RF Single color controller
SR-2836DIM & SR-2836DDIM
Wiring diagram
1)Receiver Connection Diagram for Single Unit
SR-283 6DIM
5
SR-283 6DDIM
Feature
SR-2836DIM & SR-2836DDIM are RF controllers for single color lighting. Each white can achieve 256 levels
brightness adjustment. Key part can be uninstall every easily to change battery and frames from other factory.
Receivers work with WIFI-RF convertor to be controlled by smart phone
Parameter
Remote
Part No.
Operation Voltage
SR-2836DIM 3VDC
Receiver
Part No.
Input Voltage
SR-1009FA 12-36VDC
SR-1009EA 12-36VDC
SR-1009FA3 12-36VDC
SR-1009FA7 12- 36V DC
Ope rat ion
Fre que ncy
916.63MHz
Output Current
4x5A
4x350mA
Remarks
RF Wireless
Output Power
4x(60-180)W
4x(96-288)W4x8A
4x(4.2-12.6)W
4x(8.4-25.2)W4x700mA
Remarks
Consta nt voltag e
Consta nt voltag e
Consta nt curren t
Consta nt curren t
Installation
Po
w
e
r su
pp
ly
P
o
we
r s
u
p
pl
y
SR-2836DIM
SR-2836DDIM
Singl e Color LED Str ip
Singl e Color LED Str ip
Singl e Color LED Str ip
Singl e Color LED Str ip
Power Supply
12-36VDC
Learning K ey
SR-100 9FA
LED CO NTROL LER
110V-230VAC
LN
1234
white
Singl e Color LED Str ip
Power Supply
12-36VDC
Learning K ey
SR-100 9FA
LED CO NTROL LER
4x10A
110V-230VAC
LN
1234
white
4x5A
2) Connection Diagram for Multiple UnitsReceiver
Power Supply
12-36VDC
Learning K ey
Learning K ey
Learning K ey
SR-100 9FA
LED CO NTROL LER
4x5A
SR-100 9FA
LED CO NTROL LER
4x5A
SR-100 9FA
LED CO NTROL LER
4x5A
110V-230VAC
LN
1234
white
1234
white
1234
white
Sing le Colo r LED Str ip
Sing le Colo r LED Str ip
Sing le Colo r LED Str ip
Sing le Colo r LED Str ip
Sing le Colo r LED Str ip
Sing le Colo r LED Str ip
Sing le Colo r LED Str ip
Sing le Colo r LED Str ip
Sing le Colo r LED Str ip
Sing le Colo r LED Str ip
Sing le Colo r LED Str ip
Sing le Colo r LED Str ip
Operation
a.Learning
Press shortly the learning Key on the receiver, then push the rotary button .Once successfully learn, the LED
lights will blink on the receiver. Do the same for the other receivers if you use them, you can add as many
optional receivers as you want
b.Operation
-Short push rotary button to switch ON/OFF
-Adjust dim brightness by the rotary button from left to right 1-100%
-Adjust dim brightness by the rotary button from right to left 100-1%
Safety & Warnings
1) Th e pro duc t sha ll be i nst all ed an d ser vic ed by a q ual ifi ed pe rso n.
2) IP20.Please avoid the sun and rain. When installed outdoors, please ensure it is mounted in a water proof
enclosure.
3) Always be sure to mount this unit in an area with proper ventilation to avoid overheating.
4) Please check if the output voltage of any LED power supplies used comply with the working voltage of the
product.
5) Never connect any cables while power is on and always assure correct connections to avoid short circuits
before switching on.
6)
Please ensure that the cable is secured tightly in the connector
7) For update information please consult your supplier.
Warranty Agreement
1) We p rov ide l ife lon g tec hni cal a ssi sta nce w ith t his p rod uct :
5-year warranty. We pr int d ate o n eve ry pr odu cts , for e xam ple : 1125 means year 2011, wee k 25. The
warranty is for free repair or replacement and covers manufacturing faults only.
For faults beyond the 5-year warranty we reserve the right to charge for time and parts.
2) Limited Wa rre nty
Any defects caused by wrong operation.
Any damages caused by unauthorized removal, maintenance, modifying, incorrect connection and
replacement of chips.
Any damages due to transportation, vibration etc. after purchase.
Any damages caused by earthquake, fire, lightning, pollution and abnormal voltage.
Any damages caused by negligence, inappropriate storing at high temperatures and humidity or near
harmful chemicals.
Product has been updated
3) Repair or replacement as provided under this warranty is the exclusive remedy to the customer.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly approved by
manufacturer could void your authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
