Sun Cupid Technology N5701L Users manual

Getting Started

With Your

G1 OverviewIndex

G1 Overview 3

Setting up Your Phone 4

Getting Start 6

Safety information 7

Certificate 11

Warranty information & Registration 15

Customer Support 15

Front/Back

Rear

camera

Camera

flash

Volume
control

Fingerprint

sensor

Wake/Sleep
button

Top

Bottom

SIM Tray

Front
camera

Earpiece

AUX-In/Headset jack

microUSB
connector

Speaker

3

Setting Up Your Phone

Follow these step-by-step instructions to set up your G1.
Power off the phone before inserting any cards!

1

Remove SIM Tray

• Remove the SIM tray by inserting a pin eject key/

paper clip in the small circular hole at the bottom of
the tray. The tray will then eject from the phone.

2

Configuration 1: Dual SIM Standby

• Orient SIM card to match layout on tray.

• SIM 1 (Nano) supports 4GLTE connections.

• SIM 2 (Micro) supports 4GLTE connections.

3

Configuration 2: microSD™ Card/SIM

• Orient microSD/SIM card to match layout on tray.

• microSD card supports up to 64GB

• SIM 2 (Micro) supports 4GLTE connections.

4

Replace SIM Tray

• After placing the SIMs and/or memory card in the

tray, slide it back into its slot. It will click and hold
in place.

5

Charge/Sync

• Plug in the type C connector to charge the phone

or transfer data.

1

2

3

Warning:

SIM cards are small enough to become a choking hazard, so
please keep them away from Children & Pets. SIM cards are also
quite delicate. Please be careful when handling your card.

4 5
