Sun-Stream SSR-820R-IHR, SSR-820G-IHR User Manual

User’s Manual & Operating Instructions

Model Numbers

SSR-820R-IHR / SSR-820G-IHR

3098007

CONSUMER: READ AND SAVE THESE INSTRUCTIONS

DANGER

WARNING

Fax: (215)-891-8461 • Web: www.remingtonheater.com • Email: info@pinnacleint.com

DO NOT operate in the presence of explosives and/or flammable fumes.

USE THIS HEATER ONLY AS DESCRIBED IN THIS MANUAL. ANY OTHER USE NOT RECOMMENDED BY THE MANUFACTURER MAY CAUSE FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS.

668 Stony Hill Road #302 Yardley, PA 19067 USA • Toll Free (800)-641-6996

401000001-14

NEVER LEAVE HEATER UNATTENDED WHILE

CONNECTED TO A POWER SOURCE

Table Of Contents

Safety Information.............................................1-2

Specications and Features.................................3

Assembly

Operation..............................................................6

Maintenance.........................................................7

.........................................................

4-5

Troubleshooting Guide.........................................8

Exploded View

Parts List..............................................................9

Warranty.............................................................10

........................

..........

...

Safety Information

WARNING

used or stored.

WARNING

blocked. Heater must be kept clear of all obstructions. Maintain a 3 foot minimum clearance from front and 12 inches from sides. Heaters must be kept clean of lint, dirt, and debris.

WARNING

FIRE OR EXPLOSION MAY OCCUR! Heater has hot arching or sparking parts inside. Do not use it in areas where gasoline, paint or flammable liquids are

RISK OF FIRE. To prevent a possible fire, Do not block intakes or exhaust in any manner. Do not use on soft surfaces, like a bed where openings may become

BURN HAZARD. This heater is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. If provided, use handles when moving the heater.

OVERHEATING OR FIRE MAY OCCUR. Do not place heater behind doors.

To protect against electrical shock, do not immerse unit, plug, or cord in water or spray with liquids.

...

....9

WARNING

appliances. Arrange cord away from traffic area and where it will not be tripped over.

WARNING

this may cause an electric shock or fire, or damage the heater. Unplug heater before performing any maintenance or when not in use, to disconnect heater, turn control to low, then remove plug from outlet.

WARNING

Wash hands after handling.

DO NOT route cord under carpeting. DO NOT cover cord with throw rugs, runners or similar coverings. DO NOT route cord under furniture or

DO NOT Operate any heater with a damaged cord or plug. Discard heater or return to an authorized service facility for examination and/or repair.

RISK OF ELECTRICAL SHOCK. Connect to properly grounded outlets only. Do not insert or allow foreign objects to enter any ventilation or exhaust opening as

NEVER SUSPEND ANY OBJECTS FROM MOUNTED HEATER.

Close supervision is necessary when any appliance is used by or near children.

CALIFORNIA RESIDENTS: This product contains chemicals, including lead, known to the State of California to cause birth defects or other reproductive harm.

1

NEVER LEAVE HEATER UNATTENDED WHILE

CONNECTED TO A POWER SOURCE

Safety Information

WARNING

turning on the power while you are working on the heater. When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following:

WARNING

– Extreme caution is necessary when any

heater is used by or near children or invalids.

– Do not use outdoors.

– This heater is not intended for use in

bathrooms, laundry areas and similar indoor locations. Never locate heater where it may fall into a bathtub or other water container.

– Do not use heater in wet or moist locations.

– Always locate heater on a stable and level

surface.

– Do not place the heater against paperboard or

low-density berboard surfaces.

Turn the electrical power off at the electrical panel board (circuit breaker or fuse box) and lock or tag the panel board door to prevent someone from

Read all instructions before using this heater.

WARNING

– ALWAYS use only the electrical power

(voltage and frequency) specified on the model plate of the heater.

– ALWAYS use only three-prong, grounded

outlet and extension cord.

– ALWAYS unplug the heater when not in use.

– ALWAYS install the heater so that it is not

directly exposed to water spray, rain, dripping water, or wind.

WARNING

TOUCH. KEEP CHILDREN, ANIMALS,

CLOTHING AND COMBUSTIBLES AWAY

FROM HEATER.

RISK OF ELECTRIC SHOCK!

CAUTION! HOT WHILE

IN OPERATION. DO NOT

Look for this icon throughout the manual for helpful tips on how to assemble, use and clean your Halogen Infrared Heater.

– Keep all combustible materials away from

this heater

Minimum Clearance From Combustibles

SSR-820R-IHR SSR-820G-IHR

Front 3 ft. 3 ft.

Top 1 ft. 1 ft. Sides 1 ft. 1 ft.

NEVER LEAVE HEATER UNATTENDED WHILE

CONNECTED TO A POWER SOURCE

Specifications

Model # SSR-820R-IHR SSR-820G-IHR

Bulb Type Ruby Red Gold Coated

Power (Watts) 1,500 1,500

Power (BTU) 5,100 5,100

Power 120V~60Hz 120V~60Hz

Amps 12.5 12.5

2

Heating Area (Ft.

) 150 150

Specications subject to change without notice.

Features

LED Lights

Front Safety Guard

Heating Bulb

SSR-820R: Ruby Red Bulb

SSR-820G: Gold Coated Bulb

Wall Mounting Bracket

Figure 1

Heating Element

Power Button

Remote

Figure 2

3

Swivel Arm

LED Lights

Power Button

NEVER LEAVE HEATER UNATTENDED WHILE

CONNECTED TO A POWER SOURCE

Assembly Instructions

– Remove heater and all packaging materials

from shipping carton.

What’s In The Box

10 mm Bolts (4) 6 mm Set Screws (2) Wall Mounting Screws (4)

Tools Needed:

– Power drill – 6 mm Allen wrench – Small Phillips head screwdriver

Small Wrench (1) Batteries (2)

Wall Mounting Bracket (1) Remote Control (1)

Missing Parts? Please Call 800-641-6996 For Assistance

Mounting:

NEVER LEAVE HEATER UNATTENDED WHILE

CONNECTED TO A POWER SOURCE

Assembly

Hanging Wall Mount

1. Secure swivel arms on the wall mounting bracket using set screws and built in hex-bolts.

2. Attach the mounting bracket to a wall stud as shown below using the four (4) included wall mounting screws. (Figure 3)

Tip: Use the back plate of the wall mounting bracket as a template to

pre-drill the holes for the mounting screws.

Wall Mounting Bracket

Back Plate

Wall Mounting

Screws

2''X4''

STUD

Attaching Heater to Wall Mount

1. The tilting heater support bracket is attached to the heater body with two knob screws.

2. Attach heater support bracket to wall mounting bracket using four (4) 10mm screws. (Figure 4)

Wall Mounting

Bracket

Heater Support Bracket

(Attached to Heater)

Figure 4

NOTE: The mounting bracket is designed to support the weight of the heater only. DO NOT hang any object other than the heater from

Figure 3

CAUTION

is attached to a minimum of a 2''X4'' wall STUD that is able to support 25 pounds

continuously.

Using The Swivel Arms

1. Loosen the swivel arms with the set screw and built in hex-bolts.

2. Position swivel arms at the desired angle.

3. Secure swivel arms by tightening set screws and hex-bolts.

The installer MUST be certain the wall mounting bracket

the wall mounting bracket, swivel arms or support bracket.

WARNING

AS DESCRIBED ABOVE ON A 2''X4''

WALL STUD.

Using The Tilting Support Bracket

1. Loosen the tilting support bracket using the knob screws.

2. Position the tilting support bracket at the desired angle.

3. Secure the tilting head bracket by tightening the knob screws.

5

DO NOT MOUNT HEATER ON THE CEILING. MOUNT ONLY

NEVER LEAVE HEATER UNATTENDED WHILE

CONNECTED TO A POWER SOURCE

Operation

Operating The Heater:

Heater Controls

1. Plug power cord into 120V AC power outlet. (See Grounding Methods)

2. Use pull cord to turn power to heater on and off. The red light on the back cover will illuminate indication power is on.

3. Once the power is on, use the push button on the rear of the heater to control the heating element and LED lights. (See Chart Below)

Push Button Control

Press 1 Time Heating element turns on.

Press 2 Times

Press 3 Times

Press 4 Times

4. The remote control can also be used to control the heating element and LED lights. Direct the remote towards the sensor and press buttons for desired function. (See Chart Below)

Press 1 Time LED lights turn on.

Press 2 Times LED lights turn off.

Press 1 Time Heating element turns on.

Press 2 Times Heating element turns off

Heating element turns off. LED lights turn on.

Heating element turns on. LED lights turn on.

Heating element turns off. LED lights turn off.

Remote Control

Left Button

Right Button

Grounding Instructions

SSR-820R-IHR / SSR-820G-IHR:

– This heater is for use on 120 Volts. The

cord has a plug as show at A (below). An adapter as shown at C is available for connecting three-blade grounding-type plugs two-slot receptacles. The green grounding lug extending from the adapter must be connected to the permanent ground such as a properly grounded outlet box. The adapter should not be used if a three-slot grounded receptacle is available.

Grounding Methods

C

Grounding Means

A

Figure 5

Metal Screw

B

Grounding Pin

6

NEVER LEAVE HEATER UNATTENDED WHILE

CONNECTED TO A POWER SOURCE

Maintenance

WARNING

re-installed properly before operating the heater.

ALWAYS DISCONNECT HEATER FROM POWER SUPPLY BEFORE SERVICING.

RISK OF BURNS! THIS HEATER IS HOT WHILE OPERATING. ALLOW TO COOL

COMPLETELY BEFORE PERFORMING MAINTENANCE OR STORAGE.

When servicing or replacement of a component in the heater requires the removal or disconnection of a safety device, that safety device must be

Cleaning:

1. Clean the outer shell of the heater with a soft damp cloth.

2. Dry the outer shell of the heater with a soft cloth and allow to dry completely before operating heater.

3. Do Not use abrasives, rough brushes or scrubbing pads to clean the heater.

WARNING

gasoline, furniture / metal polish or any other flammable substances to clean this heater.

FIRE OR EXPLOSION MAY

OCCUR! Do Not use alcohol,

Storage:

Short Term Storage

1. Disconnect heater from power supply.

NOTE: For heaters used outdoors, do not store outdoors while not in use.

Long Term Storage

1. Disconnect heater from power supply.

2. Remove heater from wall mount.

Tip: Leave wall mounting bracket hanging during off-season for easy installation

when heater is taken out of storage.

Tip: Use compressed air to clean any dirt or debris from the front guard or around

the bulb.

4. Do Not submerge the heater in water or other liquid to clean.

3. Complete all cleaning procedures.

4. Wrap cord and heater in plastic shipping bags.

5. Store in a cool, dry place.

Tip: Keep original shipping materials to store heater during off-season.

7

No power

NEVER LEAVE HEATER UNATTENDED WHILE

CONNECTED TO A POWER SOURCE

Troubleshooting

Problem Possible Cause Solution

1. Unit is not plugged in properly.

2. Defective fuse.

1. Connect unit to proper

power supply.

2. Replace fuse.

Push button switch does not work

Remote control does not work.

1. Main power switch is off. 1. Pull pull-cord to turn on

main power.

1. The batteries are drained.

2. Remote control is not

directed at the receiving sensor.

1. Replace batteries.

2. Change position of the

remote and ensure it is pointed directly at the receiving sensor.

8

NEVER LEAVE HEATER UNATTENDED WHILE

CONNECTED TO A POWER SOURCE

Exploded View

10

8

9

7

6

5

1

4

3

2

Parts List

Item # Description SSR-820R-IHR SSR-820G-IHR

1 Safety Guard 40-001-0100 40-001-0100 2 Halogen Bulb 40-002-0100 40-002-0200

3 LED Bulb 40-003-0100 40-003-0100

4 LED Bulb Bracket 40-001-0200 40-001-0200 5 LED Bulb Socket 40-003-0110 40-003-0110 6 PCB 40-003-0200 40-003-0200 7 Power Switch 40-003-0500 40-003-0500

8 Power Cord 40-003-0600 40-003-0600

9 Support Bracket 40-001-0300 40-001-0300

10 Wall Mounting Bracket 40-001-0400 40-001-0400

9

NEVER LEAVE HEATER UNATTENDED WHILE

CONNECTED TO A POWER SOURCE

LIMITED WARRANTY

Pinnacle Products International, Inc. warrants this heater to the original retail purchaser only, to be free from defects in material and workmanship for a period of one (1) year from the date of initial purchase. This product must be properly installed, maintained and operated in accordance with the instructions provided.

Pinnacle Products International, Inc. requires reasonable proof of your date of purchase from an authorized retailer or distributor. Therefore, you should keep your sales slip, invoice or cancelled check from the original purchase. This Limited Warranty shall be limited to the repair or replacement of parts, which prove defective under normal use and service within the warranty period, and which Pinnacle Products International , Inc. shall determine at its reasonable discretion.

This warranty does not apply to products purchased for rental use.

This Limited Warranty does not cover any failures or operating difculties due to normal wear and tear, accident, abuse, misuse, alteration, misapplication, improper installation or improper maintenance and service by you or any third part. Failure to perform normal and routine maintenance on the heater, shipping damage, damage related to insects, birds or animals of any kind, and damage due to weather conditions are also not covered. In addition, the Limited Warranty does not cover damage to the nish, such as scratches, dents, discoloration, rust or other weather damage, after purchase.

All transportation costs for the return of damaged product or parts will be the responsibility of the purchaser. Upon receipt of damaged item, Pinnacle Products International, Inc. will examine the item and determine if defective. Pinnacle Products International, Inc. will repair or replace and return the item, freight pre-paid.

If Pinnacle Products International, Inc. nds the item to be in normal operating condition, or not defective the item will be returned freight collect. This Limited Warranty is in lieu of all other express warranties. Pinnacle Products International, Inc. disclaims al warranties for products that are purchased from sellers other than authorized dealers or distributors.

AFTER THE PERIOD OF THE ONE (1) YEAR EXPRESS WARRANTY EXPIRES, Pinnacle Products International,

Inc. DISCLAIMS ANY AND ALL IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR APPLICATION. FURTHER, Pinnacle Products International, Inc. SHALL HAVE NO LIABILITY WHATSOEVER TO PURCHASER OR ANY THIRD PARTY FRO ANY SPECIAL, INDIRECT, PUNITIVE INCIDENTAL, OR CONSEQUENTIAL DAMAGES. Pinnacle

Products International, Inc. assumes no responsibility for any defects caused by third parties. This Limited Warranty gives the purchaser specic legal rights; a purchaser may have other rights depending upon where he or she lives. Some states do not allow the exclusion or limitation of special, incidental or consequential damages, or limitations on how long a warranty lasts, so the above exclusion and limitations may not apply to you.

Pinnacle Products International, Inc. does not authorize any person or company to assume for it any other obligation or liability in connection with the sale, installation, use, removal, return or replacement of its equipment, and no such representations are binding on Pinnacle Products

International, Inc.

Always be sure to specify the model number and serial number when making any claim with Pinnacle Products International, Inc. For your convenience, use the space provided below to list this information.

Register Your Product Online at: http://www.remingtonheater.com/Product_Registration.php

Locating Your Serial Number:

Your serial number can be found on the heater’s rating label. For Example: 14010001. Have your Serial Number ready before calling customer service at 800-641-6996.

Model #:________________________________

Serial #:________________________________

Date of Purchase: ________________________

10

668 Stony Hill Road #302 Yardley, PA 19067 USA • Toll Free (800)-641-6996

Fax: (215)-891-8461 • Web: www.pinnacleint.com • Email: info@pinnacleint.com

Sun-Stream SSR-820R-IHR, SSR-820G-IHR User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
