SVM-208

VIDEO DIGITAL MICROSCOPE

SVM-208 Digital Microscope

Back View

Vertical Shaft

Height Lock Knob

Height Limited Loop

Signal Cable

()

Power Wires(Black)

15

Front View

Aperture Adjust

Fine Adjust

Pedestal

SVM-208 Digital Microscope

Photographic System

Focus Adjust Knob

Optical System

Lens

SVM-208

SVM-208

CCD

/

Thank you for your purchasing SVM-208 Video Digital Microscope.

SVM-208 Video Digital Microscope is researched and designed
quality
technology of eliminating interferential beam and wide range depth of
field meanwhile, It is adapted Hi-quality SONY CCD camera, Therefore
it can provide the Hi-definite picture. Moreover the unit is equipped double
illumination. The upper illumination is applied in surface inspection. And
the background illumination is applied in profile inspection. The unit can
be used in various inspected field. The microscope can be directly
connected with video monitor, which helps inspector to avoid optic tiredness
and reading from scale. Our microscope makes more efficiency and less,
reduces working time. The optional mythologic software can be applied
in the measurements of length & width, radius, angle, and so on. In some
aspect, the microscope can replace profile projector, toolmaker measuring
microscope and optical image measuring system.
