A+ SERVER 1022G-URF
SUPER
®
USER’S MANUAL
Revision 1.0b
The information in this User’s Manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
makes no commitment to update or to keep current the information in this manual, or to notify any
person or organization of the updates. Please Note: For the most up-to-date version of this
manual, please see our web site at www.supermicro.com.
Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product
described in this manual at any time and without notice. This product, including software and
documentation, is the property of Supermicro and/or its licensors, and is supplied only under a
license. Any use or reproduction of this product is not allowed, except as expressly permitted by
the terms of said license.
IN NO EVENT WILL SUPERMICRO BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO
USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. IN PARTICULAR, SUPERMICRO SHALL NOT HAVE LIABILITY FOR ANY
HARDWARE, SOFTW ARE, OR DA TA STORED OR USED WITH THE PRODUCT, INCLUDING THE
COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH
HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between manufacturer and customer shall be governed by the laws of Santa
Clara County in the State of California, USA. The State of California, County of Santa Clara shall
be the exclusive venue for the resolution of any such disputes. Super Micro's total liability for all
claims will not exceed the price paid for the hardware product.
FCC Statement: This equipment has been tested and found to comply with the limits for a Class
A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the manufacturer’s instruction manual, may cause harmful
interference with radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference, in which case you will be required to correct the interference at your
own expense.
California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate
warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate
Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”
WARNING: Handling of lead solder materials used in this
product may expose you to lead, a chemical known to
the State of California to cause birth defects and other
reproductive harm.
Manual Revision 1.0b
Release Date: December 30, 2010
Unless you request and receive written permission from Super Micro Computer, Inc., you may not
copy any part of this document.
Information in this document is subject to change without notice. Other products and companies
referred to herein are trademarks or registered trademarks of their respective companies or mark
holders.
Copyright © 2010 by Super Micro Computer, Inc.
All rights reserved.
Printed in the United States of America
Preface
About This Manual
This manual is written for professional system integrators and PC technicians. It
provides information for the installation and use of the A+ SERVER 1022G-URF.
Installation and maintenance should be performed by experienced technicians
only.
The A+ SERVER 1022G-URF is a 1U rackmount server based on the SC815TQR700UB server chassis and the Super H8DGU-F serverboard. Please refer to our
web site for updates on supported processors.
Manual Organization
Chapter 1: Introduction
The fi rst chapter provides a checklist of the main components included with the
server system and describes the main features of the Super H8DGU-F serverboard
and the SC815TQ-R700UB chassis.
Chapter 2: Server Installation
This chapter describes the steps necessary to install the A+ SERVER 1022G-URF
into a rack and check out the server confi guration prior to powering up the system. If
your server was ordered without the processor and memory components, this chapter
will refer you to the appropriate sections of the manual for their installation.
Chapter 3: System Interface
Refer to this chapter for details on the system interface, which includes the functions
and information provided by the control panel on the chassis as well as other LEDs
located throughout the system.
Chapter 4: System Safety
You should thoroughly familiarize yourself with this chapter for a general overview
of safety precautions that should be followed when installing and servicing the A+
SERVER 1022G-URF.
Chapter 5: Advanced Serverboard Setup
This chapter provides detailed information on the H8DGU-F serverboard,
including the locations and functions of connectors, headers and jumpers. Refer
iii
Preface
A+ SERVER 1022G-URF User's Manual
iv
to this chapter when adding or removing processors or main memory and when
reconfi guring the serverboard.
Chapter 6: Advanced Chassis Setup
Refer to Chapter 6 for detailed information on the SC815TQ-R700UB chassis.
You should follow the procedures given in this chapter when installing, removing
or reconfi guring Serial ATA or peripheral drives and when replacing system power
supply units and cooling fans.
Chapter 7: BIOS
The BIOS chapter includes an introduction to BIOS and provides detailed information
on running the CMOS Setup Utility.
Appendix A: BIOS POST Error Codes
Appendix B: Installing Windows
Appendix C: System Specifi cations
v
Preface
Notes
vi
A+ SERVER 1022G-URF User's Manual
Table of Contents
Chapter 1 Introduction
1-1 Overview .........................................................................................................1-1
1-2 Serverboard Features .....................................................................................1-2
Processors ......................................................................................................1-2
Memory ...........................................................................................................1-2
UIO ..................................................................................................................1-2
Serial ATA .......................................................................................................1-2
Onboard Controllers/Ports ..............................................................................1-2
Graphics Controller .........................................................................................1-3
Other Features ................................................................................................1-3
1-3 Server Chassis Features ................................................................................1-3
System Power .................................................................................................1-3
Hard Drive Subsystem ....................................................................................1-3
PCI Expansion Slots ....................................................................................... 1-3
Front Control Panel ......................................................................................... 1-4
I/O Backplane ..................................................................................................1-4
Cooling System ...............................................................................................1-4
1-4 Contacting Supermicro ....................................................................................1-6
Chapter 2Server Installation
2-1 Overview .........................................................................................................2-1
2-2 Unpacking the System ....................................................................................2-1
2-3 Preparing for Setup ......................................................................................... 2-1
Warnings and Precautions! ........................................................................................2-2
Choosing a Setup Location .............................................................................2-2
Rack Precautions ............................................................................................2-2
Server Precautions ..........................................................................................2-2
Rack Mounting Considerations .......................................................................2-3
Ambient Operating Temperature ................................................................ 2-3
Reduced Airfl ow ......................................................................................... 2-3
Mechanical Loading ................................................................................... 2-3
Circuit Overloading ..................................................................................... 2-3
Reliable Ground ......................................................................................... 2-3
2-4 Installing the System into a Rack ................................................................... 2-4
Identifying the Sections of the Rack Rails ...................................................... 2-4
Installing the Inner Rails ................................................................................. 2-4
Installing the Outer Rails .................................................................................2-5
vii
Table of Contents
Installing the Server into the Rack ..................................................................2-6
Installing the Server into a Telco Rack ........................................................... 2-7
2-5 Checking the Serverboard Setup ....................................................................2-8
2-6 Checking the Drive Bay Setup ........................................................................2-9
Chapter 3 System Interface
3-1 Overview .........................................................................................................3-1
3-2 Control Panel Buttons .....................................................................................3-1
UID ..................................................................................................................3-1
Reset ...............................................................................................................3-1
Power ..............................................................................................................3-2
3-3 Control Panel LEDs ........................................................................................3-2
Universal Information LED ..............................................................................3-2
NIC2 ................................................................................................................3-3
NIC1 ................................................................................................................3-3
HDD ................................................................................................................. 3-3
Power ..............................................................................................................3-3
3-4 Hard Drive Carrier LEDs ................................................................................. 3-4
Chapter 4 System Safety
4-1 Electrical Safety Precautions .......................................................................... 4-1
4-2 General Safety Precautions ............................................................................4-2
4-3 ESD Precautions ............................................................................................. 4-3
4-4 Operating Precautions .................................................................................... 4-4
Chapter 5 Advanced Serverboard Setup
5-1 Handling the Serverboard ...............................................................................5-1
Precautions .....................................................................................................5-1
Unpacking .......................................................................................................5-1
5-2 Processor and Heatsink Installation................................................................5-2
When handling the processor, avoid placing direct pressure on the label area of the
fan. Also, do not place the serverboard on a conductive surface, which can damage
the BIOS battery and prevent the system from booting up. ......................................5-2
Installing a Passive CPU Heatsink ................................................................. 5-4
5-3 Connecting Cables .......................................................................................... 5-5
Connecting Data Cables .................................................................................5-5
Connecting Power Cables ..............................................................................5-5
Connecting the Control Panel ......................................................................... 5-5
5-4 I/O Ports ..........................................................................................................5-6
5-5 Installing Memory ............................................................................................ 5-7
Memory Support ..............................................................................................5-7
DIMM Module Population Confi guration .................................................... 5-8
viii
A+ SERVER 1022G-URF User's Manual
5-6 Adding PCI Cards ......................................................................................... 5-10
PCI Expansion Slots ................................................................................ 5-10
5-7 Serverboard Details .......................................................................................5-11
H8DGU(-F) Quick Reference ........................................................................ 5-12
5-8 Connector Defi nitions ................................................................................... 5-13
Power Connectors ...................................................................................5-13
PW_ON Connector ...................................................................................5-13
Reset Connector ...................................................................................... 5-13
Overheat/Fan Fail LED (OH)....................................................................5-14
NIC2 (LAN2) LED .....................................................................................5-14
NIC1 (LAN1) LED .....................................................................................5-14
HDD LED ..................................................................................................5-14
Power On LED .........................................................................................5-14
NMI Button ............................................................................................... 5-14
Universal Serial Bus Ports ....................................................................... 5-15
USB Headers ........................................................................................... 5-15
Fan Headers .............................................................................................5-15
Serial Ports ............................................................................................... 5-15
T-SGPIO ...................................................................................................5-16
UIO Power Connector ..............................................................................5-16
LAN1/2 (Ethernet Ports) ........................................................................... 5-16
Chassis Intrusion .....................................................................................5-17
Overheat LED ...........................................................................................5-17
Power LED/Speaker ................................................................................. 5-17
ATX PS/2 Keyboard and PS/2 Mouse Ports ............................................5-17
Unit Identifi er Button ................................................................................. 5-18
IPMB .........................................................................................................5-18
Video Connector .......................................................................................5-18
Compact Flash Card PWR Connector .....................................................5-18
5-9 Jumper Settings ............................................................................................5-19
Explanation of Jumpers ................................................................................5-19
CMOS Clear ............................................................................................. 5-19
I2C to PCI-Express Slot ........................................................................... 5-20
Watch Dog Enable/Disable ...................................................................... 5-20
LAN1/2 Enable/Disable ........................................................................... 5-20
VGA Enable/Disable .................................................................................5-20
5-10 Onboard Indicators ........................................................................................5-21
LAN1/LAN2 LEDs .....................................................................................5-21
Table of Contents
ix
Dedicated IPMI LAN LEDs .......................................................................5-21
UID LED (LE1) ........................................................................................ 5-21
Power LED ............................................................................................... 5-21
5-11 SATA Drive Connections ............................................................................... 5-22
SATA Ports ............................................................................................... 5-22
5-12 Enabling SATA RAID ..................................................................................... 5-23
Serial ATA (SATA).......................................................................................... 5-23
Installing the OS/SATA Driver ....................................................................... 5-23
Building a Driver Diskette .........................................................................5-23
Enabling SATA RAID in the BIOS ................................................................. 5-24
Using the Adaptec RAID Utility ..................................................................... 5-25
Installing the RAID Driver During OS Installation .........................................5-25
5-13 Installing Drivers ............................................................................................5-26
Supero Doctor III ........................................................................................... 5-27
Chapter 6 Advanced Chassis Setup
6-1 Static-Sensitive Devices ..................................................................................6-1
Precautions .....................................................................................................6-1
6-2 Control Panel ..................................................................................................6-2
6-3 System Fans ...................................................................................................6-2
System Fan Failure ......................................................................................... 6-3
6-4 Drive Bay Installation/Removal ....................................................................... 6-4
Removing the Front Bezel .............................................................................. 6-4
Accessing the Drive Bays ............................................................................... 6-4
Hard Drive Installation .....................................................................................6-5
DVD-ROM Drive Installation ........................................................................... 6-6
6-5 Power Supply .................................................................................................. 6-7
Power Supply Failure ................................................................................. 6-7
Chapter 7 BIOS
7-1 Introduction ......................................................................................................7-1
Starting the Setup Utility ................................................................................. 7-1
7-2 Main Menu ...................................................................................................... 7-1
System Time/System Date .............................................................................7-2
7-3 Advanced Settings Menu ................................................................................ 7-2
7-4 Security Menu ...............................................................................................7-13
7-5 Boot Menu ..................................................................................................... 7-14
7-6 Exit Menu ...................................................................................................... 7-14
Appendix A BIOS Error Beep Codes
x
A+ SERVER 1022G-URF User's Manual
Appendix B Installing Windows
B-1 Installing the Windows OS for a RAID System ..............................................B-1
B-2 Installing the Windows OS for a Non-RAID System ....................................... B-2
Appendix C System Specifi cations
Chapter 1
Introduction
1-1 Overview
The A+ SERVER 1022G-URF is a high-end server comprised of two main
subsystems: the SC815TQ-R700UB 1U server chassis and the H8DGU-F dual
processor serverboard. Please refer to our web site for information on operating
systems that have been certifi ed for use with the system (www.supermicro.com).
In addition to the serverboard and chassis, various hardware components have
been included with the 1022G-URF, as listed below:
One (1) slim DVD-ROM drive (DVM-PNSC-DVD-SBT or DVM-TEAC-DVD-•
SBT)
One (1) SATA-to-USB adapter for DVD-ROM drive (CDM-USATA-G)•
One (1) DVD-ROM drive cable (CBL-00341L) •
Four (4) sets of 4-cm counter-rotating fans (FAN-0086L4)•
One (1) air shroud (MCP-310-18002-0N)•
Two (2) 1U passive CPU heatsinks (SNK-P0042P)•
One (1) RSC-R1UU-UE16 for PCI-E card (see Section 5-6 for details)•
One (1) Slim Floppy Drive (FPD-TEAC-SB)•
SAS/SATA Accessories•
One (1) SATA backplane (BPN-SAS-815TQ)
One (1) iPASS-to-SATA cable (CBL-0188L)
Four (4) 3.5" HDD trays (MCP-220-00024-0B)
One (1) Front Control cable (CBL-0191L)
One (1) rackmount kit (CSE-PT51L)
One (1) CD containing drivers and utilities•
Chapter 1: Introduction
1-1
1-2
A+ SERVER 1022G-URF User's Manual
1-2 Serverboard Features
At the heart of the A+ SERVER 1022G-URF lies the H8DGU-F, a dual processor
serverboard based on the AMD SR5670/SP5100 chipset. Below are the main
features of the H8DGU-F. (See Figure 1-1 for a block diagram of the chipset).
Processors
The H8DGU-F supports single or dual AMD Opteron 6100 Series processors in
Socket G34 type sockets. Please refer to our web site for a complete listing of
supported processors (www.supermicro.com).
Memory
The H8DGU-F has sixteen single/dual/tri/quad channel 240-pin DIMM sockets that
can support up to 256GB of DDR3-1333/1066/800MHz registered ECC SDRAM or
64 GB of DDR3-1333/1066/800 MHz unbuffered ECC/non-ECC SDRAM. Please
refer to Chapter 5 for installing memory.
UIO
The H8DGU-F is a specially-designed serverboard that features Supermicro's UIO
(Universal I/O) technology. UIO serverboards have a PCI Expres s x8 slot that can
suppor t any on e of several t ype s of UIO c ard t ypes to ad d SAS po rt s, addit ional
LAN ports, etc. to the serverboard. This allows the user to tailor the serverboard
to their ow n need s.
Note: the ser ver does n ot com e with a UI O card i nstal led.
Serial ATA
An on -chip (SP5100) SATA contr oller is integ rated into the H 8DGU -F to prov ide
a six-po rt, 3 Gb /sec S ATA subsystem, wh ic h is RAI D 0, 1, and 10 suppo rted. The
SATA dr ives are h ot-sw appabl e units .
Note: You must have RAID set up to enable the hot-swap capability of the SATA
drives. D ocum entati on on R AI D setup gui deline s can be fo und on our we b site.
Onboard Controllers/Ports
The color-coded I/O ports include two COM ports (one header and one port), a VGA
(monitor) port, Seven USB 2.0 ports (2x rear, 4x header, 1x type A), PS/2 mouse
and keyboard ports, two gigabit Ethernet ports and one dedicated IPMI LAN port.
1-3
Chapter 1: Introduction
Graphics Controller
The H8DGU-F features an integrated Matrox G200eW graphics chip, which includes
16 MB of DDR2 memory.
Other Features
Other onboard features that promote system health include onboard voltage
monitors, auto-switching voltage regulators, chassis and CPU overheat sensors,
virus protection and BIOS rescue.
1-3 Server Chassis Features
The 1022G-URF is built upon the SC815TQ-R700UB chassis. Details on the chassis
and on servicing procedures can be found in Chapter 6.The following is a general
outline of the main features of both chassis.
System Power
The SC815TQ-R700UB features a redundant 700W power supply consisting of
two power modules. The system does not need to be shut down when replacing or
removing a single power supply module.
The SC815TQ-R700UB features a single 560W power supply module. The system
must be shut down when replacing or removing this power supply module.
Hard Drive Subsystem
The SC815TQ-R700UB chassis was designed to support four hot-swap SAS/SA T A
hard dr ives. (Req uires U IO cont roll er car d - not inc luded w ith syste m.)
Note: A SAS or SATA UIO card must be installed to support SAS or SATA
drives.
PCI Expansion Slots
A riser card (RSC-R1UU-UE16, optional) on the left side of the chassis can support
a AOC-PG-i2+ add-on card to provide two additional Gb LAN ports. Alternately, this
slot can instead support either a UIO card, one PCI-E x16 card, or four SAS/SATA
drives with an optional UIO SAS card. See our web site for details (http://www.
supermicro.com/products/nfo/UIO.cfm). See section 5-6 for further details.)
1-4
A+ SERVER 1022G-URF User's Manual
Front Control Panel
The chassis' control panel provides you with system monitoring and control. LEDs
indicate system power, HDD activity, network activity (two) and UID/overheat/fan
fail/power fail. A main power button, a system reset button and a UID button are
also included.
I/O Backplane
The SC815TQ-R700UB is an extended ATX form factor chassis that is designed to
be used in a 1U rackmount confi guration. Ports on the I/O backplane include one
COM port, a VGA port, two USB 2.0 ports, PS/2 mouse and keyboard ports and
two gigabit Ethernet ports. A UID (Unit Identifi er) button and LED are also located
beside the LAN2 Ethernet port.
Cooling System
The SC815TQ-R700UB chassis has an innovative cooling design that features
four sets of 4-cm counter-rotating fans located in the middle section of the chassis.
There is a "Fan Speed Control Mode" setting in BIOS that allows chassis fan speed
to be determined by system temperature. The power supply module also includes
a cooling fan.
1-5
Chapter 1: Introduction
Figure 1-1. AMD SR5670/SP5100 Chipset:
System Block Diagram
Note: This is a general block diagram. Please see Chapter 5 for details.
AMD
Socket G34
CPU2
DIMM A0
DIMM A1
DIMM A1
DIMM A0
HT3 Link
(8+8)x(8+8)-6.4GT/s
16x16-5.2GT/s
HT3 Link
HT3 Link
8x8-3.2GT/s
DIMM B0
DIMM B1
DIMM C0
DIMM C1
DIMM D0
DIMM D1
DIMM B0
DIMM B1
DIMM C0
DIMM C1
DIMM D0
DIMM D1
MUX
SATA x6
PCI-E GEN2 x16
Slot1
PCI-E GEN2 X4
INTEL
KAWELA
RJ45
A-Link
SP5100
BMC
VGA
WPCM450-R
PCI
LPC
SMBus
SIO
W83527
HWM
W83795G
SPI Flash
KB/MS
RMII
DDR2 SDRAM
64Mb X16bit
PSU I2C
IPMB
FE PHY
RTL8201N
VGA
RJ45
7xUSB
Clock Gen
TPM (/OPT)
RJ45
PCI-E GEN2 x8 (in x4)
Slot3
COM2
COM1
SR5670
HT3 Link
8x8-3.2GT/s
AMD
Socket G34
CPU1
1-6
A+ SERVER 1022G-URF User's Manual
1-4 Contacting Supermicro
Headquarters
Address: Super Micro Computer, Inc.
980 Rock Ave.
San Jose, CA 95131 U.S.A.
Tel: +1 (408) 503-8000
Fax: +1 (408) 503-8008
Email: marketing@supermicro.com (General Information)
support@supermicro.com (Technical Support)
Web Site: www.supermicro.com
Europe
Address: Super Micro Computer B.V.
Het Sterrenbeeld 28, 5215 ML
's-Hertogenbosch, The Netherlands
Tel: +31 (0) 73-6400390
Fax: +31 (0) 73-6416525
Email: sales@supermicro.nl (General Information)
support@supermicro.nl (Technical Support)
rma@supermicro.nl (Customer Support)
Asia-Pacifi c
Address: Super Micro Computer, Inc.
4F, No. 232-1, Liancheng Rd.
Chung-Ho 235, Taipei County
Taiwan, R.O.C.
Tel: +886-(2) 8226-3990
Fax: +886-(2) 8226-3991
Web Site: www.supermicro.com.tw
Technical Support:
Email: support@supermicro.com.tw
Tel: 886-2-8228-1366, ext.132 or 139
Chapter 2: Server Installation
2-1
Chapter 2
Server Installation
2-1 Overview
This chapter provides a quick setup checklist to get your A+ SERVER 1022G-URF
up and running. Following these steps in the order given should enable you to have
the system operational within a minimum amount of time. This quick setup assumes
that your system has come to you with the processors and memory preinstalled. If
your system is not already fully integrated with a serverboard, processors, system
memory etc., please turn to the chapter or section noted in each step for details on
installing specifi c components.
2-2 Unpacking the System
You should inspect the box the A+ SERVER 1022G-URF was shipped in and note
if it was damaged in any way. If the server itself shows damage you should fi le a
damage claim with the carrier who delivered it.
Decide on a suitable location for the rack unit that will hold the 1022G-URF. It
should be situated in a clean, dust-free area that is well ventilated. Avoid areas
where heat, electrical noise and electromagnetic fi elds are generated. You will also
need it placed near a grounded power outlet. Be sure to read the Rack and Server
Precautions in the next section.
2-3 Preparing for Setup
The box the A+ SERVER 1022G-URF was shipped in should include two sets of
rail assemblies, two rail mounting brackets and the mounting screws you will need
to install the system into the rack. Follow the steps in the order given to complete
the installation process in a minimum amount of time. Please read this section in
its entirety before you begin the installation procedure outlined in the sections that
follow.
2-2
A+ SERVER 1022G-URF User's Manual
!
!
Warnings and Precautions!
Choosing a Setup Location
Leave enough clearance in front of the rack to enable you to open the front door •
completely (~25 inches) and approximately 30 inches of clearance in the back
of the rack to allow for suffi cient airfl ow and ease in servicing.This product is for
installation only in a Restricted Access Location (dedicated equipment rooms,
service closets and the like).
This product is not suitable for use with visual display work place devices
•
acccording to §2 of the the German Ordinance for Work with Visual Display
Units.
Rack Precautions
Ensure that the leveling jacks on the bottom of the rack are fully extended to •
the fl oor with the full weight of the rack resting on them.
In single rack installation, stabilizers should be attached to the rack. In multiple •
rack installations, the racks should be coupled together.
Always make sure the rack is stable before extending a component from the •
rack.
You should extend only one component at a time - extending two or more si-•
multaneously may cause the rack to become unstable.
Server Precautions
Review the electrical and general safety precautions in Chapter 4.•
Determine the placement of each component in the rack • before you install the
rails.
Install the heaviest server components on the bottom of the rack fi rst, and then •
work up.
Use a regulating uninterruptible power supply (UPS) to protect the server from •
power surges, voltage spikes and to keep your system operating in case of a
power failure.
Chapter 2: Server Installation
2-3
Allow the hot plug SATA drives and power supply modules to cool before touch-•
ing them.
Always keep the rack's front door and all panels and components on the servers •
closed when not servicing to maintain proper cooling.
Rack Mounting Considerations
Ambient Operating Temperature
If installed in a closed or multi-unit rack assembly, the ambient operating
temperature of the rack environment may be greater than the ambient temperature
of the room. Therefore, consideration should be given to installing the equipment
in an environment compatible with the manufacturer’s maximum rated ambient
temperature (Tmra).
Reduced Airfl ow
Equipment should be mounted into a rack so that the amount of airfl ow required
for safe operation is not compromised.
Mechanical Loading
Equipment should be mounted into a rack so that a hazardous condition does not
arise due to uneven mechanical loading.
Circuit Overloading
Consideration should be given to the connection of the equipment to the power
supply circuitry and the effect that any possible overloading of circuits might have
on overcurrent protection and power supply wiring. Appropriate consideration of
equipment nameplate ratings should be used when addressing this concern.
Reliable Ground
A reliable ground must be maintained at all times. To ensure this, the rack
itself should be grounded. Particular attention should be given to power supply
connections other than the direct connections to the branch circuit (i.e. the use of
power strips, etc.).
2-4
A+ SERVER 1022G-URF User's Manual
2-4 Installing the System into a Rack
This section provides information on installing the 1022G-URF into a rack unit with
the rack rails provided. If the system has already been mounted into a rack, you
can skip ahead to Sections 2-5 and 2-6.
There are a variety of rack units on the market, which may mean the assembly
procedure will differ slightly. You should also refer to the installation instructions that
came with the rack unit you are using.
Identifying the Sections of the Rack Rails
You should have received two rack rail assemblies in the rack mounting kit. Each
assembly consists of two sections: an inner fi xed chassis rail that secures directly
to the server chassis and an outer fi xed rack rail that secures directly to the rack
itself (see Figure 2-1). Two pairs of short brackets to be used on the front side of
the outer rails are also included.
Installing the Inner Rails
Both the left and right side inner rails have been pre-attached to the chassis.
Proceed to the next step.
Figure 2-1. Identifying the Sections of the Rack Rails
(right side rail shown)
Chapter 2: Server Installation
2-5
Installing the Outer Rails
Begin by measuring the distance from the front rail to the rear rail of the rack. Attach
a short bracket to the front side of the right outer rail and a long bracket to the rear
side of the right outer rail. Adjust both the short and long brackets to the proper
distance so that the rail can fi t snugly into the rack. Secure the short bracket to the
front side of the outer rail with two screws and the long bracket to the rear side of
the outer rail with three screws. Repeat these steps for the left outer rail.
Locking Tabs: Both chassis rails have a locking tab, which serves two functions.
The fi rst is to lock the server into place when installed and pushed fully into the
rack, which is its normal position. Secondly, these tabs also lock the server in place
when fully extended from the rack. This prevents the server from coming completely
out of the rack when you pull it out for servicing.
Figure 2-2. Installing the Rack Rails
2-6
A+ SERVER 1022G-URF User's Manual
Figure 2-3. Installing the Server into a Rack
Installing the Server into the Rack
You should now have rails attached to both the chassis and the rack unit. The next
step is to install the server into the rack. Do this by lining up the rear of the chassis
rails with the front of the rack rails. Slide the chassis rails into the rack rails, keeping
the pressure even on both sides (you may have to depress the locking tabs when
inserting). See Figure 2-3 for details.
When the server has been pushed completely into the rack, you should hear the
locking tabs "click".
Chapter 2: Server Installation
2-7
Figure 2-4. Installing the Server into a Telco Rack
Installing the Server into a Telco Rack
To install the 1022G-URF into a Telco type rack, use two L-shaped brackets on
either side of the chassis (four total). First, determine how far follow the server will
extend out the front of the rack. Larger chassis should be positioned to balance the
weight between front and back. If a bezel is included on your server, remove it. Then
attach the two front brackets to each side of the chassis, then the two rear brackets
positioned with just enough space to accommodate the width of the telco rack. Finish
by sliding the chassis into the rack and tightening the brackets to the rack.
2-8
A+ SERVER 1022G-URF User's Manual
2-5 Checking the Serverboard Setup
After you install the 1022G-URF in the rack, you will need to open the top cover
to make sure the serverboard is properly installed and all the connections have
been made.
Accessing the Inside of the System
First, grasp the two handles on either side and pull the system straight out 1.
until it locks (you will hear a "click").
Depress the two buttons on the top of the chassis to release the top cover 2.
(1).
Push the cover away from you (toward the rear of the chassis) until it stops 3.
(2). You can then lift the top cover from the chassis to gain full access to the
inside of the server. See Figure 2-5.
To remove the system from the rack completely, depress the locking tabs in 4.
the chassis rails (push the right-side tab down and the left-side tab up) to
continue to pull the system out past the locked position.
Checking the Components
You may have one or two processors already installed in the serverboard. 1.
Each processor needs its own heatsink. See Chapter 5 for instructions on
processor and heatsink installation.
Your server system may have come with system memory already installed. 2.
Make sure all DIMMs are fully seated in their slots. For details on adding
system memory, refer to Chapter 5.
If desired, you can install add-on cards to the system. See Chapter 5 for 3.
details on installing PCI add-on cards.
Make sure all power and data cables are properly connected and not blocking 4.
the chassis airfl ow. See Chapter 5 for details on cable connections.
Chapter 2: Server Installation
2-9
Figure 2-5. Accessing the Inside of the System
2-6 Checking the Drive Bay Setup
Next, you should check to make sure the peripheral drives and the SATA drives and SATA
backplane have been properly installed and all connections have been made.
Checking the Drives
All drives are accessable from the front of the server. The SATA disk drives 1.
can be installed and removed from the front of the chassis without removing
the top chassis cover.
A slim DVD-ROM drive should be preinstalled in your server. For servicing 2.
the DVD-ROM drive, you will need to remove the top chassis cover. Refer to
Chapter 6 if you need to reinstall a DVD-ROM drive to the system.
Depending upon your system's confi guration, your system may have one or 3.
more drives already installed. If you need to install SATA drives, please refer
to Chapter 6.
2-10
A+ SERVER 1022G-URF User's Manual
Checking the Airfl ow
Airfl ow is provided by four sets of 4-cm fans (each set of fans consists of 1.
two fans that are mounted back to back). The system component layout was
carefully designed to direct suffi cient cooling airfl ow to the components that
generate the most heat.
Note that all power and data cables have been routed in such a way that they 2.
do not block the airfl ow generated by the fans.
Providing Power
The last thing you must do is to provide input power to the system. Plug the 1.
power cords from the power supply modules into a high-quality power strip
that offers protection from electrical noise and power surges.
It is recommended that you use an uninterruptible power supply (UPS).2.
Chapter 3: System Interface
3-1
Chapter 3
System Interface
3-1 Overview
There are several LEDs on the control panel as well as others on the SAS/SATA
drive carriers to keep you constantly informed of the overall status of the system as
well as the activity and health of specifi c components. There are also two buttons
on the chassis control panel and an on/off switch on the power supply. This chapter
explains the meanings of all LED indicators and the appropriate response you may
need to take.
3-2 Control Panel Buttons
There are three push-buttons located on the front of the chassis: a reset button, a
UID button and a power on/off button.
UID
Depressing the UID (unit identifi er) button illuminates an LED on both the front and
rear of the chassis for easy system location in large stack confi gurations. The LED
will remain on until the button is pushed a second time. Another UID button on the
rear of the chassis serves the same function.
Reset
Use the reset button to reboot the system.
3-2
A+ SERVER 1022G-URF User's Manual
Power
The main power button is used to apply or remove power from the power supply
to the server system. Turning off system power with this button removes the main
power but keeps standby power supplied to the system.
3-3 Control Panel LEDs
The control panel located on the front of the SC815TS-RR700UB chassis has fi ve
LEDs. The se LEDs pr ovide you wi th crit ical in format ion relate d to dif ferent par ts
of the system . This section ex plains what each LED i ndicates when il luminated
and any co rrec tive ac tion yo u may need to t ake.
Figure 3-1. Universal Information LED States
Universal Information LED States
State Indication
Fast Blinking Red (1x/sec) Fan Fail
Solid Red CPU Overheat
Slow Blinking Red (1x/4 sec) Power Fail
Solid Blue Local UID Button Depressed
Blinking Blue IPMI-Activated UID
Universal Information LED
When this LED blinks red quickly, it indicates a fan failure and when blinking red
slowly a power failure. The LED will be blue when used for UID (Unit Identifi er).
When on continuously it indicates an overheat condition, which may be caused by
cables obstructing the airfl ow in the system or the ambient room temperature being
too warm. Check the routing of the cables and make sure all fans are present and
operating normally. You should also check to make sure that the chassis covers
are installed. Finally, verify that the heatsinks are installed properly (see Chapter
5). This LED will remain fl ashing or on as long as the indicated condition exists.
See the table below for descriptions of the LED states.
Chapter 3: System Interface
3-3
NIC2
Indicates network activity on LAN2 when fl ashing.
2
1
Note: deactivating the UID LED must be performed in the same way it was activated.
(If the UID LED was activated via IPMI, you can only turn the LED off via IPMI and
not with the UID button.)
NIC1
Indicates network activity on LAN1 when fl ashing.
HDD
On the A+ SERVER 1022G-URF, this light indicates SATA and/or DVD-ROM drive
activity when fl ashing.
Power
Indicates power is being supplied to the system's power supply units. This LED
should normally be illuminated when the system is operating.
3-4
A+ SERVER 1022G-URF User's Manual
3-4 Hard Drive Carrier LEDs
Each hard drive carrier has two LEDs.
Green:• When illuminated, the green LED on the front of the drive carrier in-
dicates drive activity. A connection to the drive backplane enables this LED to
blink on and off when that particular drive is being accessed.
Red:
• The red LED indicates two states. When blinking, it indicates the drive is
rebuilding. When solid, it indicates a drive failure. If a hard drive fails, you should
be notifi ed by your system management software. Please refer to Chapter 6 for
instructions on replacing failed hard drives.
Chapter 4: System Safety
4-1
Chapter 4
System Safety
4-1 Electrical Safety Precautions
!
Basic electrical safety precautions should be followed to protect yourself from harm
and the A+ SERVER 1022G-URF from damage:
Be aware of the locations of the power on/off switch on the chassis as well •
as the room's emergency power-off switch, disconnection switch or electrical
outlet. If an electrical accident occurs, you can then quickly remove power from
the system.
Do not work alone when working with high voltage components.•
Power should always be disconnected from the system when removing or in-•
stalling main system components, such as the serverboard, memory modules
and fl oppy drive. When disconnecting power, you should fi rst power down the
operating system fi rst and then unplug the power cords. The unit has more than
one power supply cord. Disconnect two power supply cords before servicing to
avoid electrical shock.
When working around exposed electrical circuits, another person who is familiar •
with the power-off controls should be nearby to switch off the power if necessary.
Use only one hand when working with powered-on electrical equipment. This •
is to avoid making a complete circuit, which will cause electrical shock. Use
extreme caution when using metal tools, which can easily damage any electrical
components or circuit boards they come into contact with.
Do not use mats designed to decrease static electrical discharge as protection •
from electrical shock. Instead, use rubber mats that have been specifi cally
designed as electrical insulators.
4-2
A+ SERVER 1022G-URF User's Manual
The power supply power cords must include a grounding plug and must be •
plugged into grounded electrical outlets.
This product may be connected to an IT power system. In all cases, make sure •
that the unit is also reliably connected to Earth (ground).
Serverboard Battery: • CAUTION - There is a danger of explosion if the onboard
battery is installed upside down, which will reverse its polarites (see Figure
4-1). This battery must be replaced only with the same or an equivalent type
recommended by the manufacturer. Dispose of used batteries according to the
manufacturer's instructions.
DVD-ROM Laser: • CAUTION - this server may have come equipped with a
DVD-ROM drive. To prevent direct exposure to the laser beam and hazardous
radiation exposure, do not open the enclosure or use the unit in any unconventional way.
Mainboard replaceable soldered-in fuses: Self-resetting PTC (Positive Tempera-•
ture Coeffi cient) fuses on the mainboard must be replaced by trained service
technicians only. The new fuse must be the same or equivalent as the one
replaced. Contact technical support for details and support.
4-2 General Safety Precautions
!
Follow these rules to ensure general safety:
Keep the area around the 1012G-MTF clean and free of clutter.•
The 1022G-URF weighs approximately 40 lbs (18.1kg) when fully loaded. •
When lifting the system, two people at either end should lift slowly with their
feet spread out to distribute the weight. Always keep your back straight and lift
with your legs.
Place the chassis top cover and any system components that have been re-•
moved away from the system or on a table so that they won't accidentally be
stepped on.
Chapter 4: System Safety
4-3
While working on the system, do not wear loose clothing such as neckties and •
unbuttoned shirt sleeves, which can come into contact with electrical circuits or
be pulled into a cooling fan.
Remove any jewelry or metal objects from your body, which are excellent metal •
conductors that can create short circuits and harm you if they come into contact
with printed circuit boards or areas where power is present.
After accessing the inside of the system, close the system back up and secure •
it to the rack unit with the retention screws after ensuring that all connections
have been made.
4-3 ESD Precautions
!
Electrostatic discharge (ESD) is generated by two objects with different electrical
charges coming into contact with each other. An electrical discharge is created to
neutralize this difference, which can damage electronic com ponents and printed
circuit boards. The following measures are generally suffi cient to neutralize this
difference before contact is made to protect your equipment from ESD:
Use a grounded wrist strap designed to prevent static discharge.•
Keep all components and printed circuit boards (PCBs) in their antistatic bags •
until ready for use.
Touch a grounded metal object before removing the board from the antistatic •
bag.
Do not let components or PCBs come into contact with your clothing, which may •
retain a charge even if you are wearing a wrist strap.
Handle a board by its edges only; do not touch its components, peripheral chips, •
memory modules or contacts.
When handling chips or modules, avoid touching their pins.•
Put the serverboard and peripherals back into their antistatic bags when not •
in use.
4-4
A+ SERVER 1022G-URF User's Manual
For grounding purposes, make sure your computer chassis provides excellent •
conductivity between the power supply, the case, the mounting fasteners and
the serverboard.
4-4 Operating Precautions
!
Care must be taken to assure that the chassis cover is in place when the 1022GURF is operating to assure proper cooling. Out of warranty damage to the system
can occur if this practice is not strictly followed.
Figure 4-1. Installing the Onboard Battery
LITHIUM BATTERY
BATTERY HOLDER
Please handle used batteries carefully. Do not damage the battery in any
way; a damaged battery may release hazardous materials into the environment. Do not discard a used battery in the garbage or a public landfi ll.
Please comply with the regulations set up by your local hazardous waste
management agency to dispose of your used battery properly.
!
Chapter 5: Advanced Serverboard Setup
5-1
Chapter 5
Advanced Serverboard Setup
This ch apter cover s the ste ps requi red to inst all pro ces sors a nd heats inks to the
H8DGU-F serverboard, connect the data and power cables and install add-on
cards . All ser verb oard jumpe rs and co nnect ions are de scrib ed and a layout an d
quick re ference chart are included in this chapter. Remember to close the chassis
comple t el y wh en y o u ha v e fi nished working on the serverboard to protect and cool
the system suffi ciently.
5-1 Handling the Serverboard
Static electrical discharge can damage electronic com ponents. To prevent damage
to printed circuit boards, it is important to handle them very carefully (see Chapter 4).
Also note that the size and weight of the serverboard can cause it to bend if handled
improperly, which may result in damage. To prevent the serverboard from bending,
keep one hand under the center of the board to support it when handling.
The following measures are generally suffi cient to protect your equipment from
static discharge.
Precautions
Use a grounded wrist strap designed to prevent static discharge.•
Touch a grounded metal object before removing any board from its antistatic •
bag.
Handle a board by its edges only; do not touch its components, peripheral chips, •
memory modules or gold contacts.
When handling chips or modules, avoid touching their pins.•
Put the serverboard, add-on cards and peripherals back into their antistatic •
bags when not in use.
Unpacking
The serverboard is shipped in antistatic packaging to avoid static damage. When
unpacking the board, make sure the person handling it is static protected.
5-2
A+ SERVER 1022G-URF User's Manual
5-2 Processor and Heatsink Installation
IMPORTANT! Always connect the power cord last and remove it fi rst before
adding, removing or changing any hardware components. Make sure that you
instal l the pro ce ssor in to the CP U socket before you inst all th e heatsi nk and fan.
The H8DGU-F can support either one or two processors. If installing one processor
only, install it in to the CPU1 soc ket.
Note: When purchasing a CPU or when receiving a serverboard with a CPU preinstalled, make sure that the CPU plastic cap is in place and none of the CPU pins
are bent; otherwise, contact the retailer immediately.
!
When handling the processor, avoid placing direct pressure on the label
area of the fan. Also, do not place the ser verboard on a conductive
surface, which can damage the BIOS bat tery and prevent the system
from booting up.
Installing the Processors
Begin by removing the cover plate that 1.
protects the CPU. Lift the lever on the
CPU socket until it points straight up.
With the lever raised, lift open the silver 2.
CPU retention plate.
Chapter 5: Advanced Serverboard Setup
5-3
Triangle
Use your thumb and your index fi nger 3.
to hold the CPU. Locate and align pin
1 of the CPU socket with pin 1 of the
CPU. Both are marked with a triangle.
Align pin 1 of the CPU with pin 1 of the 4.
socket. Once aligned, carefully place
the CPU into the socket. Do not drop
the CPU on the socket, move the CPU
horizontally or vertically or rub the CPU
against the socket or against any pins
of the socket, which may damage the
CPU and/or the socket.
With the CPU inserted into the socket, 5.
inspect the four corners of the CPU to
make sure that it is properly installed
and fl ush with the socket. Then, gently
lower the silver CPU retention plate into
place.
Carefully press the CPU socket lever 6.
down until it locks into its retention
tab. For a dual-CPU system, repeat
these steps to install another CPU into
the CPU#2 socket (and into CPU#2,
#3 and #4 sockets for a quad-CPU
confi guration).
Note: in single and dual-CPU confi gurations, memory must be installed in the DIMM
slots associated with the installed CPU(s). Memory is limited to a maximum of 128
for single CPU and 256 GB for dual CPU confi gurations.
5-4
A+ SERVER 1022G-URF User's Manual
Installing a Passive CPU Heatsink
Do not apply any thermal grease to the heatsink or the CPU die -- the 1.
required amount has already been applied.
Place the heatsink directly on top of the CPU so that the heat sink screws are 2.
aligned with the mounting holes on the back plate.
Make sure the screwdriver torgue setting is no more than 5.0 Kgf-cm (4.3 lbf-3.
in) and keep the heat sink direction vertical.
Tighten each screw a few turns at a time while alternating between the two 4.
until fully tightened.
Figure 5-3. SNK-0042P Heatsink
No. 1 Screw
No. 2 Screw
Removing the Heatsink
Warni ng: W e do not recommend removing the CPU or the heatsink. However, if you do need to remove the heatsink, please follow the instructions
below to pr event damage t o the CPU o r other c ompon ents.
Unscrew the heatsink screws from the motherboard a few turns at a time, 1.
alternating between the two until the screws can be removed.
Gently2. wriggle the heatsink to loosen it from the CPU. (Do not use excessive
force when wriggling the heatsink!)
Once the CPU is loose, remove the it from the CPU socket.3.
Clean the surface of the CPU and the heatsink, removing the used thermal 4.
grease. Reapply the proper amount of thermal grease on the surface before
re-installing the CPU and the heatsink.
!
Chapter 5: Advanced Serverboard Setup
5-5
5-3 Connecting Cables
Now that the processors are installed, the next step is to connect the cables to the
serverboard. These include the data (ribbon) cables for the peripherals and control
panel and the power cables.
Connecting Data Cables
The cables used to transfer data from the peripheral devices have been carefully
routed in preconfi gured systems to prevent them from blocking the fl ow of cooling
air that moves through the system from front to back. If you need to disconnect any
of these cables, you should take care to reroute them as they were originally after
reconnecting them (make sure the red wires connect to the pin 1 locations). If you
are confi guring the system, keep the airfl ow in mind when routing the cables.
The following data cables (with their serverboard connector locations noted) should
be connected. See the serverboard layout diagram in this chapter for connector
locations.
DVD-ROM drive cable (USB4)•
SAS cable (connects to optional UIO SAS controller card)•
Control Panel cable (JF1, see next page)•
Connecting Power Cables
The H8DGU-F has a 20 - pin prim ary p ower supply c onnec tor desi gnated "JPW1"
for con nec ti on to th e ATX power supp ly. Conne ct th e app ropr iate c on nec tor f rom
the power supply to JPW1 to supply power to the serverboard. See the Connector
Defi nitions sec tion in t his ch apter for p ower con necto r pin defi nitions.
In addition, your power supply must be connected to the 8-pin Processor Power
connectors at JPW2 and JPW3.
Connecting the Control Panel
JF1 contains header pins for various front control panel connectors. See Figure 5-1
for the pin locations of the various front control panel buttons and LED indicators.
Please note that even and odd numbered pins are on opposite sides of each
header.
All JF1 wires have been bundled into single keyed ribbon cable to simplify their
connection. The red wire in the ribbon cable plugs into pin 1 of JF1. Connect the
other end of the cable to the Control Panel printed circuit board, located just behind
the system status LEDs in the chassis.
5-6
A+ SERVER 1022G-URF User's Manual
Figure 5-1. Front Control Panel Header Pins (JF1)
See the Connector Defi nitions section in this chapter for details and pin descriptions
of JF1.
5-4 I/O Ports
The I/O ports are color coded in conformance with the PC 99 specifi cation. See
Figure 5-2 below for the colors and locations of the various I/O ports.
Figure 5-2. Rear Panel I/O Ports
1
2
5
4
3 6 7 8
Rear I/O Ports
1. Keyboard 5. COM1
2. PS/2 Mouse 6. VGA Port
3. USB0/1 7. LAN1
4. IPMI LAN (H8DGU-F only 8. LAN2
NMI
x (key)
Vcc
Vcc
Vcc
Vcc
Vcc
Vcc
Reset
Power
Ground
x (key)
Power LED
HDD LED
NIC1
NIC2
OH/Fan Fail LED
Power Fail LED
Ground
Ground
2 1
20 19
Chapter 5: Advanced Serverboard Setup
5-7
5-5 Installing Memory
Figure 5-3. Installing DIMM into Slot
!
CAUTION! Exercise extreme care when installing or removing DIMM
modules to prevent any possible damage.
Memory Support
The H8DGU-F supports up to 256GB of DDR3-1333/1066/800MHz registered ECC
SDRAM or 64 GB of DDR3-1333/1066/800 MHz unbuffered ECC/non-ECC SDRAM
in 16 DIMM slots. See the following table for memory installation.
Memory speed support is dependent on the type of CPU used on the board.
Installing Memory Modules
Insert the desired number of DIMMs into the memory slots, starting with 1.
DIMM 1A. For best memory performance, please install memory modules
of the same type and same speed on the memory slots as indicated on the
tables below.
Insert each DIMM module vertically into its slot. Pay attention to the notch 2.
along the bottom of the module to avoid installing incorrectly (see Figure 5-3).
Gently press down on the DIMM module until it snaps into place in the slot. 3.
Repeat for all modules.
To Install: Insert
module vertically and
press down until it
snaps into place. Pay
attention to the alignment notch at the
bottom.
To Remove: Use
your thumbs to gently push the release
tabs near both ends
of the module. This
should release it from
the slot.
Top View of DDR3 Slot
Release Tab Release Tab
Note: Notch should align with
the receptive key point on
the slot.
Notch
Notch
Front View
5-8
A+ SERVER 1022G-URF User's Manual
Memory Population for Optimal Performance
-For a Motherboard with One CPU (CPU1) Installed
# DIMMS CPU Branch 0 Branch 1 Branch 2 Branch 3
2 DIMMs CPU1 P1-1A P1-2A
4 DIMMs CPU1 P1-1A P1-2A P1-3A P1-4A
8 DIMMs CPU1 P1-1A P1-1B P1-2A P1-2B P1-3A P1-3B P1-4A P1-4B
Memory Population for Optimal Performance
-For a Motherboard with Two CPUs (CPU1 & CPU2) Installed
# DIMMS CPU Branch 0 Branch 1 Branch 2 Branch 3
4 DIMMs CPU1 P1-1A P1-2A
CPU2 P2-1A P2-2A
8 DIMMs CPU1 P1-1A P1-2A P1-3A P1-4A
CPU2 P2-1A P2-2A P2-3A P2-4A
16 DIMMs CPU1 P1-1A P1-1B P1-2A P1-2B P1-3A P1-3B P1-4A P1-4B
CPU2 P2-1A P2-1B P2-2A P2-2B P2-3A P2-3B P2-4A P2-4B
DIMM Module Population Confi guration
For memory to work properly, follow the tables below for memory installation:
DIMM Population Table
DIMM
Slots per
Channel
DIMMs
Populated
per
Channel
DIMM Type (Reg.=
Registered)
Speeds (in MHz) Ranks per
DIMM (any
combination;
SR=Single Rank,
DR=Dual Rank,
QR=Quad Rank)
2 1 Reg. DDR3 ECC 1066,1333 SR or DR
2 1 Reg. DDR3 ECC 1066,1333 QR
2 2 Reg. DDR3 ECC 1066 Mixing SR, DR, QR
2 1 Unb. DDR3 ECC 1066,1333 SR or DR
2 2 Unb. DDR3 ECC 1066,1333 Mixing SR, DR
Note 1: Due to OS limitations, some operating systems may not show more than
4 GB of memory.
Note 2: Due to memory allocation to system devices, the amount of memory that
remains available for operational use will be reduced when 4 GB of RAM is used.
The reduction in memory availability is disproportional.
Chapter 5: Advanced Serverboard Setup
5-9
Possible System Memory Allocation & Availability
System Device Size Physical Memory Available
(4 GB Total System
Memory)
Firmware Hub fl ash memory (System BIOS) 1 MB 3.99 GB
Local APIC 4 KB 3.99 GB
Area Reserved for the chipset 2 MB 3.99 GB
I/O APIC (4 Kbytes) 4 KB 3.99 GB
PCI Enumeration Area 1 256 MB 3.76 GB
PCI Express (256 MB) 256 MB 3.51 GB
PCI Enumeration Area 2 (if needed) -Aligned on 256-M
boundary-
512 MB 3.01 GB
VGA Memory 16 MB 2.85 GB
TSEG 1 MB 2.84 GB
Memory available for the OS & other applications 2.84 GB
5-10
A+ SERVER 1022G-URF User's Manual
5-6 Adding PCI Cards
PCI Expansion Slots
A riser card is used to support a left side add-on card to the system.
Installing the PCI Expansion Card
Remove the chassis cover.1.
Install the riser card by sliding card into the appropriate slot in the 2.
motherboard.
Choose the PCI slot shield in which to place the add-on card. 3.
In that slot, open the PCI slot shield lever and slide the shield sideways. 4.
From inside the chassis, remove the PCI slot shield.5.
Slide the add-on card into the riser card and attach the add-on card bracket 6.
in place of the PCI slot shield.
Secure the add-on card by closing the PCI slot shield lever.7.
Connect cables to the add-on card as necessary.8.
Note: If the left side riser is with 2 or more x8 PCI-E slots make sure an installed
card on the left side riser is detected. If it is not, then go to the system’s BIOS Setup
and in Advanced/ PCI/PnP Confi guration /SXB1 Confi guration BIOS setting select
the [2x8] option. Then save the BIOS setting changes and reboot the system.
Chapter 5: Advanced Serverboard Setup
5-11
Figure 5-4. SUPER H8DGU-F Layout
(not drawn to scale)
5-7 Serverboard Details
JD1
JPW1
JF1
JI2C1
JI2C2
JOH1
JL1
JWF1
JPL1
JWD
JPG1
FAN3
FAN8
FAN2
FAN1
FAN7
FAN4
FAN5
FAN6
LE1
UIOP
JPW2 JPW3
IPMB
JPI2C
DP2
BATTERY
SATA5
SATA0
SATA1
SATA2
SATA3
SATA4
T-SGPIO2
T-SGPIO1
UID
P1-DIMM4A
P2-DIMM1B
P1-DIMM4B
P2-DIMM1A
USB0/1
USB6
USB4/5
USB2/3
P1-DIMM3A
P2-DIMM2B
P1-DIMM3B
P2-DIMM2A
P1-DIMM2A
P2-DIMM3B
COM1
IPMI_LAN
PCI-E 2.0 x8 in x4 SLOT
P1-DIMM2B
P2-DIMM3A
KB/MOUSE
LAN2
LAN1
P1-DIMM1A
COM2
P1-DIMM1B
P2-DIMM4A
CPU1
CPU2
VGA
JBT1
PCI-E 2.0 x16 SLOT
Winbond
BMC
AMD
SR5670
AMD
SP5100
P2-DIMM4B
JP2
Notes:
Jumpers not indicated are for test purposes only.
When LE1 LED is on, the onboard power connection is on. Make sure to unplug
the power cables before removing or installing components.
IPMI (Intelligent Platform Management Interface) 2.0 is supported by the H8DGU-F.
For more information on IPMI confi guration, refer to the Embedded BMC IPMI User
Guide @http://www.supermicro.com/support/manuals/.
Warning
To provide adequate power to the add-on cards installed on the serverboard,
please connect the UIOP PWR connector to the power supply for these cards to
work properly.
5-12
A+ SERVER 1022G-URF User's Manual
H8DGU(-F) Quick Reference
Jumper Description Default Setting
JBT1 CMOS Clear (See Section 2-7)
JI2C1/JI2C2 I2C to PCI-E Slot Enable/Disable Both Closed (Enabled)
JPG1 VGA Enable/Disable Pins 1-2 (Enabled)
JPL1 LAN 1/2 Enable/Disable Pins 1-2 (Enabled)
JWD Watch Dog Pins 1-2 (Reset)
LED Description
LAN Ports LEDs for the LAN Ethernet ports
Dedicated IPMI LAN LEDs for the dedicated IPMI LAN Ethernet port
LE1 LED for UID Button
DP2 LED for Serverboard Power-On
Connector Description
COM1/COM2 COM1 Serial Port/Header
FAN 1-8 Chassis/CPU Fan Headers
IPMB System Management Bus Header for the IPMI Slot
IPMI LAN Dedicated IPMI LAN Port (H8DGU-F only)
JD1 Speaker Header
JF1 Front Panel Connector
JL1 Chassis Intrusion Header
JOH1 Overheat Warning Header
JPW1 24-pin Main ATX Power Connector
JPW2/3 +12V 8-pin CPU Power Connectors
JWF1 Compact Flash Card Power Connector
LAN1/2 Gigabit Ethernet (RJ45) Ports
PS2 Mouse/Keyboard PS2 Mouse/Keyboard connectors
SATA0~SATA5 SATA Ports
T-SGPIO-1/TSGPIO-2 Serial General Purpose Input/Output Header for SATA
UID Unit Identifi er Button
UIOP Universal I/O Power Connector
USB0/1, USB2/3, USB4/5, USB6 Universal Serial Bus (USB) Ports, Headers and Type-A Port
VGA VGA Connector
Chapter 5: Advanced Serverboard Setup
5-13
5-8 Connector Defi nitions
Power Connectors
A 24-pin main power supply connector(JPW1)
and three 8-pin CPU PWR connectors
(JPW2/JPW3/JPW4) on the motherboard.
These power connectors meet the SSI EPS
12V specifi cation. In addition to the 24-pin
ATX power connector, the 12V 8-pin CPU
PWR connectors at JPW2/JPW3/JPW4 must
also be connected to your power supply . See
the table on the right for pin defi nitions.
Warning: To prevent damage to the power
supply or motherboard, please use a power
supply that contains a 24-pin and three 8-pin
power connectors. Be sure to connect these
connectors to the 24-pin (JPW1) and the
three 8-pin (JPW2,JPW3 and JPW4) power
connectors on the motherboard. Failure in
doing so will void the manufacturer warranty
on your power supply and motherboard.
Reset Connector
The reset connector is located on pins 3 and
4 of JF1 and attaches to the reset switch on
the computer chassis. See the table on the
right for pin defi nitions.
PW_ON Connector
The PW_ON connector is on pins 1 and 2 of
JF1. This header should be connected to the
chassis power button. See the table on the
right for pin defi nitions.
ATX Power 24-pin Connector
Pin Defi nitions
Pin# Defi nition Pin # Defi nition
13 +3.3V 1 +3.3V
14 -12V 2 +3.3V
15 COM 3 COM
16 PS_ON 4 +5V
17 COM 5 COM
18 COM 6 +5V
19 COM 7 COM
20 Res (NC) 8 PWR_OK
21 +5V 9 5VSB
22 +5V 10 +12V
23 +5V 11 +12V
24 COM 12 +3.3V
12V 8-pin PWR Connector
Pin Defi nitions
Pins Defi nition
1 through 4 Ground
5 through 8 +12V
Required Connection
Reset Button
Pin Defi nitions
(JF1)
Pin# Defi nition
3 Reset
4 Ground
Power Button
Pin Defi nitions
(JF1)
Pin# Defi nition
1 PW_ON
2 Ground
5-14
A+ SERVER 1022G-URF User's Manual
Overheat/Fan Fail LED (OH)
Connect an LED to the OH connection on
pins 7 and 8 of JF1 to provide advanced
warning of chassis overheating or fan
failure. Refer to the table on the right for pin
defi nitions and status indicators.
OH/Fan Fail LED
Pin Defi nitions
(JF1)
Pin# Defi nition
7 Vcc
8 Control
OH/Fan Fail
LED Status
State Indication
Solid Overheat
Blinking Fan fail
NIC2 (LAN2) LED
The LED connections for LAN2 are on pins
9 and 10 of JF1. Attach LAN LED cables to
display network activity. See the table on the
right for pin defi nitions.
HDD LED
The HDD LED connection is located on pins
13 and 14 of JF1. Attach the hard drive LED
cable here to display disk activity (for any
hard drives on the system, including SAS,
Serial ATA and IDE). See the table on the
right for pin defi nitions
NIC1 LED
Pin Defi nitions
(JF1)
Pin# Defi nition
11 Vcc
12 Ground
NIC2 LED
Pin Defi nitions
(JF1)
Pin# Defi nition
9 Vcc
10 Ground
NIC1 (LAN1) LED
The LED connections for LAN1 are on pins
11 and 12 of JF1. Attach LAN LED cables to
display network activity. See the table on the
right for pin defi nitions.
Power On LED
The Power On LED connector is located
on pins 15 and 16 of JF1. This connection
is used to provide LED indication of power
being supplied to the system. See the table
on the right for pin defi nitions.
Power LED
Pin Defi nitions
(JF1)
Pin# Defi nition
15 5V Stby
16 Control
NMI Button
The non-maskable interrupt button header is
located on pins 19 and 20 of JF1. Refer to the
table on the right for pin defi nitions.
NMI Button
Pin Defi nitions
(JF1)
Pin# Defi nition
19 Control
20 Ground
HDD LED
Pin Defi nitions
(JF1)
Pin# Defi nition
13 Vcc
14 HD Active
Chapter 5: Advanced Serverboard Setup
5-15
Universal Serial Bus Ports
Two Universal Serial Bus ports (USB 2.0) are
located beside the Keyboard and Mouse PS2
ports. One additional Type A port (USB6) is
included on the motherboard. See the table
on the right for pin defi nitions.
Universal Serial Bus Ports
Pin Defi nitions (USB0/1, USB6)
USB0
Pin # Defi nition
USB1
Pin # Defi nition
1 +5V 1 +5V
2 PO- 2 PO3 PO+ 3 PO+
4 Ground 4 Ground
USB Headers
Four USB 2.0 headers (USB2/3 and USB4/5)
are also included on the motherboard. These
may be connected to provide front side
access. A USB cable (not included) is needed
for the connection. See the table on the right
for pin defi nitions.
Universal Serial Bus Headers
Pin Defi nitions (USB4/5)
USB2
Pin # Defi nition
USB3
Pin # Defi nition
1 +5V 1 +5V
2 PO- 2 PO3 PO+ 3 PO+
4 Ground 4 Ground
5 Key 5 NC
Fan Header
Pin Defi nitions
Pin# Defi nition
1 Ground
2 +12V
3 Tachometer
4 PWR Modulation
Fan Headers
This motherboard has eight fan headers
(Fan1 to Fan8). These 4-pin fans headers
are backward compatible with 3-pin fans.
However, fan speed control is available
for 4-pin fans only. The fan speeds are
controlled by the BIOS. See the table on the
right for pin defi nitions
Note: NC indicates no connection.
Serial Ports
The COM1 serial port is located beside the
VGA port. Refer to the motherboard layout
for the location of the COM2 header. See the
table on the right for pin defi nitions.
Note: NC indicates no connection.
Serial Port Pin Defi nitions
(COM1/COM2)
Pin # Defi nition Pin # Defi nition
1 DCD 6 DSR
2 RXD 7 RTS
3 TXD 8 CTS
4 DTR 9 RI
5 Ground 10 NC
5-16
A+ SERVER 1022G-URF User's Manual
T-SGPIO
The T-SGPIO1/ T-SGPIO2 (Serial General
Purpose Input/Output) headers provide a bus
between the SAT A controller and the backpane
to provide SATA enclosure management
functions. Connect the appropriate cable
from the backplane to the T-SGPIO1 header
to utilize SATA management functions on
your system.
SGPIO Header Pin Defi nitions
(T-SGPIO1/T-SGPIO2)
Pin# Defi nition Pin# Defi nition
1 NC 2 Data In
3 Ground 4 Data Out
5 Load 6 Ground
7 Clock 8 NC
Note: NC indicates no connection.
UIO Power Connector
A Universal I/O (UIO) Power connector is
located next to the UID switch. Connect this
connector to the power supply to provide
adequate power to the UIO device installed
on the slot for this device to function
properly.
UIO Power Connector
Pin Defi nitions (UIOP)
Pin# Defi nition Pin# Defi nition
B1 5V_1 A1 3V3_1
B2 5V_2 A2 3V3_2
B3 5V_3 A3 3V3_3
B4 5V_4 A4 3V3_4
B5 5V_5 A5 3V3_5
B6 5V_6 A6 3V3_6
B7 5V_7 A7 3V3_7
B8 5V_8 A8 3V3_8
B9 5V_9 A9 3V3_9
B10 5V_10 A10 3V3_10
B11 N12V A11 3V3
B12 3V3_STBY A12 3V3
B13 3V3_STBY A13 P12V_2
B14 GND A14 P12V
B15 GND A15 P12V
B16 GND_1 A16 P12V
B17 GND_2 A17 P12V
B18 GND_3 A18 GND_7
LAN1/2 (Ethernet Ports)
Two Gigabit Ethernet ports (designated LAN1
and LAN2) are located beside the VGA port.
Additionally, for the H8DGU-F serverboard,
there is a dedicated LAN for IPMI on top of
the two rear USB ports. These Ethernet ports
accept RJ45 type cables.
Chapter 5: Advanced Serverboard Setup
5-17
ATX PS/2 Keyboard and PS/2 Mouse
Ports
The ATX PS/2 keyboard and PS/2 mouse are
located next to the Back Panel USB Ports
0~3 on the motherboard. See the table at
right for pin defi nitions.
PS/2 Keyboard/Mouse Pin
Defi nitions
PS2 Keyboard PS2 Mouse
Pin# Defi nition Pin# Defi nition
1 KB Data 1 Mouse Data
2 No
Connection
2 No
Connection
3 Ground 3 Ground
4 Mouse/KB
VCC (+5V)
4 Mouse/KB
VCC (+5V)
5 KB Clock 5 Mouse Clock
6 No
Connection
6 No
Connection
VCC: with 1.5A PTC (current limit)
Power LED/Speaker
On the JD1 header, pins 1~3 are used for
power LED indication, and pins 4-7 are for
the speaker. See the tables on the right for
pin defi nitions. If you wish to use the onboard
speaker, you should close pins 6~7 with a
jumper. Connect a cable to pins 4~7 of JD1
to use an external speaker.
Speaker Connector
Pin Defi nitions
Pin Setting Defi nition
Pins 4~7 External Speaker
Pins 6~7 Internal Speaker
PWR LED Connector
Pin Defi nitions
Pin Setting Defi nition
Pin 1 Anode (+)
Pin2 Cathode (-)
Pin3 NA
Chassis Intrusion
A Chassis Intrusion header is located at JL1.
Attach the appropriate cable to inform you of
a chassis intrusion.
Chassis Intrusion
Pin Defi nitions
(JL1)
Pin# Defi nition
1 Battery voltage
2 Intrusion signal
Overheat LED
Connect an LED to the JOH1 header to
provide warning of chassis overheating. See
the table on the right for pin defi nitions.
Overheat LED
Pin Defi nitions
(JOH1)
Pin# Defi nition
1 3.3V
2 OH Active
5-18
A+ SERVER 1022G-URF User's Manual
UID Button
Pin Defi nitions
Pin# Defi nition
1 Ground
2 Ground
3 Button In
4 Ground
Unit Identifi er Button
In addition to the UID (Unit Identifi er) button
on the rear I/O panel, there is another UID
button located on the control panel. When
you push either UID button, both Rear
UID and Front Panel UID Indicators will
illuminate. Push either button again to turn off
both indicators. These UID indicators provide
easy identifi cation of a system unit that may
be in need of service.
IPMB
A System Management Bus header for the
IPMI slot is located at IPMB. Connect the
appropriate cable here to use the IPMB I2C
connection on your system.
IPMB
Pin Defi nitions
Pin# Defi nition
1 Data
2 Ground
3 Clock
4 No Connection
Video Connector
A Video (VGA) connector is located below
the COM Port on the IO backplane. This
connector is used to provide video and CRT
display.
Compact Flash Card PWR Connector
A Compact Flash Card Power Connector
is located at JWF1. For the Compact Flash
Card to work properly , you will need to enable
with JCF1 and connect a Compact Flash
Card power cable to JWF1 fi rst.
Chapter 5: Advanced Serverboard Setup
5-19
5-9 Jumper Settings
Explanation of Jumpers
To modify the operation of the motherboard,
jumpers can be used to choose between
optional settings. Jumpers create shorts
between two pins to change the function
of the connector. Pin 1 is identifi ed with
a square solder pad on the printed circuit
board. See the diagram at right for an
example of jumping pins 1 and 2. Refer
to the motherboard layout page for jumper
locations.
Note: On two-pin jumpers, "Closed" means
the jumper is on and "Open" means the
jumper is off the pins.
Connector
Pins
Jumper
Setting
3 2 1
3 2 1
CMOS Clear
JBT1 is used to clear CMOS, which will also clear any passwords. Instead of pins,
this jumper consists of contact pads to prevent accidentally clearing the contents
of CMOS.
To Clear CMOS
First power down the system and unplug the power cord(s).1.
With the power disconnected, short the CMOS pads with a metal object such 2.
as a small screwdriver.
Remove the screwdriver (or shorting device).3.
Reconnect the power cord(s) and power on the system.4.
Note: Do not use the PW_ON connector to clear CMOS.
JBT1 contact pads
5-20
A+ SERVER 1022G-URF User's Manual
VGA Enable/Disable
JPG1 allows you to enable or disable the
VGA port. The default position is on pins 1
and 2 to enable VGA. See the table on the
right for jumper settings.
VGA Enable/Disable
Jumper Settings (JPG1)
Jumper Setting Defi nition
Pins 1-2 Enabled
Pins 2-3 Disabled
I2C to PCI-Express Slot
JI2C1/JI2C2 allows you to enable the I2C bus
to communicate with the PCI-Express slot.
For the jumpers to work properly, please set
both jumpers to the same setting. If enabled,
both jumpers must be enabled. If disabled,
both jumpers must be disabled. See the table
on the right for jumper settings.
I2C to PCI-Express Slot
Jumper Settings
(JI2C1/JI2C2)
Jumper Setting Defi nition
Closed Enabled
Open Disabled
Watch Dog Enable/Disable
JWD enables the Watch Dog function, a
system monitor that takes action when a
software application freezes the system.
Jumping pins 1-2 will have WD reboot the
system if a program freezes. Jumping pins
2-3 will generate a non-maskable interrupt
for the program that has frozen. See the
table on the right for jumper settings. Watch
Dog must also be enabled in BIOS.
Note: When Watch Dog is enabled,
the user must write their own
application software to disable the
Watch Dog Timer.
Watch Dog
Jumper Settings (JWD)
Jumper Setting Defi nition
Pins 1-2 Reset
Pins 2-3 NMI
Open Disabled
LAN1/2 Enable/Disable
Change the setting of jumper JPL1 to enable
to enable or disable the LAN1 and LAN2
Ethernets ports. See the table on the right
for jumper settings. The default setting is
enabled.
LAN1/2 En/Disable
Jumper Settings (JPL1)
Jumper Setting Defi nition
Pins 1-2 Enabled
Pins 2-3 Disabled
Chapter 5: Advanced Serverboard Setup
5-21
5-10 Onboard Indicators
LAN1/LAN2 LEDs
The Ethernet ports (located beside the VGA
port) have two LEDs. On each Gb LAN port,
one LED blinks to indicate activity while the
other may be green, amber or off to indicate
the speed of the connection. See the table
on the right for the functions associated with
the connection speed LED.
Dedicated IPMI LAN LEDs
A dedicated IPMI LAN is also included on
the H8DGU-F serverboard (DP5001). The
amber LED on the right indicates activity,
while the green LED on the left indicates
the spe ed of the co nnecti on. See the t able
at right fo r more info rmati on.
UID LED (LE1)
A rear UID LED Indicator, located at LE1,
works in conjunction with the rear UID switch
to provide easy identifi cation for a unit that
might be in need of service. Refer to Page
2-15 for further UID details.
Power LED
DP2 is an Onboard Power LED. When
this LED is lit, it means power is present
on the serverboard. Be sure to turn off the
system and unplug the power cord(s) before
removing or installing components.
LAN LED
(Connection Speed
Indicator)
LED Color Defi nition
Off 10 MHz
Green 100 MHz
Amber 1 GHz
IPMI LAN Link LED (Left) &
Activity LED (Right)
Color Status Defi nition
Link
(Left)
Green:
Solid
100 Mb/s
Activity
(Right)
Amber:
Blinking
Active
Power LED (DP2)
State System Status
On Standby power present on
motherboard
Off No power connected
5-22
A+ SERVER 1022G-URF User's Manual
5-11 SATA Drive Connections
SATA Ports
There are no jumpers to confi gure the SATA
ports, which are designated SATA0 through
SATA5. See the table on the right for pin
defi nitions.
SATA Ports Pin Defi nitions
(SATA0-SATA3)
Pin # Defi nition Pin # Defi nition
1 Ground 5 RXN
2 TXP 6 RXP
3 TXN 7 Ground
4 Ground
Chapter 5: Advanced Serverboard Setup
5-23
5-12 Enabling SATA RAID
Now that the hardware is set up, you must install the operating system and the
SATA RAID drivers, if you wish to use RAID with your SATA drives. The installation
procedure differs depending on whether you wish to have the operating system
installed on a RAID array or on a separate non-RAID drive. See the instructions
below for details.
Serial ATA (SATA)
Serial ATA (SATA) is a physical storage interface that employs a single cable with a
minimum of four wires to create a point-to-point connection between devices. This
connection is a serial link that supports a SATA transfer rate from 150 MBps. The
serial cables used in SATA are thinner than the traditional cables used in Parallel
ATA (PATA) and can extend up to one meter in length, compared to only 40 cm for
PATA cables. Overall, SATA provides better functionality than PATA.
Installing the OS/SATA Driver
Before installing the OS (operating system) and SA TA RAID driver, you must decide
if you wish to have the operating system installed as part of a bootable RAID array
or installed to a separate non-RAID hard drive. If on a separate drive, you may
install the driver either during or after the OS installation. If you wish to have the
OS on a SATA RAID array, you must follow the procedure below and install the
driver during the OS installation.
Building a Driver Diskette
Y ou must fi rst build a driver diskette from the Supermicro CD-ROM that was included
with the system. (You will have to create this disk on a computer that is already
running and with the OS installed.)
Building a Driver Diskette
Insert the CD into your CD-ROM drive and start the system. A display as 1.
shown in Figure 5-7 will appear.
Click on the icon labeled "Build Driver Diskettes and Manuals" and follow the 2.
instructions to create a fl oppy disk with the driver on it.
Once it's been created, remove the fl oppy and insert the installation CD for 3.
the Windows Operating System you wish to install into the CD-ROM drive of
the new system you are about to confi gure.
5-24
A+ SERVER 1022G-URF User's Manual
Figure 5-5. BIOS Setup Screen
Note: You need to have an external USB fl oppy when building the driver diskette.
Window's Vista, Windows 2008 or later Windows OS systems can use a USB stick
instead of a fl oppy.
Enabling SATA RAID in the BIOS
Before installing the Windows Operating System, you must change some settings
in BIOS. Boot up the system and hit the <Del> key to enter the BIOS Setup Utlility.
After the Setup Utility loads,
Use the arrow keys to move to the Exit menu. Scroll down with the arrow 1.
keys to the "Load Optimal Defaults setting and press <Enter>. Select "OK" to
confi rm, then <Enter> to load the default settings.
Use the arrow keys to move to the "Advanced" menu, then scroll down to 2.
"Chipset Confi guration". Next enter "SourthBridge Confi guration" and press
the <Enter> key. Once in this submenu, scroll down to "OnChip SATA Type"
and choose the "RAID" option (see Figure 5-5).
Hit the <Esc> key twice and scroll to the Exit menu. Select "Save Changes 3.
and Exit" and hit <enter>, then hit <Enter> again to verify.
Chapter 5: Advanced Serverboard Setup
5-25
After exiting the BIOS Setup Utility, the system will reboot. When prompted 1.
during the startup, press the <CTRL+A> key when prompted to run the DotHill RAID Utility program (see Figure 5-6).
Figure 5-6.Adaptec RAID Utility Program Screen
Using the Adaptec RAID Utility
The Adaptec® RAID Utility program is where you can defi ne the drives you want
to include in the RAID array and the mode and type of RAID.
Installing the RAID Driver During OS Installation
Y ou may also use the procedure below to install the RAID driver during the Window's
OS installation:
With the Windows OS installation CD in the CD-ROM drive, restart the 1.
system.
When you see the prompt, hit the <F6> key to enter Windows setup.2.
Eventually a blue screen will appear with a message that begins "Windows 3.
could not determine the type of one or more storage devices . . ." When you
see the screen, hit the <S> key to "Specify Additional Device", then insert the
driver diskette you just created into the fl oppy drive.
Highlight "Manufuacturer Supplied Hardware Support Disk" and hit the 4.
<Enter> key.
5-26
A+ SERVER 1022G-URF User's Manual
Highlight the fi rst "Adaptec RAID" driver shown and press the <Enter> key to 5.
install it.
Press <Enter> again to continue with the Windows setup.6.
Figure 5-7. Driver/Tool Installation Display Screen
5-13 Installing Drivers
The CD that came bundled with the system contains drivers, some of which must
be installed, such as the chipset driver. After inserting this CD into your CD-ROM
drive, the display shown in Figure 5-7 should appear. (If this display does not appear ,
click on the My Computer icon and then on the icon representing your CD-ROM
drive. Finally, double click on the S "Setup" icon.)
Click the icons showing a hand writing on paper to view the readme fi les for each
item. Click the computer icons to the right of these items to install each item (from
top to the bottom) one at a time. After installing each item, you should reboot the
system before moving on to the next item on the list. The bottom icon with a CD
on it allows you to view the entire contents of the CD.
Chapter 5: Advanced Serverboard Setup
5-27
Supero Doctor III
The Supero Doctor III program is a Web base management tool that supports remote
management capability. It includes Remote and Local Management tools. The local
management is called SD III Client. The Supero Doctor III program included on the
CD-ROM that came with your motherboard allows you to monitor the environment
and operations of your system. Supero Doctor III displays crucial system information
such as CPU temperature, system voltages and fan status. See the Figure below
for a display of the Supero Doctor III interface.
Note: The default User Name and Password for SuperDoctor III is ADMIN /
ADMIN.
Note: When SuperDoctor III is fi rst installed, it adopts the temperature threshold
settings that have been set in BIOS. Any subsequent changes to these thresholds
must be made within Super Doctor, as the Super Doctor settings override the BIOS
settings. To set the BIOS temperature threshold settings again, you would fi rst need
to uninstall SuperDoctor III.
Figure 5-8. Supero Doctor III Interface Display Screen (Health Information)
5-28
A+ SERVER 1022G-URF User's Manual
Note: Super Doctor III Software Revision 1.0 can be downloaded from our
Web Site at: ftp://ftp.supermicro.com/utility/Supero_Doctor_III/. You can also
download the Super Doctor III User's Guide at: <http://www.supermicro.com/
PRODUCT/Manuals/SDIII/UserGuide.pdf>. For Linux, we recommend that you use
the Supero Doctor II applictation instead.
Figure 5-9. Supero Doctor III Interface Display Screen (Remote Control)
Chapter 5: Advanced Serverboard Setup
5-29
Notes
Chapter 6: Advanced Chassis Setup
6-1
Chapter 6
Advanced Chassis Setup
This chapter covers the steps required to install components and perform
maintenance on the 815TS-R700UBP chassis. For component installation, follow
the steps in the order given to eliminate the most common problems encountered.
If some steps are unnecessary, skip ahead to the next step.
Tools Required: The only tool you will need to install components and perform
maintenance is a Philips screwdriver.
6-1 Static-Sensitive Devices
Electrostatic discharge (ESD) can damage electronic com ponents. To prevent
damage to any printed circuit boards (PCBs), it is important to handle them very
carefully. The following measures are generally suffi cient to protect your equipment
from ESD damage.
Precautions
Use a grounded wrist strap designed to prevent static discharge.•
Touch a grounded metal object before removing any board from its antistatic •
bag.
Handle a board by its edges only; do not touch its components, peripheral chips, •
memory modules or gold contacts.
When handling chips or modules, avoid touching their pins.•
Put the serverboard, add-on cards and peripherals back into their antistatic •
bags when not in use.
For grounding purposes, make sure your computer chassis provides excellent •
conductivity between the power supply, the case, the mounting fasteners and
the serverboard.
6-2
A+ SERVER 1022G-URF User's Manual
Figure 6-1. Chassis: Front and Rear Views
6-2 Control Panel
The control panel (located on the front of the chassis) must be connected to the JF1
connector on the serverboard to provide you with system status indications. These
wires have been bundled together as a ribbon cable to simplify the connection.
Connect the cable from JF1 on the serverboard to the appropriate header on the
Control Panel PCB (printed circuit board). Make sure the red wire plugs into pin 1
on both connectors. Pull all excess cabling out of the airfl ow path.
The control panel LEDs inform you of system status. See "Chapter 3: System
Interface" for details on the LEDs and the control panel buttons. Details on JF1 can
be found in "Chapter 5: Advanced Serverboard Setup."
6-3 System Fans
Four 4-cm heavy duty counter-rotating fans provide the cooling for the A+
SERVER 1022G-URF. Each fan unit is actually made up of two fans joined backto-back, which rotate in opposite directions. This counter-rotating action generates
exceptional airfl ow and works to dampen vibration levels. It is very important that
the chassis top cover is properly installed and making a good seal in order for the
cooling air to circulate properly through the chassis and cool the components. See
Figure 6-2.
System Reset
Control PanelSystem LEDs
Main Power Hard Drive Bays
Slim DVD-ROM Drive
Note: the SC815TQ-560UBP chassis (6016T-UF/6016T-NTF) has only a single
power supply module.
Power Supply Modules PCI Expansion Slots (w/ Riser Cards)
Mouse/Keyboard Ports
USB Ports
COM1 Port VGA Port Ethernet Ports
Chapter 6: Advanced Chassis Setup
6-3
System Fan Failure
Fan speed is controlled by system temperature via a BIOS setting. If a fan fails,
the remaining fan will ramp up to full speed and the overheat/fan fail LED on the
control panel will turn on. Replace any failed fan at your earliest convenience with
the same type and model (the system can continue to run with a failed fan).
Remove the top chassis cover while the system is still running to determine which
of the two fans has failed. Then power down the system before replacing a fan.
Removing the power cords is also recommended as a safety precaution.
Replacing System Fans
After determining which fan has failed, turn off the power to the system.1.
Unplug the fan cable from the serverboard and remove the failed fan from the 2.
chassis.
Replace the failed fan with an identical 4-cm, 12 volt fan (available from 3.
Supermicro: p/n FAN-0086L4).
Push the new fan into the vacant space in the housing while making sure 4.
the arrows on the top of the fan (indicating air direction) point in the same
direction as the arrows on the other fans.
Figure 6-2. System Cooling Fans
Optional Fan
6-4
A+ SERVER 1022G-URF User's Manual
Accessing the Drive Bays
Hard Drives: Because of their hotswap capability, you do not need to access the
inside of the chassis or power down the system to install or replace SATA drives.
Proceed to the next section for instructions.
DVD-ROM Drive: For installing/removing a DVD-ROM drive, you will need to gain
access to the inside of the 1022G-URF by removing the top cover of the chassis.
Proceed to the "DVD-ROM Drive Installation" section later in this chapter for
instructions.
Note: Only a "slim" DVD-ROM drive will fi t into the 1022G-URF.
Figure 6-3. Removing the Front Bezel
1. Unlock
2. Press release knob
3. Remove bezel assembly
Reposition the fan housing back over the two mounting posts in the chassis, 5.
then reconnect the fan wires to the same chassis fan headers you removed
them from.
Power up the system and check that the fan is working properly and that 6.
the LED on the control panel has turned off. Finish by replacing the chassis
cover.
6-4 Drive Bay Installation/Removal
Removing the Front Bezel
If your system has a front bezel (optional) attached to the chassis, you must fi rst
remove it to gain access to the drive bays. To remove the bezel, fi rst unlock the
front of the chassis then press the release knob (see Figure 6-3). Carefully remove
the bezel with both hands. A fi lter located within the bezel can be removed for
replacement/cleaning. It is recommended that you keep a maintenance log of
fi lter cleaning/replacement, since its condition will affect the airfl ow throughout the
whole system.
Chapter 6: Advanced Chassis Setup
6-5
Hard Drive Installation
The hard drives are mounted in drive carriers to simplify their installation and
removal from the chassis. These carriers also help promote proper airfl ow for
the drive bays. For this reason, even empty carriers without drives installed must
remain in the chassis.
Mounting a Hard Drive in a Drive Carrier
Insert a drive into the carrier with the printed circuit board side facing down so 1.
that the mounting holes align with those in the carrier.
Secure the drive to the carrier with six screws, as shown in Figure 6-4.2.
Figure 6-4. Mounting a Hard Drive in a Carrier
!
Use caution when working around the hard drive backplane. Do not touch
the backplane with any metal objects and make sure no ribbon cables
touch the backplane or obstruct the holes, which aid in proper airfl ow.
Important: Regardless of how many hard drives are installed, all drive carriers must remain in the drive bays to maintain proper airfl ow.
!
6-6
A+ SERVER 1022G-URF User's Manual
Installing/Removing a Hard Drive
To remove a carrier, push the release button located beside the drive LEDs.1.
Swing the colored handle fully out and use it to pull the unit straight out (see 2.
Figure 6-5).
Note: Your operating system must have RAID support to enable the hot-plug capability of the hard drives.
Figure 6-5. Removing a Hard Drive from the Server
DVD-ROM Drive Installation
The top cover of the chassis must be opened to gain full access to the DVD-ROM
drive bay. The 1022G-URF accomodates only slim-line DVD-ROM drives. Side
mounting brackets are needed to mount a slim-line DVD-ROM drive in the 1022GURF server. You must power down the system before installing or removing a
DVD-ROM drive.
Removing the Chassis Cover
Grasp the two handles on either side and pull the unit straight out until it 1.
locks (you will hear a "click").
Chapter 6: Advanced Chassis Setup
6-7
Depress the two buttons on the top of the chassis to release the top cover 2.
and at the same time, push the cover away from you until it stops. You can
then lift the top cover from the chassis to gain full access to the inside of the
server.
Removing/Installing a Drive
With the chassis cover removed, unplug the power and data cables from the 1.
drive you want to remove.
Locate the locking tab at the rear of the drive. It will be on the left side of the 2.
drive when viewed from the front of the chassis.
Pull the tab away from the drive and push the drive unit out the front of the 3.
chassis.
Add a new drive by following this procedure in reverse order. You may hear a 4.
faint *click* of the locking tab when the drive is fully inserted.
Remember to reconnect the data and power cables to the drive before 5.
replacing the chassis cover and restoring power to the system.
6-5 Power Supply
The A+ SER VER 1022G-URF has a 700 watt redundant power supply confi guration
consisting of two hot-swap power modules. The power supply modules have an
auto-switching capability, which enables them to automatically sense and operate
with a 100V - 240V input voltage.
Power Supply Failure
If either of the two power supply modules fail, the other module will take the full
load and allow the system to continue operation without interruption. The Universal
Information LED on the control panel will blink slowly and remain so until the failed
module has been replaced. Replacement modules can be ordered directly from
Supermicro (see contact information in the Preface). The power supply modules
have a hot-swap capability, meaning you can replace the failed module without
powering down the system.
6-8
A+ SERVER 1022G-URF User's Manual
Replacing the Power Supply
You do not need to shut down the system to replace a power supply module. The
redundant feature will keep the system up and running while you replace the failed
hot-swap module. Replace with the same model, which can be ordered directly from
Supermicro (see Contact Information in the Preface).
First unplug the power cord from the failed power supply module.1.
To remove the failed power module, push the release tab (on the back of the 2.
power supply) to the side and then pull the module straight out (see Figure
6-6).
The power supply wiring was designed to detach automatically when the 3.
module is pulled from the chassis.
Replace the failed power module with another PWS-651-1R power supply 4.
module.
Simply push the new power supply module into the power bay until you hear 5.
a click.
Finish by plugging the AC power cord back into the module.6.
Figure 6-6. Removing/Replacing the Power Supply
Chapter 7: BIOS
7-1
Chapter 7
BIOS
7-1 Introduction
This chapter describes the AMI BIOS Setup Utility for the A+ SERVER 1022G-URF.
The AMI ROM BIOS is stored in a Flash EEPROM and can be easily updated.
This chapter describes the basic navigation of the AMI BIOS Setup Utility setup
screens.
Starting the Setup Utility
To enter the BIOS Setup Utility, hit the <Delete> key while the system is booting-up.
(In most cases, the <Delete> key is used to invoke the BIOS setup screen. There
are a few cases when other keys are used, such as <F1>, <F2>, etc.) Each main
BIOS menu option is described in this manual.
The Main BIOS screen has two main frames. The left frame displays all the options
that can be confi gured. “Grayed-out” options cannot be confi gured. The right frame
displays the key legend. Above the key legend is an area reserved for a text
message. When an option is selected in the left frame, it is highlighted in white. Often
a text message will accompany it. (Note that BIOS has default text messages built
in. We retain the option to include, omit, or change any of these text messages.)
Settings printed in Bold are the default values.
A " " indicates a submenu. Highlighting such an item and pressing the <Enter>
key will open the list of settings within that submenu.
The BIOS setup utility uses a key-based navigation system called hot keys. Most
of these hot keys (<F1>, <F10>, <Enter>, <ESC>, <Arrow> keys, etc.) can be used
at any time during the setup navigation process.
7-2 Main Menu
When you fi rst enter AMI BIOS Setup Utility, you will see the Main Menu screen.
You can always return to the Main Menu by selecting the Main tab on the top of
the screen with the arrow keys.
The Main Menu screen provides you with a system overview, which includes the
version, built date and ID of the AMIBIOS, the type, speed and number of the
processors in the system and the amount of memory installed in the system.
7-2
A+ SERVER 1022G-URF User's Manual
System Time/System Date
You can edit this fi eld to change the system time and date. Highlight System Time
or System Date using the <Arrow> keys. Enter new values through the keyboard.
Press the <Tab> key or the <Arrow> keys to move between fi elds. The date must
be entered in DAY/MM/DD/YYYY format. The time is entered in HH:MM:SS format.
Please note that time is in a 24-hour format. For example, 5:30 A.M. appears as
05:30:00 and 5:30 P.M. as 17:30:00.
7-3 Advanced Settings Menu
Boot Feature
Quick Boot
If Enabled, this option will skip certain tests during POST to reduce the time
needed for the system to boot up. The options are Enabled and Disabled.
Quiet Boot
If Disabled, normal POST messages will be displayed on boot-up. If Enabled,
this display the OEM logo instead of POST messages.
Add On ROM Display Mode
This option sets the display mode for Option ROM. The options are Force BIOS
or Keep Current.
Bootup Num Lock
This option selects the power-on state for the NUM lock to either On or Off.
PS/2 Mouse Support
Use this option to select support for the PS/2 mouse. Options are Disabled,
Enabled or Auto.
Wait for F1 if Error
This setting controls the system response when an error is detected during the
boot sequence. When enabled, BIOS will stop the boot sequence when an error
is detected, at which point you will need to press the F1 button to re-enter the
BIOS setup menu. The options are Enabled and Disabled.
Hit 'DEL' Message Display
Use this option to Enable or Disable the "Press DEL to run setup" message in
POST.
Chapter 7: BIOS
7-3
Watch Dog Function
Allows system to restart when system is inactive more than 5-minutes. The
options are Enabled and Disabled.
Power Button Function
This sets the function of the power button when you turn off the system. Options
include 4-second Overide and Instant Off.
Restore on AC Power Loss
This sets the action that occurs when an AC power loss occurs. Options include
Power Off, Power On and Last State.
Interrupt 19 Capture
Select Enabled to allow ROMs to trap Interrupt 19. The options are Enabled
and Disabled.
EUP Support
This setting allows you to enable or disable supplied standby power in S5. Set to
Enabled to for EUP requirements and set to Disabled for wakening capability.
Processor and Clock Options
CPU Confi guration
This displays static information on the Module Version, Physical Count and
Logical Count for the system's processor(s) and clock.
CPU Information
The information for the installed processor includes Revision, Cache L1/L2/L3,
Speed, NB CLK, Able to Change Frequency and uCode Patch Level.
GART Error Reporting
This option should remain disabled for normal operation. The driver developer
may enable this option for testing purposes. Options are Enabled or Disabled.
Microcode Update
This setting Enables or Disables microcode updating.
Secure Virtual Machine Mode
This setting is used to Enable or Disable SVM.
Power Now
This setting is used to Enable or Disable the AMD Power Now feature.
7-4
A+ SERVER 1022G-URF User's Manual
Power Cap
This option can decide the highest P-state in the OS. Options include P-state
0 through P-state 4.
ACPI SRAT Table
This option Enables or Disables the building of the ACPI SRAT Table.
CPU Down Core
This option sets down core support for the CPU. Options include Disabled, 2
Cores through 10 Cores in even numbered increments.
C1E Support
This option enables C1E support. Options include Enabled and Disabled.
Clock Speed Spectrum
This option enables or disables spread spectrum modulation.
Advanced Chipset Control
NorthBridge Confi guration
Memory Confi guration
Bank Interleaving
Select Auto to automatically enable a bank-interleaving memory scheme
when this function is supported by the processor. The options are Auto
and Disabled.
Node Interleaving
This option enables node memory interleaving. Options include Auto or
Disabled.
Channel Interleaving
This option enables channel memory interleaving. Options include Auto
or Disabled.
CS Sparing
This setting will reserve a spare memory rank in each node when enabled.
Options are Enabled and Disabled.
Chapter 7: BIOS
7-5
Bank Swizzle Mode
This setting Enables or Disables the bank swizzle mode.
ECC Confi guration
ECC Mode
This submenu affects the DRAM scrub rate based on its setting. Options
include Disabled, Basic, Good, Super, Max and User. Selecting User
activates the other options for user setting.
DRAM ECC Enable
This setting allows hardware to report and correct memory errors automatically, maintaining system integrity. Options are Enabled or Disabled. This is option is only active if ECC Mode above is set to User.
DRAM Timing Confi guration
DRAM Timing Confi g
This option allows you to set the DRAM timing confi guration for the system.
Options include Auto or Manual.
Memory Timing Parameters
This selects the which node's timing parameters to display. Options are CPU
Node 0 or CPU Node 1.
IOMMU
This setting is used to enable or disable or set the GART size in systems without
AGP. Options include Enabled and Disabled.
OHCI/EHCI HC Device Functions
These settings allow you to either Enable or Disable functions for OHCI or EHCI
bus devices.
USB 2.0 Controller Mode
Use this setting to confi gure the USB 2.0 Controller in either Hi-Speed (480
Mps) or Full Speed (12 Mps) mode. Options include Enabled (Hi-Speed Mode)
or Disabled (Full Speed Mode).
7-6
A+ SERVER 1022G-URF User's Manual
Legacy USB Support
Select "Enabled" to enable the support for USB Legacy. Disable Legacy support
if there are no USB devices installed in the system. "Auto" disabled Legacy
support if no USB devices are connected. The options are Disabled, Enabled
and Auto.
IDE Confi guration
Onboard PCI IDE Controller
This setting allows you to Enable or Disable the PCI IDE controller.
On Chip SATA Channel
This setting allows you to Enable or Disable the OnChip SATA channel.
On Chip SATA Type
Use this setting to set the On Chip SATA type. Options include
Native IDE, RAID, AMD-AHCI and Legacy IDE.
SATA IDE Combined Mode
This setting allows you to Enable or Disable the SATA IDE combined mode.
PATA Channel Confi guration
This allows you to set PATA channel confi guration. Options include S ATA as
Primary or SATA as secondary.
Primary/Secondary/Third/Fourth IDE Master/Slave
LBA/Large Mode
LBA (Logical Block Addressing) is a method of addressing data on a disk
drive. The options are Disabled and Auto.
Block (Multi-Sector Transfer)
Block mode boosts IDE drive performance by increasing the amount of data
transferred. Only 512 bytes of data can be transferred per interrupt if block
mode is not used. Block mode allows transfers of up to 64 KB per interrupt.
Select "Disabled" to allow the data to be transferred from and to the device
one sector at a time. Select "Auto" to allows the data transfer from and to the
device occur multiple sectors at a time if the device supports it. The options
are Auto and Disabled.
Chapter 7: BIOS
7-7
PIO Mode
PIO (Programmable I/O) mode programs timing cycles between the IDE drive
and the programmable IDE controller. As the PIO mode increases, the cycle
time decreases.
The options are Auto, 0, 1, 2, 3, and 4. Select Auto to allow BIOS to auto
detect the PIO mode. Use this value if the IDE disk drive support cannot be
determined. Select 0 to allow BIOS to use PIO mode 0, which has a data
transfer rate of 3.3 MBs. Select 1 to allow BIOS to use PIO mode 1, which
has a data transfer rate of 5.2 MBs. Select 2 to allow BIOS to use PIO mode
2, which has a data transfer rate of 8.3 MBs. Select 3 to allow BIOS to use
PIO mode 3, which has a data transfer rate of 11.1 MBs. Select 4 to allow
BIOS to use PIO mode 4, which has a data transfer rate of 16.6 MBs. This
setting generally works with all hard disk drives manufactured after 1999.
For other disk drives, such as IDE CD-ROM drives, check the specifi cations
of the drive.
DMA Mode
Selects the DMA Mode. Options are Auto, SWDMA0, SWDMA1, SWDMA2,
MWDMA0. MDWDMA1, MWDMA2, UDMA0. UDMA1, UDMA2, UDMA3,
UDMA4 and UDMA5. (SWDMA=Single Word DMA, MWDMA=Multi Word
DMA, UDMA=UltraDMA.)
S.M.A.R.T.
Self-Monitoring Analysis and Reporting Technology (SMART) can help predict
impending drive failures. Select "Auto" to allow BIOS to auto detect hard
disk drive support. Select "Disabled" to prevent AMI BIOS from using the
S.M.A.R.T. Select "Enabled" to allow AMI BIOS to use the S.M.A.R.T. to support hard drive disk. The options are Disabled, Enabled, and Auto.
32-Bit Data Transfer
Select "Enabled" to activate the function of 32-Bit data transfer. Select "Disabled" to deactivate the function. The options are Enabled and Disabled.
IDE Detect Timeout (Sec)
Use the +/- keys to adjust and select the time out for detecting ATA/ATAPI
devices. The default value is 35.
7-8
A+ SERVER 1022G-URF User's Manual
PCI/PnP Confi guration
Clear NVRAM
Select Yes to clear NVRAM during boot-up. The options are Yes and No.
Plug & Play O/S
Select Yes to allow the OS to confi gure Plug & Play devices. (This is not required
for system boot if your system has an OS that supports Plug & Play.) Select No
to allow AMIBIOS to confi gure all devices in the system.
PCI Latency Timer
This option sets the latency of all PCI devices on the PCI bus. Select a value
to set the PCI latency in PCI clock cycles. Options are 32, 64, 96, 128, 160,
192, 224 and 248.
ROM Scan Ordering
This setting determines which kind of option ROM activates prior to another.
Options include Onboard First and Addon First.
SXB1 Slot/SXB2 Slot
These settings Enable or Disable the specifi ed PCI slot in your system.
Onboard LAN Option ROM Select
This setting allows you to select the onboard LAN option ROM for iSCSI or
PXE.
Load Onboard LAN 1 Option ROM
This option allows you to Enable or Disable the onboard LAN 1 option ROM.
Load Onboard LAN 2 Option ROM
This option allows you to Enable or Disable the onboard LAN 2 option ROM.
Primary Video Controller
This option specifi es the primary video controller for Onboard VGA or Other.
Chapter 7: BIOS
7-9
SuperIO Device Confi guration
Serial 1 Address
This option specifi es the base I/O port address and Interrupt Request address
of serial port 1. Select "Disabled" to prevent the serial port from accessing any
system resources. When this option is set to Disabled, the serial port physically
becomes unavailable. Select "3F8/IRQ4" to allow the serial port to use 3F8 as its
I/O port address and IRQ 4 for the interrupt address. Options include Disabled,
3F8/IRQ4, 3E8/IRQ4 and 2E8/IRQ3
Serial 2 Address
This option specifi es the base I/O port address and Interrupt Request address
of serial port 2. Select "Disabled" to prevent the serial port from accessing any
system resources. When this option is set to "Disabled", the serial port physically
becomes unavailable. Select "2F8/IRQ3" to allow the serial port to use 2F8 as its
I/O port address and IRQ 3 for the interrupt address. Options include Disabled,
2F8/IRQ3, 3E8/IRQ4 and 2F8/IRQ3.
Serial Port 2 Attribute
This option allows you to set COM2 as a normal serial port or as virtual COM
for SOL. Options are SOL or COM.
Remote Access Confi guration
Remote Access
Use this option to Enable or Disable Remote Access in your system. If enabled,
the settings below will appear.
Serial Port Number
Use this setting to select the serial port for console redirection. Options include
COM1, COM2*. The displayed base address and IRQ for the serial port changes
to refl ect the selection you make.
Note: Make sure the selected port is enabled.
Serial Port Mode
Selects the serial port settings to use. Options are (115200 8, n, 1), (57600 8,
n, 1), (38400 8, n, 1), (19200 8, n, 1) and (09600 8, n, 1).
Flow Control
Selects the fl ow control to be used for console redirection. Options are None,
Hardware and Software.
7-10
A+ SERVER 1022G-URF User's Manual
Redirection After BIOS POST
Options are Disable (no redirection after BIOS POST), Boot Loader (redirection
during POST and during boot loader) and Always (redirection always active).
Note that some OS's may not work with this set to Always.
Terminal Type
Selects the type of the target terminal. Options are ANSI, VT100 and VTUTF8.
VT-UTF8 Combo Key Support
Allows you to Enable or Disable VT-UTF8 combination key support for ANSI/
VT100 terminals.
Sredir Memory Display Delay
Use this setting to set the delay in seconds to display memory information.
Options are No Delay, 1 sec, 2 secs and 4 secs.
Hardware Health Confi guration
CPU Overheat Alarm
This setting allows you to specify the type of alarm for CPU overheating. Options
include The Early Alarm and The Default Alarm.
Fan Speed Control
This feature allows the user to determine how the system will control the speed
of the onboard fans. The options are Full Speed/FS (Max Cooling), Performance/
PF (Better Cooling), Balanced/BL (Balance between performance and energy
saving), Energy Saving/ES (Lower Power and Noise).
Other items in the submenu are systems monitor displays for the following
information:
CPU T emperature, CPU1 Temperature, CPU2 T emperature, NB Temperature,
VRD1 Temperature, VRD2 Temperature, System Temperature, Air Temperature, Fan 1-8 Reading, CPU1 VCore, CPU2 VCore, CPU1 Mem VTT, CPU2
Mem VTT, CPU1 Mem, CPU2 Mem, 1.1V, 1.8V, 5V +12V, -12V, 3.3 Vcc, 3.3
VSB, VBAT and HT Voltage.
Chapter 7: BIOS
7-11
ACPI Confi guration
PS2 KB/MS Wakeup
This setting allows you to Enable or Disable PS2 keyboard and mouse
wakeup.
ACPI Aware O/S
This setting Enables or Disables ACPI support for the system's operating system.
Options include Yes (enabled) or No (disabled).
ACPI APIC Support
Determines whether to include the ACPI APIC table pointer in the RSDT pointer
list. The available options are Enabled and Disabled.
Headless Mode
Use this setting to Enable or Disable headless operation mode through ACPI.
ACPI Version Features
Use this setting the determine which ACPI version to use. Options are ACPI
v1.0, ACPI v2.0 and ACPI v3.0.
IPMI Confi guration
This menu shows static information about the IPMI fi rmware revision and status of
the BMC, as well as options for IPMI confi guration.
View BMC System Event Log
Pressing the Enter key will open the following settings. Use the "+" and "-" keys
to navigate through the system event log.
Clear BMC System Event Log
Selecting this and pressing the Enter key will clear the BMC system event log.
Set LAN Confi guration
Use the "+" and "-" keys to choose the desired channel number. This displays
Channel Number and Channel Number Status information.
This menu contains options for inputing settings for the SET LAN Confi guration
Command. See IPMI 1.5 Specifi cation, table 11.1 for details. Use the "+" and
"-" keys to choose the desired channel number.
Note: Each question in this group may take a considerable amount of time.
7-12
A+ SERVER 1022G-URF User's Manual
IP Address Source
Select the source of this machine's IP address. If Static is selected, you will
need to know and enter manually the IP address of this machine below. If
DHCP is selected, the BIOS will search for a DHCP (Dynamic Host Confi gu-
ration Protocol) server in the network it is attached to, and request the next
available IP address. The options are DHCP and Static.
The following items are assigned IP addresses automatically if DHCP is
selected under IP Address Source above:
IP Address
This submenu sets the IP address source as either Static or DHCP. Selecting
Static allows you to manually set the IP Address, Subnet Mask and Gateway
Address.
In the fi eld provided here enter the IP address in the decimal form of xxx.xxx.
xxx.xxx with xxx having a value of less than 256 and in decimal form only The
IP address and current IP address in the BMC are shown.
Subnet Mask
In the fi eld provided here enter the Subnet address in the decimal form of
xxx.xxx.xxx.xxx with xxx having a value of less than 256 and in decimal form
only. The current subnet address in the BMC is shown.
Gateway Address
In the fi eld provided here enter the Gateway address in the decimal form of
xxx.xxx.xxx.xxx with xxx having a value of less than 256 and in decimal form
only. The current Gateway address in the BMC is shown.
MAC Address
In the fi eld provided here enter the MAC address in the hex form of xx.xx.
xx.xx.xx.xx with xx in hex form only. The current MAC address in the BMC
is shown.
BMC Watch Dog Timer Action
This setting is used to set the Watch Dog function, which allows the BMC to reset
or powerdown the system if the OS crashes or hangs. Options include Disabled,
Reset System, Power Down and Power Cycle.
Chapter 7: BIOS
7-13
Event Log Confi guration
View Event Log
Pressing the Enter key will open the event log. Use the "" and "" keys to
navigate through the system event log.
Mark All Events as Read
Selecting this and pressing the Enter key marks all events as read in the event
log.
Clear Event Log
Selecting this and pressing the Enter key clears the system event log.
SR56x0 (RD890S) PCIE Error Log
This setting allows you set an error log ofr PCIE errors. Options include Yes
or No.
7-4 Security Menu
AMI BIOS provides a Supervisor and a User password. If you use both passwords,
the Supervisor password must be set fi rst.
Change Supervisor Password
Select this option and press <Enter> to access the sub menu, and then type in
the password.
Change User Password
Select this option and press <Enter> to access the sub menu, and then type in
the password.
Boot Sector Virus Protection
This option is near the bottom of the Security Setup screen. Select "Disabled" to
deactivate the Boot Sector Virus Protection. Select "Enabled" to enable boot sector
protection. When "Enabled", AMI BIOS displays a warning when any program (or
virus) issues a Disk Format command or attempts to write to the boot sector of the
hard disk drive. The options are Enabled and Disabled.
7-14
A+ SERVER 1022G-URF User's Manual
7-5 Boot Menu
Boot Device Priority
This feature allows you to prioritize the boot sequence from the list of available
devices. A device that is in parenthesis has been disabled in the corresponding
type menu.
Hard Disk Drives
This feature allows you to specify the boot sequence from the list of available hard
disk drives. A device that is in parenthesis has been disabled in the corresponding
type menu.
CD/DVD Drives
This feature allows you to specify the boot sequence from the list of available CD/
DVD drives. A device that is in parenthesis has been disabled in the corresponding
type menu.
Retry Boot Devices
This option allows you to retry boot devices. Options include Enabled and
Disabled.
7-6 Exit Menu
Select the Exit tab from AMI BIOS Setup Utility screen to enter the Exit BIOS Setup
screen.
Save Changes and Exit
When you have completed the system confi guration changes, select this option
to leave BIOS Setup and reboot the computer, so the new system confi guration
parameters can take effect. Select Save Changes and Exit from the Exit menu and
press <Enter>.
Discard Changes and Exit
Select this option to quit BIOS Setup without making any permanent changes to the
system confi guration and reboot the computer. Select Discard Changes and Exit
from the Exit menu and press <Enter>.
Discard Changes
Select this option and press <Enter> to discard all the changes and return to AMI
BIOS Utility Program.
Chapter 7: BIOS
7-15
Load Optimal Defaults
To set this feature, select Load Optimal Defaults from the Exit menu and press
<Enter>. Then Select "OK" to allow BIOS to automatically load the Optimal Defaults
as the BIOS Settings. The Optimal settings are designed for maximum system
performance, but may not work best for all computer applications.
Load Fail-Safe Defaults
To set this feature, select Load Fail-Safe Defaults from the Exit menu and press
<Enter>. The Fail-Safe settings are designed for maximum system stability, but not
maximum performance.
7-16
A+ SERVER 1022G-URF User's Manual
Notes
A-1
Appendix A: BIOS Error Beep Codes
Appendix A
BIOS Error Beep Codes
During the POST (Power-On Self-Test) routines, which are performed each time
the system is powered on, errors may occur.
Non-fatal errors are those which, in most cases, allow the system to continue the
boot-up process. The error messages normally appear on the screen.
Fatal errors are those which will not allow the system to continue the boot-up
procedure. If a fatal error occurs, you should consult with your system manufacturer
for possible repairs.
These fatal errors are usually communicated through a series of audible beeps. The
numbers on the fatal error list (on the following page) correspond to the number
of beeps for the corresponding error. All errors listed, with the exception of Beep
Code 8, are fatal errors.
A-1 AMIBIOS Error Beep Codes
Beep Code Error Message Description
1 beep Refresh Circuits have been reset (Ready to power up)
5 short, 1 long Memory error No memory detected in system
1 long, 8 short Video error Video adapter disabled or missing
A-2
A+ SERVER 1022G-URF User's Manual
Notes
Appendix B: Installing Windows
B-1
Appendix B
Installing Windows
After all hardware components have been installed, you must fi rst confi gure Intel
South Bridge RAID Settings before you install the Windows OS and other software
drivers. T o confi gure RAID settings, please refer to RAID Confi guration User Guides
posted on our web site at www.supermicro.com/support/manuals.
Note: The following OS installation instructions are written for the Windows XP/2003
OS only. If you have the Windows 2008 or Windows Vista OS, please follow the
instructions displayed on your screen to install the OS.
B-1 Installing the Windows OS for a RAID System
Insert Microsoft's Windows XP/Windows 2003 Setup CD in the CD-ROM drive 1.
and the system will start booting up from CD.
Press the <F6> key when the message "Press F6 if you need to install a third 2.
party SCSI or RAID driver" displays.
When the Windows XP/Windows 2003 Setup screen appears, press "S" to 3.
specify additional device(s).
Insert the driver diskette you created in Section 5-11, 4. Building a Driver
Diskette, into Drive A: and press the <Enter> key.
Highlight "Manufuacturer Supplied Hardware Support Disk" and hit the 5.
<Enter> key.
Highlight the fi rst "Adaptec RAID" driver shown and press the <Enter> key to 6.
install it. Soon a similar blue screen will appear again.
Again hit the <S> key, then highlight the second item, "nForce Storage 7.
Controller" and press the <Enter> key, then <Enter> again to continue with
the Windows setup.
Press the <Enter> key to continue the installation process. (If you need to 8.
specify any additional devices to be installed, do it at this time.) Once all
devices are specifi ed, press the <Enter> key to continue with the installation.
B-2
A+ SERVER 1022G-URF User's Manual
From the Windows XP/Windows 2003 Setup screen, press the <Enter> key. 9.
The XP/2003 Setup will automatically load all device fi les and then, continue
the Windows XP/Windows 2003 installation.
After the Windows XP/Windows 2003 OS Installation has completed, the 10.
system will automatically reboot.
B-2 Installing the Windows OS for a Non-RAID System
Insert Microsoft's Windows XP/Windows 2003/Windows 2008/Windows Vista 11.
Setup CD in the CD drive, and the system will start booting up from CD.
Continue with the OS installation. The Windows OS Setup screen will display.12.
From the Windows OS Setup screen, press the <Enter> key. The Windows 13.
OS Setup will automatically load all device fi les and then continue with the
OS installation.
After the Windows OS Installation is complete, the system will automatically 14.
reboot.
Insert the Supermicro Setup CD that came with your serverboard into the CD 15.
drive during system boot, and the main screen will display.
C-1
Appendix C: System Specifi cations
Appendix C
System Specifi cations
Processors
Dual AMD Opteron 6100 series (Socket G34 type) processors
Note: You must install at least two processors for full functions to be supported.
Note: Please refer to our web site for a complete listing of supported processors.
Chipset
One AMD SR5670 chipset and one SP5100 Southbridge chipset
BIOS
16 Mb AMIBIOS® SPI Flash ROM
Memory Capacity
Sixteen single/dual/tri/quad channel DIMM slots supporting up to 256GB
of DDR3-1333/1066/800MHz registered ECC SDRAM or 64 GB of DDR31333/1066/800 MHz unbuffered ECC/non-ECC SDRAM
Note: See the memory section in Chapter 5 for details.
SATA Controller
AMD SP5100 on-chip controller for six-port Serial ATA (RAID 0, 1 and 10
supported)
Drive Bays
Four (4) hot-swap drive bays to house four (4) SAS/SATA drives
Peripheral Drive Bays
One (1) slim DVD-ROM drive
Expansion Slots
One UIO card and one PCI Express x16 slot
C-2
A+ SERVER 1022G-URF User's Manual
Serverboard
H8DGU-F (Proprietary form factor)
Dimensions: 12.28" x 13.05" (312 x 331 mm)
Chassis
SC815TQ-R700UBP
Form Factor: 1U rackmount
Dimensions: (WxHxD) 17 x 1.7 x 25.6 in. (432 x 43 x 650 mm)
Weight
Gross (Bare Bone): 43 lbs. (19.5 kg.)
System Cooling
Four (4) 4-cm heavy-duty counter-rotating fans
System Input Requirements
AC Input Voltage: 100-240 VAC
Rated Input Current: 8A (115V) to 4A (230V)
Rated Input Frequency: 50-60 Hz
Power Supply
Rated Output Power: 700W (Model# PWS-651-1R)
Rated Output Voltages: +5V (25A), +3.3V (12A), +12V (54A), +5Vsb (3A)
Operating Environment
Operating Temperature: 10º to 35º C (50º to 95º F)
Non-operating Temperature: -40º to 70º C (-40º to 158º F)
Operating Relative Humidity: 8% to 90% (non-condensing)
Non-operating Relative Humidity: 5 to 95% (non-condensing)
C-3
Appendix C: System Specifi cations
Regulatory Compliance
Electromagnetic Emissions: FCC Class A, EN 55022 Class A, EN 61000-3-2/3-3, CISPR 22 Class A
Electromagnetic Immunity: EN 55024/CISPR 24, (EN 61000-4-2, EN 61000-4-3,
EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11)
Safety: CSA/EN/IEC/UL 60950-1 Compliant, UL or CSA Listed (USA and
Canada), CE Marking (Europe)
California Best Management Practices Regulations for Perchlorate Materials:
This Perchlorate warning applies only to products containing CR (Manganese
Dioxide) Lithium coin cells. “Perchlorate Material-special handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate”
C-4
A+ SERVER 1022G-URF User's Manual
(continued from front)
The products sold by Supermicro are not intended for and will not be used in life support systems,
medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency
communication devices or other critical systems whose failure to perform be reasonably expected
to result in signifi cant injury or loss of life or catastrophic property damage. Accordingly, Supermicro
disclaims any and all liability, and should buyer use or sell such products for use in such ultrahazardous applications, it does so entirely at its own risk. Furthermore, buyer agrees to fully
indemnify, defend and hold Supermicro harmless for and against any and all claims, demands,
actions, litigation, and proceedings of any kind arising out of or related to such ultra-hazardous
use or sale.
