Page 1

Sun™External I/O Expansion Unit

for SPARC

Enterprise

T5120/T5140/T5220/T5240/T5440

Servers

Product Notes

Part No. 820-4800-12 March 2010, Revision A

Page 2

FUJITSU LIMITED provided technical input and review on portions of this material.

Sun Microsystems, Inc. and Fujitsu Limitedeach own or control intellectual property rights relating to productsand technology described in this document,and such products, technologyand this document are protected by copyright laws, patentsand other intellectual property laws and internationaltreaties. The intellectual property rightsof Sun Microsystems, Inc. andFujitsu Limited in suchproducts, technology and this document include,without limitation, one or more of the United States patents listed athttp://www.sun.com/patents and one ormore additional patentsor patent applications in the United Statesor other countries.

This documentand the product and technology to which itpertains are distributed under licensesrestricting their use, copying, distribution, and decompilation.No part of such product or technology, or of this document, may bereproduced inany form by anymeans without prior written authorizationof Fujitsu Limited and Sun Microsystems, Inc., and their applicable licensors, ifany.The furnishing of this document to you doesnot give you any rights or licenses, expressor implied, with respect tothe product or technology to which it pertains, and this document doesnot contain or represent anycommitment of any kind on the part of Fujitsu Limited orSun Microsystems, Inc., or anyafﬁliate of either ofthem.

This documentand the product and technology described in thisdocument may incorporate third-party intellectualproperty copyrighted by and/or licensedfrom suppliers to Fujitsu Limited and/or Sun Microsystems, Inc., including software and font technology.

Per theterms of the GPL or LGPL, a copy of the source code governed by the GPL or LGPL, asapplicable, is available upon requestby the End User.Please contact Fujitsu Limited or Sun Microsystems, Inc.

This distribution may include materials developed by third parties.

Parts of the product may be derived from Berkeley BSD systems, licensed from the University of California. UNIX is a registered trademark in the U.S. and in other countries, exclusively licensed through X/Open Company, Ltd.

Sun, Sun Microsystems, the Sun logo, Java, Netra, Solaris, Sun Ray, Answerbook2, docs.sun.com, OpenBoot, and Sun Fire are trademarks or registered trademarks of Sun Microsystems, Inc., or its subsidiaries, in the U.S. and other countries.

Fujitsu and the Fujitsu logo are registered trademarks of Fujitsu Limited.

All SPARC trademarks are used under license and are registered trademarks of SPARC International, Inc. in the U.S. and other countries. Products bearing SPARC trademarks are based upon architecture developed by Sun Microsystems, Inc.

SPARC64 is a trademark of SPARC International, Inc., used under license by Fujitsu Microelectronics, Inc. and Fujitsu Limited.

The OPEN LOOK and Sun™ Graphical User Interface was developed by Sun Microsystems, Inc. for its users and licensees. Sun acknowledges the pioneering efforts of Xerox in researching and developing the concept of visual or graphical user interfaces for the computer industry. Sun holds anon-exclusive license from Xerox tothe Xerox Graphical User Interface,which license also coversSun’s licensees who implementOPEN LOOK GUIs and otherwise comply with Sun’s written license agreements.

United StatesGovernment Rights - Commercial use. U.S. Government usersare subject to the standardgovernment user license agreements of Sun Microsystems, Inc. and Fujitsu Limitedand the applicable provisions of the FARand its supplements.

Disclaimer: The only warranties granted by Fujitsu Limited, Sun Microsystems, Inc. or any afﬁliate of either of them in connection with this document or any product or technology described herein are those expressly set forth in the license agreement pursuant to which the product or technology is provided. EXCEPT AS EXPRESSLY SET FORTH IN SUCH AGREEMENT, FUJITSU LIMITED, SUN MICROSYSTEMS, INC. AND THEIR AFFILIATES MAKE NO REPRESENTATIONS OR WARRANTIES OF ANY KIND (EXPRESS OR IMPLIED) REGARDING SUCH PRODUCT OR TECHNOLOGY OR THIS DOCUMENT, WHICH ARE ALL PROVIDED AS IS, AND ALL EXPRESS OR IMPLIED CONDITIONS, REPRESENTATIONS AND WARRANTIES, INCLUDING WITHOUT LIMITATION ANY IMPLIED WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR NON-INFRINGEMENT, ARE DISCLAIMED, EXCEPT TO THE EXTENT THAT SUCH DISCLAIMERS ARE HELD TO BE LEGALLY INVALID. Unless otherwise expressly set forth in such agreement, to the extent allowed by applicable law, in no event shall Fujitsu Limited, Sun Microsystems, Inc. or any of their afﬁliates have any liability to any third party under any legal theory for any loss of revenues or proﬁts, loss of use or data, or business interruptions, or for any indirect, special, incidental or consequential damages, even if advised of the possibility of such damages.

DOCUMENTATION IS PROVIDED “AS IS” AND ALL EXPRESS OR IMPLIED CONDITIONS, REPRESENTATIONS AND WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR NON-INFRINGEMENT, ARE DISCLAIMED, EXCEPT TO THE EXTENT THAT SUCH DISCLAIMERS ARE HELD TO BE LEGALLY INVALID.

Please

Recycle

Page 3

Contents

Preface v

External I/O Expansion Unit Product Notes 1

Supported Hardware and Software 1

Patch Information 2

Functionality Issues 2

Known Issues 2

PSU Does Not Automatically Turn On Again After Power Failure 2

Changing the Status of a PSU That Is Marked As Faulty 3

Other Current Issues 4

Closed Issues 5

Documentation Updates 6

Connecting I/O Boats to Different Domains 6

iii

Page 4

iv External I/O Expansion Unit Product Notes for SPARC Enterprise T5xxx Servers • March 2010

Page 5

Preface

These product notes contain late-breaking information about the Sun™ External I/O Expansion Unit when used with SPARC

Enterprise T5120, T5140, T5220, T5240, and

T5440 servers.

Related Documentation

Document sets for the External I/O Expansion Unit are available for two server families:

■ Sun SPARC Enterprise M4000/M5000/M8000/M9000 servers

■ Sun SPARC Enterprise T5120/T5140/T5220/T5240/T5440 servers

There are differences between the two document sets, so ensure that you have the correct set of documents.

Online documentation is available at:

http://docs.sun.com/app/docs/prod/ext.io.exp#hic

The following table lists the documentation that supports SPARC Enterprise T5120/T5140/T5220/T5240/T5440 servers.

Application Title Part Number Format Location

Installation and service

Late-breaking information

Sun External I/O Expansion Unit Installation and Service Manual for SPARC Enterprise T5120/T5140/T5220/T5240/T5440 Servers

Sun External I/O Expansion Unit for SPARC Enterprise T5120/T5140/T5220/T5240/T5440 Servers Product Notes

The following table lists the documentation that supports SPARC Enterprise M4000/M5000/M8000/M9000 servers.

819-5020-xx PDF Online

819-4800-xx PDF

HTML

Online

Page 6

Application Title Part Number Format Location

Installation and service

Late-breaking information

Sun External I/O Expansion Unit Installation and Service Manual for SPARC Enterprise M4000/M5000/M8000/M9000 Servers

Sun External I/O Expansion Unit for SPARC Enterprise M4000/M5000/M8000/M9000 Servers Product Notes

819-1141-xx PDF Online

819-5324-xx PDF

HTML

Online

Technical Support

If you have technical questions or issues that are not addressed in the External I/O Expansion Unit documentation, contact your local Sun Service representative.

For customers in the U.S. or Canada, call 1-800-USA-4SUN (1-800-872-4786). For customers in the rest of the world, find the World Wide Solution Center nearest you by visiting the web site:

http://www.sun.com/service/contacting/solution.html

Note – For the latest patch information go to http://sunsolve.sun.com.

Installation information and README files are included in the patch download.

vi External I/O Expansion Unit Product Notes for SPARC Enterprise T5xxx Servers • March 2010

Page 7

Accessing Documentation

Instructions for installing, administering, and using your External I/O Expansion Unit are provided in the External I/O Expansion Unit documentation set. The entire documentation set is available for download from the following web site:

http://www.sun.com/documentation/

Note – Information in these product notes supersedes the information in the

External I/O Expansion Unit documentation set.

Sun Welcomes Your Comments

Sun is interested in improving its documentation and welcomes your comments and suggestions. You can submit your comments by going to:

http://www.sun.com/hwdocs/feedback

Please include the title and part number of your document with your feedback:

Sun External I/O Expansion Unit for SPARC Enterprise T5120/T5140/T5220/T5240/T5440 Servers Product Notes, part number 820-4800-12

Preface vii

Page 8

viii External I/O Expansion Unit Product Notes for SPARC Enterprise T5xxx Servers • March 2010

Page 9

External I/O Expansion Unit Product Notes

This document includes these sections:

■ “Supported Hardware and Software” on page 1

■ “Functionality Issues” on page 2

■ “Documentation Updates” on page 6

Supported Hardware and Software

The following hardware, firmware, and software versions are supported in this release:

■ SPARC

■ The following table lists for each server the first version of the Solaris™

Operating System (OS) and the first version of Integrated Lights Out Management (ILOM) system firmware to support the External I/O Expansion Unit.

Enterprise T5120, T5140, T5220, T5240, and T5440 servers

Server Solaris Version ILOM Firmware

SPARC Enterprise T5120 Solaris 10 8/07 OS 7.1.6.d

SPARC Enterprise T5140 Solaris 10 8/07 OS 7.1.6.d

SPARC Enterprise T5220 Solaris 10 8/07 OS 7.1.6.d

SPARC Enterprise T5240 Solaris 10 8/07 OS 7.1.6.d

SPARC Enterprise T5440 Solaris 10 5/08 OS 7.1.7.d

Page 10

Note – The use of the External I/O Expansion Unit to connect the host server to an

external boot disk drive is not supported.

Patch Information

There are currently no patches that are specific for the External I/O Expansion Unit. Patch requirements can be revised at any time. For the availability of patches, see

“Technical Support” on page vi.

Functionality Issues

This section lists known issues for the External I/O Expansion Unit.

Note – Additional issues regarding the External I/O Expansion Unit might be

found in the software release notes for your operating system or the hardware product notes for your server.

Known Issues

PSU Does Not Automatically Turn On Again After Power Failure

A PSU might not automatically turn on again after an interruption of AC power that lasts at least 55 seconds. This failure can occur if the AC cord is temporarily unplugged, or if the AC circuit temporarily loses input AC power. Note that turning the PSU AC switch off and on manually does not cause this failure. When AC power is restored, on the front of the PSU the AC LED will light, but the OK LED will remain off.

The workaround is to turn off the PSU AC switch for approximately 15 seconds, then turn the PSU AC switch on again. The green OK LED and the green AC LED on the front of the PSU should light up.

2 External I/O Expansion Unit Product Notes for SPARC Enterprise T5xxx Servers • March 2010

Page 11

If the External I/O Expansion Unit is in use by the system when AC power interruption occurs, the server ’s service processor may change the PSU fault status to faulty and light the amber FAULT LED on the PSU. Once a PSU is marked faulty, the fault status will persist through power cycles so the fault status must be manually cleared. See below for the workaround to clear the PSU fault status.

Changing the Status of a PSU That Is Marked As Faulty

If a server’s service processor detects that a PSU is off, the status of the PSU changes to faulty. The faulty status can persist after the PSU is turned back on.

To clear the fault status of a PSU:

1. Ensure that the hardware problem is cleared and the green OK LED is on.

2. Ensure that the domain is on and the External I/O Expansion Unit can be accessed by the service processor.

The External I/O Expansion Unit should be visible under this command:

-> show /SYS

3. Issue the following command:

-> set clear_fault_action=true /SYS/IOX@nnnn/PSx

Where nnnn is the External I/O Expansion Unit and x is the instance of the power supply.

External I/O Expansion Unit Product Notes 3

Page 12

Other Current Issues

TABLE 1 lists open issues for the External I/O Expansion Unit.

TABLE 1 Current Issues (1 of 2)

CR ID Description Workaround

6582282 Ambient temperature at alarm

threshold triggers an excessive number of warning messages.

Ext info /SYS/IOX@nnnn/PSn THERMCTRL/T_AMBIENT has exceeded high warning threshold

(Message repeats.)

6600214 When the power supply unit turns on,

the overtemperature LED might turn on in error.

6660119 If the power supply units are still on

when you disconnect the AC cables, the Fault LED on the PSU might turn on, and the FRUID will be marked faulty.

Reduce the ambient temperature if it is at or exceeds the maximum (38˚C/100˚F). Note: the ambient temperature is measured at the intakes of the PSUs.

Multiple messages are generated if the ambient temperature continuously fluctuates above and below the maximum value.

A single message is generated if the ambient temperature exceeds the maximum without fluctuating above and below the maximum.

If the temperature is within normal limits, recover with this procedure:

• Power off both power supply units on the External I/O Expansion Unit.

• When the DC Power LED ( ) on both power supply units turn off, disconnect both AC cables.

• After 10 seconds or more, reconnect the AC cables.

• Power on the External I/O Expansion Unit.

If the recovery procedure fails, contact a certified service engineer.

To prevent this problem, be sure to turn off the power supply units in the External I/O Expansion Unit before you disconnect the AC cables.

If this problem occurs, verify that the AC cables are properly connected, then turn on the power supply units. Issue the following command to clear the fault and reset the error LEDs on the power supply units:

set clear_fault_action=true /SYS/IOX@nnnn/PSx

6711118 Faults in the External I/O Expansion

Unit that are diagnosed by PSH (Predictive Self-Healing) might display the incorrect location for the suspected FRU(s).

4 External I/O Expansion Unit Product Notes for SPARC Enterprise T5xxx Servers • March 2010

There is no workaround at this time.

Page 13

TABLE 1 Current Issues (2 of 2)

CR ID Description Workaround

6738517 Infiniband I/O cards are not supported. When an External I/O Expansion Unit is connected to a

SPARC Enterprise T5120, T5140, T5220, or T5240 server, Infiniband I/O cards are not supported in either the server or in the External I/O Expansion Unit.

Also note that the SPARC Enterprise T5440 server does not support Infiniband I/O cards, either directly within the T5440 server or within an attached External I/O Expansion Unit.

Closed Issues

TABLE 2 lists issues that were closed.

TABLE 2 Closed Issues

CR ID Fixed in: Description Workaround

6562085 Fan Controller

firmware 2.2

6563777 Fan Controller

firmware 2.4

An I/O boat might not report the correct internal temperature.

If an I/O boat is removed and then inserted again in the External I/O Expansion Unit, the server might generate error messages.

6565649 A PCI Express boat might intermittently not

power on or might display an undervoltage error message.

Ignore the reported temperature.

Reset the External I/O Expansion Unit with the ILOM command:

reset /SYS/IOX@nnnn

where nnnn is the External I/O Expansion Unit system serial number.

The software should automatically restore I/O boat operation. Contact a certified service engineer to request a replacement I/O boat. Note that the fault LED on the I/O boat will continue to be lighted after I/O boat power is restored but the I/O boat will otherwise operate normally.

External I/O Expansion Unit Product Notes 5

Page 14

Documentation Updates

Connecting I/O Boats to Different Domains

The following notes will appear on page 2-16 of the Sun External I/O Expansion Unit Installation and Service Manual in Section 2.6, “Installing the Link Kit”:

Note – If you are installing a second boat in the External I/O Expansion Unit, both

boats must be connected to the same host server. Do not connect the second boat to a different server. The second boat can be connected to a different domain on the same server, but not to a domain on a different server.

Note – Do not daisy-chain two boats (connect a boat to another boat through link

cards). Daisy-chain configurations are not allowed.

The new notes will be repeated on page 1-36 of the manual, in Section 1.4.2, “Dual Boat Configuration.”

These notes will replace the following note that is currently on page 2-16:

Note – If you are installing a second boat in the External I/O Expansion Unit, both

boats must be connected to the same host server. Do not connect the second boat to a different server. Also, do not connect the second boat to the first boat; a daisychain configuration is not allowed.

6 External I/O Expansion Unit Product Notes for SPARC Enterprise T5xxx Servers • March 2010
