Verve® Irons
Instruction Booklet
This book covers the use and care of the following Verve™ Irons:
SR6850 Verve
®
68 Resilium® Shot & Spray Iron with Safety Auto-Off
SR6650 Verve
®
66 Stainless Shot & Spray Iron with Safety Auto-Off
SR6550 Verve
®
65 Platinum Shot & Spray Iron with Safety Auto-Off
SR6250 Verve
®
62 Platinum Shot & Spray Iron
Please read these instructions carefully
and retain for future reference.
Verve™ Irons
Instruction Booklet
This book covers the use and care of the following Verve™ Irons:
SR6800 Verve
™
68 Resilium® Shot & Spray Iron with Safety Auto-Off
SR6600 Verve
™
66 Stainless Shot & Spray Iron with Safety Auto-Off
SR6500 Verve
™
65 Platinum Shot & Spray Iron with Safety Auto-Off
SR6200 Verve
™
62 Platinum Shot & Spray Iron
Please read these instructions carefully
and retain for future reference.
Sunbeam’s Safety Precautions 3
Features of your Verve Iron 4
Using your Verve Iron 6
The Safety Auto-Off Feature 7
Care and Cleaning of your Verve Iron 8
Ironing Tips & Tricks 9
Ironing Chart 10
Contents
Important instructions – retain
for future use.
3
Sunbeam’s Safety Precautions
Sunbeam is very safety conscious when
designing and manufacturing consumer
products, but it is essential that the product
user also exercise care when using an
electrical appliance. Listed below are
precautions which are essential for the safe use
of an electrical appliance:
• Read carefully and save all the instructions
provided with an appliance.
• Always turn the power off at the power outlet
before you insert or remove a plug.
Remove by grasping the plug - do not pull on
the cord.
• Turn the power off and remove the plug
when the appliance is not in use and
before cleaning.
• Do not use your appliance with an extension
cord unless this cord has been checked
and tested by a qualified technician or
service person.
• Always use your appliance from a power
outlet of the voltage (A.C. only) marked
on the appliance.
• This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision or
instruction concerning use of the appliance
by a person responsible for their safety.
• Children should be supervised to ensure that
they do not play with the appliance.
• The temperature of accessible surfaces may
be high when the appliance is operating.
• Never leave an appliance unattended while
in use.
• Do not use an appliance for any purpose
other than its intended use.
• Do not place an appliance on or near a hot
gas flame, electric element or on a heated
oven.
• Do not place on top of any other appliance.
• Do not let the power cord of an appliance
hang over the edge of a table or bench top
or touch any hot surface.
• Do not operate any electrical appliance with
a damaged cord or after the appliance has
been damaged in any manner. If damage
is suspected, return the appliance to the
nearest Sunbeam Appointed Service Centre
for examination, repair or adjustment.
• For additional protection, Sunbeam
recommend the use of a residual current
device (RCD) with a tripping current not
exceeding 30mA in the electrical circuit
supplying power to your appliances.
• Do not immerse the appliance in water
or any other liquid unless recommended.
• Appliances are not intended to be operated
by means of an external timer or separate
remote control system.
• This appliance is intended to be used in
household and similar applications such
as: staff kitchen areas in shops, offices and
other working environments; farm houses; by
clients in hotels, motels and other residential
type environments; bed and breakfast type
environments.
SAFETY PRECAUTIONS FOR YOUR IRON
• Do not leave a hot iron within reach of
children. If they come into contact with a
hot iron it could lead to serious burns.
• Iron only on an ironing board.
• An iron takes approximately 30 minutes to
cool down. Allow the iron to cool completely
before storing.
• Do not wind the cord around the soleplate
while the iron is still hot.
• Do not leave the iron unattended while it is
plugged into the power outlet.
• Always unplug the iron from the power
outlet before filling or emptying the water
tank.
• The iron must be used and rested on a
stable surface.
• The iron is not to be used if it has been
dropped, if there are visible signs of
damage or if it is leaking.
If you have any concerns regarding the performance and use of your appliance,
please visit www.sunbeam.com.au or contact the Sunbeam Consumer Service Line.
Ensure the above safety precautions are understood.
4
Features of your Sunbeam
Verve Iron
Powerful shot of steam
Pressing the shot of steam button instantly
produces a powerful shot of steam to remove
stubborn wrinkles.
Vertical shot of steam
Pressing the shot of steam button with the iron
in an upright position produces a vertical shot of
steam, which is ideal for steaming curtains and
suits, and removing creases from delicate fabrics.
Fine spray mist
Pressing the spray button provides a fine mist
spray to dampen hard-to-iron fabrics.
Easy-fill water inlet
Holds 300ml of water for continual high steam
performance without having to refill the tank
regularly.
Drip-s
top steam system
The drip-stop steam system automatically stops
water flowing to the steam chamber should the
temperature fall too low to generate steam.
This prevents dripping, even at low
temperatures.
Full length button groove
For ironing around buttons.
2400 watts for fast heat up
Provides faster initial heat up and rapid heat
recovery during ironing. The 2400W element
helps to maintain your selected temperature,
and provides superior shot of steam output.
Teflon® Platinum Pro non-stick soleplate
(SR6200 & SR6500)
Teflon® Platinum Pro is DuPont’s premium non-stick
coating. It glides easily
across all types of fabric and
prevents sticking. This hard wearing surface consists of a
unique three coat system for superior durability and scratch
resistance. It simply wipes clean for fuss free maintenance.
Resilium® non-scratch soleplate
(SR6800)
Resilium® is a durable, scratch
resistant surface that provides a
superior glide and prevents rucking.
Exclusive to Sunbeam, this premium
soleplate features 172 steam holes
to maximise steam distribution.
5
Safety auto-off
The iron automatically switches itself off if
left in the ironing position (horizontal) for 30
seconds, or in the heel rest position (vertical)
for 15 minutes. (For more information on the
safety auto off feature see page 7).
Power light
Illuminates to indicate that the iron is
connected to the power outlet and the power
is turned on.
Thermostat light
Illuminates to indicate that the iron is
heating and goes out when it has reached the
temperature selected on the temperature dial.
The thermostat light cycles on and off during
ironing as the iron maintains the selected
temperature.
Stable heel rest
Extra large heel rest keeps the iron stable on
the ironing board.
Cord wrap
The built-in cord wrap facility allows you to
wind the cord around the heel for neat and
tidy storage of the cord when the iron is not
in use.
Concentric steam and temperature dials
The steam and temperature dials are
positioned together for easy adjustment.
Variable steam dial
Allows you to select the desired steam output
for each garment. Alternatively, select the DRY
setting to iron without steam.
Temperature dial
Allows you to select the desired temperature
for each garment. The adjustable temperature
dial also indicates the amount of steam
recommended for use on each temperature
setting.
Stainless steel soleplate
Sleek and smooth, stainless steel is
an excellent heat conductor and is
extremely durable and hard wearing.It
fea
tures a quality polished finish that is
easy to clean and care for.
Steam Dial
Temperature Dial
Before first use
Remove any adhesive stickers, plastic covers
or cardboard sleeves from the soleplate.
Ensure that all adhesive is removed by rubbing
the soleplate with a cloth dampened with
methylated spirits.
Fill the water tank and empty the water. This
will rinse out any foreign particles remaining
in the water tank from the manufacturing
process.
NOTE: When turned on for the first time,
your new iron may give off vapours for up
to 10 minutes. This is due to the initial
heating of the materials used. It is safe, not
detrimental to the performance of the iron,
and will not reoccur.
Filling the iron with water
Befo
re filling the iron with water ensure the
power is turned off and the plug is removed
from the power outlet. The iron can be filled
with water while it is hot.
Place the iron on its heel and open the water
inlet cover.
Slowly pour water into the water inlet until
the maximum water level is reached. Do not
exceed the maximum water level indicator.
Push the water inlet cover firmly to close.
NOTE: The special soleplate design allows you
to use tap water with your Verve iron without
affecting the steam performance. However in
very hard water areas, Sunbeam recommends
the use of distilled water, or wate
r which has
been demineralised.
For best performance, we recommend the use
of Sunbeam Water Demineraliser, available
from selected retailers. This will produce up to
30 litres of demineralised water.
Do not fill the iron with fabric conditioner,
starches or any other solution as these will
damage the steam mechanism. Do not use
contaminated water.
Using your iron
1. Insert the plug into a 230/240 volt power
outlet and turn the power on. The power
ON light (positioned on top of the handle)
will illuminate to indicate that the iron is
switched on and heating.
2. Turn the temperatu
re dial to the desired
setting by aligning the setting on the
dial with the temperature indicator. The
thermostat light will illuminate to indicate
that the iron is heating to the selected
temperature. When the thermostat light
goes out the iron has reached the selected
temperature and is ready to use.
NOTE: When the temperature dial is changed
from a high setting to a lower temperature
setting during ironing, the thermostat light will
go out immediately. This indicates that the
iron is cooling to the selected temperature.
To ensure that the iro
n has reached the
selected temperature and is not too hot, wait
until the thermostat light comes on again and
then goes out before ironing.
Steam ironing
Follow steps 1 and 2 above.
NOTE: When steam ironing, ensure that the
temperature dial is set to any temperature
within the steam band, and that the tank
is at least ¼ full of water.
3. Turn the steam dial to the desired
steam setting.
For best results, select the steam setting
that corresponds to the selected temperature,
as indicated on the temperature dial.
6
Using your Sunbeam Verve Iron
Steam Dial
Temperature Dial
Dry ironing
Follow steps 1 and 2 above.
3. Select DRY on the steam dial.
This will cut off the steam flow if there is
water in the tank.
Using the shot of steam
The shot of steam can be used when dry
or steam ironing, when the temperature dial
is set to any temperature within the steam
band or above the two dot (••) setting.
1. Ensure the tank is at least
¼ full of water.
2. Select the desired temperature and wait
until the thermostat light goes out.
3. Press the shot of steam button
several
times with the iron on the soleplate to
prime the pump.
Note: If the tank has run dry, it may be
necessary to re-prime the pump after filling
the iron with water.
Using the spray mist
The spray mist can be used whether dry or
steam ironing to pre-dampen hard to iron
fabrics.
1. Ensure the tank is at least
¼ full of water.
2. Press the spray button during ironing to
release a fine mist from the spray nozzle.
The safety auto-off mecha
nism automatically
turns the iron off if you forget.
The iron will automatically shut off if left
on the heel rest (vertical) for 15 minutes,
or in the ironing position (horizontal) for 30
seconds, without being moved.(See figure 2).
The thermostat and power lights on the
handle will flash and a warning beep will
sound to let you know that you have left the
iron unattended.
Power to the iron's heating element will be
cut.
Once the iron is moved the power will
reconnect. Allow the iron
to heat until the
thermostat light goes out, and continue
ironing as normal.
7
Using your Sunbeam Verve Iron (continued)
The safety auto-off feature
(Models SR6550, SR6650 & SR6850)
Figure 2
15 minutes 30 seconds
After each use
1. Turn the power off and remove the plug
from the power outlet.
2. Allow the iron to cool before winding
the cord around the built-in cord wrap.
Storage
Always store the iron on its heel rest.
Do not store the iron with the soleplate
facing down, or in the carton.
Cleaning
To clean the exterior of your iron, wipe
over with a damp soft cloth and wipe dry.
Caution: Do not use harsh abrasives,
chemical cleaners or solvents to clean the
exterior of your iron as these will damage the
surface.
Cleaning the steam holes
To remove build up from the steam holes
which may affect steam performance,
use a cotton wool tip m
oistened in
methylated spirits.
Cleaning the Resilium
®
soleplate (SR6850)
Wipe with a soft damp cloth and wipe dry.
Cleaning the Stainless Steel soleplate
(SR6650)
Using a stainless steel or metal cleaner,
rub gently with a damp cloth and wipe dry.
Cleaning the Teflon
®
Platinum Pro
non-stick soleplate
(SR6250, SR6550)
The non-stick coating reduces sticking
of fabrics and starches to the soleplate.
Do not iron over sharp objects such as
buttons, studs and zippers, as these may
scratch the surface.
Wipe the soleplate with a damp soft
cloth
after each use. If polyester has burnt to the
soleplate, iron a damp cotton cloth while hot.
Caution: Do not use scouring pads, abrasives
or harsh cleaners to clean your Resilium
®
,
Teflon
®
Platinum Pro or Stainless steel
soleplate, as these will scratch and damage
the surface.
8
Care and Cleaning
Tip # 27 - Iron shirts like a pro
Start with the collar, working from the outer
edges into the middle. Iron the shoulder
next, followed by the cuffs and sleeves.
Place the collar at the narrow end of the
board so that one front panel of the shirt
is extended flat. Iron the front panel from
shoulder to shirt tail. Rotate to iron the
back of the shirt. Rotate and complete the
remaining front panel.
Tip # 34 - Tips for T-shirts
Straighten seams on t-shirts before hanging
out to dry. To avoid damage to printed
graphics and logos turn the t-shirt inside out
and iron the reverse side of the print. Never
iron areas of your t-shirt where perspiration
marks are visible as the heat of the iron will
permanently fix the stain.
Tip # 54 - Hung out to dry
When washing is complete, remove shirts
from the machine immediately, shake them
out and hang them on coat hangers to air dry
– this will keep wrinkles to a minimum.
Tip # 18 - Selecting the right temperature
If you are unsure of the correct setting for a
particular garment, test a small area such as
a seam or inside hem before ironing a visible
area. Start with a low temperature and slowly
increase the heat to find the best setting.
Tip # 33 - Don’t be afraid to iron silk
Don’t be afraid to iron silk. Although delicate
in appearance, silk is the strongest and most
resilient of all natural fibres. To achieve the
best results, set to a low cotton setting and
use regular shots of steam. Always use a
pressing cloth to avoid shine marks.
Tip # 13 - Ironing the seam
Always press seams in the same direction
they were made. When a garment is
produced, the fibres will naturally settle
in the direction they were initially pressed,
so it’s best not to iron against the grain.
Tip # 26 - Sort types of fabric
Sort articles to be ironed according to the
type of fabric. This will reduce the need to
adjust the temperature constantly. Start with
articles requiring lower temperatures and
work your way through to items requiring
higher settings.
Tip # 2 - Summer frocks and frills
Steam is the key when ironing delicate
summer fabrics such as muslin, cotton and
linen. Don’t press down with the iron, simply
hover above the garment and steam it using
a vertical shot of steam. Ruffling, netting,
tulle or intricate hand detailing is also best
ironed using this method.
Tip # 5 - Pressing your winter woollies
Steam is crucial when pressing your winter
woollies. Woollen garments can be hung and
steamed using the vertical shot of steam
feature. After steaming, brush the garment
with your hand to plump up woollen fibres.
If ironing the garment flat it is best to use
a pressing cloth. Don’t be afraid to apply
pressure – steam and hold.
Tip # 42 - Table settings to impress
To avoid unwanted creases always iron
your table cloth after taking it out of the
cupboard. A dinner party is a special
occasion, so treat the table cloth as you
would your own outfit. For best results, lay
towels across your table and iron the table
cloth over the towels. This will save you time
and ensure a beautifully presented table
setting.
9
Ironing Tips and Tricks
Ironing Chart
Fabric Temp setting Ironing Ironing recommendation
Acrylic
MINIMUM
Min to •
Dry iron on reverse side of fabric
Acetate
MINIMUM
Min to •
Dry iron on reverse side of fabric
while still damp
Nylon
MINIMUM
Min to •
Iron on reverse side of fabric
Polyester
SYNTHETIC
•
Iron on reverse side of fabric
Rayon
SYNTHETIC
•
Iron on reverse side of fabric
Viscose
SYNTHETIC
•
Mainly dry iron. Steam can be used under
manufacturer's instructions
Silk
SILK
• •
Iron on reverse side of fabric. Use an ironing
cloth to prevent shine marks
and use regular shots of steam
Cotton Blends
WOOL
• •
Check label and follow manufacturer’s
instructions. Use setting for the fibre
requiring the lowest setting
Wool
WOOL
• •
Steam iron on reverse side of fabric
or use an ironing cloth. Brush gently
to raise the fibres
Wool Blends
WOOL
• •
Steam iron on reverse side of fabric
or use an ironing cloth. Brush gently
to raise the fibres
Corduroy
COTTON
• • •
Steam iron on reverse side of fabric
or use an ironing cloth. Brush gently
to raise the fibres
Cotton
COTTON
• • •
Steam iron while still damp or use spray
to dampen. Use medium to high steam
Linen
LINEN
• • • to Max
Iron on reverse side of fabric or use an
ironing cloth to prevent shine marks,
especially with dark colours. Iron while
still damp or use spray to dampen.
Use medium to high steam
Denim
MAXIMUM
• • • to Max
Iron while still damp or use spray
to dampen. Use maximum steam
10
Should you experience any difficulties with
your appliance, please phone our customer
service line for advice on 1300 881 861 in
Australia, or 0800 786 232 in New Zealand.
Alternatively, you can send a written claim
to Sunbeam at the address listed below.
On receipt of your claim, Sunbeam will
seek to resolve your difficulties or, if the
appliance is defective, advise you on how
to obtain a replacement or refund.
Your Sunbeam 2 Year Replacement
Guarantee naturally does not cover misuse
or negligent handling and normal wear and
tear.
Similarly your 2 Year Replacement Guarantee
does not cover freight or any other costs
incurred in making a claim. Please retain
your receipt as proof of purchase.
The benefits given to you by this guarantee
are in addition to your other rights and
remedies under any laws which relate to the
appliance.
Our goods come with guarantees that cannot
be excluded under the Australian Consumer
Law and under the New Zealand Consumer
Guarantees Act.
In Australia you are entitled to a
replacement or refund for a major failure and
for compensation for any other reasonably
foreseeable loss or damage. You are also
entitled to have the goods repaired or
replaced if the goods fail to be of acceptable
quality and the failure does not amount to
a major failure.
Should your appliance require repair or
service after the guarantee period, contact
your nearest Sunbeam service centre.
For a complete list of Sunbeam’s authorised
service centres visit our website or call:
Australia
www.sunbeam.com.au
1300 881 861
Units 5 & 6, 13 Lord Street
Botany NSW 2019 Australia
New Zealand
www.sunbeam.co.nz
0800 786 232
26 Vestey Drive, Mt Wellington
Auckland, New Zealand
In the unlikely event that this appliance develops any malfunction
within 2 years of purchase (3 months commercial use) due to
faulty materials or manufacture, we will replace it for you
free of charge.
2 Year Replacement Guarantee
is a registered trademark.
Need help with your appliance?
Contact our customer service team or visit
our website for information and tips on
getting the most from your appliance.
In Australia
Visit www.sunbeam.com.au
Or call 1300 881 861
In New Zealand
Visit www.sunbeam.co.nz
Or call 0800 786 232
‘Verve’ and ‘Resilium’ are registered trademarks
of Sunbeam Corporation.
‘Teflon’ is a registered trademark of DuPont.
Made in China.
Due to minor changes in design or otherwise,
the product may differ from the one shown in this leaflet.
© Copyright.
Sunbeam Corporation Limited 2011.
ABN 45 000 006 771
Units 5 & 6, 13 Lord Street
Botany NSW 2019 Australia
Unit 3, Building D
26 Vestey Drive
Mt Wellington Auckland
New Zealand
Sunbeam Corporation is a division of GUD Holdings Ltd.
6/11
Loading...
