A SSEMBLY A ND U SER G UIDE
MODELS PRO 24RS / 24RSF / 24RST
26RS / 26RST
22031A
Limited Lifetime Warranty
SunQuest®warrants your tanning unit to be free of structural defects in its material and workmanship,
under normal use, for its lifetime. SunQuest will repair or replace, at their discretion, any defect to the
structure which affects the performance of the unit.
For 6 months from the date of purchase, SunQuest will provide replacements for parts that prove to
be defective in material or workmanship. Acrylic shields, fluorescent lamps, and lamp starters are
excluded from this warranty. Labor will be covered for 30 days from purchase date. Normal wear,
damage from misuse or abuse, damage incurred in transit, or damage done by unauthorized repairs
or modifications are not covered by this warranty.
ETS, Inc. disclaims any implied warranty of merchantability or fitness for any period beyond the
expressed warranty. Some states do not allow limitations on how long an implied warranty lasts, so
the above limitations may not apply to you.
No one has authority to change or modify this Limited Lifetime Warranty in any respect. To obtain
service under the Limited Lifetime Warranty, contact ETS, Inc. at 1-800-228-6292, and ask for the
Technical Service Department.
ETS, Inc. SHALL NOT BE LIABLE FOR LOSS OF USE, LOSS OF TIME , INCONVENIENCE, RENTAL OR
SUBSTITUTE PRODUCTS, LOSS OF BUSINESS, LOSS OF INCOME, OR ANY OTHER INCIDENTAL OR
CONSEQUENTIAL DAMAGES. Some states do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitation or exclusion may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights which
may vary from state to state.
All warranty service must be performed by an authorized service person. If your tanning unit must
be returned for service, all freight charges must be at your expense. Contact your place of purchase
for the address of the SunQuest Service Center nearest you. Proof of purchase is required to obtain
warranty service.
This warranty covers the original purchaser only. This warranty is void if the unit is modified
in any manner from its original design.
i
W
Congratulations on your purchase of this technologically advanced sun tanning unit.
It has been designed to provide years of dependable service for you.
Please read all the instructions in this booklet before installing and using the unit.
Always be sure to observe all safety precautions.
elcome
C
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
ontents
Unpacking and Inspection . . . . . . . . . . . . . . . . . . . . . . .1
Tools Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Pre-Installation Planning . . . . . . . . . . . . . . . . . . . . . . . . .3
Assembly Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Making Electrical Connections . . . . . . . . . . . . . . . . . . . . .9
Before You Tan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Exposure Times . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Using Your Sunbed . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Cleaning After Use . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Thorough Periodic Cleaning . . . . . . . . . . . . . . . . . . . . .12
Mechanical Inspection . . . . . . . . . . . . . . . . . . . . . . . . .12
Replacing Lamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Timer Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Obtaining Service . . . . . . . . . . . . . . . . . . . . . . . . . .back cover
ii
s
LABELING NOTICE: Labels are affixed on all systems to inform the user of possible dangers. Regulations are stated in
21 CFR, Section 1040.20, and require that all products manufactured after September 8, 1986 which use sunlamps
must display the following:
DANGER
mature aging of the skin and skin cancer. WEAR PROTECTIVE EYEWEAR; FAILURE TO MAY RESULT IN SEVERE BURNS
OR LONGTERM INJURY TO THE EYES.
Medications or cosmetics may increase your sensitivity to the ultraviolet radiation. Consult physician before using
sunlamp if you are using medications or have a history of skin problems or believe yourself especially sensitive to
sunlight. If you do not tan in the sun, you are unlikely to tan from the use of this product.
Minimum use distance from face tanner is 1 inch or 2.54 centimeters. Minimum use distance elsewhere is touching
the clear plastic panels. Do not use without clear plastic panels (or wire grid for models using wire grid) in place.
Tanning normally appears after the first few sessions and maximizes after approximately four weeks. Tan once or
twice per week thereafter to maintain appearance. Frequency of sessions should be limited to every other day.
Persons already having a base tan may begin at advanced levels corresponding to the extent of their base tan.
afety Information
Ultraviolet radiation. Follow instructions. Avoid overexposure.As with natural sunlight, overexposure can cause eye and skin injury and allergic reactions. Repeated exposure may cause pre-
RECOMMENDED EXPOSURE TIMES IN MINUTES MAXIMUM EXPOSURE TIME IS 20 MINUTES
Skin Type: Week # Week 1 Week 2 Week 3 Week 4 Subsequent
I Sensitive Skin (Burns easily and severely and does not tan.) NOT RECOMMENDED FOR TANNING
II Light (Burns easily and severely and tans minimally.) 4 8 12 16 20
III Normal (Burns moderately and tans average.) 6 10 15 20 20
IV Dark (Burns minimally, tans easily and above average.) 8 12 16 20 20
New lamps emit approximately 20% more UV during the first 50 hours of operation. Recommended tanning times
should therefore be reduced by approximately 20% during that period.
Session # 1st-3rd 4th-6th 7th-10th 11th-13th Maximum
W
ARNING: •Read the instructions booklet before using this sunlamp product.•To use, lie down under canopy
and pull down as far as adjustment will allow. All persons in the room should wear protective eyewear when lamps
are on.
•
Recommended eyewear: provided eyeshields (Lucas Products Super Sunnies or Intrexco No. 5635/1) or
equivalent eyewear as defined under 21 CFR 1040.20. Other types of eyewear may not provide adequate protection.
•
Disconnect power cord before attempting to clean, relamp, or engage in the maintenance of this product.
ONLY THE FOLLOWING LAMPS HAVE BEEN CERTIFIED FOR USE IN THE RS MODEL SERIES:
VelocityTMWolff®Model 71T12100W 24RS
Diamond Sun®S Wolff®Model 71T12100W 24RS and 26RS
ONLY THE FOLLOWING LAMPS HAVE BEEN CERTIFIED FOR USE IN THE RSF MODEL SERIES:
ONLY THE FOLLOWING LAMPS HAVE BEEN CERTIFIED FOR USE IN THE RST MODEL SERIES:
THIS EQUIPMENT MUST BE CONNECTED TO A GROUNDED OUTLET.
THIS PRODUCT IS IN CONFORMITY WITH PERFORMANCE STANDARDS FOR SUN LAMP PRODUCTS UNDER 21 CFR
PART 1040.20
TM
Velocity
Diamond Sun®S Wolff®Model 71T12100W & Model 59T12080W 24RSF
Philips Model HPA 400/30s or CosmoTech Model 23045 or CosmoTech 20046 (Facial Unit) 24 RSF
VelocityTMWolff®Model 71T12100W 24RST
Diamond Sun
Turbo SunTMS Wolff®Model F8-T5-10W 24RST and 26RST
Wolff®Model 71T12100W & Model 59T12080W 24RSF
®
S Wolff®Model 71T12100W 24RST and 26RST
iii
nstallation
I
Unpacking and Inspection
Your sunbed comes in two cardboard cartons, one for the bench and one for the
canopy or top deck. Open the cartons
and remove the bench and canopy as follows.
The bench and canopy are each wrapped
in plastic. Pull back the plastic and, with
a helper, grasp the bench and pull it from
the carton bottom, leaving the plastic
wrap and the carton packaging. Do the
same for the canopy. Do not try to lift
either unit with the plastic still on as it
may slip.
Note! The cartons are reusable, in the
unlikely event that you may find it necessary to return your sunbed.
The canopy box contains the canopy unit
and a pair of gas springs. The bench box
contains the following items:
• Bench Unit
• Box containing necessary assembly
hardware, safety goggles, and pillow
• Box containing two stand legs
• Assembly and User Guide
Inspect these items, including the canopy
and bench, and make sure they are free
from any visible damage. Report the
extent of any damage to the transportation company.
Record the serial numbers of the canopy
and bench in the area provided on the
back of this manual. This information will
be required whenever you call customer
service.
1
Installation-Tools Required
Tools Required
’
ll need the following tools to assemble your sunbed:
You
Utility Knife
Allen Wrench
(Supplied in Hardware Box)
2
Installation-Pre-Installation Planning
Pre-Installation Planning
Before you begin to assemble your sunbed, you should observe the following preinstallation considerations.
• Your sunbed operates from a 220V
AC source. You should have an electrical outlet (like the type shown
below) installed in the room in which
you will use the unit. The outlet
should be on a dedicated circuit. (We
recommend installation by a professional electrician.) The outlet must be
earth grounded.
IMPORTANT!
Use of a voltage source above 230V AC may
prevent proper operation of the sunbed and
could cause damage and void the warranty.
• Make sure the room in which you
intend to use your sunbed is well ventilated. Air from the room is used to
cool the sunbed, and a poorly ventilated room may cause the unit to
become hot and cause discomfort to
the user.
• Your sunbed is designed to operate in
an ambient room temperature of 80°F
maximum and 70% relative humidity.
• Place your sunbed no closer than 6"
from any wall. Make sure that curtains, drapes, and other room furniture do not obstruct the airflow into
the end caps or out of the fan opening areas.
20 AMP NEMA #6-20R RECEPTACLE
• Proper assembly of your sunbed
requires three people. Plan to have a
couple of helpers assist you.
3
Installation-Assembly Procedures
Assembly Procedures
Hardware Inventory
Before you begin, use the utility knife to
cut open the Hardware Box and remove
the small bag of hardware. In addition to
a small Allen wrench and pillow, make
sure you have the following hardware
items.
NOTE: The larger 5/16” metal washers
and six 5/16” Allen-head bolts may be
pre-installed in bottom of bench.
Allen-Head Bolt
5/16" x 1"
Quantity 8
5/16" Metal Washer
Quantity 6
5/16" Metal Washer
Quantity 2
Bushing
Quantity 2
Allen-Head Bolt
5/16" x 1 1/2"
Quantity 2
Nylon Washer
Quantity 2
Hinge Brackets
Quantity 2
(left and right)
Safety Goggles
Quantity 1
4
Attaching Legs to Bench
Lay the bench upside down on the floor.
Locate the two stand legs and attach to
the bench as shown below.
1. Using the 5/16" x 1" bolts and the six
larger sized 5/16" washers, attach the
stand legs with the skirt mounting holes
toward the back of the bed as shown.
Install center bolt first. You may have to
gently push sides of legs in to align holes.
Tighten with the Allen wrench.
Installation-Assembly Procedures
SKIRT MOUNTING HOLES
2. Turn bench right side up on floor. Place
so that power cord connector is facing
toward wall outlet.
(ELECTRICAL CONNECTOR INDICATES
BACK OF BENCH)
5
Installation-Assembly Procedures
Attaching Hinge Brackets to Bench
Locate the two hinge brackets and identify the left and right brackets.
1. Install the hinge brackets to the ends of
the bench such that the short boss
engages the stud above the bolt hole, and
the long boss engages the hole below the
bolt hole. Then secure using the 5/16" x
1" Allen-head bolt and 5/16" metal washer. Tighten bolt snug, then an additional
half turn.
2. Place the bushings into the hinge
brackets as shown below.
6
Attaching Canopy to Bench
1. Lift the canopy and hold it between
the hinge brackets. You may want to use
some of the cardboard packing, laid
across the bench, to support the canopy.
Installation-Assembly Procedures
2. Insert the 5/16" x 1 1/2" bolts with the
nylon washers into both hinge brackets.
Tighten bolts into the endcap threaded
inserts until snug, then an additional half
turn. Do not overtighten to avoid damaging threaded inserts.
7
Installation-Assembly Procedures
Attaching Gas Springs
1. The gas springs are shipped with lock-
ing clips installed. These clips must be
removed before gas springs can be
installed on the bed.
2. With a helper holding the canopy
open, align open ends of gas spring ball
joints with pivot studs and push into
place. Be sure spring cylinder is in up
position as shown. Reinstall locking clips.
Repeat on other side. DO NOT lower
canopy until both gas springs are
installed! F
ailure to install locking clips
may result in the gas springs working
loose, allowing the canopy to fall, which
may cause serious injury!
3. Lift and lower canopy a few times to
lubricate gas springs for optimum performance.
Your gas springs contain one of these two
types of ends. Remove locking clips as shown
before assembly.
8
Making Electrical Connections
Warning! Be sure AC power is discon-
nected before connecting cables.
1. Connect the canopy to bench power
cord to the bench receptacle. The
plug is polarized. Align the terminals
and firmly push on until seated then
tighten the threaded locking ring, as
shown.
Installation-Making Electrical Connections
2. Plug the three-prong 220V AC power
cord into a dedicated outlet (see
page 3).
THREADED
LOCKING RING
RECEPTACLE
ON BENCH
ELECTRICAL PANEL
CANOPY
POWER CORD
9
O
peration
Before You Tan
Before using your sunbed, please note
the following important precautions:
• Your skin should be free of cosmetics,
tanning oils, or other body lotions
prior to tanning except for those
specifically made for use with tanning
devices. However, do not remove
natural body oils by bathing or showering immediately before tanning.
• Your hair should be free of gels,
mousses, sprays, or other hair products prior to tanning. These products
can cause damage to the sunbed
acrylic. As an alternative, a shower
cap or towel can be worn to keep
treated hair away from the sunbed
surfaces.
• Some medication may increase your
sensitivity to ultraviolet light. It is recommended that you consult a physician before using this sunbed if taking
any medication or if you suspect that
your skin might be especially sensitive
to sunlight. Included with this manual
is an FDA booklet on medications that
increase sensitivity to light.
• As with all electrical appliances, do
not operate this device near water
or while you are wet.
Exposure Times
We recommend that you tan every other
day, following the tanning times in the
exposure schedule. Tanning normally
appears after the first few sessions and
maximizes after approximately four
weeks. Tan once or twice per week thereafter to maintain appearance. Persons
already having a base tan may begin at
advanced levels corresponding to the
extent of their base tan.
Follow the guidelines for skin type and
exposure times as shown in the table
below.
RECOMMENDED EXPOSURE TIMES IN MINUTES MAXIMUM EXPOSURE TIME IS 20 MINUTES
Skin Type: Week # Week 1 Week 2 Week 3 Week 4 Subsequent
I Sensitive Skin (Burns easily and severely and does not tan.) NOT RECOMMENDED FOR TANNING
II Light (Burns easily and severely and tans minimally.) 4 8 12 16 20
III Normal (Burns moderately and tans average.) 6 10 15 20 20
IV Dark (Burns minimally, tans easily and above average.) 8 12 16 20 20
10
Session # 1st-3rd 4th-6th 7th-10th 11th-13th Maximum
Using Your Sunbed
O
FF
20
15
10
5
0
C
O
O
L
D
O
W
N
Once you have read Before You Tan and
Exposure Times, you are ready to use your
sunbed. Proceed as follows.
WARNING! Your sunbed is designed for
individual use. Only one pair of protective goggles is provided. Always wear
these or another approved pair of goggles. Regular sunglasses do not provide
adequate protection from ultraviolet
light. You should never look at the lamps
when turned on without wearing the
appropriate protective goggles.
Operation-Using Your Sunbed
FACE TANNER ROCKER SWITCH
Step 1. For units equipped with a face
tanner, activate the face tanner
by placing the rocker switch
located next to the timer knob
into the
“
I” (ON) position. If you
do not wish to use the face tanner, leave the switch in the “O”
(OFF) position.
Note! The F model face tanner
lamps need a longer after-use
cooling period before they will
light up again.
Step 2. Set the timer to the desired
number of minutes (after first
determining the proper time
period from the table on page
10). The lamps will turn on as
soon as you move the rotary dial
from the “0” position.
Step 3. Lift the canopy, lie down on the
bench (face up), and lower the
canopy toward your body. For
best results, position the canopy
as close as possible to your body,
but do not bring the canopies
with face tanners any closer
than 1 inch from your body.
Step 4. When the timer reaches 0, the
lamps will automatically turn off.
The cooling fans run for 3 minutes after the lamps shut off to
aid in cooling the sunbed. This
cool down cycle is controlled by
the timer and is indicated on the
timer plate as
“
Cool Down”. You
will notice that the timer will
continue to count down to the
“Off” position. At this time, the
fans will shut off.
11
C
are & Maintenance
Cleaning After Use
Clean and disinfect your tanning bed’s
bench and canopy after each use. Use a
non-abrasive disinfectant cleaner that
does not contain ammonia or ammonia
derivatives. Ammonia may damage the
acrylic shield. Spray the acrylic lightly
with disinfectant and wipe dry with a
clean soft cloth. We recommend
SunQuest
acrylic cleaner.
®
disinfectant and SunQuest
Thorough Periodic Cleaning
Introduction
The cooling fans draw air through the bed
and over time will cause a dust buildup
on the lamps and reflectors. This will
reduce the tanning effectiveness of the
bed. When a dust buildup is observed, it
is necessary to thoroughly clean the
inside of the bench and canopy.
Warning! Disconnect sunbed from electrical power before cleaning.
Cleaning the Canopy and Bench
Step 1. Remove the acrylic shields and
lamps as described in
Lamps.
Step 2. With a soft cloth, wipe the entire
length of each lamp to remove
any film buildup.
Step 3. Clean both sides of the acrylic
shields with a non-ammonia dis-
®
Step 4. Wipe the reflectors with a clean
Step 5. Re-install the lamps and acrylic
Mechanical Inspection
Your tanning bed has been built for years
of service. To ensure trouble-free operation throughout its life, inspect the unit’s
mechanical integrity every 400-500 hours
of use.
• Inspect the unit’s fasteners verifying
• Inspect gas springs for signs of wear.
• Inspect the timer as indicated in this
• Inspect the AC power cord and its
• Inspect the acrylic. Broken, cracked
infectant cleaner.
damp cloth.
shields.
that all are firmly in place. Pay particular attention to the hinge bolts.
Gas springs that will not hold the
canopy in the full open position
when raised should be immediately
replaced.
manual under Timer Maintenance.
connections.
or badly scratched acrylics should be
immediately replaced.
Replacing
12
Care & Maintenance-Replacing Lamps
Replacing Lamps
Introduction
To be assured of maximum tanning effectiveness, change lamps after approximately 800-1000 hours of use. Tanning
will continue after this time but at a slower rate. To ensure trouble-free operation
of your sunbed, replace the lamp starters
whenever the lamps are replaced.
Warning! Disconnect sunbed from electrical power before servicing.
Removing/Replacing Acrylic Shields
The acrylic shields in the canopy and
bench are both secured in place by colored profile strips which run the length of
the canopy and bench, both front and
back. To remove the strips, gently pry up
on the outside edge of the strip near the
middle of the bed with a flat, blunt object
(such as a putty knife) until the retainer
releases its latching action (See figure
below). Continue prying up the strip
throughout its full length until removed.
Repeat for the other strips. The long
edges of the acrylic shield are now
exposed.
Canopy Shield
Standing in front of the sunbed, grasp the
long exposed edge of the acrylic and
carefully begin sliding it toward you, until
it is removed from the sunbed. You may
need to pull the shield edge down slightly to clear the edge of the bed.
Bench Shield
Slide the acrylic shield toward the head
or foot end of the bed. The short edge of
the acrylic shield at the opposite end
should now be visible. Remove the shield
by lifting from this end.
After changing lamps, replace the acrylic
shield by reversing the above steps. On
bench shields, take special care to
ensure that the acrylic is centered from
head to foot before installing the
retaining strips. Replace each retainer
by first installing its ends into place under
the endcaps, then working toward the
center, pushing it into place.
Putty Knife
Profile Strip
Acrylic Shield
13
Care & Maintenance-Replacing Lamps
Removing/Replacing Lamps
After removing the acrylic shield, replace
lamps as follows:
Step 1. Grasp the lamp at one end and
at the middle, then turn the
lamp a quarter turn. The lamp
may then be gently removed
from its holder.
Step 2. To re-install a lamp, insert the
pins located on the ends of the
lamp into the slots on top of the
lamp holder and turn the lamp a
quarter turn.
Only the following lamp types have been certified for use in SunQuest Solariums
Application
Pro 24RS
Pro 24RSF
Canopy and Bench
Recommended Replacement Lamps
Do not use lamps other than those specified below. The use of uncertified lamps
is a violation of Federal regulations and
will void your warranty. These lamps have
an average life span of 800-1000 hours of
effective tanning use. Lamps used longer
than that begin to lose their effectiveness
even though they will continue to light.
Lamp Model Number
Diamond Sun®S Wolff®Model 71T12100W
Diamond Sun®S Wolff®Model 59T12080W (24RSF only)
VelocityTMWolff®Model 71T12100W
VelocityTMWolff®Model 59T12080W (24RSF only)
Pro 24RST
Pro 26RST
Pro 26RS
14
Facial Unit
Only the following lamp types have been certified for use in SunQuest Solariums
Application
Canopy and Bench
Turbo Face Tanner
Only the following lamp types have been certified for use in SunQuest Solariums
Application
Canopy and Bench
Philips Model HPA 400/30s
CosmoTech Model 23045
CosmoTech Model 20046
Lamp Model Number
Diamond Sun®S Wolff®Model 71T12100W
VelocityTMWolff®Model 71T12100W (24RST only)
Turbo SunTMS Wolff®Model F8-T5-10W
Lamp Model Number
Diamond Sun®S Wolff®Model 71T12100W
Care & Maintenance-Replacing Lamps
Removing/Replacing Face Tanner Lamp
on F Models
After removing the canopy acrylic shield,
replace the face tanner lamp as follows:
Step 1. Support the face tanner assem-
bly with your hand while
unscrewing the two retaining
screws. The face tanner glass
casing will now swing downward.
Step 2. The lamp can now be
exchanged. The lamp holders
are equipped with spring contacts which enables the lamp to
be removed easily. Remove the
old lamp and discard. Install the
new lamp, using a clean cloth or
paper towel. Ensure that the
lamp is firmly seated in the lamp
holders.
Note! Never take hold of the lamp such
that your fingers are in contact with the
lamp glass. Finger oils will greatly reduce
the lamp’s operational life.
Step 3. Gently close the face tanner
glass casing and lock it closed
with the screws. Ensure that the
screws firmly secure the glass
casing.
Warning! Never turn the equipment on
while the face tanner is disassembled or
when the glass filters have been moved.
The direct light can cause severe injury to
the eyes and to other areas of the body.
Immediately discontinue use of this
equipment if the face tanner glass is broken or if any unfiltered light can be seen
escaping the face tanner assembly.
RETAINING
SCREWS
15
Care & Maintenance-Timer Maintenance
Timer Maintenance
Your SunQuest®sunbed is equipped with
a backup shut-off timer which will automatically turn off the sunbed in the
unlikely event of a malfunction of the primary timer. This important safety feature
also prevents the user from resetting the
timer before the end of the pre-set maximum time interval. The electronic timer
limiting circuit is automatically reset each
time the primary timer is turned to the
OFF position.
Annually, or whenever your sunbed is relamped, check the operation and accuracy of the timer system as follows. DO
NOT perform these tests with a person in
the sunbed.
Step 1. Obtain an accurate watch capa-
ble of measuring in seconds. Set
the timer to its maximum interval. Using the watch, time how
long the lamps remain on. The
lamps should shut off within plus
or minus 10% of the maximum
timer interval.
Step 2. Set the timer to the maximum
time interval. Wait ten minutes,
then turn the knob back to the
maximum time position. The
electronic time limiting circuit
should turn the lamps off at an
elapsed time equal to approximately 10% beyond the maximum timer interval, even
though the primary timer continues to show time left.
16
Call ETS Customer Service if your timer
does not operate properly, or if you
experience difficulty with these tests.
T
roubleshooting
SolutionProblem
Lamps fail to light
One or more lamps fail
to light
Canopy fails to stay in the
up or down position
1. Check source of AC power. Reset circuit breaker or
replace fuse if necessary.
2. Make sure the unit is plugged into outlet.
3. Make sure cord between canopy and bench is
properly connected.
4. Make sure timer dial is turned to a number past 0.
1. Check that lamp is installed correctly.
2. Switch unlit lamp with a lamp that lights. If the
new lamp lights and the old lamp still does not,
replace old lamp.
3. If replacing lamp does not remedy problem, contact your service representative.
Gas springs should hold the canopy fully open as
well as allow it to rest fully closed. If the canopy is
left open for an extended period of time it may
creep down. This is considered normal. Keep the
canopy closed when not in use. Replace gas springs
when they no longer have sufficient power to hold
the canopy open when raised.
Sunbed does not stay lit
1. Check source of AC power. Reset circuit breaker or
replace fuse if necessary.
2. Check timer system per maintenance instructions in
this guide. Contact your local service representative.
17
Notes
18
CALL FOR SERVICE OR
QUESTIONS:
1•800•228•6292
6270 Corporate Drive
Indianapolis, IN 46278-2900
Have the following information ready
when calling ETS to order parts or service
for your bed:
Date Purchased
Canopy Serial Number
Bench Serial Number
Loading...
