ELECTRIC WOOD CHIPPER + SHREDDER

OPERATOR’S MANUAL

A Division of Snow Joe®, LLC Model CJ601E-RM Form No. SJ-CJ601E-RM-880E-V1

14-AMP | 16:1 REDUCTION RATIO

THANKS FOR YOUR PURCHASE OF A REMANUFACTURED PRODUCT.

To make sure you get the most out of your

product, be sure to register online at

snowjoe.com

to enjoy full product support.

PASTE UPC LABEL HERE

ELECTRIC WOOD CHIPPER + SHREDDER

OPERATOR’S MANUAL

14-AMP | 16:1 REDUCTION RATIO

A Division of Snow Joe®, LLC Model CJ601E-RM Form No. SJ-CJ601E-RM-880E-V1

IMPORTANT!

Safety Instructions

All Operators Must Read These Instructions Before Use

Always follow these safety guidelines. Failure to do so may

result in serious bodily injury or death.

General Safety WARNINGS!

You and any other operator of this wood chipper + shredder must read, understand, and follow these instructions in their entirety. Failure to follow these instructions may result in ELECTRIC SHOCK, FIRE, and/or serious PERSONAL

INJURY.

Notice the personal safety alert symbol manual to draw your attention to a WARNING given along with the particular operating instruction. This means that the operation requires special ATTENTION, CAUTION, and

AWARENESS.

m used in this

mWARNING! Wear appropriate personal hearing

protection during use. Under some conditions and duration of use, noise from this product may contribute to hearing loss.

mWARNING! The rotating blades can cut you. Keep

hands and feet away from the hopper and the discharge chute.

Before using the wood chipper + shredder, familiarize yourself with the controls, especially how to stop the unit in an emergency. The only individuals who should use the wood chipper + shredder are those who thoroughly understand these instructions and know how to properly operate the unit. Children should never be allowed access to the wood chipper + shredder.

Retain this manual for future reference and reread it at the start of each chipping season.

General Safety

1. Avoid dangerous environments – Do not use the wood

chipper + shredder in rain or in damp or wet locations. Do not operate the unit in gaseous or explosive atmospheres

or use the unit near ammable or combustible liquids.

Motors in these tools normally spark, and the sparks might ignite fumes.

2. Dress properly – Do not wear loose clothing or jewelry as such articles can become caught in moving parts. Wear a protective covering to contain long hair. Wearing rubber gloves and substantial non-slip footwear is recommended when working outdoors.

3. Use safety glasses – Also use dust mask, safety footwear, snug-tting clothing, protective gloves, hearing, and head protection.

4. Extension cords – To prevent electric shock, use only with an extension cord suitable for outdoor use.

5. Disconnect the tool – Disconnect the wood chipper + shredder from the power supply when it is not in use, before servicing it, when changing accessories, and when performing any other maintenance task.

6. Do not abuse the cord – Never carry the wood chipper + shredder by the cord or yank the cord to disconnect it from the receptacle. Keep the cord away from heat, oil, and sharp edges.

7. Stay alert – Watch what you are doing. Use common sense. Do not operate the wood chipper + shredder when you are tired or under the inuence of drugs, alcohol, or other medication.

8. Store idle tool indoors – When not in use, the wood chipper + shredder should be stored indoors in a dry and high or locked-up place out of the reach of children.

9. Maintain the wood chipper + shredder with care –

Keep the cutting edges sharp and clean for optimal performance and to reduce the risk of injury. Inspect the extension cord periodically and immediately replace it if damaged. Keep the handles dry, clean, and free from oil and grease. Follow the additional recommendations described in the Care + Maintenance section of this manual.

10. Check for damaged parts – Before further use of the appliance, a part that is damaged should be carefully checked to determine that it will operate properly and perform its intended function. Check for alignment of moving parts, binding of moving parts, breakage of parts,

mounting, and any other condition that may aect its

SAVE THESE INSTRUCTIONS

operation. A part that is damaged should be properly repaired or replaced. Contact the Snow Joe customer service center at 1-866-SNOWJOE (1-866-766-9563) for assistance.

11. Lighting – Only operate your wood chipper + shredder in

daylight or good articial light.

12. Do not overreach – Keep proper footing and balance at all times.

13. Never leave a running tool unattended – Turn the

wood chipper + shredder o and wait until it comes to a

complete stop before leaving the work area.

14. Avoid accidental starting – Do not carry the wood

chipper + shredder with your nger on the switch. Make sure the switch is o before plugging in or unplugging the

unit.

15. Use the right tool – Do not use this machine for any job except that for which it was intended.

16. Keep children, bystanders, and pets away – All spectators, including pets, should be kept a safe distance away from the work area.

+ Sun Joe®

Personal Safety

1. Before starting the wood chipper + shredder, make sure

that the hopper inlet is empty.

2. Keep your face and body away from the opening.

3. Do not allow hands or any other part of the body or

clothing near the hopper or discharge chute.

4. Never put your hands into the hopper while the wood chipper + shredder is running. Always use the paddle supplied with your wood chipper + shredder to push items into the hopper.

5. Do not try to force objects larger than the recommended diameter of 1-1/2" into the hopper.

6. Always stand clear of the discharge zone when operating the wood chipper + shredder. Never reach under the unit until it has come to a complete stop.

7. When feeding material into the wood chipper + shredder, be careful to remove pieces of metal, rocks, bottles, cans or other foreign objects that may damage the blades.

8. If the cutting mechanism strikes a foreign object or if the wood chipper + shredder should start making any unusual

noise or vibration, turn it o and allow it to come to a

complete stop. Disconnect from power supply and take the following steps:

– Inspect for damage;

– Check for and tighten any loose parts.

mWARNING! Never reach into the hopper until the

wood chipper + shredder has come to a complete stop and is unplugged. The blades will continue to rotate for a few

seconds after the unit is turned o.

9. Do not allow processed material to build up in the discharge zone; this may prevent proper discharge and can result in kickback of material through the hopper.

mWARNING! Never put your hands near the

discharge chute. Failure to heed the warning could result in serious injury.

10. If the wood chipper + shredder becomes clogged, turn it OFF and disconnect from power supply before clearing debris. Keep the power source clear of debris and other accumulations to prevent damage to the power source.

Remember that the starting mechanism on engine

powered tools will cause the cutting mechanism to move.

11. Keep all guards and deectors in place and in good

working condition.

12. Do not operate the wood chipper + shredder on a paved or gravel surface where ejected material could cause injury.

13. Turn o the wood chipper + shredder and disconnect it

from the power supply whenever you leave the work area.

14. Do not tilt the wood chipper + shredder while it is running.

15. Never reach into the hopper until the wood chipper +

shredder has come to a complete stop and has been disconnected from the power supply.

Electric Safety

1. Ground fault circuit interrupter (GFCI) protection should

be provided on the circuit(s) or outlet(s) to be used for this electric wood chipper + shredder. Receptacles are available having built-in GFCI protection and may be used for this measure of safety.

2. To prevent electric shock, use only with an extension cord suitable for outdoor use, such as SW-A, SOW-A, STW-A, STOW-A, SJW-A, SJOW-A, SJTW-A, or SJTOW-A.

Before use, check that the extension cord is in good

condition. When using an extension cord, make sure to use one heavy enough to carry the current to the product. For lengths up to 50 ft (15 m), a No. 14 AWG (or greater) extension cord must be used. For lengths more than 50 ft (15 m) and up to 100 ft (30 m), a No. 12 AWG (or greater) extension cord must be used. An undersized cord will cause a drop in line voltage resulting in loss of power and overheating.

m WARNING! m

Electric shock may cause SEVERE INJURY or DEATH. Heed these warnings:

• Do not allow any part of the wood chipper + shredder

to make contact with water while it is in operation. If

the appliance becomes wet while turned o, wipe dry

before starting.

• Use only a UL-, CSA- or ETL-rated extension cord for

outdoor, all-weather use.

• Do not use an extension cord over 100 ft (30 m).

• Do not touch the appliance or its plug with wet hands

or while standing in water. Wearing rubber boots

oers some protection.

Table 1. Method of Securing Extension Cord

Cord set Appliance cord

(A) Tie cord as shown

(B) Connect plug and receptacle

EXTENSION CORD CHART

Cord Length:

Min. Wire Gauge (A.W.G.):

3. To reduce the risk of electric shock, this appliance has a polarized plug (i.e. one blade is wider than the other). Use this appliance only with a polarized UL-, CSA-, or ETL-listed extension cord recommended for outdoor, all-weather use, such as the Snow Joe Power Joe SJTW-A 14-gauge 50-foot extension cord with lighted end (Model PJEXT50-B). Visit snowjoe.com to purchase this extension cord online or, to order by phone, call 1-866-SNOWJOE (1-866-766-9563).

The appliance plug will t into a polarized extension

cord only one way. If the appliance plug does not t

fully into the extension cord, reverse the plug. If the plug

still does not t, obtain a correct polarized extension

cord. A polarized extension cord will require the use of a

polarized wall outlet. The extension cord plug will t into

the polarized wall outlet only one way. If the plug does

not t fully into the wall outlet, reverse the plug. If the plug still does not t, contact a qualied electrician to install

the proper wall outlet. Do not modify the appliance plug, extension cord receptacle, or extension cord plug in any way.

4. To prevent the appliance cord from disconnecting from the extension cord during operation, make a knot with the two cords as shown in Table 1.

Up to 50 ft

(15 m)

+50 ft - 100 ft

(+15 m - 30 m)

+ Sun Joe®

5. Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with

earthed (grounded) power tools. Unmodied plugs and

matching outlets will reduce risk of electric shock.

6. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.

7. If the supply cord is damaged, it must be replaced by an electrician or a power tool repairer.

8. When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock.

9. If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.

10. Have your tool repaired by an electrician or a qualied

service center. This power tool complies with relevant safety requirements. To avoid danger, electrical appliances

must only be repaired by qualied personnel using original

spare parts; otherwise this may result in considerable damage to the user.

Double-Insulated Appliances

In a double-insulated appliance, two systems of insulation are provided instead of grounding. No grounding means is provided on a double-insulated appliance, nor should a means for grounding be added to the appliance. Servicing a doubleinsulated appliance requires extreme care and knowledge

of the system, and should be performed only by qualied

service personnel at an authorized Snow Joe dealer. Replacement parts for a double-insulated appliance must be identical to the parts they replace. A double-insulated appliance is marked with the words “Double Insulation” or “Double Insulated.” The symbol may also be marked on the appliance.

DOUBLE-INSULATED: GROUNDING NOT

REQUIRED. WHEN SERVICING, USE ONLY IDENTICAL REPLACEMENT PARTS.

This wood chipper + shredder is double-insulated, eliminating the need for a separate grounding system. Use only identical replacement parts. Read the instructions before servicing double-insulated appliances. Use this electric wood chipper + shredder only as described in this manual.

(square within a square)

+ Sun Joe®

Safety Symbols

The following table depicts and describes safety symbols that may appear on this product. Read, understand, and follow all instructions on the machine before attempting to assemble and operate.

Symbols SymbolsDescriptions Descriptions

READ THE OPERATOR'S MANUAL(S) – Read, understand,

and follow all instructions in the user manual(s) before attempting to assemble and operate.

WARNING! Do not expose the unit to rain or wet conditions.

SAFETY ALERT – Indicates a precaution, a warning, or a danger.

WEAR EYE AND HEARING PROTECTION – For protection

against injury, wear ear defenders and safety goggles.

Wear protective gloves when using the machine and handling debris.

DANGER! ROTATING BLADES – Keep hands and

feet away from openings while the unit is running.

SWITCH OFF! Remove plug from outlet immediately if the cord is damaged or cut.

Thrown objects and rotating blade can cause severe injury.

Wear foot protection when using the machine and handling debris.

SWITCH OFF! Remove plug from outlet before cleaning or conducting maintenance checks.

Keep bystanders a safe distance away from the work area.

Double Insulation.

Know Your Electric Wood Chipper + Shredder

Read the owner’s manual and safety instructions carefully before operating the electric wood chipper + shredder. Compare the illustration below to the electric wood chipper + shredder in order to become familiar with the location of the various controls and adjustments. Save this manual for future reference.

1. Paddle

2. Hopper

3. Main body

4. Shredder stand assembly

5. Wheel axle

6. Wheel

7. Paddle holder

8. Appliance cord

9. Motor

10. Reset button

11. Removable safety switch

12. Hopper locking knob

10 11

Technical Data

Rated Voltage 120 V ~ 60 Hz

Motor Electric

Power 14 A

Feed Type Manual

No Load Speed 4100 ± 10% rpm

Cutting Diameter 1.5 in. (3.8 cm)

Decibel Rating 113 dB

Wheel Size 6 in. (15.2 cm)

Reduction Ratio 16:1

Hopper Dimensions 2 in. x 5 in. (5.1 cm x 12.7 cm)

Weight 25.4 lbs (11.5 kg)

Unpacking

Carton Contents

• Electric wood chipper + shredder main body with hopper

• Electric wood chipper + shredder stand assembly

• Paddle holder

• Paddle

• Wheel axle with hardware

• Wheels (2)

• Shredder stand assembly washers and screws (2)

• Wrench

• Hex key

• Manuals with registration card

1. Carefully remove the electric wood chipper + shredder and check to see that all of the above items are supplied.

2. Inspect the product carefully to make sure no breakage or

damage occurred during shipping. If you nd damaged or

missing parts, DO NOT return the unit to the store. Please call the Snow Joe 1-866-SNOWJOE (1-866-766-9563).

NOTE: Do not discard the shipping carton and packaging

material until you are ready to use the electric wood chipper + shredder. The packaging is made of recyclable materials. Properly dispose of these materials in accordance with local regulations or save the packaging for long-term product storage.

IMPORTANT! The equipment and packaging material are not toys. Do not let children play with plastic bags, foils, or small parts. These items can be swallowed and pose a

suocation risk!

+ Sun Joe® customer service center at

Assembly

2. Insert the wheel axle into the shredder stand assembly,

and re-assemble the shaft sleeve and the support cover (Fig. 2).

Fig. 2

Shaft sleeve

Stand assembly

3. Remove the wheel cover from the wheel (Fig. 3).

Wheel axle

Shaft sleeve

Fig. 3

Wheel

Wheel cover

4. Assemble the wheel on the end of the wheel axle, x it

with the spacer and the nut (Fig. 4).

Wheels Fitting

NOTE: The hardware for the wheels are already assembled on

the wheel axle.

1. Remove all the wheel spacers and nuts on the wheel axle, and remove the shaft sleeve and support cover on one side of the wheel axle (Fig. 1).

Fig. 1

Nut

Shaft sleeveSpacer

NutWheel axle

Spacer

Fig. 4

Wheel axle

5. Press the wheel cover into the wheel to cover the end of

the axle. You may use a hammer to seat them securely over the axle. There may be some clearance between the wheel and the wheel cover, it is not necessary to press it to the bottom (Fig. 5).

Wheel

Spacer

Nut

Fig. 5

Wheel cover

Wheel

Fitting the Paddle Holder and the Paddle

1. Stand the unit up, and clip the paddle holder to the

standing assembly (Fig. 8).

Fig. 8

Standing assembly

6. Repeat the steps 2 – 4 to assemble the other wheel.

Stand Assembly Fitting

1. Turn the wood chipper + shredder main body upside

down, insert the two ends of the stand assembly into the housing (Fig. 6).

Fig. 6

Main body

Stand assembly

2. Align the holes on the main body housing and stand

assembly, insert the washer into the screw and install into the stand assembly on both sides (Fig. 7).

Paddle holder

2. Clip the paddle into the paddle holder (Fig. 9).

Fig. 9

Paddle holder

Paddle

NOTE: Be sure to place the paddle in the paddle holder every

time after using.

Operation

Fig. 7

Screw

Washer

Starting + Stopping

mWARNING! Before starting, ensure that the feed inlet

is empty.

mWARNING! The wood chipper + shredder will not run

if the hopper is open or not closed tightly. Always close the hopper tightly by turning the hopper locking knob clockwise before starting the machine (Fig. 10).

OFF

REMOVE TO LOCK

Fig. 10

OFF

REMOVE TO LOCK

Hopper locking knob

3. To power the wood chipper + shredder o, push the

removable safety switch to the OFF position. To disable the machine, remove the safety switch completely (Fig. 13).

Fig. 13

1. Make sure the removable safety switch is in the OFF

position. Plug the wood chipper + shredder's appliance cord using an approved extension cord, making a knot with the two cords (Fig. 11).

Fig. 11

Extension cord

Appliance cord

2. Push the removable safety switch to the ON position to

power the wood chipper + shredder on (Fig. 12).

Fig. 12

Removable safety switch

NOTE: As a safety precaution, the removable safety switch

can be removed when you are not using the wood chipper + shredder to prevent children from starting it accidentally. The unit cannot be started when the safety switch is removed. Make sure to replace the removable safety switch before operation.

Basic Shredding Procedure

mWARNING! Always wear ear and eye protection and

wear gloves during operation.

1. Connect the wood chipper + shredder to a proper power source and switch on the unit; the wood chipper + shredder will start to work. Insert the shredding material inside the hopper through the feeding funnel to shred them (Fig. 14).

Removable safety switch

Fig. 14

Insert the shredding material

Feeding funnel

2. Use the paddle to push the material inside the hopper if

OFF

REMOVE TO LOCK

needed (Fig. 15).

Fig. 15

Paddle

mWARNING! Never put your hands into the hopper

while the wood chipper + shredder is running. Always use the paddle supplied with your shredder to push items into the hopper.

3. Only insert as much material as needed to prevent blockage of the feeding funnel. Chop garden waste that has been stored for a few days and is wilted and damp alternately with dry branches. This prevents the cutting blades from blocking up. Branches with leaves must be completely chopped before new material is fed. Make sure that the chopped material can fall freely from the ejection slot.

4. Keep hold of branches while feeding them into the wood chipper + shredder until they are automatically drawn in.

5. Keep to the working speed of the wood chipper + shredder and do not overload it.

6. To protect the wood chipper + shredder from clogging, shred wilted garden waste that has been left to dry for a few days and shred thin twigs alternately with branches.

7. Before you shred roots, remove any remaining soil and stones from them.

8. Do not shred soft, damp material such as kitchen waste; take it straight to be composted.

9. Keep a few dry branches for the end, as they will help clean the wood chipper + shredder.

10. Only switch the wood chipper + shredder o after all of

the shredding material has passed through the discharge chutes. Otherwise, the discharge chutes may jam the next time the shredder is turned on.

Overload Protection

Your electric wood chipper + shredder is designed with overload protection. If the shredder is clogged during shredding, the overload protection will cut the power automatically to protect your shredder. Wait at least 1 minute before restart the unit when the power is cut.

1. To restart the wood chipper + shredder, rst press the

reset button (Fig. 16).

Fig. 16

Reset button

2. Then, push the removable safety switch to ON position to

restart the wood chipper + shredder (Fig. 12).

Care + Maintenance

mATTENTION! Before performing any cleaning or

maintenance, disconnect the unit from the power supply.

mWARNING! Always wear gloves when cleaning and

maintaining.

Cleaning

1. Use only a warm damp cloth and a soft brush to clean

your wood chipper + shredder.

2. Never spray water on the wood chipper + shredder or wash it with water. Do not use detergents or solvents as these could cause irreparable damage to your shredder.

3. Make sure the ventilation slots are always kept clean and are free of debris.

4. Open the hopper to clean the inside of the unit. Unscrew the hopper locking knob counterclockwise, and remove

the hopper (Fig. 17).

Fig. 17

OFF

REMOVE TO LOCK

Hopper locking knob

5. Clean the cutting blades and the discharge area. Remove

wood sticks or objects that may clog the blades. Check the blades for damage.

6. After cleaning the inside of the wood chipper + shredder, replace the hopper and lock the hopper locking knob by turning it clockwise (Fig. 18).

Fig. 18

Hopper locking knob

1. Stop the motor and disconnect the unit from the power

supply.

2. Unscrew the hopper locking knob counterclockwise to open the hopper (Fig. 17).

3. Align the cutting head past the splash guard so that the blade bolts can be removed; secure the cutting head from rotating by inserting a rod (e.g. a screwdriver) or rag between the cutting head and body. Unscrew the blade bolts using the supplied hex key, and remove the blade (Fig. 19).

4. Reverse the direction of the original blade, or install a new blade. Align the slots on the blade with the grooves on the cutting head. Tighten the bolts with the supplied hex key (Fig. 19).

Fig. 19

Bolts

Blade

Splash guard

Cutting Blade Replacement

The wood chipper + shredder has two reversible blades that are attached to a rotary plate with two bolts. Before any maintenance or cleaning is done on the blades, always turn

the switch o and disconnect the plug from the outlet.

mWARNING! Be sure to wear protective gloves when

handling the blades.

IMPORTANT: Only use original replacement parts specied for

this wood chipper + shredder.

You can purchase a replacement blade (Model CJ601E-RBLD) and other genuine replacement parts by ordering online at snowjoe.com or, to order by phone, contact Snow Joe Sun Joe

customer service at 1-866-SNOWJOE

(1-866-766-9563). The use of parts that do not meet the

original equipment specications may lead to improper

performance of the wood chipper + shredder, may compromise operator safety, and will void the manufacturer's warranty.

5. Repeat step 3 and 4 to replace the other blade.

6. Replace the hopper; tighten the hopper locking knob by

turning it clockwise.

Storage

Follow the steps below to prepare the electric wood chipper + shredder for storage:

1. Disconnect the power supply to the wood chipper + shredder.

2. Clean the wood chipper + shredder with a damp cloth or hand brush.

3. Inspect the wood chipper + shredder carefully for worn, loose, or damaged parts. Check connections and screws and tighten if necessary. Pay special attention to the blade and replace if it shows signs of wear. Refer to the Care + Maintenance section.

4. Store the wood chipper + shredder indoors in a dry, clean, and cool area out of the reach of children. Do not store the unit next to corrosive materials, such as fertilizer and rock salt.

5. Wipe the extension cord to remove any foreign substances, such as oil or stains. Replace the extension cord immediately if it is cut or damaged in any way.

6. Do not cover the wood chipper + shredder with a solid plastic sheet. Plastic coverings trap moisture around the shredder, which can damage the unit.

Service + Support

If your Sun Joe® electric wood chipper + shredder requires service or maintenance, please call the Snow Joe

customer service center at 1-866-SNOWJOE (1-866-766-9563).

+ Sun Joe®

Model + Serial Numbers

When contacting the company or reordering parts, you will need to provide the model and serial numbers of your product.

These are found on the decal axed to the housing or handle

of your electric wood chipper + shredder. Copy these numbers into the space provided below.

Record the following numbers from the housing or handle of your new product:

C J 6 0 1 E - R M

Model #:

Serial #:

Troubleshooting

Problem Remedy

Motor does not run

Chipping material is not being pulled in

Blades cutting

ineciently

Possible Cause

• Power failure/unit not plugged into a

working receptacle.

• The overload protection has

responded.

• The hopper is opened.

• The material is jammed in the feed

inlet.

• The cutting blades are blocked.

• The discharge chute is blocked.

• Blade edges are worn.

• Check to make sure unit is plugged into a

working outlet. Make sure extension cord is not damaged.

• Remove any chips and press the reset

button. Wait one minute before pressing the ON/OFF switch to restart the unit.

• Check to make sure the hopper is secured

and the hopper locking knob is tightened.

• Examine the cutting head and remove any

blocked material. Replace the hopper.

• Disconnect the power supply and open

the hopper. Open the blade cover. Remove the blocked material and replace the blade cover and hopper.

• Disconnect the power supply and open the

hopper. Open the plate of the discharge chute to clear the blocked material. Replace the plate and hopper.

• Reverse the blades or replace with new

blades.

Only a company specialist may be able to correct faults that cannot be rectied with the aid of this table. Please call the Snow Joe

+ Sun Joe® customer service center at 1-866-SNOWJOE (1-866-766-9563).

Optional Accessories

WARNING! ALWAYS use only authorized Snow Joe

replacement parts or accessories that are not intended for use with this tool. Contact Snow Joe whether it is safe to use a particular replacement part or accessory with your tool. The use of any other attachment or accessory can be dangerous and could cause injury or mechanical damage.

+ Sun Joe® replacement parts and accessories. NEVER use

+ Sun Joe® if you are unsure

ModelAccessories Item

Sun Joe® CJ601E electric wood chipper + shredder replacement blade

Sun Joe® CJ601E electric wood chipper + shredder paddle

Snow Joe® + Sun Joe® SJTW-A 14-gauge 50-foot extension cord with lighted end

CJ601E-RBLD

CJ601E-1

PJEXT50-B

NOTE: Accessories are subject to change without any obligation on the part of Snow Joe changes. Accessories can be ordered online at snowjoe.com or via phone by contacting the Snow Joe service center at 1-866-SNOWJOE (1-866-766-9563).

+ Sun Joe® to provide notice of such

+ Sun Joe® customer

SNOW JOE® + SUN JOE® REFURBISHED GOODS WARRANTY

GENERAL CONDITIONS:

Snow Joe

+ Sun Joe® operating under Snow Joe®, LLC warrants this refurbished product to the original purchaser for 90 days against defects in material or workmanship when used for normal residential purposes. If a replacement part or product is needed, it will be sent free of charge to the original purchaser except as noted below.

The duration of this warranty applies only if the product is put to personal use around the household. It is the owner’s responsibility to correctly perform all maintenance and minor adjustments explained in the owner’s manual.

HOW TO OBTAIN YOUR REPLACEMENT PART OR PRODUCT:

To obtain a replacement part or product, please visit snowjoe.com/help or email us at help@snowjoe.com for instructions. Please be sure to register your unit beforehand to speed up this process. Certain products may require a serial

number, typically found on the decal axed to the housing

or guard of your product. All products require a valid proof of purchase.

EXCLUSIONS:

• Wearing parts like belts, augers, chains and tines are

not covered under this warranty. Wearing parts can be purchased at snowjoe.com or by calling 1-866-SNOWJOE (1-866-766-9563).

• Batteries are covered in full for 90-days from the date of

purchase.

Snow Joe® + Sun Joe® may from time to time change the design of its products. Nothing contained in this warranty shall be

construed as obligating Snow Joe

+ Sun Joe® to incorporate such design changes into previously manufactured products, nor shall such changes be construed as an admission that previous designs were defective.

This warranty is intended to cover product defects only.

Snow Joe

, LLC is not liable for indirect, incidental or

consequential damages in connection with the use or misuse of

the Snow Joe

+ Sun Joe® products covered by this warranty. This warranty does not cover any cost or expense incurred by the purchaser in providing substitute equipment or service during reasonable periods of malfunction or non-use of this product while waiting for a replacement part or unit under this warranty. Some states do not allow exclusions of incidental or consequential damages so the above exclusions may not apply

in all states. This warranty may give you specic legal rights in

your state.

HOW TO REACH US:

We’re here to help Monday through Friday from 9AM to 6PM EST. You can reach us at 1-866-SNOWJOE (1-866-766-9563), online at snowjoe.com, via email at help@snowjoe.com or tweet us @snowjoe.

EXPORTS:

Customers who have purchased Snow Joe

+ Sun Joe®

products exported from the United States and Canada should

contact their Snow Joe

+ Sun Joe® distributor (dealer) to obtain

information applicable to your country, province or state. If for

any reason, you are not satised with the distributor’s service, or if you have diculty obtaining warranty information, contact

your Snow Joe

+ Sun Joe® seller. If in the event your eorts are

unsatisfactory, please reach out to us directly.

snowjoe.com

mWARNING! This product or its power cord contains chemicals, including lead, known to the State

of California to cause cancer and birth defects or other reproductive harm. Wash hands after handling. For more information go to www.P65Warnings.ca.gov.

mWARNING! Some dust created by power sanding, sawing, grinding, drilling, and other construction

activities contains chemicals known [to the State of California] to cause cancer, birth defects, or other reproductive harm. Some examples of these chemicals are:

• lead from lead-based paints,

• crystalline silica from bricks and cement and other masonry products, and

• arsenic and chromium from chemically-treated lumber.

Your risk from these exposures varies, depending on how often you do this type of work. To reduce your exposure to these chemicals: work in a well ventilated area, and work with approved safety equipment, such as those dust masks that are specically designed to lter out microscopic particles. For more information go to www.P65Warnings.ca.gov.

sunjoe CJ601E-RM Operator's Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
