Sunbeam 7655-10 User Manual

C@

Health At

Read All Instructions Carefully Before Use

Home

Finger Blood Pressure Monitor

Instruction Booklet

Save These Instructions Instructions

DO’S AND DON’TS

FOR ACCURATE BLOOD PRESSURE READINGS

1. DO Read instructions carefully before using Monitor.

2. DO Rest arm on a flat surface so that finger is at heart level
when taking measurements.

3. DO Remain calm, quiet and still when measurements are being

taken.

4. DO Make sure that the Finger Cuff is adjusted properly according

to your instruction manual.

5. DO Insure that the exhaust velocity is 2-5 mmHg per second at
the systolic point each time a measurement is taken.

10

6. DO Wait at least

7. DO Pump unit 30 to 60 mmHg above normal systolic before beginning measurement.

8. DO Consult your physician before adjusting your medication based on readings from
this Monitor.

9. DO Use fresh alkaline batteries.

IO. DO Use a dry, soft cloth to clean the instrument.

11.

DO use your left index finger when taking measurement. Use of an alternate finger may

result in an inaccurate reading.

12. DO make sure that your finger is warm.

minutes between taking measurements.

1. DO NOT move arms or hands when measurement is being taken.

2. DO NOT talk or chew gum when measurement is being taken.

3. DO NOT take a series of measurements without waiting at least 10 minutes
between measurements.

4. DO NOT adjust medication based on readings from this Monitor.

5. DO NOT make any adjustments to unit; there are no user serviceable parts. Return to
Service Station for repair.

6. DO NOT smoke during or at least 30 minutes prior to taking blood pressure measurements.

7. DO NOT drop or otherwise mechanically shock the Monitor. This is a delicate
precision device.

8. DO NOT use thinner, alcohol, benzene or wet cloth to clean unit.

9. DO NOT subject to extremes in temperature, humidity, direct sunlight or dust.

Manufactured to meet specifications set by the Association for the Advancement of

Medical Instrumentation (AAMI)

WHAT IS BLOOD PRESSURE?

Blood pressure:

Systolic:

Diastolic:

Millimeters of Mercury (mmHg):

Measurement of the rate of pressure exerted by the blood upon the
walls of the blood vessels. The heart contracts and then

relaxes, producing the two levels of blood pressure.

The highest point of blood pressure; level of blood pressure

produced as your heart beats.

The lowest point of blood pressure; level of blood pressure

produced as your heart rests between beats.

Blood pressure measurements are measured in terms of the
height of mercury in a column. Measurements are written one
over the other. For example, a systolic pressure of 120 mmHg and

diastolic pressure of 80 mmHg is expressed as “120 over 80.”

Blood pressure varies constantly and may change due to:

l

physical trauma

l

mental anxieties

l

smoking

-----

exercise

l

eating

l

drinking caffeinated or alcoholic beverages

Only a qualified physician can determine whether your blood pressure is normal.

Hypertension:

IMPORTANT:

is high blood pressure, and is most common among adults and the
elderly; left unattended, it can cause serious health problems such as a
stroke, heart attack, etc. Therefore, it is important to monitor blood

pressure on a continued and timely basis.

Only a physician is qualified to interpret your blood pressure
measurements, and no device can replace regular medical exami­nations by your physician. It is recommended that your physician
review your procedure for using this blood pressure monitor. Your
physician should verify blood pressure measurements before
making adjustments to medication.
