Specifications
?
PS2A phantom power unit could be used to power 2ps of
Representative use
JUST PLAY IT
PS2A
Phantom Power
Operating voltage
AC 100~240V (50~60Hz)
Dc output
48+/- 2V
Signal separability
>= 95dB
Current output
Max 2x6.5 mA (short circuit)
Undulatory voltage
<=0.15m V
Power consumption
2VA
RoHS
The PS2A including the product and packages follow the instruction of
EU 2002/95/EC and comply to RoHS.
Dimensions
160mm X130mm X 56mm(6.3X5.1X2.2 in)
condenser microphone or a pair of stereo condenser
microphone.
?
Very low undulation and background
noise output (lower than common
mixer's phantom unit around -12dB) suit for use in recording
system.
?
Fit to power any condenser microphone by 48V particularly
for operating CM-2, CM-5, CM-8 series microphone of
SUPERLUX, it cause low noise natural sound obtainable.
High durability even in use
?
continuously.
Wide powered range adaptable AC 100V~240V (50~60Hz)
?
ON/OFF switch attached.
Supplied accessory
Supplied with 6.5mm X 1.8M power cable (with option on "U" plug of
US. Standard or "E" plug of Eur. Standard attached)
Φ
CM series recording microphone
S241 recording/ microphoneinstrument
SMKH8K s mtereo icrophone
S125 h mheld-and icrophone
User Guide
GOANG-FANNCO.,LTD.
2007, SUPERLUX I
LB100PS2A01EN (Rev. 1)
Net weight
1400 grams (43.4 oz.)
E type
U type
nc.
ECM999 M microphoneeasurement
PRA518 mConference icrophone
Knowing your microphone
Superlux provides variety selection of microphones for professionals and amatures. To
know your microphone is the first step to successful result.
Type of transducer
Dynamics
Durable and simple structure, operates in all kinds of environments. A good dynamic
microphone is capable to operate at very high sound pressure level without distortion.
Due to structure limit, dynamics cannot be built as small as condenser, but dynamics
doesn requirepower to operate.
Condenser
Extremely light weight diaphragm, very sensitive to sound. Very small versions
available for hiding applications. High performance condenser microphones are
regarded as standard equipment of recording studios for extreme detail capturing.
Operates with power, such as phantom or battery.
Powering microphone
Condenser microphones work with power. Professional standard is 48VDC phantom
power. Some microphones work with lower voltage as low as 1.5VDC, such as battery
power model.
Distance to source
Close miking or distant miking sound very differently. Vocal recording or live
performance practice close miking mostly. Suitable proximity effect is one desired
target, and lower feedback problemis another factorfor live soundapplication.
While distant miking is common practice for recording, especially stereo pair
recording withlarge groupof performers, suchas orchestra or choir.
Distant miking generally picks up less bass section with pressure gradient type of
microphone (cardioid, figure-8, shotgun...) due to acoustic nature and lack of
proximity effects.
Rich bass with distant miking can be recorded with pressure type of microphone
(Omni), which performsthe same frequency response with close or distant pick-up.
Mounting the microphone
Pressure gradient microphone is very sensitive to vibration. Suitable shock mount for
high performance microphone is necessary for extreme low noise recording. Sturdy
stand can set the microphone excatly at the sweet spot and keep it there. Choose heavy
duty microphone stand for studio condenser microphone which weights much more
than handle microphone.
Superlux provides wide range of microphone stands for various demands. Big Foot
Willie is specially developed for large condenser microphones that able to support 2
large microphoneswith stereo bracket for single point stereo recording.
Extension foot on all the 'E' versions serve to mount heavy studio microphone in limit
space live soundapplications.
