Sunlite T400 Instruction Manual

T400 Timer

Instruction Manual

Instruction Manual

Liquid Crystal Display (LCD) and integrated circuit are used in this digital timer. The screen of the timers have

a large display. Multi-functions, easy to use, heavy loading, etc.

The digital timers display the present time accurately. It can control eight groups of ON/OFF switches, it can

give a random timing output when required. There are also many combinations, such as hourly, daily, weekly,

group of the week, for the timers on and off selection.

1. Setting of time

Before using the timer, present time must be set.

Press “CLOCK” and “HOUR” at the same time for setting the hour.

Press “CLOCK” and “MIN” at the same time for setting the minute.

Press “CLOCK” and “WEEK” at the same time for setting the week.

2. Setting of timer program

Press “PROG” to enter into the setting mode, The display shows “1ON”

Press “HOUR”, “MIN” and “WEEK” to set the hour and minute as well the day of the week for the timer

ON.

Press ”PROG” again for the setting the OFF time, the display shows “1OFF”

Repeat 2.2 for adjusting hour, minute and week.

Press “PROG” again to enter into the second ON/OFF mode.

Repeat 2.1 to 2.4 for setting the timer ON/OFF.

There are in total, eight groups of timer settings. During time setting mode, press “R” for the cancelling the

setting time. Press the “R” again for the coming back to the previous setting time.

3. Combination weekly setting

During the timer ON/OFF setting mode, press “WEEK” once. The display will show Mo., Tu., We, Th., Fr.,

Sa, Su, This means it is a daily on/off setting.

Press “WEEK” again, the week day will show, set to the required week day, in this setting, the timer will

only work in the setting week day.

After the display showing Su, the next press will show Mo, Tu, We, Th, Fr, The timer gives the setting

only for the working day in the week.

Press “WEEK” again, the display will show Sa, Su. That means the timer gives the setting only in the

week end and Sunday.

Press “WEEK” again, the display will show the whole week except Sunday. That means the timer will

work on the week day except Sunday.

Press “WEEK” again, the display will show Mo, We, Fr, the timer will work in these 3 days.

Press “WEEK” again, the display will show Tu, Th, Sa. The timer will work in these 3 days.

Press “WEEK” again, the display will show Mo, Tu, We. The timer will work in these 3 days.

Press “WEEK” again, the display will show Th, Fr, Sa. The timer will work in these 3 days.

Press “WEEK” again, there is no week day showing. The timer won’t work in all the days.

Press “R” for cancelling the setting week days. Press it again for coming back to the previous week day.

4. Timer ON/OFF turn on or turn off mode

Press” ”, there is an indicator in the display show “ON” or “AUTO” or” OFF” stage.

Press the indicator to “ON”, the timer will give a permanent “switch on” output.

Press the indicator to “AUTO”, the timer will be switched on and switched off during the setting time.

Press the indicator to “OFF”, the timer is turned off.

5. Special Functions

Press “WEEK” and “Hour” at the same time. The display will show “O” at the right hand side. This means

the ON timing and OFF timing will be extended from 2 Minutes to 32 minutes randomly.

6. NOTES

Output loading should not exceed 115V~，15A，1725W

Before use it is recommended to plug the unit into a power main for a few hours for charging the battery

inside the timer.

The tolerance of the timer is 2 minutes per month.

Summer time can be added to the timer (optional, please contact your dealer).

This timer is 24-hour display, 12-hour version is available, please contact your dealer.

6.6 If you find the no display on the LCD, please recharge the timer before using.
