Sun SPARCEnterprise
™
M3000 Server
Product Notes For XCP Version 1092
Part No. 2821-1843-11
May 2010, Revision A
Copyright ©2010, Oracleand/or its affiliates andFUJITSU LIMITED.All rights reserved.
Oracle and/orits affiliatesand Fujitsu Limited each ownor controlintellectual propertyrights relatingto productsand technology described in this
document, andsuch products,technology and this document are protected bycopyright laws,patents, and otherintellectual propertylaws and
international treaties.
This documentand theproduct and technology to whichit pertainsare distributedunder licenses restricting their use, copying, distribution,and
decompilation. Nopart ofsuch product or technology, or of thisdocument, maybe reproducedin anyform by any means withoutprior written
authorization ofOracle and/orits affiliates and Fujitsu Limited,and theirapplicable licensors, if any. The furnishings ofthis documentto you does not
give youany rightsor licenses, express orimplied, withrespect tothe productor technology to which itpertains, andthis document doesnot containor
represent any commitment ofany kindon the part of Oracleor FujitsuLimited, or any affiliate of either ofthem.
This documentand theproduct and technology described inthis documentmay incorporate third-party intellectual property copyrighted by and/or
licensed fromthe suppliersto Oracle and/or its affiliates andFujitsu Limited,including softwareand font technology.
Per theterms ofthe GPL orLGPL, acopy of the source code governed bythe GPLor LGPL, as applicable, isavailable uponrequest bythe End User. Please
contact Oracleand/or itsaffiliates or Fujitsu Limited.
This distributionmay includematerials developed bythird parties.
Parts ofthe productmay bederived fromBerkeley BSDsystems, licensedfrom theUniversity of California. UNIX isa registered trademarkin theU.S. and
in othercountries, exclusivelylicensed through X/Open Company,Ltd.
Oracle andJava areregistered trademarksof Oracleand/or its affiliates. Fujitsu and the Fujitsulogo areregistered trademarksof FujitsuLimited.
All SPARCtrademarks areused underlicense andare registered trademarksof SPARCInternational, Inc.in theU.S. and other countries. Products bearing
SPARC trademarksare basedupon architecturesdeveloped byOracle and/or its affiliates. SPARC64 is a trademarkof SPARCInternational, Inc., used
under licenseby FujitsuMicroelectronics, Inc.and Fujitsu Limited. Other namesmay betrademarks of their respective owners.
United StatesGovernment Rights- Commercial use. U.S. Governmentusers aresubject tothe standardgovernment user license agreements ofOracle
and/or itsaffiliates andFujitsu Limited and the applicableprovisions ofthe FAR and its supplements.
Disclaimer: Theonly warrantiesgranted by Oracleand FujitsuLimited, and/or any affiliate of either ofthem inconnection with this document orany
product ortechnology describedherein arethose expresslyset forthin the license agreement pursuantto whichthe productor technology is provided.
EXCEPT ASEXPRESSLYSET FORTH INSUCH AGREEMENT, ORACLE OR FUJITSULIMITED, AND/ORTHEIR AFFILIATES MAKENO
REPRESENTATIONSOR WARRANTIESOF ANY KIND (EXPRESS ORIMPLIED) REGARDINGSUCH PRODUCT ORTECHNOLOGY ORTHIS
DOCUMENT,WHICH AREALL PROVIDED AS IS, ANDALL EXPRESSOR IMPLIED CONDITIONS, REPRESENTATIONSAND WARRANTIES,
INCLUDING WITHOUTLIMITATIONANY IMPLIED WARRANTY OF MERCHANTABILITY,FITNESS FOR A PARTICULARPURPOSE OR NONINFRINGEMENT,ARE DISCLAIMED,EXCEPT TOTHE EXTENT THAT SUCHDISCLAIMERS AREHELD TOBE LEGALLY INVALID.Unless
otherwise expresslyset forthin such agreement, to the extent allowedby applicablelaw,in no event shall Oracleor FujitsuLimited, and/or any of their
affiliates haveany liabilityto any third party under any legaltheory forany loss of revenues or profits, lossof useor data, or business interruptions, orfor
any indirect,special, incidentalor consequential damages, even ifadvised ofthe possibility of such damages.
DOCUMENTATIONIS PROVIDED“AS IS” ANDALL EXPRESSOR IMPLIED CONDITIONS, REPRESENTATIONSAND WARRANTIES,
INCLUDING ANYIMPLIED WARRANTYOF MERCHANTABILITY, FITNESS FOR APARTICULAR PURPOSE OR NON-INFRINGEMENT,ARE
DISCLAIMED, EXCEPTTO THEEXTENT THAT SUCH DISCLAIMERS AREHELD TOBE LEGALLYINVALID.
Please
Recycle
Copyright ©2010, Oracleet/ou ses sociétésaffiliées etFUJITSU LIMITED.Tousdroits réservés.
Oracle et/ouses sociétésaffiliées et Fujitsu Limited détiennentet contrôlentchacune des droits de propriété intellectuelle relatifs aux produitset
technologies décritsdans cedocument. De même,ces produits,technologies etce document sont protégés par des loissur lecopyright, des brevets,
d’autres loissur lapropriété intellectuelleet des traités internationaux.
Ce document,le produitet les technologies afférentssont exclusivement distribués avec deslicences quien restreignentl’utilisation, la copie, la
distribution etla décompilation.Aucune partie dece produit,de cestechnologies ou de ce documentne peutêtre reproduitesous quelqueforme que ce
soit, parquelque moyenque ce soit,sans l’autorisationécrite préalable d’Oracle et/ou sessociétés affiliéeset deFujitsu Limited, et de leurséventuels
bailleurs delicence. Cedocument, bien qu’ilvous aitété fourni, ne vous confère aucundroit etaucune licence,expresses outacites, concernant leproduit
ou latechnologie auxquelsil se rapporte.Par ailleurs,il ne contient ni nereprésente aucunengagement, dequelque type que ce soit,de lapart d’Oracle ou
de FujitsuLimited, oudes sociétés affiliées del’une oul’autre entité.
Ce document,ainsi queles produits et technologies qu’ildécrit, peuventinclure desdroits depropriété intellectuellede parties tierces protégés par
copyright et/oucédés souslicence par desfournisseurs àOracle et/ou ses sociétés affiliées etFujitsu Limited,y compris des logiciels etdes technologies
relatives auxpolices decaractères.
Conformément auxconditions dela licence GPLou LGPL,une copie du code source régipar lalicence GPL ou LGPL, selonle cas,est disponible sur
demande parl’Utilisateur final.Veuillezcontacter Oracleet/ou ses sociétés affiliées ouFujitsu Limited.
Cette distributionpeut comprendredes composantsdéveloppés par des parties tierces.
Des partiesde ceproduit peuvent être dérivées des systèmes BerkeleyBSD, distribuéssous licence par l’Université deCalifornie. UNIXest une marque
déposée auxÉtats-Unis etdans d’autres pays, distribuée exclusivementsous licencepar X/Open Company,Ltd.
Oracle etJava sontdes marques déposées d’Oracle Corporationet/ou deses sociétés affiliées. Fujitsu et le logoFujitsu sontdes marquesdéposées de
Fujitsu Limited.
Toutes lesmarques SPARCsont utiliséessous licence et sont desmarques déposéesde SPARCInternational, Inc.,aux États-Unis etdans d’autrespays. Les
produits portantla marqueSPARCreposent surdes architectures développéespar Oracleet/ou ses sociétés affiliées. SPARC64 est unemarque deSPARC
International, Inc.,utilisée souslicence par FujitsuMicroelectronics, Inc. et FujitsuLimited. Toutautre nommentionné peut correspondre àdes marques
appartenant àd’autres propriétaires.
United StatesGovernment Rights- Commercial use. U.S. Governmentusers aresubject tothe standardgovernment user license agreements ofOracle
and/or itsaffiliates andFujitsu Limited and the applicableprovisions ofthe FAR and its supplements.
Avis denon-responsabilité : lesseules garantiesoctroyées par Oracle et FujitsuLimited et/outoute société affiliée de l’une ou l’autre entitéen rapport
avec cedocument outout produit ou toute technologiedécrits dansles présentes correspondent aux garanties expressément stipulées dans lecontrat de
licence régissantle produitou la technologie fournis. SAUFMENTION CONTRAIREEXPRESSÉMENT STIPULÉE DANS CE CONTRAT,ORACLE OU
FUJITSU LIMITEDET LESSOCIÉTÉS AFFILIÉES ÀL’UNEOU L’AUTRE ENTITÉ REJETTENT TOUTE REPRÉSENTATIONOU TOUTEGARANTIE,
QUELLE QU’ENSOIT LANATURE (EXPRESSE OU IMPLICITE)CONCERNANT CEPRODUIT, CETTE TECHNOLOGIE OUCE DOCUMENT,
LESQUELS SONTFOURNIS ENL’ÉTAT.EN OUTRE,TOUTES LESCONDITIONS, REPRÉSENTATIONS ETGARANTIES EXPRESSESOU TACITES, Y
COMPRIS NOTAMMENTTOUTE GARANTIEIMPLICITE RELATIVE ÀLA QUALITÉMARCHANDE, À L’APTITUDE ÀUNE UTILISATION
PARTICULIÈREOU À L’ABSENCEDE CONTREFAÇON, SONT EXCLUES, DANSLA MESUREAUTORISÉE PARLA LOI APPLICABLE. Sauf mention
contraire expressément stipuléedans cecontrat, dans la mesure autorisée par laloi applicable,en aucun cas Oracle ouFujitsu Limitedet/ou l’une ou
l’autre deleurs sociétésaffiliées nesauraient êtretenues responsablesenvers une quelconque partie tierce,sous quelquethéorie juridique que ce soit,de
tout manqueà gagnerou de pertede profit,de problèmesd’utilisation oude perte de données, oud’interruptions d’activités,ou de tout dommage
indirect, spécial,secondaire ouconsécutif, mêmesi ces entités ont étépréalablement informéesd’une telle éventualité.
LA DOCUMENTATIONEST FOURNIE « EN L’ÉTAT »ET TOUTEAUTRE CONDITION,DÉCLARATIONET GARANTIE, EXPRESSE OU TACITE,EST
FORMELLEMENT EXCLUE,DANS LAMESURE AUTORISÉE PARLA LOI EN VIGUEUR, YCOMPRIS NOTAMMENT TOUTE GARANTIE
IMPLICITE RELATIVEÀ LA QUALITÉ MARCHANDE, ÀL’APTITUDEÀ UNE UTILISATION PARTICULIÈREOU ÀL’ABSENCE DE
CONTREFAÇON..
Contents
Preface ix
1. Sun SPARC Enterprise M3000 Server Product Notes for XCP 1092 1
What’s New in XCP 1090, 1091 and 1092 1
Active Directory and LDAP/SSL 2
Configuring XSCF for Active Directory Support 3
Configuring XSCF for LDAP/SSL Support 4
The proxyuser System Account 4
Airflow Indicator 4
Power Consumption Monitoring 5
Upgrading and Downgrading XCP 6
Upgrading to XCP 1090, 1091 or XCP 1092 6
Downgrading XCP Firmware 6
Minimum Required Firmware, Operating Systems, and Browsers 7
Solaris Patch Requirements 8
Solaris 10 5/09 with SPARC64 VII 2.75 GHz Processors 8
Solaris 10 10/08 with SPARC64 VII 2.75 GHz Processors 8
Obtaining Solaris Patches 8
Patches for Emulex PCI Express (PCIe) Cards 9
Functionality Issues and Limitations 9
v
Limitations for SPARC64 VII Processors 9
General Functionality Issues and Limitations 10
Additional Information and Procedures 12
Sun Java Enterprise System 12
Logging In to the System 12
Booting From a WAN Boot Server 13
Enabling Web Console SMF Service 13
▼ To Enable the Web Console SMF Service: 13
Identifying Degraded Memory in a System 14
▼ To Identify Degraded Memory in a System: 14
2. Information About Hardware 15
Note on the Use of 200V Power Supply 15
Connecting an SAS Device With Multiple SAS Targets to Onboard External SAS
Interface Not Supported 15
Booting Multiple Systems From a Single J4200 JBOD Storage Array 16
Notes on the Use of USB Memory 17
Hardware Documentation Updates 17
3. Information About Software 19
XCP Issues and Workarounds 19
Solaris OS Issues and Workarounds 20
Solaris Issues for All Supported Releases 20
Solaris Issues Fixed in Solaris 10 10/09 22
Solaris Issues Fixed in Solaris 10 5/09 23
Solaris Issues Fixed in Solaris 10 10/08 24
Documentation Updates 25
SPARC Enterprise M3000/M4000/M5000/ M8000/M9000 Servers XSCF Reference
Manual 25
vi Sun SPARC Enterprise M3000 Server Product Notes for XCP 1092 • May 2010
SPARC Enterprise M3000/M4000/M5000/ M8000/M9000 Servers XSCF User’s
Guide 28
Contents vii
viii Sun SPARC Enterprise M3000 Server Product Notes for XCP 1092 • May 2010
Preface
These product notes contain important and late-breaking information about the Sun
SPARC Enterprise M3000 server hardware, software, firmware, and documentation,
covering the XCP 1090, XCP 1091, and XCP 1092 firmware releases. This document is
written for experienced system administrators with working knowledge of computer
networks, and advanced knowledge of the Oracle Solaris Operating System.
Some references to server names are abbreviated for readability. For example, if you
see a reference to the SPARC Enterprise M3000 server or simply the M3000 server,
note that the full product name is the Sun SPARC Enterprise M3000 server.
Note – Generally, Product Notes content supersedes that of other product
documentation because Product Notes are published with more frequency. However,
in case of a conflict, compare the publication date on each document’s title page.
ix
Related Documentation
Related documents are listed in the following table. All are available online. See
“Where to View Related Documentation” on page xi.
Note – All glossaries in the following documents have been moved to the separate
glossary document listed in the table.
Application Title
Latest information Sun SPARC Enterprise M3000 Server Product Notes
Sun SPARC Enterprise M4000/M5000 Servers Product Notes
Sun SPARC Enterprise M8000/M9000 Servers Product Notes
Overview Sun SPARC Enterprise M3000 Server Overview Guide
Sun SPARC Enterprise M4000/M5000 Servers Overview Guide
Sun SPARC Enterprise M8000/M9000 Servers Overview Guide
Planning Sun SPARC Enterprise M3000 Server Site Planning Guide
Sun SPARC Enterprise M4000/M5000 Servers Site Planning Guide
Sun SPARC Enterprise M8000/M9000 Servers Site Planning Guide
Safety/Compliance Sun SPARC Enterprise M3000 Server Safety and Compliance Guide
Sun SPARC Enterprise M4000/M5000 Servers Safety and Compliance Guide
Sun SPARC Enterprise M8000/M9000 Servers Safety and Compliance Guide
Getting started Sun SPARC Enterprise M3000 Server Getting Started Guide
Sun SPARC Enterprise M4000/M5000 Servers Getting Started Guide
Sun SPARC Enterprise M8000/M9000 Servers Getting Started Guide
– Also provided in the shipping kit.
Planning/Installation Sun SPARC Enterprise Equipment Rack Mounting Guide (Sun Rack 1000,
900 and Sun Rack II)
Installation Sun SPARC Enterprise M3000 Server Installation Guide
Sun SPARC Enterprise M4000/M5000 Servers Installation Guide
Sun SPARC Enterprise M8000/M9000 Servers Installation Guide
– Also provided in the shipping kit..
Service Sun SPARC Enterprise M3000 Server Service Manual
Sun SPARC Enterprise M4000/M5000 Servers Service Manual
Sun SPARC Enterprise M8000/M9000 Servers Service Manual
Glossary Sun SPARC Enterprise M3000/M4000/M5000/M8000/M9000 Servers
Glossary
Software
administration
x Sun SPARC Enterprise M3000 Server Product Notes for XCP 1092 • May 2010
Sun SPARC Enterprise M3000/M4000/M5000/M8000/M9000 Servers XSCF
User’s Guide
Application Title
Software
administration
Software
administration
Software
administration
Capacity on Demand
administration
Sun SPARC Enterprise M3000/M4000/M5000/M8000/M9000 Servers XSCF
Reference Manual
Sun SPARC Enterprise M4000/M5000/M8000/M9000 Servers Dynamic
Reconfiguration (DR) User’s Guide
Sun Management Center (Sun MC) Software Supplement
Sun SPARC Enterprise M4000/M5000/M8000/M9000 Servers Capacity on
Demand (COD) User’s Guide
Where to View Related Documentation
Hardware documents:
http://docs.sun.com/app/docs/prod/sparc.m3k~m3000-hw?l=en#hic
http://docs.sun.com/app/docs/prod/sparc.m4k~m4000-hw?l=en#hic
http://docs.sun.com/app/docs/prod/sparc.m5k~m5000-hw?l=en#hic
http://docs.sun.com/app/docs/prod/sparc.m8k~m8000-hw?l=en#hic
http://docs.sun.com/app/docs/prod/sparc.m9k~m9000-hw?l=en#hic
Software documents:
http://docs.sun.com/app/docs/prod/sparc.m9k~m9000-sw?l=en#hic
Oracle Solaris Operating System documents:
http://docs.sun.com
Preface xi
Documentation, Support, and Training
Function URL
Documentation http://www.sun.com/documentation/
Support http://www.sun.com/support/
Training http://www.sun.com/training/
Documentation Feedback
Submit comments about this document by clicking the Feedback[+] link at
http://docs.sun.com. Include the title and part number of your document with
your feedback:
Sun SPARC Enterprise M3000 Server Product Notes for XCP Version 1092, part number
821-1843-11.
xii Sun SPARC Enterprise M3000 Server Product Notes for XCP 1092 • May 2010
CHAPTER
1
Sun SPARC Enterprise M3000
Server Product Notes for XCP 1092
This document covers the XCP 1090, XCP 1091, and XCP 1092 firmware releases.
This chapter contains the following sections:
■ “What’s New in XCP 1090, 1091 and 1092” on page 1
■ “Minimum Required Firmware, Operating Systems, and Browsers” on page 7
■ “Solaris Patch Requirements” on page 8
■ “Obtaining Solaris Patches” on page 8
■ “Functionality Issues and Limitations” on page 9
■ “Additional Information and Procedures” on page 12
What’s New in XCP 1090, 1091 and 1092
■ The XCP 1092 release updates information about the Active Directory and
LDAP/SSL features that were were introduced in the XCP 1091 release..
■ The XCP 1092 firmware is the first XCP release to support the new commands
setpacketfilters(8) and showpacketfilteres(8). See the new man pages
using the man(1) command.
■ The XCP 1091 firmware was the first XCP release to support the 2.75GHz
SPARC64 VII processor on the Sun SPARC Enterprise M3000 server. Earlier XCP
firmware releases do not support this faster version of the processor, which in
other respects is functionally identical to all SPARC64 VII processors.
■ The XCP 1091 firmware introduced the Active Directory and LDAP/SSL features.
See “Active Directory and LDAP/SSL” on page 2 and “Documentation Updates”
on page 25.
1
■ The XCP 1090 firmware was the first XCP release to support the new XSCF
command showdateoffset(8). For details, see the man page.
■ The XCP 1090 firmware was the first XCP release to support the Airflow and
Power indicators. For more information, see “Airflow Indicator” on page 4 and
“Power Consumption Monitoring” on page 5.
Active Directory and LDAP/SSL
The XCP 1091 release introduced support for the Active Directory and LDAP/SSL
features. Some changes to these features were introduced in the XCP 1092 release.
This section contains the latest information about these features.
■ Active Directory is a distributed directory service from Microsoft® Corporation.
Like an LDAP directory service, it is used to authenticate users.
■ LDAP/SSL (originally called LDAP over SSL) offers enhanced security to LDAP
users by way of Secure Socket Layer (SSL) technology. It uses LDAP directory
service to authenticate users.
Note – For security reasons, XSCF uses only LDAP over SSL to communicate with
an Active Directory server or an LDAP/SSL server.
Active Directory and LDAP/SSL each provide both authentication of user
credentials and authorization of the user access level to networked resources. They
use authentication to verify the identity of users before they can access system
resources, and to grant specific access privileges to users in order to control their
rights to access networked resources.
User privileges are either configured on XSCF or learned from a server based on
each user’s group membership in a network domain. A user can belong to more
than one group. Active Directory or LDAP/SSL authenticates users in the order in
which the users’ domains are configured. (A user domain is the authentication
domain used to authenticate a user.)
Once authenticated, user privileges can be determined in the following ways:
■ In the simplest case, users’ privileges are determined directly through the Active
Directory or LDAP/SSL configuration on the XSCF. There is a defaultrole
parameter for both Active Directory and LDAP/SSL. If this parameter is
configured or set, all users authenticated via Active Directory or LDAP/SSL are
assigned privileges set in this parameter. Setting up users in an Active Directory
or LDAP/SSL server requires only a password with no regard to group
membership.
■ If the defaultrole parameter is not configured or set, user privileges are
learned from the Active Directory or LDAP/SSL server based on the user’s group
membership. On XSCF, the group parameter must be configured with the
2 Sun SPARC Enterprise M3000 Server Product Notes for XCP 1092 • May 2010
corresponding group name from the Active Directory or LDAP/SSL server. Each
group has privileges associated with it which are configured on the XSCF. A
user’s group membership is used to determine the user’s privileges once the user
is authenticated.
Three types of groups can be configured: administrator, operator, and custom. To
configure an administrator or operator group, only group name is required.
An administrator group has platadm, useradm, and auditadm privileges associated
with it. An operator group has platop and auditop privileges associated with it. To
configure a custom group, both group name and privileges are required. For each
type of group, up to five groups can be configured. A user assigned to more than
one group receives the sum of all privileges associated with those groups.
To support these new features, two new configuration screens (Active Directory
and LDAP/SSL) have been added to the Settings menu of the XSCF Web. Remote
users can log in and use the XSCF Web once they have been authenticated by Active
Directory or LDAP/SSL.
Note – If you are an Active Directory or LDAP/SSL user, log in to the XSCF
network using SSH and password rather than user public key. If you already
uploaded a public key, use the following command to delete it:
XSCF> setssh -c delpubkey -a -u proxyuser
Configuring XSCF for Active Directory Support
The commands setad(8) and showad(8) let you set and view the Active Directory
configuration from the command line.
By default, Active Directory support is disabled. To enable Active Directory support,
use the following command:
XSCF> setad enable
To disable Active Directory support, use the following command:
XSCF> setad disable
To show if Active Directory support is enabled or disabled, enter: :
XSCF> showad
Chapter 1 Sun SPARC Enterprise M3000 Server Product Notes for XCP 1092 3
Use the setad(8) command with its various parameters to configure AD. For
example, you can use it to set up one primary and five alternate Active Directory
servers, assign group names and privileges, configure a particular user domain,
control logging of diagnostic messages, and more. User domain can be configured
explicitly through the setad userdomain command on XSCF, or entered at login
prompt using the form, user@domain.
See the setad(8) and showad(8) man pages, and the notes about these commands in
TABLE 3-7.
Note – Once Active Directory has been configured and used, downgrading the
firmware is not advised. However, if you must downgrade to an earlier release, run
the following command immediately after doing so:
restoredefaults -c xscfu.
Configuring XSCF for LDAP/SSL Support
The commands setldapssl(8) and showldapssl(8) let you set and view
LDAP/SSL configuration from the command line. These commands do for
LDAP/SSL what the setad(8) and showad(8) commands do for AD, and support
many of the same parameters.
For more information, see the setldapssl(8) and showldapssl(8) man pages.
The proxyuser System Account
To support Active Directory and LDAP/SSL, the XCP 1091 release added a new
system account named proxyuser. Before using the Active Directory or LDAP/SSL
features, check to ensure that no user account of that name already exists. If one
does, use the deleteuser(8) command to remove it, then reset XSCF before using
these features.
Airflow Indicator
Introduced in the XCP 1091 release, the Airflow indicator value indicates the volume
of air exhausted from the M3000 server while it is running. The value does not
include air emitted from peripheral devices.
Note – Airflow monitoring measurement values are for reference only.
4 Sun SPARC Enterprise M3000 Server Product Notes for XCP 1092 • May 2010
To display the amount of exhaust air, use the showenvironment air command.
XSCF> showenvironment air
Air Flow:63CMH
Note – Airflow measurements might be incorrect if taken during or shortly after
server power-on or power-off, or during or shortly after replacement of the power
supply. For best results, check these values after at least one minute has passed.
For details of the showenvironment(8) command, refer to the man page. For
installation details of the SPARC Enterprise M3000 server, see the SPARC Enterprise
M3000 Server Site Planning Guide and the SPARC Enterprise M3000 Server Installation
Guide.
You can also obtain the exhaust air data using the SNMP agent function. To obtain
the data of exhaust air using the SNMP agent function, install the latest XSCF
extension MIB definition file to the SNMP manager. For details on the XSCF
extension MIB definition file, see the
SPARC Enterprise M3000/M4000/M5000/M8000/M9000 Servers XSCF User’s Guide.
Power Consumption Monitoring
Introduced in the XCP 1091 release, the power consumption monitoring function
indicates the amount of power consumed while the SPARC Enterprise M3000 server
is running. The value does not include that of peripheral devices.
Note – Power consumption monitoring measurement values are for reference only.
The power consumption value of the server varies by the conditions such as the
power supply in use, CPU types, system configurations, or system load. For more
information, see the SPARC Enterprise M3000/M4000/M5000/M8000/M9000 Servers
XSCF User’s Guide.
To display the power consumption, use the showenvironment power command.
XSCF> showenvironment power
Permitted AC power consumption:470W
Actual AC power consumption:450W
Chapter 1 Sun SPARC Enterprise M3000 Server Product Notes for XCP 1092 5
Note – Power measurements might be incorrect if taken during or shortly after
server power-on or power-off, or during or shortly after replacement of the power
supply.
For details of the showenvironment(8) command, see the man page. For
installation details of the SPARC Enterprise M3000 server, see the SPARC Enterprise
M3000 Server Site Planning Guide.
You can also obtain the power consumption data using the SNMP agent function. To
obtain the power consumption data using the SNMP agent function, install the latest
XSCF extension MIB definition file to the SNMP manager. For details on the XSCF
extension MIB definition file, see the SPARC Enterprise
M3000/M4000/M5000/M8000/M9000 Servers XSCF User’s Guide.
Upgrading and Downgrading XCP
Upgrading to XCP 1090, 1091 or XCP 1092
For information about upgrading your firmware, see the Sun SPARC Enterprise
M3000/M4000/M5000/M8000/M9000 Servers XSCF User’s Guide.
Note – After upgrading XCP firmware, use the rebootxscf(8) command to reset
the XSCF.
Downgrading XCP Firmware
Downgrading your XCP firmware to an earlier release is not advised. However, if
you must downgrade your XCP 1092 firmware to the XCP 1091 or XCP 1090 release,
or your XCP 1091 release to the XCP 1090 version, execute the following command
afterward to clear old-style audit logs:
XSCF> restoredefaults -c xscfu
6 Sun SPARC Enterprise M3000 Server Product Notes for XCP 1092 • May 2010
Minimum Required Firmware,
Operating Systems, and Browsers
The Solaris Operating System is preinstalled on new M3000 servers.
TABLE 1-1 lists the earliest firmware and operating system (OS) versions that are
required in this release. ..
TABLE 1-1 Minimum Required Firmware and Operating System Versions
Minimum XCP
Processor Type
SPARC64 VII processors, 2.52GHz XCP 1080 Solaris 10 10/08 – with no patches required
Version Minimum Operating System Version
SPARC64 VII processors,
2.52GHz with 8GB DIMMs
SPARC64 VII processors, 2.75GHz XCP 1091 Solaris 10 10/08 – with the Solaris 10 10/09
XCP 1081 Solaris 10 10/08 – with no patches required
Patch Bundle required.
Solaris 10 10/09 – with no patches required
Note – As for all releases, installation of the SunAlert Patch Cluster is recommended. Also,
note that the Solaris 10 10/09 Patch Bundle is also known as MU8.
Many web browsers support the XSCF Web. The browsers in
TABLE 1-2 have
demonstrated compatibility with the XSCF Web through testing.
TABLE 1-2 Tested Web Browser Versions
Web Browser Application Version
Firefox 2.0 and 3.0
Microsoft Internet Explorer 6.0 , 7.0 and 8.0
Chapter 1 Sun SPARC Enterprise M3000 Server Product Notes for XCP 1092 7
Solaris Patch Requirements
This section lists mandatory patches, patch bundles, and SunAlert patch clusters for
the M3000 server. Always refer to the patch README for information about patch
requirements and special installation instructions.
The patch identifiers listed in this section represent the minimum level of the patches
that must be installed. The two-digit suffix represents the minimum revision level of
the patch. Check http://sunsolve.sun.com for the latest patch revision. Apply
patches in the order listed.
Solaris 10 5/09 with SPARC64 VII 2.75 GHz
Processors
The Solaris 10 10/09 Patch Bundle is required, and the SunAlert Patch Cluster is
recommended. See:
http://sunsolve.sun.com/show.do?target=patches/patch-access
Solaris 10 10/08 with SPARC64 VII 2.75 GHz
Processors
The Solaris 10 10/09 Patch Bundle is required, and the SunAlert Patch Cluster is
recommended. See:
http://sunsolve.sun.com/show.do?target=patches/patch-access
Obtaining Solaris Patches
The SunsConnection Update Manager can be used to reinstall the patches if
necessary or to update the system with the latest set of mandatory patches. For more
information about the Sun Connection Update Manager, refer to the Sun Update
Connection System Administration Guide at:
http://docs.sun.com/app/docs/prod/updconn.sys
Or visit:
8 Sun SPARC Enterprise M3000 Server Product Notes for XCP 1092 • May 2010
http://wikis.sun.com/display/SunConnection/Update+Manager
Installation information and README files are included in the patch downloads.
Two options are available to register your system and to use the Sun Connection
Update Manager to obtain the latest Solaris OS patches:
■ Use the Update Manager GUI to obtain patches. For more information, refer to
the Sun Update Connection documentation at the links mentioned previously.
■ Use the smpatch(1M) command to obtain patches. For more information, refer to
the smpatch(1M) man page or the reference manual collection for your version of
Solaris.
Patches for Emulex PCI Express (PCIe)
Cards
The following Emulex cards require drivers supplied in patch 120222-26 or later:
■ XSEFC402AF Sun StorageTek
Channel PCIe HBA
™
Enterprise Class 4-Gigabit Dual-Port Fiber
■ XSEFC401AF Sun StorageTek Enterprise Class 4-Gigabit Single-Port Fiber
Channel PCIeHBA
Functionality Issues and Limitations
This section describes issues and limitations known at the time of this release.
Limitations for SPARC64 VII Processors
Caution – You must complete the upgrades to the XCP firmware and to the Solaris
OS before inserting SPARC 64 VII processors into the chassis.
Chapter 1 Sun SPARC Enterprise M3000 Server Product Notes for XCP 1092 9
General Functionality Issues and Limitations
Note – Do not use the Service Processor (SP) as the Network Time Protocol (NTP)
server. Using an independent NTP server provides optimal reliability in maintaining
consistent time on the SP and the domains. For more information about NTP, see the
Sun Blueprint document, Using NTP to Control and Synchronize System Clocks:
http://www.sun.com/blueprints/0701/NTP.pdf
■ For power-on after power-off, wait at least 30 seconds before turning the system
power back on by using the main line switch or the circuit breakers on the
distribution panel.
■ You cannot use the following user account names, as they are reserved for system
use: adm, admin, apache, bin, daemon, default, ldap, nobody, ntp,
operator, proxyuser, root, rpc, rpcuser, and sshd.
■ An XSCF user account user name cannot match an LDAP user name, and an
XSCF user account number (UID) cannot match an LDAP UID number.
■ If your M3000 server is running the Solaris 10 10/09 OS and IPMP, you must
disable probe-based failure detection to correct for CR 6888928. See InfoDoc
211105 (86869).
■ When you use the external power control interface of the external power
controller, the following notification signals are not supported:
■ The OS panic or the server hardware error signal (*CPUN/RTNU).
■ The server hardware error signal (power fail, temperature error, and fan error)
(*ALARM).
■ When you import XCP or update the firmware using the XSCF you might see
Web session ID errors displayed on the web browser. When you specify the
timeout period as over 30 minutes in the Autologout setting, Internal Server
Errors might be displayed. To reconnect to the XSCF Web close the current
browser and open the new browser.
■ Before using the XSCF Web, disable pop-up blocking and remove any plug-ins
such as the search tool installed with the browser.
■ XSCF-LAN is compliant with auto-negotiation. Set the network device that
connects with XSCF-LAN to the auto-negotiation mode. Otherwise, when you
connect the XSCF-LAN and the network device (fixed to the full-duplex mode,
according to the IEEE 802.3 rule), the XSCF-LAN communicates in half-duplex
mode and network communication speed might slow or communication errors
may occur.
■ For information about I/O options and storage, such as the number of cards
supported in a domain, see the Sun Cross Platform IO Support page:
http://wikis.sun.com/display/PlatformIoSupport/Home/
10 Sun SPARC Enterprise M3000 Server Product Notes for XCP 1092 • May 2010
■ The setsnmp(8) and showsnmp(8) commands do not notify the user of
authorization failure. Upon such failure, confirm that the SNMP trap host is
working and re-execute the command using the correct user name.
Chapter 1 Sun SPARC Enterprise M3000 Server Product Notes for XCP 1092 11
Additional Information and Procedures
This section describes additional issues and limitations known at the time of this
release.
Sun Java Enterprise System
The Sun Java™ Enterprise System software is a comprehensive set of software and
life cycle services that make the most of your software investment. The software and
installation instructions can be found at the following web address:
http://www.sun.com/software/javaenterprisesystem/index.jsp
The software might not include patches that are mandatory for your server. After
installing the software, refer to “Solaris Patch Requirements” on page 8 for
information about checking for and installing required patches.
For an overview and documentation, go to:
http://www.sun.com/service/javaes/index.xml
Note – Due to an issue that arises from the installation of the Java Enterprise System
5 Update 1 on your system, it might be necessary to enable the WebConsole SMF
service.
Logging In to the System
In addition to the standard default login, M3000/M4000/M5000/M8000/M9000
servers are delivered with a temporary login called admin to enable remote initial
login, through a serial port. The admin user privileges are fixed to useradm and
cannot be changed. You cannot log in as temporary admin using the standard UNIX
user name and password authentication or SSH public key authentication. The
temporary admin account has no password, and one cannot be added for it.
The temporary admin account is disabled after someone logs in as the default user,
or after someone logged in as temporary admin has successfully added the first user
with valid password and privileges.
If, before the default login is used, you cannot log in as temporary admin, you can
determine if someone else has done so by executing the showuser -l command.
12 Sun SPARC Enterprise M3000 Server Product Notes for XCP 1092 • May 2010
Booting From a WAN Boot Server
The WAN boot installation method enables you to boot and install software over a
wide area network (WAN) by using HTTP. To support booting the M3000 server
from a WAN boot server, you must have the appropriate wanboot executable
installed and OpenBoot
support.
For information about WAN boot servers, refer to the Solaris 10 Installation Guide:
Network-Based Installations for the version of Solaris 10 OS that you are using. You
can find Solaris 10 OS documentation here:
http://docs.sun.com/app/docs/prod/solaris.10
If you do not upgrade the wanboot executable, the server will panic, with messages
similar to the following:
krtld: load_exec: fail to expand cpu/$CPU
krtld: error during initial load/link phase
panic - boot: exitto64 returned from client program
™
version 4.24.10 or above to provide the needed hardware
Enabling Web Console SMF Service
▼ To Enable the Web Console SMF Service:
● Log in to a terminal as root, then type:
# svcadm enable svc:/system/webconsole:console
If you have to reload the software, go to the following web site for download and
installation instructions:
http://www.sun.com/software/preinstall
If you download a fresh copy of software, that software might not include patches
that are mandatory for your server. Before installing the software, refer to “Solaris
Patch Requirements” on page 8 for information about checking for and installing
required patches.
Chapter 1 Sun SPARC Enterprise M3000 Server Product Notes for XCP 1092 13
Identifying Degraded Memory in a System
▼ To Identify Degraded Memory in a System:
1. Log in to XSCF.
2. Type the following command:
XSCF> showstatus
3. The following example reveals that DIMM number 0A on the Motherboard unit
has degraded memory:
XSCF> showstatus
MBU_A Status: Normal;
MEM#0A Status:Degraded
14 Sun SPARC Enterprise M3000 Server Product Notes for XCP 1092 • May 2010
CHAPTER
2
Information About Hardware
This chapter describes special instructions and issues about M3000 server hardware.
■ “Note on the Use of 200V Power Supply” on page 15
■ “Connecting an SAS Device With Multiple SAS Targets to Onboard External SAS
Interface Not Supported” on page 15
■ “Booting Multiple Systems From a Single J4200 JBOD Storage Array” on page 16
■ “Notes on the Use of USB Memory” on page 17
■ “Hardware Documentation Updates” on page 17
Note on the Use of 200V Power Supply
For servers that have the B-type plug, confirm that a 15A overcurrent protection
device is available outside the server. If one is not available, prepare an external 15A
overcurrent protection that can be achieved by means of no-fuse breakers (NFBs) or
fuses. The B-type plug refers to plugs other than grounding-type ones with two
parallel blades, such as the NEMA L6-30, L6-20, L6-15, and L5-15.
Connecting an SAS Device With
Multiple SAS Targets to Onboard
External SAS Interface Not Supported
It is not supported to connect an SAS device containing multiple SAS targets to the
onboard external SAS interface. Instead, use a Sun StorageTek Host Bus Adaptor
(SG-XPCIE8SAS-E-Z). [CR 6765239]
15
Booting Multiple Systems From a Single
J4200 JBOD Storage Array
Sun Storage J4200 SAS JBOD arrays have six general-purpose SAS connectors. With
FW version 3A32 or higher, each of them can be connected to separate SAS initiators,
therefore up to six systems can be connected to the array. Each system can use a
different disk on the array as its boot device. J4200 arrays have 12 disks, so each boot
device can be mirrored for higher reliability. J4200 SAS arrays can be configured into
multiple zones to provide a more secure environment.
See especially:
Sun StorageTek Common Array Manager Software documentation, at:
http://docs.sun.com/app/docs/prod/stor.arrmgr#hic
See especially:
■ Sun StorageTek Common Array Manager Software Release Notes 6.4.1
■ Sun StorageTek Common Array Manager User Guide for Open Systems
16 Sun SPARC Enterprise M3000 Server Product Notes for XCP 1092 • May 2010
Notes on the Use of USB Memory
To execute the dumpconfig(8), restoreconfig(8) or snapshot(8) command,
if you specify USB memory as the destination to store data, prepare the USB
memory as a medium in advance.
The data stored will include the information about the system. To use USB memory,
you need to pay attention to the management of the USB memory in which the data
stored, from the data security viewpoint.
We do not provide guarantees on the proper operation and connectivity to the XSCF
of every USB memory currently manufactured on the market. Depending on the
USB memory in use, defects such as the XSCF firmware error or reset may occur. In
case such defects occurred, stop the use of USB memory immediately.
To connect the USB memory to the USB port for the XSCF, connect the USB memory
directly to the USB port. If connected via the USB hub or USB extension, it might
cause errors.
Hardware Documentation Updates
This section contains late-breaking hardware information and corrections that
became known after the documentation set was published.
TABLE 2-1 lists known documentation updates.
TABLE 2-1 Hardware Documentation Updates
Title Page Number Update
SPARC Enterprise M3000 Server
Overview Guide
1-25 1.4.6.2 "SAS Port"
The article on "SAS Port" will be replaced by the following.
The SAS port connects the server to an external device, such
as a tape drive, which has an SAS interface. For information
on which devices can be connected, contact a service
engineer.
Note that the transfer rate of this port is up to 600MB/s
(3Gbps x 2wide).
Chapter 2 Information About Hardware 17
18 Sun SPARC Enterprise M3000 Server Product Notes for XCP 1092 • May 2010
CHAPTER
3
Information About Software
This chapter describes specific software and firmware issues and workarounds. It
includes the following sections:
■ “XCP Issues and Workarounds” on page 19
■ “Solaris OS Issues and Workarounds” on page 20
■ “Documentation Updates” on page 25
XCP Issues and Workarounds
This section lists XCP issues known to exist in the XCP 1092 release. If you are using
XCP 1090 or 1091 firmware, refer to this section in the Sun SPARC Enterprise M3000
Server Product Notes for that version of the firmware.
TABLE 3-1 lists XCP issues and possible workarounds.
TABLE 3-1 XCP Issues and Workarounds
ID Description Workaround
6789066 In the settimezone -c adddst command,
when you set eight or more letters to the
abbreviation of time zone and the name of
Daylight Saving Time, execution of the
showlogs command induces a segmentation
fault and results in an error.
Specify the abbreviation of time zone and the
name of Daylight Saving Time in seven letters
or less.
19
Solaris OS Issues and Workarounds
This section contains information about Solaris OS issues. The following tables list
issues you might encounter, depending in part on which Solaris OS release you are
using.
Solaris Issues for All Supported Releases
TABLE 3-2 lists Solaris OS issues that you might encounter in any Solaris release. If
your domains are not running the latest Solaris release, also take notice of CRs fixed
in releases later than yours, as noted in the tables that follow.
TABLE 3-2 Solaris OS Issues and Workarounds for All Supported Releases (1 of 3)
CR ID Description Workaround
6531036 The error ‘message network
initialization failed’ appears
repeatedly after a boot net installation.
6532215 volfs or dscp services might fail when a
domain is booted.
No workaround is available. This message can
be safely ignored.
Restart the service. To avoid the problem, issue
the following commands.
# svccfg -s dscp setprop \
start/timeout_seconds=count: 300
# svccfg -s volfs setprop \
start/timeout_seconds=count: 300
# svcadm refresh dscp
# svcadm refresh volfs
20 Sun SPARC Enterprise M3000 Server Product Notes for XCP 1092 • May 2010
TABLE 3-2 Solaris OS Issues and Workarounds for All Supported Releases (2 of 3)
CR ID Description Workaround
6660168 If a ubc.piowbeue-cpu error occurs on a
domain, the Solaris Fault Management
cpumem-diagnosis module might fail, causing
an interruption in FMA service. If this
happens, you will see output similar to the
following sample in the console log:
SUNW-MSG-ID: FMD-8000-2K, TYPE:
Defect, VER: 1, SEVERITY: Minor
EVENT-TIME: Fri Apr 4 21:41:57 PDT
2008
PLATFORM: SUNW,SPARC-Enterprise, CSN:
2020642002, HOSTNAME: <hostname>
SOURCE: fmd-self-diagnosis, REV: 1.0
EVENT-ID: 6b2e15d7-aa65-6bcc-bcb1cb03a7dd77e3
DESC: A Solaris Fault Manager
component has experienced an error
that required the module to be
disabled. Refer to
http://sun.com/msg/FMD-8000-2K for
more information.
AUTO-RESPONSE: The module has been
disabled. Events destined for the
module will be saved for manual
diagnosis.
IMPACT: Automated diagnosis and
response for subsequent events
associated with this module will not
occur.
REC-ACTION: Use fmdump -v -u <EVENTID> to locate the module. Use fmadm
reset <module> to reset the module
If fmd service fails, issue the following
command on the domain to recover:
# svcadm clear fmd
Then restart cpumem-diagnosis:
# fmadm restart cpumem-diagnosis
6668237 After DIMMs are replaced the corresponding
DIMM faults are not cleared on the domain.
6723202 The raidctl command cannot be used to
create a hardware RAID using the onboard
SAS/LSI controller on the M3000 server.
The raidctl command can be used to view
disk/controller status, and can be used on any
PCI Host Bus Adapter (HBA) installed in the
system.
6745410 Boot program ignores the Kadb option which
causes the system not to boot.
Use the following commands:
# fmadm repair fmri|uuid
# fmadm rotate
No workaround is available.
Use kmdb instead of kadb.
Chapter 3 Information About Software 21
TABLE 3-2 Solaris OS Issues and Workarounds for All Supported Releases (3 of 3)
CR ID Description Workaround
6872501 Cores are not offlined when requested by the
XSCF. This CR affects only Solaris 10 5/09 and
Solaris 10 10/09 releases.
6888928 IPMP interface fails since probe packets are not
sent through that interface. Problem occurs
with M3000/M4000/M5000/M8000/M9000
servers running the Solaris 10 10/09 OS and
IPMP, or any Solaris release running IPMP
with Patch 141444-09 installed.
Use fmdump(1M) with its -v option on the
Service Processor to identify the faulty core.
Once identified, use psradm(8) on the domain
to offline the core.
Disable probe-based failure detection. See
InfoDoc 211105 (86869).
Solaris Issues Fixed in Solaris 10 10/09
TABLE 3-4 lists issues that have been fixed in Solaris 10 10/09 OS. You might
encounter them in earlier releases.
TABLE 3-3 Solaris OS Issues and Workarounds Fixed in Solaris 10 5/09
CR ID Description Workaround
6572827 The prtdiag -v command reports PCI bus
types incorrectly. It reports “PCI” for PCI-X
leaf devices and “UNKN” for legacy PCI
devices.
No workaround is available.
22 Sun SPARC Enterprise M3000 Server Product Notes for XCP 1092 • May 2010
Solaris Issues Fixed in Solaris 10 5/09
TABLE 3-4 lists issues that have been fixed in Solaris 10 5/09 OS. You might encounter
them in earlier releases.
TABLE 3-4 Solaris OS Issues and Workarounds Fixed in Solaris 10 5/09
CR ID Description Workaround
6623226 The Solaris command lockstat(1M) or the
dtrace lockstat provider might cause a system
panic.
6680733 Sun Quad-port Gigabit Ethernet Adapter UTP
(QGC) & Sun Dual 10 GigE Fiber XFP Low
Profile Adapter (XGF) NICs might panic under
high load conditions.
6689757 Sun Dual 10 GigE Fiber XFP Low Profile
Adapter (XGF) with a single or improperly
installed XFP optical transceivers might cause
the following error to show on the console:
The XFP optical transceiver is broken
or missing.
6725885 cfgadm will display non-existent M3000
system boards (SB1 to SB15).
Do not use the Solaris lockstat(1M)
command or the dtrace lockstat provider.
There is no workaround available.
Check and make sure that both XFP optical
transceivers are firmly seated in the housing.
Do not mix INTEL and Sun XFP optical
transceivers in the same Adapter.
Do NOT plumb a port with the ifconfig
command if the port does not contain an XFP
optical transceiver or it contains one but the
transceiver is not in use.
The cfgadm output for SB1-SB15 can be
ignored.
Chapter 3 Information About Software 23
Solaris Issues Fixed in Solaris 10 10/08
TABLE 3-5 lists issues that have been fixed in Solaris 10 10/08 OS. You might
encounter themin earlier releases..
TABLE 3-5 Solaris OS Issues and Workarounds Fixed in Solaris 10 10/08
CR ID Description Workaround
6556742 The system panics when DiskSuite cannot read
metadb during DR. This bug affects the
the
following cards:
• SG-XPCIE2FC-QF4, 4-Gigabit PCI-e DualPort Fiber Channel HBA
• SG-XPCIE1FC-QF4, 4-Gigabit PCI-e SinglePort Fiber Channel HBA
• SG-XPCI2FC-QF4, 4-Gigabit PCI-X DualPort Fiber Channel HBA
• SG-XPCI1FC-QF4, 4-Gigabit PCI-X SinglePort Fiber Channel HBA
6608404 Hot-plug of the X4447A-Z, PCI-e Quad-port
Gigabit Ethernet Adapter UTP card might
cause other network devices to fail.
6720261 If your domain is running Solaris 10 5/08 OS,
the system might panic/trap during normal
operation:
6737039 WAN boot of M3000 servers fails
intermittently with a panic early in the boot
process. Sample output:
ERROR: Last Trap: Fast Data Access MMU
Miss
%TL:1 %TT:68 %TPC:13aacc %TnPC:13aad0
%TSTATE:1605
%PSTATE:16 ( IE:1 PRIV:1 PEF:1 )
DSFSR:4280804b ( FV:1 OW:1 PR:1 E:1
TM:1 ASI:80 NC:1 BERR:1 )
DSFAR:fda6f000 DSFPAR:401020827000 DTAG:6365206f66206000
Panic can be avoided when a duplicated copy of
the metadb is accessible via another Host Bus
Adaptor.
There is no workaround.
Set the following parameter in the system
specification file (/etc/system):
set heaplp_use_stlb=0
Then reboot the domain.
Power off and power on the chassis, then retry
the operation.
24 Sun SPARC Enterprise M3000 Server Product Notes for XCP 1092 • May 2010
Documentation Updates
This section contains late-breaking information that became known after the listed
document was published or that was very recently added.
Note – Online man pages are updated more frequently than the SPARC Enterprise
M3000/M4000/M5000/ M8000/M9000 Servers XSCF Reference Manual.
SPARC Enterprise M3000/M4000/M5000/
M8000/M9000 Servers XSCF Reference Manual
The following changes are not included in the XCP 1090 edition of this document
dated August 2009.
TABLE 3-6 XSCF Reference Manual
man page Change
Advanced Directory and
LDAP/SSL man pages
adduser(8) Added the following information: “If the Service Processor is configured to use
applynetwork(8) Modified for clarity.
ioxadm(8) Modified to include new information.
password(8) Modified value ranges for clarity. Most are 1 - 999999999.
setdscp(8) Added the following text:
setdualpowerfeed(8) Modified to include the statement: “The dual power feed mode cannot be used
sethostname(8) Added information in EXTENDED DESCRIPTION.
Four new man pages related to these features:
setad(8), setldapssl(8), showad(8), and showldapssl(8). You can use the
man(1) command to view these man pages online.
Lightweight Directory Access Protocol (LDAP), Active Directory, or LDAP/SSL
for user account data, the user name and UID (if specified) must not already be
in use locally or in LDAP, Active Directory, or LDAP/SSL.”
“The specified netmask must be a subset of the default netmask based on
network class.
with 100V power on M4000/M5000 servers.”
Chapter 3 Information About Software 25
TABLE 3-6 XSCF Reference Manual
man page Change
sethttps(8) Added to EXTENDED DESCRIPTION:
“The size of the file to be generated by sethttps(8) grows with the total
character count typed in the operands for configuring self-certification authority,
creating a self-signed web server certificate, and creating a CSR. If the file to be
generated is too large for XSCF, the command fails with an error. If you see this
error, reduce the number of characters in the operands and execute the
sethttps(8) command again”
setldap(8) Added the following information: “An XSCF user account user name cannot
match an LDAP user name and an XSCF user account number (UID) cannot
match an LDAP UID number. “
setnameserver(8) • Added to OPERANDS:
“You cannot specify the loopback address (127.0.0.0/8), the network address,
or a broadcast address.”
• Added to OPTIONS:
New options for registering a specified domain name to the DNS search path:
-c addsearch
-c delsearch
Along with the addition of DNS search path, related descriptions for DNS search
path were added to applynetwork(8), sethostname(8), and
shownameserver(8). For details, see the online versions of these man pages as
of the XCP 1091 release.
setnetwork(8) Modified -m in OPTIONS, and added to OPERANDS:
“You cannot specify the loopback address (127.0.0.0/8), the network address, a
broadcast address, or a class D or E (224.0.0.0 - 255.255.255.255) address.”
Also, added information about xscf#0-lan#0 and xscf#0-lan#1.
setntp(8) • Added to OPERANDS:
“You cannot specify the loopback address (127.0.0.0/8), the network address,
or a broadcast address.”
• Added to OPTIONS: A new option for setting the local clock of XSCF:
-m localaddr=value.
Along with the addition of clock address, related descriptions for local addresses
will be added to showntp(8). For details, see the online version of the setntp(8)
and showntp(8) man pages.
setpacketfilters(8) This new man page was added in the XCP 1092 release.
setpasswordpolicy(8) Modified value ranges for clarity. Most are 1 - 999999999.
26 Sun SPARC Enterprise M3000 Server Product Notes for XCP 1092 • May 2010
TABLE 3-6 XSCF Reference Manual
man page Change
setroute(8) • Added to OPTIONS:
“You cannot specify the loopback address (127.0.0.0/8), the network address,
or a broadcast address.”
• Changed in OPTIONS:
Old text – “If you specified 0.0.0.0 in the -n option, do not specify the -m
option.”
New text – “If you specified 0.0.0.0 in the -n option, you must specify 0.0.0.0
in the -m option or you must omit the -m option.”
setupfru(8) Added to EXTENDED DESCRIPTION:
“Although a CMU with two CPUMs can be configured into Quad-XSB mode on
an M8000/M9000 server, the server generates a "configuration error" message for
these XSBs because they do not have at least one CPUM and memory.”
setupplatform(8) Added the following information: “An XSCF user account user name cannot
match an LDAP user name and an XSCF user account number (UID) cannot
match an LDAP UID number. “
showdevices(8) Added to EXTENDED DESCRIPTION:
“The showdevices(8) command displays a complete list of devices when
executed right after a Solaris OS boot or a DR operation. However, when
executed at other times, showdevices does not display a complete list if the
Solaris OS has unloaded drivers for any unused devices. To be certain the
displayed list is complete, run the devfsadm command with the -v option on
the domain before running showdevices. For more information about the
devfsadm command, see the Solaris devfsadm(1M) man page.”
showenvironment(8) Added:
“Airflow volume information is not supported on the M4000/M5000 servers.”
Replaced:
Old text – “The power consumption information is displayed on the
M3000/M4000/M5000 servers.”
New text – “The power consumption information is displayed on the M3000
server.”
showhardconf(8) Added to EXAMPLES: A new example of a M3000 server with DC power, added
PCI card information, and added -M option.
showlogs(8) Added:
-M option, new information for Status and Detail log/Power log in EXTENDED
DESCRIPTION, and other references to Pow.Fail/Recov.
showpacketfilters(8) This new man page was added in the XCP 1092 release.
Chapter 3 Information About Software 27
SPARC Enterprise M3000/M4000/M5000/
M8000/M9000 Servers XSCF User’s Guide
The following changes were added to or not included in the August 2009 edition of
this document.
TABLE 3-7 Documentation Updates
Subject Change
Active Directory and
LDAP/SSL
Power Consumption
Monitoring Limitation
XSCF Unit/Firmware
Updates
Not yet added. See “Active Directory and LDAP/SSL” on page 2 of these
Product Notes.
Added in the 1090 update of this document:
In the following cases, inaccurate power consumption values might be shown in
the MIB, in the showenvironment power command output, and on the XSCF
Web:
• During or for a short time after server power-on or power-off.
• During or for a short time after active replacement of a power supply unit.
To ensure the values are accurate, wait one minute, then check the values again.
Not yet changed in Chapter 8.1.10:
Replace steps 2 and 3 in these sections:
• Confirming That the XSCF Firmware is Updated When the XSCF Unit is
Replaced (in a System with a Single XSCF Unit or Both Replacement in a
System with Redundant XSCF Units
• Confirming That the XSCF Firmware is Updated When the MBU is Replaced
(in the M3000 Server)
The replacement steps are:
2. If the replacement unit and the replaced unit have different versions, a
message is displayed. In this case, the firmware is not updated automatically. The
operator must match the number of the firmware versions.
3. When you update, follow the procedure in "Updating XCP From External
Media" or "Updating XCP from the Network." After updating, confirm the
version.
28 Sun SPARC Enterprise M3000 Server Product Notes for XCP 1092 • May 2010
Loading...
