PLEASE READ THIS MANUAL CAREFULLY BEFORE USING
2.6 cu. ft. Erase-Board Refrigerator
RF-261B (Black)
RF-261P (Pink)
Thank you for your purchase. To ensure that you get the best results from your new refrigerator,
please take the time to read through the simple instructions in this booklet.
Please be sure that packaging materials are disposed in accordance with the current
environmental requirements.
PREPARING TO INSALL
READ THESE INSTRUCTIONS COMPLETELY AND CAREFULLY
Ventilation
There is need of good ventilation around the refrigerator for dissipation of
heat, high efficiency of refrigeration and low power consumption. For this
purpose, following clearance is needed for proper air circulation:
Back: 4” (100mm) from the wall
Sides: 8” (200mm)
Top: 12” (300mm)
• A clear space should be left to open the door to 160º
Protection from Moisture
Avoid placing unit where heavy moisture is present, this is to minimize
possibility of metal parts rusting. Never spray water onto the unit.
Never spray water directly onto the unit – which may damage the insulation.
Protection from Heat
Keep unit away from any heat source and direct sunlight.
Location
Unit should be placed on a flat and solid ground, which can support the
refrigerator when fully loaded. Adjust the leveling legs so the unit is firmly
positioned on the floor. Do not place unit near anything that may echo.
Keep Away from Danger
Do not place refrigerator near any combustibles such as gas, petrol,
alcohol, lacquer and etc. The above mentioned should not be stored in the
refrigerator.
Moving
Secure all loose items (such as shelves and ice tray). Unit should never be
set horizontally, upside down or declined more than 45º.
1
SAFETY INSTRUCTIONS
WARNING!
Use this appliance only for its intended purpose as described.
Power Supply
This unit is applied with power supply of single phase alternating
current of 115V~, 60Hz. If fluctuation of voltage is so large that
the voltage exceeds the above scope, it is suggested to apply
A.C. Automatic voltage regulator to the refrigerator. This
appliance is equipped with a 3-prong (grounding) plug which
mates with a standard 3-prong wall outlet. DO NOT, UNDER
ANY CIRCUMSTANCES, CUT OR REMOVE THE THIRD
(GROUND) PRONG FROM THE POWER CORD. If you have
only a 2-prong wall outlet, it is your responsibility to have it
replaced with a properly grounded 3-prong wall outlet.
Power Cord
Be sure the cord is not folded into coil during operation. Keep
cord away from the compressor (located at the back of the unit),
due to its high surface temperature when operating. We strongly
suggest against the use of an extension cord. However, if one
must be used, the extension cord must be UL-listed, with
grounding type plug and electrical rating matching that of the
unit. Contact the manufacturer immediately should the cord be
frayed or damaged.
Safety Precautions
When using electrical appliances, basic safety precautions should be followed, including the
following:
• Refrigerator should be installed and positioned according to the Installation instructions.
• Children should be supervised. Do not allow young children to climb or play with the refrigerator.
• Never store gasoline, explosive substances or other flammables in this appliance.
• Clearance between the doors and cabinets are quite small, keep fingers out of these areas. Be
extra cautious when children are in the area.
• Turn the temperature control knob to the OFF (0) position and unplug before cleaning or
maintenance.
• Turn the temperature control knob to the OFF (0) position and unplug before replacing light bulb.
• To prevent risk of child entrapment, remove doors before disposing the refrigerator.
• Under federal law, refrigerants must be removed prior to product disposal. Check with the company
handling the disposal for further instructions.
• Do not place heavy or corrosive objects in the unit.
• Do not store bottled drinks in the freezer compartment, to prevent breakage and damaging the unit.
• Do not touch food and containers in the freezer compartment with wet hands.
• The appliance is not intended for use by young children or infirm persons without supervision.
• This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision/instruction concerning the use of the appliance by a person responsible for their safety.
• Do not use electrical appliances inside the food storage compartments.
• If a gas leak is suspected, do not plug or unplug the unit – may cause sparks and fire calamities.
2
