Supermicro X7DCX User Manual

SUPER

X7DCX

®

USER’S MANUAL

Revision 1.0

The information in this User’s Manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
makes no commitment to update or to keep current the information in this manual, or to notify any
person or organization of the updates. Please Note: For the most up-to-date version of this

manual, please see our web site at www.supermicro.com.

Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product
described in this manual at any time and without notice. This product, including software, if any,
and documentation may not, in whole or in part, be copied, photocopied, reproduced, translated or
reduced to any medium or machine without prior written consent.

IN NO EVENT WILL Super Micro Computer, Inc. BE LIABLE FOR DIRECT, INDIRECT, SPECIAL,
INCIDENTAL, SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE
OR INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER MICRO COMPUTER, INC. SHALL
NOT HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED OR USED
WITH THE PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING,
INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between manufacturer and customer shall be governed by the laws of Santa
Clara County in the State of California, USA. The State of California, County of Santa Clara shall
be the exclusive venue for the resolution of any such disputes. Super Micro's total liability for all
claims will not exceed the price paid for the hardware product.

FCC Statement: This equipment has been tested and found to comply with the limits for a Class B
digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
manufacturer’s instruction manual, may cause interference with radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, you are encouraged to try to correct the interference by one or more of
the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
Consult the dealer or an experienced radio/television technician for help.

California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate
warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate
Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”.

WARNING: Handling of lead solder materials used in this
product may expose you to lead, a chemical known to
the State of California to cause birth defects and other
reproductive harm.

Manual Revision 1.0
Release Date: November 23, 2008
Unless you request and receive written permission from Super Micro Computer, Inc., you may not

copy any part of this document.
Information in this document is subject to change without notice. Other products and companies

referred to herein are trademarks or registered trademarks of their respective companies or mark
holders.

Copyright © 2008 by Super Micro Computer, Inc.
All rights reserved.

Printed in the United States of America

Preface

This manual is written for system integrators, PC technicians and
knowledgeable PC users. It provides information for the installation and use of the

X7DCX motherboard.

About This Motherboard

The X7DCX supports dual Intel Xeon Quad-Core/Dual-Core
5400/5300/5200/5100 Sequence processors with a front side bus speed of up to
1333 MHz. With mul ti- co re processors, cos t-ef fec tive Inte l 5100 chipset and l ow­power nat ive DDR 2 memor y built in, the X 7DCX deliver s superb p roces sing ca ­pacity without sacrifi cing affordability. This motherboard offers powerful business
capabilities with optimal power effi ciency, ideal for complex application computing
in a multi - user e nviro nment . Please refer to the motherboard specifi cations pages
on our web site (http://www.supermicro.com/products/motherboard/) for updates.
This product is intended to be professionally installed.

Preface

Manual Organization

Chapter 1 introduces the motherboard, providing information on the layout, con-

nectors/jumpers, features, specifi cations and the chipset.
Chapter 2 provides hardware installation instructions. Read this chapter when

installing the processor, memory modules and other hardware components into
the system.

Chapter 3 includes an introduction to the BIOS and provides detailed information
on running the CMOS Setup utility.

If you encounter any problems, see Chapter 4, which describes troubleshooting
procedures for the video, the memory and the system setup stored in the CMOS.

Appendix A lists BIOS POST Error Codes. Appendix B and Appendix C provide
the Windows OS and Other Software Programs Installation Instructions.

Conventions Used in the Manual

Special attention should be given to the following symbols for proper installation and
to prevent damage done to the components or injury to yourself.

Warning: Important information given to ensure proper system installation
or to prevent damage to the components.

iii

X7DCX User's Manual

Note: Additional Information given to differentiate various models or to
ensure correct system setup.

iv

Contacting Supermicro

Contacting Supermicro

Headquarters

Address: Super Micro Computer, Inc.

980 Rock Ave.

San Jose, CA 95131 U.S.A.
Tel: [phone]
Fax: [phone]
Email: [e-mail] (General Information)

[e-mail] (Technical Support)
Web Site: www.supermicro.com

Europe

Address: Super Micro Computer B.V.

Het Sterrenbeeld 28, 5215 ML

's-Hertogenbosch, The Netherlands
Tel: [phone]
Fax: [phone]
Email: [e-mail] (General Information)

[e-mail] (Technical Support)

[e-mail] (Customer Support)

Asia-Pacifi c

Address: Super Micro Computer, Inc.

4F, No. 232-1, Liancheng Rd.

Chung-Ho 235, Taipei County

Taiwan, R.O.C.
Tel: [phone]
Fax: [phone]
Web Site: www.supermicro.com.tw
Technical Support:
Email: [e-mail]

Tel: [phone], ext.132 or 139

v

X7DCX User's Manual

Table of Contents

Preface ...........................................................................................................3

Chapter 1 Introduction ............................................................................. 1-1

1-1 Overview .........................................................................................................1-1

Checklist ..........................................................................................................1-1

X7DCX Quick Reference ................................................................................1-4

X7DCX Jumpers ............................................................................................1-4

X7DCX Connectors/Headers ..........................................................................1-5

Motherboard Features .....................................................................................1-6

1-2 Chipset and Processor Features Overview ....................................................1-9

The 5100 Memory Controller Hub (MCH) .......................................................1-9

The Ninth Generation I/O Controller Hub (ICH9R) ......................................... 1-9

1-3 Special Features ...........................................................................................1-10

1-4 PC Health Monitoring .................................................................................... 1-10

1-5 ACPI Features ................................................................................................1-11

Slow Blinking LED for Suspend-State Indicator ............................................1-11

Main Switch Override Mechanism ................................................................ 1-12

External Modem Ring-On ............................................................................. 1-12

1-6 Power Supply ................................................................................................1-12

1-7 Super I/O ....................................................................................................... 1-13

Chapter 2 Installation ................................................................................ 2-1

2-1 Static-Sensitive Devices .................................................................................. 2-1

Precautions .....................................................................................................2-1

Unpacking .......................................................................................................2-1

2-2 Mounting the Motherboard in the Chassis ...................................................... 2-2

Installation Procedures ....................................................................................2-2

2-3 Installing a Processor and Heatsink Fans ...................................................... 2-4

Installing the LGA771 Processor .................................................................... 2-4

Loading the Processor into the Socket ...........................................................2-5

Installing the Heatsink ..................................................................................... 2-6

Uninstalling the Heatsink ................................................................................2-6

2-4 Installing DIMMs ..............................................................................................2-8

DIMM Installation ............................................................................................2-8

Memory Support ..............................................................................................2-8

Possible System Memory Allocation & Availability ..................................... 2-9

2-5 Control Panel Connectors/IO Ports...............................................................2-10

Back Panel Connectors/IO Ports .................................................................. 2-10

vi

Table of Contents

Front Control Panel ........................................................................................2-11

Front Control Panel Pin Defi nitions............................................................... 2-12

NMI Button ............................................................................................... 2-12

Power LED ...............................................................................................2-12

HDD LED ..................................................................................................2-13

NIC1/NIC2 LED Indicators ....................................................................... 2-13

Overheat/Fan Fail LED (OH)....................................................................2-14

Power Fail LED ........................................................................................ 2-14

Reset Button .............................................................................................2-15

Power Button ............................................................................................ 2-15

2-6 Connecting to the Headers and Connectors ................................................ 2-16

Power Connectors .........................................................................................2-16

ATX Power Connector .............................................................................. 2-16

Processor Power Connector .................................................................... 2-16

Fan Headers ................................................................................................. 2-17

Fan Headers .............................................................................................2-17

I/O Connections ............................................................................................2-18

ATX PS/2 Keyboard and PS/2 Mouse Ports ............................................2-18

Serial Ports ............................................................................................... 2-18

Universal Serial Bus (USB) ...................................................................... 2-19

GLAN 1/2 (Giga-bit Ethernet Ports) ......................................................... 2-19

VGA Connector ........................................................................................ 2-20

Serial ATA Ports........................................................................................ 2-20

T-SGPIO Headers .................................................................................... 2-21

Onboard Headers ..........................................................................................2-22

Wake-On-Ring ..........................................................................................2-22

Wake-On-LAN ..........................................................................................2-22

Power LED/Speaker ................................................................................. 2-23

Chassis Intrusion ...................................................................................... 2-23

SMB ..........................................................................................................2-24

Power I

2

C Connector ................................................................................2-24

2-7 Jumper Settings ............................................................................................ 2-25

Explanation of Jumpers ................................................................................ 2-25

GLAN Enable/Disable ..............................................................................2-25

CMOS Clear ............................................................................................. 2-26

Watch Dog Enable/Disable ...................................................................... 2-26

VGA Enable/Disable .................................................................................2-27

2

I

C Bus to PCI Slots ................................................................................. 2-27

2-8 Onboard Indicators ........................................................................................ 2-28

vii

X7DCX User's Manual

GLAN LEDs .............................................................................................. 2-28

Onboard Power LED ................................................................................ 2-28

2-9 Floppy, SIMSO IPMI and HDD Connections ................................................ 2-29

Floppy Connector ..................................................................................... 2-29

IDE Connector .......................................................................................... 2-30

SIMSO IPMI Slot ..................................................................................... 2-30

Chapter 3 Troubleshooting ......................................................................3-1

3-1 Troubleshooting Procedures ........................................................................... 3-1

Before Power On ........................................................................................... 3-1

No Power ........................................................................................................ 3-1

No Video ......................................................................................................... 3-2

Losing the System’s Setup Confi guration .......................................................3-2

3-2 Technical Support Procedures ........................................................................ 3-2

3-3 Frequently Asked Questions ...........................................................................3-3

3-4 Returning Merchandise for Service.................................................................3-4

Chapter 4 BIOS ..........................................................................................4-1

4-1 Introduction ......................................................................................................4-1

System BIOS ...................................................................................................4-1

How To Change the Confi guration Data ......................................................... 4-1

Starting the Setup Utility ................................................................................. 4-1

4-2 Running Setup ................................................................................................ 4-2

4-3 Main BIOS Setup ............................................................................................ 4-2

4-4 Advanced Setup .............................................................................................. 4-7

4-5 Security .........................................................................................................4-23

4-6 Boot ...............................................................................................................4-24

4-7 Exit ................................................................................................................4-25

Appendix A BIOS POST Error Codes .....................................................A-1

A-1 Recoverable POST Errors ..............................................................................A-1

Appendix B Installing the Windows OS .................................................B-1

B-1 Installing the Windows XP/2003 OS for systems with RAID Functions .........B-1

B-2 Installing the Windows OS to Systems without RAID Functions .................... B-2

Appendix C Installing Other Software Programs and Drivers ............ C-1

C-1 Installing Other Drivers ...................................................................................C-1

C-2 Confi guring Supero Doctor II .......................................................................... C-2

viii

Chapter 1: Introduction

Chapter 1

Introduction

1-1 Overview

Checklist

Congratulations on purchasing your computer motherboard from an acknowledged
leader in the industry. Supermicro boards are designed with the utmost attention to
detail to provide you with the highest standards in quality and performance. Check
that the following items have all been included with your motherboard. If anything
listed here is damaged or missing, contact your retailer.

All the following items are included in the retail box.

One (1) Super mic ro Main board

•

One (1) fl oppy cable (CBL-0 022L)•

One (1) IDE c able (CB L-036 L-03)•

Six (6) SATA cables (CBL-0044L)•

One (1) I/O Bac kpla ne (CSE- PT07L))•

One (1) Super micr o CD co ntaini ng drive rs and ut iliti es•

One (1) User 's/ BIOS M anual ( MNL-1029)•

1-1

X7DCX User's Manual

X7DCX Image

Note: The drawings and pictures shown in this manual were based on the

latest PCB Revision available at the time of publishing of the manual. The
motherboard you’ve received may or may not look exactly the same as the
graphics shown in the manual.

1-2

X7DCX Motherboard Layout

Chapter 1: Introduction

USB0/1

COM1

VGA

LAN1

LAN2

LAN

CTRL

JPL2

S I/O

X7DCX

COM2

KB/MS

JWOR

Fan6

JPL1

LAN

CTRL

JPG1

JI2C2

Fan5

Slot7 PCI-Ex4(inx8 slot)

Slot6 PCI-Ex8

Slot5 PCI-Ex8(in x16slot)

Slot4 PCI-Ex8

Slo3 PCI-Ex8

Slo2 PCI-Ex8

Slot1 PCI 33MHz

JI2C1

CH1_DIMM0

CH0_DIMM0

CH1_DIMM1

CH0_DIMM1

CH1_DIMM2

CH0_DIMM2

JWOL

JPW3

SMBus1

JSMB1

JPW2

DIMM1B

DIMM1A

DIMM2B

DIMM2A

DIMM3B

DIMM3A

Intel

North Bridge

PLX
PCI-Exp.
Switch

USB6

JUSB4

Fan7

CPU1 Fan

BIOS

JBT1

IDE
CTRL

USB7

JUSB5

PWR I2C

South Bridge

JUSB3

Intel

USB4/5

JUSB2

USB2/3

CPU1

CPU2

T-SGPIO1

T-SGPIO2

I-SATA5

VGA
CTRL

I-SATA4

JPW1

Fan1

JF1

Fan2

JD1

DP1

SP1

Fan3

Fan8

CPU2 Fan

JBAT1

JWD1

SIMSO

I-SATA0

I-SATA2

I-SATA1

I-SATA3

JL1

Fan4

Floppy

IDE

Notes:

Jumpers not indicated are for test purposes only.

•

See Chapter 2 for detailed information on jumpers, I/O ports and JF1 front panel •
connections.

" " indicates the location of Pin 1.

•

1-3

X7DCX User's Manual

X7DCX Quick Reference

10
11

12

13

14

15

565758

Fan5

1
2

3

COM1

4

VGA

Fan6

KB/MS

USB0/1

JPW3

CH1_DIMM0

CH0_DIMM0

CH1_DIMM1

CH0_DIMM1

CH1_DIMM2

CH0_DIMM2

JPW2

DIMM1B

DIMM1A

DIMM2B

DIMM2A

DIMM3B

DIMM3A

5455

Fan7

CPU1 Fan

53

PWR I2C

CPU1

5
6

7

8

9

LAN

CTRL

JPL2

S I/O

LAN1

LAN2

JPL1

LAN

CTRL

Slot7 PCI-Ex4(inx8 slot)

Slot6 PCI-Ex8

Slot5 PCI-Ex8(in x16slot)

Slot4 PCI-Ex8

Slo3 PCI-Ex8

X7DCX

Slo2 PCI-Ex8

COM2

16

Slot1 PCI 33MHz

JWOL

JPG1

JWOR

JI2C1

JI2C2

1718192021 22

SMBus1

JSMB1

Intel

North Bridge

PLX
PCI-Exp.
Switch

BIOS

JBT1

IDE
CTRL

USB6

USB7

JUSB5

JUSB4

232425

Intel

South Bridge

USB2/3

USB4/5

JUSB3

JUSB2

26 27 28

CPU2

T-SGPIO1

T-SGPIO2

VGA
CTRL

I-SATA4

I-SATA5

293031

I-SATA3

52

JPW1

JBAT1

I-SATA0

I-SATA2

I-SATA1

JL1

32333435

SIMSO

Fan4

36

Fan1

JF1

Fan2

DP1

SP1

Fan3

Fan8

CPU2 Fan

JWD1

IDE

Floppy

JD1

51

50

49

48
47

46

45
44

43
42

41
40

39
38

37

X7DCX Jumpers

Jumper Label Description Default Setting

JBT1 26 CMOS Clear (See Chapter 2)

2

JI

C1/JI2C2 19/20 SMB to PCI slots Connect Enable Off (Disabled)
JPL1/JPL2 5/11 LAN1/2 Enable/Disable Pins 1-2 (Enabled)
JPG1 18 VGA Enable/Disable Pins 1-2 (Enabled)
JWD1 40 Watch Dog Pins 1-2 (Reset)

1-4

Chapter 1: Introduction

X7DCX Connectors/Headers

Connector Label Description

BIOS Chip 24 Phoenix BIOS SPI Chip
COM1/COM2 3/16 COM1/COM2 Serial Port/Header

Fan1: 51, Fan2: 49,

Fans 1~6

Fan5: 57, Fan6: 58

Fans 7~8 Fan7: 54, Fan8: 44 CPU Fans
Floppy 38 Floppy Drive Connector

IDE 37 IDE Connector
I-SATA0 ~5 34/33/32/31/30/29 Intel (South Bridge) SATA Ports 0~5

JBAT1 43 Onboard Battery
JD1 47 Onboard Speaker/Power LED
JF1 50 Front Panel Control Connector
JL1 35 Chassis Intrusion Header
JPW1 52 12V 8-Pin Auxiliary PWR Connector
JPW2 55 ATX 24-pin Main Power Connector
JPW3 56 4-Pin CPU PWR Connector
JWOL 21 Wake-On-LAN Header
JWOR 17 Wake-On-Ring Header
LAN1/2 6/7 Gigabit Ethernet (RJ45) Ports
KB/MS 1 Keyboard/Mouse (JKM1)
PWR I
SIMSO 39 SIMSO (Remote Management) IPMI
SMBus1 (JSMB1) 22 System Management Bus
SP1 46 Internal Buzzer/Speaker
T-SGPIO1/2 42/41 SATA General Purpose I/O Headers
USB 0~1 2 Back Panel Universal Serial Bus (USB)

2

C 53 Power Supply SMBus I2C Header

Fans 1~6: Chassis/System FansFan3: 45, Fan4: 36,

USB 2~3, 4~5 USB2/3:28, 4/5: 27 Front Panel USB Headers #2~3, #4~5
USB 6~7 USB 6: 23, 7: 25 FP USB Connectors #6~7

VGA 4 VGA Connector

X7DCX LED Indicators

LED Label Description

DP1 48 Power LED

1-5

X7DCX User's Manual

Motherboard Features

CPU

Dual Intel•
Sequence processors at a front side bus speed of 1333 MHz/1066 MHz

®

64-bit Xeon LGA 771 Quad-Core/Dual-Core 5400/5300/5200/5100

Memory

Six 240-pin DIMM sockets with support up to 48 GB ECC Buffered (Registered) •
DDR2 667/533 MHz Memory (See Section 2-4 in Chapter 2 for DIMM Slot
Population.)

Chipset

Intel 5100 chipset, including: the 5100 Memory Control Hub (MCH), and the •
ICH9R South Bridge

Expansion Slots

Six PCI-Exp.x8 slots (Slots 2~6, one in x16 slot: Slot5)•
One PCI-Exp. x4 in x8 slot (Slot7)•
One PCI 33MHz slot (Slot1)•
One SIMSO IPMI slot (with full KVM support if a SIMSO+ Add-on Card is •

installed)

BIOS

16 Mb Phoenix•
DMI 2.3, PCI 2.2, APM 1.2, ACPI 1.0/2.0, Plug and Play (PnP), USB Keyboard

•

support, Hardware BIOS Virus Protection, and SMBIOS 2.3

®

SPI Flash EEPROM

PC Health Monitoring

Onboard voltage monitors for CPU core, Memory, Chipset, +1.8V, +3.3V, +5V, •
+12V, −12V, +3.3V standby, +5V standby and VBAT)

Fan status monitor with fi rmware control

•

CPU/chassis temperature monitors•
Low noise fan speed control •
Fan status monitor for on-off control•
CPU fan auto-off in sleep mode•
Pulse Width Modulation (PWM) fan control•
I• 2C temperature sensing logic
Thermal Monitor 2 (TM2) support

•

PECI Ready (Platform Environment Control Interface)•
CPU slow-down on temperature overheat•

1-6

CPU thermal trip support for processor protection•
Power-up mode control for recovery from AC power loss•
Chassis intrusion detection•
System resource alert via Supero Doctor III•

ACPI Features

Slow blinking LED for suspend state indicator•
Main switch override mechanism•
ACPI Power Management•
Power-on mode for power recovery•

Onboard I/O

Six SATA 2 ports (supporting RAID0, 1,10 and 5 in the Windows OS environ-•
ment)

One SIMSO IPMI socket

•

Two Intel 82573V and 82573L LAN chips support two Giga-bit LAN ports•

Chapter 1: Introduction

One EIDE Ultra DMA/100 bus master interface supports UDMA Mode 5 and •
PIO Mode 4

One fl oppy port interface

•

Two COM ports(1 header, 1 port) supports Fast UART 16550 connections•
Up to eight USB 2.0 (Universal Serial Bus) (two ports, two headers and two •

Type A connectors)
Super I/O: Winbond W83627DHG

•

XGI Z9s 32 MB Controller supports one VGA port•

Other

External modem ring-on•
Wake-on-LAN (WOL)•
Wake-on-Ring (WOR)•
Console redirection•
Onboard Fan Speed Control by Thermal Management via BIOS•

CD/Diskette Utilities•

BIOS fl ash upgrade utility and device drivers•

Dimensions

Extended ATX 13.0" (L) x 12" (W) (330.2 mm x 304.8 mm)•

1-7

X7DCX User's Manual

PCI-E x8

PCI-E x8

PCI-E x8

VGA

CONN

PCI-E x8

PCI-E Bridge

PCI-E x8

PEX8532

PCI-E x8

LAN1
RJ45

LAN2
RJ45

DDR2 SDRAM 32MB

LAN

82573V

LAN

82573L

VGA

Volari/Z9S

VRD

PCI-E X16

PCI-E x8

PCI-E x1

PCI-E x1

PCI-E x4

PCI-E x8

PCI 33MMz

Porcessor#2

1067/1333

MT/S

PCI-E x8

PCI-E x8

PCI-E x8

Lane 5

Lane 6

Lanes1/2/3/4

Ports

#6,7

Ports

#4,5

Ports

#2,3

Porcessor#1

Intel 5100

MCH

Port

#0

DMI

ICH9R

1067/1333

MT/S

PCIE x4

#0-3

#0-2

#0-1

DDR2 667

3.0 Gb/S

USB 2.0

VRD

#0

#0

#1

#1-1

#2

#1

#3

#2

#3

#1-3

#1-2

DDR2 667

#5

#4

SATA

#7

#6

#5

#4

USB

PCI Slot

IT8213F

IDE

CONN

SIMSO

LPC

SIO

W83627DHG

MS

KB

COM1

External

SPI

COM2

Internal/SOL

Block Diagram

Note: This is a general block diagram. Please see the previous Motherboard Fea-

tures pages for details on the features of each motherboard.

1-8

Chapter 1: Introduction

1-2 Chipset and Processor Features Overview

Built upon the functionality and the capability of the Intel 5100 chipset, the
X7DCX motherboard provides the performance and feature set required for dual
processor-based high-end computer systems with confi guration options optimized
for intensive computing, high energy-effi ciency and complex business applications.
The 5100 chipset supports single or dual Intel Xeon 64-bit Quad-Core/Dual-Core
5400/5300/5200/5100 Sequence processors with front side bus speeds of up to
1333 MHz. The chipset consists of the 5100 Memory Controller Hub (MCH), Intel
I/O Controller Hub (ICH9R) and the I/O subsystem.

The 5100 Memory Controller Hub (MCH)

The Intel 5100 MCH chip is designed for symmetric multiprocessing across two
independent front side bus interfaces. Each front side bus uses a 64-bit wide,
1333/1066 MTS data bus capable of transferring data at 8.5/10.6 GB/s for a total
bandwidth of 17/21.3 GB/s. The MCH supports a 36-bit wide address bus and up
to four DDR2 667 MHz/533 MHz DIMM modules, providing a total memory capacity
of up to 48 GB.

The 5100 MCH also provides three x8 PCI-Express interfaces and one x4 DMI
Interface to the ICH9R. Each PCI Express port on the MCH provides 4 GB/s bi­directional bandwidth if confi gured as a x8 port, or 2 GB/s bi-directional bandwidth
if confi gured as a x4 port.

The Ninth Generation I/O Controller Hub (ICH9R)

The I/O Controller ICH9R provides the data buffering and interface arbitration re­quired for the system to operate effi ciently. It also provides the bandwidth needed
for the system to maintain its peak performance. The Direct Media Interface (DMI)
provides the connection between the MCH and the ICH9R. The ICH9R supports up
to one PCI-Express x16 slot, six Serial ATA ports and six USB 2.0 ports. In addition,
the ICH9R offers the Intel Matrix Storage Technology which provides various RAID
options for data protection and rapid data access. It also supports the next genera­tion of client management through the use of PROActive technology in conjunction
with Intel's next generation Gigabit Ethernet controllers.

1-9

X7DCX User's Manual

1-3 Special Features

Recovery from AC Power Loss

BIOS pr ovides a set ting fo r you to determi ne how the syst em will res pond whe n
AC power is lo st an d the n re sto red t o the sy ste m. You can cho os e for t he sy stem
to remain powered off (in which case you must hit the power switch to turn it
back on) or for it to aut omat ic all y retur n to a p ower- on state. S ee t he Power Lo st
Contr ol setting i n the Advanc ed BIOS Setup s ection to c hange this s etting. Th e
default set tin g is Last State.

1-4 PC Health Monitoring

This section describes the PC health monitoring features of the X7DCX. All have an
onboard System Hardware Monitor chip that supports PC health monitoring.

Voltage Monitoring

An onboard voltage monitor will scan the CPU Core, Chipset, +1.8V, +3.3V, +5V,
+12V, -12V, +3.3V Standby, +5V Standby and VBAT voltages continuously. Once
a voltage becomes unstable, a warning is given or an error message is sent to
the screen. Users can adjust the voltage thresholds to defi ne the sensitivity of the
voltage monitor.

Fan Status Monitor with Firmware Control

The PC health monitor can check the RPM status of the cooling fans. The onboard
CPU and chassis fans are controlled by Thermal Management via BIOS (under
Hardware Monitoring in the Advanced Setting).

Environmental Temperature Control

The thermal control sensor monitors the CPU temperature in real time and will turn
on the thermal control fan whenever the CPU temperature exceeds a user-defi ned
threshold. The overheat circuitry runs independently from the CPU. Once it detects
that the CPU temperature is too high, it will automatically turn on the thermal fan
control to prevent any overheat damage to the CPU. The onboard chassis thermal
circuitry can monitor the overall system temperature and alert users when the chas­sis temperature is too high.

1-10

Chapter 1: Introduction

CPU Overheat LED and Control

This feature is available when the user enables the CPU overheat warning function
in the BIOS. This allows the user to defi ne an overheat temperature. When the CPU
temperature reaches the pre-defi ned overheat threshold, both the overheat fan and
the warning LED are triggered.

System Resource Alert

This feature is available when used with Supero Doctor III in the Windows OS
environment or used with Supero Doctor II in Linux. Supero Doctor is used to
notif y the user of cer tain system events. For example, if the system is running
low on vir tual memor y and there is insuffi cient hard drive space for saving the
data, you c an be a lerted of t he pote ntia l pro ble m. You can also c onfi gure Supero
Docto r to provide yo u with warn ings when t he system tempe rature goe s beyond
a pre- de fi ned range.

1-5 ACPI Features

ACPI stands for Advanced Confi guration and Power I nter face. T he ACPI spe cifi -
cation defi nes a fl exible and ab st rac t ha rd ware i nterfac e t hat p rovi de s a st an dar d
way to integrate powe r manage ment featur es throu ghout a PC sys tem, inclu ding
its hardware, operating system and application software. This enables the system
to automat ically turn o n and off peri pherals such as C D-RO Ms, network c ards,
hard disk dr ives and p rinter s. This al so incl udes co nsumer d evices c onne cted to
the PC suc h as VCRs, T Vs, teleph ones and s tereos.

In addition to enabling operating system-directed power management, ACPI
provid es a gener ic system eve nt mecha nism for Pl ug and Play an d an oper ating
system-independent interface for confi guration control. ACPI leverages the Plug
and Play BIO S dat a str uc ture s whi le pr ovid ing a pr oc es sor a rch itec tur e- in dep en ­dent implementation that is compatible with Windows 2000, Windows XP and
Windows 2003 Servers.

Slow Blinking LED for Suspend-State Indicator

When the CPU goes into a suspend state, the chassis power LED will start blinking
to indic ate t hat t he C PU i s in s usp e nd m od e. W he n th e us er p re s se s any key, the
CPU will wake -u p and the L ED will auto matic ally st op blink ing and r emain on.

1-11

X7DCX User's Manual

Main Switch Override Mechanism

When an ATX power supply is used, the power button can function as a system
suspend button to make the system enter a SoftOff state. The monitor will be
suspended and the hard drive will spin down. Pressing the power button again
will cause the whole system to wake-up. During the SoftOff state, the ATX power
supply provides power to keep the required circuitry in the system alive. In case
the system malfunctions and you want to turn off the power, just press and hold
the power button for 4 seconds. This option can be set in the Power section of the
BIOS Setup routine.

External Modem Ring-On

Wake-up events can be triggered by a device such as the external modem ringing
when the system is in the Standby or Off state. The external modem ring-on can
only be used with an ATX 2.01 (or above) compliant power supply.

Wake-On-LAN is defi ned as the ability of a management application to remotely
power up a computer that is powered off. Remote PC setup, up-dates and asset
tracking can occur after hours and on weekends so that daily LAN traffi c is kept
to a minimum and users are not interrupted. The motherboard has a 3-pin header
(WOL) to connect to the 3-pin header on a Network Interface Card (NIC) that has
WOL capability. In addition, an onboard LAN controller can also support WOL
without any connection to the WOL header. The 3-pin WOL header is to be used
with a LAN add-on card only.

Note: Wake-On-LAN requires an ATX 2.01 (or above) compliant power supply.

1-6 Power Supply

As with all computer products, a stable power source is necessary for proper and
reliable operation. It is even more important for processors that have high CPU
clock rates.

The X7DCX can only accommodate 24-pin ATX power supply. Although most power
supplies generally meet the specifi cations required by the motherboard, some are
inadequate. You should use one that will supply at least 400W of power, depend­ing on your system confi guration. In addition, the 12V 8-pin is also required for
adequate power supply to the CPU. Also your power supply must supply 1.5A for
the Ethernet ports.

It is strongly recommended that you use a high quality power supply that meets
ATX power supply Specifi cation 2.02 or above. It must also be SSI compliant (info
at http://www.ssiforum.org/). Additionally, in areas where noisy power transmission
is present, you may choose to install a line fi lter to shield the computer from noise.

1-12

Chapter 1: Introduction

It is recommended that you also install a power surge protector to help avoid prob­lems caused by power surges.

1-7 Super I/O

The disk drive adapter functions of the Super I/O chip include a fl oppy disk drive
controller that is compatible with industry standard 82077/765, a data separator,
write pre-compensation circuitry , decode logic, data rate selection, a clock generator ,
drive interface control logic and interrupt and DMA logic. The wide range of functions
integrated onto the Super I/O greatly reduces the number of components required
for interfacing with fl oppy disk drives. The Super I/O supports 360 K, 720 K, 1.2
M, 1.44 M or 2.88 M disk drives and data transfer rates of 250 Kb/s, 500 Kb/s or
1 Mb/s. It also provides two high-speed, 16550 compatible serial communication
ports (UARTs). Both UARTs provide legacy speed with baud rate of up to 115.2
Kbps as well as an advanced speed with baud rates of 250 K, 500 K, or 1 Mb/s,
which support higher speed modems.

The Supe r I/O provides fun ction s that com ply with AC PI (A d va n ced Confi guration
and Power Interfa ce), which incl u d e s su p por t o f l e g a c y and ACPI power ma n a g e-

1-13

X7DCX User's Manual

Notes

1-14

Chapter 2: Installation

Chapter 2

Installation

2-1 Static-Sensitive Devices

Electro-Static-Discharge (ESD) can damage electronic com ponents. To prevent
damage to your system board, it is important to handle it very carefully . The following
measures are generally suffi cient to protect your equipment from ESD.

Precautions

Use a grounded wrist strap designed to prevent static discharge.•

Touch a grounded metal object before removing the board from the antistatic •
bag.

Handle the board by its edges only; do not touch its components, peripheral

•

chips, memory modules or gold contacts.

When handling chips or modules, avoid touching their pins.

•

Put the motherboard and peripherals back into their antistatic bags when not •
in use.

For grounding purposes, make sure your computer chassis provides excellent

•

conductivity between the power supply, the case, the mounting fasteners and
the motherboard.

Use only the correct type of onboard CMOS battery as specifi ed by the

•

manufacturer. Do not install the onboard battery upside down to avoid possible
explosion.

Unpacking

The motherboard is shipped in antist atic packag i n g t o avo id static da mage. When
unpacking the board, make sure the person handling it is static protected.

2-1

X7DCX User's Manual

2-2 Mounting the Motherboard in the Chassis

For proper installation, please follow the instructions below to mount the mother­board into the chassis before installing the CPU on the motherboard.

Tools needed

Phillips screwdriver•

#6 32 x5mm pan head screw as shown below.•

Installation Procedures

Locate the mounting holes on the motherboard. Refer to the layout below for •
the locations of the mounting holes. (The holes marked with arrows are the
mounting holes on this motherboard.)

X7DCX

Locate the mounting holes on the chassis.•

Align the mounting holes on the motherboard against the mounting holes on •
the chassis.

Insert a #6 pan head screw into a pair of mounting holes on the motherboard

•

and on the chassis.

Using a Phillips screwdriver, tighten the screw. Make sure that the standoffs on

•

the chassis click in or are screwed in tightly.

Repeat the step above until the motherboard is securely installed into the

•

chassis.

2-2

Chapter 2: Installation

Notes

1. All motherboards have standard mounting holes to fi t different types of
chassis. Make sure that the locations of all the mounting holes for both
motherboard and chassis match.

2. Some components are very close to the mounting holes. Please take
precautionary measures to avoid damaging the components when install­ing the motherboard into the chassis.

2-3

X7DCX User's Manual

!

2-3 Installing a Processor and Heatsink Fans

Warning: When handling the processor package, avoid placing

direct pressure on the label area of the fan.

Notes:

Always c onnec t the powe r cor d last and al ways remove it b efore ad ding, 1.
removin g or chan ging any c ompon ents. M ake sure that yo u insta ll the pr o­cess or into the C PU soc ket before you i nstall t he CPU he atsink .

Intel's boxed Xeon CPU package contains the CPU fan and heatsink assem-2.
bly. If you buy a CPU separately, make sure that you use only Intel-certifi ed
multi-directional heatsink and fan.

Make sure to install the motherboard into the chassis before you install the 3.
CPU heatsink and fan.

When purchasing a motherboard with an LGA 771 CPU Socket, make sure 4.
that the CPU plastic cap is in place, and none of the CPU Socket pins are
bent; otherwise, contact the retailer immediately.

Refer to the Chipset/MB Features Section for more details on CPU support.5.

Installing the LGA771 Processor

Press the load lever to release 1.
the load plate, which covers the
CPU socket, from its locking
position.

Gently lift the load lever to open 2.
the load plate.

Use your thumb and your index 3.
finger to hold the CPU at the
North Center Edge and the South
Center Edge of the CPU.

PnP Cap on
top of the
Load Plate

Load Lever

Load Plate
(with PnP Ca p
attach ed)

2-4

Loading the Processor into the Socket

!

Chapter 2: Installation

Align CPU Pin1 (the CPU corner 1.
marked with a triangle) against the
socket corner that is marked with a
triangle cutout.

Align the CPU key that is the 2.
semi-circle cutout below a gold dot
against the socket key, the notch
on the same side of the triangle
cutout on the socket.

Once aligned, carefully lower the 3.
CPU straight down to the socket.
(Do not drop the CPU on the
socket. Do not move the CPU
horizontally or vertically. Do not
rub the CPU against the surface
or against any pins of the socket
to avoid damage to the CPU or
the socket.)

North
Center
Edge

South
Center
Edge

Socket Key
(Socket Notch)

CPU Key (semi­circle cutout)
below the circle.

Corner with a
triangle cutout

Load Lever

CPU in the
CPU socket

gold dot

CPU Pin1

With the CPU installed in the 4.
socket, inspect the four corners of
the CPU to make sure that the CPU
is properly installed. Then, close
the load plate.

Use your thumb to gently push the 5.
load lever down to lock it.

Plastic cap is

If the CPU is properly installed into 6.
the soc ket, the plastic c ap will be
automatically released from the
load plate wh en th e cli p is pus hed
in the clip lock. Remove the plastic
cap fr om the mo ther board.

Warning: Please save t he plast ic PnP c ap. The mot herb oard mu st

be shipp ed with t he PnP ca p prope rly in stalle d to protec t the CP U

socket pins . Shipm ent with out the Pn P cap pr oper ly insta lled wi ll

cause da mage to t he soc ket pins.

released from
the load plate
if the CPU
properly in­stalled.

2-5

X7DCX User's Manual

!

Installing the Heatsink

CEK Heatsink Installation

Do not apply any thermal grease to the 1.
heatsink or the CPU die; the required
amount has already been applied.

Place the heatsink on top of the CPU 2.
so that the four mounting holes are
aligned with those on the retention
mechanism.

Screw in two diagonal screws (ie the #1 3.
and the #2 screws) until just snug (-do
not fully tighten the screws to avoid
possible damage to the CPU.)

Finish the installation by fully tightening 4.
all four screws.

CEK Passive Heatsink

Screw#1 Screw#2

Screw#1

Uninstalling the Heatsink

Warning: We do not recommend that the CPU or the heatsink be

removed. However, if you do need to uninstall the heatsink, please

follow the instructions on the next page to uninstall the heatsink to

prevent damage done to the CPU or the CPU socket.

Screw#2

2-6

Unscrew and remove the heatsink 1.
screws from the motherboard in the
sequence as shown in the picture on
the right.

Hold the heatsink as shown in the pic-2.
ture on the right and gently wriggle the
heatsink to loosen it from the CPU. (Do
not use excessive force when wriggling
the heatsink!!)

Once the heatsink is loosened, remove 3.
the heatsink from the CPU socket.

Clean the surface of the CPU and the 4.
heatsink to get rid of the old thermal
grease. Reapply the proper amount
of thermal grease on the surface be­fore you re-install the CPU and the
heatsink.

Chapter 2: Installation

2-7

X7DCX User's Manual

2-4 Installing DIMMs

Exercise extreme care when installing or removing DIMM

module s to prevent any po ssib le damag e. Also n ote that th e

memor y is i nterl eaved to imp rove per fo rman ce..

DIMM Installation

Insert the desired number of DIMMs into the memory slots, starting with 1.
DIMM #1A. The memory scheme is interleaved, so you must install two mod­ules at a time, beginning with DIMM 1A, DIMM 1B, then DIMM 2A, DIMM 2B,
and DIMM 3A, DIMM 3B.

Insert each DIMM module vertically into its slot. Gently press down on the 2.
DIMM module until it snaps into place in the slot. Repeat for all modules. Pay
attention to the notch along the bottom of the module to prevent inserting the
DIMM module incorrectly.

CAUTION

This motherboard supports both dual-rank and single-rank memory modules. 3.
For system memory to work properly, please use all dual-rank memory mod­ules or use all single-rank memory modules on the same motherboard. Check
the Supermicro web site for other information.

Memory Support

The X7DCX supports up to 48 GB Buffered (Registered) ECC DDR2 667/533 MHz
in 6 DIMMs. Populating memory slots of the same bank with a pair (or pairs) of
memory modules of the same size and same type will result in two-way Inter-

leaved Memory which will improve memory performance. (See the table below.)

No. of

DIMMs

2DIMMs DIMM1A ------ ------ DIMM1B ------ -----­4DIMMs DIMM1A DIMM2A ------ DIMM1B DIMM2B -----­6DIMMs DIMM1A DIMM2A DIMM3A DIMM2A DIMM2B DIMM3B

(Notes: i. DIMM slot# specified: DIMM slot to be populated; “---“: DIMM slot not to be
populated. ii. Both 533 MHz and 667MHz DIMMs are supported; however, you need to use
the memory modules of the same speed and of the same type on a motherboard. iii. For
memory to work properly, you need to follow the restrictions listed above. )

Note 1: Due to OS limitations, some operating systems may not show
more than 4 GB of memory.

Optimized DIMM Population Configurations

Note 2: Due to memory allocation to system devices, memory remaining

available for operational use will be reduced when 4 GB of RAM is used.
The reduction in memory availability is disproportional. (See the following
table for details.)

2-8

Possible System Memory Allocation & Availability

Chapter 2: Installation

System Device Size Physical Memory

Firmware Hub fl ash memory (System BIOS) 1 MB 3.99
Local APIC 4 KB 3.99
Area Reserved for the chipset 2 MB 3.99
I/O APIC (4 Kbytes) 4 KB 3.99
PCI Enumeration Area 1 256 MB 3.76
PCI Express (256 MB) 256 MB 3.51
PCI Enumeration Area 2 (if needed) -Aligned on 256-

MB boundary­VGA Memory 16 MB 2.85
TSEG 1 MB 2.84
Memory available to OS and other applications 2.84

512 MB 3.01

Remaining (-Available)
(4 GB Total System Memory)

Installing and Removing DIMMs

Notch

DDR2 ECC (Buffered) Memory

Notch

X7DCX

To Rem o ve :

Use your thumbs to
gently push the re­lease tabs near both
ends of the module
to release it from the
slot.

Release Tab

Release Tab

Release Tab

To Install: Insert module vertically and press
down until i t sn ap s into p lace. Pay attent io n to t he
alignme nt notch at th e botto m.

Top View of DDR2 ECC Slot

Release Tab

2-9

X7DCX User's Manual

1234567

8

2-5 Control Panel Connectors/IO Ports

The I/O p ort s are col or cod ed in co nforma nce wit h the PC 9 9 speci fi cation. See
the grap hic s below f or the c olor s and lo cati ons of th e vari ous I/O p or ts.

Back Panel Connectors/IO Ports

X7DCX

Back Panel I/O Port Locations and Defi nitions

Back Panel Connectors

1 Keyboard (Purple)
2 PS/2Mouse (Green)
3 USB 0
4 USB 1
5 COM 1 (Turquoise)
6 VGA (Blue)
7 LAN 1
8 LAN 2

(See Section 2-5 for details.)

2-10

Chapter 2: Installation

Front Control Panel

JF1 contains header pins for various buttons and indicators that are normally lo­cated on a control panel at the front of the chassis. These connectors are designed
specifi cally for use with Supermicro server chassis. See the fi gure below for the
descriptions of the various control panel buttons and LED indicators. Refer to the
following section for descriptions and pin defi nitions.

Front Control Panel Header (JF1) Pins

20

19

X7DCX

Ground

X

Power LED

HDD LED

NIC1 LED

NIC2 LED

OH/Fan Fail LED

PWR Fail LED

Ground

12

1920

NMI

X

Vcc

Vcc

Vcc

Vcc

Vcc

Vcc

Reset

FP Reset Button

Ground

2-11

PWR

2

1

FP Power Button

X7DCX User's Manual

Front Control Panel Pin Defi nitions

NMI Button

The non-maskable interrupt button
header is located on pins 19 and 20
of JF1. Refer to the table on the right
for pin defi nitions.

Power LED

The Power LED connection is located
on pins 15 and 16 of JF1. Refer to the
table on the right for pin defi nitions.

NMI Button

Pin Defi nitions (JF1)

Pin# Defi nition
19 Control
20 Ground

Power LED

Pin Defi nitions (JF1)

Pin# Defi nition
15 +5V
16 Ground

X7DCX

2-12

A. NMI
B. PWR LED

Ground

X

Power LED

B

HDD LED

NIC1 LED

NIC2 LED

OH/Fan Fail LED

PWR Fail LED

Ground

Ground

1920

A

NMI

X

Vcc

Vcc

Vcc

Vcc

Vcc

Vcc

Reset

FP ResetButton

FP Power Button

PWR

2

1

HDD LED

Chapter 2: Installation

The HDD LED connection is located
on pin 14 of JF1. Attach a hard-drive
LED cable here to display disk activity
(for SATA hard drives on the system).
See the table on the right for pin
defi nitions.

NIC1/NIC2 LED Indicators

HDD/UID LED

Pin Defi nitions (JF1)

Pin# Defi nition
13 UID Signal
14 HD Active

The NIC (Network Interface Control­ler) LED connection for GLAN port1 is
located on pins 11 and 12 of JF1 and
the LED connection for GLAN Port2
is on Pins 9 and 10. Attach the NIC
LED cables to display network activity .
Refer to the table on the right for pin
defi nitions.

Pin Defi nitions (JF1)

Pin# Defi nition
9/11 Vcc
10/12 Ground

A. HDD LED
B. NIC1 LED
C. NIC2 LED

Ground

X

Power LED

A

HDD LED

NIC1 LED

B

NIC2 LED

C

OH/Fan Fail LED

GLAN1/2 LED

1920

NMI
X

Vcc

Vcc

Vcc

Vcc

Vcc

X7DCX

2-13

PWR Fail LED

Ground

Ground

Vcc

Reset

FP ResetButton

FP Power Button

PWR

2

1

X7DCX User's Manual

Overheat/Fan Fail LED (OH)

Connect an LED to the OH/Fan Fail
connection on pins 7 and 8 of JF1 to
provide advanced warnings of chassis
overheating or fan failure. Refer to the
table on the right for pin defi nitions.

Power Fail LED

The Power Fail LED connection is
located on pins 5 and 6 of JF1. Refer
to the table on the right for pin defi ni-
tions.

OH/Fan Fail LED

Pin Defi nitions (JF1)

Pin# Defi nition
7 Vcc
8 Ground

OH/Fan Fail Indicator

Status

State Defi nition
Off Normal
On Overheat
Flash-

ing

Fan Fail

PWR Fail LED

Pin Defi nitions (JF1)

Pin# Defi nition
5 Vcc
6 Ground

X7DCX

A

B

2-14

A. OH/Fan Fail LED
B. PWR Supply Fail

Ground

X

Power LED

HDD LED

NIC1 LED

NIC2 LED

OH/Fan Fail LED

PWR Fail LED

Ground

Ground

1920

NMI

X

Vcc

Vcc

Vcc

Vcc

Vcc

Vcc

Reset

FP ResetButton

FP Power Button

PWR

2

1

Reset Button

The Reset Button connection is located
on pins 3 and 4 of JF1. Attach it to the
hardware reset switch on the computer
case. Refer to the table on the right for
pin defi nitions.

Power Button

Chapter 2: Installation

Reset Button

Pin Defi nitions (JF1)

Pin# Defi nition
3 Reset
4 Ground

The Power Button c o n ne ction i s located
on pins 1 and 2 of JF1. Momentarily
contacting both pins will power on/off
the system. This button can also be
configured to function as a suspend
butto n (with a set ting in th e BIOS - see
Chapter 4). To turn of f the power w hen
set to suspe nd mode, press t he button
for at least 4 seconds. Refer to the table
on the r ight for p in defi nitions.

A. Reset Button
B. PWR Button

Ground

X

Power LED

Power Button

Pin Defi nitions (JF1)

Pin# Defi nition

1 Signal
2 +3V Standby

1920

NMI

X

Vcc

X7DCX

OH/Fan Fail LED

PWR Fail LED

2-15

HDD LED

NIC1 LED

NIC2 LED

Ground

Ground

Vcc

Vcc

Vcc

Vcc

Vcc

Reset

FP ResetButton

FP Power Button

PWR

2

1

A

B

X7DCX User's Manual

2-6 Connecting to the Headers and Connectors

Power Connectors

ATX Power Connector

A 24-pin main power supply connector
(JPW2) and an 8-pin CPU PWR connector
(JPW3) are located on the motherboard.
These power connectors meet the SSI EPS
12V specifi cation. The 4-pin 12V PWR con-
nection (JPW1) is also required to provide
adequate power to the system. For the
8-pin PWR (JPW3), please refer to the item
listed below. See the table on the right for
pin defi nitions.

Processor Power Connector

In addition to the Primary ATX power con­nector (above), the 12V 8-pin CPU PWR
connector at JPW3 must also be connected
to your power supply. See the table on the
right for pin defi nitions.

B

COM1

VGA

LAN
CTRL

JPL2

S I/O

X7DCX

COM2

KB/MS

USB0/1

LAN1

LAN2

JWOR

Fan6

JPL1

LAN

CTRL

JPG1

Fan5

CH1_DIMM0
CH0_DIMM0
CH1_DIMM1
CH0_DIMM1
CH1_DIMM2
CH0_DIMM2

Slot7 PCI-Ex4(inx8 slot)

Slot6 PCI-Ex8

Slot5 PCI-Ex8(in x16slot)

Slot4 PCI-Ex8

Slo3 PCI-Ex8

Slo2 PCI-Ex8

Slot1 PCI 33MHz

SMBus1

JWOL

JI2C1

JI2C2

JSMB1

A

JPW2

JPW3

DIMM1B
DIMM1A
DIMM2B
DIMM2A
DIMM3B

DIMM3A

Intel

North Bridge

PLX
PCI-Exp.
Switch

USB6
JUSB4

Fan7

CPU1 Fan

BIOS

IDE
CTRL

USB7
JUSB5

PWR I2C

CPU1

CPU2

T-SGPIO1

T-SGPIO2

USB2/3

VGA
CTRL

I-SATA4

I-SATA5

I-SATA2

I-SATA1

I-SATA3

JBT1

Intel

South Bridge

USB4/5

JUSB3

JUSB2

JBAT1

ATX Power 24-pin Connector

Pin Defi nitions

Pin# Defi nition Pin # Defi nition
13 +3.3V 1 +3.3V
14 -12V 2 +3.3V
15 COM 3 COM
16 PS_ON 4 +5V
17 COM 5 COM
18 COM 6 +5V
19 COM 7 COM
20 Res (NC) 8 PWR_OK
21 +5V 9 5VSB
22 +5V 10 +12V
23 +5V 11 +12V
24 COM 12 +3.3V

Required Connection

12V 4-pin Power Con-

nector

Pin Defi nitions

Pins Defi nition
1 and 2 Ground
3 and 4 +12V

Required Connection

12V 8-pin Power CPU

Connector

Pin Defi nitions

Pins Defi nition

C

JPW1

Fan1

JF1

Fan2

JD1

DP1

SP1

Fan3

Fan8

CPU2 Fan

JWD1

SIMSO

IDE

Floppy

I-SATA0

Fan4

JL1

1 through 4 Ground
5 through 8 +12V

Required Connections

A. 24-pin ATX PWR
B. 4-pin PWR
C. 8-pin Processor PWR

2-16

G

F

D

H

E

Fan Headers

Fan Headers

The X7DCX has six chassis/system fan
headers (Fans 1~Fan 6), and two CPU
fan headers (Fans 7~8). These fan head­ers support 4-pin or 3-pin fans. However,
for the system to function properly, please
use all 3-pin or all 4-pin fans on a moth­erboard. See the table on the right for pin
defi nitions.

Note: The speeds of 4-pin (PWM) fans
are controlled by Thermal Management
via BIOS Hardware Monitoring in the
Advanced Setting. (The default setting
is Disabled.)

Chapter 2: Installation

Fan Header

Pin Defi nitions

Pin# Defi nition
1 Ground
2 +12V
3 Tachometer
4 PWR Modulation

COM1

VGA

LAN
CTRL

JPL2

S I/O

X7DCX

COM2

KB/MS

USB0/1

LAN1

LAN2

JWOR

Fan6

JPL1

LAN

CTRL

JPG1

Fan5

CH1_DIMM0
CH0_DIMM0
CH1_DIMM1
CH0_DIMM1
CH1_DIMM2

CH0_DIMM2

Slot7 PCI-Ex4(inx8 slot)

Slot6 PCI-Ex8

Slot5 PCI-Ex8(in x16slot)

Slot4 PCI-Ex8

Slo3 PCI-Ex8

Slo2 PCI-Ex8

Slot1 PCI 33MHz

SMBus1

JWOL

JI2C1

JI2C2

JSMB1

PWR I2C

JPW2

JPW3

DIMM1B
DIMM1A
DIMM2B
DIMM2A
DIMM3B
DIMM3A

North Bridge

PLX
PCI-Exp.
Switch

Fan7

CPU1 Fan

CPU1

Intel

BIOS

JBT1

IDE
CTRL

USB6

USB7

JUSB3

JUSB5

JUSB4

Intel

South Bridge

USB4/5

JUSB2

USB2/3

CPU2

T-SGPIO1
T-SGPIO2

I-SATA5

JPW1

Fan1

JF1

Fan2

DP1

SP1

Fan3

Fan8

CPU2 Fan

JBAT1

VGA
CTRL

SIMSO

Floppy

I-SATA4

I-SATA0

I-SATA2

I-SATA1

I-SATA3

Fan4

JL1

A. Fan 1

A

B. Fan 2
C. Fan 3

B

D. Fan 4

JD1

E. Fan 5
F. Fan 6

C

G. Fan 7 (CPU Fan 1)
H. Fan 8 (CPU Fan 2)

JWD1

IDE

2-17

X7DCX User's Manual

I/O Connections

ATX PS/2 Keyboard and PS/2
Mouse Ports

The ATX PS/2 keyboard and the PS/2
mouse are located on the I/O back­plane. See the table on the right for pin
defi nitions. (The mouse port is above
the keyboard port.) See the table on
the right for pin defi nitions.

Serial Ports

COM1 and COM2 are serial port con­nections located on the motherboard.
COM1 is a connector located on the
I/O backplane. COM2 is a header lo­cated below PCI Slot 1 to provide front
access. See the table on the right for
pin defi nitions.

PS/2 Keyboard and

Mouse Port Pin

Defi nitions

Pin# Defi nition
1 Data
2NC
3 Ground
4 VCC
5 Clock
6NC

Serial Port Pin Defi nitions

Pin # Defi nition Pin # Defi nition
1 DCD 6 DSR
2 RXD 7 RTS
3 TXD 8 CTS
4 DTR 9 RI
5 Ground 10 NC

Pin 10 (Key) is available on
COM2 only. NC: No Connec­tion.

COM1

VGA

LAN
CTRL

JPL2

S I/O

X7DCX

COM2

KB/MS

USB0/1

LAN1

LAN2

Fan6

A

B

JPL1

JWOR

C

Fan5

LAN

CTRL

Slot7 PCI-Ex4(inx8 slot)

Slot6 PCI-Ex8

Slot5 PCI-Ex8(in x16slot)

Slot4 PCI-Ex8

Slo3 PCI-Ex8

Slo2 PCI-Ex8

Slot1 PCI 33MHz

JWOL

JPG1

JI2C1

JI2C2

CH1_DIMM0
CH0_DIMM0
CH1_DIMM1
CH0_DIMM1
CH1_DIMM2
CH0_DIMM2

SMBus1
JSMB1

JPW3

DIMM1B
DIMM1A
DIMM2B
DIMM2A
DIMM3B

DIMM3A

North Bridge

Intel

PLX
PCI-Exp.
Switch

USB6
JUSB4

CPU1 Fan

BIOS

IDE
CTRL

USB7
JUSB5

JPW1

CPU1

CPU2

CPU2 Fan

T-SGPIO1

T-SGPIO2

JBT1

Intel

South Bridge

USB2/3

USB4/5

JUSB3

JUSB2

JBAT1

VGA
CTRL

SIMSO

Floppy

I-SATA4

I-SATA5

I-SATA0

I-SATA2

I-SATA1

I-SATA3

Fan4

JL1

PWR I2C

Fan7

JPW2

A. Keyboard/Mouse

Fan1

B. COM1

JF1

C. COM2

Fan2

JD1

DP1

SP1

Fan3

Fan8

JWD1

IDE

2-18

Chapter 2: Installation

D

E

G

F

Universal Serial Bus (USB)

There are eight USB 2.0 (Universal
Serial Bus) ports/headers on the
motherboard. Two of them are Back
Panel USB ports: USB 0~1. The other
six are Front Panel USB connectors:
USB 2~3, USB 4~5, USB 6 and USB

7. See the tables on the right for pin
defi nitions.

Note: To comply with FCC require­ments, please do not attach an un­shielded cable to a USB port, even
if there is no device attached to the
cable. Use only a shielded USB cable
that meets the requirements for a USB
device.

Back Panel USB

(USB 0~1)

Pin# Defi nitions
1 +5V
2 PO­3 PO+
4 Ground
5 N/A

Front Panel USB

Pin Defi nitions (USB 2~7)

USB 2/4/6/7
Pin # Defi nition

USB 3/5

Pin # Defi nition
1 +5V 1 +5V
2 PO- 2 PO­3 PO+ 3 PO+
4 Ground 4 Ground
5 No connection 5 Key

GLAN 1/2 (Giga-bit Ethernet
Ports)

Two G-bit Ethernet ports are located
on the I/O backplane. These ports
accept RJ45 type cables.

USB6
JUSB4

Fan7

CPU1 Fan

BIOS

IDE
CTRL

JBT1

USB7
JUSB5

JUSB3

PWR I2C

Intel

South Bridge

C

USB4/5

JUSB2

B

USB2/3

CPU1

CPU2

T-SGPIO1

T-SGPIO2

I-SATA5

COM1

VGA

LAN
CTRL

JPL2

S I/O

X7DCX

COM2

KB/MS

USB0/1

LAN1

LAN2

A

JWOR

Fan5

Fan6

JPL1

LAN

CTRL

Slot7 PCI-Ex4(inx8 slot)

Slot6 PCI-Ex8

Slot5 PCI-Ex8(in x16slot)

Slot4 PCI-Ex8

Slo3 PCI-Ex8

Slo2 PCI-Ex8

Slot1 PCI 33MHz

JPG1

JI2C1

JI2C2

CH1_DIMM0
CH0_DIMM0
CH1_DIMM1
CH0_DIMM1
CH1_DIMM2

CH0_DIMM2

JWOL

SMBus1

JSMB1

JPW2

JPW3

DIMM1B
DIMM1A
DIMM2B
DIMM2A
DIMM3B

DIMM3A

Intel

North Bridge

PLX
PCI-Exp.
Switch

LAN 1~2

JF1

A. USB 0/1
B. USB 2/3
C. USB 4/5

JPW1

Fan1

Fan2

D. USB 6

JD1

DP1

SP1
Fan3

Fan8

CPU2 Fan

JBAT1

VGA
CTRL

SIMSO

Floppy

I-SATA4

I-SATA0

I-SATA2

I-SATA1

I-SATA3

Fan4

JL1

E. USB 7
F. LAN Port 1
G. LAN Port 2

JWD1

IDE

2-19

X7DCX User's Manual

G

F

D

E

VGA Connector

A VGA connector is located next to
COM1 port on the IO backplane.
Refer to the board layout below for
the location.

Serial ATA Ports

Six Serial ATA (SATA) ports (I­SATA0~I-SATA5) are located at
JS1~JS6 on the motherboard. These
SATA connections are supported by
Intel South Bridge to provide Serial­Link signal transmissions on the
motherboard. See the table on the
right for pin defi nitions. Refer to the
board layout below for the locations
of the headers.

SATA Port

Pin Defi nitions

Pin# Defi nition Pin Defi nition
1 Ground 2 TX+
3 TX- 4 Ground

5 RX- 6 RX+
7 Ground NA

COM1

A

VGA

LAN
CTRL

JPL2

S I/O

X7DCX

COM2

KB/MS

USB0/1

LAN1

LAN2

JWOR

Fan6

JPL1

CTRL

JPG1

Fan5

CH1_DIMM0
CH0_DIMM0
CH1_DIMM1
CH0_DIMM1
CH1_DIMM2

CH0_DIMM2

LAN

Slot7 PCI-Ex4(inx8 slot)

Slot6 PCI-Ex8

Slot5 PCI-Ex8(in x16slot)

Slot4 PCI-Ex8

Slo3 PCI-Ex8

Slo2 PCI-Ex8

Slot1 PCI 33MHz

JWOL

JI2C1

JI2C2

SMBus1
JSMB1

JPW3

DIMM1B
DIMM1A
DIMM2B
DIMM2A
DIMM3B

DIMM3A

North Bridge

Intel

PLX
PCI-Exp.
Switch

USB6
JUSB4

CPU1 Fan

BIOS

IDE
CTRL

USB7
JUSB5

JPW1

Fan1

CPU1

Fan2

DP1

CPU2

T-SGPIO1

T-SGPIO2

USB2/3

VGA
CTRL

I-SATA4

I-SATA5

I-SATA2

I-SATA3

JBT1

Intel

South Bridge

USB4/5

JUSB3

JUSB2

SP1

Fan3

Fan8

CPU2 Fan

JBAT1

SIMSO

Floppy

C

I-SATA0

I-SATA1

B

Fan4

JL1

PWR I2C

Fan7

JPW2

JF1

JWD1

IDE

JD1

A. VGA
B. SATA0
C. SATA1
D. SATA2
E. SATA3
F SATA4
G SATA5

2-20

T-SGPIO Headers

Chapter 2: Installation

Two T-SGPIO (Serial-Link General
Purpose Input/Output) headers are
located between the South Bridge
and the VGA Controller on the
motherboard. These headers are
used to communicate with the Serial­Link System Monitoring chip on the
backplane. See the table on the right
for pin defi nitions. Refer to the board
layout below for the locations of the
headers.

GPIO1/2

Pin Defi nitions

Pin# Defi nition Pin Defi nition
1NC 2 NC
3 Ground 4 DATA Out

5 Load 6 Ground
7 Clock 8 NC

NC: No Connections

COM1

VGA

LAN
CTRL

JPL2

S I/O

X7DCX

COM2

KB/MS

USB0/1

LAN1

LAN2

JWOR

Fan6

JPL1

LAN
CTRL

JPG1

Fan5

CH1_DIMM0
CH0_DIMM0
CH1_DIMM1
CH0_DIMM1
CH1_DIMM2

CH0_DIMM2

Slot7 PCI-Ex4(inx8 slot)

Slot6 PCI-Ex8

Slot5 PCI-Ex8(in x16slot)

Slot4 PCI-Ex8

Slo3 PCI-Ex8

Slo2 PCI-Ex8

Slot1 PCI 33MHz

SMBus1

JWOL

JI2C1

JI2C2

JSMB1

PWR I2C

USB6
JUSB4

Fan7

CPU1 Fan

BIOS

IDE
CTRL

JUSB5

JPW1

Fan1

CPU1

Fan2

DP1

CPU2

A

T-SGPIO1
T-SGPIO2

B

USB2/3

VGA
CTRL

I-SATA4

I-SATA5

I-SATA2

I-SATA3

JBT1

Intel

South Bridge

USB7

USB4/5

JUSB3

JUSB2

SP1
Fan3

Fan8

CPU2 Fan

JBAT1

SIMSO

Floppy

I-SATA0

I-SATA1

Fan4

JL1

JPW2

JPW3

DIMM1B
DIMM1A
DIMM2B
DIMM2A
DIMM3B

DIMM3A

Intel

North Bridge

PLX
PCI-Exp.
Switch

JF1

JD1

JWD1

IDE

A. SGPIO1
B. SGPIO2

2-21

X7DCX User's Manual

Onboard Headers

Wake-On-Ring

The Wake-On-Ring header is located
at JWOR. Use this header to "wake
up" your system when it receives an
incoming call to the modem while in
suspend state. See the table on the
right for pin defi nitions. Y ou must have
a Wake-On-Ring card and cable to
use this feature.

Wake-On-Ring

Pin Defi nitions

Pin# Defi nition
1 Ground
2 Wake-up

Wake-On-LAN

The Wake-On-LAN header is located
at JWOL on the motherboard. See
the table on the right for pin defi ni-
tions. (You must have a LAN card
with a Wake -O n-LA N conne c to r, and
cable to u se this fe ature.)

USB6
JUSB4

Fan7

CPU1 Fan

BIOS

IDE
CTRL

USB7
JUSB5

PWR I2C

CPU1

CPU2

T-SGPIO1

T-SGPIO2

JBT1

Intel

South Bridge

I-SATA5

USB2/3

USB4/5

JUSB3

JUSB2

COM1

VGA

LAN
CTRL

JPL2

S I/O

X7DCX

COM2

KB/MS

USB0/1

LAN1

LAN2

Fan6

JPL1

A

JPG1

JWOR

Fan5

CH1_DIMM0
CH0_DIMM0

CH1_DIMM1
CH0_DIMM1
CH1_DIMM2
CH0_DIMM2

LAN

CTRL

Slot7 PCI-Ex4(inx8 slot)

Slot6 PCI-Ex8

Slot5 PCI-Ex8(in x16slot)

Slot4 PCI-Ex8

Slo3 PCI-Ex8

Slo2 PCI-Ex8

B

Slot1 PCI 33MHz

JWOL

JI2C1

JI2C2

SMBus1
JSMB1

JPW2

JPW3

DIMM1B
DIMM1A
DIMM2B
DIMM2A
DIMM3B
DIMM3A

Intel

North Bridge

PLX
PCI-Exp.
Switch

Wake-On-LAN

Pin Defi nitions

Pin# Defi nition
1 +5V Standby
2 Ground
3 Wake-up

JPW1

CPU2 Fan

JBAT1

VGA
CTRL

SIMSO

Floppy

I-SATA4

I-SATA0

I-SATA2

I-SATA1

I-SATA3

Fan4

JL1

A. WOR

Fan1

B. WOL

JF1

Fan2

JD1

DP1

SP1
Fan3

Fan8

JWD1

IDE

2-22

Power LED/Speaker

On the JD1 header, pins 1-3 are for a power
LED, and pins 4-7 are for the speaker.
See the table on the right for speaker pin
defi nitions.

Note: The speaker connector pins are
for use with an external speaker. If you
wish to use the onboard speaker, you
should close pins 6-7 with a jumper.

Chapter 2: Installation

Speaker Connector

Pin Defi nitions

Pin Setting Defi nition
Pins 6-7 Internal Speaker
Pins 4-7 External Speaker

Chassis Intrusion

A Chassis Intrusion header is located at
JL1 on the motherboard. Attach an appro­priate cable from the chassis to inform you
of a chassis intrusion when the chassis is
opened.

USB6
JUSB4

Fan7

CPU1 Fan

BIOS

IDE
CTRL

USB7
JUSB5

PWR I2C

CPU1

CPU2

T-SGPIO1
T-SGPIO2

USB2/3

VGA
CTRL

I-SATA4

I-SATA5

I-SATA2

I-SATA1

I-SATA3

JBT1

Intel

South Bridge

USB4/5

JUSB3

JUSB2

COM1

VGA

S I/O

X7DCX

COM2

LAN
CTRL

JPL2

KB/MS

USB0/1

LAN1

LAN2

JWOR

Fan6

JPL1

LAN
CTRL

JPG1

Fan5

CH1_DIMM0

CH0_DIMM0

CH1_DIMM1
CH0_DIMM1
CH1_DIMM2

CH0_DIMM2

Slot7 PCI-Ex4(inx8 slot)

Slot6 PCI-Ex8

Slot5 PCI-Ex8(in x16slot)

Slot4 PCI-Ex8

Slo3 PCI-Ex8

Slo2 PCI-Ex8

Slot1 PCI 33MHz

SMBus1

JWOL

JI2C1

JI2C2

JSMB1

JPW2

JPW3

DIMM1B
DIMM1A
DIMM2B

DIMM2A
DIMM3B
DIMM3A

Intel

North Bridge

PLX
PCI-Exp.
Switch

JBAT1

Chassis Intrusion

Pin Defi nitions (JL1)

Pin# Defi nition
1 Intrusion Input
2 Ground

JPW1

Fan1

Fan2

DP1

SP1
Fan3

Fan8

CPU2 Fan

SIMSO

Floppy

I-SATA0

Fan4

B

JL1

A. PWR LED/Speaker
B. Chassis Intrusion

JF1

JD1

A

JWD1

IDE

2-23

X7DCX User's Manual

SMB

A System Management Bus header
is located at JSMB1. Connect an ap­propriate cable here to utilize SMB on
your system.

Power I2C Connector

Power I2C (Power SMB) connector
monitors the status of the power
supply, fan and system temperature.
See the table on the right for pin
defi nitions.

SMB Header

Pin Defi nitions

Pin# Defi nition
1 Data
2 Ground
3 Clock
4 No Connection

PWR SMB

Pin Defi nitions

Pin# Defi nition
1 Clock
2 Data

3 PWR Fail
4 Ground
5 +3.3V

COM1

VGA

LAN

CTRL

JPL2

S I/O

X7DCX

COM2

KB/MS

USB0/1

LAN1

LAN2

JWOR

Fan6

JPL1

LAN
CTRL

JPG1

Fan5

CH1_DIMM0
CH0_DIMM0

CH1_DIMM1
CH0_DIMM1
CH1_DIMM2
CH0_DIMM2

Slot7 PCI-Ex4(inx8 slot)

Slot6 PCI-Ex8

Slot5 PCI-Ex8(in x16slot)

Slot4 PCI-Ex8

Slo3 PCI-Ex8

Slo2 PCI-Ex8

A

Slot1 PCI 33MHz

SMBus1

JWOL

JI2C1

JI2C2

JSMB1

B

JPW3

DIMM1B
DIMM1A
DIMM2B

DIMM2A
DIMM3B
DIMM3A

North Bridge

Intel

PLX
PCI-Exp.
Switch

USB6
JUSB4

CPU1 Fan

BIOS

IDE
CTRL

JUSB5

JPW1

CPU1

CPU2

CPU2 Fan

T-SGPIO1

T-SGPIO2

JBT1

Intel

South Bridge

USB7

JUSB3

USB4/5

JUSB2

USB2/3

JBAT1

VGA
CTRL

SIMSO

Floppy

I-SATA4

I-SATA5

I-SATA0

I-SATA2

I-SATA1

I-SATA3

Fan4

JL1

PWR I2C

Fan7

JPW2

A. Overheat LED

Fan1

B. PWR SMB

JF1

Fan2

JD1

DP1

SP1
Fan3

Fan8

JWD1

IDE

2-24

2-7 Jumper Settings

Connector

Pins

Jumper

Cap

Setting

Chapter 2: Installation

Explanation of Jumpers

To modify the operation of the mother­board, jumpers can be used to choose
between optional settings. Jumpers
create shorts between two pins to
change the function of the connector.
Pin 1 is identifi ed with a square solder
pad on the printed circuit board. See
the motherboard layout pages for
jumper locations.

Note: On two pin jumpers,
"Closed" means the jumper is on and
"Open" means the jumper is off the
pins.

GLAN Enable/Disable

JPL1/JPL2 enable or disable GLAN
Port1/GLAN Port2 on the mother­board. S ee the table o n the right fo r
jumper settings. The default setting is
Enabled.

3 2 1

3 2 1

Pin 1-2 short

GLAN Enable

Jumper Settings

Pin# Defi nition
1-2 Enabled (default)
2-3 Disabled

COM1

VGA

S I/O

X7DCX

COM2

LAN
CTRL

JPL2

KB/MS

USB0/1

LAN1

LAN2

JWOR

Fan6

JPL1

LAN
CTRL

B

JPG1

Fan5

CH1_DIMM0

CH0_DIMM0

CH1_DIMM1
CH0_DIMM1
CH1_DIMM2
CH0_DIMM2

A

Slot7 PCI-Ex4(inx8 slot)

Slot6 PCI-Ex8

Slot5 PCI-Ex8(in x16slot)

Slot4 PCI-Ex8

Slo3 PCI-Ex8

Slo2 PCI-Ex8

Slot1 PCI 33MHz

SMBus1

JWOL

JI2C1

JI2C2

JSMB1

PWR I2C

JPW3

DIMM1B
DIMM1A
DIMM2B

DIMM2A
DIMM3B
DIMM3A

North Bridge

Intel

PLX
PCI-Exp.
Switch

USB6
JUSB4

CPU1 Fan

BIOS

IDE
CTRL

USB7
JUSB5

JPW1

Fan1

CPU1

DP1

CPU2

CPU2 Fan

T-SGPIO1
T-SGPIO2

JBT1

Intel

South Bridge

USB2/3

USB4/5

JUSB3

JUSB2

JBAT1

VGA
CTRL

SIMSO

Floppy

I-SATA4

I-SATA5

I-SATA0

I-SATA2

I-SATA1

I-SATA3

Fan4

JL1

Fan7

JPW2

A. GLAN 1 Enable
B. GLAN 2 Enable

JF1

Fan2

JD1

SP1
Fan3

Fan8

JWD1

IDE

2-25

X7DCX User's Manual

CMOS Clear

JBT1 is used to clear CMOS. Instead of pins, this "jumper" consists of contact pads
to prevent the accidental clearing of CMOS. To clear CMOS, use a metal object such
as a small screwdriver to touch both pads at the same time to short the connection.
Always remove the AC power cord from the system before clearing CMOS. Note:
For an ATX power supply, you must completely shut down the system, remove the
AC power cord and then short JBT1 to clear CMOS.

Watch Dog Enable/Disable

Watch Dog (JWD1) is a system moni­tor that can reboot the system when a
software application hangs. Close pins
1-2 to reset the system if an applica­tion ha ngs. Close pi ns 2-3 to gener ate a
non- maskabl e interr upt signal fo r the ap ­plicat ion t hat han gs. S ee th e tab le on t he
right for jumper settin gs. Watch Dog must
also be enabled in the BIOS.

USB6
JUSB4

Fan7

CPU1 Fan

BIOS

IDE
CTRL

USB7
JUSB5

PWR I2C

CPU1

CPU2

T-SGPIO1

T-SGPIO2

USB2/3

VGA
CTRL

I-SATA4

I-SATA5

I-SATA2

I-SATA1

I-SATA3

JBT1

A

Intel

South Bridge

USB4/5

JUSB3

JUSB2

COM1

VGA

LAN
CTRL

JPL2

S I/O

X7DCX

COM2

KB/MS

USB0/1

LAN1

LAN2

JWOR

Fan6

JPL1

LAN

CTRL

JPG1

Fan5

CH1_DIMM0
CH0_DIMM0

CH1_DIMM1
CH0_DIMM1
CH1_DIMM2
CH0_DIMM2

Slot7 PCI-Ex4(inx8 slot)

Slot6 PCI-Ex8

Slot5 PCI-Ex8(in x16slot)

Slot4 PCI-Ex8

Slo3 PCI-Ex8

Slo2 PCI-Ex8

Slot1 PCI 33MHz

SMBus1

JWOL

JI2C1

JI2C2

JSMB1

JPW2

JPW3

DIMM1B
DIMM1A
DIMM2B
DIMM2A
DIMM3B
DIMM3A

Intel

North Bridge

PLX
PCI-Exp.
Switch

JBAT1

Watch Dog

Jumper Settings

Jumper Setting Defi nition
Pins 1-2 Reset

(default)
Pins 2-3 NMI
Open Disabled

JPW1

CPU2 Fan

SIMSO

I-SATA0

Fan4

JL1

A. Clear CMOS

Fan1

B. Watch Dog Enable

JF1

Fan2

JD1

DP1

SP1
Fan3

Fan8

B

JWD1

IDE

Floppy

2-26

Chapter 2: Installation

VGA Enable/Disable

JPG1 allows you to enable or disable the
VGA port. The default position is on pins
1 and 2 to enable VGA. See the table on
the right for jumper settings.

2

I

C Bus to PCI Slots

Jumpers JI

2

C1 and JI2C2 allow you to con­nect th e System Ma nagement B us (SMB)
to PCI-E and PCI slots. The default setting
is set to Disabled. See the table on the
right f or jump er set ting s.

VGA Enable/Disable

Jumper Settings (JPG1)

Both Jumpers Defi nition
Pins 1-2 Enabled
Pins 2-3 Disabled

I2C to PCI-Slots

Jumper Settings

Jumper Defi nition
On Enabled
Off Disabled (Default)

COM1

VGA

LAN
CTRL

JPL2

S I/O

X7DCX

COM2

KB/MS

USB0/1

LAN1

LAN2

JWOR

Fan6

JPL1

LAN
CTRL

A

JPG1

JI2C2

Fan5

CH1_DIMM0
CH0_DIMM0
CH1_DIMM1
CH0_DIMM1

CH1_DIMM2
CH0_DIMM2

Slot7 PCI-Ex4(inx8 slot)

Slot6 PCI-Ex8

Slot5 PCI-Ex8(in x16slot)

Slot4 PCI-Ex8

Slo3 PCI-Ex8

Slo2 PCI-Ex8

Slot1 PCI 33MHz

B

C

SMBus1

JWOL

JI2C1

JSMB1

JPW3

JPW2

DIMM1B
DIMM1A

DIMM2B
DIMM2A
DIMM3B

DIMM3A

Intel

North Bridge

PLX
PCI-Exp.
Switch

USB6
JUSB4

Fan7

CPU1 Fan

BIOS

IDE
CTRL

USB7
JUSB5

JBT1

JUSB3

PWR I2C

Intel

South Bridge

USB4/5

JUSB2

CPU1

CPU2

T-SGPIO1

T-SGPIO2

USB2/3

2-27

JPW1

Fan1

Fan2

DP1

SP1

Fan3

Fan8

CPU2 Fan

JBAT1

VGA
CTRL

SIMSO

Floppy

I-SATA4

I-SATA5

I-SATA0

I-SATA2

I-SATA1

I-SATA3

Fan4

JL1

A. VGA Enable
B. JI

JF1

C. JI

JD1

JWD1

IDE

2

2

C1

C2

X7DCX User's Manual

2-8 Onboard Indicators

GLAN LEDs

There ar e tw o GL AN p or ts o n the mot h­erboard. Each Gigabit Ethernet LAN port
has two L ED s . T he ye l lo w LE D in di cates
activity, while the Link LED may be
green, amber or off to indicate the speed
of the connection. Se e the tab l es at right
for more i nform ation.

Onboard Power LED

An Onboard Power LED is located at DP1
on the motherboard. When this LED Indi­cator is on, the system is on. Be sure to
unplug the power cable before removing
or adding any components. See the table
on the right for more details.

Link
LED

Activity
LED

Rear View
(when viewing from the back of the chassis.)

GLAN Activity Indicator

LED Setting

Color Status Defi nition
Y ellow Flashing LAN Active

GLAN Link Indicator

LED Settings

LED Color Defi nition
Off No Connection or 10 Mbps
Green 100 Mbps
Amber 1 Gbps

Onboard PWR LED Indicator

LED Settings

LED Color Defi nition
Off System Off (PWR cable

Green System On
Green:

Flashing
Quickly

Green:
Flashing
Slowly

not connected)

ACPI S1 State

ACPI S3 (STR) State

COM1

VGA

LAN
CTRL

JPL2

S I/O

X7DCX

COM2

KB/MS

USB0/1

LAN1

LAN2

A

B

JWOR

Fan6

JPL1

JPG1

Fan5

CH1_DIMM0
CH0_DIMM0
CH1_DIMM1
CH0_DIMM1
CH1_DIMM2

CH0_DIMM2

LAN
CTRL

Slot7 PCI-Ex4(inx8 slot)

Slot6 PCI-Ex8

Slot5 PCI-Ex8(in x16slot)

Slot4 PCI-Ex8

Slo3 PCI-Ex8

Slo2 PCI-Ex8

Slot1 PCI 33MHz

JWOL

JI2C1

JI2C2

SMBus1
JSMB1

JPW3

DIMM1B
DIMM1A
DIMM2B
DIMM2A
DIMM3B

DIMM3A

North Bridge

Intel

PLX
PCI-Exp.
Switch

USB6
JUSB4

CPU1 Fan

BIOS

IDE
CTRL

USB7
JUSB5

JPW1

CPU1

CPU2

CPU2 Fan

T-SGPIO1

T-SGPIO2

JBT1

Intel

South Bridge

USB2/3

USB4/5

JUSB3

JUSB2

JBAT1

VGA
CTRL

SIMSO

I-SATA4

I-SATA5

I-SATA0

I-SATA2

I-SATA1

I-SATA3

Fan4

JL1

PWR I2C

Fan7

JPW2

A. GLAN Port1 LEDs

Fan1

B. GLAN Port2 LEDs

JF1

C. Onboard PWR LED

Fan2

JD1

DP1

C

SP1

Fan3

Fan8

JWD1

IDE

Floppy

2-28

Chapter 2: Installation

2-9 Floppy, SIMSO IPMI and HDD Connections

Note the fo llowi ng when c onne cting t he fl oppy and hard disk drive cables:

• The fl oppy disk dri ve cabl e has seven t wiste d wires .

• A re d mark o n a wire t ypic ally de signate s the lo cati on of pin 1.

• A single fl oppy disk drive ribbon cable has 34 wires and two connectors to

provide for two fl oppy disk drives. The connector with t wisted wires always
connects to drive A, and the connector that does not have twisted wires always
connects to drive B.

Floppy Drive Connector

Floppy Connector

The fl oppy co nnec tor is lo cated n ext
to the ID E d rive. See t h e table b e l o w
for pin de fi nitions.

Pin# Defi nition Pin # Defi nition
1 Ground 2 FDHDIN
3 Ground 4 Reserved
5 Key 6 FDEDIN
7 Ground 8 Index
9 Ground 10 Motor Enable
11 Ground 12 Drive Select B
13 Ground 14 Drive Select B
15 Ground 16 Motor Enable
17 Ground 18 DIR
19 Ground 20 STEP
21 Ground 22 Write Data
23 Ground 24 Write Gate
25 Ground 26 Track 00
27 Ground 28 Write Protect
29 Ground 30 Read Data
31 Ground 32 Side 1 Select
33 Ground 34 Diskette

Pin Defi nitions (Floppy)

COM1

VGA

LAN
CTRL

JPL2

S I/O

X7DCX

COM2

KB/MS

USB0/1

LAN1

LAN2

JWOR

Fan6

JPL1

LAN

CTRL

JPG1

Fan5

CH1_DIMM0
CH0_DIMM0
CH1_DIMM1
CH0_DIMM1
CH1_DIMM2
CH0_DIMM2

Slot7 PCI-Ex4(inx8 slot)

Slot6 PCI-Ex8

Slot5 PCI-Ex8(in x16slot)

Slot4 PCI-Ex8

Slo3 PCI-Ex8

Slo2 PCI-Ex8

Slot1 PCI 33MHz

SMBus1

JWOL

JI2C1

JI2C2

JSMB1

JPW3

DIMM1B
DIMM1A
DIMM2B
DIMM2A
DIMM3B

DIMM3A

North Bridge

Intel

PLX
PCI-Exp.
Switch

USB6
JUSB4

CPU1 Fan

BIOS

IDE

CTRL

JBT1

USB7
JUSB5

JUSB3

Intel

South Bridge

USB4/5

JUSB2

USB2/3

CPU1

CPU2

T-SGPIO1

T-SGPIO2

JPW1

Fan1

JF1

Fan2

DP1

SP1
Fan3

Fan8

CPU2 Fan

JBAT1

VGA
CTRL

I-SATA4

I-SATA5

A

SIMSO

Floppy

I-SATA0

I-SATA2

I-SATA1

I-SATA3

Fan4

JL1

PWR I2C

Fan7

JPW2

A. Floppy

JD1

JWD1

IDE

2-29

X7DCX User's Manual

IDE Connector

An IDE C onnec tor is loc ated next to
the fl oppy drive on the motherboard.
See the table on the right for pin
defi nitions.

SIMSO IPMI Slot

A SIMSO I PMI slot is lo cated nex t to
the fl oppy drive on the motherboard.
This connection offers Intelligent Plat­form Management Interfacing (IPMI)
capability for multi-platform, multi­user communications and remote
system management. It also provides
full KVM support if a SIMSO+ Add­on card is installed on this slot. Refer
to the layout below for the IPMI slot
location.

IDE Drive Connectors

Pin Defi nitions

Pin# Defi nition Pin # Defi nition
1 Reset IDE 2 Ground
3 Host Data 7 4 Host Data 8
5 Host Data 6 6 Host Data 9
7 Host Data 5 8 Host Data 10
9 Host Data 4 10 Host Data 11
11 Host Data 3 12 Host Data 12
13 Host Data 2 14 Host Data 13
15 Host Data 1 16 Host Data 14
17 Host Data 0 18 Host Data 15
19 Ground 20 Key
21 DRQ3 22 Ground
23 I/O Write 24 Ground
25 I/O Read 26 Ground
27 IOCHRDY 28 BALE
29 DACK3 30 Ground
31 IRQ14 32 IOCS16
33 Addr1 34 Ground
35 Addr0 36 Addr2
37 Chip Select 0 38 Chip Select 1
39 Activity 40 Ground

COM1

VGA

X7DCX

S I/O

COM2

USB6
JUSB4

Fan7

CPU1 Fan

BIOS

IDE

CTRL

USB7

JUSB5

PWR I2C

CPU1

CPU2

T-SGPIO1

T-SGPIO2

JBT1

Intel

South Bridge

I-SATA5

USB2/3

USB4/5

JUSB3

JUSB2

JPW1

CPU2 Fan

JBAT1

B

VGA
CTRL

SIMSO

Floppy

I-SATA4

I-SATA0

I-SATA2

I-SATA1

I-SATA3

Fan4

JL1

Fan5

Fan6

KB/MS

USB0/1

LAN1

LAN2

LAN

CTRL

JPL2

JWOR

JPL1

LAN
CTRL

JPG1

CH1_DIMM0
CH0_DIMM0

CH1_DIMM1
CH0_DIMM1
CH1_DIMM2
CH0_DIMM2

Slot7 PCI-Ex4(inx8 slot)

Slot6 PCI-Ex8

Slot5 PCI-Ex8(in x16slot)

Slot4 PCI-Ex8

Slo3 PCI-Ex8

Slo2 PCI-Ex8

Slot1 PCI 33MHz

SMBus1

JWOL

JI2C1

JI2C2

JSMB1

JPW2

JPW3

DIMM1B
DIMM1A
DIMM2B

DIMM2A
DIMM3B
DIMM3A

Intel

North Bridge

PLX
PCI-Exp.
Switch

Fan1

JF1

Fan2

JD1

DP1

SP1
Fan3

Fan8

A

JWD1

IDE

A. IDE Drive
B. SIMSO IPMI

2-30

Chapter 3: Troubleshooting

Chapter 3

Troubleshooting

3-1 Troubleshooting Procedures

Use the following procedures to troubleshoot your system. If you have followed all
of the procedures below and still need assistance, refer to the ‘Technical Support
Procedures’ and/or ‘Returning Merchandise for Service’ section(s) in this chapter.

Note: Always disconnect the power cord before adding, changing or installing
any hardware components.

Before Power On

Make sure that there are no short circuits between the motherboard and the 1.
chassis.

Disconnect all ribbon/wire cables from the motherboard, including those for 2.
the keyboard and mouse. Remove all add-on cards.

Install a CPU in CPU Socket and connect the chassis speaker and the power 3.
LED to the motherboard. (Make sure that the CPU is properly seated. Be sure
to check all jumper settings as well.)

No Power

Make sure that there are no short circuits between the motherboard and the 1.
chassis.

Make sure that all jumpers are set to their default positions. 2.

Make sure that the 115V/230V switch on the power supply is properly set.3.

Turn the power switch on and off to test the system. The battery on your moth-4.
erboard may be old. Check to verify that it still supplies ~3VDC. If it does not,
replace it with a new one.

3-1

X7DCX User's Manual

No Video

If the power is on, and you have no video, please remove all the add-on 1.
cards and cables.

Use the speaker to determine if any beep codes exist. Refer to the Appendix 2.
for details on beep codes.

Losing the System’s Setup Confi guration

Make sure that you are using a high quality power supply. A poor quality 3.
power supply may cause the system to lose the CMOS setup information.
Refer to Section 1-6 for details on recommended power supplies.

The bat ter y on your m other boar d may be old. C heck to ve rif y that i t still sup -4.
plies ~3V DC. If it d oes not , repla ce it wi th a new one.

If the above steps do not fi x the Setup Confi guration problem, contact your 5.
vendor for repairs.

Memory Errors

Make sure the DIMM modules are properly and fully installed. Check if 1.
DIMMs of different speeds or types have been installed. Also make sure that
the BIOS setup is confi gured for the fastest speed of RAM used.

It is rec omme nded to u se the sa me R AM s peed fo r all DI MMs i n the syste m. 2.
Make sure you ar e using t he cor rect t ype of D DR 2 Buf fere d (Registe red)
ECC 667/533 M Hz SD R AM (reco mmend ed by the ma nufac turer.)

Check f or bad DI MM mo dules o r slots by swap ping a sin gle mo dule bet ween 3.
four slot s and not ing the r esults . Make sure al l memor y m odule s are full y
seated in th eir slot s. As an inter leaved m emor y sch eme is use d, you must
instal l two mo dules at a t ime, be ginning w ith Ba nk 1, then Bank 2, an d so on
(see Sect ion 2- 4). Check t he pos itio n of the 115V/230V switc h on the p ower
supply.

3-2 Technical Support Procedures

Before contacting Technical Support, please take the following steps. Also, note that
as a motherboard manufacturer, Supermicro does not sell directly to end-users, so
it is best to fi rst check with your distributor or reseller for troubleshooting services.

3-2

Chapter 3: Troubleshooting

They should know of any possible problem(s) with the specifi c system confi guration
that was sold to you.

Please go through the ‘Troubleshooting Procedures’ and 'Frequently Asked 1.
Question' (FAQ) sections in this chapter or see the FAQs on our web site
(http://www.supermicro.com/support/faqs/) before contacting Technical Sup­port.

BIOS upgrades can be downloaded from our web site at http://www.supermi-2.
cro.com/support/bios/.

If you still cannot resolve the problem, include the following information when 3.
contacting Supermicro for technical support:

Motherboard model and PCB revision number

•

BIOS release date/version (this can be seen on the initial display when your •
system fi rst boots up)

System confi guration

•

An example of a Technical Support form is on our web site at http://www.•
supermicro.com/support/contact.cfm/.

Distr ibutor s: For immediate as sistan ce, pleas e have your acc ount numbe r ready
when plac ing a cal l to our techni cal suppo rt dep artm ent. We can be re ached by
e- mail at supp or t@sup ermi cro.co m or by fax at : (408) 503 - 80 00, o ption 2 .

3-3 Frequently Asked Questions

Question: What are the various types of memory that my motherboard can
support?

Answer: The X7DCX has six 240-pin DIMM slots that support DDR2 Registered

ECC 667/533 MHz SDRAM modules. It is strongly recommended that you do not
mix memory modules of different speeds and sizes. (See Chapter 2 for detailed
Information.)

Question: How do I update my BIOS?
Answer: It is recommended that you do not upgrade your BIOS if you are experi-

encing no problems with your system. Updated BIOS fi les are located on our web
site at http://www.supermicro.com/support/bios/. Please check our BIOS warning
message and the information on how to update your BIOS on our web site. Also,
check the current BIOS revision, and make sure that it is newer than your BIOS
before downloading. Select your motherboard model and download the BIOS fi le to

3-3

X7DCX User's Manual

your computer. Unzip the BIOS fi les onto a bootable fl oppy and reboot your system.
Follow the Readme.txt to continue fl ashing the BIOS.

Warning: Do not shut down or reset the system while updating BIOS to
prevent possible system boot failure!

Question: What's on the CD that came with my motherboard?
Answer: The supplied compact disc has quite a few drivers and programs that will

greatl y enhanc e your sys tem. We rec omme nd that you r eview th e CD and in stall
the appl icat ions you n eed. Ap plic ation s on the C D inclu de chip set dri vers fo r the
Window s OS, and s ecur ity a nd audio d river s.

3-4 Returning Merchandise for Service

A receipt or copy of your invoice marked with the date of purchase is required be­fore any warranty service will be rendered. You can obtain service by calling your
vendor for a Returned Merchandise Authorization (RMA) number. When returning
to the manufacturer, the RMA number should be prominently displayed on the
outside of the shipping carton, and mailed prepaid or hand-carried. Shipping and
handling charges will be applied for all orders that must be mailed when service
is complete.

This warranty only covers normal consumer use and does not cover damage in­curred in shipping or from failure due to the alternation, misuse, abuse or improper
maintenance of products.

During the warranty period, contact your distributor fi rst for any product problems.

3-4

Chapter 4: BIOS

Chapter 4

BIOS

4-1 Introduction

This chapter describes the Phoenix BIOS™ Setup utility for the X7DCX. The Phoe­nix ROM BIOS is stored in a fl ash chip and can be easily upgraded using a fl oppy
disk-based program.

Note: Due to periodic changes to the BIOS, some settings may have been added
or deleted and might not yet be recorded in this manual. Please refer to the Manual
Download area of our web site at <http://www.supermicro.com> for any changes to
the BIOS that may not be refl ected in this manual.

System BIOS

BIOS is the Basic Input Output System used in all IBM® PC, XT™, AT®, and PS/2®
compatible computers. The Phoenix BIOS utility stores the system parameters,
types of disk drives, video displays, etc. in the CMOS. The CMOS memory requires
very little electrical power. When the computer is turned off, a backup battery pro­vides power to the CMOS Logic, enabling it to retain system parameters. Each time
the computer is powered on, the computer is confi gured with the values stored in
the CMOS Logic by the system BIOS, which gains control at boot up.

How To Change the Confi guration Data

The CMOS information that determines the system parameters may be changed by
entering the BIOS Setup utility. This Setup utility can be accessed by pressing the
<Delete> key at the appropriate time during system boot. (See below.)

Starting the Setup Utility

Normally , the only visible POST (Power On Self Test) routine is the memory test. As
the memory is being tested, press the <Delete> key to enter the main menu of the
BIOS Setup utility. From the main menu, you can access the other setup screens,
such as the Security and Power menus. Beginning with Section 4-3, detailed de­scriptions are given for each parameter setting in the Setup utility.

Warning: Do not shut down or reset the system while updating BIOS

to prevent possible boot failure.

4-1

X7DCX User's Manual

4-2 Running Setup

Default settings are in bold text unless otherwise noted.

The BIOS setup options described in this section are selected by choosing the ap­propriate text from the main BIOS Setup screen. All displayed text is described in
this section, although the screen display is often all you need to understand how
to set the options (see the next page).

When you fi rst power on the computer, the Phoenix BIOS™ is immediately acti-
vated.

While the BIOS is in control, the Setup program can be activated in one of two
ways:

1. By pressing <Delete> immediately after turning the system on, or

2. When the message shown below appears briefl y at the bottom of the screen
during the POST (Power On Self-Test), press the <Delete> key to activate the main
Setup menu:

Press the <Delete> key to enter Setup

4-3 Main BIOS Setup

All main Setup options are described in this section. The main BIOS Setup screen
is displayed below.

Use the Up/Down arrow keys to move among the different settings in each menu.
Use the Left/Right arrow keys to change the options for each setting.

Press the <Esc> key to exit the CMOS Setup Menu. The next section describes in
detail how to navigate through the menus.

Items that use submenus are indicated with the
press the <Enter> key to access the submenu.

Xicon. With the item highlighted,

4-2

Main BIOS Setup Menu

Chapter 4: BIOS

Main Setup Features

System Time

To set the system date and time, key in the correct information in the appropriate
fi elds. Then press the <Enter> key to save the data.

System Date

Using the arrow keys, highlight the month, day and year fi elds, and enter the correct
data. Press the <Enter> key to save the data.

BIOS Date

This fi eld displays the date when this version of BIOS was built.

Legacy Diskette A

This setting allows the user to set the type of fl oppy disk drive installed as diskette A.
The options are Disabled, 360Kb 5.25 in, 1.2MB 5.25 in, 720Kb 3.5 in, 1.44/1.25MB,

3.5 in and 2.88MB 3.5 in.

4-3

X7DCX User's Manual

XSATA Port 0, SATA Port 1, SATA Port 2, SATA Port 3, SATA
Port 4, SATA Port 5, and Ext. Primary Master/Slave

These settings allow the user to set the parameters of the slots indicated above.
Hit <Enter> to activate the following sub-menu screen for detailed options of these
items. Set the correct confi gurations accordingly. The items included in the sub-
menu are:

Type

This option allows the user to select the type of IDE hard drive. The option
Auto will allow the BIOS to automatically confi gure the parameters of the
HDD installed at the connection. Enter a number between 1 to 39 to select a
predetermined HDD type. Select User to allow the user to enter the parameters
of the HDD installed. Select CDROM if a CDROM drive is installed. Select ATAPI
if a removable disk drive is installed.

CHS Format

The following items will be displayed by the BIOS:

TYPE: This item displays the type of IDE or SATA Device.

Cylinders: This item indicates the status of Cylinders.

Headers: This item indicates the number of headers.

Sectors: This item displays the number of sectors.

Maximum Capacity: This item displays the maximum storage capacity of the

system.

LBA Format

The following items will be displayed by the BIOS:

Total Sectors: This item displays the number of total sectors available in the
LBA Format.

Maximum Capacity: This item displays the maximum capacity in the LBA
Format.

Multi-Sector Transfers

This item allows the user to specify the number of sectors per block to be used
in multi-sector transfer. The options are Disabled, 4 Sectors, 8 Sectors, and
16 Sectors.

4-4

Chapter 4: BIOS

LBA Mode Control

This item determines whether the Phoenix BIOS will access the IDE Channel 0
Master Device via the LBA mode. The options are Enabled and Disabled.

32 Bit I/O

This option allows the user to enable or disable the function of 32-bit data transfer.
The options are Enabled and Disabled.

Transfer Mode

This option allows the user to set the transfer mode. The options are Standard,
Fast PIO1, Fast PIO2, Fast PIO3, Fast PIO4, FPIO3/DMA1 and FPIO4/DMA2.

Ultra DMA Mode

This option allows the user to select Ultra DMA Mode. The options are Disabled,
Mode 0, Mode 1, Mode 2, Mode 3, Mode 4, and Mode 5.

Serial ATA

This setting allows the user to enable or disable the function of the Serial ATA. The
options are Disabled and Enabled.

Native Mode Operation

Select the native mode for ATA. The options are: Parallel ATA, Serial ATA, Both,
and Auto.

SATA Controller Mode

Select Compatible to allow the SATA and PATA drives to be automatically-detected
and be placed in the Legacy Mode by the BIOS. Select Enhanced to allow the
SATA and PATA drives to be to be automatically-detected and be placed in the
Native IDE Mode. (Note: The Enhanced mode is supported by the Windows

2000 OS or a later version.)

When the SATA Controller Mode is set to Enhanced, the following items will
display:

Serial ATA (SATA) RAID Enable

Select Enable to enable Serial ATA RAID Functions. (For the Windows OS
environment, use the RAID driver if this feature is set to Enabled. If this item is
set to Disabled, the item-SATA AHCI Enable will be available.) The options are
Enabled and Disabled.

When this item is set to Enabled, the following item will display:

4-5

X7DCX User's Manual

ICH RAID Code Base

Select Intel to enable Intel's SATA RAID fi rmware to confi gure Intel's SATA RAID
settings. The options are Intel and Adaptec.

SATA AHCI

Select Enable to enable the function of Serial ATA Advanced Host Interface. (Take
caution when using this function. This feature is for advanced programmers only.
The options are Enabled and Disabled.)

System Memory

This display informs you how much system memory is recognized as being present
in the system.

Extended Memory

This display informs you how much extended memory is recognized as being
present in the system.

4-6

Chapter 4: BIOS

4-4 Advanced Setup

Choose Advanced from the Phoenix BIOS Setup Utility main menu with the ar­row keys. You should see the following display. The items with a triangle beside
them have sub menus that can be accessed by highlighting the item and pressing
<Enter>.

XBoot Features

Access the submenu to make changes to the following settings.

QuickBoot Mode

If enabled, this feature will speed up the POST (Power-On Self Test) routines by
skipping certain tests after the computer is turned on. The options are Enabled and
Disabled. If Disabled, the POST routine will run at normal speed.

QuietBoot Mode

This setting allows you to Enable or disable the graphic logo screen at the boot­up.

POST Errors

Set to Enabled to display POST Error Messages if an error occurs at the bootup.
If set to Disabled, the system will continue to boot without displaying any error
message even when a boot error occurs.

ACPI Mode

Select Yes to employ ACPI (Advanced Confi guration and Power Interface) power
management on your system. The options are Yes and No.

4-7

X7DCX User's Manual

Power Button Behavior

If set to Instant-Off, the system will power off immediately as soon as the user
hits the power button. If set to 4-sec., the system will power off when the user
presses the power button for 4 seconds or longer. The options are instant-off and
4-sec override.

Resume On Modem Ring

Select On to “wake your system up” when an incoming call is received by your
modem. The options are On and Off.

Power Loss Control

This setting allows you to choose how the system will react when power returns
after an unexpected loss of power. The options are Stay Off, Power On, and Last

State.

Watch Dog

If enabled, this option will automatically reset the system if the system is not active
for more than 5 minutes. The options are Enabled and Disabled.

Summary Screen

This setting allows you to Enable or Disable the summary screen which displays
the system confi guration during bootup.

XMemory Cache

Cache System BIOS Area

This setting allows you to designate a reserve area in the system memory to be used
as a System BIOS buffer to allow the BIOS to write (cache) data into this reserved
memory area. Select Write Protect to enable this function, and this area will be
reserved for BIOS ROM access only. Select Uncached to disable this function and
make this area available for other devices.

Cache Video BIOS Area

This setting allows you to designate a reserve area in the system memory to be
used as a Video BIOS buffer to allow the BIOS to write (cache) data into this
reserved memory area. Select Write Protect to enable the function and this area
will be reserved for Video BIOS ROM access only. Select Uncached to disable this
function and make this area available for other devices.

4-8

Chapter 4: BIOS

Cache Base 0-512K

If enabled, this feature will allow the data stored in the base memory area: block
0-512K to be cached (written) into a buffer, a storage area in the Static DROM
(SDROM) or to be written into L1, L2 cache inside the CPU to speed up CPU
operations. Select Uncached to disable this function. Select Write Through to al­low data to be cached into the buffer and written into the system memory at the
same time. Select Write Protect to prevent data from being written into the base
memory area of Block 0-512K. Select Write Back to allow the CPU to write data
back directly from the buffer without writing data to the System Memory for fast
CPU data processing and operation. The options are Uncached, Write Through,
Write Protect, and Write Back.

Cache Base 512K-640K

If enabled, this feature will allow the data stored in the memory area: 512K-640K
to be cached (written) into a buffer, a storage area in the Static DROM (SDROM)
or written into L1, L2, L3 cache inside the CPU to speed up CPU operations.
Select Uncached to disable this function. Select Write Through to allow data to
be cached into the buffer and written into the system memory at the same time.
Select Write Protect to prevent data from being written into the base memory area
of Block 512-640K. Select Write Back to allow the CPU to write data back directly
from the buffer without writing data to the System Memory for fast CPU data pro­cessing and operation. The options are Uncached, Write Through, Write Protect,
and Write Back.

Cache Extended Memory

If enabled, this feature will allow the data stored in the extended memory area to
be cached (written) into a buffer, a storage area in the Static DROM (SDROM) or
written into L1, L2, L3 cache inside the CPU to speed up CPU operations. Select
Uncached to disable this function. Select Write Through to allow data to be cached
into the buffer and written into the system memory at the same time. Select Write
Protect to prevent data from being written into the extended memory area above
1MB. Select Write Back to allow the CPU to write data back directly from the buffer
without writing data to the System Memory for fast CPU data processing and opera­tion. The options are Uncached, Write Through, Write Protect, and Write Back.

Discrete MTRR Allocation

If enabled, MTRRs (-Memory Type Range Registers) are confi gured as distinct,
separate units and cannot be overlapped. If enabled, the user can achieve better
graphic effects when using a Linux graphic driver that requires the write-combining
confi guration with 4GB or more memory. The options are Enabled and Disabled.

4-9

X7DCX User's Manual

XPCI Confi guration

Access the submenu to make changes to the following settings for PCI devices.

Onboard GLAN-1/Onboard GLAN-2 (Gigabit- LAN) OPROM Confi gure

Select Enabled to allow the system to boot from the GLAN-1 connection or the
GLAN-2 connection. The options are Disabled and Enabled.

Default Primary Video Adapter

This item allows the user to select the Primary Video Adapter between two adapters
instead of selecting among three or more adapters. The options are Other and

Onboard Video.

Reset Confi guration Data

If set to Yes, this setting clears the Extended System Confi guration Data (ESCD)
area. The options are Yes and No.

XSlot1 PCI 33MHz, Slot2 PCI-Exp. x8, Slot3 PCI-Exp. x8,
Slot4 PCI-Exp. x8, Slot5 PCI-Exp. x8, Slot6 PCI-Exp. x8 and
PCI-Exp. x4

Access the submenu to make changes to the following items:

Option ROM Scan

When enabled, this setting will initialize the device expansion ROM. The options
are Enabled and Disabled.

Enable Master

This setting allows you to enable the selected device as the PCI bus master.
The options are Enabled and Disabled.

Latency Timer

This setting allows you to set the clock rate for Bus Master. A high-priority, high­throughout device may benefi t from a greater clock rate. The options are Default,

0020h, 0040h, 0060h, 0080h, 00A0h, 00C0h, and 00E0h. For Unix, Novell and
other Operating Systems, please select the option: other. If a drive fails after
the installation of a new software, you might want to change this setting and
try again. A different OS requires a different Bus Master clock rate.

Large Disk Access Mode

This setting determines how large hard drives are to be accessed. The options are
DOS or Other (for Unix, Novelle NetWare and other operating systems).

4-10

Chapter 4: BIOS

XAdvanced Chipset Control

Access the submenu to make changes to the following settings.

Warning: Take Caution when changing the Advanced settings. An incorrect
setting may cause the system become unstable. When this occurs, reset
the setting to the default setting.

Accelerate MRC

If Enabled, the BIOS will ignore the Memory Reference Code (MRC) when there
is no change to DIMM population in order to speed up system boot. The options
are Enabled and Disabled.

Clock Spectrum Feature

If Enabled, the BIOS will monitor the level of Electromagnetic Interference caused
by the components and will attempt to decrease the interference whenever needed.

The options are Enabled and Disabled.

Crystal Beach Confi guration Enabled

This feature cooperates with the Intel I/O AT (Acceleration T echnology) to accelerate
the performance of TOE devices. (Note: A TOE device is a specialized, dedicated
processor that is installed on an add-on card or a network card to handle some or all
packet processing of this add-on card. For this motherboard, the TOE device is built

inside the ICH9R South Bridge chip.) The options are Enabled and Disabled.

SERR Signal Condition

This setting specifi es the ECC Error conditions that an SERR# is to be asserted.
The options are None, Single Bit, Multiple Bit, and Both.

4GB PCI Hole Granularity

This feature allows you to select the granularity of PCI hole for PCI slots. If MTRRs
are not enough, this option may be used to reduce MTRR occupation. The options
are: 256 MB, 512 MB, 1GB and 2GB.

Channel 0 Rank Sparing/Channel 1 Rank Sparing

Select Enabl e to enable the function of memory sparing for Memory Bus of
Channel 0 /Chann el 1. The opti ons are Ena bled an d Disabled.

Enhanced x8 Detection

Select Enabled to enable Enhanced x8 DRAM UC Error Detection. The options
are Dis abled an d Enabled.

4-11

X7DCX User's Manual

Demand Scrub

Scrubbing is a process that allows the North Bridge to correct correctable memory
errors found on an FBD memory module. When the CPU or I/O issues a demand­read command, and the read data from memory turns out to be a correctable ECC,
it is cor re cted a nd se nt to the o ri gina l sour ce. M em or y is u pdate d as well. S ele ct
Enabled t o use De mand S cr ubbi ng for EC C memo r y co rr ect ion. T he opt ion s are

Enabled and Disabled.

Patrol Scrub

Scrubbing is a process that allows the North Bridge to correct correctable memory
errors found on FBD memory modules. Select Enabled to use Patrol Scrubbing,
a background ECC memory correction activity initiated by the North Bridge to fi nd
and cor rect memo ry erro rs by scanning al l memory mo dules doing si mulated
"RE A Ds" w hil e che ck ing f or ECC er ro rs . Whe n an ECC er ro r is de tect ed dur ing
this pro cess, i t is logge d as a Patrol er ror. A corre ctable e rror is c orre cted and
writ ten back i nto memo ry. The opti ons are Enabl ed and Disabled.

Route Port 80h Cycles to

This feature allows the user to decide which bus to send debug information to. The
options are Disabled, PCI and LPC.

Enabling Multimedia Timer

Select Yes to activate a set of timers that are alternative to the traditional 8254
timers for the OS use. The options are Yes and No.

USB Host Controller 1

Selec t Enabled to ena ble USB Hos t Controll er 1. The options ar e Enabled and
Disabled.

USB Host Controller 2

Selec t Enabled to ena ble USB Ho st Control ler 2. The opt ions are Enabled and
Disabled.

Legacy USB Support

This setting allows you to enable support for Legacy USB devices. The settings
are Enabled and Disabled.

4-12

Chapter 4: BIOS

XAdvanced Processor Options

Access the submenu to make changes to the following settings.

CPU Speed

This is a display that indicates the speed of the installed processor.

Frequency Ratio (Available if supported by the CPU.)

The feature allows the user to set the internal frequency multiplier for the CPU.
The options are: Default, x6, x7, x8, and x.

Core-Multi-Processing (Available if supported by the CPU.)

Set to Enabled to use a processor's Second Core and beyond. (Please refer to
Intel's web site for more information.) The options are Disabled and Enabled.

Machine Checking (Available when supported by the CPU.)

Set to Enable d to enable M achine Che cking sup port to a llow the CPU t o detect
and report hardware errors via a set of model-specifi c registers (MSRs). The
options are Enabled and Disabled.

Thermal Management 2 (Available if supported by the CPU.)

Set to Enabled to use Thermal Management 2 (TM2) which will lower CPU voltage
and frequency when the CPU temperature reaches a predefi ned overheat threshold.
Set to Disabled to use Thermal Manager 1 (TM1), allowing CPU clocking to be
regulated via CPU Internal Clock modulation when the CPU temperature reaches

the overheat threshold.

C1 Enhanced Mode (Available if supported by the CPU.)

Set to Enabled to enable Enhanced Halt State to lower CPU voltage/frequency to
prevent overheat. The options are Enabled and Disabled. (Note: please refer to
Intel’s web site for detailed information.)

Execute Disable Bit (Available if supported by the CPU and the OS.)

Set to Enabled to enable Execute Disable Bit and allow the processor to classify
areas in memory where an application code can execute and where it cannot,
preventing virus infection during an attack. The options are Disabled and Enabled.
Note: For more information regarding hardware/software support for this function,
please refer to Intel's and Microsoft's web sites.

Adjacent Cache Line Prefetch (Available when supported by the CPU.)

The CPU fetc hes t he c ac he lin e for 6 4 by tes i f this o pti on is se t to Dis abl ed. Th e
CPU fetches both cache lin es for 128 bytes as comprised if Enabled. T he optio ns

4-13

X7DCX User's Manual

are Disabled and Enabled.

Hardware Prefetcher (Available when supported by the CPU.)

Set to Enabled to activate the hardware components that are used in conjunction
with software programs to prefetch data in order to shorten execution cycles and
maximize data processing effi ciency. The options are Disabled and Enabled.

Intel <R> Virtualization Technology (Available if supported by the CPU.)

Select Enabled to use the feature of Virtualization Technology to allow one platform
to run multiple operating systems and applications in independent partitions, creating
multiple "virtual" systems in one physical computer. The options are Enabled and
Disabled. Note: If there is any change to this setting, you will need to power off
and restart the system for the change to take effect. Please refer to Intel’s web
site for detailed information.

Intel EIST Support (Available if supported by the CPU.)

Select Enabled to use the Enhanced Intel SpeedStep Technology and allows the
system to automatically adjust processor voltage and core frequency in an effort
to reduce power consumption and heat dissipation. The options are Enabled and
Disabled. Note: Please refer to Intel’s web site for detailed information.

XCPU Cache Control

Access the submenu to make changes to the following settings.

DCU Prefetch

Select Enable to enable DCU (Data Cache Unit) Prefetch support for perfor­mance enhancement. The options are Enabled and Disabled.

IP Prefetch

Select Enable to enable IP Prefetch support to enhance network performance.
The options are Enabled and Disabled.

Direct Cache Access (Available when supported by the CPU.)

Set to Enable to route inbound network IO traffi c directly into processor caches
to reduce memory latency and improve network performance. The options are
Disabled and Enabled.

XI/O Device Confi guration

Access the submenu to make changes to the following settings.

4-14

Chapter 4: BIOS

KBC Clock Input

This setting allows you to select clock frequency for KBC. The options are 6MHz,
8MHz, 12MHz, and 16MHz.

Serial Port A

This setting allows you to assign control of serial port A. The options are Enabled
(user defi ned), Disabled, and Auto (BIOS- or OS- controlled).

Base I/O Address

This setting allows you to select the base I/O address for serial port A. The op­tions are 3F8, 2F8, 3E8, and 2E8.

Interrupt

This setting allows you to select the IRQ (interrupt request) for serial port A. The
options are IRQ3 and IRQ4.

Serial Port B

This setting allows you to assign control of serial port B. The options are Enabled
(user defi ned), Disabled, and Auto (BIOS controlled).

Mode

This setting allows you to set the type of device that will be connected to serial
port B. The options are Normal, IR (for an infrared device) and Ask IR.

Base I/O Address

This setting allows you to select the base I/O address for serial port B. The op­tions are 3F8, 2F8, 3E8 and 2E8.

Interrupt

This setting allows you to select the IRQ (interrupt request) for serial port B. The
options are IRQ3 and IRQ4.

Floppy Disk Controller

This setting allows you to assign control of the fl oppy disk controller. The options
are Enabled (user defi ned), Disabled, and Auto (BIOS and OS controlled).

Base I/O Address

This setting allows you to select the base I/O address for the Floppy port. The
options are Primary and Secondary.

4-15

X7DCX User's Manual

XDMI Event Logging

Access the submenu to make changes to the following settings.

Event Log Validity

This is a display to inform you of the event log validity. It is not a setting.

Event Log Capacity

This is a display to inform you of the event log capacity. It is not a setting.

View DMI Event Log

Highlight this item and press <Enter> to view the contents of the event log.

Event Logging
This setting allows you to Enable or Disable event logging.

ECC Event Logging
This setting allows you to Enable or Disable ECC event logging.

Mark DMI Events as Read

Highlight this item and press <Enter> to mark the DMI events as read.

Clear All DMI Event Logs

Select Yes and press <Enter> to clear all DMI event logs. The options are Yes
and No.

4-16

Chapter 4: BIOS

XConsole Redirection

Access the submenu to make changes to the following settings.

COM Port Address

This item allows you to specify which COM port to direct the remote console to:
Onboard COM A or Onboard COM B. The options are Onboard COM A, Onboard
COM B and Disabled.

Note: The default COM port will be set to COM B when an IPMI card is
installed on the motherboard.

BAUD Rate

This item allows you to set the BAUD rate for the console redirection. The options
are 300, 1200, 2400, 9600, 19.2K, 38.4K, 57.6K, and 115.2K.

Console Type

This item allows you to choose the console redirection type. The options are VT100,
VT100/8bit, PC-ANSI/7bit, PC ANSI, VT100+,

Flow Control

This item allows you to set the fl ow control for the console redirection. The options
are: None, XON/XOFF, and CTS/RTS.

Console Connection

This item allows you to decide how the console redirection is to be connected:
either Direct or Via Modem.

Continue CR after POST

This item allows you to decide whether you want to continue with the console
redirection after POST routines. The options are On and Off.

and VT-UTF8.

4-17

X7DCX User's Manual

XHardware Monitor Logic

CPU Temperature Threshold

This option allows the user to set the CPU Overheat Temperature Threshold. When
the CPU temperature reaches this overheat threshold, the system will slow down
and the CPU fan will be activated to prevent CPU overheat. The options are TCon­trol (the Thermal Control Setting inside the CPU), TControl + 5
Setting + 5

0

C), and TControl + 100 (Thermal Control Setting + 100C).

CPU 1 Temperature/CPU 2 Temperature/System 1 Temperature/ System 2
Temperature

The BIOS will automatically detect and display the temperature settings of the
devices indicated above.

Fan1 - Fan 8

If the feature of Auto Fan Control is enabled, the BIOS will automatically display
the status of the fan as specifi ed.

0

(Thermal Control

Fan Speed Control Modes

This feature allows the user to decide how the system controls the speeds of the
onboard fans. The CPU temperature and the fan speed are correlative. When
the CPU on-die temperature increases, the fan speed will also increase, and vice
versa. If the option is set to 3-pin fan, the fan speed is controlled by voltage. If the
option is set to 4-pin, the fan speed will be controlled by Pulse Width Modulation
(PWM). Select 3-pin if your chassis came with 3-pin fan headers. Select 4-pin if
your chassis came with 4-pin fan headers. Select Workstation if your system is
used as a Workstation. Select Server if your system is used as a Server. Select
Disable to disable the fan speed control function to allow the onboard fans to run
at full speed (12V) at all times. The Options are: 1. Disable, 2. 3-pin (Server), 3.
3-pin (Workstation), 4. 4-pin (Server) and 5. 4-pin (Workstation).

Voltage Monitoring

The following items will be monitored and displayed:
Vcore A:/Vcore B:/-12V/+12V/P1V8/+3.3V/5Vsb/5VDD/P_VTT/Vbat

Note: In the Windows OS environment, the Supero Doctor III settings take prece­dence over the BIOS settings. When fi rst installed, Supero Doctor III adopts the
temperature threshold settings previously set in the BIOS. Any subsequent changes
to these thresholds must be made within Supero Doctor, since the SD III settings
override the BIOS settings. For the Windows OS to adopt the BIOS temperature
threshold settings, please change the SDIII settings to be the same as those set
in the BIOS.

4-18

Chapter 4: BIOS

XIPMI (The option is available only when an IPMI card is
installed in the system.)

IPMI Specifi cation Version: This item displays the current IPMI Version.
BMC Hardware Firmware Version:

Management Controller) Hardware/Firmware Version.

System Event Logging

Select Enabled to enable IPMI Event Logging. When this function is set to Disabled,
the system will continue to log events received via system interface. The options
are Enabled and Disabled.

Clear System Event Logging

Enabling this function to force the BIOS to clear the system event logs during the
next cold boot. The options are Enabled and Disabled.

Existing Event Log Number

This item displays the number of the existing event log.

Event Log Control

This item displays the current BMC (Baseboard

System Firmware Progress

Enabling this function to log POST progress. The options are Enabled and

Disabled.

BIOS POST Errors

Enabling this function to log POST errors. The options are Enabled and
Disabled.

4-19

X7DCX User's Manual

BIOS POST Watch Dog

Set to Enabled to enable POST Watch Dog. The options are Enabled and

Disabled.

OS Boot Watch Dog

Set to Enabled to enable OS Boot Watch Dog. The options are Enabled and

Disabled.

Timer for Loading OS (Minutes)

This feature allows the user to set the time value (in minutes) for the previous
item: OS Boot Watch Dog by keying-in a desired number in the blank. The default
setting is 10 (minutes.) (Please ignore this option when OS Boot Watch Dog is
set to "Disabled".)

Time Out Option

This feature allows the user to determine what action to take in an event of a system
boot failure. The options are No Action, Reset, Power Off and Power Cycles.

XSystem Event Log/System Event Log (List Mode)

These options display the System Event (SEL) Log and System Event (SEL) Log
in List Mode. Items include: SEL (System Event Log) Entry Number, SEL Record
ID, SEL Record Type, Time Stamp, Generator ID, SEL Message Revision, Sensor
Type, Sensor Number, SEL Event Type, Event Description, and SEL Event Data.

System Event Log

4-20

System Event Log (in List Mode)

Chapter 4: BIOS

XRealtime Sensor Data

This feature display information from motherboard sensors, such as temperatures,
fan speeds and voltages of various components.

4-21

X7DCX User's Manual

XIPMI LAN Control

This feature allows the user to confi gure IPMI LAN Control settings.

VLAN Tagging

Select Enabled to enable Virtual LAN(s) for IPMI connections and allow the user to
confi gure VLAN settings. The options are Enabled and Disabled.

VLAN ID

If VLAN Tagging above is set to Enabled, this item allows the user to change the
VLAN ID. If VLAN Tagging is disabled, this item will be ignored by the fi rmware.

IP Address Source

This item allows the user to select the IP address source for the connection. The
options are DHCP (Dynamic Host Controller Protocol), and Static.

This item displays the IP address for the IPMI connection detected.

IP Subnet Mask

This item displays the IP Subnet Mask for the IPMI connection detected.

Default Gateway

This item displays the Default Gateway for the IPMI connection detected.

MAC Address

This item displays the MAC Address for the IPMI connection detected.

Update LAN Settings

Select Yes to allow BIOS update LAN setting. The options are Yes and No.

4-22

Chapter 4: BIOS

4-5 Security

Choose Security from the Phoenix BIOS Setup Utility main menu with the arrow
keys. You should see the following display. Security setting options are displayed by
highlighting the setting using the arrow keys and pressing <Enter>. All Security BIOS
settings are described in this section.

Supervisor Password Is:

This indicates if a supervisor password has been entered for the system. Clear
means such a password has not been used and Set means a supervisor password
has been entered for the system.

User Password Is:

This indicates if a user password has been entered for the system. Clear means
such a password has not been used and Set means a user password has been
entered for the system.

Set Supervisor Password

When the item Set Supervisor Password is highlighted, hit the <Enter> key. When
prompted, type the Supervisor's password in the dialogue box to set or to change
supervisor's password, which allows access to the BIOS.

Set User Password

When the item Set User Password is highlighted, hit the <Enter> key. When
prompted, type the user's password in the dialogue box to set or to change the
user's password, which allows access to the system at boot-up.

4-23

X7DCX User's Manual

Password on Boot

This setting allows you to determine if a password is required for a user to enter
the system at bootup. The options are Enabled (password required) and Disabled
(password not required).

4-6 Boot

Choose Boot from the Phoenix BIOS Setup Utility main menu with the arrow keys.
You should see the following display. See details on how to change the order and
specs of boot devices in the Item Specifi c Help window. All Boot BIOS settings are
described in this section.

Boot List

Candidate
List

Boot Priority Order/Excluded from Boot Orders

The devices included in the boot list section (above) are bootable devices listed in
the sequence of boot order as specifi ed. The boot functions for the devices included
in the candidate list (above) are currently disabled. Use a <+> key or a <-> key to
move the device up or down. Use the <f> key or the <r> key to specify the type of
an USB device, either fi xed or removable. You can select one item from the boot
list and hit the <x> key to remove it from the list of bootable devices (to make its
resource available for other bootable devices). Subsequently, you can select an
item from the candidate list and hit the <x> key to remove it from the candidate
list and put it in the boot list. This item will then become a bootable device. See
details on how to change the priority of boot order of devices in the "Item Specifi c
Help" window.

4-24

Chapter 4: BIOS

4-7 Exit

Choose Exit from the Phoenix BIOS Setup Utility main menu with the arrow keys. Y ou
should see the following display. All Exit BIOS settings are described in this section.

Exit Saving Changes

Highlight this item and hit <Enter> to save any changes you made and to exit the
BIOS Setup utility.

Exit Discarding Changes

Highlight this item and hit <Enter> to exit the BIOS Setup utility without saving any
changes you may have made.

Load Setup Defaults

Highlight this item and hit <Enter> to load the default settings for all items in the
BIOS Setup. These are the safest settings to use.

Discard Changes

Highlight this item and hit <Enter> to discard (cancel) any changes you have made.
You will remain in the Setup utility.

Save Changes

Highlight this item and hit <Enter> to save any changes you made. You will remain
in the Setup utility.

4-25

X7DCX User's Manual

Notes

4-26

Appendix A: BIOS POST Error Codes

Appendix A

BIOS POST Error Codes

This section lists Recoverable POST (Power On Self Test) Error codes for the
Phoenix BIOS.

A-1 Recoverable POST Errors

When a recoverable type of error occurs during POST, the BIOS will display a
POST code that describes the problem. BIOS may also issue one of the following
beep codes:

1 long and two short beeps - video confi guration error
1 repetitive long beep - no memory detected
1 continuous beep/Front Panel Overheat LED On - Motherboard Overheating

A-1

X7DCX User's Manual

Notes

A-2

Appendix B: Installing the Windows OS

Appendix B

Installing the Windows OS

After all the hardware has been installed, you must fi rst confi gure Intel South Bridge
RAID settings before you install the OS and other software drivers. To install the
Linux OS or to confi gure RAID settings, please refer to the OS Installation or RAID
Confi guration User Guides posted on our web site at www.supermicro.com/sup-
port/manuals. Please note that the ICH9R Driver does not support the Windows
2000 OS.

B-1 Installing the Windows XP/2003 OS for systems with
RAID Functions

Insert Microsoft's Windows XP/2003 Setup CD in the CD Driver, and the 1.
system will start booting up from CD.

Press the <F6> key when the message-" Press F6 if you need to install a 2.
third party SCSI or RAID driver" displays.

When the Windows XP/2003 Setup screen appears, press "S" to specify ad-3.
ditional device(s).

Insert the driver diskette-"ITE RAID XP/2003 Driver for IDE" into Drive A: and 4.
press the <Enter> key.

When the Windows XP/2003 Setup screen appears, press "S" to specify ad-5.
ditional device(s).

Insert the driver diskette-"Intel AA RAID XP/2003 Driver for ICH9R" into Drive 6.
A: and press the <Enter> key.

Choose the Intel(R) ICH9R 7. SATA RAID Controller from the list indicated in
the XP/2003 Setup Screen, and press the <Enter> key.

Press the <Enter> key to continue the installation process. (If you need to 8.
specify any additional devices to be installed, do it at this time.) Once all
devices are specifi ed, press the <Enter> key to continue with the installation.

From the Windows XP/2003 Setup screen, press the <Enter> key. The 9.
XP/2003 Setup will automatically load all device fi les and then, continue the
Windows XP/2003 installation. After the OS Installation is completed, the
system will automatically reboot.

B-1

X7DCX User's Manual

B-2 Installing the Windows OS to Systems without RAID
Functions

Insert Microsoft's Windows XP/2000/2003 Setup CD in the CD Driver, and the 1.
system will start booting up from CD.

Press the <F6> key when the message-" Press F6 if you need to install a 2.
third party SCSI or RAID driver" displays.

When the Windows XP/2000/2003 Setup screen appears, press "S" to specify 3.
additional device(s).

Insert the driver diskette-"ITE RAID XP/2000/2003 Driver for IDE" into Drive 4.
A: and press the <Enter> key.

Press the <Enter> key to proceed with the installation process. (If you need 5.
to specify any additional devices to be installed, do it at this time.) Once all
devices are specifi ed, press the <Enter> key to continue with the installation.

From the Windows XP/2000/2003 Setup screen, press the <Enter> key. The 6.
XP/2000/2003 Setup will automatically load all device fi les and then continue
with the Windows XP/2000/2003 installation.

After the Windows XP/2000/2003 OS Installation is completed, the system will 7.
automatically reboot.

Insert the Supermicro Setup CD that came with your motherboard into the CD 8.
Drive during system boot, and the main screen will display.

B-2

Appendix C: Installing Other Software Programs and Drivers

Appendix C

Installing Other Software Programs and Drivers

C-1 Installing Other Drivers

Afte r you've inst alled th e Windows O perati ng System, a sc reen as sho wn below
will app ear. You are ready t o instal l soft ware p rogra ms and dr ivers th at have not
yet been installed. To install t h e s e s o ft wa re p rogram s a n d drivers , click t h e i cons
to the ri ght of the se items .

Driver/Tool Installation Display Screen

Note:

Click t he ic ons sho wing a ha nd wr iting o n the pa per to vi ew the re adme
fi les for e ac h i tem . Cl ic k a c o m pu ter i c o n o n t he r i g ht of an i te m to i nst a ll
an item (fro m top to the bottom) one at a ti me. After installing each

ite m, yo u m u st r e- b o ot t h e sy st e m b e f o re p r o c e e di n g w i t h t h e n ex t
item on the list.

C-1

X7DCX User's Manual

C-2 Confi guring Supero Doctor III

The Supero Doctor III program is a Web-based management tool that supports
remote management capability. It includes Remote and Local Management tools.
The local management is called the SD III Client. The Supero Doctor III program
included on the CDROM that came with your motherboard allows you to monitor
the environment and operations of your system. Supero Doctor III displays crucial
system information such as CPU temperatures, system voltages and fan status.
See the Figure below for a display of the Supero Doctor III interface.

Note 1: Both default username and password are ADMIN.
Note 2: In the Windows OS environment, the Supero Doctor III settings

take precedence over the BIOS settings. When fi rst installed, Supero
Doctor III adopts the temperature threshold settings previously set in the
BIOS. Any subsequent changes to these thresholds must be made within
Supero Doctor, since the SD III settings override the BIOS settings. For
the Windows OS to adopt the BIOS temperature threshold settings, please
change the SDIII settings to be the same as those set in the BIOS.

Supero Doctor III Interface Display Screen-I (Health Information)

C-2

Appendix C: Installing Other Software Programs and Drivers

Supero Doctor III Interface Display Screen-II (Remote Control)

Note: SD III Sof t ware c an be dow nlo aded f rom o ur Web site at: f t p://f tp.

supermicro.com/utility/Supero_D octor_III/. You can also download SDIII
User's Guide at: ht tp://w ww.supermicro.com/PRODUCT/Manuals/SDIII/
UserG uide.pdf. For th e Linux OS, we will st ill recom mend that you use
Supero Doctor II.

C-3

X7DCX User's Manual

Notes

C-4

(Disclaimer Continued)

The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices,
aircraft/emergency communication devices or other critical systems whose failure to perform be reasonably expected to result in signifi cant injury or loss of life or catastrophic
property damage. Accordingly, Supermicro disclaims any and all liability, and should buyer use or sell such products for use in such ultra-hazardous applications, it does so
entirely at its own risk. Furthermore, buyer agrees to fully indemnify, defend and hold Supermicro harmless for and against any and all claims, demands, actions, litigation, and
proceedings of any kind arising out of or related to such ultra-hazardous use or sale.
