SUNRICH TECHNOLOGY IU-100, IU-110, IU-120 User Manual

USB to RS-422/485 Serial Adapter

User Manual

Ver. 4.00

All brand names and trademarks are properties of their

respective owners.

Contents:

Chapter 1: Introduction ...................................................... 3

1.1 Product Introduction .................................................... 3

1.2 Features ........................................................................ 3

1.3 System Requirements .................................................. 4

1.4 Package Contents ......................................................... 4

Chapter 2: Getting Started ................................................. 4

2.1 Hardware Layout ......................................................... 4

2.2 Pin Assignment ............................................................ 9

2.3 Jumper Settings.......................................................... 10

2.4 Driver Installation ...................................................... 11

2.4.1 Installation for Windows XP/Vista/7/8/10 .......... 11

2.4.2 Installation for Linux 2.6.31 or later ................... 12

2.4.3 Installation for Mac OS X ................................... 12

2.4.4 Installation for Windows CE............................... 12

MN3000100022 Page 2

Chapter 1: Introduction

 Compliant with USB 2.0 specification
 Serial communication speeds up to 1Mbps
 RS-422 and RS-485 auto detect and switching
 ±15KV ESD protection on all signal pins
 Additional I/O or IRQ not required
 LEDs for indicating TxD/RxD activity
 Wall mount support
 Drivers provided for Windows, Mac OS X and Windows CE

1.1 Product Introduction

USB to RS-422/485 Serial Adapter provides an easy way to add
1/2/4 serial ports to your desktop or notebook computer. This USB to
Serial Adapter functions as a converter between a USB port and
standard serial ports. You can easily connect this adapter to the USB
port on your PC or USB hub and get access to any RS-422/485 devices.
This device is suitable for portable devices, and industrial applications.

1.2 Features

MN3000100022 Page 3

1.3 System Requirements

 Windows® XP/Vista/7/8/10/Server2008/2012
 Mac OS X 10.4 or later, Linux and Windows CE
 Available USB port

 1 x USB to RS-422/485 Serial Adapter
 1 x Driver CD
 1 x User Manual
 1 x USB type A-B cable
 1 x Power Adapter (Optional)

Note: Contents may vary depending on country/market.

1.4 Package Contents

Chapter 2: Getting Started

2.1 Hardware Layout

1-Port USB to RS-422/485 Serial Adapter:

MN3000100022 Page 4
