HOMEOWNER'S CARE AND
sledoMtlovilliMsledoMcinortcelE
NMC-TSDCNMC-LCDCNEC-TSDCNEC-LCDC
PMC-TSDCPMC-LCDCPEC-TSDCPEC-LCDC
NMC-FPDCNMC-RCDCNEC-FPDCNEC-RCDC
PMC-FPDCPMC-RCDCPEC-FPDCPEC-RCDC
OPERATION INSTRUCTIONS
DIRECT VENT
MULTI-OPEN SERIES
VENTED GAS FIREPLACE HEATERS - DIRECT VENT MODELS
P/N 725,001M REV. F 09/2005
CDST (See-through)
CDCL (Corner-Left) CDCR (Corner-Right)
RETAIN THESE INSTRUCTIONS
FOR FUTURE REFERENCE
WH Report No. J20006712
WARNING: IF THE INFORMATION IN THIS MANUAL
IS NOT FOLLOWED EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
FOR YOUR SAFETY: Do not store or use gasoline
or other flammable vapors or liquids in the vicinity of this or any other appliance.
FOR YOUR SAFETY: What to do if you smell gas:
• DO NOT light any appliance.
• DO NOT touch any electrical switches.
• DO NOT use any phone in your building.
• Immediately call your gas supplier from a
neighbor’s phone.
Follow your gas suppliers instructions.
• If your gas supplier cannot be reached, call the
fire department.
Installation and service must be performed by a
qualified installer, service agency or the gas
supplier.
CDPF (Peninsula)
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
MODELS
A French manual is available upon request. Order Form Number
725,001CF.
Ce manuel d’installation est disponible en francais, simplement en
faire la demande. Numéro de la pièce 725,001CF.
AVERTISSEMENT: ASSUREZ-VOUS DE BIEN SUIVRE
LES INSTRUCTIONS DONNÉ DANS CETTE NOTICE POUR
RÉDUIRE AU MINIMUM LE RISQUE D'INCENDIE OU
POUR ÉVITER TOUT DOMMAGE MATÉRIEL, TOUTE
BLESSURE OU LA MORT.
POUR VOTRE SÉCURITÉ: Ne pas entreposer ni utiliser
d'essence ni d'autre vapeurs ou liquides inflammables
dans le voisinage de cet appareil ou de tout autre
appareil.
POUR VOTRE SÉCURITÉ: Que faire si vous sentez une
odeur de gaz:
• Ne pas tenter d'allumer d'appareil.
• Ne touchez à aucun interrupteur. Ne pas vous servir
des téléphones se trouvant dans le batiment où
vous vous trouvez.
• Evacuez la piéce, le bâtiment ou la zone.
• Appelez immédiatement votre fournisseur de gaz
depuis un voisin. Suivez les instructions du
fournisseur.
• Si vous ne pouvez rejoindre le fournisseur de gaz,
appelez le service dos incendies.
L'installation et service doit être exécuté par un qualifié
installeur, agence de service ou le fournisseur de gaz.
1
CONGRATULATIONS!
GENERAL INFORMATION
In selecting this SUPERIOR Direct-Vent Gas Appliance you have chosen the finest and
most dependable fireplace to be found anywhere. It's a beautiful, prestigious alternative
to a wood burning fireplace. Welcome to a Family of tens of thousands of satisfied
SUPERIOR Fireplace Owners.
Please carefully read and follow all of the instructions found in this manual. Please pay
special attention to the safety instructions provided in this manual. The Homeowner's
Care and Operation Instructions included here will assure that you have many years of
dependable and enjoyable service from your SUPERIOR product.
TABLE OF CONTENTS
Introduction..................................... page 2
General Information......................... page 2
Operation/Care of Your Appliance.... page 3
Variable Flame Adjustment .............. page 4
Glass Cleaning................................. page 4
Maintenance .................................... page 4
Front Glass Enclosure Panel,
Removal and Installation ............... page 4
Maintenance Schedule..................... page 5
Burner Adjustments......................... page 6
Flame Appearance and Sooting ....... page 6
Adjustment ...................................... page 6
Log Placement,Decorative Volcanic Stone and
Glowing Embers (Rockwool) ........... page 7
Ceramic Fiber Chunks Placement .... page 7
Millivolt Appliance Checkout............ page 7
Electronic Appliance Checkout......... page 8
Wiring Diagrams.............................. page 8
Warranty.......................................... page 8
Replacement Parts ........................... page 8
Product Reference Information ....... page 8
Accessory Components................... page 9
Lighting Instructions – Millivolt....... page 12
Lighting Instructions – Electronic.... page 14
Troubleshooting Guide – Millivolt ..... page 16
Troubleshooting Guide – Electronic .. page 17
Replacement Parts List..................... page 18
INTRODUCTION
The Fireplace models covered in this manual
are Direct-Vent sealed combustion gas fireplace heaters designed for residential application. Direct-Vent appliances operate with the
combustion chamber completely isolated from
the indoor environment. All air for combustion is brought in from the outside and exhaust gases are vented through the same
direct vent, vent system.
The millivolt appliances are designed to operate on either natural or propane gas. A millivolt
gas control valve with piezo ignition system
provides safe, efficient operation. If any optional accessories which require electrical
power are being installed, the electrical power
must be provided at the time of appliance
installation.
The electronic appliances are designed to operate on either natural or propane gas. An
electronic intermittent pilot system provides
safe, efficient operation. External electrical
power is required to operate these units.
These appliances comply with National Safety
Standards and are tested and listed by Warnock
Hersey (Report No. J20006712) to ANSI
Z21.88-2000 (in Canada, CSA-2.33-2000), and
CAN/CGA-2.17-M91 in both USA and Canada,
as vented gas fireplace heaters.
Installation must conform to local codes. In
the absence of local codes, installation must
comply with the current National Fuel Gas
Code, ANSI Z223.1 (NFPA 54). (In Canada, the
current CAN/CGA B149 installation code.) Electrical wiring must comply with local codes. In
the absence of local codes, installation must
be in accordance with the National Electrical
Code, NFPA 70 - (latest edition). (In Canada,
the current CSA C22.1 Canadian Electric Code.)
DO NOT ATTEMPT TO ALTER OR MODIFY
THE CONSTRUCTION OF THE APPLIANCE OR
ITS COMPONENTS. ANY MODIFICATION OR
ALTERATION MAY VOID THE WARRANTY,
CERTIFICATION AND LISTINGS OF THIS UNIT.
WARNING: IMPROPER INSTALLATION,
ADJUSTMENT, ALTERATION, SERVICE
OR MAINTENANCE CAN CAUSE INJURY
OR PROPERTY DAMAGE. REFER TO
THIS MANUAL. FOR ASSISTANCE OR
ADDITIONAL INFORMATION CONSULT
A QUALIFIED INSTALLER, SERVICE
AGENCY OR THE GAS SUPPLIER.
Note: Installation and repair should be per-
formed by a qualified service person. The appliance should be inspected annually by a qualified professional service technician. More frequent inspections and cleanings may be required due to excessive lint from carpeting,
bedding material, etc. It is imperative that the
control compartment, burners and circulating
air passage ways of the appliance be kept clean.
S'assurer que le brùleur et le compartiment
des commandes sont propres. Voir les instructions d'installation et d'utilisation qui
accompagnent l'appareil.
Provide adequate clearances around air openings and adequate accessibility clearance for
service and proper operation. Never obstruct
the front openings of the appliance.
Due to high temperatures the appliance should
be located out of traffic and away from furniture and draperies. Locate furniture and window coverings accordingly.
WARNING: THESE FIREPLACES ARE
VENTED HEATERS. DO NOT BURN
WOOD OR OTHER MATERIAL IN THESE
APPLIANCES.
These appliances are designed to operate on
natural or propane gas only.
On Millivolt models the input of the appliance can
be adjusted between 30,000 and 37,500 BTU/HR
when using natural gas or propane gas.
On Electronic models the input is fixed at 37,500
BTU/HR for both gas types.
The following table shows the units' orifice size
for the elevations indicated.
.taN.porP
44#55#
*ezisecifirO
noitavelE
)sretem(teeF
0054-0
)0731-0(
ledoM
.oN
TSDC
FPDC
RCDC
LCDC
* Each model has two burners. Each burner
contains one of these orifices.
Maximum manifold pressure is 3.5 in. w.c.
(0.87 kPa) for natural gas and 10 in. w.c.
(2.49 kPa) for LP/Propane gas.
2
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Do not use these appliances if any part has
Piezo Ignitor
Gas Valve
Control
Compartment
Access panel
Hinge Pin
been under water. Immediately call a qualified,
professional service technician to inspect the
appliance and to replace any parts of the
control system and any gas control which
have been under water.
Ne pas se servir de cet appareil s'il a été plongé
dans l'eau, complètement ou en partie. Appeler
un technicien qualifié pour inspecter l'appareil et
remplacer toute partie du système de contrôle et
toute commande qui ont été plongés dans l'leau.
Test gage connections are provided on the
front of the millivolt gas control valve (identified OUT for the manifold side and IN for inlet
pressure. A ¹⁄₈" NPT test gage connection is
provided on the electronic gas control valve
adjacent to the outlet to the main burner.
Minimum inlet gas pressure to these appliances
is 5.0 inches water column (1.24 kPa) for natural
gas and 11 inches water column (2.74 kPa) for
propane for the purpose of input adjustment.
Maximum inlet gas supply pressure to these appliances is 10.5 inches water column (2.61 kPa) for
natural gas and 13.0 inches water column (3.23 kPa)
for propane.
The appliance must be isolated from the gas
supply piping system (by closing its individual
manual shut-off valve) during any pressure testing of the gas supply piping system at test
pressures equal to or less than ¹⁄₂ psig (3.5 kPa).
The appliance and its individual shut-off valve must
be disconnected from the gas supply piping system
during any pressure testing of that system at pressures in excess of ¹⁄₂ psig (3.5 kPa).
These appliances must not be connected to a
chimney or flue serving a separate solid fuel
burning appliance.
Any safety guard or screen removed for servicing the appliance must be replaced prior to
operating the appliance.
WARNING: FAILURE TO COMPLY WITH
THE INSTALLATION AND OPERATING INSTRUCTIONS PROVIDED IN THIS DOCUMENT WILL RESULT IN AN IMPROPERLY INSTALLED AND OPERATING APPLIANCE, VOIDING ITS WARRANTY.
ANY CHANGE TO THIS APPLIANCE AND/
OR ITS OPERATING CONTROLS IS DANGEROUS. IMPROPER INSTALLATION
OR USE OF THIS APPLIANCE CAN CAUSE
SERIOUS INJURY OR DEATH FROM FIRE,
BURNS, EXPLOSION OR CARBON MONOXIDE POISONING.
Carbon Monoxide Poisoning: Early signs of
carbon monoxide poisoning are similar to
the flu with headaches, dizziness and/or nausea. If you have these signs, obtain fresh air
immediately. Turn off the gas supply to the
appliance and have it serviced by a qualified
professional, as it may not be operating
correctly.
WARNING: CHILDREN AND ADULTS
SHOULD BE ALERTED TO THE HAZARDS
OF HIGH SURFACE TEMPERATURES. USE
CAUTION AROUND THE APPLIANCE TO
AVOID BURNS OR CLOTHING IGNITION.
YOUNG CHILDREN SHOULD BE CAREFULLY SUPERVISED WHEN THEY ARE IN
THE SAME ROOM AS THE APPLIANCE.
WARNING: DO NOT PLACE CLOTHING
OR OTHER FLAMMABLE MATERIALS
ON OR NEAR THIS APPLIANCE.
AVERTISSEMENT: SURVEILLER LES
ENFANTS. GARDER LES VÊTEMENTS,
LES MEUBLES, L'ESSENCE OU AUTRES
LIQUIDES À VAPEUR INFLAMMABLES
LOIN DE L'APPAREIL.
OPERATION AND CARE OF YOUR
APPLIANCE
Appliance operation may be controlled by the
following means: an optional unit-mounted
ON/OFF control switch (Millivolt appliances
only), an optional wall-mounted ON/OFF control switch or an optional remote control. The
unit-mounted ON/OFF control switch may be
mounted in the bracket below the gas valve
(see Figure 2 on page 4)
.
Gas Controls/Control Compartment Access
The gas controls can be found behind the control
compartment access panel. To open the control
compartment access panel, actuate the spring
loaded magnetic catches securing the panel, by
gently depressing the outer top corners of the
panel until the catches "pop" the door free,
allowing it to swing out and down to open.
To ease door closure, depress the catches to
place them in their retracted position, then
close the door.
Millivolt appliances are fitted with the gas
control valve shown in
On these systems, the piezo ignitor, Hi/Lo flame
adjustment knob, and pilot and main gas ON/
OFF control knob are located on gas valve.
Figure 2 on page 4
.
Operation of millivolt and electronic gas control systems are different. Before lighting
and operating your appliance determine if
you have a millivolt or electronic appliance.
Refer to Figure 1
control valve. Millivolt appliances will be
fitted with the gas control valve shown in
Figure 2 on page 4
Appliances with electronic systems will be
fitted with the electronic valve shown in
3 on page 4
control valve that your appliance uses.
. Familiarize yourself with the gas
Control Compartment Access -
Millivolt Control Valve Shown
for access to the gas
.
Figure
Figure 1
Millivolt Appliances -
To light millivolt appliances refer to the detailed lighting instructions found on
(English) and page 13
pliance lighting instructions may also be
found on the pull out lighting instruction
labels attached to the gas control valve.
Millivolt appliances may be fitted with an optional ON/OFF rocker switch which is used to
control the main burner operation. The optional ON/OFF rocker switch should be installed in one of the two rectangular slots in the
piezo igniter mounting bracket below the gas
valve. Once the pilot is lit, the ON/OFF rocker
switch will control the main burner operation.
To operate: Toggle the switch between its ON
and OFF positions.
If your millivolt appliance is equipped with an
optional wall-mounted ON/OFF switch or remote control kit and the pilot is lit, the appliance main burner may be turned on and off
with the wall switch or remote control.
(French). Millivolt ap-
page 12
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
3
Variable Flame Height Adjustment
Manifold Pressure Port
TPTH TP TH
I
H
L
W
O
P
I
L
O
T
Optional Burner ON/OFF
Rocker Switch Location
Inlet Pressure Port
IN
OUT
F
F
O
P
I
L
it
O
T
O
N
Main Gas
Control Knob
Piezo Ignitor
Factory-Installed Blower ON/OFF
Rocker Switch Location
Figure 2 Millivolt Gas Valve
Electronic Appliances -
To light electronic appliances refer to the detailed lighting instructions found in both English and French on
pages 14 and 15
of these
2. When lit for the first time, this appliance will
emit a slight odor for 14 hours. This is due to the
“burn-in” of internal paints and lubricants used in
the manufacturing process.
instructions respectively. Electronic appliance
lighting instructions may also be found on the
pull out lighting instruction labels attached to
the gas control valve.
3. Keep lower control compartment clean by
vacuuming or brushing at least twice a year.
More frequent cleaning may be required due to
excessive lint from carpeting, bedding materi-
If your electronic appliance is equipped with an
optional remote wall switch or remote control
kit the appliance main burner may be turned on
als, etc. It is important that control compartments, burners and circulating air passageways of the appliance be kept clean.
and off with the wall switch or remote control.
If your electronic appliance is not equipped
with a wall switch or remote control, the main
burner must be turned off and on with the gas
control switch. Toggle the switch from ON to
OFF to operate the main burner.
4. Always turn off gas to the pilot (millivolt
appliances) and let the unit cool down before
cleaning. Before re-lighting, refer to the lighting instructions in this manual. Lighting in-
structions may also be found on the pull out
lighting instruction labels attached to the
gas control valve.
Manifold Pressure Port
ON/OFF Switch
5. Always keep the appliance area clear and
CONTROL
OFF
ON
Inlet
IG
N
IT
E
R
IN
I
S
P
Electronic
Gas Control
Valve
Pressure
Port
Figure 3 Honeywell Electronic Gas Valve
free from combustible materials, gasoline and
other flammable liquids.
6. Remember, Millivolt appliances have a continuous burning pilot flame. Exercise caution
when using products with combustible vapors.
Glass Cleaning
It will be necessary to clean the glass periodically. During start-up it is normal for condensation to form on the inside of the glass. This
Variable Flame Height Adjustment
( Millivolt Appliances only)
can cause lint, dust and other airborne particles to cling to the glass surface. Also initial
paint curing may deposit a slight film on the
1. All Millivolt appliances are equipped with a
variable gas control valve. Flame height for these
models may be adjusted through a range between fixed low and high settings while the
appliance is in operation. Adjust the flame height
as desired after lighting the appliance by rotating
the variable adjustment control knob located on
the front of the valve
(refer to Figure 2)
4
.
glass. It is therefore recommended that the
glass be cleaned two or three times with a nonammonia household cleaner and warm water (a
gas fireplace glass cleaner is recommended).
After that the glass should be cleaned two or
three times during each heating season, depending on the circumstances present.
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Note: Clean glass after first two weeks of
operation.
WARNING: DO NOT USE ABRASIVE
CLEANERS. NEVER CLEAN THE GLASS
WHEN IT IS HOT.
CAUTION: DO NOT TOUCH THE FRONT
ENCLOSURE GLASS WITH YOUR HANDS
WHILE THE FIREPLACE IS IN USE.
Maintenance
The appliance and venting system should be
thoroughly inspected before initial use and at
least annually by a qualified service technician. However, more frequent periodic inspections and cleanings should be performed by
the homeowner. Homeowner must contact a
qualified service technician at once if any
abnormal condition is observed.
Refer to the maintenance schedule for maintenance tasks, procedures, periodicity and by whom
they should be performed. Always verify proper
operation of the appliance after servicing.
IMPORTANT: TURN OFF GAS AND ANY
ELECTRICAL POWER BEFORE SERVICING
THE APPLIANCE.
Glass Enclosure Panels - Removal and
Installation.
WARNING: NEVER OPERATE THE APPLIANCE WITHOUT THE GLASS ENCLOSURE PANELS IN PLACE AND SECURE.
DO NOT OPERATE APPLIANCE WITH ANY
OF THE GLASS PANELS CRACKED, BROKEN OR MISSING. REPLACEMENT PANELS ARE AVAILABLE THROUGH YOUR
LOCAL LENNOX DEALER AND MUST BE
INSTALLED BY A LICENSED OR QUALIFIED SERVICE TECHNICIAN.
These are direct-vent appliances. They are designed to operate only with the glass enclosure
panels properly installed. Generally the glass
enclosure panels should not be removed except to gain access to the components within
the firebox, and the appliance may only be
operated without the front glass enclosure panel
in place for very brief periods of time during
initial appliance checkout and adjustment.
During this appliance checkout and adjustment period, a potential safety hazard exists
- EXERCISE EXTREME CAUTION to prevent the
occurrence of any burn injuries from the exposed flames or hot surfaces. Also note, that
while the front glass enclosure panel (or any of
the panels) is removed, the flame appearance
will appear to be smaller than normal.
Maintenance Schedule
Annually (Before the onset of the Burning Season)
Maintenance Task Accomplishing Person Procedure
Inspecting/Cleaning Burner, Logs
and Controls
Check Flame Patterns and Flame Height
Inspecting/Cleaning Pilot Burner and the Two
Main Burners
Checking Vent System
Appliance Checkout
Periodically (After the Burning Season)
Qualified Service Technician
Qualified Service Technician
Qualified Service Technician
Qualified Service Technician
Qualified Service Technician
Inspect valve and ensure it is properly operating. Check piping for leaks. Vacuum the control compartment, fireplace logs and burner
area.
Refer to
Figure 6 on page 7
and verify that the
flame pattern and height displayed by the
appliance conforms to the picture. Flames
must not impinge on the log set.
Refer to
Figure 9 on page 7 (millivolt) or Figure
10 on page 8 (electronic)
. Remove any surface
build-up on pilot and burner assembly. Clean the
pilot nozzles, ignitor/flame rod and hood with a
soft brush. Ensure the pilot flame engulfs the
flame sensor as shown.
Inspect the vent system at the top and at the
base (within the firebox) for signs of blockage
or obstruction. Look for any signs of dislocation of the vent components.
Perform the appropriate appliance checkout
procedure detailed in this manual.
Maintenance Task Accomplishing Person Procedure
Cleaning Firebox Interior
Check Flame Patterns and Flame Height
Checking Vent System
Cleaning Glass Enclosure Panels
WARNING: HANDLE THE GLASS WITH EXTREME CARE! TEMPERED GLASS IS SUSCEPTIBLE TO DAMAGE (SCRATCHES, FOR
EXAMPLE) – HANDLE GLASS DOORS (GLASS
ENCLOSURE PANELS) GENTLY WHILE REINSTALLING THEM.
Homeowner
Homeowner
Homeowner
Homeowner
WARNING: DO NOT ATTEMPT TO SUBSTITUTE THE MATERIALS USED ON THESE
DOORS, OR REPLACE CRACKED OR BROKEN GLASS WITH ANY MATERIALS OTHER
THAN THOSE PROVIDED BY THE APPLIANCE
MANUFACTURER.
Carefully remove logs, decorative volcanic stone
and glowing embers. Vacuum out interior of the
firebox. Clean firebox walls and log grate. Replace
logs, decorative volcanic stone and glowing em-
page 7
bers as detailed on
Refer to
Figure 6 on page 7
.
and verify that
the flame pattern and height displayed by the
appliance conforms to the picture. Flames
must not impinge on the log set.
Inspect the vent system at the top and at the
base (within the firebox) for signs of blockage or obstruction. Look for any signs of
dislocation of the vent components.
Clean as necessary following the directions
provided in this manual. DO NOT TOUCH OR
CLEAN GLASS WHILE IT IS HOT.
THE GLASS DOORS OF THIS APPLIANCE MUST
ONLY BE REPLACED AS A COMPLETE UNIT AS
PROVIDED BY THE MANUFACTURER. DO
NOT ATTEMPT TO REPLACE BROKEN,
CRACKED OR CHIPPED GLASS SEPARATELY.
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
5
Refer to
Figure 4
and remove the front glass
enclosure panel as follows:
1. Remove the top louver assembly or radiant
panel.
2. Open the control compartment access panel.
To open the control compartment access panel,
actuate the spring-loaded magnetic catches
securing the panel, by gently depressing the
outer top corners of the panel until the catches
"pop" the door free, allowing it to swing out and
down to open.
3. Locate the two (2) latches at the top of the
control compartment. To disengage the two
latches from the bottom vee-flange of the glass
enclosure panel, reach for the handles located
towards the back of the latches and pull the
handles down toward the front of the unit.
4. Swing the bottom of the door out and raise
it slightly to lift the top flange of the door frame
away from the appliance.
Control Compartment Access Panel and Hinge
Top Flange
Glass Door Frame
Front Glass
Enclosure Panel
Bottom Vee-flange
Glass Door Frame
Glass Door Latch
Firebox Floor
Figure 4 CDST Shown
To install the front glass enclosure panel,
proceed as follows:
1. Visually inspect the gasket on the backside
of the panel. The gasket surface must be clean,
free of irregularities and seated firmly.
2. Position the glass enclosure panel in front of
the firebox opening at a 45 degree angle and
engage the top flange over the lip at the top of
the firebox opening.
3. Swing the glass enclosure panel down and
back. Ensure the gasket seats evenly as the
panel draws shut. Engage the Vee-flange at the
bottom of the panel with the latches and close
the latches to secure the panel.
4. Reinstall the top louver assembly or radiant
panel.
6
Burner Adjustments
The following paragraphs address burner adjustment concerns and procedures.
Flame Appearance and Sooting
Proper flame appearance is a matter of taste.
Generally most people prefer the warm glow of
a yellow to orange flame. Appliances operated
with air shutter openings that are too large will
exhibit flames that are blue and transparent.
These weak, blue and transparent flames are
termed anemic. If the air shutter opening is too
small sooting may develop.Sooting is indicated by black puffs developing at the tips of
very long orange flames. Sooting results in
black deposits forming on the logs, appliance
inside surfaces and on exterior surfaces adjacent to the vent termination.
Sooting is caused by incomplete combustion in
the flames and a lack of combustion air entering
the air shutter opening. To achieve a warm
yellow to orange flame with an orange body that
does not soot, the shutter opening must be
adjusted between these two extremes. No smoke
or soot should be present. Reposition the log set
if the flames impinge on any part of it.
If the log set is properly positioned and
sooting conditions exist, the air shutter opening on the main burner tube should be adjusted. Normally, the more offsets in the vent
system, the greater the need for the air shutter
to be opened further.
WARNING: AIR SHUTTER ADJUSTMENT SHOULD ONLY BE PERFORMED
BY A QUALIFIED PROFESSIONAL SERVICE TECHNICIAN.
ENSURE THAT ALL GLASS PANELS ARE IN
PLACE AND SEALED DURING ADJUSTMENT.
Adjustment
CAUTION: THE ADJUSTMENT ROD AND
NEARBY APPLIANCE SURFACES ARE HOT.
EXERCISE CAUTION TO AVOID INJURY WHILE
ADJUSTING FLAME APPEARANCE.
To adjust the flame, rotate the adjustment
rod (located in the lower control area) counterclockwise to increase or clockwise to reduce the air shutter opening. Adjust the air
shutter to the recommended setting as
shown in
ate for at least 15 minutes. Observe the flame
continuously. If it appears weak or sooty as
previously described, adjust the air shutter
by rotating the adjustment rod until the flame
appearance is as desired.
Figure 5
. Allow the burner to oper-
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Air Shutter
Adjusting
Rod
Increase Shutter
Opening In This
Decrease Shutter
Opening In This
Direction
Note - Both air shutters open and close
simultaneously when the air shutter
adjusting rod is moved.
Note - Burners are omitted in this view for clarity.
Direction
Air Shutter
Opening
Air Shutter
Adjusting
Arms
Burner
Venturi
Tube
Orifice
RENRUBNIAM***
GNITTESRETTUHSYROTCAF
saGlarutaN
sledoM
sehcni
)mm(
TSDC
FPDC
RCDC
LCDC
OWT*
8/1)3(
STOLS
enaporP
saG
sehcni
)mm(
OWT**
61/11)71(
STOLS
Adjustment Rod Positions (when viewed
from above):
*Natural Gas
**Propane
- fully clockwise
- fully counter clockwise
*** Settings shown are for each burner.
Figure 5
The adjustment rod and associated adjustable
air shutter is patented technology. Flame adjustments can be made quickly and accurately
to taste without the need of disassembling the
appliance and waiting for 15 minutes after each
adjustment.
Propane models may exhibit a flame pattern
that may candle or appear stringy. If this is
problematic or persists as the appliance is
continually operated, adjust the air shutter
closed as described in the previous paragraphs.
Operate the appliance for a period of time as the
effect diminishes, ensuring that the appliance
does not develop sooty flames.
When satisfied that the appliance operates properly, proceed to finish the installation. Leave the
control knob in “ON” position and turn the
remote switch “OFF.” Close the lower control
compartment access panel.
Log Placement
WARNING: LOG SET GETS VERY HOT
AND WILL REMAIN HOT UP TO ONE
HOUR AFTER GAS SUPPLY IS TURNED
OFF. HANDLE ONLY WHEN LOG SET IS
COOL. TURN OFF ALL GAS TO THE
APPLIANCE BEFORE INSTALLING THE
GRATE AND LOG SET.
WARNING: THIS APPLIANCE IS NOT
DESIGNED TO BURN WOOD. ANY ATTEMPT TO DO SO COULD CAUSE IRREPARABLE DAMAGE TO YOUR APPLIANCE AND PROVE HAZARDOUS TO
YOUR SAFETY.
Figure 6
WARNING: THE SIZE AND POSITION
OF THE LOG SET WAS ENGINEERED TO
GIVE YOUR APPLIANCE A SAFE, RELIABLE AND ATTRACTIVE FLAME PATTERN. ANY ATTEMPT TO USE A DIFFERENT LOG SET IN THE FIREPLACE
WILL VOID THE WARRANTY AND WILL
RESULT IN INCOMPLETE COMBUSTION, SOOTING, AND POOR FLAME
QUALITY.
The log set, the decorative volcanic stone
and the glowing embers (rockwool) are located inside the unit. Refer to the following
information and
placement instructions for the logs, the decorative volcanic stone and the glowing embers.
Figure 6
pattern for this particular appliance.
Install the unitized log set:
a - The bottom of the log set is notched to
accommodate the pilot.
b - Place the log set so that the four inner
notches on the underside of the log set fit over
the four risers located on the burner ends. See
Figure 6
. This procedure is accomplished primarily by feel, as the log set masks the burner
risers as it is being installed.
c - As a final check for correct log set placement, check that the four outer notches on the
underside of the log set fit over the burner
tines as indicated in
Figures 6 and 7
for detailed
also shows a typical flame
Figure 6
.
NOTE: INSTALL REAR BURNER FIRST,
THEN FRONT BURNER.
Outer Log
Notch Location
Riser - Inner Log
Notch Location
Outer Log
Notch Location
FIREBOX SUBFLOOR
LOG NOTCH LOCATION RELATIVE TO BURNER
FRONT BURNER
FRONT OF FIREPLACE
REAR BURNER
Riser - Inner Log
Notch Location
Outer Log
Notch Location
Pilot Assembly
Outer Log
Notch Location
Figure 7
Note: If the burners have been removed for
any reason, rear burner must be installed
before front burner. See Figures 7 and 8.
Install the decorative volcanic stone and
glowing embers (rockwool):
Spread the decorative volcanic stone on the
simulated brick floor of the firebox around the
burners to simulate ashes. Maintain a ¹⁄₂ in.
gap between the bottom of the horizontal grate
section and the top of the pile of decorative
volcanic stone. Place a few dime-sized pieces
of the glowing ember material on the pan
burner in front of the burned out area on both
sides of the log set. The glowing embers may
touch one another, but should not overlap
each other.
BURNER POSITIONING
NOTE: INSTALL REAR BURNER FIRST,
THEN FRONT BURNER.
BRACKET A
Note: The burners are not identical. Position them so
that the circular burner ports run as shown. Note
especially the vertical run of ports relative to the pilot
burner. Bracket A on the rear burner will interfere
with the pilot burner if an attempt is made to install
the rear burner in the front burner’s position.
REAR BURNER
FRONT BURNER
Figure 8
Millivolt Appliance Checkout
The pilot flame should be steady, not lifting or
floating. Flame should be blue in color with
traces of orange at the outer edge. The top ³⁄₈"
(10 mm) at the pilot generator (thermopile) and
the top ¹⁄₈" min (tip) of the quick drop out thermocouple should be engulfed in the pilot flame. The
flame should project 1" (25 mm) beyond the
hood at all three ports. See
To light the burner, refer to the lighting instruc-
pages 12 and 13.
tions on
MILLIVOLT
Thermocouple
Pilot
Nozzels
Figure 9
Thermopile
BURNER
PORTS
Figure 9.
Ignitor Rod
Hood
PILOT
BURNER
³⁄₈" Min
(9 mm)
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
7
Electronic Appliance Checkout
1. If any of the original wire as supplied must be replaced,
1. it must be replaced with Type AWM 105°C – 18 GA. wire.
2. 120V, 60Hz – Less than 3 amps.
BK
Transf.
120 V.
24 V
Factory Wired Field Wired
BL
Electronic Wiring Diagram (Honeywell)
Showing the Blower Wiring for the Optional
FBK-250 Kits
R
WH
BL
OPT
BLOWER
G
W
120
VAC.
BK
W
Gas Valve
B
R
IGNITER
PILOT
ASSEMBLY
BK
G
Outlet Box Green
Ground Screw
Hot side of Outlet
Schematic Representation Only
*ON/OFF Switch (Integral
with Gas Valve)
White Wire
To Opposite
Side
Optional FBK-250
Module
*Leave the ON/OFF switch, which is integral
with the gas valve, in the ON position.
G
OPTIONAL APPLIANCE-MOUNTED ON/OFF SWITCH
OR OPTIONAL WALL SWITCH
OR OPTIONAL THERMOSTAT
OR OPTIONAL REMOTE RECEIVER
To light the burner, refer to the lighting instructions on
page 14 and 15
. Ensure the ignitor
lights the pilot. The pilot flame should engulf the
flame sensor as shown in
Proper Flame
Adjustment
Figure 10
3/8 To 1/2 Inch
(9 mm to 13 mm)
Ground
Electrode
Flame Rod
Hot Surface
Igniter
Figure 10
With proper care and maintenance, your appliance will provide many years of enjoyment. If you
should experience any problem, first refer to the
trouble shooting guide in this manual. If problem
persists, contact your Lennox distributor.
WIRING DIAGRAMS
Wiring diagrams are provided here for reference purposes only. This information is also
provided on schematics attached directly to
the appliance on a pullout panel located within
the control compartment.
Electronic Wiring Diagram (Honeywell)
Showing the Blower Wiring for the Optional
FBK-100 and FBK-200 Kits
1. If any of the original wire as supplied must be replaced,
1. it must be replaced with Type AWM 105°C – 18 GA. wire.
2. 120V, 60Hz – Less than 3 amps.
**ON/OFF Switch (Integral
with Gas Valve)
Gas Valve
BK
R
BL
OPT
BLOWER
Hot side of Outlet
W
OPTIONAL APPLIANCE-MOUNTED ON/OFF SWITCH
*Blower speed control switch is provided in FBK200 blower kit.
**Leave the ON/OFF switch, which is integral
with the gas valve, in the ON position.
*OPTIONAL
ACCESSORY
G
B
G
Junction Box
SWITCH
Black
pigtail
Red
pigtail
R
BK
W
G
Green Ground
Transf.
120 V.
24 V
Outlet Box
Screw
White Wire
to Opposite
PILOT
ASSEMBLY
IGNITER
Break Off
Tab
W
BL
OR OPTIONAL WALL SWITCH
OR OPTIONAL THERMOSTAT
OR OPTIONAL REMOTE RECEIVER
Factory Wired Field Wired
Schematic Representation Only
BK
VAC.
Side
120
CAUTION: LABEL ALL WIRES PRIOR TO DISCONNECTION WHEN SERVICING CONTROLS.
WIRING ERRORS CAN CAUSE IMPROPER AND
DANGEROUS APPLIANCE OPERATION.
If any of the original wire as supplied must be replaced,
it must be replaced with Type AWM 105°C, 18 GA. wire.
OR WALL-MOUNTED ON/OFF SWITCH (Accessory Option)
*TWIST WIRES “A” AND “B” TOGETHER TO OPERATE UNIT
SOLELY BY MANIPULATING THE GAS VALVE CONTROL KNOB;
OR CONNECT WIRES TO OPTIONAL UNIT-MOUNTED ON/OFF
WARRANTY
Your gas appliance is covered by a limited twenty
year warranty. You will find a copy of the warranty accompanying this manual. Please read
Millivolt Wiring Diagram
Thermopile
AB
*UNIT-MOUNTED ON/OFF SWITCH (Accessory Option)
OR THERMOSTAT (Accessory Option)
OR REMOTE CONTROL RECEIVER (Accessory Option)
SWITCH OR WALL-MOUNTED ON/OFF SWITCH OR
THERMOSTAT TO OPERATE UNIT.
TP
the warranty to be familiar with its coverage.
8
Retain this manual. File it with your other documents for future reference.
1. The model number of the appliance.
2. The serial number of the appliance.
3. The part number.
REPLACEMENT PARTS
A complete parts list is found at the end of this
manual. Use only parts supplied from the
manufacturer.
Normally, all parts should be ordered through
TH
TP
TH
your Lennox distributor or dealer. Parts will be
shipped at prevailing prices at time of order.
When ordering repair parts, always give the
following information:
4. The description of the part.
5. The quantity required.
6. The installation date of the appliance.
If you encounter any problems or have any
questions concerning the installation or application of this system, please contact your distributor, or Lennox directly:
LHP
1110 West Taft Avenue • Orange, CA 92865
PRODUCT REFERENCE INFORMATION
We recommend that you record the following important information about your fireplace. Please
contact your Lennox dealer for any questions or concerns. For the number of your nearest Lennox
dealer, please call 800-731-8101
Your Fireplace's Model Number _______________________________________
Your Fireplace's Serial Number ________________________________________
The Date On Which Your Fireplace Was Installed __________________________
The Type of Gas Your Fireplace Uses ___________________________________
Your Dealer's Name_________________________________________________
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
ACCESSORY COMPONENTS
tinU
ledoM
.oN
TSDC -2 - 2
FPDC 12 1 2
RCDC
LCDC
rooDssalG
51L08
B06-EKFD
11 1 1
Door Frame Kits
Two types of decorative door frame kits are
available for use with these appliances - one in
polished brass finish, the other, in brushed stainless steel finish. The DFK is designed to attach
directly to the front face of the appliance at its
extreme edges. The DFK provides a picture frame
finish for the appliance. The door frame kit can be
Remote Control System (Standard) H0249 RCL
retrofitted onto previously installed appliances.
Standard Remote Control System
(Model RCL)
The Model RCL (Standard) Remote Control
stiKemarFrooD
STESFOREBMUNDNA.ONLEDOM/.ONGOLATAC
hsiniFssarBdehsiloPhsiniFsselniatSdehsurB
ediw.ni42rof
ediw.ni04rof
rooDssalG
21L08
B06/6-KFD
ediw.ni42rof
rooDssalG
02L08
P06-EKFD
ediw.ni04rof
rooDssalG
71L08
P06/6-KFD
Arch Door Kits
Two types of arch door kits are available for the
Multi-Open Series. Both types of kits are easy
to install and do not require hardware to attach
them to the standard door frame. These kits can
be retrofitted to previously installed Multi-Open
Series appliances. The decorative arch kits can
not be used in conjunction with the screen
panel kit.
System, features a simplistic on/off control
function for the fireplace. This model includes
a hand-held transmitter, a remote receiver with
wall-mount coverplate and all hardware required to install the unit. The remote receiver
can be wall or hearth mounted.
The transmitter has ON and OFF functions that
are activated by pressing either button on the
face of the transmitter. When a button on the
transmitter is pressed, a signal light illuminates
briefly to verify that a signal has been sent.
The Model RCL is designed to operate with all
millivolt ignition systems, as well as electronic
ignition systems. It may be installed with use
for either natural or propane gas appliances.
The RCL offers ease of installation and allows
you to execute on-off commands to the fireplace effortlessly with one simple motion.
The Model RCL comes complete with detailed
operating instructions.
Flame Modulating Remote Control
Natural Gas H0301 RCL-MN
LP/Propane Gas H0302 RCL-ML
Flame Modulating Remote Controls were developed to provide a safe, reliable and user-friendly
remote control system for appliances equipped
with a Millivolt Gas Valve. A detailed set of
instructions are included with each remote.
YTITNAUQDNA.ONLEDOM/.ONGOLATAC-stiKrooDhcrA
hsiniFssarBdehsiloPhsiniFsselniatSdehsurB
tinU
ledoM
.oN
ediw.ni42rof
rooDssalG
59L08
B06-EKDA
ediw.ni04rof
rooDssalG
39L08
B06/6-KDA
ediw.ni42rof
rooDssalG
50L18
P06-EKDA
ediw.ni04rof
rooDssalG
30L18
P06/6-KDA
TSDC -2 - 2
FPDC 12 1 2
RCDC
LCDC
11 1 1
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
ON/OFF Wall Switch Kit 85L87 FWSK
ON/OFF Wall Switch Kit
The ON/OFF wall switch kit may be used to
control the operation of the fireplace burner as
an alternative to the unit-mounted ON-OFF
switch. Install the ON/OFF wall switch in a
convenient location near the fireplace.
9
ACCESSORY COMPONENTS CONTINUED
Remote Control System (Deluxe) H0251 RCL-T
Clean Faced Panel Kit
A clean faced panel kit is available to convert the
standard louvered appliances to radiant models
more suited for finishing around the firebox opening with non-combustible materials such as tile.
stiKlenaPdecaFnaelCkcalB
.ONLEDOM/.ONGOLATAC
STESFOREBMUNDNA
Deluxe Remote Control System
(Model RCK-D)
The Model RCL-T (Deluxe) Remote Control
System has all of the features of the standard
system along with an added easy to read LCD
screen which presents access to many enhancements, including; battery power level indicator, timer, mode of operation, thermostatic
display including room temperature in either
metric of English units, flame indicator and
clock. Fully programmable, the Model RCL-T
allows for virtual command over nearly all
operational and temperature variables, using
the hand held remote control transmitter.
The Model RCL-T (Deluxe) remote control system is installed in the same manner as the
standard system, may be operated with electronic and millivolt systems with either natural
or propane gas. The RCL-T comes complete
with detailed operating instructions.
Rocker Switch Kit 80L41 FRS
Optional Unit Mounted Rocker Switch
An optional rocker switch kit can be installed
directly on all Millivolt Gas Valve Equipped
Multi-Open Series appliances to provide for On
and Off operation in lieu of a wall switch. This kit
is designed to install in the lower control compartment out of view and is perfect for use in
high volume areas such as lobbies and model
homes where limited access to the appliance
On/Off switch is desirable. This kit can be
retrofitted to previously installed appliances
and may be temporarily installed in place of
other switch circuitry.
tinU
ledoM
.oN
ediw.ni42rof
rooDssalG
97L08
06-EKPFC
rooDssalG
77L08
06/6-KPFC
TSDC -2
FPDC 12
RCDC
LCDC
11
Polished Brass and Brushed Stainless Hood Kits
Attractive hoods are available in two styles to be used on the Multi-Open Series appliances.
These hoods are designed to be fitted to the glass viewing sides of the appliance. In addition
to providing an aesthetically pleasing appearance to your appliance installation, the hood
reduces heat effects to decorative mantles and finish materials located above the fireplace
opening. The hood kit replaces the standard hood that comes with these appliances and snaps
into place. These kits can be retrofitted to previously installed appliances.
stiKdooH
STESFOREBMUNDNA.ONLEDOM/.ONGOLATAC
hsiniFssarBdehsiloPhsiniFsselniatSdehsurB
tinU
ledoM
.oN
ediw.ni42rof
rooDssalG
55L08
B06-EKH
TSDC -2- 2
FPDC 121 2
RCDC
LCDC
111 1
ediw.ni04rof
rooDssalG
35L08
B06/6-KH
ediw.ni42rof
rooDssalG
36L08
P06-EKH
ediw.ni04rof
rooDssalG
16L08
P06/6-KH
ediw.ni04rof
10
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
ACCESSORY COMPONENTS CONTINUED
tinU
ledoM
.oN
TSDC -2 - 2
FPDC 12 1 2
RCDC
LCDC
ediw.ni42rof
rooDssalG
49M62
B6-EKTD
11 1 1
Door Frame Kits (2-Piece, Top and Bottom)
Two types of decorative door frame kits are available for use with these appliances - one, in polished brass finish; the other, in brushed stainless
steel finish. The DTK is designed to attach directly
to the front face of the appliance at the glass
enclosure panels top and bottom edges. The DTK
provides a touch of elegance to the appliance. The
door frame kit can be retrofitted onto previously
installed appliances.
)eceip-2(stiKemarFrooD
STESFOREBMUNDNA.ONLEDOM/.ONGOLATAC
hsiniFssarBdehsiloPhsiniFsselniatSdehsurB
ediw.ni04rof
rooDssalG
98M91
B6-KTD
ediw.ni42rof
rooDssalG
59M62
SB6-EKTD
ediw.ni04rof
rooDssalG
09M91
SB6-KTD
Screen Panel Kit
24 inch Wide Glass Door 80L46 SPKE-60
40 inch Wide Glass Door 80L44 SPK-6/60
Screen Panel Kit
An optional screen panel can be installed on the
Multi-Open Series doors. These screen panels
are easy to install. These kits can be retrofitted to
previously installed appliances. The screen panel
kits can not be used in conjunction with either of
the arch door kits or door frame kits.
(FBK-200 Models Only)
Louvers Kits
Decorative louvers are available for use with
Multi-Open Series fireplaces. These louvers are
designed to replace the standard black louvers
that are provided with the appliance or to replace the radiant panels if they were installed as
an accessory. The polished brass and brushed
stainless steel louver kits includes eight (8)
louvers. They provide a touch of elegance to
any Multi-Open Series appliance. This kit can
be retrofitted to previously installed appliances.
stiKrevuoL
STESFOREBMUNDNA.ONLEDOM/.ONGOLATAC
hsiniFssarBdehsiloPhsiniFsselniatSdehsurB
tinU
ledoM
.oN
ediw.ni42rof
rooDssalG
17L08
B06-EKL
TSDC -2 - 2
FPDC 12 1 2
RCDC
LCDC
11 1 1
ediw.ni04rof
rooDssalG
96L08
B06/6-KL
ediw.ni42rof
rooDssalG
57L08
SB06-EKL
ediw.ni04rof
rooDssalG
37L08
SB06/6-KL
Forced Air Blower Kits
-Single Speed 80L84 FBK-100
-Variable Speed with wall-mounted switch
80L85 FBK-200
-Variable Speed with unit-mounted switch
80L86 FBK-250
Forced Air Kit
The FBK-100 blower provides for a constant
velocity forced air circulation feature for your
appliance. The FBK-200 assembly with variable
speed wall switch provides a forced air circulation feature for your appliance. The FBK-250
comes complete with a unit mounted switch
operating system.
Touch-Up Paint Kit (Black) 90L73 FTPK-B
Touch-Up Paint Kit (Tan) 98K67
Touch-Up Paint Kit
Repair of minor scratches and discoloration of
the appliance black painted cabinet surfaces may
be accomplished with the touch-up paint kit.
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
11
LIGHTING INSTRUCTIONS – MILLIVOLT GAS VALVE
FOR YOUR SAFETY READ BEFORE LIGHTING
WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION
MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
A. This appliance has a pilot which must be lighted with a piezo
ignitor. When lighting the pilot, follow these instructions
exactly.
B. BEFORE OPERATING smell all around the appliance area for
gas. Be sure to smell next to the floor because some gas is
heavier than air and will settle on the floor.
WHAT TO DO IF YOU SMELL GAS
• Extinguish any open flame.
• Open windows.
• Do not light any appliance.
• Do not touch any electrical switches.
LIGHTING INSTRUCTIONS
1. STOP! Read the safety information above on this page.
2. Access the lower control compartment.
3. Turn remote wall switch to “OFF.”
4. Verify main line shut-off valve is open.
5. Push in gas control knob slightly and turn clockwise
to “OFF.”
IN
TPTH TP TH
I
H
L
W
O
P
I
L
O
T
OUT
F
F
O
P
I
L
it
O
T
O
N
• Do not use any phone in your building.
• Immediately call your gas supplier from a neighbor’s phone.
• If your gas supplier cannot be reached, call the fire depart-
ment.
C. Use only your hand to push in or turn the gas control knob.
Never use tools. If the knob will not push in or turn by hand,
do not try to repair it, call a qualified service technician. Force
or attempted repair may result in a fire or an explosion.
D. Do not use this appliance if any part has been under water.
Immediately call a qualified service technician to inspect the
appliance and to replace any part of the control system and
any gas control which has been under water.
6. Wait five (5) minutes to clear out any gas. If you then smell gas,
STOP! Follow “B” in the safety information above on this page. If you
do not smell gas, go to the next step.
7. Push in gas control knob slightly and turn counterclockwise
to “PILOT.”
8. Push in control knob all the way and hold in. Immediately light the
pilot by triggering the spark ignitor (pushing the button) until pilot
lights. Continue to hold the control knob in for about 1 ¹⁄₂ minutes
after the pilot is lit. Release knob and it will pop back up. Pilot should
remain lit. If it goes out, repeat steps 5 through 8.
• If knob does not pop up when released, stop
and immediately call your service
technician or gas supplier.
• If pilot will not stay lit after several
tries, turn the control knob to “OFF”
and call your service technician or
gas supplier.
12
Note: Knob cannot be turned from “PILOT” to “OFF”
unless the knob is pushed in slightly. Do not force.
TO TURN OFF GAS TO APPLIANCE
1. Turn remote wall switch “OFF.” The pilot will remain lit for
normal service.
2. For complete shutdown, turn remote wall switch to “OFF.”
3. Access the lower control compartment.
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
9. Turn gas control knob counterclockwise
to “ON.”
10. Close lower control compartment.
4. Depress gas control knob slightly and turn clockwise
to “OFF.” Do not force.
5. Close lower control compartment.
INSTRUCTIONS D’ALLUMAGE – VANNE GAZ MILLIVOLT
POUR VOTRE SÉCURITÉ, LISEZ CES INSTRUCTIONS AVANT L’ALLUMAGE
AVERTISSEMENT : SI VOUS NE SUIVEZ PAS CES INSTRUCTIONS À LA LETTRE, IL POURRAIT S’EN SUIVRE UN INCENDIE OU
UNE EXPLOSION CAUSANT DES DOMMAGES MATÉRIELS, DES BLESSURES CORPORELLES OU MÊME DES PERTES DE VIE.
A. Cet appareil est muni d’une veilleuse qui doit être allumée avec un
allumeur piézo-électrique. Lorsque vous allumez la veilleuse, suivre
exactement ces instructions.
B. AVANT L’ALLUMAGE: Assurez-vous que vous ne détectez aucune
odeur de gaz autour de l’apareil ainsi que près du sol; certains gaz, étant
plus lourds que l’air, descendent au niveau du sol.
VOICI CE QUE VOUS DEVEZ FAIRE SI VOUS DÉCELEZ UNE ODEUR
DE GAZ:
• Éteignez toute flamme visible.
• Ouvrez les fenêtres.
• N’allumez aucun appareil.
• Ne touchez à aucun commutateur électrique.
• Ne vous servez d’aucun téléphone dans votre édifice.
INSTRUCTIONS D'ALLUMAGE
1. ARRÊTEZ! Lisez les consignes de sécurité au verso de cette plaque.
2. Ouvrez le compartiment de contrôle du bas.
3. Tournez l’interrupteur mural à la position d’arrêt “OFF”.
4. Assurez-vous que la soupape d’arrêt de la canalisation principale est
ouverte.
5. Enfoncez légèrement le bouton de réglage du gaz et tournez-le dans
le sens des aiguilles d’une montre jusqu’à la position
d’arrêt “OFF”.
IN
O
it
OUT
F
F
N
P
I
L
O
T
O
TPTH TP TH
I
H
L
W
O
P
I
L
O
T
• Appelez immédiatement votre compagnie de gaz en utilisant le téléphone
du voisin.
• S’il vous est impossible de contacter votre compagnie de gaz, appelez
le service des incendies.
C. N’utilisez que votre main pour manipuler le bouton de réglage du gaz.
N’utilisez jamais d’outils. Si le bouton refuse de tourner ou de bouger,
n’essayez pas de le réparer. Communiquez immédiatement avec un
technicien de service qualifié. Toute tentative pour le forcer ou le
réparer, risquerait de provoquer un incendie ou une explosion.
D. Ne vous servez pas de cet appareil si l’un de ses éléments a été
immergé dans l’eau. Appelez immédiatement un technicien compétent
pour faire inspecter l’appareil et remplacer toute pièce du système de
réglage ou commande du gaz qui a été sous l’eau.
8. Enfoncez le bouton de réglage jusqu’au fond et gardez-le enfoncé.
Allumez immédiatement la veilleuse en déclenchant l’allume-gaz à
étincelle (en poussant le bouton) jusqu’à ce que la veilleuse
s’enflamme. Continuez de tenir le bouton de réglage enfoncé
pendant environ 90 secondes après l’allumage de la veilleuse.
Relâchez le bouton et il sortira subitement. La veilleuse devrait
rester allumée. Si elle s’éteint, répétez les étapes 5 à 8
inclusivement.
• Si le bouton ne sort pas automatiquement après avoir été relâché,
arrêtez immédiatement et téléphonez
à votre technicien de service ou à
votre fournisseur de gaz.
• Si la veilleuse refuse de rester
allumée après plusieurs tentatives,
tournez le bouton de réglage jusqu’à
sa position d’arrêt “OFF” et
téléphonez à votre technicien de
service ou à votre fournisseur de gaz.
Remarque: Il est impossible de tourner le bouton de “PILOT” à “OFF” à
moins qu’il ne soit légèrement enfoncé. Ne le forcez pas.
6. Attendez cinq (5) minutes pour l’evacuation du gaz. Si vous décelez
une odeur de gaz, ARRÊTEZ ! Retournez au point “B” des consignes
de sécurité au verso de cette plaque. Si vous ne remarquez aucune
odeur de gaz, passez à l’étape suivante.
7. Enfoncez légèrement le bouton de réglage du gaz et tournez-le en
sens inverse des aiguilles d’une montre jusqu’à la position de
veilleuse “PILOT”.
POUR FERMER LE GAZ QUI ALIMENTE L’APPAREIL
1. Tournez l’interrupteur mural à la position d’arrêt “OFF”. La veilleuse
restera allumée jusqu’au retour du service normal.
2. Pour une fermeture complète, tournez l’interrupteur mural à la
position d’arrêt “OFF”.
3. Ouvrez le compartiment de contrôle du bas.
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
9. Tournez le bouton de réglage du gaz en sens inverse des aiguilles
d’une montre jusqu’à sa position de marche “ON”.
10. Fermez le compartiment de contrôle du bas.
11. Au besoin, rebrancher l’appareil au courant électrique et remettre
l’interrupteur du brûleur principal à la position “ON” ou régler le
thermostat à la température désirée.
12. Si l’appareil ne fonctionne pas, suivre les instructions intitulées
“Pour fermer le gaz qui alimente l’appareil” et appeler un
technicien ou le fournisseur de gaz.
4. Enfoncez légèrement le bouton de réglage du gaz et tournez-le dans
le sens des aiguilles d’une montre jusqu’à la position
d’arrêt “OFF”. Ne forcez pas le bouton.
5. Fermez le compartiment de contrôle du bas.
13
LIGHTING INSTRUCTIONS — ELECTRONIC
FOR YOUR SAFETY READ BEFORE LIGHTING
WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION
MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
A. When lighting the appliance, follow these instructions
exactly.
B. BEFORE OPERATING smell all around the appliance area
for gas. Be sure to smell next to the floor because some
gas is heavier than air and will settle on the floor.
WHAT TO DO IF YOU SMELL GAS
• Extinguish any open flame.
• Open windows.
• Do not light any appliance.
• Do not touch any electrical switches.
• Do not use any phone in your building.
LIGHTING INSTRUCTIONS
1. STOP! Read the safety information above on this page.
2. Turn remote wall switch to “OFF.”
3. Open lower control compartment door.
4. Verify main line shut-off valve is open.
• Immediately call your gas supplier from a neighbor’s
phone.
• If your gas supplier cannot be reached, call the fire
department.
C. Use only your hand to turn the gas control lever. Never
use tools. If the lever will not turn by hand, do not try to
repair it, call a qualified service technician. Force or
attempted repair may result in a fire or an explosion.
D. Do not use this appliance if any part has been under
water. Immediately call a qualified service technician to
inspect the appliance and to replace any part of the
control system and any gas control which has been
under water.
5. Turn the ON/OFF switch to “OFF”. Do not force.
6. Wait five (5) minutes to clear out any gas. If you then
smell gas, STOP! Follow “B” in the safety information
above on this page. If you do not smell gas, go to the
next step.
7. Turn the ON/OFF switch to “ON”. Do not force.
14
ON/OFF Switch
CONTROL
OFF
ON
IGNITER
Front View
IN
PSI
TO TURN OFF GAS TO APPLIANCE
1. For complete shut-down, turn remote wall switch to
“OFF.”
2. Open lower control compartment door.
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
8. Turn “ON” all electrical power to appliance (remote wall
or appliance switch).
9. Close lower control compartment door.
TO SHUT OFF
1. Turn off all electrical power to the appliance (remote wall
switch).
3. Turn the ON/OFF switch to “OFF”. Do not force.
4. Close the main line shut-off valve.
5. Close lower control compartment door.
INSTRUCTIONS D’ALLUMAGE — ELECTRONIC
POUR VOTRE SÉCURITÉ, LISEZ CES INSTRUCTIONS AVANT L’ALLUMAGE
AVERTISSEMENT: SI VOUS NE SUIVEZ PAS CES INSTRUCTIONS À LA LETTRE, IL POURRAIT S’EN SUIVRE UN INCENDIE OU
UNE EXPLOSION CAUSANT DES DOMMAGES MATÉRIELS, DES BLESSURES CORPORELLES OU MÊME DES PERTES DE VIE.
A. Lorsque vous allumez l’appareil, suivez exactement ces instruc-
tions.
B. AVANT L’ALLUMAGE: Assurez-vous que vous ne détectez
aucune odeur de gaz autour de l’apareil ainsi que près du sol;
certains gaz, étant plus lourds que l’air, descendent au niveau
du sol.
VOICI CE QUE VOUS DEVEZ FAIRE SI VOUS DÉCELEZ UNE
ODEUR DE GAZ
• Éteignez toute flamme visible.
• Ouvrez les fenêtres.
• N’allumez aucun appareil.
• Ne touchez à aucun commutateur électrique.
• Ne vous servez d’aucun téléphone dans votre édifice.
INSTRUCTIONS D’ALLUMAGE
1. ARRÊTEZ ! Lisez les consignes de sécurité au verso de cette
plaque.
2. Tournez l’interrupteur mural à la position d’arrêt “OFF”.
3. Ouvrez la porte du compartiment de contrôle du bas.
4. Assurez-vous que la soupape d’arrêt de la canalisation principale
est ouverte.
• Appelez immédiatement votre compagnie de gaz en utilisant
le téléphone du voisin.
• S’il vous est impossible de contacter votre compagnie de
gaz, appelez le service des incendies.
C. N’utilisez que votre main pour manipuler l'interrupteur “ON/
OFF” de la valve à gaz. N’utilisez jamais d’outils. Si
l’interrupteur ne bouge pas manuellement, n’essayez pas de le
réparer. Communiquez immèdiatement avec un technicien de
service qualifié. Toute tentative pour forcer l’interrupteur ou le
réparer, risquerait de provoquer un incendie ou une explosion.
D. Ne vous servez pas de cet appareil si l’un de ses éléments a été
immergé dans l’eau. Appelez immédiatement un technicien
compétent pour faire inspecter l’appareil et remplacer toute
pièce du système de réglage ou commande du gaz qui a été sous
l’eau.
6. Attendez cinq (5) minutes pour l’evacuation du gaz. Si vous
décelez une odeur de gaz ARRÊTEZ ! Retournez au point “B” des
consignes de sécurité au verso de cette plaque. Si vous ne
remarquez aucune odeur de gaz, passez à l’étape suivante.
7. Tournez la manette de réglage du gaz jusqu’à la position de marche
“ON”. Ne la forcez pas.
8. Ouvrez le courant électrique (“ON”) qui alimente l’appareil
(interrupteur mural ou l'appareil).
5. Tournez la manette de réglage du gaz à la position d’arrêt “OFF”.
Interrupteur
ON/OFF
CONTROL
OFF
ON
IGNITER
Vue de face
IN
PSI
POUR FERMER LE GAZ QUI ALIMENTE L’APPAREIL
1. Pour une fermeture complète, tournez l’interrupteur mural à la
position d’arrêt “OFF”.
2. Ouvrez la porte du compartiment de contrôle du bas.
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
9. Fermez la porte du compartiment de contrôle du bas.
10. Au besoin, rebrancher l’apareil au courant électrique et
remettre l’interrupteur principal du brûleur à la position “ON”
ou régler le thermostat à la température désirée.
11. Si l’appareil ne se met pas en marche, suivre les instructions
intitulées “Pour fermer le gaz qui alimente l’appareil” et appeler
un technicien ou le fournisseur de gaz.
POUR ÉTEINDRE L’APPAREIL
1. Coupez tout le courant électrique qui alimente l’appareil
(interrupteur mural).
3. Tournez la manette de réglage du gaz à la position d’arrêt “OFF”.
Ne la forcez pas.
4. Fermez la soupape d’arrêt de la canalisation principale.
5. Fermez la porte du compartiment de contrôle du bas.
15
TROUBLESHOOTING THE MILLIVOLT GAS CONTROL SYSTEM
N
ote: Before troubleshooting, make sure that the appliance main line gas shut-off valve and the gas control valve are in the "OPEN"
position and the burner ON/OFF switch is in the “ON” position.
Important: Valve system troubleshooting should only be accomplished by a qualified service technician.
1. Spark ignitor will not light
pilot after repeated
triggering of ignitor button.
2. Pilot will not stay lit after
carefully following the
lighting instructions.
3. Pilot burning, no gas to
burner, Valve knob “ON,”
Wall Switch “ON.”
POSSIBLE CAUSES
A. Defective ignitor
(no spark at electrode).
B. Defective or misaligned electrode
at pilot (spark at electrode).
C. Gas supply pressure errant.
D. Pilot orifice plugged.
A. Defective pilot generator
(thermocouple).
A. Wall switch or wires defective.
CORRECTIVE ACTIONSYMPTOM
Check for spark at electrode and pilot; if no spark and
electrode wire is properly connected, replace ignitor.
Using a match, light pilot. If pilot lights, turn off pilot and
trigger the ignitor button again. If pilot lights, an improper gas
mixture caused the bad lighting and a longer purge period is
recommended. If pilot will not light – check gap at electrode
and pilot – should be ¹⁄₈" to have a strong spark. If gap
measures ¹⁄₈", replace pilot
Check inlet gas pressure. It should be within the limits as
marked on the rating plate.
Clean or replace pilot orifice.
Check pilot flame, it must impinge on thermocouple
9 on page 7)
impingement on thermocouple. Ensure that the connection
between the valve and thermocouple are tight and secure.
Check wall switch and wires for proper connections. Jumper
wire across terminals at wall switch, if burner comes on,
replace defective wall switch. If okay, jumper wires across wall
switch wires at valve, if burner comes on, wires are faulty or
connections are bad.
Clean and/or adjust pilot for maximum flame
(Figure 9 on page 7)
.
(Figure
16
4. Frequent pilot/burner outage
problem.
B. Thermopile may not be generating
sufficient millivoltage.
C. Plugged burner orifice.
A. Pilot flame may be too low or
blowing (high) causing the pilot/
valve safety to drop out.
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Check thermopile with millivolt meter. Take reading at thermopile terminals of gas valve. Should read 325 millivolts minimum with optional wall switch “OFF.” Replace faulty thermopile if reading is below specified minimum.
Check burner orifice for stoppage and remove.
Clean and/or adjust pilot flame for maximum flame impinge-
ment on thermocouple
(Figure 9 on page 7)
.
TROUBLESHOOTING THE ELECTRONIC IGNITION SYSTEM
N
ote: Before troubleshooting, make sure that the appliance main line gas shut-off valve and the gas control valve are in the "OPEN"
position and the burner ON/OFF switch is in the “ON” position.
Important: Valve system troubleshooting should only be accomplished by a qualified service technician.
SYMPTOM POSSIBLE CAUSES CORRECTIVE ACTION
1. Burner will not light.
2. Burners come “ON” but
go “OFF.”
START
• Turn Off Gas Supply
• Assure Valve Switch Is In ON Position
• Disconnect Control Harness
• Set Thermostat To Call For Heat
Insert A
24 Volt Hot
24 Volt
Switched
Check For Damaged Or Missing Terminals
In Connector
Insert B
Igniter Terminals
End View Of
Control Harness
Connector
24 Volt
Common
A. Faulty Valve System.
B. “OFF/ON” or wall switch
defective.
A. Burner orifice plugged.
B. Obstructed vent system.
• Check For Proper Voltage At Control Harness
(See Insert A). Voltage Should Be 24V
Between Thermostat Or Pressure Switch
And 24V Common And 24V Hot.
YES
• Plug Control Harness Into Valve. Wait For
Internal Check Delay.
• Igniter Warms Up And Glows Red.
1
YES
• Turn On Gas Supply. • Pilot Burner Lights.
YES
See Below.
Disconnect the two black wires from the wire nuts. Test switch(s) for
continuity with a multimeter. If continuity is not indicated, switch(s) is
defective and must be replaced.
Note: Before replacing “OFF/ON” switch, be sure to check wiring for loose
connections or broken wires and repair as needed.
Check main burner orifice(s) for stoppage. Clean or replace.
Check vent system for obstructions.
CHECK
• Line Voltage Power
NO
• Low Voltage Transformer
• Limit Controller
2
• Thermostat
• Wiring
• With Pilot Burner Cable Connected, Measure
NO
Voltage At Valve HSI Element Output. 24V
Nominal. (See Insert B)
YES
• Replace Igniter/Flame Rod Assembly.
YES
NO
• Check That Pilot Gas Is Flowing. Wait To
Assure Plot Gas Tubing Is Purged. Recycle
Call For Heat If Necessary.
YES
• Measure Voltage Between 24V Hot And 24V Common
Leads To Valve Control. Must Measure At Least 19.5
VAC With Igniter Powered (See Insert A). To Identify
Proper Lead, This Check Must Be Done With The
Valve Control Connected And Igniter Powered.
YES
• Replace Pilot Assembly.
NO
2
1
• Replace Valve.
NO
• Replace Valve.
NO
• Check Transformer And
Line Volt Supply.
Igniter Will Cycle Off And Back On Once During
1
The 90 Second Ignition Trial. All Voltage
Measurements Must Be Taken While The Igniter
Is Powered.
• Main Valve Opens And Main Burner Lights.
YES
• System Is Okay.
When Measured Voltage At Connections, Use
2
Care To Assure Terminals Are Not Damaged.
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
• Check That Pilot Flame Makes Good Contact With
Pilot Burner Flame Rod.
NO
• Check For Good Electrical Connection Through The
Pilot Tubing.
• If Both Of The Above Are Good, Replace Igniter/Flame
Rod Assembly.
YES
• Cycle Thermostat Off And Back On.
• Main Burner Lights.
NO
• Replace Valve.
17
REPLACEMENT PARTS LIST
.oNNOITPIRCSED
.oNtraP.ytQ.ytQ.ytQ.ytQ
TSDCFPDCLCDCRCDC
a1.ni42-kcalb,dooHZE14919-BLenon111
b1.ni04-kcalb,dooHZC14919-BL2211
a2.ni42-kcalb,lenaPrevuoLreppUE40429-BLenon111
b2.ni04-kcalb,lenaPrevuoLreppUC40429-BL2211
a3.ni42-ylbmessAerusolcnEssalGE43529-BLenon111
b3.ni04-ylbmessAerusolcnEssalGC43529-BL2211
a4.ni42-kcalb,lenaPrevuoLrewoLE50429-BLenon111
b4.ni04-kcalb,lenaPrevuoLrewoLC50429-BL2211
5)dnarB(etalpemaN1039L652211
6teSgoL1026L961111
7srebmEgniwolGfogaB35L881111
8enotScinacloVevitaroceDfogaB24L082222
9lenaPrevuoL,tengaM6234902433
enaporPdnalarutaN
a01
b01tnorFF25459-BL1111
11gnitnuoMyarTrenruB,teksaG1015L911111
21)renrubrep(gnitnuoMebuTirutneV,teksaG1058K341111
a31
b31tnorF1004L061111
41lenaPerusolcnEssalG,hctaL1012L964644
51dedaoL-gnirpS,hctaL,tengaM1013L962211
61doRtnemtsujdArenruB16559-BL1111
71rotcennoCeniLsaGxelF23L391111
teSrenruBniaM
/ebuTirutneV
rettuhSriA
raeRE25459-BL1111
raeR1029L471111
18
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
REPLACEMENT PARTS LIST
GAS CONTROLS — SIT MILLIVOLT
.oNNOITPIRCSED
.03TIS-evlaVsaG1070K3411035J881
.13retingIozeiP1068K0111068K011
.23ylbmessAtoliP1071L9611081L961
.33rotareneGtoliP1097J0611097J061
.43elpuocomrehT1075L4711075L471
.53ebuTtoliP1065L4711065L471
.63elbaCdnAedortcelE1085L4711085L471
.73ecifirO1008J0621025L912
larutaNenaporP
.oNtraP.ytQ.oNtraP.ytQ
GAS CONTROLS — HONEYWELL ELECTRONIC
.oNNOITPIRCSED
.04llewyenoH-evlaVsaG1081L2611091L261
.14ylbmessAtoliP1041L2611051L261
.24remrofsnarT1023J2411023J241
.34)tiK(ylbmessArotingI45L78145L781
.44ecifirO1008J0621025L912
.54ebuTtoliP06659-BL106659-BL1
larutaNenaporP
.oNtraP.ytQ.oNtraP.ytQ
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
19
REPLACEMENT PARTS
Model CDPF Shown - see table on page 18 and 19 for
replacement parts applicable to CDST, CDCR and CDCL
Cabinet
Firebox
7
8
6
15
14
12
9
1b
2b
3b
10a
13a
13b
12
10b
4b
16
17
33
34
36
32
42
5
11
37
44
30
31
1a
2a
3a
43
40
41
4a
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
The manufacturer reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products.
Consult your local distributor for fireplace code information.
45
35
Printed in U.S.A. © 2002 by Lennox Hearth Products
P/N 725,001M REV. F 09/2005
20
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
LHP
1110 West Taft Avenue • Orange, CA 92865
Loading...
