Super Circuits SY30304, SY30308, SY30316 User Manual

SY303 Series Video
Camera Systems

Products: SY30304, SY30308, SY30316

Please read this manual before installing and using this system, and always
follow instructions for proper use. Please save this manual for future reference.

SY303xx_SI

ii

www.supercircuits.com

WARNING

!

To reduce the risk of re and electrical shock, do not expose any product to rain or
moisture unless it is designated as weatherproof.

CAUTION



Always follow the instructions in the product manual when applying power. Fire and
equipment damage can occur if power is applied incorrectly.

CAUTION



Do not install or operate Supercircuits products in small, unventilated areas. Heat build up
will signicantly reduce the performance and life of the product and may cause a re.

LEGAL NOTICE

Supercircuits products are designed to meet safety and performance standards with the use of specic
Supercircuits authorized accessories. Supercircuits disclaims liability associated with the use of non­Supercircuits authorized accessories.

The recording, transmission, or broadcast of any person’s voice without their consent or a court order is
strictly prohibited by law.

Supercircuits makes no representations concerning the legality of certain product applications such as
the making, transmission, or recording of video and/or audio signals of others without their knowledge
and/or consent. We encourage you to check and comply with all applicable local, state, and federal laws
and regulations before engaging in any form of surveillance or any transmission of radio frequencies.

Other trademarks and trade names may be used in this document to refer to either the entities claiming
the marks and names or their products. Supercircuits, Inc. disclaims any proprietary interest in
trademarks and trade names other than its own.

No part of this document may be reproduced or distributed in any form or by any means without the
express written permission of Supercircuits, Inc.

© 2010 Supercircuits, Inc. All rights reserved.

11000 N. Mopac Expressway, Building 300, Austin, TX 78759
Sales/Support: 1.800.335.9777 | Fax: [phone]

WARNING

RISK OF ELECTRIC SHOCK. DO NOT OPEN.

To reduce the risk of electric shock, do not
remove the cover (or back). No user serviceable
parts exist inside. Refer servicing to qualied
service personnel.

1SY303 Series Video Camera Systems

TABLE OF CONTENTS

Table of Contents

SECTION 1 Getting Started: Unpacking Your System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

1.1 Unpacking the equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

SECTION 2 Equipment Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

2.1 Camera testing with the monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

2.2 Camera and DVR testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

SECTION 3 Installation Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

3.1 Camera placement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

3.2 Weatherproof cameras . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

3.3 Cable runs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

3.4 DVR/recorder placement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

3.5 Uninterruptible power supplies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

SECTION 4 Device Inter-Connection Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

SECTION 5 Troubleshooting FAQ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2

www.supercircuits.com

SECTION 1: GETTING STARTED

SECTION 1

Getting Started: Unpacking Your System

For most installations, Supercircuits video systems come with everything needed to install and operate
your video surveillance system. If your system uses multiple power supplies, you may also need multi­outlet power strips.

1.1 Unpacking the equipment

Remove the equipment from its packaging and place it on a at, clean surface. Inspect each item. If any
visible damage is present, contact your supplier or Supercircuits for a replacement.

Verify that your order is complete. Within your order you should nd:

• The number of cameras you ordered. Each camera includes mounting screws and a power adapter

(unless you ordered a single universal power supply for your system)

• Monitor with the associated video and power cables

• DVR with power cables

• A 100’ BNC video/power cable for each camera

• Any other accessories ordered

NOTE

For larger systems, components may ship separately.
