Sun Oracle Sun X2-8 Installation Manual

Sun Server X2-8 (formerly Sun Fire X4800 M2) Installation Guide

Part No: E20816–06 August 2013

This software and related documentation are provided under a license agreement containing restrictions on use and disclosure and are protected by intellectual property laws. Except as expressly permitted in your license agreement or allowed by law, you may not use, copy, reproduce, translate, broadcast, modify, license, transmit, distribute, exhibit, perform, publish, or display any part, in any form, or by any means. Reverse engineering, disassembly, or decompilation of this software, unless required by law for interoperability, is prohibited.

The information contained herein is subject to change without notice and is not warranted to be error-free. If you nd any errors, please report them to us in writing.

If this is software or related documentation that is delivered to the U.S. Government or anyone licensing it on behalf of the U.S. Government, the following notice is applicable:

U.S. GOVERNMENT END USERS. Oracle programs, including any operating system, integrated software, any programs installed on the hardware, and/or documentation, delivered to U.S. Government end users are "commercial computer software" pursuant to the applicable Federal Acquisition Regulation and agency-specic supplemental regulations. As such, use, duplication, disclosure, modication, and adaptation of the programs, including any operating system, integrated software, any programs installed on the hardware, and/or documentation, shall be subject to license terms and license restrictions applicable to the programs. No other rights are granted to the U.S. Government.

This software or hardware is developed for general use in a variety of information management applications. It is not developed or intended for use in any inherently dangerous applications, including applications that may create a risk of personal injury. If you use this software or hardware in dangerous applications, then you shall be responsible to take all appropriate fail-safe, backup, redundancy, and other measures to ensure its safe use. Oracle Corporation and its aliates disclaim any liability for any damages caused by use of this software or hardware in dangerous applications.

Oracle and Java are registered trademarks of Oracle and/or its aliates. Other names may be trademarks of their respective owners.

Intel and Intel Xeon are trademarks or registered trademarks of Intel Corporation. All SPARC trademarks are used under license and are trademarks or registered trademarks of SPARC International, Inc. AMD, Opteron, the AMD logo, and the AMD Opteron logo are trademarks or registered trademarks of Advanced Micro Devices. UNIX is a registered trademark of The Open Group.

This software or hardware and documentation may provide access to or information on content, products, and services from third parties. Oracle Corporation and its aliates are not responsible for and expressly disclaim all warranties of any kind with respect to third-party content, products, and services. Oracle Corporation and its aliates will not be responsible for any loss, costs, or damages incurred due to your access to or use of third-party content, products, or services.

Ce logiciel et la documentation qui l’accompagnesont protégés par les lois sur la propriété intellectuelle. Ils sont concédés sous licence et soumis à des restrictions d’utilisation et de divulgation. Sauf disposition de votre contrat de licence ou de la loi, vous ne pouvez pas copier, reproduire, traduire, diuser, modier, breveter, transmettre, distribuer, exposer, exécuter, publier ou acher le logiciel, même partiellement, sous quelque forme et par quelque procédé que ce soit. Par ailleurs, il est interdit de procéder à toute ingénierie inverse du logiciel, de le désassembler ou de le décompiler, excepté à des ns d’interopérabilité avec des logiciels tiers ou tel que prescrit par la loi.

Les informations fournies dans ce document sont susceptibles de modication sans préavis. Par ailleurs, Oracle Corporation ne garantit pas qu’elles soient exemptes d’erreurs et vous invite, le cas échéant, à lui en faire part par écrit.

Si ce logiciel, ou la documentation qui l’accompagne,est concédé sous licence au Gouvernement des Etats-Unis, ou à toute entité qui délivre la licence de ce logiciel ou l’utilise pour le compte du Gouvernement des Etats-Unis, la notice suivante s’applique:

Ce logiciel ou matériel a été développé pour un usage général dans le cadre d’applications de gestion des informations. Ce logiciel ou matériel n’est pas conçu ni n’est destiné à être utilisé dans des applications à risque, notamment dans des applications pouvant causer des dommages corporels. Si vous utilisez ce logiciel ou matériel dans le cadre d’applications dangereuses, il est de votre responsabilité de prendre toutes les mesures de secours, de sauvegarde, de redondance et autres mesures nécessaires à son utilisation dans des conditions optimales de sécurité. Oracle Corporation et ses aliés déclinent toute responsabilité quant aux dommages causés par l’utilisation de ce logiciel ou matériel pour ce type d’applications.

Oracle et Java sont des marques déposées d’OracleCorporation et/ou de ses aliés. Tout autre nom mentionné peut correspondre à des marques appartenant à d’autrespropriétaires qu’Oracle.

Intel et Intel Xeon sont des marques ou des marques déposées d’Intel Corporation. Toutes les marques SPARC sont utilisées sous licence et sont des marques ou des marques déposées de SPARC International, Inc. AMD, Opteron, le logo AMD et le logo AMD Opteron sont des marques ou des marques déposées d’Advanced Micro Devices. UNIX est une marque déposée d’The Open Group.

Ce logiciel ou matériel et la documentation qui l’accompagne peuvent fournir des informations ou des liens donnant accès à des contenus, des produits et des services émanant de tiers. Oracle Corporation et ses aliés déclinent toute responsabilité ou garantie expresse quant aux contenus, produits ou services émanant de tiers. En aucun cas, Oracle Corporation et ses aliés ne sauraient être tenus pour responsables des pertes subies, des coûts occasionnés ou des dommages causés par l’accès à des contenus, produits ou services tiers, ou à leur utilisation.

130826@25097

Contents

Using This Documentation ...................................................................................................................7

Sun Server X2-8 Name Change .....................................................................................................7

Product Downloads ........................................................................................................................7

Documentation and Feedback ......................................................................................................8

About This Documentation ...........................................................................................................9

Change History ...............................................................................................................................9

Installation Overview .......................................................................................................................... 11

Front and Back Features and Components ...................................................................................... 13

Front Features and Components ............................................................................................... 13

Back Features and Components ................................................................................................. 14

Unpacking the Server and Identifying the Rack Mounting Hardware ......................................... 17

How to Identify Your Rack Mounting Kit ................................................................................. 17

How to Unpack the Server .......................................................................................................... 19

Installing the Server In the Rack Using the Standard Rack Mounting Kit .................................... 23

Tools and Sta Required ............................................................................................................. 24

Installing Optional Equipment .................................................................................................. 24

Compatible Racks ........................................................................................................................ 25

Contents of the Standard Rack Mounting Kit .......................................................................... 25

Location of the Rack Mounting Kit and the Shipping Bracket Kit ......................................... 27

Installing the Server In a Rack Using the Standard Rack Mounting Kit ................................ 28

Removing and Installing the Standard Rack Mounting Kit Shipping Brackets ................... 41

Installing the Server in the Rack Using the Universal Rack Mounting Kit ................................... 47

Tools and Sta Required ............................................................................................................. 48

Installing Optional Equipment .................................................................................................. 48

Compatible Racks ........................................................................................................................ 49

Contents of the Universal Rack Mounting Kit ......................................................................... 49

Installing the Server in a Rack Using the Universal Rack Mounting Kit ............................... 51

Installing and Removing the Universal Shipping Brackets ..................................................... 81

Contents

Removing the Server from the Rack .................................................................................................. 91

How to Remove the Server from the Rack ................................................................................ 91

How to Remove the Rackmounting Hardware from the Rack ............................................... 94

Cabling and Power .............................................................................................................................. 97

Attaching Administration (SP) Cables ...................................................................................... 97

Cabling NEMs and PCIe EMs .................................................................................................. 101

Powering the Server On and O ............................................................................................... 103

Getting Service for Your Server ....................................................................................................... 107

How to Find the Server’s Serial Number .................................................................................. 107

Determining Your Server Management Strategy .......................................................................... 109

Oracle Integrated Lights Out Manager ................................................................................... 110

Oracle Hardware Management Pack ....................................................................................... 110

Oracle Hardware Installation Assistant .................................................................................. 111

Conguring the Preinstalled Solaris Operating System ............................................................... 113

Conguring the Preinstalled Oracle Solaris OS ..................................................................... 114

Installation Worksheet .............................................................................................................. 114

How to Connect to the Server Using the Server’s IP Address ............................................... 117

(Optional) How to Redirect the Console Output to the Video Port .................................... 118

How to Connect to the Server Using a Serial Capture Program ........................................... 119

Oracle Solaris OS Information Products and Training ......................................................... 120

Conguring the Preinstalled Oracle Linux Operating System .................................................... 121

Oracle Linux Conguration Worksheet ................................................................................. 121

Congure the Preinstalled Oracle Linux OS .......................................................................... 122

Conguring the Preinstalled Oracle VM Software ........................................................................ 127

How to Congure Oracle VM .................................................................................................. 127

Conguration Worksheets ....................................................................................................... 130

Getting Started With Oracle VM ............................................................................................. 132

Communicating With Oracle ILOM and the System Console .................................................... 135

Server Connections .................................................................................................................... 135

About Oracle ILOM SP IP Addresses and the Oracle ILOM Interfaces .............................. 135

Determining the SP IP Address ................................................................................................ 136

Connecting to Oracle ILOM ..................................................................................................... 137

Connecting to the System Console .......................................................................................... 140

I/O and Interrupt Resource Allocation ........................................................................................... 147

Option ROM and I/O Space Allocation .................................................................................. 147

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 20134

Contents

Allocating MSI Interrupt Space (Oracle Solaris OS Only) .................................................... 152

How to Identify and Fix Interrupt Resource Shortages ......................................................... 153

Sun Server X2-8 Specications ........................................................................................................ 159

Physical Specications for the Sun Server X2-8 ..................................................................... 159

Power Specications for the Sun Server X2-8 ......................................................................... 159

Environmental Specications .................................................................................................. 160

Acoustic Specications .............................................................................................................. 160

Requesting Physical Media ............................................................................................................... 161

How to Request Physical Media Online .................................................................................. 161

How To Request Physical Media by Phone ............................................................................. 162

Index ................................................................................................................................................... 165

UsingThis Documentation

This section provides product information, documentation and feedback links, and a document change history.

■

“Sun Server X2-8 Name Change” on page 7

■

“Product Downloads” on page 7

■

“Documentation and Feedback” on page 8

■

“About This Documentation” on page 9

■

“Change History” on page 9

Sun Server X2-8 Name Change

The Sun Server X2-8 was formerly named the Sun Fire X4800 M2 server. This former name might still appear in the software. The name change does not indicate any change in system features or functionality.

The new name identies the following:

■

X identies an x86 product.

■

The rst number, 2, identies the generation of the server.

■

The second number, 8, identies the number of processors.

Product Downloads

You can nd downloads for all Oracle x86 servers and server modules (blades) on My Oracle Support (MOS). On MOS you can nd two type of downloads:

■

Software release bundles specic to the rackmount server, server module, modular system (blade chassis), or NEM. These software release bundles include Oracle ILOM, Oracle Hardware Installation Assistant and other platform software and rmware.

■

Standalone software common across multiple types of hardware. This includes the Hardware Management Pack.

Documentation and Feedback

▼

Get Software and Firmware Downloads

Go to http://support.oracle.com.

The Patches and Updates screen appears.

At the top of the page, click the Patches and Updates tab.

Search elds appear.

In the PatchSearch box, click Product or Family(AdvancedSearch).

Alternatively, type a full or partial product name (for example Sun Server X2–8) until a match appears.

In the Release pull-down list, select the release from the drop-down list.

Expand the folders to see component oerings.

Click Search.

A list of updates (patches) appears.

To selecta patch, click the check boxesnext to the patch name (you can select more than one

patch).

A popup action panel appears. The panel lists several action options.

To download the update, click Download in the popup panel.

The download appears automatically.

Documentation and Feedback

Documentation Link

All Oracle products http://www.oracle.com/documentation

Sun Server X2-8 http://www.oracle.com/

Oracle ILOM 3.0 http://www.oracle.com/goto/ILOM/docs

Provide feedback on this documentation at: http://www.oracle.com/goto/docfeedback.

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 20138

pls/topic/lookup?ctx=sfx4800m2

About This Documentation

This documentation set is available in both PDF and HTML. The information is presented in topic-based format (similar to online help) and therefore does not include chapters, appendices, or section numbering.

You can get a PDF that includes all information about a particular topic subject (such as hardware installation or product notes) by clicking the PDF button on the top of the page.

Change History

The following lists the release history of this documentation set:

■

July 2011 – Initial publication.

■

October 2011 – Revised for SW1.1.

■

April 2012 – Revised to add preinstalled Oracle VM, and additional rack mounting instructions.

■

June 2012 – Revided for SW1.1.1. Revised to add the preinstalled Oracle Solaris 11 operating system.

■

July 2012 – Revised to change the product name to Sun Server X2–8 and to add 32 GB DIMM support.

■

September 2012 – Added rmware versions to Product Notes.

■

December 2012 – Revised for SW1.1.2. Added support for dual-ranked and quad-ranked 16 GB DIMMs.

■

December 2012 – Removed erroneous listing of Windows Server 2008 pre-R2 as a supported OS. For Microsoft Windows, only Windows Server 2008 R2 SP1 is supported.

■

January 2013 – Minor edit to Service Manual and Product Notes for memory DIMM population rules.

■

January 2013 – Minor editorial corrections to Product Notes and Service Manual.

■

March 2013 – Support for Windows Server 2012 added to Product Notes. Installation Guide revised to add the preinstalled Oracle Linux operating system.

■

July 2013 – Revised for SW1.2. Updated information in Product Notes on operating system support, nding Windows Server 2008 drivers, and new CRs. Updated Service Manual to add procedure animation links and make minor editorial changes.

■

August 2013 – Revised Installation Guide and Oracle ILOM Supplement to add information about changing the default Oracle ILOM password.

Change History

Installation Overview

The following table lists the tasks that you must do to install your Oracle Sun Server X2-8.

Note – The Sun Server X2-8 was formerly named the Sun Fire X4800 M2 server. This former

name might still appear in the product. The name change does not indicate any change in system features or functionality.

Task Description Link

1. Unpack the box. “How to Unpack the Server” on page 19

Identify your rackmount kit Do you have the standard or

universal?

2. Familiarize yourself with the server features.

3. Install the server in a rack. “Installing the Server in the Rack Using the

4. Connect power cords, cables, and peripherals.

5. Power on the server. “How to Apply Standby Power for Initial

6. Check system specications.

7. Manage the server. “Determining Your Server Management

8. Congure or install an operating system.

Congure the optional preinstalled Oracle Solaris OS.

“How to Identify Your Rack Mounting Kit” on page 17

“Front and Back Features and Components” on page 13

Universal Rack Mounting Kit” on page 47

“Attaching Administration (SP) Cables” on page 97

Service Processor Conguration” on page 103

“Sun Server X2-8 Specications” on page 159

Strategy” on page 109

“Communicating With Oracle ILOM and the System Console” on page 135

“Conguring the Preinstalled Solaris Operating System” on page 113

Installation Overview

Task Description Link

Congure the optional preinstalled Oracle VM operating system.

For installation of Oracle Solaris OS when it is not preinstalled.

For assisted installation of Linux.

For unassisted installation of Linux.

For assisted installation of Windows.

For unassisted installation of Windows.

For installation of Oracle VM when it is not preinstalled.

“Conguring the Preinstalled Oracle VM Software” on page 127

Sun Server X2-8 (formerly Sun Fire X4800 M2) Installation Guide for Oracle Solaris Operating System

Oracle Hardware Installation Assistant 2.5 User's Guide for x86 Servers in the

Oracle

Hardware Installation Assistant library

Sun Server X2-8 (formerly Sun Fire X4800 M2) Installation Guide for Linux Operating Systems

Oracle Hardware Installation Assistant 2.5 User's Guide for x86 Servers in the

Oracle

Hardware Installation Assistant library

Sun Server X2-8 (formerly Sun Fire X4800 M2) Installation Guide for Windows Operating Systems

Sun Server X2-8 (formerly Sun Fire X4800 M2) Server Installation Guide for Virtual Machine Software

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201312

Front and Back Features and Components

■

“Front Features and Components” on page 13

■

“Back Features and Components” on page 14

Front Features and Components

345

5-2M

PS3

5-2M

PS2

PS1

PS0

5-2M

HDD4 HDD5 HDD6 HDD7

5-2M

HDD3HDD2HDD1HDD0

BL3

BL2

BL1

BL0

Back Features and Components

Note – To nd the chassis serial number, see “How to Find the Server’s Serial Number” on

page 107

Figure Legend

1 Locate button/LED (white) 5 Over temperature LED (amber)

2 Service Action Required LED

(amber)

3 Power/OK LED (green) 7 Hard drives (HDD0 through HDD7)

4 Power button (recessed) 8 CPU modules (BL0 through BL3)

6 Power supplies (PS0 through PS3)

For back panel features and components, see “Back Features and Components” on page 14.

Back Features and Components

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201314

FM2 FM3 NEM0

NEM1

Back Features and Components

EM3.1

EM3.0

EM2.1

EM2.0

EM1.1

EM1.0

EM0.1

EM0.0

FM0 FM1

Figure Legend

1 Fan modules (FM0 through

FM3).

4 Service processor module (SP).

The SP provides I/O connectors for system management. See

AC0 AC1 AC2 AC3

“Attaching Administration (SP) Cables” on page 97 for details.

2 Network express modules

5 AC power connectors.

(NEMs).

3 PCIe Express modules. 6 Chassis ground.

For front panel features and components, see “Front Features and Components” on page 13.

Unpacking the Server and Identifying the Rack Mounting Hardware

This section provides procedures for unpacking the server and identifying the rack mounting hardware.

■

To identify the rack mounting hardware and the correct rack mounting instructions, see

“How to Identify Your Rack Mounting Kit” on page 17.

■

To unpack your server, see “How to Unpack the Server” on page 19.

▼

How to IdentifyYour Rack Mounting Kit

Your server might include one of two types of rack mounting hardware. These are:

Name Contents See this section

Standard

Universal

Unpack the server as described in “How to Unpack the Server” on page 19.

■

Rack mounting hardware (371–4742)

■

Shipping bracket kit (371–4376–24)

■

Rack mounting hardware (350–1662)

■

Shipping bracket kit (341–6410)

“Installing the Server In the Rack Using the Standard Rack Mounting Kit” on page 23

“Installing the Server in the Rack Using the Universal Rack Mounting Kit” on page 47

The rack mounting hardware is in the accessory kit.

Look for a part number on the containers that hold the rack mounting hardware.

■

371–4742 identies a standard rack mounting kit.

■

350–1662 identies a universal rack mounting kit.

■

If you cannot nd a number, open the container and compare the adapter brackets with the following gure.

Unpacking the Server and Identifying the Rack Mounting Hardware

Legend Description See

1 Adapter bracket for round-hole racks in

universal rack mounting kit

2 Adapter bracket for square-hole racks

universal rack mounting kit

3 Front adapter bracket for standard rack

mounting kit

4 Rear adapter bracket for standard rack

mounting kit

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201318

“How to Install the Universal Rack Mounting Hardware in a Round-Hole Rack” on page 67

“How to Install the Universal Rack Mounting Hardware in a Square-Hole Rack ” on page 57

“Installing the Server In the Rack Using the Standard Rack Mounting Kit” on page 23

Unpacking the Server and Identifying the Rack Mounting Hardware

Legend Description See

See Also

1 Adapterbracket for round-hole racks in universal rack

mounting kit

2 Adapterbracket for square-hole racks universal rack

mounting kit

3 Front adapter bracket for standard rack mounting kit

4 Rear adapter bracket for standard rack mounting kit

“Installing the Server in the Rack Using the Universal Rack Mounting Kit” on page 47

“Installing the Server In the Rack Using the Standard Rack Mounting Kit” on page 23

“Installing the Server in the Rack Using the Universal Rack Mounting Kit” on page 47

“Installing the Server In the Rack Using the Standard Rack Mounting Kit” on page 23

▼

How to Unpack the Server

The following gure shows the packaging components.

Open the top of the box (1).

a. Cut the straps.

b. Cut or remove the tape.

c. Open the aps.

Lift the box (1) away from the server.

Remove the accessorytray (2) and set it and its contents aside.

Remove the foam inserts (4).

When it is time to install the server (5) in the rack, either:

■

Remove the server (5) from the pallet (6).

■

Use a mechanical lift to raise the pallet with the server on it to its location in the rack, then, slide the server o the pallet directly into the rack.

Unpacking the Server and Identifying the Rack Mounting Hardware

For rack mounting instructions, see one of the rack mounting sections as indicated in “How to

Identify Your Rack Mounting Kit” on page 17

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201320

Unpacking the Server and Identifying the Rack Mounting Hardware

Legend Description

1Box

2 Accessory tray, which contains rack mounting kit, shipping brackets, and other

items

3 Rack mounting kit

4 Packaging foam inserts

5 Server

6 Pallet

“How to Identify Your Rack Mounting Kit” on page 17See Also

Installing the Server In the Rack Using the Standard Rack Mounting Kit

This topic describes how to install your server in a rack using the standard rack mounting hardware.

If you are not certain whether you have the standard rack mounting kit or the universal rack mounting kit, see corresponding section.

Note the following:

■

If your server is shipped already installed in a rack, skip to “How to Remove the Standard

Rack Mounting Kit Shipping Brackets ” on page 41

■

If you are going to ship the server in a rack, you must install the shipping brackets as described in

page 43

This section contains the following topics:

■

“Tools and Sta Required” on page 24

■

“Installing Optional Equipment” on page 24

■

“Compatible Racks” on page 25

■

“Contents of the Standard Rack Mounting Kit” on page 25

■

“Location of the Rack Mounting Kit and the Shipping Bracket Kit” on page 27

■

“Installing the Server In a Rack Using the Standard Rack Mounting Kit” on page 28

■

“Removing and Installing the Standard Rack Mounting Kit Shipping Brackets” on page 41

“How to Identify Your Rack Mounting Kit” on page 17, then proceed to the

“How to Install the Standard Rack Mounting Kit Shipping Brackets” on

ToolsandSta Required

Tools and Sta Required

Caution – The server weighs about 180 pounds (100 kg) when fully loaded with components. To

reduce the risk of serious personal injury or equipment damage, use a mechanical lift to install the server into the rack. If a lift is not available, remove components as described in

Remove Components to Reduce Weight” on page 28

80 pounds (45 kg).

Always load equipment into a rack from the bottom up so that it does not become top-heavy and tip over. Deploy your rack’s anti-tilt bar to prevent the rack from tipping during equipment installation.

Before installing the server into a rack, gather the tools, equipment, and sta required.

Tools,Equipment, and Stang Required Notes

Two trained sta Two people are needed to install the server and operate the lift.

No. 2 10-inch Phillips screwdriver (magnetic tip recommended)

Mechanical lift Strongly recommended. If not available, reduce the weight of the

server. See

page 28

“How to

. This reduces the weight of the server to

“How to Remove Components to Reduce Weight” on

Compatible rack See

Rack mounting kit See

Mounting Kit” on page 28

Shipping brackets See

Shipping Brackets” on page 41

■

Installing Optional Equipment

For information about how to install options such as DIMMs, PCIe EMs, and NEMs, power supplies, and CPU modules, refer to the Sun Server X2-8 (formerly Sun Fire X4800 M2) Service

Manual

For information about issues and known workarounds, refer to the

Sun Fire X4800 M2) Product Notes

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201324

“Compatible Racks” on page 25.

“Installing the Server In a Rack Using the Standard Rack

“Removing and Installing the Standard Rack Mounting Kit

. You must remove the shipping brackets if your server was shipped in a rack.

You must install the shipping brackets if you plan to ship your server in a rack.

Sun Server X2-8 (formerly

Compatible Racks

The rack mounting hardware is compatible with a wide range of equipment racks that meet the following standards:

■

Four-post rack (mounting at both front and rear).

Note – Two-post racks are not compatible.

■

Rack must have 5RU space available.

■

Rack should have a horizontal opening and unit vertical pitch conforming to ANSI/EIA 310-D-1992 or IEC 60927 standards.

■

Distance between front and rear mounting planes between approximately 26 and 34.5 inches (660.4 mm and 876.3 mm).

■

Minimum clearance depth (to front cabinet door) in front of front rack mounting plane: 1 inch (25.4 mm).

■

Minimum clearance depth (to rear cabinet door) behind front rack mounting plane: 27.5 inches (700 mm).

■

Minimum clearance width (between structural supports and cable troughs) between front and rear mounting planes: 18 inches (456 mm).

Contents of the Standard Rack Mounting Kit

The standard rack mounting kit comes with the following hardware:

Contents of the Standard Rack Mounting Kit

Figure Legend

1, 2 Left (1) and right (2) shelf rails Once the front and rear adapter brackets are installed on the

rack, the shelf rails drop into place. The hooks on the front and rear rails hook into the slots on the adapter brackets.

The shelf rails expand to match the depth of the rack.

These are not slide rails. Once the server is mounted in the chassis, it does not move.

3, 4 Front mounting adapter brackets (2

pair)

These attach to the rack and support the shelf rails.

There are two types of front adapter brackets; one for round-hole racks (3), and another for square-hole racks (4). Use the one that matches your rack.

5 and 7 An assortment of M6 and 10-32

screws

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201326

Oracle provides extra screws to support dierent congurations. Unused hardware can be discarded or recycled when you have completed the installation.

Location of the Rack Mounting Kit and the Shipping Bracket Kit

Figure Legend

6 Rear adapter brackets (1 pair) These attach to the rack and support the shelf rails.

8 M6 cage nuts Used to adapt the rear adapter bracket to the back of

square-hole racks.

Location of the Rack Mounting Kit and the Shipping Bracket Kit

The accessory kit that contains the rack mounting kit also contains the shipping bracket kit.

The following gure shows the location of the contents in the box:

Legend Description

1 Foam packaging material

2 Rack mounting hardware

Installing the Server Ina Rack Using the Standard Rack Mounting Kit

Legend Description

3 Shipping brackets

Installing the Server In a Rack Using the Standard Rack Mounting Kit

This section provides instructions for installing your server in a rack. Itincludes:

■

“How to Remove Components to Reduce Weight” on page 28

■

“How to Install the Standard Rack Mounting Hardware in a Rack” on page 33

■

“How to Insert the Server Into the Rack” on page 37

The rack mounting kit does not include slide rails. Once the server is installed, it does not slide in or out of the rack.

The rack mounting kit shares a box with the shipping bracket kit.

■

See “Removing and Installing the Standard Rack Mounting Kit Shipping Brackets” on

page 41

■

See “Contents of the Standard Rack Mounting Kit” on page 25 for a description of the contents of the rack mounting kit.

for information about the shipping brackets.

BeforeYou Begin

▼

How to Remove Components to Reduce Weight

This procedure describes how to remove components from your server so that two persons can lift it into the rack. If you are going to use a mechanical lift, you do not need to perform this procedure.

Caution – Circuit boards and hard drives contain electronic components that are extremely

sensitive to static electricity. Ordinary amounts of static electricity from clothing or the work environment can destroy the components located on these devices. Do not touch the components without antistatic precautions, especially along the connector edges. For more information, refer to

Fire X4800 M2) Service Manual

Note – This procedure assumes that the server is powered o and all cables are disconnected.

Mark all CPU modules with their slot numbers.

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201328

“Antistatic Precautions and Procedures” in Sun Server X2-8 (formerly Sun

Installing the Server Ina Rack Using the Standard Rack Mounting Kit

Caution – To prevent system failure, you must return CPU modules to their original locations.

Mark CPU module slot locations carefully before removing them from the chassis.

Remove the CPU modules from the front of the chassis.

The chassis contains four CPU module slots; each must have a CPU module or a ller panel.

Note – Because of their light weight, there is no need to remove ller panels.

For each CPU module:

a. Pinch the green tabs to release the ejectors(1).

b. Pull both ejectors out to release the module (2).

Caution – When the module is partway out of the chassis, close the ejectors, and grasp the

module. Do not handle the module by the ejectors.

Installing the Server Ina Rack Using the Standard Rack Mounting Kit

c. Gently slide the module forward until it is clear of the chassis (3).

Caution – The CPU module is heavy. Use two hands.

d. Close the ejectors on the CPU module.

e. Place the CPU module on an antistatic mat.

Remove the four power supplies from the front of the chassis.

a. Pinch the handle to release the lever (1).

b. Pull the lever (2) to release the power supply.

c. Slide the power supply out of the chassis (3).

Remove the PCIe express modules from the back of the chassis.

The upper bays can be used as a hand hold when moving the chassis.

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201330

Installing the Server Ina Rack Using the Standard Rack Mounting Kit

Caution – Do not insert forks from a lift device into these open bays, as this causes severe and

non-repairable damage.

a. Mark all PCIe EM cardswith their slot locations.

Caution – To prevent system failure, you must return PCIeEM cards to their original

locations. Mark PCIe EM slot locations carefully before removing them from the chassis.

b. Rotate the lever (1) to release the module.

c. Slide the module out of the chassis (2).

Remove the upper left fan module (FM2) if necessary.

Squeeze the clamp (1) to release the fan module (2), then pull it from the chassis (3).

You can use the recess as a hand-hold when moving the chassis.

Caution – Do not insert forks from a lift device into this open bay, as this causes severe and

non-repairable damage.

Installing the Server Ina Rack Using the Standard Rack Mounting Kit

See Also

“How to Replace the Components in the Server” on page 32

▼

How to Replace the Components in the Server

The procedure “How to Remove Components to Reduce Weight” on page 28 describes how to remove components from the server. After the server is installed in the rack, you must replace the components.

Reverse the steps in

●

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201332

“How to RemoveComponents to Reduce Weight” on page 28.

Installing the Server Ina Rack Using the Standard Rack Mounting Kit

Caution – All CPU modules and PCIe EM modules must be returned to their original locations.

Failure to do so can result in system failure.

▼

How to Install the Standard Rack Mounting Hardwarein a Rack

The rack mounting hardware consists of front and rear adapter brackets with cage nuts, screws, and shelf rails.

Caution – The server weighs about 180 pounds (100 kg) when fully loaded with components. To

reduce the risk of serious personal injury or equipment damage, use a mechanical lift to install the server into the rack. If a lift is not available, remove components as described in

Remove Components to Reduce Weight” on page 28

. This reduces the weight of the server to 80

pounds (45 kg).

Verify that you havea 5RU space in your rack.

“How to

Select the two front adapter brackets that match your rack.

See the following gure.

The server ships with two sets of front adapter brackets: one (1) for racks with square holes and one (2) for racks with round holes. Select the adapter brackets that match your rack.

Attach the frontadapter brackets tothe rack.

Make sure you orient the adapter brackets correctly, with the arrow pointing up.

Select the screws that match your rack.

■

Use one M6 per side for a square-hole rack.

■

Use three M6 or three 10-32 per side for a threaded round-hole rack.

Installing the Server Ina Rack Using the Standard Rack Mounting Kit

The following gure shows the front adapter brackets being attached to a square-hole rack (1) and a round-hole rack (2).

If your rack has round holes, use two screws each (1) to fasten the two rear adapter brackets (2)

to the rack.

If your rack has square holes, skip this step.

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201334

Installing the Server Ina Rack Using the Standard Rack Mounting Kit

The top of the rear bracket should sit 1 RU (three holes) lower than the top of the front bracket.

If your rackhas square holes:

a. Insert the cage nuts (1) for the rear adapter bracketsin the holes on the rack.

The top of the rear bracket should sit 1 RU (three holes) lower than the top of the front bracket.

b. If you are going to install shipping brackets, insert the cage nuts for the shipping brackets (2)

in the holes in the rear of the rack.

Note the orientation of the cage nuts for the shipping bracket.

■

They face outside the rack, in the opposite direction of the cage nuts for the adapter brackets.

■

They are located in the rst and third holes above the cage nuts for the adapter brackets.

Note – If you are going to install shipping brackets so you can ship your system in a rack, and

your system has a square-hole rack, you must install the rear cage nuts for the shipping bracket on the rack now, before installing the rear adapter bracket. You cannot add the cage nuts for the rear shipping bracket when the rear adapter brackets are in place. See

“Removing and Installing the Standard Rack Mounting Kit Shipping Brackets” on page 41

for instructions to install the shipping brackets.

Installing the Server Ina Rack Using the Standard Rack Mounting Kit

c. Use two screws (3) to fasten each rear adapter bracket (4) to the rack.

Place the shelf rails into the rack.

The following gure shows a square-hole rack.

The shelf rails expand (1) to t the rack, then slip into the slots on the adapter brackets (2), and drop into place (3).

Be certain to place the shelf rails in the proper orientation, with the shelf facing inward and the gap towards the front of the rack.

Caution – Drop Hazard! Be certain that the rails are rmly seated in the brackets before

proceeding.

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201336

Installing the Server Ina Rack Using the Standard Rack Mounting Kit

Next Steps

“How to Insert the Server Into the Rack” on page 37

▼

How to Insert the ServerInto the Rack

The following procedure explains how to insert the server into the rack and on to the shelf rail assemblies on the rack.

Installing the Server Ina Rack Using the Standard Rack Mounting Kit

BeforeYou Begin

Perform the steps in “How to Install the Standard Rack Mounting Hardware in a Rack” on

page 33

Lift the server to its position on the rack.

The use of a lift is recommended.

Caution – The server weighs 180 pounds (82 kg). To reduce the risk of serious personal injury or

equipment damage, use a mechanical lift to install the server into the rack. If a lift is not available, remove components as instructed in

Weight” on page 28

Slide the server onto the shelf rails.

Caution – Drop Hazard! Do not release the server until it is 12 inches (304 mm) into the rack, and

and use two persons to lift the server into place.

“How to Remove Components to Reduce

is rmly supported by the shelf rails. The shelf rails can not support the server until it is 12 inches (304 mm) inside the rack.

Note – If the server is still on a pallet, you can leave it on the pallet and lift both the server and the

pallet with the mechanical lift, and slide the server o the pallet and onto the shelf rails.

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201338

Installing the Server Ina Rack Using the Standard Rack Mounting Kit

12” (304mm)

Installing the Server Ina Rack Using the Standard Rack Mounting Kit

Use four screws to attach the front of the server to the front of the rack.

Use either the M6 x 25, or the 10-32 x 1 screws.

■

On a threaded rack, use four M6 x 25, or four 10-32 x 1 screws.

■

On a square-hole rack, use four M6 x 25 screws.

See Also

If you removedcomponents from the server,replace them afterit is mounted in the rack. See

“How to RemoveComponents to Reduce Weight” on page 28.

■

“How to Remove the Server from the Rack” on page 91

■

“Cabling and Power” on page 97

■

“How to Remove Components to Reduce Weight” on page 28

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201340

Removing and Installing the Standard RackMounting Kit Shipping Brackets

Removing and Installing the Standard Rack Mounting Kit Shipping Brackets

If the server is shipped in a rack, it must be supported by shipping brackets.

■

If the server is shipped to you in a rack, you must remove the shipping brackets before placing it in service. See

Brackets ” on page 41

■

If you plan to ship the server in a rack, see “How to Install the Standard Rack Mounting Kit

Shipping Brackets” on page 43

The shipping bracket parts are in the accessory tray with the rack mounting hardware. See

“Location of the Rack Mounting Kit and the Shipping Bracket Kit” on page 27 for details.

▼

How to Remove the Standard Rack Mounting Kit Shipping Brackets

This procedure describes how to remove brackets from a system equipped with the standard rack mounting kit.

The standard shipping bracket kit consists of a front bracket, a rear bottom bracket, a rear top bracket, screws to connect them to the rack, and cage nuts to be used with the rear brackets on racks with square holes. These appear in

Shipping Brackets” on page 43

“How to Remove the Standard Rack Mounting Kit Shipping

“How to Install the Standard Rack Mounting Kit

Removing and Installing the Standard RackMounting Kit Shipping Brackets

Remove the four screws (1) that fasten the front shipping bracket (2) to the front of the server

and remove it.

The front shipping bracket contains eight threaded holes used for storing unused screws (four

M6 and four 10–32). Remove the screws that match the threads on your rack and use them to secure the server to the rack.

There might be two sets of screws stored on the front of the shipping bracket. Use the set that matches the threading on your rack.

Thread the long screws that youremoved in Step 1 into the four empty holes on the shipping

bracket.

They will be stored there in case you need to reinstall the shipping bracket.

Remove the four screws (1) that fasten the rear top shipping bracket (2) over the back of the

server and remove it.

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201342

Removing and Installing the Standard RackMounting Kit Shipping Brackets

Remove the four screws (3) that fasten the rear bottom shipping bracket (4) under the back of

the server and remove it.

▼

How to Install the Standard Rack Mounting Kit Shipping Brackets

This procedure describes how to install brackets into a system equipped with the standard rack mounting kit.

The shipping bracket kit contains the following parts:

Removing and Installing the Standard RackMounting Kit Shipping Brackets

Figure Legend

1 Front shipping bracket

2, 3 Two sets of screws (M6 and 10-32). Each set contains four screws for the front shipping

bracket (2) and eight screws for the rear shipping brackets (5 and 6)

4 Eight M6 cage nuts for rear shipping bracket in square-hole racks

5 Top rear shipping bracket

6 Bottom rear shipping bracket

Note – The shipping bracket kit is shipped in the accessory tray with the rack mounting kit. See

“Location of the Rack Mounting Kit and the Shipping Bracket Kit” on page 27 for details.

Remove the four (short) screws that fasten the front of the server to the rack.

Insert the front shipping bracket (1) into the front of the serverwith the supporting ange

underneath the server.

The front shipping bracket contains eight threaded holes used for storing unused screws (four

M6 and four 10–32). Remove the long screws that match the threads on yourrack.

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201344

Removing and Installing the Standard RackMounting Kit Shipping Brackets

Use the four long screws (M6 or 10–32) (1) to fasten the shipping bracket (2) to the front of the

server.

Insert the short screwsinto the four empty storage holes on the shipping bracket.

They will be stored there to be used when you remove the shipping bracket.

If you areinstalling the shipping brackets in a rack with square holes, check to ensure that the

cage nuts are installed in the rear.

Note the orientation and location of the cage nuts for the shipping bracket.

■

There are four cage nuts per side (eight total).

■

They are installed on the inside of the rack, facing outward. This is the opposite direction from the cage nuts for the shelf adapter brackets.

■

For each shipping bracket, there should be two shipping bracket cage nuts; one in the hole directly above the shipping bracket cage nut, and one in the third hole above the shipping bracket cage nut.

If the cage nuts are not in place, you must:

a. Remove the serverand the mounting hardware from the rack, as described in

the Serverfrom the Rack”on page 91

“Removing

Removing and Installing the Standard RackMounting Kit Shipping Brackets

b. Reinstall the adapter bracketsand the server,and install the rear shipping bracket cage nuts

as you install the rear adapter brackets. This is included in the rack mounting procedure.

“How to Install the Standard Rack Mounting Hardware in a Rack” on page 33.

See

Insert the rear top shipping bracket (1) over the back of the server with the side panels facing down.

Use four screws (2) to fasten it to the rack (4).

Insert the rear bottom shipping bracket (3) under the back of the server with the side panels

facing up.

Use four screws (4) to fasten it to the rack.

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201346

Installing the Server in the Rack Using the Universal Rack Mounting Kit

This section describes how to install your server in a rack using the universal rack mounting hardware.

If you are not certain whether you have the standard rack mounting kit or the universal rack mounting kit, see corresponding section.

Note the following:

■

If your server is shipped already installed in a rack, skip to “How to Remove the Universal

Shipping Brackets” on page 85

■

If you are going to ship the server in a rack, you must install the shipping brackets as described in

This section contains the following topics:

■

“Tools and Sta Required” on page 48

■

“Installing Optional Equipment” on page 48

■

“Compatible Racks ” on page 49

■

“How to Unpack the Server” on page 19

■

“Contents of the Universal Rack Mounting Kit” on page 49

■

“Installing the Server in a Rack Using the Universal Rack Mounting Kit” on page 51

■

“Installing and Removing the Universal Shipping Brackets” on page 81

“How to Identify Your Rack Mounting Kit” on page 17, then proceed to the

“How to Install the Universal Shipping Brackets” on page 81.

ToolsandSta Required

Tools and Sta Required

Caution – The server weighs about 180 pounds (100 kg) when fully loaded with components. To

reduce the risk of serious personal injury or equipment damage, use a mechanical lift to install the server into the rack. If a lift is not available, remove components as described in

Remove Components to Reduce Weight” on page 51

80 pounds (45 kg).

Before installing the server into a rack, gather the tools, equipment, and sta required.

Tools,Equipment, and Stang Required Notes

Two trained sta Two people are needed to install the server and operate the lift.

No. 2 10-inch Phillips screwdriver (magnetic tip recommended)

Mechanical lift Strongly recommended. If not available, reduce the weight of the

server. See

page 51

“How to

. This reduces the weight of the server to

“How to Remove Components to Reduce Weight” on

Compatible rack See

Rack mounting kit See

Mounting Kit” on page 51

Shipping brackets See

page 81

■

Installing Optional Equipment

For information about how to install options such as DIMMs, PCIe EMs, and NEMs, power supplies, and CPU modules, refer to the Sun Server X2-8 (formerly Sun Fire X4800 M2) Service

Manual

For information about issues and known workarounds, refer to the

Sun Fire X4800 M2) Product Notes

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201348

“Compatible Racks ” on page 49.

“Installing the Server in a Rack Using the Universal Rack

“Installing and Removing the Universal Shipping Brackets” on

. You must remove the shipping brackets if your server was shipped in a rack.

You must install the shipping brackets if you plan to ship your server in a rack.

Sun Server X2-8 (formerly

Compatible Racks

The rack mounting hardware is compatible with a wide range of equipment racks that meet the following standards:

■

Four-post rack (mounting at both front and rear).

Note – Two-post racks are not compatible.

■

Rack must have 5RU space available.

■

Rack should have a horizontal opening and unit vertical pitch conforming to ANSI/EIA 310-D-1992 or IEC 60927 standards.

■

Distance between front and rear mounting planes between approximately 26 and 34.5 inches (660.4 mm and 876.3 mm).

■

Minimum clearance depth (to front cabinet door) in front of front rack mounting plane: 1 inch (25.4 mm).

■

Minimum clearance depth (to rear cabinet door) behind front rack mounting plane: 27.5 inches (700 mm).

■

Minimum clearance width (between structural supports and cable troughs) between front and rear mounting planes: 18 inches (456 mm).

Contents of the Universal Rack Mounting Kit

The universal rack mounting kit comes with the following hardware:

Contents of the Universal Rack Mounting Kit

Figure Legend

1 Top rear braces These attach to the posts at the upper back of the server.

2, 3 Left (2) and right (3) shelf rails Once the front and rear adapter brackets are installed on the

rack, the shelf rails drop into place. The hooks on the rails hook into the slots on the front and rear brackets.

The shelf rails expand to match the depth of the rack.

These are not slide rails. Once the server is mounted in the chassis, it does not move.

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201350

Figure Legend

Installing the Server in a Rack Using the Universal Rack Mounting Kit

4 An assortment of M6 and 10-32

screws

The screws are packaged by size and type. They include:

■

12–M6X35

■

12–M6X12

■

4 – M6 X 4 athead

■

4 – 10-32 X 10

■

12 – 10-32 shoulder screws

5 Adapter brackets (2 sets of four each) These attach to the rack and support the shelf rails.

6 M6 cage nuts Used to attach the top rear braces to square-hole racks.

Oracle provides extra screws to support dierent congurations. Unused hardware can be discarded or recycled when you have completed the installation.

There are two sets of adapter brackets: one for round-hole racks, and another for square-hole racks. Use the set that matches your rack.

Installing the Server in a Rack Using the Universal Rack Mounting Kit

This section provides instructions for installing your server in a rack. Itincludes:

■

“How to Remove Components to Reduce Weight” on page 51

■

“How to Replace the Components in the Server” on page 56

■

“How to Install the Universal Rack Mounting Hardware in a Square-Hole Rack ” on page 57

■

“How to Install the Universal Rack Mounting Hardware in a Round-Hole Rack” on page 67

■

“How to Insert the Server Into the Rack” on page 77

Note – The rack mounting kit does not include slide rails. Once the server is installed, it does not

slide into or out of the rack.

▼

How to Remove Components to Reduce Weight

This procedure describes how to remove components from your server so that two persons can lift it into the rack. If you are going to use a mechanical lift, you do not need to perform this procedure.

Installing the Server in a Rack Using the Universal Rack Mounting Kit

BeforeYou Begin

Caution – Circuit boards and hard drives contain electronic components that are extremely

“Antistatic Precautions and Procedures” in Sun Server X2-8 (formerly Sun

Fire X4800 M2) Service Manual

Note – This procedure assumes that the server is powered o and all cables are disconnected.

Mark all CPU modules with their slot numbers.

Caution – To prevent system failure, you must return CPU modules to their original locations.

Mark CPU module slot locations carefully before removing them from the chassis.

Remove the CPU modules from the front of the chassis.

The chassis contains four CPU module slots; each must have a CPU module or a ller panel.

Note – Because of their light weight, there is no need to remove ller panels.

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201352

Installing the Server in a Rack Using the Universal Rack Mounting Kit

For each CPU module:

a. Pinch the green tabs to release the ejectors(1).

b. Pull both ejectors out to release the module (2).

Caution – When the module is partway out of the chassis, close the ejectors, and grasp the

module. Do not handle the module by the ejectors.

c. Gently slide the module forward until it is clear of the chassis (3).

Caution – The CPU module is heavy. Use two hands.

d. Close the ejectors on the CPU module.

e. Place the CPU module on an antistatic mat.

Installing the Server in a Rack Using the Universal Rack Mounting Kit

Remove the four power supplies from the front of the chassis.

a. Pinch the handle to release the lever (1).

b. Pull the lever to release the powersupply (2).

c. Slide the power supply out of the chassis (3).

Remove the PCIe express modules from the back of the chassis.

The upper bays can be used as a hand-hold when you are moving the chassis.

Caution – Do not insert forks from a lift device into these open bays, as this causes severe and

non-repairable damage.

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201354

Installing the Server in a Rack Using the Universal Rack Mounting Kit

a. Mark all PCIe EM cardswith their slot locations.

Caution – To prevent system failure, you must return PCIeEM cards to their original

locations. Mark PCIe EM slot locations carefully before removing them from the chassis.

b. Rotate the lever to release the module (1).

c. Slide the module out of the chassis (2).

Remove the upper left fan module (FM2) if necessary.

Squeeze the clamp (1) to release the fan module (2), and then pull it from the chassis (3).

You can use the recess as a hand-hold when moving the chassis.

Caution – Do not insert forks from a lift device into this open bay, as this causes severe and

non-repairable damage.

Installing the Server in a Rack Using the Universal Rack Mounting Kit

See Also

“How to Install the Universal Rack Mounting Hardware in a Square-Hole Rack ” on page 57

“How to Install the Universal Rack Mounting Hardware in a Round-Hole Rack” on page 67

“How to Replace the Components in the Server” on page 56

▼

How to Replace the Components in the Server

The procedure “How to Remove Components to Reduce Weight” on page 51 describes how to remove components from the server. After the server is installed in the rack, you must replace the components.

Reverse the steps in

●

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201356

“How to RemoveComponents to Reduce Weight” on page 51.

Installing the Server in a Rack Using the Universal Rack Mounting Kit

Caution – All CPU modules (CMODs) and PCIe EM modules must be returned to their original

locations. Failure to do so can result in system failure.

Note – When you reseat the CMODs, simultaneously push both handles past the locks, until they

touch the chassis. This extra motion ensures that the pawl seats the CMOD connectors correctly.

▼

How to Install the Universal Rack Mounting Hardwarein a Square-Hole Rack

The rack mounting kit consists of adapter brackets, rear braces, shelf rails, cage nuts, and screws.

Caution – The server weighs about 180 pounds (100 kg) when fully loaded with components. To

reduce the risk of serious personal injury or equipment damage, use a mechanical lift to install the server into the rack. If a lift is not available, remove components as described in

Remove Components to Reduce Weight” on page 51

. This reduces the weight of the server to 80

pounds (45 kg).

“How to

Note – To install rack mounting hardware in round-hole racks, see “How to Install the Universal

Rack Mounting Hardware in a Round-Hole Rack” on page 67

This task requires the following screws and connectors:

Function Description

Attach adapter brackets to front rack posts Four M6 x 12

Attach adapter brackets to rear rack posts Four M6 x 12

Attach braces to rear rack posts Four M6 x 12

and four M6 cage nuts

Locking screws for rails Four M4 x 10 athead

Gather the necessary screws and connectors.1

Installing the Server in a Rack Using the Universal Rack Mounting Kit

Verify that you havea 5RU space in your rack.

Select the set of adapter brackets for square-hole racks.

The server ships with two sets of adapter brackets: one for racks with square holes (1) and one for racks with round holes (2). The brackets for square-hole racks (1) have threads. See the following gure.

Note – Arrows on the brackets (3) indicate how the bracket should be oriented. Be sure to install

all brackets with the “Top” arrow (3) pointing up.

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201358

Installing the Server in a Rack Using the Universal Rack Mounting Kit

Attach the bracketsto the front posts.

Place the brackets so that the bottom of the bracket is aligned with the bottom of the (5RU) space where the server will go, and that the arrow labeled “Top” points up.

Note – The accessory tray includes a printed template that you can use to help align the adapter

brackets.

Use one M6 x 12 screw per side. Pass the screw from the outside of the rack, through the holes in the post, and into the threads on the adapter brackets.

The other two holes (per side) are used later, to attach the bezel of the server to the rack.

Attach the bracketsto the rear posts.

Place the brackets so that the bottom of the bracket is aligned with the bottom of the (5RU) space where the server will go, and that the arrow labeled “Top” points up.

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201360

Installing the Server in a Rack Using the Universal Rack Mounting Kit

Use three M6 X 12 screws per side (1) to fasten the bracket (2) to the posts (3).

Attach upper rearbraces (1) to the rack posts (2) directly above the adapter brackets, as shown in the following gure.

Install two M6 cage nuts (4) per side, and then use two M6 x 12 screws (3).

Installing the Server in a Rack Using the Universal Rack Mounting Kit

Before tightening the screws, slide the braces (1) up as far as they will go. The holes on the braces are oval shaped so they can move a little up and down when the screws are loose.

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201362

Installing the Server in a Rack Using the Universal Rack Mounting Kit

Remove the six screws (1) that hold the left and right shelf extenders (2) on the shelf rails (3),

and then removethe shelf extenders.

You must remove the shelf extenders before installing the server in the rack. They are used for other products.

Installing the Server in a Rack Using the Universal Rack Mounting Kit

Place the shelf rails into the rack.

The shelf rails expand (1) to t the rack, then slip into the slots on the adapter brackets (2), and drop into place (3).

Be certain to place the shelf rails in the proper orientation. They are labeled “FRONT LEFT” and “FRONT RIGHT.”

Caution – Drop Hazard! Be certain that the rails are rmly seated in the brackets before

proceeding.

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201364

Installing the Server in a Rack Using the Universal Rack Mounting Kit

Thread the fourM4 X 10 athead lockingscrews (1) into the adapter brackets.

These prevent the shelf rails from accidentally lifting out of the adapter brackets.

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201366

Installing the Server in a Rack Using the Universal Rack Mounting Kit

Next Steps

“How to Insert the Server Into the Rack” on page 77

▼

How to Install the Universal Rack Mounting Hardwarein a Round-Hole Rack

The rack mounting kit consists of adapter brackets, rear braces, shelf rails, cage nuts, and screws.

Caution – The server weighs about 180 pounds (100 kg) when fully loaded with components. To

reduce the risk of serious personal injury or equipment damage, use a mechanical lift to install the server into the rack. If a lift is not available, remove components as described in

Remove Components to Reduce Weight” on page 51

. This reduces the weight of the server to 80

pounds (45 kg).

Note – To install rack mounting hardware in square-hole racks, see “How to Install the Universal

Rack Mounting Hardware in a Square-Hole Rack ” on page 57

“How to

This task uses the following screws and connectors:

Function Description for M6 Racks Description for 10-32 Racks

Attach adapter brackets to front rack posts Four M6 x 12 Four 10-32 x 10

Attach adapter brackets to rear rack posts FourM6 x 12 Four 10-32 x 10 shoulder screws

Attach braces to rear rack posts Four M6 x 12 Four 10-32 x 10 shoulder screws

Locking screws for rails Four M4 x 10 athead Four M4 x 10 athead

Gather the necessary screws and connectors.

Verify that you havea 5RU space in your rack.

Select the set of adapter brackets for round-hole racks.

The server ships with two sets of adapter brackets: one for racks with square holes (1), and one for racks with round holes (2). The adapter brackets for square-hole racks (1) have threads. The adapter brackets for round-hole (tapped) racks (2) do not. See the following gure.

Installing the Server in a Rack Using the Universal Rack Mounting Kit

Note – Arrows on the adapter brackets (3) indicate how they should be oriented. Be sure to

install all brackets with the “Top” arrow (3) pointing up.

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201368

Installing the Server in a Rack Using the Universal Rack Mounting Kit

Attach the adapter brackets to the front posts.

Place the adapter brackets so that the bottom of the adapter bracket is aligned with the bottom of the (5RU) space where the server will go, and that the arrow labeled “Top” points up.

Use three M6 x 12 or 10-32 x 10 shoulder screws for each side. Pass the screws from the inside of the rack, through the adapter bracket, and into the threads on the post.

Note – The accessory box includes a printed template that you can use to help align the adapter

brackets.

Attach the adapter brackets to the rear posts.

Place the adapter brackets so that the bottom of the adapter bracket is aligned with the bottom of the (5RU) space where the server will go, and that the arrow labeled “Top” points up.

Pass two screws (1) from the inside of the rack, through the top and bottom holes in the adapter bracket (2), and thread them into the post (3).

Note – Do not use the center screw in the adapter bracket. It is reserved for the optional shipping

bracket kit described in

■

For M6 racks, use two M6 x 12 screws per side.

■

For 10-32 racks, use two 10-32 shoulder screws per side.

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201370

“Installing and Removing the Universal Shipping Brackets” on page 81.

Installing the Server in a Rack Using the Universal Rack Mounting Kit

Attach upper rearbraces (1) to the rack posts (2) directly above the adapter brackets, as shown

in the following gure.

Use either two M6 x 12 or two 10-32 x 10 screws (3) per side.

Installing the Server in a Rack Using the Universal Rack Mounting Kit

Before tightening the screws, slide the braces (1) up as far as they will go. The holes on the braces are oval shaped so they can move a little up and down when the screws are loose.

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201372

Installing the Server in a Rack Using the Universal Rack Mounting Kit

Remove the six screws (1) that hold the left and right shelf extenders (2) on the shelf rails (3),

and then removethe shelf extenders.

You must remove the shelf extenders before installing the server in the rack. They are used for other products.

Installing the Server in a Rack Using the Universal Rack Mounting Kit

Place the shelf rails into the rack.

The shelf rails expand (1) to t the rack, then slip into the slots on the adapter brackets (2), and drop into place (3).

Be certain to place the shelf rails in the proper orientation. They are labeled “FRONT LEFT” and “FRONT RIGHT.”

Caution – Drop Hazard! Be certain that the rails are rmly seated in the brackets before

proceeding.

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201374

Installing the Server in a Rack Using the Universal Rack Mounting Kit

Thread the fourM4 X 10 athead lockingscrews (1) into the adapter brackets.

These prevent the shelf rails from accidentally lifting out of the adapter brackets.

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201376

Installing the Server in a Rack Using the Universal Rack Mounting Kit

Next Steps

BeforeYou Begin

“How to Insert the Server Into the Rack” on page 77

▼

How to Insert the ServerInto the Rack

Perform the steps in “How to Install the Universal Rack Mounting Hardware in a Square-Hole

Rack ” on page 57 Round-Hole Rack” on page 67

Lift the server to its position in the rack.

or in “How to Install the Universal Rack Mounting Hardware in a

The use of a mechanical lift is recommended.

Caution – The server weighs 180 pounds (82 kg). To reduce the risk of serious personal injury or

equipment damage, use a mechanical lift to install the server into the rack. If a lift is not available, remove components as instructed in

Weight” on page 51

Slide the server onto the shelf rails.

Caution – Drop Hazard! Do not release the server until it is 12 inches (304 mm) into the rack, and

, and use two persons to lift the server into place.

“How to Remove Components to Reduce

is rmly supported by the shelf rails. The shelf rails can not support the server until it is 12 inches (304 mm) inside the rack.

Note – If the server is still on a pallet, you can leave it on the pallet and lift both the server and the

pallet with the mechanical lift, and slide the server o the pallet and onto the shelf rails.

Installing the Server in a Rack Using the Universal Rack Mounting Kit

12” (304mm)

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201378

Installing the Server in a Rack Using the Universal Rack Mounting Kit

Use four screws to attach the front bezel of the serverto the front of the rack, as shown in the

following gure.

■

For square-hole racks, use four M6 x 16 screws.

■

For round-hole racks, use four M6 x 12, or four 10-32 x 10 screws.

Note – On square-hole racks, the screws pass through the rack and thread into the adapter

bracket. On round-hole racks, the screws thread into the rack rails.

Move the rear braces so they are snug against the server chassis. See the following gure.

From the rear of the system:

a. Loosen the screws(1).

b. Slide the braces down(2).

c. Tighten the screws(1).

Installing the Server in a Rack Using the Universal Rack Mounting Kit

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201380

Installing and Removing the Universal Shipping Brackets

If you removedcomponents from the server,replace them afterthe server is mounted in the

rack. See

“How to Replace the Components in the Server”on page 56.

See Also

■

“How to Remove the Server from the Rack” on page 91

■

“Cabling and Power” on page 97

■

“How to Remove Components to Reduce Weight” on page 51

Installing and Removing the Universal Shipping Brackets

If the server is shipped in a rack, it must be supported by shipping brackets.

■

If the server is shipped to you in a rack, you must remove the front brackets before placing it in service. Removing the rear brackets is optional. See

Shipping Brackets” on page 85

■

If you plan to ship the server in a rack, see “How to Install the Universal Shipping Brackets”

on page 81

If you have ordered a server with shipping brackets, they are shipped in the accessory tray.

▼

How to Install the Universal Shipping Brackets

This procedure describes how to install brackets into a system equipped with the universal rack mounting kit.

The following picture shows the shipping bracket kit.

“How to Remove the Universal

Installing and Removing the Universal Shipping Brackets

Figure Legend

1 Front shipping bracket.

2 Screws and cage nuts. The kit contains two sets of screws (M6 and 10-32), plus cage

nuts. The cage nuts are not used for the Sun Server X2-8.

3 Bottom rear shipping bracket.

Remove the two(short) screws that fasten the bottom of the bezel to the rack.

Insert the front bracket (2) into the front of the server with the supporting ange underneath

the server.

See the following gure.

Use the two long screws (M6 x 25 or 10-32 x 1) (1) to fasten the shipping bracket(2) to the front

of the server.

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201382

Installing and Removing the Universal Shipping Brackets

Note – The front shipping bracket includes eight threaded holes (3) used for storing unused

screws. When the shipping brackets are not installed, the bracket holds the long screws used to install them. When the shipping brackets are installed, it stores the short screws that were used before the shipping brackets were installed.

Insert the short screwsinto the empty storage holes on the shipping bracket.

They will be stored there to be used when you remove the shipping bracket.

For square-hole racks,remove the bottom screws (1) that hold the rear adapter brackets (2) in

place. See the following gure.

Caution – Do not remove the bottom screws unless you are certain that the upper screw (3) is in

place. Otherwise, the server could fall.

Installing and Removing the Universal Shipping Brackets

Insert the rear bottom bracket(1) under the back of the serverwith the side panels facing up, as

shown in the following gure.

Use four screws (2) to fasten it to the rack. Do not nish tightening these screws. They should be tight enough to hold the bracket in place, but you should still be able to move the bracket slightly.

■

For square-hole racks, use the two screws that you removed in Step 5.

■

For round-hole racks, use either 10-32 x 10 or M6 x 12.

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201384

Installing and Removing the Universal Shipping Brackets

The bracket should be fastened to the posts, but loose enough to move slightly.

Push the bracketup so that it rests rmly against the bottom of the server, and then nish tightening the screwsthat hold the bracket in place.

If necessary, loosen the screws enough so that you can move the bracket, and then tighten them after pushing it against the bottom of the server.

Caution – To prevent damage to the server during shipping, the bottom shipping bracket must

rest rmly against the bottom of the server.

▼

How to Remove the Universal Shipping Brackets

This procedure describes how to remove brackets from a system equipped with the universal rack mounting kit.

The universal shipping bracket kit consists of a front bracket, a rear bottom bracket, and screws to connect them to the rack.

Installing and Removing the Universal Shipping Brackets

Figure Legend

1 Front shipping bracket.

2 Screws and cage nuts. The kit contains two sets of screws (M6 and 10-32), plus cage

nuts. The cage nuts are not used for the Sun Server X2-8.

3 Bottom rear shipping bracket.

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201386

Installing and Removing the Universal Shipping Brackets

Remove the twoscrews (1) that fasten the frontbracket (2) to the front of the server and remove

it.

Installing and Removing the Universal Shipping Brackets

Find the screws from the frontof shipping bracket that match your rack and use them to fasten

the bezel into the rack.

The front shipping bracket contains eight threaded holes used for storing unused screws (four M6 and four 10-32). Remove the screws that match the threads on your rack and use them to secure the server to the rack.

Thread the long screws that youremoved in Step 1 into the matching empty holes on the

shipping bracket.

They will be stored there in case you need to reinstall the shipping bracket.

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201388

Installing and Removing the Universal Shipping Brackets

Remove the four screws (1) that fasten the rear bottom bracket (2) under the back of the server

and remove it.

Replace the four screws that youremoved in Step 4.

BeforeYou Begin

Removing the Server from the Rack

This section provides instructions for removing your server from a the rack.

■

“How to Remove the Server from the Rack” on page 91

■

“How to Remove the Rackmounting Hardware from the Rack” on page 94

▼

How to Remove the Server from the Rack

This procedure assumes that you have turned o the server, and removed any cables or cords that would restrict the movement of the server.

Caution – The Sun Server X2-8 weighs about 180 pounds (100 kg) when fully loaded with

components. To reduce the risk of serious personal injury or equipment damage, use a mechanical lift to remove the sever from the rack. If a mechanical lift is not available, remove components to reduce weight and use two persons to lift it.

Disconnect all cables from the rear of the system.

If a lift is not available, remove components to reduce the system’s weight. See

Components to Reduce Weight”on page 51

“How to Remove

Removing the Server from the Rack

Remove the four screws from the front bezel of the system.

Using two hands,slide the server toward yourself and remove it from the shelf rails.

Caution – Drop hazard. You must support the weight of the server before it is within 6 inches

(152 mm) of being clear of the rack posts. We highly recommend that you release the weight of the server while it is still 12 inches (304 mm) inside the rack.

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201392

Removing the Server from the Rack

12” (304mm)

Removing the Server from the Rack

See Also

“How to Insert the Server Into the Rack” on page 77

▼

How to Remove the Rackmounting Hardware from the Rack

This task shows how to remove the rack mounting hardware from the universal rack and from the standard rack. This task is similar for each; however the universal rack is shown.

In this procedure, the dierences between the universal rack and the standard rack are trivial, except where they are noted.

Remove the four locking screws (1).

Perform this step for the universal rack mounting kit only. The standard rack mounting kit does not include these screws.

See the following gure.

Lift the two shelf rails (2) to disengage the hooks from the adapter brackets.

You can compress the shelf rails once you have disengaged the hooks from the adapter brackets.

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201394

Removing the Server from the Rack

Remove the screws that hold the adapter brackets (3 and 4) in place, and remove the brackets.

The universal rack mounting kit is shown. The standard rack mounting kit is similar, but slightly dierent.

Removing the Server from the Rack

Remove the screws (1) that hold the rear braces (2) in place, and remove the braces.

Perform this step for the universal rack mounting kit only. The standard rack mounting kit does not include these braces.

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201396

Cabling and Power

This section describes how to attach cables to the server and how to power the server on and o.

■

“Attaching Administration (SP) Cables” on page 97

■

“Cabling NEMs and PCIe EMs” on page 101

■

“Powering the Server On and O” on page 103

Attaching Administration (SP) Cables

The service processor module (SP) provides connections used for system administration. These include serial and Ethernet cables for Oracle ILOM, and serial, video, and USB cables for the host console. Connectors are provided on the SP itself, and on the multiport cable, which connects to the SP.

See the following gures.

Attaching Administration (SP) Cables

1 2 3

Figure Legend

1 Connect an Ethernet cable between the NET MGT port and the network to which future

connections to the SP will be made. NET MGT port 0 is the suggested default.

2 Connect a serial cable between the SER MGT port and a terminal device or a PC.

You might need an adapter. The server comes with a DB9-to-RJ45 serial port adapter.

The SER MGT port provides a direct serial connection to the SP.You can use this to discover the SP’s IP address, and congure it if necessary. DHCP is the default, but you can congure it to use a static IP address as well. Once you know the SP’s IP address, you can use a web browser or an SSH connection to communicate with the SP over the NET MGT port. Alternatively, you can continue to use the serial port to communicate with the SP command line interface (CLI).

Refer to the Oracle Integrated Lights Out Manager 3.0 documentation for details.

Connect the multiport cable to the KVM connector. This cable provides connectors for the serial console, the video console, and USB.

3 Connect power cable to power source.

4 EM slots – see

5 NEM slots – see

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 201398

“Cabling NEMs and PCIe EMs” on page 101.

Attaching Administration (SP) Cables

Figure Legend

1 Video console

2 Serial console

3 USB (2 connectors)

Attaching Administration (SP) Cables

FIGURE 1 SP Connectors

Figure Legend

1 Net management ports 0 and 1 2 Serial management

3 Fault LED 4 Power/OK LED

5 Temperature LED 6 Multiport cable connector

7 Locate button/LED 8 SP OK LED

Sun Server X2-8 (formerly Sun FireX4800M2) Installation Guide • August 2013100
