STP2002QFP
Revision 1.0–April 1996
STP2002QFP
Fast Ethernet, Parallel Port, SCSI
(FEPS)
USER’S GUIDE
OVERVIEW 1
1.1 Introduction
The STP2002QFP FEPS (Fast Ethernet®, Parallel, SCSI) is an ASIC that provides integrated high-performance SCSI, 10/100 Base-T Ethernet, and a Centronics compatible parallel port.
1.2 Features
FEPS features include the following:
• IEEE 1496 SBus master interface with support for 64-bit mode access
• IEEE 1496 SBus slave interface, 32-bit mode only
• 20 MB/s fast and wide single-ended SCSI using a QLogic FAS366 core
• 10/100-Mb/sec Ethernet on the motherboard
• MII (Media Independent Interface) interface to support external transceivers
• DMA2-compatible Centronics parallel port with a maximum throughput of 4
MB/s
• Supports use on an SBus card device
• Provides a path to an FCode PROM for use on SBus boards
• JTAG support for boundary and internal scan testing
1.3 Overview
FEPS contains four major blocks: SBus Adapter (SBA), SCSI_Channel,
ENET_Channel, and PP_Channel. Each channel uses the Channel Engine In-
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
terface (CEI) for slave and DMA transfers with the SBus (via SBA). The SBA
provides buffering and bus conversion between the SBus and the channel engine interface. Interrupts from the channel engine go directly to the SBus. The
SBA contains no software-accessible registers.
The channel engine interface provides a common interface to the three
channel engines thus reducing verification time. This interface limits the
amount of “awareness” that the SBA has concerning DMA transactions.
The SBA supports only 32-bit programmed I/O on the SBus. There are two
64-byte DMA write buffers, to allow buffered writes. A round-robin arbitration scheme will be used between the three channel engines.
The SCSI_Channel contains the SCSI DVMA and the FAS366. The SCSI
channel can perform 64-bit SBus DMA transfer. The SCSI DVMA provides
the two 64-byte buffers to transfer data to/from FAS366. The FAS366 allows
for a 16-bit SCSI data path and a throughput of 20 Mbytes/sec. The programming model of the SCSI DVMA follows the DMA2’s SCSI. All programmed
I/O access to the FAS366 is driven by the SCSI DMA.
The Ethernet DMA can perform 64-bit SBus DMA transfers.The Ethernet
DMA has two 2K-byte FIFOs (one for transmit and one for receive). The
transmit portion of the Ethernet DMA can assist in TCP checksum generation. This requires the entire frame to be loaded into the TxFIFO before the
checksum can be inserted into the frame (that resides in the TxFIFO). The
receive portion of the Ethernet DMA can assist in checking the checksum of
an incoming frame. The receive DMA can also pass incoming frames from
the BigMac (Media Access Conmtroller) before the entire frame has been
buffered in the RxFIFO.
1.4 Technology Information
Technology features of FEPS are as follows:
• 240-pin PQFP
• 112K gates + 4K bytes dual-ported RAM
• 5-V operation only
• 1.5-W maximum power consumption
• 16–25-MHz SBus interface and parallel port, 40-MHz SCSI core, 25-MHz Fast
Ethernet core
• 48-mA SCSI, 16-mA MII direct interconnect-capable drivers
1.5 Compliance
This part is fully compliant with IEEE 1496 SBus, ANSI SCSI-2 X3T9.2/86-
2
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
109 rev10h, ISO/IEC 8802-3, IEEE 802.3u 100 Base-T, IEEE 1149.1 (
JTAG), Centronics-protocol-compatible parallel port, and the Sun4u system
architecture.
STP2002QFP
Sun Microsystems,
3
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
SBus
SBA
Channel Engine Interface
SCSI_IRQ
SCSI DVMA ENET DMA PP DMA
FAS366 BigMac PP Core
SCSI_Channel ENET_Channel PP_Channel
SCSI
Bus
MII
Interface
ENET_IRQ
Parallel Port
Figure 1. STP2002QFP Block Diagram
PP_IRQ
Boot PROM
4
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
STP2002QFP
1.6 Pin Descriptions
The signal pins are grouped by function in the following tables.
Table 1: SBus Signals
Signal Name Type Pin Count Description
SB_D[31:0] I/O 32 SBus data
SB_A[27:0] I/O 28 SBus address
SB_SEL I 1 SBus slave select
SB_BR O 1 SBus DVMA request
SB_BG I 1 SBus DVMA grant
SB_ACK[2:0] I/O 3 SBus acknowledge codes
SB_SIZ[2:0] I/O 3 SBus transfer size
SB_RD I/O 1 SBus direction
SB_CLK I 1 SBus clock
SB_RESET I 1 SBus reset
SB_AS I 1 SBus address strobe
SB_LERR I 1 SBus late error
SB_DATAPAR I/O 1 SBus data parity
SB_SC_INT O 1 SCSI interrupt request to the system
SB_ET_INT O 1 Ethernet interrupt request to the system
SB_PP_INT O 1 Parallel port interrupt request to system
Total SBus 78
Sun Microsystems,
Table 2: SCSI Signals
Signal Name Type Pin Count Description
SCSI_D[15:0] I/O 16 SCSI data
SCSI_DP[1:0] I/O 2 SCSI data parity
SCSI_SEL I/O 1 SCSI select
SCSI_BSY I/O 1 SCSI busy
SCSI_REQ I/O 1 SCSI request
SCSI_ACK I/O 1 SCSI acknowledge
SCSI_MSG I/O 1 SCSI message phase
SCSI_CD I/O 1 SCSI command/not data
SCSI_IO I/O 1 SCSI direction
SCSI_ATN I/O 1 SCSI attention
SCSI_RST I/O 1 SCSI reset
5
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
Table 2: SCSI Signals
Signal Name Type Pin Count Description
SCSI_XTAL2 O 1 SCSI crystal output
SCSI_XTAL1 I 1 SCSI crystal input
POD I 1 SCSI power detect
Total SCSI 30
Table 3: Ethernet Signals
Signal Name Type Pin Count Description
ENET_TX_CLK I 1 Ethernet transmit clock input
ENET_TXD[3:0] O 4 Ethernet transmit data
ENET_TX_EN O 1 Ethernet transmit enable
ENET_COL I 1 Ethernet transmit collision detected
ENET_CRS I 1 Ethernet carrier sense
ENET_RX_CLK I 1 Ethernet receive clock
ENET_RXD[3:0] I 4 Ethernet receive data
ENET_RX_DV I 1 Ethernet receive data valid
ENET_RX_ER I 1 Ethernet receive error
ENET_MDC O 1 Ethernet management device clock
ENET_MDIO0 I/O 1 Ethernet management device I/O data for
on-board transceiver
ENET_MDIO1 I/O 1 Ethernet management device I/O data for
on-board transceiver
ENET_BUFFER_EN
_0
ENET_TX_CLKO O 1 Ethernet transmit clock output
Total Ethernet 20
O 1 Ethernet buffer enable
6
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
STP2002QFP
Table 4: Parallel Port Signals
Signal Name Type Pin Count Description
PP_DATA[7:0] I/O 8 Parallel port data bus
PP_STB I/O 1 Parallel port data strobe
PP_BSY I/O 1 Parallel port busy
PP_ACK I/O 1 Parallel port acknowledge
PP_PE I 1 Parallel port paper error
PP_SLCT I 1 Parallel port select
PP_ERROR I 1 Parallel port error
PP_INIT O 1 Parallel port initialize/ALE high address byte
PP_SLCT_IN O 1 Parallel port select in
PP_AFXN O 1 Parallel port audio feed/ALE low address byte
PP_DSDIR O 1 Parallel port data strobe direction
PP_BSYDIR O 1 Parallel port busy direction
PP_ACKDIR O 1 Parallel port ack direction
PP_DDIR O 1 Parallel port data direction
ID_CS I/O 1 ID PROM chip select
Total Parallel Port 22
Sun Microsystems,
Table 5: JTAG/Miscellaneous Signals
Signal Name Type Pin Count Description
JTAG_TDO O 1 JTAG test data out
JTAG_TDI I 1 JTAG test data in
JTAG_TMS I 1 JTAG test mode select
JTAG_CLK I 1 JTAG clock
JTAG_RESET I 1 JTAG TAP reset
STOP_CLOCK I 1 Stop clock input
CLK_10M O 1 10-MHz clock output
Total JTAG 7
7
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
Table 6: Power/Ground/Other Signals
Signal Name Type Pin Count Description
VDD_CORE 4
VSS_CORE 4
V
DD
V
SS
Reserved 1
MODE 1 Mode select (stand alone/chipset)
Total 83
21
52
8
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
STP2002QFP
SBUS ADAPTER 2
2.1 Introduction
The SBus Adapter (SBA) is the layer between the Channel Engine Interface
(CEI) and the SBus. It provides one master port on the SBus side to funnel
three DMA channel engines (CE) onto the SBus, and one slave port for SBus
accesses to the CEs. The SBA can be viewed as a block of data path and flow
control between SBus and channel engine interface.
2.2 SBus Capabilities
2.2.1 Slave Accesses
• Supports byte/half-word/word access, but not burst transfer
• Supports 32-bit transfer mode
• Parity generation/checking
• Does not generate late error
Sun Microsystems,
• Does not generate Rerun Ack
• Maximum latency < 22 SBus clocks
2.2.2 Master Accesses
• Compliant to IEEE 1496
• Supports 64-bit/32-bit transfer mode
• Supports byte/half-word/word transfer size
• Supports burst transfer size from 8 bytes to 64 bytes
• Parity generation/checking
• Does not issue atomic transaction
• Does not support bus sizing
2.2.3 Address Decoding
In order to eliminate the need of NEXUS driver in between FEPS device driver and the kernel there are no registers insides the SBA block (a register inside
SBA would be a global register which means a NEXUS driver is needed).
However, SBA does decode the physical address input and the access size for
9
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
slave accesses from SBus. The physical address is decoded to select a target
CE to respond to the access. A physical address that cannot be resolved to the
selection of any channel engine will cause SBus Adapter to return Error Ack.
The access size is decoded to Error Ack 64-bit transfer mode or burst transfer
that is not supported by FEPS.
2.3 Theory of Operation
2.3.1 Master Operations
All master operations are originated from the channel engines. The operations
start when one or more bus requests are asserted on the channel engine interface.
2.3.1.1 DVMA Write
DVMA write cycle starts when the channel engine with highest priority asserts BR signal on CEI with RD (bit[63] of CE_DOUT signal) signal de-asserted. The arbiter inside SBA asserts grant signal (BG) to the requesting CE
and kick off the CEI write state machine. CEI write state machine first latches
the DVMA address, transfer size and channel ID from the requesting CE and
then begin to move data from CEI and write them to the current DVMA data
write buffer. When the whole burst of write data are written to the write buffer, the CEI state machine places a write request into the request command
queue of the SBus Master Port State machine and, at the mean time, it release
the arbiter to arbitrate the next request on the CEI. The master port state machine wakes up and requests the SBus whenever there is a request in the
queue. When the whole burst of Data is written to the SBus, the master port
state machine return the acknowledgment (MEMDONE) and status
(CE_DWERR) to the corresponding CE.
When a CE is granted for DMA write, the CEI bus is locked until the whole
burst of write data is moved over to the write data buffer. During this period,
only the slave write operation from the SBus can occur on the CEI. A slave
read would have to wait until the DMA write cycle is done. On the other hand,
a slave read operation will have the same effect as DMA write that will also
lock up the CEI for the duration of the whole transaction.
10
2.3.1.2 DVMA Read
DVMA Read cycle starts with the highest priority channel engine asserts BR
signal on CEI with RD (bit[63] of CE_DOUT signal) signal asserted. The arbiter latches the DVMA address, transfer size and channel ID and places a
Read request into the request command queue of the SBus master port state
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
machine. After this the arbiter is available to arbitrate and grant the next request on the CEI provided that there is a DMA write or read buffer still available. The master port state machine wakes up and request the SBus whenever
there is a request in the queue. When SBus is granted, the master port state
machine asserted BG to the corresponding CE and pass the read data over to
the CEI bus.
STP2002QFP
2.3.2 Slave Operation
When both AS and SEL input signals are asserted, the slave port begin to respond to the slave access from the SBus. Based on the physical address, one
of the channel engines is selected to respond to the slave access. Slave writes
goes directly through to the CEI bus without arbitration because it share the
CEI data-in data bus with DVMA read which is mutually exclusive to slave
operation. Slave reads share the CEI data-out bus with all other CEI operations and have to go through arbiter to compete with channel engines.
Because a SBus DVMA read operation may encounter a retry, there is condition that a CE is being granted with DVMA read and a slave access still
comes in. The CE has to make sure that it can still respond to this slave access
under this condition.
Sun Microsystems,
11
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
SCSI CHANNEL 3
3.1 Introduction
The SCSI channel consists of SCSI DVMA (also referred to as SCSI channel
engine) and FAS366, a “Fast and Wide” SCSI controller core. The SCSI
DVMA provides two 64-byte buffers used to transfer data to/from the
FAS366. The FAS366 supplies a 16-bit SCSI data path and a throughput of
20 MB/sec. All programmed I/O access to the FAS366 is driven by the SCSI
DVMA.
Several programmable registers can be used by the SCSI device driver to
direct the SCSI engine and FAS366 to move blocks of data to/from host
memory or to/from devices on the SCSI bus. Once the transfer is complete,
an interrupt is generated on the SBus to inform the driver that block movement is complete, freeing it to initiate further transfers.
3.2 SCSI DVMA
SCSI DVMA is responsible for data movement between FAS366 and the host
memory. It contains two 64-byte buffers. The purpose for providing these
buffers is to have prefetch capability. With this scheme of prefetch buffers,
one buffer can be used for writing/reading data on SBus, while the other buffer can be used for reading/writing data from/to FAS366. For SCSI write operation (reading from host memory and writing to FAS366), a chunk of data
is moved from the host memory and stored in the buffers. When FAS366 is
ready to accept data, this data is written to FAS366. For SCSI read operation
(reading from FAS366 and writing to host memory), data being read from
FAS366 is stored in the buffers. This data is written into host memory at a later time. The whole idea of providing buffers is to absorb the difference in data
transfer rate, between SBus and SCSI bus.
12
3.3 FAS366
FAS366 is a Fast and Wide SCSI controller core and is integrated into FEPS
as a hard macro.
The following are some of the features of the FAS366 core:
• Supports ANSI X3T9.2/86-109 (SCSI-2) standard
• Sustained SCSI data transfer rates:
- 10-MHz synchronous (fast SCSI)
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
- 5-MHz synchronous (normal SCSI)
- 6-MHz asynchronous
• REQ/ACK programmable assertion/deassertion control
• Power-on connect/disconnect to SCSI bus (hot plugging)
• Target block transfer sequence
• Initiator block transfer sequence
• Bus idle timer
• Reduced SCSI bus overhead
• On-chip, single-ended SCSI drivers (48 mA)
• Target and initiator modes
• 16-bit recommand counter
• Differential mode support
For more information on FAS366, refer to the FAS366 specification from
Emulex.
STP2002QFP
Sun Microsystems,
3.4 Test Support
The SCSI DVMA will support full internal and boundary scan. The FAS366
core does not support full internal scan. SCSI I/O pads will support boundary
scan.
13
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
PARALLEL PORT CHANNEL 4
4.1 Introduction
The parallel port interface implementation of FEPS is almost identical to the
one on the STP2000 Master I/O controller chip to leverage the existing device
driver. The only difference is that the DIR bit has to be set during a memory
clear operation. It allows the CPU to send data to the standard Centronics
printer in both programmed I/O and DMA modes. The parallel interface can
support bidirectional transfers using Xerox and IBM schemes. A 64-byte
buffer is used to buffer data to and from the channel engine interface and the
parallel port in DMA mode, depending on the direction of the transaction. In
synchronous mode, the port can support data transfer rate up to 4 Mbytes/s.
The parallel port interface also provides the data path to read the FCode
PROM when the FEPS chip is used on a SBus extended card. Two external
8-bit latches are needed to latch the MSB and LSB of the EPROM address.
Refer to the FEPS Application note for more details on this mode.
4.2 Parallel Port FIFO Operation
Between the parallel port and the SBus interface is a 64-byte FIFO (P_FIFO).
This FIFO is bypassed for slave accesses to the parallel port registers. Consistency control ensures that all data written by the external device gets to
main memory in a deterministic manner, and is handled completely in hardware. One of the consistency control mechanisms used on transfers to memory is draining of all P_FIFO data upon the access of any parallel port register.
The conditions that cause data in the P_FIFO to be drained to memory are
as follows:
1. 4, 16, or 32 bytes (depending on P_BURST_SIZE) have been
written into the P_FIFO.
2. The P_INT_PEND bit in the P_CSR is set.
3. The CPU does a slave write to a parallel port internal register
other than the P_TST_CSR (writing P_ADDR does not cause
draining if P_DIAG is set).
4. The P_RESET or P_INVALIDATE bit in the P_CSR is set.
5. The P_ADDR register is loaded from P_NEXT_ADDR when
P_DIAG is not set.
14
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
None of these conditions will cause draining if P_ERR_PEND = 1, indicating that a memory error has occurred. If condition 4 or 5 occurs when the
P_ERR_PEND bit is 1, the P_FIFO will be invalidated and all dirty data will
be discarded.
STP2002QFP
4.3 Bidirectional Parallel Port Interface
The parallel port can operate unidirectionally or bidirectionally in either a
programmed I/O mode or in a DMA mode. The hardware interface can be
configured to operate with a wide range of devices through the following
mechanisms:
• Bidirectional signal configuration for the interface control signals—
data strobe, acknowledge, and busy. Each control signal can be individually configured as a unidirectional or bidirectional signal.
• Programmable pulse widths for all generated signals and programma-
ble data setup time for data transfers.
• Programmable protocol definition for all combinations of acknowl-
edge and busy handshaking.
Sun Microsystems,
This interface configuration capability will allow operation over a wide
range of data transfer rates and protocol definitions.
4.3.1 DMA Mode
Since no software intervention is required for data transfer, the interface protocol and timing required must be programmed via the configuration registers. DMA transfers are initiated/enabled by setting the P_EN_DMA bit of
the P_CSR. The operation of the interface is dependent on the direction of
transfer and the protocol selected as described below.
4.3.1.1 Unidirectional Operation (Transfers to the Peripheral Device)
This mode of operation is the Centronics implementation of a unidirectional
parallel port. Operation of the parallel port in this mode requires the direction
control bit (DIR) of the transfer control register (TCR) to be 0. Timing variations are handled via the DSS (data setup to data strobe) and DSW (data
strobe width) bits of the hardware configuration register. The timebase for
programmability is the SBus clock. The DSS parameter (7 bits) can be programmed from a minimum of 0 SBus clocks to 127 SBus clocks in steps of
one SBus clock. The DSW parameter (7 bits) is also programmed in steps of
one SBus clocks, however when DSW= 0, 1, 2, or 3, data strobe width is de-
15
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
fined as three SBus clocks. That is, the minimum data strobe width is three
SBus clocks. The following table shows the nominal range of programmability for different SBus clock speeds.
16
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
STP2002QFP
Table 7:
SBus Clock DSS DSW
16.67 MHz 0–7.62 µs 180.0 ns–7.62 µs
20 MHz 0–6.35 µs 150.0 ns–6.3 µs
25 MHz 0–5.08 µs 120.0 ns–5.08 µs
The desired handshake protocol can be selected using the ACK_OP
(acknowledge operation) and BUSY_OP (busy operation) bits of the opera-
tions configuration register (OCR). The function of these bits is defined as
follows:
ACK_OP 1 = Handshake complete with receipt of P_ACK (PP_ACK).
0 = P_ACK (PP_ACK) is ignored.
BUSY_OP 1 = Handshake complete with receipt of P_BSY (PP_BSY).
0 = P_BSY (PP_BSY) is not used for handshaking.
These two bits allow selection of one of four possible protocols, however
only three of these protocols make sense and are valid selections. The case of
ACK_OP=BUSY_OP=1, is not supported. For all protocol selections, if
P_BSY (PP_BSY) is active, further data transfers will not occur until P_BSY
(PP_BSY) is negated. The following table summarizes the protocol definitions for transfers to the peripheral device.
Sun Microsystems,
Table 8:
BUSY_OP ACK_OP Protocol Definition
0 0 No handshaking occurs
0 1 Acknowledge is required for each byte transferred
10P_BSY is used as acknowledge and is required for each byte
transferred. ACK is ignored
1 1 Invalid
The transfer modes are shown and discussed in the following sections.
4.3.1.1.1 No Handshake (BUSY_OP=0, ACK_OP=0)
Data transfers are controlled by the use of P_D_STRB (PP_STB) and optionally P_BSY (PP_BSY). There is no acknowledge in this mode and P_ACK
(PP_ACK) is a don’t care. P_BSY (PP_BSY) is used to gate further transfers
17
STP2002QFP
P_DATA (O)
P_D_STRB (O)
P_ACK (I)
P_BSY (I)
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
when the peripheral device cannot receive another byte of data. P_BSY
(PP_BSY) is sampled before data strobe becomes active and after data strobe
becomes inactive, to ensure that a data transfer is not attempted while the device is busy.
It is this mode, which provides the fastest transfer of data over the interface, the fastest cycle time is six SBus clocks per byte. This transfer time is
arrived at as follows: DSS=0, DSW=3 (minimum width of DSW is three
SBus clocks), and three SBus clocks between consecutive data strobes. This
assumes that P_BSY (PP_BSY) is not asserted during the transfer cycle. Reference Figure 2.
1
DSS
2
DSW
3
Don’t Care
4
1
DSS
2
DSW
5
1. Data setup as defined in the hardware configuration register.
2. Data strobe width as defined in the hardware configuration register.
3. There is a three SBus clock delay from the end of data strobe to the next byte of data being clocked onto the P_DATA
bus.
4. Acknowledge is a don’t care condition for all data transfers.
P_BSY is active, it gates further data transfers.
5. When
Figure 2.
4.3.1.1.2 Handshake with Ack: BUSY_OP=0, ACK_OP=1)
Data transfers are controlled by the use of P_D_STRB (PP_STB), P_ACK
(PP_ACK), and optionally P_BSY (PP_BSY). P_ACK (PP_ACK) is required for each byte transferred. If P_BSY (PP_BSY) is active at the end of
the cycle, further data transfers will be gated until P_BSY (PP_BSY) becomes inactive. If P_BSY (PP_BSY) is not present, then data transfers will
proceed. P_BSY (PP_BSY) is also sampled immediately before P_D_STRB
(PP_STB) is generated to ensure that a data transfer is not attempted while the
device is busy. Reference the data transfer diagram in Figure 3.
18
Sun Microelectronics
P_DATA (O)
P_D_STRB
(O)
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
1
DSS
2
DSW
3
STP2002QFP
5
P_ACK (I)
1. Data setup as defined in the hardware configuration register.
2. Data strobe width as defined in the hardware configuration register.
3. Acknowledge is required for each byte transferred.
P_BSY is active, it gates further data transfers.
4. When
P_BSY is not present, the next data byte will be gated on to the bus following ACK (there is a minimum of three SBus clocks between
5. If
the trailing edge of ACK and the next data byte).
6. All signal polarities shown are at the HIOD pins. Polarities on the interface cable should be inverted (except P_DATA).
4
Figure 3.
4.3.1.1.3 Handshake with Busy (ACK_OP=0, BUSY_OP=1)
Data transfers are controlled by the use of P_D_STRB (PP_STB) and P_BSY
(PP_BSY). P_ACK (PP_ACK) is a don’t care in this mode. P_BSY
(PP_BSY) is required as an acknowledge after P_D_STRB (PP_STB) and
will gate any further data transfers while it is active. P_BSY (PP_BSY) is also
sampled immediately before P_D_STRB (PP_STB) is generated to ensure
that a data transfer is not attempted while the device is busy. Reference the
data transfer diagram in Figure 4.
P_DATA (O)
P_D_STRB
(O)
P_ACK (I)
1
DSS
DSW
2
3
Don’t Care
4
5
1. Data setup as defined in the hardware configuration register.
2. Data strobe width as defined in the hardware configuration register.
3. Acknowledge is a don’t care condition for all data transfers.
P_BSY is required as an acknowledge for each byte transferred. While P_BSY is present, it gates fuirther data transfers.
4.
5. The next byte of data will be gated on to the bus following the trailing edge of
the trailing edge of
6. All signal polarities shown are at the HIOD pins. Polarities on the interface cable should be inverted (except P_DATA).
P_BSY and the next byte of data).
P_BSY (there is a minimum of three SBus clocks between
Figure 4.
Sun Microsystems,
19
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
4.3.1.2 Bidirectional Operation
Bidirectional data transfer over the parallel port can be accomplished by the
use of either of two master/slave protocols. The “master write” protocol or the
“master read/write” protocol. The IBM implementation of a bidirectional parallel port uses the master write protocol in which the master always writes
data to the slave and when the direction of data transfer needs to be reversed,
mastership is exchanged. The Xerox implementation uses the master
read/write protocol where data transfer is performed in either direction under
control of the fixed master. The parallel port will operate as either master or
slave when configured for master write protocol, and only as the master when
configured for the master read/write protocol.
The selection of one of these bidirectional transfer methods is accomplished indirectly through the specification of the bidirectional nature of the
data strobe signal. Since in both methods data strobe resides with the master,
a bidirectional data strobe implies the IBM master write scheme and a fixed
data strobe (output only) implies the Xerox master read/write scheme.
The interface control signals—data strobe, acknowledge, and busy—are
individually configurable as bidirectional or unidirectional pins. The bidirectional signal configuration bits are located in the operation configuration
register. The functions of the bits are as follows:
20
DS_DSEL 1 = P_DS (PP_DSDIR) is bidirectional, master write protocol selected.
0 = P_DS (PP_DSDIR) is fixed as output. Master read/write protocol
selected.
ACK_DSEL 1 = P_ACK (PP_ACK) is bidirectional.
0 = P_ACK (PP_ACK) is fixed as an input.
BUSY_DSEL 1 = P_BSY (PP_BSY) is bidirectional.
0 = P_BSY (PP_BSY) is fixed as an input.
To allow external driver/receiver connection, each of these control signals
and the data bus has a corresponding direction control pin. The DIR bit of the
transfer control register is used to switch the direction of the data bus and the
pins that have been configured as bidirectional. The state of the DIR bit is
reflected on the P_D_DIR (PP_DDIR) pin for external transceiver control
and direction control communication to the attached device. While DIR=0,
all pins remain in their unidirectional sense which is defined to be consistent
with the unidirectional parallel port as follows:
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
STP2002QFP
Table 9:
Signal I/O DIR_Pin State
P_D_STRB (PP_STB) O P_DS_DIR (PP_DSDIR) 1
P_ACK (PP_ACK) I P_ACK_DIR (PP_ACKDIR) 0
P_BSY (PP_BSY) I P_BSY_DIR (PP_BSYDIR) 0
P_DATA (PP_DATA) O P_D_DIR (PP_DDIR) 1
When DIR is set to 1, the pins configured as bidirectional change direction
and their corresponding direction control pins are set accordingly. Note that
the input status pins (ERR, SLCT, PE), which are readable in the input regis-
ter, are not configurable. They are fixed as inputs. Similarly, the output pins
(PP_AFXN, PP_INIT, PP_SLCT_IN) of the output register are fixed as
outputs.
The transfer modes are shown and discussed in the following sections.
4.3.1.3 Master Write Protocol, Slave Operation
This section describes the parallel port operation as a slave when it is configured for master write protocol (DS_DSEL=1). Operation as a master is the
same as is described in the “Unidirectional Operation (Transfers to the Peripheral Device)” section on page 15.
In this mode, acknowledge and/or busy can be generated in response to a
data strobe. The width of the P_ACK (PP_ACK) pulse can be defined using
the DSW bits of the hardware configuration register. The P_BSY (PP_BSY)
hold time and P_ACK (PP_ACK) positioning after the trailing edge of data
strobe are defined using the DSS bits. However, note that in this mode DSS
has a tolerance of +3 to 4 SBus clocks, due to synchronization delays. The
nominal programmability range is the same as was specified in the “Unidirectional Operation (Transfers to the Peripheral Device)” section on page 15.
The ACK_OP and BUSY_OP bits are used to specify handshake protocol.
The function of the bits take on a new meaning when the parallel port is a
slave.
Sun Microsystems,
ACK_OP 1 = Generate P_ACK (PP_ACK) in response to a data strobe.
0 = P_ACK (PP_ACK) is not generated. P_ACK is held in an inactive state.
BUSY_OP 1 = Generate P_BSY (PP_BSY) as an acknowledge, in response to data strobe.
0 = P_BSY (PP_BSY) is not generated for each byte transferred, but is asserted
as required.
21
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
These two bits allow selection of one of four possible handshake protocols.
The following table summarizes the protocol definitions for transfers to the
parallel port from the peripheral device.
For all protocol selections, P_BSY (PP_BSY) will become active if one of
the following conditions occur: The P_DMA_ON bit is reset indicating
DMA cannot proceed; or the
P_FIFO is unable to accept more data. Internally, P_BSY (PP_BSY) will
always be generated for these conditions. However, if the P_BSY (PP_BSY)
pin is not configured as an output, it will not be driven and the external interface will not be able to detect the busy condition. In this case, data could be
lost. In all cases, if P_BSY (PP_BSY) is asserted it will have the following
timing characteristics:
P_D_STRB
(I)
1. WHen data strobe is detected, P_BSY will be generated within 3 SBus clocks, if required.
P_BSY hold time after data strobe is configurable via DSS.
2.
1
2
DSS
Figure 5.
The transfer modes are shown and discussed in the following sections.
4.3.1.3.1 No Handshake: (BUSY_OP=0, ACK_OP=0)
No handshake signals are generated in this mode. If P_ACK (PP_ACK) is
configured as an output, it will remain low or inactive. P_BSY (PP_BSY) will
be generated as required to gate further transfers, but not as a handshake signal. The operation of the interface as defined assumes the bidirectional sense
of each signal has been configured as follows: DIR=1, DS_DSEL=1,
ACK_DSEL=X, BUSY_DSEL=1. If P_ACK (PP_ACK) is configured as
an output, it will remain low or inactive. The configuration of P_BSY
(PP_BSY) as an output is suggested to avoid potential data loss. Reference
the parallel port timing section for detailed timing requirements for this mode.
4.3.1.3.2 Handshake with ACK: (BUSY_OP=0, ACK_OP=1)
Data transfers are acknowledged using P_ACK (PP_ACK). The position of
P_ACK (PP_ACK) relative to the trailing edge of data strobe is set using
DSS. Note that in this mode, the actual positioning of P_ACK (PP_ACK) will
be DSS plus 3 to 4 SBus clocks, due to synchronization delays. The width of
P_ACK (PP_ACK) is set using DSW. P_BSY (PP_BSY) will be generated
22
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
STP2002QFP
as required to gate further transfers but not as a handshake signal. The operation of the interface as defined assumes the bidirectional sense of each signal
has been configured as follows: DIR=1, DS_DSEL=1, ACK_DSEL=1,
BUSY_DSEL=1. The configuration of P_BSY (PP_BSY) as an output is
suggested to avoid potential data loss. Reference the data transfer diagram in
Figure 6.
P_DATA (I)
P_D_STRB
(I)
P_ACK (O)
3
1. Acknowledge position relative to data strobe (DSS - hardware configuration register).
2. Acknowledge width (DSW - hardware configuration register).
P_BSY will be asserted if required.
3.
4. All signal polarities shown are at the HIOD pins. Polarities on the interface cable should be inverted (except P_DATA).
1
DSS
2
DSW
Figure 6.
Sun Microsystems,
4.3.1.3.3 Handshake with BUSY: (BUSY_OP=1, ACK_OP=0)
Data transfers are acknowledged using P_BSY (PP_BSY). P_BSY
(PP_BSY) will be generated off of the leading edge of P_D_STRB (PP_STB)
and will remain active for the period specified by DSS (plus 3 to 4 SBus
clocks) beyond the end of P_D_STRB (PP_STB). The operation of the interface as defined assumes the bidirectional sense of each signal has been configured as follows: DIR=1, DS_DSEL=1, ACK_DSEL=X,
BUSY_DSEL=1. The configuration of P_ACK as an input will not hinder the
operation of the interface as far as handshaking is concerned. If P_ACK is
configured as an output, it will remain low or inactive. Reference the data
transfer diagram Figure 7.
23
STP2002QFP
P_DATA (I)
P_D_STRB
(I)
P_ACK (O)
1. P_BSY hold time after data strobe (DSS - hardware configuration register)
2. All signal polarities shown are at the HIOD pins. Polarities on the interface cable should be inverted (except P_DATA).
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
Logic 0
1
DSS
Figure 7.
4.3.1.3.4 Handshake with ACK and BUSY: (BUSY_OP=1, ACK_OP=1)
Both P_ACK (PP_ACK) and P_BSY (PP_BSY) are generated in response to
a data strobe. P_BSY (PP_BSY) will be generated off of the leading edge of
P_D_STRB (PP_STB) and will remain active for 3 SBus clocks beyond the
end of P_ACK (PP_ACK). The position of P_ACK (PP_ACK) relative to the
trailing edge of data strobe is defined by DSS (again DSS has a tolerance of
+3 to 4 SBus clocks). The width of P_ACK (PP_ACK) is set usingDSW. The
operation of the interface as defined assumes the bidirectional sense of each
signal has been configured as follows: DIR=1, DS_DSEL=1,
ACK_DSEL=1, BUSY_DSEL=1. Reference the data transfer diagram in
Figure 8.
P_DATA (I)
P_D_STRB
(I)
P_ACK (O)
1. Acknowledge position relative to data strobe (DSS - hardware configuration register).
2. Acknowledge width (DSW - hardware configuration register).
P_BSY is deasserted 3 SBus clocks following the trailing edge of ACK.
3.
4. All signal polarities shown are at the HIOD pins. Polarities on the interface cable should be inverted (except P_DATA).
1
DSS
2
DSW
3
Figure 8.
24
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
STP2002QFP
4.3.1.4 Master Read/Write Protocol (Xerox Mode)
This section describes the parallel port operation while master read cycles are
performed. Operation while master write cycles are performed is the same as
is described in the “Unidirectional Operation (Transfers to the Peripheral Device)” section on page 15.
Data transfer for master read cycles is accomplished by the master generating a data strobe (request for data) with no data present on the P_DATA
(PP_DATA) bus. The peripheral responds by placing data on the P_DATA
(PP_DATA) bus and generating an P_ACK (PP_ACK) which functions as a
strobe. Only one handshake protocol is valid for master read cycles and is
described below.
4.3.1.4.1 Handshake with ACK: (BUSY_OP=0, ACK_OP=1)
Data is transferred to the HIOD by the use of P_ACK (PP_ACK).
P_D_STRB (PP_STB) width is defined by DSW. DSS is used to define the
required interval from P_ACK (PP_ACK) to the next P_D_STRB (PP_STB).
P_BSY (PP_BSY) will gate further data transfers if present. The operation of
the interface as defined assumes the bidirectional sense of each signal has
been configured as follows: DIR=1, DS_DSEL=0, ACK_DSEL=0,
BUSY_DSEL=0. Reference the data transfer diagram in Figure 9.
P_DATA (I)
P_D_STRB
(O)
P_ACK (I)
1. Data strobe width as defined in the hardware configuration register.
2. DSS is used for ACK to P_D_STRB stiming (Hardware configuration register).
3. Acknowledge is used as a strobe and is required for each byte transferred.
P_BSY is active, it gates further data transfers.
4. If
5. All signal polarities shown are at the HIOD pins. Polarities on the interface cable should be inverted (except P_DATA).
1
DSW
3
2
DSS
4
Figure 9.
4.3.2 Programmed I/O Mode
Programmed I/O mode is intended to allow the parallel port to operate primarily under software control. Data latching, interrupt, and busy generation are
performed in hardware as required. The following two sections describe op-
Sun Microsystems,
25
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
eration for transfers to and from the peripheral device.
4.3.2.1 PIO on Transfers to the Peripheral Device
For transfers to the peripheral device, all signals are under the control of software. There is no hardware assist other than interrupt generation.
4.3.2.2 PIO on Transfers From the Peripheral Device
The two modes of bidirectional operation previously discussed are supported
with hardware-assisted data latching. The bidirectional select bits
(DS_DSEL, ACK_DSEL, BUSY_DSEL) should be set according to the desired configuration. The handshake protocol bits (ACK_OP, BUSY_OP)
have no function in PIO mode.
During operation as a slave under the master write protocol (DS_DSEL=1,
DIR=1), data is sampled and latched once data strobe has been detected.
P_BSY (PP_BSY) becomes active at the same time that data is latched and
must be made inactive under software control.
During operation under master read/write protocol (DS_DSEL=0,
DIR=1), master reads are assisted by sampling and latching the data once
P_ACK (PP_ACK) has been detected. P_BSY (PP_BSY) is not generated in
this mode.
26
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
STP2002QFP
4.4 Differences from STP2000 (MACIO) Parallel Port
• PP_INIT and PP_AFXN have extra functions: high and low address
latch clocks
• EPROM address is given by parallel port data bus
• DIR bit in the TCR register must be set during memory clear operation
4.5 Test Support
The TST_CSR provides a way for the user to test the DMA engine. The test
consists of moving one block data of the size of a read burst from the host
memory into the FIFO. The user then instructs the engine to drain data back
to the host memory at an address which is programmable.
The maximum size of a read burst is 32 bytes. Since the starting address of
the FIFO register cannot be programmed, the user has no control over which
FIFO registers should be tested. And since the maximum size of the burst is
limited to 32 bytes, the entire FIFO (64 bytes) cannot be tested.
Sun Microsystems,
27
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
ETHERNET CHANNEL 5
5.1 Introduction
The Ethernet channel is a dual-channel intelligent DMA controller on the system side, and an IEEE 802.3 Media Access Control (MAC) on the network
side. It is designed as a high-performance full-duplex device, allowing for simultaneous transfers of data from/to host memory to/from the “wire.” The
two main functions of the Ethernet channel are to provide MAC function for
a 10-/100-Mbps CSMA/CD protocol based network and to provide a highperformance two-channel DVMA host interface between the MAC controller
and the SBus. The Ethernet channel supports 10/100-Mbit Fast Ethernet. The
Fast Ethernet standard is backwards compatible with the standard 10-Mb/s
Ethernet standard. The speed is auto-sensed. An RJ-45 connector supports
twisted-pair style of Ethernet. In addition, a Media Independent Interface
(MII) connection is supported through an external transceiver to allow adaptation to any other form of Ethernet (AUI/TP/ThinNet).
28
5.2 Functional Description
5.2.1 Overview
Packets scheduled for transmission are transferred over the SBus into a local
transmit FIFO and are later transferred to the TX_MAC core for protocol processing and transmission over the medium. A programmable transmit threshold is provided to enable the transmission of the frame. The reverse process
takes place in the receive path. Packets received from the medium are processed by the RX_MAC, loaded into the receive FIFO, and are later transferred to the host memory over the SBus. The receive threshold for data
transfers is 128 bytes.
At the device driver level, the user deals with transmit and receive descriptor-ring data structures for posting packets and checking status. In the
transmit case, packets may be posted to the hardware in multiple buffers
(descriptors), and the transmit DMA engine will perform “data gather.” In the
receive case, the receive DMA engine will store an entire packet in each
buffer that was allocated by the host. “Data scatter” is not supported, but
instead a programmable first byte-alignment offset within a burst is
implemented.
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
For TCP packets, hardware support is provided for TCP checksum computation. On transmit, it is assumed that the entire packet is loaded into the local
FIFO before its transmission begins. The checksum is computed on-the-fly
while the packet is being transferred from the host memory into the local
FIFO. The checksum result is then stuffed into the appropriate field in the
packet, and the transmission of the frame begins. On receive, checksum is
computed on the incoming data stream from the MAC core, and the result is
posted to the device driver as part of the packet status in the descriptor.
STP2002QFP
5.2.2 Functional Blocks
The Ethernet channel is comprised of five major blocks:
• BigMAC core
• Management interface (MIF)
• Ethernet transmit (ETX)
• Ethernet receive (ERX)
• Shared Ethernet block (SEB)
5.2.2.1 BigMAC Core
Sun Microsystems,
The BigMAC core implements the IEEE 802.3 MAC protocol for 10-/100Mbps CSMA/CD networks. It consists of four major functional modules:
• Host interface buffer
Implements the programmed I/O interface between the SEB and BigMAC core
• Transmit MAC (TX_MAC)
- Implements the IEEE 802.3 transmit portion of the protocol
- Implements the slave interface handshake between the ETX and
TX_MAC for frame data transfers
- Performs the synchronization between the system clock domain and
the transmit media clock domain in the transmit data path
• Receive MAC (RX_MAC)
- Implements the IEEE 802.3 receive portion of the protocol
- Implements the slave interface handshake between the ERX and
RX_MAC for frame data transfers
- Performs the synchronization between the system clock domain and
the receive media clock domain in the receive data path
29
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
• Transceiver interface (XIF)
- Implements the MII interface protocol (excluding the management
interface)
- Performs the nibble-to-byte and byte-to-nibble conversion between
the protocol engine and the MII
30
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
5.2.2.2 Management Interface Function (MIF)
The management interface block implements the management portion of the
MII interface to an external transceiver, as defined in the IEEE 802.3 MII
specification.
It allows the host to program and collect status information from two
external transceivers connected to the MII. The MIF supports three modes of
operation.
Bit-Bang Mode
The Bit-Bang mode of operation provides maximum flexibility with minimum hardware support for the serial communication protocol between the
host and the transceivers. The actual protocol is implemented in software, and
the interaction with the hardware is done via three one-bit registers: data,
clock, and output_enable. Each read/write operation on a transceiver register
would require approximately 150 software instructions by the host.
Frame Mode
This mode of operation provides a much more efficient way of communication between the host and the transceivers. The serial communication protocol between the host and the transceivers is implemented in hardware, and the
interaction with the software is done via one 32-bit register (frame register).
When the software wants to execute a read/write operation on a transceiver
register, all it has to do is load the frame register with a valid instruction
(frame), and poll the valid bit for completion. The hardware will detect the
instruction, serialize the data, execute the serial protocol on the MII management interface and set the valid bit to the software.
STP2002QFP
Sun Microsystems,
Polling Mode
As defined in the IEEE 802.3u MII standard, a transceiver shall implement at
least one status register that will contain a defined set of essential information
needed for basic network management. Since the MII does not include an interrupt line, a polling mechanism is required for detecting a status change in
the transceiver. In order to reduce the software overhead, the above mentioned polling mechanism has been implemented in hardware. When this
mode of operation is enabled, the MIF will continuously poll a specified
transceiver register, and generate a maskable interrupt when a status change
is detected. Upon detection of an interrupt, the software can read a local status
register that will provide the latest contents of the transceiver register, and an
indication which bits have changed since it was last read. This mode of oper-
31
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
ation can only be used when the MIF is in the frame mode.
5.2.2.3 Ethernet Transmit Block (ETX)
The Ethernet transmit block provides the DMA engine for transferring frames
from the host memory to the BigMAC. It contains a local buffer of 2K bytes
for rate adaptation between the available bandwidth on the SBus and on the
network.
5.2.2.4 Ethernet Receive Block (ERX)
The Ethernet receive block provides the DMA engine for transferring frames
from the BigMAC to the host memory. It contains a local buffer of 2K bytes
for rate adaptation between the available bandwidth on the network and on
the SBus.
5.2.2.5 Shared Ethernet Block (SEB)
The shared Ethernet block contains common functions that are shared between the ETX and ERX blocks. It performs the first level arbitration between the receive and transmit DMA channels for access to the SBus and
provides one common interface between the Ethernet channel and the SBus
adapter (SBA). It also separates the DMA data path from the programmed I/O
data path.
32
5.2.3 Clock Domains
The Ethernet channel contains three completely asynchronous clock domains.
System Clock Domain
The bulk of the logic in the Ethernet channel is driven off this clock. It is
sourced by the system bus and is defined to be in the range of 16.67 MHz
through 33.33 MHz.
Transmit Clock Domain
This clock is used to drive the transmit protocol engine in the BigMAC core.
It is sourced by the MII and has the operating frequency of 2.5/25 MHz 100
ppm. The 2.5/25 MHz version of this clock (TX_NCLK) is used for byte-tonibble conversion of the data stream to the MII and for synchronization of the
asynchronous signals from the MII (CRS and COLL). The 1.25/12.5 MHz divide-by-two version of this clock (TX_BCLK) is used for transmit protocol
processing and state machine operation.
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
Receive Clock Domain
This clock is used to drive the receive protocol engine in the BigMAC core.
It is sourced by the MII and has the operating frequency of 2.5/25 MHz 100
ppm. The 2.5/25 MHz version of this clock (RX_NCLK) is used for strobing
in the packet data from the MII and for nibble-to-byte conversion of the incoming data stream. The 1.25/12.5 MHz divide-by-two version of this clock
(RX_BCLK) is used for receive protocol processing and state machine operation.
STP2002QFP
5.2.4 Host Memory Data Management
The device driver maintains two data structures in the host memory: one for
transmit and the other for receive packets. Both data structures are organized
as wrap-around descriptor rings. Each descriptor ring has a programmable
number of descriptors (in the range of 16 through 256). Each descriptor has
two entries (words): a control/status word and a pointer to a data buffer.
The interaction between the hardware and the software is managed via a
semaphore (OWN) bit, that resides in the control/status portion of the descriptor. When the OWN bit is set to 1, the descriptor is owned by the hardware.
If the OWN bit is cleared to 0, the descriptor is owned by the software. The
owner of the descriptor is responsible for releasing the ownership when it can
no longer use it. Once the ownership is released, the previous owner may no
longer treat the descriptor contents as valid, since the new owner may overwrite it at any time.
Sun Microsystems,
5.2.5 Transmit Data Descriptor Ring
A transmit packet that is posted by an upper layer protocol to the device driver
may reside in several data buffers (headers and data) which are scattered in
the host memory. When the device driver posts the packet to the hardware, it
allocates a descriptor for each buffer. The descriptor contains the necessary
information about the buffer that the hardware needs for the packet transfer.
When the packet is ready for transmission, the descriptor(s) ownership is
turned over to the hardware, and a programmed I/O command is issued to the
transmit DMA channel to start the packet transfer from the host memory to
the TxFIFO.
When the packet transfer has been completed, the transmit DMA channel
turns over the descriptor ownership back to the driver and polls the next
descriptor in the ring. If the descriptor is owned by the hardware, the next
packet transfer begins. If not, the DMA channel “goes to sleep” until a new
command is issued.
33
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
The size of the descriptor ring is programmable, and it can be varied in the
range of 16–256 in increments of 16 descriptors: 16, 32, 48, ..., 240, 256.
5.2.6 Receive Free Buffer Descriptor Ring
For receive operation, the device driver requests a pool of free buffers from
the operating system. The buffers are posted to the hardware by allocating a
descriptor for each buffer. The descriptor contains the necessary information
about the buffer that the hardware needs for the packet transfer.
When a packet is ready to be transferred from the RxFIFO to the host memory, the receive DMA channel polls the next descriptor in the ring. If the
hardware owns the descriptor (free buffer available), the packet transfer
begins. During the first burst, the receive DMA engine performs header padding of the packet by inserting a programmable number of junk words at the
beginning of the packet.
When the packet transfer has been completed, the receive DMA channel
updates the descriptor with status information about the received packet, and
turns over the descriptor ownership back to the driver. If a packet is ready to
be transferred from the RxFIFO to the host memory but the driver does not
have any free buffers allocated to the hardware, the packet will be dropped
into the bit bucket, and the DMA channel will try again when the next packet
is ready to go.
The size of the descriptor ring is programmable and can assume the following values: 32, 64, 128, 256.
34
5.2.7 Local Memory Data Management
Each DMA channel contains its own dedicated on-chip local buffer of 2K
bytes (fixed) in size. The local buffers are used for temporary storage of packets en route to/from the network, and are organized as wrap-around FIFOs.
In general, the local buffer organization and data structures are invisible to
the software, except for diagnostic purposes.
Since the local buffers reside in the data path, their logical organization
changes depending on the SBus width. For a 32-bit SBus, the FIFO organization is 512 words × 33 bits. For a 64-bit SBus, the FIFOs are organized as 256
words × 65 bits. The extra bits (bit 33 or bit 65) along the word are used as
end-of-packet delimiters (or tags). When a packet is stored in the local buffer,
the tag will be cleared to 0 for the entire data portion of the packet, except for
the last word. The tag will be set to 1 for the last data word of the packet and
for the control/status word.
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
STP2002QFP
5.2.8 Transmit FIFO Data Structures
When a transmit packet is transferred from the host into the local memory, the
first byte of the packet in the FIFO is always loaded to be word (or doubleword) aligned. If the packet is composed of several data buffers, the data buffers are concatenated as a contiguous byte stream in the FIFO (gather function). The last byte of a packet can reside at any byte boundary, therefore the
last data word of the packet is marked by a tag. At the end of the packet a control word is appended, which is again marked by a tag bit. The control word
indicates the last byte boundary for the packet.
5.2.9 Receive FIFO Data Structures
When a receive packet is transferred from the RX_MAC into the local memory, the half-word (16-bit) data stream is packed into words (or double
words), with the first byte of the packet starting at a programmable offset
within the first word.
Even though the receive data structure’s functionality does not require to
tag the last data word of a packet, the hardware will do that to provide a more
robust implementation.
At the end of the packet a status word is appended, which is again marked
by a tag bit. This word provides status information about the received frame,
which is either passed to the device driver or used for unloading the frame
from the RxFIFO.
Sun Microsystems,
35
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
5.3 Error Conditions and Recovery
There are two types of error conditions that can be encountered during the
normal operation of the Ethernet channel: fatal errors and non-fatal errors. Fatal errors are errors that should never occur. They usually indicate a serious
failure of the hardware or a serious programming error. When this type of error occurs, the recovery process is non-graceful. The corresponding DMA
channel will freeze, and the software is expected to reset the channel after the
appropriate actions are taken to correct the failure. Fatal error events are always reported to the software via an interrupt. Non-fatal errors are errors that
are expected to occur when certain conditions occur on the network or in the
system. When this type of error occurs, a graceful recovery mechanism is provided via a combination of hardware and software, as described below. Nonfatal errors may or may not be reported to the software.
5.3.1 Fatal Errors
The error conditions described below can occur both in the transmit and in the
receive DMA channels.
Master_Error_Ack
This error condition indicates that an SB_ERR_ACK was detected by the
DMA channel during a DVMA cycle.
36
Slave_Error_Ack
This error condition indicates that an SB_ERR_ACK was generated by the
DMA channel during a programmed I/O cycle. The hardware will generate
an SB_ERR_ACK if a programmed I/O cycle is executed with SB_SIZE other than a word transfer.
Late_Error
This error condition indicates that an SB_LATE_ERROR was detected by the
DMA channel during a DVMA cycle.
DMA_Read_Parity_Error
This error condition indicates that a parity error was detected by the DMA
channel during a DVMA read cycle.
Slave_Write_Parity_Error
This error condition indicates that a parity error was detected by the DMA
channel during a
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
programmed I/O write cycle.
FIFO_Tag_Error
The data structures in the local FIFOs make use of tag bits for delimiting
packet boundaries. The last data word and the control/status word of a frame
are expected to have their tag bits set to 1. If the unload control state machine
does not see two consecutive tag bits set to 1, a local memory failure is recognized, and the unloading process is aborted.
STP2002QFP
5.3.2 Non-Fatal Errors
The error conditions described below can occur in the specified DMA channel only.
Tx_FIFO_Underrun
This error condition can occur only when the programmable threshold is used
to enable transmission of the frame by the TX_MAC (the threshold value is
less than the maximum frame size). If the available bandwidth on the SBus
dedicated to transmit DMA is less than the available throughput on the network, the TxFIFO may run out of data before the frame transmission has
completed. The TX_MAC may become “starved” for data, and the frame
transmission is aborted. The unloading of the frame from the FIFO will continue until the entire frame is transferred to the TX_MAC, but the TX_MAC
will drop the remainder of the frame into the bit bucket. The TX_MAC will
generate an interrupt to the device driver to indicate the occurrence of this
event.
Sun Microsystems,
Rx_Abort (Early and Late)
A receive frame can be aborted for various reasons at any time during the
frame transfer from the network to the host memory. The intent of the provided abort mechanism is to utilize the available hardware resources efficiently,
without incurring unnecessary performance penalties.
If an abort condition is detected before the frame transfer has begun from
the RX_MAC into the RxFIFO (address detection criteria, short fragment,
etc.), the RX_MAC drops the frame and the receive DMA channel never sees
it.
If an abort condition occurred after the frame transfer from the RX_MAC
into the RxFIFO has begun, but before at least 128 bytes of data were transferred from the RX_MAC to the RxFIFO (long fragment, etc.), the load
control state machine rewinds the write pointer to the shadow write pointer
37
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
and gets ready to receive the next frame. This way the FIFO locations that
were occupied by the long fragment are reused by the next frame.
If an abort condition is detected after at least 128 bytes of data were transferred from the RX_MAC to the RxFIFO (very long fragment, CRC error,
code error on the media, etc.), the load control state machine sets the abort bit
in the status word that is appended to the frame and gets ready to receive the
next frame. When the aborted frame is unloaded from the RxFIFO, the unload
control state machine detects the abort bit in the status word and reuses the
current descriptor (host data buffer) for the next frame.
This error condition is not reported to the software, but the events causing
it have their individual reporting mechanisms.
Rx_FIFO_Overflow
If the available bandwidth on the SBus dedicated to receive DMA is less than
the available throughput on the network, the RxFIFO may run out of space
and not be able to receive any more data from the RX_MAC. This condition
propagates to the RX_MAC, and when it runs out of space in its synchronization FIFO the frame is aborted using the Rx_ABORT mechanism that was
described above.
The RX_MAC will continue to receive the frame from the network, but the
remainder of the frame is dropped “on the floor.” The RX_MAC will generate an interrupt to the device driver to indicate the occurrence of this event.
38
Rx_Buffer_Not_Available
When a receive frame is ready to be transferred to the host memory, the DMA
control state machine fetches the next descriptor from the ring. If the descriptor is not owned by the hardware, the error condition is encountered. The unloading process unloads the frame from the RxFIFO and drops it “on the
floor.” When the next frame in the FIFO is to be unloaded, the DMA control
state machine polls the descriptor again. An interrupt is generated to the device driver to indicate the occurrence of this event.
Rx_Buffer_Overflow
The unloading process transfers frames from the RxFIFO to data buffers in
the host memory. If the size of a buffer in the host memory is smaller than the
frame size, the buffer is filled up and the remainder of the frame is dropped
“on the floor.” This error condition is not reported to the software via an interrupt. Instead, when the descriptor is returned to the device driver, an overflow status bit is set in the descriptor. Also, the length field in the descriptor
specifies the actual size of the frame received.
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
STP2002QFP
5.4 Programmer’s Reference
5.4.1 Overview
During normal operation, the software-to-hardware interaction is primarily
performed via the host memory data structures, with a minimal command/status handshake (less than one interrupt per packet). Software intervention is required for initialization of the hardware after resetting the channel, for
network management, for error recovery, and for diagnostic purposes. Local
FIFOs’ data structures and most of the registers are invisible to the software,
except for diagnostic purposes.
5.4.2 Host Memory Data Structures
The host memory data structures are organized as wrap-around descriptor
rings of programmable size. The transmit and receive data structures are very
similar, except for three major differences:
1. Descriptor layout
2. Number of descriptors per packet: one for receive, unlimited for
transmit
3. Data buffer alignment restrictions: none for transmit, one for
receive
Programming Note: The pointers to descriptor ring base addresses
must be 2K-byte aligned.
Sun Microsystems,
39
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
5.4.3 Transmit Data Structures
Table 10: Transmit Data Structure Descriptor Layout: Control Word
Field Bits Description
Data buffer size 13:0 Indicates the number of data bytes in the buffer.
All values are legal in a 16-KB range, including
0
Checksum start offset 19:14 Indicates the number of bytes from the first byte
of the packet that should be skipped before the
TCP checksum calculation begins. This field is
only meaningful if the Checksum Enable bit is
set to 1
Checksum stuff offset 27:20 Indicates the byte number from the first byte of
the packet that will contain the first byte of the
computed TCP checksum. This field is only
meaningful if the checksum enable bit is set to 1
Checksum enable 28 If set to 1, the computed TCP checksum will be
stuffed into the packet
End of packet 29 When set to 1, indicates the last descriptor of a
transmit packet
Start of packet 30 When set to 1, indicates the first descriptor of a
transmit packet
Ownership semaphore 31 To turn over ownership, the hardware clears this
bit, and the software sets it
40
Table 11: Transmit Data Structures: Descriptor Layout: Data Buffer
Pointer
Field Bits Description
Data buffer pointer 31:0 This 32-bit pointer indicates the first data byte of the
transmit buffer
Programming Restrictions:
• If a packet occupies more than one descriptor, the software must turn
over the ownership of the descriptors to the hardware last-to-first, in
order to avoid race conditions.
• If a packet resides in more than one buffer, the Checksum_Enable,
Checksum_Stuff_Offset and Checksum_Start_Offset fields must have
the same values in all the descriptors that were allocated to the packet.
• The hardware implementation relies on the fact, that if a buffer starts
at an odd byte boundary, the DMA state machine can rewind to the
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
nearest burst boundary and execute a full DVMA burst read.
STP2002QFP
Packet #1
Packet #2
Packet #3
Descriptor
#0
#n
#n+1
#n+2
#n+3
Last Descriptor
Control Word
Data Buffer Pointer
Control Word
Data Buffer Pointer
Control Word
Data Buffer Pointer
Control Word
Data Buffer Pointer
Control Word
Data Buffer Pointer
Control Word
Data Buffer Pointer
031
Sun Microsystems,
31 30 29 28 27 20 19 14 13 0
OWN
SOP
EOP
CHK
Checksum_Stuff_Offse Checksum_Start_Offse Tx_Data_Buffer_Size
SM
Enable
Tx_Data_Buffer_Pointer
Figure 10. Transmit Host Data Structures
41
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
5.4.4 Receive Data Structures
Table 12: Receive Data Structures Descriptor Layout: Status Word
Field Bits Description
TCP checksum 15:0 This field contains the 16-bit TCP checksum
that was calculated on the entire frame. It will
be updated for every frame that was received
from the network. The software has the choice
of either making use of it or ignoring it.
Free_buffer/Packet_data size 29:16 When the descriptor ownership is passed from
the software to the hardware, this field contains the size of the free buffer that was
allocated for the packet. When the descriptor
ownership is passed from the hardware to the
software, this field indicates the actual number
of packet data bytes that were dumped into the
buffer.
Overflow 30 When an Rx_Buffer_Overflow condition
occurs, this bit will be set to 1 for the frame
that could not fit into the allocated buffer.
Ownership semaphore 31 To turn over ownership, the hardware clears
this bit and the software sets it.
End of packet 29 When set to 1, indicates the last descriptor of
a transmit packet.
Start of packet 30 When set to 1, indicates the first descriptor of
a transmit packet.
Ownership semaphore 31 To turn over ownership, the hardware clears
this bit and the software sets it.
42
Table 13: Receive Data Structures: Descriptor Layout: Free Buffer Pointer
Field Bits Description
Free buffer pointer 31:2 This 29-bit pointer, points to the beginning of the free
buffer. The first byte of the actual packet data inside the
buffer will always reside at a programmable offset from
this location, but within a double-word range.
Programming Restrictions:
• Free receive data buffers must be 64-byte aligned.
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
STP2002QFP
5.4.5 Local Memory Data Structures
The local memory data structures are organized as wrap-around FIFOs that
can store an unlimited number of packets. The transmit and receive data
structures are very similar, except for the format of the control/status word
that is appended to the end of a packet and the alignment of the first byte of a
packet when it is loaded into the FIFO. Also, the RxFIFO does not have a
shadow read pointer. The logical organization of the FIFOs changes depending on the SBus configuration. For a 32-bit SBus, the FIFO organization is
512 words × 33 bits. For a 64-bit SBus, the FIFOs are organized as 256 words
× 65 bits. The 512 words × 33 bits configuration makes use of both the Tag_0
and the Tag_1 bits in the FIFO, while the 256 words × 65 bits configuration
uses only the Tag_0 bit.
On the diagrams shown below, frames #1 and #2 represent a 512 words ×
33 bits configuration, and frame #n represents a 256 words × 65 bits configuration. In reality, of course, only one configuration is used at a given time.
The configuration is selected by programming the extended transfer mode bit
in global configuration register. The amount of “junk” at the beginning of a
frame in the RxFIFO is determined by the first_byte_offset field in the ERX
configuration register.
Sun Microsystems,
43
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
Packet #1
Packet #2
Packet #n
Descriptor
Descriptor
Descriptor
Last Descriptor
31 30 29 16 15 0
Over-
OWN
Flow
31
#0
#1
#n
Free_Buffer/Packet_Data Size TCP_Checksum
Status Word
Free Buffer Pointer
Status Word
Free Buffer Pointer
Status Word
Free Buffer Pointer
Status Word
Free Buffer Pointer
Free Buffer Pointer
0
1
Reserved
44
Figure 11. Receive Host Data Structure
The software has the capability to read and write the FIFOs (including
tags) at any time, using programmed I/O instructions. This feature should be
used for diagnostic purposes only. During normal operation, the FIFOs are
invisible to the software.
5.4.6 TxFIFO Data Structures
Table 14: TxFIFO Data Structures: Control Word Layout
Field Bits Description
Last byte boundary 2:0 This field indicates the offset of the last byte of the packet
within the last data word (or double word), depending on the
configuration, in the FIFO
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
STP2002QFP
Figure 12 below shows the organization of the TxFIFO. The first byte of
the frame is always loaded to be word or double-word aligned.
5.4.7 RxFIFO Data Structures
Table 15: RxFIFO Data Structures: Status Word Layout
Field Bits Description
Frame checksum 15:0 This field contains the 16-bit TCP checksum for the
frame, as computed during the frame transfer from the
Rx_MAC to the RxFIFO.
Frame size 26:16 This field indicates the size of the frame in bytes as cal-
culated by the Rx_MAC
30 Reserved
Receive abort 31 This bit communicates the occurrence of a late abort
event to the unload control state machine. The frame
should be dropped and the descriptor reused for the next
frame.
Figure 13 below shows the organization of the RxFIFO. The first byte of
the frame is always loaded at a programmable offset within the first word or
double word.
Sun Microsystems,
45
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
Addr_0
Shadow
Read_Ptr
Read_Ptr
Shadow
Write_Ptr
Write_Ptr
Addr 255
Tag_0
0
.
.
.
.
0
0
1
0
.
.
.
.
0
0
1
0
.
.
.
.
.
0
.
.
.
0
0
1
1
63
Frame #1 Data
Frame #2 Data
Frame #2 Control
Frame #3 Data
.
.
.
.
Frame #n Data
Frame #n Control
junk
junk
Tag_1
32
0
.
.
.
.
0
0
1
0
.
.
.
.
0
1
0
.
.
.
.
.
.
x
x
x
x
x
x
x
x
Frame #1 Data
Frame #1 Control
Frame #2 Data
junk
Frame #3 Data
.
.
.
.
Frame #n Data
junk
Frame #n Control
031
32-Bit
Mode
Wrap-
Around
FIFO
64-Bit
Mode
46
Tag_0/Tag_1
1
Reserved
2
Byte
Boundary
0
Frame Control
Word
Figure 12. TxFIFO Organization
5.4.8 Other User Accessible Resources
Besides the host and local memory data structures, the hardware provides a
programmed I/O path to a variety of hardware resources for initialization, error recovery, diagnostics, and network management. From the software perspective, all the programmable resources should be treated as 32-bit entities.
If not all 32 bits are used in a register, the unused bits are grouped as the most
significant bits of the word. Register fields that are not used are ignored during a PIO write, and return 0s during a PIO read. The description of these resources is grouped by functionality and not necessarily by their physical
location. The default value for all the registers/counters is 0x00000000, un-
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
less specified otherwise.
STP2002QFP
Addr_0
Read_Ptr
Shadow
Write_Ptr
Write_Ptr
Addr 255
Tag_0
0
.
.
.
.
0
0
1
0
.
.
.
.
0
0
1
0
.
.
.
.
.
0
.
.
.
0
0
1
1
63
junk
Frame #1 Data
junk
Frame #2 Data
Frame #2 Control
junk
Frame #3 Data
.
.
.
.
junk
Frame #n Data
Frame #n Control
junk
junk
Tag_1
32
0
.
.
.
.
0
0
1
0
.
.
.
.
0
1
0
.
.
.
.
.
.
x
x
x
x
x
x
x
x
Frame #1 Data
Frame #1 Control
Frame #2 Data
junk
Frame #3 Data
.
.
.
.
Frame #n Data
junk
Frame #n Control
031
32-Bit
Mode
Wrap-
Around
FIFO
64-Bit
Mode
Tag_0/Tag_1
Sun Microsystems,
29
3031
Rx_
1
Abort
Rsrvd
Frame Size
16
15 0
Figure 13. RxFIFO Organization
Frame Checksum
Frame Status
Word
47
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
TESTABILITY 6
6.1 Introduction
This section describes the features of the JTAG Test Access Port (TAP) and
other testability structures for the FEPS. The JTAG macro which implements
the IEEE Standard 1149.1-1990 provides access to the test structures on the
chip.
The TAP includes the TAP controller state machine, an instruction register, a bypass register, a device identification register, and the necessary
decoding logic. The TAP requires five dedicated pads: test data input (TDI),
test data output (TDO), test mode select (TMS), test clock (TCK), and test
reset (TRST).
6.2 JTAG Macro
ISCAN_MODE
JTAG_TCK
JTAG_TMS
JTAG_TDI
JTAG_TRST
BSCAN_TDO
ISCAN_SO
JTAG_CONTR
Figure 14.
JTAG_TDO_EN
BSCAN_CDR
BSCAN_SDI
BSCAN_SDR
BSCAN_UDR
BSCAN_IMC
BSCAN_OMC
JTAG_TDO
ISCAN_CLK
ISCAN_SDR
SCSI_SELECT
ISCAN_SDI
48
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
Table 16: JTAG Macro I/O Signals
JTAG_TCK JTAG clock from chip pads
JTAG_TDI JTAG test data in from chip pads
JTAG_TDO JTAG test data out to chip pads
JTAG_TRST JTAG test reset from chip pads
JTAG_TMS JTAG mode select from chip pads
JTAG_TDO_EN JTAG test data out enable to chip pads
BSCAN_CDR Boundary scan clock data register
BSCAN_SDI Boundary scan data input (to BSCAN cells)
BSCAN SDR Boundary scan shift data register
BSCAN_UDR Boundary scan update data register
BSCAN_IMC Boundary scan input mode control
BSCAN_OMC Boundary scan output mode control
BSCAN_TDO Boundary scan test data output
ISCAN_CLK Internal scan clock
ISCAN_SDR Internal shift select
ISCAN_SDI Internal scan data input
ISCAN_TDO Internal scan test data output
SCSI_SELECT SCSI test mode select signal
ISCAN_MODE Internal scan mode select signal
STP2002QFP
Sun Microsystems,
The above signals describe the I/O signals of the JTAG macro. The JTAG
macro is composed of the following blocks: TAP controller, instruction register, instruction decode logic, bypass register, internal register clocking
logic, JTAG ID register, JTAG boundary scan control logic, and the TDO
MUX logic.
The following sections describe each of these blocks.
6.2.1 TAP Controller
The TAP controller is a 16-state finite state machine. Transitions between
states occur synchronously at the rising edge of JTAG_TCK in response to
the JTAG_TMS signal or when JTAG_TRST goes low.
49
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
DR_CLOCK
JTAG_TCK
JTAG_TMS
JTAG_TRST
JTAG_TAP
DR_UPDATE
DR_SHIFT
IR_CLOCK
IR_SHIFT
JTAG_TDO_EN
REG_SEL
TAP_RESET
DR_CAPTURE
IR_UPDATE
Figure 15.
6.2.2 Instruction Register
The instruction register is used to select the test to be performed and/or the
test data register to be accessed. The FEPS instruction register is four bits
wide and is a shift register with parallel load and parallel outputs. At the start
of an instruction register shift cycle (during the CAPTURE-IR state), the least
two significant bits are loaded with 01 pattern. During the TEST-LOGIC-RESET controller state the instruction register must have the IDCODE. The instruction register state is updated at the falling edge of the JTAG_TCK. The
shifting of the instruction register occurs at each rising edge of JTAG_TCK.
50
IR-CLOCK
IR_SHIFT
JTAG_TDI
IR_UPDATE
TAP_RESET
IR_TDO
JTAG_JR
IR_VALUE[3:0]
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
STP2002QFP
Figure 16.
The following instructions are supported in the FEPS.
Table 17: FEPS-Supported Instructions
Value Instruction Scan Chain IMC OMC BCAP ICAP
0000 Extest Boundary 0 1 1 0
0001 Sample Boundary 0 0 1 0
0010 Intscan Internal 0 0 0 1
0011 ATPG ATPG 1 1 1 1
0100 Debug Internal 1 1 0 0
0101 Reserved Bypass 0 0 0 0
0110 Clamp Bypass 1 1 0 0
0111 Intest Boundary 1 1 1 0
1000 Reserved Bypass 0 0 0 0
1001 SCSI_TEST Bypass 0 0 0 0
1010 Reserved Bypass 0 0 0 0
1011 Reserved Bypass 0 0 0 0
1100 SEL_CCR CCR 0 0 0 0
1101 Reserved Bypass 0 0 0 0
1110 IDCODE ID 0 0 0 0
1111 Bypass Bypass 0 0 0 0
Sun Microsystems,
• IMC1 = core driven by boundary scan (BS) cell, 0 = core driven by pin
• OMC1 = pin driven by BS cell, 0 = pin driven by core
• BCAP1 = capture clock generated for BS cell, 0 = no clock
• ICAP1 = capture clock generated for internal flops, 0 = no clock
51
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
6.2.3 Instruction Decode Logic
BYPASS_SELECT
ID_SELECT
ISCAN_MODE
ATPG_SELECT
IR_VALUE[3:0]
JTAG_DECODE
INTERNAL_SELEC
T
DEBUG_SELECT
BSCAN_SELECT
SCSI_SELECT
CCR_SELECT
BSCAN_OMC
Figure 17.
The instruction decode logic decodes the value at the parallel outputs of the
instruction register and selects the appropriate scan data register and control
signals.
52
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
STP2002QFP
TDI
ATPG_MODE
MUX
BSCAN_CDR
ISCAN_CLK
IR_CLOCK
DR_CLOCK
DR_CLOCK
DR_CLOCK
Boundary Scan Register
Internal Scan Register
JTAG Instruction Register
MUX
JTAG ID Register
Bypass Register
Clock Control Register
Test Mode Selects
Figure 18.
6.2.4 Bypass Register
The bypass register provides a minimum length path between the test data input and the test data output. It consists of a single shift-register stage that
loads a constant 0 in the Capture-DR TAP controller state when the mandatory BYPASS instruction is selected.
Sun Microsystems,
JTAG_TDI
DR_CLOCK
DR_SHIFT
BYPASS_SELEC
T
JTAG_BYPASS
Figure 19.
BYPASS_TDO
53
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
6.2.5 Internal Register Clocking Logic
This module generates the scan clock for the internal scan flops and the scan
enable to for the scan flops.
ISCAN_MODE
DEBUG_SELEC
T
IS_CLOCK
DR_CLOCK
DR_CAPTURE
DR_SHIFT
ISCAN_DR
ISCAN_CLK
Figure 20.
6.2.6 JTAG ID Register
This is a 32-bit shift register which has four fields. The least significant bit is
a 1, the next 11 bits [11:1] are the manufacturer’s ID, the next 16 bits [27:12]
are the chip ID, and the most significant 4 bits [31:28] are the chip vintage.
The JTAG ID for FEPS Rev 1.0 is 01792045 hex, for FEPS Rev 2.0 and 2.1
it is 11792045 hex, and for FEPS Rev 2.2 it is 21792045 hex.
JTAG_TDI
DR_CLOCK
JTAG_ID
DR_SHIFT
ID_TDO
54
ID_SELECT
Figure 21.
6.2.7 Boundary Scan Control Logic
This block generates the boundary scan clock and the boundary scan shift and
update signals which form part of the boundary scan control bus that runs
along the boundary scan chain. This control bus feeds the boundary scan
cells.
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
STP2002QFP
DR_CLOCK
DR_UPDATE
JTAG_BS
DR_SHIFT
BSCAN_SELECT
BSCAN_CDR
BSCAN_UDR
BSCAN_SDR
Figure 22.
6.2.8 TDO MUX logic
This block implements the muxing of the signal which is to appear at the TDO
output pin. It has one flop to ensure that changes on the TDO pin happen on
the falling edge of JTAG_TCK when the data is not being shifted in the data
registers. When data is not being shifted through the chip, TDO is set to a
high-impedance state.
BYPASS_TDO
ISCAN_TDO
BSCAN_TDO
ID_TDO
IR_TDO
JTAG_TDO
Sun Microsystems,
CCR_TDO
BYPASS_SELECT
CCR_SELECT
ID_SELECT
ATPG_SELECT
ISCAN_MODE
REG_SEL
JTAG_TCK
BSCAN_SELECT
JTAG_TDI
JTAG_TDO_M
BSCAN_SDI
55
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
Figure 23.
6.3 Special JTAG Instructions
In addition to the mandatory instructions, the FEPS JTAG implements some
special instructions.
6.3.1 Debug Modes
6.3.1.1 Dumping Internal State
Using the DEBUG instruction, the internal chain can be selected. This instruction provides nondestructive internal node visibility during lab debug.
No capture clock is issued for this instruction. While the debug instruction is
selected, both the inputs and outputs are defined by the contents of the boundary scan register.
6.3.1.2 Clock Controller
The clock controller will deterministically stop FEPS internal clocks upon the
occurrence of an external event. The clock controller can only be accessed via
the CCR scan chain. This chain is selected via the SEL_CCR instruction.
The clock controller consists of a stop enable bit and three synchronizers
for the SBus, ENET-Tx, and ENET-Rx domains. When the stop bit is set, the
clock_stop signal will switch the source of the internal clock from the clock
pins to the internal controller. This clock source switching is synchronized to
the rising edge for each clock domain.
56
6.3.2 INTEST
INTEST can be used to apply stimulus to test the on-chip logic when the chip
sits on a board. This requires that the core be driven off the input boundaryscan cells and the core drives the output boundary-scan cells. For this we require that the clock pads be made controllable via boundary scan. INTEST
can also be used to apply burn-in vectors if the burn-in tester is pin limited
and can’t accommodate all the FEPS pins.
6.3.3 SCSI Test Mode
The SCSI Test mode will provide access to the I/O signals of the SCSI
FAS366 core through the I/O pins. This mode isolates the SCSI core by providing controllability and observability to its I/O signals. The vectors applied
will yield 95% coverage in the SCSI core area which does not have internal
scan.
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
STP2002QFP
6.4 Clock Stop Pin
This pin can deterministically stop the clocks in FEPS. After the instruction
register is updated with the SEL_CCR instruction, an initializing pattern is
loaded into the CCR scan data register. In the run-test/idle state, any external
event which triggers the clock stop pin will switch the clock source from the
clock pins to the ISCAN_CLK signal generated by the JTAG logic. This signal is held high in the run-test/idle controller state. The switching is synchronized with the rising edge of the clocks of the respective clock domains.
The clocks that need to be stopped are those that are those that control the
flops in the full scan area which are the SBus, ENET-Tx, and ENET-Rx
clocks.
Int_Scan_Enable shifts the clock between the SBus_CLK and the
ISCAN_CLK. This clock tree feeds the scan flops in the SBA, parallel port,
and SCSI DMA where the scan flops have the same system and scan clock.
ENET_Tx_Scan_En is the clock enable for the scan flops in the Ethernet
Tx clock domain. Here the scan flops have TX_CLK as the system clock and
a SBUS_CLK as the scan clock. ENET_Rx_Scan_En is the clock enable for
the scan flops in the Ethernet Rx clock domain. Here the scan flops have
RX_CLK as the system clock and a SBUS_CLK as the scan clock.
Sun Microsystems,
6.5 Test Vectors
The RAMs and data buffers are tested using high-coverage functional vectors
which target memory-specific faults. The full scan area is tested by combinational ATPG vectors which yield a high fault coverage.
57
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
PROGRAMMING MODEL 7
7.1 Introduction
Refer to the FEPS application note (STB0106) for programming notes and a
complete address map for the registers for all interfaces.
7.2 Parallel Port Channel Registers
7.2.1 Control/Status Register
Table 18: Control/Status Register Address
Register Physical Address Access Size
Control/Status register (P_CSR) 0xC80_0000 4 bytes
Table 19: Control/Status Register Definition
Field Bits Description Type
P_INT_PEND 0 Set when a PP DMA or PP control interrupt is pending or when P_TC is set
and P_TCI_DIS is not set.
P_ERR_PEND 1 Set when an interrupt is pending due to an SBus error condition. R
P_DRAINING 3:2 Both bits set when the P_FIFO is draining to memory, otherwise both bits are
0.
P_INT_EN 4 When set, enables SB_P_IRQ to become active when either P_INT_PEND or
P_ERR_PEND is set.
P_INVALIDATE 5 When set, invalidates the P_FIFO. Resets itself. Reads as 0. W
P_SLAVE_ERR 6 Set on slave access size error to a PP register. Reset by P_RESET,
P_INVALIDATE, or writing to 1.
P_RESET 7 When set, acts as a hardware reset to the parallel port only. R/W
P_WRITE 8 DMA direction. 1 = to memory; 0 = from memory R
P_EN_DMA 9 When set, enables DMA transfers to/from the PP. R/W
12:10
P_EN_CNT 13 When set, enables the PP byte counter to be decremented R/W
P_TC 14 Terminal count. Set when byte count expires. Reset on write of 1 if
P_EN_NEXT=1.
REV_MIN [2:0] 17:15 FEPS minor revision number
P_BURST_SIZE 19:18 Defines sizes of SBus read and write bursts for PP transfers. R/W
P_DIAG 20 When set, disables draining and resetting of P_FIFO on loading of P_ADDR
22:21
register.
R
R
R/W
R/W
R/W
R/W
58
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
STP2002QFP
Table 19: Control/Status Register Definition
Field Bits Description Type
P_TCI_DIS 23 When set, disables P_TC from generating an interrupt. R/W
P_EN_NEXT 24 When set, enables DMA chaining and next address/byte count auto-load
mechanism. P_EN_CNT must also be set.
P_DMA_ON 25 DMA On. When set, indicates that DMA transfers are not disabled due to any
hardware or software condition.
P_A_LOADED 26 Set when the contents of the address and byte count are considered valid dur-
ing chained transfers.
P_NA_LOADED 27 Set when next address and byte count registers have been written but have not
been used for chaining.
REV_MAJ [3:0] 31:28 FEPS major revision number R
The RESET state of this register is as follows:
P_ERR_PEND = 0 P_INT_EN = 0
P_INVALIDATE = 0 P_SLAVE_ERR = 0
P_RESET = 0 P_EN_DMA = 0
P_EN_CNT = 0 P_TC = 0
P_BURST_SIZE = 0 P_TCI_DIS = 0
P_EN_NEXT = 0 P_DMA_ON = 0
P_A_LOADED = 0 P_NA_LOADED = 0
P_WRITE = 1
R/W
R
R
R
Sun Microsystems,
P_INT_PEND:
Interrupt pending is the logical OR of the following enabled PP interrupt
sources:
(P_TC and !P_TCI_DIS), DS_IRQ, ACK_IRQ, BUSY_IRQ, ERR_IRQ,
PE_IRQ, SLCT_IRQ.
P_ERR_PEND:
Error pending will be set due to an SBus error acknowledge or an SBus late
error. It indicates an SBus error condition. PP DMA is stopped
(P_DMA_ON=0) when this bit is set. This bit can be reset by setting
P_INVALIDATE or P_RESET.
P_DRAINING:
When P_FIFO is draining to memory, both bits are set. Do not assert
P_RESET or P_INVALIDATE or write to the P_ADDR register when set.
59
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
P_DRAINING bits are not valid while P_ERR_PEND is set and should be ignored.
P_INVALIDATE:
Setting this bit invalidates the P_FIFO. If P_ERR_PEND = 0 when
P_INVALIDATE is set, all dirty data in the P_FIFO will first be drained to
memory. If P_ERR_PEND = 1 when P_INVALIDATE is set, all dirty data
in the P_FIFO will be discarded. In addition to invalidating the P_FIFO, setting this bit causes P_ERR_PEND and P_TC to be reset. If P_EN_NEXT =
1, P_A_LOADED, and P_NA_LOADED will also be reset.
P_RESET:
This bit functions as a hardware reset to the parallel port. It will remain active
once written to one until written to zero, unless cleared by an SBus reset
(SB_RESET asserted). Setting P_RESET or asserting SB_RESET will invalidate the P_FIFO and reset all parallel port interface state machines to their
idle states. If P_ERR_PEND = 0 when P_RESET is set, all dirty data in the
P_FIFO will first be drained to memory. When this occurs, P_RESET must
not be cleared until draining is complete, as indicated by P_DRAINING = 00.
If P_ERR_PEND = 1 when P_RESET is set, no draining will take place and
all dirty data in the P_FIFO will be discarded.
60
P_WRITE:
This read only bit reflects the direction for DMA transfers. It is a logical OR
of the DIR bit of the parallel control register (P_TCR) and the MEM_CLR bit
of the parallel operation control register (P_OCR).
P_EN_DMA:
When set, enables DMA transfer to/from parallel port. Loss of data may occur
when DMA is disabled in the middle of a data transfer from parallel port.
P_TC:
This bit will be set when the byte counter (P_BCNT) transitions to/from
0x000001 to 0x000000. This will generate an interrupt if enabled by
P_INT_EN and not disabled by P_TCI_DIS. During unchained transfers,
P_TC causes P_DMA_ON to be reset. When P_EN_NEXT = 0, P_TC is
cleared by P_INVALIDATE, P_RESET, or SB_RESET. When
P_EN_NEXT = 1, P_TC can also be cleared by writing a 1 to it.
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
STP2002QFP
P_BURST_SIZE:
This field defines the sizes of SBus read and write bursts used by the FEPS
for parallel port transfers. All reads from memory will be one size, either 4,
8, or 1 word (in “no burst mode). SBus writes to memory can be byte, halfword, or one of the burst sizes given in the table. The FEPS will always use
the largest possible size for writes, which is dependent on P_BURST_SIZE
and the number of bytes that need to be drained. Also, P_BURST_SIZE determines the draining level of the P_FIFO. When the P_FIFO has been filled
with this amount of data, it will always be drained to memory. The sizes given
in Table 20 are in SBus words.
Table 20:
P_BURST_SIZERD_BURST_SIZ
E WR_BURST_SIZES FIFO_Draining_Level
00 4 words 4 words 4 words
01 8 words 4, 8 words 8 words
10 No bursts
11 Reserved Reserved Reserved
1
SBus reads are always one word in no burst mode.
1
No bursts 1 word
Sun Microsystems,
P_DMA_ON:
When set, indicates that the FEPS is able to respond to parallel port DMA requests. Reads as 1 when (P_A_LOADED or P_NA_LOADED) and
P_EN_DMA & !(P_ERR_PEND); otherwise reads as 0.
REV_MIN [2:0]:
FEPS minor revision number.
REV_MAJ [3:0]:
FEPS major revision number. Starts from 2.
Example: for Rev x.y silicon, the {REV_MAJ[3:0], REV_MIN[2:0] = [x,y]}
61
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
7.2.2 DMA Address and Next Address Register
Table 21: DMA Address and Next Address Register Address
Register Physical Address Access Size
DMA address and next address register (P_ADDR) 0xC80_0004 4 bytes
Table 22: DMA Address and Next Address Register Definition
Field Bits Description Type
P_ADDR 31:0 DVMA address register R/W
P_NEXT_ADDR 31:0 Next DVMA address register W
This 32-bit read/write register contains the virtual address for parallel port
DMA transfers. It is implemented as a 32-bit loadable counter which points
to the next byte that will be accessed via the parallel port.
If the P_EN_NEXT (enable next address) bit in the P_CSR is set, then a
write to the P_ADDR register will write to the P_NEXT_ADDR register
instead. If P_EN_NEXT is set when the byte counter (P_BCNT) expires, and
the P_NEXT_ADDR register has been written since the last time the byte
counter expired, then the contents of P_NEXT_ADDR are copied into
P_ADDR. If P_EN_NEXT is set when the byte counter (P_BCNT) expires,
but the P_NEXT_ADDR register has not been written since the last time the
byte counter expired, then DMA activity is stopped and DMA requests from
the parallel port will be ignored until P_NEXT_ADDR is written or
P_EN_NEXT is cleared. (Also, the P_DMA_ON bit will read as 0 while
DMA is stopped because of this.) When DMA is re-enabled by writing to the
P_NEXT_ADDR register, the contents of P_NEXT_ADDR are copied into
P_ADDR before DMA activity actually begins.
62
Note: A write to the P_ADDR register will invalidate the P_FIFO. A
write to the P_NEXT_ADDR register does not have this effect.
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
STP2002QFP
7.2.3 Byte Count Register
Table 23: Byte Count Register Address
Register Physical Address Access Size
Byte count register (P_BCNT) 0xC80_0008 4 bytes
Table 24: Byte Count Register Definition
Field Bits Description Type
P_BCNT 23:0 DMA byte count register R/W
P_NEXT_BCNT 23:0 Next DMA byte count register W
This register is implemented as a 24-bit down counter. When reading this register as a word, bits 31:24 will read as 0s. The register should be loaded with
a 24-bit byte count which, if enabled via the P_EN_CNT bit in the P_CSR,
will be decremented every time a byte is transferred between the FEPS and
whatever external device is connected to the parallel port. During a transition
of this register from 1 to 0, the terminal count signal (P_TC), will generate an
interrupt if not disabled via the P_TCI_DIS bit of the P_CSR.
If the P_EN_NEXT bit in the P_CSR is set, then a write to the P_BCNT
register will write to the P_NEXT_BCNT register instead. Whenever the
P_NEXT_ADDR register is copied into the P_ADDR register, the
P_NEXT_BCNT register is copied into the P_BCNT register at the same
time. If P_NEXT_ADDR is being copied in P_ADDR and P_NEXT_BCNT
has not been written since the last time P_NEXT_BCNT was copied in
P_BCNT, the last value that was written into P_NEXT_BCNT will again be
copied into P_BCNT. This provides a shortcut in setting up consecutive
DMA transfers of equal size from different addresses, in that
P_NEXT_BCNT only needs to be written once as long as P_NEXT_ADDR
is loaded for each successive transfer. If P_EN_NEXT is not set when
P_BCNT expires (changes from 0x000001 to 0x000000), then parallel port
DMA activity will be stopped and the P_DMA_ON bit will read as 0 until
P_ADDR is written. If P_EN_NEXT is set, then DMA will be stopped on
P_BCNT expiration.
Sun Microsystems,
Note: Loading P_BCNT with 0 will allow 2**24 bytes to be transferred before it expires.
63
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
7.2.4 Test Control/Status Register
Table 25: Test Control/Status Register Address
Register Physical Address Access Size
Test control/Status register (P_TST_CSR) 0xC80_000C 4 bytes
64
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
STP2002QFP
Table 26: Test Control/Status Register Definition
Field Bits Description Type
LD_TAG 31 When set to 1. loads FIFO DMA address register
(ADDR_TAG) with value in D_ADDR
REQ_OUT 30 Reads as 1, when FIFO is making a request for an
SBus read or write.
RD_BURST 30 When set to 1, initiates a DMA burst read from
memory into FIFO from address in ADDR_TAG
WR_CNT 29 When set to 1, loads FIFO_CNT register with
D_TST_CSR[5:0]
WRITE 28 When set to 1, puts FIFO into WRITING mode.
Reads as 1 when FIFO in WRITING mode.
DRAIN 27 Reads as 1 if FIFO is draining. When set to 1,
forces FIFO to drain.
EMPTY 26 Reads as 1, if FIFO buffer empty. R
FULL 25 Reads as 1, if FIFO buffer is full. R
LO_MARK 24 Reads as 1, if FIFO buffer has enough room for 1
SBus read burst of data.
HI_MARK 23 Reads as 1, if FIFO contains enough data for 1
SBus write burst.
COUNT 5:0 Reads CNT register containing number of bytes
stored in FIFO buffer.
COUNT 5:0 When WR_CNT=1, write CNT register contain-
ing number of bytes stored in FIFO buffer.
W
R
W
W
R/W
R/W
R
R
R
W
Sun Microsystems,
Note:The P_TST_CSR is intended for diagnostic and test use only and should never be
written while a DMA transfer is active
7.2.5 Hardware Configuration Register
Table 27: Hardware Configuration Register Address
Register Physical Address Access Size
Hardware configuration register (P_HCR) 0xC80_0010 2 bytes
65
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
Table 28: Hardware Configuration Register Definition
Field Bits Description Type
DSS 6:0 Data setup before data strobe in increments of 1 SBus clock R/W
7 Unused. Reads as 0 R
DSW 14:8 Data strobe width in increments of 1 SBus clock R/W
TEST 15 Test bit which when set, allows the buried counters to be
read
R/W
DSS:
Data setup to data strobe. This 7-bit quantity is used to define several different timing specifications for the interface. The contents of this field of the register are used to load a hardware timer whose timebase is the SBus clock. The
programmability range is from a minimum of 0 SBus clocks to 127 SBus
clocks. Bit 0 is the LSB and bit 6 is the MSB. The sections on unidirectional
and bidirectional transfers should be referenced for detail information on the
use of this timer.
DSW:
Data strobe width. This 7-bit quantity is used to define data strobe and acknowledge pulse widths for the interface. The contents of this field of the register are used to load a hardware timer whose timebase is the SBus clock. The
programmability range is from a minimum of 3 SBus clocks to 127 SBus
clocks. In the case of the value being 0, 1, 2, or 3, the timer will be loaded
with a value of 3. Bit 8 is the LSB and bit 14 is the MSB. The sections on unidirectional and bidirectional transfers should be referenced for detail information on the use of this timer.
66
7.2.6 Operation Configuration Register
This 16-bit read/write register is used to specify the operation of the interface.
Bidirectional specification of the control signals (P_D_STRB, P_ACK,
P_BSY), handshake protocol, memory clear, and diagnostic mode are defined
in this register. The detailed function of the bits is described in Table 30. Reset value of this register is all bits 0, except DS_DSEL and IDLE, which are
reset to 1, and bit 1, which always reads as 1 for backward compatibility with
the HIOD parallel port.
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
STP2002QFP
Table 29: Operation Configuration Register Address
Register Physical Address Access Size
Operation configuration register (P_HCR) 0xC80_0012 2 bytes
Table 30: Operation Configuration Register Definition
Field Bits Description Type
0 Reserved R/W
1 Reserved R
2 Reserved R
IDLE 3 Reads as 1, when the PP data transfer state machines
are idle
4 Reserved R
5 Reserved R
6 Reserved R
SRST 7 When set, resets the parallel port. Must be reset by
software.
ACK_OP 8 Acknowledge operation R/W
BUSY_OP 9 Busy operation R/W
EN_DIAG 10 When set, enables diagnostic operation R/W
ACK_DSEL 11 Acknowledge bidirectional select. When set,
P_BSY is bidirectional
BUSY_DSEL 12 Busy bidirectional select. When set, P_D_STRB is
bidirectional
DS_SEL 13 Data strobe bidirectional select. When set,
P_D_STRB is bidirectional
DATA_SRC 14 Data source for memory clear operation R/W
MEM_CLR 15 When set, enables memory clear R/W
R
R/W
R/W
R/W
R/W
Sun Microsystems,
IDLE:
When this bit is set, it indicates that the parallel port data transfer state machines are in their idle states. The state machines should be idle when changing direction and/or configuring operational modes and when enabling a
memory clear operation.
SRST:
Setting this bit will place the parallel port data transfer state machines and
programmable timers into reset. It will not reset any of the parallel port reg-
67
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
isters. This bit must be reset by software.
ACK_OP:
Used to specify the handshake protocol to be used on the interface. The meaning of this bit differs depending on the direction of transfer. The sections on
unidirectional and bidirectional transfers should be referenced for detail information on this bit. The general definition is as follows:
1 = Handshake using PP_ACK
0 = PP_ACK is inactive
BUSY_OP:
Used to specify the handshake protocol to be used on the interface. The meaning of this bit differs depending on the direction of transfer. The sections on
unidirectional and bidirectional transfers should be referenced for detail information on this bit. The general definition is as follows:
1 = Handshake performed using PP_BSY
0 = PP_BSY is not used for handshaking
EN_DIAG:
Setting this bit enables diagnostic mode which does three things:
68
• Bits 0–2 of the output register are gated on to bits 0–2 of the input reg-
ister. This allows testing of the data path and the interrupt generation
logic.
• The internal DS, ACK, and BUSY latch bits drive the internal DS_IRQ
and ACK_IRQ, and BUSY_IRQ interrupt-generation logic.
• When reading the DS, ACK, and BUSY bits of the transfer control reg-
ister, the read data comes from the internal latches instead of the external pins. During diagnostic mode, if the DS or ACK bits are configured
as outputs, the output pins will be gated to an inactive level. The BUSY
output will be driven active and the DIR output will be latched in its
current state.
ACK_DSEL:
This bit is a bidirectional select for the PP_ACK signal. When this bit is 0,
PP_ACK is an input, when 1 it is a bidirectional signal. The PP_ACKDIR pin
will reflect the direction of PP_ACK. The switching of direction is controlled
by the DIR bit of the transfer control register. The function of the two pins
is as follows:
DIR=0 DIR=1
PP_ACK Input Output
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
PP_ACKDIR0 1
BUSY_DSEL:
This bit is a bidirectional select for the PP_BSY signal. When reset, PP_BSY
is fixed as an input. When set, PP_BSY is a bidirectional signal. The
PP_BSYDIR pin will reflect the direction of PP_BSY. The switching of direction is controlled by the DIR bit of the transfer control register. The func-
tion of the two pins is as follows:
DIR=0 DIR=1
PP_BSY Input Output
PP_BSYDIR 0 1
DS_DSEL:
This bit is a bidirectional select for the PP_STB signal. When reset, PP_STB
is fixed as an output. When set, PP_STB is a bidirectional signal. The
PP_DSDIR pin will reflect the direction of PP_STB. The switching of direction is controlled by the DIR bit of the transfer control register. The function
of the two pins is as follows:
DIR=0 DIR=1
PP_STB Output Input
PP_DSDIR 1 0
STP2002QFP
Sun Microsystems,
This bit also defines transfer protocol as follows:
1 = Data strobe is bidirectional. Master write transfer protocol is selected.
0 = Data strobe is fixed as an output. Master read/write transfer protocol is
selected.
DATA_SRC:
This bit specifies the data to be sourced during a memory clear operation.
When set, the sourced data will be ones. When reset, the sourced data will be
0s.
MEM_CLR:
This bit enables memory clear operation. The DMA control registers need to
be configured, the DIR bit in the TCR register must be set and DMA must be
enabled.
69
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
7.2.7 Parallel Data Register
The data register is an 8-bit read/write port used to transfer data to and from
the external device. In programmed I/O mode data written to this register is
presented to the I/O pins if the DIR bit of the transfer control register is 0. A
read of this register will result in the data previously written or if the DIR bit
of the transfer control register is set to 1, the latched data from the last data
strobe. The data port is not accessible via slave write cycles during DMA
(P_DMA_ON=1). Any write cycles during DMA will not generate errors, the
data will simply not be written.
Since both DMA and PIO share the same data register, internal loopback
is possible by running a single-byte DMA cycle followed by a PIO cycle to
verify the data. This will test both the DMA and slave data paths.
Table 31: Parallel Data Register Address
Register Physical Address Access Size
Parallel data register (P_DR) 0xC80_0014 1 byte
Table 32: Parallel Data Register Definition
70
Field Bits Description Type
P_DR 7:0 Parallel data R/W
7.2.8 Transfer Control Register
The transfer control register is an 8-bit register whose contents define/reflect
the state of the external interface handshake and direction control signals. The
DS, ACK, and BUSY bits will reflect the state of the external pins, when read.
Writing these bits defines a value to be driven onto the external pins if the individual direction select bits (DS_DSEL, ACK_DSEL, BUSY_DSEL) and
the direction control bit (DIR) are configured such that the HIOD is driving
these pins as outputs. The write bits and read bits are different. That means
that values typically written to these bits may not be reflected on a read cycle.
However, by setting the EN_DIAG bit of the operation control register, these
register bits become read/write (see the EN_DIAG bit description of the
OCR).
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
STP2002QFP
Table 33: Transfer Control Register Address
Register Physical Address Access Size
Transfer Control register (P_TCR) 0xC80_0015 1 byte
Sun Microsystems,
71
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
Table 34: Transfer Control Register Definition
Field Bits Description Type
DS 0 Data strobe R/W
ACK 1 Acknowledge R/W
BUSY 2 Busy (active low) R/W
DIR 3 Direction control. 0 = write to external device, 1 = read R/W
4 Unused (reads as 0) R
5 Unused (reads as 0) R
6 Unused (reads as 0) R
7 Unused (reads as 0) R
DS:
Reading this bit reflects the state of the bidirectional PP_STB pin. Writing
this bit with DS_DSEL=0 or with DS_SEL=1 and DIR=0 will cause the value
written to be driven onto PP_STB. The reset state of the output latch is 0, but
the value read back from this bit after reset will reflect the input signal being
driven onto PP_STB.
72
ACK:
Reading this bit reflects the state of the bidirectional PP_ACK pin. Writing
this bit with ACK_DSEL=1 will cause the value written to be driven onto
PP_ACK if DIR=1. The reset state of the output latch is 0, but the value read
back from this bit after reset will reflect the input signal being driven onto
PP_ACK.
BUSY:
Reading this bit reflects the state of the bidirectional PP_BSY pin. Writing
this bit with BUSY_DSEL=1 will cause the value written to be driven onto
PP_BSY if DIR=1. The reset state of the output latch is 0, but the value read
back from this bit after reset will reflect the input signal being driven onto
PP_BSY.
DIR:
This bit defines and controls the direction of data transfer: 0=write to external
device,
1= read from external device. It is also driven externally on the PP_DDIR pin.
This bit also controls the direction of DMA operation. In the case of a memory clear operation, this bit (must be set) and the MEM_CLR bits define the
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
STP2002QFP
DMA direction. The state of the DIR bit is reflected in the P_WRITE bit of
the P_CSR. Reset state of this bit is 1.
7.2.9 Output Register
The output register is an 8-bit read/write register whose contents are driven
on to the corresponding external pins. In diagnostic mode (EN_DIAG=1),
bits 0–2 are gated on to input register bits 0–2. The external outputs remain
low while diagnostic mode is enabled. All bits are 0 after reset.
Table 35: Output Register Address
Register Physical Address Access Size
Output register (P_OR) 0xC80_0016 1 byte
Table 36: Output Register Definition
Field Bits Description Type
SLCT_IN 0 Select in. This bit is output on the PP_SLCT_IN pin. R/W
AFXN 1 Auto feed. This bit is output on the PP_AFXN pin. R/W
INIT 2 Initialize. This bit is output on the P_INIT pin R/W
3 Reserved (V1 bit on HIOD parallel port) R/W
4 Reserved (V2 bit on HIOD parallel port) R/W
5 Reserved (V3 bit on HIOD parallel port) R/W
6 Unused (reads as 0) R
7 Unused (reads as 0) R
Sun Microsystems,
7.2.10 Input Register
The input register is an 8-bit read/write register whose contents reflect the
state of several external input pins and their corresponding interrupts. In diagnostic mode (EN_DIAG=1), bits 0–2 are driven from output register bits
0–2.
Table 37: Input Register Address
Register Physical Address Access Size
Input register (P_IR) 0xC80_0017 1 byte
73
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
Table 38: Input Register Definition
Field Bits Description Type
ERR 0 Error input. This pin reflects the state of the ERR input pin R
SLCT 1 Select input. This pin reflects the state of the SLCT input
pin
PE 2 Paper empty. This pin reflects the state of the PP_PE input
pin
3 Unused (reads as 0) R
4 Unused (reads as 0) R
5 Unused (reads as 0) R
6 Unused (reads as 0) R
7 Unused (reads as 0) R
R
R
7.2.11 Interrupt Control Register
This 16-bit read/write register is used to specify operation of the parallel port
interrupts. Interrupt enables, polarity, and IRQ pending bits are contained in
this register. The detailed function of these bits are described following the
table. Reset value of this register is all bits 0.
74
Table 39: Interrupt Control Register Address
Register Physical Address Access Size
Interrupt Control register (P_ICR) 0xC80_0018 2 bytes
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
STP2002QFP
Table 40: Interrupt Control Register Definition
Field Bits Description Type
ERR_IRQ_EN 0 When set, enables ERR interrupts R/W
ERR_IRP 1 ERR interrupt polarity. 1=on rising edge, 0=on
trailing edge
SLCT_IRQ_EN 2 When set, enables SLCT interrupts R/W
SLCT_IRP 3 SLCT interrupt polarity. 1=on rising edge, 0=on
trailing edge
PE_IRQ_EN 4 When set, enable PE interrupts R/W
PE_IRP 5 PE interrupt polarity. 1=on rising edge, 0=on
trailing edge
BUSY_IRQ_EN 6 When set, enables BUSY interrupts R/W
BUSY_IRP 7 BUSY interrupt polarity. 1=on rising edge, 0=on
trailing edge
ACK_IRQ_EN 8 When set, enables ACK interrupts on rising edge
of ACK
DS_IRQ_EN 9 When set, enables DS interrupts on the rising
edge of DS
ERR_IRQ 10 When set, error IRQ pending R/W
SLCT_IRQ 11 When set, select IRQ pending R/W
PE_IRQ 12 When set, paper IRQ pending R/W
BUSY_IRQ 13 When set, busy IRQ pending R/W
ACK_IRQ 14 When set, acknowledge IRQ pending R/W
DS_IRQ 15 When set, data strobe IRQ pending R/W
R/W
R/W
R/W
R/W
R/W
R/W
Sun Microsystems,
*_IRQ_EN: When set, enables interrupts on the corresponding bits of the
input and transfer control registers. Note that the interrupt enable bit of the
PD_SCR must also be enabled to allow a hardware interrupt to be generated.
*_IRP: Defines the polarity of the edge triggered interrupts on the corresponding bits of the input register. 0=interrupt generated on the 1 to 0
transition of the signal. 1= interrupt generated on the 0 to 1 transitions of the
signal. Note that when configuring the interrupt polarity of a given signal, it
is possible to generate a false interrupt. It is suggested that when the interrupt
polarities are being programmed, interrupts be disabled, and all interrupt
sources be cleared upon completion of programming.
ERR_IRQ, SLCT_IRQ, PE_IRQ, BUSY_IRQ:
When set, an interrupt is pending on the corresponding bit. The interrupt is
cleared and the bit is reset when a 1 is written to the corresponding bit. Writ-
75
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
ing a 0 to these locations leaves the bit(s) unchanged.
ACK_IRQ:
When set, an interrupt is pending due to the receipt of PP_ACK. The interrupt
is set on the 0 to 1 transition of PP_ACK. This interrupt is intended to facilitate PIO transfers while configured as master under master write protocol.The
interrupt is cleared and the bit is reset when a 1 is written to this bit. Writing
a 0 to this location leaves the bit unchanged.
DS_IRQ:
When set, an interrupt is pending due to the receipt of PP_STB. This interrupt
is intended to facilitate PIO transfers while configured as slave under master
write protocol. The interrupt is cleared and the bit is reset when a 1 is written
to this bit. Writing a 0 to this location leaves the bit unchanged.
7.3 SCSI Channel Registers
7.3.1 SCSI Control/Status Register
Table 41: Control/Status Register Address
Register Physical Address Access Size
Control/Status register (D_CSR) 0x880_0000 4 bytes
Table 42: Control/Status Register Definition
Field Bits Description Type
D_INT_PEND 0 Set when either FAS366_IRQ is active, or if
D_ERR_PEND is set, or if DVMA loop-back is
complete
D_ERR_PEND 1 Set when a SCSI DVMA transfer received an
SBus ERR acknowledge. Also set when a parity
error or a late error detected
D_DRAINING 2 Non-zero when buffers are draining SCSI data to
memory; 0 otherwise
3 Reserved R
D_INT_EN 4 When set, enables SBus SCSI_IRQ when
INT_PEND or ERR_PEND is set
5 Reserved (reads as 0) R
6 Reserved (reads as 0) R
D_RESET 7 When set, invalidates the buffers and resets SCSICER/W
R
R
R
R/W
76
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
STP2002QFP
Table 42: Control/Status Register Definition
Field Bits Description Type
D_WRITE 8 DMA direction for SCSI transfers; 1 = to mem-
ory, 0 = from memory
D_EN_DMA 9 When set, enables DMA from the FAS366
unless blocked by other conditions
D_REQ_PEND 10 Do not assert D_RESET, while this is a 1 R
D_DMA_REV 14:11 0001 for current implementation R
D_WIDE_EN 15 When set, enables wide-mode SBus DVMA for
SCSI
16 Reserved (reads as 1) R
D_DSBL_ESP_DR_
N
D_BURST_SIZE 19:18 Defines SCSI DVMA burst size (see table
D_TWO_CYCLE 21 If set, provides a 2-cycle DMA access to
D_DSBL_PARITY_CHK25 When set, disables checking for parity on the
D_PAUSE_FAS366 26 When asserted, it will cause FAS366 pause input
D_HW_RST_FAS366 27 When asserted, it will cause the hardware reset
D_DEV_ID 31:28 Device ID (1011 for this implementation) R
17 When set, disables drain of buffers on slave
accesses to the FAS366 registers
below)
20 Reserved (reads as 1) R
FAS366, else it is a 3-cycle access. Default value
is 0.
22 Reserved (reads as 0) R
23 Reserved (reads as 1) R
24 Reserved (reads as 0) R
bus. Default value is a 1.
to be asserted. Default value is 0.
to FAS366 to be asserted. Default value is 0.
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Sun Microsystems,
Table 43: BURST_SIZE Encoding
BURST_SIZ
E Read Burst Size Write Burst Size Buffer Drain Level
00 4 words 4 words 16 words
01 8 words 8 words 16 words
10 Reserved Reserved Reserved
11 16 words 16 words 16 words
D_INT_PEND:
77
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
This bit is set to indicate that FAS366 has asserted its interrupt signal. Once
FAS366 asserts its interrupt signal, all the bytes in prefetch buffers are
drained to the host memory, before setting this bit or generating an interrupt
on SBus. Draining of buffers, before posting the interrupt to device driver,
saves PIOs. This bit will also be set during DMA loop-back. This bit will also
be set when the D_ERR_PEND bit is set.
D_ERR_PEND:
This bit is set in response to an Error ACK, during DVMA. This bit is reset
on setting D_RESET. This bit will also be set, when a parity error or a late
error is detected.
D_DRAINING:
When the buffers are draining to memory, this bit is set. DO NOT assert
D_RESET or write to D_ADDR register when set. This bit is not valid while
D_ERR_PEND is set and should be ignored.
D_RESET:
This bit will remain active once set to 1, until set to 0 or is cleared by a hardware reset. Setting D_RESET or asserting hardware reset will invalidate the
prefetch buffers, reset all of the state machines to their idle states.
78
Note: This bit must be asserted at the end of each DMA transfer. In
other words, whenever D_ADDR and D_BCNT are programmed with
a new value, D_RESET should have been asserted prior to this
programming.
D_REQ_PEND: This bit is set when a DVMA read or write request is pending. Do not assert D_RESET when D_REQ_PEND or/and D_DRAINING
bit(s) is (are) set.
D_DSBL_ESP_DRN: If set, draining will not be forced when the CPU
makes a slave access to the FAS366, while SCSI DVMA is in progress. This
bit could be useful in block-mode operation, where FAS366 does not generate
interrupts on successful execution of commands. In such a case, device drivers can use this bit to prevent forced draining, when making a slave access to
the FAS366 to monitor status.
7.3.2 SCSI Address Register
This register indicates the starting address from which DMA transfer takes
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
STP2002QFP
place.
Table 44: SCSI Address Register Address
Register Physical Address Access Size
Address register (D_ADDR) 0x880_0004 4 bytes
Table 45: SCSI Address Register Definition
Field Bits Description Type
D_ADDR 31:0 Virtual address used in SCSI DVMA access R/W
Note: To determine the exact address at which an error occurred, two
cases have to be dealt with. These are the following:
Case 1: The error occurs on the SCSI Bus
For this case, the starting address of the block/command is known, as
this is programmed before any data movement between FAS366 and
SCSI DMA block takes place. Reading of transfer count register from
FAS366, would indicate the number of data bytes read/written. Using
the starting address and the byte count, the exact address can be calculated.
Case 2: The error occurs on the SBus
Data on the SBus is always moved in a DMA burst of byte/halfword/word/double word for up to 64 bytes. A read of D_ADDR
register will indicate the address of the location at which the next burst
will take place. In a burst of 64/32/16 etc., if an error occurred on the
SBus, it will not be possible to identify the exact location at which an
error on SBus occurred.
Sun Microsystems,
7.3.3 SCSI Byte Count Register
Table 46: SCSI Byte Count Register Address
Register Physical Address Access Size
Byte Count register (D_BCNT) 0x880_0008 4 bytes
Table 47: SCSI Byte Count Register Definition
Field Bits Description Type
D_BCNT 31:0 DVMA transfer length counter R/W
79
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
• Byte counter is decremented, every time a byte is transferred between
SCSI and FAS366.
• No interrupt is generated when the D_BCNT reaches 0 (expires).
• D_BCNT will clear to 0, if D_RESET is asserted.
• D_BCNT should not be programmed with a number, different than the
one in the transfer count register of FAS366.
7.3.4 SCSI Test Control/Status Register
Table 48: SCSI Test Control/Status Register Address
Register Physical Address Access Size
Test control/Status register (D_TST_CSR) 0x880_000C 1 byte
Table 49: SCSI Test Control/Status Register Definition
Field Bits Description Type
PARITY_ERROR 0 Set when a parity error is detected on the
internal channel engine interface (CEI)
LATE_ERROR 1 Set when a late error is detected on the CEI R/W
LOOP-BACK MODE 2 When set, programs the SCSI channel to be
in DMA LOOP_BACK mode
LOOPBACK_DONE
ERROR_ACK 4 Set when an error ACK is detected on the CEI R
3 When set, indicates that DMA LOOP-BACK
is complete
R/W
W
R
80
Parity_Error:
This bit is set if a parity error is detected on the CEI. It will cleared on a hardware reset or a software reset (D_RESET).
Late_Error:
This bit is set if a late error is detected on the CEI. It will cleared on a hardware reset or a software reset (D_RESET).
Loop_Back_Mode:
This bit when set, enables the loop-back mode on the SCSI channel. The
SCSI CE will provide a DMA loop-back mode, in which, data from the host
memory will be moved to the prefetch buffers. Once the data is in the prefetch
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
buffers, it will be looped back to host memory. FAS366 is completely bypassed during this operation.
As the prefetch buffers can store 128 bytes, 128 bytes will be moved from
the host memory to SCSI CE. After the DMA read is complete the 128 bytes
will be looped back to host memory, by a DMA write. Bit[2] of D_TST_CSR
register will program SCSI CE to be in DMA loop-back mode. Bit[3] of
D_TST_CSR register will indicate that loop-back is complete. The starting
address should be programmed at a 64-byte boundary.
For a programmer, the following will be the sequence of events.
1. Reset the SCSI CE.
2. Program the starting address in D_ADDR register.
3. Program the D_BCNT to 128 bytes.
4. Set the bit[2] of D_TST_CSR to select the loop-back mode.
5. Select DMA read (by writing to WRITE bit in D_CSR), Burst
Size should be programmed for 64B.
6. Enable DMA.
STP2002QFP
7. Wait for interrupt.
8. After the interrupt, look at bit[3] of D_TST_CSR.
9. If the bit[3] is set, 128 bytes of data from host memory has been
moved into the prefetch buffers.
10. Reset the SCSI CE.
11. Program the starting address in D_ADDR reg, this is the address
where data coming out to prefetch buffers, will be written in host
memory.
12. Program the D_BCNT to 128 bytes.
13. Set the bit[2] of D_TST_CSR.
14. Select DMA write (by writing to the WRITE bit in CSR), Burst
Size should be programmed for 64 bytes.
15. Enable DMA.
16. Wait for interrupt.
17. After the interrupt, look at bit[3] of D_TST_CSR.
18. If this bit is set, 128 bytes from the prefetch buffers have been
written back to the host memory.
Sun Microsystems,
81
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
This completes the loop-back of 128 bytes. This sequence can be repeated
any number of times.
82
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
STP2002QFP
7.4 FAS366 (SCSI Controller Core) Registers
The FAS366 registers are used by the CPU to control the operation of the
SCSI bus. Through these registers, the CPU configures, commands, and monitors data, command, and information transfers between the FAS366 and the
SCSI bus.
Note: For the case of SCSI read (data-in phase only) when FAS366 is
operating in narrow mode and if the number of bytes coming to
FAS366 from the target is an odd number, FAS366 can be programmed in two modes.
1) FAS366 does not give up the last one byte. It generates an interrupt
when the last one byte is still in FAS366 FIFO. The device driver has
to make a slave access to FAS366 to write one byte so that the last byte
is padded. Then the device driver can make another slave access to read
both the bytes out and discard the padded byte. This is the default
mode.
2) FAS366 pads the last byte and generates an interrupt only after the
SCSI CE has read all the bytes. This mode can be entered by setting the
bit 7 of the configuration register #3. This bit gets cleared after every
reset.
Sun Microsystems,
7.4.1 FAS366 Transfer Counter Low Register (Read Only)
This 16-bit transfer counter register consists of two eight-bit, read-only registers. The counter is used to count the number of bytes transferred in a DMA
command or received in a command sequence in target mode. When a DMA
command is issued, the transfer counter is loaded with the value contained in
the transfer count register. The value in the transfer counter is decremented as
bytes are transferred.
When a sequence terminates early, the sum of the transfer counter and the
FIFO flags registers indicate the number of bytes remaining to be transferred.
Table 50: FAS366 Transfer Counter Low Register (Read Only) Address
Register Physical Address Access Size
Transfer counter low 0x881_0000 2 bytes
83
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
Table 51: FAS366 Transfer Counter Low Register (Read Only) Definition
Field Bits Description Type
Transfer counter low 15:0 Holds the 16 bits of transfer counter R
7.4.2 FAS366 Transfer Count Low Register (Write Only)
This 16-bit transfer count register is comprised of two eight-bit, write-only
registers. The transfer count register is normally loaded prior to writing a
DMA command to the command register. This value indicates the number of
bytes to be transferred into the FIFO.
Table 52: FAS366 Transfer Count Low Register (Write Only) Address
Register Physical Address Access Size
Transfer count low 0x881_0000 2 bytes
Table 53: FAS366 Transfer Count Low Register (Write Only) Definition
84
Field Bits Description Type
Transfer count low 15:0 Programmed with 16 bits of transfer count W
7.4.3 FAS366 Transfer Counter High Register (Read Only)
Table 54: FAS366 Transfer Counter High (Read Only) Register Address
Register Physical Address Access Size
Transfer counter high 0x881_0004 2 bytes
Table 55: FAS366 Transfer Counter High (Read Only) Register Definition
Field Bits Description Type
Transfer counter high 15:0 Holds the 16 bits of transfer counter R
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
STP2002QFP
7.4.4 FAS366 Transfer Count High (Write Only) Register
Table 56: FAS366 Transfer Count High Register (Write Only) Address
Register Physical Address Access Size
Transfer count high 0x881_0004 2 bytes
Table 57: FAS366 Transfer Count High Register (Write Only) Definition
Field Bits Description Type
Transfer count high 15:0 Programmed with 16 bits of transfer count W
7.4.5 FAS366 FIFO Register
The SCSI data FIFO consists of 16 registers, each two bytes wide. Data can
be read/written from/to FIFO, with a slave or DMA access. The data is loaded
into the FIFO top register and is unloaded from the FIFO bottom register.
Table 58: FAS366 FIFO Register Address
Register Physical Address Access Size
FIFO register 0x881_0008 1 byte
Sun Microsystems,
Table 59: FAS366 FIFO Register Definition
Field Bits Description Type
FIFO 7:0 Data port for FIFO access R/W
7.4.6 FAS366 Command Register
The command register is an eight-bit, read/write register that functions as a
two-byte deep FIFO, enabling the CPU to stack commands to the FAS366.
Each command loaded into the command register is defined by an eight-bit
command code, which consists of the DMA indicator, the command mode,
and the command indicator.
Table 60: FAS366 Command Register Address
Register Physical Address Access Size
Command register 0x881_000C 1 byte
85
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
Table 61: FAS366 Command Register Definition
Field Bits Description Type
Command 7:0 Functions as a 2-byte deep command holder R/W
7.4.7 FAS366 Status #1 Register
This eight-bit, read-only register indicates the status of the FAS366 core and
the SCSI bus phase, and qualifies the reason for an interrupt.
86
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
STP2002QFP
s
Table 62: FAS366 Status #1 Register Address
Register Physical Address Access Size
Status #1 register 0x881_0010 1 byte
Table 63: FAS366 Status #1 Register Definition
Field Bits Description Type
Status #1 7:0 Indicates the status of FAS366 and SCSI bus phase R
7.4.8 FAS366 Select/Reselect Bus ID Register
The select/reselect bus ID register is an eight-bit, write-only register that
stores encoded values for the SCSI bus ID and the selection/reselection ID.
Table 64: FAS366 Select/Reselect Bus ID Register Address
Register Physical Address Access Size
Select/Reselect bus ID register 0x881_0010 1 byte
Table 65: FAS366 Select/Reselect Bus ID Register Definition
Sun Microsystems,
Field Bits Description Type
Select/Reselect bus ID 7:0 Stores encoded values for SCSI bus ID W
7.4.9 FAS366 Interrupt Register
This eight-bit, read-only register is used in conjunction with information contained in the Status #1 register and sequence step register to determine the
cause of an interrupt. This register reflects the status of the completed command. Reading the interrupt register while an interrupt is pending clears all
interrupt register bits to 0.
Table 66: FAS366 Interrupt Register Address
Register Physical Address Access Size
Interrupt register 0x881_0014 1 byte
87
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
Table 67: FAS366 Interrupt Register Definition
Field Bits Description Type
Interrupt register 7:0 Used for determination of the cause of an interrupt R
7.4.10 FAS366 Select/Reselect Time-Out Register
The select/reselect time-out register is an eight-bit, write-only register that
specifies the amount of time to wait for a response during selection or reselection. The select/reselect time-out register is typically loaded to specify a
time-out period of 250 ms.
Table 68: FAS366 Select/Reselect Time-Out Register Address
Register Physical Address Access Size
Select/reselect time-out register 0x881_0014 1 byte
Table 69: FAS366 Select/Reselect Time-Out Register Definition
Field Bits Description Type
Select/reselect time-out 7:0 Used for specifying the response time
during selection/reselection
W
88
7.4.11 FAS366 Sequence Step Register
Sequence step register bits are latched until the interrupt register is read.
Reading the Interrupt register while an interrupt is pending clears the sequence step register to 0.
Table 70: FAS366 Sequence Step Register Address
Register Physical Address Access Size
Sequence step register 0x881_0018 1 byte
Table 71: FAS366 Sequence Step Register Definition
Field Bits Description Type
Sequence step 7:0 Indicates the last executed sequence/step R
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
STP2002QFP
7.4.12 FAS366 Synchronous Transfer Period Register
The synchronous transfer period register is an eight-bit, write-only register.
This register specifies the minimum time, in input clock cycles, between leading edges of successive REQ or ACK pulses on the SCSI bus during synchronous data transfers.
Table 72: FAS366 Synchronous Transfer Period Register Address
Register Physical Address Access Size
Synchronous transfer period register 0x881_0018 1 byte
Table 73: FAS366 Synchronous Transfer Period Register Definition
Field Bits Description Type
Synchronous transfer
period
7:0 Specifies the time between successive REQ
and ACK pulses on the SCSI bus
7.4.13 FAS366 FIFO Flags Register
The FIFO flags register is an eight-bit, read-only register that provides the
user with the option of addressing only one register for FIFO count and sequence information.
W
Sun Microsystems,
Table 74: FAS366 FIFO Flags Register Address
Register Physical Address Access Size
FIFO flags register 0x881_001C 1 byte
Table 75: FAS366 FIFO Flags Register Definition
Field Bits Description Type
FIFO flags 7:0 Provides information on FIFO R
7.4.14 FAS366 Synchronous Offset Register
The synchronous offset register is an eight-bit, write-only register. This register specifies the maximum REQ/ACK offset allowed during synchronous
transfers. An offset of 0 specifies asynchronous operation.
89
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
Table 76: FAS366 Synchronous Offset Register Address
Register Physical Address Access Size
Synchronous offset register 0x881_001C 1 byte
Table 77: FAS366 Synchronous Offset Register Definition
Field Bits Description Type
Synchronous offset 7:0 Specifies the REQ/ACK offset during syn-
chronous transfers
W
7.4.15 FAS366 Configuration #1 Register
The configuration #1 register is an eight-bit, read/write register that specifies
different operating options for the FAS366.
Table 78: FAS366 Configuration #1 Register Address
Register Physical Address Access Size
Configuration #1 register 0x881_0020 1 byte
90
Table 79: FAS366 Configuration #1 Register Definition
Field Bits Description Type
Configuration #1 7:0 Specifies different operation options for FAS366 R/W
7.4.16 FAS366 Clock Conversion Factor Register
The clock conversion factor register enables the software pause and the fast
sync response time; sets parity ATN and interrupt masks; and indicates the
clock conversion factor.
Table 80: FAS366 Clock Conversion Factor Register Address
Register Physical Address Access Size
Clock conversion factor register 0x881_0024 1 byte
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
STP2002QFP
Table 81: FAS366 Clock Conversion Factor Register Definition
Field Bits Description Type
Clock conversion factor 7:0 Allows for fast synchronous response time,
set parity ATN and interrupt masks and
indicates the clock conversion factor
7.4.17 FAS366 Status #2 Register
The status #2 register is a read-only register that indicates detailed status information about the FIFO, the DMA interface, the sequence counter, the
transfer counter, the recommand counter, and the command register.
Table 82: FAS366 Status #2 Register Address
Register Physical Address Access Size
Status #2 register 0x881_0024 1 byte
Table 83: FAS366 Status #2 Register Definition
W
Sun Microsystems,
Field Bits Description Type
Status #2 7:0 Indicates status of FAS366 and SCSI bus R
7.4.18 FAS366 Test Register
The test register is an eight-bit, write-only register that is used during production chip testing to test the FAS366 in various modes.
Table 84: FAS366 Test Register Address
Register Physical Address Access Size
Test register 0x881_0028 1 byte
Table 85: FAS366 Test Register Definition
Field Bits Description Type
Test 7:0 Used during production chip testing to test FAS366 W
91
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
7.4.19 FAS366 Configuration #2 Register
Configuration #2 is an eight-bit read/write register that specifies different operating options for the FAS366.
Table 86: FAS366 Configuration #2 Register Address
Register Physical Address Access Size
Configuration #2 register 0x881_002C 1 byte
Table 87: FAS366 Configuration #2 Register Definition
Field Bits Description Type
Configuration #2 7:0 Specifies different operating options for FAS366 R/W
7.4.20 FAS366 Configuration #3 Register
This eight-bit, read/write register is used to enable normal or fast synchronous
transfer timing, ID message reserved bit checking, receipt of three-byte messages when selected with ATN, and recognition of 10-byte Group 2 commands.
92
Table 88: FAS366 Configuration #3 Register Address
Register Physical Address Access Size
Configuration #3 register 0x881_0030 1 byte
Table 89: FAS366 Configuration #3 Register Definition
Field Bits Description Type
Configuration #3 7:0 Specifies different operating options for FAS366 R/W
7.4.21 FAS366 Recommand Counter Register
The 16-bit recommand counter consists of two eight-bit, read/write registers:
the recommand counter low register, and the recommand counter high register. The recommand counter is enabled when the recommand function is enabled, and is disabled when the recommand functions is disabled. The
recommand counter is decremented at the end of each block transfer before
the SCSI command is re-executed.
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
STP2002QFP
Table 90: FAS366 Recommand Counter Register Address
Register Physical Address Access Size
Recommand counter low register
Recommand counter high register
0x881_0038
0x881_003C
1 byte
1 byte
Table 91: FAS366 Recommand Counter Register Definition
Field Bits Description Type
Recommand count low
Recommand count high
7:0
Lower 8 bits of recommand count
7:0
Upper 8 bits of recommand count
After power-up or a chip reset, and until the recommand counter register is
loaded, the FAS366 part-unique ID code is readable from the recommand
counter low register. This part-unique ID indicates FAS366 family code and
the revision level at power-up.
7.5 Ethernet Channel Registers
R/W
7.5.1 Global Software Reset Register
This two-bit register is used to perform an individual software reset to the
ETX or ERX modules (when the corresponding bit is set), or a global software reset to the entire Ethernet channel (when both bits are set). These bits
can be set to 1 using a programmed I/O write to the defined address. They become self-cleared after the corresponding reset command has been executed.
Table 92: Global Software Reset Register Address
Register Physical Address Access Size
Global software reset register 0x8C0_0000 4 bytes
Table 93: Global Software Reset Register Definition
Field Bits Description Type
ETX software reset 0 Individual software reset to the ETX module R/W
ERX software reset 1 Individual software reset to the ERX module R/W
31:2 Reserved R
Note: To ensure proper operation of the hardware after a software reset
(individual or global), this register must be polled by the software.
Sun Microsystems,
93
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
When both bits read back as 0s, the software is allowed to continue to
program the hardware.
7.5.2 Global Configuration Register
This five-bit register is used to determine the system-related parameters that
control the operation of the DMA channels.
Table 94: Global Configuration Register Address
Register Physical Address Access Size
Global configuration register 0x8C0_0004 4 bytes
Table 95: Global Configuration Register Definition
Field Bits Description Type
Burst_Size 1:0 This field determines the size of the host bus
bursts that the DMA channels will execute:
00 — 16-byte burst
01 — 32-byte burst
10 — 64-byte burst
11 — Reserved
Extended_Transfer_Mode 2 When set to 1, 64-bit CEI and SBus DVMA
transactions will be performed. If cleared to 0,
a 32-bit CEI/SBus is assumed
Parity_Enable 3 When set to 1, parity checking is performed
for DVMA read and PIO write cycles
27:4 Reserved R/W
Ethernet channel ID 31:28 This field identifies the version number of the
Ethernet channel. Current version # is 0000
R/W
R/W
R/W
R/W
94
7.5.3 Global Interrupt Mask Register (RW)
This 32-bit register is used to determine which status events will cause an interrupt. If a mask bit is cleared to 0, the corresponding event causes an interrupt signal to be generated on the SBus. The layout of this register
corresponds bit-by-bit to the layout of the status register, with the exception
of bit [23]. The MIF interrupt is not maskable here, and should be masked at
the source of the interrupt in the MIF.
Default value is 0xFF7FFFFF.
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
STP2002QFP
Table 96: Global Interrupt Mask Register Address
Register Physical Address Access Size
Global interrupt mask register 0x8C0_0104 4 bytes
7.5.4 Global Status Register
This 32-bit register is used to communicate the software events that were detected by the hardware. If a status bit is set to 1, it indicates that the corresponding event has occurred. All the bits are automatically cleared to 0 when
the status register is read by the software, with the exception of bit [23]. The
MIF status bit will be cleared after the MIF status register is read.
Table 97: Global Status Register Address
Register Physical Address Access Size
Global status register 0x8C0_0100 4 bytes
Table 98: Global Status Register Definition
Field Bits Description Type
Frame_Received 0 A frame transfer from the RX_MAC to the RxFIFO has
been completed
Rx_Frame_Counter_Expired 1 The Rx_Frame_Counter rolled over from FFFF to 0000 R
Alignment_Error_Counter_Expired 2 The Alignment_Error_Counter rolled over from FF to
00
CRC_Error_Counter_Expired 3 The CRC_Error_Counter rolled over from FF to 00 R
Length_Error_Counter_Expired 4 The Length_Error_Counter rolled over from FF to 00 R
RxFIFO_Overflow 5 The synchronous FIFO in the RX_MAC has an over-
flow. A receive frame was dropped by the RX_MAC
Code_Violation_Counter_Expired 6 The Code_Violation_Counter rolled from FF to 00 R
SQE_Test_Error 7 A signal quality error was detected in the XIF R
Frame_Transmitted 8 The TX_MAC has sucessfully transmitted a frame on
the medium
TxFIFO_Underrun 9 The TX_MAC has experienced an underrun in the syn-
chronous FIFO due to data starvation caused by transmit
DMA
Max_Packet_Size_Error 10 The TX_MAC attempted to transmit a frame that
exceeds the maximum size allowed
Normal_Collision_Counter_Expired 11 The Normal_Collision_Counter rolled over from FFFF
to 0000
R
R
R
R
R
R
R
Sun Microsystems,
95
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
Table 98: Global Status Register Definition
Field Bits Description Type
Excessive_Collision_Counter_Expired 12 The Excessive_Collision_Counter rolled over from FF
to 00
Late_Collision_Counter_Expired 13 The Late_Collision_Counter rolled over from FF to 00 R
First_Collision_Counter_Expired 14 The First_Collision_Counter rolled over from FFFF to
0000
Defer_Time_Expired 15 The Defer_Timer rolled over from FFFF to 0000 R
Rx_Done 16 A frame transfer from RxFIFO to the host memory has
been completed
Rx_Buffer_Not_Available 17 The receive DMA engine tried to transfer a receive
frame from the RxFIFO to the host memory, but did not
find any descriptors that were available. The frame was
dropped by the DMA engine.
Rx_Master_Err_Ack 18 An Error ACK occurred during a receive DMA cycle R
Rx_Late_Err 19 A late error occurred during a receive DMA cycle R
Rx_DMA_Par_Err 20 A parity error was detected during a receive DMA read
cycle (descriptor access)
Rx_Tag_Err 21 The receive unload control state machine did not see two
consecutive tag bits
EOP_Error 22 The transmit load control detected a descriptor with the
OWN bit cleared, before the last descriptor of the current
frame (EOP = 1) has been processed
MIF_Interrupt 23 The status register in the MIF has at least one unmasked
interrupt set
Tx_Done 24 A frame transfer from the host memory to the TxFIFO
has completed
Tx_All 25 The transmit DMA has transferred to the TxFIFO all the
frames that have been posted to it by software. There are
no transmit descriptors that are currently owned by the
hardware
Tx_Master_Err_Ack 26 An Error ACK occurred during a transmit DMA cycle R
Tx_Late_Err 27 A late error occurred during a transmit DMA cycle R
Tx_DMA_Par_Err 28 A parity error was detected during a transmit DMA read
cycle
R
R
R
R
R
R
R
R
R
R
R
96
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
STP2002QFP
Table 98: Global Status Register Definition
Field Bits Description Type
Tx_Tag_Err 29 The transmit unload control state machine did not see
two consecutive tag bits set
Slave_Err_Ack 30 An Error ACK was generated by the hardware during a
PIO cycle to the Ethernet channel area. This is an indication that the PIO cycle was executed with SB_SIZE
other than a word transfer
Slave_Par_Err 31 A parity error was detected during a PIO write cycle to
the Ethernet channel
7.5.5 ETX Transmit Pending Command
Table 99: ETX Transmit Pending Command Address
Register Physical Address Access Size
ETX transmit pending command 0x8C0_2000 4 bytes
This one-bit command must be issued by the software for every packet that
the driver posts to the hardware. The bit is set to 1 using a programmed I/O
write to the defined address. This bit becomes self-cleared after the command
has been executed. This command is used as a wake up signal to the transmit
DMA engine.
R
R
R
Sun Microsystems,
7.5.6 ETX Configuration Register
This 10-bit register determines the ETX-specific parameters that control the
operation of the transmit DMA channel.
Table 100: ETX Configuration Register Address
Register Physical Address Access Size
ETX configuration register 0x8C0_2004 4 bytes
97
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
Table 101: ETX Configuration Register Definition
Field Bits Description Type
Tx_DMA_Enable 0 When set to 1, the DMA operation of the channel
is enabled. The load control state machine will
respond to the next TX_Pending command. When
cleared to 0, the DMA operation of the channel
will cease as soon as the transfer of the current data
buffer has been completed
Tx_FIFO_Threshold9:1 This field determines the number of packet data
words that will be loaded into the TxFIFO before
the frame transmission by the TX_MAC is
enabled.
The maximum allowable threshold is 1BF. If the
desire is to buffer an entire standard Ethernet
frame before transmission is enabled, this field has
to be programmed to a value greater than 1BF.
Paced_Mode 10 When set to 1, the Tx_All interrupt (bit 25 in the
global status register) will become set only after
the TxFIFO becomes empty. If cleared to 0, the
Tx_All interrupt will function as described in
“Global Interrupt Mask Register (RW)” section on
page 94.
R/W
R/W
R/W
98
The default value of this register is set to 0x3FE
7.5.7 ETX Transmit Descriptor Pointer (RW)
This 29-bit register points to the next descriptor in the ring. The 21 most significant bits are used as the base address for the descriptor ring, while the 8
least significant bits are used as a displacement for the current descriptor.
Table 102: ETX Transmit Descriptor Pointer Register Address
Register Physical Address Access Size
ETX transmit descriptor pointer register 0x8C0_2008 4 bytes
Note: The transmit descriptor pointer must be initialized to a 2K bytealigned value after power-on or software reset.
7.5.8 ETX Transmit Descriptor Ring Size
This four-bit register determines the number of descriptor entries in the ring.
The number of entries can vary from 16 through 256 in increments of 16.
Sun Microelectronics
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
STP2002QFP
Table 103: ETX Transmit Descriptor Ring Size Register Address
Register Physical Address Access Size
ETX transmit descriptor ring size register 0x8C0_202C 4 bytes
Default: 0xF; 256 descriptor entries.
7.5.9 ETX Transmit Data Buffer Base Address
Table 104: ETX Transmit Data Buffer Base Address Register Address
Register Physical Address Access Size
ETX transmit data buffer base address register 0x8C0_200C 4 bytes
Table 105: ETX Transmit Data Buffer Base Address Register Definition
Field Bits Description Type
Transmit data
buffer base address
31:0 This 32-bit register points to the beginning of
the transmit data buffer in the host memory. It
is loaded by the DMA state machine during the
descriptor fetch phase. This register is used to
generate the DVMA burst address by adding to
it the data buffer displacement.
R
Sun Microsystems,
7.5.10 ETX Transmit Data Buffer Displacement (RO)
This 10-bit counter keeps track of the next DVMA read burst address. It is
used as a displacement for the data buffer base address. The counter increments by 1, 2, or 4 (depending on the burst size) after a DVMA read burst cycle has been executed by the transmit DMA engine. The counter is cleared
when the data buffer base address is loaded by the DMA state machine. This
register is used to generate the DVMA burst address by adding it to the buffer
base address.
Table 106: ETX Transmit Data Buffer Displacement Register Address
Register Physical Address Access Size
ETX transmit data buffer displacement register 0x8C0_2010 4 bytes
99
STP2002QFP
Fast Ethernet, Parallel Port, SCSI (FEPS) - STP2002QFP
Table 107: ETX Transmit Data Buffer Displacement Register Definition
Field Bits Description Type
Transmit data buffer
displacement
9:0 10-bit counter, keeps track of the next
DVMA read burst address
R
7.5.11 ETX Transmit Data Pointer
This 32-bit register points to the next DVMA read burst address. Its contents
is the sum of the transmit data buffer base address and the transmit data buffer
displacement.
Table 108: ETX Transmit Data Pointer Register Address
Register Physical Address Access Size
ETX transmit pointer register 0x8C0_2030 4 bytes
Table 109: ETX Transmit Data Pointer Register Definition
Field Bits Description Type
Transmit data pointer 31:0 Points to next DVMA read burst address.
Value is the sum of
Data_Buffer_Base_Address and
Data_Buffer_Displacement
R
7.5.12 ETX TxFIFO Packet Counter
This eight-bit up/down counter keeps track of the number of frames that currently reside in the TxFIFO. The counter increments when a frame is loaded
into the FIFO, and decrements when a frame has been transferred to the
TX_MAC. This counter is used to enable frame transfer from the TxFIFO to
the TX_MAC.
Table 110: ETX TxFIFO Packet Counter Register Address
Register Physical Address Access Size
ETX TxFIFO packet counter register 0x8C0_2024 4 bytes
100
Sun Microelectronics
Loading...
