Supermicro X7DCL-3, X7DCL-i User Manual

®

SUPER

X7DCL-3

X7DCL-i

USER’S MANUAL

Revision 1.0a

The information in this User’s Manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
makes no commitment to update or to keep current the information in this manual, or to notify any
person or organization of the updates. Please Note: For the most up-to-date version of this

manual, please see our web site at www.supermicro.com.

Super Micro Computer Inc. ("Supermicro") reserves the right to make changes to the product
described in this manual at any time and without notice. This product, including software, if any,
and documentation may not, in whole or in part, be copied, photocopied, reproduced, translated or
reduced to any medium or machine without prior written consent.

IN NO EVENT WILL SUPER MICRO COMPUTER BE LIABLE FOR DIRECT, INDIRECT, SPECIAL,
INCIDENTAL, SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE
OR INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER MICRO COMPUTER SHALL NOT
HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE
PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING
OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between manufacturer and customer shall be governed by the laws of Santa
Clara County in the State of California, USA. The State of California, County of Santa Clara shall
be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for
all claims will not exceed the price paid for the hardware product.

FCC Statement: This equipment has been tested and found to comply with the limits for a Class
A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the manufacturer’s instruction manual, may cause harmful
interference with radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference, in which case you will be required to correct the interference at your
own expense.

California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate
warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate
Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”

WARNING: Handling of lead solder materials used in this
product may expose you to lead, a chemical known to
the State of California to cause birth defects and other

reproductive harm.

Manual Revision 1.0a

Release Date: April 28, 2008

Unless you request and receive written permission from Super Micro Computer, Inc., you may not
copy any part of this document.

Information in this document is subject to change without notice. Other products and companies
referred to herein are trademarks or registered trademarks of their respective companies or mark
holders.

Copyright © 2008 by Super Micro Computer, Inc.
All rights reserved.

Printed in the United States of America

Preface

About This Manual

This manual is written for system integrators, PC technicians and

knowledgeable PC users. It provides information for the installation and use of

the

supports dual Intel Xeon Quad Core/Dual Core 5400/5300/5200/5100 Series

processors (w/771 LGA) with a front side bus speed of up to 1.333 GHz. With

dual 64-bit Xeon Quad Core/Dual Core 5400/5300/5200/5100 Series proces-

sors built- i n, t he X7DC L- 3 / X 7 D CL-i of fers substa nt i al functio n a l i ty enhanc e m ents

to the motherboards based on the Intel Core microarchitecture while remaining

compatible with the IA-32 software. The features supported by this motherboard

include Intel Virtualization Technology, Enhanced Intel SpeedStep technology,

Extended Memory 64 Technology (EM64T) and Native DDR 2 DIMM modules.

These features allow the motherboard to operate at much higher speeds with

lower power consumption in much safer thermal environments than the traditional

motherboards. The X7DCL-3/X7DCL-i is ideal for complex business applications

and servers. Please refer to the motherboard specifi cations pages on our web site

(http://www.supermicro.com/products/motherboard/) for updates. This product is

intended to be professionally installed.

X7DCL-3/X7DCL-i motherboard. The X7DCL-3/X7DCL-i

Preface

Manual Organization

Chapter 1 describes the features, specifications and performance of the

mainboard and provides detailed information about the chipset.

Chapter 2 provides hardware installation instructions. Read this chapter when

installing the processor, memory modules and other hardware components into

the system. If you encounter any problems, see Chapter 3, which describes

troubleshooting procedures for the video, the memory and the system setup

stored in the CMOS.

Chapter 4 includes an introduction to the BIOS, and provides detailed information

on running the CMOS Setup utility.

Appendix A lists BIOS POST Error Codes. Appendix B and Appendix C provide

the Windows OS and other Software Installation Instructions.

Conventions Used in the Manual:

Special attention should be given to the following symbols for proper installation

and to prevent damage done to the components or injury to yourself.

Danger/Caution: Instructions to be strictly followed to prevent catastrophic

system failure or to avoid bodily injury.

Warning: Important information given to ensure proper system installation or

to prevent damage to the components.

Note: Additional Information given to ensure correct system setup.

iii

X7DCL-3/X7DCL-i User's Manual

Table of Contents

Preface

About This Manual ........................................................................................... iii

Manual Organization ........................................................................................ iii

Conventions Used in the Manual ....................................................................... iii

Chapter 1: Introduction

1-1 Overview ......................................................................................................... 1-1

Checklist ................................................................................................... 1-1

Contacting Supermicro ............................................................................. 1-2

X7DCL-3/i Image ....................................................................... 1-3

X7DCL-3/i Layout ...................................................................... 1-4

Quick Reference ...................................................................................... 1-5

Motherboard Features ................................................................................ 1-6

Intel 5100 Chipset: System Block Diagram ............................................. 1-8

1-2 Chipset Overview ........................................................................................... 1-9

1-3 Special Features ........................................................................................... 1-10

1-4 PC Health Monitoring .................................................................................... 1-10

1-5 ACPI Features .............................................................................................. 1-11

1-6 Power Supply ............................................................................................... 1-12

1-7 Super I/O ........................................................................................................ 1-12

Chapter 2: Installation

2-1 Static-Sensitive Devices ................................................................................. 2-1

Precautions ................................................................................................ 2-1

Unpacking ................................................................................................ 2-1

2-2 Processor and Heatsink Installation ............................................................... 2-2

2-3 Installing DIMMs ............................................................................................. 2-6

2-4 Control Panel Connectors and IO Ports ......................................................... 2-8

Back Panel Connectors/IO Ports .................................................................. 2-8

Front Control Panel ....................................................................................... 2-9

Front Control Panel Pin Defi nitions ............................................................. 2-10

NMI Button ............................................................................................. 2-10

Power LED ............................................................................................. 2-10

HDD LED .............................................................................................. 2-11

NIC1/NIC2 LED Indicators ..................................................................... 2-11

Overheat/Fan Fail LED ......................................................................... 2-12

Power Fail LED ........................................................................................ 2-12

Reset Button ......................................................................................... 2-13

iv

Table of Contents

Power Button .......................................................................................... 2-13

2-5 Connecting Cables ....................................................................................... 2-14

ATX Power Connector .......................................................................... 2-14

Processor Power Connector ................................................................. 2-14

Universal Serial Bus (USB) ..................................................................... 2-15

Fan Headers .......................................................................................... 2-16

Chassis Intrusion .................................................................................... 2-16

ATX PS/2 Keyboard and Mouse Ports ..................................................... 2-17

Serial Ports .............................................................................................. 2-17

Wake-On-Ring .......................................................................................... 2-18

Wake-On-LAN .......................................................................................... 2-18

GLAN 1/2 (Ethernet) Ports ....................................................................... 2-19

Speaker/Power LED Header .................................................................. 2-19

Alarm Reset .............................................................................................. 2-20

Power Supply Failure/Power Fault ........................................................... 2-20

VGA Connector ........................................................................................ 2-21

SGPIO Headers ....................................................................................... 2-21

Power SMB (I

BP Power SMB (I

2

C) ...................................................................................... 2-22

2

C) ................................................................................ 2-22

Keylock ..................................................................................................... 2-23

2-6 Jumper Settings ............................................................................................ 2-24

Explanation of Jumpers ......................................................................... 2-24

GLAN Enable/Disable ............................................................................ 2-24

CMOS Clear ............................................................................................ 2-25

Watch Dog ................................................................................................ 2-25

VGA Enable/Disable ................................................................................. 2-26

2

I

C Bus to PCI Slots ................................................................................. 2-26

SAS Enable .............................................................................................. 2-27

Software RAID Enable ............................................................................. 2-27

2-7 Onboard LED Indicators ............................................................................... 2-28

GLAN LEDs .............................................................................................. 2-28

Onboard Power LED ................................................................................ 2-28

System Status LED .................................................................................. 2-29

CPU_VRM Overheat LEDs ...................................................................... 2-29

System Status LED .................................................................................. 2-30

2-8 Floppy, SIMLC IPMI and Hard Disk Drive Connections ............................... 2-31

Floppy Connector .................................................................................... 2-31

IDE Connector .......................................................................................... 2-32

SIMLC IPMI Slot ...................................................................................... 2-32

v

X7DCL-3/X7DCL-i User's Manual

Chapter 3: Troubleshooting

3-1 Troubleshooting Procedures ........................................................................... 3-1

Before Power On ....................................................................................... 3-1

No Power ................................................................................................... 3-1

No Video .................................................................................................. 3-1

Losing the System’s Setup Confi guration ................................................ 3-1

Memory Errors ........................................................................................... 3-2

3-2 Technical Support Procedures ....................................................................... 3-2

3-3 Frequently Asked Questions .......................................................................... 3-3

3-4 Returning Merchandise for Service ................................................................. 3-3

Chapter 4: BIOS

4-1 Introduction ....................................................................................................... 4-1

4-2 Running Setup ................................................................................................. 4-2

4-3 Main BIOS Setup ............................................................................................. 4-2

4-4 Advanced Setup ............................................................................................... 4-7

4-5 Security Setup ............................................................................................... 4-20

4-6 Boot Setup ...................................................................................................... 4-21

4-7 Exit .................................................................................................................. 4-22

Appendices:

Appendix A: BIOS POST Error Beep Codes ............................................................. A-1

Appendix B: Installing the Windows OS .................................................................... B-1

Appendix C: Installing Other Software Programs and Drivers ..................................C-1

vi

Chapter 1: Introduction

Chapter 1

Introduction

1-1 Overview

Checklist

Congratulations on purchasing your computer motherboard from an acknowledged

leader in the industry. Supermicro boards are designed with the utmost attention to

detail to provide you with the highest standards in quality and performance. Check

that the following items have all been included with your motherboard. If anything

listed here is damaged or missing, contact your retailer.

The following items are included in the Retail Box.

One (1) Super Micro Mainboard

One (1) ribbon cable for IDE devices (CBL-0036L-2)

One (1) fl oppy ribbon cable (CBL-0022L)

Eight (8) SATA cables (CBL-0044L) (X7DCL-3)

Six (6) SATA cables (CBL-0044L) (X7DCL-i)

One (1) I/O backpanel shield (CSE-PT07L)

One (1) CPU Retention Module (SKT-0159)

One (1) Supermicro CD containing drivers, software and utilities (CDR-X7)

One (1) User's/BIOS Manual (MNL-0957)

Optional

(For SAS HostRAID 5)

One (1) I-Button (AOC-iBUTTON 68) (X7DCL-3)

1-1

X7DCL-3/X7DCL-i User's Manual

Contacting Supermicro

Headquarters

Address: Super Micro Computer, Inc.

980 Rock Ave.

San Jose, CA 95131 U.S.A.

Tel: [phone]

Fax: [phone]

Email: [e-mail] (General Information)

[e-mail] (Technical Support)

Web Site: www.supermicro.com

Europe

Address: Super Micro Computer B.V.

Het Sterrenbeeld 28, 5215 ML

's-Hertogenbosch, The Netherlands

Tel: [phone]

Fax: [phone]

Email: [e-mail] (General Information)

[e-mail] (Technical Support)

[e-mail] (Customer Support)

Asia-Pacifi c

Address: Super Micro, Taiwan

4F, No. 232-1, Liancheng Rd.

Chung-Ho 235, Taipei County

Taiwan, R.O.C.

Tel: [phone]

Fax: [phone]

Web Site: www.supermicro.com.tw

Technical Support:

Email: [e-mail]

Tel: [phone], ext.132 or 139

1-2

X7DCL-3/X7DCL-i Image

Chapter 1: Introduction

Note: The drawings and pictures shown in this manual were based on the

latest PCB Revision available at the time of publishing of the manual. The

motherboard you’ve received may or may not look exactly the same as the

graphics shown in the manual.

1-3

X7DCL-3/X7DCL-i User's Manual

X7DCL-3/X7DCL-i Motherboard Layout

(not drawn to scale)

KB/MS

USB0/1

JBS1

COM1

JCOM1

JVGA1

VGA

JKM1

JPWF1

JAR

JPW1

8-Pin PWR

24-Pin PWR

DIMM2A

DIMM1A

DIMM2B

DIMM1B

DIMM2C

DIMM1C

2

JPW2

X7DCL-3/i

LAN1

JLAN1

JPL2

I-Button

LAN

CTRL

JIBTN1

JEXP1

Slot6 PCI-E x8

Intel

North Bridge

SP1

Buzzer

5100

LAN2

JLAN2

FAN5

FAN6

LAN

CTRL

C1

SMB_PS

JPI

Fan 1

JP2

JP1

CPU1

CPU2

CPU1 VRM OH LED

LED5

Fan 2

LED6

CPU2 VRM OH LED

Fan 3

BIOS

ITE

CTRL

Intel

ICH9R

South Bridge

JBT1

Battery

J10

J9

USB4/5

JIPMI

BPI2C

JPA2

USB2/3

JUSB3
J5

SATA5

SAS-GPIO1

SAS-GPIO0

JUSB2

SATA-GPIO0

J7

SATA3

SATA4

JD1

SAS1

SAS0

J8

SATA-GPIO1

SATA2

CTRL

SAS3

SAS2

LSI

SAS

SATA1

SAS4

SATA0

SAS5

PWR LED

LED3

JPA1

LED1

SAS6

SAS7

JFDD1

JL1

FP CTRL

JF1

Floppy

IDE

JIDE1

Fan 4

JPL1

VGA

CTRL

S I/O

COM2

Notes:

JPG1

JWOR1

JCOM2

JI2C2

JPCI3

JPCI2

JWD1

JPCI1

JKEY1

JEXP2

Slot5 PCI-E x8

JI2C1

Slot4 PCI-E x4(in x8 slot)

Slot3 PCI 33MHz

Slot2 PCI 33MHz

JWOL1

Slot1 PCI 33MHz

SIMLC

LED4

System Status LED

1. Jumpers not indicated are for test purposes only.

2. See Chapter 2 for detailed information on jumpers, I/O ports and JF1 front panel

connections.

3. " " indicates the location of Pin 1.

4. When LED3 is on, make sure to unplug the power cable before removing or

installing components.

5. All features and components related to SAS are available on the X7DCL-3 only,

including SAS Connectors, the LSI SAS HostRAID Controller, and the I-Button

socket. I-Button is used to support RAID 5 (optional.)

1-4

Chapter 1: Introduction

Quick Reference (X7DCL-3/X7DCL-i)

Jumper Description Default Setting

JBT1 CMOS Clear See Chapter 2

JI2C1/JI2C2 SMB to PCI/PCI-Exp Slots Open (Disabled)

JPG1 VGA Enable Pins 1-2 (Enabled)

JPA1 (Note) SAS Enable Pins 1-2 (Enabled)

JPA2 (Note) Software RAID/IT RAID Mode Closed (Software RAID)

JPL1/ JPL2 GLAN1/GLAN2 Enable Pins 1-2 (Enabled)

JWD Watch Dog Pins 1-2 (Reset)

Connector Description

2

BPI

C Back Panel Power System Management (I2C) Header

COM1/COM2 COM1/COM2 Serial Port and Header

FAN 1-6 Fans 1-2: CPU Fans, Fans 3-6: System cooling fans

Floppy Floppy Disk Drive Connector (JFDD1)

FP Control Front Control Panel Connector (JF1)

IDE IDE Hard Drive

J7/J8/9/10 Serial-Links General Purpose Input/Output Headers

(J7/J8: SATA T-SGPIO 0/1, J9/J10: SAS T-SGPIO 0/1)

JAR1 Alarm Reset Header

JD1 Power LED(pins1-3)/SpeakerHeader (pins 4-7)

JIBTN1 I-Button Socket

JL1 Chassis Intrusion Header

JPW1 +12V 8-pin PWR

JPW2 Primary 24-Pin ATX PWR Connector

JPWF1 Power Supply Failure (See Chapter 2)

JUSB1/JUSB2/3 BP USB0/1 (JUSB1), FP USB2/3/4/5 (JUSB2/3)

JWOL Wake-on-LAN Header

JWOR Wake-on-Ring Header

Keylock Keylock Header (JKEY1)

LAN1/2 G-bit Ethernet Ports 1/2

PWR I

SAS0-SAS7 (Note) Serial Attached SCSI Connectors (#0-#7) (X7DCL-3)

SATA0-SATA5 SATA 0-5 Connectors

SIMLC IPMI SIMLC Slot (JIPMI)

VGA VGA Por t

2

C Power System Management (I2C) Header (JPI2C1)

LED Indicator Description

LED1 SAS LED

LED3/LED4 Power LED (LED3)/System Status LED (LED4)

LED5/LED6 CPU1/CPU2 VRM Overheat (respectively)

Note: SAS is available on the X7DCL-3 only.

1-5

X7DCL-3/X7DCL-i User's Manual

Motherboard Features

CPU

• Dual Intel

®

64-bit Xeon LGA 771 Quad Core/Dual Core 5400/5300/5200/5100

Series processors at a front side bus speed of 1333 MHz/1066 MHz

Memory

• Six 240-pin DIMM sockets with support up to 32 GB Single-Rank, Registered/

ECC DDR2 667/533 Memory (See Section 2-3 in Chapter 2 for DIMM Slot

Population.)

Chipset

• Intel 5100 chipset, including: the 5100 Memory Control Hub (MCH) and the

ICH9R South Bridge

Expansion Slots

• Two PCI-E x8 slot (Slot 5/Slot 6), and one in PCI-E x4 (in x8) slot (Slot 4)

• Three 32-bit PCI 33 MHz slot (Slot 1/Slot 2/Slot 3)

• One SIMLC IPMI Slot (Slot 0)

BIOS

• 8 Mb Phoenix

®

Flash ROM

• DMI 2.3, PCI 2.2, ACPI 1.0, Plug and Play (PnP), USB Keyboard support,

Hardware BIOS Virus Protection and SMBIOS 2.3

PC Health Monitoring

• Onboard voltage monitors for CPU core voltage, Memory voltage, +1.8V, +3.3V,

+5V, +12V, −12V, +3.3V standby, +5V standby and VBAT)

• Fan status monitor with fi rmware control

• CPU/chassis temperature monitors

• Low noise fan speed control

• Platform Environment Control Interface (PECI) ready

• CPU fan auto-off in sleep mode

• Pulse Width Modulation (PWM) fan control

2

• I

C temperature sensing logic

• Thermal Monitor 2 (TM2) support

• CPU slow-down on temperature overheat

• CPU thermal trip support for processor protection

• Power-up mode control for recovery from AC power loss

• Chassis intrusion detection

• System resource alert via Supero Doctor III

1-6

Chapter 1: Introduction

ACPI Features

• Slow blinking LED for suspend state indicator

• Main switch override mechanism

• ACPI Power Management

• Power-on mode for power recovery

Onboard I/O

• Six SATA ports support RAID 0, 1, 10 and 5 (in the Windows OS environ-

ment)

• Eight SAS ports supports RAID 0, 1, 10 and 5. (For X7DCL-3 only)

• One SIMLC IPMI 2.0 socket

• Intel 82573V and 82573L LAN chips support two Giga-bit LAN ports

• One EIDE Ultra DMA/100 bus master interface

• One fl oppy port interface

• Two COM ports(1 header, 1 port)

• Up to six USB 2.0 (Universal Serial Bus) (2 ports, 4 Headers)

• XGI Volari Z9s 32 MB Graphic Controller

• Super I/O: Winbond W83627HG

Other

• External modem ring-on

• Wake-on-LAN (WOL)

• Wake-on-Ring (WOR)

• Console redirection

• Onboard Fan Speed Control by Thermal Management via BIOS

CD/Diskette Utilities

• Device drivers and Software

Dimensions

• ATX 12.05" x 10" (306.1mm x 254 mm)

1-7

X7DCL-3/X7DCL-i User's Manual

#7

#6

#5

#4

#3

#2

SAS

#1

#0

3.0 Gb/S

RJ45

RJ45

ISL6312A

LSI 1068E

82573V

82573L

PCI-EXP x8

PCI-E x8

PCI-EXP x8

PCI-E x8

PCI-EXP x8

PCI-EXP x1

PCI-EXP x1

PROCESSOR#2

1067/1333

MT/S

PORT

#2,3

PORT

#4,5

PORT

#6,7

LANE5

LANE6

PROCESSOR#1

MCH

Intel 5100

PORT

#0

PCIE X4

DMI

ICH9R

1067/1333

MT/S

#0-2

#0-1

#0-3

DDR2 667

3.0 Gb/S

#1-2

#1-1

ISL6312A

#1-3

DDR2 667

#3

#2

#1

#0

#5

#4

SATA

LANE1/2/3/4

PCI-E x8 Slot

DDR2 SDRAM 32MB

VGA
CONN

VGA

Volari Z9S

IT8213F

PCI-33

PCI-33

PCI-33

IDE

PCI-E x4Signal

PCI 33MHz

LPC

SIO

W83627HG

MS

KB

COM1

External

FWH

USB 2.0

COM2

INTERNAL/SOL

#0

#1

#2

#3

#5

#4

USB

Block Diagram of the Intel 5100 Chipset

Note: This is a general block diagram. Please see the previous Motherboard

Features pages for details on the features of each motherboard.

1-8

Chapter 1: Introduction

1-2 Chipset and Processor Features Overview

Built upon the functionality and the capability of the Intel 5100 chipset, the X7DCL-

3/X7DCL-i motherboard provides the performance and feature set required for

dual processor-based high-end servers with confi guration options optimized for

intensive computing, high energy-effi ciency and complex business applications.

The 5100 chipset supports single or dual Intel Xeon 64-bit Quad Core/Dual Core

5400/5300/5200/5100 Series processors with front side bus speeds of up to 1.333

GHz. The chipset consists of the 5100 Memory Controller Hub (MCH), Intel I/O

Controller Hub (ICH9R) and the I/O subsystem.

The 5100 Memory Controller Hub (MCH)

The Intel 5100 MCH chip is designed for symmetric multiprocessing across two

independent front side bus interfaces. Each front side bus uses a 64-bit wide,

1066/1333 MTS data bus capable of transferring data at 8.5/10.6 GB/s for a total

bandwidth of 17/21.3 GB/s. The MCH supports a 36-bit wide address bus and up

to six DDR2 667 MHz/533 MHz DIMM modules, providing a total memory capac-

ity of up to 32 GB.

The 5100 MCH also provides six x4 PCI-Express interfaces and one x4 DMI

Interface to the ICH9R. Each PCI Express port on the MCH provides 4 GB/s bi-

directional bandwidth if confi gured as a x8 port, or 2 GB/s bi-directional bandwidth

if confi gured as a x4 port.

The Ninth Generation I/O Controller Hub (ICH9)

The I/O Controller ICH9R provides the data buffering and interface arbitration

required for the system to operate effi ciently. It also provides the bandwidth needed

for the system to maintain its peak performance. The Direct Media Interface (DMI)

provides the connection between the MCH and the ICH9R. The ICH9R supports

up to six PCI-Express x1 slots, six Serial ATA ports and twelve USB 2.0 ports.

In addition, the ICH9R offers the Intel Matrix Storage Technology which provides

various RAID options for data protection and rapid data access. It also supports the

next generation of client management through the use of PROActive technology in

conjunction with Intel's next generation Gigabit Ethernet controllers.

1-9

X7DCL-3/X7DCL-i User's Manual

1-3 Special Features

Recovery from AC Power Loss

BIOS provides a setting for you to determine how the system will respond when

AC power is lost and then restored to the system. You can choose for the system

to remain powered off (in which case you must hit the power switch to turn it back

on) or for it to automatically return to a power-on state. See the Power Lost Control

setting in the Advanced BIOS Setup section to change this setting. The default

setting is Last State.

1-4 PC Health Monitoring

This section describes the PC health monitoring features of the X7DCL-3/X7DCL-

i. All have an onboard System Hardware Monitor chip that supports PC health

monitoring.

Onboard Voltage Monitors

An onboard voltage monitor will scan for the CPU Cores, Chipset Voltage, +1.8V,

+3.3V, +5V, +12V, -12V, +3.3V Standby, +5V Standby and VBAT continuously.

Once a voltage becomes unstable, a warning is given or an error message is sent

to the screen. Users can adjust the voltage thresholds to defi ne the sensitivity

of the voltage monitor.

Fan Status Monitor with Firmware Control

The PC health monitor can check the RPM status of the cooling fans. The onboard

CPU and chassis fans are controlled by Thermal Management via BIOS (under

Hardware Monitoring in the Advanced Setting).

Environmental Temperature Control

The thermal control sensor monitors the CPU temperature in real time and will turn

on the thermal control fan whenever the CPU temperature exceeds a user-defi ned

threshold. The overheat circuitry runs independently from the CPU. Once it detects

that the CPU temperature is too high, it will automatically turn on the thermal fan

control to prevent any overheat damage to the CPU. The onboard chassis thermal

circuitry can monitor the overall system temperature and alert users when the chas-

sis temperature is too high.

CPU Overheat LED and Control

This feature is available when the user enables the CPU overheat warning function

in the BIOS. This allows the user to defi ne an overheat temperature. When the

CPU temperature reaches the pre-defi ned overheat threshold, both the overheat

fan and the warning LED are triggered.

1-10

Chapter 1: Introduction

System Resource Alert

This feature is available when used with Supero Doctor III in the Windows OS

environment or used with Supero Doctor II in Linux. Supero Doctor is used to

notify the user of certain system events. For example, if the system is running

low on virtual memory and there is insuffi cient hard drive space for saving the

data, you can be alerted of the potential problem. You can also confi gure Supero

Doctor to provide you with warnings when the system temperature goes beyond

a pre-defi ned range.

1-5 ACPI Features

ACPI stands for Advanced Confi guration and Power Interface. The ACPI specifi -

cation defi nes a fl exible and abstract hardware interface that provides a standard

way to integrate power management features throughout a PC system, including its

hardware, operating system and application software. This enables the system to

automatically turn on and off peripherals such as CD-ROMs, network cards, hard

disk drives and printers. This also includes consumer devices connected to the PC

such as VCRs, TVs, telephones and stereos.

In addition to enabling operating system-directed power management, ACPI

provides a generic system event mechanism for Plug and Play and an operating

system-independent interface for confi guration control. ACPI leverages the Plug

and Play BIOS data structures while providing a processor architecture-independent

implementation that is compatible with Windows 2000, Windows XP and Windows

2003 Servers.

Slow Blinking LED for Suspend-State Indicator

When the CPU goes into a suspend state, the chassis power LED will start blinking

to indicate that the CPU is in suspend mode. When the user presses any key, the

CPU will wake-up and the LED will automatically stop blinking and remain on.

Main Switch Override Mechanism

When an ATX power supply is used, the power button can function as a system

suspend button to make the system enter a SoftOff state. The monitor will be

suspended and the hard drive will spin down. Pressing the power button again

will cause the whole system to wake-up. During the SoftOff state, the ATX power

supply provides power to keep the required circuitry in the system alive. In case

the system malfunctions and you want to turn off the power, just press and hold

the power button for 4 seconds. This option can be set in the Power section of

the BIOS Setup routine.

1-11

X7DCL-3/X7DCL-i User's Manual

External Modem Ring-On

Wake-up events can be triggered by a device such as the external modem ringing

when the system is in the Standby or Off state. Note that external modem ring-on

can only be used with an ATX 2.01 (or above) compliant power supply.

Wake-On-LAN is defi ned as the ability of a management application to remotely

power up a computer that is powered off. Remote PC setup, up-dates and asset

tracking can occur after hours and on weekends so that daily LAN traffi c is kept to

a minimum and users are not interrupted. The motherboard has a 3-pin header

(WOL) to connect to the 3-pin header on a Network Interface Card (NIC) that has

WOL capability. In addition, an onboard LAN controller can also support WOL

without any connection to the WOL header. The 3-pin WOL header is to be used

with a LAN add-on card only.

Note: Wake-On-LAN requires an ATX 2.01 (or above) compliant power supply.

1-6 Power Supply

As with all computer products, a stable power source is necessary for proper and

reliable operation. It is even more important for processors that have high CPU

clock rates.

The X7DCL-3/X7DCL-i can only accommodate 24-pin ATX power supply. Although

most power supplies generally meet the specifi cations required by the motherboard,

some are inadequate. You should use one that will supply at least 400W of power.

In addition, the 12V 8-pin is also required for adequate power supply to the CPU.

Also your power supply must supply 1.5A for the Ethernet ports.

It is strongly recommended that you use a high quality power supply that meets ATX

power supply Specifi cation 2.02 or above. It must also be SSI compliant (info at

http://www.ssiforum.org/). Additionally, in areas where noisy power transmission is

present, you may choose to install a line fi lter to shield the computer from noise. It

is recommended that you also install a power surge protector to help avoid problems

caused by power surges.

1-7 Super I/O

The disk drive adapter functions of the Super I/O chip include a fl oppy disk drive

controller that is compatible with industry standard 82077/765, a data separator,

write pre-compensation circuitry, decode logic, data rate selection, a clock genera-

tor, drive interface control logic and interrupt and DMA logic. The wide range of

functions integrated onto the Super I/O greatly reduces the number of components

required for interfacing with fl oppy disk drives. The Super I/O supports 360 K, 720

1-12

Chapter 1: Introduction

K, 1.2 M, 1.44 M or 2.88 M disk drives and data transfer rates of 250 Kb/s, 500 Kb/s

or 1 Mb/s. It also provides two high-speed, 16550 compatible serial communication

ports (UARTs). Both UARTs provide legacy speed with baud rate of up to 115.2

Kbps as well as an advanced speed with baud rates of 250 K, 500 K, or 1 Mb/s,

which support higher speed modems.

The Super I/O supports one PC-compatible printer port (SPP), Bi-directional Printer

Port (BPP), Enhanced Parallel Port (EPP) or Extended Capabilities Port (ECP).

The Super I/O provides functions that comply with ACPI (Advanced Confi guration

and Power Interface), which includes support of legacy and ACPI power manage-

ment through an SMI or SCI function pin. It also features auto power management

to reduce power consumption.

1-13

X7DCL-3/X7DCL-i User's Manual

Notes

1-14

Chapter 2: Installation

Chapter 2

Installation

2-1 Static-Sensitive Devices

Electro-Static-Discharge (ESD) can damage electronic com ponents. To prevent

damage to your system board, it is important to handle it very carefully. The fol-

lowing measures are generally suffi cient to protect your equipment from ESD.

Precautions

• Use a grounded wrist strap designed to prevent static discharge.

• Touch a grounded metal object before removing the board from the antistatic

bag.

• Handle the board by its edges only; do not touch its components, peripheral

chips, memory modules or gold contacts.

• When handling chips or modules, avoid touching their pins.

• Put the motherboard and peripherals back into their antistatic bags when not

in use.

• For grounding purposes, make sure your computer chassis provides excellent

conductivity between the power supply, the case, the mounting fasteners and

the motherboard.

• Use only the correct type of onboard CMOS battery as specifi ed by the

manufacturer. Do not install the onboard battery upside down to avoid possible

explosion.

Unpacking

The motherboard is shipped in antistatic packaging to avoid static damage. When

unpacking the board, make sure the person handling it is static protected.

2-1

X7DCL-3/X7DCL-i User's Manual

!

2-2 Processor and Heatsink Fan Installation

When handling the processor package, avoid placing direct pressure

on the label area of the fan.

Notes:

Always connect the power cord last and always remove it before adding, re-

•

moving or changing any components. Make sure that you install the processor

into the CPU socket before you install the CPU heatsink.

Intel's boxed Xeon CPU package contains the CPU fan and heatsink assembly.

•

If you buy a CPU separately, make sure that you use only Intel-certifi ed multi-

directional heatsink and fan.

Make sure to install the motherboard into the chassis before you install the

•

CPU heatsink and fan.

When purchasing a motherboard with an LGA 771 CPU Socket, make sure

•

that the CPU plastic cap is in place, and none of the CPU Socket pins are

bent; otherwise, contact the retailer immediately.

Refer to the Chipset/MB Features Section for more details on CPU support.

•

Installing the LGA771 Processor

Load Lever

Press the load lever to release

1.

the load plate, which covers the

CPU socket, from its locking

position.

Gently lift the load lever to open

2.

the load plate.

PnP Cap on

top of the

Load Plate

Load Plate

(with PnP Cap

attached)

2-2

Chapter 2: Installation

!

Loading the Processor into the Socket

Use your thumb and your index

1.

fi nger to hold the CPU at the North

Center Edge and the South Center

Edge of the CPU.

Align CPU Pin1 (the CPU corner

2.

marked with a triangle) against the

socket corner that is marked with a

triangle cutout.

Align the CPU key that is the semi-

3.

circle cutout below a gold dot against

the socket key, the notch on the

same side of the triangle cutout on

the socket.

Once aligned, carefully lower the

4.

CPU straight down to the socket.

(Do not drop the CPU on the socket.

Do not move the CPU horizontally

or vertically. Do not rub the CPU

against the surface or against any

pins of the socket to avoid damage

to the CPU or the socket.)

Socket Key

(Socket Notch)

CPU Key (semi-

circle cutout)

below the circle.

Corner with a

triangle cutout

North Center Edge

South Center Edge

gold dot

CPU Pin1

Load Lever

With the CPU installed in the socket,

5.

inspect the four corners of the

CPU to make sure that the CPU is

properly installed. Then, close the

load plate.

Use your thumb to gently push the

6.

load lever down to lock it.

If the CPU is properly installed into

7.

the socket, the plastic cap will be

automatically released from the load

plate when the clip is pushed in the

clip lock. Remove the plastic cap

from the motherboard.

Warning: Please save the plastic

PnP cap. The motherboard must be

shipped with the PnP cap properly in-

stalled to protect socket pins. Shipment

without the PnP cap properly installed will

cause damage to the socket pins.

CPU in the CPU socket

Plastic cap

is released

from the

load plate

if the CPU

properly in-

stalled.

2-3

X7DCL-3/X7DCL-i User's Manual

!

Installing the Heatsink

Do not apply any thermal grease to the

1.

heatsink or the CPU die; the required

amount has already been applied.

Place the heatsink on top of the CPU

2.

so that the four mounting holes are

aligned with those on the retention

mechanism.

Screw in two diagonal screws (ie the

3.

#1 and the #2 screws) until just snug (-

do not fully tighten the screws to avoid

possible damage to the CPU.)

Finish the installation by fully tighten-

4.

ing all four screws.

CEK Passive Heatsink

Screw#1 Screw#2

Screw#1

To Un- install th e Hea tsi nk

Warning: We do not recommend that

the CPU or the heatsink be removed.

However, if you do need to uninstall the

heatsink, please follow the instructions on

the next page to uninstall the heatsink to

prevent damage done to the CPU or the

CPU socket.

Screw#2

2-4

Unscrew and remove the heatsink screws

1.

from the motherboard in the sequence as

shown in the picture on the right.

Hold the heatsink as shown in the pic-

2.

ture on the right and gently wriggle the

heatsink to loosen it from the CPU. (Do

not use excessive force when wriggling

the heatsink!!)

Once the heatsink is loosened, remove

3.

the heatsink from the CPU socket.

Clean the surface of the CPU and the

4.

heatsink to get rid of the old thermal

grease. Reapply the proper amount of

thermal grease on the surface before you

re-install the CPU and the heatsink.

Chapter 2: Installation

Mounting the Motherboard in the Chassis

All motherboards have standard mounting holes to fi t different types of chassis.

Make sure that the locations of all the mounting holes for both motherboard and

chassis match. Make sure that the metal standoffs click in or are screwed in

tightly. Then, use a screwdriver to secure the motherboard onto the motherboard

tray. (Note: some components are very close to the mounting holes. Please take

precautionary measures to prevent damage done to these components when you

install the motherboard into the chassis.)

2-5

X7DCL-3/X7DCL-i User's Manual

2-3 Installing DIMMs

Note: Check the SuperMicro web site for recommended memory modules.

CAUTION

Exercise extreme care when installing or removing DIMM

modules to prevent any possible damage. Also note that the

memory is interleaved to improve performance (see step 1).

DIMM Installation

1. Insert the desired number of DIMMs into the memory slots, starting with DIMM

#1A. The memory scheme is interleaved, so you must install two modules

at a time, beginning with DIMM 1A, DIMM 2A, then DIMM 1B, DIMM 2B, and

DIMM 1C, DIMM 2C. (See the Memory Installation Table Below.)

2. Insert each DIM M mo d ule ver tically into i t s slot. Pay attention to t he n otch along

the bottom of the module to prevent inserting the DIMM module incorrectly.

3. Gently press down on the DIMM module until it snaps into place in the slot.

Repeat for all modules (See step 1 above.)

Memory Support

The X7DCL-3/X7DCL-i supports up to 32 GB Single-Rank, Registered ECC DDR2

667/533 in 6 DIMMs. Populating DIMM modules with pairs of memory modules

of the same size and same type will result in Interleaved Memory which will

improve memory performance.

Note 1: For the PCB Rev. 1.1 motherboard, Slots 1A and 2A support Dual-Rank

modules; however, Slots 1B, 2B, 1C and 2C support Single-Rank memory only.

The PCB Rev. 1.1a board supports 6 Dual-Rank or 6 Single-Rank modules.

No. of

DIMMs

2DIMMs DIMM 1A ------ ------ DIMM 2A ------ -----­4DIMMs DIMM 1A DIMM 1B ------ DIMM 2A DIMM 2B -----­6DIMMs DIMM 1A DIMM 1B DIMM 1C DIMM 2A DIMM 2B DIMM 2C

(Notes: i. DIMM slot# specified: DIMM slot to be populated; “---“: DIMM slot not to be
populated. ii. Both Registered ECC DDR2 667MHz and 533 MHz DIMMs are supported;
however, you need to use the memory modules of the same speed and of the same type on
a motherboard. iii. For memory to work properly, you need to follow the restrictions listed
above. )

Optimized DIMM Population Configurations

Channel 0 Channel 1

Note 2: Due to OS limitations, some operating systems may not show more than

4 GB of memory.

Note 3: Due to memory allocation to system devices, memory remaining available

for operational use will be reduced when 4 GB of RAM is used. The reduction in

memory availability is disproportional. (Refer to the following Memory Availability

Table for details.

2-6

Possible System Memory Allocation & Availability

Chapter 2: Installation

System Device Size Physical Memory

Firmware Hub fl ash memory (System BIOS) 1 MB 3.99

Local APIC 4 KB 3.99

Area Reserved for the chipset 2 MB 3.99

I/O APIC (4 Kbytes) 4 KB 3.99

PCI Enumeration Area 1 256 MB 3.76

PCI Express (256 MB) 256 MB 3.51

PCI Enumeration Area 2 (if needed) -Aligned on 256­MB boundary-

VGA Memory 16 MB 2.85

TSEG 1 MB 2.84

Memory available to OS and other applications 2.84

512 MB 3.01

Remaining (-Available)
(4 GB Total System Memory)

Figure 2-2. Installing and Removing DIMMs

DDR2 DIMM

X7DCL-3/i

To R e move :

Use your thumbs to

gently push the re-

lease tabs near both

ends of the module

to release it from the

slot.

To I nstall : Insert module vertically and press

down until it snaps into place. Pay attention to the

alignment notch at the bottom.

Top View of DDR2 Slot

2-7

X7DCL-3/X7DCL-i User's Manual

123

4

567

8

2-4 Control Panel Connectors/IO Ports

The I/O ports are color coded in conformance with the PC 99 specifi cation. See
Figure 2-3 below for the colors and locations of the various I/O ports.

Back Panel Connectors/IO Ports

X7DCL-3/i

Back Panel I/O Port Locations and Defi nitions

Back Panel Connectors

1. Keyboard (Purple)

2. PS/2 Mouse (Green)

3. Back Panel USB Port 0

4. Back Panel USB Port 1

5. COM Port 1 (Turquoise)

6. VGA Port (Blue)

7. Gigabit LAN 1

8. Gigabit LAN 2

(See Section 2-5 for details.)

2-8

Chapter 2: Installation

Front Control Panel

JF1 contains header pins for various buttons and indicators that are normally

located on a control panel at the front of the chassis. These connectors are de-

signed specifi cally for use with Super Micro server chassis. See Figure 2- 4 for the

descriptions of the various control panel buttons and LED indicators. Refer to the

following section for descriptions and pin defi nitions.

JF1 Header Pins

1920

Ground

NMI

X7DCL-3/i

X

Power LED

HDD LED

NIC1 LED

NIC2 LED

OH/Fan Fail LED

PWR Fail LED

Ground

Ground

X

Vcc

Vcc

Vcc

Vcc

Vcc

Vcc

Reset

PWR

2

1

Reset Button

Power Button

2-9

X7DCL-3/X7DCL-i User's Manual

Front Control Panel Pin Defi nitions

NMI Button

The non-maskable interrupt button

header is located on pins 19 and 20

of JF1. Refer to the table on the right

for pin defi nitions.

Power LED

The Power LED connection is located

on pins 15 and 16 of JF1. Refer to the

table on the right for pin defi nitions.

NMI Button

Pin Defi nitions (JF1)

Pin# Defi nition

19 Control

20 Ground

Power LED

Pin Defi nitions (JF1)

Pin# Defi nition

15 +5V

16 Ground

X7DCL-3/i

2-10

A. NMI

B. PWR LED

Ground

B

Power LED

HDD LED

NIC1 LED

NIC2 LED

OH/Fan Fail LED

PWR Fail LED

Ground

Ground

1920

NMI

A

X

2

X

Vcc

Vcc

Vcc

Vcc

Vcc

Vcc

Reset

Reset Button

Power Button

PWR

1

HDD LED

Chapter 2: Installation

The HDD LED connection is located

on pins 13 and 14 of JF1. Attach a

hard drive LED cable here to display

disk activity (for any hard drives on

the system, including SAS, Serial

ATA and IDE). See the table on the

right for pin defi nitions.

NIC1/NIC2 LED Indicators

The NIC (Network Interface Control-

ler) LED connection for GLAN port1

is located on pins 11 and 12 of JF1

and the LED connection for GLAN

Port2 is on Pins 9 and 10. Attach the

NIC LED cables to display network

activity. Refer to the table on the right

for pin defi nitions.

HDD LED

Pin Defi nitions (JF1)

Pin# Defi nition

13 +5V

14 HD Active

GLAN1/2 LED

Pin Defi nitions (JF1)

Pin# Defi nition

9/11 Vcc

10/12 Ground

X7DCL-3/i

2-11

A. HDD LED

B. NIC1 LED

C. NIC2 LED

Ground

Power LED

HDD LED

A

B

NIC1 LED

NIC2 LED

C

OH/Fan Fail LED

PWR Fail LED

Ground

Ground

1920

NMI

X

2

X

Vcc

Vcc

Vcc

Vcc

Vcc

Vcc

Reset

Reset Button

Power Button

PWR

1

X7DCL-3/X7DCL-i User's Manual

Overheat/Fan Fail LED (OH)

Connect an LED to the OH/Fan Fail

connection on pins 7 and 8 of JF1

to provide advanced warnings of

chassis overheating or fan failure.

Refer to the table on the right for pin

defi nitions.

Power Fail LED

The Power Fail LED connection is

located on pins 5 and 6 of JF1. Re-

fer to the table on the right for pin

defi nitions.

OH/Fan Fail LED

Pin Defi nitions (JF1)

Pin# Defi nition

7 Vcc

8 Ground

OH/Fan Fail Indicator

Status

State Defi nition

Off Normal

On Overheat

Flash­ing

Pin Defi nitions (JF1)

Pin# Defi nition

5 Vcc

6 Ground

Fan Fail

PWR Fail LED

X7DCL-3/i

2-12

A. OH/Fan Fail LED

B. PWR Supply Fail

Ground

X

Power LED

HDD LED

NIC1 LED

NIC2 LED

OH/Fan Fail LED

A

PWR Fail LED

B

Ground

Ground

1920

NMI

X

Vcc

Vcc

Vcc

Vcc

Vcc

Vcc

Reset

Reset Button

Power Button

PWR

2

1

Reset Button

The Reset Button connection is located

on pins 3 and 4 of JF1. Attach it to the

hardware reset switch on the computer

case. Refer to the table on the right for

pin defi nitions.

Power Button

The Power Button connection is located

on pins 1 and 2 of JF1. Momentarily

contacting both pins will power on/off

the system. This button can also be

configured to function as a suspend

button (with a setting in the BIOS - see

Chapter 4). To turn off the power when

set to suspend mode, press the button

for at least 4 seconds. Refer to the table

on the right for pin defi nitions.

Chapter 2: Installation

Reset Button

Pin Defi nitions (JF1)

Pin# Defi nition

3 Reset

4 Ground

Power Button

Pin Defi nitions (JF1)

Pin# Defi nition

1 Signal

2 +3V Standby

X7DCL-3/i

2-13

A. Reset Button

B. PWR Button

Ground

Power LED

HDD LED

NIC1 LED

NIC2 LED

OH/Fan Fail LED

PWR Fail LED

Ground

Ground

1920

NMI

X

Vcc

Vcc

Vcc

Vcc

Vcc

Vcc

Reset

X

Reset Button

A

Power Button

PWR

2

1

B

X7DCL-3/X7DCL-i User's Manual

2-5 Connecting Cables

ATX Power C onne ctor

A 24-pin main power supply connec-

tor is located at JPW2, and an 8-pin

CPU PWR connector is locatged at

JPW1 on the motherboard. These

power connectors meet the SSI EPS

12V specifi cation. See the table on

the right for pin defi nitions. For the

8-pin PWR (JPW1), refer to the item

below.

Processor Power
Connector

In addition to the Primary ATX power

connector, the 12V 8-pin CPU PWR

connector at JPW1 must also be con-

nected to provide adequate power to

your processors. See the table on the

right for pin defi nitions.

ATX Power 24-pin Connector

Pin Defi nitions

Pin# Defi nition Pin # Defi nition

13 +3.3V 1 +3.3V

14 -12V 2 +3.3V

15 COM 3 COM

16 PS_ON 4 +5V

17 COM 5 COM

18 COM 6 +5V

19 COM 7 COM

20 Res (NC) 8 PWR_OK

21 +5V 9 5VSB

22 +5V 10 +12V

23 +5V 11 +12V

24 COM 12 +3.3V

12V 8-pin Power CPU

Connector

Pin Defi nitions

Pins Defi nition

1 through 4 Ground

5 through 8 +12V

Required Connection

A. 24-pin ATX PWR

B. 8-pin Processor PWR

CPU1

CPU1 VRM OH LED

LED5

JPWF1

JAR

KB/MS

USB0/1

COM1

VGA

8-Pin PWR

B

24-Pin PWR

A

DIMM2A

DIMM1A

DIMM2B

DIMM1B

DIMM2C

DIMM1C

SMB_PS

Fan 1

X7DCL-3/i

LAN1

JPL2

FAN6

VGA

CTRL

LAN

CTRL

FAN5

I-Button

LAN

CTRL

JPG1

SI/O

JWOR1

JKEY1

JI2C2

JWD1

Slot6 PCI-E x8

Slot5 PCI-E x8

JI2C1

Slot4 PCI-E x4(in x8 slot)

Slot3 PCI 33MHz

Slot2 PCI 33MHz

Slot1 PCI 33MHz

SIMLC

JWOL1

Intel

North Bridge

SP1

Buzzer

5100

System Status LED

Intel

ICH9R

South Bridge

SATA5

JBT1

BIOS

Battery

ITE

SAS-GPIO1

CTRL

SAS-GPIO0

USB4/5

JPA2

USB2/3

BPI2C

LED4

LAN2

JPL1

COM2

SATA-GPIO0

SATA4

SAS1

SAS0

SATA3

JD1

JP2

JP1

SATA-GPIO1

SATA2

SAS2

CPU2

Fan 2

LED6

CPU2 VRM OH LED

Fan 3

PWR LED

LED3

FP CTRL

JPA1

SATA1

SATA0

LED1

LSI
SAS
CTRL

SAS3

SAS4

Floppy

IDE

JL1

SAS6

SAS7

SAS5

Fan 4

2-14

Chapter 2: Installation

Universal Serial Bus (USB)

There are six USB 2.0 (Universal Serial

Bus) ports/headers on the motherboard.

Two of them are Back Panel USB ports

(USB#0/1: JPUSB1), and the other

four are Front Panel USB connectors

(USB#2/3: JUSB2), or Front-Accessible

USB headers (USB#4/#5: JUSB3). See

the tables on the right for pin defi ni-

tions.

Back Panel USB (0/1)

Pin Defi nitions

Pin# Defi nitions

1 +5V

2PO-

3PO+

4 Ground

5N/A

Front Panel USB

Pin Defi nitions (USB2/3/4/5)

USB2/3
Pin # Defi nition

USB4/5
Pin # Defi nition

1 +5V 1 +5V

2 PO- 2 PO-

3 PO+ 3 PO+

4 Ground 4 Ground

5 Key 5 No connection

A. Backpanel USB 0/1

B. Front Panel USB 2/3

C. Front Panel USB 4/5

CPU1

CPU1 VRM OH LED

LED5

JPWF1

JAR

KB/MS

USB0/1

COM1

VGA

8-Pin PWR

A

24-Pin PWR

DIMM2A

DIMM1A

DIMM2B

DIMM1B

DIMM2C

DIMM1C

SMB_PS

Fan 1

X7DCL-3/i

LAN1

JPL2

COM2

CTRL

LAN

CTRL

FAN5

FAN6

I-Button

LAN

CTRL

VGA

JPG1

SI/O

JWOR1

JKEY1

JI2C2

JWD1

Slot6 PCI-E x8

Slot5 PCI-E x8

JI2C1

Slot4 PCI-E x4(in x8 slot)

Slot3 PCI 33MHz

Slot2 PCI 33MHz

Slot1 PCI 33MHz

SIMLC

JWOL1

Intel

North Bridge

SP1

Buzzer

5100

System Status LED

Intel

ICH9R

South Bridge

SATA5

JBT1

BIOS

Battery

ITE

SAS-GPIO1

CTRL

SAS-GPIO0

JPA2

C

LED4

USB4/5

B

USB2/3

BPI2C

LAN2

JPL1

SATA-GPIO0

SATA4

SAS1

SAS0

SATA3

JD1

JP2

JP1

SATA-GPIO1

SATA2

SAS3

SAS2

LSI
SAS
CTRL

CPU2

SATA1

SAS4

SAS5

SATA0

CPU2 VRM OH LED

PWR LED

LED3

JPA1

LED1

SAS6

SAS7

Fan 2

LED6

Fan 3

FP CTRL

Floppy

IDE

JL1

Fan 4

2-15

X7DCL-3/X7DCL-i User's Manual

G

F

E

D

Fan Headers

The X7DCL-3/X7DCL-i has four chassis/

system fan headers (Fan3 to Fan6), and

two CPU Fans (Fans 1/2). All these fans

are 4-pin fans. However, Pins 1-3 of the fan

headers are backward compatible with the

traditional 3-pin fans. See the table on the

right for pin defi nitions. Note: The onboard

fan speeds are controlled by Thermal Man-

agement via BIOS Hardware Monitoring in

the Advanced Setting

. (The default setting

is Disabled.) Please use all 3-pin fans or

all 4-pin fans on the motherboard.

Chassis Intrusion

A Chassis Intrusion header is located at

JL1 on the motherboard. Attach an appro-

priate cable from the chassis to inform you

of a chassis intrusion when the chassis is

opened.

Fan Header

Pin Defi nitions (Fan1-6)

Pin# Defi nition

1 Ground

2 +12V

3 Tachometer

4 PWR Modulation

Chassis Intrusion

Pin Defi nitions (JL1)

Pin# Defi nition

1 Intrusion Input

2 Ground

CPU1

CPU2

SATA-GPIO1

SATA1

SATA2

LSI
SAS
CTRL

SAS3

SAS4

SATA0

SAS5

CPU1 VRM OH LED

CPU2 VRM OH LED

PWR LED

LED3

JPA1

LED1

SAS6

SAS7

LED5

A. Fan 1

B. Fan 2

C. Fan 3

D. Fan 4

E. Fan 5

F. Fan 6

G. Chassis Intrusion

Fan 2

LED6

B

Fan 3

C

FP CTRL

Floppy

IDE

JL1

Fan 4

JPWF1

JAR

KB/MS

USB0/1

COM1

VGA

8-Pin PWR

24-Pin PWR

DIMM2A

DIMM1A

DIMM2B

DIMM1B

DIMM2C

DIMM1C

SMB_PS

Fan 1

A

X7DCL-3/i

LAN1

JPL2

FAN6

VGA

CTRL

LAN

CTRL

FAN5

I-Button

LAN

CTRL

JPG1

SI/O

JWOR1

JKEY1

JI2C2

JWD1

Slot6 PCI-E x8

Slot5 PCI-E x8

JI2C1

Slot4 PCI-E x4(in x8 slot)

Slot3 PCI 33MHz

Slot2 PCI 33MHz

Slot1 PCI 33MHz

SIMLC

JWOL1

Intel

North Bridge

SP1

Buzzer

5100

System Status LED

JP2

JP1

Intel

ICH9R

South Bridge

BIOS

ITE

CTRL

LED4

USB4/5

SATA-GPIO0

SATA3

SATA4

SATA5

JBT1

JPA2

SAS-GPIO1

SAS-GPIO0

USB2/3

JD1

SAS2

SAS1

SAS0

Battery

BPI2C

LAN2

JPL1

COM2

2-16

Chapter 2: Installation

ATX PS /2 Key boar d and
PS/2 Mouse Ports

The ATX PS/2 keyboard and the PS/2

mouse are located at JKM1. See the

table on the right for pin defi nitions.

(The mouse port is above the key-

board port.) See the table on the right

for pin defi nitions.

Serial Ports

COM1 is a connector located on the

IO Backpanel, and COM2 is a header

located at JCOM2. See the table on

the right for pin defi nitions.

PS/2 Keyboard and

Mouse Port Pin

Defi nitions

Pin# Defi nition

1Data

2NC

3 Ground

4 VCC

5 Clock

6NC

Serial Port Pin Defi nitions

(COM1/COM2)

Pin # Defi nition Pin # Defi nition

1 CD 6 DSR

2RD 7 RTS

3TD 8CTS

4DTR 9RI

5 Ground 10 NC

(Pin 10 is available on COM2
only. NC: No Connection.)

CPU1

CPU1 VRM OH LED

LED5

A. Keyboard/Mouse

B. COM1

C. COM2

JPWF1

JAR

8-Pin PWR

A

KB/MS

USB0/1

COM1

B

VGA

24-Pin PWR

DIMM2A

DIMM1A

DIMM2B

DIMM1B

DIMM2C

DIMM1C

SMB_PS

Fan 1

X7DCL-3/i

LAN1

JPL2

C

COM2

CTRL

LAN

CTRL

FAN5

FAN6

I-Button

LAN

CTRL

VGA

JPG1

SI/O

JWOR1

JKEY1

JI2C2

JWD1

Slot6 PCI-E x8

Slot5 PCI-E x8

JI2C1

Slot4 PCI-E x4(in x8 slot)

Slot3 PCI 33MHz

Slot2 PCI 33MHz

Slot1 PCI 33MHz

SIMLC

JWOL1

Intel

North Bridge

SP1

Buzzer

5100

System Status LED

Intel

ICH9R

South Bridge

SATA5

JBT1

BIOS

Battery

ITE

SAS-GPIO1

CTRL

SAS-GPIO0

USB4/5

JPA2

USB2/3

BPI2C

LED4

LAN2

JPL1

SATA-GPIO0

SATA4

SAS1

SAS0

SATA3

JD1

JP2

JP1

SATA-GPIO1

SATA2

SAS3

SAS2

LSI
SAS
CTRL

CPU2

SATA1

SAS4

SAS5

SATA0

CPU2 VRM OH LED

PWR LED

LED3

JPA1

LED1

SAS6

SAS7

Fan 2

LED6

Fan 3

FP CTRL

Floppy

IDE

JL1

Fan 4

2-17

X7DCL-3/X7DCL-i User's Manual

Wake-On-Ring

The Wake-On-Ring header is lo-

cated at JWOR1. This feature allows

your computer to receive and be

"awakened" by an incoming call to

the modem when the system is in

the suspend state. See the table on

the right for pin defi nitions. You must

have a Wake-On-Ring card and cable

to use this feature.

Wake-On-LAN

The Wake-On-LAN header is located

at JWOL1 on the motherboard. See

the table on the right for pin defi ni-

tions. (You must have a LAN card

with a Wake-On-LAN connector, and

cable to use this feature.)

Wake-On-Ring

Pin Defi nitions

Pin# Defi nition

1 Ground

2 Wake-up

Wake-On-LAN

Pin Defi nitions

Pin# Defi nition

1 +5V Standby

2 Ground

3 Wake-up

CPU1

CPU1 VRM OH LED

LED5

A. WOR

B. WOL

JPWF1

JAR

KB/MS

USB0/1

COM1

VGA

8-Pin PWR

24-Pin PWR

DIMM2A

DIMM1A

DIMM2B

DIMM1B

DIMM2C

DIMM1C

SMB_PS

Fan 1

X7DCL-3/i

LAN1

JPL2

FAN6

VGA

CTRL

LAN

CTRL

FAN5

I-Button

LAN

CTRL

JPG1

SI/O

A

JWOR1

JKEY1

JI2C2

JWD1

Slot6 PCI-E x8

Slot5 PCI-E x8

JI2C1

Slot4 PCI-E x4(in x8 slot)

Slot3 PCI 33MHz

Slot2 PCI 33MHz

Slot1 PCI 33MHz

SIMLC

JWOL1

Intel

5100

North Bridge

SP1

Buzzer

B

System Status LED

Intel

ICH9R

South Bridge

SATA5

JBT1

BIOS

Battery

ITE

SAS-GPIO1

CTRL

SAS-GPIO0

USB4/5

JPA2

USB2/3

BPI2C

LED4

LAN2

JPL1

COM2

SATA-GPIO0

SATA4

SAS1

SAS0

SATA3

JD1

JP2

JP1

SATA-GPIO1

SATA2

SAS2

CPU2

Fan 2

LED6

CPU2 VRM OH LED

Fan 3

PWR LED

LED3

FP CTRL

JPA1

SATA1

SATA0

LED1

LSI
SAS
CTRL

SAS3

SAS4

Floppy

IDE

JL1

SAS6

SAS7

SAS5

Fan 4

2-18

GLAN 1/2 (Giga-bit Ethernet
Ports)

Two G-bit Ethernet ports are located

at JLAN1 and JLAN2 on the I/O

backplane. These ports accept RJ45

type cables.

Power LED/Speaker

On the JD1 header, pins 1-3 are for

a power LED, and pins 4-7 are for

the speaker. See the table on the

right for speaker pin defi nitions. Note:

The speaker connector pins are for

use with an external speaker. If you

wish to use the onboard speaker, you

should close pins 6-7 with a jumper.

Chapter 2: Installation

GLAN1

Speaker Connector

Pin Setting Defi nition

Pins 6-7 Internal Speaker

Pins 4-7 External Speaker

GLAN2

A. GLAN1

B. GLAN2

C. PWR LED/Speaker

CPU1

CPU1 VRM OH LED

LED5

JPWF1

JAR

KB/MS

USB0/1

COM1

VGA

8-Pin PWR

24-Pin PWR

DIMM2A

DIMM1A

DIMM2B

DIMM1B

DIMM2C

DIMM1C

SMB_PS

Fan 1

X7DCL-3/i

A

LAN1

JPL2

COM2

CTRL

LAN

B

CTRL

FAN5

FAN6

I-Button

LAN

CTRL

VGA

JPG1

SI/O

JWOR1

JKEY1

JI2C2

JWD1

Slot6 PCI-E x8

Slot5 PCI-E x8

JI2C1

Slot4 PCI-E x4(in x8 slot)

Slot3 PCI 33MHz

Slot2 PCI 33MHz

Slot1 PCI 33MHz

SIMLC

JWOL1

Intel

North Bridge

SP1

Buzzer

5100

System Status LED

Intel

ICH9R

South Bridge

SATA5

JBT1

BIOS

Battery

ITE

SAS-GPIO1

CTRL

SAS-GPIO0

USB4/5

JPA2

USB2/3

BPI2C

LED4

LAN2

JPL1

SATA-GPIO0

SATA4

C

SAS1

SAS0

SATA3

JD1

JP2

JP1

SATA-GPIO1

SATA2

SAS3

SAS2

LSI
SAS
CTRL

CPU2

SATA1

SAS4

SAS5

SATA0

CPU2 VRM OH LED

PWR LED

LED3

JPA1

LED1

SAS6

SAS7

Fan 2

LED6

Fan 3

FP CTRL

Floppy

IDE

JL1

Fan 4

2-19

X7DCL-3/X7DCL-i User's Manual

Alarm Reset

If three power supplies are installed,

the system will notify you when any of

the three power modules fails. Con-

nect JAR1 to a micro-switch to turn

off the alarm that is activated when a

power module fails. See the table on

the right for pin defi nitions.

PWR Supply Failure/PWR
Fault Detect

The system can notify you in the

event of a power supply failure. This

feature is available when three power

supply units are installed in the chas-

sis with one acting as a backup. If you

only have one or two power supply

units installed, you should disable

this (the default setting) with JPWF1

to prevent false alarms.

Alarm Reset

Pin Defi nitions

Pin Setting Defi nition

Pin 1 Ground

Pin 2 +5V

PWR Supply PWR Fault

Connector

Jumper Setting Defi nition

On Enabled

Off Disabled (Default)

B

CPU1

CPU2

SATA-GPIO1

SATA1

SATA2

LSI
SAS
CTRL

SAS3

SAS4

SATA0

SAS5

CPU1 VRM OH LED

CPU2 VRM OH LED

PWR LED

LED3

JPA1

LED1

SAS6

SAS7

LED5

A. Alarm Reset

B. PWR Fault

Fan 2

LED6

Fan 3

FP CTRL

Floppy

IDE

JL1

Fan 4

JPWF1

JAR

KB/MS

USB0/1

COM1

VGA

A

8-Pin PWR

24-Pin PWR

DIMM2A

DIMM1A

DIMM2B

DIMM1B

DIMM2C

DIMM1C

SMB_PS

Fan 1

X7DCL-3/i

LAN1

JPL2

FAN6

VGA

CTRL

LAN

CTRL

FAN5

I-Button

LAN

CTRL

JPG1

SI/O

JWOR1

JKEY1

JI2C2

JWD1

Slot6 PCI-E x8

Slot5 PCI-E x8

JI2C1

Slot4 PCI-E x4(in x8 slot)

Slot3 PCI 33MHz

Slot2 PCI 33MHz

Slot1 PCI 33MHz

SIMLC

JWOL1

Intel

North Bridge

SP1

Buzzer

5100

System Status LED

JP2

JP1

Intel

ICH9R

South Bridge

BIOS

ITE

CTRL

LED4

USB4/5

SATA-GPIO0

SATA3

SATA4

SATA5

JBT1

JPA2

SAS-GPIO1

SAS-GPIO0

USB2/3

JD1

SAS2

SAS1

SAS0

Battery

BPI2C

LAN2

JPL1

COM2

2-20

VGA Connector

E

D

A VGA connector (JVGA) is located next

to the COM1 port on the IO backplane.

Refer to the board layout below for the

location.

GPIO Headers

Chapter 2: Installation

Four GPIO (Serial Links General Purpose

Input/Output) headers are located at J7,

J8, J9, J10 on the motherboard. These

headers are used to communicate with

the Seriel-Links System Monitoring chip

on the backplane. J7 and J8 are used to

monitor SATA activities, J9 and J10 are

used to monitor SAS connections. See

the table on the right for pin defi nitions.

Refer to the board layout below for the

locations of the headers.

(J9, J10: X7DCL-3 Only.)

JPWF1

JAR

KB/MS

USB0/1

COM1

A

VGA

8-Pin PWR

24-Pin PWR

DIMM2A

DIMM1A

DIMM2B

DIMM1B

DIMM2C

DIMM1C

X7DCL-3/i

LAN1

JPL2

COM2

CTRL

LAN

CTRL

FAN5

FAN6

I-Button

LAN

CTRL

VGA

JPG1

SI/O

JWOR1

JKEY1

JI2C2

JWD1

JI2C1

Slot6 PCI-E x8

Slot5 PCI-E x8

Slot4 PCI-E x4(in x8 slot)

Slot3 PCI 33MHz

Slot2 PCI 33MHz

JWOL1

Slot1 PCI 33MHz

SIMLC

LAN2

JPL1

Intel

North Bridge

SP1

Buzzer

5100

System Status LED

LED4

SMB_PS

BIOS

CTRL

ITE

Intel

ICH9R

South Bridge

USB4/5

BPI2C

JBT1

Battery

JPA2

Fan 1

B

SAS-GPIO1

SAS-GPIO0

USB2/3

SATA5

SATA-GPIO0

SATA4

SAS1

SAS0

SATA3

JD1

JP2

JP1

C

SATA-GPIO1

SATA2

SAS3

SAS2

LSI
SAS
CTRL

Serial-Links GPIO

Pin Defi nitions

Pin# Defi nition Pin Defi nition

1NC 2 NC

3 Ground 4 DATA Out

5 Load 6 Ground

7 Clock 8 NC

Note: NC= No Connections

CPU1 VRM OH LED

LED5

A. VGA

B. J7: SATA_GPIO#0

C. J8: SATA_GPIO#1

CPU1

D. J9: SAS_GPIO#0

E. J10: SAS_GPIO#1

CPU2

Fan 2

LED6

CPU2 VRM OH LED

Fan 3

PWR LED

LED3

FP CTRL

JPA1

SATA1

SATA0

LED1

Floppy

IDE

JL1

SAS6

SAS7

SAS5

SAS4

Fan 4

2-21

X7DCL-3/X7DCL-i User's Manual

Power SMB (I2 C) Connector

Power SMB (I2 C) Connector (JPI2C1)

monitors the status of the power supply,

fan and system temperature. See the

table on the right for pin defi nitions.

BP PWR SMB (I2 C) Connector

Backplane Power SMB (I2 C) Connector

(J5) monitors power supply of backplane

IO connectors. See the table on the right

for pin defi nitions.

PWR SMB

Pin Defi nitions

Pin# Defi nition

1 Clock

2Data

3 PWR Fail

4 Ground

5 +3.3V

BP PWR SMB

Pin Defi nitions

Pin# Defi nition

1 SMB_DAT_ICH_EXT

2 Ground

3 SMB_CLK_ICH_EXT

5 No Connection

CPU1

CPU1 VRM OH LED

LED5

A. PWR SMB

B. Backplane PWR SMB

JPWF1

JAR

KB/MS

USB0/1

COM1

VGA

8-Pin PWR

24-Pin PWR

DIMM2A

DIMM1A

DIMM2B

DIMM1B

DIMM2C

DIMM1C

SMB_PS

Fan 1

A

X7DCL-3/i

LAN1

JPL2

COM2

CTRL

LAN

CTRL

FAN5

FAN6

I-Button

LAN

CTRL

VGA

S I/O

Slot6 PCI-E x8

Slot5 PCI-E x8

JI2C2

JI2C1

Slot4 PCI-E x4(in x8 slot)

JPG1

JWD1

JKEY1

JWOR1

Slot3 PCI 33MHz

Slot2 PCI 33MHz

Slot1 PCI 33MHz

SIMLC

JWOL1

Intel

North Bridge

SP1

Buzzer

5100

System Status LED

Intel

ICH9R

South Bridge

SATA5

JBT1

BIOS

Battery

ITE

SAS-GPIO1

CTRL

SAS-GPIO0

USB4/5

BPI2C

JPA2

USB2/3

B

LED4

LAN2

JPL1

SATA-GPIO0

SATA4

SAS1

SAS0

SATA3

JD1

JP2

JP1

SATA-GPIO1

SATA2

SAS3

SAS2

LSI
SAS
CTRL

CPU2

SATA1

SAS4

SAS5

SATA0

CPU2 VRM OH LED

PWR LED

LED3

JPA1

LED1

SAS6

SAS7

Fan 2

LED6

Fan 3

FP CTRL

Floppy

IDE

JL1

Fan 4

2-22

Chapter 2: Installation

Keylock

The keyboard lock connection is desig-

nated JKEY1. Utilizing this header allows

you to inhibit any actions made on the

keyboard, effectively "locking" it.

Keylock

Pin Defi nitions

Pin# Defi nition

1 Ground

2 Keylock R-N

VGA

KB/MS

USB0/1

COM1

LAN1

LAN2

CPU1

CPU1 VRM OH LED

LED5

A. Keylock

JPWF1

JAR

8-Pin PWR

DIMM2A

DIMM1A

DIMM2B

DIMM1B

DIMM2C

DIMM1C

24-Pin PWR

SMB_PS

Fan 1

X7DCL-3/i

SATA-GPIO0

SATA4

SAS1

SAS0

SATA3

JD1

JP2

JP1

SATA-GPIO1

SATA2

SAS3

SAS2

LSI
SAS

CTRL

CPU2

SATA1

SAS4

SAS5

SATA0

CPU2 VRM OH LED

PWR LED

LED3

JPA1

LED1

SAS6

SAS7

Fan 2

LED6

Fan 3

FP CTRL

Floppy

IDE

JL1

Fan 4

JPL2

LAN

CTRL

FAN5

FAN6

I-Button

LAN

CTRL

JPL1

VGA

CTRL

JPG1

SI/O

COM2

A

JWOR1

JKEY1

JI2C2

JWD1

Slot6 PCI-E x8

Slot5 PCI-E x8

JI2C1

Slot4 PCI-E x4(in x8 slot)

Slot3 PCI 33MHz

Slot2 PCI 33MHz

Slot1 PCI 33MHz

SIMLC

JWOL1

Intel

North Bridge

SP1

Buzzer

5100

System Status LED

Intel

ICH9R

South Bridge

SATA5

JBT1

BIOS

Battery

ITE

SAS-GPIO1

CTRL

SAS-GPIO0

USB4/5

JPA2

USB2/3

BPI2C

LED4

2-23

X7DCL-3/X7DCL-i User's Manual

Connector

Pins

Jumper

Cap

Setting

2-6 Jumper Settings

Explanation of
Jumpers

To modify the operation of the

motherboard, jumpers can be used

to choose between optional settings.

Jumpers create shorts between two pins

to change the function of the connector.

Pin 1 is identifi ed with a square solder

pad on the printed circuit board. See

the motherboard layout pages for jumper

locations.

Note: On two pin jumpers, "Closed"

means the jumper is on and "Open"

means the jumper is off the pins.

3 2 1

3 2 1

Pin 1-2 short

GLAN Enable/Disable

JPL1/JPL2 enable or disable GLAN

Port1/GLAN Port2 on the mother-

board. See the table on the right for

jumper settings. The default setting is

Enabled.

JPWF1

JAR

KB/MS

USB0/1

COM1

VGA

8-Pin PWR

24-Pin PWR

DIMM2A

DIMM1A

DIMM2B

DIMM1B

DIMM2C

DIMM1C

X7DCL-3/i

B

LAN1

JPL2

LAN2

LAN

CTRL

FAN5

FAN6

I-Button

LAN

CTRL

Slot6 PCI-E x8

A

JWOR1

JKEY1

JI2C2

JWD1

JI2C1

Slot5 PCI-E x8

Slot4 PCI-E x4(in x8 slot)

Slot3 PCI 33MHz

Slot2 PCI 33MHz

JWOL1

Slot1 PCI 33MHz

SIMLC

JPL1

VGA

CTRL

JPG1

SI/O

COM2

Intel

North Bridge

SP1

Buzzer

5100

System Status LED

SMB_PS

LED4

BIOS

CTRL

ITE

Intel

ICH9R

South Bridge

USB4/5

BPI2C

JBT1

Battery

JPA2

Fan 1

SAS-GPIO1

SAS-GPIO0

USB2/3

SATA5

SATA4

SAS0

JP2

SATA-GPIO0

SATA3

JD1

SAS2

SAS1

JP1

SATA-GPIO1

SATA2

SAS3

SAS

CTRL

GLAN Enable

Jumper Settings

Pin# Defi nition

1-2 Enabled (default)

2-3 Disabled

CPU1 VRM OH LED

LED5

A. GLAN Port1 Enable

B. GLAN Port2 Enable

CPU1

CPU2

Fan 2

LED6

CPU2 VRM OH LED

Fan 3

PWR LED

LED3

FP CTRL

JPA1

SATA1

SATA0

LED1

LSI

SAS4

Floppy

IDE

JL1

SAS6

SAS7

SAS5

Fan 4

2-24

Chapter 2: Installation

CMOS Clear

JBT1 is used to clear CMOS. Instead of pins, this "jumper" consists of contact

pads to prevent the accidental clearing of CMOS. To clear CMOS, use a metal

object such as a small screwdriver to touch both pads at the same time to short

the connection. Always remove the AC power cord from the system before clear-

ing CMOS.

Note: For an ATX power supply, you must completely shut down the system,

remove the AC power cord and then short JBT1 to clear CMOS.

Watch Dog Enable/Disable

Watch Dog

Watch Dog is a system monitor that can reboot

the system when a software application hangs.

Close pins 1-2 to reset the system if an applica-

tion hangs. Close pins 2-3 to generate a non-

maskable interrupt signal for the application that

hangs. See the table on the right for jumper set-

tings. Watch Dog must also be enabled in the

BIOS.

Jumper Settings

Jumper Setting Defi nition

Pins 1-2 Reset

(default)

Pins 2-3 NMI

Open Disabled

CPU1

CPU1 VRM OH LED

LED5

A. Clear CMOS

B. Watch Dog Enable

JPWF1

JAR

KB/MS

USB0/1

COM1

VGA

8-Pin PWR

24-Pin PWR

DIMM2A

DIMM1A

DIMM2B

DIMM1B

DIMM2C

DIMM1C

SMB_PS

Fan 1

X7DCL-3/i

LAN1

JPL2

COM2

CTRL

LAN

CTRL

FAN5

FAN6

I-Button

LAN

CTRL

VGA

JPG1

SI/O

JWOR1

JKEY1

JI2C2

JWD1

JI2C1

B

Slot6 PCI-E x8

Slot5 PCI-E x8

Slot4 PCI-E x4(in x8 slot)

Slot3 PCI 33MHz

Slot2 PCI 33MHz

Slot1 PCI 33MHz

SIMLC

JWOL1

Intel

North Bridge

SP1

Buzzer

5100

System Status LED

Intel

ICH9R

South Bridge

SATA5

A

JBT1

BIOS

Battery

ITE

SAS-GPIO1

CTRL

SAS-GPIO0

USB4/5

JPA2

USB2/3

BPI2C

LED4

LAN2

JPL1

SATA-GPIO0

SATA4

SAS1

SAS0

SATA3

JD1

JP2

JP1

SATA-GPIO1

SATA2

SAS3

SAS2

LSI
SAS
CTRL

CPU2

SATA1

SAS4

SAS5

SATA0

CPU2 VRM OH LED

PWR LED

LED3

JPA1

LED1

SAS6

SAS7

Fan 2

LED6

Fan 3

FP CTRL

Floppy

IDE

JL1

Fan 4

2-25

X7DCL-3/X7DCL-i User's Manual

VGA Enable/Disable

JPG1 allows you to e n a b l e or disable the

VGA port. The default position is on pins

1 and 2 to enable VGA. See the table on

the right for jumper settings.

I2C Bus to PCI/PCI-Exp. Slots

Jumpers JPI2C1/JPI2C2 allow you to

connect the System Management Bus

2

(I

C) to PCI/PCI-Exp. slots. The default

setting is Open to disable the connec-

tion. See the table on the right for jumper

settings.

VGA Enable/Disable

Jumper Settings

Both Jumpers Defi nition

Pins 1-2 Enabled (Default)

Pins 2-3 Disabled

I2C to PCI/PCI-Exp. Slots

Jumper Settings

Jumper Setting Defi nition

Closed Enabled

Open Disabled (Default)

CPU1

CPU1 VRM OH LED

LED5

A. VGA Enabled

2

C1

B. JPI

2

C2

C. JPI

JPWF1

JAR

KB/MS

USB0/1

COM1

VGA

8-Pin PWR

24-Pin PWR

DIMM2A

DIMM1A

DIMM2B

DIMM1B

DIMM2C

DIMM1C

SMB_PS

Fan 1

X7DCL-3/i

LAN1

JPL2

FAN6

VGA

CTRL

LAN

CTRL

FAN5

I-Button

LAN

CTRL

C

JPG1

SI/O

JWOR1

JKEY1

JI2C2

JWD1

B

JI2C1

A

Slot6 PCI-E x8

Slot5 PCI-E x8

Slot4 PCI-E x4(in x8 slot)

Slot3 PCI 33MHz

Slot2 PCI 33MHz

Slot1 PCI 33MHz

SIMLC

JWOL1

Intel

North Bridge

SP1

Buzzer

5100

System Status LED

Intel

ICH9R

South Bridge

SATA5

JBT1

BIOS

Battery

ITE

SAS-GPIO1

CTRL

SAS-GPIO0

USB4/5

JPA2

USB2/3

BPI2C

LED4

LAN2

JPL1

COM2

SATA-GPIO0

SATA4

SAS1

SAS0

SATA3

JD1

JP2

JP1

SATA-GPIO1

SATA2

SAS2

CPU2

Fan 2

LED6

CPU2 VRM OH LED

Fan 3

PWR LED

LED3

FP CTRL

JPA1

SATA1

SATA0

LED1

LSI

SAS

CTRL

SAS3

SAS4

Floppy

IDE

JL1

SAS6

SAS7

SAS5

Fan 4

2-26

SAS Enable/Disable

Chapter 2: Installation

JPA1 allows you to enable or disable

SAS Connectors. The default position is

on pins 1 and 2 to enable SAS. See the

table on the right for jumper settings.

(Note: This feature is available on the

X7DCL-3 only.)

Software RAID Enable

JPA2 allows you to select the SAS RAID

mode. You can use either Software

RAID or IT RAID. Close this jumper to

use Software RAID (Default). Set this

jumper to open to use the IT RAID mode.

Contact Tech. Support at Supermicro for

more information. See the table on the

right for jumper settings.

SAS Enable/Disable

Jumper Settings

Jumper Settings Defi nition

Pins 1-2 Enabled (Default)

Pins 2-3 Disabled

Software RAID

Jumper Settings

Jumper Settings Defi nition

Close (Default) Software RAID Enabled

Open (Note) IT Mode Enabled

(Note: Also contact tech support at Super Micro for

further instructions.)

(Note: This feature is available on the

X7DCL-3 only.)

JPWF1

JAR

KB/MS

USB0/1

COM1

VGA

8-Pin PWR

24-Pin PWR

DIMM2A

DIMM1A

DIMM2B

DIMM1B

DIMM2C

DIMM1C

X7DCL-3/i

LAN1

JPL2

COM2

FAN6

CTRL

LAN

CTRL

FAN5

I-Button

LAN

CTRL

VGA

SI/O

JPG1

JWOR1

JKEY1

JI2C2

JWD1

JI2C1

Slot6 PCI-E x8

Slot5 PCI-E x8

Slot4 PCI-E x4(in x8 slot)

Slot3 PCI 33MHz

Slot2 PCI 33MHz

JWOL1

Slot1 PCI 33MHz

SIMLC

LAN2

JPL1

Intel

North Bridge

SP1

Buzzer

5100

System Status LED

LED4

SMB_PS

BIOS

CTRL

ITE

Intel

ICH9R

South Bridge

JBT1

Battery

USB4/5

BPI2C

JPA2

Fan 1

SAS-GPIO1

SAS-GPIO0

USB2/3

B

SATA5

SATA-GPIO0

SATA4

SAS1

SAS0

JD1

JP2

SATA3

SAS2

JP1

SATA-GPIO1

SATA2

SAS3

LSI
SAS
CTRL

CPU1

CPU2

SATA1

SAS4

SATA0

SAS5

CPU1 VRM OH LED

CPU2 VRM OH LED

PWR LED

LED3

JPA1

LED1

SAS6

SAS7

LED5

A. SAS Enabled

B. Software RAID Enable

Fan 2

LED6

Fan 3

A

FP CTRL

Floppy

IDE

JL1

Fan 4

2-27

X7DCL-3/X7DCL-i User's Manual

2-7 Onboard LED Indicators

GLAN LEDs

There are two GLAN ports on the moth-

erboard. Each Gigabit Ethernet LAN port

has two LEDs. The yellow LED indicates

activity, while the power LED may be

green, orange or off to indic ate the speed

of the connection. See the tables at right

for more information.

Onboard Power LED (LED3)

An Onboard Power LED is located at

LED3 on the motherboard. When this

LED is lit, the system is on. Be sure

to turn off the system and unplug the

power cord before removing or installing

components. See the layout below for the

LED location.

Link

LED

Activity

LED

Rear View
(when viewing from the back of the chassis.)

GLAN Activity Indicator

Settings

Color Status Defi nition

Yellow Flashing LAN Active

GLAN Link Indicator

Settings

LED Color Defi nition

Off No Connection or 10 Mbps

Green 100 Mbps

Amber 1 Gbps

CPU1

CPU1 VRM OH LED

LED5

A. GLAN Port1 LEDs

B. GLAN Port2 LEDs

C. Onboard PWR LED

JPWF1

JAR

KB/MS

USB0/1

COM1

VGA

8-Pin PWR

24-Pin PWR

DIMM2A

DIMM1A

DIMM2B

DIMM1B

DIMM2C

DIMM1C

SMB_PS

Fan 1

X7DCL-3/i

A

LAN1

JPL2

LAN

B

LAN2

JPL1

COM2

FAN6

VGA

CTRL

CTRL

FAN5

I-Button

LAN

CTRL

JPG1

SI/O

JWOR1

JKEY1

JI2C2

JWD1

Slot6 PCI-E x8

Slot5 PCI-E x8

JI2C1

Slot4 PCI-E x4(in x8 slot)

Slot3 PCI 33MHz

Slot2 PCI 33MHz

Slot1 PCI 33MHz

SIMLC

JWOL1

Intel

North Bridge

SP1

Buzzer

5100

System Status LED

Intel

ICH9R

South Bridge

SATA5

JBT1

BIOS

Battery

ITE

SAS-GPIO1

CTRL

SAS-GPIO0

USB4/5

JPA2

USB2/3

BPI2C

LED4

SATA-GPIO0

SATA4

SAS1

SAS0

SATA3

JD1

JP2

JP1

SATA-GPIO1

SATA2

SAS2

CPU2

Fan 2

LED6

CPU2 VRM OH LED

Fan 3

C

PWR LED

LED3

FP CTRL

JPA1

SATA1

SATA0

LED1

LSI

SAS

CTRL

SAS3

SAS4

Floppy

IDE

JL1

SAS6

SAS7

SAS5

Fan 4

2-28

Chapter 2: Installation

System Status LED (LED4)

A Status LED Indicator is located at

LED4 on the motherboard. This LED dis-

plays different colors to show the status

of the system. Refer to the table on the

right for system status. See the layout

below for the LED location.

CPU_VRM Overheating LED
Indicators (LED5/LED6)

Two CPU_VRM Overheat LEDs are locat-

e d a t L E D 5 a n d L E D 6 o n t h e m o t h e r b o a r d .

These LEDs provide indications for

CPU_VRM Overheating. Refer to the

table on the right for LED5 and LED6

settings. See the layout below for the

LED locations.

Status LED Indicator

Settings

LED Color Defi nition

Green Power On, system: normal

Red PWR on, PWR problem(s)

occur(s) or the 3rd PWR
not properly installed

Yellow System Off, AC PWR:

connected

CPU_VRM Overheat LED Indicator

Settings

LED# Description

LED5: On CPU1_VRM Overheating

LED6: On CPU2_VRM Overheating

A. LED4: System Status LED

B. LED5: CPU1_VRM OH LED

C. LED6: CPU2_VRM OH LED

CPU1

B

CPU1 VRM OH LED

LED5

JPWF1

JAR

KB/MS

USB0/1

COM1

VGA

8-Pin PWR

24-Pin PWR

DIMM2A

DIMM1A

DIMM2B

DIMM1B

DIMM2C

DIMM1C

SMB_PS

Fan 1

X7DCL-3/i

LAN1

JPL2

COM2

CTRL

LAN

CTRL

FAN5

FAN6

I-Button

LAN

CTRL

VGA

JPG1

SI/O

JWOR1

JKEY1

JI2C2

JWD1

Slot6 PCI-E x8

Slot5 PCI-E x8

JI2C1

Slot4 PCI-E x4(in x8 slot)

Slot3 PCI 33MHz

Slot2 PCI 33MHz

Slot1 PCI 33MHz

SIMLC

JWOL1

Intel

North Bridge

SP1

Buzzer

5100

System Status LED

Intel

ICH9R

South Bridge

SATA5

JBT1

BIOS

Battery

ITE

SAS-GPIO1

CTRL

USB4/5

SAS-GPIO0

JPA2

USB2/3

BPI2C

A

LED4

LAN2

JPL1

SATA-GPIO0

SATA4

SAS1

SAS0

SATA3

JD1

JP2

JP1

SATA-GPIO1

SATA2

SAS3

SAS2

LSI
SAS
CTRL

CPU2

SATA1

SAS4

Fan 2

LED6

CPU2 VRM OH LED

C

Fan 3

PWR LED

LED3

FP CTRL

JPA1

SATA0

LED1

Floppy

IDE

JL1

SAS6

SAS7

SAS5

Fan 4

2-29

X7DCL-3/X7DCL-i User's Manual

SAS LED Indicator (LED1)

A SAS LED is located at LED1 on the

motherboard. This LED indicates the status

of SAS connections. Refer to the table on

the right for LED1 settings. See the layout

below for the LED location.

(Available on the X7DCL-3 only)

SAS LED Indicator

Settings

LED# Description

LED1: On SAS: Active

LED1: Off SAS: Not Active

A. LED1: SAS LED

CPU1

CPU1 VRM OH LED

LED5

JPWF1

JAR

KB/MS

USB0/1

COM1

VGA

8-Pin PWR

24-Pin PWR

DIMM2A

DIMM1A

DIMM2B

DIMM1B

DIMM2C

DIMM1C

SMB_PS

Fan 1

X7DCL-3/i

LAN1

JPL2

FAN6

VGA

CTRL

LAN

CTRL

FAN5

I-Button

LAN

CTRL

JPG1

SI/O

JWOR1

JKEY1

JI2C2

JWD1

Slot6 PCI-E x8

Slot5 PCI-E x8

JI2C1

Slot4 PCI-E x4(in x8 slot)

Slot3 PCI 33MHz

Slot2 PCI 33MHz

Slot1 PCI 33MHz

SIMLC

JWOL1

Intel

North Bridge

SP1

Buzzer

5100

System Status LED

Intel

ICH9R

South Bridge

SATA5

JBT1

BIOS

Battery

ITE

SAS-GPIO1

CTRL

SAS-GPIO0

USB4/5

JPA2

USB2/3

BPI2C

LED4

LAN2

JPL1

COM2

SATA-GPIO0

SATA4

SAS1

SAS0

SATA3

JD1

JP2

JP1

SATA-GPIO1

SATA2

SAS2

CPU2

Fan 2

LED6

CPU2 VRM OH LED

Fan 3

PWR LED

LED3

FP CTRL

JPA1

A

SATA1

SATA0

LED1

LSI

SAS

CTRL

SAS3

SAS4

Floppy

IDE

JL1

SAS6

SAS7

SAS5

Fan 4

2-30

Chapter 2: Installation

2-8 Floppy Drive, SIMLC IPMI and Hard Disk Drive
Connections

Note the following when connecting the fl oppy and hard disk drive cables:

• The fl oppy disk drive cable has seven twisted wires.

• A red mark on a wire typically designates the location of pin 1.

Floppy Drive Connector

Floppy Connector

The fl oppy connector is located at

JFDD1. See the table below for pin

defi nitions.

JPWF1

KB/MS

USB0/1

COM1

VGA

JAR

8-Pin PWR

DIMM2A

DIMM1A

DIMM2B

DIMM1B

DIMM2C

DIMM1C

24-Pin PWR

X7DCL-3/i

LAN1

JPL2

LAN2

LAN

CTRL

FAN5

FAN6

I-Button

LAN

CTRL

Slot6 PCI-E x8

JPL1

VGA

CTRL

SI/O

COM2

Slot5 PCI-E x8

JI2C2

JI2C1

Slot4PCI-Ex4(inx8slot)

JPG1

JWOR1

JKEY1

Slot3 PCI 33MHz

Slot2 PCI 33MHz

JWD1

JWOL1

Slot1 PCI 33MHz

SIMLC

Intel

North Bridge

SP1

Buzzer

5100

System Status LED

LED4

SMB_PS

BIOS

ITE

CTRL

Intel

ICH9R

South Bridge

USB4/5

Fan 1

SATA-GPIO0

SATA3

SATA4

SATA5

JBT1

JD1

Battery

SAS-GPIO1

SAS-GPIO0

JPA2

USB2/3

SAS2

SAS1

SAS0

BPI2C

JP2
JP1

SATA-GPIO1

SATA2

SAS3

CTRL

Pin# Defi nition Pin # Defi nition

1 Ground 2 FDHDIN

3 Ground 4 Reserved

5 Key 6 FDEDIN

7 Ground 8 Index

9 Ground 10 Motor Enable

11 Ground 12 Drive Select B

13 Ground 14 Drive Select B

15 Ground 16 Motor Enable

17 Ground 18 DIR

19 Ground 20 STEP

21 Ground 22 Write Data

23 Ground 24 Write Gate

25 Ground 26 Track 00

27 Ground 28 Write Protect

29 Ground 30 Read Data

31 Ground 32 Side 1 Select

33 Ground 34 Diskette

CPU1 VRM OH LED

LED5

A. Floppy Disk Drive

CPU1

CPU2

Fan 2

LED6

CPU2 VRM OH LED

Fan 3

PWR LED

LED3

FP CTRL

A

JPA1

SATA1

SATA0

LED1

LSI
SAS

SAS4

Floppy

IDE

JL1

SAS6

SAS7

SAS5

Fan 4

Pin Defi nitions (Floppy)

2-31

X7DCL-3/X7DCL-i User's Manual

IDE Connector

An IDE Connector is located at JIDE1

on the motherboard. This motherboard

uses the ITE IT8213F Controller. An

IDE Driver is required for the IDE drive

to function properly. See the table on

the right for pin defi nitions.

SIMLC IPMI Slot

A Low Profile SIMLC IPMI Slot is

located on the motherboard. Refer

to the layout below for the IPMI Slot

location.

IDE Drive Connector

Pin Defi nitions

Pin# Defi nition Pin # Defi nition

1 Reset IDE 2 Ground

3 Host Data 7 4 Host Data 8

5 Host Data 6 6 Host Data 9

7 Host Data 5 8 Host Data 10

9 Host Data 4 10 Host Data 11

11 Host Data 3 12 Host Data 12

13 Host Data 2 14 Host Data 13

15 Host Data 1 16 Host Data 14

17 Host Data 0 18 Host Data 15

19 Ground 20 Key

21 DRQ3 22 Ground

23 I/O Write 24 Ground

25 I/O Read 26 Ground

27 IOCHRDY 28 BALE

29 DACK3 30 Ground

31 IRQ14 32 IOCS16

33 Addr1 34 Ground

35 Addr0 36 Addr2

37 Chip Select 0 38 Chip Select 1

39 Activity 40 Ground

A. IDE

B. SIMLC

CPU1

CPU1 VRM OH LED

LED5

JPWF1

JAR

KB/MS

USB0/1

COM1

VGA

8-Pin PWR

24-Pin PWR

DIMM2A

DIMM1A

DIMM2B

DIMM1B

DIMM2C

DIMM1C

SMB_PS

Fan 1

X7DCL-3/i

LAN1

JPL2

FAN6

VGA

CTRL

LAN

CTRL

FAN5

I-Button

LAN

CTRL

JPG1

SI/O

JWOR1

JKEY1

JI2C2

JWD1

Slot6 PCI-E x8

Slot5 PCI-E x8

JI2C1

Slot4 PCI-E x4(in x8 slot)

Slot3 PCI 33MHz

Slot2 PCI 33MHz

Slot1 PCI 33MHz

SIMLC

JWOL1

Intel

5100

North Bridge

SP1

Buzzer

B

System Status LED

Intel

ICH9R

South Bridge

SATA5

JBT1

BIOS

Battery

ITE

SAS-GPIO1

CTRL

SAS-GPIO0

USB4/5

JPA2

USB2/3

BPI2C

LED4

LAN2

JPL1

COM2

SATA-GPIO0

SATA4

SAS1

SAS0

SATA3

JD1

JP2

JP1

SATA-GPIO1

SATA2

SAS2

CPU2

Fan 2

LED6

CPU2 VRM OH LED

Fan 3

PWR LED

LED3

FP CTRL

JPA1

SATA1

SATA0

LED1

LSI

SAS

CTRL

SAS3

SAS4

Floppy

IDE

A

JL1

SAS6

SAS7

SAS5

Fan 4

2-32

Chapter 3: Troubleshooting

Chapter 3

Troubleshooting

3-1 Troubleshooting Procedures

Use the following procedures to troubleshoot your system. If you have followed all

of the procedures below and still need assistance, refer to the ‘Technical Support

Procedures’ and/or ‘Returning Merchandise for Service’ section(s) in this chapter.

Note: Always disconnect the power cord before adding, changing or install-

ing any hardware components.

Before Power On

Make sure that there are no short circuits between the motherboard and the

1.

chassis.

Disconnect all ribbon/wire cables from the motherboard, including those for

2.

the keyboard and mouse. Remove all add-on cards.

Install a CPU in CPU Socket and connect the chassis speaker and the power

3.

LED to the motherboard. (Make sure that the CPU is properly seated. Be sure

to check all jumper settings as well.)

No Power

Make sure that there are no short circuits between the motherboard and the

1.

chassis.

Make sure that all jumpers are set to their default positions.

2.

Make sure that the 115V/230V switch on the power supply is properly set.

3.

Turn the power switch on and off to test the system. The battery on your

4.

motherboard may be old. Check to verify that it still supplies ~3VDC. If it

does not, replace it with a new one.

No Video

If the power is on but you have no video, remove all the add-on cards and

1.

cables.

Use the speaker to determine if any beep codes exist. Refer to the Appendix

2.

for details on beep codes.

Losing the System’s Setup Confi guration

Make sure that you are using a high quality power supply. A poor quality

1.

power supply may cause the system to lose the CMOS setup information.

Refer to Section 1-6 for details on recommended power supplies.

The battery on your motherboard may be old. Check to verify that it still

2.

3-1

X7DCL-3/X7DCL-i User's Manual

supplies ~3VDC. If it does not, replace it with a new one.

If the above steps do not fi x the Setup Confi guration problem, contact your

3.

vendor for repairs.

NOTE

If you are a system integrator, VAR or OEM, a POST diagnostics

card is recommended. For I/O port 80h codes, refer to App. B.

Memory Errors

Make sure the DIMM modules are properly and fully installed. Check if

1.

DIMMs of different speeds or types have been installed. Also make sure that

the BIOS setup is confi gured for the fastest speed of RAM used.

It is recommended to use the same RAM speed for all DIMMs in the system.

2.

Make sure you are using the correct type of Single-Rank, Registered ECC

DDR2 667/533 SDRAM (recommended by the manufacturer.)

Check for bad DIMM modules or slots by swapping a single module between

3.

four slots and noting the results. Make sure all memory modules are fully

seated in their slots. As an interleaved memory scheme is used, you must

install two modules at a time, beginning with DIMM 1A, then DIMM 2A, and

so on (see Section 2-3). Check the position of the 115V/230V switch on the

power supply.

3-2 Technical Support Procedures

Before contacting Technical Support, please take the following steps. Also, note

that as a motherboard manufacturer, Super Micro does not sell directly to end-us-

ers, so it is best to fi rst check with your distributor or reseller for troubleshooting

services. They should know of any possible problem(s) with the specifi c system

confi guration that was sold to you.

1.

Please go through the ‘Troubleshooting Procedures’ and 'Frequently Asked

Question' (FAQ) sections in this chapter or see the FAQs on our web site (http://

www.supermicro.com/support/faqs/) before contacting Technical Support.

2.

BIOS upgrades can be downloaded from our web site at http://www.supermicro.

com/support/bios/.

3.

If you still cannot resolve the problem, include the following information when

contacting Super Micro for technical support:

•

Motherboard model and PCB revision number

•

BIOS release date/version (this can be seen on the initial display when your

system fi rst boots up)

3-2

Chapter 3: Troubleshooting

System confi guration

•

An example of a Technical Support form is on our web site at http://www.

•

supermicro.com/support/contact.cfm/.

Distributors: For immediate assistance, please have your account number

•

ready when placing a call to our technical support department. We can be

reached by e-mail at [e-mail] or by fax at: [phone],

option 2.

3-3 Frequently Asked Questions

Question: What are the various types of memory that my motherboard can

support?

Answer: The X7DCL-3/X7DCL-i has six 240-pin DIMM slots that support Single-

Rank, Registered ECC DDR2 667/533 SDRAM modules. It is strongly recom-

mended that you do not mix memory modules of different speeds and sizes. (See

Chapter 2 for detailed Information.)

Question: How do I update my BIOS?

Answer: It is recommended that you do not upgrade your BIOS if you are experi-

encing no problems with your system. Updated BIOS fi les are located on our web

site at http://www.supermicro.com/support/bios/. Please check our BIOS warning

message and the information on how to update your BIOS on our web site. Also,

check the current BIOS revision, and make sure that it is newer than your BIOS

before downloading. Select your motherboard model and download the BIOS fi le

to your computer. Unzip the BIOS fi les onto a bootable fl oppy and reboot your

system. Follow the Readme.txt to continue fl ashing the BIOS.

(

Warning: Do not shut down or reset the system while updating BIOS to

prevent possible system boot failure!)

Question: What's on the CD that came with my motherboard?

Answer: The supplied compact disc has quite a few drivers and programs that will

greatly enhance your system. We recommend that you review the CD and install

the applications you need. Applications on the CD include chipset drivers for the

Windows OS, and security and audio drivers.

3-4 Returning Merchandise for Service

A receipt or copy of your invoice marked with the date of purchase is required

before any warranty service will be rendered. You can obtain service by calling

your vendor for a Returned Merchandise Authorization (RMA) number. When

returning to the manufacturer, the RMA number should be prominently displayed

3-3

X7DCL-3/X7DCL-i User's Manual

on the outside of the shipping carton, and mailed prepaid or hand-carried. Ship-

ping and handling charges will be applied for all orders that must be mailed when

service is complete.

This warranty only covers normal consumer use and does not cover damage in-

curred in shipping or from failure due to the alternation, misuse, abuse or improper

maintenance of products.

During the warranty period, contact your distributor fi rst for any product prob-

lems.

3-4

Chapter 4: BIOS

Chapter 4
BIOS

4-1 Introduction

This chapter describes the Phoenix BIOS™ Setup utility for the X7DCL-3/X7DCL-i.

The Phoenix ROM BIOS is stored in a fl ash chip and can be easily upgraded using

a fl oppy disk-based program.

Note: Due to periodic changes to the BIOS, some settings may have been added or

deleted and might not yet be recorded in this manual. Please refer to the Manual

Download area of the Super Micro web site <http://www.supermicro.com> for any

changes to the BIOS that may not be refl ected in this manual.

System BIOS

The BIOS is the Basic Input Output System used in all IBM® PC, XT™, AT®, and

®

PS/2

compatible computers. The Phoenix BIOS stores the system parameters,

types of disk drives, video displays, etc. in the CMOS. The CMOS memory requires

very little electrical power. When the computer is turned off, a backup battery pro-

vides power to the CMOS Logic, enabling it to retain system parameters. Each time

the computer is powered on, the computer is confi gured with the values stored in

the CMOS Logic by the system BIOS, which gains control at boot up.

How To Change the Confi guration Data

The CMOS information that determines the system parameters may be changed by

entering the BIOS Setup utility. This Setup utility can be accessed by pressing the

<Delete> key at the appropriate time during system boot. (See below.)

Starting the Setup Utility

Normally, the only visible POST (Power On Self Test) routine is the memory test. As

the memory is being tested, press the <Delete> key to enter the main menu of the

BIOS Setup utility. From the main menu, you can access the other setup screens,

such as the Security and Power menus. Beginning with Section 4-3, detailed de-

scriptions are given for each parameter setting in the Setup utility.

Warning: Do not shut down or reset the system while updating BIOS

to prevent possible boot failure.

4-1

X7DCL-3/X7DCL-i User's Manual

4-2 Running Setup

Default settings are in bold text unless otherwise noted.

The BIOS setup options described in this section are selected by choosing the ap-

propriate text from the main BIOS Setup screen. All displayed text is described in

this section, although the screen display is often all you need to understand how

to set the options (see the next page).

When you fi rst power on the computer, the Phoenix BIOS™ is immediately acti-

vated.

While the BIOS is in control, the Setup program can be activated in one of two

ways:

1. By pressing <Delete> immediately after turning the system on, or

2. When the message shown below appears briefl y at the bottom of the screen

during the POST (Power On Self-Test), press the <Delete> key to activate the main

Setup menu:

Press the <Delete> key to enter Setup

4-3 Main BIOS Setup

All main Setup options are described in this section. The main BIOS Setup screen

is displayed below.

Use the Up/Down arrow keys to move among the different settings in each menu.

Use the Left/Right arrow keys to change the options for each setting.

Press the <Esc> key to exit the CMOS Setup Menu. The next section describes in

detail how to navigate through the menus.

Items that use submenus are indicated with the

press the <Enter> key to access the submenu.

icon. With the item highlighted,

4-2

Main BIOS Setup Menu

Chapter 4: BIOS

Main Setup Features

System Time

To set the system date and time, key in the correct information in the appropriate

fi elds. Then press the <Enter> key to save the data.

System Date

Using the arrow keys, highlight the month, day and year fi elds, and enter the correct

data. Press the <Enter> key to save the data.

BIOS Date

This fi eld displays the date when this version of BIOS was built.

Legacy Diskette A

This setting allows the user to set the type of fl oppy disk drive installed as diskette A.

The options are Disabled, 360Kb 5.25 in, 1.2MB 5.25 in, 720Kb 3.5 in, 1.44/1.25MB,

3.5 in and 2.88MB 3.5 in.

4-3

X7DCL-3/X7DCL-i User's Manual

 IDE Primary Master/Slave, SATA Port1, SATA Port2, SATA Port3
and SATA Port4

These settings allow the user to set the parameters of IDE Primary Master/Slave,
SATA Port1 Master/Slave, SATA Port2 Master/Slave, SATA Port3 Master, and

SATA Port4 Master slots. Hit <Enter> to activate the following sub-menu screen

for detailed options of these items. Set the correct confi gurations accordingly. The

items included in the sub-menu are:

Type

This option allows the user to select the type of IDE hard drive. The option

Auto will allow the BIOS to automatically confi gure the parameters of the

HDD installed at the connection. Enter a number between 1 to 39 to select a

predetermined HDD type. Select User to allow the user to enter the parameters

of the HDD installed. Select CDROM if a CDROM drive is installed. Select ATAPI

if a removable disk drive is installed.

4-4

Chapter 4: BIOS

CHS Format

The following items will be displayed by the BIOS:

TYPE: This item displays the type of IDE or SATA Device.

Cylinders: This item indicates the status of Cylinders.

Headers: This item indicates the number of headers.

Sectors: This item displays the number of sectors.

Maximum Capacity: This item displays the maximum storage capacity of the

system.

LBA Format

The following items will be displayed by the BIOS:

Total Sectors: This item displays the number of total sectors available in the

LBA Format.

Maximum Capacity: This item displays the maximum capacity in the LBA

Format.

Multi-Sector Transfers

This item allows the user to specify the number of sectors per block to be used

in multi-sector transfer. The options are Disabled, 4 Sectors, 8 Sectors, and

16 Sectors.

LBA Mode Control

This item determines whether the Phoenix BIOS will access the IDE Channel 0

Master Device via the LBA mode. The options are Enabled and Disabled.

32 Bit I/O

This option allows the user to enable or disable the function of 32-bit data transfer.

The options are Enabled and Disabled.

Transfer Mode

This option allows the user to set the transfer mode. The options are Standard,

Fast PIO1, Fast PIO2, Fast PIO3, Fast PIO4, FPIO3/DMA1 and FPIO4/DMA2.

Ultra DMA Mode

This option allows the user to select Ultra DMA Mode. The options are Disabled,

Mode 0, Mode 1, Mode 2, Mode 3, Mode 4, and Mode 5.

4-5

X7DCL-3/X7DCL-i User's Manual

Serial ATA

This setting allows the user to enable or disable the function of the Serial ATA. The

options are Disabled and Enabled.

Native Mode Operation

Select the native mode for ATA. The options are: Parallel ATA, Serial ATA, Both,

and Auto.

SATA Controller Mode

Select Compatible to allow the SATA and PATA drives to be automatically-detected

and be placed in the Legacy Mode by the BIOS. Select Enhanced to allow the

SATA and PATA drives to be to be automatically-detected and be placed in the

Native IDE Mode. (Note: The Enhanced mode is supported by the Windows

2000 OS or a later version.)

When the SATA Controller Mode is set to "Enhanced", the following items will

display:

Serial ATA (SATA) RAID Enable

Select Enable to enable Serial ATA RAID Functions. (For the Windows OS

environment, use the RAID driver if this feature is set to Enabled. If this item is

set to Disabled, the item-SATA AHCI Enable will be available.) The options are

Enabled and Disabled.

ICH RAID Code Base

Select Intel to enable Intel's SATA RAID fi rmware to confi gure Intel's SATA RAID

settings.

SATA AHCI

Select Enable to enable the function of Serial ATA Advanced Host Interface. (Take

caution when using this function. This feature is for advanced programmers only.

The options are Enabled and Disabled.)

System Memory

This display informs you how much system memory is recognized as being present

in the system.

Extended Memory

This display informs you how much extended memory is recognized as being

present in the system.

4-6

Chapter 4: BIOS

4-4 Advanced Setup

Choose Advanced from the Phoenix BIOS Setup Utility main menu with the arrow keys.

You should see the following display. The items with a triangle beside them have sub

menus that can be accessed by highlighting the item and pressing <Enter>.

Boot Features

Access the submenu to make changes to the following settings.

QuickBoot Mode

If enabled, this feature will speed up the POST (Power On Self Test) routine by

skipping certain tests after the computer is turned on. The settings are Enabled

and Disabled. If Disabled, the POST routine will run at normal speed.

QuietBoot Mode

This setting allows you to Enable or Disable the graphic logo screen during boot-

up.

POST Errors

Set to Enabled to display POST Error Messages if an error occurs during bootup.

If set to Disabled, the system will continue to boot without displaying any error

message even when a boot error occurs.

ACPI Mode

Use the setting to determine if you want to employ ACPI (Advanced Confi guration

and Power Interface) power management on your system. The options are Yes

and No.

4-7

X7DCL-3/X7DCL-i User's Manual

Power Button Behavior

If set to Instant-Off, the system will power off immediately as soon as the user
hits the power button. If set to 4-sec., the system will power off when the user
presses the power button for 4 seconds or longer. The options are instant-off and
4-sec override.

Resume On Modem Ring

Select On to “wake your system up” when an incoming call is received by your
modem. The options are On and Off.

Power Loss Control

This setting allows you to choose how the system will react when power returns

after an unexpected loss of power. The options are Stay Off, Power On, and

Last State.

Watch Dog

If enabled, this option will automatically reset the system if the system is not active

for more than 5 minutes. The options are Enabled and Disabled.

Summary Screen

This setting allows you to Enable or Disable the summary screen which displays

the system confi guration during bootup.

Memory Cache

Cache System BIOS Area

This setting allows you to designate a reserve area in the system memory to be used

as a System BIOS buffer to allow the BIOS to write (cache) data into this reserved

memory area. Select Write Protect to enable this function, and this area will be

reserved for BIOS ROM access only. Select Uncached to disable this function and

make this area available for other devices.

Cache Video BIOS Area

This setting allows you to designate a reserve area in the system memory to be

used as a Video BIOS buffer to allow the BIOS to write (cache) data into this

reserved memory area. Select Write Protect to enable the function and this area

will be reserved for Video BIOS ROM access only. Select Uncached to disable this

function and make this area available for other devices.

4-8

Chapter 4: BIOS

Cache Base 0-512K

If enabled, this feature will allow the data stored in the base memory area: block

0-512K to be cached (written) into a buffer, a storage area in the Static DROM

(SDROM) or to be written into L1, L2 cache inside the CPU to speed up CPU

operations. Select Uncached to disable this function. Select Write Through to allow

data to be cached into the buffer and written into the system memory at the

same time. Select Write Protect to prevent data from being written into the base

memory area of Block 0-512K. Select Write Back to allow the CPU to write data

back directly from the buffer without writing data to the System Memory for fast

CPU data processing and operation. The options are Uncached, Write Through,

Write Protect, and Write Back.

Cache Base 512K-640K

If enabled, this feature will allow the data stored in the memory area: 512K-640K

to be cached (written) into a buffer, a storage area in the Static DROM (SDROM)

or written into L1, L2, L3 cache inside the CPU to speed up CPU operations.

Select Uncached to disable this function. Select Write Through to allow data to

be cached into the buffer and written into the system memory at the same time.

Select Write Protect to prevent data from being written into the base memory

area of Block 512-640K. Select Write Back to allow the CPU to write data back

directly from the buffer without writing data to the System Memory for fast CPU

data processing and operation. The options are Uncached, Write Through, Write

Protect, and Write Back.

Cache Extended Memory

If enabled, this feature will allow the data stored in the extended memory area to

be cached (written) into a buffer, a storage area in the Static DROM (SDROM)

or written into L1, L2, L3 cache inside the CPU to speed up CPU operations.

Select Uncached to disable this function. Select Write Through to allow data

to be cached into the buffer and written into the system memory at the same

time. Select Write Protect to prevent data from being written into the extended

memory area above 1MB. Select Write Back to allow the CPU to write data back

directly from the buffer without writing data to the System Memory for fast CPU

data processing and operation. The options are Uncached, Write Through, Write

Protect, and Write Back.

Discrete MTRR Allocation

If enabled, MTRRs (-Memory Type Range Registers) are confi gured as distinct,
separate units and cannot be overlapped. If enabled, the user can achieve better
graphic effects when using a Linux graphic driver that requires the write-combining
confi guration with 4GB or more memory. The options are Enabled and Disabled.

4-9

X7DCL-3/X7DCL-i User's Manual

PCI Confi guration

Access the submenu to make changes to the following settings for PCI devices.

Onboard GLAN-1/Onboard GLAN-2 (Gigabit- LAN) OPROM

Confi gure

Select Enabled to allow the system to boot from the GLAN-1 connection or the

GLAN-2 connection. The options are Disabled and Enabled.

Reset Confi guration Data

If set to Yes, this setting clears the Extended System Confi guration Data- (ESCD)

area. The options are Yes and No.

Slot1 PCI 33MHz, Slot2 PCI 33MHz, Slot3 PCI 33MHz, Slot4 PCI-Exp.
x4, Slot5 PCI-Exp. x8, and Slot6 PCI-Exp. x8

Access the submenu for each of the settings above to make changes to the

following:

Option ROM Scan

When enabled, this setting will initialize the device expansion ROM. The options

are Enabled and Disabled.

Enable Master

This setting allows you to enable the selected device as the PCI bus master.

The options are Enabled and Disabled.

Latency Timer

This setting allows you to set the clock rate for Bus Master. A high-priority, high-

throughout device may benefi t from a greater clock rate. The options are Default,

0020h, 0040h, 0060h, 0080h, 00A0h, 00C0h, and 00E0h. For Unix, Novell and

other Operating Systems, please select the option: other. If a drive fails after

the installation of a new software, you might want to change this setting and

try again. A different OS requires a different Bus Master clock rate.

Large Disk Access Mode

This setting determines how large hard drives are to be accessed. The options are

DOS or Other (for Unix, Novelle NetWare and other operating systems).

4-10

Chapter 4: BIOS

Advanced Chipset Control

Access the submenu to make changes to the following settings.

Warning: Take Caution when changing the Advanced settings. An incorrect

setup, a very high DRAM frequency or an incorrect DRAM timing may cause

the system become unstable. When this occurs, reset the setting to the default

setting.

Crystal Beach Features

This feature cooperates with the Intel I/O AT (Acceleration Technology) to accelerate
the performance of TOE devices. (Note: A TOE device is a specialized, dedicated
processor that is installed on an add-on card or a network card to handle some or all
packet processing of this add-on card. For this motherboard, the TOE device is built

inside the ICH9R South Bridge chip.) The options are Enabled and Disabled.

SERR Signal Condition

This setting specifi es the ECC Error conditions that an SERR# is to be asserted.

The options are None, Single Bit, Multiple Bit, and Both.

4GB PCI Hole Granularity

This feature allows you to select the granularity of PCI hole for PCI slots. If MTRRs

are not enough, this option may be used to reduce MTRR occupation. The options

are: 256 MB, 512 MB, 1GB and 2GB.

Route Port 80h Cycles to

This feature allows the user to decide which bus to send debug information to. The

options are Disabled, PCI and LPC.

Enabling Multi-Media Timer

Select Yes to activate a set of timers that are alternative to the traditional 8254

timers for the OS use. The options are Yes and No.

USB Host Controller 1

Select Enabled to enable USB Host Controller 1. The options are Enabled and

Disabled.

USB Host Controller 2

Select Enabled to enable USB Host Controller 2. The options are Enabled and

Disabled.

Legacy USB Support

This setting allows you to enable support for Legacy USB devices. The settings

are Enabled and Disabled.

4-11

X7DCL-3/X7DCL-i User's Manual

Advanced Processor Options

Access the submenu to make changes to the following settings.

CPU Speed

This is a display that indicates the speed of the installed processor.

Frequency Ratio (Available if supported by the CPU.)

The feature allows the user to set the internal frequency multiplier for the CPU.

The options are: Default, x12, x13, x14, x15, x16, x17 and x18.

Core-Multi-Processing (Available if supported by the CPU.)

Set to Enabled to use a processor's Second Core and beyond. (Please refer to

Intel's web site for more information.) The options are Disabled and Enabled.

Thermal Management 2 (Available if supported by the CPU.)

Set to Enabled to use Thermal Management 2 (TM2) which will lower CPU voltage

and frequency when the CPU temperature reaches a predefi ned overheat threshold.

Set to Disabled to use Thermal Manager 1 (TM1), allowing CPU clocking to be

regulated via CPU Internal Clock modulation when the CPU temperature reaches

the overheat threshold.

C1 Enhanced Mode (Available if supported by the CPU.)

Set to Enabled to enable Enhanced Halt State to lower CPU voltage/frequency to

prevent overheat. The options are Enabled and Disabled. (Note: please refer to

Intel’s web site for detailed information.)

Execute Disable Bit (Available if supported by the CPU and the
OS.)

Set to Enabled to enable Execute Disable Bit and allow the processor to classify

areas in memory where an application code can execute and where it cannot, and

thus preventing a worm or a virus from inserting and creating a fl ood of codes to

overwhelm the processor or damage the system during an attack. This feature is

available when your OS and your CPU support the function of Execute Disable

Bit. The options are Disabled and Enabled. Note: For more information regarding

hardware/software support for this function, please refer to Intel's and Microsoft's

web sites.

Intel <R> Virtualization Technology (Available if supported by the
CPU.)

Select Enabled to use the feature of Virtualization Technology to allow one platform

to run multiple operating systems and applications in independent partitions, creating

multiple "virtual" systems in one physical computer. The options are Enabled and

Disabled. Note: If there is any change to this setting, you will need to power off

4-12

Chapter 4: BIOS

and restart the system for the change to take effect. Please refer to Intel’s web site

for detailed information.

Intel EIST Support (Available if supported by the CPU.)

Select Enabled to use the Enhanced Intel SpeedStep Technology and allows the

system to automatically adjust processor voltage and core frequency in an effort

to reduce power consumption and heat dissipation. The options are Enabled and

Disabled. Please refer to Intel’s web site for detailed information.

I/O Device Confi guration

Access the submenu to make changes to the following settings.

KBC Clock Input

This setting allows you to select clock frequency for KBC. The options are 6MHz,

8MHz, 12MHz, and 16MHz.

Serial Port A

This setting allows you to assign control of serial port A. The options are Enabled

(user defi ned), Disabled, and Auto (BIOS- or OS- controlled).

Base I/O Address

This setting allows you to select the base I/O address for serial port A. The options

are 3F8, 2F8, 3E8, and 2E8.

Interrupt

This setting allows you to select the IRQ (interrupt request) for serial port A. The
options are IRQ3 and IRQ4.

Serial Port B

This setting allows you to assign control of serial port B. The options are Enabled

(user defi ned), Disabled, Auto (BIOS controlled) and OS Controlled.

Mode

This setting allows you to set the type of device that will be connected to serial

port B. The options are Normal and IR (for an infrared device).

Base I/O Address

This setting allows you to select the base I/O address for serial port B. The

options are 3F8, 2F8, 3E8 and 2E8.

Interrupt

This setting allows you to select the IRQ (interrupt request) for serial port B. The

options are IRQ3 and IRQ4.

4-13

X7DCL-3/X7DCL-i User's Manual

Floppy Disk Controller

This setting allows you to assign control of the fl oppy disk controller. The options

are Enabled (user defi ned), Disabled, and Auto (BIOS and OS controlled).

Base I/O Address

This setting allows you to select the base I/O address for the Floppy port. The

options are Primary and Secondary.

DMI Event Logging

Access the submenu to make changes to the following settings.

Event Log Validity

This is a display to inform you of the event log validity. It is not a setting.

Event Log Capacity

This is a display to inform you of the event log capacity. It is not a setting.

View DMI Event Log

Highlight this item and press <Enter> to view the contents of the event log.

Event Logging

This setting allows you to Enable or Disable event logging.

ECC Event Logging

This setting allows you to Enable or Disable ECC event logging.

Mark DMI Events as Read

Highlight this item and press <Enter> to mark the DMI events as read.

Clear All DMI Event Logs

Select Yes and press <Enter> to clear all DMI event logs. The options are Yes

and No.

4-14

Chapter 4: BIOS

Console Redirection

Access the submenu to make changes to the following settings.

COM Port Address

This item allows you to specify which COM port to direct the remote console to:

Onboard COM A or Onboard COM B. This setting can also be Disabled.

BAUD Rate

This item allows you to set the BAUD rate for the console redirection. The options

are 300, 1200, 2400, 9600, 19.2K, 38.4K, 57.6K, and 115.2K.

Console Type

This item allows you to choose the console redirection type. The options are VT100,

VT100/8bit, PC-ANSI/7bit, PC ANSI, VT100+,

and VT-UTF8.

Flow Control

This item allows you to set the fl ow control for the console redirection. The options

are: None, XON/XOFF, and CTS/RTS.

Console Connection

This item allows you to decide how the console redirection is to be connected:

either Direct or Via Modem.

Continue CR after POST

This item allows you to decide whether you want to continue with the console

redirection after POST routines. The options are On and Off.

4-15

X7DCL-3/X7DCL-i User's Manual

Hardware Monitor Logic

CPU Temperature Threshold

This option allows the user to set a CPU temperature threshold that will activate the

alarm system when the CPU temperature reaches this pre-set temperature threshold.

The hardcode default setting is 80

CPU is 75oC and for the 5000 Series CPU is 80oC.) (See below.)

Temperature Monitoring (Available if supported by the CPU)

This function monitors the following PECI (Platform Environment Control Interface)

items:

CPU1 Temperature/CPU1 Second Core/CPU2 Temperature/CPU2 Second

Core/System Temperature

Fan1-Fan6 Speeds: If the feature of Auto Fan Control is enabled, the BIOS will

automatically display the status of the fans indicated in this item.

o

C. (The default setting for the Intel 5100 Series

Fan Speed Control Modes

This feature allows the user to decide how the system controls the speeds of the

onboard fans. The CPU temperature and the fan speed are correlative. When

the CPU on-die temperature increases, the fan speed will also increase, and vice

versa. If the option is set to 3-pin fan, the fan speed is controlled by voltage. If the

option is set to 4-pin, the fan speed will be controlled by Pulse Width Modulation

(PWM). Select 3-pin if your chassis came with 3-pin fan headers. Select 4-pin if

your chassis came with 4-pin fan headers. Select Workstation if your system is

used as a Workstation. Select Server if your system is used as a Server. Select

Disable to disable the fan speed control function to allow the onboard fans to run

at full speed (12V) at all times. The Options are: 1. Disable, 2. 3-pin (Server), 3.

3-pin (Workstation), 4. 4-pin (Server) and 5. 4-pin (Workstation).

Voltage Monitoring

The following items will be monitored and displayed:

Vcore A:/Vcore B:/-12V/+12V/P1V5/+3.3V/5Vsb/5VDD/P_VTT/Vbat

Note: In the Windows OS environment, the Supero Doctor III settings take prece-

dence over the BIOS settings. When fi rst installed, Supero Doctor III adopts the

temperature threshold settings previously set in the BIOS. Any subsequent changes

to these thresholds must be made within Supero Doctor, since the SD III settings

override the BIOS settings. For the Windows OS to adopt the BIOS temperature

threshold settings, please change the SDIII settings to be the same as those set

in the BIOS.

4-16

Chapter 4: BIOS

IPMI (The option is available only when an IPMI card is installed

in the system.)

0IP0M0000I Specification Version:

Version.

This item displays the current IPMI

Firmware Version: This item displays the current Firmware Version.

System Event Logging

Select Enabled to enable IPMI Event Logging. When this function is set to Disabled,

the system will continue to log events received via system interface. The options

are Enabled and Disabled.

Clear System Event Logging

Enabling this function to force the BIOS to clear the system event logs during the

next cold boot. The options are Enabled and Disabled.

Existing Event Log Number

This item displays the number of the existing event log.

Event Log Control

System Firmware Progress

Enabling this function to log POST progress. The options are Enabled and

Disabled.

BIOS POST Errors

Enabling this function to log POST errors. The options are Enabled and

Disabled.

BIOS POST Watch Dog

Set to Enabled to enable POST Watch Dog. The options are Enabled and

Disabled.

4-17

X7DCL-3/X7DCL-i User's Manual

OS Boot Watch Dog

Set to Enabled to enable OS Boot Watch Dog. The options are Enabled and

Disabled.

Timer for Loading OS (Minutes)

This feature allows the user to set the time value (in minutes) for the previous

item: OS Boot Watch Dog by keying-in a desired number in the blank. The default

setting is 10 (minutes.) (Please ignore this option when OS Boot Watch Dog is set

to "Disabled".)

Time Out Option

This feature allows the user to determine what action to take in an event of a system

boot failure. The options are No Action, Reset, Power Off and Power Cycles.

System Event Log/System Event Log (List Mode)

These options display the System Event (SEL) Log and System Event (SEL) Log

in List Mode. Items include: SEL (System Event Log) Entry Number, SEL Record

ID, SEL Record Type, Time Stamp, Generator ID, SEL Message Revision, Sensor

Type, Sensor Number, SEL Event Type, Event Description, and SEL Event Data.

4-18

Chapter 4: BIOS

Realtime Sensor Data

This feature display information from motherboard sensors, such as temperatures,

fan speeds and voltages of various components.

4-19

X7DCL-3/X7DCL-i User's Manual

4-5 Security

Choose Security from the Phoenix BIOS Setup Utility main menu with the arrow

keys. You should see the following display. Security setting options are displayed

by highlighting the setting using the arrow keys and pressing <Enter>. All Security

BIOS settings are described in this section.

Supervisor Password Is:

This indicates if a supervisor password has been entered for the system. Clear

means such a password has not been used and Set means a supervisor password

has been entered for the system.

User Password Is:

This indicates if a user password has been entered for the system. Clear means

such a password has not been used and Set means a user password has been

entered for the system.

Set Supervisor Password

When the item Set Supervisor Password is highlighted, hit the <Enter> key. When

prompted, type the Supervisor's password in the dialogue box to set or to change

supervisor's password, which allows access to the BIOS.

Set User Password

When the item Set User Password is highlighted, hit the <Enter> key. When

prompted, type the user's password in the dialogue box to set or to change the

user's password, which allows access to the system at boot-up.

4-20

Chapter 4: BIOS

Password on Boot

This setting allows you to determine if a password is required for a user to enter

the system at bootup. The options are Enabled (password required) and Disabled

(password not required).

4-6 Boot

Choose Boot from the Phoenix BIOS Setup Utility main menu with the arrow keys.

You should see the following display. See details on how to change the order and

specs of boot devices in the Item Specifi c Help window. All Boot BIOS settings are

described in this section.

Boot List

Candidate
List

Boot Priority Order/Excluded from Boot Orders

The devices included in the boot list section (above) are bootable devices listed in

the sequence of boot order as specifi ed. The boot functions for the devices included

in the candidate list (above) are currently disabled. Use a <+> key or a <-> key to

move the device up or down. Use the <f> key or the <r> key to specify the type of

an USB device, either fi xed or removable. You can select one item from the boot

list and hit the <x> key to remove it from the list of bootable devices (to make its

resource available for other bootable devices). Subsequently, you can select an

item from the candidate list and hit the <x> key to remove it from the candidate

list and put it in the boot list. This item will then become a bootable device. See

details on how to change the priority of boot order of devices in the "Item Specifi c

Help" window.

4-21

X7DCL-3/X7DCL-i User's Manual

4-7 Exit

Choose Exit from the Phoenix BIOS Setup Utility main menu with the arrow keys. You

should see the following display. All Exit BIOS settings are described in this section.

Exit Saving Changes

Highlight this item and hit <Enter> to save any changes you made and to exit the

BIOS Setup utility.

Exit Discarding Changes

Highlight this item and hit <Enter> to exit the BIOS Setup utility without saving any

changes you may have made.

Load Setup Defaults

Highlight this item and hit <Enter> to load the default settings for all items in the

BIOS Setup. These are the safest settings to use.

Discard Changes

Highlight this item and hit <Enter> to discard (cancel) any changes you made.

You will remain in the Setup utility.

Save Changes

Highlight this item and hit <Enter> to save any changes you made. You will remain

in the Setup utility.

4-22

Appendix A: POST Error Beep Codes

Appendix A

POST Error Beep Codes

This section lists POST (Power On Self Test) error beep codes for the Phoenix BIOS.

POST error beep codes are divided into two categories: recoverable and terminal.

This section lists Beep Codes for recoverable POST errors.

Recoverable POST Error Beep Codes

When a recoverable type of error occurs during POST, BIOS will display a POST

code that describes the problem. BIOS may also issue one of the following beep

codes:

1 long and two short beeps - video confi guration error

1 repetitive long beep - no memory detected

A-1

X7DCL-3/X7DCL-i User's Manual

Notes

A-2

Appendix B: Installing the Windows OS

Appendix B

Installing the Windows OS

After all hardware components have been installed, you must fi rst confi gure Intel

South Bridge RAID Settings before you install the Windows OS and other software

drivers. To confi gure RAID settings, please refer to RAID Confi guration User Guides

posted on our website at www.supermicro.com/support/manuals.

B-1 Installing the Windows XP/2000/2003 OS for
Systems with RAID Functions

Insert Microsoft's Windows XP/2000/2003 Setup CD in the CD Driver, and the

1.

system will start booting up from CD.

Press the <F6> key when the message-" Press F6 if you need to install a

2.

third party SCSI or RAID driver" displays.

When the Windows XP/2000/2003 Setup screen appears, press "S" to specify

3.

additional device(s).

Insert the driver diskette-"Intel AA RAID XP/2000/2003 Driver for ICH9R" into

4.

Drive A: and press the <Enter> key.

Choose the Intel(R) ICH9R SATA RAID Controller from the list indicated in

5.

the XP/2000/2003 Setup Screen, and press the <Enter> key.

Press the <Enter> key to continue the installation process. (If you need to

6.

specify any additional devices to be installed, do it at this time.) Once all

devices are specifi ed, press the <Enter> key to continue with the installation.

From the Windows XP/2000/2003 Setup screen, press the <Enter> key. The

7.

XP/2000/2003 Setup will automatically load all device fi les and then, continue

the Windows XP/2000/2003 installation.

After the Windows XP/2000/2003 OS Installation is completed, the system will

8.

automatically reboot.

B-1

X7DCL-3/X7DCL-i User's Manual

B-2 Installing the Windows XP/2000/2003 OS for
Systems without RAID Functions

Insert Microsoft's Windows XP/2000/2003 Setup CD in the CD Driver, and the

1.

system will start booting up from CD.

Continue with the OS installation. The Windows OS Setup screen will display.

2.

From the Windows XP/2000/2003 Setup screen, press the <Enter> key. The

3.

XP/2000/2003 Setup will automatically load all device fi les and then continue

with the Windows XP/2000/2003 installation.

After the Windows XP/2000/2003 OS Installation is completed, the system will

4.

automatically reboot.

Insert the Supermicro Setup CD that came with your motherboard into the CD

5.

Drive during system boot, and the main screen will display.

B-2

Appendix C: Installing Other Software Programs and Drivers

Appendix C

Software Installation

C-1 Installing other Drivers and the OS

After you've installed the Windows Operating System, a screen as shown below

will appear. You are ready to install software programs and drivers that have not

yet been installed. To install these software programs and drivers, click the icons

to the right of these items.

Notes:

1. Click the icons showing a hand writing on the paper to view the readme fi les

for each item. Click a computer icon on the right of an item to install an item (from

top to the bottom) one at a time. After installing each item, you must re-boot

the system before proceeding with the next item on the list.

2. The X7DCL-3 supports SAS RAID features. To confi gure the LSI SAS HostRAID,

please refer to the LSI folder for the LSI SAS HostRAID Utility and documentation.

The LSI folder is included in the CD-ROM that came with your motherboard.

Driver/Tool Installation Display Screen

C-1

X7DCL-3/X7DCL-i User's Manual

C-2 Confi guring Supero Doctor III

The Supero Doctor III program is a Web-based management tool that supports

remote management capability. It includes Remote and Local Management tools.

The local management is called the SD III Client. The Supero Doctor III program

included on the CDROM that came with your motherboard allows you to monitor

the environment and operations of your system. Supero Doctor III displays crucial

system information such as CPU temperatures, system voltages and fan status.

See the Figure below for a display of the Supero Doctor III interface.

Note 1: Both default username and password are ADMIN.

Note 2: In the Windows OS environment, the Supero Doctor III settings take

precedence over the BIOS settings. When fi rst installed, Supero Doctor III adopts

the temperature threshold settings previously set in the BIOS. Any subsequent

changes to these thresholds must be made within Supero Doctor, since the SD

III settings override the BIOS settings. For the Windows OS to adopt the BIOS

temperature threshold settings, please change the SDIII settings to be the same

as those set in the BIOS.

Supero Doctor III Interface Display Screen-I (Health Information)

C-2

Appendix C: Installing Other Software Programs and Drivers

Supero Doctor III Interface Display Screen-II (Remote Control)

Note: SD III Software can be downloaded from our Web site at: ftp://ftp.

supermicro.com/utility/Supero_Doctor_III/. You can also download SDIII User's

Guide at: http://www.supermicro.com/PRODUCT/Manuals/SDIII/UserGuide.pdf.

For the Linux OS, we will still recommend that you use Supero Doctor II.

C-3

X7DCL-3/X7DCL-i User's Manual

Notes

C-4
