Sumo Quatro 3m 2015, 4m 2015, 3.5m 2015, 6m 2015, 5m 2015 Operator's Manual And Parts List

3m, 3.5m, 4m, 5m & 6m Machines
2015
Operator Manual
And
Parts List
Redgates
Melbourne
York
YO42 4RG Tel. 01759 319900 Fax. 01759 319901
1.0 Registration
To activate your SUMO Warranty, you must complete this page and send it back to us at:
Sumo UK Ltd
Redgates
Melbourne
York
YO42 4RG
Tel. 01759 319900
Fax. 01759 319901
(NO REGISTRATION = NO WARRANTY)
SUMO SERIAL No: For your own records.
(Serial plate on side of headstock)
Sumo Quatro Registration Document
NAME:
ADDRESS:
Telephone Number:
SUMO SERIAL No.
(Serial plate on side of headstock)
DEALERSHIP NAME AND BRANCH:
COMMENTS:
Postcode:
DATE:
In order to obtain your free pair of Sumo overalls and baseball cap please fill in this form and send back to us at:
Sumo UK Ltd
Redgates
Melbourne
York
YO42 4RG
Tel. 01759 319900
Fax. 01759 319901
SUMO SERIAL No:
Overall size:
tick where applicable
NAME:
ADDRESS:
Small (38 chest)
Medium (42 chest)
Large (46 chest)
Extra large (50 chest)
XX Large (54 chest)
XXX Large (58 chest)
Postcode:
Page 2
2.0 Summary
The SUMO Quatro, a unique one pass soil conditioning machine designed and manufactured in Britain, comprising as its name suggests of four elements, each of these tuned to comprehensively create the finish required. Three of the four elements are controlled using the machines electro hydraulics, therefore meaning that the Quatro can be run in various configurations.
Firstly
A double row of 500mm concave discs, mounted in pairs on independently suspended arms giving a shock proof durable system with quality low maintenance triple sealed taper roller bearings. Double mounting gives unrivalled performance when working in adverse conditions. The hydraulically adjustable front discs mean that disc working depth can be changed to ensure the machine is used to it full potential.
Secondly
The ultra low draught auto reset protected Subsoiler legs are mounted in a staggered pattern on a heavy duty toolbar, adjusting to a maximum depth of 400mm (at the point) via pins. Due to the design of the legs and their mounting, when a leg is obstructed, the auto reset ram allows the leg to trip. Both rows of legs trip in a fashion which allows the point to come clear of the ground and to pass by the obstacle. These legs feature quick change points and shins.
Thirdly
A repeat bank of double row discs to create a fine tilth.
Finally
The patented Multipacka is uniquely designed to fulfil a number of criteria, comprising, 609mm x 10mm tube mounted on heavy duty quality bearings fitted with notched cutting/ drive rings to keep turning in arduous conditions, giving a total diameter of 800mm. The ring shoulders feature a convex shape adjacent to the barrel, creating consolidation and cracking even on the top of the ridge. All these features make a packer which presses and firms to a higher quality with a lower power requirement than any other packer available.
Before using the SUMO Quatro it is absolutely necessary that you read this Operators Manual and Safety Instructions attentively.
Specifications, descriptions and illustrations in this brochure are accurate, as known, at the time of publication but may be subject to change.
Table of Contents
1.0 Registration
2.0 Summary
3.0 Safety
4.0 Operation and adjustments
4.1 Operating
4.2 Adjustments
4.3 Auto-Reset legs
5.0 Maintenance
5.1 Spares
5.2 Winter storage
6.0 Parts and Assembly
6.1 Twin disc unit
6.2 Single disc unit
6.3 Active soil retainer
6.4 Cast leg socket
6.5 Leg assembly Auto-Reset
6.6 Packer, scrapers and bearings assembly
6.7 Drawbar assembly 6m
6.8 Drawbar assembly 4m
6.9 Drawbar knuckle joint
7.0 Disc hydraulic ram
7.1 Wheels and brakes 6m
7.2 Wheels and brakes 4m
7.3 Leg hydraulic circuit
7.3 Leg hydraulic circuit continued
7.4 6m & 4m Wing hydraulic circuit
7.5 Light and bracket
7.6 Stickers and paint
3.0 Safety
This manual contains basic advice which should be observed during setting-up, operation and maintenance. Therefore, this operating manual must be read by the personnel concerned prior to starting up, using the machine and be available at all times.
If safety instructions are not complied with, then this can lead to the risk of injury to yourself and others as well as damage to the environment or the machine. Non-compliance to the safety instructions can also lead to claims for damages becoming invalid.
3.1 Qualification and Training
Ensure that only reliable, authorized personnel work on or with the machine. Statutory minimum
age limits must be observed.
Employ only trained or instructed staff; the individual responsibilities of the personnel concerning
operation, setting up, maintenance and repair must be clearly established.
Define the machine operators’ responsibilities – also with regard to observing traffic regulations.
The operator must have the authority to refuse any instructions issued by third parties, which contravene safety.
Persons undergoing training or instruction or taking part in a general training course should not be
allowed to work on or with the machine unless they are under the constant supervision of an experienced person.
The use of spare parts, accessories and ancillary equipment not supplied and/or not approved by
SUMO could have detrimental effects to the construction of the SUMO machine or on its functions and hence impair the active and/or passive driving and/or operational safety (accident prevention).
SUMO shall not be responsible for any damage caused by the use of spare parts, accessories and
ancillary equipment not supplied and/or approved by SUMO.
Conversions of or modifications to the machine may only be carried out after consultation with
SUMO.
3.2 General safety
Warning signs and other notices on the machine provide important information for the safe
operation. Observing them will serve your safety.
Before starting work, make yourself familiar with all the equipment and controls as well as their
functions.
The user should wear close-fitting clothing. Keep the machine and in particular the bearings clean to avoid risk of fire. Check around the machine before moving off or starting up (watch out for children!). Make sure
you have adequate all-round visibility.
Always match your speed to the local conditions. Avoid sudden turning manoeuvres when driving
uphill or downhill or when travelling across a slope.
Observe the respective regulations when using public roads. Take into account the length, the wide overhang, the folded height and the sideways force acting
on the machine when turning or negotiating curves.
3.3 Special safety instructions
Take extreme care when hitching up or unhitching machine to/from the tractor. Never allow persons to stand between the tractor and the machine unless the tractor is secured
against rolling away by means of parking brake and/or wheel chocks.
It is forbidden to allow persons to ride on the machine at any time. A safe distance should be
maintained from the machine by observers when in work.
Never stand or work beneath suspended loads. Ensure all persons are stood clear of the machine when folding or unfolding. When making adjustments to the machines care should be taken not to trap any body parts in
moving or pivoting parts.
When making adjustments to the machine the tractor engine should be switched off to prevent the
hydraulics from operating.
4.0 Operation and Adjustment
4.1 Operating
Optimum soil conditioning will occur when the Quatro wing frames are running horizontal (parallel with the ground). Adding or removing slices from the drawbar ram allows for finite angle adjustment of the working angle. Forward working speed should be governed by the local conditions as well as the finish produced by the Sumo Quatro
4.2 Adjustments
Depth adjustment of the Subsoiler legs is achieved by firstly removing the linch pin and then the depth pins. The leg can then be lifted or lowered to the required position and then the shear pin and clip should be replaced. The maximum leg depth is 400 mm. The easiest and most accessible way to change the leg depths (if available) is to fold the wings up and slide the legs in or out.
To adjust the disc working depth, the appropriate channel should be selected on the electro hydraulic control box. Operating the tractor hydraulics will then allow adjustments to be made. Slices are also present on the rams to give exact positioning. The disc unit slices, mixes and cultivates the top 50 ­100mm of soil.
4.3 Auto-Reset Legs
The pressure in the hydraulic circuit controlling the auto-reset Subsoiler legs can be altered depending on circumstances and preference up to a maximum of 120 bar. (Exceeding this pressure may result in damage to the machine). The higher the hydraulic pressure, the more resistance the legs have to tripping.
To alter the pressure in the hydraulic circuit:
1. Select the appropriate channel on the electro hydraulic control box.
2. Change line A of the Auto- Reset circuit using the tractor hydraulics.
3. The pressure is set according to the Auto-Reset valve block (mounted on the side of the chassis).
The large gold/silver knob with lock-off ring can be adjusted in & out. Wind in for more resistance. Try one turn at a time.
4. Once a change has been made to the pressure setting, cycle the legs up and down again to set the
pressure in the circuit. Even though the pressure is locked in the circuit, this system does remain active in that the legs can be raised up out of work.
5. The tractor hydraulics should be returned to float to relieve any back pressure before commencing
work at the new pressure
DO NOT TIGHTEN POINTS UP WITH AIR RACHETS OR OVER TIGHTEN WITH
SPANNERS. EXSESIVE TIGHTENING WILL RESULT IN POINTS CRACKING
5.0 Maintenance
The packer bearings should be greased with one pump once a week and after washing off.
The disc bearings should be greased until old grease is forced out once a week when in normal use and after washing off.
The condition of the subsoiler legs, the points and the discs should be regularly monitored in order to maintain the most efficient use of the machine.
Wheel studs should be checked that they are tight after the first 10hrs operation and again regularly every week when in use. They should be tightened to a torque setting of 450Nm.
Tyre pressures should be set to 30 PSI and regularly checked
The condition and position of the packer scrapers should also be observed in order to prevent soil building up on the packer. Ensure the scrapers are not touching the packer though, as this will add rolling resistance as well as causing premature wear of the packer.
Grease points requiring one pump every 50 hours are located on rams, wing, hinge, bushes, drawbar hinge bushes front and back, both top and bottom elements. Exposed chrome ram rods should also be greased weekly to prevent these valuable parts from rusting and causing costly oil leaks.
5.1 Spares
When ordering replacement parts please have your serial number, part numbers (listed in Section 8.0) and quantities at hand.
5.2 Winter storage
When machines are to be parked up for the winter period, correct storage techniques are an important part of protecting the machine to ensuring a hassle free season. When the machine has finished work it should be cleaned down and washed off to remove all traces of soil.
Following washing off, the packer bearings should be greased with one pump and the disc bearings should be greased until old grease is forced out. Other grease points are located on all rams, wing hinge bushes and drawbar hinge bushes, and these should receive two or three pumps of grease.
Wheel studs should be checked that they are tight. Tyre pressures should also be checked to ensure there is not a slow puncture before entering storage.
When the machine is parked up a note should be made of what wearing parts require replacing ready for
the next seasons work. The wearing parts can then be ordered in time ready for the next season’s work in
good time to avoid delays when the machine is required earlier than expected!
7.6 Stickers and paint
Sticker
Description
Quantity
Part No.
Big Sumo horizontal sticker
6
SWB125
Big Quatro sticker
6
SU013
Big Union Jack sticker
150 x 100mm
4
SWB127
Vertical Sumo sticker
80 x 295mm
2
SWB128
Small Union Jack sticker
4
SWB129
Small Sumo Horizontal
Sticker
4
SWB130
Sumo touch - up paint
Sumo Red
1/2 Litre
SWB131
Sumo Black
1/2 Litre
SWB132
