Sunny SF-B2721 User Manual

COMFORT XL FOLDING

RECUMBENT BIKE

SF-B2721

USER MANUAL

IMPORTANT! Read all instructions carefully before using this product. Retain owner’s

manual for future reference. For customer service, please contact:

[e-mail]

1

IMPORTANT SAFETY INFORMATION

We thank you for choosing our product. To ensure your safety and health, please use this

equipment correctly. It is important to read this entire manual before asse mb ling and using the

equipment. Safe and effective use can only be achieved if the equipment is assembled, maintained

and used properly. It is your responsibility to ensure that all users of the equipment are informed of

all warnings and precautions.

1. Before starting any exercise program you should consult your physician to determine if you have

any medical or physical conditions that could put your health and safety at risk, or prevent you
from using the equipment properly. Your physician’s advice is essential if you are taking
medication that affects your heart rate, blood pressure or cholesterol level.

2. Be aware of your body’s signals. Incorrect or excessive exercise can damage your health. Stop

exercising if you experience any of the following symptoms: pain, tightness in your chest, irregular
heartbeat, shortness of breath, lightheadedness, dizziness or feelings of nausea. If you do
experience any of these conditions, you should consult your physician before continuing with your
exercise program.

3. Keep children and pets away from the equipment. The equipment is d esigned fo r adult use only.

4. Use the equipment on a solid, flat level surface with a protective cover for your floor or carpet. To

ensure safety, the equipment should have at least 2 feet (60 CM) of f re e space all around it.

5. Ensure that all nuts and bolts are securely tightened before using the equipment. The safety of the

equipment can only be maintained if it is regularly examined for dama ge and/or wear and tear.

6. Always use the equipment as indicated. If you find any defective components while assembling or

checking the equipment, or if you hear any unusual noises coming from the equipment during
exercise, discontinue use of the equipment immediately and do not u se until the problem has
been rectified.

7. Wear suitable clothing while using the equipment. Avoid wearing loose clothing that may become

entangled in the equipment.

8. Do not place fingers or objects into the moving parts of the equipment

9. The maximum weight capacity of this unit is 300 pounds (136 KG).

10.The equipment is not suitable for therapeutic use.

11.Use caution when lifting and moving the equipment. Always use proper liftin g technique and seek

assistance if necessary.

12.Your product is intended for use in cool, dry conditions. You should avoid storage in extreme cold,

hot or damp areas as this may lead to corrosion and other re lated problems.

13.This e quipme nt is designed for indoor and home use only! It is not intended for commercial use!

WARNING: This product can expose you to one or more chemicals known to th e State of

California to cause cancer and birth defects or reproductive harm. For more inf ormation

go to www.P65Warnings.ca.gov.

2

EXPLODED DIAGRAM

3

PARTS LIST

NO. Description Spec. QTY NO. Description Spec. QTY

1 Meter 1 33 Cap 1

2 Handle Bar 1 34 Tube 1

3 Sponge 2 35 Bushing 1

4 Bolt M5 2 36 Label 1

5 Bolt M8 2 37 Tube 1

6 Bolt M4 2 38 Sleeve 2

7 Pulse 2 39 Sensor 1

8 Washer M8 6 40 Bolt M8 4

9 Tension 1 41 Plastic Washer 1

10 W asher 1 42 Bolt M4 8

11 Screw M5 1 43 Rod 1

12 Seat 1 44 Bushing 6

13 Seat Tube 1 45 Bolt M8 1

14 Bushing 1 46 Cover-R 1

15 W asher 7 47 Front Cover 1

16 Bolt M8 7 48 Cover-L 1

17 Back Pad 1 49 Seat Connect Tube 1

18 Cap 1 50 Wire 1

19 Bolt M8 3 51 Cap Nut 4

20 Bolt M5 2 52

Rear End Cap 2

21 Cup Holder 1 53 Main Frame 1

22 Back Pad Tube 1 54 Spacer 1

23 Bolt M8 2 55 Cap 2

24 W asher 2 56 Nut M10 2

25 Nut M8 4 57L/R Crank-L&R 2

26 Sponge 2 58L/R Pedal-L&R 2

27 Seat Handle Bar 1 59 Bolt M6 11

28 Cap 2 60 Mounting Plate 2

29

Handlebar Bracket

1 61 Reed 6

30 Bolt M8 2 62 Bearing 6003 2

31 Cap 2 63 Bearing Seat 2

32 Pop-Pin Knob 2 64 Pulley 1
