Sun Cupid Technology S2801L User Manual
Getting Started
With Your
4G LTE mobile phone
Model: S2801L, F4L, NUU F4L
Index
F4L Overview 3
Setting Up Your Phone 4
Safety Information 6
Certificate 13
Warranty Information & Registration 15
Customer Support 15
F4L Overview
Earpiece
LCD Screen
The Keypad
Notification/Status
1
Bar/ Option
Back/Delete (Typing)
2
Navigation (Up/Down/
Left/Right)/Shortcut
3
wheel
Menu/Confirm
4
Answer Call/Phone
5
Dialer
End Call/Power On/
Off/Home Screen/
Press Volume Down
6
key together for
screenshot
Holding 1 for
7
Voicemail Call
Holding # key swaps
between General and
8
Silent mode/Delete
(Typing)
Holding * key for
9
recent tasks
Holding 0 key for
Camera
AUX-In/Headset jack
microUSB connector
Volume control
Microphone
1
5
7
91010
2
3
4
6
8
3
Setting Up Your Phone
Follow these step-by-step instructions to set
up your F4L.
Power off the phone before inserting any cards!
1
Remove Back Cover
• Remove the back cover by
sliding the back cover down
with your fingers
2
Insert SIM
• Orient SIM card to match diagram
on slot.
• SIM support 4G LTE connections.
3
Insert microSD™ Memory Card
(Optional)
• Remember to power off the phone and re-
move battery before inserting memory card.
4
Insert the Battery
• Align the battery contacts, then insert the battery
contact-first.
5
Replace Back Cover
• After installing the SIM card, memory card, and battery,
align the cover and slide it closed. Be sure to press all
around the edges to ensure a secure fit.
6
Charge/Sync
• Plug in the microUSB connector to charge the phone
or transfer data.
4
6
3
4
2
5
Warning:
SIM cards are small enough to become a choking
hazard, so please keep them away from children
& pets. SIM cards are also quite delicate. Please
be careful when handling your card.
1
5
Safety Information
• This section contains important information about the operation
of your device, it also contains information about how to use the
device safely. Read this information carefully before using your
device.
Electronic device
Do not use your device if using the device is prohibited.
Do not use the device if doing so causes danger or interference
with other electronic devices.
Interference with medical equipment
• Follow rules and regulations set forth by hospitals and health care
facilities. Do not use your device where prohibited.
• Some wireless devices may affect the performance of hearing aids
or pacemakers. Consult your service provider for more information.
• Pacemaker manufacturers recommend that a minimum distance
of 15 cm be maintained between a device and a pacemaker to
prevent potential interference with the pacemaker. If using a
pacemaker, hold the device on the side opposite the pacemaker
and do not carry the device in your front pocket.
Protecting your hearing when using a headset
• To prevent possible hearing damage, do not listen at high volume
levels for long periods.
• Using a headset at high volumes may damage your hearing.
To reduce this risk, lower the headset volume to a safe and
comfortable level.
• Exposure to high volumes while driving may cause distraction and
increase your risk of an accident.
Areas with flammables and explosives
•
Do not use the device where flammables or explosives are stored
6
