10/100 Mbps Ethernet ExpressCard
User Manual
Ver. 2.00
All brand names and trademarks are properties of their
respective owners.
MN5000000041 Page2
Features and Benefits
Fully compliant with ExpressCard Specification 1.0
ExpressCard/34 Form Factor Module
Fully compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
10/100M data rate auto-negotiation
LEDs indicate the status of data transmission
Support Wake On Lan (WOL) power management (optional)
Feature full duplex mode that doubles the network connection
speed
Supports Windows® 2000, XP/2003/Vista/7 (32/64 bit)
System Requirements
Windows® 2000, XP/2003/Vista/7 (32/64 bit)
ExpressCard-enabled system with an available ExpressCard slot
Package Contents
1 x 10/100 Mbps Ethernet ExpressCard
1 x Driver CD
1 x User Manual
Note: Contents may vary depending on country/market.
MN5000000041 Page3
Hardware Description
LED Indicators
The following table provides descriptions of the LED status and
their meaning.
LED Color Status Description
F
(100/ACT)
GREEN
ON The port is connecting with 100 Mbps
BLINK Sending/Receiving Packets
L
(10/ACT)
GREEN
ON The port is connecting with 10 Mbps
BLINK Sending/Receiving Packets
MN5000000041 Page4
Hardware Installation
General instructions for installing the card are provided below. Since
the design of system may vary, refer to your system’s reference manual
for further information, if needed.
Insert the 10/100 Mbps Ethernet ExpressCard into the ExpressCard slot
of your system. Make sure it is inserted all the way in for a solid
connection.
Driver Installation
For Windows® 2000, XP/2003 32/64 bit
1. Please insert the CD driver bound with 10/100 Mbps Ethernet
ExpressCard into your CD-ROM Drive.
2. At the Windows desktop click Start, then Run.
3. Type D:\ExpressCard\RTL81XXX\setup.exe, then click OK.
(Change D:\ to match your CD-ROM drive letter)
4. Follow the on-screen instructions to complete the instructions to
complete the installation to complete the installation.
For Windows® Vista 32/64 bit
1. Please insert the CD driver bound with 10/100 Mbps Ethernet
MN5000000041 Page5
ExpressCard into your CD-ROM Drive.
2. At the Windows desktop click Start, then Run.
3. Type D:\ExpressCard\RTL81XXX\Vista\setup.exe, then click
OK. (Change D:\ to match your CD-ROM drive letter)
4. Follow the on-screen instructions to complete the instructions to
complete the installation to complete the installation.
For Windows® 7 32/64 bit
1. Please insert the CD driver bound with 10/100 Mbps Ethernet
ExpressCard into your CD-ROM Drive.
2. At the Windows desktop click Start, then Run.
3. Type D:\ExpressCard\RTL81XXX\Win7\setup.exe, then click
OK. (Change D:\ to match your CD-ROM drive letter)
4. Follow the on-screen instructions to complete the instructions to
complete the installation to complete the installation.
