Suntek Wireless 1093A User Manual
Model: STW-1093A
FLEX Technology
UUSSEERR’’SS GGUUIIDDEE
Word Message Pager
ⓒ 2004 Sun Telecom International, Inc.
All Rights Reserved.
Printed in KOREA 12/2004
S/N :
Rev : 1.00
1. General Safety Instructions
1.1 Battery Safety
1.2 Agency Approvals
1.3 Cleaning Your Pager
1.4 Care and Maintenance
2. Introduction
2.1 Welcome
2.2 Features
3. Getting Started
3.1 What’s included in the package ?
3.2 Outline & Control Buttons
3.3 Indicator & Symbols
3.4 Battery Information
3.5 Installing/Replacing the Battery
3.6 Backlighting
3.7 Out of Range Indicator
3.8 Using the Main Menu
3.9 Main Menu
3.10 Turning On Your Pager
3.11 Turning Off Your Pager
4. Messages
4.1 Reading Messages
4.2 Scrolling Between Messages
4.3 Working with the Message
Options Menu
4.4 Deleting Messages
4.5 Moving a Message to Saved Folder A/B
4.6 Deleting Read Messages with
Main Menu
4.7 Deleting All Messages with Main Menu
5. Message Boxes & Folder
5.1 Using Your News/Info InBox
5.2 Saved Folder A, Saved Folder B
6. Preferences
6.1 Setting the Quiet Mode
6.2 Setting the Time and Date
6.3 Selecting the InBox and the News/Info
Alert Type
6.4 Selecting the Tone of InBox and News/
Info Alert
6.5 Setting the Reminder Alert
6.6 Setting the LCD Contrast
6.7 Setting the Key Click
6.8 Setting the Alarms
6.9 Setting the Auto On/Off
6.10 Setting the Private Time
6.11 Setting the UI Style
6.12 Setting the Button Switch
6.13 Setting the Zoom In/Out
6.14 About
7. Limited Warranty
Contents
2
3
Follow these guidelines to help ensure the safe use of your pager and accessories.
1.1 Battery Safety
☞ Do not dispose of the battery in fire. Batteries can explode when exposed to fire.
☞ To prevent injure or burns, do not allow metal objects to contact or short circuit the
battery connectors.
1.2 Agency Approvals
The pager has been approved for use by the Federal Communications Commission (FCC) and
Underwriter’s Laboratories, Inc. (UL).
1.3 Cleaning Your Pager
To clean smudges and grime from the exterior of your pager, use a soft, non-abrasive cloth
moistened in a mild soap and water solution. Do not immerse in water. Do not use alcohol or
other cleaning solution.
1.4 Care and Maintenance
The pager is durable, reliable, and can provide years of dependable service ; however the are
1. General Safety Instructions
4
5
precision electronic products. Water and moisture, excessive heat, and extreme shock may
damage the device. Do not expose your device to these conditions. If repair is required, the
Service Organization, staffed with specially trained technicians, offers repair and maintenance
facilities in the USA.
You can protect your pager purchase with an optional extended limited warranty covering
parts and labor.
2.1 Welcome
Congratulations on your purchase of our Pager. By incorporating some of the most advanced
electronic paging technologies, the pager is reliable and easy to use. Best of all, it is
affordable and will keep you in touch with those important to you. Please carefully read this
manual before using your pager in order to fully understand the functions and capabilities.
Once again, congratulations on your purchase.
This guide contains operating instructions that explain how to use your new pager, and it
provides helpful suggestions for first-time users as well as experienced users.
2. Introduction
2.2 Features
Technology
·FLEXProtocol for Advanced Paging Reliability
·16 FLEX Addresses
·Information Services Capable
Display
·20 character x 6 Line LCD display
·120 x 48 High Resolution LCD EL Backlight
·Show Time and Date
Indicators/ Alert Features
·Built-In Alarm Clock ( 2 Alarms )
·User Selectable Alerts
·Vibrating Alert
·Reminder Alert
·Graphical Battery Gauge
·Error Message Indication
·New Message Indication
·Battery Status Display
·Message Full Indication
·Out of Service Range Indication
Messaging Features
·Stores up to 210,000 total characters
·Duplicate Message Management
·Selective Erase / Erase All
·Messages Saved While Off or Changing
the Battery
·2 Folders for Important Messages
·Message Preview
·Time and Date Stamp
·Message Scrolling
Control Features
·Zoom In/Out
·Private Time
·Auto On/Off
·Quiet Mode
·Key Click
·Adjusting LCD Contrast
·Selectable ICON Interface/ Text Interface
·Joystick Navigation
·Button Switch for Left-handed users
6
7
3.1 What’s included in the package ?
- Word Pager - Holster - Chain - 1 ‘AA’Alkaline Battery - User’s Guide
3. Getting Started
8
9
3.3 Indicator & Symbols
Button Description
Esc, Backlight
Directions(Left, Right, Up, Down), Enter
Enter
Left Button Joystick Right Button
InBox
News/Info InBox
Seved Folder 1
Seved Folder 2
Battery Level
Preferences
Delete Messages
Delete Read MSGs
Delete All MSGs
Power Off
Back/Escape
Next Message
Move to Folder
Delete Message
InBox in News
MailBox Alert
News/Info Alerts
Set Alarm1
Set Alarm2
Quiet Mode
Set Private Time
Set Auto On/Off
Set Time & Date
Key Click
Reminder Alert
Set Contrast
Set UI Style
Button Switch
Zoom In/Out
About
ICON Description
More Up
Power On Indicator
Out of Service Range Indicator
Audible Alert Indicator
Alarm Set Indicator
More Down
3.2 Outline & Control Buttons
3. Getting Started 3. Getting Started
3.4 Battery Information
Your pager use 1 ‘AA’alkaline battery. Check the battery gauge in the Vital Signs menu.
If is displayed to the down of the screen, the battery is low.
If is displayed, you cannot receive messages but you can still read unread messages.
3.5 Installing/Replacing the Battery
1. Holding the pager face down. Push and slide the battery door.
Lift up the battery door to open.
2. Remove the old battery, noting the polarity.
3. Insert a new battery so the positive (+) and negative (-) polarity markings on the battery
match the polarity diagram near the battery compartment.
4. Replace the battery door cover.
10
3. Getting Started 3. Getting Started
CAUTION: Note the polarity markings (+) and (-).
Do not insert the battery backwards.
Push
11
