Sunstar KM-590BL PME User Manual

PARTS BOOK

KM-590BL

High Speed, 1-Needle,
Unison Feed Lock Stitch Machine
With Vertical Large Hock
1본침 본봉 총합송 재봉기
(수직2배 훅)

SunStar CO., LTD.

PME-120921

Information

A. Parts Book 구성
Structure of Part Book

①:관계 별 고유 코드
Unique code by mechanism
②:관계 별 고유 명칭
Unique name by mechanism
③:관계도
Explode view
④Ref.No:파트별 고유 식별 번호

⑤Parts No.:고유 제품 코드
Unique Product code
Ex)

①

Unique identification number by part

②

구분

Category

구 부품

Old part

신 부품

New Part

③

Code

01-030C-1230

AS-000000-00

GP-000000-00

EP-000000-00

④

⑥Note:공지사항 표기 및 메모
Refers to notice and memo
⑦품 명:파트의 고유 품명
Name of Part:Unique name of parts
⑧Q’ty :파트의 수량
The number of parts

⑨Assembly no.:조(조) 파트의 식별 번호

조(조) 파트

Set parts

기구적 파트

Instrumental parts

전기적 파트

Electrical parts

⑥ ⑦ ⑧ ⑨ ⑤

Unique identification number by set part

비고

remarks

Warning

1. 조에 속한 파트는 개별 조립 시 제품의 파손 또는 재봉 불량이 발생될 수 있어

해당 파트에 대한 주문 시에는 조 품목으로만 구입이 가능합니다.

2. 본 책자는 Parts Book으로 제작되었으므로 매뉴얼로 사용 불가합니다.

3. 사전 예고 없이 사양이 변경 될 수도 있습니다.

1. The parts classified as ass’y items may cause damage to the machine or bad sewing
when they are separately assembled. Hence, when they are ordered, they can be
purchased as ass’y items only.

2. This is a parts book. It cannot be used as a manual.

3. Parts are Subject to change in Design Without Prior Notice.

Note

ㆍ썬스타 제품의 부품은 아래 인터넷주소로 접속하시어 신청할 수 있습니다.

http://www.sunstarcs.com

ㆍ가입된 회원께서는 썬스타 포탈 사이트에 로그인후 필요한 부품을 신청할 수 있습니다.

ㆍ부품관리-발주관리-발주등록 항목에서 부품번호와 신청수량을 입력하여 등록하시면 발주가 됩니다.

ㆍ부품번호를 모르시는 경우 파츠북 조회를 클릭하시고 사용하는 기종을 검색하여 선택하시면

해당 기종의 파츠북을 조회할 수 있습니다.

ㆍ파츠북은 관계별로 구분되어 있으며 관계를 알고 있다면 부품 찾기가 용이합니다.

ㆍYou can make an order for the parts of Sunstar machine to connect internet address.

http://www.sunstarcs.com
ㆍYou can request for parts you want after login if you are a registered member.

ㆍIn parts Management - Order Management - Order Registration entry,
you can place an order by entering the part numb er and quantity.
ㆍIf you don’t know the parts number, click the parts book menu bar.
In a download list, you can read parts book by searching model you use.
ㆍThis parts book is classified by the mechanism, therefore you can find part easily.

CONTENTS

목 차

A

B

C

D

E
F

G

H

Machine Body & Thread Tension Adjusting Mechanism

외장 및 실장력 조절 관계

Upper Shaft & Upright Shaft and Lower Shaft Mechanism

상축, 바늘대 및 입축, 하축 관계

Needle Bar & Upper Feed Mechanism

바늘대 및 상피이드 관계

Lower Feed Mechanism

하피이드 관계

Presser Bar & Knee Lifting Mechanism

누름대 및 무릎올림 관계
Lubrication Mechanism
급유 관계

Accessories Mechanism

액세서리 관계

Gauge Parts

게이지 파트

Index

인덱스

6

8

12

16

20

22

24

26

28

Machine Body & Thread Tension Adjusting Mechanism

A

A-3

A-3-1

외장 & 실장력 조절 관계

A-10

A-8

A-9

A-37

A-20

A-5

A-31

A-12

A-32

A-11

A-4

A-2

A-29

A-7

A-6

A-18

A-19

A-24

A-22

A-21

A-23

A-7

A-1

A-6

A-34

A-33

A-27

A-13

A-14

A-25

A-26

A-35

A-16

A-17

A-15

6

A-36

Ref. No. Parts No. Note Name of Parts 품 명 Q’ty

A-1 01-001A-590L Arm Bed Ass’Y 암 베드(조) 1Set

A-2 01-004A-590L

A-3 SC-0498-3710 Screw(11/64″n=40) 홈붙이 냄비 작은나사(11/64″n=40) 1

A-3-1 SC-0498-3710

A-4 01-006A-3400

A-5 SC-0498-3710

A-6 01-007C-3400

A-7 SC-0120-2118

A-8 01-008R-3400

A-9 01-109C-3400

A-10 SC-0175-1230

A-11 01-110C-3400

A-12 SC-0365-3710

A-13 01-144A-257A

A-14 SC-000568-00

A-15 01-212A-590L Needle Plate 바늘판 1

A-16 SC-000568-00

A-17 01-134A-1230 Slide Plate Ass'y 미끄럼판(조) 1Set

A-18 01-032C-1230 Thread Guide Bar 곡봉 실걸이 1

A-19 SC-0499-1230 Screw(11/64″n=40) 육각구멍붙이 멈춤나사(11/64″n=40) 1

A-20 01-015A-1230 Three Hole Thread Guide Plate 세구멍 실걸이 1

A-21 01-027C-1230 Nut For A-20 세구멍 실걸이 너트 1

A-22 44-008A-3400 Upper Thread Oil Felt Holder 윗실 급유 휄트 잡이 1

A-23 SC-0120-1230 Screw(9/64″n=40) 홈붙이 냄비 작은나사(9/64″n=40) 1

A-24 44-009M-3400 Upper Thread Oil Felt 윗실 급유 휄트 1

A-25 01-035P-3400 Machine Number Plate 번호판 1

A-26 01-035P-7400 Setting Pin For A-25 번호판 핀 2

A-27 GP-009175-00 Model Mark(KM-590BL) 모델 마크 1

A-29 01-110R-1230 Rubber Plug For Face Plate(Middle) 면판 고무마개(중) 흰색(3) 1

A-31 01-116A-2350 Upper Thread Guide Bar 실 안내봉 1

A-32 01-027C-1230 Nut For A-31 세구멍 실걸이 너트 1

A-33 40-104A-640L Thread Tension Post Ass'y 실 조절 장치(조) 1Set

A-34 SC-0509-1230 Screw(15/64″n=28) 홈붙이 멈춤나사(15/64″n=28) 1

A-35 01-110R-1230 Rubber Plug For Arm(Middle) 면판 고무마개(중) 흰색(3) 3

A-36 01-112R-1230 Rubber Plug For Arm(Small) 고무마개(소) 흰색(5) 3

A-37 01-027A-1230 Thread Guide With Three Holes 세구멍 실걸이(조) 1

Face Plate 면판 1

Screw(11/64″n=40) 홈붙이 납작 작은나사(11/64″n=40) 1

Top Cover 윗뚜껑 1

Screw(11/64″n=40) 홈붙이 납작 작은나사(11/64″n=40) 2

Thread Guide For Arm 아암 실안내 2

Screw(9/64″n=40) 홈붙이 냄비 작은나사(9/64″n=40) 2

Rubber Plug For Face Plate (Large) 면판급유마개 1

Cover For Take-Up Lever 실채기 카바 1

Screw(11/64″n=40) 홈붙이 납작 작은나사(11/64″n=40) 1

Side Cover 뒷뚜껑 1

Screw(9/64″n=40) 홈붙이 냄비 작은나사(9/64″n=40) 2

Gauge Attachment Holder 게이지 부착판 1

Screw(11/64″n=40) 홈붙이 접시 작은나사(11/64″n=40) 1

Screw(11/64″n=40) 홈붙이 접시 작은나사(11/64″n=40) 2

Applied

Period

7

Upper Shaft & Upright Shaft and Lower Shaft Mechanism

B

B-3

B-2

B-1

상축, 세운축, 하축 관계

B-10

B-11

B-9

B-7

B-8

B-5

B-6

B-22

B-21

B-4

B-13

B-12

B-14

B-16

B-15

B-17

B-24

B-23

B-59

B-19

B-27

B-28

B-20

B-30

B-18

B-37

B-57 B-58

B-38

B-39

B-36

B-44 B-45

B-46

B-35

B-49

B-52

B-47

B-53

B-31

B-32

B-26

B-25

B-29

B-34

B-33

B-48

B-50

B-51

B-56

B-55

B-54

B-41

B-40

8

B-42

B-43

Ref. No. Parts No. Note Name of Parts 품 명 Q’ty

B-1 08-101A-3400 Thread Take-Up Lever Ass'y 실채기(組)W331012G02 1Set

B-2 SC-0507-1230 Screw(15/64″n=28) 홈붙이 멈춤나사(15/64″n=28) 1

B-3 44-0000-1230 Oil Wick 유심 1

B-4 GP-030852-00 Upper Shaft 상축 1

B-5 02-002A-3400 Link Cam 링크 캠 1

B-6 SC-0123-1230 Screw(9/32″n=28) 홈붙이 납작 작은나사(9/32″n=28) 1

B-7 SC-0124-7400 Screw(9/32″n=28) 홈붙이 납작 작은나사(9/32″n=28) 1

B-8 SC-A129-4515 Screw(1/4″n=40) 홈붙이 멈춤나사(1/4″n=40) 2

B-9 02-003A-3400 Upper Shaft Front Bushing 상축 앞 붓싱 1

B-10 SC-0507-1230 Screw(15/64″n=28) 홈붙이 멈춤나사(15/64″n=28) 1

B-11 02-010M-3400 Oil Felt For B-9 상축 앞 붓싱 휄트 1

B-12 02-004A-3400 Upper Shaft Middle Bushing 상축 중 붓싱 1

B-13 SC-0507-1230 Screw(15/64″n=28) 홈붙이 멈춤나사(15/64″n=28) 1

B-14 44-017M-3400 Oil Felt For B-12 상축 중붓싱 급유 휄트 1

B-15 02-005A-3400 Upper Shaft Rear Bushing 상축 후 붓싱 1

B-16 SC-0507-1230 Screw(15/64″n=28) 홈붙이 멈춤나사(15/64″n=28) 1

B-17 44-017M-3400 Oil Felt For B-15 상축 중붓싱 급유 휄트 1

B-18 02-006A-3400 Pulley 풀리 1

B-19 SC-0150-2500 Screw(15/64″n=28) 홈붙이 납작 작은나사(15/64″n=28) 2

B-20 SC-0188-1230 Screw(5/16″n=24) 홈붙이 바인딩 작은나사(15/64″n=24) 1

B-21 02-121A-1230 Collar For Upper Shaft 메스 작동 캠 카라 1

B-22 SC-0504-4515 Screw(1/4″n=40) 홈붙이 멈춤나사(1/4″n=40) 2

B-23 02-106A-1230 Upper Shaft Gear 상축 기어 1

B-24 SC-A129-4515 Screw(1/4″n=40) 홈붙이 멈춤나사(1/4″n=40) 2

B-25 03-001A-3400 Upright Shaft 세운축 1

B-26 03-102A-3400 Upright Shaft Upper Bushing 세운축 상붓싱 1

B-27 SC-0114-1230 Screw(15/64″n=28) 홈붙이 멈춤나사(15/64″n=28) 1

B-28 03-107M-3710 Oil Felt For B-26 입축 상붓싱 휄트 1

B-29 03-103A-3400 Upright Shaft Lower Bushing 세운축 하붓싱 1

B-30 SC-0114-1230 Screw(15/64″n=28) 홈붙이 멈춤나사(15/64″n=28) 1

B-31 02-212A-1230 Upright Shaft Upper Gear 압축 상기어 1

B-32 SC-A129-4515 Screw(1/4″n=40) 홈붙이 멈춤나사(1/4″n=40) 2

B-33 02-213A-1230 Upright Shaft Lower Gear 압축 하기어 1

B-34 SC-A129-4515 Screw(1/4″n=40) 홈붙이 멈춤나사(1/4″n=40) 2

B-35 07-001A-3400 Lower Shaft 하축 1

B-36 07-002A-3400 Lower Shaft Front Bushing 하축 앞붓싱 1

B-37 SC-0507-1230 Screw(15/64″n=28) 홈붙이 멈춤나사(15/64″n=28) 1

B-38 07-003C-3400 Oil Cap(Large) For B-36 하축 앞붓싱 기름 구멍마개(大) 1

B-39 GP-034051-00 Oil Cap(Small) For B-36 하축 앞붓싱 기름 구멍마개(小) 2

B-40 44-019M-3400 Oil Felt For B-36 하축 전붓싱 급유 휄트 1

B-41 44-026P-3400 Oil Felt Pipe For B-36 하축 전붓싱 급유 파이프(6×7×25L) 1

B-42 44-020C-3400 Oil Felt Holder For B-36 하축 전붓싱 급유 휄트잡이 1

B-43 SC-0175-1230 Screw For B-42 윗뚜껑 죔나사 1

B-44 44-021S-3400 Oil Adjusting Screw For B-36 하축 기름 조절나사 1

B-45 44-022G-3400 Spring For B-44 하축 유량 조절 스프링 1

B-46 07-005A-3400 Lower Shaft Middle Bushing 하축 중붓싱 1

B-47 07-006A-3400 Lower Shaft Rear Bushing 하축 후붓싱 1

B-48 SC-0114-1230 Screw(15/64″n=28) 홈붙이 멈춤나사(15/64″n=28) 1

B-49 03-107M-3710 Oil Felt For B-47 압축 상붓싱 휄트 1

B-50 02-214A-1230 Lower Shaft Gear 하축 뒷기어 1

B-51 SC-A129-4515 Screw(1/4″n=40) 홈붙이 멈춤나사(1/4″n=40) 2

B-52 44-025A-1230 Collar For Lower Shaft 오일 펌프 카라(B) 7.94×17×8 1

B-53 SC-0512-1230 Screw(11/64″n=40) 육각구멍붙이 멈춤나사(11/64″n=40) 2

B-54 07-013A-1230 Inner Bobbin Stopper 가마잡이 1

B-55 07-011W-1230 Washer For B-54 가마잡이 와셔 1

B-56 SC-A174-4122 Screw(11/64″n=40) 홈붙이 납작 작은나사(11/64″n=40) 1

B-57 07-007A-590L Rotary Hook Ass'y 로터리 훅(組) HSM-AITR(280) 1Set

Applied

Period

9

Upper Shaft & Upright Shaft and Lower Shaft Mechanism

B

B-3

B-2

B-1

상축, 세운축, 하축 관계

B-10

B-11

B-9

B-7

B-8

B-5

B-6

B-22

B-21

B-4

B-13

B-12

B-14

B-16

B-15

B-17

B-24

B-23

B-59

B-19

B-27

B-28

B-20

B-30

B-18

B-37

B-57 B-58

B-38

B-39

B-36

B-44 B-45

B-46

B-35

B-49

B-52

B-47

B-53

B-31

B-32

B-26

B-25

B-29

B-34

B-33

B-48

B-50

B-51

B-56

B-55

B-54

B-41

B-40

10

B-42

B-43

Ref. No. Parts No. Note Name of Parts 품 명 Q’ty

B-58 GP-021885-00 Bobbin Case Ass'y 보빈 케이스(組) BC-NJ280L-NB 1Set

B-59 07-108A-590L Bobbin 보빈 1

Applied

Period

11

Needle Bar and Upper Feed Mechanism

C

C-26

바늘대 및 상피이드 관계

C-14

C-13

C-12

C-28

C-15

C-16

C-17

C-18

C-29

C-27

C-20

C-19

C-2

C-1

C-8

C-7

C-6

C-3

C-9

C-4

C-5

C-10

C-67

C-71

C-11

C-68

C-66

C-38

C-31

C-35

C-36

C-21

C-49

C-48

C-30

C-39

C-32 C-33

C-40

C-22

C-34

C-47

C-24

C-70

C-52

C-25

C-69

C-23

C-51

C-50

C-61

C-65

C-64

C-46

C-45

C-60

C-37

C-43

C-41

C-44

C-42

C-54
C-56

C-53

C-55

12

C-59

C-62

C-63

Ref. No. Parts No. Note Name of Parts 품 명 Q’ty

C-1 15-101A-3800 Upper Feed Lifting Eccentric Cam 상하운동 캠 1

C-2 SC-A129-4515 Screw(1/4″n=40) 홈붙이 멈춤나사(1/4″n=40) 2

C-3 15-202A-3800 Upper Feed Eccentric Cam Rod 상하운동 캠 롯드 1

C-4 44-023M-3400 Oil Felt For C-3 노루발 상하운동 캠 롯드 급유 휄트 1

C-5 44-015C-3400 Oil Felt Holder For C-3 상하운동 캠 롯드 유심잡이 1

C-6 15-203A-3800 Upper Feed Lifting Eccentric Wheel Crank 상하운동 크랭크 1

C-7 SC-0140-5607 Screw(1/4″n=24) 육각보울트(1/4″n=24) 1

C-8 15-007A-5607 Upper Feed Lifting Adjusting Shaft 상하운동 조절축 1

C-9 15-206A-3800 Bushing For C-8 상하운동 조절축 붓싱 1

C-10 15-009A-5607 Washer For C-8 상하운동 조절축 와셔 1

C-11 SN-0116-3400 Nut(3/16″n=32) 육각너트(3/16″n=32) 1

C-12 15-118A-590L Upper Feed Driving Shaft 상하 운동축 1

C-13 15-119A-3400 Bushing For C-12 노루발 상하 운동축 붓싱 2

C-14 SC-0114-1230 Screw(15/64″n=28) 홈붙이 멈춤나사(15/64″n=28) 2

C-15 15-117A-5607 Connecting Link For Upper Feed 상피이드 연결링크 1

C-16 15-015S-5607 Shaft Screw For C-15 상피이드 연결링크 축나사 1

C-17 SC-0116-3400 Nut(1/4″n=40) 육각너트(1/4″n=40) 1

C-18 15-218A-5607 Connecting Link For Upper Feed Foot 상피이드 노루발 연결 링크 1

C-19 15-119A-5607 Walking Bar Driving Link 상피이드 노루발 운동 링크 1

C-20 15-120A-590L Walking Bar 상피이드 노루발대 1

C-21 15-322A-5607 Upper Feed Presser Foot 상피이드 노루발(D) 1

C-22 SC-0128-7400 Screw(11/64″n=40) 홈붙이 냄비 작은나사(11/64″n=40) 1

C-23 15-123A-5607 Walking Bar Guide Plate 노루발대 안내판(K2555) 1

C-24 SC-0174-4122 Screw(11/64″n=40) 홈붙이 납작 작은나사(11/64″n=40) 2

C-25 01-017W-1600 Washer For C-24 뒷뚜껑 죔와셔 2

C-26 15-117A-3800 Walking Bar Guide Block 상피이드 노루발 안내블럭 1

C-27 15-035A-590L Walking Foot Pressure Adjusting Pole 상피이드 노루발 압력봉 1

C-28 15-027G-590L Walking Foot Pressure Spring 상피이드 노루발 압력 스프링 1

C-29 SC-0203-5607 Screw(5/16″n=28) 홈붙이 납작 작은나사(5/16″n=28) 1

C-30 15-001A-3400 Adjusting Shaft For Needle Bar Driving 수평운동 조절축 1

C-31 SN-0116-3400 Nut(1/4″n=40) 육각너트(1/4″n=40) 1

C-32 15-103A-3400 Block For C-30 노루발 수평운동축 블럭 1

C-33 06-151W-7400 Washer For C-30 포트 죔나사 와셔 1

C-34 05-014C-1230 E-Ring(Ø4) 인상판 E링(Ø4) 1

C-35 15-004A-3400 Adjusting Crank For Needle Bar Driving 수평운동 조절 크랭크 11

C-36 15-005S-3400 Screw(15/64″n=28) 수평운동 조절 크랭크 죔나사 1

C-37 15-134A-3400 Link For Needle Bar Driving 노루발 수평운동 링크 1

C-38 15-006S-3400 Stud Screw For C-37 수평운동 링크 단나사 1

C-39 06-021W-7400 Wsaher For C-38 역진 레버와셔 1

C-40 SN-0107-4000 Nut(9/32″n=28) 육각너트(9/32″n=28) 1

C-41 04-105A-590L Needle Bar Driving Rod 바늘대 수평운동 롯드 1

C-42 GP-029566-00 Stud Screw(Front) For C-41 바늘대 수평운동 롯드 단나사 1

C-43 15-008S-3400 Stud Screw(Rear) For C-41 수평운동 롯드 단나사 1

C-44 SN-0105-4000 Nut(15/64″n=28) 육각너트(15/64″n=28) 2

C-45 15-010A-3400 Needle Bar Driving Shaft Crank(Rear) 노루발 수평운동축 크랭크(後) 1

C-46 SC-A129-4515 Screw(1/4″n=40) 홈붙이 멈춤나사(1/4″n=40) 2

C-47 15-011A-3400 Needle Bar Driving Shaft 노루발 수평운동축 1

C-48 15-112A-3400 Needle Bar Driving Shaft Front Bushing 수평운동축 앞붓싱(14.72×23×27) 1

C-49 SC-0114-1230 Screw(15/64″n=28) 홈붙이 멈춤나사(15/64″n=28) 1

C-50 15-113A-3400 Needle Bar Driving Shaft Rear Bushing 수평운동축 후붓싱(14.72×22.5×25) 1

C-51 SC-0114-1230 Screw(15/64″n=28) 홈붙이 멈춤나사(15/64″n=28) 1

C-52 GP-056231-00 Needle Bar 바늘대 1 Aug.06.12

C-53 04-002A-5607 Thread Guide For Needle Bar 바늘대 실안내 1

C-54 SC-0125-5607 Screw(3/32″n=56) 홈붙이 바인딩 작은나사(3/32″n=56) 1

C-55 - Needle 바늘 1

C-56 SC-0160-5607 Screw(9/64″n=40) 홈붙이 둥근납작 작은나사(9/64″n=40) 1

C-59 15-114A-3400 Rod For Needle Bar Driving Shaft 노루발 수평운동축 롯드 1

Applied

Period

13

Presser Foot & Upper Feed Mechanism

C

C-26

노루발 및 상피이드 관계

C-14

C-13

C-12

C-28

C-15

C-16

C-17

C-18

C-29

C-27

C-20

C-19

C-2

C-1

C-8

C-7

C-6

C-3

C-9

C-4

C-5

C-10

C-67

C-71

C-11

C-68

C-66

C-38

C-31

C-35

C-36

C-21

C-49

C-48

C-30

C-39

C-32 C-33

C-40

C-22

C-34

C-47

C-24

C-70

C-52

C-25

C-69

C-23

C-51

C-50

C-61

C-65

C-64

C-46

C-45

C-60

C-37

C-43

C-41

C-44

C-42

C-54
C-56

C-53

C-55

14

C-59

C-62

C-63

Ref. No. Parts No. Note Name of Parts 품 명 Q’ty

C-60 15-015S-3400 Stud Screw For C-59 노루발 수평운동축 롯드 단나사 1

C-61 SN-0107-1230 Nut(9/32″n=28) 육각너트(9/32″n=28) 1

C-62 06-017P-3400 Connection Pin For C-59 와이 롯드 연결핀 1

C-63 SC-0122-1230 Screw(15/64″n=28) 홈붙이 납작 작은나사(15/64″n=28) 1

C-64 04-008A-590L Needle Bar Frame 바늘대 후레임 1

C-65 44-0000-1230 Oil Wick 유심 1

C-66 15-030P-3800 Hinge Pin For C-64 바늘대 후레임 힌지 핀 1

C-67 SC-0114-1230 Screw(15/64″n=28) 홈붙이 멈춤나사(15/64″n=28) 1

C-68 44-0000-1230 Oil Wick 유심 1

C-69 04-006A-590L Guide For Needle Bar Frame 바늘대 후레임 안내 1

C-70 SC-0174-4122 Screw(11/64″n=40) 홈붙이 납작 작은나사(11/64″n=40) 2

C-71 15-026W-3400 Washer 노루발 상하운동 조절축 와셔 1

Applied

Period

15

Lower Feed Mechanism

D

D-52

D-51

하피이드 관계

D-2

D-1

D-4

D-3

D-6

D-5

D-7

D-66

D-65

D-62

D-64

D-23

D-10

D-8

D-63

D-22

D-9

D-21

D-20

D-17

D-58

D-11

D-59

D-19

D-16

D-18

D-12

D-15

D-13

D-14

D-32

D-33

D-54

D-38

D-53

D-39

D-43

D-46

D-42

D-41

D-44

D-35

D-34

D-40

D-24

D-55

D-56

D-61

D-25

D-26

D-31

D-29

D-57

D-30

D-27

D-67

D-60

D-37

D-36

D-28

D-68

D-45

D-50-1

D-50

D-49

D-48

D-47

16

D-50-1

D-50

Ref. No. Parts No. Note Name of Parts 품 명 Q’ty

D-1 06-001A-3400 Feed Cam 피이드 캠 1

D-2 SC-0509-1230 Screw(15/64″n=28) 홈붙이 멈춤나사(15/64″n=28) 2

D-3 06-002A-3400 Connection Ring For Y-Rod Y-롯드 연결링 1

D-4 44-018M-3400 Oil Felt For D-3 Y-롯드 연결링 급유 휄트 1

D-5 44-015C-3400 Holder For D-4 상하운동 캠 롯드 유심잡이 1

D-6 06-103A-3400 Y-Rod Y-롯드 1

D-7 06-004A-3400 Feed Link 피이드 링크 1

D-8 06-005A-3400 Connection Shaft For Feed Link 피이드 링크 연결축 1

D-9 SC-0330-7400 Screw(15/64″n=28) 홈붙이 납작 작은나사(15/64″n=28) 1

D-10 SC-0122-1230 Screw(15/64″n=28) 홈붙이 납작 작은나사(15/64″n=28) 1

D-11 06-006A-3400 Feed Regulator Dial Shaft 다이알 축 1

D-12 06-010R-1230 O-Ring For D-11 다이알 축 오링 1

D-13 06-007C-3400 Feed Regulator Control Plate 다이알 문자 지시판 1

D-14 SC-0193-1230 Screw(3/16″n=28) 홈붙이 납작 작은나사(3/16″n=28) 1

D-15 06-026P-1230 Pin For D-13 다이알 핀 1

D-16 06-027G-1230 Spring For D-15 다이알 스프링 1

D-17 06-108A-3400 Feed Regulator 피이드 조절기 1

D-18 06-109A-3400 Feed Regulator Shaft 피이드 조절축 1

D-19 SC-0183-2700 Screw(15/64″n=28) 홈붙이 납작 작은나사(15/64″n=28) 1

D-20 06-110A-3400 Bushing For D-18 피이드 조절기축 붓싱 1

D-21 SC-0507-1230 Screw(15/64″n=28) 홈붙이 멈춤나사(15/64″n=28) 1

D-22 06-013A-3400 Reverse Feed Control Lever Shaft 역진 레버축 1

D-23 06-114C-3400 Spring Holder For D-22 역진 레버축 스프링 걸이 1

D-24 SC-0497-1230 Screw(3/16″n=28) 홈붙이 납작 작은나사(3/16″n=28) 1

D-25 06-115C-590L Spring Holder For Reverse Feed Control Lever 역진 레버 스프링 걸이 1

D-26 SC-0173-1230 Screw(3/16″n=28) 홈붙이 냄비 작은나사(3/16″n=28) 2

D-27 06-016A-3400 Feed Rock Shaft Crank 수평밀대 크랭크 1

D-28 SC-0253-7400 Screw(1/4″n=24) 홈붙이 냄비 작은나사(1/4″n=24) 1

D-29 06-017P-3400 Connection Pin For Y-Rod Y-롯드 연결핀 1

D-30 SC-0122-1230 Screw(15/64″n=28) 홈붙이 납작 작은나사(15/64″n=28) 1

D-31 06-118A-3400 Feed Rock Shaft 수평 밀대 1

D-32 06-119A-3400 Feed Rock Shaft Front Bushing 수평 밀대 앞붓싱(14.72×23×20) 1

D-33 SC-0114-1230 Screw(15/64″n=28) 홈붙이 멈춤나사(15/64″n=28) 1

D-34 06-120A-3400 Feed Rock Shaft Middle Bushing 수평 밀대 중붓싱(14.72×22.5×20) 1

D-35 SC-0507-1230 Screw(15/64″n=28) 홈붙이 멈춤나사(15/64″n=28) 1

D-36 06-121A-3400 Feed Rock Shaft Rear Bushing 수평 밀대 후붓싱 1

D-37 SC-0507-1230 Screw(15/64″n=28) 홈붙이 멈춤나사(15/64″n=28) 1

D-38 06-022A-3400 Feed Bar Crank 톱니받침 크랭크 1

D-39 06-023S-3400 Screw(3/16″n=28) 톱니받침 크랭크 죔나사 2

D-40 06-124A-3400 Feed Bar Shaft 톱니받침 축 1

D-41 04-009C-3710 E-Ring(Ø5) 이링 1

D-42 SC-0175-1230 Screw(11/64″n=40) 홈붙이 납작 작은나사(11/64″n=40) 2

D-43 06-125A-3400 Feed Bar 톱니받침 1

D-44 06-026A-3400 Feed Bar Block Shaft 톱니받침 블럭축 1

D-45 SC-0128-7400 Screw(11/64″n=40) 홈붙이 냄비 작은나사(11/64″n=40) 1

D-46 06-127A-3400 Feed Bar Block 톱니받침 블럭 1

D-47 06-128A-3400 Feed Lifting Shaft 들대 1

D-48 06-029A-3400 Feed Lifting Shaft Crank(Front) 들대 크랭크(組) 1

D-49 SC-0497-1230 Screw(3/16″n=28) 홈붙이 납작 작은나사(3/16″n=28) 1

D-50 SC-0360-3400 Screw(3/8″n=28) 홈붙이 멈춤나사(3/8″n=28) 2Set

D-50-1 06-030C-3400 Nut For D-50 들대 지지나사 너트 2

D-51 06-154A-1230 Crank Rod 크랭크 롯드 1

D-52 06-007C-1600 C-Ring For D-51 크랭크 롯드 스토퍼링(Ø20) 1

D-53 06-007A-590L Feed Dog 톱니 1

D-54 SC-0130-1230 Screw(1/8″n=44) 홈붙이 납작 작은나사(1/8″n=44) 2

D-55 02-013A-3710 Collar For Feed Rock Shaft 상축카라(14.72×22×8.5) 1

D-56 SC-A129-4515 Screw(1/4″n=40) 홈붙이 멈춤나사(1/4″n=40) 2

Applied

Period

17

Lower Feed Mechanism

D

D-52

D-51

하피이드 관계

D-2

D-1

D-4

D-3

D-6

D-5

D-7

D-66

D-65

D-62

D-64

D-23

D-10

D-8

D-63

D-22

D-9

D-21

D-20

D-17

D-58

D-11

D-59

D-19

D-16

D-18

D-12

D-15

D-13

D-14

D-32

D-33

D-54

D-38

D-53

D-39

D-43

D-46

D-42

D-41

D-44

D-35

D-34

D-40

D-24

D-55

D-56

D-61

D-25

D-26

D-31

D-29

D-57

D-30

D-27

D-67

D-60

D-37

D-36

D-28

D-68

D-45

D-50-1

D-50

D-49

D-48

D-47

18

D-50-1

D-50

Ref. No. Parts No. Note Name of Parts 품 명 Q’ty

D-57 06-050A-1230 Reverse Feed Control Lever 역진레버 1

D-58 06-053W-1230 Washer For Reverse Feed Control Lever Shaft 레버와셔 1

D-59 SC-0186-1230 Screw(3/16″n=32) 홈붙이 냄비 작은나사(3/16″n=32) 1

D-60 SC-0185-1230 Screw(3/16″n=32) 홈붙이 바인딩 작은나사(3/16″n=32) 1

D-61 06-013G-3800 Spring For Reverse Feed Control Lever 역진 레버 스프링 1

D-62 06-160A-3400 Reverse Feed Control Lever Crank(Ass'y) 역진 레버 크랭크(組) 1Set

D-63 SC-0184-1600 Screw(3/16″n=28) 홈붙이 냄비 작은나사(3/16″n=28) 1

D-64 SC-0175-1230 Screw(11/64″n=40) 홈붙이 납작 작은나사(11/64″n=40) 1

D-65 06-032A-1230 Connection Stud Screw For Y-Rod 피이드 조절기 연결 단나사 1

D-66 SN-0107-1230 Nut(9/32″n=28) 육각너트(9/32″n=28) 1

D-67 06-032A-1230 Connection Stud Screw For Crank Rod 피이드 조절기 연결 단나사 1

D-68 SN-0107-1230 Nut(9/32″n=28) 육각너트(9/32″n=28) 1

Applied

Period

19

Presser Bar and Knee Lifting Mechanism

E

E-15

E-14

E-11

노름대 및 무릎올림 관계

E-4

E-5

E-33

E-13

E-12

E-17

E-34

E-20

E-19

E-18

E-22

E-26

E-21

E-32

E-16

E-10

E-3

E-9

E-2

E-7

E-1

E-8

E-6

E-35

E-36

E-31

E-30

E-29

E-25

E-24

E-28

E-23

E-27

20

Ref. No. Parts No. Note Name of Parts 품 명 Q’ty

E-1 05-101A-7400 Presser Bar 누름대 1

E-2 05-109A-3800 Bushing For Presser Bar 누름대 붓싱 1

E-3 SC-0113-3400 Screw(11/64″n=40) 홈붙이 멈춤나사(11/64″n=40) 1

E-4 SC-0367-3400 Screw(9/16″n=20) 홈붙이 납작 작은나사(9/16″n=20) 1

E-5 SN-0100-4000 Nut(9/16″n=20) 육각너트(9/16″n=20) 1

E-6 05-006G-5607 Pressure Adjusting Spring 압력 조절 스프링 1

E-7 05-007A-5607 Sub Presser Foot 보조 노루발(B) 1

E-8 SC-0315-2302 Screw(9/64″n=40) 홈붙이 납작 작은나사(9/64″n=40) 1

E-9 05-023A-590L Presser Bar Bracket 누름대 브라켓 1

E-10 SC-A129-4515 Screw(1/4″n=40) 홈붙이 멈춤나사(1/4″n=40) 1

E-11 05-112A-5607 Roller For Presser Bar Bracket 누름대 브라켓 로울러 1

E-12 05-012A-590L Roller Shaft 누름대 브라켓 로울러 축 1

E-13 05-111A-5607 Screw For E-12 누름대 브라켓 축 나사 1

E-14 05-124A-590L Guide For E-11 누름대 브라켓 로울러 안내 1

E-15 SC-0178-7400 Screw(11/64″n=40) 홈붙이 냄비 작은나사(11/64″n=40) 2

E-16 05-016P-3400 Lock Pin For E-14 브라켓 안내 로크핀(3×32) 2

E-17 05-006A-7400 Presser Bar Lifter 누름대 올리기 1

E-18 05-118P-3400 Hinge Pin For E-17 누름대 올리기 핀 1

E-19 SC-0499-1230 Screw(11/64″n=40) 육각구멍붙이 멈춤나사(11/64″n=40) 1

E-20 05-022C-3400 Stopper For Presser Bar Lifter 누름대 올리기 스토퍼(3×20) 1

E-21 GP-029564-00 Knee Lifting Lever 무릎올림 레버 1

E-22 43-001S-3400 Stud Screw For E-21 무릎올림 레버 단나사 1

E-23 43-102A-3400 Knee Lifting Pole 무릎올림봉 1

E-24 43-103A-3400 Nut(3/16″n=28) 육각너트(3/16″n=28) 1

E-25 43-003A-3400 Holder For E-23 무릎올림봉잡이 1

E-26 43-004S-3400 Stud Screw For E-25 무릎올림봉 단나사 1

E-27 43-005A-3400 Knee Lifting Link Ass'y 무릎올림 링크(조) 1Set

E-28 43-006G-3400 Spring For E-27 무릎올림 스프링 1

E-29 SC-0179-3710 Screw(11/64″n=40) 홈붙이 둥근납작 작은나사(11/64″n=40) 2

E-30 43-008C-3400 Stopper For Knee Lifting Lever 무릎올림 레버 스토퍼(6×25) 1

E-31 40-001C-3400 Tension Release Pin 실늦추기 핀 1

E-32 40-103C-3400 Tension Release Plate 실늦추기 판 1

E-33 16-015S-3710 Stud Screw For E-32 연결 링크 단나사 1

E-34 15-033C-3400 Washer For E-33 노루발 운동 레바 지지판 링 1

E-35 40-102C-3400 Cover For Tension Release Plate 실늦추기 판 커버 1

E-36 SC-0543-2302 Screw(11/64″n=40) 홈붙이 납작 작은나사(11/64″n=40) 2

Applied

Period

21

Lubrication Mechanism

F

F-2

F-1

F-13

F-12

F-14

급유 관계

F-3

F-44

F-4

F-6

F-21

F-20

F-25

F-24

F-22

F-9

F-9-1

F-26

F-23

F-5

F-8

F-30

F-29

F-28

F-41

F-27

F-35

F-36

F-16

F-39

F-37

F-32

F-38

F-31

F-11

F-42

F-43

F-40

F-33

F-34

F-10

F-45

F-48

F-46

F-46 F-47

F-51

F-52

F-53

F-7

F-8

F-6

F-5

F-15

F-18

F-17

F-19

F-54

F-49 F-50

22

Ref. No. Parts No. Note Name of Parts 품 명 Q’ty

F-1 44-101A-3400 Oil Tank Cover For Thread Take-Up Lever 실채기 급유탱크 카바 1

F-2 SC-0543-2302 Screw(11/64″n=40) 홈붙이 납작 작은나사(11/64″n=40) 3

F-3 44-002C-3400 Packing For F-1 실채기 급유탱크 패킹 1

F-4 44-003M-3400 Oil Felt For Thread Take-Up Lever 실채기 급유 휄트 1

F-5 44-004A-3400 Oil Tank Ass'y 오일탱크(組) 2Set

F-6 SC-0179-3710 Screw(11/64″n=40) 홈붙이 둥근납작 작은나사(11/64″n=40) 8

F-7 01-017W-1600 Washer For F-6 뒷뚜껑 죔와셔 4

F-8 44-005C-3400 Oil Tank Packing 오일탱크 패킹 2

F-9 44-006C-3400 Oil Tank Pushing Plate Ass'y 오일탱크 누름판(組) 1Set

F-9-1 44-007C-3400 Oil Pipe For F-5 오일탱크 파이프 1

F-10 44-110A-3400 Oil Wick Holder For Feed Link 피이드 링크 유심잡이 1

F-11 SC-0531-2302 Screw(9/64″n=40) 홈붙이 둥근납작 작은나사(9/64″n=40) 1

F-12 44-011C-3400 Oil Pipe(Large) For Thread Take-Up Lever 급유파이프(大) 1

F-13 44-012C-3400 Oil Pipe(Middle) For Thread Take-Up Lever 급유파이프(中) 1

F-14 44-013C-3400 Oil Pipe(Small) For Thread Take-Up Lever 급유파이프(小) 2

F-15 44-0000-1230 Oil Wick 유심 1

F-16 44-012C-1230 Oil Pipe For D-67 환류 파이프 1

F-17 44-114C-3400 Oil Wick Holder For D-67 크랭크 롯드 유심 잡이 1

F-18 SC-0365-3710 Screw(9/64″n=40) 홈붙이 냄비 작은나사(9/64″n=40) 1

F-19 01-017W-1600 Washer For F-18 뒷뚜껑 죔와셔 1

F-20 44-012R-7400 Rubber Cap For Oil Tank 주유구 마개(6-8) 1

F-21 44-0000-1230 Oil Wick 유심 1

F-22 44-012C-1230 Oil Wick Pipe For B-9 환류 파이프 1

F-23 44-026G-7400 Oil Wick Pipe Holder For B-9 휄트잡이 스프링 1

F-24 44-0000-1230 Oil Wick 유심 1

F-25 44-124C-3400 Oil Wick Holder For C-3 Y-롯드 연결링 유심잡이 1

F-26 SC-0531-2302 Screw(9/64″n=40) 홈붙이 둥근납작 작은나사(9/64″n=40) 1

F-27 44-0000-1230 Oil Wick 유심 1

F-28 44-012C-1230 Oil Pipe For B-12 환류 파이프 1

F-29 44-011C-7400 Oil Wick Pipe Holder For B-12 유심 휄트 고정판(6-7) 1

F-30 SC-0531-2302 Screw(9/64″n=40) 홈붙이 둥근납작 작은나사(9/64″n=40) 1

F-31 44-0000-1230 Oil Wick 유심 1

F-32 44-012C-1230 Oil Wick Pipe For B-15 환류 파이프 1

F-33 44-0000-1230 Oil Wick 유심 1

F-34 44-124C-3400 Oil Wick Holder For D-3 Y-롯드 연결링 유심잡이 1

F-35 44-012C-1230 Oil Wick Pipe For D-3 환류 파이프 1

F-36 44-111C-7400 Oil Wick Pipe Holder(A) For D-3 유심 휄트 고정판(6-7) 1

F-37 SC-0531-2302 Screw(9/64″n=40) 홈붙이 둥근납작 작은나사(9/64″n=40) 1

F-38 44-026G-7400 Oil Wick Pipe Holder(B) For D-3 휄트잡이 스프링 1

F-39 SC-0502-2302 Screw(9/64″n=40) 홈붙이 둥근납작 작은나사(9/64″n=40) 1

F-40 44-0000-1230 Oil Wick 유심 1

F-41 44-012C-1230 Oil Wick Pipe For D-7 환류 파이프 1

F-42 44-026G-7400 Oil Wick Pipe Holder For D-7 휄트잡이 스프링 1

F-43 SC-0502-2302 Screw(9/64″n=40) 홈붙이 둥근납작 작은나사(9/64″n=40) 1

F-44 44-0000-1230 Oil Wick 유심 1

F-45 03-010A-3710 Upper Gear Case(Ass'y) 상 기어 케이스(組) 1(Set)

F-46 SC-0109-2350 Screw(M6) 육각구멍붙이 보울트(M6) 2

F-47 SC-0205-3710 Screw(9/16″n=20) 홈붙이 납작 작은나사(9/16″n=20) 1

F-48 03-016A-3710 Lower Gear Case(Ass'y) 하 기어 케이스(組) 1(Set)

F-49 SC-0109-2350 Screw(M6) 육각구멍붙이 보울트(M6) 1

F-50 SC-0205-3710 Screw(9/16″n=20) 홈붙이 납작 작은나사(9/16″n=20) 1

F-51 03-013R-3710 Gear Case Retainer(Upper Shaft) 오일씰(B) 1

F-52 03-014R-3710 Gear Case Retainer(Upright Shaft Upper) 오일씰(C) 1

F-53 03-015R-3710 Gear Case Retainer(Upright Shaft Lower) 오일씰(D) 1

F-54 03-017R-3710 Gear Case Retainer(Lower Shaft) 오일씰(E) 1

Applied

Period

23

Accessory Mechanism

G

액세서리 관계

G-1

G-24

G-3

G-4

G-25

G-6 G-7

G-14

G-21-6

G-26

G-8

G-15

G-9

G-16

G-10

G-11

G-17

G-18

G-2

G-19

G-12

G-13

G-21-9

G-21-8

G-21-7

G-23

G-21

G-21-4

G-21-5

G-21-3

G-21-2

G-20

G-21-1

G-22

24

Ref. No. Parts No. Note Name of Parts 품 명 Q’ty

G-1 91-001C-1230 Accessory Bag 액세서리 박스 1

G-2 91-106C-2700 Head Cover 미싱 커버(大) 1

G-3 91-102C-1230 Driver(Large) 드라이버(大) 1

G-4 91-103C-1230 Driver(Middle, Small) 드라이버(中,小) 1

G-6 91-104C-1230 Attachment(Steel) 정규 1

G-7 SC-0204-1230 Screw(9/64″n=40) 홈붙이 바인딩 작은나사(9/64″n=40) 1

G-8 - Needle 바늘 5

G-9 07-108A-590L Bobbin(AL) 보빈 4

G-10 01-012A-590L Needle Plate 바늘판 1

G-11 - Nail 못 6

G-12 91-011C-1230 Oiler 유차 1

G-13 91-002C-7400 Oil Receiver 유차병 1

G-14 91-003R-3710 Bed Support Rubber(A) 힌지고무(小) 2

G-15 91-002R-3710 Bed Support Rubber(B) 힌지고무(中) 2

G-16 01-042R-1230 Rubber Cushion For Hinge 힌지고무(大) 2

G-17 01-043C-1230 Head Hinge 힌지 2

G-18 91-012C-1230 Head Rest 미싱 받침대 1

G-19 91-007A-2302 Thread Stand(Ass'y) 실패꽂이(組) 1(Set)

G-20 41-101A-1230 Bobbin Winder(Ass'y) 실감기(組) 1(Set)

G-21-1 43-108C-3400 Knee Lifting Shaft 무릎 올림축 1

G-21-2 43-007C-3400 Bracket For Knee Lifting Shaft(Ass'y) 무릎 올림축 브라켓(조) 2

G-21-3 43-101C-3400 Shaft For Knee Support Base 무릎 받침축 1

G-21-4 43-103R-3400 Rubber For Knee Support Base 무릎 받침 고무 1

G-21-5 43-105C-3400 Knee Lifting Adjusting Plate 무릎 올림 조절판 1

G-21-6 43-010G-3400 Return Spring For G-21-3 무릎 받침축 리턴 스프링 1

G-21-7 43-106C-3400 Knee Lifting Stopper 무릎 올림 스토퍼 1

G-21-8 43-110C-3400 Connection Crank For G-21-3 무릎 받침축 연결 크랭크 1

G-21-9 43-109C-3400 Connection Crank For G-21-5 무릎 올림 조절판 연결 크랭크 1

G-22 44-116A-3400 Oil Pan 유수판 1

G-23 91-002S-3400 Screw For G-21 목나사 4

G-24 91-008C-1230 Oil Can 오일 캔 1

G-25 60-101A-3400 Belt Cover Ass'y 벨트커버(조) 1(Set)

G-26 GP-031765-01 Belt Cover 벨트커버 1

Applied

Period

25

Gauge Parts

H

게이지 파트

KM-590BL

Upper Feed Presser Foot (상 피이드 노루발) Sub Presser Foot (보조 노루발)

Ref. No. Parts No. Specification Ref. No. Parts No. Specifiation

Standard Parts

15-021A-5607

C-19

E-12

05-007A-5607

15-321A-5607

Option Parts

*If You Wish to Use Special Order Parts, Use “Parts No.” Above The Chart to Order It.

26

27

Index

Parts No. Name of Parts Page Ref.No.

01-001A-590L Arm Bed Ass’Y
01-004A-590L Face Plate 7 A-2
01-006A-3400 Top Cover
01-007C-3400 Thread Guide For Arm
01-008R-3400
01-012A-590L Needle Plate 25 G-10

01-015A-1230
01-017W-1600 Washer For C-24
01-017W-1600 Washer For F-6
01-017W-1600 Washer For F-18 23 F-19

01-027A-1230
01-027C-1230 Nut For A-20 7 A-21
01-027C-1230 Nut For A-31
01-032C-1230 Thread Guide Bar 7 A-18

01-035P-3400

01-035P-7400 Setting Pin For A-25

01-042R-1230
01-043C-1230 Head Hinge
01-109C-3400
01-110C-3400 Side Cover

01-110R-1230

01-110R-1230

01-112R-1230

01-116A-2350

01-134A-1230 Slide Plate Ass'y 7 A-17
01-144A-257A

01-212A-590L Needle Plate 7 A-15

02-002A-3400 Link Cam 9 B-5

02-003A-3400

02-004A-3400

02-005A-3400

02-006A-3400 Pulley 9 B-18
02-010M-3400 Oil Felt For B-9 9 B-11

02-013A-3710

02-106A-1230 Upper Shaft Gear 9 B-23

02-121A-1230

02-212A-1230

02-213A-1230

02-214A-1230 Lower Shaft Gear

03-001A-3400 Upright Shaft

03-010A-3710

03-013R-3710

03-014R-3710

03-015R-3710

03-016A-3710

03-017R-3710

03-102A-3400

03-103A-3400
03-107M-3710 Oil Felt For B-26
03-107M-3710 Oil Felt For B-47 9 B-49

04-002A-5607

04-006A-590L

04-008A-590L Needle Bar Frame
04-009C-3710 E-Ring(Ø5) 17 D-41

04-105A-590L

05-006A-7400 Presser Bar Lifter 21 E-17
05-006G-5607

05-007A-5607 Sub Presser Foot

05-012A-590L Roller Shaft
05-014C-1230 E-Ring(Ø4)

05-016P-3400 Lock Pin For E-14
05-022C-3400

Rubber Plug For Face Plate (Large)

Three Hole Thread Guide Plate

Thread Guide With Three Holes

Machine Number Plate

Rubber Cushion For Hinge

Cover For Take-Up Lever

Rubber Plug For Face Plate(Middle)
Rubber Plug For Arm(Middle)
Rubber Plug For Arm(Small)
Upper Thread Guide Bar

Gauge Attachment Holder

Upper Shaft Front Bushing
Upper Shaft Middle Bushing
Upper Shaft Rear Bushing

Collar For Feed Rock Shaft

Collar For Upper Shaft
Upright Shaft Upper Gear
Upright Shaft Lower Gear

Upper Gear Case(Ass'y)
Gear Case Retainer(Upper Shaft)
Gear Case Retainer(Upright Shaft Upper)
Gear Case Retainer(Upright Shaft Lower)
Lower Gear Case(Ass'y)
Gear Case Retainer(Lower Shaft)
Upright Shaft Upper Bushing
Upright Shaft Lower Bushing

Thread Guide For Needle Bar
Guide For Needle Bar Frame

Needle Bar Driving Rod

Pressure Adjusting Spring

Stopper For Presser Bar Lifter

7 A-1

7 A-4
7 A-6
7 A-8

7 A-20
13 C-25
23 F-7

7 A-37

7 A-32

7 A-25

7 A-26
25 G-16
25 G-17

7 A-9

7 A-11

7 A-29

7 A-35

7 A-36

7 A-31

7 A-13

9 B-9

9 B-12

9 B-15

17 D-55

9 B-21

9 B-31

9 B-33

9 B-50

9 B-25
23 F-45
23 F-51
23 F-52
23 F-53
23 F-48
23 F-54

9 B-26

9 B-29

9 B-28

13 C-53
15 C-69
15 C-64

13 C-41

21 E-6
21 E-7
21 E-12
13 C-34
21 E-16
21 E-20

Parts No. Name of Parts Page Ref.No.

05-023A-590L Presser Bar Bracket
05-101A-7400 Presser Bar 21 E-1
05-109A-3800
05-111A-5607 Screw For E-12
05-112A-5607
05-118P-3400 Hinge Pin For E-17 21 E-18
05-124A-590L Guide For E-11
06-001A-3400 Feed Cam
06-002A-3400
06-004A-3400 Feed Link 17 D-7
06-005A-3400
06-006A-3400
06-007A-590L Feed Dog
06-007C-1600 C-Ring For D-51 17 D-52
06-007C-3400
06-010R-1230 O-Ring For D-11
06-013A-3400
06-013G-3800
06-016A-3400
06-017P-3400
06-017P-3400

06-021W-7400 Wsaher For C-38 13 C-39

06-022A-3400 Feed Bar Crank 17 D-38
06-023S-3400 Screw(3/16″n=28) 17 D-39
06-026A-3400 Feed Bar Block Shaft 17 D-44
06-026P-1230 Pin For D-13 17 D-15

06-027G-1230 Spring For D-15 17 D-16

06-029A-3400

06-030C-3400 Nut For D-50 17 D-50-1

06-032A-1230
06-032A-1230
06-050A-1230

06-053W-1230

06-103A-3400 Y-Rod 17 D-6

06-108A-3400 Feed Regulator 17 D-17
06-109A-3400 Feed Regulator Shaft 17 D-18
06-110A-3400 Bushing For D-18 17 D-20

06-114C-3400

06-115C-590L
06-118A-3400 Feed Rock Shaft
06-119A-3400
06-120A-3400
06-121A-3400
06-124A-3400 Feed Bar Shaft 17 D-40
06-125A-3400 Feed Bar 17 D-43
06-127A-3400 Feed Bar Block 17 D-46
06-128A-3400 Feed Lifting Shaft

06-151W-7400 Washer For C-30 13 C-33

06-154A-1230 Crank Rod

06-160A-3400
07-001A-3400 Lower Shaft
07-002A-3400

07-003C-3400

07-005A-3400
07-006A-3400
07-007A-590L Rotary Hook Ass'y 9 B-57

07-011W-1230 Washer For B-54

07-013A-1230 Inner Bobbin Stopper
07-108A-590L Bobbin
07-108A-590L Bobbin(AL)
08-101A-3400

15-001A-3400

Bushing For Presser Bar

Roller For Presser Bar Bracket

Connection Ring For Y-Rod

Connection Shaft Fo r F ee d L in k
Feed Regulator Dial Shaft

Feed Regulator Control Plate

Reverse Feed Control Lever Shaft
Spring For Reverse Feed Control Lever
Feed Rock Shaft Crank
Connection Pin For C-59
Connection Pin For Y-Rod

Feed Lifting Shaft Crank(Front)

Connection Stud Screw For Y-Rod
Connection Stud Screw For Crank Rod
Reverse Feed Control Lever
Washer For Reverse Feed Control Lever Shaft

Spring Holder For D-22
Spring Holder For Reverse Feed Control Lever

Feed Rock Shaft Front Bushing
Feed Rock Shaft Middle Bushing
Feed Rock Shaft Rear Bushing

Reverse Feed Control Lever Crank(Ass'y)

Lower Shaft Front Bushing
Oil Cap(Large) For B-36
Lower Shaft Middle Bushing
Lower Shaft Rear Bushing

Thread Take-Up Lever Ass'y

Adjusting Shaft For Needle Bar Driving

21 E-9

21 E-2
21 E-13
21 E-11

21 E-14
17 D-1
17 D-3

17 D-8
17 D-11
17 D-53

17 D-13
17 D-12
17 D-22
19 D-61
17 D-27
15 C-62
17 D-29

17 D-48

19 D-65
19 D-67
19 D-57
19 D-58

17 D-23
17 D-25
17 D-31
17 D-32
17 D-34
17 D-36

17 D-47

17 D-51

19 D-62

9 B-35
9 B-36
9 B-38
9 B-46
9 B-47

9 B-55

9 B-54
11 B-59
25 G-9

9 B-1

13 C-30

Parts No. Name of Parts Page Ref.No.

15-004A-3400
15-005S-3400 Screw(15/64″n=28) 13 C-36
15-006S-3400 Stud Screw For C-37
15-007A-5607
15-008S-3400
15-009A-5607 Washer For C-8 13 C-10
15-010A-3400
15-011A-3400
15-015S-3400 Stud Screw For C-59

15-015S-5607 Shaft Screw For C-15 13 C-16
15-026W-3400 Washer 15 C-71
15-027G-590L

15-030P-3800 Hinge Pin For C-64
15-033C-3400 Washer For E-33 21 E-34

15-035A-590L

15-101A-3800

15-103A-3400 Block For C-30

15-112A-3400

15-113A-3400

15-114A-3400

15-117A-3800

15-117A-5607

15-118A-590L

15-119A-3400 Bushing For C-12 13 C-13

15-119A-5607

15-120A-590L Walking Bar 13 C-20

15-123A-5607

15-134A-3400

15-202A-3800

15-203A-3800

15-206A-3800 Bushing For C-8 13 C-9

15-218A-5607

15-322A-5607

16-015S-3710 Stud Screw For E-32 21 E-33
40-001C-3400 Tension Release Pin 21 E-31
40-102C-3400
40-103C-3400

40-104A-640L

41-101A-1230 Bobbin Winder(Ass'y)

43-001S-3400 Stud Screw For E-21

43-003A-3400 Holder For E-23

43-004S-3400 Stud Screw For E-25 21 E-26

43-005A-3400
43-006G-3400 Spring For E-27 21 E-28
43-007C-3400
43-008C-3400
43-010G-3400
43-101C-3400

43-102A-3400 Knee Lifting Pole

43-103A-3400 Nut(3/16″n=28) 21 E-24

43-103R-3400
43-105C-3400
43-106C-3400 Knee Lifting Stopper
43-108C-3400 Knee Lifting Shaft 25 G-21-1
43-109C-3400
43-110C-3400

44-0000-1230 Oil Wick

44-0000-1230 Oil Wick

44-0000-1230 Oil Wick

44-0000-1230 Oil Wick

44-0000-1230 Oil Wick

44-0000-1230 Oil Wick

Adjusting Crank For Needle Bar Driving

Upper Feed Lifting Adjusting Shaft
Stud Screw(Rear) For C-41

Needle Bar Driving Shaft Crank(Rear)
Needle Ba r D rivin g S ha ft

Walking Foot Pressure Spring

Walking Foot Pressure Adjusting Pole
Upper Feed Lifting Eccentric Cam

Needle Bar Driving Shaft Front Bushing
Needle Bar Driving Shaft Rear Bushing
Rod For Needle Bar Driving Shaft
Walking Bar Guide Block
Connecting Link For Upper Feed
Upper Feed Driving Shaft

Walking Bar Driving Link

Walking Bar Guide Plate
Link For Needle Bar Driving
Upper Feed Eccentric Cam Rod
Upper Feed Lifting Eccentric Wheel Crank

Connecting Link For Upper Feed Foot
Upper Feed Presser Foot

Cover For Tension Release Plate
Tension Release Plate
Thread Tension Post Ass'y

Knee Lifting Link Ass'y

Bracket For Knee Lifting Shaft(Ass'y)
Stopper For Knee Lifting Lever
Return Spring For G-21-3
Shaft For Knee Support Base

Rubber For Knee Support Base
Knee Li ft in g A dj us ting Pla te

Connection Crank For G-21-5
Connection Crank For G-21-3

13 C-35

13 C-38
13 C-8
13 C-43

13 C-45
13 C-47
15 C-60

13 C-28
15 C-66

13 C-27
13 C-1
13 C-32
13 C-48
13 C-50
13 C-59
13 C-26
13 C-15
13 C-12

13 C-19

13 C-23
13 C-37
13 C-3
13 C-6

13 C-18
13 C-21

21 E-35
21 E-32

7 A-33
25 G-20
21 E-22
21 E-25

21 E-27

25 G-21-2
21 E-30
25 G-21-6
25 G-21-3
21 E-23

25 G-21-4
25 G-21-5
25 G-21-7

25 G-21-9
25 G-21-8

9 B-3
15 C-65
15 C-68
23 F-15
23 F-21
23 F-24

28

Index

Parts No. Name of Parts Page Ref.No.

44-0000-1230 Oil Wick
44-0000-1230 Oil Wick 23 F-31
44-0000-1230 Oil Wick
44-0000-1230 Oil Wick

44-0000-1230 Oil Wick 23 F-44
44-002C-3400 Packing For F-1 23 F-3
44-003M-3400

44-004A-3400 Oil Tank Ass'y
44-005C-3400 Oil Tank Packing
44-006C-3400
44-007C-3400 Oil Pipe For F-5 23 F-9-1

44-008A-3400
44-009M-3400 Upper Thread Oil Felt
44-011C-3400
44-011C-7400
44-012C-1230 Oil Pipe For D-67
44-012C-1230 Oil Wick Pipe For B-9
44-012C-1230 Oil Pipe For B-12
44-012C-1230
44-012C-1230 Oil Wick Pipe For D-3
44-012C-1230 Oil Wick Pipe For D-7 23 F-41
44-012C-3400

44-012R-7400
44-013C-3400
44-015C-3400
44-015C-3400 Holder For D-4 17 D-5
44-017M-3400 Oil Felt For B-12 9 B-14
44-017M-3400 Oil Felt For B-15 9 B-17
44-018M-3400 Oil Felt For D-3 17 D-4
44-019M-3400 Oil Felt For B-36
44-020C-3400

44-021S-3400
44-022G-3400 Spring For B-44 9 B-45
44-023M-3400 Oil Felt For C-3 13 C-4

44-025A-1230
44-026G-7400
44-026G-7400
44-026G-7400

44-026P-3400 Oil Felt Pipe For B-36

44-101A-3400

44-110A-3400
44-111C-7400
44-114C-3400

44-116A-3400 Oil Pan 25 G-22
44-124C-3400
44-124C-3400

60-101A-3400 Belt Cover Ass'y
91-001C-1230 Accessory Bag 25 G-1
91-002C-7400 Oil Receiver

91-002R-3710

91-002S-3400 Screw For G-21

91-003R-3710

91-007A-2302 Thread Stand(Ass'y)
91-008C-1230 Oil Can 25 G-24
91-011C-1230 Oiler
91-012C-1230 Head Rest 25 G-18
91-102C-1230 Driver(Large)
91-103C-1230 Driver(Middle, Small)
91-104C-1230 Attachment(Steel)
91-106C-2700 Head Cover
GP-009175-00
GP-021885-00 Bobbin Case Ass'y

Oil Felt For Thread Take-Up Lever

Oil Tank Pushing Plate Ass'y

Upper Thread Oil Felt Holder

Oil Pipe(Large) For Thread Take-Up Lever
Oil Wick Pipe Holder For B-12

Oil Wick Pipe For B-15

Oil Pipe(Middle) For Thread Take-Up Lever
Ru bbe r Cap For O il Ta nk
Oil Pipe(Small) For Thread Take-Up Lever
Oil Felt Holder For C-3

Oil Felt Holder For B-36
Oil Adjusting Screw For B-36

Collar For Lower Shaft
Oil Wick Pipe Holder For B-9
Oil Wick Pipe Holder(B) For D-3
Oil Wick Pipe Holder For D-7

Oil Tank Cover For Thread Take-Up Lever
Oil Wick Holder For Feed Link
Oil Wick Pipe Holder(A) For D-3
Oil Wick Holder For D-67

Oil Wick Holder For C-3
Oil Wick Holder For D-3

Bed Support Rubber(B)

Bed Support Rubber(A)

Model Mark(KM-590BL)

23 F-27

23 F-33
23 F-40

23 F-4
23 F-5
23 F-8
23 F-9

7 A-22

7 A-24
23 F-12
23 F-29
23 F-16
23 F-22
23 F-28
23 F-32
23 F-35

23 F-13
23 F-20
23 F-14
13 C-5

9 B-40

9 B-42

9 B-44

9 B-52
23 F-23
23 F-38
23 F-42

9 B-41
23 F-1
23 F-10
23 F-36
23 F-17

23 F-25
23 F-34
25 G-25

25 G-13
25 G-15
25 G-23
25 G-14
25 G-19

25 G-12

25 G-3
25 G-4
25 G-6
25 G-2

7 A-27
11 B-58

Parts No. Name of Parts Page Ref.No.

GP-029564-00 Knee Lifting Lever 21 E-21
GP-029566-00
GP-030852-00 Upper Shaft
GP-031765-01 Belt Cover 25 G-26
GP-034051-00
GP-056231-00 Needle Bar 13 C-52
SC-000568-00 Screw(11/64″n=40)
SC-000568-00 Screw(11/64″n=40)
SC-0109-2350 Screw(M6)
SC-0109-2350 Screw(M6) 23 F-49
SC-0113-3400 Screw(11/64″n=40) 21 E-3
SC-0114-1230 Screw(15/64″n=28) 9 B-27
SC-0114-1230 Screw(15/64″n=28)
SC-0114-1230 Screw(15/64″n=28) 9 B-48
SC-0114-1230 Screw(15/64″n=28)
SC-0114-1230 Screw(15/64″n=28)
SC-0114-1230 Screw(15/64″n=28)
SC-0114-1230 Screw(15/64″n=28)
SC-0114-1230 Screw(15/64″n=28)
SC-0116-3400 Nut(1/4″n=40)
SC-0120-1230 Screw(9/64″n=40) 7 A-23
SC-0120-2118 Screw(9/64″n=40) 7 A-7
SC-0122-1230 Screw(15/64″n=28) 15 C-63
SC-0122-1230 Screw(15/64″n=28) 17 D-10
SC-0122-1230 Screw(15/64″n=28) 17 D-30
SC-0123-1230 Screw(9/32″n=28) 9 B-6
SC-0124-7400 Screw(9/32″n=28) 9 B-7
SC-0125-5607 Screw(3/32″n=56) 13 C-54
SC-0128-7400 Screw(11/64″n=40) 13 C-22
SC-0128-7400 Screw(11/64″n=40)
SC-0130-1230 Screw(1/8″n=44) 17 D-54
SC-0140-5607 Screw(1/4″n=24) 13 C-7
SC-0150-2500 Screw(15/64″n=28) 9 B-19
SC-0160-5607 Screw(9/64″n=40) 13 C-56
SC-0173-1230 Screw(3/16″n=28) 17 D-26
SC-0174-4122 Screw(11/64″n=40) 13 C-24
SC-0174-4122 Screw(11/64″n=40) 15 C-70
SC-0175-1230 Screw(11/64″n=40)
SC-0175-1230 Screw For B-42
SC-0175-1230 Screw(11/64″n=40)
SC-0175-1230 Screw(11/64″n=40)
SC-0178-7400 Screw(11/64″n=40) 21 E-15
SC-0179-3710 Screw(11/64″n=40) 21 E-29
SC-0179-3710 Screw(11/64″n=40) 23 F-6
SC-0183-2700 Screw(15/64″n=28) 17 D-19
SC-0184-1600 Screw(3/16″n=28) 19 D-63
SC-0185-1230 Screw(3/16″n=32)
SC-0186-1230 Screw(3/16″n=32) 19 D-59
SC-0188-1230 Screw(5/16″n=24)
SC-0193-1230 Screw(3/16″n=28) 17 D-14
SC-0203-5607 Screw(5/16″n=28)
SC-0204-1230 Screw(9/64″n=40) 25 G-7
SC-0205-3710 Screw(9/16″n=20)
SC-0205-3710 Screw(9/16″n=20) 23 F-50
SC-0253-7400 Screw(1/4″n=24)
SC-0315-2302 Screw(9/64″n=40) 21 E-8
SC-0330-7400 Screw(15/64″n=28)
SC-0360-3400 Screw(3/8″n=28)
SC-0365-3710 Screw(9/64″n=40)
SC-0365-3710 Screw(9/64″n=40)
SC-0367-3400 Screw(9/16″n=20)
SC-0497-1230 Screw(3/16″n=28)

Stud Screw(Front) For C-41

Oil Cap(Small) For B-36

13 C-42

9 B-4

9 B-39

7 A-14
7 A-16

23 F-46

9 B-30

13 C-14
13 C-49
13 C-51
15 C-67
17 D-33
13 C-17

17 D-45

7 A-10

9 B-43
17 D-42
19 D-64

19 D-60

9 B-20

13 C-29

23 F-47

17 D-28

17 D-9
17 D-50

7 A-12
23 F-18
21 E-4
17 D-24

Parts No. Name of Parts Page Ref.No.

SC-0497-1230 Screw(3/16″n=28)
SC-0498-3710 Screw(11/64″n=40) 7 A-3
SC-0498-3710 Screw(11/64″n=40)
SC-0498-3710 Screw(11/64″n=40)
SC-0499-1230 Screw(11/64″n=40) 7 A-19
SC-0499-1230 Screw(11/64″n=40) 21 E-19
SC-0502-2302 Screw(9/64″n=40)
SC-0502-2302 Screw(9/64″n=40)
SC-0504-4515 Screw(1/4″n=40)
SC-0507-1230 Screw(15/64″n=28) 9 B-2
SC-0507-1230 Screw(15/64″n=28) 9 B-10
SC-0507-1230 Screw(15/64″n=28) 9 B-13
SC-0507-1230 Screw(15/64″n=28)
SC-0507-1230 Screw(15/64″n=28) 9 B-37
SC-0507-1230 Screw(15/64″n=28)
SC-0507-1230 Screw(15/64″n=28)
SC-0507-1230 Screw(15/64″n=28)
SC-0509-1230 Screw(15/64″n=28)
SC-0509-1230 Screw(15/64″n=28)
SC-0512-1230 Screw(11/64″n=40)
SC-0531-2302 Screw(9/64″n=40) 23 F-11
SC-0531-2302 Screw(9/64″n=40) 23 F-26
SC-0531-2302 Screw(9/64″n=40) 23 F-30
SC-0531-2302 Screw(9/64″n=40) 23 F-37
SC-0543-2302 Screw(11/64″n=40) 21 E-36
SC-0543-2302 Screw(11/64″n=40) 23 F-2
SC-A129-4515 Screw(1/4″n=40) 9 B-8
SC-A129-4515 Screw(1/4″n=40) 9 B-24
SC-A129-4515 Screw(1/4″n=40) 9 B-32
SC-A129-4515 Screw(1/4″n=40)
SC-A129-4515 Screw(1/4″n=40) 9 B-51
SC-A129-4515 Screw(1/4″n=40) 13 C-2
SC-A129-4515 Screw(1/4″n=40) 13 C-46
SC-A129-4515 Screw(1/4″n=40) 17 D-56
SC-A129-4515 Screw(1/4″n=40) 21 E-10
SC-A174-4122 Screw(11/64″n=40) 9 B-56
SN-0100-4000 Nut(9/16″n=20) 21 E-5
SN-0105-4000 Nut(15/64″n=28)
SN-0107-1230 Nut(9/32″n=28)
SN-0107-1230 Nut(9/32″n=28)
SN-0107-1230 Nut(9/32″n=28)
SN-0107-4000 Nut(9/32″n=28) 13 C-40
SN-0116-3400 Nut(3/16″n=32) 13 C-11
SN-0116-3400 Nut(1/4″n=40) 13 C-31

- Needle 13 C-55

- Needle 25 G-8

- Nail

17 D-49

7 A-3-1
7 A-5

23 F-39
23 F-43

9 B-22

9 B-16

17 D-21
17 D-35
17 D-37

7 A-34

17 D-2

9 B-53

9 B-34

13 C-44
15 C-61
19 D-66
19 D-68

25 G-11

29
