CHAPTER

1

Introduction to DR

Dynamic Reconfiguration (DR) enables you to logically attach and detach system
boards to and from the operating system without causing machine downtime. DR is
used in conjunction with hot swap, which is the process of physically removing or
inserting a system board. You can use DR to add a new system board, reinstall a
repaired system board, or modify the domain configuration on the Sun Enterprise
10000 system.

If a system board is being used by the operating system, you must detach it before
you can power it off and remove it. After a new or upgraded system board is
inserted and powered on, you may attach it to the operating system.

You can execute DR operations through the Hostview GUI (see hostview(1M))or
through the dr(1M) shell application. DR supports the following operations:

■ DR Attach – Logically attaches a system board to the operating system running in

a domain. A system board is logically attached when its resources—processors,
memory, and I/O adapters—are configured into a domain and are available to
the Solaris operating system. The system board must already be present in the
system, powered on, and not be a member of a domain. Normally, you attach a
system board after it is inserted and powered on by your service provider or after
it is detached from another domain.

■ DR Detach – Logically detaches a system board from the operating system. A

system board is logically detached when its resources—processors, memory, and
I/O adapters—are removed from the domain configuration and are no longer
available to the domain. Normally, you detach a system board to either move it to
another domain or prepare it for removal.

While DR operations are being performed within a domain, dr_daemon(1M) (see
the Solaris Reference Manual for SMCC-Specific Software) and the operating system
write messages regarding the status or exceptions to the domains’ syslog message
buffer ( /var/adm/messages) and the SSP message files (
messages and
information displayed by Hostview and the dr(1M) shell application, the
dr_daemon(1M) and operating system messages are useful for determining the
status of DR requests.

$SSPOPT/adm/messages). In addition to the status and exception

$SSPOPT/adm/host/

1

Note – Only one DR operation per platform can be active at any time. A DR

operation that is partially completed and then dismissed within one domain does
not prevent a subsequent DR operation from being started in a different domain. A
partially completed DR operation must be finished before a subsequent DR
operation is permitted in the same domain.

2 Sun Enterprise 10000 Dynamic Reconfiguration User’s Guide • May 1998

CHAPTER

2

DR Configuration Issues

This chapter describes how to configure a domain for all DR operations and
capabilities. The DR features are enabled only when the OpenBoot™ PROM (OBP)
environment variable dr-max-mem is set to a non-zero value. The sections in this
chapter include more information about dr-max-mem.

Note – DR features are disabled on domains that have less than 512-Mbytes of

memory.

Caution – Be careful when choosing the slot into which a board is inserted to

prevent disk controller renumbering. For more information, see “Reconfiguration
After a DR Operation” on page 9.

Memory: dr-max-mem

The value for dr-max-mem depends on the version of the Solaris operating
environment (2.5.1, 2.6, or higher) that is running in the domain. This section
includes information on both versions.

dr-max-mem With Solaris 2.6

With Solaris 2.6 or higher, the memory-related data structures are dynamically
allocated during the DR Attach operation. They are also dynamically removed
during the DR Detach operation; therefore, dr-max-mem with Solaris 2.6 becomes an
on/off switch. With dr-max-mem set to zero, DR operations are disabled. This is
true no matter which version of Solaris is running in the domain.

3

dr-max-mem With Solaris 2.5.1

The kernel has a number of memory-related data structures such as page structures,
which are statically allocated at boot time and are based on the amount of physical
memory in the domain at that time. Use DR Attach to dynamically add a board and
its physical memory after the domain is booted. This extra memory can be
supported by the kernel only if enough memory data structures are allocated at boot
time to support it. These structures cannot be added dynamically after boot time.

To reserve enough memory data structures to support DR Attach operations, each
domain supports the OBP environment variable, dr-max-mem, which the kernel
reads at boot time. dr-max-mem specifies the maximum number of megabytes to
which the domain can grow without requiring a reboot. Each domain has its own
unique copy of dr-max-mem.

▼ To Set dr-max-mem With Solaris 2.5.1

1. Calculate the optimum value for dr-max-mem by combining the amount of
memory most likely to be added during all DR Attaches and the current amount
of memory present in the domain and setting dr-max-mem to the total.

Note that if dr-max-mem is too large relative to the memory in the domain, its size
can impact the performance of the operating system. Therefore, the operating system
limits the maximum value of dr-max-mem at boot time, as follows:

TABLE2-1 dr-max-mem Maximum Values

Current Physical
Memory

256-Mbytes 0
512-Mbytes 16-Gbytes
1024-Mbytes 32-Gbytes
2048-Mbytes 64-Gbytes

dr-max-mem

Maximum Value

If the value of dr-max-mem is smaller than the amount of physical memory present
when the domain is booted, the operating system sets its working copy of dr-max-
mem to the current memory size. You cannot attach more memory, but you can
detach, then re-attach memory. The maximum amount of memory you can re-attach
in this manner is the amount present when the domain was booted. Note that the
OBP variable dr-max-mem is not modified in this situation.

Caution – Set dr-max-mem high enough so that all anticipated new memory can be

dynamically attached, but no higher. If you set it too low and later attach a board
whose memory combined with domain memory exceeds the value of dr-max-mem,

4 Sun Enterprise 10000 Dynamic Reconfiguration User’s Guide • May 1998

the memory on that board will not be attached. If you set the value of dr-max-mem
too high, you over-allocate data structures, which can waste available memory and
adversely affect system performance. If you set it to zero, the DR functions are
disabled.

dr-max-mem must be set before the domain is booted.

2. Set the dr-max-mem environment variable by bringing up the OBP prompt for the
domain and typing the following command:

ok# setenv-dr dr-max-mem

NNN

where NNN is the number of megabytes of memory to be supported by the domain
after the boards are attached. The value of dr-max-mem persists across domain
reboots, and is only applicable to that particular domain. This value will apply to all
boot environments for the domain.

Note – Once you have set the dr-max-mem value for a domain, that value remains

the same no matter which Solaris boot disk you select.

If the dr-max-mem variable is non-zero, the following messages are displayed at
boot time in the domain’s syslog message buffer (/var/adm/messages):

DR: current memory size is
DR: capacity to allow an additional

XXX

MBytes

YYY

MBytes of memory

In this message, XXX represents the amount of physical memory available to the
operating system and is effectively the same as the operating system variable,
physinstalled. YYY is the difference between dr-max-mem and XXX.

When a board with memory is successfully attached or detached, another message is
displayed:

DR: capacity to allow an additional

ZZZ

MBytes of memory

In this message, ZZZ represents the updated amount of memory that can still be
attached.

Chapter 2 DR Configuration Issues 5

Configuration for DR Detach

This section describes how to configure DR before you perform a detach operation.

Note – The DR Detach feature requires that the OBP variable dr-max-mem is set to

a non-zero value. This setting is required at the time the domain is booted.

I/O Devices

The DR Detach feature relies on the Alternate Pathing (AP) feature or Solstice™
DiskSuite™ mirroring when used to detach a board that hosts I/O controllers that
are attached to vital system resources. Currently, AP and Solstice DiskSuite do not
work together; however, AP does work with Veritas Volume Manager. If, for
example, the root or /usr partition is on a disk attached to a controller on the board,
the board cannot be detached unless there is a hardware alternate path to the disk—
and AP has been configured to take advantage of it—or the disk is mirrored. The
alternate path or the mirrors must be hosted by other boards in the system. The
same applies to network controllers. The board that hosts the Ethernet controller that
connects the SSP to the Enterprise 10000 platform cannot be detached unless an
alternate path exists to an Ethernet controller on another board for this network
connection.

The domain swap space should be configured as multiple partitions on disks
attached to controllers hosted by different boards. With this kind of configuration, a
particular swap partition is not a vital resource because swap partitions can be
added and deleted dynamically (see swap(1M) for more information).

Note – When memory (swapfs) or disk swap space is detached, there must be

enough memory or swap disk space remaining in the domain to accommodate
currently running programs.

A board that is hosting non-vital system resources can be detached whether or not
there are alternate paths to the resources. All of the board's devices must be closed
before the board can be detached; all of its file systems must be unmounted; and, its
swap partitions must be deleted. You may have to kill processes that have open files
or devices, or place a hard lock on the file systems (using lockfs(1M)) before you
unmount the boards. There is a domain disruption penalty associated with the
detach operation.

6 Sun Enterprise 10000 Dynamic Reconfiguration User’s Guide • May 1998

All I/O device drivers involved with I/O devices on the board(s) must support the
DDI_DETACH option in the driver detach entry point. This option releases all system
resources associated with that device or adapter.

Memory

If you use memory interleaving between system boards, those system boards cannot
be detached because DR does not yet support interboard interleaving. By default,
hpost(1M) does not set up boards with interleaved memory. Look for the following
line in the hpost(1M) file .postrc (see postrc(4)):

mem_board_interleave_ok

If mem_board_interleave_ok is present, you may not be able to detach a board
that contains memory.

Pageable and Nonpageable Memory

Before you can detach a board, the operating system must vacate the memory on
that board. Vacating a board means flushing its pageable memory to swap space and
copying its permanent memor y (that is, nonpageable kernel and OBP memory) to
another memory board. To relocate nonpageable memory, the operating system on a
domain must be temporarily suspended, or quiesced. The length of the suspension
depends on the domain I/O configuration and the current running workload.
Detaching a board with nonpageable memory is the only time when the operating
system is suspended; therefore, you should know where nonpageable memory
resides, so you can avoid significantly impacting the domain’s operation. When
permanent memory is on the board, the operating system must find other memory
to receive the copy.

You can use the dr(1M) command drshow(1M) to determine if a board’s memory is
pageable or nonpageable:

% dr
dr> drshow board_number mem

Similarly, you can determine if a board’s memory is pageable by looking at the DR
Memory Configuration window, which is available when you perform a detach
operation within Hostview. The DR Memory Configuration window is described in
“Viewing Domain Information” on page 41.

Chapter 2 DR Configuration Issues 7

The kernal and OBP load into the lowest physical address space, which generally is
on the lowest numbered system board in the domain. Exceptions to this rule do
exist, so you should always use the drshow(1M) command to check the board’s
memory.

Target Memory Constraints

When permanent memory is detached, DR chooses a target memory area to receive
a copy of the memory. The DR software automatically checks for total adherence. It
does not allow the DR memory operation to continue if it cannot verify total
adherence. A DR memory operation might be disallowed because of the following
reasons:

■ The domain is not large enough to hold a copy of the nonpageable memory.

■ The domain is interleaved with memory on other boards.

If no target board is found, the detach operation is refused, and DR displays a
warning message on the system console:

Jul 28 06:00:00 unix: WARNING:dr_build_adg_detach_list:no target
memory board found

Correctable Memory Errors

Correctable memory errors (CEs) indicate that a system board’s memory (that is, one
or more of its Dual Inline Memory Modules, or DIMMs, or portions of the hardware
interconnect) may be faulty and need replacement. When the SSP detects correctable
memory errors, it initiates a record-stop dump to save the diagnostic data, which can
interfere with a DR detach operation. Therefore, Sun Microsystems suggests that
when a record-stop occurs from a correctable memory error, you allow the record­stop dump to complete its process before you initiate a DR detach operation.

If the faulty component causes repeated reporting of correctable memory errors, the
SSP performs multiple record-stop dumps. If this happens, you should temporarily
disable the dump-detection mechanism on the SSP, allow the current dump to finish,
then initiate the DR detach operation. After the detach operation finishes, you
should re-enable the dump detection by performing the following steps:

1. Log in to the SSP as the ssp user.

2. Disable record-stop dump detection:

SSP% edd_cmd -x stop

8 Sun Enterprise 10000 Dynamic Reconfiguration User’s Guide • May 1998

This command suspends all event detection on all of the domains.

3. Monitor the in-progress record-stop dump:

SSP% ps -ef | grep hpost

In the grep output, the -D option of hpost indicates that a record-stop dump is
in progress.

4. Perform the DR detach operation.

5. Enable event detection:

SSP% edd_cmd -x start

Swap Space

The domain swap configuration consists of the swap devices and swapfs (memory).
The domain must contain enough swap space so that it can flush pageable memory.
For example, if you want to remove 1-Gbyte of memory from a 2-Gbyte domain, you
will need 1-Gbyte of swap space, depending on the load. Insufficient swap space
prevents DR from completing the detach of a board that contains memory. If this
happens, the memory drain phase does not complete, so you must abort the detach
operation.

Reconfiguration After a DR Operation

This section describes how to reconfigure your domain after you have attached or
detached a system board.

The DR user interface enables you reconfigure the domain after a DR Attach or DR
Detach operation. The reconfiguration sequence is the same as the reconfiguration
boot sequence (boot -r):

drvconfig; devlinks; disks; ports; tapes;

Chapter 2 DR Configuration Issues 9

When you execute the reconfiguration sequence after you attach a board, device
path names not previously seen by the domain are written to the
/etc/path_to_inst file. The same path names are also added to the /devices
hierarchy, and links to them are created in the /dev directory.

When to Reconfigure

You should reconfigure the domain if any of the following conditions occur:

■ Board Addition – When you add a board to a domain, you must execute the

reconfiguration sequence to configure the I/O devices that are associated with the
board.

■ Board Deletion – If you remove a board that is not to be replaced, you may, but do

not have to, execute the reconfiguration sequence to clean up the /dev links.

■ Board Replacement – If you remove a board then reinsert it in a different slot or if

you replace a board with another board that has different I/O devices, you must
execute the reconfiguration sequence to configure the I/O devices that are
associated with the board. However, if you replace a board with another board
that hosts the same set of I/O devices, inserting the replacement into the same slot,
you do not need to execute the reconfiguration sequence. But, be sure to insert a
replacement board into the same slot that was vacated to retain the original /dev
link names.

10 Sun Enterprise 10000 Dynamic Reconfiguration User’s Guide • May 1998

Disk Devices

Disk controllers are numbered consecutively as the disks(1M) program encounters
them. All disk partitions are assigned /dev names according to the disk controller
number that disks(1M) assigns. For example, all disk partitions that are accessible
using disk controller 1 are named /dev/dsk/c1t

where:
c1 is the disk controller number

L, in most cases, corresponds to the disk target number
M corresponds to the logical unit number, and
N corresponds to the partition number.

When the reconfiguration sequence is executed after a board is detached, the /dev
links for all of the disk partitions on that board are deleted. The remaining boards
retain their current numbering. Disk controllers on a newly inserted board are
assigned the next available lowest number by disks(1M).

For example, suppose the system has four system boards numbered 0 to 3, and you
detach boards 1 and 2, which are then removed from the system. Your service
provider repairs board 2 and reinserts it, and you attach it. If you now execute
disks(1M), controller numbers from board 1 are reassigned to controllers on board
2 if the old board 1 controller numbers are the next available lowest numbers.

L

dMsN

Note – The disk controller number is part of the /dev link name used to access the

disk. If that number changes during the reconfiguration sequence, the /dev link
name also changes. This change may affect file system tables and software, such as
Solstice DiskSuite, which use the /dev link names. Update /etc/vfstab files and
execute other administrative actions to change the /dev link names.

DR and AP Interaction

Note – Alternate Pathing (AP) is not supported in Solaris 2.6 Hardware: 3/98.

DR notifies the AP subsystem when system boards are attached, detached, or placed
in the drain state. In addition, DR queries AP about which controllers are in the AP
database and their status (active or inactive). This communication occurs between
the dr_daemon(1M) and ap_daemon(1M). If the ap_daemon(1M) is not present,

Chapter 2 DR Configuration Issues 11

an error message is placed in the domains’ syslog messages buffer and DR
operations continue without error. To disable this interaction, use the -a option
when you invoke dr_daemon(1M). See the dr_daemon(1M) man page in the Solaris
Reference Manual for SMCC-Specific Software.

If you are using AP version 2.1, the operating system automatically switches off the
active disk controllers on outgoing boards during the complete-detach phase of DR.
If you are using AP version 2.0, you need to manually switch off the active disk
controllers before you start the complete-detach phase. For Solaris 2.6, you must
upgrade to AP version 2.1. For more information about DR and AP interaction, see
the Solaris 2.6 Hardware 3 Beta on Sun Enterprise Servers AnswerBook.

RPC Time-Out or Loss of Connection

The dr_daemon(1M), which runs in each domain, communicates with Hostview
and the dr(1M) shell application (both of which run on the SSP) by way of Remote
Procedure Calls (RPCs). If an RPC time-out or connection failure is reported during
a DR operation, check the domain. The daemon must be configured in the domain’s
/etc/inetd.conf file. The following line (which appears on a single line) must be
present in the file:

300326/4 tli rpc/tcp wait root /usr/platform/sun4u1/ sbin/
dr_daemon dr_daemon

If the DR daemon is configured in /etc/inetd.conf, kill the dr_daemon(1M) if it
is currently running. In addition, send a HUP signal to the inetd(1M) daemon to
cause it to re-read the inetd.conf(4) configuration file:

# kill dr_daemon_pid
# kill -HUP inetd_pid

In the first command,
second command,
check /var/adm/messages for possible error messages from inetd(1M)if it's
having trouble starting the dr_daemon(1M). The DR daemon executable file should
exist in the /usr/platform/sun4u1/sbin/dr_daemon directory.

At this point you should try the DR operation again, starting from the beginning.

12 Sun Enterprise 10000 Dynamic Reconfiguration User’s Guide • May 1998

dr_daemon_pid

inetd_pid

is the process ID of the DR daemon. In the

is the process ID of the inetd(1M)daemon. You can

System Quiescence Operation

During a DR Detach operation on a system board with nonpageable OBP or kernel
memory, the operating system is briefly quiesced; that is, all operating system and
device activity on the domain centerplane must cease during the critical phase of the
operation. The quiescence only affects the target domain; other domains in the
system are not affected.

Before it can quiesce, the operating system must temporarily suspend all processes,
processors, and device activities. If the operating system cannot quiesce, it displays
its reasons, which may include the following:

■ Real-time processes are running in the domain.

■ A device that cannot be quiesced by the operating system (that is, a

suspend-unsafe device) is open.

The conditions that cause processes not to suspend are generally temporary in
nature. You can retry the operation until the quiescence succeeds.

A quiescent failure due to real-time processes or open suspend-unsafe devices is
known as a forcible condition. You have the option of performing either a retry or
forced retry. When you force the quiesce, you give the operating system permission
to continue with the quiescence even if forcible conditions are still present.

Caution – Exercise care when using the force option.

If a real-time process is running, determine if suspending the process would produce
an adverse effect on the functions performed by the process. If not, you can force the
operating system to quiesce. (To force a quiescence, you can either click the Force
button within Hostview as described in “To Detach a Board With Hostview” on
page 35, or enter the complete_detach command with the force option within
the dr(1M) shell application. Otherwise, you can abort the operation and try again
later.

If any suspend-unsafe device is open and cannot be closed, you can manually
suspend the device, and then force the operating system to quiesce. After the
operating system resumes, you can manually resume the device (see “Suspend-Safe/
Suspend-Unsafe Devices” on page 14).

If the operating system fails to quiesce, pay close attention to the reasons for the
failure. If the operating system encountered a transient condition—a failure to
suspend a process—you can try the operation again. If, however, the condition(s)
requires your approval (for example, a real-time process is running) or intervention
(for example, a suspend-unsafe device is open), you can force the operating system
to quiesce.

Chapter 2 DR Configuration Issues 13

Suspend-Safe/Suspend-Unsafe Devices

A suspend-safe device is one that does not access the domain centerplane (for
example, it does not access memory or interrupt the system) while the operating
system is quiesced. A driver is considered suspend-safe if it supports operating
system quiescence (suspend/resume) and guarantees that when a suspend request is
successfully completed, the device that the driver manages will not attempt to access
the domain centerplane, even if the device is open when the suspend request is
made. All other I/O devices are suspend-unsafe when open.

Note – At the time of this printing, the drivers released by Sun Microsystems that

are known to be suspend-safe are sd, isp, esp, fas, sbus, pci, pei-pci, qfe, hme
(SunFastEthernet™), nf (NPI-FDDI), qe (Quad Ethernet), le (Lance Ethernet), the
SSA drivers (soc, pln, and ssd), and the Photon drivers (sf, socal, ses). The
known suspend-unsafe driver is the tape-related driver (st). This list will change
over time. To add a driver to this list, see “Adding Suspend-Safe Devices” on
page 17.

The operating system refuses a quiesce request if a suspend-unsafe device is open. If
you can manually suspend the device, you can force the operating system to quiesce.
To manually suspend the device, you may have to close the device by killing the
processes that have it open, ask users not to use the device, or disconnect the cables.
For example, if a device that allows asynchronous unsolicited input is open, you can
disconnect its cables prior to quiescing the operating system, preventing traffic from
arriving at the device and the device from accessing the domain centerplane. You
can reconnect the cables after the operating system resumes. If you cannot make a
device suspend its accesses to the domain centerplane, you should not force the
operating system to quiesce. Doing so could cause a domain to crash or hang.
Instead, postpone the DR operation until the suspend-unsafe device is no longer
open.

Caution – If you attempt a forced quiesce operation while activity is occurring on a

suspend-unsafe device, the domain may hang. However, if the domain hangs, it will
not affect other domains that are running on the Enterprise 10000 system.

Special Handling for Tape Devices

Athough all tape devices are suspend-unsafe, all SCSI tape devices that are natively
supported by Sun Microsystems are detach-safe (see st(7D) for a list of natively­supported drives). If a system board that you are detaching contains a natively­supported tape device and if the tape device is not in use, then you can detach the
board. If you want to use a tape device that is not natively supported by Sun, you

14 Sun Enterprise 10000 Dynamic Reconfiguration User’s Guide • May 1998

can use it, but you should make it detach-safe. To ensure correct input/output and
DR operations, you need to make a suitable entry in /kernel/drv/st.conf with
the ST_UNLOADABLE (0x0400) flag set in the entry (see st(7D) for more
information). After you update st.conf, you must reboot the domain to process the
new entry.

The sequential nature of tape devices prevents them from being reliably suspended
in the middle of an operation, and then resumed. Therefore, all tape drivers are
suspend-unsafe and cannot be quiesced. Before you execute a DR operation that
quiesces the operating system, make sure that all of the tape devices in the domain
are closed or are not in use. If a tape device is detected in the domain, you can either
force the quiescent operation, or you can unload the st(7D) driver by using the
modunload(1M) command prior to the quiescent operation.

Special Handling of Sun™ StorEdge™ A3000

The Sun StorEdge A3000 (formerly known as the RSM 2000) has dual controller
paths with automatic load balancing and automatic failover. To detach a system
board that has one or both of the StorEdge A3000’s controllers, the controllers on the
board that being detached must be idle or offline. You can take these controllers
offline manually by using the rm6 or rdacutil programs before you attempt to
detach the system board.

DR and DDI

Not all drivers support the Enterprise 10000 system’s Dynamic Reconfiguration (DR)
features. To support DR, a driver must be able to perform two basic DDI/DKI
(Device Driver Interface/Device Kernel Interface) functions, DDI_DETACH and
DDI_SUSPEND/DDI_RESUME. These two functions impact DR in different ways.

DR and DDI_DETACH

You can detach a system board that hosts a device only if the driver for that device
supports the DDI_DETACH interface, or is not currently loaded. DDI_DETACH
provides the ability to detach a particular instance of a driver without impacting
other instances that are servicing other devices. A driver that supports DDI_DETACH
is called detach-safe; a driver that does not support DDI_DETACH is called detach-
unsafe (see “DR Detach-Safe Devices” on page 19).

Detaching a detach-unsafe driver that is loaded involves the following process.

Chapter 2 DR Configuration Issues 15

■ Stopping all usage of the controller for the detach-unsafe device and all other

controllers of the same type on all of the boards in the domain.
Since the detach-unsafe driver must be unloaded, you must stop use of that

controller type on all of the system boards in the domain. The remaining
controllers can be used again after the DR Detach is complete.

■ Using standard Solaris interfaces to manually close and to unload all such drivers

on the board.
See modload(1M) in the SunOS Reference Manual.

■ Detaching the system board in the normal fashion.

If you cannot accomplish the above process, you can reboot your domain with the
board blacklisted (see blacklist(4)), so the board can be removed later.

Note – Many third-party drivers (those purchased from vendors other than Sun

Microsystems) do not support the standard Solaris modunload interface. Conditions
that invoke the functions occur infrequently during normal operation and the
functions are sometimes missing or work improperly. Sun Microsystems suggests
that you test these driver functions during the qualification and installation phases
of any third-party device.

DR and DDI_SUSPEND/DDI_RESUME

To perform a DR Detach of a board that contains nonpageable OBP or kernel
memory, the domain must be quiesced. Memory can be detached only when all of
the drivers throughout the entire domain (not just on the board being detached)
either support the DDI_SUSPEND/DDI_RESUME driver interface, or are closed.
Drivers that support these DDI functions are called suspend-safe; drivers that do not
are called suspend-unsafe (see “Adding Suspend-Safe Devices” on page 17). Note that
a quiesce is required only when detaching a board that contains nonpageable
memory.

The most straightforward way to quiesce a domain is to close any suspend-unsafe
devices. For each network driver you must execute the ifconfig(1M) command
with its down parameter, then again with its unplumb parameter (see
ifconfig(1M) for more information).

Note – It should be possible to unplumb all network drivers. However, this action is

rarely tested in normal environments and may result in driver error conditions. If
you use DR, Sun Microsystems suggests that you test these driver functions during
the qualification and installation phases of any suspend-unsafe device.

16 Sun Enterprise 10000 Dynamic Reconfiguration User’s Guide • May 1998

If the system refuses to quiesce because a suspend-unsafe driver is open, you can force
the operating domain to quiesce. Doing so forces the operating system to permit the
detach. Note that, although a detach can be forced to proceed when there are open

suspend-unsafe devices in the system, it is not possible to force a detach when a
detach-unsafe device resides on the board and its driver is loaded.

To successfully force the operating system to quiesce, you must manually quiesce
the controller. Procedures to do that, if any, are device-specific. The device must not
transfer any data, reference memory, or generate interrupts during the operation. Be
sure to test any procedures used to quiesce the controller while it is open prior to
executing them on a production system.

Caution – Using the force option to quiesce the operating system, without first

successfully quiescing the controller, can result in a domain failure and subsequent
reboot.

Adding Suspend-Safe Devices

Before each Enterprise 10000 system is shipped, Sun Microsystems configures the
DR driver (dr) to recognize those devices that support DDI_SUSPEND/DDI_RESUME;
that is, the devices that can be safely quiesced. The Note in “Suspend-Safe/Suspend­Unsafe Devices” on page 14 lists the known suspend-safe and suspend-unsafe
devices at the time this guide was produced.

If you want to add a device to your system and the device and its driver support
DDI_SUSPEND/DDI_RESUME, configure the DR driver to recognize the device as
suspend-safe by placing an entry in the /etc/system file. This file enables you to
append the list already maintained in the operating system. No harm results from a
device being listed multiple times. If you are not sure whether a device supports
DDI_SUSPEND/DDI_RESUME, ask your service provider or the manufacturer of the
device.

If a listed device is open when a quiescence is requested, the device is suspended
and resumed prior to the quiescence. Tape devices are not suspend-safe; do not
append such devices to the suspend-safe list in the /etc/system file.

Note – In an earlier release, the suspend-safe list was called the dr_safe list.

You can use the old name, but when the
messages are displayed:

NOTICE:
NOTICE: dr: next time use new style (suspend_safe_listx)

dr: using old style safe/bypass list (dr_safe_listx)

dr module is first loaded, the following

Chapter 2 DR Configuration Issues 17

You can add new devices that support quiescing to the /etc/system file with the
following format, where device names represent device driver module names:

set hswp:suspend_safe_list1=”device1 device2 . . . devicen”
set hswp:suspend_safe_list2=”device1 device2 . . . devicen”
set hswp:suspend_safe_list3=”device1 device2 . . . devicen”
set hswp:suspend_safe_list4=”device1 device2 . . . devicen”
set hswp:suspend_safe_list5=”device1 device2 . . . devicen”

Note – The /etc/system file can contain up to five suspend-safe strings, each no

more than 128 characters long.

You should add devices to the suspend-bypass list only if they do not perform I/O
operations and do not support DDI_SUSPEND/DDI_RESUME.

Adding Suspend-Bypass Devices

The Enterprise 10000 system has a preset list of devices that it ignores during the
quiescent process, making no attempt to quiesce them. These devices, which include
pseudo devices, do not perform I/O operations and do not need to be suspended
during the quiesce.

Caution – Do not add suspend-unsafe devices to the suspend-bypass list.

You can add devices to the /etc/system file which do not support quiescing, but
which can be safely ignored during the quiesce process. Do so in the following
format, where device names represent device-driver module names:

set hswp:suspend_bypass_list1=”device1 device2 . . . devicen”
set hswp:suspend_bypass_list2=”device1 device2 . . . devicen”
set hswp:suspend_bypass_list3=”device1 device2 . . . devicen”
set hswp:suspend_bypass_list4=”device1 device2 . . . devicen”
set hswp:suspend_bypass_list5=”device1 device2 . . . devicen”

Note – The /etc/system file can contain up to five suspend-bypass strings, each

no more than 128 characters long.

18 Sun Enterprise 10000 Dynamic Reconfiguration User’s Guide • May 1998

DR Detach-Safe Devices

Before each Enterprise 10000 system is shipped, DR is configured to recognize those
devices that can be safely detached. A driver is safe for detaching if it fully supports
the DDI/DKI DDI_DETACH function in the driver’s detach entry point. Normally,
such DR-capable drivers must also support DDI_SUSPEND and DDI_RESUME,as
described in “DR and DDI_SUSPEND/DDI_RESUME” on page 16. However, some
exceptions do exist, such as tape devices that can be detach-safe while they are
inherently suspend-unsafe.

If you want to add a device to your system and the device and its driver can be
safely detached, be sure to add the device name to the detach-safe list in the
/etc/system file. This file appends the list already maintained in the system. No
harm results when a device is listed multiple times. If you are not sure whether a
device can be safely detached, ask your service provider.

If a DR Detach operation fails because the board hosts a device that is not included
in the detach-safe list and if the corresponding driver is loaded, the system displays
a message similar to the following:

WARNING: DR: driver (

where xxx is the name of the driver module as it would reside under /kernel/drv
and named in /etc/name_to_major.

You can add new devices that support DR Detach to the /etc/system file with the
following format, where device names represent device driver module names:

set dr:detach_safe_list1=”device1 device2 . . . devicen”
set dr:detach_safe_list2=”device1 device2 . . . devicen”
set dr:detach_safe_list3=”device1 device2 . . . devicen”
set dr:detach_safe_list4=”device1 device2 . . . devicen”
set dr:detach_safe_list5=”device1 device2 . . . devicen”

xxx

) not known to support DDI_DETACH

Note – The /etc/system file can contain up to five detach-safe strings, each no

more than 128 characters long.

Chapter 2 DR Configuration Issues 19

20 Sun Enterprise 10000 Dynamic Reconfiguration User’s Guide • May 1998

CHAPTER

3

Using Dynamic Reconfiguration

Attaching a System Board

Note – This section gives a broad overview of the actions that occur when you

execute DR Attach. For step-by-step instructions, see “To Attach a Board With
Hostview” on page 23.

You can attach system boards that are present in the machine, powered on, and not
part of an active domain (that is, not being used by an operating system). These
unattached boards may have been hot-swapped into the system after the system was
booted, blacklisted when the system was booted, or detached from another domain.

Note – If the system board has been hot-swapped into the system, you should run

the thermcal_config(1M) command immediately after the board has been
powered on.

Prior to attaching a board, diagnostics are run on the board, requiring that at least
one processor be present on the board and not be blacklisted. After you’ve selected
an eligible board and a target domain, the DR Attach operation proceeds through
two operations: Init Attach and Complete Attach.

Init Attach

During the Init Attach phase, DR diagnoses and configures the selected board,
preparing it and its devices for attachment to the operating system. During this
phase, DR performs the following tasks:

21

■ Adds the board to the target domain’s board list in the domain_config(4) file

on the SSP.

■ Runs hpost -H on the board to configure it. hpost isolates the board on the

Enterprise 10000 system centerplane by placing it into a single-board hardware
domain (see hpost(1M)).

■ Runs obp_helper -H which loads download_helper to the board, and takes

the processors on the board out of reset mode, allowing them to spin in
download_helper.

■ Reconfigures the centerplane and board domain mask registers, placing the board

in the target hardware domain.

DR displays the output of these hpost(1M)and obp_helper(1M) operations,
including the steps that succeeded and those that caused exceptions.

If hpost(1M) and obp_helper(1M) succeed, the operating system is notified and
requests OBP to probe the board. The operating system then scans the OBP device
tree and adds the devices to its configuration, but the devices are not attached to the
system.

After the Init Attach phase is completed, the OBP board configuration can be
displayed to confirm which devices are present on the board. You can then enter the
Complete Attach phase or you can abort the operation.

If you abort the operation, DR removes the board configuration from the operating
system data structures and removes the board from the domain_config(4) file,
leaving the board in a state where it is not assigned to any domain. The board may
then be removed from the system by using hot swap, left in the system unattached,
or attached at a later time.

Complete Attach

During the Complete Attach phase, DR attempts to complete the attach operation by
making the resources that are hosted by the new system board available to the
operating system. If a problem occurs that prevents the attachment of any device on
the board, the dr_daemon(1M)(described in the Solaris Reference Manual for SMCC-
Specific Software) logs that problem in the system message buffer. To determine which
devices were successfully attached, display and check the domain configuration for
the board.

After a board is successfully attached, you have the option of reconfiguring the I/O
devices. See “Reconfiguration After a DR Operation” on page 9 for more
information. This operation can take several minutes to complete.

22 Sun Enterprise 10000 Dynamic Reconfiguration User’s Guide • May 1998

Attach Buttons

When you perform an attach operation using the Hostview GUI program (which
transparently calls a separate executable: drview(1M)) the following buttons
appear at various times during the attach process:

■ init attach – Begins the attach operation (see “Init Attach” on page 21). Once

the operation has completed successfully, the label on this button changes to
complete.

■ complete – Completes the attach operation (see “Complete Attach” on page 22).

■ reconfig – Automatically reconfigures the device directories in the domain. You

may want to run the reconfiguration operation after attaching a board (see
“Reconfiguration After a DR Operation” on page 9).

■ abort – Cancels the attach operation. This button is enabled after the Init Attach

operation has been successfully completed (see “Init Attach” on page 21).

■ dismiss – Terminates the step that is currently in progress, but leaves the board

in its current state (Present, Init Attach, In Use). You can remove the DR attach
window by choosing dismiss at any point during the attach operation. The
dismiss button terminates any work being done on the SSP for the attach
operation. For example, if hpost(1M) is running when you click dismiss, that
hpost(1M)process is terminated. Note that dismiss does not terminate work
being done on the host by way of RPCs to the dr_daemon(1M). Once an RPC is
initiated, the host completes the RPC regardless of whether the calling program is
waiting for the RPC to finish.

The host dr_daemon(1M) keeps track of the progress of the attach operation.
Once the Init Attach operation completes successfully, it remembers this state.
Therefore, you can dismiss the window, then return to the DR operation later and
complete or abort the attach.

■ help – Accesses online information regarding DR Attach operations.

▼ To Attach a Board With Hostview

Note – Before you perform the following steps, you should read “Attaching a

System Board” on page 21.

1. From Hostview, choose Configuration

The Attach—Board and Domain Selection window is displayed (

➤ Board ➤ Attach.

FIGURE 3-1).

Chapter 3 Using Dynamic Reconfiguration 23

attach - Board and Domain Selection

Select board in main window. Then click "Select".

Board

Domain

Select domain in main window. Then click "Select".

Target domain

dismiss helpexecute

FIGURE 3-1 Attach—Board and Domain Selection Window

select

select

2. Select the board that you want to attach in the main Hostview window (if that
board is not already selected).

3. Click the top Select button.

The Board and Source Domain fields are automatically filled in for you. (You can
also manually edit those fields.)

4. In the main Hostview window, select the domain to which you want to attach the board.

You can select any board that is currently a member of that domain.

5. Click the bottom Select button.

The Target Domain field is automatically filled in for you. (You can also manually
edit that field.)

6. Click the Execute button.

If any errors occur, the error messages appear in the main Hostview window.
Otherwise, the Dynamic Reconfiguration window is displayed with the init
attach button visible (

24 Sun Enterprise 10000 Dynamic Reconfiguration User’s Guide • May 1998

FIGURE 3-2).

Dynamic Reconfiguration

DR - Attach Board

Attaching Board: Target Domain: xf25
Information:

Checking environment . . .
Establishing Control Board Server connection . . .
Initializing SSP SNMP MIB . . .
Establishing communication with DR daemon . . .

xf2: System Status - Summary
BOARD # : 5 6 7 physically present.

BOARD # : 0 2 4 being used by the system.

System Information

cpu memory

device

obp

properties

allunsafe

init attach

abort

FIGURE 3-2 Dynamic Reconfiguration Window With init attach Button

dismiss

reconfig

help

7. Click the Init Attach button.

Clicking on the Init Attach button begins the first phase of the board attach process.
First, the system updates the SSP domain.config(4) file by adding the system
board to the target domain’s board list. Next, the system uses hpost(1M) to self-test
the system board. After the self-test is complete, the board is made visible to the
running target domain by merging it into the hardware domain via the centerplane
and the system board hardware register modification. Finally, during the conclusion
of the init attach, OBP probes the new board to discover what CPU, I/O, and
memory resources are present on the board. When this phase is finished, the caption
on the button changes to complete. Before you click the complete button,
however, you may want to view the domain information to verify that you want to
proceed, as described in “Viewing Domain Information” on page 41.

The Init Attach operation can take a few minutes to complete. Output from the
hpost(1M) commands is directed to the Information pane of the Dynamic
Reconfiguration window.

If the Init Attach fails, look for the cause in the output in the Information pane. Once
you have determined the cause, you may want to choose Init Attach again.

The window should now appear similar to that shown in

FIGURE 3-3, with the

complete button enabled.

8. Click the complete button.

Chapter 3 Using Dynamic Reconfiguration 25

Dynamic Reconfiguration

DR - Attach Board

Attaching Board: Target Domain: xf25

Information:

POST (level=16, verbose=20, -H0, 0020) execution time 2:52
hpost is complete.
obp_helper -H -m20
Board debut complete.
Reconfiguring domain mask registers.
Board attachment initiated successfully.

Ready to COMPLETE board attachment.

System Information

cpu memory

device

obp

properties

allunsafe

complete

abort

FIGURE 3-3 Dynamic Reconfiguration Window

dismiss

reconfig

help

The complete operation normally takes less than one minute to finish. When it has
successfully completed, DR displays the following message:

Board attachment completed successfully

9. The system board resources—processors, memory, and I/O devices—are now
available to the operating system.

You can view the domain information about the newly attached board by using the
buttons (CPU, Memory, Device, and so forth), as described in “Viewing Domain
Information” on page 41.

Caution – Before you choose the reconfig option, be sure to read

“Reconfiguration After a DR Operation” on page 9.

10. Click the dismiss button.

The DR Attach operation is complete.

26 Sun Enterprise 10000 Dynamic Reconfiguration User’s Guide • May 1998

▼ To Attach a Board By Using dr(1M)

Note – The following procedure explains how to attach a board by using dr(1M)

with SSP version 3.1, or higher. If you are using SSP version 3.0, refer to a previous
version of the Dynamic Reconfiguration User’s Guide.

Before you perform the following steps, read “Attaching a System Board” on
page 21. The process of attaching a board is very similar whether you use Hostview
or dr(1M). The basic concepts are not repeated in this section.

The dr(1M) shell was introduced in Chapter 1. A quick reference guide is available
in the dr(1M) application by using the help command.

1. Set SUNW_

HOSTNAME to the appropriate domain using the domain_switch(1M)

command.

% domain_switch xf3

2. Execute the dr(1M) command in an SSP Window to bring up the dr(1M) prompt.

In the following example, the target domain is called xf3.

% dr
Checking environment...
Establishing Control Board Server connection...
Initializing SSP SNMP MIB...
Establishing communication with DR daemon...

xf3: Domain Status - Summary

BOARD #: 0 1 2 5 6 8 9 10 11 13 physically present.
BOARD #: 4 7 being used by the domain.
dr>

Chapter 3 Using Dynamic Reconfiguration 27

3. Begin the init_attach(1M) operation for the designated board.

In this example, board 6 is being attached to xf3 domain.

dr> init_attach 6
Initiate attaching board 6 to domain xf3.
Adding board 6 to domain_config file.
/opt/SUNWssp/bin/hpost -H40,28
Opening SNMP server library...

Significant contents of /export/home/ssp/.postrc:
blacklist_file ./bf
redlist_file ./rf
Reading centerplane asics to obtain bus configuration...
Bus configuration established as 3F.
phase cplane_isolate: CP domain cluster mask clear...
...
phase final_config: Final configuration...
Configuring in 3F, FOM = 2048.00: 4 procs, 4 SCards, 1024 MBytes.
Creating OBP handoff structures...
Configured in 3F with 4 processors, 4 SBus cards, 1024 MBytes
memory.
Interconnect frequency is 83.294 MHz, from SNMP MIB.
Processor frequency is 166.631 MHz, from SNMP MIB.
Boot processor is 6.0 = 24
POST (level=16, verbose=20, -H28,0040) execution time 3:07
hpost is complete.
obp_helper -H -m24
Board debut complete.
Reconfiguring domain mask registers.
Board attachment initiated successfully.

Ready to COMPLETE board attachment.

4. Abort or complete the attach operation.

■ After the system successfully completes the init_attach(1M) operation, you

can use the drshow(1M) OBP display to see an inventory of the board resources.

dr> drshow board_number OBP

■ If you wish to abort the attach operation, execute the abort_attach(1M)

command.

dr> abort_attach board_number

28 Sun Enterprise 10000 Dynamic Reconfiguration User’s Guide • May 1998

■ If you wish to complete the board attach operation, execute the

complete_attach(1M) command.

dr> complete_attach 6
Completing attach for board 6.
Board attachment completed successfully.
dr>

After you successfully attach the board, all of the drshow(1M) displays become
available.

5. Type drshow(1M) to display the I/O information for the newly attached board.

dr> drshow 6 IO

SBus Controllers and Devices for Board 6

---------------------- Sbus 0 : Slot 0 : SUNW,pln0 -------------

device opens name usage

------ ----- ---- ----­ssd0 0 /dev/dsk/c1t0d0s0
ssd16 0 /dev/dsk/c1t1d0s0
ssd32 0 /dev/dsk/c1t2d0s0
ssd48 0 /dev/dsk/c1t3d0s0
ssd64 0 /dev/dsk/c1t4d0s0
ssd80 0 /dev/dsk/c1t5d0s0

---------------------- Sbus 0 : Slot 1 : SUNW,pln2 -------------

device opens name usage

------ ----- ---- ----­ssd96 0 /dev/dsk/c2t0d0s0
ssd97 0 /dev/dsk/c2t0d1s0
...

6. Type

exit to terminate this dr(1M) session.

dr> exit
%

The SSP login shell is again displayed.

Chapter 3 Using Dynamic Reconfiguration 29

Detaching a System Board

Note – This section gives a broad overview of the actions that occur when you

execute DR Detach. For step-by-step instructions, see “To Detach a Board With
Hostview” on page 35.

System boards that are currently being used by the operating system can be
detached if they meet the requirements covered in “Configuration for DR Detach”
on page 6. Once you select an eligible board, you can detach that board by
performing two operations: drain and complete detach.

Drain

The primary function of the drain operation is to determine how the board’s
memory is to be vacated by the operating system and, if required, to select a target
memory area for copying the board's nonpageable memory. If a suitable target
memory area is not available when the drain operation is requested, the request is
denied. If the drain is rejected for this reason, you can continue to retry until target
memory is available. See “Configuration for DR Detach” on page 6.

Once the drain operation is started, the board's pageable memory is flushed to a
disk, which removes it from use by the domain. Whenever a page of memory
becomes free, that page is locked from further use. The drain has no noticeable
impact on the processes using the board’s CPU and I/O resources. However, less
memory is available to the domain.

Note – After memory is drained, enough memory and swap space must remain in

the domain to accommodate the current workload.

During the drain period, Hostview and dr(1M) are available to monitor the detach
progress. You can view the current status of the drain operation, including the
number of memory pages remaining to be drained, and the usage of devices on the
board. With this information, you can prepare the domain for detaching the
remaining board devices.

If you decide not to proceed with the detach operation, you can abort the operation,
and the board's memory is returned to regular usage. You can also abort the
operation during the drain process or after the drain has been completed. If extreme
memory pressure exists during the drain, you will see little, or no, progression in the

30 Sun Enterprise 10000 Dynamic Reconfiguration User’s Guide • May 1998

percentage of drained pages, and you may want to abort the drain and wait until the
workload on the domain has decreased, enabling it to accommodate the reduction in
memory.

The drain operation is complete when all of the memory pages are drained. You can
then complete the detach operation.

Complete Detach

Before you can complete the detach operation, you must terminate all usage of board
resources (processors, memory, and I/O devices). DR terminates the use of memory,
processors, and network devices automatically, but you must terminate the use of all
non-network I/O devices.

Note – To identify the components that are on the board to be detached, use

drshow(1M), or use the displayed windows in Hostview (when you select the
Configuration menu and then choose the Board pull-down menu and the
Detach menu item). Another somewhat less informative way to identify the

components is to execute the prtdiag(1M) command on the domain.

Network Devices

DR automatically terminates usage of all network interfaces on the board that is
being detached. When you complete the detach operation, the dr_daemon(1M)
identifies all configured interfaces on the board being detached and issues the
following ifconfig(1M) commands on each such interface.

ifconfig interface down
ifconfig interface unplumb

Additionally, if FDDI interfaces are detached, DR kills the FDDI network monitoring
daemon before you perform the detach operation. DR then restarts it after the detach
is complete. Note that the /usr/sbin/nf_snmd daemon for nf devices is neither
started nor stopped when a board that contains a FDDI interface is attached.

DR does not execute these commands on a board that contains a network interface
that fits any of the following conditions. In these cases, the detach operation fails
and DR displays an error message.

■ The interface is the primary network interface for the domain; that is, the

interface whose IP address corresponds to the network interface name contained
in the file /etc/nodename. Note that bringing down the primary network

Chapter 3 Using Dynamic Reconfiguration 31

interface for the domain prevents network information name services from
operating, which results in the inability to make network connections to remote
hosts using applications such as ftp(1), rsh(1), rcp(1), rlogin(1). NFS
client and server operations are also affected.

■ The interface is on the same subnet as the SSP host for the system; that is, the

subnet of the IP address that corresponds to the SSP host name found in /etc/
ssphostname. Bringing down this interface interrupts communication between

the host and SSP. Since DR operations are initiated on the SSP, control of the
detach process would be lost. (Note that the /etc/ssphostname file contains the
name of the SSP that controls the host; therefore, if you rename the SSP, the
/etc/ssphostname must be manually updated.)

■ The interface is the active alternate for an Alternate Pathing (AP) meta device

when the AP meta device is plumbed. Interfaces used by AP should not be the
active path when the board is being detached. Manually switch the active path to
an interface that is not on the board being detached. If no such path exists,
manually execute the ifconfig down and ifconfig unplumb commands on
the AP interface. (To manually switch an active path, use the apconfig(1M)
command.)

Non-Network Devices

All non-network devices must be closed before they are detached. In the Hostview
device display and in the drshow(1M) I/O listing, there is an open count field that
indicates how many processes have opened particular devices. To see which
processes have these devices open, use the fuser(1M) command on the domain.

You must perform certain tasks for non-network devices. Although the following list
of tasks implies a sequence of order, strict adherance to the order is not necessary.

1. If the redundancy features of Alternate Pathing or Solstice DiskSuite mirroring

are used to access a device connected to the board, reconfigure these subsystems
so that the device or network is accessible via controllers on other system boards.
Note that for Alternate Pathing 2.1, the system automatically switches the disk
devices to an alternate interface if one is available.

2. Unmount file systems, including Solstice DiskSuite meta-devices that have a

board-resident partition (for example, umount /partit).

3. Remove Alternate Pathing or Solstice DiskSuite databases from board-resident

partitions. The location of Alternate Pathing or Solstice DiskSuite databases is
explicitly chosen by the user and can be changed.

4. Remove any private regions used by Sun Volume Manager or Veritas Volume

Manager. Volume manager by default uses a private region on each device that it
controls, so such devices must be removed from volume manager control before
they can be detached.

32 Sun Enterprise 10000 Dynamic Reconfiguration User’s Guide • May 1998

5. Remove disk partitions from the swap configuration by using swap(1M).

6. Either kill any process that directly opens a device or raw partition, or direct it to
close the open device on the board.

7. If a detach-unsafe device is present on the board, close all instances of the device
and use modunload(1M) to unload the driver.

Caution – Unmounting file systems may affect NFS client systems.

Processors

The boot processor is responsible for servicing the tick-timer interrupts and for
maintaining the netcon BBSRAM buffer. Before detaching a board on which the boot
processor resides, the dr_daemon(1M) must assign the boot processor role to
another active (online) processor.

Note – When a board is detached, all processes bound to its processors are

automatically unbound. You can use pbind(1M) to rebind them to other processors.

Finishing the Complete Detach Operation

Once all board usage is terminated, you can perform the complete detach operation.
If a device is still in use at this time, the detach operation fails and the device in use
is reported. After you resolve the problem, you can perform the complete detach
operation again.

If the board that you want to detach contains nonpageable memory, the complete
detach operation may also fail due to quiescence problems, which are described in
“System Quiescence Operation” on page 13. After you resolve the quiescent
problem, you can again execute the complete detach operation.

If you decide that you do not want to proceed with the detach operation at this time,
you can abort the detach. The board's memory is returned to normal usage and
detached board devices are reattached. If the system configuration was modified to
remove board usage (that is, file systems were unmounted and networks were
unplumbed), you must undo these modifications and return the devices to normal
operation.

After the board is successfully detached from the operating system, it is isolated
from the centerplane by moving it out of the host’s hardware domain. In addition,
the board list is automatically updated in the SSP domain_config(4) file.

Chapter 3 Using Dynamic Reconfiguration 33

You can now attach the board to another domain, power it off, and remove it by way
of hot swapping, leaving it in the system unattached, or reattaching it at a later time.

Hostview Detach Buttons
