Sun Lawn EM-1 User Manual

Owner’s Manual

for

™

Electric Rechargeable Power

Reel Mower

(Model EM-1)

™

Sunlawn, Inc.

325 Garfield Street

Fort Collins, CO 80524

Tel: [phone]

FAX: [phone]

For service inquiries, parts replacement,

and maintenance tips, see

www.sunlawn.com

© 2006 by Sunlawn, Inc

Owner’s Manual — Sunlawn EM-1

Please read this guide and use these operating instructions to become
familiar with the mower and its features. The charging of batteries,
operation of the mower, and notes on safety and maintenance
procedures are important for the use and enjoyment of this product.

Sunlawn, Inc. (the Manufacturer) guarantees this product for private
use for a period of 2 years from the date of purchase. This guarantee
applies to all serious defects of the product which can be proven to
have been caused by faulty materials or workmanship. The
Manufacturer has the option of supplying a replacement of the product
in perfect working order or repairing the product free of charge at an
authorized facility, provided that the following conditions are fulfilled:

BEFORE USING THE NEW ELECTRIC RECHARGEABLE

POWER REEL MOWER

WARRANTY

• The appliance has been handled correctly and in accordance with
the instructions in the Owner’s Manual.

• Neither the buyer nor a third party has attempted to repair the
product.

This guarantee is void if replacement parts or accessories are used
other than those approved by the Manufacturer.

The product, accompanied by a copy of the original receipt, must be
delivered, prepaid, to a service center authorized by the Manufacturer.

This Manufacturer’s guarantee shall not affect any guarantee claims
against the dealer or seller of the product.

!

WARNING

For safety reasons persons of less than 16 years of age
or persons not familiar with these operating instructions
must not use the electric rechargeable mower.

USE OF THIS PRODUCT

1

Owner’s Manual — Sunlawn EM--1

This mower is designed for use on residential lawns. It is not designed
for commercial use or for use in public facilities, parks, sporting
grounds, roads, or in agriculture or forestry areas.

This mower is for cutting lawns only. It must not be used to trim
hedges, bushes or shrubs, for cutting or pruning, or for any mowing
where both wheels and the roller are not fully supporting the mower.

PARTS LIST

Please check when unpacking the unit to be sure that all items listed
below are included:

A. Mower
B. 3 handle sections (1 each upper, middle, lower)
C. 4 handle bolts
D. 4 wing nuts
E. 2 screws for two-handed safety switch
F. Velcro cable keeper straps (not shown)
G. Orange power key
H. Battery charger
I. Stainless steel blade adjustment gauge
J. Owner’s Manual (not shown)

ASSEMBLY

A.

I.

2

B.

C.

G.

D.

H.

E.

CHARGED OK

CHARGING

!

ASSEMBLE THE HANDLE SECTIONS

CAUTION

Be careful to keep the mower upright. When
the battery cover is not latched and the mower
is not upright, the batteries may fall out
causing damage to the batteries or the electric
circuits.

1. Set the cutting height to the highest setting. (See Operation section

– Adjusting the cutting height, page 7). This will make it easier to
attach the lower handle section.

2. Fit the lower section of the handle so that the holes are over the

handle posts on the mower. Then rock the handle to align the locking
tabs and allow the handle section to fit into place.

Owner’s Manual — Sunlawn EM-1

Bottom Handle Mount Hole

3. Continue assembly of the middle and top sections of the handle

using the handle bolts and wing nuts. The top section must be

attached with the two holes near the grip area on the right side
(standing behind the mower).

Top / Middle Handle Mount Hole

3
