Sun Microsystems PCI High Speed Quad Port Serial Interface Adapter User Manual

Sun PCI High Speed Quad Port
Serial Interface Adapter
User’s Guide
Part No. 819-1207-11 May 2010, Revision A
Copyright ©2005, 2010,Oracle and/orits affiliates. Allrights reserved. This softwareand related documentation areprovided under alicense agreementcontaining restrictions on use anddisclosure andare protected by
intellectual propertylaws. Exceptas expressly permitted in yourlicense agreementor allowed by law, youmay notuse, copy, reproduce, translate, broadcast, modify, license,transmit, distribute,exhibit, perform, publish, ordisplay any part, in any form, or by anymeans. Reverseengineering, disassembly, or decompilationof thissoftware, unless requiredby law for interoperability, is prohibited.
The informationcontained hereinis subject to changewithout notice and is notwarranted tobe error-free. If you find any errors,please report themto us in writing.
If thisis softwareor related softwaredocumentation thatis delivered to theU.S. Governmentor anyonelicensing it on behalf ofthe U.S.Government, the following noticeis applicable:
U.S. GOVERNMENTRIGHTS. Programs,software, databases, and related documentationand technicaldata delivered to U.S. Governmentcustomers are "commercial computer software"or "commercial technical data" pursuant tothe applicableFederal AcquisitionRegulation and agency-specific supplemental regulations.As such,the use, duplication, disclosure, modification, andadaptation shallbe subjectto the restrictionsand licenseterms set forth inthe applicableGovernment contract,and, to the extent applicableby theterms ofthe Government contract, the additionalrights setforth inFAR
52.227-19, CommercialComputer Software License (December2007). OracleUSA, Inc.,500 Oracle Parkway, Redwood City, CA 94065. This softwareor hardware is developed for generaluse in a variety ofinformation management applications.It isnot developed orintended foruse in any
inherently dangerous applications, including applications whichmay createa risk of personal injury. If you use this softwareor hardware indangerous applications, thenyou shallbe responsible to take all appropriatefail-safe, backup, redundancy, andother measures to ensurethe safeuse. Oracle Corporation andits affiliatesdisclaim any liability forany damages caused byuse of this software or hardware in dangerousapplications.
Oracle andJava areregistered trademarks ofOracle and/orits affiliates. Other namesmay betrademarks oftheir respective owners. AMD, Opteron,the AMDlogo, and the AMDOpteron logo aretrademarks orregisteredtrademarks ofAdvanced Micro Devices. Inteland IntelXeon are
trademarks orregistered trademarks ofIntel Corporation.All SPARC trademarksare used under license andare trademarksor registered trademarksof SPARCInternational, Inc. UNIX is aregistered trademark licensedthrough X/Open Company, Ltd.
This software or hardware and documentation may provide access to or information on content, products, and services from third parties. Oracle Corporation and its affiliates are not responsible for and expressly disclaim all warranties of any kind with respect to third-party content, products, and services. Oracle Corporation and its affiliates will not be responsible for any loss, costs, or damages incurred due to your access to or use of third-party content, products, or services.
Copyright ©2005, 2010,Oracle et/ouses affiliés. Tous droitsréservés. Ce logicielet ladocumentation quil’accompagne sont protégéspar leslois surla propriété intellectuelle. Ils sontconcédés souslicence etsoumis à des
restrictions d’utilisationet dedivulgation. Sauf disposition devotre contrat de licence oude laloi, vousne pouvez pas copier,reproduire,traduire, diffuser,modifier, breveter, transmettre, distribuer,exposer,exécuter, publier ouafficher le logiciel, même partiellement,sous quelqueforme etpar quelque procédéque cesoit. Par ailleurs, ilest interdit de procéder àtoute ingénierieinverse du logiciel, de ledésassembler oude ledécompiler, excepté à des finsd’interopérabilité avecdes logiciels tiers outel que prescrit par laloi.
Les informationsfournies dansce documentsont susceptibles de modification sanspréavis. Parailleurs, OracleCorporation ne garantit pas qu’elles soient exemptesd’erreurs etvous invite, le caséchéant, à lui enfaire part par écrit.
Si celogiciel, oula documentationqui l’accompagne, est concédé souslicence auGouvernement desEtats-Unis, ou à toute entitéqui délivre la licencede ce logicielou l’utilisepour lecompte du Gouvernement des Etats-Unis,la noticesuivante s’applique:
U.S. GOVERNMENT RIGHTS. Programs, software, databases, and related documentation and technical data delivered to U.S. Government customers are "commercial computer software" or "commercial technical data" pursuant to the applicable Federal Acquisition Regulation and agency-specific supplemental regulations. As such, the use, duplication, disclosure, modification, and adaptation shall be subject to the restrictions and license terms set forth in the applicable Government contract, and, to the extent applicable by the terms of the Government contract, the additional rights set forth in FAR 52.227-19, Commercial Computer Software License (December 2007). Oracle America, Inc., 500 Oracle Parkway, Redwood City, CA 94065.
Ce logicielou matériela étédéveloppé pour un usage généraldans lecadre d’applications de gestion desinformations. Celogiciel ou matériel n’est pas conçu nin’est destinéà être utilisé dans des applicationsà risque,notamment dans des applications pouvantcauser desdommages corporels. Si vous utilisez celogiciel oumatériel dansle cadre d’applicationsdangereuses, il est de votreresponsabilité de prendre toutes les mesures desecours, de sauvegarde, deredondance et autresmesures nécessaires àson utilisationdans des conditions optimales desécurité. OracleCorporation etses affiliés déclinent touteresponsabilité quantaux dommages causés parl’utilisation de ce logicielou matériel pour cetype d’applications.
Oracle etJava sontdes marques déposées d’Oracle Corporation et/oude sesaffiliés.Tout autre nom mentionnépeut correspondre à desmarques appartenant àd’autres propriétaires qu’Oracle.
AMD, Opteron,le logoAMD et le logoAMD Opteron sont des marquesou desmarques déposées d’Advanced Micro Devices.Intel etIntel Xeon sont des marques oudes marques déposées d’IntelCorporation. Toutes les marques SPARC sontutilisées souslicence et sont des marquesou desmarques déposées deSPARC International, Inc. UNIX estune marque déposée concédée sous licencepar X/OpenCompany, Ltd.
Ce logicielou matérielet ladocumentation qui l’accompagne peuvent fournirdes informationsou desliens donnant accès à descontenus, desproduits et des servicesémanant detiers. OracleCorporation et ses affiliés déclinenttoute responsabilité ou garantieexpresse quant aux contenus, produitsou services émanantde tiers.En aucuncas, Oracle Corporation et sesaffiliés ne sauraient être tenuspour responsables des pertes subies, descoûts occasionnés oudes dommagescausés parl’accès à des contenus, produitsou servicestiers, ou à leur utilisation.
Please
Recycle

Contents

Regulatory Compliance Statements xi
Declaration of Conformity xv
Preface xvii
1. Product Overview 1
Product Description 1
Features 2
Hardware and Software Requirements 3
2. SunHSI/U Adapter Installation 5
Installation Process 5
To Install the Adapter 5
External Cabling 6
RS-232 to RS-449 Connections 7
3. SunHSI PCI Software Installation 9
Installation Overview 9
Before Installing the Software 11
Verifying the Software and Hardware Requirements 11
To Remove Older Versions of the Software 11
iii
Installing the Software 12
To Install the SunHSI Software 12
To Test the Installation 14
Configuring the Software 14
To Configure for Point-to-Point Protocol 15
4. SunHSI Utilities 17
hsip_init Utility 17
T1 Compatibility Options 18
Operating Modes Options 18
HDLC Mode 19
IBM (SDLC) Mode 19
hsip_loop Utility 20
hsip_stat Utility 21
A. Cable Pin Assignments & Signals 23
Pin Assignments 23
Interface Signals 27
B. Null Modem Cable Requirements 29
Configuring Internal or External Clocking 30
Building the Null Modem Cable 30
RS-449 Null Modem Cable 31
X.21 to RS-449 Converter 34
C. T1 Inverted Data and Clock Signals 35
Data Signal Inversion 35
Bipolar with 8-Zero Substitution 36
HDLC Zero Insertion Algorithm 36
Clock Signal Inversion 37
iv Sun PCI High Speed Quad Port Serial Interface Adapter User’s Guide • May 2010
D. SunVTS Diagnostic Testing 39
Using the SunVTS sunlinkTest 39
E. Viewing the Man Pages 41
Man Pages 41
To View Man Pages in the C Shell Environment 41
To View Man Pages in Bourne or Korn Shell Environments 42
Glossary 43
Contents v
vi Sun PCI High Speed Quad Port Serial Interface Adapter User’s Guide • May 2010

Figures

FIGURE 1-1 SunHSI/U Adapter 2
FIGURE 3-1 SunHSI Software Directories and Files 10
FIGURE 3-2 SunHSI Devices Created by the Postinstall Script 10
FIGURE B-1 Null modem Cable (Both Suns Supply Clocking) 32
FIGURE B-2 Null modem Cable (Sun System Supplies Clocking for Both Sides) 33
FIGURE B-3 X.21 to RS-449 Converter 34
vii
viii Sun PCI High Speed Quad Port Serial Interface Adapter User’s Guide • May 2010

Tables

TABLE 1-1 Hardware and Software Requirements 3
TABLE 3-1 Required Disk Space 11
TABLE A-1 RS-449 Connector Pin Assignments 23
TABLE A-2 RS-449 Interface Signals 27
TABLE B-1 RS-449 Signals 31
TABLE B-2 X.21 Signals 31
TABLE D-1 Sun VTS Documentation 39
ix
x Sun PCI High Speed Quad Port Serial Interface Adapter User’s Guide • May 2010

Regulatory Compliance Statements

Your Sun product is marked to indicate its compliance class:
Federal Communications Commission (FCC) — USA
Industry Canada Equipment Standard for Digital Equipment (ICES-003) — Canada
Voluntary Control Council for Interference (VCCI) — Japan
Bureau of Standards Metrology and Inspection (BSMI) — Taiwan
Certification and Accreditation Administration of the People’s Republic of China (CNCA) — China
Korea Communications Commission (KCC) — Korea
Please read the appropriate section that corresponds to the marking on your Sun product before attempting to install the product.

FCC Class A Notice

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy, and if it is not installed and used in accordance with the instruction manual, it may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference, in which case the user will be required to correct the interference at his own expense.
Modifications: Anymodifications madeto thisdevice thatare notapproved by Sun Microsystems, Inc. may void the authority granted to the user by the FCC to operate this equipment.

FCC Class B Notice

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/television technician for help.
Modifications: Anymodifications madeto thisdevice thatare notapproved by Sun Microsystems, Inc. may void the authority
granted to the user by the FCC to operate this equipment.
xi

ICES-003 Class A Notice - Avis NMB-003, Classe A

This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.

ICES-003 Class B Notice - Avis NMB-003, Classe B

This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
xii Sun PCI High Speed Quad Port Serial Interface Adapter User’s Guide • May 2010

BSMI Class A Notice

The following statement is applicable to products shipped to Taiwan and marked as Class A on the product compliance label.

CCC Class A Notice

The following statement is applicable to products shipped to China and marked with “Class A” on the product’s compliance label.

Korean Class A Notice

The following is the Korean Class A Broadcasting and Telecommunication Products for Business Purpose Statement.
Regulatory Compliance Statements xiii
xiv Sun PCI High Speed Quad Port Serial Interface Adapter User’s Guide • May 2010

Declaration of Conformity

To receive a copy of the latest Declaration of Conformity (DoC) for the product, create an online request at(https://www2.sun.de/dct/forms/reg_us_1607_755_0.jsp), or send email to: compliance_request_ww@oracle.com.
xv
xvi Sun PCI High Speed Quad Port Serial Interface Adapter User’s Guide • May 2010

Preface

This document provides information for users of the Sun PCI High Speed Quad Port Serial Interface Adapter from Oracle. Information provided includes adapter installation, software installation and configuration, utilities, cable pin-outs and signals, and null modem cable requirements. This document is intended for use by either first-time or experienced users.
If you have just acquired this product, review the introductory sections and follow the guidelines for installing and using the adapter.
Note – The Sun PCI High Speed Quad Port Serial Interface adapter is high-speed
serial-interface (HSI) adapter for PCI applications The adapter is referred to as SunHSI/U in this manual.
How This Book Is Organized
This document is organized as follows:
Chapter 1 describes the products and lists system requirements.
Chapter 2 provides instructions for installing the adapter.
Chapter 3 contains the SunHSI software installation instructions.
Chapter 4 describes the utilities supplied with the SunHSI software.
Appendix A lists the cable pin assignments and signals.
Appendix B provides information on external clocking and the null modem cable.
Appendix C explains the inverted data and clock signals for T1.
xvii
Appendix D gives an overview of the SunVTS diagnostic software.
Appendix E provides instructions for viewing the man pages.
Typographic Conventions
Typeface Meaning Examples
AaBbCc123 The names of commands, files,
and directories; on-screen computer output
AaBbCc123
AaBbCc123 Book titles, new words or terms,
What you type, when contrasted with on-screen computer output
words to be emphasized. Replace command-line variables with real names or values.
Edit your.login file. Use ls -a to list all files.
% You have mail.
% su Password:
Read Chapter 6 in the User’s Guide.
These are called class options.
Yo u must be superuser to do this. To delete a file, type rm filename.
Note – Characters display differently depending on browser settings. If characters
do not display correctly, change the character encoding in your browser to Unicode UTF-8.
Related Documentation
The documents listed as online are available at:
http://docs.sun.com/app/docs/prod/serial.adapt.card?l=en#hic
Application Title
Installation Sun PCI High Speed Quad Port Serial Interface Adapter 819-1207 PDF,
Issues & updates Sun PCI High Speed Quad Port Serial Interface Adapter
Release Notes
xviii Sun PCI High Speed Quad Port Serial Interface Adapter User’s Guide • May 2010
Part Number Format Location
HTML
819-1208 PDF,
HTML
Online
Online
Documentation, Support, and Training
These web sites provide additional resources:
Sun Function URL
Documentation http://docs.sun.com/
Support http://www.sun.com/support/
Training http://www.sun.com/training/
Document Feedback
Submit comments about this document by clicking the Feedback [+] link at:
http://docs.sun.com/. Include the title and part number of your document with
your feedback:
Sun PCI High Speed Quad Port Serial Interface Adapter User’s Guide, part number 819-1207-11
Preface xix
xx Sun PCI High Speed Quad Port Serial Interface Adapter User’s Guide • May 2010
CHAPTER
1

Product Overview

This chapter includes the following topics:
“Product Description” on page 1
“Features” on page 2
“Hardware and Software Requirements” on page 3

Product Description

The Sun PCI High Speed Quad Port Serial Interface adapter is high-speed serial interface (HSI) adapter for PCI applications and is referred to as the SunHSI/U adapter in this manual. The adapter offers comprehensive hot-plug compatibility with Solstice WAN software packages available through Sun. The SunHSI software is a transparent interface on the SunHSI/U adapter, providing a compliant environment for SunLink WAN packages operating on similar Sun communication modules.
The SunHSI/U adapter (see controller with onboard CPU and memory dedicated to WAN communication functions. This architecture operates much more efficiently at high data rates than unintelligent WAN modules. Onboard intelligence allows the workstation or server to be off-loaded from many of the low-level communication tasks that it must perform when there is no native intelligence on the controller.
FIGURE 1-1) is an intelligent, four-port communication
1
FIGURE 1-1 SunHSI/U Adapter
The adapter comes with the RS-449 industry standard connectors (for example, DB-37).
The protocols that operate with the SunHSI/U adapter include the Solstice X.25 and Solstice Point-to-Point Protocol (PPP). The SunHSI/U adapter conforms to the Sun Synchronous Serial Driver Interface Specification.

Features

Four synchronous RS-449 serial ports
Each port can be independently configured
T1/E1 transfer speed simultaneously on all four ports
Works in 3.3 Volt 66 MHz and 5 Volt 33 MHz PCI slots
Increased RS-232 support for data transmission range, up to 100 Kbps
Meets PCI local bus specification, rev. 2.2
Oracle Solaris 64-bit and 32-bit Operating System compatibility
Hot-plug capability
2 Sun PCI High Speed Quad Port Serial Interface Adapter User’s Guide • May 2010

Hardware and Software Requirements

The hardware and software requirements for the SunHSI/U adapter are listed in
TABLE 1-1.
TABLE 1-1
Sun Systems
Hardware and Software Requirements
Workstations Sun Blade 100, 150, 1500, 1000, 2000, 2500
Servers Sun Fire V210, V240, 280R, V440, V480, V490, V880, V890, V1280, E2900,
E6900/E4900, 15K/12K, E25K/E20K
NEBS-certified
Netra 240, 440, 1280
servers
Operating Systems
Solaris 10, Solaris 9, and Solaris 8
SunHSI Software (PCI device drivers, man pages, and utilities)
SunHSI/P 3.1 or newer
Diagnostics Version
Solaris 10 SunVTS 6.0 and subsequent compatible releases
Solaris 9 SunVTS 5.0 and subsequent compatible releases
Solaris 8 SunVTS 4.0 and subsequent compatible releases
The Sun HSI/P softwareis downloadable from the SunDownload Centerat:
http://www.sun.com/download
Chapter 1 Product Overview 3
4 Sun PCI High Speed Quad Port Serial Interface Adapter User’s Guide • May 2010
CHAPTER
2

SunHSI/U Adapter Installation

This chapter describes how to install the adapter in your system and includes the following topics:
“Installation Process” on page 5
“To Install the Adapter” on page 5
“External Cabling” on page 6

Installation Process

A simplified version of the installation process follows:
1. Install the adapter (see “To Install the Adapter” on page 5).
2. Install the SunHSI PCI software (see “SunHSI PCI Software Installation” on
page 9).
3. Test the installation (see “To Test the Installation” on page 3-14).

To Install the Adapter

Caution – Electronic components on printed circuit boards are extremely sensitive
to static electricity. Ordinary amounts of static electricity generated by your clothing or work environment can damage the electronic equipment. When installing the SunHSI/U adapter in a system, use anti-static grounding straps and antistatic mats to help prevent damage due to electrostatic discharge.
5
Note – Refer to your system installation guide or service manual for detailed
instructions for the following steps.
1. Power off your system, using the standard shutdown procedures described in
the Solaris Handbook for Sun Peripherals or your system service manual.
The Solaris Handbook for Sun Peripherals is shipped with the Solaris OS software and is available on the http://docs.sun.com web site.
2. Remove the cover from the unit to access the card slots and connectors.
3. Select an available 3.3 Volt or 5 Volt PCI slot and remove the slot filler panel.
4. Insert the adapter into the PCI connector of the system unit.
Ensure that the front plate on the adapter mounts flush with the chassis panel opening.
5. Install the front plate screw to secure the adapter into the chassis.
This also provides a chassis ground connection to the adapter.
6. Reinstall the cover on the unit.
7. Attach the serial port cable assembly to the I/O connector on the adapter.
8. Connect any cables from the peripheral devices to the RS-449 connectors on the adapter’s cable.
9. Turn power back on and allow the system to reboot.
This completes the hardware installation. Proceed to “SunHSI PCI Software
Installation” on page 9.

External Cabling

The SunHSI/U adapter provides external connectivity through a passive cabling system. A hydra-style connector provides connectivity to four RS-449 devices by means of four DB-37 female connectors in a DTE configuration.
Note – Always use shielded twisted pair RS-449 cables with your SunHSI/U
adapter.
6 Sun PCI High Speed Quad Port Serial Interface Adapter User’s Guide • May 2010

RS-232 to RS-449 Connections

In order to connect RS-232 devices to the adapter, you need to install an externally powered RS-449 to RS-232 interface converter to each DB-37 connector on which you intend to connect an RS-232 device. A converter is necessary because of incompatibilities between RS-232 and RS-449 signal levels.
To obtain an externally powered RS-232 to RS-449 interface converter, contact:
Black Box Corporation at: http://www.blackbox.com
Note – Use only externally powered RS-449 devices with the SunHSI/U adapter.
Chapter 2 SunHSI/U Adapter Installation 7
8 Sun PCI High Speed Quad Port Serial Interface Adapter User’s Guide • May 2010
CHAPTER
3

SunHSI PCI Software Installation

This chapter describes how to install the SunHSI PCI software and includes the following sections:
“Installation Overview” on page 9
“Before Installing the Software” on page 11
“Installing the Software” on page 12
“Configuring the Software” on page 14

Installation Overview

Software for unbundled products is distributed in the form of software packages. The SunHSI PCI software package can be downloaded from the Sun Download Center at:
http://www.sun.com/download
You can use the pkgadd command to install software packages, to spool software packages for installation at a later date, or to remove software packages from your system. For more information see the Solaris System Administration Guide. When you have completed the software installation and run the postinstallation script, you will have created the software directories and files illustrated in
FIGURE 3-1.
FIGURE 3-1 and
Note – If you are upgrading to the SunHSI/U adapter from the SunHSI/P adapter
or if you are running a SunHSI/P adapter along with the SunHSI/U adapter, youmust upgrade the SunHSI software to the latest version.
9
FIGURE 3-1 SunHSI Software Directories and Files
root
/bin
hsip_init*
/man1m /man7d hsip_loop* hsip_stat*
hsip_init.1m* hsip_loop.1m* hspi_stat.1m*
* Signifies a symbolic link.
FIGURE 3-2 SunHSI Devices Created by the Postinstall Script
/man
hsip.7d*
/opt
/SUNWconn
/HSIP
/man
/man1m /man7d
hsip_init.1m
hsip.7d
hsip_loop.1m hsip_stat.1m
/kernel
/bin
hsip_init hsip_loop hsip_stat
/drv
HSIP /sparcv9
HSIP
root
/dev
/hihp
Clone device
(Control Port)
/hihp0 /hihp1 /hihp2 /hihp3
Board 1
10 Sun PCI High Speed Quad Port Serial Interface Adapter User’s Guide • May 2010
/hihp4 /hihp5 /hihp6 /hihp7
Board 2
/hihp8
/hihp9 /hihp10 /hihp11
Board 3 Board N
/hihpn /hihpn /hihpn /hihpn

Before Installing the Software

Verifying the Software and Hardware Requirements

Before installing the software, answer the following questions:
Does your system have any available 3.3V or 5V PCI slots?
Have you downloaded the SunHSI software from the Sun Download Center at:
http://www.sun.com/download
What is the installation directory (default directory is /opt)?
Do you have the superuser password for both the system where the software is to
be installed and the system with download software, if different?
Does your system have enough disk space?
Use both the following commands to check for disk space:
# df -k /opt # df -k /
TABLE 3-1 Required Disk Space
SunHSI Package Name Default Installation Directory Approximate Space Required
SUNWhsip / 1 Mbyte
SUNWhsipm and SUNWhsipu /opt 1 Mbyte total

To Remove Older Versions of the Software

Caution – Do not overwrite any existing SunHSI software packages. If you install
the SunHSI software packages over existing SunHSI software packages, you will have two instances of the software packages. This might cause problems when installing or backing out of software patches.
Chapter 3 SunHSI PCI Software Installation 11
Before installing the SunHSI PCI software on your system, check your system to see if previous versions of the SunHSI software are installed. If older SunHSI software exists, you must remove this software before installing the new SunHSI software.
Using the pkginfo command, check the system for installed SunHSI software
packages:
# /usr/bin/pkginfo | grep SUNWhsip system SUNWhsip SunHSI/P Driver for PCI system SUNWhsipm SunHSI/P Man Pages for PC system SUNWhsipu SunHSI/P Utilities for PCI
If no SunHSI packages are installed, skip to the next section,“Installing the
Software” on page 12, to continue with the software installation.
If there are SunHSI packages installed, remove them by logging on as superuser (root) and typing the following command:
# /usr/sbin/pkgrm SUNWhsip SUNWhsipu SUNWhsipm

Installing the Software

The SunHSI PCI driver, utilities, and man pages are distributed in the standard Solaris pkgadd distribution format. The pkgadd utility loads the SUNWhsip, SUNWhsipm, and SUNWhsipu packages onto the system from the distribution media.

To Install the SunHSI Software

1. Access the directory where the SunHSI software has been downloaded.
# cd download-directory
where download-directory is the name of the directory where the SunHSI software was downloaded.
12 Sun PCI High Speed Quad Port Serial Interface Adapter User’s Guide • May 2010
2. Log in as superuser or change to superuser.
You must possess superuser privileges to invoke the following commands. This ensures that all preinstallation scripts in the software package will be executed with superuser privileges.
# /usr/bin/su Password: superuser-password
3. Using the pkgadd command, install the software packages as follows:
# pkgadd -d /download-directory/sunhsip_3_1/Product
The following packages are available:
SUNWhsip SunHSI/P Driver for PCI 3.1,REV=2005.xx.xx SUNWhsipm SunHSI/P Man pages for PCI 3.1,REV=2005.xx.xx SUNWhsipu SunHSI/P Utilities for PCI 3.1,REV=2005.xx.xx
Select package(s) you wish to process (or ‘all’ to process all packages). (default: all) [?,??,q]: all
where download-directory is the name of the directory where the SunHSI software was downloaded.
a. Type all or leave blank then press the Return key to continue the
installation of the driver software.
If the pkgadd utility warns you that some scripts must be executed with superuser permissions, type y.
4. After successful completion of the package installation, reboot the system using the reconfigure option.
a. Synchronize the hard disks and halt the system, using the following
commands.
# /usr/sbin/sync # /usr/sbin/halt
b. At the ok prompt, type the boot command with the -r option:
ok boot -r
Chapter 3 SunHSI PCI Software Installation 13
5. After the system reboots, verify the installation by typing the following commands:
# /usr/bin/pkginfo | grep SUNWhsip system SUNWhsip SunHSI/P Driver for PCI system SUNWhsipm SunHSI/P Man Pages for PC system SUNWhsipu SunHSI/P Utilities for PCI
# modinfo | grep HSIP 126 7bb24000 17708 150 1 HSIP (PT-PCI334 Driver)
# grep HSIP /etc/path_to_inst "/ssm@0,0/pci@18,700000/pci1214,334a@2" 0 "HSIP"
The output shows that the packages are installed, the driver is loaded, and that the software is mapped to the adapter.

To Test the Installation

Type the following command (replace n with the adapter port you are testing):
# hsip_loop -c 100 -l 2048 -s 2048000 -t 1 hihpn
This command runs an internal loopback test. For more information, see the hsip_loop(1M) man page.

Configuring the Software

To configure the adapter for the Point-to-Point Protocol (PPP), see “To Configure for
Point-to-Point Protocol” on page 3-15. Also refer to the Solaris System Administration
Guide: Network Services documentation for the version of Solaris that you are running. These documents are available from the following web site:
http://docs.sun.com/
To configure the adapter for the X.25 9.2 protocol, refer to the Solstice X.25 9.2 Administration Guide (806-1234). The X.25 9.2 documents are available from the
following web site:
http://docs.sun.com/
14 Sun PCI High Speed Quad Port Serial Interface Adapter User’s Guide • May 2010

To Configure for Point-to-Point Protocol

1. Change to the /etc/ppp directory and create an executable file called conf_hsip, containing the following information:
#!/bin/ksh -x
DEVICE=‘echo $DEVICE | sed ‘s/?dev?//’’ /opt/SUNWconn/bin/hsip_init $DEVICE speed=2048000 mode=fdx loopback=no \ nrzi=no txc=baud rxc=rxc txd=txd rxd=rxd signal=no 2>&1 > /dev/null
2. Create another executable file called demand, containing the following information:
if [ -f /var/run/ppp-demand.pid ] &&
/usr/bin/kill -s 0 ‘/bin/cat /var/run/ppp-demand.pid’ then :
else
env DEVICE=hihp0 /usr/bin/pppd hihp0 :qa1b-hihp0 call far-hsip env DEVICE=hihp1 /usr/bin/pppd hihp1 :qa1b-hihp1 call far-hsip env DEVICE=hihp2 /usr/bin/pppd hihp2 :qa1b-hihp2 call far-hsip env DEVICE=hihp3 /usr/bin/pppd hihp3 :qa1b-hihp3 call far-hsip
fi
3. Change to the /etc/ppp/peers directory and create an executable file called far-hsip, containing the following information:
connect ‘/etc/ppp/conf-hsip’ local sync noauth 0: ipcp-accept-local nodefaultroute passive persist noccp nopcomp novj noaccomp
4. Add the client site hosts on the server machine and add the server site hosts on the client machine.
a. Edit the server’s /etc/hosts file and add the client site local hosts.
Chapter 3 SunHSI PCI Software Installation 15
b. Edit the client’s /etc/hosts file and add the server site local hosts.
Note – Both IP addresses have to be on the same subnet.
Refer to the hosts(4) man page and the sample /etc/hosts files:
#Server site (/etc/hosts) # Client site (/etc/hosts) #======================= #======================= #local #local
192.10.10.10 qa8a-hihp0 192.10.10.20 qa1b-hihp0
193.10.10.10 qa8a-hihp1 193.10.10.20 qa1b-hihp1
194.10.10.10 qa8a-hihp2 194.10.10.20 qa1b-hihp2
195.10.10.10 qa8a-hihp3 195.10.10.20 qa1b-hihp3
#remote #remote
192.10.10.20 qa1b-hihp0 192.10.10.10 qa8a-hihp0
193.10.10.20 qa1b-hihp1 193.10.10.10 qa8a-hihp1
194.10.10.20 qa1b-hihp2 194.10.10.10 qa8a-hihp2
195.10.10.20 qa1b-hihp3 195.10.10.10 qa8a-hihp3
5. Edit the /etc/netmasks file as follows:
192.10.10.0 255.255.255.0
193.10.10.0 255.255.255.0
194.10.10.0 255.255.255.0
195.10.10.0 255.255.255.0
6. Start the PPP connection by typing the following commands:
/etc/rc2.d/S47pppd stop /etc/rc2.d/S47pppd start
16 Sun PCI High Speed Quad Port Serial Interface Adapter User’s Guide • May 2010
CHAPTER
4

SunHSI Utilities

The SunHSI software includes the hsip_init, hsip_loop, and hsip_stat utilities. This chapter contains a short description of each utility. Refer to each man page to get more information on the commands. Also see “Viewing the Man Pages”
on page 41.
This chapter includes the following topics:
hsip_init Utility” on page 17
hsip_loop Utility” on page 20
hsip_stat Utility” on page 21
Note – You need to be superuser (root) in order to run the hsip_init,
hsip_loop,orhsip_stat utilities.

hsip_init Utility

The hsip_init utility enables you to modify some of the hardware operating modes common to synchronous serial lines. This modification is needed for the operation of some communications packages and is useful in troubleshooting a link. See the hsip_init(1M) man page for details.
The hsip_init utility includes options for T1 compatibility and operating modes. See
“T1 Compatibility Options” on page 18 and “Operating Modes Options” on page 18
for information on these options.
17

T1 Compatibility Options

The version of the hsip_init utility shipped with the SunHSI software has options that enable you to invert data and clock signals to accommodate the requirements of T1 or CEPT transmission equipment. The hsip_init parameters that allow for inversion are:
txd – transmit data signal
rxd – receive data signal
txc – transmit clock signal
rxc – receive clock signal
The effect of the default settings for all of these parameters is that SunHSI software does not invert the data or clock signal controlled by the parameter. To invert a signal, you specify a setting of the form param-name=-paramname, for example, txc=-txc.
As an example, suppose you want to invert the transmit and receive data signals on the first SunHSI/U port (port 0) on the second SunHSI/U adapter in your system. To do so, enter the following command:
# hsip_init hihp4 txd=-txd rxd=-rxd
To invert both clock and data signals, enter:
# hsip_init hihp4 txd=-txd rxd=-rxd txc=-txc rxc=-rxc
Appendix C discusses the background and requirements for these inverted settings.

Operating Modes Options

This section describes the operating modes that you can set with the hsip_init utility.
The SunHSI software operates in two main operating modes, the high-level data link control (HDLC) mode and the IBM (SDLC) mode. The HDLC mode always operates in a full-duplex, point-to-point fashion. While the IBM mode defaults to a full-duplex, point-to-point, operation.
18 Sun PCI High Speed Quad Port Serial Interface Adapter User’s Guide • May 2010
HDLC Mode
The default operating mode used by the SunHSI software is the HDLC full-duplex protocol (mode=fdx). In this mode the transmitter is always enabled. The transmitter sends flag bytes continuously when it is not sending a data frame.
If no message is currently being transmitted, the driver will attempt to start sending its next message. At this point the driver indicates that it is busy transmitting, to prevent the transmission of another message concurrently. The driver also activates a mechanism that ensures that the transmit operation will not hang if the hardware is not responding.
When the transmission is completed, the busy mechanism previously set is cleared and the next message can be transmitted. If the transmission is hung an abort sequence is sent instead of the cyclic redundancy check (CRC), so that the receiver will not interpret the frame as valid data. The message is discarded, and the output error statistic is incremented, which allows for a proper recovery by higher level protocols.
The received data is buffered until a complete frame has been received. If any error occurs during the reception of a frame, the appropriate statistic is incremented and the frame is discarded.
IBM (SDLC) Mode
SDLC mode is designed to support IBM system network architecture (SNA) communications. It uses most of the same protocols used in HDLC mode, with two major exceptions:
When the line is idle, instead of sending flag bytes the transmitter is disabled.
The request-to-send (RTS) and clear-to-send (CTS) signals are used to gate
transmission.
IBM Full-Duplex Mode
When the SunHSI software is set to this mode (mode=ibm-fdx), the software uses a full-duplex point-to-point communication protocol. Both ends of the link are expected to have RTS and CTS signals asserted at all times when data is being exchanged. When starting a message transmission, the interface raises the RTS signal and expects the CTS signal to be asserted immediately. If this is not done, all messages currently queued for transmission are discarded, and the write operation returns an error.
Chapter 4 SunHSI Utilities 19
If the CTS signal drops before the frame transmission is complete, the frame is discarded and the abort error statistic is incremented. If the transmission underruns, an abort sequence is not sent and the frame is silently discarded. The RTS signal remains asserted until the data transmission is complete.
IBM Half-Duplex Mode
Half-duplex is a submode of the IBM mode (mode=ibm-hdx). Half-duplex mode operates in the same manner as full-duplex mode except that transmission cannot occur while receiving, and vice-versa. When a transmission is completed, the RTS signal is dropped. Dropping the RTS signal tells the remote station to begin transmitting if it is ready to.
IBM MultiPoint Mode
In a multipoint configuration (mode=ibm-mpt), more than two stations share a link. This configuration is accomplished by designating one station as a primary station and the rest as secondary stations. In this mode, the port acts as a secondary station. The primary station arbitrates traffic on the link by polling the secondary stations, to see if they are ready to transmit.
If a secondary station has data to transmit, it will raise its RTS signal and check for CTS signals. When a CTS signal comes up the station may begin transmitting, following the same rules for RTS and CTS signals used in half-duplex mode. When the transmission is complete the secondary drops the RTS signal, which enables another station to respond to a poll and begin transmitting. The RTS signal cannot be dropped until the transmission is complete.

hsip_loop Utility

The hsip_loop utility is high-speed, synchronous, serial loopback test program for high-speed serial interface. The utility performs several loopback tests that exercise the components of a serial communications link. See the hsip_loop(1M) man page for more information.
20 Sun PCI High Speed Quad Port Serial Interface Adapter User’s Guide • May 2010

hsip_stat Utility

The hsip_stat utility reports the event statistics maintained by the SunHSI device driver. The report might be a single snapshot of the accumulated totals, or a series of samples showing incremental changes. At the beginning of the report, the device name being used to query a particular device appears. See the hsip_stat(1M) man page for more information.
Chapter 4 SunHSI Utilities 21
22 Sun PCI High Speed Quad Port Serial Interface Adapter User’s Guide • May 2010
APPENDIX
A

Cable Pin Assignments & Signals

This appendix includes the following information:
“Pin Assignments” on page 23
“Interface Signals” on page 27

Pin Assignments

A shielded, hydra-style breakout cable providing four 37-pin, D-shell (DB-37) DTE connectors is available for the SunHSI/U adapter. Since there are not enough wires to create the signal ground (pin 19) connections, use the shield ground (pin 1) of the DB-37 connector for this signal. The pin assignments for the cabling and connectors are shown in
TABLE A-1.
TABLE A-1 RS-449 Connector Pin Assignments
80-Pin Amp. Pin No.
1 RxD1(A) 6 Port 1 Receive Data
2 RxD1(B) 24 Port 1 Receive Data
3 DTR1(A) 12 Port 1 Data Terminal Ready
4 DTR1(B) 30 Port 1 Data Terminal Ready
5 TxD1(A) 4 Port 1 Transmit Data
6 TxD1(B) 22 Port 1 Transmit Data
7 RTS1(A) 7 Port 1 Request To Send
8 RTS1(B) 25 Port 1 Request To Send
9 TxC1(A) 17 Port 1 Transmit Clock
RS-449 Signal Name
RS-449 DB-37 Pin No. Description
23
TABLE A-1 RS-449 Connector Pin Assignments (Continued)
80-Pin Amp. Pin No.
RS-449 Signal Name
RS-449 DB-37 Pin No. Description
10 TxC1(B) 35 Port 1 Transmit Clock
11 TxCI1(A) 5 Port 1 Transmit Clock In
12 TxCI1(B) 23 Port 1 Transmit Clock In
13 DCD1(A) 13 Port 1 Data Carrier Detect
14 DCD1(B) 31 Port 1 Data Carrier Detect
15 DSR1(A) 11 Port 1 Data Set Ready
16 DSR1(B) 29 Port 1 Data Set Ready
17 CTS1(A) 9 Port 1 Clear To Send
18 CTS1(B) 27 Port 1 Clear To Send
19 RxC1(A) 8 Port 1 Receive Clock
20 RxC1(B) 26 Port 1 Receive Clock
Shield Ground SG 1 Port 1 Shield Ground and Signal Ground
21 RxD2(A) 6 Port 2 Receive Data
22 RxD2(B) 24 Port 2 Receive Data
23 DTR2(A) 12 Port 2 Data Terminal Ready
24 DTR2(B) 30 Port 2 Data Terminal Ready
25 TxD2(A) 4 Port 2 Transmit Data
26 TxD2(B) 22 Port 2 Transmit Data
27 RTS2(A) 7 Port 2 Request To Send
28 RTS2(B) 25 Port 2 Request To Send
29 TxC2(A) 17 Port 2 Transmit Clock
30 TxC2(B) 35 Port 2 Transmit Clock
31 TxCI2(A) 5 Port 2 Transmit Clock In
32 TxCI2(B) 23 Port 2 Transmit Clock In
33 DCD2(A) 13 Port 2 Data Carrier Detect
34 DCD2(B) 31 Port 2 Data Carrier Detect
35 DSR2(A) 11 Port 2 Data Set Ready
36 DSR2(B) 29 Port 2 Data Set Ready
37 CTS2(A) 9 Port 2 Clear To Send
38 CTS2(B) 27 Port 2 Clear To Send
24 Sun PCI High Speed Quad Port Serial Interface Adapter User’s Guide • May 2010
TABLE A-1 RS-449 Connector Pin Assignments (Continued)
80-Pin Amp. Pin No.
RS-449 Signal Name
RS-449 DB-37 Pin No. Description
39 RxC2(A) 8 Port 2 Receive Clock
40 RxC2(B) 26 Port 2 Receive Clock
Shield Ground SG 1 Port 2 Shield Ground and Signal Ground
41 RxD3(A) 6 Port 3 Receive Data
42 RxD3(B) 24 Port 3 Receive Data
43 DTR3(A) 12 Port 3 Data Terminal Ready
44 DTR3(B) 30 Port 3 Data Terminal Ready
45 TxD3(A) 4 Port 3 Transmit Data
46 TxD3(B) 22 Port 3 Transmit Data
47 RTS3(A) 7 Port 3 Request To Send
48 RTS3(B) 25 Port 3 Request To Send
49 TxC3(A) 17 Port 3 Transmit Clock
50 TxC3(B) 35 Port 3 Transmit Clock
51 TxCI3(A) 5 Port 3 Transmit Clock In
52 TxCI3(B) 23 Port 3 Transmit Clock In
53 DCD3(A) 13 Port 3 Data Carrier Detect
54 DCD3(B) 31 Port 3 Data Carrier Detect
55 DSR3(A) 11 Port 3 Data Set Ready
56 DSR3(B) 29 Port 3 Data Set Ready
57 CTS3(A) 9 Port 3 Clear To Send
58 CTS3(B) 27 Port 3 Clear To Send
59 RxC3(A) 8 Port 3 Receive Clock
60 RxC3(B) 26 Port 3 Receive Clock
Shield Ground SG 1 Port 3 Shield Ground and Signal Ground
61 RxD4(A) 6 Port 4 Receive Data
62 RxD4(B) 24 Port 4 Receive Data
63 DTR4(A) 12 Port 4 Data Terminal Ready
64 DTR4(B) 30 Port 4 Data Terminal Ready
65 TxD4(A) 4 Port 4 Transmit Data
66 TxD4(B) 22 Port 4 Transmit Data
Appendix A Cable Pin Assignments & Signals 25
TABLE A-1 RS-449 Connector Pin Assignments (Continued)
80-Pin Amp. Pin No.
RS-449 Signal Name
RS-449 DB-37 Pin No. Description
67 RTS4(A) 7 Port 4 Request To Send
68 RTS4(B) 25 Port 4 Request To Send
69 TxC4(A) 17 Port 4 Transmit Clock
70 TxC4(B) 35 Port 4 Transmit Clock
71 TxCI4(A) 5 Port 4 Transmit Clock In
72 TxCI4(B) 23 Port 4 Transmit Clock In
73 DCD4(A) 13 Port 4 Data Carrier Detect
74 DCD4(B) 31 Port 4 Data Carrier Detect
75 DSR4(A) 11 Port 4 Data Set Ready
76 DSR4(B) 29 Port 4 Data Set Ready
77 CTS4(A) 9 Port 4 Clear To Send
78 CTS4(B) 27 Port 4 Clear To Send
79 RxC4(A) 8 Port 4 Receive Clock
80 RxC4(B) 26 Port 4 Receive Clock
Shield Ground SG 1 Port 4 Shield Ground and Signal Ground
26 Sun PCI High Speed Quad Port Serial Interface Adapter User’s Guide • May 2010

Interface Signals

Functional descriptions of the RS-449 interface signals are provided in TABLE A-2.
TABLE A-2 RS-449 Interface Signals
RS-449 Pin No. Signal Name Function
1 Shield Ground Enables tandem sections of shielded cable to retain continuity
through the connector.
19 Signal Ground (SG) Directly connects the DTE circuit ground to the DCE circuit
ground, providing a path for DTE and DCE signal commons.
4/22 Transmit Data (TxD) Used by the DTE to pass binary data to the DCE for
transmission over the communications channel.
6/24 Receive Data (RxD) Used by the DCE to pass binary data received from the
communications channel to the DTE.
5/23 Transmit Clock in (TxCI) Enables the DCE to transmit signal element timing to the DTE.
This enables the DTE Transmit Data signal on circuit TxD to be in synchronization with On/Off transitions on this lead.
8/26 Receive Clock (RxC) Transitions on this lead enables the DTE to time data received
over circuit RxD.
17/35 Transmit Clock (TxC) Enables the DTE to provide transmit timing information to the
DCE so that the DTE can synchronize with data arriving over the TxD lead.
7/25 Request to Send (RTS) Used by the DTE to advise the DCE it is ready to transmit data.
9/27 Clear to Send (CTS) Used by the DCE to advise the DTE that the DCE is ready to
send data over the communications channel.
11/29 Data Set Ready (DSR) Used to advise the DTE of the Ready status on the DCE. In
most cases, this signal simply implies the unit is powered on.
12/30 Data Terminal Ready (DTR) Used by the DTE to advise the DCE it is ready to transmit or
receive.
13/31 Data Carrier Detect (DCD) The DCE uses this lead to advise the DTE that an incoming
signal on the communications channel is present. When first initialized this signal is an indication to the DTE to expect data momentarily.
Appendix A Cable Pin Assignments & Signals 27
28 Sun PCI High Speed Quad Port Serial Interface Adapter User’s Guide • May 2010
APPENDIX
B

Null Modem Cable Requirements

A synchronous null modem cable is a specially-configured cable that simulates modems that are connected back-to-back. When the distance between the two host systems is not great, you may be able to use a null modem cable instead of a synchronous modem or a synchronous modem eliminator.
The maximum distance a null modem cable can work is determined by the specification for your serial port interface.
There are two steps you must perform to use a null modem cable for machine supplied clocking:
Run hsip_init (see “Configuring Internal or External Clocking” on page 30) so that the Sun system, in the absence of a synchronous modem, supplies clocking on the serial line.
Build or configure the cable for the null modem.
Note – You must run hsip_init each time you reboot your system.
The following topics are included in this appendix:
“Configuring Internal or External Clocking” on page 30
“Building the Null Modem Cable” on page 30
29

Configuring Internal or External Clocking

To configure an RS-449 port to provide transmit clocking for itself as well as receive clocking for the other end of the link, set the txc (transmit clock) and rxc (receive clock) parameters in hsip_init to baud and rxc, respectively. For example, the following hsip_init command sets the data rate of the first Sun HSI serial port to 9600 bps and sets the clocking as just described:
# hsip_init hihp0 9600 txc=baud rxc=rxc
You enter such a command at both ends of a link if both sides are supplying clocking.
In the situation in which you have Sun systems at both ends of a link and have one system supplying clocking for both sides, on the system that is not supplying the clocking, you enter:
# hsip_init hihp0 9600 txc=txc rxc=rxc

Building the Null Modem Cable

To build a null modem cable, you can configure your own cable or use a standard cable with an adapter box.
Note – Be sure to use shielded, twisted pair wire when building a null modem cable.
If you decide to use an adapter box, be sure to obtain an adapter that allows you to change the pin configurations. Pre-configured adapters generally do not work with synchronous protocols because they do not handle clock signals correctly.
30 Sun PCI High Speed Quad Port Serial Interface Adapter User’s Guide • May 2010

RS-449 Null Modem Cable

TABLE B-1 and TABLE B-2 list the signals and names for RS-499 and X.21 circuits
TABLE B-1 RS-449 Signals
Circuit Name Direction
TxD Transmit Data To DCE
RxD Receive Data From DCE
TxC Transmit Clock To DCE
TxCI Transmit Clock In From DCE
RxC Receive Clock From DCE
RTS Request to Send To DCE
CTS Clear to Send From DCE
DCD Data Carrier Detect From DCE
DTR Data Terminal Ready To DCE
DSR Data Set Ready From DCE
SG Signal Ground
TABLE B-2 X.21 Signals
Circuit Name Direction
G Signal Ground
T Transmit To DCE
R Receive From DCE
C Control To DCE
I Indication From DCE
S Signal Element Timing From DCE
B Byte Timing From DCE
Appendix B Null Modem Cable Requirements 31
FIGURE B-1 illustrates a synchronous null modem cable that allows you to connect
two Sun systems that each supply clocking, using the RS-449 interface. Each Sun supplies clocking on pins 17 and 35. The null modem cable routes this clocking to pins 8 and 26 on the opposite side to provide receive clocking.
Because the RS-449 interface is balanced, there are two pins for each signal. For example, Transmit Data (TxD), pins 4 and 22, is connected to Received Data (RxD), pins 6 and 24. This means that pin 4 is connected to pin 6 and pin 22 is connected to pin 24.
FIGURE B-1 Null modem Cable (Both Suns Supply Clocking)
TxD (4,22)
RxD (6,24)
RTS (7,25)
CTS (9,27)
DSR (11,29)
SG (19)
DCD (13,31)
RxC (8,26)
DTR (12,30)
TxC (17,35)
Sun workstation
TxD (4,22)
RxD (6,24)
RTS (7,25)
CTS (9,27)
DSR (11,29)
SG (19)
DCD (13,31)
RxC (8,26)
DTR (12,30)
TxC (17,35)
Sun workstation
32 Sun PCI High Speed Quad Port Serial Interface Adapter User’s Guide • May 2010
FIGURE B-2 illustrates a synchronous null modem cable that allows you to another
system, Sun or non-Sun, using the RS-449 interface. The Sun supplies both the transmit and receive clocks for the other system. Note that this null modem cable is not symmetrical.
FIGURE B-2 Null modem Cable (Sun System Supplies Clocking for Both Sides)
TxD (4,22)
RxD (6,24)
RTS (7,25)
CTS (9,27)
DSR (11,29)
SG (19)
DCD (13,31)
RxC (8,26)
DTR (12,30)
TxC (17,35)
Sun workstation that supplies clocking
TxD (4,22)
RxD (6,24)
RTS (7,25)
CTS (9,27)
DSR (11,29)
SG (19)
DCD (13,31)
TxCI (5,23)
RxC (8,26)
DTR (12,30)
Sun or foreign device
Appendix B Null Modem Cable Requirements 33

X.21 to RS-449 Converter

FIGURE B-3 illustrates the pin connections required for an X.21 to RS-449 converter.
FIGURE B-3 X.21 to RS-449 Converter
T(2,9)
S (6,13)
C (3,10)
R (4,11)
I (5,12)
G (8)
X.21 interface (15 pin connector)
TxD (4,22)
RxC (8,26)
TxCI (5,23)
RTS (7,25)
CTS (9,27)
RxD (6,24)
DCD (13,31)
SG (19)
RS-449 Interface Workstation (37 Pin Connector)
When using an X.21 conversion you must perform the following hsip_init operation:
# hsip_init hihp0 9600 txc=txc rxc=rxc
Note – Both receive and transmit clock inputs (RxC and TxCI) need a clock signal if
txc is set to txc and rxc is set to rxc.
34 Sun PCI High Speed Quad Port Serial Interface Adapter User’s Guide • May 2010
APPENDIX
C

T1 Inverted Data and Clock Signals

This appendix includes the following topics:
“Data Signal Inversion” on page 35
“Clock Signal Inversion” on page 37

Data Signal Inversion

The requirement for inverting data signals arises from the “ones density” problem you encounter with most T1 transmission lines in North America. The T1 transmission scheme uses a signaling mechanism known as Alternate Mark Inversion (AMI), in which one bits are represented by a positive or negative pulse, while zero bits are represented by the absence of a pulse. In this scheme, the polarity of each pulse must be the opposite of the polarity of the pulse which immediately preceded it. This signaling scheme makes it possible to embed a reference clock for the data into the data stream itself.
Various types of T1 transmission equipment, such as Data Service Units (DSU), Channel Service Units (CSU), repeaters, and various telephone central office equipment, must be able to keep a phase locked loop (PLL) circuit locked on to this reference clock. This PLL circuit uses the pulses generated when one bits are transmitted to lock the embedded clock to a local reference oscillator. To keep the PLL circuit locked on the extracted clock, a certain density of pulses (one bits) must be guaranteed. For North American T1 lines, the density requirement dictates that at least one out of every 16 bits must be a one (see AT&T Technical Publication 62411). Another way of stating this is that no more than 15 consecutive zero bits can occur anywhere in the data stream.
T1 lines were originally intended to carry voice traffic, wherein the digitized voice signals could be altered to meet the ones-density requirement by forcing every eighth bit of a voice channel to be a one. This practice introduces a small—but virtually
35
inaudible—amount of distortion in the voice signal. Digital data streams between two computers are another matter, since the corruption of even one data bit causes a packet to be rejected. Note that in a typical data packet it is quite easy to produce bit patterns that violate the ones-density requirement. A random file could easily contain a sequence of bytes that would produce 16 or more consecutive zero bits if transmitted serially.
There are many different schemes for circumventing the ones-density requirement. The most common technique simply reserves every eighth bit of the signal for a “density bit” and forces this bit to be a one. Obviously, these bits are not available for data transmission, which means that 12.5 percent of the bandwidth of the T1 line is wasted. When you consider that the lease cost for a coast-to-coast T1 line can be exceedingly expensive, this waste of bandwidth can be unacceptable. There are alternatives.

Bipolar with 8-Zero Substitution

One of them uses a special code that transmission equipment can generate when using the AMI signalling scheme. This special code depends on the fact that two successive one bits that are represented by pulses of the same polarity result in a signal known as a “Bipolar Violation.” A CSU can be designed so that it will automatically replace any string of eight consecutive zeros with a special code pattern that contains two of Bipolar Violations. A compatible, receiving CSU recognizes this special code and converts it back to a pattern of eight zeros. This technique is known by the acronym B8ZS, which stands for Bipolar with 8-Zero Substitution.
All CEPT lines (the European equivalent of T1) mandate the use of a variant of B8ZS that holds the density requirement down to no more than three consecutive zeros. However, telephone companies in North America have been slow to adopt B8ZS, because it would entail a significant capital investment. Therefore, the B8ZS solution will not solve the ones-density problem in the short term.

HDLC Zero Insertion Algorithm

An alternative to B8ZS—an alternative used by the SunHSI/P product—makes use of the fact that the HDLC framing rules specify that any data stream that contains five or more consecutive one bits requires that the transmitting end insert a zero bit after the fifth one bit. This guarantees that the HDLC flag pattern 01111110 (hex 7E) does not occur randomly inside a frame. The receiving end must automatically discard the zero bit that follows a pattern of five consecutive ones. So, HDLC framing, which is used by SunHSI/P, guarantees that, except for the flag pattern, in any set of six bits, at least one bit will be a zero. If you include the flag pattern, you can say that in any set of seven bits, at least one bit will be a zero.
36 Sun PCI High Speed Quad Port Serial Interface Adapter User’s Guide • May 2010
By inverting the data signal with HDLC framing on both ends of a link, the HDLC zero insertion algorithm becomes a ones insertion algorithm. This guarantees that in any set of seven bits, at least one bit will be a one. Thus, the HDLC data stream meets the density requirements of North American T1 lines without sacrificing any bandwidth.

Clock Signal Inversion

The need to invert clock lines is separate from the need to invert data lines. Most computer, modem, and terminal vendors adhere to an industry standard specification known as RS-334. This specification defines the relationship between a data bit and a reference clock on a synchronous serial link. The specification also says that a device should transmit data with reference to the rising edge of the clock signal and that data should be received with reference to the falling edge of the clock signal.
When using long cables or cables not carrying a clock signal, a phase shift may occur causing a high number of errors. In such cases, inverting the clock signal may correct the phase shift. You may also need to invert the clock signal when connecting a SunHSI/P port to equipment not adhering to the RS-334 standard.
Appendix C T1 Inverted Data and Clock Signals 37
38 Sun PCI High Speed Quad Port Serial Interface Adapter User’s Guide • May 2010
APPENDIX
D

SunVTS Diagnostic Testing

The SunVTS software executes multiple diagnostic hardware tests from a single user interface, and is used to verify the configuration and functionality of most hardware controllers and devices. The SunVTS software operates primarily from a graphical user interface, enabling test parameters to be set quickly and easily while a diagnostic test operation is being performed.
Refer to the SunVTS documents (see monitor the sunlink diagnostic. These SunVTS documents are available online at the following URL:
http://www.sun.com/documentation
Select the document for the Solaris release on your system.
TABLE D-1 Sun VTS Documentation
Title Description
SunVTS User’s Guide Describes the SunVTS diagnostic environment.
SunVTS Test Reference Manual Describes each SunVTS test (including sunlink) and
describesthe various test options and command-line arguments.
SunVTS Quick Reference Card Provides an overview of the user interface.
TABLE D-1) for instructions on how to run and

Using the SunVTS sunlinkTest

The sunlink diagnostic test, which is shipped with the SunVTS software, verifies the functionality of SunHSI adapters. This test can be run from the SunVTS user interface, or it can be run from the command line. Refer to the SunVTS Test Reference Manual for more information about the sunlink test.
39
Note – Some of the sunlink tests require a RS-449 loopback plug, which can be
ordered through Sun (part number 540-1430).
40 Sun PCI High Speed Quad Port Serial Interface Adapter User’s Guide • May 2010
APPENDIX
E

Viewing the Man Pages

The following man pages are included with the SunHSI software:
hsip(7d)
hsip_init(1m)
hsip_loop(1m)
hsip_stat(1m)
If you cannot view these man pages, you need to add the /opt/SUNWconn/man/ directory to your MANPATH environment variable. Depending on the UNIX shell you are using, this variable might be defined in one of a number of startup files.

Man Pages

To View Man Pages in the C Shell Environment

1. Examine your $HOME/.login and $HOME/.cshrc files to locate the MANPATH
variable.
2. Using a text editor, add the following line to the end of the file containing the
MANPATH variable.
setenv MANPATH “/opt/SUNWconn/man/:$MANPATH”
41
If neither of the files in Step 1 contains the MANPATH variable, add the following line to the end of one of the files, or contact your system administrator for assistance.
setenv MANPATH “/opt/SUNWconn/man/”
3. Use the source command on the file you edited to make the changes effective in your current window.
For example, if you added the MANPATH line to the .login file, you would type:
hostname% source $HOME/.login
Note – If you log out and then back into your system, you update the MANPATH
variable in all command windows and shells.
To View Man Pages in Bourne or Korn Shell
Environments
1. Using a text editor, add these two lines to the end of the $HOME/.profile file.
MANPATH=/opt/SUNWconn/man:$MANPATH export MANPATH
If this file did not already contain this variable, add the following two lines to the end of the file, or contact your system administrator for assistance.
MANPATH=/opt/SUNWconn/man export MANPATH
2. Make the changes effective in your current window.
$ . $HOME/.profile
Note – If you log out and then back into to your system, you update the MANPATH
variable in all command windows and shells.
42 Sun PCI High Speed Quad Port Serial Interface Adapter User’s Guide • May 2010

Glossary

AMI Alternate Mark Inversion
bps Bits per second
CEPT European Conference of Postal and Telecommunications Administrations
CSU Channel Service Unit
CPU tCentral Processing Unit
DSU Data Service Unitr.
E1 European equivalent of T1
HDLC High-Level Data Link Control
MHz MegaHertz
PLL Phase-locked loo
PPP Point-to-Point Protocol
SDLC Synchronous Data Link Control
SNA System Network Architecture
T1 A communications service providing leased-line support for 1,554,000 bps
on twisted copper wire.
WAN Wide Area Network
43
44 Sun PCI High Speed Quad Port Serial Interface Adapter User’s Guide • May 2010
Loading...
