Sundance SMT363XC2 User Manual

SMT363XC2
User Manual
User Manual (QCF42); Version 3.0, 8/11/00; © Sundance Multiprocessor Technology Ltd. 1999
Version 2.2 Page 2 of 27 SMT363XC2 User Manual

Revision History

14/11/03 First release JPA 1.0.0
02/12/03 Added addressing mode section (LED Setting)
JPA 1.0.1
Updated ComPort section
20/10/04 Updated block diagram.
JPA 1.0.2
Removed endianess section
Updated LED section
Replaced Timer and interrupt section by Interrupt section
07/06/05 Added: power consumption SM 1.0.3
09/08/05 Update: Support the firmware V1.1 SM 2.0
05/12/05 Updated LED descriptions. GP 2.1
29/11/07 Removed HPI connection from block diagram. GP 2.2
Version 2.2 Page 3 of 27 SMT363XC2 User Manual

Table of Contents

Revision History.......................................................................................................... 2
Table of Contents ....................................................................................................... 3
Contacting Sundance ................................................................................................. 5
Notational Conventions .............................................................................................. 6
DSP ........................................................................................................................ 6
SDB ........................................................................................................................ 6
SHB ........................................................................................................................ 6
Register Descriptions.............................................................................................. 6
Outline Description ..................................................................................................... 7
Intended Audience...................................................................................................... 7
Block Diagram ............................................................................................................ 8
Architecture Description ............................................................................................. 9
NET+50 ...................................................................................................................... 9
DSP ............................................................................................................................ 9
Boot Mode............................................................................................................... 9
DPRAM ................................................................................................................. 10
EMIF Control Registers......................................................................................... 10
CE1 - IO Control ................................................................................................... 11
SDRAM..................................................................................................................... 11
FLASH...................................................................................................................... 11
RS232 ...................................................................................................................... 12
Serial ports ............................................................................................................... 12
FPGA........................................................................................................................ 12
Version control ...................................................................................................... 12
Firmware versions .................................................................................................... 12
Reprogramming the firmware and boot code............................................................ 12
Comports.................................................................................................................. 13
SHB .......................................................................................................................... 13
Architecture........................................................................................................... 13
Global bus ................................................................................................................ 13
Version 2.2 Page 4 of 27 SMT363XC2 User Manual
LED Setting .............................................................................................................. 14
LED Register......................................................................................................... 14
CONFIG & NMI......................................................................................................... 15
Config Register ..................................................................................................... 15
Timer ........................................................................................................................ 16
Timer Control Register .......................................................................................... 16
IIOF interrupt ............................................................................................................ 17
Code Composer ....................................................................................................... 18
Application Development .......................................................................................... 18
SMT6400 .............................................................................................................. 18
SMT6060 .............................................................................................................. 18
3L Diamond........................................................................................................... 18
SMT6500 .............................................................................................................. 18
FPGA Memory Map.................................................................................................. 19
SHB pinout ............................................................................................................... 20
SHB generic pin-out.............................................................................................. 20
Jumper Pin-Outs....................................................................................................... 21
JP1 - NET+50 connections ............................................................................ 21
JP2 - Serial port header ................................................................................. 21
JP3 - Xilinx CPLD programming port. ............................................................ 22
JP4 - NetICE port........................................................................................... 22
LED Descriptions...................................................................................................... 23
Mechanical Configuration ......................................................................................... 24
Operating Conditions................................................................................................ 25
Safety.................................................................................................................... 25
EMC...................................................................................................................... 25
General Requirements.......................................................................................... 25
Power Consumption.............................................................................................. 25
Bibliography.............................................................................................................. 26
INDEX ...................................................................................................................... 27
Version 2.2 Page 5 of 27 SMT363XC2 User Manual

Contacting Sundance

You can contact Sundance for additional information by login onto the Sundance
support forum. Please note that first users have to register first.
Version 2.2 Page 6 of 27 SMT363XC2 User Manual

Notational Conventions

DSP
The terms DSP, C6713 and TMS320C6713 will be used interchangeably throughout this document.
SDB
The term SDB will be used throughout this document to refer to the Sundance Digital Bus interface.
SHB
The term SHB will be used throughout this document to refer to the Sundance High­speed Bus interface.

Register Descriptions

The format of registers is described using diagrams of the following form:
31–24 23–16 15–8 7–0
OFLAGLEVEL
R,00000000 RW,10000000 R,00000000 R,10000000
The digits at the top of the diagram indicate bit positions within the register and the central section names bits or bit fields. The bottom row describes what may be done to the field and its value after reset. Shaded fields are reserved and should only ever be written with zeroes.
R Readable by the CPU
W Writeable by the CPU
RW Readable and writeable by the CPU
Binary digits indicate the value of the field after reset
Version 2.2 Page 7 of 27 SMT363XC2 User Manual

Outline Description

The SMT363XC2 is an Ethernet module, size 1 TIM offering the following features:
NetSilicon ARM-chip Net+50
TMS320C6713 processor running at 225MHz
Six Comports
64MB of SDRAM
8MB Flash ROM
Global Bus connector
High bandwidth data I/O via 2 Sundance Digital Buses (SDB)

Intended Audience

There are two existing versions of the firmware for the SMT363XC2. These two versions differ by the number and the type of communication resources (comport and SDB interfaces) provided.
For each of the versions of the different firmware is loaded in the FPGA:
- Firmware version 1.0 or
- Firmware version 1.1
This user manual covers the version 1.1 of the firmware for the SMT363XC2 implemented with the model described in the SMT6500 help file.
The changes between the firmware version 1.0 and version 1.1 are described in the section Firmware versions.
Version 2.2 Page 8 of 27 SMT363XC2 User Manual

Block Diagram

The following drawing shows the block diagram of the SMT363XC2 module.
The main components of the SMT363XC2 are:
- A Texas Instruments DSP
- One Xilinx Virtex-II FPGA
- One NetSilicon ARM Net+50 device with integrated MAC controller for connection to an Ethernet network.
- 16/64MB of SDRAM
DSP and
FPGA PSU
4 LEDs &
4 I/O pins
JTAG Header
Sundance High-speed
Bus
60-way Samtec
J1 Top Primary TIM
Global Bus
J3 Global Expansion
Connector
Connector
Comm-Port 3
24 I/O pins
2x Comm-Ports/SDL
Xilinx FPGA
Virtex-II
1.5V
74 I/O pins
J2 Bottom Primary TIM
15 I/O pins
Timer,& C ontrol
48 I/O pins
4x Comm-Port/SDL
Connector
Comm-Port 1, 2, 4
32-bit EMIF
Dual Port
RAM
8M bytes Flash
16/64M bytes
SDRAM
2 x (4/16M x 16)
'C6211/6711/6713
DSP
NET+50
16M bytes SDRAM
2 x (4M x 16)
McBSP,
GPIO, LEDs
RJ45, RS232,
LEDs
Figure 1: SMT363XC2 block diagram
Version 2.2 Page 9 of 27 SMT363XC2 User Manual

Architecture Description

NET+50

The NET+50 is a cost-effective, high-performance 32-bit network attached microprocessor developed especially for high-bandwidth applications in Intelligent Networked Devices. Based on ARM's architecture, it integrates 10/100Base-T Ethernet MAC with an MII interface, a distributed 10-channel linking DMA controller and a memory controller supporting all of the popular memory devices in use today.
This device is connected directly to an Intel LXT971 PHY device, which provides an IEEE 802.3 compatible 10Base-T and 100Base-T physical layer interface. Also, directly connected to the NET+50 are 16Mbytes of SDRAM, an RS232 level converter and a 128KB Dual Port RAM (DPRAM). LEDs 4 and 4 are controlled via PORTA bits 0 and 1.
DSP
The Texas Instruments DSP can run at up to 225MHz. The DSP is doted of 16MB (optional 64MB) of SDRAM.
The DSP is a TMS320C6713 type.
An on-board 37.5MHz crystal oscillator provides the clock used for the DSP which then multiplies this by for input to the DSP. DSP internally multiplies this up to the required frequency, using a PLL.

Boot Mode

The DSP is connected to the on-board flash ROM that contains the Sundance bootloader and the FPGA bitstream.
Following reset, the DSP will automatically load the data from the flash ROM into its internal program memory at address 0 and then start executing from there. All this code is the Sundance bootloader, and it is made up of three parts: FPGA configuration, processor configuration and the Comport boot procedure. FPGA configuration uses data in the ROM to configure the FPGA. A processor configuration sets the processor into a standard state, copies its comport boot procedure into a dual-port RAM (DPRAM) implemented in the FPGA, and releases the NET+50 chip from reset. The Net+50 chip is configured to boot from this DPRAM.
The bootloader is executed. It will continually check the six comports until data appears on one of them. This will next load a program in boot format from this comport. Note that the bootloader will not read data arriving on other comports. Finally the control is passed to the loaded DSP application.
It is safest to wait for the configuration to complete. Note that comports will appear to be "not ready" until the FPGA has been configured.
The FPGA programming algorithm is not described here. It can be found in the boot code.
Version 2.2 Page 10 of 27 SMT363XC2 User Manual

DPRAM

The DPRAM in the FPGA is only intended to be used during this boot process; more general use is not recommended.
A 128KB memory is directly connected to both the DSP and the NET+50 devices. Each can access the memory independently and at their respective maximum data rates.
The DPRAM is decoded as the boot ROM in the NET+50’s memory space.
The DPRAM supports the generation of interrupts to either of its ports. This functionality is achieved by the DSP writing to a specific DPRAM address, which in turn generates an interrupt to the NET+50 (PINT2* pin). Similarly, the NET+50 can write to a specific address which generates an interrupt which can be routed to the DSP.

EMIF Control Registers

The DSP has a single external memory interface (EMIF) which is 32 bits wide.
A full description of the registers used to control the EMIF can be found in the DSP
C6000 Peripherals Reference GuideError! Reference source not found.Error!
Reference source not found..
The standard bootstrap will initialise these registers to use the following resources:
Memory space
(EMIF)
Resource
Address range
CE0 SDRAM 0x80000000 - 0x83FFFFFF
CE1 Flash / IO Control 0x90000000 - 0x903FFFFF
CE2 DPRAM 0xA0000000 - 0xA7FFFFFF
CE3 Virtex 0xB0000000 - 0xB0FFFFFF
The power on (and reset) state for the semaphore enable (DPRAM related) is disabled. This bit determines whether the flash or DPRAM-semaphore registers are accessed on CE1.
Version 2.2 Page 11 of 27 SMT363XC2 User Manual

CE1 - IO Control

Several I/O connections are required to control the NET+50 reset signal, upper flash address signals, and the control signals for FPGA programming. These are all accessed via the CE1 memory space and defined settings for some data lines.
D31 D30 D29 D0 Function
0 0 0 X Flash write
0 0 1 N NET+50 reset control. Reset(active low)=N
0 1 0 N Flash address A20 control. A20=N
0 1 1 N Flash address A21 control. A21=N
1 0 0 N FPGA PROG pin control. PROG(active low)=N
1 0 1 X FPGA CCLK pin control. Generates pulse on CCLK
1 1 0 N DPRAM semaphore enable when N=1

SDRAM

Memory space CE0 is used to access 16MB (or optional 64MB) of SDRAM over the EMIF.
The speed of the SDRAM is dependent on the processor variant. Using the C6713, the SDRAM will operate at 100MHz.
Using the C6713, the SDRAM operates at a programmable rate up to the maximum allowed on the EMIF.
The EMIF CE0 memory space control register should be programmed with the value 0x00000030.

FLASH

An 8MB Flash ROM is connected to the DSP in the EMIF CE1 memory space. The ROM holds boot code for the DSP, configuration data for the FPGA, the boot code for the Net+50 chip and optional user-defined code.
A software protection algorithm is in place to prevent programs accidentally altering the ROM’s contents. Please contact Sundance for further information about re­programming this device.
The CE1 memory space control register should be programmed with the value 0xFFFFFF23.
Version 2.2 Page 12 of 27 SMT363XC2 User Manual

RS232

A single RS-232 channel is provided at true RS232 levels. The signals provided are TBD and are presented on wire-wrap posts.

Serial ports

The DSP provides two serial ports, which are connected to a pin header on the SMT363XC2 module. Additionally, some of the serial port signals are connected to the Virtex2 FPGA in order to provide extra signals, which can be used for external interrupts.

FPGA

The FPGA (Field Programmable Gate Array) is a Xilinx Virtex-II XC2V1000 device.
It implements the following communication resources:
Six comport interfaces
Two 16-bit Sundance Digital Bus interfaces
One global bus interface

Version control

Revision numbers for both the boot code and FPGA firmware are stored in the Flash ROM during programming as zero-terminated ASCII strings.
The SMT6001 utility can be used to display the version numbers of the bootloader and the FPGA data.

Firmware versions

The SMT6001 utility includes the latest version of the bootloader and the latest version of the FPGA data that implements the FPGA architecture described in the
SMT6500 help file.
Note that the new firmware supports two more comports. Customers who wish to use the old firmware that supported only 4 comports options can obtain it
support web forum.
from our

Reprogramming the firmware and boot code

The contents of the flash ROM are managed using the SMT6001 utility. This includes the latest firmware and bootloader along with complete documentation on how to reprogram the ROM. The utility assumes that you have Code Composer Studio installed and that it has been configured correctly for the installed TIMs. The Sundance Wizard can help you with this.
To confirm that the ROM has been programmed correctly, you should run the confidence test in the BoardInfo utility (SMT6300).
Version 2.2 Page 13 of 27 SMT363XC2 User Manual

Comports

The DSP has 6 comports, numbered 0 to 5.
The addresses of the Comport registers are shown in the Error! Reference source
not found., and are described in the SMT6400 help file.
SHB
The SMT363XC2 provides one SHB connector, which is connected to the DSP to give two 16-bit SDB interfaces. These interfaces operate with a fixed clock rate of 100MHz.

Architecture

SDB0 and SDB1 on the DSP are presented on the TIM's SHB connector, SDBA and SDBB respectively.
SDBA SDBB
The addresses of the SDB registers are shown in the Virtex Memory Map, and are described in the
SMT6400 help file.

Global bus

The SMT363XC2 provides a single global bus interface. This is only accessible from the DSP. The addresses of the global bus registers are shown in the Virtex Memory
Map, and are described in the SMT6400 help file.
Version 2.2 Page 14 of 27 SMT363XC2 User Manual

LED Setting

The SMT363XC2 has 8 LEDs.
LED D1 always displays the state of the FPGA DONE pin. This LED is off when the FPGA is configured (DONE=1) and on when it is not configured (DONE=0).
This LED should go on when the board is first powered up and go off when the FPGA has been successfully programmed (this is the standard operation of the boot code resident in the flash memory device). If the LED does not light at power-on, check that you have the mounting pillars and screws fitted properly. If it stays on, the DSP is not booting correctly, or is set to boot in a non-standard way.
Two of the LEDs (D2-3) can be controlled with the LED register. Writing 1 will illuminate the LED; writing 0 will turn it off.

LED Register

(0xB00D0000)
31–4 3 2 1 0
- -
RW,0 RW,1 RW,0 RW,0
LED
D3
LED
D2
Despite LED register bit 2 is writable; user should not change the value of this bit.
When SMT363XC2 embeds 16MB of SDRAM, the DSP is configured to access SDRAM with 8 column address bits and 12 row address bits, whereas when SMT363XC2 embeds 64MB SDRAM, it’s configured with 10 column address bits and 13 row address bits (EMIF SDRAM Control register).
It results that FPGA’s is moved in the DSP’s memory space.
Writing a value to this bit changes the way the FPGA decodes the address, and therefore it's location in the EMIF memory space.
This bit should be set to ‘1’ when 64MB of SDRAM are fitted on-board; otherwise it should be set to ‘0’ when 16MB of SDRAM are fitted on-board.
Version 2.2 Page 15 of 27 SMT363XC2 User Manual

CONFIG & NMI

The TIM specification describes the operation of an open-collector type signal CONFIG that is driven low after reset.
This signal, on a standard C4x based TIM, is connected to the processor’s IIOF3 pin. On the SMT365, the CONFIG signal is asserted after power on, and can be released by writing the value (1<<6) to the config register. Conversely, CONFIG may be re­asserted by writing 0 to this bit. It is not possible for software to read the state of the CONFIG signal.
The NMI signal from the TIM connector can be routed to the DSP NMI pin.
WARNING: Several software components include code sequences that assume
setting GIE=0 in the DSP CSR will inhibit all interrupts; NMI violates that assumption. If an NMI occurs during such code sequences it may not be safe to return from the interrupt. This may be particularly significant if you are using the compiler’s software pipelining facility.

Config Register

31–8 7 6 5–0
NMI CONFIG
Field Description
0 drive CONFIG low
CONFIG
1 tri-state CONFIG
0 Disconnect NMI from the DSP
NMI
1 Connect NMI from TIM to the DSP.
Config and NMI DSP lines are described in the SMT6400 help file.
Version 2.2 Page 16 of 27 SMT363XC2 User Manual

Timer

The TIM TCLK0 and TCLK1 signals can be routed to the DSP’s TOUT/TINP pins. The signal direction must be specified, together with the routing information in the timer control register.

Timer Control Register

31–6 5 4 3–0
Reserved TCLK1 TCLK0 Reserved
Field Description
TCLK0
0 TIM TCLK0 is an input
1 Enable TIM TCLK0 as an output
0 TIM TCLK1 is an input
TCLK1
1 Enable TIM TCLK1 as an output
If the TIM TCLKx pin is selected as an output, the DSP TOUTx signal will be used to drive it. The TIM TCLKx pin will always drive the DSP TINPx input.
C6x
TOUT0
TINP0
TCLK0EN
TCLK0
FPGA
The Timer control register is described in the SMT6400 help file.
Version 2.2 Page 17 of 27 SMT363XC2 User Manual

IIOF interrupt

The firmware can generate pulses on the external interrupt lines of the TIM.
Only the interrupt line IIOF1 and IIOF2 are connected from/to the DSP and the HOST.
IIOF1 is connected from the DSP side to the HOST side: so, the DSP interrupts the HOST
IIOF2 is connected from the HOST side to the DSP side: so, the HOST interrupts the DSP
The IIOF interrupt lines are described in the SMT6400 help file.
Version 2.2 Page 18 of 27 SMT363XC2 User Manual

Code Composer

This module is fully compatible with the Code Composer Studio debug and development environment. This extends to both the software and JTAG debugging hardware. The driver to use is the tixds6x1x_11.dvr. CCS version 3.0 or later is required as the reprogramming utility (SMT6001) requires it.
Troubleshooting
Our Knowledge data base and FAQ sections may help you to resolve some known issues.

Application Development

Depending on the complexity of your application, you can develop code for SMT363XC2 modules in several ways.

SMT6400

For simple applications, the Sundance SMT6400 software support package (project examples) and its associated header files (SmtTim.h and ModSup.h) can suffice.
The SMT6400 product is installed by the Sundance Wizard and it is free of charge.

SMT6060

SMT6060-FTP is a utility that allows and easy and cost-effective integration of the Net+50 ARM chip
and the DSP that can be found on SMT363. It is ready to use and provide a
SMT6060-TCPIP is a software package that provides Ethernet connectivity via the industry standard
Berkeley sockets interface to a 3L/Diamond network of DSP processors. The package is typically used when there is at least one SMT363 present in the system; however, using a feature of the SMT6025 software package, it also provides seamless connectivity via the HOST PC’s (Winsock 2.2) Ethernet hardware. The software is ready-to-use and provides sockets connectivity to any Sundance DSP processor.
TCI/IP interface to a host.

3L Diamond

This module is fully supported by 3L Diamond, which Sundance recommends for all but the simplest of applications. An SMT363XC2 has to be declared as appropriate in configuration files as one processors of type:
SMT363XC2_1 (16MB SDRAM)
SMT363XC2_2 (64MB SDRAM)

SMT6500

This is the
support package for the FPGA. It may be used to develop your application
in the FPGA of the module.
Version 2.2 Page 19 of 27 SMT363XC2 User Manual

FPGA Memory Map

volatile unsigned *SMT363CP0 =(unsigned *)0xB0000000;
volatile unsigned *SMT363CP1 =(unsigned *)0xB0008000;
volatile unsigned *SMT363CP2 =(unsigned *)0xB0010000;
volatile unsigned *SMT363CP3 =(unsigned *)0xB0018000;
volatile unsigned *SMT363CP4 =(unsigned *)0xB0020000;
volatile unsigned *SMT363CP5 =(unsigned *)0xB0028000;
volatile unsigned *SMT363CP0_STAT =(unsigned *)0xB0004000;
volatile unsigned *SMT363CP1_STAT =(unsigned *)0xB000C000;
volatile unsigned *SMT363CP2_STAT =(unsigned *)0xB0014000;
volatile unsigned *SMT363CP3_STAT =(unsigned *)0xB001C000;
volatile unsigned *SMT363CP4_STAT =(unsigned *)0xB0024000;
volatile unsigned *SMT363CP5_STAT =(unsigned *)0xB002C000;
volatile unsigned *SMT363STAT =(unsigned *)0xB003C000;
volatile unsigned *SMT363SDBA =(unsigned *)0xB0040000;
volatile unsigned *SMT363SDBB =(unsigned *)0xB0050000;
volatile unsigned *SMT363SDBA_STAT =(unsigned *)0xB0048000;
volatile unsigned *SMT363SDBB_STAT =(unsigned *)0xB0058000;
volatile unsigned *SMT363SDBA_FLAG =(unsigned *)0xB004C000;
volatile unsigned *SMT363SDBB_FLAG =(unsigned *)0xB005C000;
volatile unsigned *GLOBAL_BUS =(unsigned *)0xB00A0000;
volatile unsigned *GLOBAL_BUS_CTRL =(unsigned *)0xB0080000;
volatile unsigned *GLOBAL_BUS_START =(unsigned *)0xB0088000;
volatile unsigned *GLOBAL_BUS_LENGTH =(unsigned *)0xB0090000;
volatile unsigned *SMT363TCLK =(unsigned *)0xB00C0000;
volatile unsigned *SMT363TIMCONFIG =(unsigned *)0xB00C8000;
volatile unsigned *SMT363LED =(unsigned *)0xB00D0000;
volatile unsigned *SMT363INTCTRL4 =(unsigned *)0xB00E0000;
volatile unsigned *SMT363INTCTRL4_EXT =(unsigned *)0xB00E4000;
volatile unsigned *SMT363INTCTRL5 =(unsigned *)0xB00E8000;
volatile unsigned *SMT363INTCTRL4_EXT =(unsigned *)0xB00Ec000;
volatile unsigned *SMT363INTCTRL6 =(unsigned *)0xB00F0000;
volatile unsigned *SMT363INTCTRL4_EXT =(unsigned *)0xB00f4000;
volatile unsigned *SMT363INTCTRL7 =(unsigned *)0xB00F8000;
volatile unsigned *SMT363INTCTRL4_EXT =(unsigned *)0xB00fc000;
Version 2.2 Page 20 of 27 SMT363XC2 User Manual

SHB pinout

SHB generic pin-out

Hw QSH Pin number QSH Pin number Hw
CLK 1 2 D0
D1 3 4 D2
D3 5 6 D4
D5 7 8 D6
D7 9 10 D8
D9 11 12 D10
Hw0
Hw1
D11 13 14 D12
D13 15 16 D14
D15 17 18 USERDEF0
USERDEF1 19 20 USERDEF2
USERDEF3 21 22 WEN
REQ 23 24
25 26
27 28
29 30
31 32
33 34
35 36
CLK 37 38 D0
D1 39 40 D2
D3 41 42 D4
D5 43 44 D6
D7 45 46 D8
D9 47 48 D10
D11 49 50 D12
D13 51 52 D14
D15 53 54 USERDEF0
USERDEF1 55 56 USERDEF2
USERDEF3 57 58 WEN
REQ 59 60
Hw0
ACK
Hw1
ACK
Note: Hw is a short for Half-word (i.e. 16-bit Word)
Version 2.2 Page 21 of 27 SMT363XC2 User Manual

Jumper Pin-Outs

JP1 - NET+50 connections

1
SPI_CLK
2
SPI_RX
3
RXD
4
RTS
5
DTR
6
DSR
7
V33
8
11
SPE_EN
12
SPI_TX
13
TXD
14
CTS
15
DCD
16
RI
17
GND
18
FA6
9
FA3
10
FA1
FA78
19
FA45
20
FA2

JP2 - Serial port header

2 4 6 8 10 12 14 16
FSX1 FSR1 DX1 DR1 CLKX1 CLKR1 CLKS1 GND
FSX2 FSR2 DX2 DR2 CLKX2 CLKR2 CLKS2 GND
1 3 5 7 9 11 13 15
Refer to the DSP’s Peripheral Reference Guide for signal description and usage.
Version 2.2 Page 22 of 27 SMT363XC2 User Manual

JP3 - Xilinx CPLD programming port.

JP4 - NetICE port

1
V33
3
GND
5
TDO
1
TCLK
3
TMS
5
TDI
2
TCK
4
TMS
6
TDI
2
TRST (NC)
4
NC
6
V33
7
TDO
8
GND
Typically, TRST is not connected to the NET+50.
Version 2.2 Page 23 of 27 SMT363XC2 User Manual

LED Descriptions

LED
Connection Function
1 FPGA.DONE Shows the state of the FPGA’s configuration.
If this LED is ON, then the FPGA is NOT configured. This LED should power up in the ON state and extinguish after a second.
2 FPGA.LED0 Controlled by the LED register.
DSP Heartbeat (SMT6060-TCPIP, rpcproxy.tsk)
3 FPGA.LED1 Controlled by the LED register.
4 NET50.PORTA0 Controlled by PORTA bit 0 of the NET+50.
Net+50 Heartbeat (SMT6060-TCPIP, netsocksvr_v0p5p7.dat)
5 NET50.PORTA1 Controlled by PORTA bit 1 of the NET+50.
6 PHY.LED3 Link receive status (ON=receiving, OFF=not
receiving)
7 PHY.LED2/NET50.PORTC6 Link up status (ON=connected,
OFF=disconnected)
8 PHY.LED1 Link speed status (ON=100Mbit,
OFF=10Mbit)
Version 2.2 Page 24 of 27 SMT363XC2 User Manual

Mechanical Configuration

Version 2.2 Page 25 of 27 SMT363XC2 User Manual

Operating Conditions

Safety

The module presents no hazard to the user.
EMC
The module is designed to operate within an enclosed host system that provides adequate EMC shielding. Operation within the EU EMC guidelines is only guaranteed when the module is installed within an appropriate host system.
The module is protected from damage by fast voltage transients introduced along output cables from outside the host system.
Short-circuiting any output to ground does not cause the host PC system to lock up or reboot.

General Requirements

The module must be fixed to a TIM40-compliant carrier board.
The SMT363XC2 TIM is in a range of modules that must be supplied with a 3.3V power source. In addition to the 5V supply specified in the TIM specification, these new generation modules require an additional 3.3V supply to be presented on the two diagonally-opposite TIM mounting holes. The lack of this 3.3V power supply should not damage the module, although it will obviously be inoperable; prolonged operation under these circumstances is not recommended.
The SMT363XC2 is compatible with all Sundance TIM carrier boards. It is a 5V tolerant module, and as such, it may be used in mixed systems with older TIM modules, carrier boards and I/O modules.
Use of the TIM on SMT327 (cPCI) motherboards may require a firmware upgrade. If LED D6 on the SMT363XC2 remains illuminated once the TIM is plugged in and powered up, the SMT327 needs the upgrade. The latest firmware is supplied with all new boards shipped. Please contact Sundance directly if you have an older board and need the upgrade.
The external ambient temperature must remain between 0°C and 40°C, and the relative humidity must not exceed 95% (non-condensing).

Power Consumption

The power consumption of this TIM is dependent on the operating conditions in terms of core activity and I/O activity. The SMT363XC2 module consumes about 3.18 Watts.

Bibliography

1. Sundance Help file
2.
SMT6400 help file (DSP support package) and SMT6500 help file (FPGA support package)
3. SMT6060 user manual (Ethernet support package)
4.
NET+50 Microprocessor
5.
TMS320C6000 Peripherals Reference Guide (literature number SPRU190)
It describes common peripherals available on the TMS320C6000 digital signal processors. This book includes information on the internal data and program memories, the external memory interface (EMIF), the host port, multichannel-buffered serial ports, direct memory access (DMA), clocking and phase-locked loop (PLL), and the power-down modes.
6.
TIM-40 MODULE SPECIFICATION Including TMS320C44 Addendum
7.
SDB Technical Specification
8. SHB Technical Specification
9.
TMS320C4x User's Guide (literature number SPRU063)
It describes the C4x 32-bit floating-point processor, developed for digital signal processing as well as parallel processing applications. Covered are its architecture, internal register structure, instruction set, pipeline, specifications, and operation of its six DMA channels and six communication ports. Software and hardware applications are included.
10.
Xilinx Virtex-II datasheet
11.
TMSC6713 datasheet
User Manual (QCF42); Version 3.0, 8/11/00; © Sundance Multiprocessor Technology Ltd. 1999
Version 2.2 Page 27 of 27 SMT363XC2 User Manual

INDEX

A
Application Development · 18
B
Bibliography · 26
C
Code Composer · 18 CONFIG & NMI · 15 Contacting Sundance · 5
E
email address · 5
F
Firmware versions · 12
M
memory space (CE0 to CE3) · 10
N
Notational Conventions · 6
O
Operating Conditions · 25
P
Power consumption · 25
R
Register Descriptions · 6
S
I
IIOF lines · 17
L
LEDs · 14
FPGA DONE pin · 14 LED register · 14
SDB · 13 SHB pinout · 20 SMT6400 · 18 SMT6500 · 18
T
Timer · 16
V
Version Control · 12
Loading...
