Operator’s Manual
GTI 26
BCI 26
2-Cycle Trimmer
2-Cycle Brush Cutter
SAVE THESE INSTRUCTIONS
DO NOT RETURN THIS UNIT TO THE RETAILER. PROOF
OF PURCHASE WILL BE REQUIRED FOR WARRANTY
SERVICE.
For assistance regarding the assembly, operation or maintenance of
the unit, please call 1-844-786-7335 (in the United States) or contact
email box customerservice@sunseekertools.com
.
Warranty service is available through an authorized service center.
To locate a service center in your area, please write us email or
call the number listed above. Service on this unit, both within and
after the warranty period, should only be performed by an
authorized and approved service center. When servicing, use only
identical replacement parts.
All information, illustrations, and specifications in this manual are
based on the latest product information available at the time of
printing. We reserve the right to make changes at any time without
notice.
The product may vary slightly from the illustrations contained in this
manual.
IMPORTANT: Read this manual thoroughly before using this product. Follow all instructions.
BCI26/GTI26/ 00
2017/01
SERVICE
SPARK ARRESTOR NOTE
NOTE: For users on U.S. Forest Land and in the states of
California, Maine, Oregon and Washington. All U.S. Forest Land
and the state of California (Public Resources Codes 4442 and
4443), Oregon and Washington require, by law that certain internal
combustion engines operated on forest brush and/or grass-covered
areas be equipped with a spark arrestor, maintained in effective
working order, or the engine be constructed, equipped and
maintained for the prevention of fire. Check with your state or local
authorities for regulations pertaining to these requirements. Failure
to follow these requirements could subject you to liability or a fine.
This unit is factory equipped with a spark arrestor. If it requires
replacement, contact your local service dealer to install the
appropriate muffler assembly.
This product contains a chemical
known to the state of California to cause cancer, birth
defects or other reproductive harm.
NOTE: Advises you of information or instructions vital to the
operation or maintenance of the equipment.
Read the operator’s manual and follow all warnings and safety
instructions. Failure to do so can result in serious injury to the
operator and/or bystanders.
• IMPORTANT SAFETY INSTRUCTIONS •
READ ALL INSTRUCTIONS BEFORE OPERATING
• • Be aware of risk of injury to the head, hands and feet.
Carefully inspect the area before starting the unit. Remove
rocks, broken glass, nails, wire, string and other objects that
may be thrown or become entangled with the unit.
Clear the area of children, bystanders and pets; keep them
outside a 50-foot (15 m) radius, at a minimum. Even then, they
are still at risk from thrown objects. Encourage bystanders to
wear eye protection. If you are approached, stop the unit
immediately.
Squeeze the throttle control and check that it returns
automatically to the idle position. Make all adjustments or
repairs before using the unit.
Do not change the engine governor settings or overspeed the
engine.
This unit is intended for occasional, household use only.
•
•
•
Read the instructions carefully. Be familiar with the controls and
proper use of the unit.
Do not operate this unit when tired, ill or under the influence of
alcohol, drugs or medication.
•
•
•
Never allow children to operate the unit. Teens must be trained, •
accompanied and supervised by an adult. Never allow adults to
operate the unit without proper instruction.
All guards and safety attachments must be installed properly
before operating the unit.
Inspect the unit before use. Replace damaged parts. Check for
fuel leaks. Make sure all fasteners are in place and secure.
Replace parts that are cracked, chipped, or damaged in any
way. Do not operate the unit with loose or damaged parts.
Only use the trimming line described in the Specifications
section of this manual. Never use metal-reinforced line, wire,
chain or rope. These can break off and become dangerous
projectiles.
Do not replace the cutting head with rigid or metal blades. Doing
so could result in serious injury.
•
•
•
•
2
WARNING: When using the unit, all safety
instructions must be followed. Please read these
instructions before operating the unit in order to ensure the
safety of the operator and any bystanders. Please keep
these instructions for later use.
CALIFORNIA PROPOSITION 65
WARNING:
DANGER:
Signals an EXTREME hazard.
Failure to obey a safety DANGER symbol WILL result in
serious injury or death to yourself or to others.
WARNING: Signals a SERIOUS hazard.
Failure to obey a safety WARNING symbol CAN result in
serious injury to yourself or to others.
CAUTION: Signals a MODERATE hazard.
Failure to obey a safety CAUTION symbol MAY result in
property damage or injury to yourself or to others.
SYMBOL MEANING
The purpose of safety symbols is to attract your attention to
possible dangers. The safety symbols, and their explanations,
deserve your careful attention and understanding. The safety
warnings do not by themselves eliminate any danger. The
instructions or warnings they give are not substitutes for proper
accident prevention measures.
SAFETY
SAFETY WARNINGS FOR GAS UNITS
•
Before setting the unit down, always make sure the engine is off
and all moving parts have stopped.
If you strike or become entangled with a foreign object, stop the
unit immediately and check for damage. Do not operate the unit
before repairing damage. Do not operate the unit with loose or
damaged parts.
Turn the engine off and disconnect the spark plug for
maintenance or repair.
Use only original equipment manufacturer (OEM) replacement
parts and accessories for this unit. These are available from your
authorized service dealer. Use of any other parts or accessories
could lead to serious injury to the user, or damage to the unit,
and void the warranty.
Keep the unit clean. Carefully remove vegetation and other
debris that could block moving parts.
To reduce fire hazard, replace a faulty muffler and spark arrestor.
Keep the engine and muffler free from grass, leaves, excessive
grease or carbon build up.
If the unit starts to vibrate abnormally, stop the unit immediately.
Inspect the unit for the cause of the vibration. Vibration is
generally an indicator of trouble.
•
•
•
Store fuel only in containers specifically designed and approved
for the storage of such materials.
Always stop the engine and allow it to cool before filling the
tank. Never remove the fuel tank cap or add fuel when the
engine is hot. Always loosen the fuel tank cap slowly to relieve
any pressure in the tank before fueling.
Always mix and add fuel in a clean, well-ventilated outdoor area
where there are no sparks or flames. DO NOT smoke.
Never operate the unit without the fuel cap securely in place.
Avoid creating a source of ignition for spilled fuel. Wipe up any
spilled fuel from the unit immediately, before starting the unit.
Move the unit at least 30 ft. (9.1 m) from the fueling source and
site before starting the engine. DO NOT smoke.
Never start or run the unit inside a closed room or building.
Breathing exhaust fumes can kill. Operate this unit only in a well
ventilated outdoor area.
•
•
•
•
•
•
•
•
•
OTHER SAFETY WARNINGS
• • Maintain the unit with care.
All service, other than the maintenance procedures described in
this manual, should be performed by an authorized service
dealer.
Never remove, modify or make inoperative any safety device
furnished with the unit.
Before inspecting, servicing, cleaning, storing, transporting or
replacing any parts on the unit:
1. Stop the unit.
2. Make sure all moving parts have stopped.
3. Allow the unit to cool.
4. Disconnect the spark plug wire.
Secure the unit while transporting.
Never store the unit with fuel in the tank, inside a building where
fumes may reach an open flame (pilot lights, etc.) or sparks
(switches, electrical motors, etc.).
Store the unit in a dry place, secured or at a height to prevent
unauthorized use or damage. Keep the unit out of the reach of
children.
Never douse or squirt the unit with water or any other liquid.
Keep handles dry and clean (free from debris, oil and grease).
Clean the unit after each use. Refer to Cleaning and Storage. Do
not use solvents or strong detergents.
Keep these instructions. Refer to them often and use them to
instruct other users. If you loan this unit to others, also loan
them these instructions.
WHILE OPERATING
•
Wear safety glasses or goggles that meet current ANSI / ISEA
Z87.1 standards and are marked as such. Wear ear/hearing
protection when operating this unit. Wear a face mask or dust
mask if the operation is dusty.
Wear heavy long pants, boots, gloves and a long sleeve shirt. Do
not wear loose clothing, jewelry, short pants, sandals or go
barefoot. Secure hair above shoulder level.
The cutting head shield must always be in place while operating
the unit. Do not operate the unit without both trimming lines
extended and the proper line installed. Do not extend the
trimming line beyond the length of the shield.
The cutting head should remain stationary when the engine
idles. If it does not, refer to Adjusting the Idle Speed.
Adjust the handle to provide the best grip, if applicable.
Make sure the cutting head is not in contact with anything
before starting the unit.
Use the unit only in daylight or good artificial light.
Avoid accidental starting. Be in the starting position whenever
pulling the starter rope. The operator and unit must be in a
stable position while starting. Refer to Starting and Stopping.
Use the right tool. Only use this tool for its intended purpose.
Always hold the unit with both hands when operating. Keep a
firm grip on both handles or grips.
Do not overreach. Always keep proper footing and balance. Take
extra care when working on stairs, steep slopes or inclines. To
avoid serious injury, do not operate the unit while on a ladder or
a roof.
Keep hands, face, and feet away from all moving parts. Do not
touch or try to stop moving parts.
Do not touch the engine, gear housing or muffler. These parts
get extremely hot from operation, even after the unit is turned
off.
Do not operate the unit faster than the speed needed to do the
job. Do not run the unit at high speed when not in use.
Do not force the unit. It will do a better, safer job when used at
the intended rate.
Always stop the unit when operation is delayed or when walking
from one location to another.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
SAVE THESE INSTRUCTIONS
•
•
•
•
•
WARNING: Gasoline is highly flammable and
its vapors can explode if ignited. Take the following
precautions:
3
• SAFETY & INTERNATIONAL SYMBOLS •
This operator's manual describes safety and international symbols and pictographs that may appear on this product. Read the operator's
manual for complete safety, assembly, operating and maintenance and repair information.
SYMBOL MEANING SYMBOL MEANING
OFF or STOP
WARNING: Small objects can be
WARNING: Keep all bystanders,
from the operating area.
or cylinder. You may get burned. These parts get
the cutting head shield. To prevent serious injury, do
not replace the cutting head with rigid or metal blades.
containing greater than 10% ethanol will likely
• ON/OFF STOP CONTROL
ON / START / RUN
• ON/OFF STOP CONTROL
• PRIMER BULB
Push primer bulb, fully and slowly, 10 times.
• THROWN OBJECTS CAN CAUSE SEVERE INJURY
propelled at high speed, causing injury.
Min. 50
ft
15 m
• KEEP BYSTANDERS AWAY
especially children and pets, at least 50 feet (15 m)
• HOT SURFACE
WARNING: Do not touch a hot muffler
extremely hot from operation. When turned off, they
remain hot for a short time.
• SHARP BLADE
WARNING: There is a sharp blade on
not touch the line cutting blade.
• DO NOT USE METAL BLADES
WARNING: To prevent serious injury, do
• SAFETY ALERT SYMBOL
Indicates danger, warning or caution. May be used in
conjunction with other symbols or pictographs.
• READ OPERATOR'S MANUAL
WARNING:
Read the operator’s
manual(s) and follow all warnings and safety
instructions. Failure to do so can result in serious
injury to the operator and/or bystanders.
• WEAR EYE AND HEARING PROTECTION
WARNING:
Thrown objects and loud
noise can cause severe eye injury and hearing loss.
Wear eye protection meeting current ANSI / ISEA
Z87.1 standards and ear protection when operating
this unit. Use a full face shield when needed.
• WEAR FOOT PROTECTION
Always wear heavy-duty, non-slip footwear when
operating this unit.
• WEAR HAND PROTECTION
Always wear heavy-duty, non-slip gloves when
handling this unit.
• HANDLE POSITION
Make sure the handle is positioned beyond the end of
the safety label.
• UNLEADED FUEL
Always use clean, fresh unleaded fuel.
• OIL
Refer to operator’s manual for the proper type of oil.
• DO NOT USE E85 FUEL IN THIS UNIT
WARNING: It has been proven that fuel
damage this engine and void the warranty.
4
APPLICATIONS
As a trimmer /brush cutter:
•
•
•
Cutting grass and light weeds.
Edging
Decorative trimming around trees, fences, etc.
Other optional attachments may be used with this unit.
KNOW YOUR UNIT
Muffler
Spark Plug
Air Filter
Cover
Starter Rope Grip
Throttle Lockout
On/Off Switch
Fuel Cap
Handle
Rear Handle
Throttle
Control
Shaft Housing
Coupler
Choke Lever
Primer Bulb
Cutting Head
Cutting Head
Shield
Muffler
Spark Plug
Air Filter
Cover
Throttle Lockout
On/Off Switch
Strap Hanger
Fuel Cap
Handle
Rear Handle
Throttle
Control
Shaft Housing
Coupler
Cutting Head
Cutting Head
Shield
5
* All specifications are based on the latest product information available at the time of printing. We reserve the right to make changes at any
1. Mounting the rod:
-Pull out the stop pin (1) and push the lower part of the rod (2) right down until the stop pin (1) clicks into the hole (3) in the rod.
This is easier to do if you rotate the bottom of the rod (2) slightly in both directions. The pin (1) is in place when it is completely
lodged in the hole.
-Once inserted, tighten the knob (4) securely.
2. Assemble the handle on the machine.
First put hex screws into the handle, second take handle on the shaft. Assemble the lower plate into the handle (bottom), and then
tighten the nut knob enough. See the bellowing pictures
time without notice.
SPECIFICATIONS*
Model name
GTI 26 BCI 26
Engine type
Air-Cooled, 2-Cycle Air-Cooled, 2-Cycle
Engine displacement
25.4cc (1.52 cu. in.) 25.4cc (1.52 cu. in.)
Rated motor power
0.7kw 0.7kw
Lubrication
Fuel/Oil Mixture Fuel/Oil Mixture
Fuel/Oil ratio
40:1 40:1
Volumes of fuel tank
20 oz. (600ml) 20 oz. (600ml)
Trimmer mechanism
Bump Head Bump Head
Cutting path diameter
15 in. (380mm) 17in (430mm)
Trimming line
0.079 in.(2.0mm) 0.095 in. (2.4mm)
Max. engine speed
(with cutting attachment, no-load)
8400/min 9700/min
ASSEMBLY
When assembling this machine, please follow the instructions for assembly steps.
6
7
3.1 Fitting the guard for curved shaft grass deflector:
-Remove the guard plug (1) from the end of the bottom part of the rod (2).
--Secure the guard (3) to the support (4) using the supplied bolts (5)
.
3.2 Fitting the guard for straight shaft grass deflector
Fix the transmission with hex key and wrench enclosed as standard
accessories for tightening
the nuts with the safe guard.
-The guard is fixed to the angle transmission by two screws
Warning! Use only original manufacturer's replacement parts, accessories and
attachments. Failure to do so can cause poor performance, possible injury and may void
your warranty. Never use the machine without the guard assembled!
4. Assembly and disassembly of the cutting head
4.1 Assembly and disassembly of the cutting head for GTI26:
a) Assembly
Block rotation of the shaft (1) with a proper wrench.
Fit the cutting line head (2) screwing it clockwise.
b) Disassembly
Block rotation of the shaft (1) with a proper wrench.
Remove the cutting line head (2) unscrewing it anticlockwise.
4.2 Assembly and disassembly of the cutting head for BCI26:
a) Release the nut. Line up the two holes of flange and shield, use one screw driver to hold the
flange as below and turn the socket wrench clockwise, the nut will be released.
b) Fit the Nylon cutting head. Remove another shield after release the nut. Still hold the flange,
take the Nylon cutting head on the shaft and rotate counter-clockwise, the Nylon cutting head is
fitted.
FIG 3.1
FIG 4.1
8
c) Release the Nylon cutting head. Use screw driver to hold flange and then rotate the Nylon
cutting head clockwise, it will be replaced.
d) Fit the blade. Take the outer flange off after release the nut, then put the blade, outer flange,
shield and nut according to priority as below picture. Note the blade rotation direction needs be
same as below picture. Use screw driver to hold flange and tighten nut counter-clockwise, ensure
the nut is tightened enough.
e) Release blade. Use screw driver to hold flange and release nut, the blade can be took off.
Warning!
Please make sure the cutting head has been assembled correctly before use!
5. Fit the belt. According to picture showing, fit the belt well.
OPERATION
When operating this machine, please follow the instructions for operations steps.
1. Filling with fuel
Never use oil for 4-cycle engine use or water-cooled 2-cycle engine. If can cause spark
plug fouling exhaust port blocking or piston ring sticking.
Mixed fuels, which have been left unused for a period of one month or more may clog the
carburetor or result in the engine failing to operate properly. Put remaining fuel into an
airtight container and keep it in the dark and cool room.
Mix a regular grade gasoline (leaded or unleaded, alcohol-free) and a quality-proven
motor oil for air-cooled 2 cycle engines.
RECOMMENDED MIXING RATIO
GASOLINE 40: OIL 1
WARNING! Take care of the emission of exhaust gases. Always shut off engine
before fueling. Never add fuel to a machine with a running or hot engine. Take care
of fire!
WARNING! Never smoke whilst refueling and avoid inhaling the petrol fumes.
WARNING! Carefully open the tank top as pressure could have formed inside.
Danger of injury!
Fuel is explosive!
- Turn off and cool the motor down before filling the tank with fuel.
- You must observe all safety instructions relating to handing fuel.
Risk of device damage!
The device is supplied without motor or gearbox oil.
Before operating, you must fill it with fuel.
9
Before refuelling:
Shake the fuel mixture container well.
Place the machine on a flat stable surface, with the fuel tank cap facing upwards.
Clean the fuel tank cap and the surrounding area to avoid any dirt from entering the tank
during refilling.
Carefully open the fuel tank cap to allow the pressure inside to decrease gradually. Use
a funnel to refill and avoid filling the tank to the brim.
– Unscrew the tank cap and remove it.
– Pour in the fuel carefully, avoid spilling.
– Screw the tank cap on firmly by hand.
Draining fuel
– Hold a collection container beneath the fuel drain bolt.
– Unscrew the tank cap and remove it.
- Allow the fuel to run out completely.
- Screw the tank cap on firmly by hand.
WARNING! Always close the fuel tank cap firmly.
WARNING! Immediately clean all traces of fuel which may have dripped on the
machine or the ground and do not start the engine until the petrol fumes have
dissipated.
10
Start on the unit
Do not start the unit until it has been completely assembled. Before switching on the unit,
always check the oil.
Check before use!
Check the safe condition of the device:
– Check the device for leaks.
– Check the device for visual defects.
– Check that all parts of the device have been securely fitted.
-Check that all safety devices are in proper condition.
Once the machine has been set up properly, start the engine as follow:
1. Press the fuel pump more than 10 times.
2. Turn the engine switch to the ON position.
Danger of injury!
Do not operate the device unless you did not find any faults. If a part has become
defective, make sure to replace it before you use the device again.
Danger of injury!
Before starting work, always check the ground and remove all objects
which could be thrown by the device.
11
. 3. Put the choke lever on the (OFF) position.
4. Pull the recoil starter handle 3-5 times to start the engine. Hold the machine firmly on the
ground with one hand on the power unit, in order not to lose control of the machine during
startup as following picture.
5. Pull the starter grip slowly for 10 - 15 cm until you feel some resistance, then tug it a few
times until you hear the engine turn over. Then adjust the choke lever to (ON) position.
12
6. Pull the starter grip again until the engine starts as normal.
7. When the engine is running and idling, the throttle lever on handle is as below picture.
First press the lock off lever and then switch the throttle lever on, the machine will be
working.
8. Adjusting line length when working: This machine is fitted with a “Tap & Go”head.To
release more line, tap the cutting line head against the round with engine at top speed: the
line will be released automatically and the knife cut off the excess length.
9. If meet any problem occurs, press the engine switch, the machine will stop running.
If need stop cutting head working, release the throttle lever.
13
10. If any problem occurs, pull the pin of safety belt, then release the brush cutter
immediately.
11. If the machine is hot, the throttle level can be adjusted to ON position directly when re
start the machine.
12.WARNING! Do not use the machine for sweeping, tilting the cutting line head. The
power of the engine could throw objects and small stones 15 metres or more, causing
damage or injuries to people.
Note:
1. Do not start the motor in tall grass
2. While mowing, lay the connection cable safely on footpaths and on areas which
have already been mown.
3. When the engine has been switched off, the cutter continues running for several
seconds therefore do not get close to the cutting head of the brush cutter until the
cutter has come to a standstill!
When the engine has been switched off, the cutter continues running for several
seconds therefore do not close to cutting head of grass trimmer until the cutter has
come to a standstill!
Correct maintenance is essential to maintain the original efficiency and safety of the
CLEANING AND STORAGE
14
ROUTINE MAINTENANCE
machine over time.
Before performing any maintenance or cleaning work, always turn off the engine.
1. Do not spray the unit with water. Ingress of water may damage the engine and electrical
connection.
2. Clean the unit with a cloth, hand brush, etc.
WARNING! During maintenance operations:
– Remove the spark plug cap.
– Wait until the engine is sufficiently cold.
– Never dispose of oils, fuel or other polluting materials in unauthorized places.
Maintenance schedule
12 hours of use 24 hours of
36 hours of
Air filter
clean
clean
replace
Spark plug
check
clean
replace
Expert inspection is required:
a) If the grass trimmer strikes an object.
b) If the motor stops suddenly
c) If the nylon cutter is damaged
d) If the gears are damaged.
Replacing and recleaning the nylon spool at the end of the trimming season. Always
re-cleaned the nylon spool or, if required, replace the nylon spool with a new one. Always
have the nylon spool re-cleaned or replaced by a customer service centre.
STORAGE
At the end of each working session, carefully clean the machine of dust and debris, and
make sure that there are no damaged parts, replacing any faulty parts. The machine must
be stored in a dry place away from the elements and with the cover correctly fitted.
CLEANING THE ENGINE AND THE SILENCER
To reduce fire risks, periodically clean the cylinder fins with compressed air and clear the
silencer area to get rid of sawdust, branches, leaves or other debris.
STARTING UNIT
To avoid overheating and damage to the engine, always keep the cooling air vents clean
and free of sawdust and debris. If you notice signs of wear on the starter cable, contact
your Dealer for a replacement.
NUTS AND SCREWS
Periodically check that all the nuts and screws are securely tightened and the handgrips are
tightly fastened.
15
Change and clean the spark plug
-Periodically remove and clean the spark plug using a metal brush to get rid of any
deposits.
-Check and reset the correct distance between the electrodes.
-Replace the spark plug and fasten it firmly using the supplied wrench.
-The spark plug must be replaced with one with the same characteristics whenever the
electrodes have burnt or the insulation has worn, and in any case every 100 working hours.
Clean the air filter
IMPORTANT Cleaning the air filter is essential to guarantee the efficiency and duration of
the machine. Do not work with a damaged filter or without a filter, as this could permanently
damage the engine. It must be cleaned after every 12 working hours.
Clean the filter as follows:
Loosen the knob, remove the cover and the filter element
Wash the filter element with soap and water. Do not use petrol or other solvents.
Leave the filter to dry in the open air.
Fit the filter element and the cover back on, tightening the knob again
.
Warning!
Never run the engine without the air filter element installed.
16
SHARPENING THE LINE CUTTING KNIFE
Remove the line cutting knife (1) from the guard (2) by unscrewing the screws (3).
Fix the line cutting knife in a vice and sharpen it using a flat file, being careful to retain
the original cutting angle.
Refit the knife on the guard.
CLEANING
STORAGE
•
Never store a fueled unit where fumes may reach an open flame
or spark.
Allow the engine to cool before storing.
Lock up the unit to prevent unauthorized use or damage.
Store the unit in a dry, well-ventilated area.
Store the unit out of the reach of children.
To suspend the attachment from a hook, install the hanger cap
onto the attachment. Make sure the release button is securely
locked into one of the holes on the hanger cap.
•
•
•
•
•
Use a small brush to clean the outside of the unit. Do not use strong
detergents. Household cleaners that contain aromatic oils such as
pine and lemon, and solvents such as kerosene, can damage
plastic. Wipe off any moisture with a soft cloth.
Short-term Storage (1-2 weeks)
1. Store the unit in a horizontal position. If this is not possible, store
the unit vertically with the engine at the top.
Long-term Storage
1.
Remove the fuel cap, tip the unit and drain the fuel into an
approved container. Reinstall the fuel cap.
Start the engine and allow it to run until it stalls. This ensures
that all fuel has been drained from the carburetor.
Allow the engine to cool. Remove the spark plug and put 5
drops of any high-quality motor oil or 2-cycle oil into the
cylinder. Pull the starter rope slowly to distribute the oil. Reinstall
the spark plug.
Thoroughly clean the unit and inspect it for any loose or
damaged parts. Repair or replace damaged parts and tighten
loose screws, nuts or bolts.
2.
3.
4.
Preparing the Unit for Use after Long-term Storage
1. Remove the spark plug. Tip the unit and drain all of the oil from
the cylinder into an approved container. Reinstall the spark plug.
NOTE: Do not use fuel that has been stored for more than 30 days.
Dispose of old fuel and oil according to federal, state and local
regulations.
WARNING: To avoid serious personal injury, always
stop the engine and allow it to cool before cleaning or
maintaining the unit.
CLEANING AND STORAGE
17
Head line replacement
The fuel tank is empty Fill the fuel tank with properly-mixed fuel
Squeeze the throttle control and pull the starter rope until the
engine starts
The engine is flooded
The spark plug is fouled Replace the spark plug
The air filter is dirty Clean or replace the air filter
The idle speed is incorrect Adjust the idle speed
The fuel is old (over 30 days) and/or improperly mixed Drain the fuel tank and add fresh, properly-mixed fuel
The air filter is dirty Clean or replace the air filter
The fuel is old (over 30 days) and/or improperly mixed Drain the fuel tank and add fresh, properly-mixed fuel
The spark plug is fouled Replace the spark plug
The cutting head is bound with grass Stop the engine and clean the cutting head
The inner reel is bound up Rewind the line
The line is welded Open the cutting head and remove the welded section
Stop the unit, push the bump knob and pull the line until 4 inches
(102 mm) is outside of the cutting head
Not enough line is extended
There is oil, cleaner or lubricant in the cutting head Clean and thoroughly dry the cutting head
If further assistance is required, contact an authorized service dealer.
THE CUTTING LINE ADVANCES UNCONTROLLABLY
The line is twisted Rewind the line
The cutting head is dirty Clean the inner reel and outer spool
The cutting head is out of line Refill the cutting head with new line
THE CUTTING HEAD WILL NOT ADVANCE LINE
The air filter is dirty Clean or replace the air filter
THE ENGINE LACKS POWER OR STALLS
The cutting head is bound with grass Stop the engine and clean the cutting head
THE ENGINE WILL NOT ACCELERATE
The fuel is old (over 30 days) and/or improperly mixed Drain the fuel tank and add fresh, properly-mixed fuel
THE ENGINE WILL NOT IDLE
The choke lever was not flipped Refer to Starting Instructions in the Starting and Stopping section
The fuel is old (over 30 days) and/or improperly mixed Drain the fuel tank and add fresh, properly-mixed fuel
The primer bulb was not pressed enough Press the primer bulb 10 times or until fuel is visible
PROBLEM SOLUTION
THE ENGINE WILL NOT START
TROUBLESHOOTING
18
NOTES
19
20
MANUFACTURER’S LIMITED WARRANTY
The limited warranty set forth below is given by Sunseeker with respect to new merchandise purchased and used
in the United States, its possessions and territories .
Sunseeker warrants this product against defects in material and workmanship for a period of three (3) years
commencing on the date of original purchase and will, at its option, repair or replace, free of charge, any part
found to be defective in material or workmanship. This limited warranty shall only apply if thi
s product has been
operated and maintained in accordance with the Operator’s Manual furnished with the product, and has not been
subject to misuse, abuse, commercial use, neglect, accident, improper maintenance, alteration, vandalism,
theft, fire, water or damage because of other peril or natural disaster. Damage resulting from the installation or
use of any accessory or attachment not approved by Sunseeker for use with the product(s) covered by this
manual will void your warranty as to any resulting damage. This warranty is limited to n
inety (90) days from the
date of original retail purchase for any Sunseeker product that is used for rental or commercial purposes, or any
other income-producing purpose.
HOW TO OBTAIN SERVICE: Warranty service is available, WITH PROOF OF PURCHASE THROUGH YOUR
LOCAL AUTHORIZED SERVICE DEALER. To locate the dealer in your area, call 1-844-786-7335. No product
returned directly to the factory will be accepted unless prior written permission has been extended by the
Customer Service Department of Sunseeker.
This limited warranty does not provide coverage in the following cases:
A. Tune-ups - Spark Plugs, Carburetor Adjustments, Filters
B. Wear items - Bump Knobs, Outer Spools, Cutting Line, Inner Reels, Starter Pulley, Starter Ropes, Drive Belts,
Saw Chains, Guide Bars, Cultivator Tines, Blades.
C. Sunseeker does not extend any warranty for products sold or exported outside of the United States of America,
its possessions and territories, except those sold through Sunseeker’s authorized channels o
f export distribution.
Sunseeker reserves the right to change or improve the design of any Sunseeker Product without assuming any
obligation to modify any product previously manufactured.
No implied warranty, including any implied warranty of merchantability or fitness for a particular purpose,
applies after the applicable period of express written warranty above as to the parts as identified. No
other express warranty or guaranty, whether written or oral, except as mentioned above, given by any
person or e
ntity, including a dealer or retailer, with respect to any product shall bind Sunseeker. During
the period of the Warranty, the exclusive remedy is repair or replacement of the product as set forth
above. (Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may
not apply to you.)
The provisions as set forth in this Warranty provide the sole and exclusive remedy arising from the sales.
Sunseeker shall not be liable for incidental or consequen
tial loss or damages including, without
limitation, expenses incurred for substitute or replacement lawn care services, for transportation or for
related expenses, or for rental expenses to temporarily replace a warranted product. (Some states do not
allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you.)
In no event shall recovery of any kind be greater than the amount of the purchase price of the product sold.
Alteration of the safety features of the product shall voi
d this Warranty. You assume the risk and liability for loss,
damage, or injury to you and your property and/or to others and their property arising out of the use or misuse or
inability to use the product.
This limited warranty shall not extend to anyone other than the original purchaser, original lessee or the person
for whom it was purchased as a gift.
How State Law Relates to this Warranty: This warranty gives you specific legal rights, and you may also have
other rights which vary from state to state.
To locate your nea
rest service dealer, dial 1-844-786-7335 in the United States.
Loading...
