Sunshine PHP, PHS, PHW, PHT Owner's Manual

Owner’s manual

SUNSHINE

OUTDOOR PATIO HEATER

MODEL

IMPORTANT

Your safety is very important. Please read this manual thoroughly before you
install, operate and maintain this heater. Retain this manual for future reference.

This appliance must be installed and gas cylinder stored in accordance with the
regulation in force.

Warning: For Outdoor Use Only!

Table of Contents

Important Warnings………………………………………… ………… … ………2
Introduction…………………………………………………………………… ……3
Specifications………………………………………………………………………. 3
Important Safety Precautions…………………………………………….……..3-5

Assembly………………………………………………………………………….....5

Tools Required………………… …………… ……………………………………5
Unpacking…………………………………………………………..…………….…5

Component List………………………………………………..…………………...5

LP gas Hookup and Installation of Cylinder…………………… … … …………6

Assembly Instructions……………………………………….

.…………………...7-9

Installation………………………………………..…………………………….…...9
Operation……………………………………..………………………...……….…10
Preparation Before Lighting………………………….……………………….…..

.10

Leak Checking……………………………………….……………………………10
Lighting…………………………………………..………….. .………………..10-11
Setting Control………………………………………...…………………………..

Turn Off and Relight……………………....…………… …………………….….

Turn Off and Shut Down………………………..………………………….…….

..11
..11

….11

Storage…………………………………………..……………………….….…11-12
Maintenance………………………………………………...…………………….

…12

Troubleshooting………………………………………….………………….….…13
Service and Warranty Information………………………………………….…...14
Warranty Terms……………………………………………………...……………14
Parts List……………………………………………………………..………...15-16

IMPORTANT WARNINGS

Warning: For your safety

Improper installation, adjustment, alteration, service or maintenance can cause
Injury or property damage from hazards of fire, explosion, burn, asphyxiation,
carbon monoxide poisoning. Please be sure you understand all operating the
instructions before operate or service this heater. Read these installation,
operation and maintenance instructions thoroughly before installing or servicing
this equipment.

Warning: For your safety

Follow the correct lighting and usage procedures. Handle metal parts with care
to avoid injuries. Never allow children to operate this heater.

Warning: For your safety
Do not store or use gasoline or other flammable vapors and liquids, solid combustibles
in the vicinity of this appliance. Keep a safe distance away from the heater as
recommended by the instructions.

Warning: For your safety

If you smell gas:

1. Shut off gas to the appliance.

2. Extinguish any open flame near the appliance.

3. If odor continues, immediately call your gas supplier or local fire department.

2

Introduction

Thank you for choosing SUNSHINE Outdoor Patio Heater. Please take the time
to read these instructions and follow each step carefully for safe operation.
Retain this manual for future reference.

Specifications

Model No. PHP/PHS/PHT/PHW
Type of gas G30 (Butane) 30mbar, G31 (Propane) 37mbar
Input rating 12.5 kW (910g/hr)
Pressure 30mbar (G30), 37mbar (G31)
Gas supply inlet pressure to

regulator
Overall height 2,290 mm
Reflector diameter 865 mm

Ignition system Piezo Igniter
Electrical connections Not required

Net Weight 30 kg. (not including the cylinder)

The heater has been certified by Danish Governmental Gas
Institute, and complies with CE Requirement for Gas-Fired
Infrared Patio Heaters prEN 14543:2002 (E) Gas-Fired Portable
Infrared Heaters.

Max.150 PSI, Min. 5 PSI

Important Safety Precautions

To ensure safe use of your outdoor patio heater, you are requested to pay
close attention to these essential safety requirements.

· This is a propane, direct-fired heater. This means that all of the combustion
products enter the heated space. Even though this heater operates very
close to 100 percent combustion efficiency, it still produces small
amounts of carbon monoxide. Carbon monoxide (CO) is toxic and can
build up in a heated space. Failure to provide adequate ventilation could
result in death.

Always be sure there is plenty of fresh air when the heater is in use.
Always follow advice about ventilation in these operating instructions. If
gas odor is detected at any time, shut off the appliance immediately, and
find and correct the leak. Please set up the propane supply with utmost
care.

3

· Alert both children and elders to the hazard of high surface
temperatures.

Care must be taken for the supervision of children in the vicinity of an
operating or hot heater.

· Your children and pets should be supervised around the heater.

· This outdoor patio heater must be used for outdoors only in a well

ventilated area and must not be used in a vehicle or any enclosed

building.

· Always place the heater on a level stable surface.

· Do not move or touch the heater while hot or in operation.

· Do not alter or modify the heater in any manner.

· Use only a U.S. Department of Transportation approved 20-pound

standard cylinder equipped with an Type 1 connection with QCC
(Quick Connect Coupler).

· Use only with liquid propane gas. Do not attempt to use any other fuel.

· Always keep at least a 24 inch clearance from any combustible material.

· Do not use if the wind speed is greater than 10 miles/hr.

· Do not use if outside temperature is below 40 F.

· Do not spray aerosols near the heater while in use.

· Do not clean heater with combustible or corrosive cleaners. Use warm, soapy

water.

· Do not hang clothing or flammable materials either on or near heater.

· Place the control knob in OFF position when heater is not in use and always

disconnect the gas cylinder at its main valve and store it outdoors where it is
not accessible to children. Never store a propane cylinder indoors.

· Always allow 45 minutes for heater to cool down after use before attempting to

move your heater.

· Use only the hose and regulator with the heater provided by the factory. Check

the regulator and hose assembly before each use. If you find an excessive
abrasion or hose cut, immediately replace with the Regulator assembly listed
on the Parts List .

· Never use the heater if the ballast weight is not assembled into the base. The

base must be weighted to prevent possible tipping.

· Inspect heater before each use and inspect annually by a qualified service

person. Do not operate a damaged heater.

· Leak-check only with soapy water following initial assembly and after cylinder

is replaced. All gas connections should be checked. Look for bubbles.

Never use flame!

4

Warning:

When the heater is to be operated in the presence of other people, the purchaser
is responsible for explaining the instructions and or explaining the hazards
involved. If this heater is used in a commercial or rental installation, it is the
responsibility of the purchaser to check local codes for properly acquainting
users with the safety precautions and instructions.

Failure to comply with the precautions and instructions provided with this
heater can result in death, serious bodily injury and property loss or
damage from hazards of fire, explosion, burn, asphyxiation, carbon
monoxide poisoning. Be sure you understand all operation instructions
before attempting to operate or service this heater.

1. Assembly

Note: The assembly of this heater requires basic mechanical skills. Proper
assembly is the responsibility of the installer. All service and repair should
be done by a qualified person.

1.1 Tools required

8mm, 10mm, 11mm, 12mm Socket
#2 & #3 Phillips Head Screwdriver
Pliers or Channel Lock Pliers

Crescent or Open End Wrenches

Caution:

Do not use Teflon tape or any thread-sealing compounds with connections of
heater head regulator / hose assembly to fuel-tube.

1.2 Unpacking

·

Remove the Fuel-tube, the Post and Heater burner assembly from Box 2 of 2.

· Take out the heater burner assembly from the base assembly by removing the

three Hex-Nuts, Flat washers and Lock washers, then screw the nuts and
washers back onto the bolts at the top of the burner assembly.

· Remove all shipping packaging foam on the components.

· Check the fasteners, Regulator assembly and the Owner’s Manual provided

by the factory.

· Remove the Reflector from Box 1 of 2.

· Check the heater for any shipping damage. If any is found, immediately

contact Sunshine Lifestyle Products.

· Retain all packaging material and carton until heater warranty has expired.

Any warranty returns require original packing and carton.

5

1.3 Component List (see Figure 1)

·Reflector

·Burner assembly

·Base assembly with the

Ballast weight & bracket

·Fuel line

·Cylinder decorative cover

·Post / Slip socket cover

·Regulator / hose assembly

·Fastener package

·Owner’s manual

· Wheel kit (optional part)

Figure 1

1.4 LP gas hookup and installation of the cylinder

1.4.1 Gas requirements:

·Our heater is designed to use LP gas only, never substitute gases.

·The heater comes with a regulator/hose assembly for hookup to a standard

20 pound (5 gallon) LP Overfill Protection Device and Type 1 fitting equipped
gas cylinder. The LP cylinder is not included. You need to purchase a filled
LP cylinder that must be constructed and marked in accordance with
specifications of the U.S. Department of Transportation. Do not use dented or
rusty LP cylinders.

·Never use an LP cylinder with a damaged valve.

·Do not modify the regulator/hose assembly.

1.4.2 LP gas hookup (see Figure 2)

The heater is designed to house a 20 pound
gas cylinder on the base assembly.

·Lift the cylinder’s decorative cover and

rest it on the triangular socket.

·Place the LP cylinder into the housing

on the base, then attach the regulator
/hose assembly to the LP cylinder
valve. The regulator and the cylinder
have right-handed threads (clockwise to
tighten). Be sure this connection is tight

but do not over tighten on the LP cylindervalve. Figure 2

6
