Quantum
Instruction Booklet
This book covers the use and care of the following Sunbeam Toasters:
TA3220 Quantum 2 – 2 Slice
TA3420 Quantum 4 – 4 Slice
Please read these instructions carefully
and retain for future reference.
Sunbeam’s Safety Precautions 1
Features of your Toaster 2
Using your Toaster 4
Toaster functions 5
Care and cleaning 6
Contents
Important instructions – retain for
future use.
1
Sunbeam are very safety conscious when
designing and manufacturing consumer products,
but it is essential that the product user also
exercise care when using an electrical appliance.
Listed below are precautions which are essential
for the safe use of an electrical appliance:
• Read carefully and save all the instructions
provided with an appliance.
• Always turn the power off at the power outlet
before you insert or remove a plug. Remove
by grasping the plug – do not pull on the cord.
• Turn the power off and remove the plug
when the appliance is not in use and
before cleaning.
• Do not use your appliance with an extension
cord unless this cord has been checked
and tested by a qualified technician or
service person.
• Always use your appliance from a power
outlet of the voltage (A.C. only) marked
on the appliance.
• Close supervision is necessary when your
appliance is being used near children or
infirm persons.
• Never leave an appliance unattended while
in use.
• Young children should be supervised to ensure
that they do not play with the appliance.
• Do not use an appliance for any purpose
other than its intended use.
• Do not place an appliance on or near a hot gas
flame, electric element or on a heated oven.
Do not place on top of any other appliance.
• Do not let the power cord of an appliance hang
over the edge of a table or bench top or touch
any hot surface.
• For safety reasons and to avoid maintenance
by unskilled persons, some appliances are
‘sealed’ using tamperproof screws. Such
appliances should always be returned to the
nearest Sunbeam Appointed Service Centre
for adjustment or repair if required.
• Do not operate any electrical appliance with a
damaged cord or after the appliance has been
dropped or damaged in any manner. If damage
is suspected, return the appliance to the
nearest Sunbeam Appointed Service Centre
for examination, repair or adjustment.
• For additional protection, Sunbeam
recommend the use of a residual current
device (RCD) with a tripping current not
exceeding 30mA in the electrical circuit
supplying power to your appliances.
• Do not immerse the appliance in water
or any other liquid unless recommended.
If you have any concerns regarding the performance and use of your appliance,
please visit www.sunbeam.com.au or contact the Sunbeam Consumer Service Line.
Ensure the above safety precautions are understood.
Sunbeam’s Safety Precautions
SAFETY PRECAUTIONS FOR YOUR
SUNBEAM TOASTER.
• Do not place any objects such as toast,
bread or similar on top of your toaster when
in use.
• Operate the toaster on a flat level surface.
• Use your toaster well away from walls,
curtains, or other combustible materials.
• Do not leave your toaster unattended when
in use.
• Clean crumb tray regularly.
• Do not allow crumbs to accumulate in the
crumb tray.
• Do not toast stale bread, rice crackers or
similar on a high setting as they may catch
fire.
• WARNING: Never attempt to extract jammed
toast, crumpets or muffins with a knife or
any metal object, as contact with the live
element may cause electrocution.
Extra wide and deep bread slots
Enables you to toast a large variety of breads both
thick and thin, bagels, crumpets and muffins.
Self-centring bread slots
Whether you are toasting thick or thin bread,
your bread will always be held in the centre of
the slot to ensure even toasting.
Cool touch exterior
Remains cool to touch preventing burns and
plastic wrappers clinging to the side of your
toaster.
Removable crumb tray
Pulls out from underneath your toaster
for easy removal of crumbs.
Cord storage
The cord can be wrapped underneath
for safe and convenient storage.
2
Features of your Toaster
3
High lift lever
Raises the toast above the starting position
so you can remove the toast from the toaster
without burning your fingers. Ideal for
crumpets and muffins.
Cancel button
Immediately interrupts any toasting cycle and
pops the toast up.
Electronic browning control
Variable toast settings from 1 - 6, plus min
and frozen, toasts the bread to your desired
colour consistently.
Frozen setting defrosts and toasts your bread.
Quantum 4 – TA3420
Plug the toaster into a 230-240 volt AC
power outlet and switch the power on.
Toasting Bread
1.Position the bread into the bread slot.
2.Select the desired colour setting on the
Electronic Browning Control.
Important: Do not toast stale bread, rice
crackers or similar on a high setting as
they may catch fire.
3.Push the Toasting Lever down to
commence the toasting cycle.
4.When the colour setting is achieved, the
toaster will automatically turn off and pop
the toast up. If you need to remove the
toast before the cycle is complete, then
press the Cancel button. The Cancel
button will immediately interrupt the
toasting cycle and pop the toast up.
5.To remove small pieces of toast or bagels,
use the High Lift Lever to lift the toast
above the starting position. This will
prevent burning your fingers as you remove
the toast.
4
Using your toaster
5
Cancel button
The Cancel button immediately stops any of
the toasting cycles. As a consequence of
this, the toast will pop up.
High lift lever
When toasting small pieces of bread or
crumpets or muffins we recommend using
the High Lift Lever to prevent you from
burning your fingers.
Toasting frozen bread
Selected the Frozen setting on the Electronic
Browning Control. This setting will toast your
frozen bread. The colour of your toast on the
Frozen setting is equivalent to setting 3 or 4.
Toasting one or two pieces in your Quantum 4 –
4 slice toaster
Position the bread in the middle of the bread
slot. When toasting two pieces, position one
piece in the centre of each bread slot.
If your bread jams in the toaster, switch
power off, remove the plug from the power
outlet and ease the bread out of the toaster.
If your bread jams in the toaster, switch
power off, remove the plug from the power
outlet and ease the bread out of the toaster.
Ensure muffins or bagels are cut into even
halves and fit freely into the bread slot. Do
not force them into the toaster.
WARNING: Never attempt to extract jammed
toast, muffins, bagels or crumpets with a knife
or any other metal object, as contact with the
live element may cause electrocution.
Toaster functions
Always turn the power OFF and remove the
plug from the power outlet after use and
before cleaning your toaster.
To clean the exterior.
Wipe exterior with a slightly dampened cloth
and polish with a soft dry cloth.
Do not use metal scourers or abrasives as this
may scratch the exterior surface.
Removable Crumb Tray.
To remove the crumbs, simply slide out the
tray, empty and place it back in the toaster.
Clean the crumb tray regularly. Do not allow
crumbs to accumulate, as they will
accumulate and may cause a potential fire
hazard.
To clean the toaster interior.
Clean inside the toaster regularly. To do this,
unplug the appliance, turn it upside down
over the sink and gently shake all the crumbs
out.
6
Care and cleaning
‘Sunbeam’, and ‘Quantum’ are registered trademarks of
Sunbeam Corporation.
Made in China. Due to minor changes in design or
otherwise, the product may differ from the one shown
in this leaflet. Backed by Sunbeam‘s 12 Month
Replacement Guarantee and National Service Network.
© Copyright.
SUNBEAM CORPORATION LIMITED 2003.
(INCORPORATED IN N.S.W.) A.C.N. 000 006 771
Sunbeam Corporation is a division of GUD Holdings Ltd.
For more information or advice on this or any other
Sunbeam appliance, visit www.sunbeam.com.au or
contact the Sunbeam Consumer Service Line.
Australia 1800 025 059
New Zealand (09) 912 0747.
Consumer Hotline
Australia
1800 025 059
New Zealand
(09) 912 0747
www.sunbeam.com.au
is a registered Trademark of Sunbeam
Corporation Limited. ACN 000 006 771.
© Sunbeam Corporation Limited 2003.
