Site Preparation and Planning
This manual describes the facility planning requirements for installing a Sun
StorEdge™ 3900 or 6900 series system.
To determine the total components and storage systems your shipment will include,
consult your local Sun sales representative.
Planning Overview
Follow the guidelines as outlined in this document when planning your installation.
■ “Customer Obligations” on page 3
■ “Local Facility Safety” on page 3
■ “Facility Requirements” on page 4
■ “Cabling Requirements” on page 9
For a product overview and installation instructions, refer to the Sun StorEdge 3900
and 6900 Series Version 1.1 Installation Manual. This document and a broad selection
of other Sun system documentation is located at the following web sites:
http://docs.sun.com/documentation
Preinstallation Worksheet
This worksheet is for gathering and recording the information required to
successfully install a Sun StorEdge 3900 or 6900 series. Use this worksheet to preplan
the data and Ethernet connections from the data host and Storage Service Processor.
1
Note – The number of IP addresses necessary for your installation depends on the
configurations you select. See the Sun StorEdge 3900 and 6900 Series 1.1 Reference and
Service Manual for the number of IP addresses necessary for each of the supported
configurations.
Item Management Host Application Host TFTP Host
Host ID
Host name
Host IP address
Gateway IP address
Array IP address
Array name
TFTP host address
OS/patch revision level
Primary application
StorTools™ release
Legend:
Required field
Optional field
Not applicable
2 Sun StorEdge 3900 and 6900 Series 1.1 Site Preparation Guide • July 2002
Customer Obligations
The customer is obliged to inform Sun Microsystems, Inc. of any and all ordinances
and regulations that affect the installation. The customer is responsible for meeting
all government codes and regulations concerning facilities. The customer is also
responsible for compliance with the following requirements:
1. All local, national, and international codes covered in this specification. The
subjects covered include fire and safety, building, and electrical codes.
2. Document and inform Sun Microsystems, Inc. of any deviations from this
specification.
Local Facility Safety
Install the Sun StorEdge 3900 and 6900 series systems in accordance with the local
safety codes and regulations at the facility site. Make sure you read the safety
precautions in the Sun StorEdge 3900 and 6900 Series 1.1 Regulatory and Safety
Compliance Manual. The following sections contain additional safety information for
the local facility:
■ “Handling Precautions” on page 3
■ “Secure Installation Requirements” on page 4
■ “Placement of a Sun Product” on page 4
Note – Do not make mechanical or electrical modifications to the equipment. Sun
Microsystems, Inc. is not responsible for regulatory compliance of a modified Sun
product.
Handling Precautions
Caution – A fully configured storage system cabinet can weigh in excess of 1400
pounds (627 kg). Any floor that this system will cross must be able to withstand this
load.
3
The cabinet is equipped with wheels so that you can move it. Use enough personnel
when moving the cabinet, especially on sloping loading docks and ramps, to gain
access to a raised computer room floor. Move the cabinet slowly and deliberately,
and make sure the floor is free of foreign objects and cables that the cabinet could
roll over.
All personnel who are moving the cabinet should wear protective footwear.
Secure Installation Requirements
To minimize personal injury in the event of a seismic occurrence, you must securely
fasten the cabinet to a rigid structure extending from the floor to the ceiling, or from
the walls, of the room in which the cabinet is located.
Install the cabinet on a level surface. At each corner, on the base of the cabinet, are
adjustable nonskid pads. These must be extended when the cabinet is installed to
prevent the cabinet from rolling. These pads are not to be used to level the cabinet.
Placement of a Sun Product
If you have ordered a Sun StorEdge 3960 or 6960 series without the second cabinet,
make sure you allow enough room to install a second cabinet in the event that you
want to expand your system.
Do not block or cover the openings of your Sun product. Never place a Sun product
near a radiator or heat register. Failure to follow these guidelines can cause
overheating and affect the reliability of your Sun product.
Air cools the Sun StorEdge 3900 and 6900 series cabinets from front to back. Air
enters at the front, circulates, and is expelled at both the top and bottom rear of the
unit. The front and rear door clearances provide sufficient space for cooling. See
TABLE 5 and TABLE 6 for specific clearance specifications.
Facility Requirements
These sections contain the following information about the facility requirements for
the Sun StorEdge 3900 and 6900 series:
■ “Environmental Specifications” on page 5
■ “Electrical and Power Specifications” on page 5
4 Sun StorEdge 3900 and 6900 Series 1.1 Site Preparation Guide • July 2002
■ “Physical Specifications” on page 6
Environmental Specifications
TABLE1 Facility Environmental Specifications
Specifications Operating Nonoperating
Temperature 41˚F to 95˚F (5˚C to 35˚C) -41˚F to 140˚F (-20˚C to 60˚C)
Relative humidity 20% to 80% RH, noncondensing
80.6˚F (27˚C) maximum wet bulb
Altitude -1000 to 10,000 feet
(-305 to 3,048 meters)
Avoid temperature extremes and keep the work area clean. Maintain the operating
conditions described the following table. The storage system should be in a
computer room environment that provides control over environmental factors such
as temperature, humidity, and airborne dust. A computer room installation can also
help protect equipment from fire, flood, or other danger originating in the building.
TABLE2 Facility Environmental Specifications
5 to 95% RH noncondensing with
maximum gradient 10% per hour
-1000 to 40,000 feet
(-305 to 12,192 meters)
Environmental Factor Ambient Temperature Range Ambient Relative Humidity
Operating 70˚F to 73.5˚ F (21˚C to 23˚C) 45% to 50%
The operating environmental limits in
TABLE 1 reflect what the systems have been
tested to, in order to meet all functional requirements. The optimum operating
condition in
TABLE 2 is the recommended operating environment. Operating
computer equipment for extended periods of time at or near the temperature or
humidity extremes is known to significantly increase the failure rate of hardware
components. In order to minimize any chance of down-time due to component
failure, it is strongly recommended that customers plan and use the optimal
temperature and humidity ranges.
Electrical and Power Specifications
All Sun StorEdge 3900 and 6900 series require two independent power sources. Each
storage system cabinet has two power conditioners (distribution) for redundancy,
which are mounted in the base of the cabinet. To maintain the power redundancy,
each conditioner must be connected to independent power sources.
power required for each conditioner.
TABLE 3 lists the
5
TABLE3 Power Specifications for the System Cabinet
Specification Rating
AC voltage rating 200 to 240 VAC
AC voltage range 180 to 264 VAC
Frequency range 47 to 63 Hz
Current at 240 VAC 32A
Power consumption, maximum:
• Sun StorEdge 3910 system
• Sun StorEdge 3960 system
• Sun StorEdge 6910 system
• Sun StorEdge 6960 system
4.2 kW
8.4 kW
4.2 kW
8.4 kW
The following is recommended for all installations:
■ All AC mains and supply conductors to power distribution boxes for both the
cabinet system and the desktop system must be enclosed in metal conduit or
raceway, when specified by local, national, and/or other applicable government
codes and regulations. The supply conductors and power distribution boxes (or
equivalent metal enclosure) must be grounded at both ends.
■ The supplied storage systems require voltages within minimum fluctuation. The
facilities voltage supplied by the customer/end user must maintain a voltage of
not more than (+/-) 5%.
■ The customer facilities must provide suitable surge protection.
Physical Specifications
This section contains the physical requirements for the Sun StorEdge 3900 and 6900
series systems.
6 Sun StorEdge 3900 and 6900 Series 1.1 Site Preparation Guide • July 2002
Physical Dimensions
TABLE4 Storage System Physical Specifications
Subsystem Height Width Depth Weight
Sun StorEdge 3900SL
storage system single
cabinet
Sun StorEdge 3900SL
storage system with
expansion cabinet
Sun StorEdge 3910
storage system
Sun StorEdge 3960
storage system
Sun StorEdge 6910
storage system
Sun StorEdge 6910SL
storage system
Sun StorEdge 6960
storage system
Sun StorEdge 6960SL
storage system
Note: The values given in this table are for the maximum hardware
configuration available including the Sun StorEdge expansion cabinet in both
the Sun StorEdge 3900SL, 3960, 6960, and 6960SL storage systems.
75 in.
109.5 cm
75 in.
109.5 cm
75 in.
109.5 cm
75 in.
109.5 cm
75 in.
109.5 cm
75 in.
109.5 cm
75 in.
109.5 cm
75 in.
109.5 cm
23.9 in.
60.7 cm
47.8 in.
122 cm
23.9 in.
60.7 cm
47.8 in.
122 cm
23.9 in.
60.7 cm
23.9 in.
60.7 cm
47.8 in.
121.4 cm
47.8 in.
121.4 cm
37 in.
94 cm
37 in.
94 cm
37 in.
94 cm
37 in.
94 cm
37 in.
94 cm
37 in.
94 cm
37 in.
94 cm
37 in.
94 cm
1465 lb
665 kg
2855 lb
1295 kg
1465 lb
665 kg
2855 lb
1295 kg
1210 lb
549 kg
1210 lb
549 kg
2895 lb
1314 kg
2895 lb
1314 kg
Clearance and Service Access
Side access can be required for some service procedures. Refer to the Sun StorEdge
7
3900 and 6900 Series 1.1 Reference and Service Guide for specific service procedures.
TABLE5 Clearance and Service Access for Sun StorEdge 3910 and 6910 Series
Location For Service Access
Front 48 in.
122 cm
Rear 36 in.
92 cm
Left 36 in.
92 cm
Right 36 in.
92 cm.
TABLE6 Clearance and Service Access for Sun StorEdge 3960 and 6960 Series
Location For Service Access
Front 96 in.
244 cm
Rear 60 in.
153 cm
Left 60 in.
153 cm
Right 60 in.
153 cm
8 Sun StorEdge 3900 and 6900 Series 1.1 Site Preparation Guide • July 2002
Cabling Requirements
This section contains the cabling requirements for the Sun StorEdge 3900 and 6900
series. When cabling the system, make sure you follow these guidelines:
■ Keep power and interface cables clear of foot traffic. Route cables inside walls,
under the floor, through the ceiling, or in protective channels or raceways. Route
interface cables (excluding fiber-optic cables) away from motors and other sources
of magnetic or radio frequency interference.
■ Do not exceed cable length limitations. The following table gives the cable
specifications and lengths.
TABLE7 Cable Specifications
Cable Type Connector Maximum Length
Shielded Ethernet,
10/100BASE-T, category 5
Serial
(available only to qualified field
service representatives)
Power (220V) Standard n/a
The power cables are the standard ones shipped with the Sun StorEdge Expansion
Cabinet. The cables that connect the two cabinets together are standard Fibre
Channel cables.
RJ-45 328.084 ft. (100 m)
RJ-45 82.021 ft. (25 m)
9
10 Sun StorEdge 3900 and 6900 Series 1.1 Site Preparation Guide • July 2002
Loading...
