C
Intel HostRAID Setup Guidelines

(*For the C2SBA+II Only)

After all the hardware has been installed, you must fi rst confi gure SATA HostRAID

or SAS HostRAID* before you install the Windows Operating System and other

software drivers**.

Important Notes to the User:

Note 1: This chapter describes RAID Confi guration Instructions for the Intel ICH9R

Host RAID Controller designed for the Windows OS.

Note 2: If you do not wish to confi gure onboard SATA or SAS RAID functions,
please go directly to Section C-2 and Appendix D for the operating system & other

software installation instructions.

C-1 Introduction to Serial ATA and Parallel ATA

To confi gure the SATA RAID functions, you must fi rst use the Intel ICH9R SATA

RAID Utility program to confi gure the RAID Level that you desire before installing

the Windows XP/2000/2003 operating system and other software drivers. (The

necessary drivers are all included on the Super Micro CD that came packaged with

your motherboard.) Note that the current version of the ICH9R SATA RAID Utility

can only support Windows XP/2000/2003 Operating Systems.

Serial ATA (SATA)

Serial ATA (SATA) is a physical storage interface that uses a single cable with a

minimum of four wires to create a point-to-point connection between devices. It

is a serial link, which supports transfer rates up to 3.0 Gbps. Because the serial

cables used in SATA are thinner than the traditional cables used in Parallel ATA

(PATA), SATA systems have better airfl ow and can be installed in smaller chassis.

In addition, the cables used in PATA are limited to a length of 40cm, while Serial

ATA cables can be up to one meter in length. Overall, SATA provides better func-

tionality than PATA.

Introduction to the Intel ICH9R Serial RAID

Located in the South Bridge of the G33 chipset, the I/O Controller Hub (ICH9R)

provides the I/O subsystem with access to the rest of the system. It supports 1-

channel UltraATA/100 Bus Master IDE controller (PATA) and six Serial ATA (SATA)

ports. The ICH9R supports the following PATA and SATA device confi gurations:

Legacy mode and Native mode.

C-1

C2SBA+II/C2SBA+/C2SBA/C2SBE User's Manual

Intel HostRAID Confi gurations

The following types of Intel's HostRAID confi gurations are supported:

RAID 0 (Data Striping): this writes data in parallel, interleaved ("striped") sections

of two hard drives. Data transfer rate is doubled over using a single disk.

RAID1 (Data Mirroring): an identical data image from one drive is copied to another

drive. The second drive must be the same size or larger than the fi rst drive.

RAID 10 (Striping & Mirroring): RAID 0 and 1 schemes are combined (without parity

information) to get the benefi ts of both.

RAID 5: both data and parity information are striped and mirrored across three or

more hard drives.

Intel Matrix Storage

The Intel Matrix Storage, supported by the ICH9R, allows the user to create RAID

0, RAID 1, RAID 10 and RAID 5 sets by using only six identical hard disk drives.

The Intel Matrix Storage Technology creates two partitions on each hard disk drive

and generate a virtual RAID 0, RAID 1, RAID 10 and RAID 5 sets. It also allows

you the change the HDD partition size without any data.

Confi guring BIOS settings for SATA RAID Functions (in the Native
Mode)

1. Press the <Del> key during system bootup to enter the BIOS Setup Utility.

Note: If it is the fi rst time powering on the system, we recommend you load the

Optimized Default Settings. If you have already done so, please skip to Step 3.

2. Use the arrow keys to select the "Exit" Settings. Once in the "Exit" settings,

Scroll down to select "Load Optimized Default Settings" and press the <Enter>

key. Select "OK" to confi rm the selection. Press the <Enter> key to load the default

settings for the BIOS.

3. Use the arrow keys to select the "Main" section in BIOS.

4. Scroll down to "SATA RAID Enabled" and press <Enter>. Then, select "En-

abled."

5. Scroll down to "Exit". Select "Save and Exit" from the "Exit" menu. Press the

<Enter> key to save the changes and exit the BIOS.

6. Once you've exited the BIOS Utility, the system will re-boot.

7. During the system boot-up, press the <Ctrl> and <I> keys simultaneously to run

the Intel RAID Confi guration Utility when prompted by the following message: Press

<Ctrl> <I> for the Intel RAID Confi guration Utility.

(Note: The Intel RAID Confi guration Utility is only available for systems with two

or more drives installed. The Intel RAID Utility screen will not display in systems

with one drive installed.)

C-2

Appendix C: Intel HostRAID Setup Guidelines

Using the Intel ICH9R SATA RAID Utility Program

1. Creating, Deleting and Resetting RAID Volumes:

a. After the system exits from the BIOS Setup Utility, the system will automatically

reboot. The following screen appears after Power-On Self Test.

b. When you see the above screen, press the <Ctrl> and the <I> keys simultane-

ously to access the main menu of the SATA RAID Utility.

c. Use the Up and Down arrow keys to select Create RAID Volume, Delete RAID

Volume, Reset Disks to Non-RAID or Exit.

Note: All graphics and screen shots shown in the manual are for reference only. The

screen shots shown in the manual do not imply Super Micro's endorsement or non-en-

dorsement on any 3rd party's product. Your screens may or many not look exactly the

same as the graphics shown in this manual.

C-3

C2SBA+II/C2SBA+/C2SBA/C2SBE User's Manual

Creating a RAID 0 Volume:

a. Select "Create RAID Volume" from the main menu and press the <Enter> key.

The following screen will appear:

b. Specify a name for the RAID 0 set and press the <Tab> key or the <Enter> key

to go to the next fi eld. (You can use the <Esc> key to select the previous menu.)

c. When RAID Level item is highlighted, press the <Up Arrow>, <Down Arrow> keys

to select RAID 0 (Stripe) and hit <Enter>.

d. When the Select Disks item is highlighted, press <Enter> to select the HDD to

confi gure as RAID. The following pop-up screen displays: (*See the note on Page

C-3)

e. Use the <Up Arrow>, <Down Arrow> keys to highlight a drive and press <Space>

to select it. A triangle appears to confi rm the selection of the drive. When all RAID

drives for this volume have been selected, hit <Enter>.

f. Use the <Up Arrow>, <Down Arrow> keys to select the stripe size, ranging from

4 KB to 128 KB for the RAID 0 array, and hit <Enter>. (Note: For a server, please

use a lower stripe size, and for a multimedia system, use a higher stripe size. The

default stripe size is 128 KB.)

g. Press <Enter> when the Create Volume item is highlighted. A warning message

displays.

h. When asked "Are you sure you want to create this volume (Y/N), press "Y" to

create the RAID volume, or type "N" to go back to the Create Volume menu.

C-4

Appendix C: Intel HostRAID Setup Guidelines

Creating a RAID 1 Volume:

a. Select "Create RAID Volume" from the main menu and press the <Enter> key.

The following screen will appear:

b. Specify a name for the RAID 1 set and press the <Tab> key or the <Enter> key

to go to the next fi eld. (You can use the <Esc> key to select the previous menu.)

c. When RAID Level item is highlighted, press the <Up Arrow>, <Down Arrow> keys

to select RAID 1 (Mirror) and hit <Enter>.

d. When Select Disks Item is height lighted, press <Enter> to select the HDD to

confi gure as RAID. The following pop-up screen displays: (*See the note on Page

C-3)

e. Use the <Up Arrow>, <Down Arrow> keys to highlight a drive and press <Space>

to select it. A triangle appears to confi rm the selection of the drive. When all RAID

drives for this volume have been selected, hit <Enter>.

f. When the Capacity item is highlighted, enter your RAID volume capacity and hit

<Enter>. The default setting is the maximum capacity allowed.

g. Press <Enter> when the Create Volume item is highlighted. A warning message

displays.

h. When asked "Are you sure you want to create this volume (Y/N), press "Y" to

create the RAID volume, or type "N" to go back to the Create Volume menu.

C-5

C2SBA+II/C2SBA+/C2SBA/C2SBE User's Manual

Creating a RAID 10 (RAID 1+ RAID 0):

a. Select "Create RAID Volume" from the main menu and press the <Enter> key.

The following screen will appear:

b. Specify a name for the RAID 10 set and press <Enter>.

c. When RAID Level item is highlighted, use the <Up Arrow>, <Down Arrow> keys

to select RAID 10 (RAID1 + RAID0) and hit <Enter>.

d. When Select Disks Item is height lighted, press <Enter> to select the HDD to

confi gure as RAID. The following pop-up screen displays: (*See the note on Page

C-3)

e. Use the <Up Arrow>, <Down Arrow> keys to highlight a drive and press <Space>

to select it. A triangle appears to confi rm the selection of the drive. When all RAID

drives for this volume have been selected, hit <Enter>.

f. When the Stripe Size is highlighted, use the <Up Arrow>, <Down Arrow> keys to

select the stripe size from 4 KB to 128 KB for your RAID 10 and hit <Enter>. The

default setting is 64 KB. (Note: For a server, please use a lower stripe size, and

for a multimedia system, use a higher stripe size.)

g. When the RAID Volume Capacity item is highlighted, enter your RAID volume

capacity and hit <Enter>. The default setting is the maximum capacity allowed.

h. Press <Enter> when the Create Volume item is highlighted. A warning message

displays.

i. When asked "Are you sure you want to create this volume (Y/N), press "Y" to

create the RAID volume, or type "N" to go back to the Create Volume menu.

C-6
